Kambrook KEF16 User Manual

Banquet Frypan

KEF16 Issue 1/03

Kambrook Safety

Welcome to Kambrook and your new Banquet Frypan. At Kambrook we believe that the safe performance of our products is the first priority in any consumer product so that you, our valued customer, can confidently use and trust our products. We ask that any electrical appliance that you use be operated in a sensible fashion with due care and attention placed on the following important operating instructions:

READ ALL INSTRUCTIONS THOROUGHLY BEFORE ACTIVATING THE APPLIANCE AND RETAIN THEM FOR FUTURE REFERENCE.

Ensure that the power source to be used is the same as the voltage requirements of the product.

Switch off at the power outlet and then unplug and remove the Temperature Control Probe when the appliance is not in use and before cleaning.

Allow all parts to cool before dissembling

for cleaning.

Never immerse the power cord, plug or temperature control probe in water or any other liquid.

Before inserting the Temperature Control Probe into the Frypan socket ensure the interior of the socket is fully dry.To do this, shake out excess water then wipe the interior of the socket with a dry cloth.

Do not touch hot surfaces, use handles or knobs

This appliance is not intended for use by young children or infirm persons without supervision.

Young children should be supervised to ensure that they do not play with the appliance.

Do not leave the appliance unattended when in use.

Always use the appliance on a dry, level surface

Do not let the cord hang over the edge of a table or counter, touch hot surfaces or become knotted.

Do not place this appliance on or near a hot gas or electric burner, or where it could touch a heated oven

This appliance is for household use only. Do not use this appliance for other than its intended use. Do not use outdoors.

Extreme caution must be taken when using this appliance filled with hot oil or other liquid. Do not move during cooking and allow to cool before removing oil or other liquid.

The installation of a residual current device (safety switch) is recommended to provide additional safety protection when using electrical appliances. It is advisable that a safety switch with a rated residual operating current not exceeding 30mA be installed in the electrical circuit supplying the appliance. See your electrician for professional advice.

Regularly inspect the power cord, plug and actual appliance for any damage. If found damaged in any way, immediately cease use of the appliance and return the entire appliance to the nearest authorised

Kambr examination, replacement or repair.

Please call 1800 800 634 for Kambrook Service Centre details.

ook Ser

vice Centr

e f

Features of your Kambrook Essentials Banquet Frypan

1. Removable Temperature Control

Probe thermostatically controlled

with 10 settings.

2. Easy-Clean Non-Stick Cooking

Surface for fat free cooking

3. Glass lid with stainless steel rim

4. Super Size – 38 x 29.5cm rectangular

frypan. Extra deep – 78mm.

5. Pan Tilt Lever allows the fat and juices to drain from the food, ideal for low fat cooking.Also makes serving gravies and sauces easier.

Adjustable steam vent.

7. Cool Touch knob.

Using Your Kambrook Essentials Banquet Frypan

Before First Use

Before first use wash, rinse and dry your frypan and lid. Season the cooking surface by applying a thin coating of cooking oil with paper towelling.

Warning: Do not immerse the power cord, plug or temperature control probe in water or any other liquid.

Ensure that the frypan socket is fully dry before inserting the temperature control probe.

Plug the cord into a 230/240 volt power outlet and then turn the power on.

Set the temperature control probe to the desired temperature setting. Refer to table below.

The temperature light on the temperature control probe will switch off automatically

when the temperature selected has been reached.The light will cycle on and off during the cooking cycle indicating that the selected temperature is being maintained.

Do not use metal utensils, as these will scratch the non-stick cooking surface.

Only use wooden or good quality plastic utensils to stir or serve food.

Do not leave plastic cooking utensils in contact with the hot frypan surface while cooking.

NOTE:This frypan must be used with the temperature control probe provided. Do not use any other probe or connector.

The Glass Lid

The Cook ’n’ Look glass lid enables you to monitor your cooking without removing the lid and loosing heat.To adjust the steam outflow from the frypan, turn the adjustable steam vent (attached to the knob).

Dial Setting Uses Temp. Guide

Min – 4

4 – 8 roast vegetables, pancakes, roasting joints, Medium/High

8 – 10 Sealing steaks and roasts, cakes, boil rice, stirfry High

Slow cooking casseroles, keeping food warm,

simmering sauces, basting, bolognaise sauce

Cooking steaks, sausages, bacon, eggs, pikelets,

crumbed food, toasted sandwiches, popcorn

Simmer/Low

Care and Cleaning

Cooking in your non-stick Banquet Frypan minimises the need for oil. As a result the food does not stick and cleaning is easier.Any discolouration that may occur will only detract from the appearance of the frypan and will not affect the cooking performance.

Before cleaning, turn Banquet Frypan control probe to the ‘0’ position, switch off at the power outlet and then unplug. Remove the Temperature Control Probe from the socket of the Frypan.

To clean the interior and exterior surface and glass lid wash in hot soapy water. Remove stubborn spots with a plastic washing pad or nylon washing brush. The Banquet Frypan is completely dishwasher safe.

Note: Metal scourers will scratch the surface and should not be used.

Warning: Do not immerse the power cord, plug or temperature control probe in water or any other liquid.

Warning:After cleaning, make sure that the frypan socket is fully dry before inserting theTemperature Control Probe.

Removing Discolouration of the Non-Stick Surface

Combine: 2 tablespoons bicarbonate of soda,1⁄4 cup household bleach, 1 cup water. Pour into the frypan, place lid on and simmer for 5 – 10 minutes. Clean in a well ventilated area and avoid breathing in the vapours.Wash as directed, and re-season the frypan before using again. In some instances this may not remove all the staining.

Cooking with Your Kambrook Banquet Frypan

Stir-Frying

Recommended temperature probe setting 9 – 10

An energy efficient and healthy way of cooking foods.The benefit of this cooking method is its speed and the flavour of the foods.The non-stick cooking surface on your Banquet Frypan also means that less oil is required for cooking.The cooking action for stir frying is a continual tossing motion to ensure the food is evenly exposed to the heat and cooks quickly and evenly in a couple of minutes.

Stir frying should be carried out using a high heat setting.

Preheat your frypan before adding any ingredients, allow the temperature light to cycle ‘on’ and ‘off’ several times.This will allow the frypan to reach an even high temperature.

Stir frying is a dry heat cooking method and is best suited to tender cuts of meat. Timing is a key factor when cooking meat, as over cooking will give a tough, dry result. Cooking times depend on the size and thickness of the cut, as the bigger the cut, the more time is needed.
