KAM Powercan Tri54w Slim Instruction Manual

18 x superb quality, tri colour ultra high power 3w LEDs

Red, green and blue flicker-free 3w LEDs
Suitable for film and production purposes

Full colour mixing via DMX or manual mixing

Built-in programs

DMX and Master/Slave modes

Four different channels modes: 9 / 3 / 4 / HSV

Sound-to-Light and stand-alone modes

Dual bracket for rigging and floor use

Compact and slim housing design

Heavy duty professional housing

Dimensions: 340 x 220 x 60mm (LxWxH)

Weight: 3Kg

MANUAL VERSION 1.0

DATE 16 - 10- 11

For the latest instruction manual updates and information on the entire Kam range visit:

www.kam.co.uk

Kam products are manufactured by: Lamba plc, Unit 1, Southfields Road, Dunstable, Bedfordshire, United Kingdom LU6 3EJ

Telephone: (+44) (0)1582 690600 • Fax: (+44) (0)1582 690400 • Email: [e-mail] • Web: www.lambaplc.com

If this product is ever no longer functional please take it to a recycling plant for environmentally friendly disposal.

Due to continuous product development, specifications and appearance are subject to change. © Copyright Lamba plc 2011. E&OE.

Powercan Tri54w Slim

Ultra high power RGB LED par can lighting

Thank you for purchasing this Kam product, we are sure that it will serve you for many years to come.

To optimise the performance of this product, please read these operating instructions carefully to familiarise
yourself with the basic operations of this unit. Please retain them for future reference.This unit has been tested at
the factory before being shipped to you.

To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture. To prevent a fire
hazard, do not expose the unit to any naked flame sources. Unplug this apparatus during lightning storms or if it is
unlikely to be used for long periods of time.

When installing the unit, please ensure you leave enough space around the unit for ventilation. Slots and openings
in the unit are provided for ventilation to ensure reliable operation of the product and to protect it from overheating.
To prevent fire hazard, the openings should never be blocked or covered.

Always handle the power cable by the plug. Never pull out the plug by pulling on the cable. Never touch the power
cable when your hands are wet as this could cause an electric shock. Do not tie a knot in the cable. The power
cable should be placed such that it is not likely to be stepped on. A damaged power cable can cause a fire or give
you an electrical shock. Checkthe power cord periodicaly, if you ever find that it is damaged, replace it before
using the unit again. Contact your retailer for a replacement.

The voltage of the available power supply differs according to country or region. Be sure that the power supply
voltage of the area where this unit is to be used meets the required written on the unit.

The lightning flash symbol inside a triangle is to alert the user to the presence high voltage within the
unit’s enclosure that may be of sufficient power to constitute a risk of electrical shock to persons.

Caution: to prevent the risk of electric shock, do not attempt to open the unit. No user-serviceable parts
inside. Refer all servicing to qualified service personnel.

The exclamation mark inside a triangle is intended to alert the user to the presence of important operating
and maintenance instructions in the literature accompanying the appliance.

Select the installation location of your unit carefully. Avoid placing it in direct sunlight or locations subject to
vibration and excessive dust. Do not use the unit where there are extremes in temperature (below 41ºF / 5ºC or
exceeding 95ºF / 35ºC).

Unpacking and safety Please unpack your new product carefully. Your new product should reach you in perfect
condition. Please check that no damage has occurred during transit. If any damage is found, do not operate your
unit. Please contact the retailer you purchased it from immediately. If there is any damage to the mains cable do
not use the device. Always disconnect the unit from the mains supply when carrying out any cleaning of the unit.

Operation

DMX Modes (Three DMX modes)

1) Press <MODE> until "PERS" is displayed then press "Enter" to confirm.

2) Use <UP> and <DOWN> to select the DMX mode" 9 CH, 3 CH, 4 CH, HSu" then press "Enter" to confirm.

DMX Addressing:

1) Press <MODE> until "AddR" is displayed then press "Enter" TWICE to confirm.

2) Use <UP> and <DOWN> to select the DMX starting address (1- 512), press Enter to confirm.

When connecting several units with a DMX controller, the units will need to have the DMX address set.

If all units are to be controlled the same way

1. Ensure each unit has the number of DMX control channels set to the same mode.

2. Set the DMX address channels to the same value on each unit.

3. All units will now be controlled at the same time.

When requiring individual control of each unit

1. Assign each unit with its own DMX start value depending on the amount of channels you need to control the unit.

2. Each unit can either use the same amount of control channels or you may choose to have more control over
different units. For example one controlled by 3 channels and another controlled by 9 channels.

3. No address channels should cross over.
Example - if the first unit is set to 3 channel mode. Set DMX start address to d1. If the next unit has 9 control
channels, set the DMX start address to d4, then a third unit will have to start 9 channels on from this, so the next
starting address would be 13 and so on.

Automatic Mode

This fixture has a built-in automatic program. To access this, please see the below instructions:

1) Press <MODE> until "P -" is displayed then press "Enter" to confirm.

2) Use <UP> and <DOWN> to select the built-in programs "P-01 ~ P-10" then press the "Enter" to confirm.

3) Use <UP> and <DOWN> to select the operating speed of the programs (Values 1-255, Slow~Fast).
Press "Enter" to confirm.

Sound-to-Light Mode (Sound Mode)

1. Press <Mode> to select Sound mode (SoUd), press <Enter> to confirm.

2. Display shows "rUn" when sound mode is activated.

3. Use the sound sensitivity control to select desired sensitivity level

Static Colour Setting

1. Remove any DMX controller from the fixture.

2. Press <Mode> to select Static Colour mode (C-).

3. Press <ENTER>.

4. Using <UP> & <DOWN>, select one of the seven preset colours (see chart below)

5. Press <ENTER> to confirm

Please see below map for the static colour setting:

Selection

Sub-Selection

Function

C -

C 01

Red

C 02

Green

C 03

Blue

C 04

Cyan

C 05

Magenta

C 06

Yellow

C 07

White

User Mode/strobe

This mode allows the user to set the intensity of R, G, B separately to get endless colour mixing from the control
board without a DMX controller

1) Press <MODE> until "U -" is displayed then press "Enter" to confirm.

2) Use <UP> and <DOWN> to select the " r / G / b" for Colours intensity or "S" for strobe, then press the "Enter" to
confirm.

3) Use <UP> and <DOWN> to set the colours intensity values " 0 ~ 255" or Strobe speed values "0~20"
(Slow~Fast), then press "Enter" to confirm.

Master/Slave Operation

This mode allows for multiple Slave units to follow a single Master unit.

1) Set the Master unit to one of the standalone operating modes: Automatic, Sound mode, User mode or Static
Colour mode.

2) Set the Slave units to the DMX starting address “d1” (see DMX addressing section).
When using a Master/Slave setup, only one unit must be set as the Master unit. All other units must be set as a
Slave and to d1.

DMX values

9 Channels Mode:

CHANNEL

VALUE

FUNCTION

1

000-255

Master DIMMER 0% ~ 100%

2

000-255

Red 0% ~ 100% (or Step Time when playing CUS. 01-10)

3

000-255

Green 0% ~ 100% (or Fade time when playing CUS. 01-10)

4

000-255

Blue 0% ~ 100%

5

000-010

No Function

011-030

RED 100% / GREEN UP / BLUE 0%

031-050

RED DOWN / GREEN 100% / BLUE 0%

051-070

RED 0% / GREEN 100% / BLUE UP

071-090

RED 0% / GREEN DOWN / BLUE 100%

091-110

RED UP / GREEN 0% / BLUE 100%

111-130

RED 100% / GREEN 0% / BLUE DOWN

131-150

RED 100% / GREEN UP / BLUE UP

151-170

RED DOWN / GREEN DOWN / BLUE 100%

171-200

RED 100% / GREEN 100% / BLUE 100%

201-205

WHITE 1: 3200K

206-210

WHITE 2: 3400K

211-215

WHITE 3 4200K

216-220

WHITE 4: 4900K

221-225

WHITE 5: 5600K

226-230

WHITE 6: 5900K

231-235

WHITE 7: 6500 K

236-240

WHITE 8: 7200K

241-245

WHITE 9: 8000K

246-250

WHITE10: 8500K

251-255

WHITE11: 10000K

6

000-009

Strobe OFF

010-255

Strobe 0 ~ 20Hz ( Slow ~ Fast)

7

000-023

No Function

024-047

Auto Program 1

048-071

Auto Program 2

072-095

Auto Program 3

096-119

Auto Program 4

120-143

Auto Program 5

144-167

Auto Program 6

168-191

Auto Program 7

192-215

Auto Program 8

216-239

Auto Program 9

240-249

Auto Program 10 (Loop of above programs)

250-255

Sound activated

8

000-255

Speed of Auto Programs (Slow ~ Fast)

9

000-250

Linear dimmer

251-255

Non-Linear dimmer

3 Channel Mode:

CHANNEL

VALUE

FUNCTION

1

000-255

Red: 0% ~ 100%

2

000-255

Green: 0% ~ 100%

3

000-255

Blue: 0% ~ 100%

4 Channel Mode:

CHANNEL

VALUE

FUNCTION

1

000-255

Master Dimmer 0% ~ 100%

2

000-255

Red: 0% ~ 100%

3

000-255

Green: 0% ~ 100%

4

000-255

Blue: 0% ~ 100%

HSV Mode:

CHANNEL

VALUE

FUNCTION

1

000-255

H: Hue (colour tone)

2

000-255

S: Saturation of Colour

3

000-255

V: Luminance

Technical specification

Power supply: 100-240V AC / 50/60 Hz
Power consumption: 60w
DMX control channels: 9 / 3 / 4 / HSV
DMX512 connection: 3-pin XLR
Number of LEDs: 18
Type of LEDs: 3w tri-colour
Beam angle: approx. 25°
Dimensions (LxWxH): 340 x 220 x 60 mm
Weight: 3Kg
Maximum ambient temperature Ta: 45° C
Maximum housing temperature TC (steady state): 50° C
Fuse: F2A / 250V
