- 20 -
Barcode
®
CENTRAL HEATING BOILER
ON SOLID FUEL
KALVIS - 6 MPP
WITH PellX BURNER
USER‘S MANUAL
LST EN 303-5 ГОСТ 9817-95
ĮST 144948958.13:2004
- 2 -
- 19 -
F-02/IN-04
To _________________________________
Guarantee servicing request
Having acquainted with fireplace‘s “Kalvis________” user‘s manual (Products No.________ ) and having installed it as
required I have following claims:
1.
I consider it a manufacturing error and I ask you to send your representatives to inspect the fireplace, determine the defects
and remove them.
If the aforementioned defects are due to wrong installation and operation of the fireplace I shall cover the arrival costs of
your representatives (_______) and the time spent for travel and on site at _____/hour for each representative including the
driver.
My address
Phone number.
Name Surname Signature
Notice: Request should be sent by a registered mail to the address specified in this passport, in case of emergency call
specified phone number.
KALVIS – 6MPP 2009.05.18
- 18 -
Boiler sold
by:
Company
Sales date:
Address
Phone
Boiler
installed by:
Company
Address
Phone
Foreman
(name, last name, signature)
In case of a
breakdown
contact
Company
Address
Phone
Manufacturer
UAB “Šiaulių tauro kalvis”
Pramonės 15,
LT-78137 Šiauliai, Lithuania
Phone: (+370 41) 540556
E-mail: prekyba@kalvis.lt
- 3 -
KALVIS – 6MPP 2009.05.18
ATTENTION !
Get acquainted with this technical certificate before installing the boiler. It
shall help you to mount and operate the boiler as efficiently as possible.
1. Basic engineering data
Central heating boiler with pellet burner „Kalvis-6MPP“ (hereinafter
referred to as the boiler) is used for heating various premises with installed
central heating system with enforced water circulation.
Boiler combusts 6-8 mm diameter saw dust pellets, or may be used as
a solid fuel (coal, fire-wood) fired boiler, when burner is removed and
protection is mounted.
Main technicla data
Table 1
Name of parameter Parameter value
Fuel fired
Saw dust pellets
(max diameter ∅
6-8 mm)
Fire wood, waste
wood, coal, saw
dust and peat
briquettes, coal
Heated area, up to m
2
200
Fuel load, dm
3
470 50
Max wood length, mm 380
Combustion duration*:
- wood fired, h.
- coal fired, h.
130
3
6
Fuel consumptio per heating season, pellets /wood m³ 7 - 8 20 - 25
Nominal output, kW 20 - 25
Efficiency, no less than: - firing wood, %
- firing coal, %
80
72
78
Water pressure in the boiler, no greater than, MPa
(kgf/cm²)
0,15 (1,5)
Water volume in the boiler, l 86
Water temperature control range, °C 55 – 90 70-90
Minimum recommended water temperature in the boiler
during operation, °C
65
Recommended water tmeperature during operation, ºC 70-90
Minimum chimney draught, Pa 15 25
Smoke outlet dimensions, mm Ø198
Loading dimensions, mm 270 x 400
Voltage, V 230
Electric capacity (motor + fan), W 90 + 57
Electric protection grade IP 40
Loading hole diemnsions: H×B, mm 270 x 400
Overall dimensions, not greater than:
height x dempth x lenght, mm
1390 x 950 x 2260
Mass, not gretaer than, kg 365
* Combustion duration depends on fuel type and quality, humidity, external conditions
and other factors.
Firing wood with moisture content of over 30% is not recommended.
