Kalfire G85/44C, G60/48F, G65/44C, G70/44S, G90/44S User Instructions

User
instructions

BALANCED-FLUE GAS FIRES

DON’T COMPROMISE.

EN

Balanced-flue gas fires Kalfire G

G60/48F, G65/44C, G70/44S
G80/48F, G85/44C, G90/44S
G100/41F, G105/37C, G110/37S
G120/41F, G125/37C, G130/37S
G160/41F, G165/37C, G170/37S

for gas type: G20, G25 and G30

Balanced-flue gas fires Kalfire GP

GP60/59F, GP65/55C, GP70/55S
GP60/79F, GP65/75C, GP70/75S
GP75/59F, GP80/55C, GP85/55S
GP80/54T, GP85/50R
GP105/59F, GP110/55C, GP115/55S

for gas type: G20, G25 and G30

and
GP105/79F, GP110/75C, GP115/75S

for gas type: G20 and G25

Version 01-2019

5

4.12 Setting the Natural
Spark Generator 21

4.13 Fill the Natural
Spark Generator 21

4.14 Configure the iMatch app 21

4.15 iMatch app settings 22

4.16 Resetting the iMatch
interface 22

4.17 Using the iMatch app
through the iMatch interface 23

5. Maintenance 24

5.1 Maintenance 24

5.1.1 Cleaning the (standard)
ceramic windows. 24

5.1.2 Cleaning instructions
anti-reflective glass 24

5.1.3 Door dismantling and assembly
(corner and three-sided
appliances) 26

5.1.4 Door dismantling and assembly
(front and tunnel fireplaces) 27

5.2 Malfunctions 28

5.2.1 Removing or resetting
a malfunction. 28

5.2.2 Error codes iMatch
remote control 29

5.2.3 Error code iMatch interface 33

5.3 Malfunctions Natural
Spark Generator 33

A. Appendices 34

A.1 Product card 35
A.2 Wiring diagram 36
A.3 Certificate of compliance 37

Contents

1. General information 7

1.1 Foreword 7

1.2 Pictograms 8

1.3 Warranty 8

1.4 Compatibility iMatch interface 9

2. Safety 11

2.1 Safety instructions for
decorative elements 11

2.2 Safety related to use 11

2.3 Three safety measures
for the gas fire 12

3. Description 14

3.1 Gas fire description 14

4. Operation 16

4.1 Replacing the batteries 16

4.2 Using the iMatch
remote control 16

4.3 Setting day and time 17

4.4 Checking transmission
strength 17

4.5 Switching the appliance
on and o 18

4.6 Setting the flame intensity 18

4.7 Selecting the thermostat or
manual operating programme 18

4.8 Setting the flame intensity
by thermostat 19

4.9 Programming time segments 19

4.10 Programme choice for
the hybrid LED lighting 20

4.11 Activating/deactivating the
hybrid LED lighting and
adjusting the lighting intensity 20

6

7

The gas fire and accompanying remote
control may only be used in accordance
with the reason it was designed and
after review of the Installation Manual
and user instructions.

Modifications of whatever nature can
also affect the safety of the gas fire.
Alterations can nullify the warranty and
the periodic inspection of the gas fire
will come to lapse.

If the gas fire is not installed correctly,
all warranty and/or damage claims
against Kalfire will be declared null and
void.

This gas fire has been tested and
approved according to CE standard
EN-613. Every gas fire that leaves the
factory has been tested for technical
and functional adherence to relevant
quality standards in force.

This user instruction is available in va­rious languages on www.kalfire.com,
or through your installation bureau.
All translated instructions have been
translated from a Dutch instruction,
which is the original document.

Disclaimer

All rights reserved. No part of this
manual may be copied, distributed or
translated into other languages, in full
or in part, without the prior written per­mission of Kalfire. Kalfire reserves the
right to make changes to the manual.
Kalfire, however, cannot provide any
warranty, implicitly or explicitly, for this

1. General information

The following sections provide general
information about the gas fire:

- Foreword

- Pictograms

- Warranty

- iMatch interface compatibility

1.1 Foreword

About this manual

This user instruction has been written
for the users of the gas fire. A seperate
Installation Manual accompanies this
User Instructions. The user instructions
should remain in the vicinity of the gas
fire so that they are readily available for
fireplace users.

The gas fire may only be installed by
qualified technicians complying with all
relevant national or local regulations.
The current technology status, the
provisions of the Building & Housing
Inspectorate and the national and Eu­ropean regulations should be taken into
account with regard to the installation
work and the operation of the gas fire
once fully connected.

Maintenance and repair work may only
be carried out by authorised technical
fitters.

Effective use

This gas fire has been designed as am­biance heating and has not been desig­ned to be used as the principal heating
unit for part of a house or throughout
the house.

8

Warranty conditions

1. The warranty period for Kalfire gas

appliances amounts to two years
from the procurement date, that
must be clearly legible on the proof
of purchase.

2. The two-year warranty period
does not apply to discouloration of
the paint on the flat or design rear or
side interior, as a one-year warranty
period applies in such cases.

3. The gas fire must be installed by a

technical fitter approved by Kalfire
according to the accompanying In­stallation Manual and in compliance
with all relevant national and regional
standards in force.

4. Kalfire assumes no responsibility

for errors or defects related to the
installation of the gas fire. Placing
of the appliance, the quality and
material choice of the finished pro­duct and a check as to the correct
operation of the concentric flue duct
system are the responsibility of the
technical fitter approved by Kalfire.

5. The warranty covers no right what-

soever to compensation in the event
that the appliance cannot be used.

6. Glass, tubing and rubbers as well as

physical and chemical external in­fluences during transport, storage or
installation fall outside the scope of
the warranty.

7. Should disruption occur within the

warranty period caused by a manu­facturing error or material defect,
Kalfire will deliver the components
needed for repair to the technical
fitter of the gas fire, without paying
compensation for dismantling or as-

manual. Any risk is fully for the account
of the user.

Copyright @ 2018 Kalfire B.V.
Geloërveldweg 21, Belfeld,
The Netherlands

1.2 Pictograms

The following pictograms are used in
this manual;

IMPORTANT Warning for flamma-

ble material. Mitigate the risk of
an explosion by carrying out these
instructions carefully in the vicinity
of explosive materials.

DANGER! Warning for flammable

material. Follow instructions to
ensure that the possibility of fire
thanks to the sudden ignition of
flammable materials is prevented.

WARNING General warning. Miti-

gate the risk of injury by carrying
out the instructions carefully.

CAREFUL! General warning. Miti-

gate the risk of material damage by
following the instructions diligently.

1.3 Warranty

Kalfire products are manufactured with
meticulous precision from premium
materials. Despite this, should an error
or defect become apparent, Kalfire will
provide warranty coverage according to
the following provisions.

9

to the user instructions.

5. Should deviation from the Kalfire

specifications have occurred in any
way or form during installation of the
concentric flue duct system.

6. Should deviation from the Kalfire

specifications have occurred in any
way or form during configuration of
the decorative elements, including
possible ceramic wood logs on the
burner bed.

7. Damage attributable to external

causes (shocks, lightning, falling,
flooding or overheating of the appli­ance) during transport, storage or
installation.

8. Should the appliance be impacted

by neglect, improper use and/or
gross negligence.

9. If the repair or delivery of individual

parts be carried out by another
manufacturer or by a professional
technical fitter who has not been ap­proved by Kalfire.

1.4 Compatibility iMatch interface

The iMatch interface enables the ap­pliance to be operated by an external
application such as a tablet or smart­phone. The iMatch interface ensures
that connection is made between the
local Wi-Fi network and the appliance.
In some cases it can happen that the
interface does not function adequate­ly. This can be caused by insufficient
coverage (signal) by the Wi-Fi network
or because the appliances connected
to one another (including telephone,
tablet or router) are incompatible.

The iMatch interface and your external

sembly.

8. Renewing or replacing components

that fall under the scope of the gua­rantee do not extend the duration of
the warranty.

9. Should the technical fitter approved

by Kalfire be unable to rectify the
problem covered by the warranty,
then he is entitled upon his own
express desire to request Kalfire to
assume responsibility for doing so
(only valid in the Benelux, Germany
and France).

10. Verification or repair of an entire gas

fire or parts thereof can only take
place by appointment, after prior
consultation between Kalfire and the
technical fitter approved by Kalfire.

11. A dated proof of purchase must

be presented to Kalfire should a
possible home repair service (only
available in the Benelux, Germany
and France) be carried out within
the warranty period.

12. In the event of home repair service

outside the warranty period, materi­al costs, working hours and call-out
charges will apply.

The warranty is not applicable in the
following circumstances:

1. If the warranty provisions have not

been complied with, in part or in full.

2. If alterations to the appliance have

been brought about without Kalfire’s
written permission to do so.

3. If the appliance passes into new

ownership.

4. If the appliance has not been fitted

according to the Installation Manual
and/or has not been used according

10

appliance must be connected to the
same router (through the same net­work). The Wi-Fi signal can be checked
in advance and can be improved if
required. With regard to the huge
diversity of appliances, their compati­bility can regrettably not be confirmed
beforehand. Only after installation
of the interface can compatibility be
confirmed. Kalfire accepts no liability
for the non-functioning, or insufficient
functioning, of the iMatch interface as
a consequence of the cause described
above.

11

CAREFUL! During operation of

the appliance, small hairline cracks
may develop in the ceramic logs.
These have no negative impact on
the operation or flame profile of
the appliance. Hairline cracks do
not fall under the warranty.

CAREFUL! When heated, the gas

fires’s internal metal lining can
expand. This can cause the layer of
paint on the metal to deform, re­sulting in damage or imperfections.
The spray paint supplied with the
gas fire allows any paint damage to
be fixed.

2.2 Safety related to use

There are risks attached to using a gas
fire. The temperature of all visible parts
of the gas fire can rise steeply and the­re is a risk of fire or combustion. Be sure
that the following safety precautions
have been taken:

WARNING: The gas fire needs a

permanent power supply. When
interrupting the power supply,
previously stored errors are dele­ted. Interrupting the power supply
regularly affects the safety provisi­ons, which can result in dangerous
situations.

Fire hazard
WARNING Make sure that flam-

mable materials such as curtains

and furniture are at least 100 cm
from the fireplace. If a fireguard is
used, this distance must be at least
40 cm.

2. Safety

The following sections provide safety
information about the gas fire:

- Safety regulations for decorative

elements

- Safety related to use

- Three safety measures for the gas fire

2.1 Safety instructions for

decorative elements

FIRE HAZARD! The decorative

elements must be placed according
to the instructions. It is prohibited
to alter the number of decorative
elements or the configuration
thereof. Such alterations can lead
to hazardous situations in terms of
fire safety.

WARNING The ignition or ionisa-

tion rods must be left uncovered.
Ensure this is the case when
placing the decorative elements.
Careless decoration of the gas fire
can cause incorrect ignition, an
error code (08A or 08F) or a hazar­dous situation.

WARNING If the fireplace is de-

livered with the Natural Spark
Generator, the adhesive tape with
which the iron filter cap has been
secured should be removed during
installation. During installation of
the fireplace components, the filter
cap is covered with a ceramic wood
log or a piece of ceramic charcoal
(depending on the Kalfire GP mo­del).

12

If you notice fumes or gas, take the fol­lowing precautions:

1. Switch off the gas fire.

2. Close the main gas valve.

3. Open windows and doors.

4. Advise an approved installer of the

issue.

DANGER OF EXPLOSION! Should

damage occur, close the gas valve.
Do not use the gas fire if a glass
panel is cracked, is not in place or
incorrectly mounted.

The gas fire needs a permanent power
supply. Interrupting the power supply
can impact safety precautions.

The risk of discolouration
CAREFUL! After the convection

system of the fireplace has been
heated, air particles, cigarette
smoke, candles and oil lamps can
cause discolouration of walls and
ceilings. Ensure sufficient ventilati­on in the room in which the gas fire
is installed.

2.3 Three safety measures for the
gas fire

1. The flame is detected due to elec-

tronic ionisation measurement

Should the gas fire be unable to de-

tect a flame during ignition, the gas
supply will be interrupted for one
minute. A new ignition attempt will
follow automatically. To interrupt au­tomatic ignition attempts: Press the

button to switch off the fireplace
directly and depress this button for
approximately 10 seconds.

Fig. 1: Safe zone

WARNING Should the floor in front

of the fireplace consist of com­bustible material and the distance
from the underside of the combus­tion chamber to the floor be smaller
than 10 cm, a heat-resistant fire­guard floor plate larger than 30 cm
or a stone should be placed.

Danger of combustion
FIRE HAZARD! Do not touch the

appliance! The gas fire is hot when
switched on or just switched off.
Ensure extra safety precauti­ons and safety measures if less
able-bodied persons, elderly peo­ple and/or children have access
to the fireplace. Only the remote
control and the technical unit can
be used without fear of danger due
to combustion.

Danger caused by fumes or gas leaks
DANGER OF EXPLOSION!

Fumes and/or gas leaks can cau­se life-threatening situations.
Fumes can be the cause of carbon
monoxide poisoning and gas leaks
are an explosion risk.

30 cm

40 cm

100 cm

20°

20°

13

2. 24 hour security

The appliance will stay in a blocked

position if no flame is detected after
three automatic ignition attempts
(error code 08A). The block will take
effect after one ignition attempt with
gas type G30. This block can twice be
unlocked manually with the remote
control. If no flame is detected after
two manual releases, the appliance
will remain blocked for 24 hours (a
‘lock-out’, code 08F). In that case,
you may not use the gas fire for
24 hours.

3. Overpressure protection

The gas fire is equipped with over-

pressure protection to minimise risk.
Should explosive ignition occur, the
glass panel on the front topside will
open to reduce the pressure.

14

also be switched on separately without
engaging the Prestige burner.

The Kalfire G with a 3D burner ge­nerates an elongated and horizontal
flame pattern, well suited to a modern
household interior. The 3D burner offers
a particularly attractive and true-to-life
flame pattern. Kalfire G gas fires are
delivered with a standard or optional
luxury ceramic log set, white stones,
grey pebbles or cryptonite.

Smooth transition between gas fire
and surround

The balanced-flue gas fires are easy to
align with the household interior during
installation. The gas fire stone, often
made from natural stone, can continue
along the outer edge of the gas fire with
the help of stone supports. The side
walls can be fluidly finished in the sur­round of the gas fire. The back wall can
be extended to outside the gas fire, me­aning the metal lining remains invisible.

Operation

The balanced-flue gas fire can be ope­rated with the iMatch remote control
as standard. This enables the gas fire
to be switched on or off and the height
of the flames can be adjusted. A choice
can be made from eight modes as well
as an ECO-line. The ECO-line automati­cally generates a varied and alternating
flame pattern. This reduces gas use
considerably.

If the house is equipped with a home
automation system, then operation
of the appliance can be integrated

3. Description

The following sections describe the
gas fire:

- Description of the gas fire.

3.1 Gas fire description

Kalfire gas fires are internationally
renowned for their realistic, enchanting
flames. Kalfire appliances are easy to
operate and maintain. Kalfire balan­ced-flue gas fires are equipped with
an innovative Prestige or 3D burner,
enhancing their environmental friend­liness, sustainability and economy.

Balanced-flue gas fires

The patented Prestige burner radiates
a realistic impression of wood fire. The
Prestige burners are integrated in the
ceramic log sets stacked in the appli­ance in pyramid form. This creates the
impression of a high and voluminous
flame pattern.

The Kalfire GP can be delivered with
the Natural Spark Generator (optional).
This ensures that sparks emanate from
the burning flames in a natural manner,
and continue to burn slowly. This spark
generator option is mounted inside the
gas fire during manufacture by Kalfire
and cannot be added at a later stage.

The Kalfire GP can also be delivered
with an optional hybrid function. The
gas fire’s fuel bed is equipped with LED
lighting that simulates a bed of natu­ral embers. The lighting generates an
atmospheric imitation of the glow of a
real wood fire. The hybrid function can

15

into that system. The gas fire can also
be controlled by the iMatch App on a
smartphone or tablet. This is only pos­sible if the gas fire is equipped with the
optional iMatch interface, that serves
as the receiver.

16

3. Place the two batteries on the com-

partment floor as indicated.

4. Close the compartment cover.

5. Press the

centre button and the

display will light up.

4.2 Using the iMatch remote
control

Range of the RF signal

The iMatch remote control uses a ra­dio-frequency (RF) signal to transfer
information to the gas fire. The RF
signal is a safe signal for wireless com­munication. The signal has a range of
approximately 10 metres as long as
there are no obstacles between the
remote control and the gas fire. Obsta­cles such as walls and/or furniture can
negatively impact range. In some cases,
it can happen that the gas fire takes
longer to react. If the screen of the re­mote control illuminates after a button
is pressed, this indicates that the RF
signal has been sent.

Key of symbols:

1. Indicates the time and status when

switching the appliance on or off:

•

OK - the fireplace is switched on.

•

WARM - the ignition programme

has been activated.

•

WAIT - the ignition programme is

starting up.

2. Day of the week in numbers

(1-7, Monday is 1).

a. (glow lamp) Indicator for the LED

lighting.

3. RF-signal, a flashing icon indicating

that the appliance is beyond the re­ach of the remote control.

4. flame intensity indicator (hybrid fire)

4. Operation

The upcoming sections provide infor­mation about the use of the gas fire:

- Replacing the batteries

- Using the iMatch remote control

- Setting the day and time

- Confirming the transmission
strength

- Switching the gas fire on and off

- Adjusting the flame intensity

- Selecting the thermostat or manual
operating programme

- Regulate the flame intensity by ther­mostat

- Programming time segments

- Programme choice for the hybrid
LED lighting

- Activate/deactivate the hybrid LED
lighting and adjust

- Set the Natural Spark Generator

- Filling the Natural Spark Generator

- Configuring the iMatch app

- iMatch app settings

- Resetting the iMatch interface

- the iMatch app through the iMatch
interface

4.1 Replacing the batteries

Insert or replace the remote control AA
batteries.

A battery compartment is located at
the rear of the remote control. This can
hold two AA batteries. If the batteries
are almost flat, the battery icon beco­mes visible or all symbols on the display
start to flash. Follow the steps below to
replace the batteries:

1. Slide the compartment cover down.

2. Remove the batteries (if in place).

17

Buttons:
a. + and - buttons
b. Left button

and right
c. Centre button
d. On/off button
e. Parameter configuration button P

4.3 Setting day and time

Setting day and time.

Carry out the following steps to change
the day and time settings:

1. Hold down the P button until the

time display starts flashing.

2. Change the hour with the +or-

button and confirm the change by

pressing the centre button.

The minutes will then begin to flash.

3. Change the minutes with the + or -

button and confirm the change by

pressing the centre button. The
number indicating the day of the
week will then begin to flash
(1 = Monday).

4. Change the day with the +or-button

and confirm the change by pressing
the centre button.

5. To exit the parameters menu, press P.

6. Wait for 30 seconds while the infor-

mation is transmitted.

4.4 Checking transmission strength

Carry out the following steps in order
to modulate transmission strength bet­ween gas fire and the remote control.

1. Press P until the transmission

strength flashes at the top left of the
display.

2. Press the right button until RFCK

appears in the display.

5. The flame is ignited if the icon is

alight, if this icon is flashing one of
the following notifications requires
your attention: heat adequacy, igni­tion attempt or reignition attempt.

6. The ECO mode is activated.

7. Batteries are flat.

8. Room temperature and other

notifications such as disruptions.

9. Warning signals related to

disruptions.

10. Time segments

11. Thermostat mode.

12. Manual programme (default mode).

1 2

3

4
5

6

7

8

10

9

11

12

e.

d.

c.

b.

a.

18

flame intensity can also be displayed by
the flame intensity indicator.
The ECO mode has a modulating effect
on flame intensity (higher or lower).
This accentuates the visual effect
and user comfort of the flames, while
reducing the fire’s heat emission and
gas consumption by approximately
40%. Use the remote control to set the
flame intensity in “ECO mode” to 9,
after which the double flame icon

will
display on the screen. Adjust the flame
intensity as follows:

1. Press +or -to adjust flame intensity.

2. Release the + or - button.

3. Press the + button until the number 9

appears to switch on the ECO mode.

4.7 Selecting the thermostat or

manual operating programme

The flame intensity and the resulting
room temperature can be adjusted by
setting the remote control in manual or
thermostat mode. To ensure an accura­te temperature reading, make sure the
remote control is outside of the fire’s
radiation range. For security reasons,
the thermostat mode will be automati­cally switched off after 24 hours. If the
flames in the gas fire have been swit­ched off, the programme will restart in
manual mode automatically when next
switched on.

1. By pressing P until the icon for

thermostat

or manual mode

begin to flash.

2. Press P again to selec the icon of

your choice.

3. Briefly press

to exit the menu.

3. Walk around the appliance at a dis-

tance of 3 to 4 metres to measure
the RFCK. If the RFCK shows a value
of 4, the transmission strength of the
remote control is good. If the value
shows as 2 or 3, the RFCK values are
acceptable. Transmission strength is
insufficient at a RFCK value of 1.

4. Confirm with

to exit the menu.

4.5 Switching the appliance on and o

Carry out the following steps to turn
the appliance on or off:

1. Press

until the >OK< icon in the

display appears and starts to flash.

2. Continue to press

and then press

briefly on

to activate the ignition

programme.

3. Release both buttons.
The word >WARM< will flash at the

top left of the display as confirmati­on of activation.

4. Wait a number of seconds until you

hear a beep and the word >WAIT<
appears. The ignition programme will
start and the burner will automati­cally ignite after approximately
20 seconds.

5. Wait until you hear a second beep.
The word >WAIT< will stop flashing

after the ignition programme.

6. The gas fire flame is alight and ope-

rational.

7. Press for approximately two seconds

to extinguish the gas fire flame.

4.6 Setting the flame intensity

The height of the flames can be adjus­ted from high to low and is indicated on
the display by numbers 1 through 8. The

19

“TCOM” (temperature comfort).
TCOM indicates the maximum
temperature during all set time
segments.

5. Set the desired temperature with the

+ or - buttons at increments of 0.5°C.

6. Confirm by pressing the

(centre

button).

7. “TECO” (temperature ECO) will now

appear in the display. TECO is the
minimum temperature between the
time segments. This minimum tem­perature will be maintained all day
with the exception of the set time

segments.

8. Set the desired temperature with the

+ or - buttons at increments of 0.5°C.

9. Confirm by pressing the

(centre

button).

10. Press the right button

, so that a
flashing time in hours and minutes
appears in the top left-hand corner,
while “ON 1” appears in the middle
of the display (this is the first “on”
time).

11. Use the + and - buttons to set the

first “on” time at increments of
15 minutes.

12. Confirm by pressing the centre but-

ton

if you are happy with

the time.

13. “OFF 1” will then appear (this is the first

“Out” time).

14. Use the + and - buttons to set the

first “out” time, at increments of
15 minutes.

15. Confirm by pressing the

button.

16. Programme the other times in the

three segments in this way; should
you not require all time segments,
these other segments should be set

4.8 Setting the flame intensity by
thermostat

The remote control measures the
temperature and the flame intensity is
modulated accordingly. To ensure an
accurate temperature reading, make
sure the remote control is outside of
the fire’s radiation range.

1. Select the thermostat programme

as indicated in paragraph Selecting
the thermostat or manual operating
programme on page 18.

2. Press the button with the +or with

the -so that the temperature indica­tor on the display starts to flash.

3. Set the desired temperature with the

+ and - buttons.

4. Wait for 10 seconds before using the

remote control to save the set tem­perature.

4.9 Programming time segments

The thermostat function can be com­bined with a timer programme that
allows for up to three time segments to
be programmed. These are indicated by
switch-on times ON 1, 2, 3 and switch­off times OFF 1, 2, 3. The set program­me will run daily.

1. Check if the hand transmitter is set

at the right time (if you are not hap­py with the time, see: 4.3 Day and
night settings)

2. Press the P button (hold down brie-

fly).

3. Let go of Button P when the time

starts to flash in the top left-hand
corner of the display.

4. Press the right button

to display

20

desired “P” programme is displayed.

3. Wait until the home screen appears.

4.11 Activating/deactivating
the hybrid LED lighting and
adjusting the lighting intensity

If the gas fire is equipped with hybrid
LED lighting, it will be automatically ac­tivated as soon as the fire is turned on.
The number of horizontal bars at the
bottom of the screen indicate the level
of brightness of the LED lights. LED
lighting can also be activated when the
fire is not on. Carry out the following
steps to activate only the LED lighting:

1. Press

to turn on the screen.

2. Press the right button until “P1, P2

or P3” appears in the centre of the
screen.

3. Press

to activate the LED ighting

or increase its intensity.

4. Press

to deactivate the LED

at identical switch-on times.

17. Press P to exit the programme.

18. The

and icons on the remote
control indicate that the time seg­ments have been programmed.

4.10 Programme choice for the
hybrid LED lighting

If the gas fire is equipped with a hybrid
LED lighting function, it is possible to
vary the lighting effects. The different
parameters controlling the LED lighting
allow the oscillation, intensity and co­lour to be set. In every programme, se­lection of the word “AUTO” provides the
highest and clearest lighting intensity.

Carry out the following steps to adjust
the LED lighting programme:

1. Press the right button

until a “P1,
P2 or P3” appears in the middle of
the display.

2. Press

a number of times until the

Table: LED programme

Programme Reacts to Light clear variation

P1

Setting AUTO and Modulating
between high and low

10% to 90%, fading reddish LED
colour.

P2

Setting AUTO and Modulating
between high and low

10% to 90%, yellowish and reddish
LED colour, alternately on the
left and right-hand sides of the
appliance.

P3

Setting AUTO and Modulating
between high and low

Combination between Programme
P1 en P2

21

4.13 Fill the Natural Spark
Generator

The Natural Spark Generator system
contains a cartridge of powder (Natural
Spark Powder) on delivery. Use the
instruction delivered with bthe new
powder for refilling the Natural Spark
Generator.

4.14 Configure the iMatch app

First connect your iMatch-interface to
the local network, before the iMatch is
configured.

1. Download de iMatch app uit de App

store (Apple) of Play store (Android).

2. Open the Wi-Fi settings on your

phone or tablet.

3. Select the Wi-Fi network named

“Kalfire”.

4. Open the iMatch app.

5. Click on “Settings” in the top right

corner of the screen as depicted in

the figure.

Fig. 3: Configure the iMatch app

lighting or decrease its intensity.

4.12 Setting the Natural Spark
Generator

If the gas fire is equipped with a Natural
Spark Generator, lifelike sparks will be
produced when it is alight. The higher
the flames, the more sparks there are.
The gas fire must be alight for some
time before the Natural Spark Genera­tor can produce sparks. This is why the
appliance only activates the Natural
Spark Generator after it has been ope­rating for 10 minutes. The user can set
a time interval with the remote control.
The last Natural Spark Generator pro­gramme selected is saved when the gas
fire is turned off. Carry out the following
steps to set the time interval:

1. Press the forward right button

to
access the Natural Spark Generator
programme.

2. At the top of the screen, the word

“SP0” (or another previously-set
value) will appear in the display.

3. Press the + or - buttons to chan-

ge the Natural Spark Generator
programme. (SP0 t/m SP8).

4. Briefly press

to exit the menu.

Settings:

SP0 = Natural Spark Generator is

switched off; no sparks
SP1 = 1 spray of sparks per hour.
SP2 = 2 sprays of sparks per hour.
SP3 = 3 sprays of sparks per hour.
SP4 = 4 sprays of sparks per hour.
SP5 = 5 sprays of sparks per hour.
SP6 = 6 sprays of sparks per hour.
SP7 = 10 sprays of sparks per hour.
SP8 = random sprays of sparks, one

per minute

22

will now see an overview of already
connected appliances and you
have the possibility to add another
fireplace. Change the name of the
room(s) present. Select the room
you want to change. In the screen
that appears next you are able to
change the name.

3. Wizard: click on Wizard and follow

the instruction to install an additional
fireplace.

4.16 Resetting the iMatch interface

1. Press the reset button of the iMatch

interface; this can be found on the
rear side of the iMatch interface.

2. Hold the button down until the red

LED start flashing rapidly (approxi­mately 15 seconds).

3. Wait for the iMatch interface to

reboot.

4. Check whether the red LED is on.

Fig. 4: iMatch interface

6. Click on “Wizzard” and follow the

instructions on the screen.

7. Click on the colour corresponding

with the LED on the searched
iMatch interface.

8. Click on the grey area to assign a

name (“living room” for example).

9. Provide your local Wi-Fi network’s

name and password. Careful, name
and password are case sensitive.

10. The iMatch interface must be reset,

if the name or password do not cor­respond. See: Resetting the iMatch
interface on page 22

.

11. Check the box in case the gas fire is

a hybrid (you can check this on the
model figure).

12. Wait 40 seconds while the wizzard is

shutting down and the Kalfire
logo becomes visible.

13. Reconnect with your Wi-Fi network

(in most cases happens automati­cally).

14. Control the fireplace with the iMatch

app when the green LED lights up on
your iMatch interface.

15. Repeat step 5 to 14 for a maximum of

four fireplaces, if you want to control
multiple fireplaces with the iMatch
app.

4.15 iMatch app settings

In the iMatch app settings menu you
can select the following:

1. Language : Click on language and

select the desired language. U will
automatically return to the settings
screen

2. Appliances : Click on Appliances. You

23

not adjustable.

4. Heating mode: Press “hand control-

led” once in the middle of the circle.
Now select the heating mode Eco or

Manual.

Fig. 6: Heating mode

5. In case you choose Eco mode, the

fireplace is not controllable from the
App. The fireplace varies from mode
1 to 8 automatically.

6. Shutting down: The gas fire will

shut down, by pressing the stand­by button again. The NSG is not
controllable by using iMatch.

7. CAREFUL! The NSG cannot be

operated by the iMatch.

4.17 Using the iMatch app through

the iMatch interface

The gas fire can be controlled by using
the iMatch app, if the iMatch inter­face is connected to your local Wi-Fi
network. First install the iMatch app
on your smartphone or tablet. See:
Configure the iMatch app on page 21.

Accessing home screen

1. Click on the iMatch app icon to open it.

2. Drag the standby icon to the right to

open the home screen.

Overview home screen

1. Initiating flame: Press the standby.

A semi-circle will appear and the
fireplace will start at 100% flame

intensity.

Fig. 5: Initiating flame

2. Setting the flame intensity: Press

and hold down the black dot. Move
your finger over the circle to set the
flame intensity. The percentage will
increase and decrease with the mo­vement of your finger.

3. Hybrid LED lighting: Press “off” to

turn on the LED lighting. The LED
lighting turns on and a semi-circle
with the text Hybrid appears on the
screen. The LED lighting intensity is

24

5. Maintenance

The following sections provide informa­tion about the maintenance
of the fireplace.

- Maintenance

- Malfuntions

- Malfunction of the Natural Spark

Generator

5.1 Maintenance

Maintenance frequency

The gas fire should be inspected for
optimal, sustainable and safe use annu­ally. Malfunctions to the gas fire must
be fixed instantly. Inform your client
about the possibilities of a maintenance
contract.

Before and after the heating season

As time passes, tarnish can form on the
inside of the class. This can be removed
by using a moist cloth or non-scrat­ching cleaning detergent (ceramic glass
cleaner). Do not use corrosive or abrasi­ve substances for cleaning the fireplace.
Damage to varnish is not included in the
warranty. Small damaged can be re­moved by using heat-resistant varnish.
This varnish is available at Kalfire.

5.1.1 Cleaning the (standard)

ceramic windows.

WARNING Different cleaning in-

structions apply for anti-reflective
glass.

The gas fire glass can become contami­nated when the fireplace is burning, but
also when it is not. Potential causes can
be: Smoking materials in the fireplace

(especially in the beginning), air conta­mination, quality of the type of gas etc.

Conditions:

•

Filth and stains on the glass must be

removed immediately.

•

Never turn on the fireplace when it

has filth or stains on the glass. This
can lead to permanent contaminati­on.

•

Clean the glass after the first use

of the fireplace and clean the glass
regularly in the initial period.

•

Use scratch-free cleaning

substances only.

5.1.2 Cleaning instructions anti­reflective glass

The gas fire glass can become contami­nated when the fireplace is burning, but
also when it is not. Potential causes can
be: Smoking materials in the fireplace
(especially in the beginning), air conta­mination, quality of the type of gas etc.

Anti-reflective glass is polished ceramic
glass to which a number of metal oxide
coatings have been applied that reduce
the reflection to less than 1%.
To prevent damage to these coatings, it
is important that you carefully comply
to the following cleaning instructions. A
blue/purple discolouration can become
visible on the anti-reflective glass, as a
result of using the gas fire.

Conditions:

•

Filth or stains on the glass must be

removed immediately.

•

Never turn on the fireplace when it

has filth or stains on

25

the glass. This can lead to permanent
contamination.

•

Clean the glass after the first use of

the fireplace and clean the glass re­gularly in the initial period.

•

Wear (rubber) gloves when cleaning

the glass; fingerprints are particular­ly noticeable on anti-reflective glass.

•

Use water and a soft cotton cloth,

chamois leather
or a microfibre cloth.

•

Use neutral glass detergent only:

water solution with neutral or light
alkaline detergent without additives
or abrasive substances. The accep­table share of ammonia and solvents
that are organically soluble in water
must be smaller than 5%.

•

Carefully clean the glass: use suffi-

cient moisture, avoid pressure and
rub the substance from top to bot­tom, to prevent cleaning detergent
to remain on the glass.

•

Continuously dry the glass comple-

tely using the cloth.

•

When using a vacuum lifter to remo-

ve the door, the suction cup rubber
must be clean in order to prevent
damage to the coating.

The table below lists the types of pro­ducts never to be used when cleaning
the anti-reflective glass:

Never use the products below!: The glass coating can be damaged by:

toilet cleaners

alkaline detergents or detergents with high
levels of ammonia

hydrochloric acid acids

bleach domestos chlorine or sodium hypochlorite detergents

benzene, hexane or petroleum-based
solvents

solvents

scouring powders, abrasive materials,
steel wool, scrubbing or scouring pads,
scrapers, razor blades, paper, ceramic
stove cleaners

Aggressive cleaning materials

26

Step 3: Next, grip the door by the de­signated handles. Slightly lift the door
with glass window out of the rabbet,
move the entire door slightly to the left
or right (corner fireplace) and carefully
lift it entirely out of the fireplace. In a
three-sided appliance the door will fall
forward slightly and you will be able to
lift it straight out of the rabbet.

Fig. 9: Restoring door

Restoring door

To put the door back in place, follow
the steps explained in step 3 in reverse
order. Lock the door by moving the
handles down. Twist the metal cover
strips (step 1) back into its original
position by using the protruding lip at
the upper side of the strip.

5.1.3 Door dismantling and assembly
(corner and three-sided
appliances)

Door removal
WARNING: Wear (rubber) gloves to

prevent stains on the glass.

Step 1: To unlock the door, pull the
handles that are placed under the hood
towards you and up.

Fig. 7: Pull the handles

Step 2: Push the metal cover strip in left

or right.

Fig. 8: Metal cover strip

27

Step 3: Push the metal cover strip in left
or right.

Fig. 12: Push the metal cover strip

Step 4: Next, grip the door by the de-

signated handles. Slightly lift the door
with glass window out of the rabbet and
carefully remove it from the fireplace.

Fig. 13: Grip the door

Restoring door

To put the door back in place, follow
the steps explained in step 4 in reverse
order. Lock the door by moving the
handles down. Twist the metal cover
strips (step 3) back in its original posi­tion, by using the overlapping edge on
the upper side of the strip and fold the
metal cover strip down.

5.1.4 Door dismantling and

assembly (front and tunnel
fireplaces)

Door removal
WARNING: Wear (rubber) gloves to

prevent stains on the glass.

Step 1: Move the metal cover strips up
from the upper side.

Fig. 10: Move the metal cover strips up

Step 2: To unlock the door, pull the

handles that are placed under the hood
towards you and up.

Fig. 11: Pull the handles of the hood

28

5.2.1 Removing or resetting a
malfunction.

The automatic burner relay is equip­ped with a safety setting per gas type
for the automatic ignition attempts.
Natural gas (G20, G25) has three auto­matic ignition attempts and propane or
butane gas (G30) only has one ignition
attempt to ignite the burner. Should
the automatic ignition attempt(s) fail,
error code 08A and >ER< (Error) ap­pear. This error code can be unlocked
and removed twice using the remote
control, before a 24-hour shut down is
initiated (error code 08F).

Carry out the following steps to unlock
the fireplace;

1. Press

approximately five times,

after which the “A” code disappears.

2. Check if the gas valve is open.

3. Inspect if the ionisation pen is unob-

structed by looking through the
glass.

4. Initiate the new ignition atempt.

Press

, until >OK< flashes in the

top left corner of the display.

5. You can repeat step 1-4 once.

6 If error code 08F appears you have

to wait 24 hours before you can
reattempt to ignite the gas fire.
The waiting time must be respected,
also after a power interruption.

5.2 Malfunctions

Malfunctions can be organised in five
categories:

1. Permanent malfunctions (indicated

as >F<). This malfunction cannot be
fixed automatically, the gas fire is
blocked for 24 hours (except for the
error code 02F).

2. Recovering malfunctions (indicated
as >ALARM< or >A<). Malfunction
that can recover automatically, if the
cause has been detected and fixed.

3. Communication malfunctions (indi­cated as >E<). Malfunctions in the
communication connection between
the fireplace and the remote control

- these malfunctions can be fixed au­tomatically when the remote control
is placed closer to the technical unit
of the fireplace.
Press 1 x

.

4. Signal malfunctions (indicated as
>NOLK 0 or 1< or a flashing RF icon

). The remote control does not
communicate with the fireplace. This
malfunction
cannot be fixed automatically.

5. Fireplace failure. The automatic

burner relay requires a “time-out”
every 24 hours (according to current
inspection regulations). During this
“time-out”, all applications of the
automatic burner relay are tested.
The fireplace is automatically swit­ched off and stays down, until it is
turned on again manually.

29

5.2.2 Error codes iMatch remote control

Error code Cause Solution

Entire
display
flashing

Flat battery Replacing battery.

Low battery Replacing battery.

NOLK 0 in
the middle
of the
display

Bedienings­fout

Druk kort op >NOLK< zal nu linksboven in het display
verschijnen.

NOLK
linksboven
in het
display

No com­munication
between
remote
control and
fireplace
(for example
in case of a
new remote
control)

Synchronising remote control:

1. Open the hatch of the technical unit and carefully

remove the automatic burner relay so it is easily
accessible.

2. Remove the batteries from the remote control and

press (hereby discharging the remote control). Next,
replace the batteries into the remote control.

3. Isolate the automatic burner relay from power for

20 seconds, this will stimulate the synchronisation
speed. Supply power back to the cable. The entire
light will start flashing (once per second). Should
the gas fire is provided with a hybrid function and/
or NSG: detach the HCB cable from the automatic
burner relay.

4. Press

on the remote control until >NOLK 0<

appears on the display.
Next, release

.

5. In case >NOLK 1< or >LINK 1< appear, press

again until

>NOLK 0< appears.

6. Press the black button in the automatic burner relay

until the yellow light continuously stops flashing, then
immediately release the black button. The yellow light
will start flashing rapidly now.

7. Immediately (within 10 seconds) press

and hold

it down until the word

>LINK<starts flashing on the

display.

8. Wait until >LINK 1< appears and release

.

9. Press

. The normal display with a stationary RF

icon

will appear once the synchronisation is

successful.

10. Reconnect the HCB cable (if applicable).

11. Place the automatic burner relay back into the

technical unit and close the hatch.

30

Error code Cause Solution

02F

Tempera­ture of the
circuit board
is too high

1. Turn off the fireplace for approximately 30 minutes.

2. Then turn on the fireplace.

3. In case the error reappears, there is insufficient

ventilation in the chamber of the fireplace.

04F

No mains
voltage
supply
(two-way
switch only)

Supply mains voltage.

06F

or

flashing

No com­munication
between
remote
control and
fireplace

In case the light on the automatic burner relay
in the technical unit) does not flash:

1. Check power supply on the mains (230VAC).

2. If this is correct, check/replace the VDC transformer

and/or automatic burner relay.

In case the light on the automatic burner relay
(in the technical unit) flashes:

1. Place the remote control as close to the fireplace as

possible.

2. Briefly press

and wait approximately 60 seconds.

3. Check the transmission strength. See: Checking

transmission strength page 17. Carry out the
following steps to check the transmission strength
between the fireplace and the remote control.

4. Check for objects that could jam the signal

(for instance metal casings).

5. In case the signal keeps flashing -> synchronise.

31

Error code Cause Solution

08A

No
ionisation
measure­ment during
ignition.

A flame is visible during ignition

1. Check if the ionisation pen is completely unobstructed

by looking into the fireplace.

2. Check if the plug in the technical box is correctly

connected.See Wiring diagram on page 36.

3. Check the connection with the ionisation pen and

whether there are damages to the ionisation cable.

4. Measure the ionisation signal.

No flame is visible during ignition, but there was a spark
at the ignition pen.

1. Remove the door from the fireplace (see 5.1.3 and 5.1.4)

2. Carefully check if there no decorative elements are

obstructing the pen and if the spark correctly ignites
the burner.

3. Ignite the gas fire without the door once and check if

gas is emanating from the burner. In case no gas ema­nates from the burner: check for gas supply up to the
technical box (measure pre-pressure).

4. In the presence of pre-pressure, check whether the

cables running from the automatic burner relay to the
gas valve unit are damaged and/or disconnected.

5. In case of an excessive gas pressure level (>55mbar)

the gas valve cannot be opened for safety reasons.
The energy company or installer should fix this problem.

6. In case of no result: exchange gas regulator.

No flame is visible during ignition and no spark is visible
at the ignition pen.

1. Check whether the ignition pen is obstructed in

the fireplace.

2. Check if the plug connection is correct inside the

technical unit. See Wiring diagram on page 36.

3. Check if there is sufficient 24V D/C power supply.

4. Check the ignition cable for damages and check the

connection with the burner.

5. Check the HDIMS supply for the ignition transformer.

If the 135 V is supplied: replace the ignition

transformer,

if there is no 135 V: replace the HDIMS.

15A

Gas valve
problem

1. Check the cover wiring.

2. In case of correct wiring: exchange gas regulator.

32

Error code Cause Solution

29A

Problem
with
regulating
the gas
valve,
no flame
during
ignition

1. Check whether the gas valve is open.

2. Measure the gas pressure at the gas valve intake.

This must be > 20 mbar or with a G30(B/P) > 40 mbar.

3. Measure the burner pressure with the measurement

nipple behind the gas valve.

4. Check the gas valve wiring and connection.

5. Change gas valve settings, parameter TP01 or TP02.

6. Check/replace the gas valve.

33F

Low voltage
gas valve

Replace automatic burner relay

34F

Insufficient
voltage

1. Measure mains voltage (>220VAC)

2. Measure outgoing transformer voltage 24 VDC and

12 VDC.

3. If the outgoing voltage is lower than 20 VDC or 10

VDC, replace the transformer.

4. If the outgoing voltage is correct, check the wiring for

short-circuits.

35F

Problem
with the
electrical
driver

Replace automatic burner relay

50F

Gas valve
wiring
problem

Check the wiring and power plug connection.
Repair if necessary.

51A

Failure of
ionisation
signal
during while
fire is alight.

1. Check whether the ionisation pen is obstructed in the

fireplace.

2. Check whether the flame remains nicely in the

ionisation pen. In case the flame becomes transparent,
recirculation is occurring.

3. Check flue duct configuration.

33

5.2.3 Error code iMatch interface

Error code Cause

Solution

Red light in
iMatch inter­face is con­stantly red

The iMatch interface
has not yet been instal­led or is not provided
with a sufficient Wi-Fi
network strength.

Install the iMatch interface.

Red/green
LEDs are
flashing on the
iMatch
interface.

Distance between Wi-Fi
point and iMatch
interface is too great

Place your Wi-Fi point closed to the
iMatch interface (technical unit)
or place a Wi-Fi repeater.

You have not entered
the Wi-Fi settings
orrectly in the app

Check the Wi-Fi settings. Erase the added
room from the app. Reset the
iMatch interface and try again.

5.3 Malfunctions Natural Spark
Generator

No sparks, possible causes

If there is no spark visible (any more),
this can have the following causes:

•

Natural Spark Generator cartridge is

empty.

•

No power supply on the Natural

Spark Generator -> check whether
the Natural Spark Generator has
been connected correctly. See:
Wiring diagram on page 36 .

•

Natural Spark Generator pump / coil

is defect -> contact your dealer or
Kalfire.

34

A. Appendices

The following sections contain
appendices attached to the gas fire:

- Product card

- Wiring diagram

- Certificate of compliance

35

A.1 Product card (in conformance with (EU) 2015/1186 Appendix IV)

*the values in this table are inspection values in line with EN613, measured with a short configuration.

Model

Gas type

Energy

eciency class (kc)*

Direct

heat output

Indirect

heat output

Energy eciency

index (EEI)

Useful return at

nominal heat output

Useful return at

minimum heat output

Kalfire G60/48F Kalfire G65/44C Kalfire G70/44S G25 C 6.0 kW n/a 81% 84.0% 74.3%

Kalfire G60/48F Kalfire G65/44C Kalfire G70/44S G20 C 5.8 kW n/a 82% 85.3% 80.0%

Kalfire G60/48F Kalfire G65/44C Kalfire G70/44S G30 - 30 mbar D 5.5 kW n/a 72% 75.3% 68.3%

Kalfire G60/48F Kalfire G65/44C Kalfire G70/44S G30 - 50 mbar D 5.6 kW n/a 72% 75.7% 67.8%

Kalfire G80/48F Kalfire G85/44C Kalfire G90/44S G25 C 6.8 kW n/a 79% 82.3% 77.2%

Kalfire G80/48F Kalfire G85/44C Kalfire G90/44S G20 C 6.6 kW n/a 79% 82.6% 78.4%

Kalfire G80/48F Kalfire G85/44C Kalfire G90/44S G30 - 30 mbar D 5.1 kW n/a 75% 78.3% 49.4%

Kalfire G80/48F Kalfire G85/44C Kalfire G90/44S G30 - 50 mbar D 5.1 kW n/a 75% 78.3% 49.4%

Kalfire G100/41F Kalfire G105/37C Kalfire G110/37S G25 D 7.4 kW n/a 74% 77.4% 64.2%

Kalfire G100/41F Kalfire G105/37C Kalfire G110/37S G20 C 7.4 kW n/a 80% 83.2% 79.8%

Kalfire G100/41 Kalfire G105/37C Kalfire G110/37S G30 - 30 mbar D 8.2 kW n/a 72% 75.4% 61.6%

Kalfire G100/41F Kalfire G105/37C Kalfire G110/37S G30 - 50 mbar D 9.8 kW n /a 73% 75.8% 69.6%

Kalfire G120/41F Kalfire G125/37C Kalfire G130/37S G25 C 8.8 kW n/a 81% 83.8% 86.1%

Kalfire G120/41F Kalfire G125/37C Kalfire G130/37S G20 C 8.3 kW n/a 81% 84.6% 76.4%

Kalfire G120/41F Kalfire G125/37C Kalfire G130/37S G30 - 30 mbar C 9.7 kW n /a 81% 76.5% 73.6%

Kalfire G120/41F Kalfire G125/37C Kalfire G130/37S G30 - 50 mbar D 9.9 kW n /a 76% 78.9% 62.7%

Kalfire G160/41F Kalfire G165/37C Kalfire G170/37S G25 C 10.4 kW n/a 79% 78.9% 70.1%

Kalfire G160/41F Kalfire G165/37C Kalfire G170/37S G20 C 10,8 kW n /a 81% 81.8% 77.8%

Kalfire G160/41F Kalfire G165/37C Kalfire G170/37S G30 - 30 mbar C 11.0 kW n /a 79% 83.8% 77.0%

Kalfire G160/41F Kalfire G165/37C Kalfire G170/37S G30 - 50 mbar C 11.3 kW n/a 79% 82.0% 79.6%

Kalfire GP60/59F Kalfire GP65/55C Kalfire GP70/55S G25 D 6.2 kW n /a 72% 76.1% 62.7%

Kalfire GP60/59F Kalfire GP65/55C Kalfire GP70/55S G20 D 6.1 kW n/a 72% 76.0% 66.7%

Kalfire GP60/59F Kalfire GP65/55C Kalfire GP70/55S G30 - 30 mbar D 7.6 kW n /a 72% 76.1% 65.9%

Kalfire GP60/59F Kalfire GP65/55C Kalfire GP70/55S G30 - 50 mbar D 7.6 kW n /a 72% 76.1% 65.9%

Kalfire GP60/79F Kalfire GP65/75C Kalfire GP70/75S G25 D 7.8 kW n/a 73% 76.3% 66.2%

Kalfire GP60/79F Kalfire GP65/75C Kalfire GP70/75S G20 D 7.9 kW n/a 72% 76.2% 67.4%

Kalfire GP60/79F Kalfire GP65/75C Kalfire GP70/75S G30 - 30 mbar D 7.9 kW n/a 73% 76.8% 70.6%

Kalfire GP60/79F Kalfire GP65/75C Kalfire GP70/75S G30 - 50 mbar D 7.9 kW n/a 73% 76.8% 66.2%

Kalfire GP75/59F Kalfire GP80/55C Kalfire GP85/55S G25 D 8.0 kW n/a 73% 77.0% 78.3%

Kalfire GP75/59F Kalfire GP80/55C Kalfire GP85/55S G20 C 8.7 kW n /a 79% 83.0% 64.6%

Kalfire GP75/59F Kalfire GP80/55C Kalfire GP85/55S G30 - 30 mbar D 4.2 kW n /a 73% 77.4% 64.6%

Kalfire GP75/59F Kalfire GP80/55C Kalfire GP85/55S G30 - 50 mbar D 4.7 kW n /a 73% 77.4% 77.8%

Kalfire GP105/59F Kalfire GP110/55C Kalfire GP115/55S G25 D 7.7 kW n/a 73% 77.0% 68.2%

Kalfire GP105/59F Kalfire GP110/55C Kalfire GP115/55S G20 C 8.8 kW n/a 78% 82.0% 78.7%

Kalfire GP105/59F Kalfire GP110/55C Kalfire GP115/55S G30 - 30 mbar D 4.5 kW n/a 73% 77.4% 67.7%

Kalfire GP105/59F Kalfire GP110/55C Kalfire GP115/55S G30 - 50 mbar D 4.6 kW n/a 73% 77.4% 67.7%

Kalfire GP105/79F Kalfire GP110/75C Kalfire GP115/75S G25 C 10.3 kW n/a 77% 80.7% 78.6%

Kalfire GP105/79F Kalfire GP110/75C Kalfire GP115/75S G20 C 11.4 kW n /a 79% 82.1% 74.1%

Kalfire GP80/54T Kalfire GP85/50R G25 D 7.7 kW n/a

73% 77.0% 71.3%

Kalfire GP80/54T Kalfire GP85/50R G20 D 7.9 kW n/a 75% 79.0% 75.1%

Kalfire GP80/54T Kalfire GP85/50R G30 - 30 mbar D 6.1 kW n/a 73% 77.1% 69.6%

Kalfire GP80/54T Kalfire GP85/50R G30 - 50 mbar D 6.1 kW n/a 73% 77.1% 69.6%

36

A.2 Wiring diagram

Wiring diagram Natural Spark
Generator in the technical unit.

Fig. 14: Wiring diagram

HCB only applicable in hybrid mode
and/or Natural Spark Generator.

37

A.3 Certificate of compliance

Kalfire B.V.

Geloërveldweg 21

NL – 5951 DH, Belfeld

Certifies that the following Kalfire appliances, model gas fire:

Kalfire GP60/59F, GP65/55C, GP70/55S, Kalfire GP60/79F, GP65/75C, GP70/75S

Kalfire GP75/55F, GP80/55C, GP85/55S, Kalfire GP80/54T, GP85/50R

Kalfire GP105/59F, GP110/55C, GP115/55S, Kalfire GP105/79F, GP110/75C, GP115/75S

Kalfire G60/48F, G65/44C, G70/44S, G80/48F, G85/55C, G90/55S, G100/41F,

Kalfire G105/37C, G11037S, G120/41F, G125/37C, G130/37S, G160/41F, G165/55C

are in compliance with the appliances as described in the “EG-type-investigation-

certificate” N° E1398 / 5643 and N° E1347/5619 and are in accordance with the

applicable fundamental provisions of regulation EU 2016/426.

Date: 1 January 2019

Beijko van Melick MSc

Managing Director

Kalfire BV

38
