Adult Assembly Required.
Please read this manual carefully before giving this toy to your child.
This manual contains important information which will help you to assemble
the unit includes safety instructions.
Bigfoot® Monster Jeep Ba ery Operated Ride On
Instruc on / Assembling Manual
Item No. B00KD3FJH8
(KL-40007BF-6V)
Please keep this manual for future purpose.
Packaging has to be kept since it contains important information.
Manufactured by : Kalee Children’s Products Co, Ltd.
Made in China
Ages 3 and up
Age: Ages 3 and up
Maximum Capacity: 30 kgs / 66 lbs
Speed: 2.5-3.0km/h / 1.55-1.86mph
Battery Type: Sealed lead-acid rechargeable, 6Volt 7Ah
Charging time: Always charge the battery for 8-10 hours before first use
and when recharging is needed. Never charge for more
than 20 hours.
Power input for Charger: A/C 100-240 Volts, 60Hz
Power output to Battery: DC 7.5Volts, 1000mA
Vehicle / Battery Specifications:
WARNING:
2
Use the toy only on flat surfaces, such as sidewalks, driveways or
playgrounds. Do not ride the vehicle in dangerous places such as busy
streets, roads or highways.
Never use near swimming pools or other bodies of water.
Never ride the vehicle in muddy or sandy areas. Never ride in hilly
areas or on steep slopes. This vehicle was made to operate on dry
leveled ground.
Never ride in the dark or in dimly lit areas.
Clean the vehicle only with a damp cloth and never submerge vehicle
in water or spray with water directly from a hose.
Only one child should ride this vehicle at a time.
Do not exceed the recommended weight limit of 66 lbs.
To avoid suffocation of children please destroy all plastic bags after
assembly of the vehicle.
If vehicle is equipped with a forward / reverse switch, never press
this switch while vehicle is in motion. Always stop the vehicle before
switching directions.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10. The charger used for the vehicle are to be regularly examined for
damage to the cord, plug, enclosure and other parts, and in the event
of such damage, they must not be used until that damage had been
repaired.
11. The toy should be used with caution since skill is required to avoid
falls or collisions causing injury to the user or third parties.
CHARGING CAUTIONS:
- The charger is not a toy. Do not allow children to play with the charger or
to recharge the battery.
- Turn the power switch to “OFF” when charging.
- Before the first use, you should charge the battery for 8-10 hours. Do not
charge the battery for more than 20 hours to avoid overheating the charger.
- It is normal for the charger to feel warm during charging. If the charger
feel very hot, stop charging, unplug the charger and check the battery and
charger.
- Use the charger in a dry location only and store in a dry location
when not in use.
- Regularly check the charger, battery and their connectors for excessive
wear or damage each time you charge the battery. If damage or excessive
wear is detected, do not use the charger or the battery until you have
replaced the worn or damaged part.
BATTERY SAFETY WARNING:
- Only use the battery and charger supplied by the manufacturer.
- Do not connect the battery terminals directly together. This will cause the battery to
short-circuit.
- Never short-circuit the battery terminals or modify the electrical system.
Alterations may cause a fire resulting in serious injuries.
- Remove batteries during long periods of non-use. Always remove batteries from the
product. Dispose of batteries safely. Do not dispose of batteries in fires. The batteries
may explode or leak.
- If removable, rechargeable batteries are used, they are only to be charged under
adult supervision.
- Recharge the battery fully before storage, then charge it every 3 months to extend the
life of the battery.
- Do not mix old and new batteries
- Do not mix alkaline, standard (carbon-zinc) or rechargeable (Ni-Cd) batteries.
- Non-rechargeable batteries are not to be recharged (for steering wheel)
Different types of batteries or new or new and used batteries are not to be mixed
(for steering wheel)
- Exhausted batteries are to be removed from the toy (for steering wheel)
- Batteries are to be inserted with the correct polarity (for steering wheel)
- Rechageable batteries are to be removed from thy toy before being charged
(for steering wheel)
3
Caution:
This ride on vehicle is equipped with a built-in thermal circuit breaker.
The thermal circuit breaker is a self-resetting safety device which
automatically “trips” and shuts down the operation of the vehicle if it is
overloaded or the driving conditions are too severe. Once the circuit
breaker has tripped it will automatically reset itself after approximately
25 seconds and allow the rider to resume normal operation.
Caution:
1
2
3
4
5
6
Body
Steering Wheel
Rearview Mirror Assembly
Front Frame
Screw
Nut
Part List:
4
1pc
1pc
1pair
1pc
1pc
1pc
No. Description Qty
WARNING:
To reduce the risk of injury, adult supervision
is required.
Never use on roadways, near motor vehicles,
on or near steep inclines or steps, swimming
pools or other bodies of water. Always wear
shoes and never allow more than 1 rider.
WARNING:
Contains small parts, sharp points and
sharp edges. Adult assembly required.
WARNING:
Choking Hazard! Contains small
parts. Not for children under 3 years old!
WARNING:
This toy is unsuitable for children under
3 years due to its maximum speed.
WARNING:
Not to be used in traffic.
(prefixed on Steering Wheel)
(prefixed on Steering Wheel)
How to assemble the vehicle:
5
holes on the vehicle.
Step 1:
wheel column.
column.
withscrewdriver (not included).
Step 2:
Step 3:
Unscrew the screws on the seat by screwdriver
(not included), then open the seat.
Connect the red plug with the fuse.
Step 4:
Screw
Steering Wheel
Nut
Rearview
Mirror Assembly
The Front Frame
Undo the three screws on the backside of the steering wheel.
insert the new button cell batteries.
with the 3 screws.
Charging the Battery:
Operation of the Vehicle:
1.Make sure the battery is fully charged and the motor plug is connected to
the battery plug.
2.Before using the vehicle, please connect the plugs which located under the seat.
3.Press the direction switch to “F” and press the accelerator pedal,
vehicle will move forward.
4.To stop the vehicle remove foot from accelerator pedal. When stopped, press
the direction switch to “B” then press the accelerator
pedal, vehicle will move backward.
NOTE: Do not change directions while vehicle is in motion.
6
located near the seat.
then plug the charger into a household outlet.
charge more than 20 hours.
charger and store it in a cool and dry place.
Remove the two retaining screws from battery securing
bracket, then slide out the bracket to release the battery.
Carefully remove the battery from the compartment by
slide out into the foot well ensuring you don’t pull on any
of the wires.
Carefully release the two retaining spade connectors at
the terminals of the battery and remove the battery from
the foot well.
Carefully connect the battery ensuring the RED wire is
connected to th POSITIVE terminal and the BLACK wire
is connected to the NEGATIVE terminal of the battery.
Slide the battery back into position ensuring the wires
are loosely positioned above the battery.
Replace the battery securing bracket and resecure
retaining screws.
The supply terminals are not to be short-circuit.
How to remove & insert the battery:
Maintaining your vehicle:
It is a parents responsibility to check main parts of the vehicle before
use. Regularly examine the vehicle for potential hazards, such as the
battery, charge cable, cord and plug. Ensure screws are tightened. If
there are any damages, the vehicle must not be used until these
damages have been properly repaired or replaced.
Occasionally use a lightweight oil to lubricate moving parts such as
the wheels and steering linkages.
Keep the vehicle in an upturned position, do not overturn or incline it.
It is recommended to store the vehicle indoors when not in use. If
stored outdoors, the vehicle needs to be covered by a tarp for
protection against weather elements.
This toy should be kept away from fire. Keep the vehicle away from
sources of heat, such as stoves and heaters. Plastic parts may melt.
While charging ensure all flammable liquids are well away from the
vehicle.
ADULTS ONLY to recharge the battery after each use. Recharge the
battery at least once a month when the vehicle is not being used.
Use a soft, dry cloth to clean vehicle.
DO NOT use any chemical liquids to clean the plastic surface of the
vehicle.
DO NOT wash the vehicle with soap and water.
DO NOT drive the vehicle in rainy or snowy weather. Water will
damage the motor, electric system and battery.
When not in use all electrical sources should be turned off. Press the
power switch to the "OFF" position to turn the power off. Also
disconnect the battery connection under the seat.
Please do not change the structure of this product and circuit system.
DO NOT use the vehicle for other purposes except riding.
7
Safety Precautions:
1. While riding, adult supervision is required at all times.
2. Always wear a helmet when riding.
3. Do not ride near roads or on the footpath.
4. It is not recommended to drive the vehicle on wet surfaces or on
slopes greater than 15 degrees.
5. It is recommended to ride this vehicle on smooth surfaces only.
6. Do not use this vehicle outdoors when it is raining.
7. Make sure you come to a complete stop before changing directions
from forward to reverse.
8. Don't allow children to operate the charger or play with the battery.
9. Clean the vehicle with a dry cloth only.
10. Please follow the correct weight and age limits allowed to driver
this vehicle.
11. It is prohibited to change the circuit or add other electric parts.
12. Adults must teach their children about safe driving procedures.
13. Please turn the power off when not in use.
14. Check the seat to ensure it has been fitted and secured with a bolt
before driving.
15. Inspect all wires and connections of the vehicle perodically.
16. Charging the battery should only be done by adults.
17. Charging plug is located the bottom of the vehicle.
18. In order to avoid accidents, please ensure the vehicle is safe before
driving.
19. Do not let any child touch the wheels or be near them when the
vehicle is moving.
8
1. If vehicle fails to move:
a) Make sure the battery wires are connected properly.
b) Recharge the battery, if necessary.
c) Check the fuse and replace if damaged.
2. If vehicle runs slowly:
a) Recharge the battery.
3. If the battery can not recharged:
a) Battery or charger may be damaged. Replace if necessary.
Trouble-Shooting:
9
Manufactured by: Kalee Children’t Products Co. Ltd.
ALL RIGHTS RESERVED.
BIGFOOT®, visit www.Bigfoot4x4.com
Licensee: Kalee Trading Company/Kalee Children’s Products Co., Ltd.
Unit 816, Tower B, New Mandarin Plaza, 14 Science Museum Road,
Kowloon, Hong Kong
Made in China
You can help protect the environment! Please
non-working electrical equipments to an appriate
waste disposal center.
If you have any missing or damaged parts or need assembly assistance,
please contact our service center directly. Do not return this product to the retailer,
they do not stock replacement parts.
Support Website: http://support.bigtoysusa.com
Support Phone: 715-955-4237
Customer Service:
Loading...
