MEISTERSTÜCK
CONODUO
freestanding bath made of superior steel enamel
•
with exclusive easy-clean finish
•
straightlined, purist design
•
classic four-cornered model
•
enamelled waste cover and overflow knob integrated in the bath design (also
•
available with filling function)
bathing with a friend: two identical back rests and centrally positioned waste
•
made of KALDEWEI steel enamel
•
designed by Sottsass Associati
•
b1
a1
a6
e1
a7
f1
f8
c1
c2
r1
f9
b6
b11
f7
f2
e2
680
520
c19
80
400
80
Similar illustration
Model 173 3
External length a
Internal length (top) a
Internal length (bottom) a
External width b
Internal width (top) b
Internal width (bottom) b
Depth inside c
Depth incl. waste hole c
Height of b ath c
Width of rim (foot end; long side) e
Distanc e top edge to centre of ov er ow h ole f
Distanc e bath edge to centre o f waste hole f
Distanc e centre of waste hol e to centre of over ow hole f
Diamete r of over ow hole f
Diamete r of waste hole f
External radius r
Water volume 159 l
Waste connection diameter Ø 40/50
Fill tting connec tion 1/2“
Net weight 170 kg
Anti-slip 404 x 40 4 mm
Full anti-slip 884 x 40 4 mm
1
6
7
1
6
11
1
2
19
; e
1
2
1
2
7
8
9
1
180 0 mm
164 0 mm
118 0 m m
800 mm
640 mm
520 mm
420 mm
445 mm
610 mm
80; 80 mm
70 mm
900 mm
310 mm
Ø 52 mm
Ø 90 mm
5 mm
