2008 Built-In Grill Specifications
Bringing Gourmet Lifestyles Outdoors Since 19062
No Other Grill Cooks Like a Kalamazoo
No wonder Kalamazoo grills inspire such a loyal following. Over 115 BTUs per square inch of
primary cooking power. The ability to cook with any combination of charcoal, wood and gas.
Real hassle-free cleaning. Custom cooking surfaces. The advantages are unrivaled.
Hybrid Cooking with Charcoal, Wood and Gas Changing fuels is as
easy as opening the hybrid grilling drawer. Our powerful gas burners are
located below the hybrid drawer system. Use the burners alone to cook
with gas, or place wood or charcoal in the drawer. The gas burners can
be used to quickly and conveniently start a wood or charcoal fi re, or to
maintain the heat for longer cooking sessions.
Ultimate Versatility Grilling, searing, roasting, smoking, wok cooking,
r
otisserie and even baking. The power and versatility of Kalamazoo grills
enable home chefs to passionately pursue every cooking style they desire, on a grill that makes it look effortless.
Custom Cooking Surfaces Homeowners can select their ideal combina-
tion of cooking surface patter
There is even a solid surface available for teppanyaki-style cooking. For
even further personalization, initials, logos and other artwork can be cut
into the surface. See page 11 for more information.
ns optimized for meat, fi
sh and vegetables.
Easy-to-Use Rotisserie Cradles Forget the spit. Kalamazoo 450 and 900
Series grills come standar
infrared rotisserie system.
Integrated Cabinetry All Kalamazoo built-in and free-standing grills
come standar
deep hopper cleanout and electronic ignition modules.
Redundant Electronic Ignition The electronic ignition on a Kalamazoo
is a fully-r
wired to each burner for reliable starting.
Hassle-Free Cleaning Any ash, grease and debris funnel down the
deep-hopper design into a cleanout pan that is lar
everything and deep enough to be easy to handle. There are no shallow
grease trays on a Kalamazoo to slosh all over your patio. Another benefi t
of the deep-hopper design is that 99% of fl are-ups are eliminated.
d with integrated cabinetry for storage and access to the
edundant system. There are two independent electronic igniters
d with a no-mess r
otisserie cradle as part of the
ge enough to hold
Revolutionary hybrid grilling drawer
system.
Wok-ready cooktop cabinets add
convenient storage and expand your
cooking capabilities.
“The feature that really puts the Kalamazoo over the top
is that you can easily switch between gas and charcoal or
wood. It is as simple as opening the drawer!”
— Chef Rick Bayless
www.KalamazooGourmet.com 1.800.868.1699 3
Kalamazoo Built-In Grills
Built-In Grills with Stainless Steel Cabinets
Kalamazoo is the only manufacturer to offer built-in grills that include their
own stainless steel cabinets as a standar
Cooking Concept at the core of every grill we make utilizes a deep cookbox that extends far below the grilling surface for improved heat dynamics
and a broader range of outdoor cooking techniques. And, the hassle-free
cleaning system funnels down to a large and deep pan conveniently accessed within the cabinet. A Kalamazoo reaches all the way down to the
patio and stands on its own adjustable leveling legs for easy installation.
Each Kalamazoo is built to last and covered by a lifetime warranty. We build
the grills around a fully-welded stainless steel frame, and use much heavierguage stainless steel than our rivals, so much, in fact, that a Kalamazoo
900HB weighs-in at over 500 pounds.
Kalamazoo 900HB Hybrid Built-In Grill
K900HB
Hybrid grill cooks with charcoal, wood
and gas
122,000 BTUs total cooking power
38.3” Wide
Available in gas or hybrid charcoal, wood and gas models
432 square-inch (450 Series) or 864 square-inch (900 Series) primary
grilling area
50,000 main burner BTUs (450 Series) or 100,000 main burner BTUs
(900 Series) in 2 or 4 control zones
Infrared rotisserie cradle systems with 11,000 BTUs (450 Series) or 22,000
BTUs (900 Series) in 1 or 2 control zones
Hassle-free cleanout system
Optional custom laser-cut stainless steel cooking surfaces (see page 43)
Optional wok-ready cooktop (shown) (see page 28)
A
vailable with 22,000 BTU infrar
Natural gas standard, liquid propane confi guration optional
Hand-built in 304 stainless steel on a fully-welded frame
Toe-kicks available
d featur
ed searing burner (K900G models only)
e. Why? The Advanced
Kalamazoo 900GB Gas Built-In Grill
K900GB
Gas Grill
144,000 BTUs total cooking power
22,000 BTU infrar
38.3” Wide
ed searing bur
ner
Kalamazoo 450HB Hybrid Built-In Grill
K450HB
Hybrid grill cooks with char
and gas
61,000 BTUs total cooking power
26.9” Wide
coal, wood
Bringing Gourmet Lifestyles Outdoors Since 19064
Kalamazoo 450GB Gas Built-In Grill
K450GB
Gas grill
61,000 BTUs total cooking power
26.9” W
ide
Kalamazoo Built-In Grills (DIMENSIONS)
Kalamazoo 900HB Hybrid Built-In Grill
K900HB
OVERALL WIDTH
42.85
6.51
16.86
54.00
+/- 1.25”
ADJUSTMENT
38.26
INSTALLATION WIDTH
Kalamazoo 900GB Gas Built-In Grill
K900GB
OVERALL WIDTH
42.85
54.00
+/- 1.25”
ADJUSTMENT
COUNTER
HEIGHT
36.00
+/- 1.25”
ADJUSTMENT
16.86
COUNTER
HEIGHT
36.00
+/- 1.25”
ADJUSTMENT
7.86
+/- 1.25”
ADJUSTMENT
6.51
25.13
MIN. INSTALLATION DEPTH
26.38
MAX. INSTALLATION DEPTH
2.5” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
3.32
+/- 1.25”
ADJUSTMENT
2.5” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
38.26
INSTALLATION WIDTH
7.86
+/- 1.25”
ADJUSTMENT
MIN. INSTALLATION DEPTH
26.38
MAX. INSTALLATION DEPTH
3.32
www.KalamazooGourmet.com 1.800.868.1699 5
Kalamazoo Built-In Grills (DIMENSIONS CONTINUED)
Kalamazoo 450HB Hybrid Built-In Grill
K450HB
33.30
OVERALL WIDTH
12.75
49.70
+/- 1.5"
ADJUSTMENT
26.82
INSTALLATION WIDTH
COUNTER
HEIGHT
35.87
+/- 1.5"
ADJUSTMENT
5.28
3.06
+/- 1.5"
ADJUSTMENT
19.33
MIN. INSTALLATION DEPTH
20.64
MAX. INSTALLATION DEPTH
6” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
7.90
Kalamazoo 450GB Gas Built-In Grill
K450GB
33.30
OVERALL WIDTH
12.75
COUNTER
HEIGHT
49.70
+/- 1.5"
ADJUSTMENT
26.82
INSTALLATION WIDTH
35.87
+/- 1.5"
ADJUSTMENT
5.28
3.06
+/- 1.5"
ADJUSTMENT
19.33
MIN. INSTALLATION DEPTH
20.64
MAX. INSTALLATION DEPTH
6” REAR CLEARANCE
REQUIRED FOR HOOD
OPENING
7.90
Bringing Gourmet Lifestyles Outdoors Since 19066
Back Filler Panels for Grills
Filler panels are available to bring the back side of a Kalamazoo grill installation fl ush with the backs of our 30”-deep
kitchen cabinets and to support countertop spans behind the grill.
Filler panels connect to, and are suspended between, Kalamazoo Outdoor Kitchen Cabinets on either side. Counter overhang brackets are available.
Filler panels are ideal for island kitchen installations. Your expert Kalamazoo Outdoor Kitchen Consultant can advise you
regarding the use of these and other outdoor kitchen system components.
Filler Panel for Kalamazoo 900 Series Built-In Grills
K-BKFP-900B
2.00
38.56
31.50
Filler Panel for Kalamazoo 450 Series Built-In Grills
K-BKFP-450B
27.13
2.00
31.50
www.KalamazooGourmet.com 1.800.868.1699 7
Wok-Ready Cooktops
Why settle for a run-of-the-mill side burner when you can have a
32,000 BTU wok-ready cooktop in your outdoor kitchen. Our ingenious
design uses four concentric rings of fi re. To simmer sauces and glazes
at low temperatures, the two inner rings provide controlled heat. Turn the
burner up to high and all four rings kick in for rapid boiling or other hightemperature work.
Kalamazoo cooktops are available for built-in installations (photo at left)
or mounted in a convenient storage cabinet.
Cooktop for Built-In Installations
KKBI
Natural gas standard, liquid pr
Custom stainless steel griddle available (see page 11)
2.07
3.50 min
5.00 max
22.00
16.13
opane confi guration optional
GAS INLET
1.68
HIGH/
IGNITE
LOW
16.00
HIGH/
IGNITE
OFF
LOW
SIDE BURNER
(SELF-IGNITION)
OFF
5.43
1.44
24” Cooktop Cabinet
K-CKTP-24
Kalamazoo weather-tight rain gutter
Includes glide-out bottom tray and utensil tray with hooks ideal for hot
pads and tools
Natural gas standard, liquid propane confi guration optional
Left- or right-hinge
Toe-kicks available
24.00
2.25
33.12
30.00
12.00
GAS INLET OPENINGS
0.93
34.75
39.00
3.25
Bringing Gourmet Lifestyles Outdoors Since 19068
Create a Complete Outdoor Kitchen
Everything you need for the ultimate outdoor kitchen, including design support, is available
from Kalamazoo Outdoor Gourmet. We work with design professionals and homeowners to
plan the ideal outdoor cooking and entertaining retreat for each home.
Weather-Tight Outdoor Base Cabinets
More than 20 cabinets are available, each with a seamless rain gutter
surrounding every door and drawer opening. The cabinets ar
fi nished on all sides in hand-rubbed stainless steel.
Stainless steel construction, including all hardware
Full-extension stainless steel drawer glides
Weather-tight design
Fully-fi nished on all sides
Stainless steel levelling legs
Counter support brackets available
Toe-kicks available
Countertops shown for illustrative purposes only
e fully-
High-Performance Outdoor Refrigeration
Kalamazoo offers a complete line of outdoor refrigeration with more than
20 models available, including refrigerators and r
freezers and freezer drawers, wine chillers, keg tappers, beverage centers
and a clear ice maker. Variable speed compressors, advanced insulation
and forced air cooling add up to the most powerful and energy effi cient
outdoor refrigeration available. Check out the chart below comparing
BTUs (a measurement of cooling power) and energy consumption among
the most popular brands:
Kalamazoo U-line
BTU Output
Energy Used
(kWh/year)
Call us to speak with an outdoor kitchen design expert and get started designing your outdoor dream kitchen today.
You can also download the 2008 Outdoor Kitchen Design Resource Book from www.KalamazooGourmet.com.
995-1985
311
300-
700
339 334 N/A N/A 360
efrigerated drawers,
SubZero Viking Marvel GE
325 380 461 275
48” Outdoor Keg Tapper and GlassDoor Refrigerator and the Outdoor
Artisan Pizza Oven
www.KalamazooGourmet.com 1.800.868.1699 9
Bringing Gourmet Lifestyles Outdoors Since 190610
Plumbing and Electrical Information
Always hire a qualifi ed, professional plumber for installation of natural gas and bulk liquid
propane connections.
Shut-Off Valves For safety, a natural gas or bulk liquid propane shut-off
valve should be installed in a convenient location that is easily accessed
even when the grill or other cooking equipment is hot.
Gas Pressure Natural gas grills are optimized for 7 inches water
column pr
column pressure. For connection to a 20-pound liquid propane tank, the
Kalamazoo-provided regulator is set to the appropriate pressure. For bulk
liquid propane connections, the pressure must be regulated down to 11
inches water column by a customer-supplied regulator.
Gas Hoses All Kalamazoo grills, cooktops, lobster boilers and pizza ovens
that ar
fl exible gas lines and quick-connect hardware:
All units confi gured for use with a 20-pound liquid propane tank ship with a
gas hose and regulator for connection to the tank. Liquid propane tanks are
not included.
Gas Connection Specifi cations
Pipe Thread (NPT) connection for each piece of natural gas or bulk liquid
propane equipment provided by Kalamazoo Outdoor Gourmet according
to the following specifi cations:
essure. Liquid propane grills are optimized for 11 inches water
e confi gured for natural gas or bulk liquid propane supply ship with
K900 Grills: 3/4” diameter gas hose, 10’ long
K450 Grills: 1/2” diameter gas hose, 10’ long
Cooktops and Lobster Boiler: 1/2” diameter gas hose, 10’ long
Outdoor Artisan Pizza Oven: 1/2” diameter gas hose, 10’ long
Y
our plumber should prepare a National
K900HB and K900GB Grills
9” TO GAS INLET
K450HB and K450GB Grills
1.125” TO GAS INLET
K900 Grills: 1/2” male NPT
K450 Grills: 3/8” male NPT
Cooktops and Lobster Boiler: 3/8” male NPT
Outdoor Artisan Pizza Oven: 3/8” male NPT
Kalamazoo Outdoor Gourmet provides the quick-connect gas fi tting(s) to
thread onto these connection points.
Electrical Kalamazoo grills require electricity only for the rotisserie motor.
Locate a 110-volt GFCI outlet above the counter near the left side of the
grill for convenient operation. The r
stored indoors when not in use.
otisserie motor and transformer must be
9” TO GAS INLET
10-foot fl exible gas hose supplied by
Kalamazoo Outdoor Gour
from the bottom of the grill at the gas
inlet location indicated above.
1.88” TO GAS INLET
met originates
“This deck crushing monster can cook it all with burners to
impress Vulcan himself.”
www.KalamazooGourmet.com 1.800.868.1699 11
— Derrick Riches, About.com
Bringing Gourmet Lifestyles Outdoors Since 190612
Kalamazoo Built-In Grill Accessories
We offer a wide assortment of unique grill accessories that help make outdoor cooking an even
better experience. What else would you expect from the pioneers who invented the hybrid grill?
Custom Cooking Surfaces Laser cut from solid slabs of stainless steel
up to 1/4” thick, Kalamazoo’s custom cooking surfaces combine patterns
specially developed for the best performance with different types of food
and styles of cooking. Create any combination of these patterns and further
customize with initials, logo or other artwork (see the photo at left). The
sheer mass of these robust surfaces helps ensure great grill marks every
time. Solid surface areas are also available for teppanyaki-style cooking.
“MEAT” PATTERN “FISH” PATTERN “VEGETABLE” PATTERN
Cooktop Griddle Specially designed and fabricated for Kalamazoo wok-
r
eady side bur
and stir-fry.
ners, this heavy stainless steel griddle is perfect for fajitas
Sunbrella Grill Covers A Kalamazoo is built to withstand the elements,
but covering the grill helps it stay clean and always at the r
since a Kalamazoo deserves to be covered by nothing but the best, we
make all our covers from black Sunbrella™ fabric, silk-screened with the
Kalamazoo logo.
Grilling Rubs Kalamazoo has created signature spice blends using all-
natural ingr
grill. From the earthy coffee fl avors of our ZaZa Barbecue Rub to the rich
garlic and herbs of the Kalamazoo Rub, there is a perfect compliment
available for most any food. Check out all fi ve blends at
www.KalamazooGourmet.com.
Grillmaster’s Apron Our logo apron shows you take pride in your grilling
and in your grill. This is a full-length butcher’
with a stain-resistant fi nish.
edients that take make it easy to cr
eate bold fl avors on the
s apron in heavy black twill
eady. And
“...delivers the kind of performance I normally fi nd only in
restaurant kitchens”
www.KalamazooGourmet.com 1.800.868.1699 13
— Chef Michael Chiarello
Loading...
