Page 1
USER GUIDE
REVO GLIDER
Page 2
/kaiserbaas
Tag us & share the love.
Need help?
www.kaiserbaas.com/support
For the full Kaiser Baas
product range visit
www.kaiserbaas.com
Page 3
TABLE OF CONTENTS
SAFETY PRECAUTIONS 4
PRODUCT DIAGRAM 7
BEFORE YOU GET STARTED 8
WEIGHT RESTRICTIONS 8
OPERATING RANGE 8
PREPARATION 9
UNDERSTANDING THE REVO GLIDER 9
REVO GLIDER TIPS TO KEEP IN MIND 10
CHARGING YOUR Revo Glider 11
USING THE Revo Glider - CHARGED AND READY 12
MANOUVERING YOUR Revo Glider PART 1. 14
MANOUVERING YOUR Revo Glider PART 2. 15
ALERTS - WHAT IS THAT AWFUL BEEPING SOUND? 17
SPEED RESTRICTIONS 17
INSPECTION, MAINTENANCE AND STORAGE - KEEPING YOUR Revo Glider IN GOOD NICK 18
INSPECTION and MAINTENANCE 18
STORAGE 18
PRODUCT SPECIFICATIONS 19
FAQ 20
CONTACT US 21
Page 4
4
EN
SAFETY PRECAUTIONS
WARNING – FAILURE TO COMPLY WITH SAFETY INSTRUCTIONS MAY LEAD TO PROPERTY
DAMAGE, BODILY HARM AND IN EXTREME CIRCUMSTANCES, DEATH.
• Only charge your Revo Glider using the provided charger and cable. Failure to do so may result in
product failure and will void your manufacturer warranty.
• Please wear appropriate safety and protective gear to prevent personal injury. Please wear
safety and protective gear to the standard of protection you desire. This may include gloves, eye
protection, wrist guards and knee pads.
• Make sure to wear comfortable clothes and flat closed toe shoes when operating your Revo Glider.
Do not wear loose clothing that could be caught by the wheels and nearby objects.
• Please carefully read this User Guide, which will assist in explaining the basic working principles and
tips for using the Revo Glider.
• Do not use the Revo Glider if you are less than the 20kg minimum weight or exceed the 120kg
maximum weight.
• Before stepping on to the Revo Glider, make sure it is placed on a smooth and flat surface, that the
Revo Glider is turned on and that no Safety Alerts or Display Panel Alerts are present. Do not step
on to the Revo Glider if any Alerts are unresolved.
• Do not attempt to open or modify your Revo Glider as doing so will void your manufacturer
warranty and may cause the Revo Glider to fail leading to serious bodily harm or death.
• Do not use your Revo Glider to place yourself or your property in danger. Do not use your Revo
Glider to place anyone else or their property in danger.
• Do not operate your Revo Glider while under the influence of drugs and/or alcohol.
• Do not operate your Revo Glider when you are restless or sleepy.
• Seek the appropriate advice and always use your best judgement to keep yourself out of dangerous
situations with your Revo Glider.
Page 5
5
EN
• Do not ride your Revo Glider o curbs, ramps or attempt to perform stunts or tricks with your Revo
Glider, similar to those performed on skateboards, rollerblades and scooters.
• Do not turn sharply on your Revo Glider, especially at higher speeds.
• Do not continuously spin in place for prolonged periods of time. This may cause dizziness and you
may fall and injure yourself or other people and property.
• Do not ride your Revo Glider in an abusive or extreme manner, doing so can cause damage to your
Revo Glider and may lead to injury and death.
• Never ride your Revo Glider down stairs or escalators.
• Do not drive in or near puddles of water or other liquids, mud, sand, stones, gravel, debris or near
rough and rugged terrain.
• Do not ride in inclement weather: snow, rain, hail, sleek or on icy roads or in extreme heat.
• Do not ride your Revo Glider on slippery surfaces or steep slopes.
• If you are unsure if you can safely ride on a specific terrain, step o and carry your Revo Glider.
ALWAYS EXERCISE CAUTION.
• PAY ATTENTION- Always look at where you are riding and be aware of the riding conditions in front
of you including: people, places, property and objects around you.
• Do not operate the Revo Glider in crowded areas.
• Operate your Revo Glider with extreme consideration for people and property at all times.
• Do not operate your Revo Glider while talking, texting, looking at your phone or when otherwise
distracted.
• Do not ride your Revo Glider on the road, footpath, or cycle path.
• Do not ride your Revo Glider near motor vehicles or on public roads.
Page 6
6
EN
• Do not climb or descend steep hills with your Revo Glider.
• The Revo Glider is designed to be used by ONE individual at a time. Do not attempt to operate your
Revo Glider with two or more people on-board.
• Do not carry anything whilst using your Revo Glider.
• Individuals with lack of balance or medical conditions which aect balance should not attempt to
operate a Revo Glider.
• Do not use the Revo Glider if you are pregnant or attempting to become pregnant.
• Exercise extreme caution when allowing young children or elderly persons to use the Revo Glider.
These persons may not have the physical capabilities necessary to safely operate the Revo Glider.
• Always take into account the necessary space required to slow and stop the Revo Glider.
• DO NOT STEP FORWARD OFF YOUR REVO GLIDER.
• DO NOT JUMP OFF YOUR REVO GLIDER.
• Do not attempt to ride your Revo Glider in dark or poorly lit areas.
• Always ensure that you have sucient clearance when standing on the Revo Glider to make it safely
through doorways and other low-hanging obstructions.
• Do not step on any other parts of the Revo Glider apart from the Foot Pads.
• Always avoid operating the Revo Glider in unsafe places and where unsafe and volatile materials are
present e.g. near areas with flammable gas or liquids.
• YOU MUST COMPLY WITH ALL LOCAL, STATE AND FEDERAL LAWS IN YOUR RESPECTIVE
REGION REGARDING THE LAWFUL OPERATION OF YOUR REVO GLIDER.
Page 7
7
EN
PRODUCT DIAGRAM
DISPLAY PANEL DIAGRAM
Green Battery Icon - Revo Glider is charged
Flashing green Battery Icon - Revo Glider is reaching low-battery
Red Battery Icon - Revo Glider has low-battery
Green Operating Icon - Revo Glider is ready to ride
Red Operating Icon - Revo Glider has encountered at error
A
Fender
D
Engine & Tyres
G
Charging Port
B
Foot Pad Sensors
E
LED Indicators
H
On/O Button
C
Display
F
Underbody Protection
A
B
C
D D
E E
F
B
G H
Page 8
8
EN
BEFORE YOU GET STARTED
After reading through this guide, you must view the online tutorials for the Kaiser Baas Revo Glider to
familiarise yourself further with the features and operating controls.
You can view these tutorials here – www.kaiserbaas.com/revoglider
WEIGHT RESTRICTIONS
The Revo Glider is optimised for riders of up to 120kg – 265lbs and of a minimum weight of 20kg-45lbs.
OPERATING RANGE
In ideal conditions, the Revo Glider can travel distances of up to 20km. The typical range for the Revo
Glider is between 12-15 km
There are several factors that will decrease the optimal range of the Revo Glider:
Speed and Riding style. Maintaining a moderate speed will achieve an increased Operating Range on
the Revo Glider whereas, ‘hooning’ around with frequent stops, starts, idling and extreme acceleration
will result in a decrease in range.
Terrain. The Revo Glider is designed for smooth and flat surfaces and operating it across uneven and
rough terrain is not only dangerous, but will negatively aect the Operating Range of the Revo Glider.
Weight. The weight of the user can aect the Operating Range of the Revo Glider.
Battery Maintenance. Reasonable battery charging and maintenance will allow for the maximum
Operating Range on the Revo Glider. Over-charging or failing to follow proper charging instructions
can reduce the Operating Range.
Page 9
9
EN
PREPARATION
You must carefully read this User Guide, in its entirety, before you step on the Revo Glider.
Please follow the charging instructions in this User Guide before you attempt to use the Revo Glider.
We highly recommend that you grab a friend to be your spotter when you first start using the Revo
Glider. Your spotter will help you centre your balance and will oer you assistance should you
accidentally cause the Revo Glider to accelerate from underneath you. Your spotter should read the
User Guide and become familiar with the instructional videos prior to acting as a spotter.
UNDERSTANDING THE REVO GLIDER
The Revo Glider moves forwards and backwards using cues from your body position and posture. If
you stand straight and confidently on the Revo Glider, you will be able to control your movement to the
point where you are almost motionless.
Don’t forget, the Revo Glider is intuitive, it will move according to the cues it gets from your body. If
you lean forward slightly, or tilt your toes forward, the Revo Glider will move forward.
If you lean backwards slightly, or tilt your heels to the ground, the Revo Glider will move backwards. As
you become familiar with the Revo Glider, you will notice that tilting one foot forward and leaning the
other back will allow the Revo Glider to turn, on the spot and whilst moving.
Page 10
10
EN
REVO GLIDER TIPS TO KEEP IN MIND
Maintain a relaxed stance and position. If you tense up and try to make large adjustments, the Revo
Glider will copy you, exaggerating these motions and possibly accelerating out from underneath you.
Gain an even foot position. When you finally step up onto the Revo Glider, make sure your feet are
symmetrically placed on the Revo Glider Foot Pads. A symmetrical stance will make sure the tilt and
lean of your body is accurately interpreted by the Revo Glider.
Don’t get yourself into a flap. Avoid flailing your arms as this will aect your stance and posture on
the Revo Glider.
A solid dismount. ALWAYS dismount the Revo Glider by stepping BACKWARDS one foot at a time.
Why? Because when you step forward, your toes tilt towards the ground and the Revo Glider will think
you want to go forwards. Trust us, step backwards o the glider.
Page 11
11
EN
CHARGING YOUR REVO GLIDER
Remove your Revo Glider from its packaging and place it on a steady surface for charging.
Ensure that the charging port of the Revo Glider is clean and dry. Make sure that there is no dust, debris
or dirt inside the charging port. See Product Diagram for charging port location.
Use the included Revo Glider wall-charger and connect the Revo Glider to a suitable power point.
Use the appropriate cable provided for your region. NB: Using a non-provided cable will void your
manufacturer warranty and may cause serious product failure.
The indicator light on the Revo Glider charger should change to RED, indicating that your Revo Glider is
now charging.
When the RED indicator light on your Revo Glider charger turns to GREEN, your Revo Glider is fully
charged.
For first-time use, please charge for approximately 2 hours as your Revo Glider has been manufactured
with some residual power stored.
When you go to next charge your Revo Glider from flat, a full charge will take approximately 3 hours.
DO NOT leave unattended or over-charge the battery for more than 3 hours.
Page 12
12
EN
USING THE REVO GLIDER - CHARGED AND READY
Step 1. Place your Revo Glider on the floor, keeping in mind you should be using a smooth and flat
surface. Find a suitable place to practice using the Revo Glider.
We recommend an open flat area with a few metres in each
direction. The area should be free from obstructions and distractions.
Step 2. Press the POWER button of the Revo Glider, located on the
front edge of your Revo Glider next to the charging port. The Revo
Glider should beep, indicating that it has been powered-on.
Step 3. Check the Display Panel. The Revo Glider should display a
green Battery Icon and Operating Icon when it is ready to ride.
TROUBLESHOOTING: If you see a red Battery Light, please recharge
your Revo Glider. If the Revo Glider emits a series of warning beeps,
the Revo Glider is not in its correct starting position. Please turn the
Revo Glider o and place on a smooth surface as well as checking
that the Revo Glider’s wheels and panels are even and unobstructed.
Repeat Step 2.
Step 4. Put on your Safety Gear.
Step 5. Grab your buddy! Your spotter should stand facing you, in
front of the Revo Glider. Ideally, you will step on to the Revo Glider
and be able to use their arms or shoulders as support to centre your
balance
Step 6. Stand directly behind the Revo Glider and make sure your
spotter is ready for you to step on to the Revo Glider.
Page 13
13
EN
Step 7. Step quickly and confidently on to the Revo Glider. The Revo Glider is strong and will be able
to hold you (see Weight Restrictions - Page 8). Plant your feet evenly on to the Revo Glider and strive
to stand perfectly straight. This will make steadying the Revo Glider much easier. Use your spotter for
support but maintain straight posture as this is how you will centre your balance on the Revo Glider.
TAKE YOUR TIME. On average, it takes at least 3-5 minutes just to get used to standing on the Revo
Glider. Use the help of your spotter and allow your body and mind to understand that the straighter
you are, the more motionless the Revo Glider becomes. Remember the rules from earlier on (REVO
GLIDER TIPS TO KEEP IN MIND - Page 10).
The Revo Glider is intuitive, if you lean forward, you’ll travel forward. If you lean backwards, you’ll travel
backwards. If you do not lean at all, you should travel nowhere!
Practice stepping backwards, o the Revo Glider.
This is the single most important skill you will need
for the safe operation of the Revo Glider. DO NOT
step forwards.
ALWAYS STEP BACKWARDS, WITH A STEADY
FOOT POSITION, WHEN TRYING TO DISMOUNT
THE REVO GLIDER.
Practice stepping on and o the Revo Glider, using
the help of your spotter.
This diagram explains how to move forward
and backwards. Keeping upright places you
perfectly still.
TOP TIP: Lean your head in the direction you wish to travel.
Page 14
14
EN
MANOUVERING YOUR REVO GLIDER PART 1.
Now that you’re comfortable stepping on and o the Revo Glider, you can now focus on gradually
making the Revo Glider move forwards and backwards.
PRACTICE MAKES PERFECT and remember, the Revo Glider is intuitive. We advise you to not
overthink the gliding process but rather to remember the operating/motion rules:
Move forwards. Tilt your toes to the ground slightly to start the Revo Glider moving in a forwards
direction.
Stop moving. Flatten your feet on the Revo Glider and maintain a straight body position to stop the
Revo Glider moving.
Move backwards. Lean your heels towards the ground slightly to start the Revo Glider moving
backwards direction.
Do not ride or turn fast when travelling backwards.
Always stop in a controlled manner and avoid stopping abruptly. Stop by slowly shifting your weight
away from the direction you are travelling. Failure to stop in a controlled manner may result in the Revo
Glider losing traction causing you to fall.
TOP TIP: PRACTICE, PRACTICE, PRACTICE.
Page 15
15
EN
MANOUVERING YOUR REVO GLIDER PART 2.
Now that you can move the Revo Glider forwards and backwards, we can talk about how to turn the
Revo Glider in each direction.
Stop turning. Return your feet to an even position and stand straight. This will stop you turning in any
direction.
Practice turning slowly at first and to increase the acuteness of the turn, when tilting any one foot
towards the ground, lean the opposite heel back in an equal fashion.
Always turn in a controlled manner. Turning too quickly can result in loss of control.
Turn right: Tilt your LEFT foot towards
the ground and the Revo Glider will begin
to turn to the right.
Turn left: Tilt your RIGHT foot towards
the ground and the Revo Glider will begin
to turn to the left.
TOP TIP: PRACTICE, PRACTICE, PRACTICE until you can execute a zero-degree turning circle by
turning confidently in each direction, on the spot.
Page 16
16
EN
Now you can work turns into the forwards and backwards movement of the Revo Glider. Keep
practicing to begin navigating past obstacles and moving through joint spaces, such as rooms and
doorways.
Use caution when riding in new environments
Be careful when riding through doorways or under branches or similar objects as the Revo Glider
increases your height.
Be alert for hazards when riding including changes in the terrain such as footpaths and grass.
Page 17
17
EN
ALERTS - WHAT IS THAT AWFUL BEEPING SOUND?
When the Revo Glider needs your attention or encounters an error, it will emit a series of warning beeps
to let you know. This could be for the following reasons:
• You fell o the Revo Glider. The Revo Glider will be able to sense when you unexpectedly dismount
and will emit the warning beeping to let you know its sensors have been thrown out. Place the Revo
Glider on a smooth and flat surface, then turn the Revo Glider o, then on again.
• You activated the speed alarm. The Revo Glider has an inbuilt speed alarm that will sound when
you are moving faster than 10km per hour. Reduce your speed to deactivate the speed alarm. See
speed restrictions below.
• The Revo Glider has low-battery. The Display Panel will show a red Battery Icon alerting you to the
fact that you should charge your Revo Glider.
• The Revo Glider’s motors are overheating. This is usually caused by pushing the Revo Glider
outside of its optimal conditions e.g. riding uphill or over uneven terrain. Please allow the Revo Glider
to cool down.
SPEED RESTRICTIONS
The Revo Glider’s maximum speed is limited to about 12km per hour. Please keep in mind that riding
at 12km per hour will trip the Speed Alarm and will cause the Revo Glider to emit a series of warning
beeps. This alarm has been designed with your safety in mind as the Revo Glider is not designed for
speeds above 12km per hour. We highly recommend that users keep the Revo Glider at under 12km per
hour.
Speed Conversion: 12kp/h = 7mp/h
Page 18
18
EN
INSPECTION, MAINTENANCE AND STORAGE - KEEPING YOUR
REVO GLIDER IN GOOD NICK
We highly recommend that you routinely inspect and maintain your Revo Glider, as you would a bike,
board or car. If you discover abnormalities or have any issues with your Revo Glider, please contact
Kaiser Baas immediately for advice.
INSPECTION AND MAINTENANCE
Check the body and tyres of your Revo Glider for damage or excessive wear.
Avoid using harsh chemicals or solvents if you wish to clean and wipe down your Revo Glider. Do not
allow any liquids to enter the ports or buttons of the Revo Glider.
The Revo Glider is IP 54 rated, meaning that it can withstand small splashes of water. It is NOT water-
resistant or waterproof and must not be operated or stored in waterlogged conditions. Water and
other liquids can cause permanent damage to the circuitry and electronic components inside the Revo
Glider.
STORAGE
Store your Revo Glider indoors, in dry conditions at a suitable temperature.
If the ambient temperature of the storage location is below 0°C/32°F degrees or above 55°C/131°F
degrees, please select an alternative storage location.
To prevent dust and particles entering your Revo Glider during storage, please seal it inside its original
packaging and add additional layers of protection where desired.
If storing your Revo Glider for extended periods of time, please note that the charge level of the Revo
Glider may be depleted during storage. We recommend re-charging your stored Revo Glider every 3
months to make sure it is ready to ride when it is brought out of storage.
Page 19
19
EN
PRODUCT SPECIFICATIONS
Max Speed 10-12kp/h or 6-7mp/h
Dimensions 58.5cm x 18cm x 18cm
Weight 10.4kg
Range Upto 15km-20km Range
Max Weight Limit 120KG
Max Climbing Angle 15°
Min Turning Radius 0°
Charging Time Approximately 3 hours
Tyre Size 170mm
Tyre Type Solid Non-Inflatable
Chassis Clearance 30mm
Pedal Height 110mm
Lithium-Ion Battery Samsung 36V, 4.4AH
Waterproof and Dustproof IP54
Rated Temperature Tolerance -15C° to 50C°
Page 20
20
EN
FAQ
Is it legal to use the Revo Glider on the road or footpath?
It is likely that the Revo Glider will be regulated as a motor vehicle by each State and Territory. The Revo
Glider is not designed for use on the road or footpath and we do not advise using the Revo Glider on or
around any public road, footpath or cycle path.
Please consult your local and state road trac authorities for advice.
The Revo Glider battery icon is on. What do I do?
Please check that the unit has been charged according to the instructions.
The Revo Glider is beeping. What do I do?
See Page 17 for a guide on what the beeps could mean.
I can’t get the hang of riding the Revo Glider. What should I do?
Go over the instructions in the User Guide or watch the online tutorials at kaiserbaas.com and if you’re
still stuck give us a call, we’re happy to help.
Can the Revo Glider get a flat tyre?
No, it cannot as the tyres are solid rubber.
Page 21
21
EN
CONTACT US
Need further assistance? Please visit:
www.kaiserbaas.com/support
Or email:
helpdesk@kaiserbaas.com
For the full Kaiser Baas product range visit
www.kaiserbaas.com
Page 22
www.kaiserbaas.com
Loading...
