R50
Quick Start Guide
R50 Dash Camera
For card compatibility,
see www.kaiserbaas.com/support
Installation
Clean a small area of your windscreen.
Kaiser Baas recommends that dash
cameras be mounted behind the
Rear-View Mirror, out of the driver’s
field of view, with the power cable
around the outside of the windscreen.
Connect the GPS cable to the camera
and plug it into the USB Car Charger. The
Dash Cam will automatically turn on and
begin recording when the vehicle starts.
Insert MicroSD card.
Micro USB
Socket
Suggested
GPS
Getting Started
Connection
Connect to a smartphone:
Open your device’s WiFi settings
and select Dash Cam Network
(KB-RSERIES-XXXXXX).
Use password 12345678 to connect.
Once connected, launch the app to
see live video, track your journey,
change camera settings or download
captured footage and photos.
Live View
Live View, Playback and Download:
Once you’re connected to the dash cam
via WiFi, the camera will appear ‘online’
in the Dash Camera page where you
can click on it to view a live preview
of the current video.
Playback: Click the video icon on
the ‘online’ page and select your
desired videos for playback.
Download the KB
Drive App to get
started.
Other Settings
Once you’ve connected your
smartphone to the dash cam,
enter the settings page to modify
the general settings such as the
G-Sensor sensitivity, microphone
switch, volume etc.
Reset
To reset your dash camera, press and
hold the Reset button for 3 seconds.
The default WiFi password is 12345678.
Reset
Microphone
Speaker
LED
LED
LED Indicators:
Red: Flashing when recording
Green: Connected Wifi
Product Name : R50 DASHCAM
Product Model: KBA12027
Hardware
CPU: Hisilicon3516C_V200
Image sensor: Panasonic CMOS sensor.
Lens: 6-Glass elements, 156° Wide Angle, F1.8
Wi-Fi: 2.4GHz, 802.11b/g/n.
G-sensor: Three-Axis Accelerometer.
Technical Parameters
Video information:
1920*1080 (16:9), @30fps, *.mp4.
Audio information: 8KHz, 2 channels, AAC.
Photo information: 1920*1080, *.JPG.
Storage: Class 10 MicroSD card, Max 64GB.
Working temperature: -20℃----70℃.
Working voltage & current: DC 5V& 450mA.
Video processing: 3D denoising, WDR, image
enhancement, LDC correction, flip, etc.
R50 SPECS
Support
Visit www.kaiserbaas.com/support
or email helpdesk@kaiserbaas.com
for support. For the complete user
guide, visit www.kaiserbaas.com
Hands Free Control
To take a photo using Hands Free
Control, simply wave your hand under
the dash cam.
Setting up Hands Free Control:
In the Kaiser Baas Drive App, select
‘Photography with Video’ within Settings
to set up video recording. Your Dash Cam
will save 5 seconds of footage from before
and after your gesture.
In these settings, you can also customise
the Hands Free Control function to register
your hand gesture from different lengths.
Photos and videos can be downloaded to
your smartphone from the Gallery Page.
GPS
For optimal positioning of the GPS
module, it should be mounted as far
away from the camera as possible,
with an unobstructed view of the sky.
The GPS module will track your location
and speed to ensure that saved photos
and videos are accurate.
Camera Lens
Gesture
Indication Area
