Kaiser Baas Alpha Drone Complete User Manual
1
ALPHA
Complete User Guide
Alpha Drone
Join the social movement and follow us on
Pre-ight
Safety Precautions
Flight Equipment
Your Drone
Remote Control Transmitter
Remote Control Screen
Set Up
Flight Planning
Pairing Tips
Flight Basics
360° Flip
Filming Basics
Flight Maintenance
FAQ
Specications
Support
03
03
05
06
07
09
10
12
13
14
18
20
21
23
24
25
DISCOVER: FREEDOM
Share your footage with us on social media
#KBdiscover
To view the entire Kaiser Baas
product range visit:
www.kaiserbaas.com
Contents
3 4
Disclaimers & Warnings
Please read this section carefully before using your
Kaiser Baas Alpha Drone. By operating this product,
you hereby agree to these disclaimers and signify
that you have read and understood the warnings and
conditions fully.
THIS PRODUCT IS NOT SUITABLE FOR PEOPLE
UNDER THE AGE OF 14.
Always observe the safe flying instructions within
this User Guide, as well as the guidelines and
regulations of your local aviation authorities.
Above all, maintain a safe distance from people
and property when operating your Alpha Drone – a
safe distance of 10m is recommended. Kaiser Baas
accepts no liability for damage(s) or injuries incurred
directly or indirectly from the use of this product,
including but not limited to the following conditions:
• Failure to follow the full instructions and cautions
in the User Guide, pertaining to correct assembly
and safe operation.
• Damage(s) or injuries caused by erratic operation
or poor piloting decisions.
• Damage(s) or injuries caused by mechanical
failures as a result of neglect, including the erosion
and aging of product components.
• Damage(s) or injuries caused by the Drone being
flown in the following conditions:
• Unfavourable lighting; where the Pilot’s ability to
see the Drone clearly is diminished.
• Inclement weather; moderate to high winds, rain,
snow or hail.
• Flying near electrical hazards, such as power lines
or towers.
• Flying in or near fire, floods, tsunamis, ice,
avalanche, landslide, earthquake, etc.
• Damage(s) or injuries incurred due to users
under the influence of drugs or alcohol, suffering
dizziness, fatigue, nausea and any other condition;
physical or mental that could impair the Pilot’s
ability to fly responsibly and within the boundaries
of the law.
• Damage(s) or injuries caused by malfunctions
or “hacks”, refits or the replacement of original
components with non-Kaiser Baas provided
accessories and/or parts.
• Damage(s) or injuries caused by the misuse
or incorrect operation of the battery, protection
circuits, Remote Control Remote Control
Transmitter or Battery Charger.
• Damage(s) or injuries caused by flying the Drone
in abnormal conditions and allowing external
substances to come into contact with the Drone
e.g. water, oil, soil, sand or any other material
that could enter the Drone and its internal
compartments, including the battery.
• Damage(s) or injuries caused by flying in areas
such as those with: magnetic interference, radio
interference, government regulated no-fly zones
or airports.
• Any other losses that are not covered by the scope
of Kaiser Baas liability.
Before first use: read the user’s information together
with your child.Please keep this user guide for later
reference.
Kaiser Baas reserves the right to make changes
to this User Guide if required. Please check the
Kaiser Baas website for the most up to date version
of this guide: www.kaiserbaas.com/support. The
information within this manual is subject to change
without notice.
Safety Warnings & Operating
Guidelines
Even though the Alpha Drone may look small and
light, there are important safety considerations to
bear in mind when operating this device. Always
observe the following guidelines:
Flying the drone requires skill and users must be
trained under direct supervision of an adult.
DO NOT fly the Drone within 10m of people
anywhere. Consider your personal liability when
you choose to operate your Drone.
DO NOT attempt to handle or catch the Drone while
it is in operation.
DO NOT attempt to handle the Drone while the
Rotor Blades are still spinning.
DO NOT allow others to approach the Drone while
it is in operation and the Rotor Blades are in motion.
Hands, hair and loose clothes must be kept away from
the spinning Rotor Blades.
Always make sure that you have completely
“disarmed” the Drone before handling.
Always maintain Visual Line-of-Sight (VLOS)
with the Drone.
Always fly between official sunrise and official sunset,
local time.
Never engage in careless or reckless manoeuvres.
Consider the impact reckless behaviour might have on
other Drone enthusiasts and future Pilots.
Never operate your Drone when intoxicated or
when you are incapacitated in any other way.
Always ensure the room where the drone is used is
sufficiently large and free from obstacles and persons.
Always follow your local aviation authority’s guidelines.
Adult supervisors should always check the drone is
assembled as instructed within this user guide. All
assembly shall be performed under adult supervision.
5 6
Pre-Flight Drone Battery Safety
Warnings concerning the use of
the battery
Safety Precautions
Connect the battery to the included USB
battery charger to begin charging. Use
this charging time to familiarise yourself
with the operation and controls of your
new drone.
Please do not leave the drone battery
in direct sunlight or expose to extreme
temperatures. Do not leave charging
batteries unattended. Do not store batteries
in any clothing pockets or on your person
at any time. Do not bend, crush, scrape,
or puncture battery.
If a battery is damaged or misshapen,
carefully dispose of the damaged unit
immediately and correctly.
• Lithium Polymer batteries are extremely
hazardous and liable to cause serious
injuries to persons or property. The user
accepts liability for the use of a Lithium
Polymer battery. As the manufacturer
and the distributor cannot ensure the
battery is used correctly (charging,
discharging, storage, etc.), they cannot
be held liable for damages caused to
persons or property.
Please read the included CASA flyer
‘Flying with control’.
Learn and be aware of the laws and
restrictions when flying your drone. Do
not fly your Alpha Drone any closer than
5.5km to any airfield, or any closer than
30 metres to boats, buildings, people, or
animals. Be aware of your surroundings
and exercise caution when using your
drone. For more information on this go
to http://www.casa.gov.au/ within Australia,
or your local aviation authority if you are
outside of Australia. Do not attempt to open
the housing of the Alpha Drone, battery,
or the Remote Control Transmitter, or
attempt to modify it in any way. Any
unauthorised tampering with the product
will void the warranty and may affect the
operation of your drone. Only charge
the battery with the included cable.
Do not leave your battery unattended
whilst charging.
Keep both the Alpha Drone and the
Remote Control Transmitter away from
water and other liquids. If water or
other liquids come into contact with the
Alpha Drone, battery, or Remote Control
Transmitter, do not operate. This product
is not suitable for those 14 years
and under.
• In the event of battery leakage, avoid
the liquid coming into contact with skin
and eyes. In case of contact with the
skin, seek medical advice immediately.
Wash copiously with soap and water.
In case of contact with the eyes, rinse
copiously with cold water and consult
a doctor. If you notice a suspicious
smell or noise or observe smoke around
the charger, disconnect it immediately.
• Non-compliance with the instructions
above could result in gas being given
off, fire, electric shock or an explosion.
• Risk of explosion if battery is replaced
by an incorrect type.
• Dispose of used batteries according
to the instructions.
7 8
Flight Equipment Your Drone
4 x Rotor blade guards
4 x Spare rotor blades
1 x Drone battery
Rotor Blade Guards
Feet
Lights
Camera
Rear Profile
C E
BA
D F
A A
B B
D
E
F
G
C C
2 x Landing feet
1 x USB battery charger
1 x Screwdriver
SD Card slot
Battery Hatch
Power Switch
AA D E
BB E F
CC F G
D
