FOR SAFETY MEASUREMENTS!!

WARNING

INTRODUCTION

2. SPECIFICATIONS

3. SAFETY PRECAUTIONS

4. NAME ILLUSTRATION

WARNING 1. Checks of Body and Test Lead

WARNING 3. Warning for High Voltage Measurements

WARNING 4. Dangerous Voltage Measurement Procedures

WARNING 2. High Power Line Measurements Prohibited

WARNING 7. Test Lead Detachment

WARNING 6. Maximum Measurement Range Observance

WARNING 5. Correct Selection of RANGE Switch

To prevent an electrical shock hazard to the operator and/or damage to the instruments, read this instruction manual carefully before using the Multitester. WARNINGS with the symbol on the Multitester and this instruction manual are highly important.

Important Symbols

The symbol listed in IEC 61010-1 and ISO 3864 means "Caution (refer to instruction manual)".

WARNING : The symbol in this manual advises the user of an electrical shock hazard that could result in serious injury or even death.

CAUTION : The symbol in this manual advises the user of an electrical shock hazard that could cause injury or material damages.

Do not measure High Power Line that might exceed 2kVA. Measurement on High Power Line is very dangerous. It sometimes includes High Surge Voltage that could cause dangerous arcs of explosive short in the instrument and could result in serious injury to the operator. When measuring high voltage, even for Low Power Line (Low Energy Circuit), take extra care to avoid electrical shock hazard and/or damage to the instrument.

Thank you for purchasing KAISE "MODEL KF-20 ANALOG MULTITESTER". To obtain the maximum performance of this instrument, read this Instruction Manual carefully, and take safe measurement.

Inspect the instrument and acessories for transport damage. If there is any damage or missing items, ask your local dealer for replacement. Confirm that the following items are contained in the package.

2-1. MEASUREMENT SPECIFICATIONS

2-2. GENERAL SPECIFICATIONS

3-1. WARNINGS

3-2. GENERAL WARNINGS AND CAUTIONS

1. Analog Multitester

2. Test Lead (100-51)

3. Holster

4. Spare Battery (1.5V R6P)

5. Instruction Manual

Allligator Clip

Red Test Lead

Black Test Lead

Allligator Clip

Red Test Lead

Black Test Lead

Children and the persons who do not have enough knowledge about electric measurements must not use this instrument. Do not measure the electricity naked or barefooted to protect yourself from electrical shock hazard. Be careful not to get hurt with the sharp test lead pins. Do n

ot polish the case or attempt to clean it with any cleansing fluid like gasoline or benzine. If necessary, use silicon oil or antistatic fluid. Avoid the multitester from hard mechanical shock or vibration, high temperature and strong magnetic field. Remove the batteries when the multitester is out of use for a long time. The exhausted batteries might leak electrolyte and corrode the inside.

WARNING 1.

WARNING 2.

WARNING 3. CAUTION 1.

CAUTION 2.

CAUTION 3.

Measurement exceeding the specified maximum values of each measurement range is prohibited.

Always confirm that RANGE Switch is set to the correct position. Do not measure voltage in DC-mA, Ω and BAT. ranges.

Detach test leads from the measuring circuit before rotating RANGE Switch or opening rear case for battery or fuse replacement.

WARNING

Detach test leads from the circuit before rotating RANGE Switch to avoid electric shock hazard and serious damage to the instrument.

Select suitable scale from "0 - 6", "0 - 12", or "0 - 30" applying certain multiple. Reading examples :

Multiply the scale value depending on the measurement range. Reading examples :

Read the scale directly.

For accurate measurement, read following notes carefully.

DC 0.3V range : Read "0 - 30" scale multiplying by 1/100. DC 120V range : Read "0 - 12" scale multiplying by 10. DC 60uA range : Read "0 - 6" scale multiplying by 10. DC 300mA range : Read "0 - 30" scale multiplying by 10.

"x 1" range : Read the scale directly. "x 100" range : Multiply the scale value by 100. "x 1k" range : Multiply the scale value by 1,000.

Correct knowledge of electric measurements is essential to avoid unexpected danger such as operator's injury or damage to the instrument. Read carefully and observe the following precautions for safety measurements.

Before measurement, confirm the body of this instrument and handle insulators of the Test Lead have no cracks or any other damages. Dust, grease and moisture must be removed. 

This instrument is applicable for Low Energy Circuit measurements only. Do n

ot use for High Power Line (High Energy Circuit) measurements such as

Distribution Transformers, Bus Bars and Large Motors.

Even for Low Energy Circuits of electric/electronic appliances, such as heating elements, small motors, line cords and plugs, High Voltage Measurements are very dangerous. Do not touch Multitester, Test Leads, and any part of the circuit. Generally, shock hazard could occur when the current between the circuit, that involves more than 33V rms or 46.7V DC or peak, and ground goes up to 0.5mA or more.

For dangerous voltage measurement, strictly observe the warnings below. (refer to fig.1)

ANALOG MULTITESTER

KF-20

INSTRUCTION MANUAL

In case of live-line measurement, strictly observe the warnings below (refer to fig 2.)

fig. 1

fig. 5

fig. 2

fig. 3

fig. 4

1. UNPACKING AND INSPECTIONS

1 pce. 1 set 1 pce. 1 pce. 1 pce.

Turn off the circuit to be measured. Plug black test lead to "- (COM)" terminal and red test lead into "+" terminal. Attach black and red alligator clips to test lead pins. Set RANGE Switch to desired DC or AC voltage range. Connect b

lack alligator clip to - (earth) side and red alligator clip to + (positive) side of the measuring circuit. Do n

ot hold Multitester and test leads in your hands. Keep safety distance from power source or circuit to be measured not to touch the dangerous voltage. Turn on the circuit to be measured, and read the meter. Turn o

ff the circuit again. Detach alligator clips after confirming the meter

returns into "0".

Set RANGE Switch to desired DC or AC voltage range. Attach a

lligator clip to black test lead pin, and connect to - (earth) side of the measuring circuit. Do n

ot hold Multitester in your hands. Keep safety distance from power source or circuit to be measured not to touch the dangerous voltage. Connect red test lead to + (positive) side, and read the meter. Detach red test lead from the circuit first, then detach black alligator clip.

Before measurement, confirm that meter points to "0". (zero-adjusted) Select proper range referring to 「5-1. 6-(1) Range Selection」. Read the meter from directly over the pointer. Measurement i

n strong magnetic field or on iron plate causes reading error or meter sensitivity wrong. Once-a-year p

eriodical calibration is necessary to maintain tolerance accuracy

and to take safety measurements.

Set the switch to a desired measurement range. To measure uncertain voltage or current, firstly measure the approximate value at the highest range, then change the switch into the suitable range. For c

orrect voltage and current measurements, select the range to point the right side of the meter scale. (between center scale and maximum scale) For c

orrect resistance measurement, select the range to point around the center of OHMS scale.

DC Voltage ( DC-V ) AC Voltage ( AC-V ) DC Current ( DC-mA ) Resistance ( Ω )

1.5V Battery Test Hi Range Lo Range

Temperature ( ℃ )

DC : ±3％ f.s., AC : ±4％ f.s. Ω/ TEMP : ±3％ f.s.length

1.5V R6P (AA) battery ×1 136(H)×90(W)×30 (D)mm, 215g 100-51 Test Lead ×1 set

Holster ×1

1.5V R6P (AA) Battery (built-in and spare) ×1 each Spare Fuse (0.3A/250V)×1 (inside the rear case) Instruction Manual

660 Clamp Adapter 810-02 Temperature Probe 940 Alligator Clip

0.3 / 3 / 12 / 30 / 120 / 300 / 1200V 12 / 30 / 120 / 300 / 1200V

60 A / 3mA / 30mA / 300mA

5KΩ / 500KΩ / 5MΩ

1.5V R20P / R14P / R6P

1.5V 250mA

1.5V 50mA

−50℃〜＋250℃

Accuracy

Overload Protection

Power Supply Dimensions & Weight

Accessories

Optional Accessories

×1 and 300mA range : protected by internal diode and 0.3A / 250V fuse

1200

300

120

300

120

30 300

0.3

BAT.

×1×

100

AC-VDC-V

TEMP

DC AC

BATT

TEMP

1.5V VOLT

BATT

MADE IN JAPAN

NO.

PROTECTION

10,000／V AC

20,000／V DC

15 6 3

10 4

100

200

500

0 0

20 8 4

25 10

30 12 6

250

200

100

‑50

1.5

1.0

0.5

℃

CAL

OHMS

KF-20

C O M



Meter Case

Pointer

Zero Adjustment Screw

RANGE Switch

Rear Case

Meter Scale

0ΩADJ. Knob

＋Terminal

−(COM)

Terminal

100-51 Test Lead

KF-20 contains 1 x fast-acting 0.3A/250V (φ5x20mm) fuse to protect Resistance and Current measurement ranges. For replacement, refer to 「6-2. FUSE REPLACEMENT」.

Insert black test lead into - (COM) terminal, and red test lead into + terminal.

Always confirm that RANGE Switch is set to the proper measurement range. To avoid serious damage to the instrument, do not measure voltage in DC-mA, Ω and BAT ranges.

3. FUSE

Before measurement, confirm that meter points to "0". If not, adjust the pointer by

Zero Adjustment Screw to take accurate measurement.

4. ZERO ADJUSTMENT

5. TEST LEAD

7. Meter Scale Reading

8. Measurement Accuracy

DC/AC scale (for AC/DC Voltage, DC Current measurements : V, μA, mA)

OHM scale (for Resistance measurement : Ω)

TEMP scale (for Temperature measurement : ℃)

(1) Range Selection

(2) Confirmation of the Range

6. RANGE SWITCH

Read INSTRUCTION MANUAL carefully to understand the specification and functions correctly. 「3. SAFETY PRECAUTIONS」is higly important for safety measurement.

KF-20 contains 1 x 1.5V R6P (AA) battery. Replace it referring to 「6-1. BATTERY REPLACEMENT」when exhausted.

5-1. PREPARATION FOR USE

1. INSTRUCTION MANUAL

2. BATTERY

5. MEASUREMENT PROCEDURES

TEMP

DC AC

BATT

TEMP

1.5V VOLT

BATT

0599060356-1

MADE IN JAPAN

NO.

PROTECTION

10,000／V AC

20,000／V DC

15 6 3

10 4

100

200

500

20 8 4

25 10 5

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

UCHIDA

BATT scale

TEMP scale

KF-20

DC/AC scale

OHMS scale

TAUT BAND

DROP PROOF

1200

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

6 3

10 4

100

200

2 1

500

0 0

20 8 4

25 10

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

KF-20

1200

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

6 3

10 4

100

200

2 1

500

0 0

20 8 4

25 10

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

KF-20

outlet

when measuring DC. mA /Ωrange

1200

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

6 3

10 4

100

200

2 1

500

0 0

20 8 4

25 10 5

30 12 6

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

KF-20

DROP PROOF

70-1201-KF20-1 0802

Do not measure high power line that might exceed 2kVA. Do not exceed the maximum input value of each range. Confirm that RANGE Switch is set to the correct position. Read 「3. SAFETY PRECAUTIONS」carefully for safety measurement.

KF-20 is warranted in its entirety against any defects of material or workmanship under normal use and service within a period of one year from the date of purchase of the original purchaser. Warranty service is available at KAISE AUTHORIZED SERVICE AGENCY through your local dealer. Their obligation under this warranty is limited to repairing or replacing KF-20 returned intact or in warrantable defect with proof of purchase and transport charges prepaid. KAISE AUTHORIZED DEALER and the manufacturer, KAISE CORPORATION, shall not be liable for any consequential damages, loss or otherwise. The foregoing warranty is exclusive and in lieu of all other warranties including any warranty of merchantability, whether expressed or implied. This w

arranty shall not apply to any instrument or other article of equipment which shall have been repaired or altered outside of KAISE AUTHORIZED SERVICE AGENCY, nor which have been subject to misuse, negligence, accident, incorrect repair by users, or any installation or use not in accordance with instructions provided by the manufacturer.

Check the battery connection, polarity, and capacity. Confirm that RANGE Switch is set to the correct position. Confirm t

hat the body of this instrument and handle insulators of the Test Leads have no cracks or any other damages. Check i

f any noise affects the instrument. This instrument is fully shielded

against noise, but possibly to be affected by very strong noise.

Repair service is available at KAISE AUTHORIZED SERVICE AGENCY through your local dealer. Pack the instrument securely with your name, address, telephone number and problem details, and ship prepaid to your local dealer.

KAISE AUTHORIZED DEALER

Product specifications and appearance are subject to change without notice due to continual improvements.

5-3. AC VOLTAGE MEASUREMENTS (AC-V)

WARNINGS

●

6-1. BATTERY REPLACEMENT

6-4. REPAIR

WARNINGS

WARRANTY

Replace the batteries when it is exhausted and "0Ω Adjustment" does not work.

Check the following items before asking repair service.

To avoid electrical shock, detach test leads from circuit when when opening rear case for battery or fuse replacement. Be sure to tighten the screw of rear case after the battery replacement

Detach test leads from the circuit. Unscrew rear case. Remove rear case opening from meter side and slide to the upward. Replace a

n exhausted battery into a new 1.5V R6P (AA) battery in correct polarity. Close rear case fitting from bottom to up, and tighten the screw.

422 Hayashinogo, Ueda City, Nagano Pref., 386-0156 Japan TEL : +81-268-35-1600 (REP.) / FAX : +81-268-35-1603 E-mail : sales@kaise.com http://www.kaise.com

fig. 10

6．MAINTENANCE

Do not measure over 300mA DC. Do not exceed the maximum input value of each range. Confirm that RANGE Switch is set to the correct position. Read 「3. SAFETY PRECAUTIONS」carefully for safety measurement.

5-4. DC CURRENT MEASUREMENTS (DC-mA)

WARNINGS

●

WARNINGS

●

The internal protection circuit against over current for meter movement and the internal circuit is installed. But, the instrument should be defective by such as over input measurement, or applying voltage to resistance or current range.

9. Protection Circuit

5-2. DC VOLTAGE MEASUREMENTS (DC-V)

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to a desired DC-V range. NOTE :

Connect black test lead to − (earth) side and red test lead to ＋ (positive) side of the measuring circuit.

NOTE : Connect the multitester IN PARALLEL to the circuit. NOTE : Use alligator clips for dangerous voltage measurement.

Read the meter on DC/AC scale referring to 「5-1. 7. Meter Scale Reading」. Detach test leads from the circuit.

To measure uncertain voltage, firstly measure the approximate value at 1200V range, then change the switch into the suitable range. Detach test leads from the circuit before rotating RANGE Switch.

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to a desired AC-V range. NOTE :

Connect black test lead to − (earth) side and red test lead to ＋ (positive) side of the measuring circuit.

NOTE : Connect the multitester IN PARALLEL to the circuit. NOTE : Use alligator clips for dangerous voltage measurement.

Read the meter on DC/AC scale referring to 「5-1. 7. Meter Scale Reading」. Detach test leads from the circuit.

To measure uncertain voltage, firstly measure the approximate value at 1200V range, then change the switch into the suitable range. Detach test leads from the circuit before rotating RANGE Switch.

Installed battery is for inspection purpose and might be exhausted earlier than the new battery.

300mA range is protected by 0.3A/250V fuse, but 60uA, 3mA, and 30mA ranges are not. Do not measure voltage in DC-mA range. Do not measure wall outlet or car battery by mistake.

Do not measure voltage in Ω range. When measuring in-circuit resistor, turn off the circuit to be measured and discharge the capacitors.

5-5. RESISTANCE MEASUREMENTS (Ω)

WARNINGS

●

6-2. FUSE REPLACEMENT

6-3. PERIODICAL CHECK AND CALIBRATION

WARNINGS

Always use the specified fuse. Do not use the instrument shorting fuse holder or without using the fuse. Be sure to tighten the screw of rear case after the fuse replacement.

●

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to a desired Ω range. When m

easuring in-circuit resistor, turn off the circuit to be measured and

discharge the capacitors.

0Ω Adjustment

Short-circuit m

etal pins of the test leads. Turn 0Ω ADJ. Knob until the meter

points to "0Ω".

NOTE : 0Ω Adjustment is necessary for each time when Ω range is selected. NOTE : 0Ω Adjustment does not work if the battery is exhausted. Replace it

referring to「6-1. BATTERY REPLACEMENT」. Connect t

est leads to resistor to be measured detaching its one side from the circuit. Read the meter on OHMS scale referring to 「5-1. 7. Meter Scale Reading」. NOTE : Read the scale directly when measuring in "x 1" range. In "x 100" range, multiply the scale by 100, and in "x 1k" range, multiply by 1,000. NOTE : For correct resistance measurement, select the range to point around the center of OHMS scale. Detach test leads from the resistor.

Do not test non-specified batteries to avoid electric shock hazard and serious damage to the instrument. Do not test car battery. Do not measure voltage or current in BAT range.

Battery exhausted level can be tested in Hi (1.5V 250mA), or Lo (1.5V 50mA) ranges. Testable batteries : 1.5V R20P (D), 1.5V R14P (C), 1.5V R6P (AA), 1.5V R03 (AAA)

5-6. 1.5V BATTERY TEST (BATT)

WARNINGS

●

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to "Hi" or "Lo" of BAT range.

NOTE :

"Lo" range applies 50mA, and "Hi" range applies 250mA to the battery. Confirm consumption current of the instruments that the battery will be used to select the proper testing range. Popular range selection : 1.5V R20P (D), 1.5V R14P (C) : "Hi" range

1.5V R6P (AA), 1.5V R03 (AAA) : "Lo" range Connect black test lead to − (earth) side and red test lead to ＋ (positive) side. Read the meter on BATT scale. Meter points "GOOD (blue)" : The tested battery is good. Meter p

oints "REPLACE (red)" : The tested battery is exhausted and needs to be replaced.

NOTE :

Even if meter points "REPLACE (red)" for 1.5V R6P (AA) battery tested in "Lo" range, it may be used with low consumption current instruments.

810-02 temperature probe (option) is necessary. Measurement range is -50℃ to +250℃.

5-7. TEMPERATURE MEASUREMENTS (℃)

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to TEMP (x100) range.

0Ω Adjustment

Short-circuit m

etal pins of the test leads. Turn 0Ω ADJ. Knob until the meter points to "CAL" line on TEMP scale. Remove test leads from the terminals, and insert 810-02 temperature probe. Connect temperature probe to the object to be measured. Read the meter on TEMP scale.

Plug Black Test Lead into "- (COM)" terminal and Red Test Lead into "+" terminal. Set RANGE Switch to a desired DC-mA range. WARNINGS

Turn off the circuit to be measured and discharge the capacitors. Connect b

lack test lead to − (earth) side and red test lead to ＋ (positive) side

of the measuring circuit.

NOTE : Connect the multitester IN SERIES to the circuit. NOTE : Using alligator clips is recommended for safety measurement.

Turn on the circuit to be measured. Read the meter on DC/AC scale referring to 「5-1. 7. Meter Scale Reading」. Turn off the measured circuit again and discharge the capacitors. Detach test leads from the circuit.

●

NOTE :

DC Current and Resistance measurement cannot be made if fuse blows out. This instrument contains one spare fuse inside the rear case.

Periodical check and calibration is necessary to make safety measurements and to maintain the specified accuracy. The recommended check and calibration term is once a year and after the repair service. This service is available at KAISE AUTHORIZED SERVICE AGENCY through your local dealer.

Open rear case referring to 「6-1. BATTERY REPLACEMENT」. Replace a blowout fuse into a new one. Fuse type : Fast-acting 0.3A/250V (φ5x20mm) Close rear case fitting from bottom to up, and tighten the screw.

1200

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

6 3

10 4

100

200

500

0 0

20 8 4

25 10

30 12 6

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

UCHIDA

battery

KF-20

Red Test Lead

Black Test Lead

Red Test Lead

Black Test Lead

Red Test Lead

Black Test Lead

Red Test Lead

Black Test Lead

fig. 6

fig. 7

fig. 9

fig. 8

1200

300 120

30 12

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

15 6 3

10 4

100

200

500

20 8

30 12 6

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

UCHIDA

outlet

KF-20

1200

1200 300 120

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

15 6 3

4 2

100

200

500

25 10 5

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

UCHIDA

＋

−

＋

−

Switch

KF-20

1200

300 120

30 12 3

30 300

0.3

BAT.

×1×

100

AC-V

DC-V

TEMP

DC AC

BATT

TEMP

TAUT BAND

1.5V VOLT

BATT

MADE IN JAPAN

NO.

DROP PROOF

PROTECTION

10,000／V AC

20,000／V DC

15 6 3

10 4

100

200

500

20 8 4

25 10 5

250

200

100

-50

1.5

1.0

0.5

℃

CAL

OHMS

C O M

Resistor

KF-20

Rear Case

1.5V R6P Battery

Screw

Kaise KF-20 Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
