Kaisai 12K, 30K, 36K, 42K, 48K Installation Manual

CEILING & FLOOR TYPE

Ceiling And Floor Type

Thank you very much for purchasing our air conditioner,
Before using your air conditioner, please read this manual carefully and keep it for

future reference.

INSTALLATION MANUAL

If used as MULTI unit, please refer to the Installation & operation manuals packed with outdoor unit.

PRECAUTIONS...................................................................................1

INSTALLATION INFORMATION..........................................................2

ACCESSORIES...................................................................................3

INDOOR UNIT INSTALLATION...........................................................4

OUTDOOR UNIT INSTALLATION.......................................................6

INSTALL THE REFRIGERANT PIPE...................................................8

CONNECT THE DRAIN PIPE............................................................10

ELECTRIC WIRING WORK...............................................................11

TWINS FUNCTION............................................................................13

TEST OPERATION............................................................................13

CONTENTS Page

Keep this manual where the operator can easily find them.

Read this manual attentively before starting up the units.

For safety reason the operator must read the following
cautions carefully.

The safty precautions listed here are divided into two categories.

If you do not follow these instrutions exactly, the unit may
cause property damage, personal injury or loss of life.

If you do not follow these instrutions exactly, the unit may
cause minor or moderate property damage, personal injury.

After completing the installation, make sure that the unit operates
properly during the start-up operation. Please instruct the customer on
how to operate the unit and keep it maintained.Also, inform customers
that they should store this installation manual along with the owner's
manual for future reference.

Be sure only trained and qualified service personnel to install,
repair or service the equipment.

Improper installation, repair, and maintenance may result in
electric shocks, short-circuit, leaks, fire or other damage to the
equipment.

Install according to this installation instructions strictly.
If installation is defective, it will cause water leakage, electrical
shock and fire.

When installing the unit in a small room, take measures
against to keep refrigerant concentration from exceeding
allowable safety limits in the event of refrigerant leakage.
Contact the place of purchase for more information. Excessive
refrigerant in a closed ambient can lead to oxygen deficiency.

Use the attached accessories parts and specified parts for
installation.
otherwise, it will cause the set to fall, water leakage, electrical
shock and fire.

Install at a strong and firm location which is able to withstand
the set' s weight.
If the strength is not enough or installation is not properly done,
the set will drop to cause injury.

The appliance shall not be installed in the laundry.

Before obtaining access to terminals, all supply circuits must
be disconnected.

The appliance must be positioned so that the plug is accessible.

The enclosure of the appliance shall be marked by word, or by
symbols, with the direction of the fluid flow.

For electrical work, follow the local national wiring standard,
regulation and this installation instructions. An independent
circuit and single outlet must be used.
If electrical circuit capacity is not enough or defect in electrical
work, it will cause electrical shock or fire.

Use the specified cable and connect tightly and clamp the
cable so that no external force will be acted on the terminal.
If connection or fixing is not perfect, it will cause heat-up or fire
at the connection.

Wiring routing must be properly arranged so that control board
cover is fixed properly.
If control board cover is not fixed perfectly, it will cause heat-up
at connection point of terminal, fire or electrical shock.

If the supply cord is damaged, it must be replaced by the
manufacture or its service agent or a similarly qualified person
in order to avoid a hazard.

An all-pole disconnection switch having a contact separation
of at least 3mm in all poles should be connected in fixed wiring.

When carrying out piping connection, take care not to let air
substances go into refrigeration cycle.
Otherwise, it will cause lower capacity, abnormal high pressure
in the refrigeration cycle, explosion and injury.

Do not modify the length of the power supply cord or use of
extension cord, and do not share the single outlet with other
electrical appliances.
Otherwise, it will cause fire or electrical shock.

Carry out the specified installation work after taking into
account strong winds, typhoons or earthquakes.
Improper installation work may result in the equipment falling

and causing accidents.

PRECAUTIONS

WARNING

WARNING

CAUTION

3

kaisai.com

Indoor unit installation;

Outdoor unit installation;

Install the refrigerant pipe;

Connect the drain pipe ;

Electric wiring work;

Test operation.

Twins function;

If the refrigerant leaks during installation, ventilate the area
immediately.
Toxic gas may be produced if the refrigerant comes into the
place contacting with fire.

The temperature of refrigerant circuit will be high, please keep
the interconnection cable away from the copper tube.

After completing the installation work, check that the refrigerant
does not leak.
Toxic gas may be produced if the refrigerant leaks into the
room and comes into contact with a source of fire, such as a
fan heater, stove or cooker.

Ground the air conditioner.
Do not connect the ground wire to gas or water pipes, lightning
rod or a telephone ground wire.Inappropriate grounding may
result in electric shocks.

Be sure to install an earth leakage breaker.
Failure to install an earth leakage breaker may result in electric
shocks.

Connect the outdoor unit wires , then connect the indoor unit
wires.
You are not allowed to connect the air conditioner with the
power supply until the wiring and piping is done.

While following the instructions in this installation manual, install
drain piping in order to ensure proper drainage and insulate
piping in order to prevent condensation.
Improper drain piping may result in water leakage and property
damage.

Install the indoor and outdoor units, power supply wiring and
connecting wires should be at least 1 meter away from
televisions or radios in order to prevent image interference or
noise.
Depending on the radio waves, a distance of 1 meter may not
be sufficient enough to eliminate the noise.

The appliance is not intended for use by young children or
infirm persons without supervision.

Don't install the air conditioner in the following circumstance:

The appliance shall be installed in accordance with national
wiring regulations.

Do not operate your air conditioner in a wet room such as a
bathroom or laundry room.

An all-pole disconnection device which has at least 3mm
clearances in all poles , and have a leakage current that may
exceed 10mA, the residual current device (RCD) having a rated
residual operating current not exceeding 30mA, and
disconnection must be incorporated in the fixed wiring in
accordance with the wiring rules.

CAUTION

There is petrolatum existing.

There is salty air surrounding (near the coast).

There is caustic gas (the sulfide, for example) existing
in the air (near a hot spring).

The Volt vibrates violently (in the factories).

In buses or cabinets.

In kitchen where it is full of oil gas.

There is strong electromagnetic wave existing.

There are inflammable materials or gas.

There is acid or alkaline liquid evaporating.

Other special conditions.

To install properly, please read this "installation manual" at
first.

The air conditioner must be installed by qualified persons.

When installing the indoor unit or its tubing, please follow
this manual as strictly as possible.

If the air conditioner is installed on a metal part of the
building, it must be electrically insulated according to the
relevant standards to electrical appliances.

When all the installation work is finished, please turn on
the power only after a thorough check.

Regret for no further announcement if there is any change
of this manual caused by product improvement.

INSTALLATION INFORMATION

INSTALLATION ORDER

4

kaisai.com

ATTACHED FITTINGS

Please check whether the following fittings are of full scope. If there are some spare fittings , please restore them carefully.

NAME SHAPE QUANTITY

1
(on some models)

1
(on some models)

1
(on some models)

1
(on some models)

1
(on some models)

1
(on some models)

1

1

2
(on some models)

2
(on some models)

6. Remote controller

7. Frame

8. Mounting screw(ST2.9 0-C-H)

9.Alkaline dry batteries (Am4)

10. Remote controller manual

11. Wire controller

12. Wire controller owner's manual

13. Wire controller installation manual

15. Owner's manual

16. Installation manual

Remote controller & Its Frame
(Match with
remote controller )

Wire controller & Its Frame
(Match with wire controller )

Others

5

kaisai.com

B

C

D

A

E

Hook

Connecting point of
refrigerant pipe

Connecting point of
refrigerant pipe

Drain point

(gas side)

(Liquid side)

Keep indoor unit, outdoor unit, power supply wiring and
transmission wiring at least 1 meter away from televisions
and radios. This is to prevent image interference and noise
in those electrical appliances. (Noise may be generated
depending on the conditions under which the electric wave
is generated, even if 1 meter is kept.)

CAUTION

- There is enough room for installation and maintenance.

- The ceiling is horizontal, and its structure can endure the weight
of the indoor unit.

- The outlet and the inlet are not impeded, and the influence of
external air is the least.

- The air flow can reach throughout the room.

- The connecting pipe and drainpipe could be extracted out easily.

- There is no direct radiation from heaters.

1.1 Installation place

1.2

The dimension of the unit

The indoor unit should be installed in a location that meets the
following requirements:

1. INDOOR UNIT INSTALLATION

All the pictures in this manual are for explanation purpose only.
There may be slightly different from the air conditioner you
purchased ( depend on model ). The actual shape shall prevail.

NOTE

>35mm

>1000mm

>35mm

>35mm

MODEL( )Btu/h

AA BB CC DD EE

30K

36K/42K/48K/55K

18K/24K

1650

1068

1285

675

675
675

235

235
235

1565

983

1200

220

220
220

Unit:mmUnit:mm

1.3 Install the main body

1 Ins talli ng 1 0 hanging screw bolts. (4 bolts)

O

O

Please refer to the following figures for positioning 4 screw bolts.

Evaluate the ceiling construction and please install with 10
hanging screw bolts.

The handling to the ceiling varies from the constructions,
consult the construction person for the specific condition.

- Do keep the ceiling flat. Consolidate the roof beam to avoid
possible vibration.

- Cut off the roof beam.

- Strengthen the place that has been cut off, and consolidatethe
roof beam.

After the selection of installation location, position the refrigerant
pipes, drain pipes,indoor & outdoor wires to the connection
places before hanging up the machine.

The installation of hanging screw bolts.

6

kaisai.com

1.3.4 Steel roof beam structure

Install and use directly the supporting angle steel.

Hanging screw bolt

Supporting
angle steel

Hanging bolts

2 Overhanging the indoor unit

3. Ceiling Installation

4. Wall Mounting Installtion

- Locate the hanging arm on the hanging screw bolt.

Screw nut

Shockproof cushion

Hanging arm

Hanging
screw bolt

Washer

Confirm the minimum drain tilt is 1/100 or more

NOTE

1.3.1 Wooden construction

1.3.2 New concrete bricks

1.3.3 For Original concrete bricks

Put the square timber traversely over the roof beam, then install the hanging
screw bolts.

Inlaying or embedding the screw bolts.

Use embedding screw bold, crock and stick harness.

Timber over the beam

Roof beam

Ceiling

Hanging screw bolts

(Blade shape insertion)

(Slide insertion)

Steel bar

Embedding screw bolt

(Pipe hanging and embedding screw bolt)

Install the hanging hook with expansible bolt into the concrete
deep to 45~50mm to prevent loose.

- Remove the side board and the grille.

Hanging
screw bolt

Hanging arm

Grille

Side board

20 25mm

>20mm

Downward declicity lower between(1-2)/100

Connecting point of
refrigerant pipe(gas side)

Connecting point of
refrigerant pipe(Liquid side)

Drain point

7

kaisai.com

2.1 Precautions for selecting the location

2.2 Figure of body size

2. OUTDOOR UNIT INSTALLATION

1) Choose a place solid enough to bear the weight and vibration of
the unit, where the operation noise will not be amplified.

2) Choose a location where the hot air discharged from the unit or
the operation noise will not cause a nuisance to the neighbours
of the user.

3) Avoid places near a bedroom and the like, so that the operation
noise will cause no trouble.

4) There must be sufficient spaces for carrying the unit into and out
of the site.

5) There must be sufficient space for air passage and no
obstructions around the air inlet and the air outlet.

6) The site must be free from the possibility of flammable gas
leakage in a nearby place.

7) Install units, power cords and inter-unit wire at least 3m away from
television and radio sets. This is to prevent interference to images
and sounds. (Noises may be heard even if they are more than 3m
away depending on radio wave conditions.)

8) In coastal areas or other places with salty atmosphere of sulfate
gas, corrosion may shorten the life of the air conditioner.

9) Since drain flows out of the outdoor unit, do not place under the
unit anything which must be kept away from moisture.

Cannot be installed hanging from ceiling or stacked.NOTE:

When operating the air conditioner in a low outdoor ambient
temperature, be sure to follow the instructions described below.

- To prevent exposure to wind, install the outdoor unit with its suction
side facing the wall.

- Never install the outdoor unit at a site where the suction side may
be exposed directly to wind.

- To prevent exposure to wind, it is recommended to install a baffle
plate on the air discharge side of the outdoor unit.

- In heavy snowfall areas, select an installation site where the snow
will not affect the unit.

CAUTION

- Construct a large canopy.

- Construct a pedestal.

Install the unit high enough off the
ground to prevent burying in snow.

MODEL( )Btu/hMODEL( )Btu/h

AA BB CC DD EE FF HH

24K24K

30K/36K/42K30K/36K/42K

48K/55K48K/55K

12K/18K12K/18K

945945

810810

938938

845845

640640

549549

634634

560560

405405

325325

404404

335335

448448

350350

448448

360360

385385

305305

368368

312312

395395

310310

392392

320320

810810

558558

13691369

700700

Unit:mmUnit:mm

A

B

F

E

C

D

H

8

kaisai.com

2.3 Installation guidelines

2.4 Outdoor unit installation

When installing the outdoor unit, refer to "Precautions for
selecting the location" .

Check the strength and level of the installation ground so that
the unit will not cause any operating vibration or noise after
installed.

Fix the unit securely by means of the foundation bolts.
(Prepare 4 sets of M8 or M10 foundation bolts, nuts and
washers each which are available on the market.)

Where a wall or other obstacle is in the path of outdoor unit's
inlet or outlet airflow, follow the installation guidelines below.

For any of the below installation patterns, the wall height on the
outlet side should be 1200mm or less.

1) Installing outdoor unit

2) Drain work

If drain work is necessary, follow the procedures below.

Use drain plug for drainage.

If the drain port is covered by a mounting base or floor surface,
place additional foot bases of at least 30mm in height under the
outdoor unit's feet.

In cold areas, do not use a drain hose with the outdoor unit.
(Otherwise, drain water may freeze, impairing heating
performance.)

Drain port

Bottom frame

Seal

Drain plug

Hose

Wall facing one side

Walls facing three sides

Walls facing two sides

1200
or less

Direction
of air

More than 100

More than 350

Side view

Top view

More than 50

More
than 100

More
than 350

More than 50

Top view

More than 50

More than 100

More than 350

Unit:mm

Fix with bolts

9

kaisai.com

3 INSTALL THE REFRIGERANT PIPE

Execute heat insulation work completely on both sides of the
gas piping and liquid piping. Otherwise, this can sometimes
result in water leakage.
(When using a heat pump, the temperature of the gas piping can
reach up to approximately 120 . Use insulation which is
sufficiently resistant.)

Before rigging tubes, check which type of refrigerant is used.

All field piping must be provided by a licensed refrigeration
technician and must comply with the relevant local and
national codes.

Use a pipe cutter and flare suitable for used refrigerant.

Do not mix anything other than the specified refrigerant, such
as air, etc.., Inside the refrigerant circuit.

Coat the flare both inside and ouside with ether oil or ester oil .

If the refrigerant gas leaks during the work, ventilate the area.
A toxic gas is emitted by the refrigerant gas being exposed to
a fire.

Make sure there is no refrigerant gas leak. A toxic gas may be
released by the refrigerant gas leaking indoor and being
exposed to flames from an area heater, cooking stove, etc.

Also, in cases where the temperature and humidity of the
refrigerant piping sections might exceed 30 or Rh80%,
reinforce the refrigerant insulation(20mm or thicker).
Condensation may form on the surface of the insulating material.

Only use annealed material for flare conncetions.

Coat here with ether oil or ester oil

Precautions

3.1 Flaring the pipe end

1) Cut the pipe end with a pipe cutter.

2) Remove burrs with the cut surface facing downward so that the
chips do not enter the pipe.

5) Check that the flaring is properly made.

Refer to the table below for the dimensions of flare nuts spaces
and the appropriate tightening torque. (Overtightening may
damage the flare and cause leaks.)

Pipe gauge
(mm)

Outer diam.
(mm)

Tightening torque

A(mm)

Max.

1.3

1.6

1.8

2.2

Min.

0.7

1.0

1.0

2.0

Flare dimension
A (mm)

Flare shape

O6.35

O6.35

15~16 N. m
(153~163 kgf.cm)

8.3~8.7

12.0~12.4

15.4~15.8

18.6~19.0

25~26 N. m
(255~265 kgf.cm)

35~36 N. m
(357~367 kgf.cm)

45~47 N. m
(459~480 kgf.cm)

O9.52

O9.52

O12.7

O12.7

O15.9

O15.9

R0.4~0.8

45

2

90

4

A

o

o

1 Torque wrench
2 Flare nut
3 Piping union
4 Spanner

1 234

Align the centres of both flares and tighten the flare nuts 3 or 4
turns by hand. Then tighten them fully with the torque wrenches.

3.2 Refrigerant piping

Check whether the height drop between the indoor unit and
outdoor unit, and the length of refrigerant pipe meet the following
requirements:

Capacity

Btu/h( )

The type of models

Max.allowable
piping length

25m

50m

<15000

R410A inverter
Split type air
conditioner

Max.allowable
piping height

10m

25m

30m

65m

>15000~<24000

>24000~<36000

>36000~<60000

20m

30m

Cut exactly at
right angles.

Remove burrs.

Flare's inner surface
must be flaw-free

The pipe end must
be evenly flared in a
perfect circle.

Make sure that the
flare nut is fitted.

3) Put the flare nut on the pipe.

4) Flare the pipe.

Die

Copper pipe

A

Set exactly at the position shown below.

10

kaisai.com

3.3 Purging air and checking gas leakage

When piping work is completed, it is necessary to purge the
air and check for gas leakage.

WARNING

Do not mix any substance other than the specified refrigerant
into the refrigeration cycle.
When refrigerant gas leaks occur, ventilate the room as soon as
possible.
The specified refrigerant should always be recovered and never
be released directly into the environment.
Use a vacuum pump for the specified refrigerant. Using the
same vacuum pump for different refrigerants may damage the
vacuum pump or the unit.

If using additional refrigerant, perform air purging from the
refrigerant pipes and indoor unit using a vacuum pump, than
charge additional refrigerant.
Use a hexagonal wrench(4mm) to operate the stop valve rod.
All refrigerant pipe joints should be tightened with a torque
wrench at the specified tightening torque.

1) Connect projection side of charging hose (which comes from
gauge manifold) to gas stop valve's service port.

2) Full open gauge manifold's low-pressure valve (Lo) and
completely close its high-pressure valve (Hi)
(High-pressure valve subsequently requires no operation.)

3) Do vacuum pumping and make sure that the compound
pressure gauge reads -0.1MPa (-76cmHg).*1

4) Close gauge manifold's low-pressure valve (Lo) and sop
vacuum pump.
(Keep this state for a few minutes to make sure that the
compound pressure gauge pointer does not swing back.)*2

5) Remove caps from liquid stop valve and gas stop valve.

6) Turn the liquid stop valve's rod 90 degrees counterclockwise
with a hexagonal wrench to open valve.
Close it after 5 seconds, and check for gas leakage.
Using soapy water, check for gas leakage from indoor unit's
flare and outdoor unit's flare and valve rods.
After the check is complete, wipe all soapy water off.

7) Disconnect charging hose from gas stop valve's service port
then fully open liquid and gas stop valves.
(Do not attempt to turn valve rod byond its stop.)

8) Tighten valve caps and service port caps for the liquid and
gas stop valves with a torque wrench at the specified torques.

*1. Pipe length vs. Vacuum pump run time

3.5 Refrigerant pipig work

Pipe length and refrigerant amount:

Connective
pipe length

3.4 Additional refrigerant charge

CAUTION

Refrigerant may only be charged after performing the leak
test and the vacuum pumping.
Check the type of refrigerant to be used on the machine
nameplate. Charging with an unsuitable refrigerant may
cause explosions and accidents, so always ensure that the
appropriate refrigerant is charged.
Refrigerant containers shall be opened slowly.

The outdoor unit is factory charged with refrigerant. Calculate the
added refrigerant according to the diameter and the length of the
liquid pipe of the outdoor unit/indoor unit connection.

1) Caution on the pipe handling

Protect the open end of the pipe against dust and moisture.
All pipe bends should be as gentle as possible. Use a pipe
bender for bending.

Be sure to add the proper amount of additional refrigerant.
Failure to do so may result in reduced performance.

Pipe length Up to 15m More than 15m

Not less than 15minNot less than 10 minRun time

*2. If the compound pressure gauge pointer swings back,
refrigerant may have water content or a loose pipe joint may
exists. Check all pipe joints and retighten nuts as needed,
then repeat steps 2) through 4).

Be sure to
place a cap.

If no flare cap is
available, cover the
flare mouth with
tape to keep dirt or
water out.

Wall

Rain

Less
than 5m

More
than 5m

Air purging
method

Use vacuum
pump.

Use vacuum
pump.

Additional amount of refrigerant to be charged

R410A: (L-5)x15g/m

Liquid side: 6.35mm

R410A: (L-5)x30g/m

Liquid side: 9.52mm

11

kaisai.com

For local insulation, be sure to insulate local piping
all the way into the pipe connections inside the unit.
Exposed piping may cause condensation or may
cause burns when touched.

Make sure that no oil remains on plastic parts of the
decoration panel (optional equipment).
Oil may cause degradation and damage to plastic
parts.

1 Piping insulation material(field supply)
2 Flare nut connection
3 Insulation for fitting (field supply)
4 Piping insulation material (main unit)
5 Indoor unit
6 Clamp (field supply)

A Turn seams up
B Attach to base
C Tighten the part other than the piping insulation material

Piping insulation procedure

Gas piping Liquid piping

116

6

66445

5

3

3

2

2

A

A

C

C

B

B

2) Be sure to insulate both the gas and liquid piping. Use
separate thermal insulation pipes for gas and liquid
refrigerant pipes. See the figure below.

Inter-unit wire

Liquid pipe

Liquid pipe
insulation

Drain hose

Finishing tape

Gas pipe
insulation

Gas pipe

- Keep piping as short as possible and slope it downwards at a
gradient of at least 1/100 so that air may not remain trapped
inside the pipe.

- Keep pipe size equal to or greater than that of the connecting
pipe (PVC pipe, nominal diameter 20mm in, outside diameter
25mm).

- Push the drain hose as far as possible over the drain socket,
and tighten the metal clamp securely.

4 CONNECT THE DRAIN PIPE

- Insulate the drain hose inside the building.

- If the drain hose cannot be sufficiently set on a slope, fit the
hose with drain raising piping (field supply).

1 Drain socket (attached to the unit)
2 metal clamp
3 Drain hose
4 Insulation (field supply)

- Make sure that heat insulation work is executed on the
following 2 spots to prevent any possible water leakage due
to dew condensation.
1 Indoor drain pipe.
2 Drain socket.

1 2

3 4

Install the drain pipes.

1.5m~2m

Insulating
material

Downward declivity
lower than 1/100

Bend

S shape

Put as deep as possible
(about 10cm)

Downward declivity
lower than 1/100

Vp30

Drainage test

- Check whether the drainpipe is unhindered.

- New built house should have this test done before paving the ceiling.

12

kaisai.com

5 ELECTRIC WIRING WORK

General instructions

All field wiring and components must be installed by a licensed
electrician and must comply with relevant European and national
regulations.

Use copper wire only.

A circuit breaker capable of shutting down power supply to the
entire system must be installed.

Note that the operation will restart automatically if the main
power supply is turned off and then turned back on again.

Be sure to ground the air conditioner.

Do not connect the ground wire to gas pipes, water pipes,
lightning rods, or telephone ground wires.

- Gas pipes: might cause explosions or fire if gas leaks.

- Water pipes: no grounding effect if hard vinyl piping is used.

- Telephone ground wires or lightning rods: might cause
abnormally highelectric potential in the ground during
lightning storms .

Follow the 'Wiring diagram' attached to the unit body to wire the
outdoor unit, indoor units and the remote controller.

The specification of power

Minimum norminal cross-sectional
area of conductors:

Rated current
of appliance
(A)

Nominal cross-sectional
area
(mm2)

<6 0.75
>6 and <10 1.0
>10 and <16 1.5
>16 and <25 2.5
>25 and <32 4.0
>32 and <45 6.0
>45 and <60 10.0

NOTE:
The cable size and the current of the fuse or switch are determined by the
maximum current indicated on the nameplate which located on the side panel
of the unit. Please refer to the nameplate before selecting the cable, fuse and
switch.

MODEL( )Btu/h

55K 30K~36K 42K~55K42K~48K30K~36K24K18K

FREQUENCY AND VOLT

CIRCUIT BREAKER/FUSE(A)

FREQUENCY AND VOLT

PHASE

CIRCUIT BREAKER/FUSE(A)

PHASE

15/10 15/10 15/1015/1015/1015/1015/10

208-240V 380-415V 380-415V208-240V208-240V208-240V208-240V

1Phase 1Phase 1Phase1Phase1Phase1Phase1Phase

1Phase 3Phase 3Phase1Phase1Phase1Phase1Phase

50/40 30/20 30/2040/3540/3030/2030/20

220-240V 220-240V 220-240V220-240V220-240V220-240V220-240V

POWER
(indoor)

POWER
(outdoor)

13

kaisai.com

How to connect wiring

Precautions

Remove the control box lid of the indoor unit.
Remove the cover of the outdoor unit.

Follow the "Wiring diagram label" attached to the indoor unit's control box lid to wire the outdoor unit, indoor unit and the remote controller.
Securely fix the wires with a field supplied champ.

Attach the cover of the outdoor unit.

Observe the notes mentioned below when wiring to the power
supply terminal board.

Use the specified electric wire. Connect the wire securely to
the terminal. Lock the wire down without applying excessive
force to the terminal. (Tightening torque: 1.31N.m 10%).

- Do not connect wires of different gauge to the same power
supply terminal. (Looseness in the connection may cause
overheating.)

- When connecting wires of the same gauge, connect them
according to the figure.

1

- When attaching the control box lid, make sure not to pinch
any wires.

- After all wiring connections are done, fill in any gaps in the
casing wiring holes with putty or insulation material (field
supply) thus to prevent small animals or dirt from entering
the unit from outside and causing short circuits in the control
box.

Do not connect wires of different gauge to the same grounding
terminal. Looseness in the connection may deteriorate the
protection.

Use only specified wires and tightly connect wires to the terminals.
Be careful that wires do not place external stress on the terminals.
Keep wiring in neat order so that they do not obstruct other
equipment such as popping open the service cover. Make sure
the cover closes tight. Incomplete connections could result in

overheating, and in the worst case, electric shock or fire.

2

3

Cover

Bolts

1 Signal wire socket
2 Power supply terminal block
3 Clamp for wiring
4 Wiring between units

1

2

3

4

14

kaisai.com

1

2
3
4

5

6

7 TEST OPERA TION

Refer to ''For the following items, take special care during construction
and check after installation is nished'' on page 2.

After nishing the construction of refrigerant piping, drain piping, and
electric wiring, conduct test operation accordingly to protect the unit.

Test operation after installing decoration panel

Make sure the control box lids are closed on the indoor and outdoor
units.

Open the gas side stop valve.

Open the liquid side stop valve.
Electrify crank case heater for 6 hours.
Set to cooling operation with the remote controller and start
operation by pushing ON/OFF button.

Turn o the main power supply after operation.

Check the following points. If there is any malfunction, please
resolve it according to the chapter "Troubleshooting" in the
"Owner's Manual".

The indoor unit

- Whether the switch on the remote controller works well.

- Whether the buttons on the remote controller works well.

- Whether the air flow louver moves normally.

- Whether the room temperature is adjusted well.

- Whether the indicator lights normally.

- Whether the temporary buttons works well.

- Whether there is vibration or abnormal noise during operation.

- Whether the drainage flows smoothly.

The outdoor unit

- Whether there is vibration or abnormal noise during operation.

- Whether the generated wind, noise, or condensed of by the air

conditioner have influenced your neighborhood.

- Whether any of the refrigerant is leaked.

A protection feature prevents the air conditioner from being
activated for approximately 3 minutes when it is restar ted
immediately after shut o.

6 REFRIGERANT PIPE(the unit with the twins
function)

6.1 Length and drop height permitted of the refrige rant piping

Note: Reduced length of the branching tube is the 0.5m of the

equivalent length of the pipe.

Pipe length

Drop

height

PipingMax value

Total pipe length (Actual)

(farthest from the line pipe branch)
(farthest from the line pipe branch)
Indoor unit-outdoor unit drop height

Indoor unit to indoor unit drop height

L1-L210m

L+L1+L2

30m18K+18K

L1;L215m

H1
H2

20m

0.5m

50m

24K+24K/
30K+30K

9.5 0.030kg

6.35 0.015kg

H1<20m

H2<0.5m

L

L1

L2

The line branch pipe

Outdoor unit

Indoor unit

Indoor unit

Note : All used branch pipe must be produced by Kaisai,otherweise

it causes malfunction. The indoor units should be installed
equivalently at the both side of the U type branch pipe.

O
O

6.2 Refrigerant amount to be added

Calculate the added refrigerant according to the diameter and
the length of the liquid side pipe of the outdoor/indoor unit
connection. The refrigerant is R410A.

Pipe size on
liquid side

Refrigerant to be
added per meter

The branching pipe must be installed horizontally, error angle

o

of it should not large than 10 . Otherwise, malfunction will be
caused.

U-shaped branching pipe

A direction view

Horizontal surface

Wrong

Correct

15

kaisai.com

QSDLI-016AEN(CE)

The design and specifications are subject to change without prior notice for product

improvement. Consult with the sales agency or manufacturer for details.

QSDLI-016AEN(CE)

16122500000090

20150122

kaisai.com
