Page 1
Company: Kaba Ilco Corp
Rated voltage
DC 3V
Working current
<5mA
Operating voltage
1.8V~3.6V
Transmit power
>-20dbm
Key operation force
200±50g
Operating temperature
-5°C +45°C
Stand-by current
<1uA
transmitting frequency
433.92M±75KHZ
Modulation
ASK
Battery
CR2032
Key durability
More than 100,000 times
1 key: Unlock key
2 key: Lock key
3 key: Trunk key, used to
open/close the trunk
4. Key: Start key
Address: 400 Jeffreys Road Rocky Mount, NC 27804, United States
Name: Remote Key
Model: FBK-CHRY-7B1
Operation instructions
1. After matching the key to the car, press 1 the unlock key for 2 seconds to open the
door and press 2 the lock key for 2 seconds to close the door.
2. The ignition key is used to manually unlock and start the car.
Product parameters
Page 2
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
IC WARNING
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation,
Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject
to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause
undesired operation of the device
ADVERTENCIA IC
Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS)
d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis
aux
deux conditions suivantes :
(1) Cet appareil ne doit pas causer d'interférences.
(2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de
provoquer un fonctionnement indésirable de l'appareil.
