Jwin JX-CD477 User Manual

PORTABLE

COMPACT DISC PLAYER

WITH ANTI-SHOCK 10SEC.

OPEN

INSTRUCTION MANUAL

PLEASE READ CAREFULLY BEFORE USING YOUR UNIT

MODEL: JX-CD477

LOCATION OF CONTROLS

LCD DISPLAY

STOP BUTTON
(power off)

(NOT INCLUDED)

ADAPTOR JACK

VOLUME CONTROL

CD SKIP

DC IN 4.5V

LINE OUT JACK

PHONES JACK

RECHARGE

INDICATOR

BASS BOOST

ANTI-SKIP

CD MODE

HOLD

PROGRAM

RECHARGE

PLAY/PAUSE
(power on)

OPEN

DOOR OPEN

CONTROL OPERATION AND FUNCTION
POWER SUPPLY

Your CD player r equires 2 size “AA” alkaline batteries
(not included), or use the AC adaptor 4.5V 600mA
(not included)

AC ADAPTOR OPERATION

Plug one end of the AC adaptor into the DC 4.5V jack,
then plug the other end into AC wall outlet. (not included)

PRECAUTIONS ON USING THE AC ADAPTOR

Put in AC adaptor spec. Please make sure you purchase the correct AC adaptor.
Use of an incorrect AC adaptor will damage the unit.Don’t touch the AC adaptor with
wet hands. Doing so is dangerous, as this could result in an electric shock.
If the adaptor plug is insert into the DC Jack of the Player , the power supply automatically
switch to the AC/DC power and the batteries supply will be disconnected.

BATTERY DOOR

DC OPERATION

ALKALINE BATTERY INSTALLATION (NOT SUPPLIED)

Insert two AA batteries (not supplied) into the battery compartment on the bottom
of the unit. Be sure to observe the proper polarity.

CHARGING AND USE OF RECHARGEABLE BATTERIES

This unit can fully recharge the specified rechargeable batteries, in approximately
15 hours. The rechargeable batteries (NOT supplied) should be recharged before
they are used for the first time or they have not been used for a long period of time
(over 60 days).

1. Open the battery compartment cover and insert two of the recommended
rechargeable batteries, matching polarity. (1.2V 650mA).
ALL BATTERIES MUST BE OF RECHARGEABLE NICKEL-CADMIUM TYPE, OTHERWISE
THE BATTERIES MAY EXPLODE OR LEAK.

2. Plug in the AC adaptor. (not included)

E.1

3. Slide the charge switch to ON position to start charging. The charge indicator will
light up. USE ONLY THE AC ADAPTOR FOR CHARGING.

4. After 15 hours, please unplug the AC adaptor and slide the recharge switch to
OFF position.
DO NOT CHARGE CONTINUOUSLY FOR 24 HOURS OR MORE. DOING SO CAN CAUSE
THE PERFORMANCE OF THE RECHARGEABLE BATTERIES TO DETERIORATE.

NOTE: You may play DISC’S whilst char ging the batteries.
If the operating time decreases drastically even when the rechargeable nickel-cadmium
batteries are properly recharged, purchase a new set of rechargeable nickel-cadmium
batteries. When charging for the first time or after a long time, playing time may be
reduced. In this case, charge and discharge the batteries several times.

NOTE ON ALKALINE BATTERIES

1. When replacing the alkaline batteries, use two new batteries of the same type.
Do not mix a used battery with a new one or mix different types of batteries.

2. When inserting the batteries, be sure to place the batteries as the sketch shown,
mistakenly inserting even one with improper polarity will cause leakage and the
unit will not play properly.

3. When not using the unit for an extended period of time, or not using the batteries
for a long time, remove them to prevent possible acid leakage or corrosion re­sulting in damage to your player or personal injury such as skin burns.

4. Bear in mind that battery life expectancy is based upon playing mode. Maxi­mum battery power consumption happens at maximum settings. If sound gets
distorted or if the unit fails to switch tracks, your batteries are weak. Replace both
batteries, or use AC adaptor. (not included)

5. Never charge, heat, disassemble, or throw batteries into a fire.

6. If the display shows the symbol “
replace them or use the AC adaptor.

7. If the display is blank - no numbers show when power is turned on, the batteries
are dead.
Replace them or use the AC adaptor.

”, this means your batteries are weak,

AUTO POWER ON FUNCTION

The power turns on automatically when the PLAY/PAUSE button is pressed.

AUTO POWER OFF FUNCTION

When all the tracks on a disc have been played, or the Stop button is pressed, the
power turns off automatically within 60 seconds if no button is pressed.
If you pressed the Stop button twice the power will turn off

LISTENING WITH HEADPHONES/EARPHONES

Connect the plug of the stereo headphone/earphone into the headphone jack
(marked phones) before use the unit.

CAUTION: Hearing experts advise against exposure to continuous extended play at
loud volume levels while using headphones, possible hearing loss may result.
If you experience a ringing in the ears, reduce volume or discontinue use. We want
you listening for a life time.

PLAYING A DISC

Be sure to reduce the volume before plugging in or unplugging the headphones/
earphones

1. Plug the cord of headphone/earphone into the PHONES jack.

2. Slide the Door Open button to open the CD door.

E.2
