DVD PLAYER

XV-N410B/XV-N412S

VIDEO

Before operation

Preparations 4

Basic playback 8

Various kinds of playback 11

MP3/WMA disc playback 20

Region code of DVD VIDEO

This player can play back DVD VIDEO discs whose region code numbers include “1.”

Examples of playable DVD VIDEO discs:

ALL

The player’s region code is printed on the rear of the player.

INSTRUCTIONS

JPEG disc playback 22

Changing the initial settings 24

Additional information 29

For Customer Use:

Enter below the Model No. and Serial No. which are located on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No.

Se ria l No

GNT0044-001A

[J/UJ]

Page 2

Warnings, Cautions and Others

Mises en garde, précautions et indications diverses

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “”

dangerous voltage within the produc s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

For U.S.A.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

For Canada/pour le Canada

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQUAU FOND

For Canada / Pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS B LIMITS FOR RADIO NOISE EMISSIONS FORM DIGITAL APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,” ICES003 OF THE DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMERIQUE RESPECTE LES LIMITES DE BRUITS RADIOELECTRIQUES APPLICABLES AUX APPAREILS NUMERIQUES DE CLASSE B PRESCRITES DANS LA NORME SUR LE MATERIEL BROUILLEUR: “APPAREILS NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES COMMUNICATIONS.

G-1

t’

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le coffret de l’appareil.

Ne pas exposer l’appareil à la pluie ni à l’humidité.

Caution –– STANDBY/ON button!

Disconnect the mains plug to shut the power off completely (the STANDBY/ON lamp goes off). The STANDBY/ON button in any position does not disconnect the mains line.

•

When the player is on standby, the STANDBY/ON lamp lights red.

•

When the player is turned on, the STANDBY/ON lamp lights green.

The power can be remote controlled.

Attention –– Touche STANDBY/ON!

Déconnectez la prise d’allimentation secteur pour mettre l’appareil complètement hors tension (le témoin STANDBY/ON s’éteint). La touche STANDBY/ON, sur n’ importe quelle position, ne peut pas déconnecter l’appareil du secteur.

•

Quand l’appareil est en mode de veille, le témoin STANDBY/ON est

allumé en rouge.

•

Quand l’appareil est sous tension, le témoin STANDBY/ON est alumé

on vert.

L’alimentation peut être télécommandée.

IMPORTANT FOR LASER PRODUCTS IMPORTANT POUR PRODUITS LASER

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover. There are no user serviceable parts inside the unit; leave all servicing to qualified service personnel.

interlock failed or defeated. Avoid direct exposure to beam.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED INSIDE THE UNIT.

1. PRODUIT LASER CLASSE 1

2. ATTENTION: N’ouvrez pas le couvercle supérieur. Il n’y a aucune pièce réparable par l’utilisateur à l’intérieur de l’appareil; confiez toute réparation à un personnel qualifié.

3. ATTENTION: Risque de radiations laser visible et invisible quand l’appareil est ouvert et que le système de verrouillage ne fonctionne pas ou a été mis hors service. Évitez toute exposition directe au rayon.

4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE DE PRÉCAUTION PLACÉE À L’INTERIEUR DE L’APPAREIL.

3. CAUTION:

Visible and invisible laser radiation when open and

CAUTION:

• Do not block the ventilation openings or holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

• Do not place any naked flame sources, such as lighted candles, on

the apparatus.

• When discarding batteries, environmental problems must be consid-

ered and local rules or laws governing the disposal of these batteries must be followed strictly.

• Do not expose this apparatus to rain, moisture, dripping or splashing

and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

ATTENTION

• Ne bloquez pas les orifices ou les trous de ventilation.

(Si les orifices ou les trous de ventilation sont bloqués par un journal un tissu, etc., la chaleur peut ne pas être évacuée correctement de l’appareil.)

• Ne placez aucune source de flamme nue, telle qu’une bougie, sur

l’appareil.

• Lors de la mise au rebut des piles, veuillez prendre en

considération les problèmes de l’environnement et suivre strictement les règles et les lois locales sur la mise au rebut des piles.

•N

’

exposez pas cet appareil à la pluie, à l’humidité, à un égouttement ou à des éclaboussures et ne placez pas des objets remplis de liquide, tels qu

’

un vase, sur l’appareil.

Page 3

Supplied accessories

Check that you have all the following accessories supplied to you. If anything is missing, consult your dealer immediately.

• Audio/video cable (Yellow/White/Red) (× 1)

• Remote control unit (× 1)

• R6P(SUM-3)/AA(15F) battery (× 2)

• AC power plug adaptor (× 1) (for PX model ONLY)

About this manual

• The display window information and OSD (On Screen Display) menu items are put in brackets [ ] in the operation procedures.

• Usable disc(s) for each operation/function is (are) referred to by the icons;

Precautions

Notes on the power cord

• When you are away on travel or otherwise for an extended period of time, remove the plug from the wall outlet. A small amount of power (2.0 W) is always consumed while the power cord is connected to the wall outlet.

• When unplugging the unit from the wall outlet, always pull the plug, not the power cord.

• Do not handle the power cord with wet hands!

Avoid moisture, water and dust

• Do not place the unit in moist or dusty places.

• If water gets inside the unit, turn off the power and remove the plug from the wall outlet, then consult your dealer. Using the unit in this state may cause a fire or electrical shock.

Avoid high temperatures

• Do not expose the unit to direct sunlight or place it near a heating device.

Notes on installation

• Select a place which is level, dry and neither too hot nor too cold between 5°C and 35°C (41°F and 95°F).

• Leave sufficient distance between the player and the TV.

• Do not install the player in a place subject to vibrations.

• Do not put heavy objects on the player.

To prevent malfunction of the unit

• There are no user-serviceable parts inside. If anything goes wrong, unplug the power cord and consult your dealer.

• Do not insert any metallic objects, such as wires, hairpins, coins, etc. into the player.

• Do not block the vents. Blocking the vents may damage the player.

To clean the cabinet

• Use a soft cloth. Follow the relevant instructions on the use of chemically-coated cloths.

• Do not use benzene, thinner or other organic solvents and disinfectants. These may cause deformation or discoloring.

Table of contents

Supplied accessories................................................................1

About this manual .....................................................................1

Precautions ................................................................................ 1

Before operation................................................... 2

About discs ..............................................................................2

Names of parts and controls....................................................3

Preparations ......................................................... 4

Connections............................................................................. 4

Using the remote control unit................................................... 7

Basic playback ..................................................... 8

Turning the player on and off................................................... 8

Initial setup ..............................................................................8

Starting playback .....................................................................9

Restarting playback after stopping (resuming playback) .......10

Various kinds of playback ................................. 11

Playback at various speeds...................................................11

Locating the beginning of a scene or song............................12

Playing from a specific position .............................................12

Changing the playback order.................................................13

Repeat playback....................................................................15

Changing the language, sound and scene angle ..................15

Special picture and sound effects.......................................... 16

Menu bar functions ................................................................18

MP3/WMA disc playback ................................... 20

Operations .............................................................................20

JPEG disc playback ........................................... 22

About JPEG discs.................................................................. 22

Basic operations ....................................................................22

Viewing pictures continuously (slide show mode) .................23

Changing the initial settings ............................. 24

Selecting preferences............................................................24

Limiting playback by children................................................. 27

Additional information ....................................... 29

AV COMPU LINK remote control system ..............................29

Troubleshooting.....................................................................30

Specifications ........................................................................31

Appendix A: Country/Area code list for Parental Lock........... 32

Appendix B: Table of languages and their abbreviations ......32

Appendix C: Digital output signal chart.................................. 33

Appendix D: Glossary............................................................34

Page 4

Before operation

About discs

Playable disc types

Discs with the following marks can be played back on the player.

DVD VIDEO SVCD Video CD

VIDEO

The DVD Logo is a trademark. The player can also play back the following discs:

• DVD-R and DVD-RW discs written in the DVD VIDEO format and finalized

• CD-R and CD-RW discs written in the SVCD, Video CD or Audio CD format and finalized

• CD-R and CD-RW discs written in MP3 or WMA in accordance with the “ISO 9660” format (See page 20 for details.)

• CD-R and CD-RW discs written in JPEG in accordance with the “ISO 9660” format (See page 22 for details.)

NOTE

If a disc gets dirty, scratched or warped, or due to the disc characteristics or recording conditions, it may take considerable time for the unit to read the content, or the unit may not be able to play back such discs.

Audio CD

Digital audio formats

The player supports the following digital audio formats (see page 34 “Glossary” for descriptions of each audio format):

Linear PCM, Dolby Digital, DTS (Digital Theater Systems)

NOTE

Depending on the player’s [DIGITAL AUDIO OUTPUT] setting, digital audio signals may not be output as they are recorded on the disc. See “DIGITAL AUDIO OUTPUT” on page 26 for details.

Notes on discs

• With some DVD VIDEO discs, the player starts playback automatically after inserting the disc.

• The image may be sometimes poor or noisy due to defects in the disc itself.

• With some discs, operations described in this manual may not be possible.

Care and handling of discs

If a disc gets dirty, dusty, scratched or warped, playback sound and picture may be deteriorated. Take proper precautions when handling discs.

Handling

• Do not touch the surface of the disc.

• Do not damage, stick paper to, or use any adhesive on either the label side or playback side.

Storing discs

• Keep discs in their cases. If discs are piled on top of one another without their protective cases, they can be damaged.

• Do not put discs in a location where they may be exposed to direct sunlight, or where the humidity or temperature is high. Avoid leaving discs in a car!

Cleaning discs

• Wipe with a soft dry cloth, moving from the center outwards. If a disc is difficult to clean, wipe with a cloth moistened with water.

The player can play back audio signals recorded in MIX-MODE CD, CD-G, CD-EXTRA and CD TEXT.

Color system format

This player accommodates the NTSC system, and also can play back discs recorded with PAL system whose Region Code numbers include “1.” Note that the PAL video signal on a disc is converted to an NTSC signal and output.

Unplayable discs

The player does not play back discs listed below. If you try to play back these discs, noise may generate causing damage to speakers.

• DVD-RW discs written in the VR format

• DVD-ROM, DVD-RAM, DVD AUDIO, CD-ROM, PHOTO CD, SACD

In addition, the player does not play:

• Unfinalized discs.

• Discs of irregular shape or discs with tape, seals or paste on either the label side or playback side. Playing back these discs may damage the player.

• Never use record cleaners, petrol, alcohol or any anti-static agents.

Notes on copyright

Check the copyright laws in your country before recording from DVD VIDEO, SVCD, Video CD, Audio CD, MP3, WMA and JPEG discs. Recording of copyrighted material may infringe copyright laws.

Page 5

Names of parts and controls

0 -

5768

Remote control unit

Front panel

1 STANDBY/ON button (8) 2 STANDBY/ON indicator (8) 3 Disc tray (9) 4 0 button (9) 5 4 button (11, 12, 22) 6 ¢ button (11, 12, 22) 7 7 button (9,10) 8 3 button (9,10,11) 9 8 button (9, 11) 0 Display window (see the illustration below)

- Remote sensor (7)

3 45 6 7 8 9

Display window

2143

OPEN

/CLOSE

4 5

7 8

~ ! @

SLOW

ANGLE

STANDBY/ON

DISPLAY

213

546

879

010 +10

TITLE/GROUP CANCELRETURN

3D PHONIC

SUB TITLE

ENTER

SELECTCLEAR

REPEAT

AUDIO

NEXTPREVIOUS

SLOW+

VFP

PROGRESSIVE

SCAN

ZOOM

DIMMER

^ &

* (

)

£ ¢

1 Progressive mode indicators

[P] turns on in the progressive scanning mode. [DDP] turns on depending on the [PICTURE SOURCE] preference setting and the source type of the current DVD VIDEO disc (see page 5 for details).

2 Dolby Digital/DTS indicators

[Dolby D] turns on when playing back a Dolby Digital sound source. [DTS] turns on when playing back a DTS-encoded digital sound source.

3 Resume indicator

Turns on when playback is interrupted with the resume function activated.

4 Group/title/track/chapter indicators

Show what is indicated by the multi-information display during playback.

5 Repeat mode indicator

Turn on in the repeat playback mode and shows the currently selected repeat mode.

6 Program/random indicators

Turn on in the program playback mode/random playback mode respectively.

7 3 (play)/8 (pause) indicators

Turn on in the playback mode/pause mode respectively.

8 Multi-information window

Indicates various kinds of information by numbers and alphabets, such as the player’s current status (“READ,” “OPEN,” etc.) or currently played DVD’s title and chapter number.

1 DISPLAY button (9) 2 OPEN/CLOSE button (9) 3 Numeric buttons 4 RETURN button (12) 5 TOP MENU button (12) 6 Cursor selection (5 Up, ∞ Down) buttons 7 Cursor selection (2 Left, 3 Right) buttons 8 SET UP button (9, 24) 9 4/PREVIOUS button (11, 12, 22, 23) 0 7/CLEAR button (9, 14, 15, 21, 22, 23)

- 3/SELECT button (9, 10, 11, 14, 21, 23)

= 1/SLOW– button (11) ~ button (11)

! 3D PHONIC button (17) @ ANGLE button (16) # SUBTITLE button (15) $ Infrared signal window (7)

% STANDBY/ON button (8) ^ CANCEL button (14) & TITLE/GROUP button (13, 21, 23) * MENU button (12, 22, 23) ( ENTER button ) ON SCREEN button (9, 13, 14, 15, 18, 21, 23) _ ¢/NEXT button (11, 12, 22, 23) + 8 button (9, 11, 20, 23) ¡ ¡/SLOW+ button (11)

REPEAT button (15, 21, 23)

£ VFP - PROGRESSIVE SCAN button (5, 17) ¢ AUDIO button (16)

ZOOM button (16, 23) DIMMER button

Press to change the brightness of the display window. You can select the display window brightness from three levels or off. If the brightness is set to off, nothing will be shown on the display. By pressing this button, the brightness of the blue illumination around the disc tray also changes.

Page 6

Preparations

Before making connections

• Do not connect the AC power cord until all other connections have been made.

• Connect VIDEO OUT of the player directly to the video input of your TV. Connecting VIDEO OUT of the player to a TV via a VCR may cause a monitor problem when playing back a copy-protected disc. You may also have a monitor problem when connecting the player to an integrated TV/ Video system.

NOTE

If your TV has an AV COMPU LINK terminal, you can use the AV COMPU LINK function. See “AV COMPU LINK remote control system” on page 29 for details.

Connections

Before using the player, connect the player to a TV and/or amplifier.

Connecting to a TV

The following sections A to C describe TV connections where only a TV is connected to the player so that you will hear audio from the TV.

A Connecting to a conventional TV

REMOTE

480p 480i

Set the 480i/480p/REMOTE selector to “480i.”

• In the following description, “TV” may be substituted with

“monitor” or “projector.”

• Terminal names used for other components may be different

from those used in the following description.

NOTES

• Do not connect an S-video cable to the S-VIDEO output of the player. If you do so, you will not be able to obtain correct signals from the VIDEO jack of the player.

• If your TV has a monaural audio input instead of stereo, you need to use an optional audio cable which converts stereo audio output to monaural.

VIDEO

LEFT

AUDIO

RIGHT

PONENT

COM

DEO

AXIA

REA

AUDIO OU

PTI

DIGITAL

OUT

DEO

-V

Yellow

White

Red

PU L

V COM

Ye l l o w

The player

Audio/video cable (supplied)

B Connecting to a TV with an S-video jack

If your TV has an S-VIDEO input, you can get better picture quality by connecting it with the S-VIDEO output of the player using an S-video cable instead of connecting the video input of the TV to the VIDEO jack of the player.

REMOTE

480p

Set the 480i/480p/REMOTE selector to “480i.”

480i

Red

White

NOTE

To obtain correct signals from the S-VIDEO output, do not connect cables to the VIDEO jack and COMPONENT VIDEO OUT jacks of the player.

VIDEO

S-

VIDEO

LEFT

AUDIO

RIGHT

PONE

COM

DEO

AXIAL

AUDIO OU

IGITAL

OUT

VIDE

White

The player

Red

PU LIN

S-video cable (not supplied)

Audio cable (not supplied)

Red

Page 7

C Connecting to a TV with component jacks

You can enjoy picture of high-fidelity color reproduction by connecting the COMPONENT VIDEO OUT jacks on the player to your TV.

NOTES

• Connect “Y” to “Y,” “PB” to “PB” (CB), “PR” to “PR” (CR) correctly.

• When using the COMPONENT VIDEO OUT jacks, do not connect the S-VIDEO output jack on the player.

• If your TV has component video input jacks of BNC type, use an adapter which converts a pin jack to a BNC jack (not supplied).

Progressive scan video playback available

In the Progressive scanning mode, you can enjoy high quality picture with less flickers when the COMPONENT VIDEO OUT jacks are connected to a TV or monitor that supports the progressive video input.

Selecting the 480i/480p/REMOTE selector position

Hint

Depending on the source material format, DVD VIDEO discs can be classified into two types; film source and video source (note that some DVD VIDEO discs contain both film source and video source). Film sources are recorded as 24-frame-per-second information, while (NTSC) video sources are recorded as 30frame-per-second (60-field-per-second interlaced) information. When the player plays back a film source material, Progressive (uninterlaced) signals are created using the original information. When a video source material is played back, the unit interleaves lines between the interlaced lines on each to create the interpolated picture and outputs as the progressive signal.

480p 480i

REMOTE

• If your TV equipped with component jacks does not support the progressive scanning mode: Set the 480i/480p/REMOTE selector to “480i.”

• If your TV equipped with component jacks supports the progressive scanning

S-VIDEO

VIDEO

LEFT

AUD

RIGHT

COMPON

T IN

Red

Blue

The player

White

Green

mode:

480p 480i

REMOTE

Set the 480i/480p/REMOTE selector to “480p.”

• If you want to select the scanning mode between the interlace and progressive modes (depending on the source condition, or when

IO OUT

AUD

DIGITAL

OUT

Red

COMPONENT

VIDEO OUT

-V

White

COMPU LINK

Red

Blue

Component video cable (not supplied)

Audio cable (not supplied)

connecting more than one TV, etc.): Set the 480i/480p/REMOTE selector to “REMOTE.”

Red

Green

Thus you can select the mode from the remote control unit.

Activating the Progressive scanning mode using the remote control unit

When the player is turned on and the 480i/480p/REMOTE selector is set to “REMOTE,” press and hold down VFP PROGRESSIVE SCAN for a few seconds. The scanning mode switches between the Progressive scanning and Interlaced scanning modes. When the scanning mode is set to the Progressive mode, the [P] indicator lights up in the display window. [DD] also turns on when Progressive scanned signals on a DVD VIDEO disc are directly output as they are from the player. Depending on the [PICTURE SOURCE] preference display and whether the current DVD VIDEO disc is film-source or video-

NOTES

• The Progressive scanning mode works only when you connect the player’s COMPONENT VIDEO OUT jacks to your TV.

• There are some progressive TV and High-Definition TV sets that are not fully compatible with the player, resulting in the unnatural picture when playing back a DVD VIDEO disc in the Progressive scanning mode. In such a case, use the Interlaced scanning mode. To check the compatibility of your TV set, contact your local JVC customer service center.

• All JVC progressive TV and High-Definition TV sets are fully compatible with the player (Example: AV-61S902).

source, the indicator that lights up in the display window differs, as shown in the table below.

Setting of [PICTURE SOURCE]

AUTO [DDP] [P]

FILM [DDP] [DDP]

VIDEO (NORMAL)/ (ACTIVE)

Source type of DVD VIDEO

Film source Video source

[P] [P]

Page 8

Connecting to optional audio equipment

Connecting to a stereo audio amplifier/receiver

Connect the player’s AUDIO OUT (LEFT/RIGHT) jacks to any line-level inputs (such as AUX, DVD, CD, etc.) of an audio amplifier or receiver.

Amplifier or receiver

AUDIO

LEFT

RIGHT

White

The player

Red

-V

AUDIO OUT

IGITAL

OUT

PU L

PONE

O OUT

White

Red

Connecting to a digital audio device

You can enjoy sound of enhanced quality by connecting the player’s DIGITAL OUT (either OPTICAL or COAXIAL) jack to a digital input of an amplifier, etc., using an optical or coaxial digital cable. The digital audio signal on a disc will be transferred directly from the player. If the connected digital audio equipment is a Dolby Digital or DTS decoder or an amplifier with a built-in decoder, you can enjoy high-quality surround sound.

Digital equipment

LEFT

DVD

RIGHT

OPTICAL

DIG

COAXIAL

INK

Audio cable (not supplied)

NOTES

• Connect the player and the digital audio device by using either an optical digital cable or a coaxial digital cable.

• It is not recommended to use the digital jacks for dubbing. When recording the sounds (DVD VIDEO, SVCD, Video CD or Audio CD) played back on the player, record them through the analog jacks.

• Depending on the disc, no signal may be output from the DIGITAL OUT. Make an analog connection in this case.

• Set [DIGITAL AUDIO OUTPUT] in the [AUDIO] preference display correctly according to the connected digital audio equipment. If setting made for [DIGITAL AUDIO OUTPUT] is incorrect, loud noise may be generated causing damage to the speakers (see page 26).

The player

-V

IGITAL

OUT

COMPONENT

LINK

V COM

O OUT

Coaxial digital cable (not supplied)

Audio cable (not supplied)

Optical digital cable (not supplied)

Page 9

Connecting the power cord

When all the audio/video connections have been made, connect the AC power plug to the wall outlet. Make sure that the plugs are inserted firmly. The STANDBY/ON indicator lights in red.

NOTE

(only for PX model) Use the supplied AC power plug adaptor when inserting the larger plug to the wall outlet.

Warning

• Disconnect the power cord:

- if you are not going to use the player for a long time.

- before cleaning the player.

- before moving the player.

• Do not:

- connect or disconnect the power cord with wet hands.

- pull the power cord when disconnecting it, as this may damage the cord and cause fire, electric shock, or other accidents.

Caution

• Do not alter, twist or pull the power cord, or put anything heavy on it, which may cause fire, electric shock, or other accidents.

• If the cord is damaged, consult a dealer and have the power cord replaced with a new one.

Remote sensor

Point the top of the remote control unit toward the remote sensor as directly as possible. If you operate it from a diagonal position, the operating range (approx. 5 m) may be shorter.

Remote sensor

Using the remote control unit

To install batteries

Open the compartment cover, and place the two supplied R6P (SUM-3)/AA(15F) batteries in the remote control unit according to the polarity markings (“+” and “–”) inside the compartment. Then replace the cover.

The batteries will last about six months with normal use. If the functions of the remote control unit become erratic, replace the batteries.

Precautions of the safe use of batteries

Observe the following precautions for the safe use of batteries. If they are used improperly their lives will be shortened, they may burst or their contents may leak.

• Remove the batteries from the remote control unit if it is not going to be used for a long period of time.

• Remove dead batteries and dispose of them properly.

• Never leave dead batteries lying around, take them apart, mix them with other refuse, or throw them into an incinerator.

• Never touch liquid that has leaked out of a battery.

• Do not mix new and old batteries, or batteries of different types, when replacing them.

Page 10

Basic playback

STANDBY/ON indicator

STANDBY/ON

• REGION CODE ERROR! (The region code of the DVD VIDEO disc does not match the player. The disc cannot be played back.)

• OPEN (The disc tray is opening.)

• CLOSE (The disc tray is closing.)

• NO DISC (No disc is loaded.)

NOTE

Even if you turn off the player, the player is not disconnected from the AC power source as long as it is connected to the wall outlet. This state is called standby mode. In this state, the player consumes a very small amount of power.

Initial setup

7380

When you turn on the player for the first time after purchase, the following message appears on the TV screen.

EXECUTE DVD PLAYER SETUP? - BASIC PICTURE/AUDIO SETTING YES - PRESS ENTER NO - PRESS CANCEL

DISPLAY

OPEN/CLOSE

ENTER

SET UP

About invalid operation icon

When you press a button, and if the player does not accept its operation, appears on your TV screen. Operations are occasionally unacceptable even if is not displayed.

Note that some operations may not be accepted. For example, some discs may not allow rapid advance/reverse or slowmotion playback.

STANDBY/ON

5/∞/2/3

ON SCREEN

3 (SELECT) 8

Turning the player on and off

Press STANDBY/ON on the remote control unit or press STANDBY/ON on the front panel.

The STANDBY/ON indicator on the front panel, which lights in red during standby, lights in green. The blue illumination around the disc tray turns on.

The opening display appears on the TV screen, and the following messages may appear at the bottom of the opening display.

NOW READING

You can set the display language, TV monitor type and digital output before using the player, by following the procedure below.

1 Press ENTER.

The first page of the DVD PLAYER SET UP display appears. The pull-down menu of the [ON SCREEN LANGUAGE] is already open.

DVD PLAYER SET UP

MENU LANGUAGE

AUDIO LANGUAGE

SUBTITLE

ON SCREEN LANGUAGE

SELECT

ENTER

ENGLISH

OFF

ENGLISH

ENGLISH SPANISH FRENCH

USE 5∞23 TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

ON SCREEN LANGUAGE options

2 Press 5/∞ to select the desired language.

You can select the on-screen language for the preference displays, etc. from among ENGLISH, SPANISH and FRENCH.

3 Press ENTER.

The second page is shown, in which the pull-down menu of the [MONITOR TYPE] is already open.

DVD PLAYER SET UP

MONITOR TYPE

PICTURE SOURCE

SCREEN SAVER

MP3&WMA/JPEG

SELECT

ENTER

4:3 L.B.

16:9 NORMAL

AUTO

16:9 AUTO 4:3 LB

4:3 PS

MP3&WMA

USE 5∞23 TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

MONITOR TYPE options

4 Press 5/∞ to select the desired monitor type.

For a normal (conventional) TV, select [4:3 LB] or [4:3 PS]. For a wide-screen TV, select [16:9 NORMAL] or [16:9 AUTO]. (See page 25.)

Message area

• NOW READING (The player is reading the disc information.)

Page 11

5 Press ENTER.

The third page is shown, in which the pull-down menu of the [DIGITAL AUDIO OUTPUT] is already open.

DVD PLAYER SET UP

DIGITAL AUDIO OUTPUT

ANALOG DOWN MIX

D RANGE CONTROL

OUTPUT LEVEL

SELECT

ENTER

DIGITAL AUDIO OUTPUT options

DOLBY DIGITAL/PCM

PCM ONLY

DOLBY PROLOGIC

DOLBY DIGITAL/PCM STREAM/PCM

STANDARD

USE 5∞23 TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

6 Press 5/∞ to select a desired digital output

signal type.

Set this item correctly when you connect the player to an external surround decoder or D/A converter. (If you do not connect the player to such a device, you do not have to set this item.)

• When connecting to other digital device, select [PCM ONLY].

• When connecting to a Dolby Digital decoder, select [DOLBY DIGITAL/PCM].

• When connecting to a Dolby Digital decoder or a DTS decoder, select [STREAM/PCM].

7 Press ENTER.

The TV screen returns to the opening display.

To bring up the DVD PLAYER SET UP display later

Press SET UP for a few seconds until the DVD PLAYER SET UP display appears.

If a menu is shown on the TV screen

When inserting a DVD VIDEO, SVCD or Video CD disc, a menu may be shown on the TV screen. From the menu, you can select a desired item to be played back.

For DVD VIDEO

1Press 5/∞/2/3 to select a desired item. 2Press ENTER.

The player starts playback of the selected item.

For SVCD/Video CD

Press the numeric buttons to select a desired item. The player starts playback of the selected item.

NOTES

• Do not insert an unplayable disc. (See page 2.)

• When inserting a disc on the disc tray, be sure to position the disc inside the recess. Otherwise, the disc may be damaged when the disc tray is closed, or you may not be able to remove the disc from the player.

To check the playback status

You can see the current selection number (the title/chapter number for DVD VIDEO or track number for SVCD/Video CD/ Audio CD), time information (the track or chapter time while stopped, or elapsed track or chapter time during playback) and the transport status (stop, playback, pause, etc.) on the TV screen.

Press ON SCREEN.

Example: for DVD VIDEO

Transfer rate

8.5Mbps

Current chapter

number

TITLE 33 TOTAL 1:25:58CHAP 33

Current transport

status

Starting playback

1 Press 0 (or OPEN/CLOSE on the remote

control unit) to open the disc tray.

Current title number

Note that pressing ON SCREEN again brings up the menu bar under the status bar, from which you can access various functions. See page 18 for details about the menu bar.

To turn off the status bar

Press ON SCREEN repeatedly until the status bar goes off.

Disc elapsed

time

2 Place a disc in the disc tray.

To change the display window contents

With the label side up

• To insert an 8-cm disc, place it in the inner recess.

3 Press 0 (or OPEN/CLOSE on the remote

control unit) to close the disc tray.

4 Press 3 on the player or 3 (SELECT) on the

remote control unit.

The player starts playback from the beginning.

• Depending on the disc, playback starts when you close the disc tray.

Press DISPLAY.

Example: for DVD VIDEO Each time you press DISPLAY, the elapsed time display and the title/chapter number display appear alternately.

Elapsed time

Title number

Chapter number

To stop playback completely

Press 7.

Hint

If you press 0 during playback, the player stops playback and opens the disc tray.

To stop playback temporarily

Press 8.

To resume playback, press 3 (SELECT).

Page 12

3 (SELECT)

Restarting playback after stopping (resuming playback)

Changing the resume mode

The player has three resume modes; ON, OFF and DISC RESUME.

• You can select the mode using the preference display (see page 26).

When the resume mode is “OFF”

Playback always starts from the beginning.

When the resume mode is “DISC RESUME”

The player memorizes interrupted positions for the last 30 discs played. Storing a new interrupted position will erase the interrupted position stored for the first disc. The memory of the interrupted positions are not cleared even if you open the disc tray or turn off the player.

NOTES

• If you change the [RESUME] setting from [DISC RESUME] to [OFF] or [ON], you cannot resume playback of a disc whose “resuming” position is stored. However, when you again set [RESUME] to [DISC RESUME], you will then be able to resume playback of the disc.

• If you interrupt the playback of a disc for which an interrupted position has already been stored, the memory will be updated with the new interrupted position.

• For a double-sided DVD VIDEO disc, the player regards each side as a different disc. Therefore, to resume playback of such a disc, the disc must be inserted with the same side down.

• When the player memorizes an iterrupted point for a disc, it also memorizes Audio, Subtitle and Angle settings.

• The player may not resume playback exactly from the interrupted point. In the case of an SVCD/Video CD disc with PBC function, the player may resume playback from a point slightly earlier or later than the point where playback was interrupted.

The player resumes playback from the position you interrupted playback, as long as the disc you interrupted playback is still on the disc tray. This is because the player’s resume mode is set to ON when you purchased the player. When the resume mode is set to ON, the player memorizes the position on a disc where you interrupted playback.

• When you press 7 to interrupt playback, the TV screen shows [RESUME STOP] and the [RESUME] indicator lights up in the display window.

• When you re-start playback, the TV screen shows [RESUME PLAY].

Hint

The memory of the interrupted position is not cleared even if you turn off the player.

To play back from the beginning

Press 7 while the disc is stopped. The memory is cleared. Then press 3 (SELECT).

NOTES

• The player remembers the interrupted position even if you turn the power off.

• The memory is cleared if you open the disc tray.

About On-screen guide icons

You may see the following icons displayed over the picture. They have the following meanings.

: Appears at the beginning of playback mode.

: Appears at the beginning of pause mode.

: Appears at the beginning of fast forward/backward

playback with the current speed (see page 11).

: Appears at the beginning of slow-motion playback

with the current speed (see page 11).

: Appears at the beginning of a scene recorded from

multiple angles (see page 16).

: Appears at the beginning of a scene recorded with

multiple audio languages (see page 16).

: Appears at the beginning of a scene recorded with

multiple subtitle languages (see page 15).

You can change the setting so that the on-screen guide icons do not appear on the TV screen (see page 26).

About screen saver function

A television monitor may have an image burned into it if a static image is displayed for a long time. To prevent this, the player automatically activates the screen saver function if a static picture, such as an on-screen display or menu, is displayed while no button is pressed for over 5 minutes. When the screen saver function is activated, the TV screen gets darker. Pressing any buttons will release the screen saver function. You can set the screen saver function to ON or OFF (see page

25).

Page 13

Various kinds of

x1.5 Quick Playback with sound

playback

4¢

¢ 3 (SELECT) 8

When you select 1.5 times normal speed playback, the disc is played back with sound.

• For DVD VIDEO discs, the subtitle does not go off.

• At the x1.5 Quick Playback mode, the digital sound is output in stereo linear PCM format.

• To switch from rapid reverse playback to x1.5 Quick Playback, first press 3 (SELECT), then press ¡ once.

To advance a still picture frame by frame

While paused, press 8.

Each time you press 8, the still picture advances to the next frame. Pressing 3 (SELECT) returns to normal playback.

To play back in slow motion

You can select from 1/32 times, 1/16 times, 1/4 times and 1/2 times normal speed.

During playback, press 8, then press ¡ (to play forward slow motion), or 1 (to play reverse slow motion, for DVD VIDEO disc only).

Pressing 3 (SELECT) returns to normal playback.

NOTES

• During slow motion playback, the sound will be muted.

• Reverse slow motion playback is not possible for an SVCD and

Playback at various speeds

Video CD.

To replay the previous scenes

To advance or reverse playback rapidly

(One touch replay function)

while monitoring

During playback, press ¡ or 1 on the remote control unit.

You can select from 1.5 times, 5 times, 20 times and 60 times normal speed. Pressing 3 (SELECT) returns the player to normal playback.

During playback, hold down ¢ or 4.

Playback is advanced or reversed at 5 times normal speed.

NOTE

During rapid playback, the sound will be muted except when playing an Audio CD, and when playing a DVD VIDEO or Video CD at 1.5 times normal speed. For Audio CD discs, the sound will be heard intermittently.

During DVD VIDEO playback, press .

The playback position moves back 10 seconds before the current position.

NOTES

• This function works only within the same title, though it works between chapters.

• This function may not work with some DVD VIDEO discs.

Page 14

Numeric buttons

TITLE/GROUPRETURN

TOP MENU

5/∞/2/3

ENTER

ON SCREEN

¢ 3 (SELECT)

Locating the beginning of a scene or song

For DVD VIDEO: During playback, you can skip a chapter or title,

depending on the disc configuration.

For SVCD/Video CD: During playback without PBC function, you

can skip a track.

For Audio CD: During playback or while in stop mode, you can

skip a track.

To skip forward, press ¢.

To skip backward, press 4 twice.

Using the numeric buttons

For DVD VIDEO/Audio CD: During playback or while in stop

mode

For SVCD/Video CD: During playback without PBC function or

while in stop mode

Press the numeric buttons to specify the number.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

The player starts playback from the beginning of the selection.

NOTES

• Depending on the disc type and the unit status, what is specified differs:

Playing from a specific position

Locating a desired scene from the DVD menu

DVD VIDEO discs generally have their own menus which show the disc contents. These menus contain various items such as titles of movies, names of songs, or artist information, and display them on the TV screen. You can locate a desired scene using the DVD m enu.

1 While a DVD VIDEO disc is inserted, press

TOP MENU or MENU.

The menu appears on the TV screen.

2 Press 5/∞/2/3 to select a desired item, then

press ENTER or 3 (SELECT).

The player starts playback of the selected item.

Hints

• Some DVD VIDEO discs may also have a different menu which appears when MENU is pressed.

• See the instructions of each DVD VIDEO disc for its particular menu.

• With some discs, you can select items by entering the corresponding number using the numeric buttons, which may cause the player to automatically start playback.

NOTE

The MENU button does not work while stopped.

Locating a desired scene from the menu of a SVCD/Video CD with PBC

Some SVCD/Video CD discs support the PBC function. PBC is an abbreviation of “Playback Control.” Some SVCD/Video CD discs recorded with PBC have their own menus, such as a list of the songs of the disc. You can locate a specific scene by using the PBC menu.

1 In stop mode, press 3 (SELECT) or TOP

MENU.

A disc menu appears on the TV screen.

2 Press the numeric buttons to select the

desired item.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

Player status Disc type What is specified

While stopped DVD VIDEO title

SVCD/Video CD/Audio CD track

During playback DVD VIDEO chapter

• During DVD VIDEO playback, if a menu is shown on the TV screen, the numeric buttons may be used for selecting an item in the menu.

SVCD/Video CD/Audio CD track

The player starts playback of the selected item. To return to the menu, press RETURN.

Hint

If something like [NEXT] or [PREVIOUS] appears on the TV screen, pressing ¢ advances to the next page, and pressing 4 returns to the previous page.

Page 15

About PBC (Playback Control)

Some SVCD/Video CD discs support the PBC function. The PBC function allows you to enjoy menu-driven operation and high-resolution still images which have a resolution four times greater than moving pictures.

• To play a PBC-compatible SVCD/Video CD disc without

activating the PBC function, press the numeric buttons instead of 3 (SELECT) to start playback.

• To activate the PBC function again,

1) press TOP MENU or MENU, or

2) press 7 to stop playback, then press 3 (SELECT) .

Specifying a desired title/group

1 During playback, press TITLE/GROUP.

[--] is shown in the title display area of the display window.

2 Press the numeric buttons to specify a title or

group to be played.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

The player starts playback from the specified title or group.

NOTE

This function may not work with some DVD VIDEO discs.

Locating a desired position in the current title, group or track (Time search)

3 Press the numeric buttons (0 to 9) to enter

the desired time.

The specified time is displayed in the pull-down menu.

Example (for DVD VIDEO)

To play back from 2(H):34(M):00(S) Press 2, 3, then 4.

TIME 2:34 __:

Example (for SVCD/Video CD/Audio CD)

To play back from 23(M):40(S) Press 2, 3, then 4.

TIME 23 4_:

You do not have to press “0” to enter the trailing zeros (for the last two digits in the example above).

To correct a mistake

Press 2 repeatedly to move back to the digit where you entered a wrong number, and reenter the correct one.

4 Press ENTER.

The player starts playback from the specified time.

To dismiss the menu bar

Press ON SCREEN.

Hint

“10” and “+10” buttons are not used with this function.

NOTES

• Some DVD VIDEO discs do not contain time information, and the time search function cannot be used.

• The time search function cannot be used during program and random playback modes.

Changing the playback order

You can play a disc from the desired position by specifying the time from the beginning of the current title (for DVD VIDEO) or the disc (for SVCD/Video CD/Audio CD).

For DVD VIDEO/Audio CD: During playback or while in stop

mode

For SVCD/Video CD: In any condition except SVCD/Video CD

playback with PBC

1 Press ON SCREEN twice.

The menu bar appears on the TV screen.

2 Press 2/3 to move to , then press

ENTER.

The pull-down menu for entering time appears.

Screen example for DVD VIDEO

CHAP.

TITLE 33 TOTAL 1:25:58CHAP 33

1/3 1/3OFF 1/5

8.5Mbps

TIME _:__:__

To play back in a specific order (Program play)

By programming tracks, you can play up to 99 tracks in any order. You may program the same track more than once.

1 In stop mode, press ON SCREEN twice.

The menu bar appears on the TV screen.

2 Press 2/3 to move to .

Screen example for Audio CD

OFF PROG. RND.

PROG.

TIME 25:58TRACK 33

3 Press ENTER.

The program table appears. The [PROG] indicator lights up in the display window.

Page 16

Numeric buttons

CANCEL

5/∞/2/3

ENTER

ON SCREEN

3 (SELECT)

SUBTITLE

REPEAT

4 Press the numeric buttons to specify tracks

in the desired order.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

The total program time

To check the program contents

During playback, press 7. Playback stops and the program table is shown. When the player is playing back an Audio CD and the program table is not shown, you can bring up the table by carrying out steps 1 to 3. During SVCD/Video CD playback, you can check the program contents via the menu bar.

To stop program playback

Press 7.

To clear the program

While stopped and the program table is shown, press 7.

To exit the program mode

After clearing the program, press ON SCREEN.

NOTE

When the disc tray is opened or the player is turned off, the program is cleared.

To play back in random order (Random play)

PROGRAM

No. TrackDisc 1 2 1 2 3 5 3 7 4 4 4 2 5 3 3 6 5 4 7 6 6 8 9 10

USE NUMERIC KEYS TO PROGRAM TRACKS. CANCEL DELETES THE LAST STEP.

To correct the program

Press 5/∞ to move press CANCEL. The track is erased and the subsequent

programmed tracks move up. Pressing 7 clears all the programmed tracks.

Total Program Time 00:25:12

7 DELETES ALL.

Selected track number

to the track to be corrected, then

5 Press 3 (SELECT) to start program playback.

With an Audio CD disc, the program table remains on the TV screen during program playback. (Pressing ON SCREEN brings up the status bar.) When all of the programmed tracks have finished playback, the player stops and the program table appears again. Note that the program remains.

• During program playback, you cannot edit the program contents.

1 In stop mode, press ON SCREEN twice.

The menu bar appears on the TV screen.

2 Press 2/3 to move to .

Screen example for Audio CD

OFF PROG. RND.

RND.

TIME 25:58TRACK 33

3 Press ENTER.

The player starts random playback. With a SVCD/Video CD disc, the menu bar is automatically dismissed. During random playback, the [RND] indicator lights up in the display window. After playing all tracks of the disc, the player stops the disc and exits the random playback mode.

To stop and quit random playback

Press 7. The player stops playback and exits the random playback mode.

Page 17

Repeat playback

To repeat the current selection or all tracks

For DVD VIDEO: During playback For SVCD/Video CD/Audio CD: In any condition except SVCD/

Video CD playback with PBC

Press REPEAT.

If you press REPEAT in stop mode, press 3 (SELECT) to start playback. Each time you press REPEAT, the repeat mode cycles among All repeat, Repeat 1 and off. The indication on the display window shows the selected repeat mode.

: Repeats the current title for DVD VIDEO or all tracks

for SVCD/Video CD/Audio CD.

1: Repeats the current chapter for DVD VIDEO or the

current track for SVCD/Video CD/Audio CD.

No indication: The repeat mode is off.

A window which indicates the current repeat mode will be displayed on the TV screen. The mode indication on the window is same as the one on the menu bar. (Repeat mode example on the TV screen)

4 Press ENTER at the beginning of the part you

want to repeat (point A).

The pull down menu disappears. The repeat icon shows .

A-

5 Press ENTER at the end of the part you want

to repeat (point B).

The repeat icon shows . The player locates “A” and starts repeat playback between

“A” and “B.” The [ ] indicator lights in the display window.

A-B

To quit A-B repeat playback

Press 2/3 to move to , and press ENTER twice. The A-B repeat mode turns off, then normal playback continues.

NOTE

The A and B points must be set in the same title/track.

A-B

Changing the language, sound and scene angle

To select the subtitle language (SUBTITLE)

CHAP

Some DVD VIDEO and SVCD discs contain more than one

To stop repeat playback

Press 7. When a DVD VIDEO disc is set, the player stops playback and quits the repeat mode. When an SVCD, Video CD or Audio CD disc is set, the player stops playback but does not quit the repeat mode.

To quit repeat playback

Press REPEAT until the repeat mode indicator goes off in the display window.

Hint

When the program playback mode is active with an SVCD, Video CD or Audio CD, the repeat mode changes in the same manner.

Note, however, that in the “ ” mode the player repeats all the programmed tracks instead of all tracks on the disc.

NOTE

The repeat playback may not work with some discs, even if you select one of the repeat modes.

To repeat a desired part (A-B repeat playback)

First make sure:

• The player is in playback mode except SVCD/Video CD playback with PBC.

1 Press ON SCREEN twice.

The menu bar appears on the TV screen.

2 Press 2/3 to move to , then press

ENTER.

The pull-down menu for repeat mode selection appears.

3 Press 5/∞ to select [A-B].

subtitle language. You can choose a desired one from them.

Hint

At the beginning of a DVD VIDEO disc where subtitles are recorded, appears on the TV screen (except when the [ON SCREEN GUIDE] preference is set to [OFF]).

1 During playback, press SUBTITLE.

The subtitle selection window appears on the TV screen.

1/3

ENGLISH

2 Press 5/∞ or SUBTITLE to select the subtitle.

Each time you press 5/∞ or SUBTITLE, the subtitle language changes.

3 Press ENTER.

Subtitles are displayed in the selected language. The subtitle selection window is dismissed.

NOTES

• An SVCD disc can have up to four subtitles. Pressing 5/∞ cycles through those channels regardless of whether the subtitles are recorded or not.

• The subtitle selection window will automatically disappear if you do not change the subtitle for several seconds.

• For DVD VIDEO, the selected language may be abbreviated on the TV screen. See “Appendix B: Table of languages and their abbreviations” on page 32.

Page 18

5/∞/2/3

ENTER

VFP -

3D PHONIC

ANGLE

PROGRESSIVE SCAN ZOOM

AUDIO

To change the audio language or sound (AUDIO)

The audio selection setting allows you to change the audio language of a movie, or to listen to karaoke with or without the vocal.

Hint

At the beginning of the part where multiple audio tracks are recorded, appears on the TV screen (except when the [ON

SCREEN GUIDE] preference is set to [OFF]).

1 During playback, press AUDIO.

The audio selection window appears on the TV screen.

1/3

ENGLISH

To select a scene angle of DVD VIDEO (ANGLE)

You can enjoy a variety of scene angles if the DVD VIDEO disc contains “multi-angle” parts, where multiple cameras were used to shoot the same scene from different angles.

Hint

At the beginning of a “multi-angle” part, appears on the TV screen (except when the [ON SCREEN GUIDE] preference is set to [OFF]).

1 During playback, press ANGLE.

The angle selection window appears on the TV screen.

1/3

2 Press 5/∞ or ANGLE to select the desired

angle.

Each time you press 5/∞ or ANGLE, the angle changes.

3 Press ENTER.

You can see the picture from the selected angle. The angle selection window is dismissed.

NOTE

The angle selection window will automatically disappear if you do not change the angle for several seconds.

Special picture and sound effects

To zoom in pictures

2 Press 5/∞ or AUDIO to select the desired

audio.

Each time you press 5/∞ or AUDIO, the audio changes.

For DVD VIDEO (example)

1/3 ENGLISH 2/3 FRENCH 3/3 SPANISH

For SVCD

ST1 ST2 L- 1 R-1 L- 2 R-2

For Video CD

ST (Stereo) L R

3 Press ENTER.

You can hear the selected audio. The audio selection window is dismissed.

NOTES

• The audio selection window will automatically disappear if you do not change the audio for several seconds.

• For DVD VIDEO, the selected language may be abbreviated on the TV screen. See “Appendix B: Table of languages and their abbreviations” on page 32.

1 During playback or while paused, press

ZOOM.

Pressing ZOOM causes the player to zoom in on the image. At the top left of the screen, the information for the current magnification appears for about 5 seconds. Each time you press ZOOM, the magnification is doubled (1.8, 4, 8, 16, 32 and 64 times).

ZOOM x 4

When a picture of a DVD VIDEO disc is viewed on a normal TV screen (4:3, Letter Box), black bars may appear at the top and bottom of the screen. In this case, if you select the “ZOOM x1.8” mode, the black bars become almost invisible. When a 1:2.35 or 1:1.85 DVD VIDEO source is played back, however, the black bars are visible on the screen.

2 Press 5/∞/2/3 to move the zoomed position.

To return to the normal playback

Press ENTER.

NOTE

While zoomed, the picture may look coarse.

Page 19

To adjust the picture character (VFP)

4 Press ENTER.

A window for setting parameters appears.

SATURATION + 4

The VFP (Video Fine Processor) function allows you to adjust the picture character according to the type of programming, picture tone or personal preferences.

1 During playback, press VFP - PROGRESSIVE

SCAN.

The VFP mode selection window appears on the TV screen.

2 Press 2/3 to select the desired preset.

Each time you press the button, the VFP mode changes as follows. Set the video type most suitable to the current program or the room conditions.

NORMAL CINEMA USER 1 USER 2

Selected preset

USER 1

DNR

DIGIPURE

GAMMA

BRIGHTNESS

CONTRAST

SATURATION

TINT

SHARPNESS

Parameter

[NORMAL]: for watching TV in a general room. [CINEMA]: for watching a movie software in a room with

suppressed light.

[USER 1] [USER 2]: you can adjust parameters that affect

the picture character and store the settings as a user preset. See the next step.

+ 0

+ 3

3 To define a user setting, press 5/∞ to select

a parameter to be edited from the following.

• DNR (Digital Noise Reduction) Adjust this if you notice “mosquito noise” (noise that randomly appears along the edges of digitally compressed pictures). Available range: 0 to +1.

• DIGIPURE Adjust this if you want to enhance clarity of pictures. Available range: 0 to +3.

• GAMMA

Adjust this if the neutral color is bright or dark. The brightness of dark and bright portion is maintained. Available range: –4 (darkest) to +4 (brightest).

• BRIGHTNESS

Adjust this if the picture is bright or dark on the whole. Available range: –16 (darkest) to +16 (brightest).

• CONTRAST

Adjust this if the far and near position is unnatural. Available range: –16 to +16.

• SATURATION

Adjust this if the picture is whitish or blackish. Available range: –16 (blackest) to +16 (whitest).

•TINT

Adjust this if the appearance of flesh tone is unnatural. Available range: –16 to +16.

• SHARPNESS

Adjust this if the picture is indistinct. Available range: 0 to +3.

Selected parameter

5 Press 5/∞ to adjust the level of the

parameter.

The higher value enhances the effect.

6 Press ENTER.

Repeat steps 3 to 6 if you want to set other parameters.

To dismiss the VFP mode selection window

Press VFP - PROGRESSIVE SCAN.

NOTE

The window for VFP mode selection and parameter setting disappear if no operation is made for about 10 seconds.

To simulate surround sound (3D PHONIC)

Using the 3D PHONIC function, you can get a simulated surround effect from your stereo system.

1 During playback, press 3D PHONIC.

The 3D PHONIC window appears on the TV screen.

2 Press 2/3 to select the desired mode.

Each time you press the button, the 3D PHONIC mode changes as follows:

ACTION DRAMA THEATER NONE

+ 5ACTION 4

Selected effect mode

•ACTION

Suitable for action movies and sports programs in which the sound source moves.

•DRAMA

Natural and warm sound. You can enjoy movies in a relaxed mood.

•THEATER

You can enjoy sound effects like in a theater.

3 Press 5/∞ to adjust the effect level.

You can set the effect level from [1] to [5]. The higher value enhances the effect.

To dismiss the 3D PHONIC window

Press 3D PHONIC.

NOTES

• The 3D PHONIC window disappears if no operation is made for about 10 seconds.

• The 3D PHONIC function works correctly only when playing back a DVD VIDEO disc recorded with Dolby Digital.

• When playing back a DVD VIDEO disc recorded with Dolby Digital that does not contain the rear signal, you can change the 3D PHONIC setting, but you will not be able to achieve a correct 3D effect.

• The 3D PHONIC function does not affect the Dolby Digital bitstream signal from the DIGITAL OUT jack.

• When the 3D PHONIC function is active, the [ANALOG OUT] setting in the [AUDIO] setting display is not available.

Page 20

Numeric buttons

5/∞/2/3

ENTER

ON SCREEN

Menu bar functions

To bring up the menu bar

1 When a disc is inserted, press ON SCREEN.

A status bar for the type of disc inserted will appear on the TV screen. See page 9 for details about the status bar.

2 Press ON SCREEN again.

A menu bar for the type of disc inserted will appear under the status bar.

(for DVD VIDEO)

CHAP.

TITLE 33 TOTAL 1:25:58CHAP 33

1/3 1/3OFF 1/5

8.5Mbps

Basic operation procedure

1 Press 2/3 to select the icon you want to

work with.

The selected icon is pointed by .

2 Press ENTER.

With many icons, an appropriate pull-down window appears, however, there are some exceptions.

NOTES

• A mark or text on the menu icon for the function or mode currently selected is shown in green.

• Some functions are not available during playback. (You cannot move to the associated icon when it is not available.)

(for SVCD)

OFF

(for Video CD)

OFF

(for Audio CD)

OFF PROG. RND.

PROG. RND.

To dismiss the menu bar and status bar

Press ON SCREEN.

ST1

STPROG. RND.

TIME 25:58TRACK 33

-/4

TIME 25:58TRACK 33

Page 21

Menu bar functions for DVD VIDEO

Time mode selection

During playback, selects the time mode shown in the display window and in the status bar.

Press ENTER to select the time mode from the following.

• TOTAL: Current title elapsed time

• T.REM: Current title remaining time

• TIME: Current chapter elapsed time

• REM: Current chapter remaining time

Repeat mode (See also page 15)

Selects the repeat mode during playback.

1. Open the pull-down window.

2. Press 5/∞ to select the repeat mode from the following.

• CHAPTER: Current chapter repeat

• TITLE: Current title repeat

• A-B: A-B repeat

• OFF: Repeat mode deactivated

3. Press ENTER to make the selected repeat function active.

Time search (See also page 13)

Specifies a time from the beginning of the current title as the point from which to begin playback.

CHAP.

During playback, specifies a desired chapter to be played back from.

1. Open the pull-down window.

2. Press numeric buttons (0 to 9) to enter a desired chapter

3. Press ENTER to begin playback from the specified chapter.

During playback, selects the audio language or sound track.

1. Open the pull-down window.

2. Press 5/∞ to select a desired audio language or sound track.

3. Press ENTER to begin playback with the selected audio.

During playback, selects the subtitle language.

1. Open the pull-down window.

2. Press 5/∞ to select a desired subtitle language.

3. Press ENTER to begin playback with the selected subtitle.

Chapter search

number. (For example, to specify “10,” press 1, then 0.)

Audio selection (See also page 16)

Subtitle selection (See also page 15)

Menu bar functions for SVCD/Video CD/ Audio CD

Time mode selection

Selects the time mode shown in the display window and in the status bar.

Press ENTER to select the time mode from the following.

• TIME: Current track elapsed time

• REM: Current track remaining time (while in stop mode,

• TOTAL: Disc elapsed time

• T.REM: Disc remaining time (while in stop mode, disc total time)

Selects the repeat mode.

1. Open the pull-down window.

2. Press 5/∞ to select the repeat mode from the following.

3. Press ENTER to make the selected repeat function active.

Specifies a time from the beginning of the disc as the point from which to begin playback.

PROG.

While stopped, specifies the playback order of tracks.

While stopped, activates random playback.

During SVCD/Video CD playback, selects the audio channel(s).

1. Open the pull-down window.

2. Press 5/∞ to select a desired audio channel(s).

3. Press ENTER to play back with the selected audio channel(s).

During SVCD playback, selects the subtitle.

1. Open the pull-down window.

2. Press 5/∞ to select a desired subtitle.

3. Press ENTER to begin playback with the selected subtitle.

current track total time)

Repeat mode (See also page 15)

• TRACK: Current track repeat

• ALL: All track repeat

• A-B: A-B repeat

• OFF: Repeat mode deactivated

Time search (See also page 13)

Program playback (See also pages 13 and 14)

RND.

Random playback (See also page 14)

Audio selection (See also page 16)

Subtitle selection (See also page 15)

Angle selection (See also page 16)

During playback, selects a desired scene angle in a multi-angle part.

1. Open the pull-down window.

2. Press 5/∞ to select a scene angle.

3. Press ENTER to begin playback with the selected scene angle.

Page 22

MP3/WMA disc playback

Notes for making your own MP3/WMA disc using a CD-R/CD-RW disc

• Select “ISO 9660” as the disc format.

• As for MP3 files, we recommend you to record your material at a 44.1 kHz sampling rate, using the 128 kbps data transfer rate.

• As for WMA files, make sure that the copyright feature is set to off.

• As for WMA files, we recommend you to record your material at a bit rate of 64 kbps or higher.

Basic operations

Use the following buttons to control MP3/WMA disc playback.

Numeric buttons

TITLE/GROUP

5/∞/2/3

ENTER

3 (SELECT)

ON SCREEN

¢ 8

REPEAT

Operations

The player can play back MP3 files and WMA files on a home recorded CD-R/RW disc or commercially available CD. We refer to a disc that contains MP3 and/or WMA files as an “MP3/WMA disc” in this manual. Note that if a disc contains both of MP3/WMA files and JPEG files, you can only play back files of the type selected by the [MP3&WMA/JPEG] setting in the [PICTURE] preference display (see page 26).

About MP3/WMA discs

On an MP3/WMA disc, each song is recorded as a file (track). Files are sometimes grouped into folders by artists, album, etc.

• Each file is regarded as a track.

• A folder which has one or more files is regarded as a group.

• A folder which does not directly contain any tracks is ignored.

• Files which do not belong to any folder are grouped into “group

1.”

• The player recognizes up to 150 tracks per group, and up to 99 groups per disc. If there are files other than MP3/WMA files, they also count in the 150-file total.

Max. 99 groups per disc

Track 1.mp3 Track 2.mp3 Track 3.mp3

Group 2

Group 4

Max.150 tracks per group

Group 1

Tra c k 4. m p3 Tra c k 5. m p3 Tra c k 6. m p3

Group 3

ENTER: Starts playback while stopped.

3 (SELECT): Starts playback while stopped or paused. 7: Stops playback. 8: Pauses playback. 4/¢: Skips back or forward a track during playback.

Selects the previous or next track while stopped.

If you press 3 (SELECT) during playback, or press 7 to stop playback followed by 3 (SELECT), the player starts playback from the beginning of the current track.

NOTES

• The player does not support “packet writing (UDF file)” discs.

• The player does not support the ID3 tag and WMA tag.

• The player supports discs recorded with multiple sessions.

• Some discs may not play due to disc characteristics or recording conditions.

• Programmed and random playback functions do not work with MP3/WMA discs.

• As for MP3, the player only can play back tracks with the following file extensions; “.MP3,” “.Mp3,” “.mp3” and “.mP3.”

• As for WMA, the player only can play back tracks with the following file extensions; “.WMA,” “.wma,” and any other combination of upper case and lower case letters (such as “.Wma”).

• Time required for reading the disc contents may vary for different discs, depending on the numbers of groups (folders) and tracks (files) recorded, etc.

• You cannot advance or reverse playback by pressing ¡ or 1, or by holding down ¢ or 4 during MP3/WMA disc playback.

• The player supports WMA files recorded with a bit rate of 48 kbps or higher. The player cannot play back WMA files recorded with a bit rate under 48 kbps.

Selecting the desired group and track

When inserting an MP3/WMA disc, after the disc contents are read, the MP3/WMA CONTROL display automatically appears on the TV screen. You can specify the desired group/track from the display using the following procedure.

1 Make sure that the black (cursor) bar is in the

left (group) column.

If it is in the right column, press 2 to move it to the left column.

2 Press 5/∞ to move the bar to a desired

group.

On the right column, tracks in the selected group are shown.

Page 23

3 Press 4/¢ to select a desired track, then

press ENTER or 3 (SELECT).

Press the numeric buttons to directly specify a desired track number.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

The player starts playback from the selected track.

Current track elapsed time

MP3/WMA CONTROL Group : 01 / 10 spring

summer fall winter sea mountain camp picnic skiing flower

Time : 00:03:08 Track : 01 / 06 (Total 28) begonia.mp3

german chamomile.mp3 kiwi fruit.mp3 orchard grass.mp3 petunia.mp3 north pole.mp3

Repeat playback

During playback or while stopped, press REPEAT.

Each time you press REPEAT, the repeat mode changes as follows. If you press REPEAT while stopped, you need to press ENTER or 3 (SELECT) to start repeat playback.

MP3/WMA CONTROL

Display

window

display

REPEAT TRACK

REPEAT GROUP Repeats all tracks in

REPEAT ALL Repeats all tracks on

No indication The repeat mode is off.

(CONTROL display)

Selected repeat mode

Function

Repeats the current track.

the current group.

the disc.

Group column

Track column of the

Selected track

current group

Hint

You can also select a desired track by pressing 3 to move the black bar to the right (track) column then using 5/∞.

NOTES

• If an MP3/WMA file name includes any 2-byte character, the player cannot show the file name correctly.

• Only MP3/WMA files are shown on the MP3/WMA CONTROL display.

• The order of groups/tracks shown in the MP3/WMA CONTROL display may differ from the order shown on your personal computer when you set the disc on your computer.

Direct selection

You can select a desired group directly by specifying the group number.

1 During playback or while stopped, press

TITLE/GROUP.

[--] is shown in the group display area of the display window.

2 Press the numeric buttons to specify a

desired group number.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

MP3/WMA CONTROL REPEAT TRACK Group : 01 / 10

spring

summer fall

Track : 01 / 06 (Total 28)

begonia.mp3

german chamomile.mp3 kiwi fruit.m

To stop repeat playback

Press 7. Note that the repeat mode remains active.

To quit repeat playback

During playback, press REPEAT until no repeat icon is shown on the display window. While stopped, press REPEAT until repeat mode indication on the MP3/WMA CONTROL display goes off.

NOTE

You can change the repeat mode using ON SCREEN on the remote control unit. Press ON SCREEN, and the repeat mode selection window appears on the TV screen. Press then 5/∞ to select the desired repeat mode, and finally press ENTER to make the selected repeat mode active.

Specify the group number within several seconds after pressing TITLE/GROUP (i.e. while the display window shows [--]). The player starts playback from track 1 of the selected group.

3 Press the numeric buttons to specify a

desired track number.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10. The player starts playback from the specified track.

Page 24

JPEG disc playback

Numeric buttons

ENTER

5/∞/2/3

3 (SELECT)

TITLE/GROUP MENU

ON SCREEN

¢4 87

REPEAT ZOOM

Notes for making your own JPEG disc using a CD-R/ CD-RW disc

• Select “ISO 9660” as the disc format.

• We recommend you to record your material at a 640 x 480 pixel resolution.

• This player supports the baseline JPEG format.

Basic operations

To see a desired picture

When inserting a JPEG disc, after the disc contents are read, the JPEG CONTROL display automatically appears on the TV screen.

JPEG CONTROL Group : 01 / 10 spring

summer fall winter sea mountain camp picnic skiing flower

File : 01 / 06 (Total 28) begonia.jpg

german chamomile.jpg kiwi fruit.jpg orchard grass.jpg petunia.jpg north pole.jpg

The player can play back JPEG files on a home recorded CD-R/ RW disc. We refer to a disc that contains JPEG files as a “JPEG disc” in this manual. Note that if a disc contains both of MP3/WMA files and JPEG files, you can only play back files of the type selected by the [MP3&WMA/JPEG] setting in the [PICTURE] preference display (see page 26).

About JPEG discs

On a JPEG disc, each picture is recorded as a file. Files are sometimes grouped into folders by category, etc.

• A folder which has one or more files is regarded as a group.

• A folder which does not directly contain any files is ignored.

• Files which do not belong to any folder are grouped into “group

1.”

• The player recognizes up to 150 files per group, and up to 99 groups per disc. If there are files other than JPEG files, they also count against the 150-file total.

Max. 99 groups per disc

File 1.jpg File 2.jpg File 3.jpg

Group 1

You can select a desired file for playback via this display.

1 Make sure that the black (cursor) bar is in the

left (group) column.

If it is in the right column, press 2 to move it to the left column.

2 Press 5/∞ to move the bar to a desired

group.

On the right column, files in the selected group are shown.

3 Press 4/¢ to select a desired file, then

press ENTER.

The selected file (still picture) is shown on the TV.

Hint

You can also select a desired file by pressing 3 to move the black bar to the right (file) column then using 5/∞.

NOTE

If the selected file is unplayable, a black screen appears.

To display another picture

Press 4/¢ or 5/∞ to select the desired picture.

To dismiss the picture

Press 7 or MENU. The TV screen returns to the JPEG CONTROL display.

Group 2

Group 4

Max.150 files per group

File 4.jpg File 5.jpg File 6.jpg

Group 3

Page 25

NOTES

• The player supports the baseline JPEG format.

• The player does not support “packet writing (UDF file)” discs.

• The player supports discs recorded with multiple sessions.

• The player may not be able to read some discs, or may take a long time to display a picture on the disc, due to disc characteristics, recording conditions, or numbers of groups (folders), etc.

• Programmed and random playback functions do not work with JPEG discs.

• The screen saver function will be activated if the same picture is displayed for more than 5 minutes except during slide show playback.

• The player only can play back files with the following file extensions; “.jpg,” “.jpeg,” “.JPG,” “.JPEG” and any other combination of upper case and lower case letters (such as “.Jpg”).

• If a JPEG file name includes any 2-byte character, the player may not show the file name correctly.

• If a picture has been saved at greater than 640 x 480 pixel resolution, it may take some time to display the picture.

• The player does not support pictures of more than 2400 pixels in horizontal resolution. Make sure that the horizontal resolution of the picture is 2400 pixels or less.

To zoom in the picture

1 While in pause mode, press ZOOM.

Pressing ZOOM causes the player to zoom in on the image. Each time you press ZOOM, the manginication is doubled (1.8, 4, 8, 16, 32 and 64 times).

2 Press 5/∞/2/3 to move the zoomed position.

To select the start point of the slide show

From the JPEG CONTROL display

1 Make sure that the black (cursor) bar is in the

left (group) column.

If it is in the right column, press 2 to move it to the left column.

2 Press 5/∞ to move the bar to a desired

group.

3 Press 4/¢ to select a desired file. 4 Press 3 (SELECT).

The slide show starts from the specified file.

Direct selection

1 During playback or while stopped, press

TITLE/GROUP.

2 Press the numeric buttons to specify a

desired group number.

To select 5: press 5. To select 23: press +10, +10, then 3. To select 40: press +10, +10, +10, then 10.

3 Press the numeric buttons to specify a

desired file number.

The player starts slide show playback from the specified file. If you do not specify a file, the player starts slide show playback from the first file in the group.

Viewing pictures continuously (slide show mode)

You can see files (still pictures) one after another automatically.

Repeat function

In the slide show mode, you can repeat playback of JPEG files in a group or on the disc.

1 While the JPEG CONTROL display is shown,

To start the slide show

Press 3 (SELECT).

The slide show starts from the beginning of the disc. Each file (still picture) is displayed for approximately 3 seconds.

To stop slide show playback in the middle

Press 7 or MENU. The TV screen returns to the JPEG CONTROL display. Pressing 3 (SELECT) resumes slide show playback from the last picture displayed.

To keep showing the current picture

Press 8 or ENTER. Pressing 3 (SELECT) resumes the slide show playback.

press REPEAT.

Pressing REPEAT switches the repeat mode. When the repeat mode is turned on, the [ ] indicator lights

in the display window. The selected repeat mode is shown on the JPEG CONTROL display. REPEAT ALL: All files on the disc are repeated. REPEAT GROUP: All files in the current group are repeated. No indication: The repeat mode is off.

2 Press 3 (SELECT) to start repeat playback.

To stop repeat playback

Press 7. The repeat mode remains active.

To quit repeat playback

Press 7 or MENU while the JPEG CONTROL display is shown, and press REPEAT until the repeat mode indication goes off.

NOTE

You can change the repeat mode using ON SCREEN on the remote control unit. Press ON SCREEN, and the repeat mode selection window

appears on the TV screen. Press then repeat mode, and finally press ENTER to make the selected repeat mode active.

5/∞ to select the desired

Page 26

Changing the initial settings

5/∞/2/3

SET UP

ENTER

OTHERS

RESUME

ON SCREEN GUIDE

AUTO STANDBY

AV COMPULINK MODE

PARENTAL LOCK

SELECT

ENTER

OFF

DVD1

5∞23

USE

TO SELECT, USE ENTER TO CONFIRM

TO EXIT, PRESS SETUP.

How to set preferences

1 Press SET UP.

One of the preference on-screen displays appears on the TV screen. You can see four icons at the top right of the on-screen display for the settings.

: LANGUAGE menu : PICTURE menu : AUDIO menu : OTHERS menu

2 Press 2/3 to select the appropriate icon.

The appropriate display appears on the TV screen.

3 Press 5/∞ to move to select the item you

want to edit.

The color of the selected item changes.

4 Press ENTER.

A pull-down menu appears over the selected item.

Selecting preferences

This section refers to the settings which are already made when you purchase the player. Read this section when you want to connect this player to a wide-vision TV set, or when you want to otherwise change the settings according to your preferences and viewing environment.

About the Preference display

The Preference display consists of the LANGUAGE, PICTURE, AUDIO, and OTHERS setting displays, each having setting items.

LANGUAGE

MENU LANGUAGE

AUDIO LANGUAGE

SUBTITLE

ON SCREEN LANGUAGE

SELECT

ENTER


MONITOR TYPE

PICTURE SOURCE

SCREEN SAVER

MP3&WMA/JPEG

SELECT

ENTER

AUDIO

DIGITAL AUDIO OUTPUT

ANALOG DOWN MIX

D RANGE CONTROL

OUTPUT LEVEL

SELECT

ENTER

ENGLISH

OFF

ENGLISH

5∞23

USE

TO SELECT, USE ENTER TO CONFIRM

TO EXIT, PRESS SETUP.

4:3 LB

AUTO

MP3&WMA

5∞23

USE

TO SELECT, USE ENTER TO CONFIRM

TO EXIT, PRESS SETUP.

STREAM/PCM

STEREO

NORMAL

STANDARD

USE 5∞23 TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

LANGUAGE

MENU LANGUAGE

AUDIO LANGUAGE

SUBTITLE

ON SCREEN LANGUAGE

SELECT

ENTER

ENGLISH

OFF

ENGLISH

ENGLISH SPANISH FRENCH

USE 5∞ TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

Selected item

5 Press 5/∞ to select from the options then

press ENTER.

The selected option is set.

• For details about each setting, see the following.

To dismiss a preference display

Press SET UP.

NOTES

• While an MP3/WMA or JPEG disc is inserted, you cannot bring up any preference display.

• When a preference display is shown on a wide TV screen, the upper and lower parts of the preference display sometimes may be cut off. If this happens, adjust the picture size control of the TV.

Page 27

[16:9 AUTO] (Wide television screen): select when you

LANGUAGE menu

connect the player to a wide-screen (16:9) TV.

MENU LANGUAGE

You can select the default menu language to be displayed if it is contained on a DVD VIDEO disc.

Setting options

ENGLISH, SPANISH, FRENCH, CHINESE, GERMAN, ITALIAN, JAPANESE, language code from AA to ZU

• If the disc does not have a menu in the selected language, the disc’s default language will be used.

• For details about language codes, see “Appendix B: Table of languages and their abbreviations” on page 32.

• You cannot change the setting during playback.

[4:3 LB] (Letter Box conversion): select when you connect the

player to a normal (4:3) TV. When playing back a DVD VIDEO disc recorded in wide picture format, the picture is shown with black bars at the top and bottom.

AUDIO LANGUAGE

You can select the default audio language to be played if it is contained on a DVD VIDEO disc.

Setting options

ENGLISH, SPANISH, FRENCH, CHINESE, GERMAN, ITALIAN, JAPANESE, language code from AA to ZU

• If the disc does not have the selected language, the disc’s default language will be used.

• For details about language codes, see “Appendix B: Table of languages and their abbreviations” on page 32.

• You cannot change the setting during playback.

SUBTITLE

You can select the default subtitle language to be displayed if it is contained on a DVD VIDEO disc.

[4:3 PS] (Pan Scan conversion): select when you connect the

player to a normal (4:3) TV. When playing back a DVD VIDEO disc recorded in wide picture format, the picture is zoomed to fill the screen vertically, and the left and right sides of the image are chopped off. Note, however, that the picture will be shown in the 4:3 LB mode even if you select the 4:3 PS mode depending on the disc.

Setting options

OFF, ENGLISH, SPANISH, FRENCH, CHINESE, GERMAN, ITALIAN, JAPANESE, language code from AA to ZU

• If the disc does not have a subtitle in the selected language, the disc’s default language will be used.

• For details about language codes, see “Appendix B: Table of languages and their abbreviations” on page 32.

• You cannot change the setting during playback.

PICTURE SOURCE

ON SCREEN LANGUAGE

You can select the on-screen display language of the player.

Setting options

ENGLISH, SPANISH, FRENCH

• Some on-screen messages are shown in English regardless of the setting.

• You cannot change the on-screen language shown on the MP3/ WMA display.

PICTURE menu

MONITOR TYPE

You can select the monitor type to match your TV when you play back DVD VIDEO discs recorded for wide-screen televisions.

Setting options

16:9 NORMAL, 16:9 AUTO, 4:3 LB, 4:3 PS [16:9 NORMAL] (Wide television screen): select when you

connect the player to a wide-screen (16:9) TV whose aspect ratio is fixed to 16:9 (the player automatically adjusts the screen width of the output signal correctly when playing back a 4:3 source). If you play a 4:3 DVD VIDEO source using the [16:9 NORMAL] mode, the picture character changes slightly due to the process for converting the picture width.

This mode selects whether the content on the disc is processed by field (video source) or by frame (film source). You can obtain optimal picture quality according to the source type to be played back by selecting an appropriate option. This setting is available for both the interlaced mode and progressive scanning mode.

Setting options

VIDEO(NORMAL), VIDEO(ACTIVE), FILM, AUTO [VIDEO(NORMAL)]: select when playing back a video source

disc with relatively a few movements.

[VIDEO(ACTIVE)]: select when playing back a video source disc

with relatively a lot of movements.

[FILM]: select when playing back a film source disc. [AUTO]: select when playing back a disc containing both video

and film source materials. The player recognizes the picture type (film or video source) of the current disc according to the disc information. Normally, select this option.

SCREEN SAVER

You can set the screen saver function to ON or OFF. (See page

10.)

Setting options

ON, OFF

To change the setting, see “How to set preferences” on page 24.

Page 28

MP3&WMA/JPEG

The player can play MP3/WMA and JPEG files recorded on a CD-R/CD-RW disc. However, if a disc contains both MP3/WMA and JPEG files, you can only play files of the type selected in this menu item.

Setting options

MP3&WMA, JPEG [MP3&WMA]: when selected, only MP3/WMA files can be played

back.

[JPEG]: when selected, only JPEG files can be played back.

NOTE

If you have made a change to the [MP3&WMA/JPEG] setting, open and close the disc tray, or turn off and on the player. Doing so will make the change effective.

AUDIO menu

DIGITAL AUDIO OUTPUT

To connect the player’s digital output to an external device equipped with a digital input, this item must be set correctly. See “Appendix C: Digital output signal chart” on page 33 for details about the relation between the setting and output signals.

Setting options

PCM ONLY, DOLBY DIGITAL/PCM, STREAM/PCM [PCM ONLY]: select when you connect the DIGITAL OUT jack of

the player to the linear PCM digital input of other audio equipment.

[DOLBY DIGITAL/PCM]: select when you connect the digital

input of a Dolby Digital decoder or an amplifier with a built-in Dolby Digital decoder. When this option is selected, playing back a DTS-encoded disc or disc recorded by the MPEG Multichannel format outputs a linear PCM digital signal.

[STREAM/PCM]: select when you connect the digital input of an

amplifier with a built-in DTS, MPEG Multichannel or Dolby Digital decoder, or the stand-alone unit of such a decoder.

D. RANGE CONTROL

This setting provides optimal audio quality from the analog AUDIO OUT terminals for listening to DVD VIDEO discs recorded in Dolby Digital format, at low or middle volume.

Setting options

WIDE RANGE, NORMAL, TV MODE [WIDE RANGE]: when selected, audio is played back with the

widest dynamic range so that you can enjoy powerful playback sound.

[NORMAL]: normally, select this option. [TV MODE]: select if DVD VIDEO disc sound level is lower than

TV program sound level. Thus you can hear sound at a lower volume clearly.

OUTPUT LEVEL

This setting allows you to attenuate the level of the signal output from the player’s analog AUDIO OUT jacks.

Setting options

STANDARD, LOW

• If the sound output from the speaker is distorted, select [LOW].

OTHERS menu

RESUME

You can select the resume playback mode. See page 10 for details about the resume playback function.

Setting options

ON, OFF, DISC RESUME [ON]: when selected, the player can resume playback of the disc

from the position where playback was last interrupted, if the disc is still in the disc tray.

[OFF]: when selected, the resume function is deactivated. [DISC RESUME]: when selected, the player can resume

playback of the last 30 discs played. The player retains a memory of the interrupted positions of the last 30 discs played, even though they have been removed from the disc tray.

NOTE

When [STREAM/PCM] is selected, note the following points:

- With some DVD VIDEO discs that are not fully copy-protected,

a 20 or 24 bit digital signal may be output.

- A signal recorded with the 96 kHz or higher sampling

frequency is output from the DIGITAL OUT jack with the 48 kHz sampling frequency.

- When playing a DVD VIDEO or Audio CD disc with DTS, use

a DTS decoder to get correct signals from your speakers.

ANALOG DOWN MIX

To correctly play the audio on a DVD VIDEO disc recorded with surround multichannel audio, you must set this item properly according to your audio system configuration. (This function does not work when 3D PHONIC function is activated.)

Setting options

DOLBY SURROUND, STEREO [DOLBY SURROUND]: select when listening to multichannel

surround audio with the player’s analog AUDIO OUT terminals connected to a surround decoder.

[STEREO]: select when listening to conventional two-channel

stereo audio with the player’s AUDIO OUT terminals connected to a stereo amplifier/receiver or television set, or in case you want to record the audio from a DVD VIDEO disc to MiniDisc, cassette, etc.

ON SCREEN GUIDE

The player can display “on-screen guide” icons or characters on the picture, which show what is happening to the disc or the player.

Example of “on-screen guide” icons: , ,

Setting options

ON, OFF [ON]: when selected, the on-screen guide is activated.

AUTO STANDBY

When the player is stopped for more than 30 minutes or 60 minutes, the player enters standby mode automatically.

Setting options

60, 30, OFF

AV COMPULINK MODE

You must set this item correctly to use the AV COMPU LINK system.

Setting options

DVD1, DVD2, DVD3

• See page 29 for details about the AV COMPU LINK function.

To change the setting, see “How to set preferences” on page 24.

Page 29

PARENTAL LOCK

When this option is selected, pressing ENTER on the remote control unit brings up the PARENTAL LOCK display shown below. This allows you to restrict children from playing DVD VIDEO discs.

PARENTAL LOCK

COUNTRY CODE

SET LEVEL

PASSWORD

EXIT

SELECT

ENTER

• See this page for details about the parental lock setting.

Numeric buttons

5/∞

NONE

_ _ _ _

USE 5∞ TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

ENTER

4 Press 5/∞ to select the country code.

Select the code of the country whose standards were used to rate the DVD VIDEO disc content. See “Appendix A: Country/Area code list for Parental Lock” on page 32.

PARENTAL LOCK

SELECT

ENTER

COUNTRY CODE

SET LEVEL

PASSWORD

EXIT

TV TW

NONE

_ _ _ _

UA UG UM US

USE 5∞ TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

5 Press ENTER.

moves to [SET LEVEL].

6 Press ENTER to bring up the pull-down

menu.

In the pull-down menu, [NONE] and levels [8] to [1] are available. [NONE] does not restrict playback. Level [1] is the strictest level. Discs rated higher than the selected level are restricted.

PARENTAL LOCK

SELECT

ENTER

COUNTRY CODE

SET LEVEL

PASSWORD

EXIT

NONE 8

NONE

_ _ _ _

6 5 4 3

USE 5∞ TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

7 Press 5/∞ to select a desired parental lock

level, then press ENTER.

moves to [PASSWORD].

Limiting playback by children

This function restricts playback of DVD VIDEO discs which contain violent (and other) scenes according to the level set by the user. For example, if a movie which includes violent scenes supports the parental lock feature, such scenes which you do not want to let children view can be cut or replaced with other scenes.

To set Parental Lock for the first time

8 Press the numeric buttons (0 to 9) to enter a

4-digit password.

PARENTAL LOCK

SELECT

ENTER

COUNTRY CODE

SET LEVEL

PASSWORD

EXIT

NEW PASSWORD? TO EXIT, PRESS SETUP.

NONE

1234

...

PRESS 0 ~ 9 KEY

9 Press ENTER.

1 In stop mode, bring up the OTHERS menu. 2 Press 5/∞ to move to select [PARENTAL

LOCK] then press ENTER.

The Parental Lock on-screen display appears on the TV screen.

PARENTAL LOCK

COUNTRY CODE

SET LEVEL

PASSWORD

SELECT

ENTER

EXIT

3 While is pointing to [COUNTRY CODE],

press ENTER to bring up the pull-down menu.

NONE

_ _ _ _

USE 5∞ TO SELECT, USE ENTER TO CONFIRM TO EXIT, PRESS SETUP.

The parental lock feature is set.

moves to [EXIT]. Pressing ENTER again returns to the

[OTHERS] menu of the preference display.

Hint

If you want to change the password at step 8, do it before pressing ENTER.

Page 30

To temporarily release the Parental Lock

Numeric buttons

5/∞

ENTER

To change the settings

You can change the parental lock settings later.

1 In stop mode, bring up the OTHERS menu. 2 Press 5/∞ to move to select [PARENTAL

LOCK] and press ENTER.

The parental lock on-screen display appears on the TV screen.

3 While is pointing to [PASSWORD], press

the numeric buttons to enter your current 4digit password then press ENTER.

moves to [COUNTRY CODE] if you enter the correct password. If you enter a wrong password, [WRONG! RETRY...] appears on the TV screen, and you cannot go to the next step. If you forget your password, enter “8888.” The current password is deleted and you can set a new password.

4 To change the [COUNTRY CODE] or [SET

LEVEL], press ENTER to bring up the associated pull-down menu when is pointing to the desired item.

5 Press 5/∞ to select the desired option then

press ENTER.

If you change the country code, you must reselect the parental lock level.

6 While is pointing to [PASSWORD], press

the numeric buttons to enter a 4-digit password.

The password entered in this step becomes the new password. If you want to keep the same password as before, enter the same password.

7 Press ENTER.

moves to [EXIT]. Pressing ENTER again returns to the [OTHERS] menu of the preference display.

NOTE

If you enter the wrong password more than 3 times in step 3 above, moves to [EXIT] automatically and 5/∞ do not work.

If the parental level is set to a strict value, some discs may not play at all. When you insert such a disc and try to play it, the following parental lock on-screen display appears on the TV screen, asking you whether you want the parental lock to be temporarily released or not.

1 Press 5/∞ to move to [TEMPORARY

RELEASE], then press ENTER.

PARENTAL LOCK

TEMPORARY RELEASE

NOT RELEASE

SELECT

ENTER

PASSWORD

_ _ _ _

USE 5∞ TO SELECT, USE ENTER TO CONFIRM

2 Press the numeric buttons (0 to 9) to enter

your 4-digit password.

The Parental Lock is released, and the player starts playback. If you enter a wrong password, [WRONG! RETRY...] appears on the TV screen. Enter the correct password.

NOTE

When you enter the wrong password 3 times at step 2 above, moves to [NOT RELEASE] automatically and 5/∞ do not work.

Page 31

• If you connect the player to a television and VCR via AV COMPU LINK, set the VCR’s Remote Control Code and the

Additional information

player’s AV COMPU LINK setting as follows.

- When connecting to the VIDEO-1 input terminal of the

television: The player’s AV COMPU LINK setting: DVD2 VCR’s Remote Control Code: B

- When connecting to the VIDEO-2 input terminal of the

television: The player’s AV COMPU LINK setting: DVD3 VCR’s Remote Control Code: A

To AV COMPU LINK (ll, EX or lll)

AV COMPU LINK remote control system

The JVC AV COMPU LINK system allows you to enjoy video or audio with the simplest operation. If your video/audio player (such as a DVD player, CD player and VCR) and television or/and amplifier/receiver support the JVC AV COMPU LINK system and are tied with the JVC AV COMPU LINK cable(s), simply starting the player will automatically make all necessary settings on the television and/or amplifier/receiver to allow you to enjoy the playback.

Connection and setup

Using an AV COMPU LINK cable, connect the AV COMPU LINK terminals of each component to one another.

• The player’s AV COMPU LINK setting is controlled using the OTHERS menu in the preference display. See page 26.

• For information on the connection between a TV and a receiver, refer to the receiver’s instructions.

To AV COMPU LINK (ll, EX or lll)

The player

• If you connect the player to a television and receiver via AV COMPU LINK, set the player’s AV COMPU LINK setting to DVD 1.

IMPORTANT!

When you make video connection between the player and another device (such as a receiver and TV) via the composite, Svideo or component jacks, as well as AV COMPU LINK connection, see also the instruction manual of the other device.

Receiver

Notes for connection

• If you connect the player to a receiver via AV COMPU LINK in a system including a Dolby Digital decoder, some functions may not be performed automatically.

• Connect the AUDIO OUT jacks of the player to the audio input jacks of a receiver indicating “DVD.” Otherwise, the system will not work correctly.

• There may be no description about connections to the player in the instruction manual of a television or VCR. However, a television or VCR with AV COMPU LINK terminals indicating “II,” “EX” or “III” can be connected to the player.

Operation

• If you connect the player to a television via AV COMPU LINK, set the player’s AV COMPU LINK setting as follows.

- When connecting to the VIDEO-1 input terminal of the

television: DVD2

- When connecting to the VIDEO-2 input terminal of the

television: DVD3

To AV COMPU LINK (ll, EX or lll)

The player

To AV COMPU LINK

VCR

The JVC COMPU LINK system allows you to enjoy video and/or audio by simply pressing Play on the source component (the component which plays back the video or audio, such as a DVD player or VCR). You do not even have to switch on power on the TV or receiver.

1 Turn on the main power of the television. 2 Insert a disc (or tape) into the source

component.

3 Press 3 of the source component.

The following actions are performed automatically:

• Turning on the television power.

• Setting the source of the television to the external input (VIDEO-1 or VIDEO-2).

• Turning on receiver power.

• Setting the source of the receiver to the component which has started playback.

To AV COMPU LINK

The player

Page 32

Troubleshooting

Power

Power does not come on.

\ Power plug is not inserted securely. Plug in securely.

Operation

“REGION CODE ERROR!” is shown on the TV screen.

\ Region code of the inserted disc does not match the player.

Check the region code of the disc printed on the disc jacket.

Operation is not possible.

\ Microcomputer malfunction due to lightning or static electricity.

Turn off the power and unplug the power cord, then connect the power cord again.

\ Moisture condensation caused by a sudden change of

temperature or humidity. Turn off the power, then turn it on a few hours later.

\ The disc does not allow the operation, or an unplayable disc is

inserted. Check and replace the disc (see page 2).

[LOCK] is displayed on the display window and the disc tray does not open.

\ When you press 0 while pressing down 7 on the player in

standby mode, the tray lock function is activated. The disc tray cannot be opened or closed in this status. To release this status, press 0 while pressing down 7 on the player in standby mode.

Setting cannot be changed in the [LANGUAGE] preference display.

\ Stop playback and change the setting in the [LANGUAGE]

preference display.

The audio language and subtitle cannot be changed.

\ Only one language is recorded on the disc currently being

played back.

\ The disc being played back does not accept the AUDIO button

and SUBTITLE button operation. Change the subtitle using [SUBTITLE] in the [LANGUAGE] preference display (see page

25).

No subtitle is diplayed.

\ No subtitle is recorded on the disc currently being played

back.

\ [OFF] is selected in [SUBTITLE] in the [LANGUAGE]

preference display. Select the desired language in [SUBTITLE] (see page 25).

\ Subtitle may not be displayed correctly during A-B repeat

playback.


Picture is noisy.

\ The player is connected to a VCR directly and the copyguard

function is activated. Connect the player so that the picture signal flows directly to the TV.

\ With some discs, the picture may be blurred when [PICTURE

SOURCE] is set to [FILM] or [AUTO]. Set [PICTURE SOURCE] to [VIDEO (NORMAL)] or [VIDEO (ACTIVE)].

Correct picture cannot be obtained.

\ Connect only one type of cable to the jack(s) you want to use

on this player, either the VIDEO jack, S-VIDEO jack or COMPONENT VIDEO OUT jacks. (Note that you can connect cables to the VIDEO jack and COMPONENT VIDEO OUT jacks at the same time.) If an S-VIDEO cable is connected to the S-VIDEO jack, the player is set to the S-VIDEO output mode automatically.

No picture is displayed on the TV screen or the screen is blurred or divided into two parts.

\ The player is in the progressive scanning mode though it is

connected to a TV via the VIDEO or S-VIDEO jack. Set the 480i/480p/REMOTE selector on the rear panel to “480i,” or set it to “REMOTE” and make the Progressive scanning mode inactive by using the VFP - PROGRESSIVE SCAN button (see page 5).

Audio

DVD VIDEO disc playback sound level is lower than TV broadcast sound level.

\ Set the [D.RANGE CONTROL] preference to [TV MODE] (see

page 26).

Analog audio output is distorted.

\ Set the [OUTPUT LEVEL] preference to [LOW] (see page 26).

MP3/WMA

No sound comes out.

\ MP3/WMA disc is recorded with the “packet writing (UDF file).”

It cannot be played.

Files (tracks) are not played in the recorded order.

\ This player plays the files in the alphabetic order. So, the

playback order can vary.

WMA files cannot be played back.

\ The file is copy protected. \ The file is recorded with a bit rate under 48 kbps. The player

does not support such WMA files.

JPEG

No picture is played back, or the screen turns black.

\ Format of the files is not the baseline JPEG. The player

supports only the baseline JPEG format.

The preference display cannot be turned on.

\ You cannot turn on the preference display when a JPEG disc

is inserted.

Page 33

Specifications

Specifications and appearance are subject to change without prior notice.

General

Readable discs DVD VIDEO, DVD-R (Video format), DVD-

Video format REMOTE, 480i (Interlaced scan)/480p

Other

Power requirements

Power consumption

Mass 1.9 kg (4.2 lbs) Dimensions (W × H × D)

Video outputs

COMPONENT (pin jacks)

VIDEO OUT (pin jack)

S-VIDEO OUT (S jack)

Horizontal resolution

RW (Video format), SVCD, Video CD, Audio CD (CD-DA), CD-R/RW (CD-DA, SVCD, Video CD, MP3/WMA format, JPEG)

(Progressive scan) selectable

AC 120 V , 60 Hz

12 W (POWER ON), 2.0 W (STANDBY mode)

435 mm × 44 mm × 258.6 mm

/16 inch × 1-3/4 inch × 10-3/16 inch)

(17-

Y Output: 1.0 Vp-p (75 Ω)

B/PR Output: 0.7 Vp-p (75 Ω)

1.0 Vp-p (75 Ω)

Y Output: 1.0 Vp-p (75 Ω) C Output: 286 mVp-p (75 Ω)

500 lines or more

• Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

• “DTS” and “DTS 2.0+Digital Out” are trademarks of Digital Theater Systems, Inc.

• This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Audio outputs

ANALOG OUT (pin jack)

DIGITAL OUT (COAXIAL)

DIGITAL OUT (OPTICAL)

2.0 Vrms (10 kΩ)

0.5 Vp-p (75 Ω termination)

–21 dBm to –15 dBm (peak)

Audio characteristics

Frequency response

Dynamic range 16 bit: More than 98 dB

Wow and flutter Unmeasurable (less than ± 0.002%) Total harmonic distortion

* Notes for PX model (Check the specification

indication on the rear panel.)

Power requirements AC 110 V to 240 V , 50 Hz/60

Power consumption 12 W (POWER ON), 2.0 W

CD (sampling frequency 44.1 kHz):

2 Hz to 20 kHz

DVD (sampling frequency 48 kHz):

2 Hz to 22 kHz (4 Hz to 20 kHz for DTS and Dolby Digital bitstream signals)

DVD (sampling frequency 96 kHz):

2 Hz to 44 kHz

20 bit/24 bit: More than 100 dB

16 bit: less than 0.008% 20 bit/24 bit: less than 0.008%

(STANDBY mode)

Page 34

Appendix A: Country/Area code list for Parental Lock

AD Andorra AE United Arab Emirates AF Afghanistan AG Antigua and Barbuda

AI Anguilla AL Albania AM Armenia AN Netherlands Antilles AO Angola AQ Antarctica AR Argentina AS American Samoa

AT Austria AU Australia AW Ar uba AZ Azerbaijan BA Bosnia and Herzegovina BB Barbados BD Bangladesh BE Belgium BF Burkina Faso BG Bulgaria BH Bahrain

BI Burundi

BJ Benin BM Bermuda BN Brunei Darussalam BO Bolivia BR Brazil BS Bahamas BT Bhutan BV Bouvet Island BW Botswana BY Belarus BZ Belize CA Canada CC Cocos (Keeling) Islands CF Central African Republic CG Congo CH Switzerland

CI Côte d’Ivoire CK Cook Islands CL Chile CM Cameroon CN China CO Colombia CR Costa Rica CU Cuba CV Cape Verde CX Christmas Island CY Cyprus CZ Czech Republic DE Germany DJ Djibouti DK Denmark DM Dominica DO Dominican Republic DZ Algeria EC Ecuador EE Estonia EG Egypt EH Western Sahara

ER Eritrea ES Spain ET Ethiopia

FI Finland

FJ Fiji FK Falkland Islands FM Micronesia (Federated States

of) FO Faroe Islands FR France FX France, Metropolitan GA Gabon GB United Kingdom GD Grenada GE Georgia GF French Guiana GH Ghana

GI Gibraltar GL Greenland GM Gambia GN Guinea GP Guadeloupe GQ Equatorial Guinea GR Greece GS South Georgia and the South

Sandwich GT Guatemala GU Guam

GW Guinea-Bissau

GY Guyana HK Hong Kong HM Heard Island and McDonald

Islands HN Honduras HR Croatia HT Haiti HU Hungary

ID Indonesia IE Ireland IL Israel IN India IO British Indian Ocean Territory IQ Iraq IR Iran (Islamic Republic of) IS Iceland

IT Italy JM Jamaica JO Jordan

JP Japan KE Kenya KG Kyrgyzstan KH Cambodia

KI Kiribati KM Comoros KN Saint Kitts and Nevis KP Korea, Democratic People's

Republic of KR Korea, Republic of KW Kuwait KY Cayman Islands KZ Kazakhstan

LA Lao People’s Democratic

Republic LB Lebanon LC Saint Lucia

LI Liechtenstein LK Sri Lanka LR Liberia LS Lesotho LT Lithuania LU Luxembourg LV L a t v i a LY Libyan Arab Jamahiriya MA Morocco

MC Monaco MD Moldova, Republic of MG Madagascar MH Marshall Islands

ML Mali

MM Myanmar MN Mongolia MO Macau

MP Northern Mariana Islands

MQ Martinique MR Mauritania

MS Montserrat MT Malta

MU Mauritius

MV Maldives

MW Malawi

MX Mexico MY Malaysia MZ Mozambique NA Namibia NC New Caledonia NE Niger NF Norfolk Island NG Nigeria

NI Nicaragua NL Netherlands NO Norway NP Nepal NR Nauru NU Niue NZ New Zealand

OM Oman

PA Pa n a m a PE Peru PF French Polynesia PG Papua New Guinea PH Philippines PK Pakistan PL Poland PM Saint Pierre and Miquelon PN Pitcairn PR Puerto Rico PT Portugal

PW Palau

PY Paraguay QA Qatar RE Réunion RO Romania RU Russian Federation

(for page 27)

RW Rwanda

SA Saudi Arabia SB Solomon Islands SC Seychelles SD Sudan SE Sweden

SG Singapore

SH Saint Helena

SI Slovenia SJ Svalbard and Jan Mayen SK Slovakia SL Sierra Leone

SM San Marino

SN Senegal

SO Somalia

SR Suriname ST Sao Tome and Principe SV El Salvador SY Syrian Arab Republic SZ Swaziland TC Turks and Caicos Islands TD Chad TF French Southern Territories TG Togo TH Thailand TJ Tajikistan TK Tokelau

TM Turkmenistan

TN Tunisia TO Tonga TP East Timor TR Turkey TT Trinidad and Tobago TV Tuvalu

TW Taiwan

TZ Tanzania, United Republic of UA Ukraine

UG Uganda UM United States Minor Outlying

Islands US United States UY Uruguay UZ Uzbekistan VA Vatican City State (Holy See) VC Saint Vincent and the

Grenadines VE Venezuela VG Virgin Islands (British)

VI Virgin Islands (U.S.) VN Vietnam VU Vanuatu

WF Wallis and Futuna Islands WS Samoa

YE Yemen YT Mayotte YU Yugoslavia ZA South Africa

ZM Zambia

ZR Zaire

ZW Zimbabwe

Appendix B: Table of languages and their abbreviations

AA Afar FA Persian KM Cambodian OM (Afan) Oromo SU Sundanese AB Abkhazian FI Finnish KN Kannada OR Oriya SV Swedish AF Afrikaans FJ Fiji KO Korean (KOR) PA Panjabi SW Swahili AM Ameharic FO Faroese KS Kashmiri PL Polish TA Tamil AR Arabic FY Frisian KU Kurdish PS Pashto, Pushto TE Telugu AS Assamese GA Irish KY Kirghiz PT Portuguese TG Tajik AY Aymara GD Scots Gaelic LA Latin QU Quechua TH Thai AZ Azerbaijani GL Galician LN Lingala RM Rhaeto-Romance TI Tigrinya BA Bashkir GN Guarani LO Laothian RN Kirundi TK Turkmen BE Byelorussian GU Gujarati LT Lithuanian RO Rumanian TL Tagalog BG Bulgarian HA Hausa LV Latvian, Lettish RU Russian TN Setswana BH Bihari HI Hindi MG Malagasy RW Kinyarwanda TO Tongan BI Bislama HR Croatian MI Maori SA Sanskrit TR Turkish BN Bengali, Bangla HU Hungarian MK Macedonian SD Sindhi TS Tsonga BO Tibetan HY Armenian ML Malayalam SG Sangho TT Tatar BR Breton IA Interlingua MN Mongolian SH Serbo-Croatian TW Twi CA Catalan IE Interlingue MO Moldavian SI Singhalese UK Ukrainian CO Corsican IK Inupiak MR Marathi SK Slovak UR Urdu CS Czech IN Indonesian MS Malay (MAY) SL Slovenian UZ Uzbek CY Welsh IS Icelandic MT Maltese SM Samoan VI Vietnamese DA Danish IW Hebrew MY Burmese SN Shona VO Volapuk DZ Bhutani JI Yiddish NA Nauru SO Somali WO Wolof EL Greek JW Javanese NE Nepali SQ Albanian XH Xhosa EO Esperanto KA Georgian NL Dutch SR Serbian YO Yoruba ET Estonian KK Kazakh NO Norwegian SS Siswati ZU Zulu EU Basque KL Greenlandic OC Occitan ST Sesotho

(for pages 15, 16 and 25 )

Page 35

Appendix C: Digital output signal chart

(for page 26)

Disc type

DVD with 48/44.1 kHz, 16/20/24 bit linear PCM

DVD with 96 kHz, 16/22/24 bit linear PCM

DVD with DTS 48 kHz, 16 bit, stereo linear PCM DTS bitstream

DVD with Dolby Digital 48 kHz, 16 bit, stereo linear PCM Dolby Digital bitstream

SVCD/Video CD/Audio CD 44.1 kHz, 16 bit, stereo linear PCM

Audio CD with DTS 44.1kHz, 16 bit, stereo linear PCM DTS bitstream

CD-R/RW with MP3/WMA Linear PCM

PCM ONLY DOLBY DIGITAL/PCM STREAM/PCM

48/44.1 kHz, 16 bit, stereo linear PCM

48 kHz, 16 bit, stereo linear PCM (Down sampling)

Output

Page 36

Appendix D: Glossary

480i/480p

Indicates the number of scanning lines and scanning format of an image signal. 480i indicates 480 scanning lines with interlace format, and 480p indicates 480 scanning lines with progressive format.

Aspect ratio

A ratio which defines the shape of the rectangular picture in a TV. It is the width of the picture relative to the height. A conventional TV picture is 4:3 in aspect ratio.

Bitstream

The digital form of multichannel audio data (e.g., 5.1-channel) before it is decoded into its various channels.

Chapter/title

Chapter is the smallest division and title is the largest division on DVD VIDEO. A chapter is a division of a title and similar to a track for Video CD or Audio CD.

Component video

Video signals with three channels of separate information that makes up the picture. There are some types of component video, such as R/G/B and Y/C

Composite video

A single video signal commonly used in most consumer video products that contains all luminance, color, and synchronization information.

Dolby Digital (AC3)

A six-channel system consisting of left, center, right, left rear, right rear and LFE (Low-Frequency Effect channel, for use with a sub-woofer) channels. All processing is done in the digital domain. Not all Dolby Digital discs contain six (5.1) channels of information.

Dolby Surround/Dolby Pro Logic

Dolby Surround records four channels of front and rear audio in two channels in a way that allows a decoder to recover the original four channels for playback. Because the audio is recorded in two channels, it can be played back naturally by a two-channel stereo system. Dolby Pro Logic introduces directional circuits in decoder-side processing (increasing the level of specific channels and lowering the level of silent channels) for greater spatial perspective, and adds a center speaker used primarily for dialog. The result is enhanced channel separation.

Down-mix

Internal stereo mix of multichannel surround audio by a DVD player. The down-mix signals are output from stereo output connectors.

DTS

A Digital Surround audio encoding format configured with six (5.1) channels, similar to Dolby Digital. It requires a decoder, either in the player or in an external receiver. DTS stands for Digital Theater Systems. Not all DTS discs contain six (5.1) channels of information.

Dynamic range

The difference between the loudest and softest sounds.

B(PB)/CR(PR).

Interlaced scanning

In a conventional video system, a picture is shown on the display monitor in between lines of two halves. The Interlaced scanning system places lines of the second half of the picture in-between lines of the first half of the picture.

JPEG

A popular file format for still image compression and storage. JPEG stands for Joint Photographic Experts Group. There are three sub-types of the JPEG format as follows.

• baseline JPEG: used for digital cameras, the web, etc.

• progressive JPEG: used for the web

• lossless JPEG: an old type, rarely used now

Linear PCM audio

PCM stands for “pulse code modulation.” Linear PCM is the usual method for digitally encoding audio without compression, and is used for the audio tracks on DVD VIDEO discs, Audio CDs, etc.

MP3

MP3 is an audio data compression format, which stands for MPEG-1 Audio Layer 3. Using MP3, you can achieve a data reduction of about 1:10.

NTSC (National television system committee)

A black and white and color television system format used in the U.S.A., Canada, Mexico and Japan.

PAL (Phase Alternation by Line)

A color television system format used extensively in Western Europe.

PBC

PBC stands for “Playback control” and is a method of controlling disc play for Video CDs (VCD). You are able to interact with the disc through menus.

Progressive scanning

Progressive scanning displays all the horizontal lines of a picture at one time, as a single frame. A progressive scanning DVD player converts the interlaced (480i) video from DVD into progressive (480p) format for connection to a progressive display. It dramatically increases the vertical resolution.

S-video

A video signal which improves picture quality over standard composite connections. Used on Super VHS, DVD, high end TV monitors, etc.

Tra ck

The smallest division on SVCD, Video CD and Audio CD discs.

WMA

WMA is an abbreviation of “Windows Media Audio,” and is an audio data compression format developed by Microsoft Corporation. Sound quality of data compressed using WMA is the same as that of MP3, though the WMA file size is smaller than that of MP3.

Page 37

LIMITED WARRANTY

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period as shown below. ("The Warranty Period")

PARTS LABOR

CONSUMER VIDEO 1-90

1 YR 90 DAYS

THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA AND IN COMMONWEALTH OF PUERTO RICO.

WHAT WE WILL DO:

If this product is found to be defective, JVC will repair or replace defective parts at no charge to the original owner. Such repair and replacement services shall be rendered by JVC during normal business hours at JVC authorized service centers. Parts used for replacement are warranted only for the remainder of the Warranty Period. All products and parts thereof may be brought to a JVC authorized service center on a carry-in basis except for Television sets having a screen size 25 inches and above which are covered on an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Return your product to a JVC authorized service center with a copy of your bill of sale. For your nearest JVC authorized service center, please call toll free: (800) 537-5722.

If service is not available locally, box the product carefully, preferably in the original carton, and ship, insured, with a copy of your bill of sale plus a letter of explanation of the problem to the nearest JVC Factory Service Center, the name and location of which will be given to you by the toll-free number.

If you have any questions concerning your JVC Product, please contact our Customer Relations Department.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty installation, lack of reasonable care, or if repaired or serviced by anyone other than a service facility authorized by JVC to render such service, or if affixed to any attachment not provided with the products, or if the model number or serial number has been altered, tampered with, defaced or removed;

2. Initial installation and installation and removal for repair;

3. Operational adjustments covered in the Owner's Manual, normal maintenance, video and audio head cleaning;

4. Damage that occurs in shipment, due to act of God, and cosmetic damage;

5. Signal reception problems and failures due to line power surge;

6. Video Pick-up Tubes/CCD Image Sensor, Cartridge, Stylus (Needle) are covered for 90 days from the date of purchase;

7. Accessories;

8. Batteries (except that Rechargeable Batteries are covered for 90 days from the date of purchase);

There are no express warranties except as listed above.

THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.

JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE, LOSS OR ANY OTHER DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, WITHOUT LIMITATION, DAMAGE TO TAPES, RECORDS OR DISCS) RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential damages or limitations on how long an implied warranty lasts, so these limitations or exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state.

JVC COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY, THIS WARRANTY DOES NOT APPLY. FOR DETAILS OF REFURBISHED PRODUCT WARRANTY, PLEASE REFER TO THE REFURBISHED PRODUCT WARRANTY INFORMATION PACKAGED WITH EACH REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. which is located either on the rear, bottom or side of the cabinet. Retain this information for future reference.

Model No. : Serial No. :

Purchase data : Name of dealer :

1700 Valley Road Wayne, NJ 07470

Page 38

Authorized Service Centers

QUALITY

SERVICE

HOW TO LOCATE YOUR JVC SERVICE CENTER

TOLL FREE: 1 (800) 537-5722

http://www.jvc.com

Dear Customer, In order to receive the most satisfaction from your purchase,please read the instruction booklet before operating the unit.In the event that repairs are necessary, please call 1 (800)537-5722 for your nearest authorized servicer or visit our website at www.JVC.com Remember to retain your Bill of Sale for Warranty Service.

Do not service the television yourself

Caution

To prevent electrical shock,do not open the cabinet.There are no user serviceable parts inside.Please refer to qualified service personnel for repairs.

Accessories

To purchase accessories for your JVC product,please call toll free:1 (800)882-2345 or on the web at www.JVC.com

BT-51005-5 (0301)

Page 39

XV-N410B/XV-N412S DVD PLAYER

VICTOR COMPANY OF JAPAN, LIMITED

0104KTYBICJSC

JVC XV-N412SAU, XV-N410BSE, XV-N410BUD, XV-N412SEU, XV-N412SSE Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
