XV-M565BK/M567GD
PARTS LIST
[XV-M565BK/M567GD]
* All printed circuit boards and its assemblies are not available as service parts.
Areas suffix
J ----------------------------- U.S.A.
C -------------------------- Canada
- Contents -
Exploded view of general assembly and parts list
DVD changer mechanism assembly and parts list
DVD mechanism assembly and parts list
Electrical Parts List
Packing materials and accessories parts list
3-2
3-6
3-8
3-10
3-21
3-1
XV-M565BK/M567GD
Exploded view of general assembly and parts list
Block No.
M
M
1
M
FL indicator
board
76
75
73
Volume board
3-2
33
37
74
72
54
61
56
60
59
55
57
58
Video board
Power supply
board
System control board
Traverse mechanism
control board
75
75
75
XV-M565BK/M567GD
3-3
XV-M565BK/M567GD
)
)
)
)
)
)
Parts list ( General Assembly )
Item Parts number Parts name Area
A
1 LV10244-018A FRONT PANEL 1 XV-M567GD
LV10244-015A FRONT PANEL 1 XV-M565BK
2 VJD5429-001SS JVC MARK 1
3 LV10245-006A CONTROL PANEL 1 XV-M567GD
LV10245-001A CONTROL PANEL 1 XV-M565BK
4 LV31260-003A ZOOM BUTTON 1 XV-M567GD
LV31260-001A ZOOM BUTTON 1 XV-M565BK
5 LV20815-002A PLAY BUTTON 1 XV-M567GD
LV20815-001A PLAY BUTTON 1 XV-M565BK
6 LV30787-001A PUSH BUTTON 1 THEATER
7 LV30788-001A PUSH BUTTON 1 DIMMER
8 LV20817-003A LENS (VIOLET
LV20817-001A LENS (VIOLET
9 QYSDSF2608Z SCREW 6
10 LV32063-001A POWER BUTTON 1 XV-M565BK
LV32063-003A POWER BUTTON 1 XV-M567GD
11 FSJD4001-002 INDICATOR 1
12 QYSDSF2608Z SCREW 8
13 QUQ412-0920CM FFC WIRE 1 CN801 TO CN703
14 LV31375-001A FRONT BRACKET 1
15 QYSDSF2608Z SCREW 4
16 LV31163-005A SHUTTLE RING 1 XV-M567GD
LV31163-004A SHUTTLE RING 1 XV-M565BK
17 QYSDSF2608Z SCREW 3
18 QYSDSG3008N SCREW(F.P-CHAS
QYSDSG3008M SCREW(F.P-CHAS
19 E103006-007SM CD CHASSIS BASE 1
20 LV31373-001A MECHA.BKT(F
21 LV31374-001A MECHA BKT(R
22 QYSBST3008Z T.SCREW 4 MECHA BKT
23 QZF6018-001 FOOT 2
24 E47227-036 FOOT 2 REAR
25 QYSBST3008Z T.SCREW 4 FOOT
26 LV31244-002A SPACER 2
27 QYSDSG3008M SCREW 2
28 E310244-002 FASTENER 1 AUDIO CB
29 QYSBSGG3008E T.SCREW 1 AUDIO CB
30 QUQ412-1020CM FFC WIRE 1 CN702 TO C5
31 QUQ110-2318AM FFC WIRE 1 CN701 TO C5
32 QYSBSGG3008E T.SCREW 2
33 E310244-002 FASTENER 1
34 QMF51U1-1R6-J8 FUSE
A
35 LV41362-001A HEAT SINK 1
36 LV41363-002A HOLDER 1
37 E310244-003 FASTNER 1
43 QYSBSF3008Z SCREW 1 MODULE CB
44 QUQ110-1910AJ FFC WIRE 1 PU-MODULE FW101
45 QUQ110-1110AJ FFC WIRE 1 PU-MODULE FW102
Q'ty Description
1 XV-M567GD
1 XV-M565BK
3 XV-M567GD
3 XV-M565BK
1 FRONT
2 REAR
1 F901
Block No. M1MM
3-4
XV-M565BK/M567GD
)
)
)
)
)
)
)
)
)
)
Parts list ( General Assembly )
Item Parts number Parts name Area
A
46 QJJ015-091204 SIN CR C-C WIRE 1 TO CN961
47 QUQ110-0923AM CARD WIRE 1 TO CN601
48 E309662-001SM DISC STOPPER 1
49 QYSBSF3008Z SCREW 1
50 QYSBST3008Z T.SCREW 4 MECHA
51 LV10282-001A SHIELD CASE 1
52 QYSBSGG3008E T.SCREW 4 SHIELD CASE
53 LV20821-014A REAR PANEL 1 XV-M565BK
LV20821-020A REAR PANEL 1 XV-M567GD
54 QYSBSGY3008E SPECIAL SCREW 3 REAR PANEL
55 QYSBSGY3008E SPECIAL SCREW 1 VIDEO OUT
56 QYSBSGY3008E SPECIAL SCREW 2 AV OUT
57 QYSBSGY3008E SPECIAL SCREW 1 COMPU.LINK
58 QYSBSGY3008E SPECIAL SCREW 1 COAXIAL OUT
59 QYSBSGY3008E SPECIAL SCREW 1 AUDIO OUT
60 QYSBSGY3008E SPECIAL SCREW 1 OPTICAL OUT
61 QYSBSGY3008E SPECIAL SCREW 1 AC OUTLET
62 LV20818-001A FITTING(DISC1 LOWER
LV20818-003A FITTING(DISC1 LOWER
63 LV20819-002A FITTING(DISC2 CENTR
LV20819-001A FITTING(DISC2 CENTR
64 LV20820-001A FITTING(DISC3 UPPER
LV20820-002A FITTING(DISC3 UPPER
65 LE40564-002A MARK 1
66 LE30714-001A KNOB(SHUTTLE
LE30714-005A KNOB(SHUTTLE
67 LV20009-310A METAL COVER 1 XV-M567GD
LV20009-311A METAL COVER 1 XV-M565BK
68 E406308-003 S.SCREW(SIDE M.COVER
E406308-004 S.SCREW(SIDE M.COVER
69 QYSBSGY3008E SPECIAL SCREW 2 M.COVER REAR
72 -------------------- DVD 3CHANGER LO 1 BDL1081-M001YP
73 E306805-134 SPACER 1
74 LE40505-001A HEAT SINK 1 HS964
75 QLF0064-001 FL TUBE 1 DI801
LV30225-059A SPACER 3
76 E308192-001 FL HOLDER 1 BK801
Q'ty Description
1 XV-M565BK
1 XV-M567GD
1 XV-M567GD
1 XV-M565BK
1 XV-M565BK
1 XV-M567GD
1 XV-M565BK
1 XV-M567GD
4 XV-M565BK
4 XV-M567GD
Block No. M1MM
3-5
XV-M565BK/M567GD
DVD changer mechanism assembly and parts list
FLM-C5-3M
Grease and screw lock
EM-30L
EBS0006-009B
72
51
Block No.
27
M
2
M
M
21
25
17
72
69
65
76
27
34
27
27
FIG A
27
H
H
3-6
27
27
FIG C
27
FIG C
75
FIG A
75
75
75
XV-M565BK/M567GD
Parts list (DVD changer mechanism)
A
Item
1 VKS1144-003 CHASSIS 1
2 VKS3698-003 TRAY GUIDE 2
3 VKS5532-003 PULLEY GEAR 2
4 VKB3000-164 BELT 2
5 VKS5505-003 GEAR B 2
6 VKS5506-002 GEAR C 3
7 VKS5507-002 CROSS GEAR U 1
8 VKS5508-002 CROSS GEAR L 1
9 VKS5510-003 SELECT LEVER 1
10 VKH5769-001 S.G.SHAFT 1
11 VKS5511-002 SELECT GEAR 1
12 VKW5155-003 COMP.SPRING 1 FOR SELECT GEAR
13 VKM3846-002 GEAR BRACKET 1
14 VKS5509-002MM CYLINDER GEAR 1
15 MSN-5D257A-SA2 D.C.MOTOR 2
16 QYSPSPD2616Z SCREW 2 FOR MOTOR
17 LV40612-001A COMP.SPRING 1
18 VKM3825-00AMM C.G.BASE ASS'Y 1
19 VKZ3172-00ASS CAM SW. R ASS'Y 1
20 VKZ3173-00ASS CAM SW. L ASS'Y 1
21 QYSPST2606Z SCREW 4 FOR CAM SW.
22 VKS2263-002MM CAM R1 1
23 VKS2264-002MM CAM R2 1
24 VKS2265-002MM CAM GEAR L 1
25 WDL316050MM SLIT WASHER 2
27 QYSBSF2608Z T.SCREW 16 FOR C.GEAR BASE
28 VKS3702-00FMM DRIVE UNIT 1
29 LV20466-001A MECHA HOLDER A 1
30 VKL7767-00C BRAKET ASSY 1
31 QYSBSF2606Z SCREW 2 FOR BRACKET
32 VKM3860-00B MCHA HOLDER ASS 1
33 VKL7802-00C M.HOLDER C AS'Y 1
34 QYSDST2604Z SCREW 3 FOR M.HOLDER C
35 VKL7810-00A LIFTER ASS'Y R 1
36 VKL7811-00A LIFTER ASS'Y L 1
37 VKL7812-00A LIFTER ASS'Y H 1
38 VKL2732-002 LIFTER BASE 1
39 VKM3857-001 LIFTER BRACKET 1
41 WDL266035-2 SLIT WASHER 1
43 VKS5514-002MM LOCK LEVER 3
44 VKY3133-002MM RETURN SPRING 1
46 VKY3134-003MM CLICK SPRING 1
47 VKS2252-00F TRAY ASS'Y 3
48 VKS2250-003 TOP BRACKET 1
49 VKS5515-002 S.TRAY STOPPER 1
50 VKW5156-004 TORSION SPRING 1
51 VKS3703-00J CLAMPER ASS'Y 1
62 LV41120-001A INSULATOR 2
63 LV41120-002A INSULATOR 2
65 ----------- DVD MECHA 1
69 QGB2012J1-10 CONNECTOR 1
71 VKW5187-001 R OD 1
72 LV41119-001A SPECIAL SCREW 2
75 LV41568-002A SHEET 6
76 LV41571-001A SPACER 1
Parts number Parts name
Q'ty
Block No. M2MM
Description
Area
3-7
XV-M565BK/M567GD
DVD mechanism assembly and parts list
FXL-V5M
23
6
2323
23
5
2
5
17
18
24
20
22
16
Block No.
Grease and screw lock
13
19
15
After the
14
mounting of pic up,
grease is spread
24
22
3
M
EBS0005-013B
EBS0006-014B
EBS0006-020B
M
20
M
4
19
20
5
5
3
Grease is
spread on the
entire shaft
1
After the inclination is adjusted,
32
32
the screw lock is spread on the
adjustment screws.
32
30
31
3-8
33
31
36
XV-M565BK/M567GD
Parts list (DVD mechanism)
A
Item
1 LV20463-001A MECHA BASE 1
2 LV31286-001A SHAFT HOLDER 1 1
3 LV31287-001A SHAFT HOLDER 2 1
4 LV31288-001A SHAFT HOLDER 3 1
5 QYSBST2005Z T.SCREW 4 SHAFT HOLDER
6 VDG1081-001TT5 SP.MOTOR BKT AS 1 ASS'Y
13 QAL0186-001 DVD PICK UP
A
14 LV31285-002A RACK BASE 1 FOR DVD PICK
15 LV41109-001A R.BASE SPRING 1 FOR RACK BASE
16 QYSPSPU1740M SCREW 1 FOR RACK BASE
17 LV31359-001A P.U. SPRING 1 FOR DVD PICK
18 LV41021-001A SPECIAL SCREW 1 FOR P.U.SPRING
19 LV41121-001A SHAFT 2
20 LV41115-002A SPRING 3 FOR TILT
22 LV31283-002A S.HOLDER BKT 2 FOR S.HOLDER2
23 QYSSST2615Z TAP SCREW 3 MOTOR BKT
24 QYSDST2616Z SCREW 2 S.H.BKT*2
25 LV41111-002A FPC HOLDER 1
30 QAR0106-001 FEED MOTOR 1
31 VKZ4539-026 MINI SCREW 2 FOR F.MOTOR
32 QYYASPF2610N SCREW 3 FOR TILT
33 QYSBST2005Z T.SCREW 2 FOR PW.BORD
36 LV41479-002A RACK COVER 1
Parts number Parts name
Q'ty
1
Block No. M3MM
Description
Area
3-9
XV-M565BK/M567GD
Electrical Parts List
Electrical parts list ( Main board )
Item
A
C 601 QCS11HJ-181 C CAPACITOR 180PF 5% 50V
C 603 QCS11HJ-680 C CAPACITOR 68PF 5% 50V
C 604 QCS11HJ-150 C CAPACITOR 15PF 5% 50V
C 609 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 611 QCS11HJ-181 C CAPACITOR 180PF 5% 50V
C 613 QCS11HJ-680 C CAPACITOR 68PF 5% 50V
C 614 QCS11HJ-150 C CAPACITOR 15PF 5% 50V
C 619 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 621 QCS11HJ-121 C CAPACITOR 120PF 5% 50V
C 623 QCS11HJ-470 C CAPACITOR 47PF 5% 50V
C 624 QCS11HJ-100 C CAPACITOR 10PF 5% 50V
C 629 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 631 QCS11HJ-121 C CAPACITOR 120PF 5% 50V
C 633 QCS11HJ-470 C CAPACITOR 47PF 5% 50V
C 634 QCS11HJ-100 C CAPACITOR 10PF 5% 50V
C 639 NCB21EK-104X C CAPACITOR
C 641 QCS11HJ-121 C CAPACITOR 120PF 5% 50V
C 643 QCS11HJ-470 C CAPACITOR 47PF 5% 50V
C 644 QCS11HJ-100 C CAPACITOR 10PF 5% 50V
C 649 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 659 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 701 QETN1HM-105Z E CAPACITOR 1.0MF 20% 50V
C 702 NCB21EK-104X C CAPACITOR
C 703 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C 704 NCB21EK-104X C CAPACITOR
C 705 NCB21EK-104X C CAPACITOR
C 706 QFVF1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 707 QETN0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 708 NCB21EK-104X C CAPACITOR
C 709 NCS21HJ-331X C CAPACITOR
C 710 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 711 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 712 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 714 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 715 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 716 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 717 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 718 QETN0JM-477Z E CAPACITOR 470MF 20% 6.3V
C 720 NCB21EK-104X C CAPACITOR
C 721 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 722 QCF11HZ-473 C CAPACITOR .047MF +80:-20%
C 724 QCF11HZ-103 C CAPACITOR .010MF +80:-20%
C 725 QETN1CM-477Z E CAPACITOR 470MF 20% 16V
C 726 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
C 727 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C 728 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 730 QFVJ1HJ-474Z CAPACITOR .47MF 5% 50V
C 731 QDYB1CM-103Y C.CAPACITOR
C 732 QDGB1HK-102Y C CAPACITOR
C 733 QDGB1HK-102Y C CAPACITOR
C 734 QDX31EM-473Z C.CAPACITOR
C 735 NCB21EK-104X C CAPACITOR
C 736 NCB21EK-104X C CAPACITOR
C 740 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 741 QFLC1HJ-181Z M.CAPACITOR 180PF 5% 50V
C 742 QFN31HJ-333Z M.CAPACITOR .033MF 5% 50V
C 743 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 744 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V
C 745 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V
C 746 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 747 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 750 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 751 QFLC1HJ-181Z M.CAPACITOR 180PF 5% 50V
Parts number Parts name Area
Remarks
Block No. 01
Item
A
C 752 QFN31HJ-333Z M.CAPACITOR .033MF 5% 50V
C 753 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 754 QFLC1HJ-182Z M CAPACITOR 1800PF 5% 50V
C 755 QFN31HJ-103Z M CAPACITOR .010MF 5% 50V
C 756 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C 757 QFLC1HJ-152Z M CAPACITOR 1500PF 5% 50V
C 761 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 762 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 771 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 772 QETN1CM-107Z E CAPACITOR 100MF 20% 16V
C 797 NCB21HK-103X C CAPACITOR
C 798 NCB21HK-103X C CAPACITOR
C 801 NCB21EK-104X C CAPACITOR
C 802 QEKC1AM-476Z E.CAPACITOR 47MF 20% 10V
C 811 NCB21EK-104X C CAPACITOR
C 812 QEKC0JM-476Z E.CAPACITOR 47MF 20% 6.3V
C 813 NCB21EK-104X C CAPACITOR
C 814 NCS21HJ-220X C CAPACITOR
C 821 QEKC1HM-475Z E.CAPACITOR 4.7MF 20% 50V
C 902 QFZ9067-683 C CAPACITOR
A
C 906 QCZ9079-102 C CAPACITOR
A
C 907 QETM2DM-157 E CAPACITOR
A
C 908 QCZ0136-332Z C CAPACITOR 3300PF
C 909 QCZ0136-101Z C CAPACITOR 100PF
C 910 QCS11HJ-221 C CAPACITOR 220PF 5% 50V
C 913 QCZ0136-221Z C CAPACITOR 220PF
C 914 QEMX1EM-396Z E CAPA I/M 39MF 20% 25V
C 915 QCBB1HK-471Y C CAPACITOR 470PF 10% 50V
C 916 QCZ9079-332 C CAPACITOR
A
C 917 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 918 QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%
C 931 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 951 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 952 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 953 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 954 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 956 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 957 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 960 QEMX1AM-826Z E CAPA. I/M 82MF 20% 10V
C 961 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 962 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 963 QEMX1HM-396Z E CAPA I/M 39MF 20% 50V
C 964 QETN1HM-226Z E CAPACITOR 22MF 20% 50V
C 965 QEMV1AM-108 E CAPACITOR 1000MF 20% 10V
C 966 QETN1AM-477Z E CAPACITOR 470MF 20% 10V
C 967 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 968 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 969 QETN1AM-227Z E CAPACITOR 220MF 20% 10V
C 970 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 973 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 974 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 976 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 977 QFVJ1HJ-104Z TF CAPACITOR .10MF 5% 50V
C 978 QETN1AM-107Z E CAPACITOR 100MF 20% 10V
C 979 QEMV1CM-827 E CAPACITOR 820MF 20% 16V
C 981 QCZ0205-155Z ML C CAPACITOR 1.5MF
C 982 QEMV1EM-567 E CAPACITOR 560MF 20% 25V
C 984 QETN1EM-227Z E CAPACITOR 220MF 20% 25V
C 987 QEMX1EM-187Z E CAPA I/M 180MF 20% 25V
C 989 QETN1EM-107Z E CAPACITOR 100MF 20% 25V
C 992 QETN1HM-474Z E CAPACITOR .47MF 20% 50V
C 993 QCS11HJ-101 C CAPACITOR 100PF 5% 50V
C 994 QDVB1EZ-223Y C CAPACITOR
Parts number Parts name Area
.068MF
1000PF
150MF 20%
3300PF
Remarks
3-10
XV-M565BK/M567GD
)
Q
Q
Q
Q
Q
Q
Electrical parts list ( Main board )
Item
A
C 995 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
C 996 QETN1CM-226Z E CAPACITOR 22MF 20% 16V
C 997 QETN1CM-227Z E CAPACITOR 220MF 20% 16V
CN601 QGF1016F1-09 CONNECTOR
CN701 QGF1016C1-23 CONNECTOR
CN702 QGF1205C1-10 CONNECTOR
CN703 QGF1205C1-09 CONNECTOR
CN704 QGD2501C1-03Z SOCKET
CN801 QGF1210G1-09 CONNECTOR
CN951 QGD2501C1-04Z SOCKET
CN952 QGD2501C1-04Z SOCKET
CN961 QGA2001C1-09 9P PLUG ASSY
CN971 QGD2501C1-03Z SOCKET
CN972 QGD2501C1-03Z SOCKET
CP951 ICP-N10-T ICP
A
CP952 ICP-N5-T ICP
A
C1701 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1702 QETN1EM-476Z E CAPACITOR 47MF 20% 25V
C1703 NCS21HJ-151X C CAPACITOR
C1704 NCS21HJ-221X C CAPACITOR
C1705 NCS21HJ-221X C CAPACITOR
D 609 1SS133-T2 SI DIODE
D 619 1SS133-T2 SI DIODE
D 629 1SS133-T2 SI DIODE
D 639 1SS133-T2 SI DIODE
D 649 1SS133-T2 SI DIODE
D 701 1SS133-T2 SI DIODE
D 702 MTZJ3.3B-T2 ZENER DIODE IM
D 709 1SS133-T2 SI DIODE
D 731 KV1555N-T VARI CAPACITOR
D 732 KV1555N-T VARI CAPACITOR
D 733 MTZJ5.1C-T2 ZENER DIODE
D 791 1SS133-T2 SI DIODE
D 792 1SS133-T2 SI DIODE
D 801 SLR-342VC-T LED STANDBY
D 821 SLR-342MC-T LED
D 822 SLR-342MC-T LED
D 823 SLR-342MC-T LED
D 831 1SS133-T2 SI DIODE
D 832 1SS133-T2 SI DIODE
D 833 1SS133-T2 SI DIODE
D 901 S1WB/A/60-4101 BRIDGE DIODE
A
D 902 ERA18-04-T1 FR DIODE
A
D 903 ERA18-04-T1 FR DIODE
A
D 904 ERA18-04-T1 FR DIODE
A
D 908 ERA18-04-T1 FR DIODE
A
D 910 ERA18-04-T1 FR DIODE
A
D 911 1SS133-T2 SI DIODE
D 950 MTZJ22C-T2 ZENER DIODE
D 951 ERA18-04-T1 FR DIODE
A
D 952 ERA18-04-T1 FR DIODE
A
D 953 FMB-24 FUSEIODE
A
D 954 ERA18-04-T1 FR DIODE
A
D 956 ERA18-04-T1 FR DIODE
A
D 957 ERA18-04-T1 FR DIODE
A
D 960 MTZJ2.0A-T2 ZENER DIODE
D 970 1SS133-T2 SI DIODE
D 971 1SR35-100A-T5 SI DIODE
D 972 1SS133-T2 SI DIODE
D 973 1SS133-T2 SI DIODE
D 974 1SS133-T2 SI DIODE
D 991 MTZJ5.1C-T2 ZENER DIODE
EP711 QNZ0136-001Z EARTH PLATE
Parts number Parts name Area
Remarks
Block No. 01
Item
A
EP951 QNZ0136-001Z EARTH PLATE
FC901 QNG0003-001Z FUSE CLIP
FC902 QNG0003-001Z FUSE CLIP
FW601 QUM133-10DGZ4 PARA RIBON WIRE TO CN704
FW701 QUM138-26DGZ4 PARA RIBON WIRE TO CN951&CN952
FW801 QUM136-16DGZ4 PARA RIBON WIRE TO CN971&CN972
FW802 QUM133-15Z4Z4 PARA RIBON WIRE TO FW841(SHUT
IC701 MN101C12GHC IC SYSTEM MICOM
IC702 IC-PST9140-T IC
IC703 MN35503-X IC
IC704 TC7S08F-W IC .
IC711 BA41W12ST-V5 IC
A
IC741 NJM4580M-X IC
IC751 NJM4580M-X IC
IC791 AK93C45AF-W IC
IC801 GP1U271X RM RECIVER
IC802 M35500BGP FL DRIVER
IC901 STR-G6651 IC
A
IC951 PQ05RD21 IC
IC953 NJM78M05FA IC
A
J 601 QNN0317-001 PIN JACK COMPONENT
J 602 QNZ0430-001 AV JACK S-OUT&VIDEO
J 701 QNN0170-002 PIN JACK AUDIO OUT
J 702 QNS0083-001 3.5 JACK AV COMPULINK
J 703 GP1FA550TZ OPT TRANSMITTER OPT DIGITAL OUT
J 704 QNN0347-001 PIN JACK COAXIAL DIGITAL
K 601 QQR0601-001Z FERRITE BEADS
K 603 QQR0601-001Z FERRITE BEADS
K 701 NQR0227-004X FERRITE BEADS
K 702 NQR0227-004X FERRITE BEADS
K 703 NQR0227-004X FERRITE BEADS
K 704 NQR0227-004X FERRITE BEADS
K 706 NQR0227-004X FERRITE BEADS
K 708 NQR0227-004X FERRITE BEADS
K 902 QQR0601-001Z FERRITE BEADS
L 601 QQL071J-120Y INDUCTOR
L 602 QQL071J-5R6Y INDUCTOR
L 611 QQL071J-120Y INDUCTOR
L 612 QQL071J-5R6Y INDUCTOR
L 621 QQL071J-120Y INDUCTOR
L 622 QQL071J-5R6Y INDUCTOR
L 631 QQL071J-120Y INDUCTOR
L 632 QQL071J-5R6Y INDUCTOR
L 641 QQL071J-120Y INDUCTOR
L 642 QQL071J-5R6Y INDUCTOR
L 709 QQL071J-2R2Y INDUCTOR
L 710 QQL071J-221Y INDUCTOR
L 731 QQL071J-1R2Y INDUCTOR
L 901 QQR0894-001 LINE FILTER
A
L 951 QQL01BK-R22Z P COIL
L 952 QQL31AK-101Z INDUCTOR
L 955 QQL31AK-101Z INDUCTOR
L 957 QQL31AK-101Z INDUCTOR
L 959 QQL31AK-101Z INDUCTOR
P 901 QNC0046-001 AC INLET
PC901 PC123FY IC(PHOTO COUPLE
A
PC902 PC123FY IC(PHOTO COUPLE
A
Parts number Parts name Area
601 2SA1175/FE/-T TRANSISTOR
611 2SA1175/FE/-T TRANSISTOR
621 2SA1175/FE/-T TRANSISTOR
631 2SA1175/FE/-T TRANSISTOR
641 2SA1175/FE/-T TRANSISTOR
709 DTC114YKA-X CHIP D.TRANSIST
Remarks
3-11
XV-M565BK/M567GD
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list ( Main board )
Item
A
A
R 601 NRSA02J-270X MG RESISTOR
R 602 NRSA02J-391X MG RESISTOR
R 603 NRSA02J-270X MG RESISTOR
R 604 NRSA02J-391X MG RESISTOR
R 605 NRSA02J-221X MG RESISTOR
R 606 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 609 NRSA02J-750X MG RESISTOR
R 611 NRSA02J-270X MG RESISTOR
R 612 NRSA02J-391X MG RESISTOR
R 613 NRSA02J-270X MG RESISTOR
R 614 NRSA02J-391X MG RESISTOR
R 615 NRSA02J-221X MG RESISTOR
R 616 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 619 NRSA02J-750X MG RESISTOR
R 621 NRSA02J-751X MG RESISTOR
R 622 NRSA02J-751X MG RESISTOR
R 623 NRSA02J-751X MG RESISTOR
R 624 NRSA02J-751X MG RESISTOR
R 625 NRSA02J-221X MG RESISTOR
R 629 NRSA02J-750X MG RESISTOR
R 631 NRSA02J-680X MG RESISTOR
R 632 NRSA02J-391X MG RESISTOR
R 633 NRSA02J-680X MG RESISTOR
R 634 NRSA02J-391X MG RESISTOR
R 635 NRSA02J-221X MG RESISTOR
R 636 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 639 NRSA02J-750X MG RESISTOR
R 641 NRSA02J-751X MG RESISTOR
R 642 NRSA02J-751X MG RESISTOR
R 643 NRSA02J-751X MG RESISTOR
R 644 NRSA02J-751X MG RESISTOR
R 645 NRSA02J-221X MG RESISTOR
R 649 NRSA02J-750X MG RESISTOR
R 650 QRE141J-561Y C RESISTOR 560 5% 1/4W
R 651 QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 659 NRSA02J-750X MG RESISTOR
R 701 NRSA02J-102X MG RESISTOR
R 702 NRSA02J-472X MG RESISTOR
R 703 NRSA02J-105X MG RESISTOR
R 704 NRSA02J-102X MG RESISTOR
R 705 NRSA02J-2R2X MG RESISTOR
R 706 NRSA02J-104X MG RESISTOR
R 707 NRSA02J-101X MG RESISTOR
R 708 NRSA02J-101X MG RESISTOR
R 709 NRSA02J-103X MG RESISTOR
R 711 NRSA02J-560X MG RESISTOR
R 712 NRSA02J-560X MG RESISTOR
Parts number Parts name Area
711 DTA114EKA-X DIGITAL.TRANSIS
741 2SC3576-JVC-T TRANSISTOR I/M FRE
743 2SC3576-JVC-T TRANSISTOR I/M AMUTE1
751 2SC3576-JVC-T TRANSISTOR I/M FRE
753 2SC3576-JVC-T TRANSISTOR I/M AMUTE1
791 DTA114EKA-X DIGITAL.TRANSIS
821 DTC124EKA-X TRANSISTOR
822 DTC124EKA-X TRANSISTOR
823 DTC124EKA-X TRANSISTOR
951 2SC2060/QR/-T TRANSISTOR
952 DTA144EKA-X TRANSISTOR
953 2SA1175/FE/-T TRANSISTOR
964 2SB1565/EF/ TRANSISTOR
965 2SC2785/FE/-T TRANSISTOR
966 2SA1175/FE/-T TRANSISTOR
991 2SC2785/FE/-T TRANSISTOR
Remarks
Block No. 01
Item
A
R 713 NRSA02J-560X MG RESISTOR
R 714 NRSA02J-152X MG RESISTOR
R 715 NRSA02J-560X MG RESISTOR
R 716 NRSA02J-152X MG RESISTOR
R 717 NRSA02J-101X MG RESISTOR
R 718 NRSA02J-0R0X MG RESISTOR
R 719 NRSA02J-0R0X MG RESISTOR
R 720 NRSA02J-0R0X MG RESISTOR
R 721 NRSA02J-471X MG RESISTOR
R 722 NRSA02J-471X MG RESISTOR
R 723 NRSA02J-471X MG RESISTOR
R 724 NRSA02J-471X MG RESISTOR
R 725 NRSA02J-511X MG RESISTOR
R 726 NRSA02J-471X MG RESISTOR
R 727 NRSA02J-102X MG RESISTOR
R 728 NRSA02J-471X MG RESISTOR
R 729 NRSA02J-471X MG RESISTOR
R 730 NRSA02J-333X MG RESISTOR
R 731 NRSA02J-102X MG RESISTOR
R 732 NRSA02J-333X MG RESISTOR
R 733 NRSA02J-104X MG RESISTOR
R 734 NRSA02J-333X MG RESISTOR
R 735 NRSA02J-104X MG RESISTOR
R 736 NRSA02J-181X MG RESISTOR
R 737 NRSA02J-104X MG RESISTOR
R 738 NRSA02J-153X MG RESISTOR
R 739 NRSA02J-102X MG RESISTOR
R 740 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 741 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 742 QRE141J-163Y C RESISTOR 16K 5% 1/4W
R 743 QRE141J-163Y C RESISTOR 16K 5% 1/4W
R 744 NRSA02J-682X MG RESISTOR
R 745 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 746 NRSA02J-821X MG RESISTOR
R 747 NRSA02J-362X MG RESISTOR
R 748 NRSA02J-561X MG RESISTOR
R 749 NRSA02J-103X MG RESISTOR
R 750 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 751 QRE141J-243Y C RESISTOR 24K 5% 1/4W
R 752 QRE141J-163Y C RESISTOR 16K 5% 1/4W
R 753 QRE141J-163Y C RESISTOR 16K 5% 1/4W
R 754 NRSA02J-682X MG RESISTOR
R 755 QRE141J-183Y C RESISTOR 18K 5% 1/4W
R 756 NRSA02J-821X MG RESISTOR
R 757 NRSA02J-362X MG RESISTOR
R 758 NRSA02J-561X MG RESISTOR
R 759 NRSA02J-103X MG RESISTOR
R 760 NRSA02J-105X MG RESISTOR
R 761 NRSA02J-561X MG RESISTOR
R 762 NRSA02J-821X MG RESISTOR
R 764 NRSA02J-183X MG RESISTOR
R 765 NRSA02J-561X MG RESISTOR
R 766 NRSA02J-273X MG RESISTOR
R 767 NRSA02J-151X MG RESISTOR
R 768 NRSA02J-103X MG RESISTOR
R 770 NRSA02J-105X MG RESISTOR
R 771 NRSA02J-561X MG RESISTOR
R 772 NRSA02J-821X MG RESISTOR
R 774 NRSA02J-183X MG RESISTOR
R 775 NRSA02J-561X MG RESISTOR
R 776 NRSA02J-273X MG RESISTOR
R 777 NRSA02J-151X MG RESISTOR
R 778 NRSA02J-103X MG RESISTOR
Parts number Parts name Area
Remarks
3-12
XV-M565BK/M567GD
Electrical parts list ( Main board )
Item
A
R 782 NRSA02J-221X MG RESISTOR
R 783 NRSA02J-221X MG RESISTOR
R 786 NRSA02J-333X MG RESISTOR
R 788 NRSA02J-222X MG RESISTOR
R 789 NRSA02J-222X MG RESISTOR
R 792 NRSA02J-221X MG RESISTOR
R 793 NRSA02J-221X MG RESISTOR
R 796 NRSA02J-472X MG RESISTOR
R 797 NRSA02J-473X MG RESISTOR
R 798 NRSA02J-473X MG RESISTOR
R 801 NRSA02J-222X MG RESISTOR
R 802 NRSA02J-222X MG RESISTOR
R 803 NRSA02J-222X MG RESISTOR
R 804 NRSA02J-222X MG RESISTOR
R 805 NRSA02J-222X MG RESISTOR
R 806 NRSA02J-102X MG RESISTOR
R 807 NRSA02J-102X MG RESISTOR
R 808 NRSA02J-102X MG RESISTOR
R 809 NRSA02J-102X MG RESISTOR
R 810 NRSA02J-102X MG RESISTOR
R 811 NRSA02J-102X MG RESISTOR
R 812 NRSA02J-102X MG RESISTOR
R 813 NRSA02J-102X MG RESISTOR
R 821 NRSA02J-102X MG RESISTOR
R 825 NRSA02J-271X MG RESISTOR
R 826 NRSA02J-271X MG RESISTOR
R 827 NRSA02J-271X MG RESISTOR
R 830 NRSA02J-431X MG RESISTOR
R 831 NRSA02J-681X MG RESISTOR
R 832 NRSA02J-112X MG RESISTOR
R 833 NRSA02J-222X MG RESISTOR
R 840 NRSA02J-431X MG RESISTOR
R 841 NRSA02J-681X MG RESISTOR
R 842 NRSA02J-112X MG RESISTOR
R 843 NRSA02J-222X MG RESISTOR
R 844 NRSA02J-682X MG RESISTOR
R 845 NRSA02J-431X MG RESISTOR
R 846 NRSA02J-681X MG RESISTOR
R 847 NRSA02J-112X MG RESISTOR
R 848 NRSA02J-222X MG RESISTOR
R 849 NRSA02J-682X MG RESISTOR
R 900 NRSA02J-221X MG RESISTOR
R 901 QRL01DJ-683X OMF RESISTOR
A
R 903 QRE141J-270Y C RESISTOR
A
R 904 QRE141J-222Y C RESISTOR 2.2K 5% 1/4W
R 905 QRL027J-683 OMF RESISTOR 68K 5% 1/2W
R 906 QRE141J-681Y C RESISTOR 680 5% 1/4W
R 907 QRT022J-R47 OMF RESISTOR
A
R 908 QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 910 QRE141J-754Y C RESISTOR 750K 5% 1/4W
R 911 QRE141J-754Y C RESISTOR 750K 5% 1/4W
R 952 NRSA02J-103X MG RESISTOR
R 953 NRSA02J-103X MG RESISTOR
R 954 QRZ9006-4R7X F RESISTOR
A
R 955 NRSA02J-223X MG RESISTOR
R 956 QRE141J-100Y C RESISTOR 10 5% 1/4W
R 960 NRSA02J-101X MG RESISTOR
R 961 NRSA02J-681X MG RESISTOR
R 962 NRSA02J-105X MG RESISTOR
R 963 NRSA02J-101X MG RESISTOR
R 964 NRSA02J-105X MG RESISTOR
R 965 NRSA02J-103X MG RESISTOR
R 969 NRSA02J-221X MG RESISTOR
Parts number Parts name Area
68K 5% 1/1W
27 5% 1/4W
5% 1/2W
4.7 1/0W
Remarks
Block No. 01
Item
A
R 971 NRSA02J-472X MG RESISTOR
R 972 NRSA02J-152X MG RESISTOR
R 973 NRSA02J-102X MG RESISTOR
R 974 NRSA02J-562X MG RESISTOR
R 975 NRSA02J-562X MG RESISTOR
R 976 NRSA02J-221X MG RESISTOR
R 980 NRSA02J-272X MG RESISTOR
R1704 NRSA02J-103X MG RESISTOR
R1707 NRSA02J-222X MG RESISTOR
R1708 NRSA02J-222X MG RESISTOR
R1709 NRSA02J-102X MG RESISTOR
R1710 NRSA02J-102X MG RESISTOR
R1711 NRSA02J-102X MG RESISTOR
R1712 NRSA02J-331X MG RESISTOR
R1713 NRSA02J-101X MG RESISTOR
R1714 NRSA02J-472X MG RESISTOR
R1715 NRSA02J-103X MG RESISTOR
R1716 NRSA02J-102X MG RESISTOR
R1721 NRSA02J-331X MG RESISTOR
R1722 NRSA02J-750X MG RESISTOR
R1723 NRSA02J-270X MG RESISTOR
S 801 QSW0683-001Z PUSH SW I.M
S 811 QSW0683-001Z PUSH SW I.M
S 812 QSW0683-001Z PUSH SW I.M
S 813 QSW0683-001Z PUSH SW I.M
S 814 QSW0683-001Z PUSH SW I.M
S 815 QSW0683-001Z PUSH SW I.M
S 821 QSW0683-001Z PUSH SW I.M
S 822 QSW0683-001Z PUSH SW I.M
S 823 QSW0683-001Z PUSH SW I.M
S 824 QSW0683-001Z PUSH SW I.M
S 825 QSW0683-001Z PUSH SW I.M
S 826 QSW0683-001Z PUSH SW I.M
S 831 QSW0683-001Z PUSH SW I.M
S 832 QSW0683-001Z PUSH SW I.M
S 833 QSW0683-001Z PUSH SW I.M
S 834 QSW0683-001Z PUSH SW I.M
S 835 QSW0683-001Z PUSH SW I.M
S 836 QSW0683-001Z PUSH SW I.M
S 841 QVQ0123-B15 SHUTTLE VR
SP701 VYH7653-001 IC HOLDER FOR IC701
SP802 VYH7653-002 IC HOLDER FOR IC802
T 701 QQR0880-001 PULSE TRANS
T 901 QQS0028-001 SW TRANSF
A
X 701 QAX0356-001Z RESONATOR
Parts number Parts name Area
Remarks
3-13
XV-M565BK/M567GD
Electrical parts list ( Traverse mechanism control board )
Item
A
C 101 NCB31CK-104X C CAPACITOR
C 102 NEA70JM-476X E.CAPACITOR
C 103 NCB31CK-104X C CAPACITOR
C 104 NCS31HJ-560X C CAPACITOR
C 105 NCS31HJ-101X C.CAPACITOR
C 106 NEA71CM-106X E.CAPACITOR
C 107 NCB31CK-104X C CAPACITOR
C 108 NCB31CK-104X C CAPACITOR
C 109 NCB31CK-104X C CAPACITOR
C 110 NCS31HJ-101X C.CAPACITOR
C 111 NCB21CK-184X C CAPACITOR
C 112 NCB31CK-104X C CAPACITOR
C 113 NCB31CK-104X C CAPACITOR
C 114 NCB31CK-104X C CAPACITOR
C 115 NCB31HK-392X C CAPACITOR
C 116 NCB31CK-104X C CAPACITOR
C 117 NCB11CK-105X C CAPACITOR
C 118 NEX40JM-336X E CAPACITOR
C 119 NCB31CK-104X C CAPACITOR
C 120 NCB31CK-104X C CAPACITOR
C 121 NCB21CK-334X C CAPACITOR
C 122 NCS31HJ-121X C CAPACITOR
C 123 NCB31CK-104X C CAPACITOR
C 124 NCB31CK-104X C CAPACITOR
C 125 NCB31CK-104X C CAPACITOR
C 126 NCS31HJ-221X C CAPACITOR
C 127 NCS31HJ-221X C CAPACITOR
C 128 NCB31CK-104X C CAPACITOR
C 129 NCB21CK-224X C CAPACITOR
C 130 NCB31HK-102X C CAPACITOR
C 131 NCB31HK-681X C CAPACITOR
C 132 NCB31CK-104X C CAPACITOR
C 133 NEX40JM-566X E CAPACITOR
C 134 NCB11CK-105X C CAPACITOR
C 135 NCS31HJ-221X C CAPACITOR
C 136 NCB31CK-104X C CAPACITOR
C 137 NCB31CK-104X C CAPACITOR
C 138 NCB31CK-104X C CAPACITOR
C 139 NCB31CK-104X C CAPACITOR
C 140 NCB31CK-104X C CAPACITOR
C 141 NCS31HJ-820X C CAPACITOR
C 142 NCB31HK-222X C CAPACITOR
C 143 NCB21CK-224X C CAPACITOR
C 144 NCB31CK-104X C CAPACITOR
C 145 NCB11CK-105X C CAPACITOR
C 151 NEX40JM-156X E.CAPACITOR
C 152 NEX40JM-156X E.CAPACITOR
C 153 NCB31CK-104X C CAPACITOR
C 154 NCB31CK-104X C CAPACITOR
C 191 NCB31CK-104X C CAPACITOR
C 192 NEA70JM-107X E.CAPACITOR
C 201 NCB31CK-104X C CAPACITOR
C 202 NCB31CK-393X C CAPACITOR
C 203 NCB31CK-393X C CAPACITOR
C 204 NCB31CK-393X C CAPACITOR
C 205 NCB31CK-393X C CAPACITOR
C 206 NCB31CK-104X C CAPACITOR
C 208 NCB31CK-104X C CAPACITOR
C 209 NCB31CK-104X C CAPACITOR
C 210 NCB31CK-104X C CAPACITOR
C 211 NCB31CK-104X C CAPACITOR
C 212 NCB31CK-104X C CAPACITOR
C 213 NCB31CK-104X C CAPACITOR
Parts number Parts name Area
Remarks
Block No. 02
Item
A
C 214 NCB31CK-104X C CAPACITOR
C 215 NCB31HK-392X C CAPACITOR
C 217 NCB31HK-821X C CAPACITOR
C 218 NCB31HK-331X C CAPACITOR
C 219 NCB31HK-471X C CAPACITOR
C 221 NCB31HK-271X C CAPACITOR
C 222 NCB31HK-821X C CAPACITOR
C 223 NCB31HK-821X C CAPACITOR
C 224 NEA70JM-226X E CAPACITOR
C 225 NCB11CK-105X C CAPACITOR
C 226 NCB31CK-104X C CAPACITOR
C 227 NCB31CK-104X C CAPACITOR
C 228 NEA70JM-107X E.CAPACITOR
C 229 NCB11CK-105X C CAPACITOR
C 230 NCB31CK-104X C CAPACITOR
C 231 NCB31CK-104X C CAPACITOR
C 232 NCB31CK-104X C CAPACITOR
C 233 NCS31HJ-330X C CAPACITOR
C 234 NCB31HK-331X C CAPACITOR
C 235 NCB31CK-104X C CAPACITOR
C 236 NCB31CK-823X C CAPACITOR
C 237 NCB31CK-823X C CAPACITOR
C 241 NCB31CK-104X C CAPACITOR
C 242 NEA70JM-107X E.CAPACITOR
C 262 NCB31EK-332X C CAPACITOR
C 271 NCB31CK-104X C CAPACITOR
C 273 NCB31HK-102X C CAPACITOR
C 275 NCB31HK-102X C CAPACITOR
C 276 NCB31CK-104X C CAPACITOR
C 281 NEA70JM-226X E CAPACITOR
C 282 NCB31CK-104X C CAPACITOR
C 284 NCB31HK-102X C CAPACITOR
C 286 NCB31HK-102X C CAPACITOR
C 287 NCB31CK-104X C CAPACITOR
C 288 NEA71CM-226X E.CAPAP. C.M
C 290 NCB31CK-104X C CAPACITOR
C 301 NCB31CK-104X C CAPACITOR
C 302 NCB31CK-104X C CAPACITOR
C 303 NCB31CK-104X C CAPACITOR
C 304 NCB31CK-104X C CAPACITOR
C 305 NCB31CK-104X C CAPACITOR
C 306 NCB31CK-104X C CAPACITOR
C 307 NCB31CK-104X C CAPACITOR
C 308 NCB31CK-103X C CAPACITOR
C 309 NCB31CK-104X C CAPACITOR
C 310 NCB31CK-104X C CAPACITOR
C 311 NCB31CK-104X C CAPACITOR
C 314 NCB31CK-104X C CAPACITOR
C 315 NCB31CK-104X C CAPACITOR
C 316 NEA70JM-107X E.CAPACITOR
C 317 NCB11CK-105X C CAPACITOR
C 318 NCB31CK-104X C CAPACITOR
C 319 NCB31CK-104X C CAPACITOR
C 320 NCB31CK-104X C CAPACITOR
C 321 NCB31CK-104X C CAPACITOR
C 322 NEA70JM-107X E.CAPACITOR
C 323 NCB11CK-105X C CAPACITOR
C 324 NCB31CK-104X C CAPACITOR
C 341 NCB31CK-104X C CAPACITOR
C 342 NCB31CK-104X C CAPACITOR
C 343 NCB31CK-104X C CAPACITOR
C 344 NCB31CK-104X C CAPACITOR
C 371 NCS31HJ-100X C CAPACITOR
Parts number Parts name Area
Remarks
3-14
XV-M565BK/M567GD
Electrical parts list ( Traverse mechanism control board )
Item
A
C 372 NCS31HJ-100X C CAPACITOR
C 373 NCB31CK-104X C CAPACITOR
C 374 NCB31CK-104X C CAPACITOR
C 376 NCB31CK-104X C CAPACITOR
C 391 NCB31CK-104X C CAPACITOR
C 392 NEA70JM-226X E CAPACITOR
C 401 NCB31CK-104X C CAPACITOR
C 402 NCB31CK-104X C CAPACITOR
C 403 NEA70JM-226X E CAPACITOR
C 404 NCB31CK-104X C CAPACITOR
C 405 NCB31CK-104X C CAPACITOR
C 406 NCB31CK-104X C CAPACITOR
C 407 NCB31CK-104X C CAPACITOR
C 408 NEA70JM-226X E CAPACITOR
C 409 NCB31CK-104X C CAPACITOR
C 411 NCB31CK-104X C CAPACITOR
C 412 NCB31CK-104X C CAPACITOR
C 441 NCB31CK-104X C CAPACITOR
C 442 NEX40JM-156X E.CAPACITOR
C 452 NCB31CK-104X C CAPACITOR
C 501 NCB31CK-104X C CAPACITOR
C 502 NCB31CK-104X C CAPACITOR
C 503 NCB31CK-104X C CAPACITOR
C 504 NCB31CK-104X C CAPACITOR
C 505 NCB31CK-104X C CAPACITOR
C 506 NCB31CK-104X C CAPACITOR
C 507 NCB31CK-104X C CAPACITOR
C 508 NCB31CK-104X C CAPACITOR
C 509 NCB31CK-104X C CAPACITOR
C 510 NCB31CK-104X C CAPACITOR
C 511 NCB31CK-104X C CAPACITOR
C 512 NCB31CK-104X C CAPACITOR
C 513 NCB31CK-104X C CAPACITOR
C 514 NCB31CK-104X C CAPACITOR
C 515 NCB31CK-104X C CAPACITOR
C 516 NCB31CK-104X C CAPACITOR
C 517 NCB31CK-104X C CAPACITOR
C 518 NCB31CK-104X C CAPACITOR
C 519 NCB31CK-104X C CAPACITOR
C 520 NCB31CK-104X C CAPACITOR
C 521 NCB31CK-104X C CAPACITOR
C 522 NCB31CK-104X C CAPACITOR
C 523 NCB31CK-104X C CAPACITOR
C 524 NCB31CK-104X C CAPACITOR
C 525 NCB31CK-104X C CAPACITOR
C 526 NCB31CK-104X C CAPACITOR
C 527 NCB31CK-104X C CAPACITOR
C 528 NCB31CK-104X C CAPACITOR
C 529 NCB31CK-104X C CAPACITOR
C 530 NEA70JM-107X E.CAPACITOR
C 531 NCB31CK-104X C CAPACITOR
C 532 NCB31CK-104X C CAPACITOR
C 533 NCB31CK-104X C CAPACITOR
C 534 NEA70JM-107X E.CAPACITOR
C 535 NCB31CK-104X C CAPACITOR
C 536 NCB31CK-103X C CAPACITOR
C 537 NEA70JM-226X E CAPACITOR
C 538 NCB31CK-104X C CAPACITOR
C 539 NCB31CK-104X C CAPACITOR
C 540 NEA70JM-226X E CAPACITOR
C 541 NCB31CK-104X C CAPACITOR
C 542 NEA70JM-226X E CAPACITOR
C 543 NCB31CK-104X C CAPACITOR
Parts number Parts name Area
Remarks
Block No. 02
Item
A
C 556 NEA70JM-107X E.CAPACITOR
C 557 NCB31CK-104X C CAPACITOR
C 561 NCB31CK-104X C CAPACITOR
C 562 NEA70JM-226X E CAPACITOR
C 563 NCB31CK-104X C CAPACITOR
C 564 NCB31CK-104X C CAPACITOR
C 565 NCB31CK-104X C CAPACITOR
C 566 NCB31CK-104X C CAPACITOR
C 567 NEA70JM-226X E CAPACITOR
C 568 NCB31CK-104X C CAPACITOR
C 569 NEA70JM-226X E CAPACITOR
C 570 NCB31CK-104X C CAPACITOR
CN101 QGF1016F2-19W CONNECTOR MECHA
CN102 QGF1016C2-11W CONNECTOR SP&STP
CN501 QGA2001F2-09X CONNECTOR POWER
CN502 QGF1016F2-23W CONNECTOR SYSTEM
CN503 QGF1016F2-09W CONNECTOR C.M VIDEO
D 201 1SS355-X DIODE
D 272 DAN202K-X D.TRANSISTOR
D 551 1SS355-X DIODE
D 552 1SS355-X DIODE
IC101 AN8706FHQ IC
IC102 RN5RZ20BA-X IC
IC201 MN67705EA IC
IC271 M56788FP-W IC
IC301 MN103007BGA IC
IC311 TC7SH08FU-X IC
IC312 TC7SH32FU-X IC
IC321 TC7WH74FU-X IC
IC322 TC74VHC00FT-X IC
IC371 TC7SHU04FU-X IC(DIGITAL)
IC372 TC7SHU04FU-X IC(DIGITAL)
IC374 TC7WH74FU-X IC
IC401 MN102L25GHB IC C.M u-h
IC402 MSM531622F75G-X IC C.M
IC403 AK93C65AF-X IC
IC452 TC7WT125FU-X IC(DIGITAL)
IC501 ZIVA3-PE0 IC
IC502 NAX0265-001X IC 27MHZ
IC503 TC74VHC00FT-X IC
IC504 KM416S1120DT-G8 IC
IC505 KM416S1120DT-G8 IC
IC554 MC44724AVFU IC
K 101 NQR0007-002X FERRITE BEADS
K 102 NQR0007-002X FERRITE BEADS
K 103 NQR0007-002X FERRITE BEADS
K 155 NQR0007-002X FERRITE BEADS
K 156 NQR0007-002X FERRITE BEADS
K 157 NQR0007-002X FERRITE BEADS
K 158 NQR0007-002X FERRITE BEADS
K 159 NQR0007-002X FERRITE BEADS
K 160 NQR0007-002X FERRITE BEADS
K 201 NQR0007-002X FERRITE BEADS
K 202 NQR0007-002X FERRITE BEADS
K 271 NQR0007-002X FERRITE BEADS
K 301 NQR0007-002X FERRITE BEADS
K 302 NQR0007-002X FERRITE BEADS
K 371 NQR0007-002X FERRITE BEADS
K 401 NQR0007-002X FERRITE BEADS
K 402 NQR0007-002X FERRITE BEADS
K 501 NQR0007-002X FERRITE BEADS
K 502 NQR0007-002X FERRITE BEADS
K 503 NQR0007-002X FERRITE BEADS
Parts number Parts name Area
Remarks
3-15
XV-M565BK/M567GD
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list ( Traverse mechanism control board )
Item
A
K 504 NQR0201-001X FERRITE BEADS
K 505 NQR0269-001X FERRITE BEADS
K 506 NQR0007-002X FERRITE BEADS
K 550 NQR0007-002X FERRITE BEADS
K 551 NQR0007-002X FERRITE BEADS
K 553 NQR0007-002X FERRITE BEADS
K 554 NQR0007-002X FERRITE BEADS
K 555 NQR0007-002X FERRITE BEADS
K 556 NQR0007-002X FERRITE BEADS
K 557 NQR0007-002X FERRITE BEADS
K 558 NQR0007-002X FERRITE BEADS
K 559 NQR0007-002X FERRITE BEADS
K 561 NQR0007-002X FERRITE BEADS
K 562 NQR0007-002X FERRITE BEADS
K 563 NQR0007-002X FERRITE BEADS
K 564 NQR0007-002X FERRITE BEADS
K 565 NQR0007-002X FERRITE BEADS
K 566 NQR0007-002X FERRITE BEADS
K 567 NQR0007-002X FERRITE BEADS
K 568 NQR0007-002X FERRITE BEADS
K 569 NQR0007-002X FERRITE BEADS
K 570 NQR0007-002X FERRITE BEADS
K 571 NQR0007-002X FERRITE BEADS
K 572 NQR0007-002X FERRITE BEADS
K 574 NQR0007-002X FERRITE BEADS
K 575 NQR0007-002X FERRITE BEADS
K 576 NQR0007-002X FERRITE BEADS
K 577 NQR0007-002X FERRITE BEADS
K 578 NQR0007-002X FERRITE BEADS
K 579 NQR0007-002X FERRITE BEADS
K 580 NQR0007-002X FERRITE BEADS
K 581 NQR0007-002X FERRITE BEADS
L 191 NQL044K-100X INDUCTOR
L 241 NQL044K-100X INDUCTOR
R 101 NRS125J-270X MG RESISTOR
R 102 NRS125J-2R2X MG RESISTOR
R 103 NRSA63J-123X MG RESISTOR
R 104 NRSA63J-103X MG RESISTOR
R 106 NRSA63J-223X MG RESISTOR
R 108 NRSA63J-103X MG RESISTOR
R 109 NRSA63J-823X MG RESISTOR
R 110 NRSA63J-393X MG RESISTOR
R 112 NRVA63D-123X MG RESISTOR
R 113 NRSA63J-393X MG RESISTOR
R 114 NRSA63J-272X MG RESISTOR
R 115 NRSA63J-223X MG RESISTOR
R 116 NRSA63J-103X MG RESISTOR
R 117 NRSA63J-223X MG RESISTOR
R 118 NRSA63J-153X MG RESISTOR
R 119 NRSA63J-155X MG RESISTOR
R 120 NRVA63D-332X MF RESISTOR
R 121 NRSA63J-474X MG RESISTOR
R 122 NRSA63J-474X MG RESISTOR
R 123 NRSA63J-822X MG RESISTOR
R 124 NRSA63J-183X MG RESISTOR
Parts number Parts name Area
101 2SB1424/QR/-X TRANSISTOR
102 DTC124EE-X DIGI TRANSISTOR
103 DTA124EE-X DIGI TRANSISTOR
104 DTC124EE-X DIGI TRANSISTOR
105 DTC144EE-X TRANSISTOR
251 DTC144EE-X TRANSISTOR
252 DTA144EE-X DIGI TRANSISTOR
254 DTC144EE-X TRANSISTOR
Remarks
Block No. 02
Item
A
R 125 NRSA63J-154X MG RESISTOR
R 126 NRSA63J-564X MG RESISTOR
R 127 NRSA63J-123X MG RESISTOR
R 128 NRSA63J-223X MG RESISTOR
R 129 NRSA63J-103X MG RESISTOR
R 130 NRSA63J-822X MG RESISTOR
R 131 NRSA63J-0R0X MG RESISTOR
R 201 NRSA63J-102X MG RESISTOR
R 202 NRSA63J-102X MG RESISTOR
R 203 NRSA63J-102X MG RESISTOR
R 204 NRSA63J-102X MG RESISTOR
R 205 NRSA63J-473X MG RESISTOR
R 206 NRSA63J-103X MG RESISTOR
R 207 NRSA63J-473X MG RESISTOR
R 209 NRSA63J-473X MG RESISTOR
R 210 NRSA63J-473X MG RESISTOR
R 211 NRSA63J-102X MG RESISTOR
R 212 NRSA63J-102X MG RESISTOR
R 213 NRSA63J-183X MG RESISTOR
R 214 NRSA63J-822X MG RESISTOR
R 215 NRSA63J-473X MG RESISTOR
R 216 NRSA63J-473X MG RESISTOR
R 217 NRSA63J-0R0X MG RESISTOR
R 218 NRSA63J-0R0X MG RESISTOR
R 219 NRSA63J-0R0X MG RESISTOR
R 220 NRSA63J-472X MG RESISTOR
R 221 NRSA63J-0R0X MG RESISTOR
R 222 NRSA63J-0R0X MG RESISTOR
R 223 NRSA63J-0R0X MG RESISTOR
R 224 NRSA63J-0R0X MG RESISTOR
R 225 NRSA63J-0R0X MG RESISTOR
R 226 NRSA63J-0R0X MG RESISTOR
R 227 NRSA63J-0R0X MG RESISTOR
R 228 NRSA63J-103X MG RESISTOR
R 229 NRSA63J-0R0X MG RESISTOR
R 230 NRSA63J-103X MG RESISTOR
R 231 NRVA63D-683X MF RESISTOR
R 232 NRVA63D-683X MF RESISTOR
R 233 NRSA63J-103X MG RESISTOR
R 234 NRSA63J-103X MG RESISTOR
R 235 NRSA63J-473X MG RESISTOR
R 236 NRSA63J-123X MG RESISTOR
R 237 NRSA63J-0R0X MG RESISTOR
R 238 NRSA63J-223X MG RESISTOR
R 239 NRSA63J-333X MG RESISTOR
R 240 NRSA63J-333X MG RESISTOR
R 241 NRVA63D-362X MG RESISTOR
R 242 NRSA63J-102X MG RESISTOR
R 243 NRSA63J-472X MG RESISTOR
R 244 NRSA63J-102X MG RESISTOR
R 245 NRVA63D-123X MG RESISTOR
R 247 NRVA63D-123X MG RESISTOR
R 249 NRSA63J-102X MG RESISTOR
R 251 NRVA63D-123X MG RESISTOR
R 252 NRVA63D-123X MG RESISTOR
R 253 NRVA63D-123X MG RESISTOR
R 254 NRVA63D-123X MG RESISTOR
R 257 NRSA63J-103X MG RESISTOR
R 266 NRSA63J-223X MG RESISTOR
R 268 NRSA63J-563X MG RESISTOR
R 269 NRSA63J-0R0X MG RESISTOR
R 270 NRSA63J-393X MG RESISTOR
R 271 NRSA63J-243X MG RESISTOR
Parts number Parts name Area
Remarks
3-16
XV-M565BK/M567GD
Electrical parts list ( Traverse mechanism control board )
Item
A
R 272 NRSA63J-103X MG RESISTOR
R 273 NRSA63J-103X MG RESISTOR
R 275 NRSA63J-243X MG RESISTOR
R 276 NRSA63J-103X MG RESISTOR
R 277 NRSA63J-103X MG RESISTOR
R 278 NRSA63J-223X MG RESISTOR
R 279 NRSA63J-223X MG RESISTOR
R 282 NRSA63J-223X MG RESISTOR
R 283 NRSA63J-103X MG RESISTOR
R 284 NRSA63J-103X MG RESISTOR
R 285 NRSA63J-0R0X MG RESISTOR
R 286 NRSA63J-223X MG RESISTOR
R 287 NRSA63J-103X MG RESISTOR
R 288 NRSA63J-103X MG RESISTOR
R 290 NRSA63J-0R0X MG RESISTOR
R 301 NRSA63J-473X MG RESISTOR
R 302 NRSA63J-473X MG RESISTOR
R 303 NRSA63J-473X MG RESISTOR
R 304 NRSA63J-473X MG RESISTOR
R 305 NRSA63J-473X MG RESISTOR
R 306 NRSA63J-473X MG RESISTOR
R 307 NRSA63J-473X MG RESISTOR
R 308 NRSA63J-473X MG RESISTOR
R 310 NRSA63J-102X MG RESISTOR
R 311 NRSA63J-102X MG RESISTOR
R 312 NRSA63J-102X MG RESISTOR
R 313 NRSA63J-0R0X MG RESISTOR
R 314 NRSA63J-0R0X MG RESISTOR
R 315 NRSA63J-0R0X MG RESISTOR
R 317 NRSA63J-473X MG RESISTOR
R 318 NRSA63J-0R0X MG RESISTOR
R 319 NRSA63J-0R0X MG RESISTOR
R 322 NRSA63J-473X MG RESISTOR
R 324 NRSA63J-473X MG RESISTOR
R 328 NRSA63J-473X MG RESISTOR
R 342 NRSA63J-0R0X MG RESISTOR
R 343 NRSA63J-102X MG RESISTOR
R 371 NRSA63J-105X MG RESISTOR
R 372 NRSA63J-101X MG RESISTOR
R 373 NRSA63J-0R0X MG RESISTOR
R 403 NRSA63J-472X MG RESISTOR
R 405 NRSA63J-472X MG RESISTOR
R 408 NRSA63J-472X MG RESISTOR
R 410 NRSA63J-0R0X MG RESISTOR
R 411 NRSA63J-472X MG RESISTOR
R 412 NRSA63J-103X MG RESISTOR
R 413 NRSA63J-472X MG RESISTOR
R 414 NRSA63J-472X MG RESISTOR
R 415 NRSA63J-472X MG RESISTOR
R 416 NRSA63J-472X MG RESISTOR
R 418 NRSA63J-472X MG RESISTOR
R 420 NRSA63J-0R0X MG RESISTOR
R 422 NRSA63J-0R0X MG RESISTOR
R 423 NRSA63J-0R0X MG RESISTOR
R 424 NRSA63J-0R0X MG RESISTOR
R 431 NRSA63J-472X MG RESISTOR
R 432 NRSA63J-472X MG RESISTOR
R 461 NRSA63J-0R0X MG RESISTOR
R 462 NRSA63J-0R0X MG RESISTOR
R 501 NRSA63J-102X MG RESISTOR
R 502 NRSA63J-222X MG RESISTOR
R 503 NRSA63J-103X MG RESISTOR
R 504 NRSA63J-330X MG RESISTOR
R 505 NRSA63J-330X MG RESISTOR
Parts number Parts name Area
Remarks
Block No. 02
Item
A
R 506 NRSA63J-330X MG RESISTOR
R 507 NRSA63J-330X MG RESISTOR
R 508 NRSA63J-330X MG RESISTOR
R 509 NRSA63J-330X MG RESISTOR
R 510 NRSA63J-330X MG RESISTOR
R 511 NRSA63J-330X MG RESISTOR
R 512 NRSA63J-330X MG RESISTOR
R 513 NRSA63J-330X MG RESISTOR
R 514 NRSA63J-330X MG RESISTOR
R 515 NRSA63J-330X MG RESISTOR
R 516 NRSA63J-330X MG RESISTOR
R 517 NRSA63J-330X MG RESISTOR
R 518 NRSA63J-330X MG RESISTOR
R 519 NRSA63J-330X MG RESISTOR
R 520 NRSA63J-330X MG RESISTOR
R 521 NRSA63J-330X MG RESISTOR
R 522 NRSA63J-330X MG RESISTOR
R 523 NRSA63J-181X MG RESISTOR
R 524 NRSA63J-181X MG RESISTOR
R 525 NRSA63J-181X MG RESISTOR
R 526 NRSA63J-181X MG RESISTOR
R 527 NRSA63J-181X MG RESISTOR
R 528 NRSA63J-181X MG RESISTOR
R 529 NRSA63J-181X MG RESISTOR
R 530 NRSA63J-181X MG RESISTOR
R 531 NRSA63J-330X MG RESISTOR
R 532 NRSA63J-0R0X MG RESISTOR
R 533 NRSA63J-330X MG RESISTOR
R 534 NRSA63J-330X MG RESISTOR
R 535 NRSA63J-330X MG RESISTOR
R 536 NRSA63J-330X MG RESISTOR
R 537 NRSA63J-330X MG RESISTOR
R 538 NRSA63J-330X MG RESISTOR
R 539 NRSA63J-330X MG RESISTOR
R 540 NRSA63J-330X MG RESISTOR
R 541 NRSA63J-0R0X MG RESISTOR
R 542 NRSA63J-0R0X MG RESISTOR
R 543 NRSA63J-0R0X MG RESISTOR
R 544 NRSA63J-0R0X MG RESISTOR
R 545 NRSA63J-472X MG RESISTOR
R 546 NRSA63J-332X MG RESISTOR
R 547 NRSA63J-222X MG RESISTOR
R 548 NRSA63J-332X MG RESISTOR
R 550 NRSA63J-0R0X MG RESISTOR
R 564 NRVA63D-152X MG RESISTOR
R 565 NRVA63D-332X MF RESISTOR
R 571 NRSA63J-100X MG RESISTOR
R 572 NRSA63J-181X MG RESISTOR
R 573 NRSA63J-181X MG RESISTOR
R 574 NRSA63J-181X MG RESISTOR
R 575 NRSA63J-181X MG RESISTOR
R 576 NRSA63J-181X MG RESISTOR
R 577 NRSA63J-181X MG RESISTOR
R 578 NRSA63J-181X MG RESISTOR
R 579 NRSA63J-181X MG RESISTOR
R 580 NRSA63J-181X MG RESISTOR
R 581 NRSA63J-101X MG RESISTOR
R 582 NRSA63J-0R0X MG RESISTOR
R 586 NRVA63D-122X MG RESISTOR
R 587 NRVA63D-122X MG RESISTOR
R 588 NRVA63D-102X CMF RESISTOR
R 589 NRVA63D-102X CMF RESISTOR
X 371 NAX0277-002X CRYSTAL
X 401 NAX0331-001X C RESONATOR
Parts number Parts name Area
Remarks
3-17
XV-M565BK/M567GD
QQ
QQ
QQ
QQ
Electrical parts list (DVD changer mechanism switch board)
Item Parts number Parts name Area
A
CN804QGB2016J1-07 CONNECTOR
SW 1QSW0507-001 SWITCH
SW 2QSW0507-001 SWITCH
SW 3QSW0507-001 SWITCH
SW 4QSW0507-001 SWITCH
SW 5QSW0507-001 SWITCH
SW 6QSW0507-001 SWITCH
Electrical parts list (Mechanism control board)
Item Parts number Parts name Area
A
C 801QEKC1AM-107Z E CAPACITOR 100MF 20% 10V
C 802QEK41EM-475 E CAPACITOR 4.7MF 20% 25V
C 803QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V
C 804QCFB1HZ-104Y C CAPACITOR .10MF +80:-20%
C 805QDYB1CM-103Y C CAPACITOR
C 806QEK41CM-476 E CAPACITOR 47MF 20% 16V
C 807QEK41CM-476 E CAPACITOR 47MF 20% 16V
C 808QFLC1HJ-102Z M CAPACITOR 1000PF 5% 50V
C 810QCZ0205-155Z ML C CAP I/M 1.5MF
C 811QCZ0205-155Z ML C CAP I/M 1.5MF
C 813QDYB1CM-103Y C CAPACITOR
C 821QDGB1HK-102Y C CAPACITOR
CN801QGF1205F1-10 CONNECTOR TO MICON
CN802QGB2016K1-07 CONNECTOR TO SWITCH PWB
CN803QGB2012K2-10 CONNECTOR TO CAM SW PWB
IC801 UPD65612GB-208IC
A
IC802 TA8409S IC
A
IC803 TA8409S IC
L 801
L 802
L 803
L 804
R 805QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 806QRE141J-471Y C RESISTOR 470 5% 1/4W
R 807QRE141J-471Y C RESISTOR 470 5% 1/4W
R 808QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 810QRE141J-684Y C RESISTOR 680K 5% 1/4W
R 811QRE141J-105Y C RESISTOR 1.0M 5% 1/4W
R 813QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 814QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 815QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 816QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 817QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 818QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 819QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 820QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 821QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 822QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 823QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 824QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 825QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 826QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 827QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 828QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 829QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 830QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 832QRE141J-181Y C RESISTOR 180 5% 1/4W
R 833QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 834QRE141J-102Y C RESISTOR 1.0K 5% 1/4W
R 838QRE141J-272Y C RESISTOR 2.7K 5% 1/4W
R 839QRE141J-332Y C RESISTOR 3.3K 5% 1/4W
R 840QRE141J-562Y C RESISTOR 5.6K 5% 1/4W
L231K-100Y INDUCTOR
L01BK-100Z INDUCTOR
L01BK-100Z INDUCTOR
L01BK-100Z INDUCTOR
3-18
Remarks
Remarks
Block No. 03
Block No. 04
Electrical parts list (Conection board)
Item Parts number Parts name Area
A
C 13 NCS21HJ-101X C CAPACITOR
C 14 NCS21HJ-101X C CAPACITOR
CN 10QGF1030F1-19 FFC/FPC CONNE
CN 11QGF1016F3-11 CONNECTOR
CN 12QGF1030F1-21 FFC/FPC CONNE
CN 13QGF1030F1-07 FFC/FPC CONNE
CN 14 VMC0159-002 SHORT CONNECTOR
CN 24 VMC0160-001 SHORT SOCKET FOR CN14
K 10 NQR0007-002X F.BEADS C.M
K 11 NQR0007-002X F.BEADS C.M
K 12 NQR0007-002X F.BEADS C.M
K 13 NQR0007-002X F.BEADS C.M
K 14 NQR0007-002X F.BEADS C.M
K 15 NQR0007-002X F.BEADS C.M
K 16 NQR0007-002X F.BEADS C.M
K 17 NQR0007-002X F.BEADS C.M
R 10 NRSA02J-911X MG RESISTOR
S 10QSW0620-001 SWITCH
Block No. 05
Remarks
Packing materials and accessories parts list
)
)
XV-M565BK/M567GD
Block No.
Block No.
M
M
4
M
M
5
M
M
Packing list
Item Parts number Parts name Area
A
P 1 QPA02503505P POLY BAG 1 ACCESSORY A
P 2 QPC06506515P POLY BAG 1 FOR SET
P 3 LV20509-201A CUSHION (F
P 4 LV20510-201A CUSHION (R
P 5 LV20822-001A CARTON BOX 1 XV-M565BK
Accessorys list
Item Parts number Parts name Area
A
A 1 LVT0521-001A INST BOOK J1
A 2 BT-51020-2 J=REGIST CARD 1
A 3 YU20333 SAFETY INST.
A
A 4 QMPE090-183-JD POWER CORD
A
A 5 BT-52004-1 WARRANTY CARD C1 XV-M565BK
A 6 EWP805-014 1P PLUG CORD(JE 1
A 7 QAM0004-002 S-VIDEO CORD 1
A 8 QAM0218-001 A/V CABLE 1
A 9 RM-SXVM567J REMOCON UNIT 1 XV-M567GD
A 10 ------------------- BATTERY 2
A 11 BT-20071B SVC-CENTER LIST C1 XV-M565BK
Block No. M4MM
Q'ty Description
1 FRONT
1 REAR
LV20822-008A PACKING CASE 1 XV-M567GD
Block No. M5MM
Q'ty Description
LVT0521-002A INST.BOOK C1 XV-M565BK
1
1
RM-SXVM565J REMOCON UNIT 1 XV-M565BK
3-19
Loading...
