Jvc XV-LTR1 Service Manual

SERVICE MANUAL

DVD VIDEO PLAYER

XV-LTR1

Area Suffix

J --------- U.S.A.

XV-LTR1

Contents

Safety precautions ------------------------ 1-2 Preventing static electricity ------------- 1-3 Importance admistering point on the safety ------------ 1-4 Precautions for service ----------------- 1-5

This service manual is printed on 100% recycled paper.

Disassembly method -------------------- 1-6 Adjustment method ---------------------- 1-15 Troubleshooting -------------------------- 1-19 Description of major ICs ---------------- 1-23

No.A0020

Nov. 2001

XV-LTR1

1. This design of this product contains special hardware and many circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services should be performed by qualified personnel only.

2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product should not be made. Any design alterations or additions will void the manufacturers warranty and will further relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.

3. Many electrical and mechanical parts in the products have special safety-related characteristics. These

characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in the Parts List of Service Manual. Electrical components having such features are identified by shading on the schematics and by ( ) on the Parts List in the Service Manual. The use of a substitute replacement which does not have the same safety characteristics as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or other hazards.

4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of electric shock and fire hazard. When service is required, the original lead routing and dress should be observed, and it should be confirmed that they have been returned to normal, after reassembling.

5. Leakage current check (Electrical shock hazard testing) After reassembling the product, always perform an isolation check on the exposed metal parts of the product (antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the product is safe to operate without danger of electrical shock. Do not use a line isolation transformer during this check.

Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).

Alternate check method Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor between an exposed metal part and a known good earth ground. Measure the AC voltage across the resistor with the AC voltmeter. Move the resistor connection to each exposed metal part, particularly any exposed metal part having a return path to the chassis, and measure the AC voltage across the resistor. Now, reverse the plug in the AC outlet and repeat each measurement. Voltage measured any must not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5 mA AC (r.m.s.).

0.15 F AC TYPE

1500 10W

Good earth ground

AC VOLTMETER (Having 1000 ohms/volts, or more sensitivity)

Place this probe on each exposed metal part.

!

1. This equipment has been designed and manufactured to meet international safety standards.

2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.

3. Repairs must be made in accordance with the relevant safety standards.

4. It is essential that safety critical components are replaced by approved parts.

5. If mains voltage selector is provided, check setting for local voltage.

Burrs formed during molding may be left over on some parts of the chassis. Therefore, pay attention to such burrs in the case of preforming repair of this system.

In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " " mark nearby are critical for safety. When replacing them, be sure to use the parts of the same type and rating as specified by the manufacturer. (Except the J and C version)

1-2

XV-LTR1

Preventing static electricity

Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.

1.1. Grounding to prevent damage by static electricity

Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as DVD players. Be careful to use proper grounding in the area where repairs are being performed.

1.1.1. Ground the workbench

1. Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the traverse unit (optical pickup) on it.

1.1.2. Ground yourself

1. Use an anti-static wrist strap to release any static electricity built up in your body.

(caption) Anti-static wrist strap

Conductive material (conductive sheet) or iron plate

1.1.3. Handling the optical pickup

1. In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical pickup are shorted. After replacement, return the shorted parts to their original condition. (Refer to the text.)

2. Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily destroy the laser diode.

1.2. Handling the traverse unit (optical pickup)

1. Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.

2. Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a time when attaching it to the connector.

3. Handle the flexible cable carefully as it may break when subjected to strong force.

4. It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it

1-3

XV-LTR1

Importance Admistering point on the Safety

PC902

D910

FC901

F901

FC902

R904

R908

J702

C904

P901

B7053

B7052

D901

C902

L901

C907

C905

R905

R907

B7314

B7211

R906

C906

C914

D908

PC901

R910

HS901

K902

B7054

IC901

C913

R903

B7140

D904

C918

D911

C916

B7037

B7040

D951

Q991

R960

R954

C992

B7041

D991

CP951

C960

C962

D960

L951

Q953

B7046

D950

R980

B7044

B7043

Q951

B7045

R956

R953

B5511

B7126

B7125

D31

PC30

J691

L710

B7058

B7313

R911

D903

R901

C909

B7320

D952

B7038

C963

C964

EP951

D30

B5719

CN702

Q744

L709

C737

B7124

B5512

C12

C908

C13

Q1

C984

D902

L957

T901

C982

C987

B7051

D956

D957

D954

D953

B7039

D973

C979

C965

L955

C997

L952

B7042

IC951

B7319

C966

B5701

B7049

C969

CP952

IC953

C978

B7131

B7130

B7129

B7127

B5720

B7128

B7329

B7048

C697

B7034

Q754

C738

B7036

CN555

C11

Q965

C989

L959

C15

L1

B5710

C17

D974

D972

Q966

R976

C996

C995

B5721

B7050

DI801

C821

C695

B7311

C696

B7209

B7210

Q611

B7312

R1731

Q601

D609

R606

C973

B5201

B5153

L612

L602

L611

D970

L601

L2

B7405

B7802

B5202

B7214

C16

C14

B5301

B5156

B5509

B7601

B5513

B5102

CN961

B5151

B5709

B5302

B7803

B5154

B5502

B5203

B7406

B5715

B7602

B5515

B5501

B5116

B7806

S691

B7123

B7139

C694

B7208

R616

D619

L621

B5155

B5303

B7315

RA703

B7607

B7207

B7502

B7122

B7035

R636

R650

Q621

B7033

D629

Q631

D639

L622

L632

L631

B7410

B5101

B7212

B5304

B7407

B7408

J604

B7029

B7030

B7309

B7403

B7032

B7951

B7801

B7206

B7120

,B7119

C985

B5110

B5111

B5112

B5113

B5114

B7604

B7213

B7316

RA702

B7031

B7402

B7308

B7307

B7136

B7221

B7306

B7305

B5517

B7135

B5152

R1732

B5104

CN701

B5205

B5503

B5504

B5505

B5506

B5713

B7411

B7412

B7416

B7413

B7415

B7414

B7133

B7409

B7809

B7808

B7807

B5305

B7317

RA701

J602

C609

C619

C747

C659

B7025

B7114

B7116

B7115

B7023

B7203

B7204

B7132

B7137

B7810

B7304

B7142

B7222

B7606

B7501

C745

B7401

D791

D792

B7022

C761

B7219

B7218

B5115

B7134

B7011

B7010

B7326

B7012

B7327

B7325

B7328

B7056

B7003

B7002

B7001

B7007

B7004

B7005

B7006

C728

B7217

X701

J601

C756

C757

C649

Q753

Q743

B7028

C746

B7201

B7202

B7057

B7303

B7302

B7301

B7113

C744

C749

C762

B7021

C741

C740

R745

B7016

B7009

B7008

B7141

B7013

C729

B7014

B7026

B7112

C742

R740

B7015

IC702

C629

C739

C755

C772

C754

C752

R755

R750

R753

R751

R752

C714

R741

C721

R743

C716

R742

C715

B7321

D701

C701

B7322

B7107

B7330

D709

R1730

B7111

B7324

B5707

B5708

B5704

B5703

C421

B5507

B5702

B5107

CN703

J703

C707

C1701

J603

T701

B7024

C750

C751

C730

C717

B7605

C711

B5514

B7055

B5108

B5109

D702

B7117

C1702

B7118

C771

C718

C731

K709

EP711

B7020

B7608

B5714

B7105

B7102

B7104

B7019

B7103

B7106

B5105

B7101

B7018

B5157

B7017

B5718

B5705

B5706

C422

B5508

B5106

Full Fuse Replacement Marking

Graphic symbol mark (This symbol means fast blow type fuse.)

should be read as follows ;

FUSE CAUTION

FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE ONLY WITH SAME TYPE AND RATING OF FUSES ;

F901 : 1.6 A / 125 V F901 : 1.6 A / 125 V

Marquage Pour Le Remplacement Complet De Fusible

Le symbole graphique (Ce symbole signifie fusible de type a fusion rapide.)

doit etre interprete comme suit ;

PRECAUTIONS SUR LES FUSIBLES

POUR UNE PROTECTION CONTINUE CONTRE DES RISQUES D'INCENDIE, REMPLACER SEULEMENT PAR UN FUSIBLE DU MEME TYPE ;

1-4

Precautions for Service

Handling of Traverse Unit and Laser Pickup

1. Do not touch any peripheral element of the pickup or the actuator.

2. The traverse unit and the pickup are precision devices and therefore must not be subjected to strong shock.

3. Do not use a tester to examine the laser diode. (The diode can easily be destroyed by the internal power supply of the tester.)

4. To replace the traverse unit, pull out the metal short pin for protection from charging.

5. When replacing the pickup, after mounting a new pickup, remove the solder on the short land which is provided at the center of the flexible wire to open the circuit.

6. Half-fixed resistors for laser power adjustment are adjusted in pairs at shipment to match the characteristics of the optical block. Do not change the setting of these half-fixed resistors for laser power adjustment.

Destruction of Traverse Unit and Laser Pickup by Static Electricity

Laser diodes are easily destroyed by static electricity charged on clothing

or the human body. Before repairing peripheral elements of the traverse unit or pickup, be sure to take the following electrostatic protection:

XV-LTR1

1. Wear an antistatic wrist wrap.

2. With a conductive sheet or a steel plate on the workbench on which the traverse unit or the pick up is to be repaired, ground the sheet or the plate.

3. After removing the flexible wire from the connector (CN101), short-circuit the flexible wire by the metal clip.

4. Short-circuit the laser diode by soldering the land which is provided at the center of the flexible wire for the pickup.

After completing the repair, remove the solder to open the circuit.

Please refer to "Fig.4" of "Disassembly method" for details.

Short circuit

Servo control board

1-5

XV-LTR1

Disassembly method

Removing the top cover (see Fig.1)

1.Remove the two screws A attaching the top cover on both sides of the body.

2.Remove the three screws B attaching the top cover on the back of the body.

3.Remove the top cover from the body by lifting the rear part of the top cover.

ATTENTION: Do not break the front panel tab fitted to the top cover.

Removing the mechanism assembly (see Fig.2,3)

* Prior to performing the following procedure, remove the top cover. * There is no need to remove the front panel assembly.

1.Remove the three screws C attaching the mechanism assembly on the bottom chassis.

2.Remove the two screws F attaching the lug wire and main board on the bottom chassis.

3.The servo control board is removed from the connector CN961 and CN701 connected with the main board respectively.

A x 2

F

Lug wire

CN703

Main board

Servo control board

B

Mechanism assembly

C

Fig.1

C

F

Fig.2

Mechanism

assembly

B

CN702

4.Remove the mechanism assembly by lifting the rear part of the mechanism assembly.

Removing the servo control board (see Fig.4)

* Prior to performing the following procedure, remove the top cover and mechanism assembly.

1.Disconnect the card wire from connector CN201 and CN202 on the servo control board respectively.

2.Disconnect the flexible wire from connector CN101 on the servo control board from pick-up.

< ATTENTION > At this time, please extract the wire after short-circuited of two places on the wire in part a with solder. Please remove the solder two places of part a after connecting the wire with CN101 when reassembling.

3.Two places in hook b are removed, the servo control board is lifted, and it is removed.

Hook b

CN701

Fig.3

Fig.4

CN961

Main board

Hook b

Servo control board

1-6

Removing the rear panel (see Fig.5)

XV-LTR1

*Prior to performing the following procedure, remove the top cover.

1.Remove the four screws D attaching the rear panel

on the back of the body.

Removing the front panel assembly (see Fig.6,7)

* Prior to performing the following procedure, remove the top cover. * There is no need to remove the mechanism assembly.

1.Remove the one screw E attaching the front panel

assembly on the bottom chassis.

2.Disconnect the wire from CN702 and CN703 on the

main board respectively.

3.Hook c and d are removed respectively, and the front

panel assembly is removed.

Front panel

assembly

Hook d

D

Hook c

Rear panel

D

Fig.5

Hook d

E

Fig.6

Removing the main board (see Fig.8)

* Prior to performing the following procedure, remove the top cover, mechanism assembly and rear panel.

1.Disconnect the wire from CN702 and CN703 on the

main board respectively.

2.Remove the four screws F attaching the main board

on the bottom chassis.

F

Mechanism assembly

CN703

Main board

F

CN703

Fig.7

Main board

CN702

F

CN702

Fig.8

F

1-7

XV-LTR1

Removing the clamper assembly

(See Fig.1)

1.

Remove the four screws A attaching the clamper assembly.

2.

Move the clamper in the direction of the arrow to release the two joints a on both sides.

ATTENTION:

When reattaching, fit the clamper to the two joints a.

Removing the tray (See Fig.2 and 3)

Prior to performing the following procedure, remove the clamper assembly.

1.

Push b of the slide cam into the slot on the left side of the loading base until it stops.

2.

Draw out the tray toward the front.

Joint a

A

Joint a

A

AA

Fig.1

ATTENTION:

Before reattaching the tray, slide the part c of the slide cam to the right as shown in Fig.3.

Clamper base

Push

Tray

b

Fig.2

Par t c

Slide cam

Fig.3

1-8

Removing the traverse mechanism assembly (See Fig.4 and 5)

XV-LTR1

Prior to performing the following procedure, remove the clamper assembly and the tray.

1.

Remove the four screws B attaching the traverse mechanism assembly.

ATTENTION:

Before reattaching the traverse mechanism assembly, pass the card wire extending from the spindle motor board through the notch d of the elevator.

Removing the elevator (See Fig.6 and 7)

Prior to performing the following procedure, remove the clamper assembly, the tray and the traverse mechanism assembly.

1.

Extend each bar e inside of the loading base outward and detach the elevator shaft.

B

Traverse mechanism assembly

B

BB

Fig.4

Traverse mechanism assembly

BB

Elevator

Notch d

ATTENTION:

Elevator

When reattaching, first fit the two shafts on the front of the elevator to the slots f of the slide cam.

Shafts

Slide cam

Elevator

Fig.5

e

Elevator

Loading base

Slots f

e

Fig.6Fig.7

1-9

XV-LTR1

Removing the motor assembly

(See Fig.8 and 9)

Prior to performing the following procedure, remove the clamper assembly, the tray, the traverse mechanism assembly and the elevator.

1.

Remove the belt from the pulley.

2.

Remove the screw C attaching the motor assembly.

3.

Turn over the body and remove the screw D attaching the motor assembly.

4.

Release the two tabs g retaining the motor board.

Belt

C

Motor assembly

Fig.8

Tabs g

Motor assembly

D

Loading base

Fig.9

1-10

XV-LTR1

Pulley gear

Pulley gear bracket

Motor assembly

Pulley gear bracket

E

Idle gear

Fig.10

Idle gear

Pulley gear

Tads h

Pulley gear

Removing the Idle gear / pulley gear / middle gear / slide cam (See Fig.10 to 12)

Prior to performing the following procedure, remove the clamper assembly, the tray, the traverse mechanism assembly, the elevator and the motor assembly.

1.

Press the two tabs h inward and pull out the idle gear.

2.

Remove the screw E attaching the pulley gear bracket. Slide the pulley gear bracket in the direction of the arrow and pull out the pulley gear.

3.

Slide the slide cam in the direction of the arrow to release the two joints i and remove upward.

4.

Remove the middle gear.

Slide cam

Joint i

Slide cam

Middle gear

Joint i

Fig.11

Middle gear

Fig.12

Loading base

1-11

XV-LTR1

Removing the feed motor assembly

(See Fig.13)

1.

Unsolder the two soldering j on the spindle motor board.

2.

Remove the two screws F attaching the feed motor assembly.

Removing the feed motor

(See Fig.13 to 15)

Prior to performing the following procedure, remove the feed motor assembly.

1.

Remove the screw G attaching the thrust spring.

Feed motor assembly

F

Notch k

Soldering j

Spindle motor board

Pickup

Spindle motor

Fig.13

Feed gear (M)

Thrust spring

ATTENTION:

2.

Remove the feed gear (M).

3.

Pull out the feed gear (E) and the lead screw.

4.

Remove the two screws H attaching the feed motor.

ATTENTION:

When reattaching the thrust spring, make sure that the thrust spring presses the feed gear (M) and the feed gear (E) reasonably.

When reattaching, pass the two cables extending from the feed motor through the notch k of the feed holder as shown in Fig.13.

G

Lead screw

Feed gear (E)

Fig.14

Feed motor

1-12

Feed holder

H

Fig.15

XV-LTR1

Removing the pickup (See Fig.16 and 17)

1.

Remove the screw I attaching the T spring (S) and the shaft holder. Remove also the plate.

ATTENTION:

2.

Pull out the part l of the shaft upward. Move the part m in the direction of the arrow and detach from the spindle base.

3.

Disengage the joint n of the pickup and the shaft in the direction of the arrow.

4.

Pull out the shaft from the pickup.

5.

Remove the two screws J attaching the actuator.

6.

Disengage the joint of the actuator and the lead spring. Pull out the lead spring.

When reattaching, make sure that the T spring (S) presses the shaft.

Shaft holder

I

Plate

T spring (S)

Lead spring

Pickup

Joint n

Part m

Part l

Fig.16

Actuator

J

Actuator

Lead spring

Shaft

Spring

The spring must be under the shaft when you install pick-up.

Removing the shaft holder / shaft

(See Fig.18)

1.

Remove the screw K attaching the shaft holder.

2.

Remove the shaft.

Pick-up

Pickup

K

Shaft

Fig.17

Shaft

Shaft holder

Fig.18

1-13

XV-LTR1

Removing the spindle motor assembly

(See Fig.19 to 21)

1.

Remove the three screws L attaching the spindle motor on the bottom of the mechanism base.

ATTENTION:

2.

Remove the three screws M attaching the spindle base.

When reattaching, pass the card wire extending from the spindle motor board through the notch of the spindle base.

L

Spindle motor assembly

Spindle motor

Fig.19

Spindle base

L

Fig.20

M

Spindle base

Mechanism base

Fig.21

1-14

Adjustment method

(1) Initialization method

If microprocessor (IC401,IC402,IC403) or pick-up is replaces, initialize the DVD player in the following matter

1)Take out the disc and close the tray.

2)Unplug the power plug.

3)Insert power plug into outlet while pressing both "PLAY" button and "OPEN/CLOSE" button.

4)FL Display indicate "TEST " . :Version, :Region code

5)Press "3D-PHONIC" button of remote controller. and EEPROM initialize start.

6)When indicate "DTS" on the display, initialize finishes.

7)The power is turned OFF, and Unplug the power plug.

(2) Display of "Laser current value" and "Jitter value"

"Laser current value" and "Jitter value" are displayed on the FL display by the undermentioned method. Please refer to the failure diagnosis.

1)Take out the disc and close the tray.

2)Unplug the power plug.

3)Insert power plug into outlet while pressing both "PLAY" button and "OPEN/CLOSE" button.

4)FL Display indicate "TEST " . :Version, :Region code

5)Press the "OPEN/CLOSE" button to move the tray outward. Put the test disc (VT-501) on the tray and press "OPEN/CLOSE" button. The tray should move inward (Note:Don't push to close the tray directly by hand etc.)

6)Press the "PLAY" button.

7)The laser current value and the jitter value is displayed on the FL indicator as follows.

XV-LTR1

FL Display

* The test mode is canceled when

0 0 4 0 3 9 7 8

Laser current value Jitter value

the power is turned off.

For Laser current value

The laser current value becomes 40mA for the above-mentioned. Becomes a test mode by doing above-mentioned procedure 1) - 4). Afterwards, the laser current value can be switched by pushing the button to remote controller without turning on the disk.

Remote control "4" button --- Laser of CD Remote control "5" button --- Laser of DVD

If the laser current value is 64mA or less, it is roughly good. There is a possibility to which pick-up is deteriorated, and exchange pick-up, please when there are 65mA or more laser current value.

3D PHONIC Button (Initialize start)

5 Button (Laser of DVD)

4 Button (Laser of CD)

POWER Button

DTS Display part (Initialize complete)

*Returns to a usual test mode by the thing to push the "STOP" button of remote controller.

OPEN/CLOSE

Button(Test mode)

FL Display

PLAY Button

(Test mode & display of jitter)

1-15

XV-LTR1

For Jitter value

The jitter value is displayed on the FL display referring to the previous page. The jitter value is displayed by the hexadecimal number. In the following cases, please "Flap adjustment of the pick-up guide shaft" referring to the following page. Before using the TEST disc VT-501, careful check it if there is neither damage nor dirt on the read surface.

< In the following cases, please adjustment >

* When you exchange the pick-up * When you exchange the spindle motor * When the reading accuracy of the signal is bad (There is a block noise in the screen etc..)

3D PHONIC Button (Initialize start)

5 Button (Laser of DVD)

4 Button (Laser of CD)

DTS Display part (Initialize complete)

POWER Button

FL Display

OPEN/CLOSE

Button(Test mode)

PLAY Button

(Test mode & display of jitter)

1-16

(3) Flap adjustment of the pick-up guide shaft

* Hex wrench for adjustment

Off-the-shelf (1.3mm)

* Test disc

VT-501 or VT-502

* Stud (four pieces set)

Parts No. : JIGXVS40 (One is not used though there are four. )

* Assistance board and extension cord

Parts No. : EXTXVS40MK2CB

1

EXTXVS40MK2CB-1 MAIN CONNECT

Parts No. : EXTXVS40CB

3

2

EXTXVS40MK2CB-2 CONTROL CONNECT

XV-S40

MAIN CONNECT

XV-LTR1

Parts No. : EXTXV521CB

MAIN CONNECT

4

5

XV-521 CN601

XV-521 CN503

6

CONT CONNECT

To CN701 of main board

EXTXVS40MK2CB-1 MAIN CONNECT

1

3

XV-S40 CONTROL CONNECT

CN701 XV-521

XV-521 CN502

CONT CONNECT

MAIN CONNECT

CN706 XV-521

CN501 XV-521

CONT CONNECT

To CN961 of main board

4

MAIN CONNECT

6

These parts are not used.

XV-521 CN601

2

EXTXVS40MK2CB-2 CONTROL CONNECT

To CN503 of servo control board

5

CONT CONNECT

XV-521 CN503

To CN502 of servo control board

1-17

XV-LTR1

1.The mechanism assembly is made in the state from the main body from which is detached referring to the disassembly method.

2.Three studs are installed in the mechanism assembly respectively.

3.The servo control board is removed from the mechanism assembly, and puts into the state set up as shown in figure. (Each wire connected by the servo control board this time leaves the connection maintained.) Between shaft and hook of mechanism assembly of figure Board is put.

4.The extension cord is inserted in the connector of the assistance board respectively. The main board is connected with the servo control board as shown in figure.

Mechanism

assembly

Extension

cord

Stud

Main board

Servo control board

Assistance

board

Extension

cord

Shaft & hook

Stud

Assistance

board

Assistance

board

Extension

cord

Shaft & hook

Assistance

board

Servo control board

Extension

cord

Assistance

board

1.Puts into the state to display the jitter value on the FL display referring to "Display of the jitter value".

2.The adjustment screw under the traverse mechanism is turned with hex wrench, and matches so that the jitter value displayed on the FL display may become "maximum" value.

1-18

Adjustment screw a Adjustment screw b

Adjustment screw c

<POINT>

1.Turns in the forward or the opposite direction, and makes to the position where the jitter value is good the half rotation of adjustment screw a and b(180 degrees) respectively.

2.Afterwards, adjustment screw b and c are turned in the same way, and makes to the best position.

Troubleshooting

Servo volume

Press OPEN /CLOSE key

XV-LTR1

Is tray

operation

Confirmation of tray drive circuit

N

and circuit in surrounding

correct?

Y

Is the traverse moving along the innermost

N

perimeter for SW detection?

Y

"NO DISC" message appears

Y

immediately after vertical movement of the pick-up lens

N

The state that DISC does not rotate continues for several seconds, and becomes NO DISC or an error display afterwards. The rotation of DISC becomes high-speed and abnormal, and becomes NO DISC or an error display afterwards.

N

Is focus retraction OK?

FE

OFF Even when it retracts correctly, if it is out of focus and makes repeated retries with a clicking sound, it is in error.

ON

See "(4) Focus ON error"

N

in "Check points for individual errors"

Y

Is tracking retraction OK?

See "(3) Traverse movement error" in "Check points for individual errors"

See "(2) Disk detection, distinction error" in "Check points for individual errors"

Y

See "(1) Spindle startup error" in "Check points for individual errors"

Is the inter-layer jump OK?

FE

LO LI

A

Two layers of DVD only.

N

(8) Inter-layer

jump error

Y

TE

OFF

If TE waveform reappears or fails to converge after the TE retraction, it is in error.

ON

Y

Is the spindle servo

locked correctly?

Is the RF OUT waveform

locked correctly?

Y

A

See "(5) Tracking ON error"

N

in "Check points for individual errors"

See "(6) Spindle CLV error"

N

in "Check points for individual errors"

Has the disc information

been collected?

Stop will result

Y

Is playback

N

possible?

Y

OK !

N

(7) Address read

error

Check (9),(10),(11), and (12) items in "Check points for individual errors"

1-19

XV-LTR1

Check points for each error

(1) Spindle start error

1.Defective spindle motor

*Are there several ohms resistance between each pin of CN201 "5-6","6-7","5-7"? (The power supply is turned off and measured.)

*Is the sign wave of about 100mVp-p in the voltage had from each terminal? [ CN201"9"(H1-),"10"(H1+),"11"(H2-),"12"(H2+),"13"(H3-),"14"(H3+) ]

2.Defective spindle motor driver (IC251)

*Has motor drive voltage of a sine wave or a rectangular wave gone out to each terminal(SM1~3) of CN201"5,6,7" and IC251"2,4,7"?

*Is FG pulse output from the terminal of IC251"24"(FG) according to the rotation of the motor?

*Is it "L(about 0.9V)" while terminal of IC251"15"(VH) is rotating the motor?

3.Has the control signal come from servo IC or the microcomputer?

*Is it "L" while the terminal of IC251"18"(SBRK) is operating? Is it "H" while the terminal of IC251"23"(/SPMUTE) is operating?

*Is the control signal input to the terminal of IC251"22"(EC)? (changes from VHALF voltage while the motor is working.)

*Is the VHALF voltage input to the terminal of IC251"21"(ECR)?

4.Is the FG signal input to the servo IC?

*Is FG pulse input to the terminal of IC301"69"(FG) according to the rotation of the motor?

(2) Disc Detection, Distinction error (no disc, no RFENV)

* Laser is defective. * Front End Processor is defective (IC101). * APC circuit is defective. --- Q101,Q102. * Pattern is defective. --- Lines for CN101 - All patterns which relate to pick-up and patterns between IC101 * IC101 --- For signal from IC101 to IC301, is signal output from IC101 "20" (ASOUT) and IC101 "41"(RFENV) and IC101 "22" (FEOUT)?

1-20

(3) Traverse movement NG

1.Defective traverse driver *Has the voltage come between terminal of CN101 "1" and "2" ?

2.Defective BTL driver (IC201) *Has the motor drive voltage gone out to IC201"17" or "18"?

3.Has the control signal come from servo IC or the microcomputer? *Is it "H" while the terminal of IC201"9"(STBY1) ? *TRSDRV Is the signal input? (IC301 "67")

4.TRVSW is the signal input from microcomputer? (IC401 "46")

(4) Focus ON NG

* Is FE output ? --- Pattern, IC101 * Is FODRV signal sent ? (R209) --- Pattern, IC301 "115" * Is driving voltage sent ?

IC201 "13", "14" --- If NG, pattern, driver, mechanical unit .

* Mechanical unit is defective.

(5) Tracking ON NG

XV-LTR1

* When the tracking loop cannot be drawn in, TE shape of waves does not settle. * Mechanical unit is defective.

Because the self adjustment cannot be normally adjusted, the thing which cannot be normally drawn in is thought. * Periphery of driver (IC201)

Constant or IC it self is defective. * Servo IC (IC301)

When improperly adjusted due to defective IC.

(6) Spindle CLV NG

* IC101 -- "35"(RF OUT), "30"(ARF-), "31(ARF+). * Does not the input or the output of driver's spindle signal do the grip? * Has the tracking been turned on? * Spindle motor and driver is defective. * Additionally, "IC101 and IC301" and "Mechanism is defective(jitter)", etc. are thought.

(7) Address read NG

* Besides, the undermentioned cause is thought though specific of the cause is difficult because various factors are thought.

Mechanism is defective. (jitter)

IC301, IC401.

The disc is dirty or the wound has adhered.

(8) Between layers jump NG (double-layer disc only)

Mechanism defective Defect of driver's IC(IC201) Defect of servo control IC(IC301)

1-21

XV-LTR1

(9) Neither picture nor sound is output

1.It is not possible to search *Has the tracking been turned on? *To

"(5) Tracking ON NG" in "Check points for each error"

*Is the feed operation normal? To "(3) traverse movement NG" in "Check points for each error" when it is not normal. Are not there caught of the feeding mechanism etc?

(10) Picture is distorted or abnormal sound occurs at intervals of several seconds.

Is the feed operation normal? Are not there caught of the feeding mechanism etc?

(11) Others

The image is sometimes blocked, and the image stops. The image is blocked when going to outer though it is normal in surroundings in the disk and the stopping symptom increases.

when the tracking is not normal.

There is a possibility with bad jitter value for such a symptom.

(12) CD During normal playback operation

a) Is TOC reading normal? Displays total time for CD-DA. Shifts to double-speed mode for V-CD.

YES

NO

b)Playback possible?

*--:-- is displayed during FL search. According to [It is not possible to search ] for DVD(9), check the feed and tracking systems. *No sound is output although the time is displayed.(CA-DA) DAC, etc, other than servo. *The passage of time is not stable, or picture is abnormal.(V-CD) *The wound of the disc and dirt are confirmed.

1-22

Description of major ICs

AN8703FH-V (IC101) : Frontend processor

1.Pin layout

64 49

XV-LTR1

1

16

17 32

2.Pin function

Pin No.

1 2 3 4 5 6 7 8 9

10

11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33

Symbol

LPC1

LPC01

LPC2

LPC02

VFOSHORT

TBAL FBAL

POFLT

DTRD

IDGT

STANDBY

SEN SCK

STDI RSCL JLINE

TEN

TEOUT

AGCBAL

ASOUT

FEN

FEOUT

AGCOFST

MON

AGCLVL

GND2

VREF2

VCC2

VHALF DFLTON DFLTOP

DCFLT

GND3

48

33

I/O Description

Laser input terminal (DVD)

I

O

Laser drive signal output terminal (DVD)

I

Laser input terminal (CD)

O

Laser drive signal output terminal (CD)

I

VFOSHORT control terminal

I

Tracking balance control terminal

I

Focus balance control terminal

O

Track detection threshold level terminal

I

Data slice part data read signal input terminal

(For RAM)

I

Data slice part address part gate signal input

terminal( For RAM)

I

Standby mode control terminal

I

SEN(Serial data input terminal)

I

SCK(Serial data input terminal)

I

STDI(Serial data input terminal)

I

Standard electric current terminal

I

Electric current setting terminal of JLine

I

Reversing input terminal of tracking error output AMP.

O

Tracking error signal output terminal

I

Offset adjusting terminal 1

O

Full adder signal output terminal

I

Focus error output amplifier reversing input terminal

O

Focus error signal output terminal

I

Offset adjusting terminal 2

-

Non connect

O

Output amplitude adjustment for DRC

-

Connect to GND

O

VREF2 voltage output terminal

-

Power supply terminal 5V

O

VHALF voltage output terminal

O

Reversing output terminal of filter AMP.

O

Filter AMP. output terminal

I

Capacity connection terminal for filter output

-

Connect to GND

Pin No.

Symbol I/O Description

Non connect

34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57

58

59

60

61 62 63 64

RFDIFO

RFOUT

VCC3

RFC DCRF OFTR

BDO

RFENV

BOTTOM

PEAK

AGCG AGCO

TESTSG

RFINP RFINN

VIN5 VIN6 VIN7 VIN8

VIN9 VIN10 VCC1

VREF1

VIN1

VIN2

VIN3

VIN4

GND1 VIN11 VIN12

HDTYPE

-

Connect to TP103

-

Power supply terminal 3.3V

-

Filter for RF delay correction AMP.

O

All addition amplifier capacitor terminal

O

OFTR output terminal

O

BDO output terminal

O

RF envelope output terminal

O

Bottom envelope detection filter terminal

O

Peak envelope detection filter terminal

O

AGC amplifier gain control terminal

O

AGC amplifier level control terminal

O

TEST signal input terminal

I

RF signal positive input terminal

I

RF signal negative input terminal

I

Internal four-partition (CD) RF input 1

I

Internal four-partition (CD) RF input 2

I

Internal four-partition (CD) RF input 3

-

Internal four-partition (CD) RF input 4

-

External two-partition (DVD) RF input 2

I

External two-partition (DVD) RF input 1

I

Power supply terminal 5V

-

VREF1 voltage output terminal

O

Internal four-partition (DVD) RF input 1

I

Internal four-partition (DVD) RF input 2

I

Internal four-partition (DVD) RF input 3

I

Internal four-partition (DVD) RF input 4

I

Connect to GND

-

3 beam sub input terminal 2 (CD)

I

3 beam sub input terminal 1 (CD)

I

HD Type selection

O

1-23

XV-LTR1

BA5983FM-X (IC201) : 4CH Driver

1.Block diagram

27

26

28

Vcc

25

10k

20k

24

23 22

10k

20k

21

STAND BY CH4

20

Vcc

19

10k

18

Level Shift

17 16

10k

15

10k

Level Shift

10k

1

2

3

5

4

10k

STAND BY CH1/2/3

6

7

89

Vcc

10

10k

Level Shift

11

10k

12

2.Pin function

Pin No. Pin No.Symbol SymbolI/O I/ODescription Description

10

11

12

13

14

1

2

3

4

5

6

7

8

9

BIAS IN

OPIN1(+)

OPIN1(-)

OPOUT1

OPIN2(+)

OPIN2(-)

OPOUT2

GND

STBY1

PowVcc1

VO2(-)

VO2(+)

VO1(-)

VO1(+)

Input for Bias-amplifier

I

Non inverting input for CH1 OP-AMP

I

Inverting input for CH1 OP-AMP

I

Output for CH1 OP-AMP

O

Non inverting input for CH2 OP-AMP

I

Inverting input for CH2 OP-AMP

I

Output for CH2 OP-AMP

O

Substrate ground

-

Input for CH1/2/3 stand by control

I

Vcc for CH1/2 power block

-

Inverted output of CH2

O

Non inverted output of CH2

O

Inverted output of CH1

O

Non inverted output of CH1

O

15

16

17

18

19

20

21

22

23

24

25

26

27

28

VO4(+)

VO4(-)

VO3(+)

VO3(-)

PowVcc2

STBY2

GND

OPOUT3

OPIN3(-)

OPIN3(+)

OPOUT4

OPIN4(-)

OPIN4(+)

PreVcc

O

Non inverted output of CH4

O

Inverted output of CH4

O

Non inverted output of CH3

O

Inverted output of CH3

-

Vcc for CH3/4 power block

I

Input for Ch4 stand by control

-

Substrate ground

O

Output for CH3 OP-AMP

I

Inverting input for CH3 OP-AMP

I

Non inverting input for CH3 OP-AMP

O

Output for CH4 OP-AMP

I

Inverting input for CH4 OP-AMP

I

Non inverting input for CH4 OP-AMP

-

Vcc for pre block

Level Shift

10k

13

10k

14

74VHC00MTC-X (IC455,IC503) : 2-input nand gate

1.Pin layout 2.Truth table

1-24

1A

1B

1Y

2A

2B

2Y

GND

1

2

3

4

5

6

7

(TOP VIEW)

14

13

12

11

10

9

8

VCC

4A

4B

4Y

3A

3B

3Y

L : High impedance

A

L

H

B

L

H

L

H

Y

H

L

BA6664FM-X (IC251) : 3Phase Motor Driver

1.Pin layout

RNFVMGSW

VccFGPS

EC

ECRFRFG2SBCNFBRVH-

XV-LTR1

28272625242322

1234567

NCA3NCA2NC

2.Block diagram

Hall 1

Hall 2

Hall 3

NC

A1

GND

H1+

H1-

H2+

H2-

H3+

H3-

21201918171615

8

9

GND

H1+

DRIVER

GAIN

CONTROL

1011121314

H1-

H2-

H2+

H3+

CURRENT

SENSE AMP

R

D Q

CK Q

H3-

TSD

+ -

BRAKE MODE

GAIN

SWITCH

VCC

PS

TOROUE

SENSE AMP

+

-

VCC

SHORT BRAKE

Hall Bias

28

27

26

25

24

23

22

21

20

19

18

17

16

15

R

NF

VM

GSW

VCC

FG

PS

EC

ECR

FR

FG2

SB

CNF

BR

VH

R

Vcc

NF

V

M

SERVO SIGNAL

29 30

A3

2

A2

4

A1

7

8

9

10

11

12

13

TL

HALL AMP

+

-

+

-

+

-

+

-

+

-

+

-

14

FIN

1-25

XV-LTR1

3.Pin function

Pin No.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

Symbol

NC

A3

NC

A2 NC NC

A1

GND

H1+

H1-

H2+

H2-

H3+

H3-

VH BR

CNF

SB

FG2

FR

ECR

EC PS FG

VCC

GSW

VM

RNF

I/O Description

Non connect

-

O

O O

O

Output 3 for spindle motor Non connect

Output 2 for spindle motor Non connect

Non connect

Output 1 for spindle motor Connect to ground

Positive input for hall input AMP 1

I

Negative input for hall input AMP 2

I

Positive input for hall input AMP 2

I

Negative input for hall input AMP 2

I

Positive input for hall input AMP 3

I

Negative input for hall input AMP 3

I

Hall bias terminal

I

Non connect

Capacitor connection pin for phase compensation

Short brake terminal

I

Non connect

Torque control standard voltage input terminal

I

Torque control voltage input terminal

I

Start/stop switch (power save terminal) FG signal output terminal Power supply for signal division

Gain switch Power supply for driver division

Resistance connection pin for output current sense Connect to ground

Connect to ground

-

BA6664FM-X

74VHC08SJ-X(IC411) / 74VHCT08ASJ-X(IC412):2-input AND gate

1.Pin layout 2.Truth table

1-26

1G

1A

1Y

2G

2A

2Y

GND

1

2

3

4

5

6

7

14

13

12

11

10

9

8

VCC

4G

4A

4Y

3G

3A

3Y

G

L

H

Y

A

Z

L

Z

H

Z

L

H

K4S641632E-TC75 (IC504) :CMOS SDRAM

1.Pin layout

XV-LTR1

545352515049484746454443424140393837363534333231302928

123456789

2.Block diagram

CLK

ADD

SSQ

VSSDQ15

V

DQ14

Q

Vcc

DQ1

DQ0

Vcc

Address register

DQ13

DQ2

VccQDQ12

SSQ

V

SSQ

DQ11

V

DQ10

DQ9

VccQDQ8

VSSN.C

UDQM

CLK

CKENCA11A9A8A7A6A5A4

1011121314151617181920212223242526

DQ3

DQ4

Q

Vcc

DQ5

DQ6

SSQ

V

DQ7

Vcc

LDQM

WE

CAS

RAS

CS

Bank select

Refresh counter

Row buffer

LCBR

LRAS

Row decoder

Col. buffer

A0A1A2

BS0

BS1

A10/AP

Data input register

Column decoder

27

A3

1M x 16

SS

V

Vcc

I/O Control Output buffer

LWE

LDQM

Sense AMP.

DQI

3.Pin functions

Latency & Burst length

LCKE

Programming register

LRAS LCBR LWE LCAS

Timing register

CLK CKE CS RAS CAS WE L(U)DQM

Symbol

CLK

CS

CKE

A0~A11

BS0,1

RAS

CAS

WE

LDQM

DQ0~15

Vcc/Vss

Vccq/Vssq

N.C

System clock

Chip select

Clock enable

address

Bank address strobe

Row address strobe

column address strobe

Write enable

Data input/output mask

Data input/output

Power supply/ground

Data output power/ground

Non connect

Description

LWCBR

LDQM

1-27

XV-LTR1

MN101C35DGN(IC701):System controller

Pin function

Pin No.

1 2 3

4~7

8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48

49~51 52~64 65~88 89~99

100

Symbol

D DATA

DCLK

DACOCS

DI/DO/CS/SK

VDD OSC2 OSC1

VSS

XI

XO MMOD VREF-

POWER SW

NTSEL

RGB/YC SW

S/COMPO

AIN0

AIN2 TEST0 TEST1

VREF+

RGBSEL

RESET

AVCO

AVCI

POWERON

TCLOSE

TOPEN /LMMUTE SWOPEN SWUPDN

REMO

NC

REQ

NC S2UDT U2SDT

SCLK BUSY

CPURST

NC

VS3 VS1

MUTE

STANDBYIND

NC

13G~1G

S24~S1

NC

VPP

I/O

O O O

-

O

I

-

I I I I I I

-

O

I

O

I O O O O

I

-

I

-

O

I O O O

O O O O

O O

-

DAC control data DAC control clock DAC control chip select Not use Power supply +B 5V Oscillation terminal 8MHz Oscillation terminal 8MHz Connect to ground Unused, Connect with ground Non connect Connect to ground Connect to ground Key input (power) NTSC/PAL switch input RGB/YC Switch input S/COMPONENT Switch input Key input (S831~S835) Key input (open/close) Not used Not used Power supply +B 5V RGB select control (H:RGB L:other) Reset input AV COMPULINK output AV COMPULINK input Power ON output Tray close control output Tray open control output Tray muting output (L:muting) Detection switch of tray open/close (L:open/close) Detection switch of traverse mechanism up/down (H:UP L:DOWN) Remote control interruption Non connect Communication between unit microcomputers request Non connect Communication between unit microcomputers DATA output Communication between unit microcomputers DATA input Communication between unit microcomputers CLK Communication between unit microcomputers BUSY Unit microcomputers reset Non connect S3 control (H:standby L:power ON) S1 control Muting output LED control signal output (standby) Non connect FL grid control signal output FL segment control signal output Non connect

-VDISP (apply -35V)

Description

1-28

MN102L62GGY (IC401) : Unit CPU

Pin function

Pin No. Pin No.

Symbol SymbolI/O I/OFunction Function

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46

47 48 49 50

WAIT

RE

SPMUTE

WEN

HDTYPE

CS1 CS2 CS3

DRVMUTE

SBRK

LSIRST

WORD

A0 A1 A2 A3

VDD

SYSCLK

VSS

XI

XO

VDD

OSCI OSCO MODE

A4 A5 A6 A7 A8

A9 A10 A11

VDD

A12 A13 A14 A15 A16 A17 A18 A19

VSS

A20

TXSEL

TRVSW

HUGUP HFMON HAGUP

-

Micon wait signal input

I

Read enable

O

Spindle muting output to IC251

O

Write enable

O

HD Type selection

O

Chip select for ODC

O

Chip select for ZIVA

O

Chip select for outer ROM

O

Driver mute

O

Short brake terminal

O

LSI reset

O

Bus selection input

I

Address bus 0 for CPU

O

Address bus 1 for CPU

O

Address bus 2 for CPU

O

Address bus 3 for CPU

O

Power supply

Non connect

Ground

Not use (Connect to vss)

Non connect

Power supply

Clock signal input(13.5MHz)

I

Clock signal output(13.5MHz)

O

CPU Mode selection input

I

Address bus 4 for CPU

O

Address bus 5 for CPU

O

Address bus 6 for CPU

O

Address bus 7 for CPU

O

Address bus 8 for CPU

O

Address bus 9 for CPU

O

Address bus 10 for CPU

O

Address bus 11 for CPU

O

Power supply

Address bus 12 for CPU

O

Address bus 13 for CPU

O

Address bus 14 for CPU

O

Address bus 15 for CPU

O

Address bus 16 for CPU

O

Address bus 17 for CPU

O

Address bus 18 for CPU

O

Address bus 19 for CPU

O

Ground

Address bus 20 for CPU

O

TX Select

O

Detection switch of traverse

I

inside Connect to TP408

HFM Control output to Q103

O

Connect to pick-up

O

Connect to TP407

-

51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99

100

-

P85/TM5IO

VDD

-

FEPEN

SLEEP

-

BUSY

REQ

VSS EPCS EPSK

EPDI

EPDO

VDD SCLKO S2UDT U2SDT

CPSCK

P74/SBI1

SDOUT

-

NMI

ADSCIRQ

ODCIRQ DECIRQ

CSSIRQ

ODCIRQ2

ADSEP

RST

VDD

TEST1 TEST2 TEST3 TEST4 TEST5 TEST6 TEST7 TEST8

VSS

D0 D1 D2 D3 D4 D5 D6 D7

Connect to TP406

Connect to TP405

Connect to TP404

Power supply

Connect to TP403

Serial enable signal for FEP

O

Standby signal for FEP

O

Connect to TP402

Communication busy

I

Communication request

O

Ground

EEPROM chip select

O

EEPROM clock

O

EEPROM data input

I

EEPROM data output

O

Power supply

Communication clock

O

Communication input data

I

Communication output data

O

Clock for ADSC serial

O

Not use (Pull down)

I

ADSC serial data output

O

Not use (Pull up)

I

Not use (Pull up)

I

NMI Terminal

I

Interrupt input of ADSC

I

Interrupt input of ODC

I

Interrupt input of ZIVA

I

Not use (Pull down)

I

Interruption of system control

I

Address data selection input

I

Reset input

I

Power supply

Test signal 1 input

I

Test signal 2 input

I

Test signal 3 input

I

Test signal 4 input

I

Test signal 5 input

I

Test signal 6 input

I

Test signal 7 input

I

Test signal 8 input

I

Ground

Data bus 0 of CPU

I/O

Data bus 1 of CPU

I/O

Data bus 2 of CPU

I/O

Data bus 3 of CPU

I/O

Data bus 4 of CPU

I/O

Data bus 5 of CPU

I/O

Data bus 6 of CPU

I/O

Data bus 7 of CPU

I/O

XV-LTR1

1-29

XV-LTR1

MN103S28EGA (IC301) : Super optical disc controller

1.Terminal layout

176 133

1

132

44

45 88

2.Block diagram

(core 1 I/O)

89

Analog

Servo I/O

Servo core

(core 2)

RAM

DVD-ROM Formatter

CGEN

MODE

CD-PRE

Instruction memory (40KB)

Data

memory

(6KB)

General purpose IO bus

DMA

I/F

High speed IO bus

CPU core

32 bit

ECC

Host I/F

MPEG I/F

DMA

BCU

DRAMC

ATAPI

2Mbit

DRAM

3.Pin function (1/4)

Pin No.

1,2

3 4 5 6 7 8

9~17

18 19 20 21

22~30

31 32 33 34 35

CPUADR17~9

DRAMVDD18

CPUADR8~0

DRAMVDD3

CIRC

Symbol

NINT0,1

VDD3

VSS

NINT2

WAITDOC

NMPST

DASPST

VDD18

VSS

DRAMVSS

VDD3

VSS

NCS

NWR

I/O

O

O O O

WDT

16 bit

timer x 2

SYSTEM

Interruption of system control 0,1 Power supply terminal for I/O(3.3V)

Connect to ground

Interruption of system control 2 Wait control of system control Reset of system control (Non connect) Setting of initial value of DASP signal

I

System control address

I

Power supply terminal for I/O (1.8V)

Connect to ground

Power supply terminal for DRAM (1.8V)

Connect to ground for DRAM

System control address

I

Power supply terminal for I/O (3.3V)

Connect to ground

Power supply terminal for DRAM (3.3V)

System control chip select

I

Writing system control

I

I/F

INTC

Description

1-30

3.Pin function (MN103S28EGA : 2/4)

XV-LTR1

Pin No.

36

37~44

45 46 47 48 49 50 51 52

53~56

57 58 59 60

61~64

65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99

100

Symbol

NRD

CPUDT7~0

CLKOUT1

MMOD

NRST MSTPOL SCLOCK

S DATA

OFTR

BDO

PWM1~4

VDD3

DRAMVDD18

DRAMVSS

VSS

PWM5~8

TBAL FBAL

TRSDRV

SPDRV

FG

TILTP

TILT

TILTN

TX

DTRD

IDGT

VDD18

VSS

VDD3

OSCI1

OSCO1

VSS

TSTSG

VFOSHORT

JLINE

AVSSD

ROUT

LOUT

AVDD

VCOF

TRCRS

CMPIN

LPFOUT

LPFIN

AVSS

HPFOUT

FPFIN

CSLFLT

RFDIF AVDDC PLFLT2

I/O

I

I/O

I I I

-

I I

-

O O O O

I

-

O

-

I

O

O O O

-

I I

-

I

-

I I

-

I

Description

Read signal input from system controller System control data Non connect Test mode switch signal System reset Master terminal polarity switch input Non connect Non connect Off track signal input Drop out signal input Non connect Power supply terminal for I/O (3.3V) Power supply terminal for DRAM (1.8V) Connect to ground for DRAM Connect to ground Non connect Tracking balance adjustment output Focus balance adjustment output Traverse drive output Spindle drive output Motor FG input Non connect Non connect Non connect Digital output signal Non connect Non connect Power supply terminal for I/O (1.8V) Connect to ground Power supply terminal for I/O (3.3V) Oscillation input 16.9MHz Oscillation output 16.9MHz Connect to ground Calibration signal VFO short output J-line setting output Connect to ground for analog circuit Non connect Non connect Power supply terminal for analog circuit (3.3V) JFVCO control voltage Input signal for track cross formation Non connect Non connect Pull-up to VHALF Connect to ground for analog circuit Non connect HPF input Pull-up to VHALF Non connect Power supply terminal for analog circuit (3.3V) Connect to capacitor 2 for PLL

1-31

XV-LTR1

3.Pin function (MN103S28EGA : 3/4)

Pin No.

101 102 103 104 105 106

107,108

109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135

136,137

138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154

Symbol

PLFLT1

AVSS

RVI

VREFH

PLPG

VHALF

DSLF2,1

AVDD NARF

ARF

JITOUT

AVSS DAC0 DAC1 AVDD

AD0 AD1 AD2 AD3 AD4 AD5 AD6

TECAPA

VDD3

VSS MONI0 MONI1 MONI2 MONI3

NEJECT

NTRYCTL

NDASP NCS3FX NCS1FX

DA2

NPDIAG

DA1

NIOCS16

INTRQ

NDMACK

VDD3

VSS

IORDY

NIORD

NIOWR

DMARQ

HDD15

HDD0 HDD14 VDD18

PO

UATASEL

I/O

-

O

O O

-

I/O I/O I/O

O

-

I/O

-

I/O I/O I/O

-

Description

I

Connect to capacitor 1 for PLL Connect to ground for analog circuit

I

Connect to resistor for VREF reference current source

I

Reference voltage input (2.2V) Non connect

I

Reference voltage input (1.65V)

I

Connect to capacitor 2,1 for DSL Power supply terminal for analog circuit (3.3V)

I

Equivalence RF-

I

Equivalence RF+ Output for jitter signal monitor Connect to ground for analog circuit Tracking drive output Focus drive output Power supply terminal for analog circuit (3.3V)

I

Focus error input

I

Phase difference/3 beams tracking error

I

AS : Full adder signal

I

RF envelope input

I

DVD laser current control terminal I I

CD laser current control terminal

Non connect

Power supply terminal for I/O (3.3V)

Connect to ground

Connect to TP306

Connect to TP307

Connect to TP308

Connect to TP309

Eject detection

Tray close detection

ATAPI drive active / slave connect I/O I

ATAPI host chip select I

ATAPI host chip select

ATAPI host address 2,0

ATAPI slave master diagnosis input

ATAPI host address 1

Non connect

ATAPI host interruption output I

ATAPI host DMA characteristic

Power supply terminal I/O (3.3V)

Connect to ground

NOn connect

ATAPI host read

Non connect

ATAPI host data 15

ATAPI host data 0

ATAPI host data 14

Power supply terminal for I/O (1.8V) I

Connect to ground I

Connect to ground

1-32

3.Pin function (MN103S28EGA : 4/4)

XV-LTR1

Pin No.

155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170

171~173

174 175 176

Symbol

VSS

VDD3

HDD1

HDD13

HDD2

HDD12

HDD3

VDD3

VSS

HDD11

HDD4

HDD10

HDD5 HDD9

VDD3

VSS

HDD6~8

VDDH NRESET MASTER

I/O

I/O I/O I/O I/O I/O

I/O

-

Connect to ground

-

Power supply terminal for I/O (3.3V) ATAPI host data 1 ATAPI host data 13 ATAPI host data 2 ATAPI host data 12 ATAPI host data 3

-

Power supply terminal for I/O (3.3V)

-

Connect to ground ATAPI host data 11 ATAPI host data 4 ATAPI host data 10 ATAPI host data 5 ATAPI host data 9 Power supply terminal for I/O (3.3V)

Connect to ground

ATAPI host data 6~8 Reference power supply for ATAPI (5.0V)

ATAPI host reset input

I

ATAPI master / slave select

I

Description

74VHC74MTC-X (IC454) : ZIVA Wait

1.Terminal layout

14

Vcc

13

CLR2

12

D2

11

CK2

10

PR2

9

Q2

8

Q2

Direct clear input 1

I

Data input 1

I

Clock pulse input 1

I

Direct preset input 1

I

Output

O

Output

O

Connect to ground

-

D1 CK1 PR1

Q1 Q1

1 2 3 4 5 6 7

CLR1

GND

3.Pin function

Pin No.

1 2 3 4 5 6 7

CK1 D1

PR1CLR1

Q1 Q1

CK2D2

PR2CLR2

Q2 Q2

Symbol I/O Description

CLR1

D1 CK1 PR1

Q1

GND

2.Trouth table

Input Output

CLR

PR

L

H

L

H

Pin No.

8

9 10 11 12 13 14

D

CK

X

L H X

Q

L

H

H(Note 1)

L

H

Qn

H(Note 1)

Symbol I/O Description

Q2

Q2 PR2 CK2

D2

CLR2

VCC

Output

O

Output

O

Direct preset input 2

I

Click pulse input 2

I

Data input 2

I

Clock clear input 2

I

Power supply

-

Q H

L

H

L

Qn

Function

Clear Preset

No change

1-33

XV-LTR1

CY24203SC-X (IC571) : MPEG/Audio clock generator with VCXO

1.Pin layout 2.Pin function

Pin No. DescriptionSymbol

XIN

VDD

VCXO

VSS

1 2 3 4

8

XOUT

7

27M

6

13.5M

5

16.9344M

1 2 3 4 5 6 7 8

XIN

VDD

VCXO

VSS

16.9344M

13.5 27M

XOUT

Reference crystal input Power supply Input analog control for VCXO Connect to ground

16.9344 MHz clock output

13.5 MHz clock output 27 MHz clock output Reference crystal output

GP1U271X (IC801) : Receiver for remote

+

–

Amp. Limiter

B.P.F

Demodulator

Integrator Comparator

IC-PST9140-T (IC702) : System Reset IC

1.Terminal layout

Output GNDInput

2.Block diagram

CO1

OP1

GND

VCC Vout

2

1

Input

Output

1-34

GND

3

1.Terminal layout

1

M5

2

DIN

M3

M2 M1

3 4 5 6 7 8

9 10 11 12 13 14

LRCK

BCK

DVDD2

CKO

DVSS2

OUT1C AVDD1 OUT1D

AVSS1

2. Pin function

28 27 26 25 24 23 22 21 20 19 18 17 16 15

XV-LTR1

MN35505-X (IC703) : DAC

M6 M4 M8 M7 DVDD1 VCOF XIN XOUT DVSS1 M9 OUT2C AVDD2 OUT2D AVSS2

Pin No.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28

M5

DIN

LRCK

BCK

M3

DVDD2

CKO

DVSS2

M2

M1 OUT1C AVDD1 OUT1D

AVSS1

AVSS2 OUT2D AVDD2 OUT2C

M9

DVSS1

XOUT

XIN

VCOF

DVDD1

M7 M8 M4 M6

I/OSymbol Description

I I I I I

-

I I

O

-

O

-

O

-

O

I

-

I

-

I I

Control signal for DAC Digital data input L and R clock for DAC Bit clock for DAC Control signal for DAC Power supply terminal Non connect Connect to ground Control signal for DAC Control signal for DAC Analog output 1 Power supply terminal Analog output 1 Connect to ground Connect to ground Analog output 2 Power supply terminal Analog output 2 Control signal for DAC Connect to ground Non connect Non connect VCO Frequency Power supply D+5V Connect to ground Connect to ground Control signal for DAC Clock for control signal

1-35

XV-LTR1

MR27V1602E1UTPX (IC402) :P2 ROM of 1,048,576word x 16 bit / 2,097,152 word x 8 bit

1.Pin layout

WP

A20A9A10

A11

A12

A13

A14

A15

A16

A17

BYTE

VssA0D7

D14D6D13D5D12D4Vcc

444342414039383736353433323130292827262524

123456789

WE

A19

2.Block diagram

A8A7A6A5A4A3A2

A18

A0 A1 A2 A3 A4 A5 A6 A7 A8

A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20

Address Buffer

10111213141516171819202122

A1

CE

Vss

D0D8D1D9D2

OE

D10D3D11

x 8 / x 16 Output select

CE

OE

Memory Cell Matrix

1,048,576 x 16-Bit or 2,097,152 x 8-Bit

Row Decoder

Column Decoder

D0

D1

23

BYTE

Multiplexer

Output Buffer

D12

D11

D13

When the mode of IC outputs eight bits, these pins are in the state of high impedance.

D14D2D3D4D5D6D7D8D9D10

3.Pin functions

1-36

Symbol

A0 - A20

D0 - D14

CE

OE

BYTE

Vcc

Vss

WE

WP

Function

Address Input

Data Output

Chip Enable

Output Enable

Mode Switch

Power Supply

GND

Write enable

Connect to ground

NJM4580M-X (IC741,IC751) : Dual OP amplifier

Block diagram

V+ B OUT B -IN B +IN

8765

B

A

1234

V-A +INA -INA OUT

NJM78M05FA (IC953) : Regulator

XV-LTR1

1.Terminal layout 2.Block diagram

1.INPUT

2.GND

3.OUTPUT

1 2 3

PQ05RD21 (IC951) : Regulator

2.Block diagram1.Terminal layout

Vinput

INPUT

OUTPUT

GND

1

2

Voutput

PQ05RD21

Vin

GND

Vout

Vcontrol

3

GND

Vcontrol

4

1-37

XV-LTR1

S-93C66AFJ-X (IC451) : EEPROM

1.Pin layout

2.Pin function

1

PE

CS

SK

2 3 4

VCC

1.Block diagram

DI

CS

8

NC

7

GND

6

DO

5

DI

Memory

array

Data resister

Mode decode

logitech

Pin No. DescriptionSymbol

1 2 3 4 5 6 7 8

PE

VCC

CS

SK

DI

DO

GND

NC

Address decoder

Buffer output

I/O

O

Non connect

Power supply terminal

Chip select input

I

Serial clock input

I

Serial data input

I

Serial data output Connect to ground

Non connect

-

Vcc

GND

DO

SK

Clock generation

circuit

STR-G6651 (IC901) : Switch regulator

VIN

4

START

REG

T. S. D

O.V.P

LATCH

O.S.C

Vth(2)

Comp.2

DRIVE

Comp.1

1

D

2

S

Vth(1)

5

O.C.P /F.B

3

GND

1-38

ZIVA-4.1-PA2(IC501):Back end - Digital decoder

1.Terminal layout

~

208 157

1

~

156

~

XV-LTR1

52

~

53 104

2.Pin function (1/5)

Pin No.

1 2 3 4

5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29

30

31 32 33 34 35 36

Symbol

RD

R/W

VDD

WAIT

RESET

VSS

VDD

INT

NC NC NC NC

VDD

VSS

NC NC NC NC

VSS

VDD V DATA 0 V DATA 1 V DATA 2 V DATA 3 V DATA 4 V DATA 5 V DATA 6 V DATA 7 VSYNC

HSYNC

VSS

VDD

NC NC NC

VDD

105

I/O

O

O O O O O O O O

I/O

Description

Read strobe input

I

Read/write strobe input

I

Power supply terminal 3.3V

Transfer not complete / data acknowledge. Active LOW to indicate host initiated transfer is complete. Active LOW : reset signal input

I

Connect to ground

Power supply terminal 3.3V

Host interrupt signal output Non connect

Non connect

Power supply terminal 2.5V

Connect to ground

Non connect

Connect to ground

Power supply 3.3V

Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Video data bus output. Byte serial CbYCrY data synchronous with VCLK. Vertical sync. Bi-directional, the decoder output the top border of a new field on the first HSYNC after the falling edge of VSYNC. Horizontal sync. The decoder begins outputting pixel data for a new horizontal line after the falling (active) edge of HSYNC. Connect to ground

Power supply terminal 3.3V

Non connect

Power supply terminal 2.5V

-

1-39

XV-LTR1

2.Pin function (ZIVA-4.1-PA2 : 2/5)

Pin No.

37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84

Symbol

VSS

NC NC NC NC NC

PIO0

VSS

VDD PIO1 PIO2 PIO3 PIO4 PIO5 PIO6 PIO7

M DATA 0 M DATA 1

VDD

VSS

M DATA 2 M DATA 3 M DATA 4 M DATA 5 M DATA 6 M DATA 7

MDATA15

VDD

VSS

MDATA14

VDD

VSS

MDATA13 MDATA12 MDATA11 MDATA10

M DATA 9

VDD

VSS

M DATA 8

LDQM SD-CLK CLKSEL

MADDR9 MADDR8

VDD VSS

MADDR7

I/O

Connect to ground

Non connect

Programmable I/O terminal

I/O

Connect to ground

Power supply terminal 3.3V

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

Programmable I/O terminal

I/O

SDRAM data

I/O

SDRAM data

I/O

Power supply terminal 3.3V

Connect to ground

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

Power supply terminal 3.3V

Connect to ground

SDRAM data

I/O

Power supply terminal 2.5

Connect to ground

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

SDRAM data

I/O

Power supply terminal 3.3V

Connect to ground

SDRAM data

I/O

SDRAM Lower or upper mask

O

SDRAM Clock

O

Selects SYSCLK or VCLK as clock source. Normal operation is to tie HIGH.

I

SDRAM address

O

SDRAM address

O

Power supply terminal 3.3V

Connect to ground

SDRAM address

O

Description

1-40

2.Pin function (ZIVA-4.1-PA2 : 3/5)

XV-LTR1

Pin No.

85 86 87 88 89 90 91 92 93 94 95 96 97 98

99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118

119

120

121

122 123 124 125 126 127 128

Symbol

MADDR6 MADDR5

VDD

VSS

MADDR4

MWE

SD-CAS

VDD

VSS SD-RAS SD-CS0

SD-CS1/MADDR11

SD-BS

MADDR10

MADDR0

VDD

VSS

MADDR1 MADDR2 MADDR3

RESERVED

NC NC

RESERVED

NC RESERVED RESERVED RESERVED

DAI-LRCK

DAI-BCK

VDD

VSS

DAI-DATA

DA-DATA3

DA-DATA2

DA-DATA1

DA-DATA0

DA-LRCK

VDD

VSS DA-XCK DA-BCK

DA-IEC

VDD

I/O

SDRAM address

O

SDRAM address

O

Power supply terminal 2.5V

Connect to ground

SDRAM address

O

SDRAM write enable

O

Active LOW SDRAM column address

O

Power supply terminal 3.3V

Connect to ground

Active LOW SDRAM row address

O

Active LOW SDRAM chip select 0

O

Active LOW SDRAM chip select 1 or use as MADDR11 for larger SDRAM

O

SDRAM bank select

O

SDRAM address

O

SDRAM address

O

Power supply terminal 3.3V

Connect to ground

SDRAM address

O

SDRAM address

O

SDRAM address

O
