For Customer Use:
Enter below the Model No. and Serial No. which are located either on the rear, bottom or side of the cabinet. Retain this information for future reference.
COMPACT COMPONENT SYSTEM
DVD PLAYER
XV-D2000BK
POWER
OPEN/CLOSE CATV/SAT TV
123 456 789
10 0
++++
SLOW
RESUME ANGLE SUB TITLIE DVD CATV
S
N
O
RM-SVD2000U REMOTE CONTROL
SET MUTE
CH
N
E
E
R
C
N
E
M
E
L
T
I
T
LEFT RIGHT
U
DOWN
E
DVD
TV/VIDEO
100+CH RETURN
+
10
TV
AUDIO
VOLUME
VOLUME
TV
ON /OFF
XV-D2000 DVD PLAYER
STEP
R
E
T
U
R
N
D
V
D
M
E
N
U
UP
N
R
E
T
STANDBY
POWER
ON/STANDBY
PHONES PHONES LEVEL
MIN MAX
RESUME
DOLBY DIGITAL 5.1
LINEAR PCM 96KHz SAMPLING
DOLBY
DIGITAL
DOLBY DIGITAL DECODER BUILT-IN
ON SCREEN DVD MENU
ENTER
INSTRUCTIONS
PlayBack
Control
'
Enter below the Model No. and Serial No. which are located on the rear, bottom or side of the cabinet. Retain this information for future reference.
LET0091-001A
[J ]
Warnings, Cautions and Others
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
The lightning flash with arrowhead symbol
within an equilateral triangle is intended to
within an equilateral triangle alerts the user to
alert the user to the presence of uninsulated
the presence of uninsulated "dangerous
"dangerous voltage" within the product's
voltage" within the product's enclosure that
enclosure that may be of sufficient magnitude to constitute a risk of electric
could cavse electric shock.
shock to persons. The exclamation point within an equilateral
The exclamation mark within an equilateral
triangle is intended to alert the user to the
triangle alerts the user to important operating
presence of important operating and
and maintenance (servicing) instructions in the
maintenance (servicing) instructions in the
manval for the appliance.
literature accompanying the appliance.
For U.S.A.
For U.S.A.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to
Connect the equipment into an outlet on a circuit different from that
which the receiver is connected.
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Consult the dealer or an experienced radio/TV technician for help.
.
Caution –– POWER switch!
Disconnect the mains plug to shut the power off completely. The POWER switch in any position does not disconnect the mains line. The power can be remote controlled.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open and interlock failed or bypassed. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user service- able parts inside the player; leave all servicing to qualified service personnel.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
Table of Contents
General Information ................................... 2
Important cautions ..........................................................2
Safety precautions .......................................................... 2
Introduction ................................................ 3
Introducing the XV-D2000BK..........................................3
Controls and functions.................................................... 4
Supplied accessories ...................................................... 8
Before Using for the First Time ................. 9
Before making any connections .................................... 9
Connections ..................................................................... 9
Connecting with a TV. ..................................................9
Connecting with an audio amplifier or receiver ..... 10
Connecting with an amplifier equipped with
Dolby Digital 5.1-channel inputs ........................... 11
Connecting with an audio equipment with
digital input ..............................................................12
Connecting with a Dolby Digital decoder/amplifier
with built-in Dolby Digital decoder ....................... 13
Connecting the power cord ..........................................14
Installing batteries in the remote control unit............ 14
Preliminary Knowledge ........................... 16
Playable discs by XV-D2000BK ....................................16
What are title, chapter and track? .................................. 16
How to use numeric keys ............................................. 17
On-screen guide and invalid operation icons ............ 18
On-screen displays ........................................................18
Screen saver function ...................................................20
Dolby Digital .................................................................. 21
Basic Operations ...................................... 22
Playing back ...................................................................22
Selecting an item from a menu ................................... 23
DVD Video Operations............................. 24
Displaying DVD menus .................................................24
Locating a title ............................................................... 25
Selecting a chapter........................................................ 25
Starting playback from a specific time ....................... 26
Advancing a picture frame-by-frame ..........................26
Playing in slow-motion .................................................27
Resuming playback .......................................................27
Repeating a title .............................................................27
Repeating a chapter ......................................................28
Repeating a desired part .............................................. 29
Changing the angle .......................................................30
Subtitle on/off ................................................................30
Changing the subtitle language ...................................30
Changing the audio .......................................................31
Selecting picture character........................................... 32
Down Mix .......................................................................33
Compression ..................................................................34
Audio CD Operations ............................... 35
Playing back from a desired track ............................... 35
Resuming playback .......................................................35
Playing back in a desired order ................................... 36
Repeating all tracks .......................................................37
Repeating a single track ............................................... 37
Repeating a desired part .............................................. 38
Starting playback from a specified time .....................38
Playing back only the beginning of each track .......... 39
Playing back tracks in random order...........................40
Selecting the displayed time mode .............................40
Video CD Operations ............................... 42
Playing back from a desired track ............................... 42
Advancing a picture frame-by-frame ..........................42
Playing in slow-motion .................................................42
Resuming playback .......................................................43
Playing back in a desired order ................................... 43
Repeating all tracks .......................................................44
Repeating a single track ............................................... 45
Repeating a part ............................................................45
Starting playback from a specified time .....................46
Playing back only the beginning of each track .......... 47
Playing back tracks in random order...........................47
Selecting audio channels ............................................. 48
Selecting picture character........................................... 48
Checking total disc time ............................................... 49
Accessing the PBC function ......................................... 49
Controlling Other Equipment.................. 51
Controlling TV .................................................................51
Controlling CATV converter or satellite tuner ............... 52
Controlling a JVC amplifier or receiver ......................... 52
Selecting Preferences .............................. 53
Preferences via "PREFERENCE" on-screen display .......53
Setting Parental Lock ....................................................56
Other Information .................................... 59
Care and handling of discs ...........................................59
Table of languages and their abbreviations ...............60
Manufacture's code list ................................................ 61
AV COMPULINK remote control system..................... 62
Troubleshooting ............................................................ 64
Specifications.................................................................65
1
General Information
Important cautions
Installation of the player
• Select a place which is level, dry and neither too hot nor too cold (between 5˚C and 35˚C or 41˚F-95˚F).
• Leave sufficient distance between the player and a TV.
• Do not use the player in a place subject to vibrations.
Power cord
• Do not handle the power cord with wet hands!
• A small amount of power (5 watts) is always consumed while the power cord is connected to the wall outlet.
• When unplugging the player from the wall outlet, always pull the plug, not the power cord.
Malfunctions, etc.
• There are no user serviceable parts inside. If anything goes wrong, unplug the power cord and consult your dealer.
• Do not insert any metallic object into the player.
Safety precautions
Avoid moisture, water and dust
Do not place your player in moist or dusty places.
Avoid high temperatures
Do not expose your player to direct sunlight or place it near a heating device.
When you’re away
When away on travel or otherwise for an extended period of time, pull the plug from the outlet.
Do not insert foreign objects into the player
Do not insert wires, hairpins, coins, etc. into your player.
Do not block the vents
Blocking the vents may damage your player.
Care of the cabinet
When cleaning your player, use a soft cloth and follow the relevant instructions on the use of chemically-coated cloths. Do not use benzene, thinner or other organic solvents and disinfectants. These may cause deformation or discoloring.
If water gets inside the player
Turn off the power switch and pull the plug from the electrical socket, then call the store where you made your purchase. Using the player in this state may cause a fire or electrical shock.
2
Introduction
Introducing the XV-D2000BK
DVD is the most innovative creation of audio and video technology. With the same physical size as the CD, DVD has much more storage capacity and can play back the finest images and sound. It also realizes revolutionary features such as multi­language capability, multi-angle function, etc.
The XV-D2000BK DVD player delivers the outstanding performance of DVD, thanks to JVC’s advanced technology and sophisticated graphical user navigation system. The XV-D2000BK can also play back CDs and video CDs.
High quality video images
• Amazing color purity and sharpness with extremely low video distortion.
• Greater horizontal resolution than S-VHS or Laser disc.
High quality sound
• The newly developed K2 interface LSI delivers pure sound with no digital distortion.
• 1-bit DD converter that handles 20- bit, 96-kHz Fs audio signals and JVC’s original PEM (Pulse Edge Modulation) circuit achieve more than double the resolution of conventional converters.
• By separating and isolating the power supplies for the analog and digital circuitry, the interference which causes digital noise to enter the analog system is eliminated.
• Separation of the circuits, PLL clock generators and power supplies for the audio unit and video unit improve sound quality.
Support for various DVD functions
Note: Each function below is available only if the DVD disc to be played back
supports it.
Multi-language function
Multi-language function for audio and subtitles. You can choose any combinations of audio and subtitle languages, such as English audio with subtitles, or audio with no subtitles.
Multi-angle function
You can select from multiple camera angles of the same scene.
Parental lock
You can restrict the playback of discs with scenes which you do not wish your child to see, such as adult or violent films.
Multi aspects
Images can be viewed normally on a 4:3 (normal) television from a disc made for 16:9-screen (wide) televisions.
Dolby Digital
The XV-D2000BK is fully equipped with Dolby Digital. It provides both optical and coaxial digital outputs for connection to an external Dolby Digital decoder, as well as 5.1 channel analog outputs for be connection to an external AV amplifier equipped with 5.1 channel analog inputs.
3
Introduction
XV-D2000 DVD PLAYER
POWER
ON/STANDBY
PHONES PHONES LEVEL
RESUME
STANDBY
LINEAR PCM 96KHz SAMPLING
MIN MAX
DOLBY DIGI
DOLBY
DIGITAL
DOLBY DIGITAL 5.1
1
45
2
3456
7
8 9
Controls and functions
7 Front panel
STANDBY indicator
Lights when the power cord is connected and the player is at standby. When the player turns on, the STANDBY indicator goes off.
POWER ON/STANDBY
Turns the player on or off (standby).
RESUME indicator
Lights when a point to be resumed is stored.
DOLBY DIGITAL 5.1 indicator
Lights when all the Dolby Digital 5.1-channel audio outputs (FRONT, REAR, CENTER, SUBWOOFER) on the rear panel are feeding signals.
LINEAR PCM indicator
Lights when linear PCM audio is played back by DVD or CD.
96kHz SAMPLING indicator
Lights when the sampling frequency of linear PCM audio played back by DVD is 96kHz.
Remote sensor
PHONES
Connection terminal for headphones.
PHONES LEVEL
Adjusts the listening level of headphones connected to the PHONES jack.
Display
Indicates the current status of the player.
DVD indicator
Lights when a DVD disc is inserted. It blinks just after a disc is inserted.
4
10
DOLBY DIGITAL DECODER BUILT-IN
11
12
ON SCREEN DVD MENU
13
15
14
Introduction
16
ENTER
17
18 19 20 18
Disc tray
Used to load discs.
ON SCREEN
Displays an on-screen display of the player on the television screen or monitor. (See "On-screen displays" on page 18.)
0 (Open/Close)
Opens and closes the disc tray.
///
Selects an item in on-screen displays or DVD menus.
(Cursor buttons)
ENTER
Executes a selected item in a DVD menu or on-screen display.
4/1, ¢/¡ (Skip/Search)
Performs skip, fast forward/backward, or previous/next.
7 (Stop)
Stops playback.
3 (Play/Select)
Starts playback. Also, used a SELECT button for PBC of video CD.
DVD MENU
Displays a DVD menu on the television screen or monitor.
5
Introduction
7 Remote control unit
17
10
11
12
13
14
OPEN/CLOSE CATV/SAT TV
1
2
POWER
SET MUTE TV/VIDEO
DVD
19
18
21
3
20
123 456
4
789
100+CH RETURN
+
TV
VOLUME
D
V
D
M
10
VOLUME
STEP
R
E
E
N
U
AUDIO
TV
T
U
22
23
25
24
9
26
R
N
27
28
10 0
5
6
7
8
9
++++
SLOW
RESUME ANGLE SUB TITLIE DVD CATV
O
CH
ON /OFF
N
E
E
R
C
S
N
U
N
E
M
E
L
T
I
T
UP
LEFT RIGHT
15
DOWN
16
RM-SVD2000U REMOTE CONTROL
E
N
R
E
T
6
Introduction
///
OPEN/CLOSE
Opens and closes the disc tray.
POWER-CATV/SAT
Turns the CATV converter or satellite tuner on or off.
SET
Used to set the manufacturer’s code for operating another manufacturer’s TV, CATV or satellite tuner from the remote control unit. (See "Controlling Other Equipment" on pages 51.)
Numeric keys
Depending on the selection of DVD/TV/CATV switch, they are used for entering a title, track or chapter number, or selecting a TV channel.
SLOW (for DVD/video CD)
Starts slowmotion playback. (See "Playing in slow-motion" on pages 27 and 42.)
CH
Changes the channels of TV or CATV converter/satellite tuner.
RESUME
Stores the location to be resumed later. (See "Resuming Playback" on pages 27, 35 and 43.)
ANGLE (for DVD)
Changes camera angles during playback of a DVD shooting by multiple cameras. (See "Changing the Angle" on page 30.)
(Cursor buttons)
Selects an item in on-screen display, title menus or DVD menus.
ENTER
Executes a selected item in a menu or on-screen display.
Infrared light-emitting window
Point this window toward the remote sensor on the front panel when pressing buttons.
POWER-TV
Turns the TV on or off.
POWER-DVD
Turns the XV-D2000BK on or off (standby).
MUTE
Turns the mute function of the TV on or off.
TV/VIDEO
Switches input of the TV (either TV or VIDEO).
TV VOLUME
Adjusts the TV volume.
AUDIO VOLUME
Adjusts the volume of a JVC AV amplifier or receiver.
SUB-TITLE ON/OFF (for DVD)
Turns on or off subtitles. (See "Subtitle on/off" on page 30.)
4/1, ¢/¡ (Skip/Search)
Performs skip, fast forward/backward, or previous/next.
3/SELECT
Starts playback. Also, use as a SELECT button for PBC of video CD.
8 (Pause)
Pauses during playback.
7 (Stop)
Stops playback.
ON SCREEN
Displays an on-screen display of the player on the television screen or monitor. (See "On-screen displays" on page 18.)
TITLE MENU
Displays a title menu of DVD on the TV screen.
DVD/TV/CATV
Selects the function of the numeric keys to control the corresponding device.
STEP (for DVD/video CD)
Advances pictures frame by frame. (See "Advancing a picture frame-by-frame" on pages 26 and 42.)
RETURN (for DVD/video CD)
Returns to the previous menu.
DVD MENU
Displays a DVD menu on the television screen or monitor. (See "Displaying DVD menus" on page 24.)
7
Introduction
OPEN/CLOSE CATV/SAT TV
DVD
SET MUTE
TV/VIDEO
123
456
789
10 0
10
SLOW
CH
TV
VOLUME
AUDIO
VOLUME
++++
RESUME ANGLE SUB TITLIE
DVD CATV
ON /OFF
STEP
O
N
S
C
R
E
E
N
R
E
T
U
R
N
T
I
T
L
E
M
E
N
U
D
V
D
M
E
N
U
DOWN
UP
LEFT RIGHT
E
N
E
R
T
RM-SVD2000U REMOTE CONTROL
+
POWER
100+CH RETURN
TV
7 Rear panel
ATTENUATOR 2CH
OFF
1 2 6
SUBWOOFER
CENTER
REARFRONT
ON
RIGHT LEFTRIGHT LEFT
RIGHT LEFT
NORMAL
GAIN PLUS
1
VIDEO OUT
VIDEO S-VIDEO
AUDIO OUT
PCM/DOLBY DIGITAL
3 4 5
AUDIO OUT (2CH)
2CH (RIGHT and LEFT) terminals output analog audio signals. ATTENUATOR switch attenuates the output level when it is set to ON.
AUDIO OUT (5.1CH)
FRONT (RIGHT and LEFT), REAR (RIGHT and LEFT), CENTER, and SUBWOOFER terminals output Dolby digital 5.1ch. analog audio signals. SUBWOOFER switch boosts the SUBWOOFER signal when it is set to GAIN PLUS.
VIDEO OUT
VIDEO outputs composite video signals, while S­VIDEO outputs S-video signals.
AV COMPU LINKDIGITAL OUT
OPTICALCOAXIAL
DIGITAL OUT
Outputs digital audio signals. Both coaxial and optical connectors are provided.
AV COMPU LINK
Connects with another JVC equipment supporting the AV Compulink to facilitate operations. (See "AV COMPULINK remote control system" on page 62.)
AC POWER CORD
Connects to the wall outlet.
Supplied accessories
8
Audio/video cable (x 1)
AV compulink cord (x 1)
Audio Cable (x 3)
RM-SVD2000U Remote Control Unit (x 1)
S-video cable (x 1)
R6P(SUM-3)/AA(15F) batteries (x 2) for RM-SVD2000U
Before Using for the First Time
Before making any connections
Connections
• Since different components often have different terminal names, carefully read the instruction manual supplied with the component you wish to connect.
• Do not connect the AC power cord until all other connections have been made.
7 Connecting with a TV
You can enjoy the XV-D2000BK by simply connecting it with a television set. To hear audio sound with better quality, connect the audio outputs with your audio equipment. (See the following pages.)
Note: Be sure not to plug in the power cord until all other connections have been
made.
The XV-D2000BK can be connected directly to a television set equipped with stereo audio input and video input jacks using the supplied audio/video cables.
If your television set has a monaural audio input instead of stereo, you need to use an optional audio cable which converts stereo audio output to monaural.
If your television set has an S-video input, we recommend you to connect it with S­VIDEO of the player using the supplied S-video cable, in addition to the (standard) video connection, to get a better picture quality.
Connect VIDEO OUT of the player with the video input of a television set. Connecting VIDEO OUT of the player to a TV via a VCR may cause a monitor problem when playing back a copy-protected disc.
The ATTENUATOR switch beside the 2CH audio outputs should be normally set to OFF. If you hear the audio distorted because the sensitivity of the TV’s audio input is too high, set the ATTENUATOR to ON.
ATTENUATOR switch
ATTENUATOR 2CH
ON
OFF
RIGHT LEFTRIGHT LEFT
VIDEO OUT
VIDEO S-VIDEO
RIGHT LEFT
AUDIO OUT
NORMAL
PCM/DOLBY DIGITAL
OPTICALCOAXIAL
SUBWOOFER
CENTER
REARFRONT
S-Video cable (Supplied)
Yellow
White
GAIN PLUS
AV COMPU LINKDIGITAL OUT
To S-video inputs
To video input
To audio input left
XV-D2000BK
1
To VIDEO OUT
To 2CH RIGHT
To 2CH LEFT
DVD Player
Red
Audio/video cable (Supplied)
Yellow
Red
White
Audio/video cable (mono)
(optional)
To audio input right
Yellow
Black
TV
To video input To audio input (mono)
TV
9
Before Using for the First Time
7 Connecting with an audio amplifier or receiver
You can enjoy high-quality audio by connecting the player's audio outputs (2CH) to your amplifier or receiver.
Note: Be sure not to plug in the power cord until all other connections have been
made.
Connect the player's AUDIO OUT (2CH) to any line-level inputs (such as AUX, DVD, CD, etc.) of an audio amplifier or receiver.
The ATTENUATOR switch beside the 2CH audio outputs should be normally set to OFF. If you hear the audio distorted because the sensitivity of the amplifier’s line input is too high, set the ATTENUATOR to ON.
If the “DOWN MIX” item in the DVD on-screen display is set to “OFF”, you may not be able to get the proper audio signal from the player’s 2CH outputs when playing back a DVD disc with Dolby Digital 5.1-channel audio. (See “Down Mix” on page 33)
ATTENUATOR switch
ATTENUATOR 2CH
ON
OFF
RIGHT LEFTRIGHT LEFT
VIDEO OUT
VIDEO S-VIDEO
Red
To audio inputs
Amplifier or receiver
CENTER
REARFRONT
RIGHT LEFT
AUDIO OUT
White
Audio cable (Supplied)
SUBWOOFER
NORMAL
PCM/DOLBY DIGITAL
OPTICALCOAXIAL
GAIN PLUS
XV-D2000BK
1
AV COMPU LINKDIGITAL OUT
10
Before Using for the First Time
Rear speakerRear speaker
Front speaker
Front speaker
Sub woofer
Center speaker
AV COMPU LINKDIGITAL OUT
PCM/DOLBY DIGITAL
OPTICALCOAXIAL
AUDIO OUT
CENTER
SUBWOOFER
NORMAL
RIGHT LEFT
REARFRONT
RIGHT LEFTRIGHT LEFT
OFF
ON
ATTENUATOR 2CH
VIDEO S-VIDEO
GAIN PLUS
VIDEO OUT
1
XV-D2000BK
Amplifier or receiver
To audio inputs
Audio cable (Supplied)
FRONT REAR CENTER
SUB WOOFER
FRONT REAR CENTER SUB
WOOFER
SUBWOOFER switch
7 Connecting with an amplifier equipped with Dolby Digital
5.1-channel inputs
Connect the player’s 5.1-channel outputs (FRONT-RIGHT/LEFT, REAR-RIGHT/LEFT, CENTER, and SUBWOOFER) to the Dolby Digital 5.1-channel inputs of an amplifier using audio cables. Be sure to connect correctly between corresponding terminals.
Notes: • When using 5.1-channel outputs, you have to set some preferences (CEN-
TER SPEAKER, SURROUND SPEAKERS and BASS REDIRECT) in the “PREFERENCE” display:. (See “Preferences via “PREFERENCE” on-screen display” on page 53.)
• The subwoofer output level can be selected between NORMAL and GAIN PLUS by the SUBWOOFER switch. Normally it should be set to NORMAL but to enhance the low frequency, set it to GAIN PLUS.
• You can connect the audio outputs from the player to both a Dolby sur­round system and a TV via the 5.1-channel and 2-channel outputs. However, be sure to set DOWN MIX in the DVD on-screen display correctly according to the playback system (surround system or TV) when playing back a Dolby Digital 5.1-channel source. Otherwise, audio is not played back correctly. (See “Down Mix” on page 33.) Therefore, you cannot get proper audio from both the 2-channel and 5.1­channel outputs.
11
Before Using for the First Time
7 Connecting with an audio equipment with digital input
By connecting the player’s DIGITAL OUT (coaxial or optical) with the digital input of an amplifier, DAT or MD using a digital cable, the digital stereo audio signal in a disc is directly transferred.
ATTENUATOR 2CH
ON
OFF
RIGHT LEFTRIGHT LEFT
VIDEO OUT
VIDEO S-VIDEO
REARFRONT
RIGHT LEFT
AUDIO OUT
CENTER
SUBWOOFER
NORMAL
PCM/DOLBY DIGITAL
XV-D2000BK
GAIN PLUS
AV COMPU LINKDIGITAL OUT
OPTICALCOAXIAL
1
Coaxial cable
or
Optical digital cable
To digital input
MD Player
Note: • Before actual usage, set “DIGIT AL AUDIO OUTPUT” in the “PREFERENCE”
display to “PCM ONLY,” otherwise, playing back a Dolby Digital encoded DVD may generate noise and, in the worse case, damage your speakers. See “Preference via "PREFERENCE" on-screen display” on pages 53.
• Set “DOWN MIX” setting in the DVD on-screen display to “L0/R0” or “Lt/ Rt”. (See “Down Mix” on page 33.)
12
Before Using for the First Time
AV COMPU LINKDIGITAL OUT
PCM/DOLBY DIGITAL
OPTICALCOAXIAL
AUDIO OUT
CENTER
SUBWOOFER
NORMAL
RIGHT LEFT
REARFRONT
RIGHT LEFTRIGHT LEFT
OFF
ON
ATTENUATOR 2CH
VIDEO S-VIDEO
GAIN PLUS
VIDEO OUT
1
XV-D2000BK
To digital input
Optical digital cable
Amplifier or receiver
Coaxial digital cable
or
Rear speakerRear speaker
Front speaker
Front speaker
Sub woofer
Center speaker
7 Conecting with a Dolby Digital decoder/amplifier with
built-in Dolby Digital decoder
Connect the player’s DIGITAL OUT (coaxial or optical) to the digital input of a Dolby Digital decoder or an amplifier with built-in Dolby Digital decoder using an optional digital cable.
Notes: • Before actual usage, set “DIGIT AL AUDIO OUTPUT” in the “PREFERENCE”
on-screen display to “PCM/AC-3”. See “Preference via “PREFERENCE” on­screen display” on pages 53.
• With this connection, the player’s settings for COMPRESSION, DOWN MIX, CENTER SPEAKER, SURROUND SPEAKERS and BASS REDIRECT are in­valid. Settings for these items must be done in the decoder.
13
Before Using for the First Time
Connecting the power cord
When all the connections have been made, insert the power plug into the wall outlet firmly. The STANDBY indicator lights and the setup is completed.
Warning
• Disconnect the power cord if you are not going to use the player for a long time.
• Disconnect the power cord before cleaning the player.
• Disconnect the power cord before moving it.
• Do not connect or disconnect the power cord with wet hands.
• Do not pull the power cord when disconnecting it, as this may damage the cord and cause fire, electric shock, or other accidents.
Caution
• Do not damage, remodel, twist, or pull the power cord, as this may cause fire, electric shock, or other accidents.
• Contact a dealer and get a new power cord if the cord is damaged. A damaged cord may cause fire, electric shock, or other accidents.
• Do not put anything heavy or this player on the power cord, as this may cause fire, electric shock, or other accidents.
Installing batteries in the remote control unit
The battery compartment is located on the back of the remote control unit.
1. Press down on the triangular
mark of the compartment cover, and pull up the cover to open the compartment.
2. Place the two accessory R6P
(SUM-3)/AA(15F) batteries in the remote control according to the polarity markings (“+” and “–”) inside the compartment and on the batteries.
3. Place the cover over the com-
partment, and press down lightly.
14
Before Using for the First Time
The batteries will last about one year with normal use. If the functions of the remote control become erratic, replace the batteries. See “Precautions for the safe use of batteries” below for more information.
Precautions for the safe use of batteries
Observe the following precautions for the safe use of batteries. If they are used improperly, their life will be shortened, they may burst or their contents may leak.
• Remove the batteries from the remote control if it is not going to be used for a long period of time.
• Remove dead batteries and dispose of them properly.
• Never leave dead batteries lying around, take them apart, mix them with other refuse, or throw them into an incinerator.
• Never touch liquid that has leaked out of a battery.
• Do not mix new and old batteries, or batteries of different types, when replacing them.
15
Preliminary Knowledge
Playable discs by XV-D2000BK
The XV-D2000BK can play back DVD video, video CD and audio CD discs.
• DVD players and DVD discs have their own numbers describing the region(s) where they can be played by retail areas. These numbers are called "Region Codes." The Region Code for this unit is "1", so any discs whose Region Codes is not "1" cannot be played.
Examples of playable DVD discs
ALL
• This unit is designed to use the NTSC system.
• Any other discs than listed above (CD-ROM, Photo CD, etc.) cannot be played. Playing back such discs may generate noise and damage speakers.
• Sound of CD-G discs are playable but pictures are unplayable.
• Do not play back CD-R discs. Playing back a CD-R disc may damage the contents of the disc.
1
2
1
21
4
3
What are title, chapter and track?
A DVD disc comprises “titles,” while an audio CD or video CD comprises “tracks.” Each title may be divided into some “chapters.” For example, if a disc contains some movies, each movie may have its own title number, and each movie may be divided into some chapters. In a karaoke disc, each song usually has its own title number and does not have chapters. In general, each title has an independent content, while each chapter in the same title has continuity.
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 3 Chapter 1 Chapter 2
For a DVD
Track 1 Track 2 Track 3 Track 4
For an audio CD
16
Preliminary Knowledge
How to use numeric keys
123 456 789
10 0
100+CH RETURN
+
10
According to the setting of the DVD/TV/CATV switch, the numeric key functions differ.
7 When setting the DVD/TV/CATV switch to “TV”
The numeric keys select TV channels.
7 When setting the DVD/TV/CATV switch to “CATV”
The numeric keys select channels of a CATV converter or satellite tuner.
7 When setting the DVD/TV/CATV switch to “DVD”
The numeric keys are used to select a track or title number, or to enter a specific time or chapter number.
1) To select a track or title number directly using numeric keys
• To select a number between 1 and 10 ...
Press the corresponding key(s) for the number.
• To select a number higher than 10 ...
Use the +10.
Example 1: To select 13
+10 = 3
Example 2: To select 35
+10 = +10 = +10 = 5
Example 3: To select 40
+10 = +10 = +10 = 10
2) To enter a specific time or chapter number via on-screen displays
Press the corresponding numeric keys for a desired time or number from left to right digits, then ENTER.
Example 1: To enter 10:52
1 = 0 = 5 = 2 = ENTER
Example 2: To enter chapter number 14
1 = 4 = ENTER
If you enter a wrong number, enter zeros until the wrong number disappears, then reenter the correct numbers.
17
Preliminary Knowledge
On-screen guide and invalid operation icons
7 On-screen icons
During DVD playback, you may see icons displayed over the picture. These have the following meanings.
: Displayed at the beginning of a scene recorded from multiple angles.
(See “Changing the angle” on page 30.)
: Displayed at the beginning of a scene recorded with multiple audio
languages. (See “Changing the audio” on page 31.)
: Displayed at the beginning of a scene recorded with multiple subtitles.
(See “Changing the subtitle language” on page 30.)
You can set not to display on-screen icons above via the preference settings described on pages 53.
7 Invalid operation icon
When you press a button, if the XV-D2000BK does not accept its operation, appears on your television screen. Operations are occasionally unacceptable even
if is not displayed.
Note that some operation may not be accepted. For example, some discs may not allow fast forward, fast backward or slow-motion playback.
On-screen displays
The player provides several On-Screen Displays shown below for choosing preferences for initial settings and functions which are not frequently used in most cases.
Opening display DVD during playback
18
For preferences
Preliminary Knowledge
CD (For CD during playback For video CD
or stop and for video CD during stop) (during playback)
For DVD parental lock settings
To access on-screen displays, press ON SCREEN (Note that operation for accessing the “Parental Lock” on screen displays is different.). Depending on the type of disc inserted (or “no disc”) and the player’s mode, a proper on-screen display is accessed. See "Setting Parental Lock" on pages 56.
appears at the on-screen display. You can move using
used to select items you want to work with.
Basic operations in the on-screen display are as follows.
• With an item like , you can change the setting with
it.
- type item works when you place on the item and press ENTER.
• In the message box, indicates the operation to be done.
• Numbers are entered using numeric keys.
• Some functions become effective by pressing the ENTER button after specifying
necessary entries.
• Pressing ON SCREEN again exits the on screen display.
///
by placing on
/
. is
19
Preliminary Knowledge
In the displays for playback mode of DVD and video CD, the following information is displayed under the image screen.
DVD Video CD
Screen saver function
Current title number
Current relative position on the title (B: beginning, E: end)
Current chapter number
Elapsed time from the beginning of the current title
Current track number
Current relative position on the track (B: beginning, E: end)
Elapsed time from the beginning of the current track
Refer to the corresponding paragraphs for detailed information.
A television monitor screen may be burned out if a static picture is displayed for a long time. To prevent this, the player automatically activates the screen saver function if a static picture, such as an on-screen display or menu, is displayed for 5 minutes.
Pressing any button of the player or the remote control unit will release the screen saver function and go back to the previous display.
20
Dolby Digital
Preliminary Knowledge
Dolby Digital is a surround system using the digital audio compression technology developed by Dolby laboratories Licensing Corporation. It is configured with six channels and reproduced by a speaker system including front (L and R), rear (L and R), center and sub-woofer. Because a sub-woofer in this system is an auxiliary speaker, this system is called “5.1 channel system”. In a DVD video disc, the surround audio data is recorded digitally in a bit-stream. This information is separated into up to 6 (analog) audio channel signals by a decoder, which are reproduced by up to 6 corresponding speakers via a 6-channel amplifier. A disc encoded with Dolby Digital displays the symbol. Note that not all Dolby Digital encoded DVD video discs contain 6 channel signals. Some may contain only L and R, while the others L, R and rear.
7 The XV-D2000BK fully supports Dolby Digital.
* Built in Dolby Digital decoder and equipped with 5.1ch. outputs.
You do not need an external Dolby Digital decoder. The player decodes Dolby Digital signal internally and outputs decoded analog signals from the 5.1 channel outputs, which are to be connected directly to an 6-channel amplifier equipped with 5.1 channel inputs. (See “Connecting with an amplifier equipped with Dolby Digital 5.1-channel inputs” on page 11)
* Displaying playback Dolby Digital Channels
The front panel display indicates Dolby Digital channels being played back.
L, R: for front (L, R) speakers LS, RS: for rear (L, R) speakers C: for a center speaker LFE: for a sub-woofer S: for rear speakers (monaural)
* Down Mix selection
Depending on the audio system for playback, you can select the optimum stereo mix signals. (See “Down Mix” on page 33)
* Selections/settings for 5.1-channel output signals
• Sub-woofer output level selection
You can boost the sub-woofer output level to enhance the low frequency range. (See “Rear panel” on page 8)
• Selections for Compression (See “Compression” on page 34)
You can select whether or not compressing the dynamic range when playing back with a 5.1-channel surround system. With no compression, you can enjoy a dynamic sound DVDs provide. However, we recommend to compress if you enjoy with low sound level.
• Settings for Center speaker, Surround speakers and Bass redirect
(See See “Preferences via “PREFERENCE” on-screen display” on page 53) According to your speaker configuration, you can get the optimum sound balance.
* Manufactured under license from Dolby Laboratories Licensing Corporation.
DOLBY, the double-D symbol and "AC-3" are trademarks of Dolby Laboratories Licensing Corpration.
21
Basic Operations
This chapter explains the basic playback common for DVD, audio CD and video CD. The illustrations in the left column here show the buttons of the remote control unit to be operated, however, you may use the corresponding buttons on the front panel of the player.
Playing back
OPEN/CLOSE
1. Press OPEN/CLOSE to open the disc tray.
2. Place the disc in the tray with the label side up.
ON SCREEN
/
Notes: When loading a disc in the tray, be sure to position the disc inside the recess.
3. Press 3 to close the tray.
The player starts playback from the beginning of the disc.
If a menu appears:
To stop playback:
To pause playback:
To move fast forward or fast backward:
Otherwise, the disc may be damaged when the tray is closed, and the disc may not be removed from the player.
Refer to “Selecting from menu items” on the next page.
Press 7.
Press 8. Pressing 3 resumes playback.
Hold down 4/1 or ¢/¡. Releasing the button returns the player to the normal playback mode.
*Both fast forward and fast backward move slowly for a while and then quickly
thereafter.
*During fast forward or fast backward with a DVD disc or video CD, no audio is
output.
If it seems that the picture’s vertical/horizontal ratio is not correct when playing back a DVD video disc, set the MONITOR TYPE in the PREFERENCE display correctly. See “Preferences via “PREFERENCE” on-screen display” on page 53.
22
Some functions like fast forward or fast backward are disabled because of the recording method of DVD discs. In this case, the functions do not work even if the operations are done.
///
Basic Operations
Selecting an item from a menu
With some DVD and video CD discs, a menu may appear automatically after inserting a disc or manually during playback or stop.
Example of menu
7 For DVD videodisc
To select an item in the menu:
UP
LEFT RIGHT
DOWN
123 456 789
10 0
1. Select a desired item using
E
N
R
E
T
The player starts playback of the selected item.
, then press ENTER.
With some discs, you can select the item by entering the corresponding number using the numeric keys, causing the player to automatically start playback.
7 For video CD
1. Press the numeric button corresponding to a desired item. The player automatically starts playback.
100+CH RETURN
+
10
* If you can see “NEXT” or “PREVIOUS,” or equivalents in the menu, pressing
4/1 or ¢/¡ usually turns the menu pages.
* Pressing “RETURN” returns to the previous menu.
The operation procedure may be different depending on discs. Read the manual for the discs and follow the procedure indicated in the menu.
23
DVD Video Operations
This chapter explains all the functions of the player for playing back DVD discs. You can enjoy DVD in various ways, some of which only DVD can offer. Read “Basic Operations” on pages 22 and 23 before reading this chapter.
Displaying DVD menus
Most DVD discs have their own menus for selecting an item (title or chapter) to be played. A menu may be displayed automatically after inserting a disc or manually during playback or stop.
7 To access a title menu
1. Press TITLE MENU. A title menu appears. See “Selecting an item from a menu” on page 23, as well as the operation manual of the disc, for details of menu operations.
If appears when pressing the TITLE MENU button:
The disc does not contain a title menu.
Pressing TITLE MENU again turns off the menu and resumes playback from the previous scene.
7 To access a DVD menu
1. Press DVD MENU. A DVD menu appears. See “Selecting an item from a menu” on page 23, as well as the operation manual of the disc, for details of menu operations.
If appears when pressing the DVD MENU button:
The disc does not contain any DVD menu.
Pressing DVD MENU again turns off the menu and resumes playback from the previous scene.
24
Locating a title
DVD Video Operations
You can locate a title you want to see by selecting a title number.
1. Press 7 to stop the disc.
123 456 789
10 0
100+CH RETURN
+
10
Selecting a chapter
UP
LEFT RIGHT
DOWN
2. Press the corresponding numeric keys for a desired title. The player starts playback of the title.
If appears when pressing numeric key(s):
The disc does not contain the corresponding title.
You can specify a chapter to be played back using the on-screen display.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “CHAP. SEARCH” using the The message box indicates “GO TO CHAPTER: “.
.
/
123 456 789
10 0
E
100+CH RETURN
+
10
N
R
E
T
3. Enter a desired chapter number using the numeric keys. See page 17 for details about how to use the numeric keys.
4. Press ENTER. The player starts playback from the selected chapter.
If appears when pressing ENTER:
The disc does not contain chapters, or prohibits the chapter search function.
To turn off the on-screen display:
Press ON SCREEN.
25
DVD Video Operations
Starting playback from a specific time
If a DVD disc has time information (such a disc indicates the time in the display on the front panel), you can specify the time to start playback.
1. Press ON SCREEN during playback. The on-screen display appears.
UP
LEFT RIGHT
DOWN
123 456 789
10 0
E
100+CH RETURN
+
10
N
R
E
T
2. Move to the “TIME SEARCH” using
.
/
The message box indicates “GO TO : : “.
3. Enter a desired time using the numeric keys. See page 17 for details about how to use the numeric keys.
4. Press ENTER. The player starts playback from the specified time.
Advancing a picture frame-by-frame
STEP
26
If appears when pressing ENTER:
The disc does not contain time code or specified time, or prohibits the time search function.
To turn off the on-screen display:
Press ON SCREEN.
You can advance a still picture frame-by-frame.
1. Press STEP during playback. The player pauses. Each time you press STEP, the picture advances one frame.
Pressing 3 returns the player to normal playback.
* The audio is muted during frame-by-frame playback. * You cannot backward a picture frame-by-frame.
Playing in slow-motion
DVD Video Operations
You can playback a disc in slow-motion.
+
SLOW
Resuming playback
POWER
RESUME
CATV/SAT TV
or
DVD
1. Press SLOW “+” during playback. The playback speed slows down to half the normal speed.
Thereafter, each press of SLOW “+” slows the speed down to 1/3, 1/4, 1/8, 1/16 and 1/32 of the normal speed.
Pressing SLOW “–” speeds up in reverse order of the above.
Pressing 3 returns the player to normal playback.
* Audio is muted during slow-motion playback. * When the picture is being played back at 1/32 of the normal speed (which is the
slowest), the SLOW “+” button is not effective. Similarly, “–” button is not effective during 1/2 speed playback.
* Pressing STEP or 8 in slow-motion mode freezes the motion.
The player can memorize a position on a disc you want to interrupt playback and resume playback from that position later.
7 Memorizing a position
1. During playback, Press RESUME, or press POWER to turn off the power (STANDBY). The player memorizes the current playback position of the disc, and the RESUME indicator on the front panel lights.
RESUME
Repeating a title
To clear the memory:
Take out the disc from the disc tray.
* The last memory overrides the previous memory.
7 Resuming playback
1. Press RESUME when the disc is stopped or the power is off (STANDBY).
The player will locate the memory position and resume playback.
You can repeat playback of the current title.
1. Press ON SCREEN during playback. The on-screen display appears.
27
DVD Video Operations
UP
LEFT RIGHT
DOWN
E
N
R
E
T
2. Move to “REPEAT” using
.
/
3. Press ENTER once. The message box indicates “TITLE REPEAT”. The current title will be repeated.
If appears when pressing ENTER:
You cannot repeat the title because of the disc contents.
To turn off the on-screen display:
Press ON SCREEN. Pressing it again turns on the on-screen display again.
To quit Title Repeat:
Press 7. The player stops playback and quits the title repeat mode.
Repeating a chapter
UP
LEFT RIGHT
DOWN
If you want to quit the title repeat mode but do not want to interrupt playback,
move to “REPEAT” in the on-screen display and press ENTER twice. “REPEAT” returns to its original color.
You can repeat a current chapter.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “REPEAT” using
.
/
28
E
N
R
E
T
3. Press ENTER twice. The current chapter will be repeated. The message box indicates “CHAPTER REPEAT”.
Repeating a desired part
DVD Video Operations
If appears when pressing ENTER:
You cannot repeat the chapter because of the disc contents.
To turn off the on-screen display:
Press ON SCREEN. Pressing it again turns on the on-screen display again.
To quit Chapter Repeat:
Press 7. The player stops playback and quits the chapter repeat mode.
If you want to quit the chapter repeat mode but do not want to interrupt
playback, move to “REPEAT” in the on-screen display and press ENTER once. “REPEAT” returns to its original color.
You can repeat a desired part in the current title.
1. Press ON SCREEN during playback. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
E
N
R
E
T
2. Move to “A-B REPEAT” using
.
/
3. At the beginning of the desired part (point A), press ENTER.
4. At the end of the desired part (point B), press ENTER. The player locates “A” and starts playback between “A” and “B” repeatedly.
To quit A-B Repeat:
Press 7. The player stops playback and quits the A-B repeat mode.
If you want to quit the A-B repeat mode but do not want to interrupt playback,
move to “A-B REPEAT” in the on-screen display and press ENTER.
If appears when pressing ENTER:
You cannot execute the A-B Repeat because of the disc contents.
To turn off the on-screen display:
Press ON SCREEN. Pressing it again turns on the on-screen display again.
29
DVD Video Operations
Initial setting:
angle 1
Press ANGLE once:
angle 2
Press it again:
angle 3
Press it again:
angle 1
Changing the angle
Some DVD discs may have “multi-angle” parts, in which multiple cameras were used to shoot the same scene from different angles. You can select one of these angles during playback.
ANGLE
1. Press ANGLE on the remote control unit. Each time you press the button, the angle changes in numerical order. The ANGLE function is effective only when the current playback scene is recorded from multiple angles.
Example: Selecting from three different angles
If appears when pressing ANGLE:
The current scene is not recorded from multiple angles.
* You can also select the angle via the “ANGLE” in the on-screen display.
1. Press ON SCREEN during playback.
2. Move to “ANGLE” using
3. Change the angle number using
The current angle number and the total number of recorded angles are displayed in the box.
Example:
1: currect angle number 3: total number of recorded angles
.
/
.
/
Subtitle on/off
SUB TITLIE
ON /OFF
Changing the subtitle language
You can select whether or not subtitles are displayed.
1. Press SUBTITLE ON/OFF on the remote control unit. The ON/OFF status is switched.
* Subtitles cannot be displayed unless a DVD includes subtitles. * With some discs, subtitles are always displayed and SUBTITLE ON/OFF does
not work.
You can choose the subtitle language from among the languages included on a disc during playback.
1. Press ON SCREEN during playback. The on-screen display appears.
30
DVD Video Operations
UP
LEFT RIGHT
DOWN
UP
LEFT RIGHT
DOWN
2. Move to “SUBTITLE” using
.
/
The current subtitle number and the total number of recorded subtitles are displayed in the box.
Example:
The example above indicates that 3 subtitle languages are recorded in the disc and subtitle language 1 is being played back.
3. Change the subtitle using
.
/
The subtitle language changes in numerical order.
Example: Selecting from three subtitle languages
Language 1 Language 2 Language 3
Changing the audio
UP
LEFT RIGHT
DOWN
To turn off the on-screen display:
Press ON SCREEN. Pressing it again turns on the on-screen display again.
You can change the audio language or sound during playback.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to "AUDIO" using
.
/
The current audio channel number and the total number of recorded audio channels are displayed in the box.
Example:
The example above indicates that 3 audio channels are recorded in the disc and audio channel 2 is being played back.
31
DVD Video Operations
UP
LEFT RIGHT
DOWN
Selecting picture character
UP
LEFT RIGHT
DOWN
3. Change the audio channel using
.
/
The audio channel changes in numerical order.
Example: Selecting from three audio channels
Audio 1 Audio 2 Audio 3
To turn off the on-screen display:
Press ON SCREEN. Pressing it again turns on the on-screen display again.
You can select from three picture characters; sharp, soft and noise reduction.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “PICTURE” using
.
/
UP
LEFT RIGHT
DOWN
3. Select A, B, C using
.
/
A: sharp B: soft C: noise reduction
* You can set the picture characters for DVDs and video CDs independently. * The selection is memorized even if the player turns off and on.
To turn off the on-screen display:
Press ON SCREEN.
32
Down Mix
DVD Video Operations
You can get the optimum stereo mix signals from DVD discs recorded with Dolby Digital surround multichannel audio, depending on your audio system by selecting DOWN MIX correctly. You can change DOWN MIX setting only when playing back a DVD disc recorded with Dolby Digital surround multichannel audio.
1. Press ON SCREEN during playback. The on-screen display appears.
UP
LEFT RIGHT
DOWN
2. Move to “DOWN MIX” using
.
/
3. Select from the following selections. Lt/Rt: If you monitor the player’s 2-channel audio output signals via an
amplifier with built-in Dolby Pro Logic.
Lo/Ro:If you monitor the player’s 2-channel audio output signals via a TV, an
amplifier with no built-in Dolby Pro Logic, or the player’s headphone jack. Or if you record DVD audio to a cassette tape, MD, etc.
OFF: If you monitor the player’s 5.1-channel audio output signals via an
amplifier equipped with Dolby Digital 5.1-channel inputs.
* Output signal from DIGITAL OUT
When setting “DIGITAL AUDIO OUTPUT” in the PREFERENCE on-screen display to “PCM ONLY” (see “Selecting Preferences” on page 53”), the same type of the signal as the analog 2 CH outputs is fed from the DIGITAL OUT. If you use DIGITAL OUT, select “DOWN MIX” to “Lt/Rt” or “L0/R0” according to the condition described above.
* If setting “DOWN MIX” to “OFF” while setting “CENTER SPEAKER” and
“SURROUND SPEAKER” in the PREFERENCE on-screen display to “NONE”, the same signal is output as setting to “Lt/Rt”. (see “Selecting Preferences” on page 53”)
* If “DOWN MIX” is not correctly selected, you may have a trouble in playing
back a DVD disc recorded with the Dolby Digital surround multichannel audio as follows.
• Monitoring 2-channel audio with setting “DOWN MIX” to “OFF”: Some material (such as dialog in a movie) may not be played back. (because channels except front L and R are not played back.)
• Monitoring 5.1-channel audio with setting “DOWN MIX” to “Lt/Rt” or “L0/ R0”: You cannot hear the sound from speakers except the front L and R. (because all sounds are mixed into front L and R.)
So if you connect both a Dolby Digital surround system and TV to the player and use one of them depending on the situation, you must be careful to set DOWN MIX correctly according to the playback system when playing back a Dolby Digital 5.1-channel source.
To turn off the on-screen display:
Press ON SCREEN.
33
DVD Video Operations
Compression
Most DVD video discs recorded with Dolby Digital offer wider dynamic range than conventional VHS-videos or video CDs, which usually is too wide for a general home­use. When setting “COMPRESSION” to “ON”, audio is played back with dynamic range compressed. When “OFF”, it is played back as it is recorded.
You can select ON or OFF of “COMPRESSION” only when the DOLBY DIGITAL 5.1 indicator on the player’s front panel lights, which actually means the player is playing back a DVD disc recorded with Dolby Digital 5- or 5.1-channel surround audio in the Dolby Digital 5.1-channel playback system. In other words, the following conditions are satisfied, the indicator lights.
* In the preferences, “CENTER SPEAKER” and “SURROUND SPEAKERS” are
set to “USE”, and “BASS REDIRECT” is set to “SUB”. * DOWN MIX is set to OFF. * The front panel display indicates the recorded channels as below.
UP
LEFT RIGHT
DOWN
recorded with 5 channel audio or recorded with 5.1 channel audio
In the other cases, the player automatically sets the COMPRESSION setting as below.
* For a DVD disc recorded with linear PCM or MPEG audio: OFF * For a DVD disc recorded with up to 4-channel Dolby Digital audio: ON * For a DVD disc recorded with Dolby Digital 5- or 5.1-channel audio but the
player’s preferences are not set as above (=the speaker system does not
contain all units for 5.1 channels: ON
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “COMPRESSION” using
.
/
34
UP
LEFT RIGHT
DOWN
3. Turn compression ON or OFF using
To turn off the on-screen display:
Press ON SCREEN.
.
/
Audio CD Operations
This chapter explains all the functions of the player for playing back audio CDs. Read “Basic Operations” on pages 22 and 23 before reading this chapter.
Playing back from a desired track
123 456 789
10 0
100+CH RETURN
+
10
Resuming playback
7 Using 1/4, ¢/¡ buttons during playback
Pressing ¢/¡ causes the player to jump to the next track and start playback. Therefore, press ¢/¡ as many times as required to jump to the desired track and start playback. Similarly, pressing 1/4 causes the player to jump to the beginning of the current track and start playback. By pressing it again, the player jumps to the previous track and starts playback.
7 Using numeric keys
You can also use the numeric keys on the remote control unit to select a track number. The player automatically starts playback from the selected track regardless of the player's mode.
See page 17 for details about how to use the numeric keys.
The player can memorize a position on a disc you want to interrupt playback and resume playback from that position later.
RESUME
POWER
CATV/SAT TV
or
RESUME
DVD
7 Memorizing a position
1. During playback, Press RESUME, or press POWER to turn off the power (STANDBY).
The player memorizes the current playback position of the disc, and the RESUME indicator on the front panel lights.
To clear the memory:
Take out the disc from the disc tray.
* The last memory overrides the previous memory.
7 Resuming playback
1. Press RESUME when the disc is stopped or the power is off (STANDBY).
The player will locate the memory position and start playback.
35
Audio CD Operations
Playing back in a desired order
You can listen to the tracks on a CD in the order you want.
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
UP
LEFT RIGHT
DOWN
123 456 789
10 0
or
+
10
2. Move to “PROGRAM” using
E
N
R
E
T
and press ENTER.
/
3. Select the tracks in the desired order using the numeric keys.
* See page 17 for details about how to use the numeric keys. The entered numbers
100+CH RETURN
are displayed on the screen.
* Up to 16 tracks can be programmed. You may select the same track more than
once.
If you make a mistake:
Move to CLEAR in the display using programmed track is deleted.
///
and press ENTER. The last
4. Press 3 to start the program playback.
* When all of the programmed tracks have finished playback, the player stops but
the program remains.
* Pressing 7 during the program playback makes the player stop but the program
remains.
To quit the program mode:
Move to “PROGRAM” in the display using “PROGRAM” returns to its original color.
///
and press ENTER.
36
Repeating all tracks
Audio CD Operations
1. Press ON SCREEN. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
2. Move to “REPEAT” using
.
/
3. Press ENTER once. “REPEAT ALL” is displayed and all tracks are played back repeatedly.
To stop playback
Press 7. The player stops but the All-track repeat mode remains.
To quit All-track Repeat:
Move to “REPEAT” in the on-screen display and press ENTER twice. “REPEAT” returns to its original color.
Repeating a single track
UP
LEFT RIGHT
DOWN
E
N
R
E
T
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “REPEAT” using
.
/
3. Press ENTER twice. “REPEAT1” is displayed and the current track is played back repeatedly.
To stop playback
Press 7. The player stops but the Single repeat mode remains.
37
Audio CD Operations
Repeating a desired part
UP
LEFT RIGHT
DOWN
To quit Single Repeat:
Move to “REPEAT” in the on-screen display and press ENTER. “REPEAT” returns to its original color.
E
N
R
E
T
E
N
R
E
T
You can repeat a desired part in a CD.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “A-B REPEAT” using
.
/
38
UP
LEFT RIGHT
DOWN
3. At the beginning of the desired part (point A), press ENTER.
Audio CD Operations
E
N
R
E
T
To quit A-B Repeat:
Press 7. The player stops and quits the A-B repeat mode.
Starting playback from a specified time
123 456 789
10 0
UP
LEFT RIGHT
DOWN
100+CH RETURN
+
10
E
N
R
E
T
You can playback a disc from the desired position by specifying the elapsed time from the beginning of the disc. (You have to know the corresponding elapsed time in advance. To know the elapsed time, see “Selecting the displayed time mode” on page 40.)
1. Press ON SCREEN. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
2. Move to the “TIME SEARCH” using
.
/
39
Audio CD Operations
3. Press ENTER.
You can check the first 10 seconds of each track on a disc.
1. Press ON SCREEN while the disc is stopped.
4. Enter a desired time using the numeric keys on the remote control unit. The on-screen display appears.
See page 17 for details about how to use the numeric keys.
UP
LEFT RIGHT
DOWN
Playing back only the beginning of each track
E
N
R
E
T
2. Move to “INTRO” using
5. Move to "TIME SEARCH" using
.
/
and press ENTER.
/
The player starts playback from the specified time.
If the specified time does not exist, the entered number disappears so that you can reenter the time.
3. Press ENTER. The first 10 seconds of each track on a disc are played back from the first track in numerical order. When all the tracks are played back, the player quits this function.
To quit this function during execution
Press 7.
Playing back tracks in random order
UP
LEFT RIGHT
DOWN
40
Audio CD Operations
E
N
R
E
T
The player can playback tracks in random order.
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
2. Move to “RANDOM” using
3. Press ENTER. The Random play begins. When all tracks have been played once, the Random play quits.
.
/
Selecting the displayed time mode
* The same track will not be played back more than once during the Random play.
To quit this function during execution
Press 7.
41
Video CD Operations
This chapter explains all the functions of the player for playing back video CDs. Read “Basic Operations” on pages 22 and 23 before reading this chapter.
Playing back from a desired track
7 Using 1/4, ¢/¡ buttons during playback
Pressing ¢/¡ causes the player to jump to the next track and start playback. Therefore, press ¢/¡ as many times as required to jump to the desired track and start playback. Similarly, pressing 1/4 causes the player to jump to the beginning of the current track and start playback. By pressing it again, the player jumps to the previous track and starts playback.
* Note that this operation is disabled during playback with PBC.
123 456 789
10 0
100+CH RETURN
+
10
Advancing a picture frame-by-frame
STEP
7 Using numeric keys
You can also use the numeric keys on the remote control unit to select a track number. The player automatically starts playback from the selected track regardless of the player's mode.
See page 17 for details about how to use the numeric keys.
* Note that this operation is disabled during playback with PBC.
You can advance a still picture frame-by-frame.
1. Press STEP during playback. The player pauses. Each time you press STEP, the picture advances one frame.
Pressing 3 returns the player to normal playback.
* The audio is muted during frame-by-frame playback. * You cannot backward a picture frame-by-frame.
Playing in slow-motion
+
SLOW
42
You can playback a disc in slow-motion.
1. Press SLOW “+” during playback. The playback speed slows down to half the normal speed.
Thereafter, each press of SLOW “+” slows the speed down to 1/3, 1/4, 1/8, 1/16 and 1/32 of the normal speed.
Pressing SLOW “–” speeds up in reverse order of the above.
Pressing 3 returns the player to normal playback.
* Audio is muted during slow-motion playback. * When the picture is being played back of 1/32 of the normal speed (which is the
slowest) the SLOW “+” button is not effective.
* Similarly, “–” button is not effective during 1/2 speed playback. * Pressing STEP or 8 in slow-motion mode freezes the motion.
Resuming playback
Video CD Operations
The player can memorize a position on a disc you want to interrupt playback and resume playback from that position later.
7 Memorizing a position
POWER
RESUME
CATV/SAT TV
or
RESUME
Playing back in a desired order
DVD
1. During playback, Press RESUME, or press POWER to turn off the power (STANDBY).
The player memorizes the current playback position of the disc, and the RESUME indicator on the front panel lights.
To clear the memory:
Take out the disc from the disc tray.
* The last memory overrides the previous memory.
7 Resuming playback
1. Press RESUME when the disc is stopped or the power is off (STANDBY).
The player will locate the memory position and start playback.
* The XV-D2000BK may resume playback from slightly before the memorized
position if you operate when “PBC” is indicated in the front panel display.
You can enjoy the tracks on a video CD in the order you want.
UP
LEFT RIGHT
DOWN
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
2. Move to “PROGRAM” using
E
N
R
E
T
and press ENTER.
/
43
Video CD Operations
123 456 789
10 0
+
10
100+CH RETURN
3. Select the tracks in the desired order using the numeric keys.
* See page 17 for details about how to use the numeric keys. The entered numbers
are displayed on the screen.
* Up to 16 tracks can be programmed. You may select the same track more than
once.
If you make a mistake:
Move to CLEAR in the display using
///
programmed track is deleted.
4. Press 3 to start the program playback.
* When all of the programmed tracks have finished playback, the player stops but
the program remains.
* Pressing 7 during the program playback makes the player stop but the program
remains.
and press ENTER. The last
To quit the program mode:
1. Press 7 if the player is playing.
2. Press ON SCREEN to turn on the on-screen display.
3. Move to “PROGRAM” in the display using
“PROGRAM” returns to its original color.
///
and press ENTER.
Repeating all tracks
UP
LEFT RIGHT
DOWN
E
N
R
E
T
* Note that this function cannot be used during playback with PBC. To use this
function, press 7 to stop playback and then specify any track number by using the numeric keys. (See “Playing back from a desired track” on page 42.)
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “REPEAT” using
.
/
3. Press ENTER once. “REPEAT ALL” is displayed and all tracks are played back repeatedly.
44
To stop playback
Press 7. The player stops but the All-track repeat mode remains.
To quit All-track Repeat:
Move to “REPEAT” in the on-screen display and press ENTER twice. “REPEAT” returns to its original color.
To turn off the on-screen display:
Press ON SCREEN.
Video CD Operations
Repeating a single track
UP
LEFT RIGHT
DOWN
E
N
R
E
T
* Note that this function cannot be used during playback with PBC. To use this
function, press 7 to stop playback and then specify a desired track number by using the numeric keys. (See “Playing back from a desired track” on page 42.)
1. Press ON SCREEN during playback,. The on-screen display appears.
2. Move to “REPEAT” using
.
/
3. Press ENTER twice. “REPEAT1” is displayed and the current track is played back repeatedly.
Repeating a part
UP
LEFT RIGHT
DOWN
To stop playback
Press 7. The player stops but the Single repeat mode remains.
To quit Single Repeat:
Move to “REPEAT” in the on-screen display and press ENTER. “REPEAT” returns to its original color.
To turn off the on-screen display:
Press ON SCREEN.
You can repeat a desired part in the current track.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to “A-B REPEAT” using
.
/
45
Video CD Operations
E
N
R
E
T
E
N
R
E
T
Starting playback from a specified time
3. At the beginning of the desired part (point A), press ENTER.
4. At the end of the desired part (point B), press ENTER. The player locates “A” and starts playback between “A” and “B” repeatedly.
To quit A-B Repeat:
Press 7. The player stops and quits the A-B repeat mode.
To turn off the on-screen display:
Press ON SCREEN.
You can playback a disc from the desired position by specifying the elapsed time from the beginning of the disc.
1. Press “ON SCREEN”. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
123 456 789
10 0
100+CH RETURN
+
10
2. Move to “TIME SEARCH” using
.
/
If the playback is with the PBC function, stop the playback and do the same operation again.
For video CD during stop For video CD during playback
3. Press ENTER if the disc is in stop. Skip this process if you are operating during playback.
4. Enter a desired time using the numeric keys on the remote control unit. See page 17 for details about how to use the numeric keys.
46
UP
LEFT RIGHT
DOWN
5. Move to “TIME SEARCH” using
E
N
R
E
T
The player starts playback from the specified time.
and press ENTER.
/
If the specified time does not exist, the entered number disappears so that you can reenter the time.
Video CD Operations
Playing back only the beginning of each track
UP
LEFT RIGHT
DOWN
E
N
R
E
T
You can check the first 10 seconds of each track on a disc.
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
2. Move to “INTRO” using
.
/
3. Press ENTER. The first 10 seconds of each track on a disc are played back from the first track in numerical order. When all the tracks are played back, the player quits this function.
Playing back tracks in random order
UP
LEFT RIGHT
DOWN
To quit this function during execution
Press 7.
The player can playback tracks in random order.
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
2. Move to “RANDOM” using
.
/
47
Video CD Operations
E
N
R
E
T
Selecting audio channels
UP
LEFT RIGHT
DOWN
3. Press ENTER. The Random play begins. When all tracks have been played once, the Random play quits.
* The same track will not be played back more than once during the Random play.
In some karaoke discs, one of the audio channels includes vocal while the other does not. With such discs, you can choose to enjoy karaoke without vocal or with vocal by selecting the audio channel to be played back.
1. Press ON SCREEN during playback. The on-screen display appears.
2. Move to AUDIO using
.
/
UP
LEFT RIGHT
DOWN
Selecting picture character
UP
LEFT RIGHT
DOWN
3. Select the audio channel(s) to be played back using
.
/
LR: You will hear normal stereo playback. L: You will hear L (Left) channel signal played back from both left and right
speakers.
R: You will hear R (Right) channel signal played back from both left and
right speakers.
You can select from three picture characters; sharp or soft and noise reduction.
1. Press “ON SCREEN” during playback. The on-screen display appears.
2. Move to “PICTURE” using
.
/
48
Video CD Operations
UP
LEFT RIGHT
DOWN
Checking total disc time
3. Select A, B, C using
.
/
A: sharp B: soft C: noise reduction
* You can set the picture characters for DVDs and video CDs independently. * The selection is memorized even if the player turns off and on.
To turn off the on-screen display:
Press ON SCREEN.
You can see the total disc time in the on-screen display and the front panel display while the disc is stopped.
1. Press ON SCREEN while the disc is stopped. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
Accessing the PBC function
2. Move to “TIME SELECT” using
.
/
3. Press ENTER until “TOTAL REMAIN” is selected as the display time mode.
* During playback, the elapsed time of the current track is displayed regardless of
the setting above.
When the player is playing back a video CD without using the PBC (Playback Control) function (such cases include playback of the track specified with the numeric keys), you can go into the PBC mode by two methods.
Method 1:
1. Press 7.
2. Press 3. The player starts the PBC function.
49
Video CD Operations
Method 2:
1. Press ON SCREEN during playback. The on-screen display appears.
UP
LEFT RIGHT
DOWN
E
N
R
E
T
2. Move to “PBC CALL” using
.
/
3. Press ENTER. The player starts the PBC function.
If appears:
The disc does not support PBC or it is being played back in PBC mode.
50
Controlling Other Equipment
The remote control unit supplied with the player can control other manufacturers’ TVs, CATV converters and satellite tuners, as well as JVC’s amplifiers/receivers.
When operating the other manufacturers’ components, refer to the manuals supplied with them. To operate these components with the remote control, first you need to set the manufacturers’ code for each TV, CATV converter, or satellite tuner.
When using the remote control, make sure that the DVD/TV/CATV selector is set to the correct position.
Controlling TV
To change the remote control signals for operating another manufacturer’s TV
POWER
CATV/SAT TV
DVD
SET
1. Set the DVD/TV/CATV selector to the “TV” position.
POWER
CATV/SAT TV
DVD
POWER
CATV/SAT TV
POWER
CATV/SAT TV
123 456 789
10 0
DVD
DVD
100+CH RETURN
+
10
2. Press and hold POWER-TV, then press SET. Do not release POWER-TV. Keep holding POWER-TV until the next step is completed.
3. Holding POWER-TV, enter the manufacturer’s code (two digits) using numeric buttons 1-9, and 0. See the lists on page 61 to find the manufacturer’s code.
4. Release POWER-TV. The following buttons can be used for operating the TV (with the DVD/TV/ CATV selector set to “TV” position):
• POWER-TV: Turns the TV on and off.
• CH +/-: Changes the channels.
• TV VOLUME +/-: Adjusts the volume.
• 1-9, 0, 100+(+10): Selects the TV channels. +10 button will function as the
ENTER button if your TV requires pressing ENTER after selecting a channel number.
• TV/VIDEO: Sets the input mode (either TV or VIDEO).
• 10 (CH RETURN): Returns to the previous channel. (only valid for JVC TVs)
• MUTE: Mutes the TV sound.
POWER
CATV/SAT TV
DVD
Note: Refer also to the manual supplied with your TV.
5. Try to operate your TV by pressing POWER-TV. If your TV turns on or off, you have entered the correct code.
Note: If there is more than one code listed for your brand of TV, try each one until
the correct one is entered.
51
Controlling Other Equipment
Controlling CATV converter or satellite tuner
POWER
CATV/SAT TV
TV
DVD CATV
SET
DVD
POWER
CATV/SAT TV
123 456 789
10 0
DVD
To change the Remote Control signals for operating a CATV converter or satellite tuner
1. Set the DVD/TV/CATV selector to the “CATV” position.
2. Press and hold POWER-CATV/SAT, then press SET. Do not release POWER-CATV/SAT. Keep holding POWER-CATV/SAT until the next step is completed.
3. Holding POWER-CATV/SAT, enter the manufacturer’s code (two digits) using numeric buttons 1-9, and 0.
100+CH RETURN
+
10
See the lists on page 61 to find the manufacturer’s code.
4. Release POWER-CATV/SAT. The following buttons can be used for operating the CATV converter or satellite tuner (with DVD/TV/CATV selector set to “CATV” position):
POWER
CATV/SAT TV
DVD
Controlling a JVC amplifier or receiver
• POWER-CATV/SAT: Turns on and off the CATV converter or satellite tuner.
• CH +/-: Changes the channels.
• 1-9, 0: Selects the TV channels. (See “How to use numeric keys”
on page 17)
Note: Refer also to the manual supplied with your CATV converter or satellite tuner.
5. Try to operate your CATV converter or satellite tuner by pressing POWER­CATV/SAT. If your CATV converter or satellite tuner turns on or off, you have entered the correct code.
Note: If there is more than one code listed for your brand of CATV converter or
satellite tuner, try each one until the correct one is entered.
AUDIO VOLUME controls the volume of a JVC amplifier or receiver.
52
Selecting Preferences
You can set various preferences mainly related with DVD playback via the “PREFERENCE” and “PARENTAL LOCK” on-screen displays.
Preferences via “PREFERENCE” on-screen display
7 How to set up
1. Take out the disc from the disc tray. You do not have to take out the disc if it is a DVD disc, but press 7 to make it stop. Close the disc tray before setting up.
2. Press ON SCREEN. The “PREFERENCE” on-screen display appears on the television screen.
* The "PREFERENCE" consists of two pages.
UP
LEFT RIGHT
DOWN
UP
LEFT RIGHT
DOWN
To turn the page of the on-screen display:
Move to "NEXT PAGE" or "PREV PAGE" using
3. Move to the item to be set using
4. Select the setting you prefer using
/
.
/
To turn off the on-screen display:
Press ON SCREEN.
and press ENTER.
/
.
53
Selecting Preferences
7 Items
The following preferences can be set.
MENU LANGUAGE
You can select the default “DVD menu” language to be displayed if the disc contains it.
Each time you press , the setting language changes as follows. ENGLISH = SPANISH = FRENCH = CHINESE = GERMAN = ITALIAN =
JAPANESE = language code from AA to ZU (See “Table of languages and their abbreviations” on page 60.)
Pressing changes the setting language in the reverse order of the above.
* If the selected language is not played, the disc’s default menu language is
displayed.
AUDIO LANGUAGE
Up to eight audio languages can be recorded in a DVD disc. You can select the default audio language to be played if the disc contains it.
Each time you press , the setting language changes as follows. ENGLISH = SPANISH = FRENCH = CHINESE = GERMAN = ITALIAN =
JAPANESE = language code from AA to ZU (See “Table of languages and their abbreviations” on page 60.)
Pressing changes the setting language in the reverse order of the above.
* If the selected language is not recorded, the disc’s default audio language is
reproduced.
SUBTITLE
Up to 32 subtitle languages can be recorded in a DVD disc. You can select the default subtitle language to be displayed if the disc contains it.
Each time you press , the setting language changes as follows. ENGLISH = SPANISH = FRENCH = CHINESE = GERMAN = ITALIAN =
JAPANESE = language code from AA to ZU (See “Table of languages and their abbreviations” on page 60.)
Pressing changes the setting language in the reverse order of the above.
* If the selected language is not recorded, the disc’s default subtitle language is
displayed.
ON SCREEN GUIDE
The player can display “on screen guide” icons or characters on the picture, which show what is happening to the disc or the player. You can turn the guide display on or off.
54
Selecting Preferences
[on DVD disc]
[4:3 (normal) television screen]
[16:9 wide television screen]
converted and output
squeezed recording
letter box conversion
pan scan conversion
MONITOR TYPE
You can select a monitor type when you playback DVD discs recorded for wide screen televisions.
If your television has a normal (4:3) screen, select “4:3 PS ” (cuts both sides of the “wide” picture) or “4:3 LB ” (with masking bars to maintain the “wide” aspect ratio).
If your television has a wide (16:9) screen, you have to select “16:9 WIDE”.
AV COMPULINK MODE
If you use the AV Compulink system, you must set this item correctly. Select from the three options: DVD1, DVD2 and DVD3 according to the equipment to be connected. See “AV Compulink remote control system” on pages 62.
DIGITAL AUDIO OUTPUT
To connect the player‘s digital output with an external amplifier or receiver equipped with a digital input, this item must be set correctly.
PCM ONLY: to connect to a PCM digital input of a piece of audio
equipment.
PCM/AC-3: to connect to a Dolby digital input of a Dolby Digital decoder
or an amplifier with built-in Dolby Digital decoder.
The following chart shows the relationship between kinds of playback discs and output signals.
Playback discs Output Output
(PCM/AC-3 mode) (PCM ONLY
mode)
DVD with 48-kHz, 16-bit linear PCM 48-kHz, 16-bit linear PCM DVD with 48-kHz, 20/24-bit linear PCM 48-kHz, 20-bit linear PCM DVD with 96-kHz, linear PCM no output DVD with Dolby Digital Dolby Digital bitstream 48-kHz,
16-bit linear
PCM
DVD with MPEG audio 48-kHz, 16-bit linear PCM CD 44.1-kHz, 16-bit linear PCM Video CD 44.1-kHz, 16-bit linear PCM
55
Selecting Preferences
CENTER SPEAKER
When the player is connected to an AV amplifier with Dolby Digital 5.1-channel inputs;
• set to “USE” if the system includes a center speaker.
• set to “NONE” if the system does not include a center speaker.
The audio output balance between 5.1-channel outputs is adjusted according to the setting above. You do not need to select this item when using the 2 CH outputs or DIGITAL OUT.
SURROUND SPEAKERS
When the player is connected to an AV amplifier with Dolby Digital 5.1-channel inputs;
• set to “USE” if the system includes surround speakers.
• set to “NONE” if the system does not include surround speakers.
The audio output balance between 5.1-channel outputs is adjusted according to the setting above. You do not need to select this item when using the 2 CH outputs or DIGITAL OUT.
BASS REDIRECT
It controls the low frequency output of Dolby Digital.
• set to “SUB” if the player is used in a system including a sub-woofer. With this setting, low-frequency signals in the C, LS and RS channels are fed from the sub-woofer output if the DVD video disc does not contain the sub-woofer channel signal in the Dolby Digital bitstream.
• set to “L/R” if the player is used in a system with no sub-woofer. With this setting, low-frequency signals in the C, LS and RS channels are added to the L and R outputs if the DVD video disc does not contain the sub-woofer channel signal in the Dolby Digital bitstream.
Setting Parental Lock
E
N
R
E
T
You do not need to select this item when using the 2 CH outputs or DIGITAL OUT.
The Parental Lock is one of the special features of DVD. It restricts playback of DVD discs which contains violent (and other) scenes according to the level set by the user. For example, by setting the Parental level strictly, when a movie which includes violent scenes is played back , the scenes are cut or replayed with other scenes in order not to be seen by children. With the XV-D2000BK, you can set or modify its level and password via the Parental Lock on-screen display.
Setting for the first time
1. While holding down 7, press ENTER on the remote control unit. The Parental Lock on-screen display appears.
56
UP
LEFT RIGHT
DOWN
2. Select the parental level using
.
/
You can select the level from among NONE, NC17, R, PG13, PG, and G. You cannot playback DVD discs rated higher than the selected level.
NONE means no restriction. NC17 is the strictest.
Selecting Preferences
E
N
R
E
T
123 456 789
10 0
E
100+CH RETURN
+
10
N
R
E
T
E
N
T
3. Press ENTER.
4. Enter your 4-digit password using the numeric keys.
5. Press ENTER.
The parental level and your password are set.
Changing the settings
R
E
1. While holding down 7, press ENTER on the remote control unit. The Parental Lock on-screen display appears.
123 456 789
10 0
100+CH RETURN
+
10
UP
LEFT RIGHT
DOWN
E
N
E
T
2. Enter your 4-digit password using the numeric keys and press ENTER. If you enter a wrong password, the following message appears in the message box.
E
N
R
E
T
"WRONG! RETRY......."
If you forget your password:
Enter "8888".
After entering the correct password, proceed to the following steps.
3. Select the parental level using
R
4. Press ENTER. The level is changed.
.
/
57
Selecting Preferences
123 456 789
10 0
100+CH RETURN
+
10
E
N
R
E
T
5. Enter a new password using numeric keys.
6. Press ENTER. The new setting is effective.
Temporary release of the Parental lock
When the parental level is set strictly, some discs may not be played back at all. When you insert such a disc and try to play it, the player will ask you whether you want the parental lock to be released temporarily or not.
If you select “YES”, then enter your password, the disc will start playback.
If you enter a wrong password, the following message appears.
"WRONG! RETRY......."
If you select “NO”, the parental lock on-screen display disappears.
58
Other Information
Care and handling of discs
How to handle discs
When handling a disc, do not touch the surface of the disc (reflective silver side –– the side without the label). Since discs are made of plastic, they are easily damaged. If a disc gets dirty, dusty, scratched or warped, the images and sound will not be picked up correctly, and such a disc may cause the player to malfunction.
Even on label side
Do not damage the label side, stick paper to or use any adhesive on its surface.
Storage
Make sure that discs are kept in their cases. If discs are piled on top of one another without their protective cases, they can be damaged. Do not put discs in a location where they may be exposed to direct sunlight, or in a place where the humidity or temperature is high. Avoid leaving discs in your car!
Maintenance of discs
If there are fingerprints or other dirt adhering to a disc, wipe with a soft dry cloth, moving from the center outwards. If a disc is difficult to clean, wipe with a cloth moistened with water. Never use record cleaners, petrol, alcohol or any anti-static agents.
CAUTION
Sometimes during play noise or images may be garbled. This is sometimes due to the disc. (It may not be up to industry standards.) These symptoms are caused by the discs, not by the malfunction of the player.
59
Other Information
Table of languages and their abbreviations
AA Afar AB Abkhazian AF Afrikaans AM Ameharic AR Arabic AS Assamese AY Aymara AZ Azerbaijani BA Bashkir BE Byelorussian BG Bulgarian BH Bihari BI Bislama BN Bengali, Bangla BO Tibetan BR Breton CA Catalan CO Corsican CS Czech CY Welsh DA Danish DZ Bhutani EL Greek EO Esperanto ET Estonian EU Basque FA Persian FI Finnish FJ Fiji FO Faroese FY Frisian GA Irish GD Scots Gaelic GL Galician GN Guarani GU Gujarati HA Hausa HI Hindi HR Croatian HU Hungarian HY Armenian IA Interlingua IE Interlingue
IK Inupiak IN Indonesian IS Icelandic IW Hebrew JI Yiddish JW Javanese KA Georgian KK Kazakh KL Greenlandic KM Cambodian KN Kannada KO Korean (KOR) KS Kashmiri KU Kurdish KY Kirghiz LA Latin LN Lingala LO Laothian LT Lithuanian LV Latvian, Lettish MG Malagasy MI Maori MK Macedonian ML Malayalam MN Mongolian MO Moldavian MR Marathi MS Malay (MAY) MT Maltese MY Burmese NA Nauru NE Nepali NL Dutch NO Norwegian OC Occitan OM (Afan) Oromo OR Oriya PA Panjabi PL Polish PS Pashto, Pushto PT Portuguese QU Quechua RM Rhaeto-Romance
RN Kirundi RO Rumanian RU Russian RW Kinyarwanda SA Sanskrit SD Sindhi SG Sangho SH Serbo-Croatian SI Singhalese SK Slovak SL Slovenian SM Samoan SN Shona SO Somali SQ Albanian SR Serbian SS Siswati ST Sesotho SU Sundanese SV Swedish SW Swahili TA Tamil TE Telugu TG Tajik TH Thai TI Tigrinya TK Turkmen TL Tagalog TN Setswana TO Tonga TR Turkish TS Tsonga TT Tatar TW Twi UK Ukrainian UR Urdu UZ Uzbek VI Vietnamese VO Volapuk WO Wolof XH Xhosa YO Yoruba ZU Zulu
60
Manufacture's code list
Other Information
7 TV
No. Manufacturer
01 JVC
02 MAGNAVOX
03 MITSUBISHI
04 PANASONIC
05 RCA
06 SHARP
07 SONY
08 TOSHIBA
09 ZENITH
10 HITACHI
11 PANASONIC
12 SAMSUNG
7 CATV/SAT
No. Manufacturer
01 GI JERROLD
02 GI JERROLD
03 GI JERROLD
04 GI JERROLD
05 GI JERROLD
06 GI JERROLD
07 GI JERROLD
08 GI JERROLD
09 SCIENTIFIC ATRANTA
10 SCIENTIFIC ATRANTA
11 ZENITH
12 ZENITH
13 SANYO
14 SANYO
15 SAMSUNG
13 PIONEER
14 PIONEER
15 HAMLIN/REGAL
16 HAMLIN/REGAL
17 HAMLIN/REGAL
18 HAMLIN/REGAL
19 OAK/SIGMA
20 OAK/SIGMA
21 OAK/SIGMA
22 TOCOM
23 TOCOM
24 RCA/PANASONIC
25 RCA/PANASONIC
26 RCA/PANASONIC
27 RCA(SAT)
28 SONY(SAT)
61
Other Information
AV COMPULINK remote control system
When you buy a separate TV, VCR DVD player, receiver or other components and connect them to each other, you have to operate each component individually. JVC’s AV COMPULINK remote control system meets the demand for a system made up of single components and has the ease of operation of a single unit.
7 Operation
You can enjoy pictures and/or sound by just putting a source component (which plays back the pictures and/or sound such as a DVD player or VCR) into play mode. You do not have to operate the TV and receiver including power switching.
1. Turn on the main power of the television.
2. Insert a disc into the source component.
3. Press 3 of the source component.
The following actions are performed automatically:
• Turning on the power of the television.
• Setting the source of the television to the external input (VIDEO 1 or VIDEO 2).
• Turning on the power of the receiver.
• Setting the source of the receiver to the component which has just started playback.
7 Connection and Setup
Using the AV COMPULINK cable, connect the AV COMPULINK terminals of each component to one another.
To AV COMPULINK (II)
TV
DVD player
If you connect a DVD player with a television via AV COMPULINK, set the DVD player’s AV COMPULINK setting as follows.
• When connecting with VIDEO 1 input terminal of the television: DVD2
• When connecting with VIDEO 2 input terminal of the television: DVD3
62
To AV COMPULINK (II)
To AV COMPULINK (II)
TV
DVD player Video cassette recorder
Other Information
If you connect a DVD player with a television and VCR via AV COMPULINK, set the VCR’s Remote Control Code and DVD player’s AV COMPULINK setting as follows.
• When connecting with VIDEO 1 input terminal of the television: DVD player’s AV COMPULINK setting: DVD2 VCR’s Remote Control Code: B
• When connecting with VIDEO 2 input terminal of the television: DVD player’s AV COMPULINK setting: DVD3 VCR’s Remote Control Code: A
To Audio
To TV
TV
Receiver DVD player
If you connect a DVD player with a television and receiver via AV COMPULINK, set the DVD player’s AV COMPULINK setting to DVD1.
The DVD player’s AV COMPULINK setting is operated in the “PEFERENCE” on-screen display. See “Preferences via “PEFERENCE” on-screen display” on pages 53 for operation.
Notes for connection
• If you connect a DVD player with a receiver via AV COMPULINK in a system including a Dolby digital decoder, some functions may not be done automatically.
• The AV COMPULINK terminal on some televisions indicates “II”. Do not connect the terminal indicating “II” with the AV COMPULINK terminal on a receiver. If connected, the system will not work correctly.
• Connect the AUDIO OUT jacks of the DVD player to the audio input jacks of a receiver indicating “DVD”. Otherwise, the system will not work correctly.
There is no description about connections to a DVD player in the instruction manual of a television or VCR. But a television or VCR with AV COMPULINK terminals indicating II can be connected to a DVD player.
63
Other Information
Troubleshooting
What appears to be a malfunction may not always be serious. Please go through the following list before requesting service.
Symptom Possible cause Remedy
Power does Power plug is not inserted Plug in securely. not come on. securely.
Remote control Too far from the player. Come closer to the player. does not work.
The tip of the remote unit is Point the infrared light­not pointed in the right emittingwindow toward the direction. remote sensor on the front panel.
Batteries are exhausted. Replace the batteries with new
ones.
Battery polarity is incorrect. Take out the batteries and
insert them again in the correct direction.
No picture is Connection of video cable is Connect the cable correctly displayed on incorrect. (see page 9). the monitor.
Input selection of TV is incorrect. Select correctly. Disc is not playable. (See page 16.)
No audio is Connection to stereo system Check connections reproduced. is incorrect. (see Page 9 to 13).
Input selection of amplifier Select correctly. is incorrect.
No sound from PHONES LEVEL is too low. Adjust the PHONE LEVEL. headphones.
Sound is Disc is dirty. Wipe the disc surface distorted or (see page 59). noise is generated. Picture is garbled.
player is connected to Connect player with the a VCR. TV directly.
64
Picture does MONITOR TYPE is not See “MONITOR TYPE” not fit with the correctly set. on page 55. television screen.
Operation is Microcomputer malfunctions Turn off the power, then not possible. due to lightning or static connect the power cord again.
The TV DOWN MIX is set to OFF. Set DOWN MIX to L0/R0 speakers do (see page 33). not reproduce dialogs for a DVD movie disc.
There may be causes other than the player. Check the other devices connected to the player.
Television is not correctly set. Set the television correctly.
electricity. Moisture condensation occurs Turn off the power,
by sudden change of then turn it on a few hours temperature or humidity. later.
Specifications
Other Information
General
Readable discs: DVD video, CD, Video CD Video format: NTSC color
Other
Power requirements: AC 120V Ó , 60Hz Power consumption: 30 W (POWER ON), 5 W (STANDBY mode) Mass: 4.8 kg (10.6 lbs) Dimensions (W x H x D): 435 x 112 x 327.5 mm
17-3/16 x 4-7/16 x 12-15/16 inch
Video output
VIDEO OUT (pin jack): 1.0 Vp-p (75 ohms) S-VIDEO OUT (S jack): Y Output: 1.0 Vp-p (75 ohms),
C Output: 286 mVp-p (75 ohms) Horizontal resolution 500 Lines Signal to noise ratio 65 dB
Audio output
ANALOG OUT (pin jack):
Front 2.0 Vrms (10 k ohms) Rear 2.0 Vrms (10 k ohms) Center 2.0 Vrms (10 k ohms) Sub woofer (BASS REDIRECT = “L/R”)
(NORMAL) 1.0 Vrms (5 k ohms)
(GAIN PLUS) 2.0 Vrms (10 k ohms) 2CH (ATT. OFF) 2.0 Vrms (10 k ohms) 2CH (ATT. ON) 1.0 Vrms (5 k ohms)
DIGITAL OUT:
OPTICAL -21 to -15 dBm (Peak) COAXIAL 0.5 Vp-p
Audio characteristics
Frequency response: CD (sampling frequency 44.1 kHz): 2 Hz to 20 kHz
DVD (sampling frequency 48 kHz): 2 Hz to 22 kHz DVD (sampling frequency 96 kHz): 2 Hz to 44 kHz
Dynamic range: 16 bit: More than 99 dB
20 bit: More than 108 dB
24 bit: More than 108 dB Wow and flutter: Unmeasurable (less than ± 0.002%) Total harmonic distortion: Less than 0.002%
* Specifications and appearance subject to change without prior notice.
65
VICTOR COMPANY OF JAPAN, LIMITED
EN.
Printed in Japan
JVC
0997FTYUBNPRI
Loading...
