INTRODUCTION
CONTENTS
Thank you very much for purchasing the JVC product. We sincerely
hope it proves its quality and performance to your full satisfaction.
Please read the instructions contained in this manual in order to get
the most of the product’s capability and performance. If there are
any questions concerning the product, please consult your JVC
dealer .
Feature of XL-MC2000
• This component is designed to store up to 200 compact discs,
change and play them automatically in three different playback
modes.
• This component features a digital optical output jack for direct
digital audio transmission to an MD, CD-R, amplifier or
receiver.
Select a level location to install this component, where it is free
from extremes of temperature (5 to 35°C, or 41 to 95°F),
humidity, dust, or vibration.
If noise interference is caused during AM broadcast reception
by a tuner/receiver located nearby, relocate it or this component,
or turn off either one.
• Moving the unit
Before moving the unit, first remove all the discs. Turn the power
off, making sure the standby indicator is lit. Then remove the
AC power cord from the AC outlet.
Compact discs
•Use only compact digital audio discs
Only the audio compact discs identified by
the logo shown on the right can be used with
this component.
'
English
Operation
• Keep the disc storage free of obstacles
Do not put anything other than discs in slots of the disc storage.
• Turn the power off if a problem occurs
If an unusual condition arises, turn the power off immediately. If
the condition persists whenever the power is turned on, consult
your JVC dealer.
• Do not pull the AC power cord
Do not pull the cable when unplugging the AC cord from the
wall socket or this component — hold and pull the plug body.
• Set the sound volume carefully
Be careful in setting the sound volume on your amplifier/receiver
when playing a CD, which has almost none of background noise
unlike analog records and tapes. Find out the right setting starting
with a low level setting. Setting the level too high and starting a
CD could damage the speakers.
• Protect the component against condensation
Condensation inside the component could disrupt the proper
transmission of the disc-reading laser beam, causing noise or
malfunction. If condensation ever ensues due to excessive
humidity or sudden temperature change, leave the component
turned on for a couple of hours to dry up — consult your JVC
dealer if this does not correct the condition.
3
2
SETTING UP
Connecting the unit
This compact disc changer/player needs to be connected to an
amplifier/receiver for audio reproduction.
CAUTION
Do not connect the AC power cord until all other necessary connections have been made.
Analog audio connections
First connect the OUTPUT jacks in the back of this unit with the
CD or AUX input jacks of the amplifier/receiver using the accessory
audio cord. Be sure to insert the audio cord plugs firmly into the
proper jacks matching the output and input channels — RIGHT to
RIGHT and LEFT to LEFT.
OUTPUT
LEFT
RIGHT
Digital audio connections
If the MD, CD-R, amplifier or receiver you are making connections
to has a digital optical input jack, connect the DIGITAL OUT
OPTICAL jack in the back of this unit to the CD or AUX digital
input jack on the MD, CD-R, amplifier or receiver using a
commercially available optical fiber cable.
Audio cord
(White)
(Red)
To input audio jack of
the amplifier/receiver
System control connections
If you are connecting the unit to a JVC audio component using the
CompuLink-3 remote control system, connect the units with the
accessory CompuLink cord. Either one of the COMPULINK-3
(SYNCHRO) jacks in the back of this unit can be used.
COMPULINK-3
(SYNCHRO)
CompuLink cord
To CompuLink jack
When you use this system, you can remote-control this CD unit
from the connected JVC amplifier/receiver. (See Page 12 for more
information.)
NOTE: JVC components equipped with two COMPULINK-3
(SYNCHRO) ports can be connected in series; a component with only one jack may only be connected at
the end of the series.
Power connection
Connect the accessory AC power cord into the socket in the back
of this unit. Then insert the plugs into an AC outlet. (Do not connect
the power cord to a switched AC outlet of a component if the
CompuLink system is used.)
DIGITAL OUT
Optical fiber cable
(not supplied)
OPTICAL
To digital input jack
of the MD/CD-R/amplifier/
receiver
Be sure to pull off the caps before you make any connections, as
shown above. Place the caps in a safe place.
AC power cord
Wall outlet
4
3
