JVC VR-N1600U, VR-N1600E User Manual

NETWORK VIDEO RECORDER

VR-N1600U
VR-N1600E

WARNIN G

㧠

ALARM

HDD

㧤

LOCK



SERIAL

㧝 㧞 㧟

㧡

㧥  

   

CANCEL ZOOM OUT ZOOMIN

㧢*1/'

㧣

OPERATE

REC CONTROL

LIVE/BROWSE

SELECT

PTZ/PRESET

Please read the following before getting started:

Thank you for purchasing this JVC product.

Before operating this unit, please read the instructions

carefully to ensure the best possible performance.

STARTUP GUIDE

REV FWD

SEARCHFUNCTION ALARM CLEARKEY REC/STOP STOP(PB) PLAY

SKIP

Powered by Milestone

For Customer Use:

Enter below the Serial No. which is located on the

body.

Retain this information for future reference.

Model No. VR-N1600U

Serial No.

\

LST0601-001A

IMPORTANT SAFEGUARDS

I

SAFETY PRECAUTIONS (for USA)

II

SAFETY PRECAUTIONS (for Europe)

III

IV

SICHERHEITSVORKEHRUNGEN (for Germany)

V

VI

SICHERHEITSVORKEHRUNGEN (for Germany)

VII

1600E

E

E

E

1600E

E

VIII

Getting Started

Features

Automatic detection of network cameras

Reduces the hassle of complex camera registration
procedures.

Built-in large-capacity hard disk (500 GB)

HDD expansion supported

Addition of up to 500 GB (built-in), 2 TB x 2 units (external.)

RAID1 supported

Supports RAID1 if additional built-in HDD is installed.
Writing the same data to two separate hard disks (mirroring)

to enable normal use if one of the hard disks breaks down.

Simultaneous recording up to 16 channels at 160
ips

Simultaneous recording up to 16 channels at 240 ips is
possible when the

Display/Distribution performance at 80 ips is
guaranteed

NVR Viewer is not started up.

Motion Detect

Enables recording to start automatically when AmotionB is
detected in the preset live image. You can also specify the
detection area for each camera.

Alarm Mail Notification

Enables notification by e-mails to be sent out when an alarm
or motion is detected.

How to Read this Manual

䡵 VR-N1600U/E Documents

There are two documents on this unit.

(1) Startup Guide

This is a booklet that is supplied together with VR­N1600U/E. It is also available in the PDF file format.
You can find it in the CD-ROM provided.

(2) Instruction Manual (PDF)

This manual is available in the PDF file format. You can
find it in the CD-ROM provided.

䡵 Symbols Used in this Manual

Note

Memo

A

Precautions to take during operation of this
unit.

Details for reference, such as functions and
restrictions on uses.

Page or item to refer to.

Enables simultaneous recording and playback

Playback of recorded images, jog dial playback and skip
playback are possible while recording is in progress.

Direct Search

Enables you to retrieve data of a specific date/time or alarm
position speedily.

Power failure recovery record

If a power failure occurs during recording, the system
resumes recording in the mode selected before the power
failure after recovery.

Alarm recording

Enables recording to start automatically in the alarm
recording mode when alarm signal input is received during
recording.

䡵 Content of this Manual

● The copyright of this manual belongs to JVC.

Reproduction or copy of this manual, in part or in
whole, without the prior consent of JVC is strictly
prohibited.

● Product names used in this manual are the trademarks

or registered trademarks of the respective companies.
Symbols such as 姠, 姞, 姝 and are omitted in this
manual.

● Milestone and XProtect Enterprise are the registered

trademarks of Milestone Systems, Inc.

● Designs, specifications and other details used in this

manual may be modified for improvement without prior
notice.

This STARTUP GUIDE deals only with the initial setup and
basic operational procedures on the VR-N1600U/E.

Besides the STARTUP GUIDE, the VR-N1600U/E
INSTRUCTIONS is also provided on a CD-ROM that
explains further details on the operation procedures.

For details, please refer to the CD-ROM.

2

Contents

Getting Started

Features ............................................................................2

Contents ............................................................................ 4

Precautions for Proper Use of this Product ....................... 6

Part Names and Functions ................................................8

Mounting to a Rack ......................................................... 12

Preparation

System Connection Example ..........................................13

During Initial Startup ....................................................... 14

Basic Operation

Viewing Live Images via Front Panel Control .................. 18

Displaying the [Live] Screen ........................................18

Select a view ................................................................ 18

Select a Camera ..........................................................18

Operating the Camera ................................................. 19

Playing Back Recorded Images

via Front Panel Control ..............................................20

Select a view ................................................................ 20

Searching Recorded Image

Using a Specific Date/Time .................................... 20

Playing, Skipping and Stopping Recorded Images ...... 20

Adjusting the Playback Speed

(Jog/Shuttle Playback) ...........................................21

Others

Troubleshooting ...............................................................22

Specifications ..................................................................23

3

Getting Started

Precautions for Proper Use of this Product

Locations of Storage and Use

䢇 Do not store the unit at the following places.

Doing so may cause the unit to malfunction or break
down.

● Hot or cold places beyond the allowable operating

temperature (5 I to 40 I)

● Humid places beyond the allowable operating humidity

(30%RH to 80%RH) (no condensation)

● Places that emit a strong magnetic field, such as near

transformers and motors

● Places near devices that emit radio waves, such as

transceivers and mobile phones

● Places with considerable dust and sand

● Places with strong vibrations

● Places where water droplets may be formed, such as

window sides

● Places with considerable vapor and oil, such as

kitchens

● Places that emit radiation, X-rays, and corrosive gases

䢇 Using this unit and the cable that is connected to it near

places where strong radio waves or magnetic fields (such
as near radios, TVs, transformers, and monitors) are
emitted may cause noises in the video images or color
changes.

Handling Precautions

䢇 Do not stack the devices on one another during use.

Heat and noise from the devices may cause the unit to
malfunction or break down, and lead to fire.

䢇 Do not block the ventilation holes.

Doing so may cause heat to trap inside the unit and result
in fire. Do not use this unit by laying it down sideways,
upside down, or at an angle.

䢇 Do not place objects on this unit.

Placing heavy objects, such as TV monitors, or objects
that are bigger in size on this unit may cause it to lose
balance and drop or fall, hence resulting in injuries.

䢇 Do not stand or sit on this unit.

Doing so may cause this unit to fall or break down, and
result in injuries. Keep it out of the reach of young
children.

䢇 Do not place objects with water (e.g., vases, flower pots,

cups, cosmetic products, and chemicals) on this unit.
Water may enter this unit and result in fire or electric

shock.

䢇 Do not insert objects into this unit.

Metallic or other flammable objects that enter this unit
from the ventilation holes may result in fire or electric
shock.

Precautions for Handling Hard Disk Drive

䢇 The distance between the head and the disk is only about

0.02 μm when the hard disk (henceforth HDD) is reading
the data. Vibration or impact that is exerted on the HDD

may therefore cause the head to hit against the disk,
hence causing the disk surface to dent or the disk to chip.
When this occurs, data may not be properly read, or in a
worse scenario, continued use in this condition may result
in head crash (damage). Careful attention must therefore
be paid when handling it.

䢇 Precautions During Installation and Change of Installation

Location
Moving of this unit or installation work is strictly prohibited

when the power of this unit is on or immediately after the
power is turned off (approximately 1 minute). (The HDD
continues to move under its own inertia for some time
after the power is disconnected, and exertion of vibration
or impact during this interval may result in HDD failure.)
When moving this unit, wrap it using cushioning materials
to protect it from external shock.

䢇 Handling Precautions

● Handle this unit carefully without exerting vibration or

impact on it.

● Do not remove the power plug during recording or

playback, or when the HDD is being accessed.

● The HDD is a consumable product. Perform

maintenance after it has been used for about 10,000
hours (about 1 year). (This value is based on its use in
an environment with a temperature of 25 I, and may
vary according to the environment of use.) For inquiries
on maintenance plans and expenses, consult your
nearest JVC dealer listed on the separate sheet.

䢇 When installing an external hard disk, we recommend the

use of UPS (uninterruptible power supply) to ensure the
stable operation of the system.

䢇 Power failure that occurs during formatting or

disconnection of the HDD may affect its subsequent use
even when the UPS is connected.

䢇 JVC shall not be held responsible for the compensation of

losses incurred in the event that recording or playback
fails due to defects in this unit or its hard disk drive.

● Images recorded on the HDD will be deleted when you

replace it with a new disk. Note also that recorded
images may be deleted when you upgrade the software
for this unit.

4

Precautions when Moving this Unit

䢇 Remove all connected cords before moving

Turn off the power and remove the power plug before
moving this unit. Failure to do so may cause damage on
the cords, and result in fire or electric shock.

䢇 Moving of this unit or installation work is strictly prohibited

when the power of this unit is on or immediately after the
power is turned off (approximately 1 minute).

The HDD continues to move under its own inertia for
some time after the power is disconnected, and exertion
of vibration or impact during this interval may result in
HDD failure.

䢇 When moving this unit, wrap it using cushioning materials

to protect it from external shock.

䢇 Handle this unit carefully without exerting vibration or

impact on it.

Precautions for Handling Power Cords

䢇 Do not use the supplied cords on devices other than this

unit.

䢇 Do not place heavy objects on the power cord, or place it

under this unit
Doing so may cause damage on the cords, and result in

fire or electric shock.

䢇 Do not use cords other than those supplied with this unit

Use only power cords supplied together with this unit.
Using cords with different withstanding voltage
specifications or damaged cords may result in fire or
electric shock.

䢇 Do not remove the power plug during recording or

playback, or when the HDD is being accessed.

Maintenance

䢇 Turn off the power before performing maintenance of this

unit.

䢇 Wipe this unit using a soft cloth. Wiping using thinner or

benzene may cause the surface to melt or fog. When the
surface is extremely dirty, wipe using a cloth that is dipped
into a neutral detergent diluted with water, followed by
wiping with a dry cloth.

Others

䢇 When there is variation in the supply voltage such as

during lightning, operation of this unit may be disabled to
protect the system until the supply voltage stabilizes
again.

䢇 Eliminate static electricity before performing work that

requires you to touch the input/output terminals, such as
when installing devices.

䢇 Do not touch the rear panel of this unit when it is running

as static electricity may cause it to malfunction.

䢇 When there is a large number of data recorded on this

unit, such as short alarm records, a longer time may be
required during search or backup. This is not a
malfunction.

䢇 Data recorded from TV broadcasts or video (audio)

recordings shall only be restricted to personal uses, and
their use without the prior consent of the copyright holder
is strictly prohibited under the copyright law.

䢇 The width of the border lines (black in color) of images on

the split screen varies according to the type of input
signals. This is due to the characteristics of the camera’s
input signals, and is not a malfunction. The condition may
also be improved by adjusting this unit. For details, consult
your nearest JVC dealer.

䢇 This unit comes with a high-precision hard disk device. Be

careful not to exert vibration or impact on this unit when
handling it.

䢇 Exertion of vibration or impact particularly when the power

is on or when the hard disk is being accessed may cause
this unit to break down.

䢇 When moving this unit, do so about 1 minute after

disconnecting the power supply.

䢇 Do not turn off the power switch at the rear of this unit or

unplug the power cord during recording or playback, or
when the hard disk is being accessed. Otherwise, it may
break down.

When this device is used as a general household,
there is a possibility of radio disturbance to the
radio and television receiver etc.

Energy Conservation

䢇 Turn off the power of the system for safety reasons and to

save energy if this unit is not to be used for a long time.

Copyright

䢇 Use of video or audio sound recorded using this unit for

commercial purposes or playing them for public viewing or
listening may be an infringement of the copyrights of their
respective authors under the copyright law.

䢇 These video (audio) recordings shall only be restricted to

personal uses, and their use without prior consent of the
copyright holder is strictly prohibited under the copyright
law.

5

Getting Started

Part Names and Functions

Front

T

ENTER

WARNIN G

㧠

ALARM

HDD

㧤

LOCK



FEDC

G

OPERATE

A
B

A

[OPERATE] Button/Indicator

REC CONTROL

SELECT

PTZ/PRESET

SERIAL

㧡

㧥  

CANCEL ZOOM OUT ZOOMIN

㧣

㧢*1/'

   

㧝 㧞 㧟

LIVE/BROWSE

Switches operation on or off. Press the button to turn operation

AONB

and hold down the button to turn operation AOFFB. The

indicator blinks while the recorder is starting up or shutting down.

B

[REC CONTROL] Button/Indicator

Switches the recording control mode on or off. The indicator lights
up when the recording control mode is set to on.

Press and hold the [FUNCTION] button, and press the [REC
CONTROL] button at the same time to display the menu.

Memo :

●

The main menu cannot be displayed in the recording control
mode or during recording.

●

The recording control mode performs recording in accordance
with the settings in the [Camera Record Setting] menu.

C

[SELECT] Button/Indicator

Use the S key to set to the camera selection mode. The indicator
lights up when the camera selection mode is set to on.

D

[PTZ/PRESET] Button/Indicator

Switches between the PTZ mode and PRESET mode of the S key.
The mode changes each time the button is pressed. The indicator
lights up when PTZ mode is selected and blinks when PRESET
mode is selected.

E

[SERIAL] Terminal

For connecting the communication control terminals on a mouse
(sold separately), flash memory (sold separately) or UPS (sold
separately).

Memo :

●

Use the [SERIAL1 to 4] port on the rear panel for additional hard
disk drive connection. (

A Page 8)

Note :

●

Attach the serial port cover supplied when the port is not in use.

●

Static electricity may cause the unit to malfunction. Remove any
static electricity before starting operation.

F

Status indicators

䡵

[WARNING] Indicator
Lights up when an error occurs. (
Press and hold the [ALARM CLEAR] button to turn off the light.

A Page 20)

QRS

REV FWD

SEARCHFUNCTION ALARM CLEARKEY REC/STOP STOP(PB) PLAY

HJKML

I

䡵

[ALARM] Indicator
Lights up when an alarm is activated.
Goes off when the [ALARM CLEAR] button is pressed.

䡵

[HDD] Indicator
Lights up when the built-in hard disk drive is accessed.

䡵

[LOCK] Indicator
Lights up when operation is locked.

G

[FUNCTION] Button

Press the following buttons while holding down the [FUNCTION]
button to use the following features.

[FUNCTION]
+[OPERATE]

[FUNCTION] +[REC
CONTROL]

[FUNCTION] +[LIVE/
BROWSE]

[FUNCTION] +[5] For controlling the PTZ camera.

[FUNCTION] +[6] Displays the maintenance information

H

[SEARCH] Button

Press and hold to forcibly shut down
the system.

Displays the main menu.

Reboots the NVR Viewer and the
internal distribution server.

Press and hold to log out.

screen.

Displays the date and time search screen when in the playback

(

A Page 18)

mode.

I

[KEY] Button

Press to display or hide the Asoftware keyboardB.

Memo :

●

Use the software keyboard to input characters.

J

[ALARM CLEAR] Button

Clears the [ALARM] display when an event occurs or motion is
detected. Press and hold this button to turn off the [WARNING]
indicator.

K

[REC/STOP] Button

Press to start recording in all cameras. (When in the recording
control mode, pressing this button exits the recording control mode
and starts recording on all cameras.) To stop recording, press and
hold the button.

When in the recording control mode, press and hold this button to
exit the recording control mode.

SKIP

N

P

O

6

Memo :

●

The manual recording mode executes recording from all
cameras regardless of the settings in the [Camera Record
Setting]. Recording is carried out in accordance with the frame
rate selected in [Camera Record Setting].

L

[STOP(PB)] Button

Stops playback when you press this button in the playback mode.

M

[PLAY] Button

Plays back at the speed and in the direction specified by the Shuttle
Dial position.

N

[SKIP] Button

䡵[S

]

Press to move the item selection in the reverse direction in the
menu or settings screen. Jumps to the beginning of the previous
sequence on the selected camera when you press this button in the
playback mode. Press and hold it to jump to the first image in the
database of the selected camera.

䡵[T

]

Press to move the item selection in the forward direction in the
menu or settings screen. Jumps to the beginning of the next
sequence on the selected camera when you press this button in the
playback mode. Press and hold it to jump to the last image in the
database of the selected camera.

Memo :

●

“Sequence” indicates a certain block of images that are recorded
during motion detection.

●

Recorded images are stored in the database. “Database” refers
to data recorded in this unit.

O

Jog dial

Plays back a single frame when it is rotated in the playback mode.

P

Shuttle dial

The position of the dial specifies the playback speed and playback
direction when in the playback mode. Playback speed is selectable
from x 1/20, x 1/5, x 1, x 2, x 5, x 10 and x 20 according to the
angle.

Q

[REC] Indicator

Lights up during recording. Flashes during EMERGENCY or EXT
REC IN recording.

R

Center panel

Do not remove the cover.

S

Keypad buttons/Indicator

[0] to [16]

䢇

Login screen

●

For entry of passwords (numeric characters). (Enter number
using [1] to [10/0] buttons. A0B is input when [10/0] button is
pressed.)

䢇

Setting screens on the main menu

●

PTZ mode Keypad

For selecting a menu item. ([2/D], [10/0/E])

●

Camera selection keypad mode

●

For entering numeric characters. (Enter number using [1] to
[10/0] buttons. A0B is input when [10/0] button is pressed.)

䢇

Live image display and recorded image playback screens

●

Camera selection keypad mode

For selecting a camera number. Upon selecting, the indicator
corresponding to the selected camera input lights up.

●

PTZ keypad mode (live image display screen only)

Moves the camera in the direction indicated by the arrow. ([1/

D

] [3/ ][5/C][7/B] [9/ ][10/0/E] [11/ ])

][2/
Use the [6/HOME] button to move the camera to the home
position.

●

Preset keypad mode (live image display screen only)

For selecting the preset position. ([1] to [9]. 10 to 19 can be
selected when [10/0/

䢇

During search for recorded images

For narrowing down the search using a date, month, week, or
time.

●

(Enter number using [1] to [10/0] buttons. A0B is input when
[10/0] button is pressed.)

䢇

During display of software keyboard

●

Selection keypad mode

For entering numeric characters. (A0B is input when the [1/ ]

E

to [10/0/

●

PTZ keypad mode (live image display screen only)

Moves the mouse pointer in the direction indicated by the
arrow. Press [1/ ][2/
[6/HOME] to move to the center of the screen.)

] and [10/0/E] buttons are pressed.)

E

] is pressed at first.)

D

] [3/ ][5/C][7/B] [9/ ][10/0/E] [11/ ] or

[13/CANCEL]

䢇

Setting screens on the main menu

Cancels the selection.

[14/ZOOM OUT]

䢇

Live image display and recorded image playback screens

●

PTZ keypad mode (live image display screen only)

Zooms out.

●

Preset keypad mode

For selecting the next view.

●

Press the [14/ZOOM OUT] button while holding down the
[FUNCTION] button to change the resolution of VGA output.

[15/ZOOM IN]

䢇

Live image display and recorded image playback screens

●

PTZ keypad mode (live image display screen only)

Zooms in.

●

Preset keypad mode

For selecting the previous view.

●

Press the [15/ZOOM IN] button while holding down the
[FUNCTION] button to change the resolution of VGA output.

[16/ENTER]

䢇

Setting screens on the main menu

Confirms the selection.

䢇

During display of software keyboard

To perform the mouse click operation.

T

[LIVE/BROWSE] Button/Indicator

Switches between the [Live] mode and [Browse] mode.
The indicator lights up when in the [Live] mode.
Pressing the [LIVE/BROWSE] button when the wallpaper screen is

displayed shows the [Live] screen.
Press and hold the [FUNCTION] button, and press the [LIVE/

BROWSE] button at the same time to reboot the NVR Viewer and
the internal distribution server.

Press and hold the [FUNCTION] button, and press the [LIVE/
BROWSE] button at the same time to log out of the system.

Memo :

● When [Auto Logon] is enabled, the login operation starts

automatically immediately after logging out.

7

Getting Started

Part Names and Functions
(continued)

Rear Panel

d

U

POWER

ON

OFF

AUDIO IN

AUDIO

OUT

V

SIGNALGND

W

X

U [POWER] switch

Switches the power on or off.

Memo :

● Be sure to press and hold down the [OPERATE] button on

the front panel to shut down the system before switching
off the power supply.

V

[AC IN] power input terminal

Connect to an AC outlet using the power cable supplied.

W

[AUDIO IN 1/AUDIO IN 2] audio input terminals 1/2

(RCA)

Connect to the audio output terminal of the device from
which audio signals are to be recorded.

X [AUDIO OUT] audio output terminal (RCA)

Outputs live sound in the live viewing mode.
Outputs recorded sound in the playback mode.

Memo :

● There is no audio output when playing back still images,

when running searches other than x1, or when playing
back frame-by-frame.

Y [VGA OUT] VGA output terminal

Outputs live images, recorded images and the menu
screens.

Z

[SERIAL1 to 4] serial terminals 1 to 4

For connecting the communication control terminals on a
mouse (sold separately), flash memory (sold separately),
UPS (sold separately) or additional disk drive (sold
separately).

a [LAN2] LAN2 connection terminal (Intranet)

For connecting to the remote PC network using a LAN cable.

LAN2

b

a

Color Status

Green Light off Not connecting to the network.

Blinking Connecting to the network.

Green Light off Communication is not

Blinking Communication is in progress.

c

established.

VGA OUT

Y

ALARMIN

LAN1

1
2

3
4

SERIAL

Z

Left
Indicator

Right
Indicator

b [LAN1] LAN1 connection terminal (camera

network)

For connecting to the IP camera (sold separately) network
using a LAN cable.

Color Status

Left
Indicator

Right
Indicator

Orange

Green Light off Communication at 10 Mbit/

Orange

Light off Not connecting to the network.

Light on Connecting to the network.

Blinking Communication is in progress.

second.

Light on Communication at 100 Mbit/

second.

Blinking Communication at 1 Gbit/

second.

c Connector cover

Memo :

● Do not remove the cover.

d Signal input/output terminals

For operating VR-N1600U/E using external alarm signals or
signals received from external devices, or for operating
external devices by outputting signals.

Memo :

● Diameter of applicable cables: AWG22 to AWG28

8

Rear I/O Terminals

ON

OFF

AUDIOIN

SIGNALGND

AUDIO

OUT

VGA OUT

p

䡵

Input ports

e [ALARM IN 1 to 8] alarm input terminals 1 to 8

Alarm recording is activated when signals are input to these
terminals.

f [EMERGENCY] emergency input terminal

Recording is activated in all cameras when a signal is input
to this terminal.

ALARMIN

LAN1

1
2

3
4

SERIAL

䡵

Output ports

e

LAN2

fghijklmn

j [COMMON] signal ground terminal

This is a common ground terminal. Connect it to the signal
ground terminal on the connected device. (This can be used
when there are insufficient common ground terminals.)

k [ALARM OUT] alarm output terminal

Outputs a signal when recording is started by an alarm.

o

g [ALARM RESET] alarm reset input terminal

Output from the alarm output terminal is stopped when a
signal is input during output of the Alarm Out signals.

Turns off the [ALARM] indicator F on the main unit. Press
and hold the button to turn off the [WARNING] indicator F on
the main unit.

h [EXT REC IN] external recording input terminal

Recording in all cameras is started or stopped by an external
signal. Recording will not be started in cameras to which no
video signal is being input.

i [OPE ON/OFF] Operate ON/OFF terminal

Switches between OPERATE ON or OFF when a signal is
input.

l [WARNING OUT] warning output terminal

Outputs a signal when an error such as operation
abnormality occurs on the hard disk.

m [REC TALLY] recording status output terminal

Outputs the recording status of this unit.

n [OPTION OUT1][OPTION OUT2] OPT OUT

output terminals 1/2

Outputs a signal when an event is detected.

o [COMMON] signal ground terminal

Same as j.

p [SIGNAL GND] signal ground terminal

This is a common ground terminal. Connect it to the signal
ground terminal on the connected device.

(This can be used when there are insufficient common
ground terminals.

Memo :

● Do not use this terminal for protective earthing.

9

Getting Started

Part Names and Functions
(continued)

Rear I/O Terminals

Ter minal R emark s

e[ALARM

IN]

f[EMER-

GENCY]

g[ALARM

RESET]

h[EXT REC

IN]

j[OPE ON/

OFF]

j[REC

TA LLY ]

k[ALARM

OUT]

l[WARN-

ING OUT]

m[OPTION

OUT1]
[OPTION
OUT2]

250 ms
and above

Make

250 ms
and above

Break

Memo :

● Set the impedance at the output

end to 10kK or below.

250 ms
and above

Memo :

● Set the impedance at the output

end to 10kK or below.

250 ms
and above

Memo :

● Set the impedance at the output

end to 10kK or below.

1 s and
above

OPE ON

Approx. 50 ms

OPE OFF

Memo :

● Set the impedance at the output

end to 10kK or below.

Break

Make
Output In
Progress

(External Pull-up Level)
The make contact is formed using
the individual output terminals and
the COM terminal. Turning off the

power of VR-N1600U/E switches the
output of the output terminals to
break.

Output In
Progress

Make
Contact
Input

Make
Contact
Input

Make
Contact
Input

Make
Contact
Input

Auto
Collector
Output
(DC15V, 10
mA and
below)

Mounting to a Rack

Use the supplied rack mount bracket to mount VR-N1600U/E
to the EIA rack.

1 Mount the rack mount bracket using screw (1)

● Use the 4 screws (M4 x 10 mm) supplied to fasten VR-

N1600U/E at the two sides.

2 Remove screws B of the foot (4 pcs) at the

bottom

● Remove the foot.

3 Mount to the rack using screws C

● Use the 4 screws (M5 x 11 mm) supplied to fasten this

unit to the rack.

Rack Mount
Bracket

(4 Locations)

Note :

● Do not place any object on the VR-N1600U/E unit that

has been mounted to the rack. Doing so may cause it to
lose balance and drop or fall, hence resulting in injuries or
damages.

● When mounting 2 or more units of VR-N1600U/E to the

rack, make sure to mount it at a distance that is at least
equivalent to one unit.

10

Preparation

System Connection Example

The following operations are possible with this system.

● Surveillance (live image, recording and playback) by connecting up to 16 cameras

● Checking recorded images on the VGA monitor

● Recording/Playing sound

● Alarm recording

● Remote surveillance using PCs

Supplied power cable

VGA monitor

IP cameras

Computer for configuring
cameras

NAS

AUDIO OUT

ON

OFF

ACIN100V H

USB Mouse

AUDIOIN

SIGNALGND

VGA OUT

SERIAL

Switching

Speaker (with built-in amplifier)

ALARM IN/OUT

ALARM IN/ALARM OUT

AUDIO
OUT

ALARMIN

VGAO UT

LAN2

LAN1

1
2

3
4

SERIAL

LAN2

LAN1

Switching

HUB

SERIAL

UPS control

Microphone

AUDIO IN

Mic Amp

Surveillance computer

HUB

● You can connect up to 16 cameras.

● You can connect up to 10 surveillance

computers.

Memo :

● Connect LAN1 to the camera network.

● LAN2 to the surveillance computer network.

● For details of the protocol and port number for the network

cameras on the LAN1 network, refer to the network
camera’s user manual.

● The protocol and port number used on the LAN2 network

are shown below.

● Surveillance computer: HTTP 80

● Mail: SMTP 25/POP 110

● Connect NAS to the LAN1 network.

UPS

Note :

● Connect only after having turned AOFFB the power of all

devices.

● Set the IP address of the camera to 192.168.0.xxx. When

setting the IP address of the camera to an address other
than 192.168.0.xxx, you must also change the IP address
of LAN1. Refer to the [Instruction Manual] of each camera
for procedures to change the camera’s IP address,

11

Preparation

System Connection
Example (continued)

Note :

● Do not connect LAN1 to the internet. If the internet is busy

or the relay equipment fails, you may not be able to save
important camera images. To maintain full recording
capacity, it is recommended that a dedicated network be
used. Be sure to connect the LAN1 camera network to the
same segment. (Do not use the address translation of
NAT and NAPT etc. or a router.)

● If you connect LAN2 to the internet from a surveillance

computer, you will need to configure IP Masquerading.

● Communication between LAN1 and LAN2 is not possible.

Nor is it possible to configure a camera connected to
LAN1 from the surveillance computer connected to LAN2.
In order to configure a camera connected to LAN1, it is
necessary to connect the computer for configuring
cameras to LAN1.

● LAN1 and LAN2 are incompatible with QoS. Sound may

not be played normally depending on the condition of the
circuit.

● The default LAN1 IP address is 192.168.0.253 and the

default LAN2 IP address is 192.168.1.253. To change the
address, use [INSTRUCRTIONS].

● When a single network camera is registered with multiple

units of VR-N1600U/E, recording may not be properly
completed in some cases. Camera control (e.g. PTZ
control) may also become unstable. It is recommended
that a single VR-N1600U/E be used for registering one IP
camera as well as for controlling PTZ operations.

● Do not connect a broken hub, router or deteriorated

network cable etc. Doing so may prevent the system from
operating properly.

● Connection to a keyboard is not recommended.

During Initial Startup

Perform language setting and automatic camera registration
when starting up

Before Starting Up.

● The DHCP setting is required for the IP camera

beforehand. Start up the VR-N1600U/E first, then switch
the camera on after confirming that the [Auto Detect
Setting] window is displayed.

● Refer to the user manual supplied with the camera for

instructions on how to specify the IP camera settings.

● By default, [Time Zone] is set to [(GMT-05:00) Eastern

Time](VR-N1600U)/[(GMT) Greenwich Mean Time](VR­N1600E) and [Auto Summertime Adjustment] is
checked. Specify a Time zone according to the region
used. Refer to the INSTRUCTIONS on how to specify a
Time zone settings.

LIVE/BROWSE

OPERATE

SELECT

REC CONTROL

PTZ/PRESET

SERIAL

VR-N1600U/E for the first time.

Keyp ad

㧝 㧞 㧟

㧡

㧢*1/'

㧥  

   

CANCEL ZOOMOUT ZOOM IN ENTER

[16/ENTER]
Button

WARNING

㧠

ALARM

HDD

㧣

㧤

LOCK



SEARCHFUNCTION ALARMCLEARKEY REC/STOP STOP(PB) PLAY

[KEY] Button

REV FWD

SKIP

[SKIP]
Button

12

Start up VR-N1600U/E

1 Turn on the power switch at the rear panel.

● VR-N1600U/E starts up.

Selecting a language

The [Language Setting] screen appears when you start up
VR-N1600U/E for the first time. Select the language to use
using the steps below.

1 Select a language

● Use the [2/D] or [10/0/E] button to select a language.

2 Use the [SKIP] button to select [OK], followed by

pressing the [16/ENTER] button

● The AThe system is being set up.B message may

appear depending on the setting, and the system is
automatically rebooted.

Memo :

● Selecting [OK] changes the color of the [OK] characters

from brown to orange.

Automatic Registration of Cameras

After you have started up VR-N1600U/E for the first time and
finished selecting a language, the [Auto Detect] screen
appears.

1 Check to ensure that [Auto Detect] is selected,

followed by pressing the [16/ENTER] button

● The APlease wait...B message appears.

Memo :

● The characters of the selected item switches to orange

color.

2 Check to ensure that the camera is detected

● After the message disappears, a list of detected

cameras is displayed.

● If all the cameras are not detected, press the [Auto

Detect] button again. If doing so does not solve the
problem, check the connection with the cameras and
the IP address of the cameras.

3 Swap the order of detected cameras

● Select SORT button using [SKIP] button and press 

[16/ENTER] button. The order of detected cameras
can be sorted.

● The different types of sort buttons include the [IP],

[MAC], [CH], [MAKER], and [MODEL] sort buttons.

● Select list using [SKIP] button to select [2/D], [10/0/E].

After selecting camera, press [SKIP]] button to select
[Up], [Down]. When [16/ENTER] is pressed, the order

of cameras will be swapped.

● Deselect the check box of any camera that you are not

using.

Memo :

● The camera in the upper position of list order has the first

priority. Camera number will be registered in the list order.

4 Use the [SKIP] button to select [Entry], followed

by pressing the [16/ENTER] button

● The camera that is automatically detected is registered

in the system.

5 Use the [SKIP] button to select [OK], followed by

pressing the [16/ENTER] button

● The [Configure Device] screen appears.

13

Preparation

During Initial Startup
(continued)

6 Enter the password for the network camera

● Press the [KEY] button to display the software

keyboard.

● Use the keypad to move the mouse cursor over the

software keyboard.

● Pressing the [16/ENTER] button inputs the characters

on the keyboard into the password field.

7 After password entry is complete, press [KEY]

again the close the software keyboard

8 Use the [SKIP] button to select [OK], followed by

pressing [16/ENTER]

9 Repeat the steps from 5 to 7 for every detected

camera

● The [Camera Record Setting] screen appears.

10 Set the display rate of each camera such that

the total display rate of all cameras does not
exceed 80 ips

● The default display rate is set to 8 ips. In other words,

the maximum display capacity of 80 ips will be
exceeded if 11 or more cameras are automatically
detected. In this case, you will need to follow the steps
below to adjust the display rate of each camera.

Note :

● The recording rate may drop if the total display rate of all

cameras exceeds 80 ips.

A Press the [SKIP] to select the Device Manager

●The device at the top of the list is selected.

A

B Use the [2/D] and [10/0/E] buttons to select a device

B

14

C Use the [7/B] button to display the camera

C

Memo :

● Use [SKIP] to move between the items.

● Use the [2/D] and [10/0/E] buttons to select the item to

configure.

● To enter numeric characters, press the [SELECT] button

to turn on the light of the [SELECT] indicator. Upon
entering the numeric characters, press the [PTZ/
PRESET] button to turn on the light of the [PTZ/PRESET]
indicator.

G Use the [SKIP] button to select [OK], followed by

pressing the [16/ENTER] button

11 Repeat the procedures 9 for each camera

D Use the [10/0/E] button to select a camera

D

E Use the [SKIP] button to select [Settings...], followed

by pressing the [16/ENTER] button

●The [Camera Settings] screen appears.

Speedup Settings

Recording
Settings

12 Use the [SKIP] button to select [Close],

followed by pressing the [16/ENTER] button

● Setting is complete and the [Live] screen appears.

● The [REC CONTROL] indicator lights up and recording

starts in the recording control mode.

[Live] Screen

Live Settings

F Setting the Live Image Display Rate

●Select ASame as recordingB or ASame sa speedupB

as the live image display rate in [Live Settings].

●When ASame sa speedupB is selected, the [Frame

Rate] specified in [Speedup Settings] is used as the
live image display rate.

●When ASame as recordingB is selected, the [Frame

Rate] specified in [Recording Settings] is used as the
live image display rate.

15

Basic Operation

Viewing Live Images via Front Panel Control

This section describes the procedures for viewing live
images by using the front panel of

[Live] Screen

VR-N1600U/E.

2 Press the [15/ZOOM IN] and [14/ZOOM OUT]

buttons to select a view

Note :

● Do not switch the view frequently within a short time

interval.

● When live images do not appear on VN-C625/VN-C655,

set the password on the camera unit as well as VR­N1600U/E again. For details on the setting procedures,
refer to the [INSTRUCRTIONS] of the camera in use and
procedures for setting the root password on the [Edit
device settings] screen in this manual.

● The audio setting is set to ANo Audio SourcesB when you

return from the setting screen to [Live]. Select the audio
parameters again.

Select a Camera

Select the camera image that you want to view as follows.

1 Press the [SELECT] button

● The [SELECT] indicator lights up.

2 Enter the camera number using the [1] to [16]

keypad

● When you have selected a camera, the blue bar at the

top of each live image changes to a lighter blue tone.

● Each bar comes with a tri-color square indicator, which

indicates the following features, as well as characters
that indicate the operating status of the camera.

Displaying the [Live] Screen

1 Press the [LIVE/BROWSE] button when the

wallpaper *1 or main menu *2 screen is
displayed.

● Press the [LIVE/BROWSE] button when the [Browse]

screen is displayed.

● Press the button to toggle between the [Live] and

[Browse] screens.

*1 Wallpaper Screen *2 Main Menu Screen

Select a view

For details on the view settings, refer to [INSTRUCRTIONS].

1 Press the [PTZ/PRESET] button to switch the

[PTZ/PRESET] indicator to the blinking mode

● Press the [PTZ/PRESET] button to switch the [PTZ/

PRESET] indicator between the lit and blinking modes.

A
B

C

D

[Live] Screen

16

Memo :

A Event indicator (Left: yellow)

Lights up when events specified in the [Camera Record
Setting] occur. The indicator appears black if event
indication has not been specified for the camera in
question, or if no specified event has occurred.

B Motion indicator (Center: red)

Lights up when motion is detected.

C Online indicator (Right: green)

Blinks every time an image is received from the camera.

D Operating status of the camera (Appears to the left of

the indicator)

Display Status

Live (Green) When live images are displayed

without being recorded

Recording

When recording is in progress

(Red)

Stop (Yellow) When images are not acquired from

the camera, or when the camera is in
the offline mode

● You can press the [ALARM CLEAR] button to hide the

event indicator and motion indicator.

● The image bar displays the name of the camera as well as

the name of the device to which the camera is connected.

● Pressing a number that corresponds to the selected

camera enlarges the display. To restore display to the
normal size, press the number of the camera with
enlarged display.

Operating the Camera

PTZ stands for pan, tilt and zoom.
If the camera supports the PTZ functions, you can use the

keypad, and the
move the camera up/down (tilt), left/right (pan), or enlarge/
reduce the image (zoom).

[LIVE/BROWSE] Button

[SELECT] Button

LIVE/BROWSE

OPERATE

SELECT

REC CONTROL

PTZ/PRESET

SERIAL

[PTZ/PRESET] Button

[REC CONTROL]
Button

[16/ENTER] and [13/CANCEL] buttons to

Keypad

㧝 㧞 㧟

㧡

㧢*1/'

㧥  

   

CANCEL ZOOMOUT ZOOM IN ENTER

[14/ZOOM OUT] Button

WARNING

㧠

ALARM

HDD

㧣

㧤

LOCK



[FUNCTION]
Button

[15/ZOOM IN] Button

SEARCHFUNCTION ALARMCLEARKEY REC/STOP STOP(PB) PLAY

[ALARM CLEAR] Button

REV FWD

SKIP

䡵 Pan/Tilt

1 Press the [PTZ/PRESET] button to switch the

keypad to the PTZ mode

● The [PTZ/PRESET] indicator lights up.

● Press the button to switch between the APTZ ModeB

(indicator lights up) and APreset ModeB (indicator
blinking).

2 Press the 1 to 9 keypad

● Pans/Tilts in the direction indicated by the arrow on the

keys.

● Press the [6/HOME] key to move to the home position.

䡵

Zoom In/Zoom Out

1 Press the [PTZ/PRESET] button to switch the

keypad to the PTZ mode

● The [PTZ/PRESET] indicator lights up.

● Press the button to switch between the APTZ ModeB

(indicator lights up) and APreset ModeB (indicator
blinking).

2 Press the [15/ZOOM IN] or [14/ZOOM OUT]

button

䡵 Using Preset Positions

1 Press the [PTZ/PRESET] button to switch the

keypad to the Preset mode

● The [PTZ/PRESET] indicator starts blinking.

● Press the button to switch between the APTZ ModeB

(indicator lights up) and APreset ModeB (indicator
blinking).

2 Enter the preset number using the [1] to [10/0]

keypad

● The camera moves to the preset position.

Memo :

● You can specify numbers from 10 to 19 by pressing [10/0]

followed by a number from [10/0] to [9].

Note :

● You need to specify the preset positions in advance in

order to use the preset feature.

17

Basic Operation

Playing Back Recorded Images via Front Panel Control

This section describes the procedures for playing back
recorded images using the front panel of

Displaying the [Browse] Screen

1 Press the [LIVE/BROWSE] button when the

wallpaper or main menu screen is displayed

● The NVR Viewer starts up and the [Live] screen

appears.

2 When the [Live] screen appears, press the

[LIVE/BROWSE] button again

● Press the button to toggle between the [Live] and

[Browse] screens.

VR-N1600U/E.

Note :

● Do not switch the view frequently within a short time

interval.

● When live images do not appear on VN-C625/VN-C655,

set the password on the camera unit as well as VR­N1600U/E again. For details on the setting procedures,
refer to the [INSTRUCRTIONS] of the camera in use and
procedures for setting the root password on the [Edit
device settings] screen in this manual .

● The setting in the [Audio] section is set to ANo Audio

SourcesB when you return from the setting screen to
[Browse]. Select the audio parameters again.

Searching Recorded Image Using a Specific Date/ Time

You can search for and play back images by specifying a
date and time using the

[SEARCH] button on the front panel.

1 Press the [SEARCH] button on the [Browse]

screen

● The date and time input screen appears.

[Live] Screen

Select a view

For details on the view settings, refer to [INSTRUCRTIONS].

1 Press the [PTZ/PRESET] button until the [PTZ/

PRESET] indicator blinks.

● The [PTZ/PRESET] indicator switches between lit and

blinking each time the [PTZ/PRESET] button is
pressed.

2 Press the [15/ZOOM IN] or [14/ZOOM OUT]

button to select a view

[Go To] Button

2 Use the keypad to enter the search date and

time

● Use the [SKIP] button (S or T) to select an item

and input accordingly.

3 Press the [16/ENTER] button

● The view in the image display screen on the right

jumps to the selected date and time.

Memo :

●

You can also jump to the selected date/time by clicking the
[Go To] button.

● When you are using the software keyboard, click the [Go

To] button.

Playing, Skipping and Stopping Recorded Images

Control using the [PLAY], [SKIP], and [Stop] buttons.

䡵

Control using the [PLAY], [SKIP], and [PLAY] buttons
on the front panel

[LIVE/BROWSE] Button/Indicator

[STOP(PB)] Button

キーロック

REV FWD

SKIP

OPERATE

REC CONTROL

Keypad/Indicator

㧝 㧞 㧟

LIVE/BROWSE

㧡

㧢*1/'

SELECT

㧥  

PTZ/PRESET

SERIAL

   

CANCEL ZOOMOUT ZOOM IN ENTER

WARNING

㧠

ALARM

HDD

㧣

㧤

LOCK



SEARCHFUNCTION ALARMCLEARKEY REC/STOP STOP(PB) PLAY

18

[SEARCH] Button

[16/ENTER] Button

[13/CANCEL] Button

[PTZ/PRESET] Button/Indicator

[SKIP] Button

䢇 Playing Back

1 Press the [PLAY] button

● Playback starts from the date/time indicated in [Master

Time] of [Time Navigation].

● Images are played back according to the angle of the

shuttle dial (x1/20, x1/5, x1, x2, x5, x10, x20).

[Master Time] area

[Time Navigation] Section

NVRViewer

[Browse] Screen

[Go To] Button

Adjusting the Playback Speed (Jog/Shuttle Playback)

You can adjust the playback speed by turning the jog dial/
shuttle dial on the front panel.

䡵

Shuttle Playback

● Rotate the shuttle dial during playback or when playback

is paused to start fast forward, fast reverse or slow
playback.

still

x1/20

x1/5

REV FWD

x1

x2

x5

x10

x20

Jog/Shuttle dial

x1/20

x1/5

x1

x2

x5

x10

x20

Shuttle dial (Outside)

Jog dial (Inside)

䢇 Skipping

1 Press the [SKIP] button

● The [SKIP] buttons have the following functions.

S Moves to the first image in the previous

sequence.
Moves to the oldest image in the database

of the selected camera when the button is
pressed and held down..

T Moves to the first image in the next

sequence. Moves to the first image in the
next sequence. When pressed and held
down, moves to the latest image in the
database for the selected camera.

Memo :

● “Sequence” indicates a certain block of images that are

recorded during motion detection.

● Recorded images are stored in the database.

Note :

● The [SKIP] buttons are only enabled when a camera has

been selected.

● During simultaneous recording and playback, an AAfter

Database EndB message may appear as playback
catches up with recording during playback near the
current time.

● When recording is set to be triggered by motion/event ,

VR-N1600U/E will not start recording unless a motion/
event occurs. During playback near the current time,
however, the image that is not recorded will also be
played.

䢇 Stopping

Memo :

● The playback speed that is indicated during fast forward or

fast reverse playback by rotating the shuttle dial is an
approximate value. The speed may differ depending on
the conditions, such as the playback mode (multi-view,
single view) and the recording mode (motion detection,
recorded frame rate).

䡵

Jog Playback

● Rotate the jog dial to play back frame by frame.

● Rotate the dial clockwise to play back a single frame in the

forward direction, and rotate the dial counterclockwise to
play back a single frame in the reverse direction.

● Release the dial to pause the playback. However, when

frames are played back successively in the forward or
reverse direction, playback may continue momentarily
after the jog dial is released.

Note :

● The jog dial is only enabled when a camera has been

selected.

● When the playback speed is adjusted or when playing

back at high speed during recording, the frame rate of the
recording may decrease. Check the performance meter
while adjusting the playback speed to ensure that the
display does not turn red.

1 Press the [STOP(PB)] button

● Playback stops.

䢇 Enlarging the Display

● Pressing a number that corresponds to the selected

camera enlarges the display.

● To restore display to the normal size, press the number of

the camera with enlarged display.

19

Others

Troubleshooting

Symptom Action

Power cannot be turned on. Check to ensure that the power cable has been plugged in correctly.

Check to ensure that the power switch on the rear panel is switched on.

Camera is not automatically detected. Follow instructions in the camera’s [Instruction Manual] to check the IP

address settings.
When the IP Lease feature is in use, turn off and on the power of the camera

VR-N1600U/E is started up.

when

Unable to control using [REC] and [PLAY]. Check to ensure that the operation lock is not turned on.

Images are not recorded in the recording control
mode.

Check the [Camera Recording Settings].
Check to ensure that the scheduler is set to online.
Check to ensure that the camera is in the recording control mode.

Unable to play back audio sound. Check to ensure that the audio item of the camera device is set to AEnabledB

Operation of the unit is disabled. Press and hold the [FUNCTION] button on the front panel, and press the

The following message appears after the power
is turned on.

ACOMS Settings Wrong CMOS Date/ Time Not
Press F1 to Run SETUP Press F2 to load
default values and continueB

䡵

Actions when Warning Indicator Lights Up

Error Message Action to Take

WARNING:HDD（Disk)

HDD was removed Check to ensure that the power of the external HDD is switched on.

WARNING:HDD（Raid)

WARNING:HDD(xxx:) Disconnect The NAS drive is disconnected.

in the [Camera Record Setting] menu.
Check to ensure that an audio source is selected in [Audio].

[OPERATE] button for 7 seconds or longer to shut down the power forcibly.
When the power is forcibly shut down, recorded images that are not archived

may not be properly played back.

The built-in backup battery is low.
Consult your nearest JVC dealer.

The HDD seems is no longer serviceable. Replacement is recommended.
Consult your nearest JVC dealer.

Check to ensure that the connecting cable is properly inserted.
If no abnormality is found above, consult your nearest JVC dealer.

This is a hard disk (when RAID is enabled) warning.
Consult your nearest JVC dealer. .

Check the operation of NAS.
Check the connection with NAS.

FAN S TOP Fan abnormality. Check to ensure that the fan is running.

If the fan is not moving, stop using it.
Otherwise, it may break down.
Consult your nearest JVC dealer.

20

Specifications

䡵 General

Allowable Operating Temperature

: 5 I to 40 I

Allowable Storage Temperature

: -20 I to 60 I

Allowable Operating Humidity

: 30 % to 80 %

Power Supply

VR-N1600U : AC 120 V, 50 Hz/60 Hz

VR-N1600E : AC 220 V to 240 V, 50 Hz/60 Hz

Consumption Current

VR-N1600U : 1.2 A(max.)

VR-N1600E : 0.8 A(max.)

Mass : Approx. 7.6 kg

䡵 Interface

Network : RJ-45⳯2

LAN1 : 1000BASE-T/100BASE-TX/10BASE-T

LAN2 : 100BASE-TX/10BASE-T

Serial : USB2.0 A-type (or equivalent) ⳯ 5

VGA Output : Max. 1600 ⳯ 1200

Audio Input : Analog audio RCA ⳯ 2 - 8 dBs 50 kK

(unbalanced)

Audio Output : Analog audio RCA ⳯ 1 - 8 dBs 600 K

(unbalanced)

I/O Terminals : Push terminal

Input ⳯ 12

Output ⳯ 5

GND ⳯ 3

䡵 Compression Format

Video : JPEG/MPEG-4
Audio : μ-law (64 kbps) A/D 8 bits, Fs = 8 kHz

䡵 Recording

HDD Capacity : 500 GB ⳯ 1

䡵 Attachments/Accessories

VR-N1600U

Start-up Guide .......................................1

CD-ROM................................................1

Power Cord (2 m) ..................................1

Rack Mount Bracket ..............................2

Warranty Card .......................................1

Service Information Card....................... 1

Screw (M4⳯10 mm).............................. 4

Screw (M5⳯11 mm).............................. 4

VR-N1600E

Start-up Guide .......................................1

CD-ROM................................................1

Power Cord (2 m) ..................................2

Rack Mount Bracket ..............................2

Screw (M4⳯10 mm).............................. 4

Screw (M5⳯11 mm).............................. 4

䡵 Dimensional Outline Drawing (Unit: mm)

420

WARNING

㧝 㧞 㧟

㧠

LIVE/BROWSE

OPERATE

SELECT

RECCONTROL

PTZ/PRESET

SERIAL

T The specifications and appearance of this unit may be

modified for improvement without prior notice.

㧡

㧣

㧢*1/'

㧥  

   

CANCEL ZOOMOUT ZOOMIN ENTER

ALARM

HDD

㧤

LOCK



SEARCHFUNCTION ALARMCLEARKEY REC/STOP STOP(PB) PLAY

REV FWD

SKIP

䡵 Recording/Display/Distribution capacity

When display is available

: Max. 160 ips/80 ips/80 ips

When display is not available

: Max. 240 ips/0 ips/80 ips

(When NVR Viewer is not started up)

21

22

23

VR-N1600U/VR-N1600E

NETWORK VIDEO RECORDER

LST0601-001A© 2007 Victor Company of Japan, Limited
