PARTS LIST
[ UX-P450 ]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
A ------------------------- Australia
US ---------------------- Singapore
UB --------------------- Hong Kong
UF ---------------------------- China
UX ------------------- Saudi Arabia
UN ----------------------------Asean
No.MB302
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Speaker assembly and parts list (Block No.M2)
DVD mechanism assembly and parts list (Block No.MJ)
DVD loading base assembly and parts list (Block No.MN)
Cassette mechanism assembly and parts list (Block No.MP)
Electrical parts list (Block No.01~07)
Packing materials and accessories parts list (Block No.M3)
3- 2
3- 6
3- 7
3- 9
3-11
3-13
3-20
3-1
Exploded view of general assembly and parts list
K
91
85
Block No.
74
B
G
D
75
E
71
76
84
F
73
81
98
82
79
82
78
FL board
16
100
87
A
M
72
97
t
47
M
1
M
F1003
94
H1003
54
53
u
19
102
105
p
77
Power ampl
59
K
89
k
D7500
80
H
112
DI750
9
L
34
11
83
1
13
E
3
F
D7601
13
26
4
18
D7600
5
83
15
8
11
Switch board
101
42
p
90
32
15
2
10
17
6
46
7
14
46
Headphone jack board
m
40
12
27
29
H
3-2
J
1
53
M
M
F1003
94
H1003
54
19
105
77
Power amplifier board
59
K
L
34
Power supply board
K
102
p
47
42
95
c
e
F1004
H4001
47
96
F1005
24
103
F1001
92
47
49
51
50
50
d
r
F1002
93
o
f
52
57
b
L
d
r
Video board
e
107
99
70
48
43
106
j
62
A
h
B
G
111
D
68
109
61
C
60
64
65
60
66
67
69
g
63
56
43
n
a
58
32
40
104
36 31
f
44
42
41
30
35
37
39
45
o
28
J
40
k
c
b
m
a
n
55
Main board
t
23
g
h
j
u
20
HS240
88
C
22
HS241
55
21
38
33
86
29
110
J
3-3
General Assembly
Block No. [M][1][M][M]
Symbol No. Part No. Part Name Description Local
1 GV10189-016A FRONT PANEL
2 GV30569-004A FRONT LENS
3 GV40470-001A STANDBY LENS
4 GV40471-001A REMOTE LENS
5 GV20265-009A MAIN BUTTON
6 GV40472-004A EJECT BUTTON
7 GV30555-003A VOL PLATE
8 GV40473-002A LCD LENS
9 GV30557-001A LCD HOLDER
10 GV40478-004A LED LENS
11 QYSBSF2608Z TAP SCREW M2.6 x 8mm(x10)
12 GV40035-001A SPECIAL SCREW
13 QYSDSF2006M TAP SCREW M2 x 6mm(x4)
14 GV40313-002A FELT SPACER (x2)
15 QYSBSF2606Z TAP SCREW M2.6 x 6mm(x3)
16 QYSBSF2608Z TAP SCREW M2.6 x 8mm(x4)
17 GV30349-007A SPACER
18 GV40508-001A LED HOLDER
19 LE40505-001A HEAT SINK P450UN,P450US,P450UX
20 E70945-H40B HEAT SINK HS 921
21 QYSBSG3008Z TAP SCREW M3 x 8mm
22 LV40057-H30B HEAT SINK
23 QYSBSG3008Z TAP SCREW M3 x 8mm
24 LE40505-001A HEAT SINK
26 GV40203-002A LED HOLDER B
27 GV10190-001A BOTTOM CHASSIS
28 GV40313-002A FELT SPACER (x2)
29 GV40474-001A MECHA HOLDER F (x2)
30 GV40479-001A MECHA HOLDER R
31 GV40242-004A COMMON SPACER
32 GV30349-027A SPACER
33 GV30349-005A SPACER
34 GV20269-002A SHIELD CASE
35 GV40527-001A COPPER SHIELD
36 E3400-431 SPECER
37 E3400-431 SPECER
38 E3400-431 SPECER
39 E3400-431 SPECER (x2)
40 QYSDST3005Z TAP SCREW M3 x 5mm(x2)
41 QYSDST3005Z TAP SCREW M3 x 5mm(x2)
42 QYSBSF3008Z TAP SCREW M3 x 8mm(x3)
43 QYSBST4006Z TAP SCREW M4 x 6mm(x4)
44 QMPG150-244-JC POWER CORD(AST) 2.44m BLACK P450A
44 QMPN160-200-JD POWER CORD(EU) 2m BLACK P450UB
44 QMPR480-200-JC POWER CORD(EU) 2m BLACK P450UF
44 QMPK210-205-JN POWER CORD(EU) 2.05m BLACK P450UN,P450US
44 QMPR270-200-JD POWER CORD(EU) 2m BLACK P450UX
45 QZW0033-001 STRAIN RELIEF
46 QYSSST3008Z TAP SCREW M3 x 8mm(x2)
47 QYSDST3005Z TAP SCREW M3 x 5mm(x4)
48 GV40480-002A IC HOLDER
49 GV30559-007A HEAT SINK
50 QYSBSG3008E TAP SCREW M3 x 8mm(x2)
51 QYSBSG3012Z TAP SCREW M3 x 12mm(x2)
52 QYSBSG3008E TAP SCREW M3 x 8mm(x2)
53 QYSBSTG3006Z TAP SCREW M3 x 6mm
54 QYSBSTG3006Z TAP SCREW M3 x 6mm
55 QYSBSTG3006Z TAP SCREW M3 x 6mm(x2)
56 GV20270-052A REAR PANEL P450A
56 GV20270-050A REAR PANEL P450UB
56 GV20270-048A REAR PANEL P450UF
56 GV20270-046A REAR PANEL P450UN,P450US
56 GV20270-047A REAR PANEL P450UX
57 QAU0346-001 TUNER TU 1
58 GV40481-001A FAN BRACKET
59 LV41843-002A LASER CAUTION
60 QYSBSGY3008E TAP SCREW M3 x 8mm(x2)
61 QYSBSGY3008E TAP SCREW M3 x 8mm(x2)
62 QYSBSGY3008E TAP SCREW M3 x 8mm(x2)
63 QYSBSGY3008E TAP SCREW M3 x 8mm(x2) P450UN,P450US,P450UX
64 QYSBSGY3008E TAP SCREW M3 x 8mm
65 QYSBSGY3008E TAP SCREW M3 x 8mm
66 QYSBSGY3008E TAP SCREW M3 x 8mm
67 QYSBSGY3008E TAP SCREW M3 x 8mm
3-4
Symbol No. Part No. Part Name Description Local
68 QYSBSGY3008E TAP SCREW M3 x 8mm
69 QYSBSGY3008E TAP SCREW M3 x 8mm
70 GV30349-007A SPACER
71 GV20288-003A TOP COVER ASSY
72 GV40506-001A DOOR SPRING
73 GV40034-001A DAMPER ASSY.
74 GV40220-001A LACH
75 VKL7850-002 EJECT SAFTY(R)
76 VKW5258-003 TORSION SPRING
77 GV30349-022A SPACER (x2)
78 GV40229-001A SUPPORT BRACKET
79 GV30071-001A HEAD SHIELD
80 QYSBSF2608Z TAP SCREW M2.6 x 8mm(x2)
81 QYSBSF3008Z TAP SCREW M3 x 8mm
82 QYSBSF3010Z TAP SCREW M3 x 10mm(x4)
83 QYSSSF3008Z TAP SCREW M3 x 8mm(x2)
84 GV40035-001A SPECIAL SCREW
85 GV10194-004A SIDE PANEL L
86 GV10195-001A SIDE PANEL R
87 QYSBSGY3010E TAP SCREW M3 x 10mm(x2)
88 QYSBSGY3010E TAP SCREW M3 x 10mm(x2)
89 GV30563-001A MIC VOL KNOB
90 GV30564-006A TRAY FITTING
91 GV30566-003A RATING LABEL P450A
91 GV30566-002A RATING LABEL P450UB
91 GV30566-205A RATING LABEL P450UF
91 GV30566-001A RATING LABEL P450UN,P450US,P450UX
92 QMF51W2-1R0-J8 FUSE F1001 P450A,P450UB,P450UF
92 QMF51W2-1R6-J8 FUSE F1001 P450UN,P450US,P450UX
93 QMF51W2-R80-J8 FUSE F1001 P450UN,P450US,P450UX
94 QMF51W2-3R15-J8 FUSE F1003 P450A
94 QMF51W2-2R5-J8 FUSE F1003 P450UB,P450UF
94 QMF51W2-2R0-J8 FUSE F1003 P450UN,P450US,P450UX
95 QMF51W2-1R25-J8 FUSE F1004
96 QMF51W2-6R3-J8 FUSE F1005
97 QUQH12-0922AJ FFC WIRE FC 33
98 QUQH12-1022AJ FFC WIRE FC 34
99 QUQH12-1114AJ FFC WIRE FC700
100 QUQH12-1508AJ FFC WIRE FC750
101 QUQH12-1008AJ FFC WIRE FC760
102 QUQH12-1814AJ FFC WIRE FC402
103 QUQH10-1912AJ FFC WIRE FC220
104 QUQH10-1717BJ FFC WIRE FC720
105 QUQH10-0506BJ FFC WIRE FC404
106 QUQH12-2419AJ FFC WIRE FC710
107 QQT0430-003 POWER TRANSF T1001 P450A
107 QQT0430-002 POWER TRANSF T1001 P450UB,P450UF
107 QQT0430-001 POWER TRANSF T1001 P450UN,P450US,P450UX
109 LV43268-001A CCC LABEL P450UF
110 GV40530-001A WIRE LOCATOR
111 QAR0230-001 FAN
112 QLD0312-001 LCD DISPLAY
3-5
Speaker assembly and parts list
(A,US,UB,UX,UN only)
Block No.
Block No.
M
M
2
2
M
M
M
M
3
4
1
2
5
The parts without symbol number are not service.
Speaker (Subwoofer)
Symbol No. Part No. Part Name Description Local
1 UP4-BK-00-01 SARAN BOARD (x2)
2 UP4-MK-00-01 MARK (x2)
3 UP5-WO-00-01 SPEAKER (x2)
4 UP4-ML-00-01 TAPPING SCREW (x8)
5 UP4-JD-00-01 RUBBER CUSHIO (x8)
Block No. [M][2][M][M]
3-6
DVD mechanism assembly and parts list
Block No.
M
J
M
M
Grease
=JVG-31N
=CFD-4007ZY2
=PG-641
=1401C
< Back side >
27
29
FTU-DE2-11M
25
24
23
6
5
A
19
A
16
18
17
15
14
13
12
26
10.5mm
±
2
0.1mm
28
28
8
3
22
21
4
9
7
11
10
63.3mm
20
11
0.1mm
±
1
The parts without symbol number are not service.
3-7
DVD mechanism
Symbol No. Part No. Part Name Description Local
1 LE20725-001A MECHA BASE
2 LE20699-002A SPINDLE BASE
3 QYSDST2605M TAP SCREW M2.6 x 5mm(x2)
4 LE40931-001A SHAFT
5 LV33991-001A ADJUST SPRING
6 QYSPSFU2040M TAP SCREW M2 x 4mm
7 LE20698-004A FEED HOLDER
8 QAR0215-001 FEED MOTOR
9 LV41510-201A FEED GEAR T
10 QYSPSPU2040M SCREW M2 x 4mm(x2)
11 QYSDST2605M TAP SCREW M2.6 x 5mm(x2)
12 QAL0507-001 PICK UP
13 LE20700-001A SW ACTUATOR
14 LE31067-002A LEAD SPRING
15 QYSPSFU1740Z TAP SCREW M1.7 x 4mm(x2)
16 LE40929-001A SW.LEVER
17 QYSPSFU1740Z TAP SCREW M1.7 x 4mm
18 QUQ105-2411AC FFC
19 LE40931-001A SHAFT
20 LE40855-001A FEED GEAR E
21 LE40918-001A LEAD SCREW
22 LE40930-001A FEED GEAR M
23 LE40928-001A THURUST SPRING
24 LE40927-001A PLATE
25 QYSDST2614Z TAPPING SCREW M2.6 x 14mm
26 QAR0316-001 SPINDLE MOTOR
27 QYSPSPU1740Z SCREW M1.7 x 4mm(x3)
28 LE40858-002A SPECIAL SCREW (x3)
29 QYSDST2004Z SCREW 2mm x 4mm(x2)
Block No. [M][J][M][M]
3-8
DVD loading base mechanism assembly and parts list
Grease
JVG-31N
JVS-1003
FMU-DE2-11M
20
19
18
16
5
2
Block No.
11
M
N
M
M
26
12
(All circumference)
4
3
15
9
1
10
8
14
13
7
0.10mm
-
+
17
Backside
7.95mm
e
22
f
a
b
24
24
23
24
6
Switch Board
25
c
21
e
c
d
f
a
d
b
The parts without symbol number are not service.
3-9
DVD loading base mechanism
Symbol No. Part No. Part Name Description Local
1 LE10275-006A LOADING BASE
2 LE31043-001A PULLEY GEAR
3 LE31042-001A MIDDLE GEAR
4 LE31044-001A IDLE GEAR
5 LE20665-001A SLIDE CAM
6 LE20666-003A ELEVATOR
7 LE10276-002A TRAY
8 LE31045-001A BUSHING
9 LE40898-001A SHAFT
10 QYSSSF2008Z TAP SCREW M2 x 8mm
11 QYSDSF2008Z TAP SCREW M2 x 8mm(x2)
12 LE40937-002A LEAF SPRING
13 QAR0197-001 MOTOR
14 LV42087-002A MOTOR PULLEY
15 QYSPSPU1730Z SCREW M1.7 x 3mm(x2)
16 LE40897-001A BELT
17 LE31046-003A CLAMPER
18 LV42930-003A P.C.MAGNET
19 LE40899-001A YOKE
20 LE40906-001A SPECIAL SCREW
21 ------------------ DVD TRAMECHA
22 LE40900-003A INSULATOR (x2)
23 LE40900-005A INSULATOR (x2)
24 LE40901-001A SPECIAL SCREW (x4)
25 QYWFM419025 WASHER 1.9mm/21.4mm x 0.02mm
26 LV43828-001A SPACER
Block No. [M][N][M][M]
3-10
Cassette mechanism assembly and parts list
Block No.
M
M
M
P
Grease
= EM-30L
=UD-24
=LEN-320M
=MOBIL-1
34
1
27
A
19
B
3
13
SLC-S302M
8
15
2
2
10
14
9
16
12
23
3
4
11
6
5
7
29
C
1
The lower side
24
5
6
Switch board
30
25
18
22
11
21
28
20
26
31
17
C
36
A
32
33
B
35
35
Head amplifier
board
3-11
33
32
0.1
_
+
0.15 mm
8.7
Cassette mechanism
Symbol No. Part No. Part Name Description Local
1 VKS1165-00N CHASSIS B. ASSY
2 VKS2274-002 REEL GEAR (x2)
3 VKW5286-002 B.T. SPRING (x2)
4 VKS5559-001 PLAY IDLE GEAR
5 VKS5595-002 BLIND
6 VKS5560-003 FR IDLE GEAR
7 LV42013-001A EARTH SPRING
8 SLC-RP4SVM HEAD MOUNT ASSY
9 VKY3149-002 CASSETTE SP.
10 LV31786-002A PLAY LEVER
11 VKS1166-003 CONTROL CAM
12 VKW5279-002 HEAD BASE SP(R)
13 VKW5280-001 HEAD BASE SP(L)
14 LV41584-001A BRAKE(R)
15 LV41585-003A BRAKE(L)
16 QYSBSF2005Z SCREW 2mm x 5mm
17 VKS5603-00G MAIN PULLEY ASS
18 VKS3785-001MM FR ARM
19 VKW5284-002 SWING SPRING
20 VKS2278-003 TRIGGER ARM
21 VKW5301-001 FR SPRING
22 VKW5266-001 ELEVATOR SPRING
23 WDL214025 WASHER
24 QYSBSF2005Z SCREW 2mm x 5mm
25 VKS3786-00G CLUTCH ASSY
26 VKF3205-00B F.WHEEL ASSY(R)
27 WDL183425 SLIT WASHER
28 VKF3207-00C F.WHEEL ASSY(L)
29 WDL173525-6 SLIT WASHER
30 VKZ3174-00B DC SOLENOID
31 LV42836-001A CAPSTAN BELT
32 MSI-5U2LWA D.C.MOTOR
33 VKR4761-003 MOTOR PULLEY
34 QYSPSP2604Z SCREW 2.6mm x 4mm(x2)
35 QYSBSF2608Z TAPPING SCREW 2.6mm x 8mm(x3)
36 QUQH12-0906BF WIRE
Block No. [M][P][M][M]
3-12
Electrical parts list
Main board
Block No. [0][1]
Symbol No.
IC200 LC75342M-X IC
IC202 JCV8011-X IC
IC240 KIA7810API IC
IC241 PQ05RD21 IC
IC250 GP1FA553TZ OPT TRANSMITTER
IC701 MN101C49GFK1 MASK ROM
IC702 BR24L01AF-W-X IC
IC703 BD4740G-W IC
IC705 KIA78S06P-T IC
IC707 SN74AHCT08NS-X IC
Q2200 2SC2001/LK/-T TRANSISTOR
Q2220 2SC2412K/R/-X TRANSISTOR
Q2221 KRA102S-X DIGI TRANSISTOR
Q2410 KTA1046/Y/ TRANSISTOR
Q2411 KTC3875/YG/-X SI TRANSISTOR
Q2420 KTC1027/OY/-T TRANSISTOR
Q7001 KRC107S-X DIGI TRANSISTOR
Q7002 KRC111S-X TRANSISTOR
Q7154 2SC2412K/R/-X TRANSISTOR
Q7158 2SC2412K/R/-X TRANSISTOR
Q7161 KRC102S-X DIGI TRANSISTOR
Q7162 KRC102S-X DIGI TRANSISTOR
Q7300 2SA1037AK/RS/-X TRANSISTOR
Q7301 KRC111S-X TRANSISTOR
Q7302 KRC110M-T TRANSISTOR
Q7320 2SA1037AK/RS/-X TRANSISTOR
Q7321 KRC111S-X TRANSISTOR
Q7330 KRC102S-X DIGI TRANSISTOR
Q7340 2SC2412K/R/-X TRANSISTOR
Q7360 2SA1037AK/RS/-X TRANSISTOR
Q7361 KRC111S-X TRANSISTOR
D2400 MTZJ11C-T2 Z DIODE
D2404 1N4003S-T5 SI DIODE
D2410 MTZJ5.6C-T2 Z DIODE
D2412 1SS119-041-T2 DIODE
D2413 MTZJ3.9B-T2 Z DIODE
D2420 MTZJ5.6A-T2 Z DIODE
D2421 MTZJ5.6C-T2 Z DIODE
D2422 1SS119-041-T2 DIODE
D7001 1SS119-041-T2 DIODE
D7002 1SS119-041-T2 DIODE
D7003 MTZJ4.7B-T2 Z DIODE
D7061 1SS119-041-T2 DIODE
D7062 1SS119-041-T2 DIODE
D7161 1SS119-041-T2 DIODE
D7300 1SS119-041-T2 DIODE
D7301 1SS119-041-T2 DIODE
D7320 1SS119-041-T2 DIODE
D7330 MTZJ6.2C-T2 Z DIODE
D7331 1SS119-041-T2 DIODE
D7340 1N4003S-T5 SI DIODE
D7350 MTZJ6.2C-T2 Z DIODE
D7351 1SS119-041-T2 DIODE
D7352 1SS119-041-T2 DIODE
D7353 1SS119-041-T2 DIODE
D7354 1SS119-041-T2 DIODE
D7370 MTZJ5.6C-T2 Z DIODE
D7371 1SS119-041-T2 DIODE
C2000 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2001 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2002 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2003 QTE1H28-106Z E CAPACITOR 10uF 50V
C2004 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2006 QTE1V06-106Z E CAPACITOR 10uF 35V
C2007 QTE1V06-106Z E CAPACITOR 10uF 35V
C2008 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2009 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2010 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2013 NCB31HK-561X C CAPACITOR 560pF 50V K
Part No. Part Name Description Local
Symbol No.
C2016 QTE1H28-105Z E CAPACITOR 1uF 50V
C2021 QTE1H28-106Z E CAPACITOR 10uF 50V
C2023 QTE1H28-106Z E CAPACITOR 10uF 50V
C2080 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C2081 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C2100 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C2101 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2102 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2103 QTE1H28-106Z E CAPACITOR 10uF 50V
C2104 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2106 QTE1V06-106Z E CAPACITOR 10uF 35V
C2107 QTE1V06-106Z E CAPACITOR 10uF 35V
C2108 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C2109 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2110 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2113 NCB31HK-561X C CAPACITOR 560pF 50V K
C2116 QTE1H28-105Z E CAPACITOR 1uF 50V
C2121 QTE1H28-106Z E CAPACITOR 10uF 50V
C2123 QTE1H28-106Z E CAPACITOR 10uF 50V
C2180 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C2181 QDXB1CM-332Y C CAPACITOR 3300pF 16V M
C2200 QETN1CM-337Z E CAPACITOR 330uF 16V M
C2201 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2202 QETN1CM-337Z E CAPACITOR 330uF 16V M
C2203 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C2204 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2220 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C2221 QETN1CM-477Z E CAPACITOR 470uF 16V M
C2222 QFLC1HJ-273Z M CAPACITOR 0.027uF 50V J
C2223 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2224 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2225 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2226 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2227 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2228 QETN1CM-106Z E CAPACITOR 10uF 16V M
C2229 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C2230 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2231 QETN1HM-684Z E CAPACITOR 0.68uF 50V M
C2232 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C2233 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2274 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2400 QETN1EM-477Z E CAPACITOR 470uF 25V M
C2401 QETN1CM-227Z E CAPACITOR 220uF 16V M
C2410 QETN1CM-477Z E CAPACITOR 470uF 16V M
C2411 QETN1AM-227Z E CAPACITOR 220uF 10V M
C2412 QETN1CM-107Z E CAPACITOR 100uF 16V M
C2413 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C2420 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C2421 QETN1CM-227Z E CAPACITOR 220uF 16V M
C2500 QETN1CM-476Z E CAPACITOR 47uF 16V M
C2603 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C7001 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7002 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7004 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C7005 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C7006 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7007 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7008 QETN0JM-227Z E CAPACITOR 220uF 6.3V M
C7009 QETN0JM-228Z E CAPACITOR 2200uF 6.3V M
C7031 NCS31HJ-220X C CAPACITOR 22pF 50V J
C7046 QCSB1HJ-220Y C CAPACITOR 22pF 50V J
C7048 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7103 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7112 NCS31HJ-330X C CAPACITOR 33pF 50V J
C7113 NCS31HJ-330X C CAPACITOR 33pF 50V J
C7180 QCBB1HK-151Y C CAPACITOR 150pF 50V K
C7181 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C7182 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C7320 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7330 NCB31HK-221X C CAPACITOR 220pF 50V K
C7331 NCB31HK-221X C CAPACITOR 220pF 50V K
C7340 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7350 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C7351 QETN1CM-476Z E CAPACITOR 47uF 16V M
C7352 QETN1AM-107Z E CAPACITOR 100uF 10V M
C7367 QETN1CM-476Z E CAPACITOR 47uF 16V M
Part No. Part Name Description Local
3-13
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C7370 NCS31HJ-100X C CAPACITOR 10pF 50V J
C7371 NCS31HJ-100X C CAPACITOR 10pF 50V J
C7372 NCS31HJ-100X C CAPACITOR 10pF 50V J
C7373 NCS31HJ-100X C CAPACITOR 10pF 50V J
C7374 NCS31HJ-100X C CAPACITOR 10pF 50V J
C7375 QETN1CM-476Z E CAPACITOR 47uF 16V M
R2000 QRE141J-303Y C RESISTOR 30kΩ 1/4W J
R2001 QRE141J-303Y C RESISTOR 30kΩ 1/4W J
R2002 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R2003 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R2004 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J
R2006 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2007 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R2010 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R2012 NRSA63J-203X MG RESISTOR 20kΩ 1/16W J
R2020 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R2021 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2022 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J
R2030 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
Ω
R2079 NRSA63J-471X MG RESISTOR 470
R2100 QRE141J-303Y C RESISTOR 30k
1/16W J
Ω
1/4W J
R2101 QRE141J-303Y C RESISTOR 30kΩ 1/4W J
R2102 NRSA63J-912X MG RESISTOR 9.1kΩ 1/16W J
R2103 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R2104 NRSA63J-622X MG RESISTOR 6.2kΩ 1/16W J
R2106 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R2107 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R2110 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R2112 NRSA63J-203X MG RESISTOR 20kΩ 1/16W J
R2120 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R2121 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R2122 NRSA63J-432X MG RESISTOR 4.3kΩ 1/16W J
R2130 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R2179 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R2200 QRE141J-471Y C RESISTOR 470Ω 1/4W J
R2201 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R2202 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R2203 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R2220 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J
R2221 NRSA63J-334X MG RESISTOR 330kΩ 1/16W J
R2222 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R2223 NRSA63J-225X MG RESISTOR 2.2MΩ 1/16W J
R2224 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R2225 NRSA63J-682X MG RESISTOR 6.8kΩ 1/16W J
R2226 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R2227 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R2228 NRSA63J-392X MG RESISTOR 3.9kΩ 1/16W J
R2229 QRE141J-101Y C RESISTOR 100Ω 1/4W J
Ω
R2410 QRE141J-122Y C RESISTOR 1.2k
1/4W J
R2411 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R2412 QRE141J-103Y C RESISTOR 10k
R2420 QRE141J-102Y C RESISTOR 1k
Ω
1/4W J
Ω
1/4W J
R2500 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R2710 QRE141J-151Y C RESISTOR 150
R2711 QRE141J-151Y C RESISTOR 150
Ω
1/4W J
Ω
1/4W J
R7001 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R7002 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R7003 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
Ω
R7004 NRSA63J-103X MG RESISTOR 10k
R7005 NRSA63J-681X MG RESISTOR 680
1/16W J
Ω
1/16W J
R7006 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
Ω
R7021 NRSA63J-103X MG RESISTOR 10k
R7030 NRSA63J-103X MG RESISTOR 10k
1/16W J
Ω
1/16W J
R7045 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
Ω
R7048 NRSA63J-222X MG RESISTOR 2.2k
R7049 NRSA63J-222X MG RESISTOR 2.2k
R7060 NRSA63J-393X MG RESISTOR 39k
R7061 NRSA63J-472X MG RESISTOR 4.7k
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R7062 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
Ω
R7102 NRSA63J-222X MG RESISTOR 2.2k
R7103 NRSA63J-222X MG RESISTOR 2.2k
1/16W J
Ω
1/16W J
R7104 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
Ω
R7105 NRSA63J-103X MG RESISTOR 10k
R7107 NRSA63J-222X MG RESISTOR 2.2k
1/16W J
Ω
1/16W J
R7108 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
Ω
R7109 NRSA63J-103X MG RESISTOR 10k
R7118 NRSA63J-102X MG RESISTOR 1k
1/16W J
Ω
1/16W J
R7119 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7120 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7121 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R7122 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7123 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
Ω
R7124 NRSA63J-222X MG RESISTOR 2.2k
R7125 NRSA63J-222X MG RESISTOR 2.2k
1/16W J
Ω
1/16W J
R7126 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R7127 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7128 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7129 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7131 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R7132 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7135 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7136 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7137 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7138 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7139 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7140 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7143 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
Ω
R7145 NRSA63J-122X MG RESISTOR 1.2k
R7146 NRSA63J-101X MG RESISTOR 100
1/16W J
Ω
1/16W J
R7147 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R7148 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R7149 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R7151 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7152 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7153 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7154 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7155 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7156 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7160 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7161 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7162 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7163 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7164 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7165 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7166 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7167 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7173 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7177 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7180 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7181 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7182 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7183 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7184 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7185 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7186 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R7187 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
Ω
R7188 NRSA63J-0R0X MG RESISTOR 0
1/16W J
R7189 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R7202 NRSA63J-563X MG RESISTOR 56k
R7203 NRSA63J-103X MG RESISTOR 10k
Ω
1/16W J
Ω
1/16W J
R7204 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R7205 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R7205 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R7206 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
Ω
R7207 NRSA63J-103X MG RESISTOR 10k
R7208 NRSA63J-103X MG RESISTOR 10k
1/16W J
Ω
1/16W J
R7228 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
Ω
R7229 NRSA63J-103X MG RESISTOR 10k
R7239 QRE141J-103Y C RESISTOR 10k
1/16W J
Ω
1/4W J
R7240 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R7252 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R7260 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
Ω
R7261 NRSA63J-123X MG RESISTOR 12k
R7262 NRSA63J-123X MG RESISTOR 12k
1/16W J
Ω
1/16W J
R7280 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
Ω
R7282 NRSA63J-473X MG RESISTOR 47k
R7283 NRSA63J-823X MG RESISTOR 82k
1/16W J
Ω
1/16W J
R7289 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
Ω
R7299 QRE141J-103Y C RESISTOR 10k
R7300 NRSA63J-102X MG RESISTOR 1k
1/4W J
Ω
1/16W J
R7301 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
Ω
R7302 NRSA63J-103X MG RESISTOR 10k
1/16W J
P450U
B,P450
UF,P45
0UN,P
450US
P450U
X
3-14
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R7320 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R7321 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7330 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R7331 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R7332 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R7333 NRSA63J-221X MG RESISTOR 220
R7340 NRSA63J-823X MG RESISTOR 82k
R7341 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R7342 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R7360 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R7361 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R7375 QRE141J-101Y C RESISTOR 100Ω 1/4W J
L2080 QQR0797-002 COIL
L2180 QQR0797-002 COIL
L2500 QQL231K-4R7Y COIL 4.7uH K
L2710 QQL231K-470Y COIL 47uH K
L2711 QQL231K-470Y COIL 47uH K
L2712 QQL231K-470Y COIL 47uH K
L7001 QQL231K-100Y COIL 10uH K
CN200 QGB2510J1-07 CONNECTOR B-B (1-7)
CN210 QGF1205C1-18 CONNECTOR FFC/FPC (1-18)
CN220 QGF1016F3-19 CONNECTOR FFC/FPC (1-19)
CN271 QGA2501C1-05 CONNECTOR W-B (1-5)
CN700 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN701 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
CN702 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN710 QGF1205C1-24 CONNECTOR FFC/FPC (1-24)
CN720 QGF1016F3-17 CONNECTOR FFC/FPC (1-17)
CN730 QGF1205C1-15 CONNECTOR FFC/FPC (1-15)
J200 QNN0420-001 SURROUND JACK
J271 QNS0170-001 HEADPHONE JACK
J280 QNB0038-001 SPK.TERMINAL
J700 QNS0089-001 3.5 JACK
K2201 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2202 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2203 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2204 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2205 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2206 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2207 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
K2271 QQR0621-001Z COIL
K2272 QQR0621-001Z COIL
K2500 QQR0621-001Z COIL
K7001 QQR0621-001Z COIL
K7300 QQR0621-001Z COIL
K7370 NQR0007-002X FERRITE BEADS
K7371 NQR0007-002X FERRITE BEADS
K7372 NQR0007-002X FERRITE BEADS
K7373 NQR0007-002X FERRITE BEADS
K7374 NQR0007-002X FERRITE BEADS
K7375 NRSA02J-0R0X MG RESISTOR 0
PP12 QZW0038-001 WIRE CLAMP
PP13 QZW0038-001 WIRE CLAMP
S700 QSW0454-001 SW
SP710 E3400-431 SPECER
X7001 QAX0718-001Z CRYSTAL 8.000000MHz
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Video board
Block No. [0][2]
Symbol No.
IC300 KIA7805API IC
IC301 MM1623XF-X IC
Q3005 KRC111S-X TRANSISTOR
C3001 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
Part No. Part Name Description Local
P450A,
P450U
B,P450
UN,P4
50US,
P450U
X
C3002 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3003 QFLC1HJ-103Z M CAPACITOR 0.01uF 50V J
C3004 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3005 QCBB1HK-104Y C CAPACITOR 0.1uF 50V K
C3006 QETN1AM-477Z E CAPACITOR 470uF 10V M
C3007 QETN1CM-226Z E CAPACITOR 22uF 16V M
C3010 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C3011 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3012 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C3013 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C3014 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3015 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3016 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3017 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3018 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3019 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3020 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3021 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3022 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3023 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3024 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C3025 NCS31HJ-181X C CAPACITOR 180pF 50V J
C3031 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
R3006 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3007 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3008 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3009 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3010 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3011 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R3021 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R3022 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R3023 NRSA63J-181X MG RESISTOR 180Ω 1/16W J
R3024 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R3025 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R3026 NRSA63J-271X MG RESISTOR 270Ω 1/16W J
R3027 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R3028 NRSA63J-910X MG RESISTOR 91Ω 1/16W J
R3029 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R3030 NRSA63J-910X MG RESISTOR 91Ω 1/16W J
R3031 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
CN300 QGF1205F1-24 CONNECTOR FFC/FPC (1-24)
CN301 QGA2501F1-02 CONNECTOR W-B (1-2)
JA301 QNZ0697-001 RGB CONNECTOR
JA302 QNN0434-001 PIN JACK
PP300 QZW0038-001 WIRE CLAMP
Power board
Block No. [0][3]
Symbol No.
IC411 LA4628 IC
IC440 LB1641 IC
IC750 NJU6433FG1 LCD DRIVER
IC760 GP1UM261XKVF IR DETECT UNIT 38kHz
Q1001 KTC3199/GL/-T TRANSISTOR
Q1002 KTC1027/OY/-T TRANSISTOR
Q1003 2SD1266/P/ TRANSISTOR
Q4121 2SC3576-JVC-T TRANSISTOR
Q4122 2SC3576-JVC-T TRANSISTOR
Q4123 KRA102M-T DIGI TRANSISTOR
Q4131 KRA109M-T DIGI TRANSISTOR
Q4132 KRA109M-T DIGI TRANSISTOR
Q4133 KRA109M-T DIGI TRANSISTOR
Q4134 KRA109M-T DIGI TRANSISTOR
Q4135 KRC109M-T DIGI TRANSISTOR
Q4301 KTC3199/GL/-T TRANSISTOR
Q4302 KTC3199/GL/-T TRANSISTOR
Q4303 KTA1046/Y/ TRANSISTOR
Part No. Part Name Description Local
P450U
N,P45
0US,P
450UX
3-15
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
Q7600 KRC111M-T TRANSISTOR
D1001 1N5401-TM SI DIODE
D1002 1N5401-TM SI DIODE
D1003 1N5401-TM SI DIODE
D1004 1N5401-TM SI DIODE
D1005 6A10E2 SI DIODE
D1006 6A10E2 SI DIODE
D1007 6A10E2 SI DIODE
D1008 6A10E2 SI DIODE
D1013 MTZJ6.2C-T2 Z DIODE
D1014 1N4003S-T5 SI DIODE
D1015 1SS119-041-T2 DIODE
D1018 MTZJ11C-T2 Z DIODE
D4001 2A02-M DIODE
D4002 1SS119-041-T2 DIODE
D4301 MTZJ5.1C-T2 Z DIODE
D4401 MTZJ5.6A-T2 Z DIODE
D7500 SELU1E54CM-S LED
D7600 SELU2E10C-P LED
D7601 SPR-39MVWF LED RED-GREEN
D7602 1SS119-041-T2 DIODE
D7603 1SS119-041-T2 DIODE
D7604 MTZJ10C-T2 Z DIODE
C1001 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1002 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1003 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1004 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1005 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1006 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1007 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1008 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1013 QDXB1CM-472Y C CAPACITOR 4700pF 16V M
C1014 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
C1015 QETM1EM-108 E CAPACITOR 1000uF 25V M
C1015 QETN1JM-477Z E CAPACITOR 470uF 63V M
C1016 QCZ9105-472 C CAPACITOR 4700pF 250V M
C1017 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C4001 QETM1EM-478 E CAPACITOR 4700uF 25V M
C4002 QETM1EM-478 E CAPACITOR 4700uF 25V M
C4101 QETM1EM-828 E CAPACITOR 8200uF 25V M
C4102 EETC1CM-107ZJC E CAPACITOR
C4103 QTE1H28-105Z E CAPACITOR 1uF 50V
C4107 QETN1CM-336Z E CAPACITOR 33uF 16V M
C4108 QTE1H28-105Z E CAPACITOR 1uF 50V
C4109 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C4110 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C4111 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4112 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4113 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4114 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4115 QETN1EM-107Z E CAPACITOR 100uF 25V M
C4117 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C4118 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C4121 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4131 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C4132 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C4301 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C4302 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C4401 QCFB1HZ-104Y C CAPACITOR 0.1uF 50V Z
C4402 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C4403 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4600 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7500 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C7600 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C7601 QERF1CM-476Z E CAPACITOR 47uF 16V M
C7602 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7603 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
P450U
N,P45
0US,P
450UX
P450A
,P450
UB,P4
50UF
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
R1001 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R1002 QRE141J-821Y C RESISTOR 820Ω 1/4W J
R1004 QRZ9042-2R2X F RESISTOR 2.2
Ω
R1005 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R1006 QRE141J-822Y C RESISTOR 8.2kΩ 1/4W J
R4101 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R4102 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R4103 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R4104 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R4105 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R4106 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R4107 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R4108 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
Ω
R4121 QRE141J-222Y C RESISTOR 2.2k
R4122 QRE141J-222Y C RESISTOR 2.2k
1/4W J
Ω
1/4W J
R4123 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R4131 QRE141J-433Y C RESISTOR 43kΩ 1/4W J
R4132 QRE141J-433Y C RESISTOR 43kΩ 1/4W J
R4133 QRE141J-433Y C RESISTOR 43kΩ 1/4W J
R4134 QRE141J-433Y C RESISTOR 43kΩ 1/4W J
R4301 QRE141J-681Y C RESISTOR 680Ω 1/4W J
R4302 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J
R4303 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R4304 QRE141J-681Y C RESISTOR 680Ω 1/4W J
R4305 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R4306 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R4307 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R7500 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R7501 QRE141J-134Y C RESISTOR 130kΩ 1/4W J
R7502 QRE141J-241Y C RESISTOR 240Ω 1/4W J
R7600 QRE141J-221Y C RESISTOR 220Ω 1/4W J
R7601 QRE141J-161Y C RESISTOR 160Ω 1/4W J
R7602 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R7603 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R7604 QRE141J-122Y C RESISTOR 1.2kΩ 1/4W J
R7605 QRE141J-182Y C RESISTOR 1.8kΩ 1/4W J
R7606 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R7607 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J
R7609 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R7610 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
Ω
R7611 QRE141J-122Y C RESISTOR 1.2k
R7612 QRE141J-182Y C RESISTOR 1.8k
R7613 QRE141J-222Y C RESISTOR 2.2k
1/4W J
Ω
1/4W J
Ω
1/4W J
R7614 QRE141J-272Y C RESISTOR 2.7kΩ 1/4W J
L4401 QQL244K-100Z COIL 10uH K
L4402 QQL244K-100Z COIL 10uH K
T1002 QQT0253-002 SUB TRANS
T1002 QQT0370-011 SUB TRANS
CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
CN103 QGA3901C1-05 CONNECTOR W-B (1-5)
CN104 QGB2510J1-10 CONNECTOR B-B (1-10)
CN105 QGA7901C1-04 CONNECTOR W-B (1-4)
CN401 QGB2510K2-07 CONNECTOR B-B (1-7)
CN402 QGF1205C1-18 CONNECTOR FFC/FPC (1-18)
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
P450A
,P450
UF,P4
50UB
P450U
N,P45
0US,P
450UX
P450A
,P450
UB,P4
50UF
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
3-16
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
CN403 QGB2510K2-10 CONNECTOR B-B (1-10)
CN404 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
CN750 QGF1205F1-15 CONNECTOR FFC/FPC (1-15)
CN751 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
CN760 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
DI750 QLD0312-001 LCD MODULE
JS760 QSW1060-001 ROTARY SW
RY101 QSK0124-001 RELAY
S1001 QSW0812-001 VOLTAGE SWITCH
S7600 QSW0825-001Z TACT SW
S7601 QSW0825-001Z TACT SW
S7602 QSW0825-001Z TACT SW
S7603 QSW0825-001Z TACT SW
S7604 QSW0825-001Z TACT SW
S7605 QSW0825-001Z TACT SW
S7606 QSW0825-001Z TACT SW
S7607 QSW0825-001Z TACT SW
S7608 QSW0825-001Z TACT SW
S7609 QSW0825-001Z TACT SW
S7610 QSW0825-001Z TACT SW
S7611 QSW0825-001Z TACT SW
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
Z1004 QNG0003-001Z FUSE CLIP
Z1005 QNG0003-001Z FUSE CLIP
Z1006 QNG0003-001Z FUSE CLIP
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
DVD loading switch board
Block No. [0][4]
Symbol No.
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
Part No. Part Name Description Local
DVD servo board
Block No. [0][5]
Symbol No.
IC201 LA6502-X IC
IC301 MN2DS0003AA-H IC
IC302 LM1117MP-ADJ-X IC
IC453 S-80827CNNB-W IC
IC505 K4S641632F-TC75 IC(DIGITAL)
IC505 or K4S641632H-TC75 IC(DIGITAL)
IC505 or HY57V641620HGT7 IC
IC509 AT49LV1614T90TC IC (FLASH)
IC701 AK4384VT-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
Part No. Part Name Description Local
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
P450U
N,P45
0US,P
450UX
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C111 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C208 NCB31HK-561X C CAPACITOR 560pF 50V K
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C212 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C253 NCB31HK-561X C CAPACITOR 560pF 50V K
C255 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB21CK-105X C CAPACITOR 1uF 16V K
C325 NDC31HJ-180X C CAPACITOR 18pF 50V J
C326 NDC31HJ-150X C CAPACITOR 15pF 50V J
C327 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB21CK-105X C CAPACITOR 1uF 16V K
C341 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C349 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C350 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C356 NCB21CK-105X C CAPACITOR 1uF 16V K
C359 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C371 NCB21CK-105X C CAPACITOR 1uF 16V K
C391 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C455 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C551 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C552 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C553 NBE20JM-226X TA E CAPACITOR 22uF 6.3V M
C554 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C555 NCB31CK-104X C CAPACITOR 0.1uF 16V K
3-17
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C556 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C557 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C558 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C559 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C701 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C704 NEA70JM-227X E CAPACITOR 220uF 6.3V M
C706 NEA71CM-106X E CAPACITOR 10uF 16V M
C707 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C721 NCB31HK-102X C CAPACITOR 1000pF 50V K
C902 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C903 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C904 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C906 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R101 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R102 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R103 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R104 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R105 NRS125J-270X MG RESISTOR 27Ω 1/2W J
R106 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R107 NRSA63J-101X MG RESISTOR 100
R108 NRSA63J-471X MG RESISTOR 470
R109 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R110 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R111 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R112 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R113 NRS125J-270X MG RESISTOR 27Ω 1/2W J
R114 NRSA63J-2R2X MG RESISTOR 2.2Ω 1/16W J
R115 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R116 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R117 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R118 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R120 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R122 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R123 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R125 NRS125J-1R0X MG RESISTOR 1Ω 1/2W J
R126 NRSA02J-181X MG RESISTOR 180Ω 1/10W J
R128 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R204 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R205 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R206 NRSA63J-303X MG RESISTOR 30kΩ 1/16W J
R207 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R208 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R213 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R214 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R215 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R219 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R220 NRSA63J-243X MG RESISTOR 24kΩ 1/16W J
R221 NRSA63J-682X MG RESISTOR 6.8k
R251 NRS125J-R47X MG RESISTOR 0.47Ω 1/2W J
R252 NRSA63J-2R2X MG RESISTOR 2.2
R254 NRSA63J-203X MG RESISTOR 20k
R255 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R257 NRSA63J-0R0X MG RESISTOR 0
R259 NRSA63J-103X MG RESISTOR 10k
R302 NRSA63J-240X MG RESISTOR 24Ω 1/16W J
R303 NRSA63J-270X MG RESISTOR 27
R306 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R307 NRSA63J-102X MG RESISTOR 1k
R308 NRSA63J-223X MG RESISTOR 22k
R309 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R310 NRS125J-R47X MG RESISTOR 0.47
R312 NRSA63J-0R0X MG RESISTOR 0
R313 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R314 NRSA63J-0R0X MG RESISTOR 0
R315 NRSA63J-0R0X MG RESISTOR 0
R316 NRSA63J-0R0X MG RESISTOR 0
R317 NRSA63J-0R0X MG RESISTOR 0
R318 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R319 NRSA63J-0R0X MG RESISTOR 0
R320 NRSA63J-103X MG RESISTOR 10k
R322 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R323 NRSA63J-0R0X MG RESISTOR 0
R325 NRSA63J-331X MG RESISTOR 330
R326 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R333 NRSA63J-163X MG RESISTOR 16k
R334 NRSA63J-151X MG RESISTOR 150
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R335 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R336 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R337 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R338 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R339 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R340 NRSA63D-303X MG RESISTOR 30k
R341 NRSA63D-362X MG RESISTOR 3.6k
R342 NRSA63D-222X MG RESISTOR 2.2kΩ 1/16W D
R343 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R345 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R351 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R352 NRSA63J-105X MG RESISTOR 1MΩ 1/16W J
R357 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R358 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R361 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R362 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R363 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R372 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R373 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R378 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R379 NRSA63J-102X MG RESISTOR 1k
R384 NRSA63J-102X MG RESISTOR 1k
R385 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R390 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R391 NAD0025-103X N THERMISTOR 10k
R392 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R393 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R394 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R395 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
R457 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R458 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R501 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R502 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R510 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R551 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R553 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R554 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R555 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R556 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R557 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R558 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R701 NRSA63J-1R0X MG RESISTOR 1Ω 1/16W J
R702 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R710 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R711 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R712 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R713 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R716 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R718 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R719 NRSA63J-0R0X MG RESISTOR 0
R723 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R724 NRSA63J-101X MG RESISTOR 100
R725 NRSA63J-101X MG RESISTOR 100
R727 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R728 NRSA63J-0R0X MG RESISTOR 0
R909 NRSA02J-0R0X MG RESISTOR 0
R911 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J
L501 NQL044K-100X COIL 0.20
CN101 QGF0523F1-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN501 QGF1016F2-19W CONNECTOR FFC/FPC (1-19)
CN502 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN503 QGF1016F2-17W CONNECTOR FFC/FPC (1-17)
K101 NRSA02J-0R0X MG RESISTOR 0
K102 NRSA02J-0R0X MG RESISTOR 0
K301 NQR0354-001X FERRITE BEADS
K302 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
K303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
K551 NQR0129-002X FERRITE BEADS
K552 NQR0129-002X FERRITE BEADS
K553 NQR0129-002X FERRITE BEADS
K554 NQR0129-002X FERRITE BEADS
K555 NQR0022-005X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K721 NQR0251-004X FERRITE BEADS
K722 NQR0251-004X FERRITE BEADS
Ω
1/16W D
Ω
1/16W D
Ω
1/16W J
Ω
1/16W J
Ω
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/10W J
Ω
10uH K
Ω
1/10W J
Ω
1/10W J
3-18
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
K723 NQR0251-004X FERRITE BEADS
X351 NAX0550-001X CRYSTAL 27.000MHz
Cassette switch board
Block No. [0][6]
Symbol No.
IC1 SG-105F3-BB,C PHOTO SENSER
D1 1SR139-400-T2 SI DIODE
R371 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
VR37 QVP0077-103Z TRIM RESISTOR 10k
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
Part No. Part Name Description Local
Ω
Head amp. board
Block No. [0][7]
Symbol No.
IC32 HA12238F IC R/P Equalizer
IC33 CD4094BC IC
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
Part No. Part Name Description Local
C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C306 FQETJ1AM-227Z E CAPACITOR
C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C340 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C341 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C342 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
Ω
R101 QRE141J-512Y C RESISTOR 5.1k
R102 QRE141J-512Y C RESISTOR 5.1k
R104 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R105 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R106 QRE141J-113Y C RESISTOR 11kΩ 1/4W J
R107 QRE141J-912Y C RESISTOR 9.1kΩ 1/4W J
R108 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R110 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R116 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R121 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R201 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J
R202 QRE141J-512Y C RESISTOR 5.1kΩ 1/4W J
R204 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R205 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R206 QRE141J-113Y C RESISTOR 11kΩ 1/4W J
R207 QRE141J-912Y C RESISTOR 9.1kΩ 1/4W J
R208 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R210 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R216 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R221 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R301 QRE141J-221Y C RESISTOR 220Ω 1/4W J
R302 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R303 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R304 QRJ146J-101X UNF C RESISTOR 100Ω 1/4W J
R305 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R306 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R310 QRJ146J-4R7X UNF C RESISTOR 4.7Ω 1/4W J
R313 QRE141J-2R2Y C RESISTOR 2.2Ω 1/4W J
R314 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R315 QRE141J-101Y C RESISTOR 100
R327 QRE141J-474Y C RESISTOR 470kΩ 1/4W J
R335 QRE141J-222Y C RESISTOR 2.2k
R336 QRE141J-223Y C RESISTOR 22k
R337 QRE141J-332Y C RESISTOR 3.3kΩ 1/4W J
R338 QRE141J-392Y C RESISTOR 3.9k
R339 QRE141J-104Y C RESISTOR 100k
R340 QRE141J-681Y C RESISTOR 680Ω 1/4W J
R341 QRE141J-123Y C RESISTOR 12k
R342 QRE141J-243Y C RESISTOR 24kΩ 1/4W J
R343 QRE141J-183Y C RESISTOR 18k
R344 QRE141J-472Y C RESISTOR 4.7k
R345 QRE141J-472Y C RESISTOR 4.7kΩ 1/4W J
R346 QRE141J-472Y C RESISTOR 4.7k
R347 QRE141J-103Y C RESISTOR 10k
R353 QRZ9005-100X FUSI RESISTOR 10
R372 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R375 QRE141J-151Y C RESISTOR 150
R376 QRE141J-472Y C RESISTOR 4.7k
VR31 QVP0008-203Z TRIM RESISTOR 20k
L301 QQR1118-002 OSC COIL(BIAS)
L303 QQL244K-100Z COIL 10uH K
CN31 QGF1205F1-06 CONNECTOR FFC/FPC (1-6)
CN32 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN33 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN34 QGF1201F3-10 CONNECTOR FFC/FPC (1-10)
H32 GV40397-002A IC HOLDER
Ω
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
Ω
1/4W J
Ω
1/4W J
Ω
Ω
Ω
1/4W J
Ω
Ω
1/4W J
Ω
Ω
1/4W J
1/4W J
1/4W J
1/4W J
1/4W J
1/4W J
1/4W J
1/4W J
3-19
Packing materials and accessories parts list
(UF only)
P4
P14
P3
P4
P6
P12
Block No.
M
M
3
(A,US,UB,UX,UN only)
P9
M
P5
P1
A1, A2, A3, A4,
A5, A6, A7, A8,
A9,
A10, A11,
A17, A18A13,
P13
A15
A14
A15
P11
P8
P7
A16
P10
A12
3-20
P2
Packing and Accessories
Block No. [M][3][M][M]
Symbol No. Part No. Part Name Description Local
A 1 GVT0129-014A INST BOOK ENG P450A
A 1 GVT0129-013A INST BOOK ENG CHI(PEKIN) P450UB
A 1 GVT0129-011A INST BOOK CHI(PEKIN) P450UF
A 1 GVT0129-008A INST BOOK ENG CHI(PEKIN) P450UN,P450US
A 1 GVT0129-009A INST BOOK ENG ARA PER P450UX
A 2 QAL0014-001 AM LOOP ANT
A 3 QAL0457-001 ANT.WIRE
A 4 RM-SUXP450U REMOCON
A 5 ------------------- BATTERY (x2)
A 6 QAM0216-001 SIGNAL CORD
A 7 QAM0112-002 PLUG ADAPTOR P450UN,P450US
A 8 BT-56012-1 WARRANTY CARD P450A
A 8 BT-59019-1 WARRANTY CARD P450UF
A 9 GV30024-042A UB SHEET P450UB
A 10 QAM0027-002 CONVERSION PLUG P450UX
A 11 BT-59021-2 SVC CENTRE LIST P450UF
A 12 GV30380-009A UF CARTON LABEL P450UF
A 13 GN30020-003A SURVEY CARD P450UF
A 14 UXP450K-SPBOX SPK WITH BOX (x2) P450UF
A 15 9910007711 NET ASSY (x2) P450UF
A 16 UXP450UN-SPBOX SPK WITH BOX (x2) P450A,P450UN,P450UN,P450US,P450UX
A 17 BT-59020-1 SEAL P450UF
A 18 E310162-001 CERTIFICATE TAG P450UF
P 1 QPC02503515P POLY BAG 25cm x 35cm
P 2 GV20268-002A CARTON ASSY. P450A
P 2 GV20306-201A CARTON ASSY. P450UF
P 2 GV20268-001A CARTON ASSY. P450UB,P450UN,P450US
P 2 GV20268-004A CARTON ASSY. P450UX
P 3 GV40168-009A MIRAMA SHEET
P 4 GV10196-201A CUSHION(FRONT) P450UF
P 4 GV10196-001A CUSHION(FRONT) P450A,P450UB,P450UN,P450US,P450UX
P 5 GV10197-201A CUSHION(REAR) P450UF
P 5 GV10197-001A CUSHION(REAR) P450A,P450UB,P450UN,P450US,P450UX
P 6 QPC05006515P POLY BAG 50cm x 65cm
P 7 UP4-KS-00-01 MIRROR MAT (x2) P450A,P450UN,P450UN,P450US,P450UX
P 8 UP4-KO-00-01 POLY BAG (x2) P450A,P450UN,P450UN,P450US,P450UX
P 9 UP4-KF-01-01 CUSHION(TOP) P450A,P450UN,P450UN,P450US,P450UX
P 10 UP4-KF-02-01 CUSHION(BOTTOM) P450A,P450UN,P450UN,P450US,P450UX
P 11 8000055311 CUSHION(BOTTOM) (x2) P450UF
P 12 8000055301 CUSHION(TOP) (x2) P450UF
P 13 8500041601 POLY BAG (x2) P450UF
P 14 GV40237-205A CARTON SPACER P450UF
