IR COLOR CAMERA
TK-C8301RU
Serial No.
Model No.
Enter below the Serial No. which is located
on the body. Retain this information for future
reference.
For Customer Use of TK-C8301RU :
TK-C8301RU
(For USA and Canada)
TK-C8301RE
(For Europe)
INSTRUCTIONS
LST1407-001A
FOR USA
These are general IMPORTANT SAFEGUARDS and certain items
may not apply to all appliances.
1. Read all of these instructions.
2. Save these instructions for later use.
3.
4.
5.
6.
7.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3125A
IMPORTANT SAFEGUARDS
All warnings on the product and in the operating instructions should
be adhered to.
Unplug this appliance system from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
Do not use attachments not recommended by the appliance
manufacturer as they may cause hazards.
Do not use this appliance near water - for example, near a bathtub,
washbowl, kitchen sink, or laundry tub, in a wet basement, or near
a swimming pool, etc.
Do not place this appliance on an unstable cart,
stand, or table. The appliance may fall, causing
serious injury to a child or adult, and serious
damage to the appliance. Use only with a cart or
stand recommended by the manufacturer, or sold
with the appliance. Wall or shelf mounting should
follow the manufacturer’s instructions, and should
use a mounting kit approved by the manufacturer.
An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.
Introduction
Safety Precautions
.
E-2
8.
Slots and openings in the cabinet and the back or bottom are
provided for ventilation, and to insure reliable operation of the
appliance and to protect it from overheating, these openings must
not be blocked or covered. The openings should never be blocked
by placing the appliance on a bed, sofa, rug, or other similar
surface. This appliance should never be placed near or over
a radiator or heat register. This appliance should not be placed in
a built-in installation such as a bookcase unless proper ventilation
is provided.
9.
10.
This appliance should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power supplied to your home, consult your dealer or local
power company. For appliance designed to operate from battery
power, refer to the operating instructions.
For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the product due to lightning
and power-line surges.
11.
12.
Follow all warnings and instructions marked on the appliance.
13.
Do not allow anything to rest on the power cord. Do not locate this
appliance where the cord will be abused by persons walking on it.
Do not overload wall outlets and extension cords as this can result
in fire or electric shock.
15.
Do not attempt to service this appliance yourself as opening or
removing covers may expose you to dangerous voltage or other
hazards. Refer all servicing to qualified service personnel.
14.
Never push objects of any kind into this appliance through
cabinet slots as they may touch dangerous voltage points or
short out parts that could result in a fire or electric shock. Never
spill liquid of any kind on the appliance.
.
<Continued on the following page>
Introduction
E-3
d.
e.
f.
17.
18.
If the appliance does not operate normally by following the
operating instructions. Adjust only those controls that are
covered by the operating instructions as improper adjustment
of other controls may result in damage and will often require
extensive work by a qualified technician to restore the
appliance to normal operation.
If the appliance has been dropped or the cabinet has been
damaged.
When the appliance exhibits a distinct change in performance
- this indicates a need for service.
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer that have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock
or other hazards.
Upon completion of any service or repairs to this appliance, ask
the service technician to perform routine safety checks to
determine that the appliance is in safe operating condition.
16.
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the appliance.
c. If the appliance has been exposed to rain or water.
Unplug this appliance from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
Introduction
Safety Precautions (Continued)
.
E-4
The lightning flash wish arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated "dangerous voltage" within
the product's enclosure that age" within the product's
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
FOR USA AND CANADA
Introduction
.
E-5
Information for USA
CAUTION
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
CHANGES OR MODIFICATIONS NOT APPROVED BY
JVC KENWOOD Corporation COULD VOID USER'S AUTHORITY
TO OPERATE THE EQUIPMENT.
INFORMATION (FOR CANADA)
RENSEIGNEMENT (POUR CANADA)
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Introduction
Safety Precautions (Continued)
.
E-6
FOR EUROPE
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
To prevent electric shock, do not open the cabinet.
No user serviceable parts inside. Refer servicing to qualified service
personnel.
Dear Customer
This apparatusis in conformance with the valid European directives
and standards regarding electromagnetic compatibility and electrical
safety.
European representative of JVC KENWOOD Corporation is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany
Introduction
.
E-7
Information for Users on Disposal of Old Equipment
[European Union]
Attention:
This symbol is
only valid in
the European
Union.
This symbol indicates that the electrical and electronic
equipment should not be disposed as general
household waste at its end-of-life.
Instead, the product should be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment for proper
treatment, recovery and recycling in accordance with
your national legislation.
By disposing of this product correctly, you will help to
conserve natural resources and will help prevent
potential negative effects on the environment and
human health which could otherwise be caused by
inappropriate waste handling of this product.
For more information about collection point and
recycling of this product, please contact your local
municipal office, your household waste disposal
service or the shop where you purchased the product.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
(Business users)
If you wish to dispose of this product, please visit our web page
http://www.jvc.eu to obtain information about the take-back of the
product.
[Other Countries outside the European Union]
If you wish to dispose of this product, please do so in accordance with
applicable national legislation or other rules in your country for the
treatment of old electrical and electronic equipment.
Introduction
Safety Precautions (Continued)
.
E-8
Introduction
(For USA and Europe)
v
The unit is to be powered by a DC 12 V or an AC 24 V power supply.
v
The unit is to be powered by a UL Listed DC 12 V or an AC 24 V
power supply. (For USA)
v
The AC 24 V and 12 V DC power supply shall conform to the
following: Class 2 only (For USA), Isolated power supply only (For
Europe).
v
This installation should be made by a qualified service person and
should conform to all local codes.
v
This installation shall be in accordance with the National Electrical
Code, ANSI/NFPA 70.
v
Any Mention in this manual of Alarm inputs have not been evaluated
by UL to be used for Burglar Alarm Functionality.
v
Special technique is required when installing this product. Please
refer to your dealer for installation.
v
Rating label is pasted on of the camera unit.
v
JVC KENWOOD Corporation is not liable for any compensation if you
drop the camera due to insecure mounting by not following the
installation description. Pay careful attention during installation.
v
When mounting this product to a ceiling or wall, select a location
strong enough to support the weight of this camera. If the location is
not strong enough to support the weight, be sure to reinforce the
ceiling or wall before installation.
v
The camera may drop if the mounting screws are not tightened
securely. Check that the screws are tightened appropriately and
securely.
v
Do not install the camera near lighting fixtures of high temperature,
such as spot lights. It might result in failure or fires.
v
Do not step on or hang on the camera. Doing so may cause the
camera to fall, and break, which would cause injuries.
E-9
Contents
Contents
Introduction
Safety Precautions ............................................................................ 2
Contents .......................................................................................... 10
Features .......................................................................................... 11
Operating Precautions ..................................................................... 12
Name of Parts .................................................................................. 15
Connection/Installation
Connection ...................................................................................... 17
Mounting the Camera ...................................................................... 20
Setting/Adjustment
Switch Settings ................................................................................ 22
Adjusting Image ............................................................................... 23
Checking after Operation ................................................................. 25
Adjusting the Auto White Balance ................................................... 26
Menu Setting
The Flow of Menu Screen ............................................................... 28
Menu Setting Procedure .................................................................. 30
BASIC MENU .................................................................................. 31
ADVANCED MENU ......................................................................... 33
Setting Examples
Manual Adjustment of White Balance .............................................. 41
Setting the Privacy Mask ................................................................. 42
Settings in Dark Locations ............................................................... 43
Others
Specifications .................................................................................. 46
E-10
Introduction
Thank you for purchasing this product.
Before use, please read this “INSTRUCTIONS” and the information
materials included to ensure proper use of this product.
The instructions in this manual for TK-C8301RU and TK-C8301RE.
Features
v
Wide dynamic range (WIDE-D) function
v
DAY/NIGHT surveillance with auto IR cut filter on/off (Color/Black and
White shooting)
v
Built in high reliability IR LED
v
3D noise reduction (3DNR)
v
4 areas privacy mask
v
Built-in display mode (CRT or LCD selectable)
How to Read This Manual
Conventions and symbols
: Indicates operating precautions.
Note
: Indicates reference data regarding limitations on
Memo
functions, usage and the like.
A
Contents of this manual
v
v
v
:
Indicates a reference page or item.
JVC KENWOOD Corporation holds the copyright to this manual.
Any part or all of this manual may not be reproduced without prior
consent from the company.
Product names of other companies described in this manual are
trademarks or registered trademarks of the respective companies.
Symbols such as E, T, and © are omitted in this manual.
Design, specifications and other contents described in this manual
are subject to change for improvements without prior notice.
E-11
Introduction
Operating Precautions
m
Storage and Location of Use
v
Do not install the camera in the following places.
- In a place exposed to rain or moisture.
- In a place with vapor or oil, for example in a kitchen.
- When the ambient temperature rises above or falls below the
acceptable range (from -10 f to 50 f)
- In a place at which corrosive gases are emitted.
- Near a source of radiation, X-rays, strong radio waves or
magnetism.
- In a place, such as vehicle installation, which is subject to vibration.
- In a place with excessive dirt.
v
Using this unit in the vicinity of the transmitting antenna of a radio or
TV, devices that emit strong electromagnetic waves such as a
transformer or motor, or wireless devices such as a transceiver or
mobile phone may give rise to noises in the image and changes in its
color.
v
This camera has been designed for indoor use. When using it
outdoors, it is necessary to use an outdoor camera housing
(optional).
m
Maintenance
v
Wipe the camera with a dry, soft cloth to remove any dirt.
Do not use benzene or thinner to wipe the camera. Doing so may
melt the surface or cause it to fog. For tough stains, wipe with a
neutral detergent diluted with water, followed by wiping with a dry
cloth.
v
Replace the IR LED unit every 3 years if it is used for 8 hours per
day.
m
Energy Conservation
v
When the camera is not in use for a long time, turn off the power for
safety and energy conservation reasons.
E-12
Introduction
m
Copyright Protection
v
With the exception of the user being the copyright holder or when
permission such as for duplication has been granted by the copyright
holder, permission is required in principle for the duplication,
modification, or transmission of copyrighted material.
v
Unauthorized duplication, modification, or transmission of copyrighted
material may constitute a copyright infringement, and the user may
be liable to compensate for any damages. When using copyrighted
material, be sure to check the license agreement of the copyrighted
material thoroughly.
v
When rights or rights holders are involved with regard to the targeted
duplicating subject, permission may be required for shooting or using
(processing) it. Be sure to check the licensing conditions thoroughly.
m
Disclaimer
v
Motion detection is not a feature to prevent theft or fire. We do not
accept liability for any damages that may occur.
v
We will not be responsible for any inconveniences or disturbances
caused in the event of privacy invasion as a result of camera
footages of this product.
m
Others
v
When using this camera with [AGC] set to “MID” or “HIGH”, the
sensitivity increases automatically for dark images and the screen
may appear grainy, but this is not a malfunction.
v
When the DAY & NIGHT selector switch is set to “AUTO”, the image
turns black-and-white in a dark location. As the sensitivity level is
increased in this case, the screen may appear grainy and more white
spots may appear. When switching between modes, the brighter area
on the screen is emphasized and visibility may be reduced. However,
this is not a malfunction.
<Continued on the following page>
E-13
Introduction
Operating Precautions (Continued)
v
When shooting an extremely bright object (e.g. lamp), the image on
the screen may have white vertical tailings (smear) or expansion
(blooming) may appear around it. This is a characteristic of the CCD
and not a malfunction.
v
When the white balance of this camera is set to “ATW-N” or “ATW-W”
and depending on the conditions of the object, the color tone may
differ slightly from the actual color due to the principle of the
automatic tracking white balance circuit. This is not a malfunction.
v
When this camera is used under high temperatures, vertical stripes
may appear on the screen. This is a characteristic of the CCD and
not a malfunction.
v
When this camera is moved from a cold to warm place, condensation
may occur and the camera may not work. In this case, leave the
camera under room temperature for about one hour before turning on
the power.
v
When the power supply voltage is momentarily disrupted or drops
due to lightning, turning on the air-conditioner or the like, image
distortion or noise may occur.
v
When the power supply voltage of the camera drops, the input
protection circuit inside the camera operates, and the camera may be
turned off. Make use of a voltage rating within ±10 % for the camera’s
power supply voltage.
v
The 3D noise reduction function of this camera may result in
afterimage of a moving subject. Afterimage is more likely to occur
when using the camera with [DNR LEVEL] set to “HIGH”. This is not
a malfunction.
E-14
Name of Parts
SET
MANUAL
SEE INSTRUCTION
GNDAUX
ONLY (E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
MENU
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
DC12V
AC24V
12
ADJUST
FOCUS
F
GH IJ
K
L
M
BC DAE
<Rear>
Camera
.
A Camera-mounting bracket
(A page 20)
B Rotation-preventive hole
(A page 20)
C Camera-mounting bracket
fastening screws
(M2.6 x 6 mm)
(A page 20)
D Camera-mounting screw hole
(A page 20)
E Lens Cover
(A page 23)
Introduction
F Power Supply Terminal
(A page 17)
G Selector Switch
(A page 22)
H Alarm Input/Output Terminal
(A page 19)
I [VIDEO OUT] Monitor
Terminal
(A page 18)
J [J / K / H / I] Button
(A page 22, 26, 30)
K
[SET] Button
(A page 26, 30)
L
[MENU] Button
(A page 26, 30)
M
Fall Prevention Wire Screw
(M3 x 6mm)
(A page 21)
E-15
B
C
A
Bottom of the camera
(main unit)
<Figure showing when the lens cover is removed>
Introduction
Name of Parts (Continued)
Camera (Interior)
A Gear for Focus Adjustment
(A page 24)
B Knob
(A page 24)
C Zoom Adjustment Ring
(A page 24)
.
E-16
SET
MANUAL
SEE INSTRUCTION
GNDAUX
ONLY (E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
MENU
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
DC12V
AC24V
12
ADJUST
FOCUS
(A
Connect to AC 24V or DC 12V
power supply
To the terminal of door switch etc.
page 18)
Monitor
Connection/Installation
Connection
.
Connecting the Power Supply Cable
When power is supplied to the camera, the [POWER] lamp on the side
panel lights up.
m
AC24 V or DC12 V
To prevent connection errors or a cable disconnection, use a lug plate
to connect to the terminal. The following table shows the connection
distances when 2-core VVF (vinyl-insulated vinyl sheath cables) are
used. (Reference value)
Conductor diameter
Maximum connection
distance: DC 12 V
Maximum connection
distance: AC 24 V
(mm)
Φ 1.0 and
more
Φ 1.6 and
more
50 m 140 m 220 m
130 m 350 m 550 m
<Continued on the following page>
Φ 2.0 and
more
E-17
Connection/Installation
Connection (Continued)
v
Memo
Connecting the Monitor
Connect with a 75 K coaxial cable (BNC) such as RG-59 or equivalent.
If thin cables are used, the resistance of the cables will be
high and a significant voltage drop will occur when the
camera is at its maximum power consumption. Either use a
thick cable with low resistance or place the power supply
near to the camera and shorten the length of the cable to
restrict the voltage drop at the rated current of camera to
below 10 %. If voltage drop occurs during operation, the
performance will be unstable.
v
Do not connect an AC 24 V cable to a commercial power
supply. If it is connected by mistake, the internal circuit may
be damaged. Sent the camera to the nearest JVC service
center for inspection as the internal circuit may be damaged.
v
Do not connect DC 12 V and AC 24 V cables at the same
time.
v
When using a DC 12 V power supply, ensure that the
polarities of the cable are correct.
E-18
MANUAL
SEE INSTRUCTION
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
ADJUST
FOCUS
Please use a shielded
cable.
AUX(IN)
*
GND
AUX(OUT)
GND
100K
Connection/Installation
Connecting the Alarm Input/Output Terminal
Menu settings may be required depending on the connected equipment.
(A page 40)
The default setting has been set to alarm input (IN:ALARM).
m
Alarm input terminal
Connect the infrared sensor, door sensor, metal sensor, manual switch
sensor and the like.
v
To prevent noise from entering the internal circuit, supply non-voltage
setting signal to the alarm input signal.
v
Do not supply voltage.
v
Using the menu, you can select whether to set to alarm when the
contact is short (MAKE), or when the contact is open (BREAK).
v
Supply such that the alarm signal stays at a minimum of 200 ms or
more. Otherwise, the alarm signal may not be recognized.
.
m
Alarm output terminal
Connect to alarm devices such as alarm, indicator, light or buzzer.
v
The alarm output signal is open collector output and turns ON during
an alarm. (Maximum voltage 16 V, current 30 mA)
v
This terminal has a polarity. Make sure to connect such that a higher
voltage is output from the + terminal than from the - terminal.
Otherwise, it will result in damages.
.
E-19
MAX.
7 mm
Camera-mounting bracket
Rotation-preventive
hole
Camera-mounting
screw hole
Camera-mounting bracket fastening
screws (x2: M2.6 x 6 mm)
3
2
1
Camera-mounting bracket
fastening screws
Camera-mounting bracket
Connection/Installation
Mounting the Camera
When mounting the camera on a fixer, pan/tilt and the like, use the
camera-mounting screw hole located on the camera-mounting bracket.
(Length of screw: 7 mm or less)
.
Use a camera-mounting screw with a length shorter than 7 mm
Note
from the camera-mounting face. Use camera-mounting bracket
fastening screws with length shorter than 6 mm. Do not use a
screw that is longer than the specified length. It may damage
the internal parts.
m
Mounting the Camera-Mounting Bracket on Top of the Camera
The camera-mounting bracket is originally mounted at the bottom of the
camera before shipment but it can also be mounted on top of the camera.
1
Remove the camera-mounting bracket fastening screws (x2).
The camera-mounting bracket is removed from the camera.
2
Mount the camera-mounting bracket on top of the camera.
3
Mount the camera onto a fixer, pan/tilt unit and the like.
.
E-20
D
C
12V
SET
MANUAL
SEE INSTRUCTION
G
N
D
A
U
X
ONLY
(
E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
MENU
OUT
VIDEO
O
N
C
RT
O
N
O
FF
W
IDE-D
OFF
LCD
B
LC
O
FF
D
/N
AU
T
O
M
O
N
ITOR TYPE
A
C24V
12
A
D
JU
ST
FO
C
U
S
6mm
2 mm
6 mm
M3 x 6 mm
Fall prevention wire
Connection/Installation
m
Fall Prevention
v
Special attention is required when installing the camera to the wall or
ceiling. You should not engage in the installation work yourself. Ask a
professional to do the job. Otherwise, injuries or accidents may occur
if the camera falls.
v
When installing the camera on a fixer, pan/tilt unit and the like, make
sure to install it firmly using a rotation-preventive hole to prevent fall.
v
To prevent fall, connect the camera to a section with sufficient
strength (ceiling slab or channel) using a fall prevention wire.
v
Pay attention to the length, strength, routing and material (insulation
properties) of the fall prevention wire used.
v
Use the screw (M3 x 6 mm) on the back of the camera for the
installation of the fall prevention wire. Do not use a screw that is
longer than 6 mm as it may damage the internal parts.
.
When mounting the camera to the ceiling, ensure to wear
Note
safety glasses to protect the eye from any falling objects.
E-21
SET
MANUAL
SEE INSTRUCTION
ONLY (E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
ADJUST
FOCUS
A
B
C
D
E
Setting/Adjustment
Switch Settings
.
A [D/N AUTO/OFF]DAY & NIGHT Selector Switch
Set this to “AUTO” when shooting a subject with continually changing
brightness (day/night). The image switches to color when the subject is
bright, and black and white when it is dark. The image is set to color at
all times when “OFF” is selected.
You can set the image to black and white at all times using the menu.
(Default setting: AUTO)
B [BLC OFF/ON] Backlight Compensation Selector Switch
Set this to “ON” when shooting in backlight. The subject becomes
easier to see as brightness is adjusted according to the photometry
area set in [BLC AREA] of the menu.
(Default setting: OFF)
C [MONITOR TYPE LCD/CRT] Monitor Type Selector Switch
Set this to “LCD” or “CRT” according to the monitor in use.
(Default setting: LCD)
D
[WIDE-D OFF/ON] WIDE-D Selector Switch
When this is set to “ON”, subjects with a high contrast can be seen
clearly and naturally.
(Default setting: OFF)
E [FOCUS ADJUST] Focus Adjust Button
Press and hold the J button to open the lens iris for easy focusing.
(A page 24)
E-22
1
Setting/Adjustment
Adjusting Image
After mounting the camera, adjust the images while looking at the
actual image. Discharge the static electricity from your body by touching
the metallic part of the monitor terminal before handling the camera as
static electricity may cause the camera to malfunction.
1
Remove the lens cover.
.
① Press the mark of the lens cover (either left or right) from top and
bottom, and remove one of the catches from the camera.
② Remove another catch from the camera.
v
Note
Do not pull the lens cover too hard. The fall prevention sheet
may be detached from the camera.
v
When removing the lens cover, make sure to pull it straight
forward to avoid hitting the lens. It may cause malfunction if
the lens cover hits the lens.
2
Adjust the camera direction for shooting.
Aim the camera in the shooting direction.
v
Note
3
Adjust the image size.
Do not hold the lens while adjusting the camera direction.
Doing so may damage the lens.
Adjust the image size by loosening the fastening screw of the zoom
adjustment ring and moving the ring to the left/right. Tighten the
fastening screw after the adjustment is completed.
<Continued on the following page>
E-23
3
4
A
Zoom adjustment ring
Bottom of the camera
(main unit)
Knob
Catch
Gear for focus adjustment
Setting/Adjustment
Adjusting Image (Continued)
4
Fine adjust the focus
① Press and hold the [J] button.
v
Focus Adjust mode will be activated and “FOCUS ADJUST MODE”
is displayed on the monitor screen.
v
The contours are emphasized as the iris opens and the depth of
field becomes shallow.
v
After adjustment, press [K, H, I] / [SET] / [MENU] to exit focus
adjust mode. The mode is also automatically deactivated after
about 30 seconds.
v
Memo
② Shoot the subject.
③ Confirm that the catch is at position A in the diagram, and then
rotate the knob to adjust the focus to the optimum position.
During the Focus Adjust mode, the electronic shutter
will function automatically. As a result the screen will
appear grainy. This is not a malfunction.
.
E-24
Sensor part
Taper (tilted)
Light shiedling cushion
<Light shielding cushion attached
correctly>
Light shiedling cushion
Setting/Adjustment
v
Note
Below conditions may cause malfunctions. Adjust view angle
and [AUTO LEVEL] in the menu setting, etc. in case of
malfunctions:
- when the sensor part is hidden
- when the sensor part is exposed to strong light
- when brightness of the subject and the sensor part differ
drastically.
.
Checking after Operation
A light shielding cushion is attached to the lens so that the lens is not
exposed to infrared light directly. After adjustment, when attaching the
lens cover, make sure that the light shielding cushion is attached
correctly with the taper (tilted) side facing up (refer to the figure below).
If the light shielding cushion is not attached correctly or deformed,
infrared light reaches to the lens, causing the recorded images to look
shiny white.
.
E-25
AWC OPERATION
WHITE BALANCE CONTROL
E
AWC SET
R GAIN
B GAIN
AWC OK
WHITE BALANCE CONTROL
E
AWC SET
R GAIN
B GAIN
160
160
160
160
SET
MANUAL
SEE INSTRUCTION
GNDAUX
ONLY (E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
MENU
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
DC12V
AC24V
12
ADJUST
FOCUS
AWC OK
(adjustment completed)
AWC OPERATION
(during operation)
MENU button
J K H I button
SET button
Setting/Adjustment
Adjusting the Auto White Balance
Each light source has its own color temperature. Therefore, when the
main light source lighting the subject is changed, adjust the white
balance again.
1
Press the [MENU] button.
2
Select [WHITE BALANCE] with the [J / K] button and “AWC”
with the [H / I] button, then press the [SET] button.
3
Zoom in to fill the screen with white.
Place a white object at the center of the screen, under the same lighting
condition as the subject to be shot and zoom in to fill the screen with
white.
4
Press the [SET] button.
Auto white balance adjustment begins. During operation, “AWC
OPERATION” is displayed on the screen.
5
Adjustment is complete.
When the appropriate white balance is acquired, “AWC OK” is
displayed.
.
E-26
Setting/Adjustment
m
Error display
If auto white balance adjustment is not successful, the following
messages will appear on the monitor.
v
AWC ERROR : NG (Subject error)
Displayed when there is not enough white color on the subject or the
color temperature is not suitable.
Fill the screen with a white object thoroughly and adjust the white
balance again.
v
AWC ERROR : LOW LIGHT (Insufficient illumination)
Displayed when the light is low. Increase the illumination, then readjust
the white balance.
v
AWC ERROR : HIGH LIGHT (Excessive illumination)
Displayed when the light is too bright. Decrease the illumination, then
readjust the white balance.
v
AWC ERROR : TIME OVER (Subject movement)
Displayed when the subject moves. Keep the subject still, then readjust
the white balance.
E-27
D. ZOOM
DNR LEVEL
ENHANCE LEVEL
AUTO BLACK
BLACK LEVEL
COLOR LEVEL
*
WB AREA
LCD TYPE
VIDEO SETTINGS..
VIDEO EFFECT..
AGC
SENSE UP
WHITE BALANCE
WHITE BALANCE CONTROL
ATW - N
ATW -W
AWC
CAMERA TITLE
ADVANCED MENU
BASIC MENU
(A
ALC PRIORITY
WIDE-D LEVEL
SHUTTER SPEED
B&W Av:Pk
BRIGHTNESS
BLC AREA
Av:P k
ALC SETTINGS..
A
*
(A
(A
(A
(A
(A
(A
(A
(A
(A
Displayed as [COLOUR LEVEL] for the E model.
page 36)
page 35 - 36)
page 33 - 35)
page 33 - 41)
page 32)
page 32)
page 32)
page 31)
page 31)
page 31 - 32)
Menu Setting
The Flow of Menu Screen
.
E-28
D/N MODE
AUTO LEVEL
AUTO T IME
DAY/NIGHT
TITLE SIZE
TITLE COLOR *
ALARM TIME
AUX FUNCTION
IN POLARITY
OUT POLARITY
AUX FUNCTION
FACTORY SETTINGS..
CCD SPOT CORRECTION..
DEMONSTRATION..
ALARM TIME
TITLE COLOR *
TITLE SIZE
AREA EDIT..
DETECT LEVEL
IR LED MODE
MASK No. 4
MASK No. 3
MASK No. 2
MASK No. 1
BRIGHTNESS
PRIVACY MASK..
MOTION DETECT
MAINTENANCE..
A
(A
(A
(A
(A
(A
*
page 40 - 41)
page 39)
page 38)
page 37)
page 37)
Displayed as [TITLE COLOUR] for the E model.
Menu Setting
.
E-29
SET
MANUAL
SEE INSTRUCTION
GNDAUX
ONLY (E TYPE
)
ISOLATED POWER
(
U TYPE
)
CLASS 2 ONLY
MENU
VIDEO
OUT
ON
CRT
ON
OFF
WIDE-D
OFF
LCD
BLC OFF
D/N AUTO
MONITOR TYPE
DC12V
AC24V
12
ADJUST
FOCUS
BASIC MENU
WHITE BALANCE
AGC
SENSE UP
CAMERA TITLE
ADVANCED MENU..
ATW -W
MID
OFF
- - -
BASIC MENU
WHITE BALANCE
AGC
SENSE UP
CAMERA TITLE
ADVANCED MENU..
ATW -W
MID
OFF
- - -
Change mark
Sub-menu
Cursor
MENU button
J K H I button
SET button
Menu Setting
Menu Setting Procedure
1
Press the [MENU] button.
2
Set the cursor (E) to a desired menu item with the [ J / K ]
button.
3
Change the setting with the [ H / I ] button.
When a setting has been changed, a change mark (Z) is displayed.
4
Press the [MENU] button to exit the setting.
To display the sub-menu, set the cursor (E) to an item with
Memo
sub-menu and press the [SET] button.
.
E-30
Menu Setting
BASIC MENU
WHITE BALANCE Screen
This menu item allows to adjust camera white balance.
[Setting values:ATW-N, ATW-W, AWC] (Default value: ATW-W)
ATW-N:This is the ATW (Auto-Tracking White Balance) mode. The
ATW-W:This mode supports a wider range of color temperature (color
AWC:This is the AWC (preset white balance adjustment) mode.
WHITE BALANCE CONTROL Screen
AWC SET
Press the [SET] button to adjust and preset the white balance
automatically.
Memo
R GAIN
Adjusts the R (red) hue during AWC. The larger the number, the more
reddish the color becomes.
[Setting values:0 to 255] (Default value: 102)
B GAIN
Adjusts the B (blue) hue during AWC. The larger the number, the more
bluish the color becomes.
[Setting values:0 to 255] (Default value: 128)
camera adjusts the white balance automatically according to
the color temperature of the scene illumination (color
temperature 3200 K to 8000 K).
temperature 2300 K to 10000 K) than ATW-N.
Press the [SET] button to display the [WHITE BALANCE
CONTROL] screen.
When the [SET] button is pressed during black-and-white
operation, “AWC ERROR:LOW LIGHT” appears and white
balance cannot be preset.
E-31
Menu Setting
BASIC MENU (Continued)
AGC
This item sets the AGC (Automatic Gain Control).
[Setting values:OFF, MID, HIGH] (Default value: MID)
v
Memo
SENSE UP
Electronic Sense Up is a function that provides higher sensitivity level
by lengthening the exposure time. Use this item to set the number of
times to increase sensitivity when the subject becomes dark.
[Setting values:OFF, x2, x4, x8, x16, x32, x64, x128]
v
Setting example
When set to “x32”, the sensitivity increases automatically until 32 times
from the standard level. Motion may become unnatural when the
sensitivity increases as shutter speed will decrease.
Memo
CAMERA TITLE
This item sets the title to be displayed on the bottom left of the screen.
[Setting values:--- (no title), CAM001 to CAM256]
Memo
When set to “HIGH”, the screen appears grainy in dark
places.
v
When [AGC] in the menu setting is set to “OFF”, the camera
won't be switched to black-and-white mode even if the [D/N
MODE] is set to “AUTO”, and IR LED won't turn on.
(Default value: OFF)
When the setting value is increased, the screen may appear
grainy, whitish, or white spots may appear; this is not a camera
malfunction.
This setting takes priority over [SHUTTER SPEED].
(Default value: ---(no title))
v
The name of the CAMERA TITLE cannot be modified.
Select it from the setting values.
E-32
AREA 4AREA 3AREA 2AREA 1
Photometry area
Menu Setting
ADVANCED MENU
ALC SETTINGS Screen
BRIGHTNESS
Adjusts video signal brightness level. The larger the value, dark area
becomes more visible. The smaller the value, bright area becomes
more visible.
[Setting values:-5 to NORMAL to 5] (Default value: NORMAL)
BLC AREA
Press the [SET] button to display the fixed photometry area. Select one
of the following four types.
.
[Setting values:AREA1 to AREA4] (Default value: AREA1)
Memo
Av:Pk
Sets the exposure detection method for the color mode to the ratio of
the AVERAGE value and PEAK value. When the screen, other than the
highlighted section, becomes dark, increase the AVERAGE value (ex.
10:0). When the highlighted section becomes dark, increase the PEAK
value (ex. 5:5).
[Setting values:10:0, 9:1, 8:2, 7:3, 6:4, 5:5] (Default value: 8:2)
When the BLC (backlight compensation) selector switch is set
to “OFF”, [BLC AREA] does not work even if it is set.
E-33
Menu Setting
ADVANCED MENU (Continued)
B&W Av:Pk
Sets the exposure detection method for the black-and-white mode to
the ratio of the AVERAGE value and PEAK value. When the screen,
other than the highlighted section, becomes dark, increase the
AVERAGE value (ex. 10:0). When the highlighted section becomes
dark, increase the PEAK value (ex. 5:5).
[Setting values:10:0, 9:1, 8:2, 7:3, 6:4, 5:5] (Default value: 8:2)
When the D/N MODE is set to “AUTO”, setting the B&W Av:Pk
Memo
to the low value (ex. 5:5) may cause hunting. Setting should be
done upon checking the actual images.
ALC PRIORITY
Sets whether to prioritize motion or picture quality when the subject
becomes dark.
[Setting values
MOTION:Prioritizes motion. AGC (Automatic Gain Control) operates
COMBO:Adjusts motion and picture quality equally.
PICTURE:Prioritizes picture quality. SENSE UP (Electronic Sense
Memo
SHUTTER SPEED
Sets the speed of the electronic shutter. The higher the shutter speed,
the smear phenomenon due to the characteristic of the CCD where
white, vertical stripes appear around a bright light source will be
emphasized.
[Setting values
Memo
:
MOTION, COMBO, PICTURE] (Default value: MOTION)
with priority.
Up) operates with priority.
When [AGC] or [SENSE UP] is set to “OFF”, “ALC PRIORITY”
does not work even if it is set.
:
1/60 (U model), 1/50 (E model), 1/100 (U model), 1/120 (E
model), 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000]
(Default value: 1/60 (U model), 1/50 (E model))
v
[SHUTTER SPEED] cannot be set in the following cases:
- when the [WIDE-D LEVEL] is set to “ON”
- when [SENSE UP] is set to “OFF”
E-34
Menu Setting
WIDE-D LEVEL
Enables subjects with a high contrast to be seen clearly and naturally.
The larger the value, the higher the contrast. The smaller the value, the
lower the contrast.
[Setting values:-5 to NORMAL to 5] (Default value: NORMAL)
Memo
VIDEO SETTINGS Screen
LCD TYPE
Enables settings to be made according to preference when using a LCD
(Liquid Crystal Display).
[Setting values:TYPE1, TYPE2] (Default value: TYPE1)
Memo
WB AREA (WHITE BALANCE AREA)
Sets the white balance target area. When set to “ON”, the area
specified in [WB AREA EDIT] is set as target.
[Setting values:OFF (whole screen), ON (set area)] (Default value: OFF)
COLOR LEVEL (U model), COLOUR LEVEL (E model)
Adjusts video signal color level.
[Setting values
Memo
When the [WIDE-D] switch is set to “OFF”, [WIDE-D LEVEL]
does not work even if it is set.
When the MONITOR TYPE selector switch is set to “CRT”,
[LCD TYPE] does not work even if it is set.
:
-5 (lighten the color) to NORMAL to 5 (darken the color)]
(Default value: NORMAL)
When [AUX FUNCTION] is set to “OUT:B&W” or during B/W
mode, [COLOR LEVEL (COLOUR LEVEL)] does not work
even if it is set.
BLACK LEVEL
Adjusts the black level of the video signal under low illumination.
[Setting values:-5 (low level) to NORMAL to 5 (high level)]
(Default value: NORMAL)
E-35
Menu Setting
ADVANCED MENU (Continued)
AUTO BLACK
Adjusts the black level of the video signal.
[Setting values:OFF, ON] (Default value: ON)
ENHANCE LEVEL
Adjusts contour correction to enhance sharpness on the monitor
screen.
[Setting values:-5 (soft) to NORMAL to 5 (sharp)]
DNR LEVEL
Sets DNR (Digital Noise Reduction). When set to “HIGH”, noise is
effectively reduced but picture quality of the video deteriorates.
[Setting values:NORMAL, HIGH] (Default value: NORMAL)
Memo
VIDEO EFFECT Screen
D.ZOOM
Sets electronic zoom magnification ratio.
[Setting values:WIDE (x1), MID (x1.4), TELE (x2)]
Memo
(Default value: NORMAL)
Set DNR (Digital Noise Reduction). Setting to “HIGH” will
improve the DNR effect but afterimage is likely to occur for
moving subjects.
(Default value: WIDE (x1))
As the video is digitally processed when electronic zoom is
used, picture quality may deteriorate slightly.
E-36
Menu Setting
PRIVACY MASK Screen
This function allows you to set and mask the parts on the screen that
you do not wish to shoot so that they are not recorded.
For details, refer to "Setting the Privacy Mask" (A page 42).
BRIGHTNESS
Sets the brightness of the part of the image that was masked. The
smaller the value, the darker the image. The larger the value, the
brighter the image.
[Setting values:0 to 10 to 15] (Default value: 10)
MASK No.1-4
[Setting values:OFF, ON] (Default value: OFF)
Memo
MAINTENANCE Screen
CCD SPOT CORRECTION
Compensates for white spots on the CCD. Press the [SET] button to
display the items for selection.
[Items for selection:CANCEL, EXECUTE]
CANCEL:Returns to the MAINTENANCE screen.
EXECUTE:Executes white spot compensation on the CCD.
Memo
FACTORY SETTINGS
The values set on the menu screen are returned to the default settings.
Press the [SET] button to display the items for selection.
[Items for selection:CANCEL, CLEAR(W/O TITLE), CLEAR(ALL)]
CANCEL
CLEAR(W/O TITLE):Returns setting values except for CAMERA
CLEAR(ALL)
Privacy mask can be individually set for each number. Up to
four masked areas can be set. Set to “ON” and press the
[SET] button to display the mask setting screen.
Attach the lens cap before executing white spot compensation
on the CCD. Also, turn on the power for 30 minutes to warm
up the camera before execution.
:
Returns to the MAINTENANCE screen.
TITLE to the default.
:
Returns all setting values to the default.
E-37
Menu Setting
ADVANCED MENU (Continued)
DAY/NIGHT Screen
D/N MODE
Sets the displayed video when the DAY & NIGHT selector switch is set
to “AUTO”. When set to black-and-white mode, the IR cut filter is
switched off and the sensitivity is increased.
[Setting values:B&W (black-and-white), AUTO (black-and-white/color)]
Memo
IR LED MODE
Sets whether or not IR LED lights up in the black-and-white mode.
[Setting values:ON, OFF] (Default value: ON)
ON
OFF
AUTO LEVEL
Sets the brightness level where the camera will switch between color
and black-and-white.
[Setting values:DARK, NORMAL, BRIGHT] (Default value: NORMAL)
(Default value: AUTO)
v
When the DAY & NIGHT selector switch is set to “OFF”, or
[AUX FUNCTION] is set to “IN : D/N”, [D/N MODE] cannot
be set.
v
When [AGC] in the menu setting is set to “OFF”, the camera
won't be switched to black-and-white mode even if the [D/N
MODE] is set to “AUTO”, and IR LED won't turn on.
:
IR LED lights up in the black and white images, and lights
off in the color images.
:
IR LED won't light up in both black and white and color
images.
AUTO TIME
Sets the detection time of the brightness level. The camera switches
between color and black-and-white when the brightness level is
detected after the selected period of time.
[Setting values:0s, 10s, 20s, 30s] (Default value: 30s)
E-38
Menu Setting
MOTION DETECT Screen
DETECT LEVEL
Sets the level to detect movements. The larger the value, the higher the
sensitivity. The smaller the value, the lower the sensitivity.
[Setting values:-5 to NORMAL to 5] (Default value: NORMAL)
Memo
AREA EDIT
Sets the detection area of Motion Detect.
TITLE SIZE
Sets the size of the text displayed when Motion Detect is functioning.
When set to “DOUBLE”, the text displayed will be twice the size of the
text in the menu.
[Setting values:NORMAL, DOUBLE] (Default value: DOUBLE)
TITLE COLOR (U model), TITLE COLOUR (E model)
Sets the color of the title displayed when Motion Detect is functioning.
[Setting values:WHITE, GREEN, CYAN, YELLOW]
ALARM TIME
Sets the output time of the alarm signal and the time to display alarm on
the screen.
[Setting values:OFF, 5s to 10s, 15s, 20s, 30s, 60s] (Default value: 5s)
Even the flicker of a fluorescent lamp can be detected when a
high value is set.
After setting, make sure to check the operation of the Motion
Detect function using [DEMONSTRATION].
(Default value: WHITE)
DEMONSTRATION
Use this to check whether the Motion Detect function is set correctly.
Press the [SET] button to start the demonstration.
E-39
Menu Setting
ADVANCED MENU (Continued)
AUX FUNCTION Screen
AUX FUNCTION
Sets the input/output signal of the AUX terminal.
[Setting values:IN:ALARM, IN:D/N, OUT:ALARM, OUT:B&W]
IN:ALARM:Displays image on the monitor when alarm signal is input
IN:D/N
OUT:ALARM:Outputs alarm signal to the AUX terminal when
OUT:B&W:Outputs alarm signal to the AUX terminal when the
Memo
m
TITLE SIZE
Sets the size of the title displayed when alarm signal is input. When
set to “DOUBLE”, the text displayed will be twice the size of the text
in the menu.
[Setting values:NORMAL, DOUBLE] (Default value: DOUBLE)
m
TITLE COLOR (U model), TITLE COLOUR (E model)
Sets the color of the title displayed when alarm signal is input.
[Setting values:WHITE, GREEN, CYAN, YELLOW]
m
ALARM TIME
Sets the time to display alarm on the screen when alarm signal is
input.
[Setting values:5s to 10s, 15s, 20s, 30s, 60s] (Default value: 5s)
(Default value: IN:ALARM)
from the AUX terminal.
:
Switches image to the color/black-and-white mode when
alarm signal is input from the AUX terminal.
movements are detected.
image switches to black-and-white.
When “IN:ALARM” is selected, press the [SET] button to
display the sub-menu. You can set the [TITLE SIZE], [TITLE
COLOR], [TITLE COLOUR] and [ALARM TIME] items on the
sub-menu.
If D/N switch is OFF, “IN:D/N” can not be selected. If D/N
switch is changed to OFF during “IN:D/N” is displayed, “IN:D/
N” is changed to “OFF”.
(Default value: WHITE)
E-40
BASIC MENU
WHITE BALANCE
AGC
SENSE UP
CAMERA TITLE
ADVANCED MENU..
ATW- W
MID
OFF
- - -
WHITE BALANCE CONTROL
AWC SET
R GAIN
B GAIN
160
160
[WHITE BALANCE CONTROL] Screen[BASIC MENU] Screen
Setting Examples
IN POLARITY
Sets the polarity of the input alarm signal.
[Setting values:MAKE (short), BREAK (open)] (Default value: MAKE)
Memo
When the [AUX FUNCTION] switch is set to “OUT:ALARM” or
“OUT:B&W”, [IN POLARITY] does not work even if it is set.
OUT POLARITY
Sets the polarity of the output alarm signal.
[Setting values:MAKE (short), BREAK (open)] (Default value: MAKE)
Memo
When the [AUX FUNCTION] switch is set to “IN:ALARM” or
“IN:D/N”, [OUT POLARITY] does not work even if it is set.
Manual Adjustment of White Balance
White balance of this camera can be set to adjust automatically
according to the subject. When the automatic adjustment results in a
“reddish screen” for example, adjust the white balance manually.
1
Set the [WHITE BALANCE] item on the menu screen to “AWC”
and press the [SET] button.
2
Press the [J/K] button to select the hue ([R GAIN]/[B GAIN]).
3
Press the [H/I] button to change the hue setting.
The hue changes according to the selected value.
4
Press the [MENU] button to exit the manual adjustment of white
balance.
Memo
The settings of [R GAIN] and [B GAIN] work during color
operation. To adjust the setting value, do so during color
operation.
.
E-41
PRIVACY MASK
MASK EDIT No1
<MENU> RETURN <SET> D-R
<SET> U-L<MENU> RETURN
MASK EDIT No1
BRIGHTNESS
MASK No.1
MASK No.2
MASK No.3
MASK No.4
10
OFF
OFF
OFF
OFF
(MASK No1) (MASK No1)
Setting Examples
Setting the Privacy Mask
1
Select the [ADVANCED MENU] item on the menu screen and
press the [SET] button.
2
Select the [PRIVACY MASK] item with the [J/K] button and
press the [SET] button.
The PRIVACY MASK screen appears on the monitor.
3
Select the mask number with the [J/K] button and set “ON”/
“OFF” with the [H/I] button, then press the [SET] button.
ON:Activates privacy mask.
OFF:Deactivates privacy mask.
4
Edit the left/upper margin of the mask with the [J/K/H/I] button.
5
Press the [SET] button.
The screen to edit the right/lower margin of the mask appears.
6
Edit the right/lower margin of the mask with the [J/K/H/I]
button.
Press the [SET] button to switch between the screen to edit
Memo
the left/upper margin of the mask and the screen to edit the
right/lower margin of the mask.
7
Press the [MENU] button.
The mask boundary of the selected number is saved and the screen
returns to the PRIVACY MASK screen.
8
Repeat steps 3 to 7 to set all desired masks (MASK No.1 to
MASK No.4).
9
Press the [MENU] button to exit.
Returns to the ADVANCED MENU screen.
.
E-42
Setting Examples
Settings in Dark Locations
The followings are examples of recommended settings for recording
scenes in various dark locations.
m
Setting the displayed images (black and white or color)
(Set in [D/N MODE])
Default setting is “AUTO”, to switch the displayed images (Color/black
and white) based on the brightness. Change the setting depending of
the recording locations.
Setting values Recording Conditions
AUTO Suitable for locations where the brightness
B&W Suitable for locations like warehouses, where it
v
Memo
When the Function Selection Switches in DAY & NIGHT
selector switch is set to “OFF”, operation error occurs and
above setting values are displayed as “---” and setting is
disabled.
v
If [IR LED MODE] in the menu setting is set to “OFF”, IR
LED won't turn on.
v
When [AGC] in the menu setting is set to “OFF”, the camera
won't be switched to black-and-white mode even if the [D/N
MODE] is set to “AUTO”, and IR LED won't turn on.
changes. Switches to the color images when
the surrounding is bright (IR LED light off), and
to the black and white images when the
surrounding is dark (IR LED light on).
is always dark (fixed at black and white images,
IR LED light on).
E-43
Setting Examples
Settings in Dark Locations (Continued)
m
Changing the level of brightness to switch the images (Color/
black and white)
[AUTO LEVEL] in [DAY/NIGHT] is set to “NORMAL” in default. Change
the setting by comparing below values and the “NORMAL” setting, and
selecting the appropriate value.
Setting values Contents
BRIGHT Suitable when the images need to be switched
DARK Suitable when the images need to be switched
m
Switching the images (Color/black and white) from the external
device
When the [AUX FUNCTION] in the menu setting is set to “IN:D/N”,
switching in between color images (IR LED light off) and black and
white images (IR LED light on) by the signals input to the AUX terminal.
v
Memo
IR LED won't turned on if the [IR LED MODE] in menu
setting is set to “OFF”.
(Color/black and white) in brighter conditions as
compared to the “NORMAL” setting.
(Color/black and white) in darker conditions as
compared to the “NORMAL” setting.
E-44
Setting Examples
m
Recording the distant subjects
Below settings are recommended when the subject in the distance
needs to be captured brightly.
Menu Setting Recommended Setting Values
[SENSE UP] x2
[AGC] HIGH
[ALC PRIORITY] PICTURE
v
Memo
Confirm that the black and white images (IR LED light on) is
selected if setting is in progress while viewing the images.
To set the black and white images (IR LED light on), set the
[IR LED MODE] to “ON”, and perform either of the following:
- Set “AUTO” in [D/N MODE], and darken the surrounding.
- Set “B&W” in [D/N MODE].
m
Adjusting brightness while IR LED is lit
(brightness adjustment in B&W Av:Pk)
Make necessary adjustments when the images are difficult to see due
to the screen being too white or too dark in the black-and-white mode.
Setting values Intended improvements
Decrease the
setting to 6:4, etc
When it is difficult to see the nearby subject
since it looks too white (Need to improve
overexposure of the subject)
Increase the
setting to 10:0, etc.
When the background images are too dark to
collapse the overall images (Need to avoid the
overall images to look dark)
v
Memo
Confirm that the black and white images (IR LED light on) is
selected if setting up is in progress while viewing the
images. To set the black and white images (IR LED light on),
set the [IR LED MODE] to “ON”, and perform either of the
following:
- Set “AUTO” in [D/N MODE], and darken the surrounding.
- Set “B&W” in [D/N MODE].
E-45
Others
Specifications
Items TK-C8301RU TK-C8301RE
Image pickup
device
Effective Pixels 768 (H) x 494 (V) 752 (H) x 582 (V)
Television
System
Scanning
Frequency
Sync system Internal sync (built-in SSG)
Video Signal VBS 1.0 Vp-p (75 K)
Video S/N ratio 52 dB (typical, AGC OFF)
Minimum
illumination
Power supply AC 24 V, DC 12 V
Power
consumption
Ambient
temperature
Mass 360 g
Accessories
1/3" Interline Transfer CCD
Based on NTSC System Based on PAL System
Horizontal:
15734.26 Hz ± 0.003 %
Vertical:
59.94 Hz ± 0.003 %
Color mode: 0.05 lx (typical, 50%, F1.2, AGC HIGH)
Black-and-white mode:
0.006 lx (typical. 50%, F1.2, AGC HIGH, IR LED
OFF)
0.000 lx (typical, 50%, F1.2, AGC HIGH, IR LED ON)
3.8 W 320 mA
-10 f to 50 f (14 g to 122 g) (Operation)
0 f to 40 f (32 g to 104 g) (Recommended)
INSTRUCTIONS ......... 1
WARRANTY CARD .... 1
Horizontal:
15625.00 Hz ± 0.003 %
Vertical:
50.00 Hz ± 0.003 %
INSTRUCTIONS ......... 1
CD-ROM ..................... 1
E-46
34 (1-3/8)
61 (2-7/16)
53 (2-1/8)
55 (2-3/16)
85 (3-3/8)
163 (6-7/16)
Others
m
External dimensions [Unit: mm (inch)]
.
* Specifications and appearance of this camera are subject to change
for improvements without notice.
E-47
TK-C8301RU
TK-C8301RE
IR COLOR CAMERA
©2012 JVC KENWOOD Corporation
LST1407-001A
