Instruction Manual

360º Portable wireless speaker

SP-AD80-B / SP-AD80-G

Contents

Safety Warnings.............................................................. 5

Unpacking ..................................................................... 12

Product Overview ......................................................... 13

Front View ...................................................................................13

Rear View ....................................................................................14

Top View ......................................................................................16

Bottom View ..............................................................................18

Important Information about Water Resistant

Operation ...................................................................... 19

Charging the Speaker .................................................. 21

Battery Life ................................................................................ 22

When the Battery is Almost Empty ................................. 23

Charging an External Device.......................................25

Connection .................................................................... 26

Using the AUX Connection ................................................. 26

Stereo Pairing Function ...............................................27

General Operation........................................................29

Powering ON/OFF................................................................... 29

Automatic Power O Function ......................................... 29

Adjusting the Volume ........................................................... 30

Torch Function ..............................................................30

Bluetooth® Operation ................................................... 31

NFC (Near Field Communication) Operation ............ 33

Listening to Music ........................................................34

Bluetooth® Mode ..................................................................... 34

AUX Mode .................................................................................. 35

Hands-free Calling........................................................36

Making a Call .............................................................................37

Redial ............................................................................................37

End Call ........................................................................................37

Receiving a Call ....................................................................... 38

Reject an Incoming Call ....................................................... 38

Maintenance .................................................................39

Hints and Tips................................................................40

Product Fiche and Specifications ............................... 44

Others Information and Licences ............................... 47

Safety Warnings

• Read all the instructions carefully before using the unit and keep them for future reference.

• Retain the manual. If you pass the unit onto a third party make sure to include this manual.

Damage

• Please inspect the unit for damage after unpacking.

• Do not continue to operate the unit if you are in any

doubt about it working normally, or if it is damaged in any way - switch o and consult your dealer.

Location of Unit

• The unit must be placed on a at stable surface and should not be subjected to vibrations.

• Do not place the unit on sloped or unstable surfaces as the unit may fall o or tip over.

• Do not place the unit close to table edge. It may fall o due to vibration during high volume listening.

Temperature

• Avoid extreme degrees of temperature, either hot or cold. Place the unit well away from heat sources such as radiators or gas/electric res.

• Avoid exposure to direct sunlight and other sources of heat.

Naked Flames

• Never place any type of candle or naked ame on the top of or near the unit.

Moisture

• Do not submerge this unit in water. It can cause serious damage.

Water Resistance

• In compliance with IPX7.

• To ensure the water resistance of the unit, all covers

for the USB port must be rmly closed.

• Even if your device is resistant to dust and water, you should avoid using it unnecessarily to environments with excessive dust, sand and mud or to moist environments with extreme high or low temperatures. The water resist ability cannot be guaranteed in all environments or conditions.

Interference

• Do not place the unit on or near appliances which may cause electromagnetic interference. If you do, it may adversely aect the operating performance of the unit, and cause a distorted sound.

Service

• To reduce the risk of electric shock, do not remove screws. The unit does not contain any userserviceable parts. Please leave all maintenance work to qualied personnel.

• Do not open any xed covers as this may expose dangerous voltages.

Built-in Battery Care

• Your product is powered by a rechargeable battery.

• The battery can be charged and discharged

hundreds of times, but will eventually wear out.

• Unplug the charger from the electrical plug and the product when not in use.

• Do not leave a fully charged battery connected to a charger, since overcharging may shorten its lifetime.

• If left unused, a fully charged battery will lose its charge over time.

• Leaving the product in hot or cold places, such as in a closed car in the summer and winter conditions, will reduce the capacity and lifetime of the battery.

• Always try to keep your device in a cool, moisturefree environment that’s less than 32°C. A product with a hot or cold battery may not work temporarily, even when the battery is fully charged. Battery performance is particularly limited in temperatures well below freezing.

• The unit should be fully recharged after using the device each time. This will keep the health of the battery.

• If you plan to store your device for longer than six months, charge the battery for an hour every six months to keep it fresh.

Battery warning!

• The battery used in this product may present a risk of re or chemical burn if mistreated.

• Do not attempt to open the product or replace the battery. It is built-in and not changeable. Use of other batteries may present a risk of re or explosion and the warranty will be terminated.

• Only recharge your battery with the provided USB cable designated for this product.

• Dispose of batteries according to local regulations. Please recycle when possible. Do not dispose as household waste or in a re as they may explode.

• Batteries may explode if damaged.

Maintenance

• Do not use any type of abrasive pad or abrasive cleaning solutions as these may damage the unit’s surface.

• Do not use liquids to clean the unit.

Thank you for purchasing your new

product. We recommend that you spend some time

reading this instruction manual in order that you fully understand all the operational features it oers. You will also nd some hints and tips to help you resolve any issues.

Read all the safety instructions carefully before use and keep this instruction manual for future reference.

Unpacking

Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to local regulations.

The following items are included:

• Main Unit

• USB to Micro USB Cable

• 3.5mm to 3.5mm Stereo Audio Cable

• Instruction Manual

If items are missing, or damaged please contact Partmaster (UK only). Tel: 0344 800 3456 for assistance.

Product Overview

Front View

1. Speakers

2. Built-in microphone

Manually open the jack cover at the rear of the unit for the connector panel. Do not use any metal or sharp objects to open the jack cover, because they will damage the rubber and impact the waterproong function.

Rear View

1. Carrying Strap

2. ON/OFF Button

• Press and hold to switch on the unit.

• Press and hold to switch o the unit.

3. Battery Indicator

• Flash blue when the unit is in ON mode, and is searching for Bluetooth device.

• Light up red when charging.

• Switch o when the unit is

fully charged.

4. Torch Button

• Press and hold to switch the torch light ON.

• When the torch light is on, press repeatedly to switch it in Dim/Flashing/ O mode.

5. Aux in Socket Connect a music player, etc. to this socket by using the supplied Stereo Audio Cable.

5 6

6. DC in 5V Socket Connect a computer, etc. to this socket with the supplied micro-USB cable to charge the unit.

7. 5V 1A Charge out Socket Supply 5V 1.0 A max for charging an external unit.

Top View

1. Button The stereo pairing function is

1 2

only available when you have two speakers:

• After you have switched

on both speakers, press and hold for about 5 seconds on one speaker. The two speakers will be automatically connected.

• Press and hold this button

on one of the speakers to disconnect the two connected speakers

3 4

Button

• Press to answer/end

an incoming call in

Bluetooth® mode.

• Press twice to dial the

last called number.

• Press and hold to reject an incoming call.

2. Volume +/– Button

• Press and hold +/– button to increase/decrease the volume.

• Press +/– button to skip to the next/previous track in Bluetooth mode.

3. NFC sensor

4. Button

• Press to activate the pairing function in Bluetooth® mode.

• Press and hold to disconnect the existing paired Bluetooth® device.

Bottom View

1. Torch light

Important Information about Water Resistant Operation

For proper water resistant operation, make sure the plastic jack cover of the unit is completely ush with the unit by pressing along the entire edge of the cover until it is completely and securely in place.

The unit is IPX7 splash proof rated. However, DO NOT immerse the unit in water. It may cause product failure.

• Make sure the jack cover and surrounding surfaces are completely dry before opening the jack cover to prevent moisture from damaging the internal electronics.

• Keep the jack cover free of dirt, sand, or other objects that can interfere with proper sealing. If for any reason the jack cover is not making a tight waterproof seal water may enter the unit.

• DO NOT clean unit with oily soaps or use chemicals or solvents. Clean with damp cloth.

Charging the Speaker

The unit has a built-in rechargeable battery, which should be charged before using the speaker for the rst time.

The battery is charged automatically whenever the unit is connected to a computer or a USB charging device.

USB to Micro USB

Cable (included)

Computer

USB charging

device

1. Open the jack cover of the speaker.

2. Connect the supplied micro-USB cable to the

speaker, and then connect the other end to a computer.

3. The charging indicator will ash during

charging. The light will switch o after the unit is fully charged.

Battery Life

When using the Bluetooth® connection, the speaker has approx. 10 hours of playback time in fully charge status and in medium sound level. Time stated above may vary, depending on ambient temperature or conditions of use.

When the Battery is Almost Empty

The Battery indicator will ash in red. When the battery becomes empty, the speaker turns o automatically.

•Micro-USB socket is for charging the unit only.

•Do not overcharge the battery as it may shorten its life.

Disconnect the USB cable after the unit is fully charged.

•The unit should be fully recharged after using the device each time. This will keep the health of the battery.

•If you plan to store your device for longer than 6 months, charge the battery for an hour every 6 months to keep it fresh.

•Use the supplied micro-USB cable only, and connect directly to a computer. Charging will not be completed properly by an indirect connection, such as via a USB hub.

•If the unit is not used for a long time, the battery indicator may not light up when you connect the micro-USB cable to charge the unit. In this case, do not disconnect the micro-USB cable from the unit and wait until the battery indicator lights up.

•Charging time varies depending on conditions of use of the battery and the output voltage of your charging device.

•The unit will get warm during charging. This is not a malfunction.

Charging an External Device

You can charge an external device (e.g. smartphone) with this product by connecting to the 5V 1A Charge out Socket of this product.

To charge your external device, you should use the charging cable of your external device. The USB cable provided here is only for charging this speaker.

5V 1A Charge

out Socket

Connection

Using the AUX Connection

Use the supplied

3.5 mm to 3.5 mm stereo audio cable to connect the headphone socket of an audio device and the Aux in socket of

3.5 mm to 3.5 mm stereo audio cable (included)

the unit. The unit will switch into AUX mode after you start

playback from the connected audio device.

Stereo Pairing Function

To create a stereo pairing, you need to have two speakers and switch them both on.

1. Press and hold the button for about 5 seconds on one of the speakers. The LED indicator will ash in blue.

2. Press and hold the button for about 5 seconds on the other speaker. The LED indicator will ash in blue. Then the two speakers will be automatically connected. You will hear a signal sound after the pairing is complete.

Press and hold the button in any one of the speakers to disconnect the connection between the two speakers.

The rst connected unit with your Bluetooth® device will be the Master speaker (left channel). Its LED indicator will ash slowly in blue.

The other unit will be the Slave speaker (right channel), the blue LED indicator will ash rapidly.

General Operation

Powering ON/OFF

• Press and hold the On/O button to switch

on/o the unit.

Automatic Power O Function

If the speaker is left in any of the following conditions for more than approximately 15 minutes, it turns o automatically.

• No Bluetooth® connection has been established

between the unit and the external mobile device.

• No audio input from the external device in

Bluetooth® or AUX mode.

• When the battery becomes empty, the unit turns

o automatically.

Adjusting the Volume

During playback, press and hold +/– buttons on the unit to increase or decrease the volume.

Torch Function

• Press and hold the

button to switch the torch light ON.

• While the torch light is

on, press the button repeatedly to switch it in Dim/Flashing/O mode.

Bluetooth® Operation

Switch the speaker on. The unit will nd the last paired Bluetooth® device and connect automatically.

If there is no previously paired device found, the speaker will enter Bluetooth® pairing mode automatically. The LED indicator will ash rapidly. Follow the steps below to pair the unit with a Bluetooth® device.

Activate your Bluetooth® device and select the search mode. “SP-AD80” will appear on your Bluetooth® device list.

1. Select “SP-AD80” and enter “0000” for the password if necessary. If connect successful, the LED indicator will light up blue.

2. To disconnect the Bluetooth® function, press and hold button to disable the function from your Bluetooth® device.

• You can enjoy music wirelessly from a smartphone, mobile phone, or music player. Also, you can make or receive a call by operating the unit.

• The operational range between the unit and the device is approximately 10 metres. Any obstacle between the device and the unit can reduce operational range.

• Before connecting a Bluetooth® device to the unit, ensure you know the device’s capabilities.

• Compatibility with all Bluetooth® devices is not guaranteed.

• Keep this player away from other electronic devices that may

cause interference.

• The player will also be disconnected when your device is moved beyond the operational range.

NFC (Near Field Communication) Operation

Pair your NFC-enabled mobile device directly with this unit by just a single tap.

1. Activate NFC on your mobile device.

2. Hold your mobile device about or less than 1 cm close to the icon of unit. The device vibrates or a message pops up.

3. To disconnect, hold the mobile device on the

icon of the unit to disconnect or disable NFC

from your mobile device.

Listening to Music

Bluetooth® Mode

You can enjoy listening to music and basic remote control operation of a Bluetooth® device via a Bluetooth® connection. The Bluetooth® device is required to support the following Bluetooth® proles.

• A2DP (Advanced Audio Distribution Prole): you

are enable to enjoy high-quality audio content wirelessly.

• AVRCP (Audio Video Remote Control Prole): use

the unit to control play.

– To pause/resume playback, press once. – To increase/decrease the volume, press and hold

+/– button

– To skip to the next/previous track in Bluetooth

mode, press +/– button

AUX Mode

If you connect an audio cable to the Aux in socket, make sure that you have started playback in your external audio device.

• Press Volume +/– button to increase/decrease

the volume.

• Operate your audio device directly for playback

features.

Hands-free Calling

You can enjoy a hands-free call with a Bluetooth® smartphone or mobile phone that supports the Bluetooth® prole HFP (Hands-free Prole) or HSP (Headset Prole), via a Bluetooth® connection.

Call functions are only applicable if mobile phone is paired and connected with the speaker and both are switched on.

The function available may vary depending on the prole supported by your Bluetooth® smartphone or mobile phone. Even if the phone has the same prole, functions may vary depending on the specications. Please refer to the manual supplied with your smartphone or mobile phone.

Making a Call

1. Activate Bluetooth® mode on your mobile device.

2. Use the buttons on your mobile device when making a call.

Redial

Press button twice to redial the last call.

End Call

Press button on the speaker to hang up the phone. You can also end the call from your phone.

Receiving a Call

When an incoming call arrives, a ring tone will be heard via the speaker.

Press button on the speaker. You will be able to hear your call through your speaker. The built-in microphone will allow you to converse with the caller.

Reject an Incoming Call

Press and hold button on the speaker to reject an incoming call.

If the caller cannot or can barely hear your voice, press + / – button to adjust the volume or talk into the microphone of the speaker.

Maintenance

Ensure the unit is fully unplugged before cleaning.

• To clean the unit, wipe the case with a slightly

moist, lint-free cloth.

• Do not use any cleaning uids containing

alcohol, ammonia or abrasives.

• Do not spray aerosol at or near the unit.

Hints and Tips

If a problem does occur, it may often be due to something very minor. The following table contains various tips. If you require additional assistance,

• for UK, please call our UK Call Centre on

0344 561 1234.

• for Ireland, please call our Ireland Call Center on

1 890 818 575.

Problem Solution

No power. • The battery may be

exhausted. Connect the USB cable and plug into a USB port of a computer which is turned on.

• Ensure that the unit is switched on.

Problem Solution

No Sound. • Ensure that the unit is

switched on.

• Check the volume level of the unit.

• Check the sound input source.

Sound is distorted. • Volume is too high. Adjust the

volume control.

Not charging. • Ensure that the micro-USB

charging cable is correctly connected with the unit.

Problem Solution

I cannot nd “SP-AD80” on my Bluetooth® device.

Voice interrupted in

• Ensure that the unit is switched on.

• Ensure that the Bluetooth® function is activated on your Bluetooth® device.

• The unit has a Bluetooth® function that can receive a signal within 10 metres. Keep a distance within 10 metres between the unit and your Bluetooth® device.

• Ensure that the unit

Bluetooth® mode.

and Bluetooth® device is connected within 10 metres.

• Ensure that no obstruction between the unit and the Bluetooth® device.

Problem Solution

NFC Pairing failed. • Ensure that the Bluetooth®

device supports NFC function.

• Ensure that the unit is in pairing mode.

• For rst time pairing, ensure that the Bluetooth® device touches NFC sensor of the unit.

• Remove mobile phone protection shell for NFC pairing.

No Sound in AUX mode.

• Ensure the audio cable is properly connected.

Product Fiche and Specifications

Brand JVC

Model SP-AD80-B (Black) /

SP-AD80-G (Green)

Speaker 6 Ω × 2

Frequency Response 180 Hz-20 kHz (+/–

3 dB)

Power Amplier Class D @ 10 W × 2

THD 10%

SNR >75dB(A)

Charging Input DC 5V, 1A (Micro

USB)

Charging Time Approx. 6 - 8 hours

(DC 5V, 1A [Micro USB])

Dimension 71 mm × 78 mm ×

185 mm

Weight 556 g

Bluetooth® Bluetooth®

Version

Maximum transmitted power

Frequency band

V4.1

8 dBm

2.4GHz ~ 2.48GHz

IP Rating IPX7

Features and specications are subject to change without prior notice.

Others Information and Licences

For general information about this appliance and handy hints and tips, please visit

www.knowhow.com/ knowledgebank or call

UK: 0344 561 1234 Ireland: 1890 818 575.

Visit Partmaster.co.uk today for

the easiest way to buy electrical

spares and accessories. With over 1 million spares and accessories available we can deliver direct to your door the very next day. Visit www. partmaster.co.uk or call 0344 800 3456 (UK customers only). Calls charged at National Rate.

The symbol on the product or its packaging indicates that this product must not be disposed of with your other household waste. Instead, it is your responsibility to dispose of your waste equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. The separate collection and recycling of your waste equipment at the time of disposal will help conserve natural resources and ensure that it is recycled in a manner that protects human health and the environment.

For more information about where you can drop o your waste for recycling, please contact your local authority, or where you purchased your product.

The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of s uch marks by DSG Retail Limited is under license. Other trademarks and trade names are those of their respective owners.

All trademarks are the property of their respective owners and all rights are acknowledged.
