WALL MOUNTING UNITS INSTRUCTIONS
EINHEIT ZUR WANDMONTAGE BEDIENUNGSANLEITUNG
DISPOSITIF D’INSTALLATION MURALE MANUEL D’INSTRUCTIONS
WANDMONTAGE-EENHEID GEBRUIKSAANWIJZING
UNIDAD PARA MONTAJE MURAL MANUAL DE INSTRUCCIONES
UNITÀ DI MONTAGGIO A PARETE ISTRUZIONI
1
Thank you for purchasing this Wall Mounting Unit.
We recommend that you read this manual thoroughly before use in order to familiarize yourself with this unit.
Please store this manual in a safe place after reading it.
Mounting a plasma display television requires specific technical knowledge. Do not attempt to mount the unit by
yourself.
Please be aware that screw holes and anchor bolts will remain in the wall surface if the Wall Mounting Unit is
removed after having been mounted to the wall.
Long-term use of the plasma display may result in discoloration of the wall surface due to heat/air emitted by the
display.
For Assembly By Authorized Service Personnel Only
Consult authorized service personnel for the installation of this unit. Installation
instructions must be followed precisely in order to prevent accidents. We are
selling this product with the understanding that it will be assembled and installed
by properly trained and qualified service personnel.
We are not liable for any damage caused by faulty assembly,
faulty wall mounting, insecure wall mounting, misuse,
alterations, or natural disasters.
ENGLISH
Danger
Incomplete or inadequate mounting of this unit to the wall may cause it to fall
down, resulting in potentially fatal accidents.
Please consult authorized service personnel for the installation of this unit.
1
Safety Precautions
Explanation of symbols
The following section describes the symbols used in this manual. Read this section prior to using the product for correct usage.
The following items contain information for your safety. Follow these precautions precisely.
Warning and Caution are defined as follows:
Danger
Warning
Caution
Improper handling in disregard of these notices may result in danger of death or bodily
harm.
Improper handling in disregard of these notices may result in bodily injury and even
death.
Mishandling of the unit in disregard of these notices may result in bodily injury or damage
to the unit.
Examples:
The indicates caution (including warning or danger).
The
[ indicates a prohibition, with the specific action indicated either in the circle itself (the
symbol at left means “Do Not Disassemble”), or in the accompanying text.
Assembly and Mounting Warnings
Danger
z Consult authorized service personnel for the installation and attachment of this
unit to the wall. Improper assembly or installation may cause the unit to fall when it is mounted,
which may result in fatal accidents. To prevent this happening, check the strength of the
materials in the mounting surface, and have at least two persons carry out the installation
in a suitable location. Check the material strength again after mounting as well.
Warning
z Using display monitors other than those authorized by JVC with the unit may result in damage or
bodily injury due to the display monitor and stand toppling over.
z Assemble all bolts, nuts and screws securely. Failure to do so may result in display monitor and
wall mounting falling down, potentially causing damage or bodily injury.
z Avoid placing heavy objects on the power cord, as damage to the power cord may result,
causing fire or electric shock.
z This unit does not come with anchor bolts for securing it to walls, etc. Be sure you have
materials on hand as appropriate for the mounting location.
z This task must be performed by at least two persons when attaching the Plasma display to the
wall mounting unit.
2
Mounting the Wall Unit
x10
Warning
■ The Wall Mounting Unit should be mounted to a wall that can adequately
hold the total weight of the plasma display and the Wall Mounting Unit
over a long period of time and which can adequately withstand
earthquakes, conceivable vibrations, and other external forces.
Improper installation may cause the plasma display to fall down, resulting in
physical injury.
z Mounting On Wooden Walls
The weight of the unit should be borne by the wall posts or studs, and these
should be reinforced if insufficiently strong. Do not install the Wall Mounting
Unit on walls made of plasterboard or thin plywood. Use the commercially sold
screws best suited for the wall structure and material.
z Mounting On Concrete Walls
Use commercially sold wall anchors capable of supporting the weight of the
plasma display.
ENGLISH
■ Do not install the Wall
Mounting Unit in a
location which is hot or
humid or which may
become wet, as the
presence of excessive
moisture may lead to fire
or electric shock.
■ Do not install the Wall
Mounting Unit near the
blower or air inlet of an
air conditioner.
■ Do not install the unit in a
location with a large
amount of dust, soot, or
cigarette smoke, as this
may lead to fire.
■ Do not install the Wall
Mounting Unit in a
location subject to
frequent vibration, impact
or other external forces.
The unit may fall down or
be damaged, causing
physical injury.
■ Do not install the unit in a
location where people
may hang on it or lean
against it.
Doing so may cause the
unit to fall down or be
damaged, resulting in
injury.
Minimum
15 cm
Minimum
20 cm
■ Do not block the
ventilation holes, and be
sure to leave sufficient
space around the unit for
ventilation.
Inadequate ventilation may
cause the unit interior to
overheat, leading to fire.
■ Do not install the Wall
Mounting Unit on a nonvertical wall.
The unit interior may
overheat, resulting in fire,
or the unit may fall down,
causing physical injury.
■ Do not install the unit in a
location exposed to
direct sunlight or strong
light, as viewing the
plasma display in an
overly bright
environment can be tiring
for the eyes.
3
Caution
z Consult authorized service personnel for electrical work. Using power cords damaged during
installation (i.e., exposed or severed wiring) may result in fire or electric shock.
z Conduct the work with adequate working space. Damage or bodily injury may result from
working under unsuitable conditions.
z Avoid mounting this unit in areas where there is electrical wiring or water pipes, as fire or electric
shock may result.
Instructions for using the Wall mounting unit
In order to secure the Plasma Panel and Wall mounting units correctly, please refer to the attached Location Sheet
for instruction.
4
2
© 2003 VICTOR COMPANY OF JAPAN, LIMITED
LCT1500-001A-U
0703-T-CR-JMUK
AEM1112-001A-U
PD-42D30ES
164mm
164mm
164mm
164mm
164mm
164mm
189mm
189mm
90mm
2
400mm
400mm
400mm
400mm
189mm
189mm
5b
3
x10
1
5a
4
x10
42V
42V
42V
42V
42V
42D
42D
42D42D
35D 35D
35D
35D
6
20˚
5c
