JVC RD-EZ11 User Manual

CD PORTABLE SYSTEM

RD-EZ11

Thank you for purchasing a JVC product.

Before operation, please read the instructions

carefully.

INSTRUCTIONS

LVT1977-002A

[J]

For customer use:

Enter below the Model No. and Serial No. which are
located either on the rear, bottom or side of the cabinet.
Retain this information for future reference.

Model No.
Serial No.

EN

©2009 Victor Company of Japan, Limited

Warnings, Cautions and Others
Mises en garde, précautions et
indications diverses

The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.

The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.

Le symbole de l’éclair à l’intérieur d’un
triangle équilatéral est destiné à alerter
l’utilisateur sur la présence d’une “tension
dangereuse” non isolée dans le boîtier du
produit. Cette tension est suffisante pour
provoquer l’électrocution de personnes.

Le point d’exclamation à l’intérieur d’un
triangle équilatéral est destiné à alerter
l’utilisateur sur la présence d’opérations
d’entretien importantes au sujet desquelles
des renseignements se trouvent dans le
manuel d’instructions.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT
EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.

AVERTISSEMENT :

POUR PRÉVENIR LES RISQUES D’INCENDIE OU DE
CHOCS ÉLECTRIQUES, NE PAS EXPOSER CE APPAREIL À
LA PLUIE OU À L’HUMIDITÉ.

0509RYMMDWMTS

For U.S.A.
Caution: Changes or modifications not expressly

approved by party responsible for compliance could
void the user’s authority to operate the equipment.

Note: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and

receiver.

– Connect the equipment into an outlet on a

circuit different from that to which the receiver is
connected.

– Consult the dealer or an experienced radio/TV

technician for help.

Pour les Etats-Unis
Attention : Les changements ou les modifications

qui ne sont pas explicitement approuvés par la partie
responsable de l’observance pourraient mettre fin au
droit de l’utilisateur d’utiliser le matériel.

R

emarque : Cet appareil a été testé et il s’est avéré

conforme aux limites applicables à un appareil
numérique de classe B, en vertu de la Partie 15
des Règles de la FCC. Ces limites sont conçues de
manière à assurer une protection raisonnable contre
les interférences nuisibles dans une installation
résidentielle. Cet appareil produit, utilise et peut émettre
une énergie de haute fréquence et, s’il n’est pas installé
et utilisé en conformité avec les instructions, il peut
causer des interférences nuisibles aux communications
radio. Il n’y a, toutefois, aucune garantie que des
interférences ne se produiront pas dans une installation
particulière. Si cet appareil cause effectivement des
interférences nuisibles à la réception de la radio ou de
la télévision, ce qu’on peut établir en mettant l’appareil
en marche et à l’arrêt, nous encourageons l’utilisateur à
tenter de corriger l’interférence par une ou plusieurs des
mesures suivantes :
– réorienter ou déplacer l’antenne de réception ;
– accroître la séparation entre l’appareil et le récepteur ;
– brancher l’appareil dans une prise ou un circuit autre

que celui auquel le récepteur est branché ;

– consulter un vendeur ou un technicien radio/TV

expérimenté pour obtenir de l’aide.

For Canada/pour le Canada

THIS DIGITAL APPARATUS DOES NOT EXCEED THE CLASS
B LIMITS FOR RADIO NOISE EMISSIONS FROM DIGITAL
APPARATUS AS SET OUT IN THE INTERFERENCE-CAUSING
EQUIPMENT STANDARD ENTITLED “DIGITAL APPARATUS,”
ICES-003 OF THE DEPARTMENT OF COMMUNICATIONS.

CET APPAREIL NUMERIQUE RESPECTE LES LIMITES
DE BRUITS RADIOELECTRIQUES APPLICABLES AUX
APPAREILS NUMIRIQUES DE CLASSE B PRESCRITES DANS
LA NORME SUR LE MATERIEL BROUILLEUR; “APPAREILS
NUMERIQUES”, NMB-003 EDICTEE PAR LE MINISTRE DES
COMMUNICATIONS.

CAUTION

To reduce the risk of electrical shocks, fire, etc.:

1. Do not remove screws, covers or cabinet.

2. Do not expose this appliance to rain or moisture.

ATTENTION

Afin d’éviter tout risque d’électrocution, d’incendie, etc.:

1. Ne pas enlever les vis ni les panneaux et ne pas ouvrir le
coffret de l’appareil.

2. Ne pas exposer l’appareil à la pluie ni à l’humidité.

CAUTION

The

OFF switch in any position does not disconnect the
mains line.
Disconnect the mains plug to shut the power off completely.
The MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain
readily operable.

ATTENTION

Le commutateur
coupe pas la ligne principale.
Débrancher la fiche principale pour couper complètement
l’alimentation du secteur.
La fiche secteur ou un coupleur est utilisé comme dispositif
de déconnexion de l’appareil, et l’appareil déconnecté doit
être prêt à être utilisé.

CAUTION: Battery shall not be exposed to excessive heat
such as sunshine, fire, or the like.

ATTENTION:

à une chaleur excessive (lumière du solei, feu, etc.).

OFF, quel que soit sa position, ne

Les piles ne doivent en aucun cas être exposées

[European Union only]

[Union européenne seulement]

SPECIFICATIONS

CD player

CD capacity: 1CD

Signal-to-noise ratio: 60 dB

Dynamic range: 60 dB

Tuner

FM tuning range: 88 MHz – 108 MHz

AM tuning range: 530 kHz – 1 700 kHz

Antennas: Telescopic antenna for FM

Ferrite core antenna for AM

General

Speakers: 9 cm (3-9/16 in) cone x 2

Speaker impedance:

Output power: 1.5 W per channel, min. RMS,

Input terminal:

Power supply: AC 120 V

Power consumption: 10 W (at operation)

Dimensions (W/H/D): 306 mm x 238 mm x 140 mm

Mass: Approx. 1.7 kg (3.8 lbs)

Accessories provided: Power cord x 1

Design and specifications are subject to change without notice.

4 Ω

driven into 4 Ω at 1 kHz with no
more than 10% total harmonic
distortions

AUDIO IN (φ 3.5) x 1

, 60 Hz

DC 9 V (R14(SUM-2)/C(14D)

-size batteries x 6)

1 W or less (on standby)

(12-1/16 in × 9-3/8 in × 5-9/16 in)

(without batteries)

IMPORTANT FOR LASER PRODUCTS

1. CLASS 1 LASER PRODUCT

2. CAUTION: Do not open the top cover or cabinet.
There are no user serviceable parts inside the unit;
leave all servicing to qualified service personnel.

3. CAUTION: Visible and/or invisible class 1M laser
radiation when open. Do not view directly with optical
instruments.

4. REPRODUCTION OF LABEL: CAUTION LABEL, PLACED
INSIDE THE UNIT.

IMPORTANT POUR PRODUITS LASER

1. PRODUIT LASER CLASSE 1

2. ATTENTION: N’ouvrez pas le couvercle supérieur ni
le coffret de l’appareil. Il n’y a aucune pièce réparable
par l’utilisateur à l’intérieur de l’appareil; confiez toute
réparation à un personnel qualifié.

3. ATTENTION: Rayonnement laser visible et/ou
invisible de classe 1M une fois ouvert. Ne pas regarder
directement dans le faisceau avec des instruments
optiques.

4. REPRODUCTION DE L’ÉTIQUETTE: ÉTIQUETTE DE
PRÉCAUTION PLACÉE À L’INTERIEUR DE L’APPAREIL.

CAUTION: Proper Ventilation

To avoid risk of electric shock and fire, and to prevent
damage, locate the apparatus as follows:

1. Front: No obstructions and open spacing.

2. Sides/Top/Back: No obstructions should be placed
in the areas shown by the dimensions below.

3. Bottom: Place on the level surface. Maintain an
adequate air path for ventilation by placing on a
stand with a height of 10 cm or more.

ATTENTION: Aération correcte

Pour prévenir tout risque de décharge électrique
ou d'incendie et éviter toute détérioration, installez
l'appareil de la manière suivante:

1. Avant: Bien dégagé de tout objet.

2. Côtés/dessus/dessous: Assurez-vous que rien ne
bloque les espaces indiqués sur le schéma
ci-dessous.

3. Dessous: Posez l’appareil sur une surface plane et
horizontale. Veillez à ce que sa ventilation correcte
puisse se faire en le plaçant sur un support d’au
moins dix centimètres de hauter.

Front view/Face Side view/Côté

CAUTION

• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by

a newspaper or cloth, etc., the heat may not be able
to get out.)

• Do not place any naked flame sources, such as
lighted candles, on the apparatus.

• When discarding batteries, environmental
problems must be considered and local rules or
laws governing the disposal of these batteries must
be followed strictly.

• Do not expose this apparatus to rain, moisture,
dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the
apparatus.

ATTENTION

• Ne bloquez pas les orifices ou les trous de
ventilation.

(Si les orifices ou les trous de ventilation sont

bloqués par un journal un tissu, etc., la chaleur peut
ne pas être évacuée correctement de l’appareil.)

• Ne placez aucune source de flamme nue, telle
qu’une bougie, sur l’appareil.

• Lors de la mise au rebut des piles, veuillez prendre
en considération les problèmes de l’environnement
et suivre strictement les règles et les lois locales sur
la mise au rebut des piles.

• N’exposez pas cet appareil à la pluie, à l’humidité,
à un égouttement ou à des éclaboussures et ne
placez pas des objets remplis de liquide, tels qu’un
vase, sur l’appareil.

REFERENCES

Playable discs

You can play back CDs with one of the marks below on the surface.

• You can also play back files in audio CD format on a finalized
CD-R or CD-RW.
– The reflection factor of CD-RW is lower than that of other

CDs, possibly causing CD-RW to take a longer time to read.

Care and maintenance

To get the best performance from the unit, keep your discs and mechanism clean.

Cleaning the unit

• Disconnect the power cord before cleaning.

• Wipe off stains with a soft cloth. If the unit is heavily stained, wipe it with a cloth soaked in water­diluted neutral detergent and wrung well, then wipe clean with a dry cloth.

• Since the unit may deteriorate in quality, become damaged or get its paint peeled off, be careful about
the following:
– DO NOT wipe it with a hard cloth.
– DO NOT wipe it forcefully.
– DO NOT wipe it with thinner or benzine.
– DO NOT apply any volatile substances such as insecticides to it.
– DO NOT allow any rubber or plastic to remain in contact for a long time.

Cleaning the CD pickup lens

Keep the CD pickup lens clean, or the sound may be degraded.
Use a blower (available at a camera store, etc.) to blow dust off
the lens.

Handling discs

• Remove the disc from its case by holding it at the edge while pressing the center hole lightly.

• Do not scratch or touch the reflective recorded surface.

• Do not stick or write anything on the label side.

• Do not bend discs.

• Avoid exposure to direct sunlight, extreme temperature or moisture.

• When cleaning the disc, wipe it with a soft cloth in a straight line from center to edge. DO NOT use
thinner, benzine, record cleaner or antistatic spray.

Blower

Lens

Troubleshooting

If you have a problem with this unit, check this list
for a possible solution before calling for service.

General

Power does not come on.

\ No power is supplied. Check the power cord

connection or battery power.

Playback sound is at a very low level.

\ When power is supplied with batteries: Batteries

are run down. Replace the batteries with new
ones.

No sound is heard.

\ The volume is set to minimum.

Radio operations

Hard to listen to broadcasts because of noise.

\ Direction of the antenna is inappropriate. Adjust

the antenna correctly.

Disc operations

The disc does not play.

\ The FUNCTION selector is not set to CD.
\ The disc is placed upside down. Place the disc

with the label side facing up.

\ The disc or the lens is dirty. Clean the disc or the

lens.

\ There is moisture condensation. Turn the unit

on and wait a few hours before use.

The sound is discontinuous.

\ The disc is scratched or dirty.

Other equipment operations

The sound from the other equipment cannot be
heard.

\ The FUNCTION selector is not set to AUDIO IN.
\ Check the connection.

PREPARATION

Connecting the power cord

NOTE

Power cord

(supplied)

AC outlet

Inserting batteries

Match the polarities (+ and –) of the batteries.

Battery compartment

NOTE

• The power will not be supplied through the batteries when the power is supplied through the AC IN jack on the unit.

• The battery is consumed more quickly than usual when operating the unit continuously or operating it in a cold place.

CAUTION

To avoid battery leakage or explosion, handle batteries properly.

• If you are not going to use this unit for a month or more, remove the batteries from the battery compartment.

• Dispose of batteries in the proper manner, according to federal, state, and local regulations.

• Do not mix with batteries of different types or with new and old ones.

• Do not attempt to charge any batteries other than rechargeable ones.

• Discard leaky batteries immediately. Battery leakage can cause skin burns or other personal injuries.

• If chemicals leak onto the unit, clean the unit completely.

• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.

• The power can also be supplied through the batteries (see below).

• A small amount of power is always consumed even while on standby.

CAUTION

• Only use JVC power cord provided for this unit to avoid malfunction or

damage to the unit.

• Remove batteries when using the power cord.

• Be sure to unplug the power cord from the outlet when going out or when

the unit is not in use for an extended period of time.

R14(SUM-2)/C(14D)
(not supplied)

GENERAL CONTROLS

TUNER OPERATIONS

Improving the FM reception

Volume knob and
function selector

Disc controls

Selecting the source to play

Disc holder

Radio controls

Display

Adjusting the volume Turning the unit off

Basic procedure

1 Set the source to TUNER.

2 Select the band—FM or AM.

3 Select a station.

Moves to indicate the

current frequency

When an FM stereo (FM ST) broadcast is hard to receive or noisy, select the monaural reception
(MONO).

• To restore stereo reception, switch to FM ST.

Adjusting the antenna

FM

AM

The AM antenna is built in, so adjusting the
position of the unit may help AM reception.

Slide the FUNCTION selector to select CD, TUNER
or AUDIO IN.

CD:

To play back a disc. (See “DISC OPERATIONS.”)

TUNER:

To listen to the radio broadcast. (See “TUNER
OPERATIONS.”)

AUDIO IN:

To listen to the other equipment connected to
the AUDIO IN jack. (See “LISTENING TO OTHER
EQUIPMENT.”)

DISC OPERATIONS

Turn the VOLUME knob to increase or decrease the
volume.

• Set the volume to minimum when you turn on the
unit.

Decrease

Increase

Slide the FUNCTION selector to OFF.

Program playback

Up to 20 tracks can be programmed to play in a
desired order.

To program the playing order

While playback is stopped...

1 Show the program creation display.

4 Repeat steps 2 and 3.

• When the 20th track is programmed, “- - -”
flashes on the display and the 21st track
cannot be programmed.

5 Start playback.

4 Adjust the volume.

LISTENING TO OTHER

Repeat/Random playback

EQUIPMENT

Select the desired playback mode.

Playback mode indicator (See below.)

Each time you press the button, the playback
mode changes as follows:

Basic procedure

1 Load a disc.

2 Set the source to CD.

The total number of
tracks

3 Start playback.

The current track
number

4 Adjust the volume.

To stop playback

To pause playback

• To resume, press the same button again.

To select a track

To locate a desired position on the disc

During playback...

Press and hold

Program number

• Now you can select the first track of the
program.

2 Select a desired track.

3 Add the track to the program.

• The next program number appears on the
display, then track selection display is shown.

Program number

• After program playback ended or stopped, the
program playback mode is automatically canceled.
(The PROGRAM indicator disappears from the
display.)

To play back the program again, press PROGRAM,

then PLAY/PAUSE 6.

To edit the program

1 While playback is stopped, press PROGRAM

repeatedly to select the program number of the
track you want to replace.

• To add a track at the end of the program, select

the last program number.

2 Perform steps 2 and 3 on the left column to select

a new track.

To erase the entire program

While playback is stopped...
1 Press PROGRAM.

• PROGRAM indicator lights up on the display.

2 Press 7.

• The entire program is also erased in the following
cases:
– when you open the disc holder.
– when the unit is turned off.
– when you select another source.

Indicator Playback mode
REPEAT Repeats the current track.
REPEAT ALL Repeats all tracks.
RANDOM Plays tracks at random.

To cancel, press the same button repeatedly until
the indicator above disappears from the display.

• Repeat playback is also canceled if the playback
is stopped.

• Random playback cannot be used during
program playback. If you program the playing
order during random playback, random
playback is canceled.

Basic procedure

1 Turn the volume to minimum.

2 Connect the equipment.

• Connect the equipment with the stereo
mini plug (3.5 mm (3/16 in) diameter) to
the AUDIO IN jack on the rear.

3 Set the source to AUDIO IN.

4 Start playing the equipment.

5 Adjust the volume.
