HD/SD Memory Card Camcorder
GY-HM650
Shown with optional microphone.
ftp
GPS
Wireless Connectivity,
FTP and Live Streaming
Newly-developed 23x Fujinon Lens
and Full HD 1/3-inch CMOS Sensors
The Fujinon wide angle 23x zoom lens provides
superb sharpness and excellent low-light performance
in tandem with three CMOS sensors with extremely
high sensitivity of F11 (60Hz) /F12 (50Hz) at 2000 lux.
Minimum illumination is an incredible 0.15 lux (typical.)
Dual Codec for Simultaneous Full
HD/SD and web-ready recording
The revolutionary new dual codec makes it possible
to record in two different resolutions, such as HD
and SD, or two different HD formats, to separate
memory cards at the same time.
Wi-Fi and Network Connectivity,
FTP and Live Streaming
Featuring Wi-Fi and network connectivity,
remote viewing is possible, while video and
audio data can be delivered to the studio via
FTP. The latest firmware update also enables
live video streaming, even while recording.
Wide Media Format Compatibility and Support for Data-rich MXF Files
The GY-HM650 records HD or SD footage to SDHC / SDXC cards in a range of file formats,
including MP4 file format (XDCAM EX™ workflow-compatible), MOV (Final Cut Pro™
compatible), and AVCHD. The camera now also supports MXF files with rich descriptive
metadata, which can be sent to the camera via Wi-Fi.
Introducing the GY-HM650, a ProHD handheld news
camera equipped with dual codecs, built-in FTP and
Wi-Fi connectivity for shooting and delivering news
footage faster than ever. Thanks to a free firmware
update, the GY-HM650 now makes live video
streaming possible too; when equipped with
Wi-Fi, 4G or 3G connectivity via USB, the camera
can stream live video transmissions in the
background while continuing to record footage.
Wi-Fi Remote Control of Camcorder
(iOS and Android OS)
Shooting
Dual Codec
Direct File Transfer
via Wi-Fi
HD/SD File
Video
Audio
Metadata
ftp
GPS
ftp
1
Shown with optional microphone.
Fujinon 23x Optical
Zoom Lens
Newly-developed Fujinon
wide angle 23x zoom lens
delivers superior low-light
performance and
the highest magnification
in the industry.
FALCONBRID™
JVC’s high-speed processor for advanced
video applications achieves stunning
image quality with superior processing
power on a single chip.
3.5-inch 920K pixel
LCD Monitor
The top-mounted
position of the
high-resolution 3.5-inch
LCD monitor is ideal
for shooting at various
angles in handheld
camera applications.
Full HD 1/3-inch CMOS Sensors
Three CMOS sensors offer an excellent sensitivity
of F11 (60Hz) / F12 (50Hz) and a remarkable
signal-to-noise ratio for superior precision
and vivid colour reproduction.
Optical Image Stabilizer
Helping to correct lateral and vertical
movement of the camera, the built-in OIS
ensures that pristine HD images remain
sharp and stable.
Focus Assist
JVC's patented focus assist system highlights
the edges of objects in the image to help
the operator keep the action in focus.
0.45-inch 1.22M pixel
Colour Viewfinder
Stunning new high-resolution LCOS viewfinder with
a crisp and detailed 16:9 aspect ratio image.
SDXC/SDHC Memory Card Recording
Dual SDHC/SDXC card slots allow footage to be
recorded either to both cards simultaneously, or
from one card to the other in relay.
Innovative Features without Compromise
3 4
ND Filters
Equipped with a built-in
4-position ND filter for greater
flexibility through a range of
lighting situations.
Shown with optional microphone.
Expanding the Possibilities with Advanced
Features in a High Definition Camcorder
Newly-developed 23x Fujinon Auto Focus Zoom
Lens with Manual Functions
The GY-HM650 is equipped with the newly-developed
Fujinon wide angle 23x zoom lens, giving the highest
magnification in the industry. Delivering superior
low-light performance and ensuring brightness at the tele end,
the lens offers F1.6-3.0, a focal range of 29mm-667mm
(35mm equivalent) and
includes servo zoom, manual
focus, and iris rings, along
with a four-position (clear,
1/4, 1/16 and 1/64) ND
filter. Other features include
an optical image stabiliser,
and chromatic aberration
correction.
High Performance Full HD 1/3-inch CMOS
Sensors
At the heart of the GY-HM650 are three,
1/3-inch CMOS sensors, each capable of
capturing full HD 1920 x 1080 resolution images.
Offering an excellent sensitivity of F11 (60Hz) /
F12 (50Hz) and a remarkable signal-to-noise
ratio, the devices provide superior precision
and colour reproduction with minimal aberration.
For improved CMOS sensor performance,
flash-band compensation is also supported.
Revolutionary FALCONBRID™ Image
Processing Engine
FALCONBRID™ is JVC’s high-speed processor
for advanced video applications. Delivering
tremendous processing power on a single chip,
the on-board FALCONBRID™ engine processes
large amounts of video data at exceptional
speeds. Together with this technology, superior
image quality has been realized with 2D DNR processing and
compensation circuitry and wide dynamic range.
MPEG-2/AVCHD Recording and Dual Codec
The GY-HM650 supports both the popular
MPEG-2 Long GOP 35/25/19Mbps format,
widely used by television broadcasters, and the highly efficient AVCHD
24/17Mbps mode, which provides compatibility with a wide range
of affordable editing systems. This means that professionals have
unprecedented flexibility to meet production standards through a wide
range of workflows. With the revolutionary dual codec,
the GY-HM650 now also supports simultaneous HD/SD or HD/proxy
recording, producing full HD files on one memory card while creating
smaller, web-friendly files on the other. Also supported is
the MPEG-4/AVC H.264 8Mbps SD format.
The GY-HM650 further provides the H.264 high-quality 35Mbps
(MOV) recording mode used in HD SLRs, meaning higher bit rates for
even better image quality. The 35Mbps bit rate is high enough to
support full 1920 x 1080 encoding, resulting in stunningly detailed,
Superior HD Imaging
Advanced Processing Engine Flexible File-based Workflow
Storage
Storage
Blu-ray
File
Server
Network
Blu-ray
File
Server
Network
QuickTime™ MOV File Workflow
Direct file access to Apple’s Final Cut Pro™
SDHC
SDXC
SDHC
SDXC
USB 2.0
SDHC Memory
Card Reader
SDHC Memory
Card Reader
XDCAM EX™ Compatible MP4 File
Workflow
Ingest MP4 clips to major NLE systems
USB 2.0
Avid
Adobe
Canopus
Apple
Avid
Adobe
Apple
Compatible NLE System
Apple Final Cut Pro™ 6.0.4 or later
Adobe Premiere Pro CS5 or later
Compatible NLE Systems
Adobe Premiere Pro CS4 4.0.1 or later
Avid Media Composer 3.5 or later
Avid News Cutter 3.5 or later
Grass Valley/Canopus Edius Pro 5.0 or later
Apple Final Cut Pro™ 6.0.4 or 7.0
Avid Media Composer 5.5 or later
Avid News Cutter 5.5 or later
Multiple File Formats for Native Workflows
Record HD or SD footage directly in
ready-to-edit QuickTime™ MOV files,
the native file format of Apple’s Final Cut
Pro™. JVC has eliminated one of the main
obstacles to achieving a smoother, more
streamlined production workflow. Native file
recording ensures your footage is ready to
edit the moment it’s shot, resulting in a more
efficient workflow and no loss of image quality.
Additionally, with the MPEG-2 mode for
Windows editing environments, it is possible
to record in MP4 format (XDCAM EX™
workflow-compatible) for direct editing in other
major NLE systems, including Avid Media
Composer, Adobe Premiere and Grass Valley
Edius Pro.
Dual SDHC/SDXC Card Slots for Maximum Versatility
Dual SDHC/SDXC card slots make the GY-HM650 a truly versatile
camcorder, offering such benefits as simultaneous recording and relay
recording with reliable and cost-effective media.
In relay recording mode, you can shoot continuously and seamlessly
over multiple cards. When one card is full, the camcorder switches
seamlessly and automatically to the other card. And because cards
are hot swappable, there is in effect no limit to the continuous shooting
time in any mode, even with lower capacity cards. It is possible to start
editing footage from one card while still shooting to the other. With
simultaneous recording, you can easily create backup or duplicate files
as you shoot without the need for any external equipment – either for
a client copy or simply for peace of mind. Additionally, while the Rec
trigger is used to pause and unpause recording on one card, the other
card can act as a continuous backup that overrides the pause function.
With the new dual codec, it is now possible to record full HD files on one
memory card while simultaneously creating smaller SD or proxy files on
the other, providing the flexibility for a range of workflow possibilities.
SDHC/SDXC media offers the best combination of price, availability,
capacity, reliability and transfer speed. With no moving parts and no pins
or other extrusions, SDHC/SDXC cards are both durable and reliable,
and compare favorably with tape on a cost-per-minute basis.
* During simultaneous back-up recording in HD mode, the duplicate file records
in the same file format and bit rate as the original.
5 6
23x
Zoom Lens
MPEG-2 AVCHD
1920 x 1080
1440 x 1080
1280 x 720
720 x 576
720 x 480
60i/50i
30p/25p/24p
60i/50i 60i/50i
60p/50p
30p/25p/24p
60p/50p
60i/50i 60i/50i
MOV/MP4/MXF MOV/MP4/MXF
MTS MTS
MOV/MP4/MXF
HQ mode
(35Mbps)
SP mode
(25Mbps)
SP mode
(19Mbps)
HQ mode
(24Mbps)
SP mode
(17Mbps)
HDSD
Proxy
480 x 270
MPEG-4/AVC H.246
1920 x 1080
1440 x 1080
1280 x 720
720 x 576
720 x 480
60i/50i
50i (GY-HM650E)
60i(GY-HM650U)
30p/25p/24p
MOVMOV MOV
UHQ mode
(35Mbps)
SD mode
(8Mbps)
Web mode
(0.8Mbps)
HDSD
Proxy
480 x 270
Card 1
Change Change
Card 2
Card 3 Card 4
Slot A Slot B
Slot A Slot B
HD File
HD File
or
SD File
or
Proxy File
HD, HD/SD or HD/Proxy
Dual Record
Relay Recording
Card 1
Card 2
While Card1 record continuously, Card2 independently perform Rec start /
Rec pause at Rec trigger.
Back up Recording
Rec
Start
Scene 1 Scene 2 Scene 3
Rec
Pause
Rec
Start
Rec
Pause
Rec
Start
Rec
Pause
broadcast standard HD images. In addition, the onboard
H.264 video format Web mode (0.8Mbps) allows for
quick on-location data transfers, allowing footage to
be delivered faster than ever.
MPEG-2
MPEG-4/AVC H.264 Ultra High-Quality (UHQ) 35Mbps Recording Mode and Proxy Recording
UHQ
Ultra-High
Quality
Wide end Tele end
Conventional 1/3" device New Full HD CMOS
F11/F12
Sensitivity
(60Hz) (50Hz)
3.5 inch
High-Performance Features
User Friendly Functions
Superb Portability and
Compact Design
With a stylish body that fits
boldly within the distinctive
range of ProHD camcorders,
the compact dimensions
and superb portability of the
GY-HM650 allow it to be
used anywhere. Lightweight
(2.45kg/5.4lbs operating
condition), versatile and extremely easy to use,
it is the perfect camcorder for next generation acquisition.
Shooter-Friendly Controls and Layouts
Ergonomics has played a major role in the design of the GY-HM650.
The camcorder's handgrip makes it very comfortable to hold, even on
long shoots. And despite its extremely compact dimensions, all the
camcorder’s main functions are accessible directly from controls and
switches on the camera body, right where you would expect them to be.
High-Resolution 920K pixels 3.5" LCD Monitor
The high-resolution 920K pixels 3.5" 16:9 aspect ratio LCD monitor
provides a wide array of monitoring and setup indications.
For maximum flexibility, the monitor is mounted at the top
of the camera, ideal
for shooting at various
angles in handheld
camera applications.
1.22 Megapixel LCOS Viewfinder
The GY-HM650 features a stunning new
high-resolution (852 x 480 x 3) LCOS
(Liquid Crystal on Silicon) 0.45" viewfinder.
The 16:9 image is crisper and more
detailed than conventional LCD viewfinders,
with higher vertical resolution and superior
RGB colour separation
GUI
The GY-HM650 takes ProHD's highly regarded GUI navigation
to the next level. Not only are menu items immediately accessible, but
settings can also be easily checked right from the settings window. With
an improved graphical interface, it’s easier than ever to customize the
settings to match individual preferences or the demands of the moment.
• White balance – Selectable
between preset and two user
settings
• Gain – (L,M,H) -6, -3, 0, 3, 6, 9,
12, 15,18, 21, 24 dB & Lolux, AGC
can be assigned to the “L/M/H”
gain switch
• Full Auto – (on/off)
• ND Filter – (Clear, 1/4, 1/16, 1/64)
• Auto/Manual Focus, One Push
Auto
• Shutter – Speed selectable by
cross keys
• Focus Assist/User 1 – (on/off)
• OIS/User 2 – (on/off)
• LoLux/User 3 – a JVC exclusive
feature that permits shooting in
adverse lighting conditions
• AE LOCK/User 4 – (on/off)
7 8
Pre Rec Mode
How many times have you missed a crucial moment because you didn’t
hit the record button in time? With Pre Rec enabled, the camcorder
continuously buffers up to 15 seconds of video, so that when recording
is started the cached video is included in the recorded file, giving you an
up to 15 second head start.
Interval Rec
This feature allows you to record single frames at set intervals,
which can be used to shoot slow-moving scenes, such as sunsets
or construction, or to capture time-lapse recordings, such as the
growing of plants.
Focus Assist Function
Helping the camera operator stay focused on the action is a focus
assist system that highlights the edges of objects in the image.
When Focus Assist switched on, the image in the viewfinder or LCD
monitor switches to monochrome and all objects that are in focus
appear with coloured edges (selectable from red, green or blue).
Keeping the important elements in the picture in focus while shooting
is greatly simplified.
Audio Recording and Monitoring Flexibility
The GY-HM650 provides a number of essential audio features.
Its built-in stereo microphone is ideal for capturing natural sound on
location, but the camera also includes two mic/line selectable XLR inputs
with phantom power. The side panel is
equipped with screws to attach a holder
for an optional wireless receiver, for which
there are dedicated mic and headphone
jacks. Also equipped with an audio
equalizer, sound can be adjusted to your
liking from the GUI.
Cutting-Edge Connectivity
Equipped with leading edge connections,
the GY-HM650 offers versatility while meeting
the needs of professional applications. For easy
monitoring of footage, you can monitor from
the digital SDI and HDMI outputs simultaneously,
easily switching between output in HD or SD.
High-Capacity Battery Systems
Capture more footage and clock more recording time with the newly
developed high-capacity (4900mAh) battery. In addition, it is also
possible to charge the battery when the camera is switched off
and plugged in using the AC adapter.
JVC ProHD Clip Manager
The ProHD Clip Manager for both Mac and Windows makes it easy
to manage MP4 clips on the GY-HM650’s memory cards from your
computer. With a few clicks of the mouse you can copy, move
or delete clips, preview clip content, as well as view and edit clip
metadata. A thumbnail view of all the clips in the current folder shows
the content of each clip at a glance. Use the viewer to watch
the whole clip, or change the clip's index frame used for the thumbnail.
You can also manage folders to keep your clips organized, and check
the remaining free space on a card. The latest version of ProHD Clip
Manager offers an even greater level of NLE compatibility by enabling
MP4 files to be converted to m2t, widely supported by NLEs.
ProHD Log and Transfer Plug-in
The ProHD Log and Transfer Plug-in is a plug-in for Apple’s Final Cut
Pro™ that lets you drop MP4 files recorded on the GY-HM650 into
the clip bin. With the plug-in installed, you can view thumbnails of
the MP4 files on a memory card from the Log and Transfer screen of
Final Cut Pro™. Simply drag and drop the thumbnails into the bin to
automatically convert the clips to QuickTime™, ready for use.
• SDI (HD/SD) out
• HDMI (HD/SD) out
• TC Sync in/out
• AV out
• USB
• Mic/Line x 2 with
phantom power
• Aux In for Wireless
Receiver
• ø2.5mm Remote Control
• ø3.5mm Stereo
Headphone out
A Powerhouse of Performance and Flexibility
Variable Frame Rate Recording (Over Crank, Under Crank)
When recording in the 720p 35Mbps mode, the camera can be set
to record at a frame rate different than the playback rate. This capability
makes it possible to record slow or fast motion when the recording is
played back at 24p, 25p or 30p. The GY-HM650 can also under-crank
in the 1080p 35Mbps mode.
Supporting Software
• Zebra/User 5 – (on/off)
• Marker/User 6 – (on/off)
Among the controls are seven userdefinable buttons that can be assigned
a range of functions for instant setting
instead of the preset settings.
Wired Remote Control
The GY-HM650 comes with a wired remote interface
(Ø2.5mm connector) for operating the camcorder remotely
when using a tripod, jib, crane or boom.
TC Sync
With TC Sync functionality, two GY-HM650 units
can be synchronized with time code using an RCA
cable. Since the terminal can be used for both
in/out functions, either unit can be the master,
providing for an ideal multi-camera operation setup.
Focus Assist OFF Focus Assist ON
Shown with optional microphone.
Discover the Next Stage with Wi-Fi
Professional Display
System Configuration
Dimensions
Unit: inches (mm)
9 10
Network Connectivity for Next-Level
Functionality
The GY-HM650 is equipped with a USB 2.0
host function so that you can connect
the main unit directly to a network adapter
for Wi-Fi or 3G/4G functionality. This allows
remote viewing of camera images, wireless
remote control, and transfer of recorded images with a PC or portable
device – such as a tablet or smartphone – using Wi-Fi direct or via an
access point.
The GY-HM650 allows you to record full HD files on one SDHC/SDXC
memory card while simultaneously creating smaller proxy files
(H.264/MOV files at 0.8Mbps:480 x 270 30p/25p/24p) on the other.
With the built-in FTP client function, you can transfer captured audio
Smartphone, Tablet
The GY-HM650 supports the MXF file
format, which allows rich metadata,
such as capture information sent via
the FTP function, or onboard GPS
data, to be embedded into the file.
This descriptive metadata is essential to
efficient operation of asset management
systems for recorded data.
Wi-Fi Adapter
Headphone
SDI cableBNC
HDMI cable
Battery
SSL-JVC50 (IDX)
USB Wi-Fi or 3G/4G adapter
Battery charger
LC-2J(IDX)
GY-HM650
Battery
(SSL-JVC50)
AC adapter
DC cable
AV cable
On camera light
Monitor/Switcher etc
Shoulder belt
Tripod
Microphone
MKH416 (Sennheiser)
or equivalent
Wireless microphone
receiver
EW112-p (Sennheiser)
UCR100 (Lectrosonics)
or equivalent
Wide conversion lens
WHV-077 (Zunow)
WCX-08 (Zunow)
HDWC8X-72 (16x9)
or equivalent
Rain cover
PR410 (Petrol)
or equivalent
Soft carrying bag
PC202 (Petrol)
PC003 (Petrol)
or equivalent
Remote Control Unit
VZ-Stealth (Varizoom)
ZC-3DV (Libec)
MVR901EPLA (Manfrotto)
521LX (Manfrotto)
or equivalent
Server
Cam1_002345.MXF
Cam1_002346.MXF
Cam1_002347.MXF
●
MOS Code
●
Story Slug
●
Photographer
●
GPS etc.
MXF data
Video
Audio
Meta data
Metadata
Range of FTP Functions via Network
and video directly from the field via an optional Wi-Fi adapter
or 3G/4G network adapter. From high-quality HD video to light,
web-friendly proxy video data, delivering footage back to the studio
has never been faster or easier.
Support for MXF Files with Rich Metadata
FTP
Client
GY-HM650
Server A
PC/Smartphone
Server B
Wi-Fi
Adapter
AP + Router
Internet
P to P (Wi-Fi Direct / Software AP)
AP + Router
Internet
AP + Router
3G/4G
Adapter
Note: 1. Recorded files in any recording mode can be transferred.
2. File transfer is only possible in 'media' mode. It is not possible in 'camera' mode, which means file transfer isn't possible during shooting.
3. It is not compatible with 'Hot Spot' Wi-Fi access points where security authentification is required.
4. Not all Wi-Fi adapters are compatible - only recommended and verified adapters can be used (listed on JVC website).
5. 3G/4G adapters are required for connection to major carrier partners.
2-9/32 (57)
(HOOD)
10-25/32 (269.5)
13-13/16 (345.5)
16-7/64 (402.5)
16-5/8 (415.5)
7-1/8 (178)
7-7/8 (197)
5-15/16 (148.5)
7-1/8 (177.5)
6-37/64 (156.5)
5
-6(
140)
Final Cut Pro is not supplied.
Apple, Apple logo, Macintosh, QuickTime, and Final Cut Pro are trademarks of Apple Inc. registered in the United States and other countries.
“AVCHD Progressive/AVCHD” and the “AVCHD Progressive/AVCHD” logo are trademarks of Panasonic Corporation and Sony Corporation.
Dolby is a registered trademark of Dolby Laboratories. The SD, SDHC and SDXC logos are trademarks of the SD Card Association. HDMI, the
HDMI Logo, and High-Denition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and
other countries. Product and company names mentioned here are trademarks or registered trademarks of their respective owners.
All screen pictures in this brochure are simulated.
Simulated pictures.
The values for weight and dimensions are approximate.
E.&O.E. Design and specications subject to change without notice.
DISTRIBUTED BY
Specification
GY-HM650
[GENERAL]
Power: DC 12V (AC adaptor), DC 7.2V (Battery)
Power consumption: Approx. 14W (with VF and LCD monitor)
Dimensions (W x H x D): 178 x 198 x 416mm (7" x 7-13/16" x 16-3/8")
Mass: Appro.2.45kg (5.4lbs) (including battery)
Operating temperature: 0˚C to 40˚C (32˚C to 104˚C)
Storage temperature: -20˚C to 50˚C (14˚C to 122˚C)
Operating humidity: 35% to 80%
Storage humidity: Under 85%
[CAMERA]
Image sensor: 1/3" 2.2M pixels progressive scan 3CMOS
Synchronizing system: internal synchronization
Stabilizer: Optical image stabilizer
Lens: Fujinon F1.6-3.0, 23x, f=4.1-94.3mm (35mm conversion: 29 to 667mm)
Sensitivity: F11 (60Hz) /F12 (50Hz), 2000lx (typical:ENG mode)
Minimum illumination: 0.15lx (typical) (1920 x 1080 mode, F.1.6, Lolux mode
with 1/30 or 1/25 shutter)
Filter diameter: 72mm
Shutter speed: 1/4 to 1/10000
Gain: -6, -3, 0, 3, 6, 9, 12, 15, 18, 21, 24 dB, Lolux, ALC
ND filter: Clear, 1/4, 1/16, 1/64
LCD display: 3.5” 920K pixels, 16:9
Viewfinder: 0.45” 1.22M pixels, 16:9
[VIDEO/AUDIO RECORDING]
Recording media: 2x SDHC/SDXC memory card Class 4/6/10
(Class4 for AVCHD and H.264 SD or Proxy only)
Video recording:
Video codec: MPEG2 Long GOP (HD), MPEG-4/AVC H.264 (HD/SD/Web)
File format: MOV (HD/SD: H.264), MP4 (XDCAM EX), MTS (AVCHD), MXF
Recording mode:
MPEG-2 Long GOP
NTSC setting:
HQ mode: 1920 x 1080/59.94i, 29.97p, 23.98p, 1440 x 1080/59.94i,
1280 x 720/59.94p, 29.97p, 23.98p
SP mode: 1440 x 1080/59.94i (25Mbps), 1280 x 720/59.94p (19Mbps)
PAL setting:
HQ mode: 1920 x 1080/50i, 25p, 1440 x 1080/50i, 1280 x 720/50p, 25p
SP mode: 1440 x 1080/50i (25Mbps), 1280 x 720/50p (19Mbps)
MPEG-4/AVC H.264 (UHQ)
NTSC setting: 1920 x 1080/59.94i
PAL setting: 1920 x 1080/50i
AVCHD
NTSC setting:
HQ mode: 1920 x 1080/59.94i, SP mode: 1920 x 1080/59.94i
PAL setting:
HQ mode: 1920 x 1080/50i, SP mode: 1920 x 1080/50i
SD (MPEG-4/AVC H.264)
NTSC setting: 720 x 480/59.94i (GY-HM650U only)
PAL setting: 720 x 576/50i (GY-HM650E only)
Proxy (MPEG-4/AVC H.264)
NTSC setting:
Web mode: 480 x 270/29.97p, 23.98p
PAL setting:
Web mode: 480 x 270/25p
Audio recording LPCM 2ch, 48kHz/16-bit (MPEG-2 Long GOP/H.264),
Dolby Digital 2ch, 48kHz/16-bit, 256kbps (AVCHD), μlow (Proxy)
[INTERFACE]
Video output: AV output, SDI output (BNC x1), HDMI output x 1
Audio input: XLR x2 (MIC,+48V/LINE), ø3.5mm mini jack x 1
Audio output: AV output
Headphone: ø3.5mm mini jack x 1
Time code link input/output: RCA x 1
Remote: ø2.5mm mini jack x 1
USB: Mini-USB2.0, Type-B/USB host A
[PROVIDED ACCESSORIES]
Battery pack (SSL-JVC50) x 1, AC adapter x 1, AV cable x 1
Optional Accessories
SSL-JVC50
Battery (IDX)
LC-2J
Battery Charger (IDX)
MOV/MP4
MPEG-2/HD
MOV MTS
H.264/HD
MOV
H.264/SD
MOV
H.264/ProxyAVCHD
SP HQ HQ SP HQ SD Proxy
720p
45 min.
22 min.
1 hr. 30 min.
3 hr.
6 hr.
4GB
8GB
16GB
32GB
12 hr.
1080i
35 min.
17 min.
1 hr. 10 min.
2 hr. 20 min.
4 hr. 40 min.
9 hr. 20 min.
25 min.
12 min.
50 min.
1 hr. 40 min.
3 hr. 20 min.
6 hr. 40 min.
25 min.
12 min.
50 min.
1 hr. 40 min.
3 hr. 20 min.
6 hr. 40 min.
50 min.
25 min.
1 hr. 40 min.
3 hr. 20 min.
6 hr. 40 min.
13 hr. 20 min.
39 min.
19 min.
1 hr. 18 min.
2 hr. 36 min.
5 hr. 12 min.
10 hr. 24 min.
1 hr. 35 min.
47 min.
3 hr. 10 min.
6 hr. 20 min.
12 hr. 40 min.
25 hr.
13 hr.
6 hr. 20 min.
26 hr.
52 hr.
104 hr.
208 hr.
720p/1080i 1080i 1080i 1080i 480i/576i 270p
64GB (SDXC)
128GB (SDXC)
Recommended SDHC/SDXC cards brands: *Sandisk, Toshiba, Panasonic.
• SDHC Class 4/6/10, SDXC
recording time (approx.)
Class 4 only correspondence with
AVCHD/H.264 mode.
KCS-8432 CEHM650GNK1209
Loading...
