JVC PD-42V485 User Manual

0 (0)

Plasma Display Users Guide

PD-42V485 PD-42V475

Illustration of PD-42V475 and RM-C1257G
Important Note:
In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.
Model Number:
Serial Number:
LCT1659-001A-A
0504TNH-II-IM

Important Safety Precautions

CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock. Do not
remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV SET
TO RAIN OR MOISTURE.
CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES
REGARDING THE USE OF THIS UNIT.
1. Operate only from the power source specified on the unit.
2. Avoid damaging the AC plug and power cord.
3. Avoid Improper installation and never position the unit where good ventilation is unattainable.
4. Do not allow objects or liquid into the cabinet openings.
5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover.
Changes or modifications not approved by JVC could void the warranty.
* When you don’t use this TV set for a long period of time, be sure to disconnect both the
power plug from the AC outlet and antenna for your safety.
* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or
other outlet unless the blades can be fully inserted to prevent blade exposure.
2
• As an “ENERGY STAR®” partner, JVC has determined that this product or product model meets the “ENERGY STAR
®
” guidelines for
energy efficiency.
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be placed on the apparatus.
3
16) Avoid improper installation and never position the unit where good ventilation is impossible. When
installing this TV, distance recommendations must be maintained between the set and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the minimum distance guidelines shown for safe operation.
8 inch/200 mm
8 inch/200 mm
6 inch/150 mm
2 inch/50 mm
17) Cautions for installation
— Do not tilt the TV towards the left or right, or towards the back.
— Install the TV in a corner on the floor so as to keep cords out of the way. — The TV will generate a slight amount of heat during operation. Ensure that sufficient space is
available around the TV to allow satisfactory cooling.
6 inch/150 mm
2 inch/50 mm
FCC Notice:
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
4

Warnings

Screen Burn-in
A characteristic of Plasma Display Panels (PDPs) is that displaying the same image for a long time causes a part of the image to stay on the screen (this is called phosphor burn-in).
Avoid burn-in as follows.
IMAGE SHIFT
The picture displayed on the screen is shifted up, down and to the left and right at regular intervals. In order to prevent burn-in, set this function to FAST or STD. (Refer to page 42.) Even if the IMAGE SHIFT function is turned off, the picture will shift to the left or right when the channel or input is changed. This is only when the ASPECT function is in REGULAR mode.
VIDEO STATUS
The VIDEO STATUS function is initially set to DYNAMIC. Unless the TV is being watched in an extremely bright room, it is recommended to change the VIDEO STATUS setting to standard, theater or game. Doing so will reduce the chance of PDP burn-in and extend the life of the PDP. (Refer to page 61).
❑ Do not display static images or characters for long periods of time.
TV on
XYZ XYZ
For example...
• Reduce PICTURE and BRIGHT on the PICTURE ADJUST menu (page 50) when viewing.
❑ Do not view for long periods of time in the REGULAR mode (page 63).
Screen size is normally chosen to ensure that the picture is displayed on the entire screen. After viewing in the REGULAR mode in which black bands may occur at the left and right of the screen, it is recommended to change to the PANORAMA mode to display the picture on the entire screen.
TV on
For example...
❑ Do not view for long periods of time using the TWIN function (page 57) or INDEX
function (page 57).
TV off
TV off
5
Warnings
If Burn-in has occurred
If burn-in occurs, try the BURN-IN IMAGE REDUCER function (page 52). If burn-in is minimal it may gradually become less noticeable.
Note: Once burn-in occurs it will never disappear completely.
Point defects
PDPs use collections of fine pixels to display images. While there is no problem with more than
99.99% of these pixels, please understand that a very small number of pixels may not light or
may light all the time.
Do not install the TV near electronic equipment that is susceptible to electromagnetic waves
It may cause interference in images, sound, etc. In particular, keep video equipment away from this product.
Effect on infrared devices
There may be interference while using infrared devices such as infrared cordless headphones.
The phenomenon described below is not a malfunction.
If the television is used at a location above an altitude of 2,000 m, a buzzing noise and image distortion may occur. This phenomenon is peculiar to PDP (Plasma Display Panel), and could occur with any television using PDP. It is not a malfunction.
Caring for the Cabinet
Normally, light dusting with a soft, non-scratching duster will keep your TV clean.
If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly moistened with water. You can add a few drops of mild liquid detergent to the water to help remove spots of oily dirt.
DO NOT allow liquid to enter the TV through the ventilation slots.
DO NOT use strong or abrasive cleaners on the TV.
DO NOT spray liquids or cleaners directly on the TV’s surface.
DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.
Caring for the Screen
When it gets dirty, wipe it gently with a soft cloth.
Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen. These will remove the coating layer and cause discolorations.
6

Table of Contents

Important Safety Precautions . 2
Warnings . . . . . . . . . . . . 6
Quick Setup . . . . . . . . . . . 8
Unpacking your TV . . . . . . . . . . . . 8
Remove the stand from the TV . . . . . . . 9
TV Models . . . . . . . . . . . . . . . . 10
TV Remote Control . . . . . . . . . . . 11
Getting Started . . . . . . . . . . . . . 12
The Remote Control . . . . . . . . . . 12
Connecting Your Devices . . . . . . . 13
Interactive Plug In Menu . . . . . . . . 23
Remote Programming . . . . . 26
Setting CATV, VCR and DVD Codes . . . 26
CATV or Satellite Codes . . . . . . . . 26
VCR Codes . . . . . . . . . . . . . . 27
DVD Codes . . . . . . . . . . . . . . 28
Search Codes . . . . . . . . . . . . . 29
Onscreen Menus . . . . . . . . 30
Using the Guide . . . . . . . . . . . . . 30
Onscreen Menu System . . . . . . . . . 31
Initial Setup . . . . . . . . . . 33
Auto Tuner Setup . . . . . . . . . . . . 33
Channel Summary . . . . . . . . . . . . 33
V-Chip . . . . . . . . . . . . . . . . . . 35
Set Lock Code . . . . . . . . . . . . . 41
Auto Demo . . . . . . . . . . . . . . . 42
Image Shift . . . . . . . . . . . . . 42
Language . . . . . . . . . . . . . . . . 42
Closed Caption . . . . . . . . . . . . . 43
Auto Shut Off . . . . . . . . . . . . . . 44
XDS ID . . . . . . . . . . . . . . . . . 44
Noise Muting . . . . . . . . . . . . . . 45
Front Panel Lock . . . . . . . . . . . . 45
V1 Smart Input . . . . . . . . . . . 46
Video Input Label . . . . . . . . . . 46
Position Adjustment . . . . . . . . . . . 47
Power Indicator . . . . . . . . . . . . . 47
TV Speaker . . . . . . . . . . . . 47
Audio Out . . . . . . . . . . . . . . 48
Digital-In . . . . . . . . . . . . . . . . . 48
Digital-In Audio . . . . . . . . . . . . . 49
Center CH Input . . . . . . . . . . . . . 49
Picture Adjust . . . . . . . . . 50
Picture Settings . . . . . . . . . . . . . 50
Adjust Picture Settings . . . . . . . . . 50
Color Temperature . . . . . . . . . . . . 50
Digital Noise Clear . . . . . . . . . . . . 51
Natural Cinema . . . . . . . . . . . 51
Color Management . . . . . . . . . . 51
Dynamic Gamma . . . . . . . . . . 52
Burn-In Image Reducer . . . . . . . . 52
Reset . . . . . . . . . . . . . . . . . . 53
Sound Adjust . . . . . . . . . 54
Sound Settings . . . . . . . . . . . . . 54
Adjust Sound Settings . . . . . . . . . 54
MTS (Multi-channel Sound) . . . . . . . 54
Clock Timers . . . . . . . . . . 55
Set Clock . . . . . . . . . . . . . . . . 55
On/Off Timer . . . . . . . . . . . . . . . 56
Button Functions . . . . . . . 57
Multi Screen Function . . . . . . . . . . 57
Index . . . . . . . . . . . . . . . . . . 57
Twin . . . . . . . . . . . . . . . . . 57
Freeze . . . . . . . . . . . . . . . . . . 58
Swap . . . . . . . . . . . . . . . . . 58
Select . . . . . . . . . . . . . . . . . . 58
Power . . . . . . . . . . . . . . . . . . 59
Number Buttons . . . . . . . . . . . . . 59
Tune . . . . . . . . . . . . . . . 59
Input . . . . . . . . . . . . . . . . . . . 59
Channel +/- . . . . . . . . . . . . . 59
Volume +/- . . . . . . . . . . . . . 59
Return + . . . . . . . . . . . . . . . 60
Sound . . . . . . . . . . . . . . . . . . 60
Muting . . . . . . . . . . . . . . . . . . 60
Video Status . . . . . . . . . . . . . . . 61
TheaterPro D6500K . . . . . . . . . . . 61
Sleep Timer . . . . . . . . . . . . . . . 61
Display . . . . . . . . . . . . . . . . . 62
C.C. . . . . . . . . . . . . . . . . . . . 62
Aspect . . . . . . . . . . . . . . . . . 63
Aspect Ratios . . . . . . . . . . . . . 63
Menu . . . . . . . . . . . . . . . . . . 64
OK . . . . . . . . . . . . . . . . . . . 64
Back . . . . . . . . . . . . . . . . . . . 64
TV/CATV Slide Switch . . . . . . . . . . 65
VCR/DVD Slide Switch . . . . . . . . . 65
VCR Buttons . . . . . . . . . . . . . . . 65
DVD Buttons . . . . . . . . . . . . . . . 65
Light . . . . . . . . . . . . . . . . . . . 65
Super Focus . . . . . . . . . . . . . . . 65
Appendices . . . . . . . . . . 66
No Program . . . . . . . . . . . . . . 66
Troubleshooting . . . . . . . . . . . . . 67
Warranty . . . . . . . . . . . . . . . . . 69
Authorized Service Centers . . . . . . . 70
Specifications . . . . . . . . . . . . . . . 71
7

Quick Setup Unpacking your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items.
POWER
TV
DVD
CATVVCR
MULTI SCREEN
TWIN
INDEX
C.C.
SWAP
SELECT
INPUT
FREEZE
DISPLAY
1
3
2
SLEEP TIMER
4
6
5
SOUND
7
9
8
RETURN+
TUNE
VIDEO STATUS
0
THEATER PRO
LIGHT
ASPECT
MUTING
OK
CH +
VOL
VOL
+
POWER
TV
AA/R06-size batteries
(used to check
operation)
–
CH –
BACK
MENU
VCR/DVD
VCR CHANNEL
TV/VCR
POWER
PREV NEXT
PLAY FFREW
REC
STOP PAUSE
OPEN/CLOSE
STILL/PAUSE
RM-C1257G
TV
Remote control
Power cord
8

Quick Setup Remove the stand from the TV

Read the following instructions and then remove the stand from the TV.
WARNING: The TV is heavy. It should always be carried by at least two people. Attempting to
Required items: Phillips screwdriver
1. Remove the screws (A) and remove the cover from the stand.
2. Remove the screws (B) from the stand.
carry it by yourself may lead to it being dropped causing injuries and damage.
Cover
Screw (A)
Screw (B)Screw (B)
3. Remove the stand from the TV.
4. Remove the screws (C) from the back of the TV.
Stand
Screw (C)
9

Quick Setup TV Models

CHANNEL
VOLUME
MENU
INPUT
POWER
Note: Before you connect your TV to another device, please refer to the proper diagrams for
your specific TV and remote.
Front
POWER
POWER button
POWER
PC INPUT
CHANNELVOLUME
OPERATE
S-VIDEO VIDEO
OVER
MENU
INPUT
L/MONO-AUDIO-R
INPUT-4
POWER
Rear
Underneath
10
AUDIO
IN
(ANALOG)
R L
R AUDIO L VIDEO
Pr Pb Y
VIDEO
DIGITAL
DIGITAL
HDMI
AUDIO
CENTER CHANNEL INPUT
INPUT-2
AV COMPULINK III
INPUT-1
INPUT-3
R AUDIO L VIDEO
R AUDIO L VIDEO
75Ω (VHF/UHF)
OVER
OVER
AUDIO
OUT
S-VIDEO
S-VIDEO
RL
Pr Pb Y
AC 120V

Quick Setup TV Remote Control

TV
CATV VCR
FREEZE
DISPLAY
SLEEP TIMER
SOUND
VIDEO STATUS
THEATER PRO
MUTING
VOL
–
MENU
VCR CHANNEL
PREV NEXT
REC
OPEN/CLOSE
MULTI SCREEN
TWIN
SWAP
1
4
7
TUNE
ASPECT
CH +
CH –
PLAY FFREW
STOP PAUSE
RM-C1257G
TV
DVD
INDEX
SELECT
VCR/DVD
POWER
POWER
C.C.
INPUT
2
5
8
RETURN+
0
LIGHT
OK
VOL
+
BACK
TV/VCR
STILL/PAUSE
3
6
9
RM-C1257G
• For information on remote control buttons, see pages 57-65.
11

Quick Setup Getting Started

V
Getting Started
These quick setup pages will provide you, in four easy steps, with the basic information you need to begin using your new television right away.
If you have questions, or for more detailed information on any of these steps, please consult other sections of this manual.
Step 1 – The Remote Control
Before you can operate your remote control, you first need to install the batteries (included).
Lift and pull the latch on the back of the remote control to open. Insert two batteries (included) carefully noting the “+” and “–” markings, placing the “–” end in the unit first. Snap the cover back into place.
When you change the batteries, try to complete the task within three minutes. If you take longer than three minutes, the remote control codes for your VCR, DVD, and/or cable box/satellite receiver may have to be reset. See pages 26 - 29.
Key Feature Buttons
The four key feature buttons at the center of the remote can be used for basic operation of the television. The top and bottom buttons will scan forward and back through the available channels. To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH –. The channels will zip by at a rate of five channels per second. The right and left buttons will turn the volume up or down. These buttons are also marked with four arrows and are used with JVC’s onscreen menu system. To use the onscreen menus, press the M
ENU button.
MUTING
VOL
–
MENU
CH +
CH –
OK
VOL
+
BACK
Basic Operation
Turn the television on and off by pressing the POWER button at the top right corner of the remote. If this is the first time you are turning on the TV, the interactive plug-in menu appears.
• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if
you need to operate a cable box.
• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to
DVD to control a DVD player. Please see pages 26 to 29 for instructions on programming your remote control to operate a cable box, VCR or DVD player.
12
POWER
TV
CATV
VCR
DVD

Quick Setup Connections

Step 2 – Connecting Your Devices

To make these connections, you will use plugs like the ones illustrated below.
S-Video Cable
Component Cables
Composite Cables
Audio Cables
Used to make video connections with S-Video VCRs, Camcorders and DVD players.
Please follow the flow chart below to determine which connection setup is right for you. Then, refer to the appropriate diagrams to connect your TV to other devices that you may have. After you are finished connecting your devices, plug the power cord into the nearest power outlet and turn on the TV.
A VCR is not necessary for operation of the television. If you follow these diagrams and the television does not work properly, contact your local cable operator.
• To connect a DVD player, see Diagram #3. A DVD player is optional.
• If you have a satellite television system, please refer to the satellite TV manual.
Do you use a Cable TV Box?
Yes
Used to connect audio/video devices like VCRs, DVD players, stereo amplifiers, game consoles, etc.
No
Do you have a VCR? Do you have a VCR?
Yes No Yes No
Diagram #2
Diagram #1 Diagram #3 Diagram #1
13
Quick Setup Connections
Diagram #1
Cable or Antenna
Output
Coaxial Cable
OR
75Ω (VHF/UHF)
TV Underneath Panel
OUT IN
Cable Box
Note:
• If you do not have a cable box, connect the cable wire from the wall outlet into the back of
the TV.
Diagram #2
INPUT-3
TV Rear Panel
R AUDIO L VIDEO
TV Underneath Panel
OVER
S-VIDEO
75Ω (VHF/UHF)
Cable or Antenna
Output
Coaxial Cable
OUT OUT
IN
Two-Way
Splitter
OR
IN
OUT
R L V
VCR
IN
OUT
OUT IN
Cable Box
Notes:
• Use the S-Video connection if possible for superior picture quality.
• Your VCR must be turned on to view premium cable channels.
14
Quick Setup Connections
Notes:
• Green, blue and red are the most common colors for DVD cables. Some models may vary
colors. Please consult the user’s manual for your DVD player for more information.
• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete
one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables.
• You may also connect the DVD player to Input 1.
Diagram #3
IN
OUT
VCR
IN
OUT OUT
INPUT-3
Coaxial Cable
Two-Way Splitter
75Ω (VHF/UHF)
R L V
IN
OUT
R AUDIO L VIDEO
Cable or Antenna
TV Underneath Panel
OR
OVER
S-VIDEO
Output
R AUDIO L VIDEO
Pr Pb Y
TV Rear Panel
AUDIO OUT
L R
INPUT-2
DVD Player (OPTIONAL)
Y
P
B
PR
OUT
Green
Blue
Red
15
Quick Setup Connections

Connecting to JVC AV Compu Link

JVC’s AV CompuLink feature makes playing video tapes or DVDs totally automatic. Simply insert a pre-recorded tape into your JVC brand VCR or DVD into your JVC DVD player and the device will automatically turn on and begin playback. At the same time, using the AV CompuLink, the VCR or DVD player sends a signal to the television telling it to turn on and switch to the proper video input.
• The AV CompuLink cable may be included with the JVC AV CompuLink unit you wish to connect. If it is not, contact JVC Parts Department at (800)-882-2345, or www.jvcservice.com for part # EWP 805-012.
• AV CompuLink can only be used with JVC brand products.
AV CompuLink Cable
To Connect: Plug one end of the AV compu link cable into the AV COMPU LINK INPUT on your VCR, DVD, or other compu link device. Plug the other end of the AV compu link cable into the AV COMPU LINK at the rear of the TV.
Note:
• The AV compu link cable has a male 3.5 mm (mono) plug on each end.
VCR
VIDEO
AUDIO
DIGITAL
DIGITAL
AV COMPULINK III
HDMI
TV Underneath Panel
IN
OUT
V L R
AV CompuLink
IN
OUT
Notes:
• In order for the VCR playback to begin automatically, the recording tabs must be removed from the VHS tape. If the tab is in place, automatic switching will occur when you push the VCR’s PLAY button.
• If your JVC brand VCR has “A code/B code remote control switching” (see your VCR’s instruction book), using VCR A code will switch the TV to input 1.
• Refer to your DVD instruction book for detailed connection information.
• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see the receiver connection instructions for detailed connection information.
• AV CompuLink is compatible with select AV CompuLink receivers.
16
Quick Setup Connections
r

Connecting to a Camcorder

You may connect a camcorder, game console or other equipment to your television by using the front input jacks (Input 4) located under the front panel door. To access, push on the door to open it. You can also connect these using the television’s rear input jacks, using the same instructions.
POWER
PC INPUT
CHANNELVOLUME
OPERATE
S-VIDEO VIDEO
OVER
MENU
L/MONO-AUDIO-R
INPUT
INPUT-4
POWER
CAMCORDER
TV front Panel
OR
1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on
the front of the TV, OR connect an S-Video cable from the front of the TV to the camcorder.
2) Connect a white composite cable from the camcorder LEFT AUDIO OUT, into the
LEFT AUDIO IN on the front of the TV.
3) Connect a red composite cable from the camcorder RIGHT AUDIO OUT, into the
RIGHT AUDIO IN on the front of the TV.
Note:
• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to the LEFT AUDIO IN on the front of the TV.

Connecting to an External Amplifier

TV Rear Panel
AUDIO
RL
OUT
1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to
the LEFT AUDIO INPUT on the amplifier.
2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to
the RIGHT AUDIO INPUT on the amplifier.
Notes:
• Refer to your amplifier’s manual for more information.
• You can use AUDIO OUTPUT for your home theater system.
Speaker Speake
Amplifier
17
Quick Setup Connections

Connecting to a Digital TV Receiver

By connecting a Digital TV Receiver, high definition pictures can be displayed on your TV in their digital form.
DTV Decoder
TV Rear Panel
AUDIO OUTDIGITAL OUT
RL
HDMI to DVI Cable
AUDIO
IN
(ANALOG)
R L
VIDEO
DIGITAL
TV Underneath Panel
After the connections have been made,
tighten the screw to secure the cables.
1) Connect the HDMI to DVI Cable from the DIGITAL OUT on the back of your DTV decoder, to the DIGITAL-IN on the back of your television.
2) Connect a red cable from the DTV decoder RIGHT AUDIO OUT, to the RIGHT AUDIO DIGITAL-IN on the back of your television.
3) Connect a white cable from the DTV decoder LEFT AUDIO OUT, to the LEFT AUDIO DIGITAL-IN on the back of your television.
• The digital-in terminal is not compatible with the picture signal of a personal computer.
• Use a HDMI to DVI cable (commercially available) in order to digitally connect the television
with a DTV decoder.
HDMI
AUDIO DIGITAL
CENTER CHANNEL INPUT
AV COMPULINK III
Notes:
• If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance
may be slightly shifted. Access the “DIGITAL-IN” in the initial setup menu to adjust it. (Refer to page 48.)
• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to
ANALOG. See "DIGITAL-IN AUDIO", page 49.
18
Quick Setup Connections

Connecting to a HDMI Compatible Device

By connecting a HDMI compatible device, high definition pictures can be displayed on your TV in their digital form. Some HDMI devices can include DVD players, D-VHS or any HDMI compatible device.
HDMI (High Definition Multimedia Interface) is the first industry supported, uncompressed, all digital audio/video interface. HDMI provides and interface between any audio/video source, such as a set-top box, DVD player, A/V receiver or an audio and/or video monitor, such as a digital television (DTV).
HDMI Compatible Device
DIGITAL OUT
AUDIO OUT
LR
HDMI Cable
VIDEO
AUDIO
DIGITAL
DIGITAL
AV COMPULINK III
HDMI
TV Underneath Panel
1) Connect the HDMI Cable from the DIGITAL OUT on the back of your DTV or HDMI device, to the DIGITAL-IN on the back of your television.
Note:
• When you do the above connection, set DIGITAL-IN AUDIO in the Initial Setup menu to DIGITAL. See "DIGITAL-IN AUDIO", page 49.
19
Quick Setup Connections

Connecting to an AV Receiver using your television's V1 Smart Input

By connecting your AV Receiver to your television's V1 Smart Input, you can watch picture sources from many different devices, without having to change or use the other input connections on your TV. This allows you to free up the other input connections so you can connect more devices to your television.
AV Receiver
MONITOR
OUT
Y
P
B
PR
MONITOR OUT
TV Rear Panel
INPUT-1
R AUDIO L VIDEO
S-VIDEO
OVER
Pr Pb Y
1) Connect an S-Video Cable from the AV Receiver's MONITOR OUT, to the S-Video INPUT-1
on the back of your TV.
2) Connect a Yellow Component Cable from the AV Receiver's MONITOR OUT, into the
VIDEO INPUT-1 on the back of your TV.
3) Connect a Green Component Cable from the AV Receiver's Y MONITOR OUT, into the Y
VIDEO INPUT-1 on the back of your TV.
4) Connect a Blue Component Cable from the AV Receiver's PB MONITOR OUT, into the PR
VIDEO INPUT-1 on the back of your TV.
5) Connect a Red Component Cable from the AV Receiver's P
B MONITOR OUT, into the PR
VIDEO INPUT-1 on the back of your TV.
Notes:
• Please refer to your AV Receiver instruction manual for more information on connecting your speakers and other devices like a DVD player.
• Use your AV Receiver's remote to switch to the different devices you have connected.
• Some AV Receiver's may not respond when the V1 Smart Input function is turned on.
• If you have video connections for each input device connected to your AV Receiver, you should not connect them using both S-Video and Composite connection at the same time when you are using V1 input as the V1 Smart Input. In this case we recommend using the S-Video connection.
20
Quick Setup Connections

Connecting to the computer

This TV can be used as a computer screen. Use a commercially available D-SUB cable to connect the TV's PC INPUT terminal to the computer's analog RGB output terminal. If you want to listen to the sound from the computer, use a commercially available RCA cable to connect the INPUT-4 audio input terminal to the computer's audio output terminal. When the sound from the computer is mono, connect to the L/MONO of INPUT-4.
POWER
PC INPUT
CHANNELVOLUME
OPERATE
S-VIDEO VIDEO
OVER
MENU
L/MONO-AUDIO-R
INPUT
INPUT-4
POWER
Notes:
• Refer to your computer manual for a detailed explanation of the connections concerning your computer.
• Make sure that the connectors are facing the correct way when connecting.
• After connecting, tighten the two screws to fix the connectors in place.
Looking at the images from a computer
After starting the computer, press the INPUT button to choose INPUT-4. You can listen to the sound when the sound from the computer is connected to the INPUT-4 AUDIO input terminal.
Notes:
• When the sound from the computer is connected to INPUT-4 by choosing external input INPUT-4, the sound from the computer can be listened to, but the images from the computer cannot be seen.
21
Quick Setup Connections
Table of signals for each type of computer
Resolution
640 x 480 (VGA)
1024 x 768 (XGA)
Vertical Frequency (Hz)
60.0
60.0
Horizontal Frequency (kHz)
31.5
42.0
• Only the above formats are supported.
• Even with the above formats at 60 Hz, some problems may be experienced depending on the quality of the synchronous signal. (Depending on the quality, some pictures may not be displayed correctly).
• Apple Macintosh* computers are not supported.
When a picture is not displayed
With some computers, some problems can be solved by changing the settings. Check the computer's refresh rate and set it to 60Hz. Computers that cannot set the refresh rate to 60 Hz, can not be used with this TV. Refer to the computer's instruction manual.
*Apple Macintosh is a registered trademark of Apple Computer, Inc.
22
Loading...
+ 50 hidden pages
Privacy Policy Cookie Policy Terms of Use
