JVC LT-Z37DX5 User Guide

LT-Z37DX5

ENGLISH

WIDE LCD PANEL TV

INSTRUCTIONS

LCT1961-001A

Thank you for buying this JVC LCD flat television. To make sure you understand how to use your new TV, please read this manual thoroughly before you begin. (“LCD” stands for Liquid Crystal Display.)

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

WARNING

• Do not allow children to hang from the TV, place their elbows on the TV or lean against the TV. Doing so may cause the TV to fall over and lead to injuries.

CAUTION

• The TV screen may be damaged if the TV is carried as shown in the diagram below. The TV should always be carried by two people.

ENGLISH

Pixel defects

LCDs use collections of fine points (“pixels”) to display images. While there is no problem with more than 99.99% of these pixels, please understand that a very small number of pixels may not light, or may light all the time.

Distance recommendations

Avoid improper installation and never position the unit where good ventilation is impossible. When installing this TV, distance recommendations must be maintained between the set and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the minimum distance guidelines shown for safe operation.

150 mm 150 mm

200 mm 200 mm

50 mm

Failure to take the following precautions may cause damage to the television or remote control.

DO NOT block the TV’s ventilation openings or holes.

(If the ventilation openings or holes are blocked by a newspaper or cloth, etc., the heat may not be able to get out.)

DO NOT place anything on top of the TV.

(such as cosmetics or medicines, flower vases, potted plants, cups, etc.)

DO NOT allow objects or liquid into the cabinet openings.

(If water or liquid is allowed to enter this equipment, fire or electric shock may be caused.)

DO NOT place any naked flame sources, such as lighted candles, on the TV.

ENGLISH

DO NOT subject the TV to direct sunlight.

The surface of the TV screen is easily damaged. Be very careful with it when handling the TV. Should the TV screen become soiled, wipe it with a soft dry cloth. Never rub it forcefully. Never use any cleaner or detergent on it.

If there is a fault, unplug the unit and call a service technician. Do not attempt to repair it yourself or remove the rear cover.

 Cleaning the screen

The screen is coated with a special thin film to reduce reflection. If this film is damaged, uneven colours, discolouration, scratches, and other problems that cannot be repaired may occur. Pay attention to the following when handling the screen.

• Do not use glue or adhesive tape on the screen.

• Do not write on the screen.

• Do not allow the screen to come in contact with any hard objects.

• Do not allow condensation to form on the screen.

• Do not use alcohol, thinner, benzene or other solvents on the screen.

• Do not rub the screen hard.

CAUTION:

• Operate only from the power source specified (AC 110 – 240 V, 50/60 Hz) on the unit.

• Avoid damaging the AC plug and power cord.

• When you are not using this unit for a long period of time, it is recommended that you disconnect the power cord from the main outlet.

Demonstration

To start the demonstration: Press the H button to display the menu bar. Then press the yellow button. Select DEMO 1 (High Speed Response) or DEMO 2 (DynaPix) from the DEMO MODE menu. Press the 6 buttons, then press the a button.

To quit the demonstration: Press the yellow button, b button, 6 p buttons or any of the number buttons.

CONTENTS

Setting up your TV ...................................4

Installation.................................................. 4

Using the stand .......................................... 4

Removing the terminal covers ................... 5

Connecting the aerial and video cassette

recorder (VCR) ....................................... 6

Connecting the power cord to the AC

outlet....................................................... 7

Putting the batteries into the remote

control..................................................... 7

Initial settings (Setup tour) ......................... 7

TV buttons and functions........................9

Turn the TV on from standby mode ........... 9

Choose a TV channel ................................ 9

Adjust the volume ...................................... 9

Using the Menu.......................................... 9

Using the Illumination................................. 9

Remote control buttons and

functions..............................................10

Turn the TV on or off from standby mode Choose a TV channel and watch images

from external devices ........................... 11

Adjust the volume .................................... 12

Display function........................................ 12

ZOOM function......................................... 13

CINEMA SURROUND function................ 14

Using the “Freeze” function...................... 14

Using the “Multi-picture” function ............. 15

RETURN PLUS function and Return

function................................................. 16

Favourite channel function....................... 17

Operating a JVC brand DVD player......... 18

... 10

Teletext function ....................................19

Basic operation ........................................ 19

Using the List Mode ................................. 19

Hold.......................................................... 20

Sub-page ................................................. 20

Reveal...................................................... 20

Size .......................................................... 20

Index ........................................................ 21

Cancel...................................................... 21

Using the TV’s menu..............................22

Basic operation ........................................ 22

PICTURE menu ......................................24

PICTURE MODE...................................... 24

BACK LIGHT............................................ 24

CONTRAST ............................................. 24

BRIGHT.................................................... 24

SHARP..................................................... 24

COLOUR.................................................. 24

TINT ......................................................... 24

WHITE BALANCE.................................... 24

FEATURES .............................................. 25

SOUND menu ......................................... 28

STEREO / I • II ......................................... 28

BASS........................................................ 28

TREBLE ................................................... 28

BALANCE ................................................ 28

CINEMA SURROUND ............................. 28

A.H.B. (Active Hyper Bass) ...................... 28

BBE .......................................................... 29

FEATURES menu................................... 30

SLEEP TIMER ......................................... 30

CHANNEL GUARD .................................. 30

APPEARANCE......................................... 32

BLUE BACK ............................................. 32

CHILD LOCK............................................ 32

AUTO SHUTOFF ..................................... 32

FAVOURITE SETTING ............................ 32

ILLUMINATION ........................................ 33

MEDIA CARD VIEWER ........................... 33

SET UP menu ......................................... 34

AUTO PROGRAM.................................... 34

EDIT/MANUAL ......................................... 34

LANGUAGE ............................................. 38

VIDEO-1 SETTING/VIDEO-3 SETTING

AI VOLUME.............................................. 38

TELETEXT LANGUAGE .......................... 39

HDMI SETTING ....................................... 39

.... 38

Displaying a computer screen.............. 40

Connecting to the computer ..................... 40

Watching images from a computer .......... 40

Table of signals for each type of

computer............................................... 40

Using a Media Card ...............................41

Supported Media Cards and file formats

Inserting the Media Card .......................... 42

Using the MEDIA CARD VIEWER ........... 43

... 41

Additional preparation ..........................46

Connecting external equipment ............... 46

Using the HDMI terminal .......................... 49

CH/CC numbers ..................................... 51

Troubleshooting ....................................52

Specifications ........................................54

ENGLISH

Setting up your TV

• When you install the TV on the wall, only use a JVC wall mounting unit (optional) which is designed for this TV.

• Make sure that the TV is installed on the wall by a skilled installer.

Installation

Cautions for installation

ENGLISH

• Install the TV in a corner on a wall or on the floor so as to keep cords out of the way.

• The TV will generate a slight amount of heat during operation. Ensure that sufficient space is available around the TV to allow satisfactory cooling. See “Distance recommendations” on page 1.

Using the stand

This TV comes with a table top stand already attached.

This stand can be used to adjust the direction of the TV screen 5° up, 10° down, and 20° to the left or right.

 Rotate the TV to the left and right:

While holding the bottom of the stand with one hand, use your other hand to hold the edge of the panel and slowly adjust the direction of the TV screen.

 Cable holder

A cable holder which is used to keep the connection cables tidy is attached to the back of the stand. Gently squeeze the left and right of the cable holder and pull it to remove it from the stand. After putting the cables in the cable holder, attach it to the back of the stand again.

Setting up your TV

Removing the terminal covers

There are connection terminals behind the covers on the left and right of the rear of the TV. Remove these two covers before connecting an antenna or VCR. Remove the covers by removing the hooks. When replacing the covers, place the side of the covers against the TV and insert the hooks.

• Leave the covers off if they do not fit properly. Do not force to replace the covers. Doing so may cause damage to the connection cables and the covers.

ENGLISH

Setting up your TV

NALO

IN(H

I AU

)

Connecting the aerial and video cassette recorder (VCR)

Caution

• Turn off all the equipment including the

ENGLISH

TV before connecting anything.

• Aerial cable is not supplied. Use a good quality 75-ohm coaxial cable.

• Read the manual that came with the VCR before connecting.

If not connecting a VCR (follow 1): Connect an aerial cable to the aerial socket on this TV.

If connecting a VCR: 1 Connect the aerial cable to the

aerial input socket on the VCR, and connect the VCR and TV with another aerial cable

2 Connect the VCR’s VIDEO OUT

(video output) terminal and the TV’s VIDEO terminal with a video cable

To connect a VCR to the TV with an SVIDEO cable: Connect the VCR’s S-VIDEO OUT (SVIDEO output) terminal and TV’s S VIDEO terminal with an S-VIDEO cable A, instead of connecting with a video cable. Note that the connection with a video cable will be ignored in case you connect a VCR to the TV with both video cable and S-VIDEO cable.

3 Connect the VCR’s VIDEO OUT

(audio L/R output) terminals and the TV’s AUDIO terminals with an audio cable

without terminal covers

IN (HDMI AUDIO)

(ANALOG)

• To connect additional external devices, please see “Connecting external equipment” on page 46.

Setting up your TV

Connecting the power cord to the AC outlet

Insert the AC plug on the power cord from the TV into AC outlet.

Caution

• Operate only from the power source specified (AC 110 – 240 V, 50/60 Hz) on the unit.

• Remove the AC plug from the outlet to completely disconnect the TV from the power supply.

Putting the batteries into the remote control

Use two AA/R6 dry cell batteries. Insert the batteries from the - end, making sure the + and - polarities are correct.

• Follow the warnings printed on the batteries.

• Battery life is about six months to one year, depending on how much you use the remote control.

• The batteries we supply are only for setting up and testing your TV, please replace them as soon as you need to.

• If the remote control does not work properly, replace the batteries.

Initial settings (Setup tour)

When the TV is first turned on, it goes into the initial settings mode, and you will see the JVC logo. Follow the instructions on the screen display to make the initial settings.

# button

PIP/TV/DVD switch

6 buttons

1 Make sure to set the PIP/TV/DVD

switch on the remote control to the TV position

• You cannot turn the TV on when the PIP/TV/DVD switch is set to the DVD position.

2 Press the # button on the remote

control

The TV turns on from standby mode and the JVC logo is displayed.

• Check that the AC plug on the power cord from the TV is connected to AC outlet.

ENGLISH

Remote control

sensor

Power lamp Illumination

lamp

Setting up your TV

• If the JVC logo does not appear this is because your TV has already been turned on for the first time: use the “LANGUAGE”, “TELETEXT LANGUAGE” and “AUTO PROGRAM” functions to make the

ENGLISH

initial settings. For details, see “SET UP menu” on page 34.

3 Press the a button

The LANGUAGE menu appears.

4 Press the 6 buttons to choose

ENGLISH. Then press the a button

The TELETEXT LANGUAGE menu appears. Set the teletext language group that corresponds to the language of the teletext programme that you want to watch. For details, see “TELETEXT LANGUAGE” on page 39.

> TELETEXT LANGUAGE

GROUP-1 GROUP-2 GROUP-3 GROUP-4

D1003

-EN

5 Press the 6 buttons to choose a

group. Then press the a button

The AUTO PROGRAM function starts. The TV channels you receive are automatically stored in the programme numbers (PR) list.

AUTO PROGRAM

14%

D0004

-EN

• To stop the AUTO PROGRAM

function, press the a button.

6 After the TV channels have been

registered in the programme numbers (PR), the EDIT menu appears

EDIT

D0038

-EN

PR ID AV 01 02 03 04 05 06 07 08 09

MOVE

CH/CC

CH CH CH CH CH CH CC CC CC

INSERT

21 22 23 24 25 26 01 02 03

MANUAL

DELETE

• You can proceed to edit the programme numbers (PR) list using the EDIT/MANUAL function. For details, see “EDIT/MANUAL” on page 34.

• If a TV channel you want to view is not stored in the programme numbers (PR) list, you can register it using the MANUAL function. For details, see “EDIT/MANUAL” on page 34.

• The AUTO PROGRAM function does not store a TV channel to the programme number PR 0 (AV).

• If you do not need to use the EDIT/ MANUAL function, press the a button to close the EDIT menu.

Now, setting up is complete. Please enjoy your new JVC TV!

TV buttons and functions

Turn the TV on from standby mode

Press the A button or the CHANNEL p buttons to turn the TV on from standby mode.

When the TV is turned on, the power lamp lights blue.

To turn the TV off:

Press the A button again. The power lamp goes off.

Caution

•The A button on the TV does not fully

isolate the TV from the AC supply. If you are not going to use the TV for a long period, be sure to disconnect the AC plug from the AC socket.

Choose a TV channel

ENGLISH

Refer to the pages in parentheses for details.

1 Remote control sensor 2 Power lamp (page 7) 3 Illumination lamp (page 33) 4 TV/VIDEO button 5 MENU/OK button (page 22) 6 CHANNEL p buttons

6 (page 22)

7 VOLUME q buttons

5 (page 22)

8 A (Stand by) button 9 Headphone jack (mini jack) (page 46)

Press the CHANNEL p buttons to choose a programme number (PR) or a VIDEO terminal

Press the TV/VIDEO button to choose a VIDEO terminal.

Adjust the volume

Press the VOLUME q buttons

The volume level indicator appears.

Using the Menu

Use the MENU/OK button

Refer to “Using the TV’s menu” (see page 22) for details of using the menu.

Using the Illumination

When the TV is turned on the Illumination lamp lights. To adjust the illumination settings, refer to “ILLUMINATION” on page 33.

Remote control buttons and functions

1 Muting button 2 Number buttons 3 1 button 4 c button 5 2 button 6 4 button 7 7 buttons 8 5 button 9 6 p buttons 0 VCR/DVD/Teletext control buttons

- p buttons = d (Favourite) button ~ # (Standby) button ! PIP/TV/DVD switch @ g (Text) button # Colour buttons $ H button % a button ^ b button & 7 q buttons * f (Freeze) button ( X (Multi) button ) c (Select) button

ENGLISH

4 5

7 8

@ #

$ %

(

)

Turn the TV on or off from standby mode

Press the # (standby) button to turn the TV on or off

When the TV is turned on, the power lamp lights blue.

• The power can be turned on by pressing

the 4 button, 6 p buttons or Number buttons.

To turn the TV on or off, set the PIP/TV/ DVD switch on the remote control to the TV position and press the # button. If the PIP/TV/DVD switch on the remote control is set to the DVD position, the TV will not be turned on or off even if the # button is pressed.

Remote control buttons and functions

Choose a TV channel and watch images from external devices

 Use the number buttons:

Enter the programme number (PR) of the channel using the number buttons.

Example:

•PR 6 → press 6

• PR 12 → press 1 and 2

 Use the 6 p buttons:

Press the 6 p buttons to choose the programme number (PR) you want or a VIDEO terminal.

 Use the 4 button:

Press the 4 button to choose a VIDEO terminal.

Programme

numbers

PR 1 – PR 99

• Since this TV is designed to make full use of the resolution of the original video source, the motion may appear unnatural when the video source is input with progressive-scanning component signals.

• If this happens, change the output setting of the connected device to interlacescanning component signal output. See the instructions that came with the device for more information.

• The PC sound is the same as the VIDEO-3 sound.

To return to a TV channel:

Press the 4 button, the 6 p buttons or the number

buttons.

To use the programme number PR 0 (AV):

When the TV and VCR are connected only by the aerial cable, choosing the programme number PR 0 (AV) allows you to view images from the VCR. Set the VCR RF channel to the programme number PR 0 (AV) manually. For details, see “EDIT/ MANUAL” on page 34.

ENGLISH

(HDMI)

• The leading character is changed from V to S (eg V1 is changed to S1) when VIDEO-1 or VIDEO-2 is connected to the S terminal.

• If you do not have a clear picture or no colour appears, follow the operation procedure “COLOUR SYSTEM” on page 26.

• If you cannot hear the normal sound even if the picture of the TV channel appears normally. Follow the description “EDIT/ MANUAL” on page 34 to use the MANUAL function to change the SYSTEM setting.

Remote control buttons and functions

Adjust the volume

Press the 7 q buttons to adjust the volume.

The volume level indicator appears and the volume changes as you press the 7 q buttons.

ENGLISH

 Muting the sound

Press the l (muting) button to turn off the sound.

Pressing the l (muting) button again restores the previous volume level.

Display function

You can see the channel number of the programme you are watching or the PR LIST. From the PR LIST, you can choose a channel or VIDEO terminal.

Press the

the information you want to see.

Pressing the

display as follows:

PR LIST

PR ID

AV 01 02 03 04 05 06 07 08 09

+10-10

D0011

-EN

Channel number display:

The channel number and channel name (when the channel name is registered) of the programme you are watching or the VIDEO terminal number is displayed.

button to display

button changes the

Channel number display

No indication

PR LIST:

The programme number (PR) and VIDEO terminal list is displayed. Pressing the a button after choosing the programme number (PR) or VIDEO terminal with the 7 buttons will display the chosen programme or VIDEO terminal.

• For programme numbers (PR) for which the CHANNEL GUARD function is set, the n (CHANNEL GUARD) mark is displayed. For details see “CHANNEL GUARD” on page 30.

• The VIDEO terminals are registered after the programme number PR 99.

• For programme numbers (PR) which is registered as a favourite channel, the d (favourite) mark is displayed. For details see “Favourite channel function” on page 17.

Remote control buttons and functions

ZOOM function

You can change the screen size according to the picture aspect ratio. Choose the optimum one from the following ZOOM modes.

• The ZOOM mode is fixed at FULL when you are using the TV as a PC screen or watching a 1080i or 720p picture signal.

AUTO:

When a WSS (Wide Screen Signalling) signal, which shows the aspect ratio of the picture, is included in the broadcast signal or the signal from an external device, the TV automatically changes the ZOOM mode to 16:9 ZOOM mode or FULL mode according to the WSS signal. If a WSS signal is not included, the picture is displayed according to the ZOOM mode set with the 4:3 AUTO ASPECT function.

• For details of the 4:3 AUTO ASPECT function, see “4:3 AUTO ASPECT” on page 27.

• When the AUTO (WSS) mode does not function correctly due to poor WSS signal quality or when you want to change the ZOOM mode, press the c button and change to another ZOOM mode.

REGULAR:

Use to view a normal picture (4:3 aspect ratio) as this is its original shape.

16:9 ZOOM:

This zooms up the wide picture (16:9 aspect ratio) to the full screen.

16:9 ZOOM SUBTITLE:

This zooms up the wide picture (16:9 aspect ratio) with subtitles to the full screen.

FULL:

This uniformly stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the wide TV screen.

• For 16:9 aspect ratio pictures that have been squeezed into a normal picture (4:3 aspect ratio), use the FULL mode to restore the picture to its original shape.

 Choose the ZOOM mode

1 Press the c button to display

the ZOOM menu

ZOOM

AUTO REGULAR PANORAMIC 14:9 ZOOM 16:9 ZOOM 16:9 ZOOM SUBTITLE FULL

ENGLISH

PANORAMIC:

This stretches the left and right sides of a normal picture (4:3 aspect ratio) to fill the screen, without making the picture appear unnatural.

• The top and bottom of the picture are slightly cut off.

14:9 ZOOM:

This zooms up the wide picture (14:9 aspect ratio) to the upper and lower limits of the screen.

D0009

-EN

2 Press the 6 buttons to choose a

ZOOM mode. Then press the a button

The picture expands and the chosen ZOOM mode is displayed in about 5 seconds.

• The ZOOM mode may be automatically changed by the control signal from an external device. When you want to return to the previous ZOOM mode, choose the ZOOM mode again.

Remote control buttons and functions

 Adjusting the visible area of the


If subtitles or the top (or bottom) of the picture are cut off, you can adjust the visible area of the picture manually.

1 Press the c button

ENGLISH

The ZOOM menu appears.

2 Press the a button to display the

ZOOM mode indicator

The indicator appears.

16 : 9 ZOOM

D0010-EN

3 While it is displayed, press the 6

buttons to change the position of the picture

• You cannot adjust the visible area in REGULAR or FULL mode.

The visible area adjustment is saved even after the TV channel is changed. However, it is cancelled if the following operations are performed.

• The power is turned off/on

• The ZOOM mode is changed

• The X (Multi) button, f (Freeze) button, or g (Text) button is pressed

• The TV is switched between TV mode and VIDEO mode

CINEMA SURROUND function

You can enjoy sounds with a wider ambience.

• This function does not work for the sound from headphones.

• When you set the CINEMA SURROUND function to HIGH mode, there may be slight volume distortion. If that occurs, please switch to LOW mode. The effect of CINEMA SURROUND functions will be less noticeable, but the volume distortion will be corrected.

MONO:

Select the MONO mode, when you listen to the mono sound. You can enjoy the sound for a wider audience similar to stereo sound.

OFF:

The CINEMA SURROUND function switches off.

• You can choose the CINEMA SURROUND mode with the “SOUND menu” (see page 28).

Using the “Freeze” function

You can view the current programme as a still picture.

1 Set the PIP/TV/DVD switch to the

PIP position

When using the “Freeze” function, set the PIP/TV/DVD switch to the PIP position.

2 Press the f button

The still picture of the current picture will appear.

current

programme

D0056

still picture

Press the 2 button to select one of CINEMA SURROUND modes

HIGH/LOW:

When you listen to stereo sound, please select HIGH or LOW mode. You can enjoy sound similar to the experience at the theatre. When you combine the functions of A.H.B. and BBE, you can enjoy more powerful sound.

Remote control buttons and functions

To cancel the “Freeze” function:

Press the f button, the 6 p buttons or the number buttons.

• The “Freeze” function does not work while a sub-picture is displayed.

• The still picture cannot be output from the TV.

• The “Freeze” function does not work for picture of PC signals.

Using the “Multi-picture” function

1 Set the PIP/TV/DVD switch to the

PIP position

When using the “Multi-picture” function, set the PIP/TV/DVD switch to the PIP position.

2 Press the X button

The “Multi-picture” menu appears.

D0101

3 Press the 5 buttons to choose

the number of screens and then press the a button

D0102

D0103

D0104

2-pictures multi:

Main-


With 1080i and 720p signals, the screen is split into two as shown below.

Main-


212

Choose to return to one screen.

Choose to change to 2-pictures multi.

Choose to change to 12-pictures multi.

Subpicture

D0056

Sub-

D1056


12-pictures multi:

Still pictures

Moving

D0058


• When set to 2-pictures multi, you can view a TV picture and a picture from an external device. You cannot view a TV picture on more than one screen at the same time.

• When 12-pictures multi is set, pictures from external devices are not displayed.

• When watching a picture from the HDMI signal, 12-pictures multi can not be displayed.

• When set to 2-pictures multi, the mainpicture can be changed by pressing the 6 p buttons. The sub- picture screen can be changed by pressing the 6 buttons. When set to 12-pictures multi and there are more than 12 pictures, the next or previous 12 screens can be displayed by pressing the 6 p buttons.

• When set to 2-pictures multi, the mainpicture sound from the TV speaker can be changed to the sub-picture sound by pressing the c button when the PIP/ TV/DVD switch is set to the PIP position. (The speaker mark moves from the main-picture to the subpicture.) The sound changes to the main-picture sound if the c button is pressed again. When the headphones are connected, you can listen to the sound from the side at which the headphones mark is displayed. No sound comes from the TV speaker.

• When set to 2-pictures multi, picture from HDMI can not be displayed on the Sub-picture.

• The pictures from VIDEO-1 (or VIDEO-3) cannot be displayed in the sub-picture when the VIDEO-1 SETTING (or VIDEO-3 SETTING) is set to COMPONENT (see page 38).

ENGLISH

Remote control buttons and functions

• The “Multi-picture” function does not work for a PC signals.

• When set to 12-pictures multi, press the 7 buttons to choose the screen you want to view and the press the a button to display that picture

ENGLISH

on the whole screen.

• The BLUE BACK function does not work when the “Multi-picture” function is being used.

• The ZOOM function does not work when the “Multi-picture” function is being used.

To return the “Multi-picture” to one screen:

Press the X button, press the 5 buttons to choose one screen, and then press the a button.

• Pressing the 4 button will also return the display to one screen.

RETURN PLUS function and Return function

The 1 button has two functions; the RETURN PLUS function and the Return function. If a channel has been registered as the “Return Channel”, the RETURN PLUS function operates. If there is no setting for the “Return Channel”, the Return function operates.

 RETURN PLUS

By registering a channel you frequently view as the “Return Channel”, you can select that channel at any time simply by pressing the 1 button.

To register a TV channel as the “Return Channel”:

Choose the Programme number to which the channel you want to register has been set, and press the 1 button and hold for more than 3 seconds continuously. “RETURN PLUS PROGRAMMED!” is displayed and the registration is completed.

To cancel a TV channel registered as the “Return Channel”:

While viewing any TV channel, press the 1 button and hold for more than 3 seconds continuously. “RETURN PLUS CANCELED!” is displayed and the registration is cancelled.

• When you turn off the TV, the registration for the “Return Channel” is cancelled.

• If you want to view the “Return Channel” and another TV channel alternately, first choose a channel other than the “Return Channel”. And then press the 1 button to change the channel to the “Return Channel” In this way, you can view two channels alternately by pressing the 1 button.

 Return function

The TV temporarily memorises the TV channel that was chosen right before the current TV channel as the “Last Channel”. By pressing the 1 button, you can alternately view the current TV channel and the “Last Channel”. If you want to view two channels alternately by using the Return function, first choose one TV channel and then choose the other TV channel with the number buttons. If you choose the TV channel without using the number buttons, there are cases where a channel other than the one you first chose is registered as the “Last Channel”.

+ 42 hidden pages
