VIDEO CD PLAYER
COMPACT
DIGITAL VIDEO
XL-MV338BK
RM-SXMV5U REMOTE CONTROL
DISC 1 DISC 2 DISC 3 POWER
1234
5678
9 10 +10
PROGRAM
CANCEL
RANDOM
REPEAT
VIDEO
HIGHLIGHT
INTRO
KEY CONTROL
MPX
ON SCREEN
ON/STANDBY
POWER
NORMAL
PBC OFFKARAOKE
DIGITAL ECHO
MIN MAX
PHONES KEY CONTROL
XL-MV338 VIDEO CD PLAYER
DOWN NORMAL UP
STANDBY
PlayBack Control
MIC 1
MIN MAX
MIN MAX
KEY CONTROL
MIC 2
MIC 3
MIN MAX
BOOKMARK
SURROUND
VOCAL
REPLACE
NTSC/PAL COMPATIBILITY
VIDEO CD
DISC
3
TRIPLE TRAY
RETURN
VIDEO CD VERSION 2.0VIDEO CD VERSION 2.0
DESIGNED BY JVCDESIGNED BY JVC
JAPAN
12345
678910
VIDEO
INTRO
SELECT
NEXTPREV
STILL
11 12 13 14 15
16 17 18 19 20
PROGRAM
+20
PlayBack
Control
INSTRUCTIONS
'
GRAPHICS
For Customer Use:
Enter below the Model No. and Serial No.
which are located either on the rear, bottom or
side of the cabinet. Retain this information for
the future reference.
Model No.
Serial No.
'
LET0079-001A
[UF]
Warnings
IMPORTANT for the U.K.
DO NOT cut off the plug for this equipment. If the plug fitted is
not suitable for the power points in your home or the cable is too
short to reach a power point, then obtain an appropriate safetyapproved extension lead or consult your dealer.
BE SURE to replace the fuse only with an identical approved
type, as originally fitted.
If nontheless the plug is cut off, remove the fuse and dispose of
the plug immediately, to avoid a possible shock hazard by
inadvertent connection to the power supply.
If this product is not supplied fitted with a plug then follow the
instructions given below:
IMPORTANT.
DO NOT make any connection to the terminal which is marked
with the letter E or by a safety ground symbol or coloured green
or green/yellow.
The wires in the lead on this product are coloured in accordance
with the following codes:
Blue : Neutral
Brown : Live
As these colours may not correspond with the coloured markings
identifying the terminals in your plug proceed as follows:
The wire which is coloured blue must be connected to the
terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the
terminal which is marked with the letter L or coloured red.
IF IN DOUBT - CONSULT A COMPETENT ELECTRICIAN.
Caution –– POWER switch!
Disconnect the plug to shut the power off completely. The POWER
switch in any position does not disconnect the unit from the power
source. The power can be remote controlled.
CAUTION
To reduce the risk of electrical shock, fire, etc.:
1. Do not remove screws, covers or any parts.
2. Do not expose this appliance to rain or moisture.
G-1
IMPORTANT FOR LASER PRODUCTS
DANGER: Invisible laser
radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE
TO BEAM. (e)
ADVARSEL: Usynlig laserstråling ved åbning, når
sikkerhedsafbrydere er ude
af funktion. Undgå udsættelse for stråling (d)
VARNING: Osynlig laserstrålning när denna del är
öppnad och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO: Avattaessa ja suojalukitus ohitettaessa olet
alttiina näkymättömälle
lasersäteilylle. Älä katso
säteeseen. (f)
LABELS
1 CLASSIFICATION LABEL PLACED ON REAR ENCLOSURE
CLASS 1
LASER PRODUCT
1. CLASS 1 LASER PRODUCT
2. DANGER: Invisible laser radiation when open and interlock failed or
defeated. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user service-
able parts inside the Unit; leave all servicing to qualified service
personnel.
2 WARNING LABEL PLACED INSIDE THE UNIT
G-2
GENERAL INFORMATION
Care and handling of
compact discs
English
How to handle CDs
When handling a compact disc, do not touch the surface of the disc
(reflective silver side –– the side without the label).
Since compact discs are made of plastic, they are easily damaged. If
a disc gets dirty, dusty, scratched or warped, the sound will not be
picked up correctly and, in addition, such a disc may cause the CD
player to malfunction.
Even on label side
Do not damage the label side, stick paper to or use any adhesive on
its surface.
Storage
Make sure that discs are kept in their cases. If discs are piled one on
top of another without their protective cases, they can be damaged. Do
not put discs in a location where they may be exposed to direct sunlight,
or in a place where the humidity or temperature is high. Avoid leaving
discs in your car!
Maintenance of discs
If there are fingerprints or other dirt adhering to a disc, wipe it with a soft
dry cloth, moving from the center outwards.
If a disc is difficult to clean, wipe with a cloth moistened with water.
Never use record cleaners, petrol, alcohol or any anti-static agents.
Which compact discs can be used?
Many types of compact discs are sold for a variety of uses. The Video
CD Player can play the following compact discs:
• Video CD
for audio and video (moving picture) reproduction,
including multiplex sound.
• Video CD with Playback Control function
featuring menu-type operation and super-fine still
pictures for audio and video (moving picture) reproduction, including multiplex sound.
• CD Graphics (CD-G)
for audio and video (still picture) reproduction,
including multiplex sound.
• Digital Audio CD, including single discs
for audio reproduction.
CDs you can't play back
Do not play back CD-ROMs, DVDs, or CD-is on this equipment. Doing
so may generate a noise which can damage your speakers.
Using the remote control
The remote control is ready to use when its batteries are installed
properly.
To use it, point its infrared light-emitting window toward the display
window of the player and press a button. The operating range of the
remote control is up to about seven meters in front of the player and
within about 30 degrees to each side –– with nothing between the
remote control and the player interrupting the beam path.
If pressing a button on the remote control does not produce any
response, check to make sure it is pointed correctly and try again. If it
still does not function, check the batteries.
COMPACT
DIGITAL VIDEO
PlayBack
Control
'
GRAPHICS
'
CAUTION
Sometimes during play noise or images may be garbled. This is
sometimes due to the disc. (It may not be up to industry standards.)
These symptom are caused by the discs, not by the malfunction of
the Player.
Page 1
BEFORE USING FOR THE FIRST TIME
Basic Connections
The Video CD Player must be connected directly to a television set or
an amplifier that is connected to a television or monitor. The television
set or the amplifier must have audio input jacks for right and left
channels and a video input jack.
Select a level, dry location free of dust and vibration, and having a
temperature maintained between 5 and 35°C (41 and 95°F).
Connecting player to a TV or amplifier
using the Audio Video cord
First connect the Audio Video cord — before connecting the AC power
cord.
Firmly insert the yellow pin plug of the Audio Video cord in the yellow
VIDEO OUT jack on the rear panel of the player; the red pin plug in the
red AUDIO OUT (RIGHT) jack; and the white pin plug in the white
AUDIO OUT (LEFT) jack. (The RIGHT and LEFT output jacks are for
the right and left audio channels.)
Then make sure that the television, amplifier or receiver is turned off,
disconnect the AC power cord and firmly insert the pin plugs at the
other end of the Audio Video cord into the matching video and audio
INPUT jacks.
Notes
• When you play a NTSC disc in PAL AUTO mode on a PAL exclusive
TV, the image may get distorted.
(If the signal doesn’t synchronize.)
In this case, reselect the mode to “PAL”.
• Select the mode before you play the disc. If you change the mode
during play, images may get distorted. In this situation stop the
player and reset the mode.
• When you play a NTSC disc in PAL AUTO mode on a Multi system
TV, the image may blink for a moment. This symptom is caused by
the Player detecting the format of the disc and not caused by a
malfunction of the Player.
Connecting the power cord
IMPORTANT
Check the setting of the LINE VOLTS switch on the rear panel of the
player. Change the setting if the switch is not set for the main voltage
supplied to your home.
With the LINE VOLTAGE switch correctly set and the audio-video
connectors connected, insert the smaller plug of the power cord
firmly into the AC POWER CORD socket on the rear panel of the
player.
When the power cord is connected, the STANDBY indicator on the
left-hand side of the player’s front panel comes on. [See “Overview
of controls” for a description of the controls on the player.]
VIDEO
AUDIO OUT VIDEO OUT SELECT
OUT
RIGHT LEFT
(Yellow)(Red) (White)
PAL
NTSC PAL AUTO
Audio Video cord
To input audio jack of
the television/amplifier/
receiver
To input video jack of
the television/amplifier/
receiver
Video out select
Set the VIDEO OUT SELECT switch on the rear panel to NTSC, PAL,
or PAL AUTO mode according to your television system.
NTSC .................... for NTSC exclusive TV
PAL ....................... for PAL exclusive TV
PAL AUTO ............ for Multisystem TV
PAL AUTO is the mode to detect the format of the
disc (NTSC/PAL) automatically and play the image on screen the right way.
LINE VOLTS
115V-127V
220V-240V
AC POWER CORD
AC power cord
Wall outlet
Line voltage alteration
What is your power main voltage? Is it between 115 and 127V, or 220
and 240V? If the LINE VOLTS switch on the rear panel of the player is
not set to your power main voltage, disconnect the power cord, if it is
already connected, and change the switch setting accordingly.
Page 2
Installing batteries
BEFORE USING FOR THE FIRST TIME
English
Putting batteries in the remote control
The battery compartment is located on the back of the remote control.
1. Press down on the triangular mark of the compartment cover,
and slide the cover off to open the compartment.
2. Place the two accessory R03 (UM-4)/AAA (24F) batteries in
the remote control according to the polarity markings (“+” and
“–”) inside the compartment and on the batteries.
Precautions for the safe use of batteries
Observe the following precautions for the safe use of batteries. Their
life will be shortened, they may burst or their contents may leak if they
are used improperly:
• Remove batteries from the remote control if it is not going to be used
for a long period of time.
• Remove dead batteries and dispose of them properly.
• Never leave dead batteries lying around, take them apart, mix them
with other refuse, or throw them into an incinerator.
• Never touch liquid that has leaked out of a battery.
• Do not mix new and old batteries, or batteries of different types,
when replacing them.
3. Place the cover over the compartment, press down lightly, and
push it upward until it snaps on.
The batteries last about one year with normal use. If function of the
remote control become erratic, replace the batteries. See “Precautions
for the safe use of batteries” below for more information.
Page 3
OVERVIEW OF CONTROLS
Here the basic function of controls on the front panel of the Player and the
remote control are explained. The function of some controls may be
restricted in actual use depending on the on-going operations. The remote
ON/STANDBY
1
POWER
NORMAL
4
DIGITAL ECHO
5
MIN MAX
PHONES KEY CONTROL
7
XL-MV338 VIDEO CD PLAYER
2
STANDBY
PBC OFFKARAOKE
8
DOWN
MIC 1
MIN MAX
3
KEY CONTROL
NORMAL UP
PlayBack Control
MIC 2
MIN MAX
6
9
MIC 3
MIN MAX
control has nine (9) unique function buttons in addition to those on the
player. The controls with identical names on the Player as on the remote
control have the same function and are used in the same manner.
10
BOOKMARK
SURROUND
VOCAL
REPLACE
11
12
13
NTSC/PAL COMPATIBILITY
14
VIDEO CD
DISC
3
TRIPLE TRAY
VIDEO
INTRO
15
RETURN
16
Left front panel of the Player
(controls marked (R) have equivalents on the remote control)
1
POWER button (R)
turns the power on and off.
2
STANDBY indicator (Red)
lights when the power cord is connected and the power is turned
off. The STANDBY indicator is not lit when the player is turned on.
3
KEY CONTROL button (R)
Transposes the music key.
DOWN button : used to flatten by a half tone.
NORMAL button: returns to original key tone.
UP # button : used to sharpen by a half tone.
4
MODE switch
Switches the KARAOKE/NORMAL/PBC OFF mode.
KARAOKE mode : one track playing mode.
NORMAL mode : continuous plural tracks playing mode. Re-
quired also for the Playback Control (PBC)
function.
PBC OFF mode : inhibits the Playback Control (PBC) function
5
DIGITAL ECHO knob
adjusts the degree of the echo effect for the microphone (1 through
3) and the wireless microphone voice.
6
MIC1 to MIC3 knobs
adjusts volume of the microphone corresponding to MIC number.
7
PHONE jack
used for connecting stereo headphones. The volume is set to a
predetermined level and is not adjustable.
8
KEY CONTROL jack
used for connecting a microphone with key control function.
9
MIC jacks (1 through 3)
used for connecting microphones (1 through 3). The jacks correspond to MIC 1 to 3 volume knobs located above.
of the video CD.
Center front panel of the Player
10
DISC1 to DISC3 trays
used to load discs. To insert/remove one or up to three (3) discs,
press the 0 OPEN/CLOSE button located at the right of the tray
corresponding to disc number.
11
BOOKMARK button
Place a "bookmark" at a video segment you want to find later for
almost instant play. (See page 12.)
12
SURROUND button
Changes the surround mode. (See page 12.)
13
VOCAL REPLACE button
activates the vocal replace function, which inserts your voice in
place of the vocals on the disc.
14
Display window
shows information about the status of operation.
15
VIDEO INTRO button (R)
applies to video CDs only. The introductory five (5) seconds of
tracks on a video CD are displayed on the television screen in order
to present the contents of the video CD. (See page 11.)
16
RETURN button (R)
Utilized for operation with the PBC function. This button is used to
return to a menu screen during play. (See page 14.)
Right front panel of the Player
17
0 (OPEN/CLOSE) buttons (Disc number 1 to 3)
Used to open and close disc trays 1 to 3 respectively. When, after
opening the DISC1 tray, another 0 (OPEN/CLOSE) button is
pressed, the DISC1 tray is first closed, then the other DISC tray
selected is opened.
18
DISC1 through DISC3 buttons with indicators (Green) (R)
plays the disc of the number indicated on the button. As soon as
the disc begins playing, the indicator blinks.
Page 4
17 18
VIDEO CD VERSION 2.0
DESIGNED BY JVC
JAPAN
12345
OVERVIEW OF CONTROLS
English
RM-SXMV5U REMOTE CONTROL
DISC 1 DISC 2 DISC 3 POWER
1234
5678
678910
20
PREV
22 23
SELECT
NEXT
21
STILL
19
Number keys (1 to 20) (R:1 to 10)
used to specify a track number for playing, changing, or programming. To operate numbers above twenty (20), press the +20 button
once. The number keys (1 to 20) are then assigned 21 to 40
numbers instead of 1 to 20. The maximum key number assignment
is 99. In PBC function operation, the number keys are additionally
utilized for the selection of menu items. See page 14 “ Operation
of Playback Control function”.
20
3 SELECT (PLAY) button (R)
Starts to play the disc with/without the Playback Control function.
21
4 / ¢ PREV / NEXT buttons
During operation with the Playback Control function
invokes previous or next screen.
During operation without the Playback Control function
skips forward or backward quickly from current track being played.
When pressed and held down, play fast backward/forward. See
page 8.
22
7 (STOP) button (R)
Stops play.
23
8 STILL (PAUSE) button (R)
temporarily suspends playing. Video motion freezes and audio
reproduction stops. Pressing the button repeatedly advances the
picture frame-by-frame. (Video CD only)
24
PROGRAM button (R)
Any desired sequence of tracks can be programmed with the
number keys and the +20 button. (on the remote control please use
+10) The program button is not available while the Playback
Control function is activated.
25
+20 button
used to shift the numbers assigned to the number keys to 21 or
higher (maximum 99).
11 12 13 14 15
16 17 18 19 20
PROGRAM
24
On the remote control unit
26
+10 button
used to shift the numbers assigned to the number keys to 11 or
higher (maximum 99).
9 10 +10
26
19
PROGRAM
+20
CANCEL
RANDOM
REPEAT
VIDEO
HIGHLIGHT
INTRO
25
KEY CONTROL
27
CANCEL button
MPX
ON SCREEN
27
28
29
30
31
32
33
34
cancels the latest track you have programmed. The latest programmed track is canceled whenever you press this button. Also
used to cancel a bookmark.
28
REPEAT button
repeats a track or inserted discs from 1 to 3.
29
RANDOM button
changes the disc track program to a random sequence from DISC
1 through 3 respectively.
30
HIGHLIGHT button
applies to a video CD to see highlights of a track. Displays the first
(5) seconds of each of nine (9) equal-time segments of the track.
31
MPX button
activates the multiplex function, which switches to NORMAL
(stereo), L-ch monoral and R-ch monoral.
32
ON SCREEN button
controls whether or not control and operation status are displayed
on the television screen or monitor.
33
1 / ¡ MANUAL SEARCH button
shifts the playing location backward and forward quickly. Holding
down the button causes it to go much faster.
34
4 / ¢ AUTO SEARCH button
skips forward or backward from a current track. Holding down the
button causes it to skip tracks much faster.
Page 5
BASIC OPERATIONS
Now you can play a
variety of video CDs!!
Overview of the three modes
This Player has three (3) modes called KARAOKE, NORMAL, and
PBC OFF mode. These are selected by the MODE switch. This
enables various ways of playing a video CD.
NORMAL PBC OFFKARAOKE
KARAOKE mode:One track playing mode. Whenever one track has
completed play, the Player stops.
NORMAL mode: Continuous plural tracks playing mode. The Player
plays tracks continuously in the order they appear
on the disc.
PBC OFF mode: This mode is identical to the NORMAL mode,
except that the PBC function is inhibited.
To set the mode, switch the MODE switch on the left side of the front
panel.
Triple disc tray usage
Up to three (3) discs can be loaded in the Player. You may insert a disc
into any of the disc trays 1 through 3 whichever you prefer.
If you want to play only a specified disc, press the corresponding disc
1, 2 or, 3 button located to the right of the 0 (OPEN/CLOSE) button.
Description of the display window
The display window indicates many aspects of control and operation
status.
4
1 52 3
1
Shows the disc number being played.
2
Shows mainly the total number of tracks and the track number
being played.
3
Shows the surround mode status and the cumulative time (minutes
and seconds) of the track and afterward, total time of the disc is
displayed.
4
The combination of VCD, PBC, and CD-G indicators lit shows the
type of disc being played.
5
Each indicator in this area lights when the corresponding function
is activated.
When three discs are in inserted, basic order of playing is as following.
• Pressing DISC 1: DISC 1 = DISC 2 = DISC 3 = STOP
• Pressing DISC 2: DISC 2 = DISC 3 = DISC 1 = STOP
• Pressing DISC 3: DISC 3 = DISC 1 = DISC 2 = STOP
DISC
3
TRIPLE TRAY
Page 6
BASIC OPERATIONS
SELECT
1234
5678
9 10 +10
English
Preparation for playing
Turn on the television set, amplifier or receiver to which the Player
is connected, and then select the proper channel and mode to
operate the Player, and set the sound volume to a reasonable
level.
Press the POWER button on the front panel or remote control.
ON/STANDBY
POWER
STANDBY
The STANDBY indicator
goes out.
The display window shows the initial information as shown below.
Easy start up
Without pressing the POWER button you can start up the Player by
pressing 3 SELECT button or disc buttons.
Inserting/removing the disc(s)
Starting to play disc(s)
Press the
the disc indicated in the Display window.
Press one of the DISC 1 through 3 buttons and the Player plays the
disc you pressed, from the 1st track. For individual track selection, use the number keys or the
When you start play, the Display window shows disc number and the
track number being played.
During play, the indicator on the DISC button blinks.
If the PBC function is activated, the display window shows “Pb” until
you play a track, and the television screen shows the initial menu, DISC
number, and “PBC”. See page 18, “Operation of Playback Control
function”.
When you press 3 SELECT button during play, the disc will restart
from the beginning of the track except when the PBC function is
activated.
33
3 SELECT (PLAY) button. The Player starts to play from
33
44
¢¢
4/
¢ PREV/NEXT buttons.
44
¢¢
or
Using number keys
Press the
tray. Then place the disc in the round recess of the tray with label
side up. To close the tray, press the
again.
If you press the 0 (OPEN/CLOSE) button of the playing disc, the
Player stops and then opens the tray.
If you press the 0 (OPEN/CLOSE) button of a disc that is not being
played, you can change discs without stopping play.
Notes
• When loading a disc in the disc tray, be sure to position the disc
inside the recess. Otherwise, the disc will be damaged when the
disc tray is closed, and the disc cannot be removed from the unit.
CD
Tray
00
0 (OPEN/CLOSE) button (1 through 3) to open the disc
00
00
0 (OPEN/CLOSE) button
00
CORRECT
INCORRECT
Press the number keys to select numbers.
On the Player.................... 1 to 20 and +20 key
Example: For number 5, press 5. For number 15, press 15. For
number 32, press +20 button, then 12. For number 42, press +20 twice,
then 2.
12345
678910
11 12 13 14 15
16 17 18 19 20
+20
On the remote control ..... 1 to 10 and +10 key
Example: For number 5, press 5. For number 15, press +10, then 5.
For number 20, press +10, then 10. For number 32, press +10 three
times, then 2.
Note
When you press number keys, track will start playing without pressing
3 SELECT button.
Page 7
BASIC OPERATIONS
Stopping play
Press the
77
7 (STOP) button to stop play at any time.
77
STILL
Pausing play
Press the
Notes
• When the 8 STILL (PAUSE) button is pressed once, “PAUSE”
• To release the pause, press the SELECT or blinking DISC 1
• During “PAUSE” the time counter on the display will blink.
88
8 STILL (PAUSE) button to temporarily suspend play.
88
STILL
appears on the television screen, the video motion freezes and the
sound is turned off. The still picture advances frame-by-frame each
time the 8 STILL (PAUSE) button is pressed. This frame-by-frame
function is effective only for video CDs.
through 3 button.
Auto search/Manual search
On the Player, during play, pressing the
the Player to replay the current track from the beginning. Press-
44
ing the
4 button twice causes the Player to play the previous
44
track. Pressing the
the next track. Holding down the
to fast reverse or forward.
On the remote control, holding down the
the disc to fast reverse or forward.
Continuing to hold down the buttons causes it to search much
faster.
On the remote control, during play, pressing the
causes the Player to replay the current track from the beginning.
Pressing the
previous track. Pressing the
to skip to the next track.
¢¢
¢ button once causes the Player to skip to
¢¢
(Remote control)
44
4 button twice causes the Player to play the
44
¢¢
¢ button once causes the Player
¢¢
44
4 button once causes
44
44
¢¢
4/
¢ buttons causes the disc
44
¢¢
NEXTPREV
11
¡¡
1/
¡ buttons causes
11
¡¡
44
4 button once
44
Page 8
(Remote control)
Using stereo headphones
Connecting stereo headphones
Connect stereo headphones to the PHONES jack at the lower-left of
the front panel. The volume level is fixed and cannot be adjusted.
PHONES
VARIOUS UNIQUE FUNCTIONS
2-1
2-2
2-3
2-4
2-5
3-1
1-1
1-2
1-3
PROGRAMMED SONGS
Various functions can
enhance your enjoyment
English
Display of operations status
Preparation
This function is controlled by the remote control.
Operation
Press the ON SCREEN button on the remote control. By pressing
the ON SCREEN button, the following information may be easily
and quickly displayed or vanished on the television screen.
Time, Disc mode, Echo effect, Key control, Program, Repeat, Random, Multiplexing, Vocal replace, Vocal masking, Bookmark, etc.
PROGRAMMED SONGS
ON SCREEN
(Remote control)
2-1 1:30
(Television screen)
Programming the track sequence you want
Preparation
It is not possible to enter programming mode during play.Verify
whether the Player is playing. If playing, stop the player with the 7
STOP button.
Canceling a programmed track
Operation
There are three (3) canceling functions (canceling the last programmed track, canceling the current track, canceling the next
track to be played).
• To cancel the last programmed track press the CANCEL
button on the remote control and the last programmed track
will be canceled. This can be done while a disc is playing.
The number located lowest is the
latest track programmed.
(Television screen)
• To cancel the current track press
• To cancel the next track, wait until the current track has
finished and press the
canceled and the unit will go to the next programmed track.
¢¢
¢ button and the next track will be
¢¢
Note
To verify the track you programmed, stop the Player and see ON
SCREEN information
77
7 STOP button.
77
Operation
1. Press the PROGRAM button to enter the programming mode.
“PROGRAM” is displayed in the display window.
PROGRAM
2. Specify the disc by the DISC (1 through 3) button and then the
track by the number keys successively. You can program up
to nine (9) tracks by repeating this procedure.
3. To play the programmed track press the
button.
33
3 SELECT (PLAY)
33
Notes
• The track number playing, next track programmed, and number of
programmed tracks are displayed from the left-top of the television
screen. You may use the ON SCREEN button to delete this
information.
• Once the programmed track is played, it is deleted from the
program.
• You may continue to program even while the disc is playing.
Page 9
VARIOUS UNIQUE FUNCTIONS
Clearing a program
To delete all programmed tracks you have entered, press the
STOP button and then the PROGRAM button. “PROG OFF” will
be displayed on the television screen.
STILL
PROGRAM
Note
The Player does not cancel the track program even if the 7 (STOP)
button is pressed. Pressing the 3 SELECT (PLAY) button again
causes the Player to resume playing from the next track.
Repeating tracks
It is possible to repeat all discs or only a single track.
Preparation
This function is controlled by the remote control.
Operation
By pressing the REPEAT button, channel REPEAT modes are
cycled as shown below.
REPEAT
= All discs
Randomly playing tracks
77
7
77
Preparations
• This function is controlled by the remote control.
• The RANDOM button is effective only in NORMAL/PBC OFF mode.
• This function plays tracks randomly from a single disc.
Operation
1. Stop the Player.
2. Press the RANDOM button and random playing will start.
“RANDOM” is displayed in the display window.
RANDOM
(Remote control)
3. To cancel random playing, after stopping the Player [
77
7 (STOP)
77
button], press the RANDOM button again.
STILL
RANDOM
(Remote control)
Note
• Random is not effective in program or KARAOKE mode.
• Only REPEAT ALL is available when in RANDOM mode.
= 1 track
(Remote control) (Display window)
REPEAT ALL
(All discs)
REPEAT1
(1 track)
(Television screen)
REPEAT OFF
Notes
• When playing a programmed sequence of tracks,only one track
repeat is available.
• Only REPEAT1 is available in KARAOKE mode.
• The Repeat function is not available when the player is set to PBC
ON.
• Only REPEAT ALL is available in RANDOM mode.
Playing a multiplex sound CD
This function is used for multiplex sound discs.
Operation
By pressing the MPX button, channel multiplexing modes are
cycled as shown below.
MPX
(Remote control)
NORMAL
(left-channel/
right-channel)
L-CH MONO R-CH MONO
(Television screen)
Page 10
VARIOUS UNIQUE FUNCTIONS
123
HIGH LIGHT
456
789
HIGHLIGHT
English
Viewing the VIDEO INTRO of a video CD
Preparation
When you play a video CD with the Playback Control function, the
mode switch is recommended to be in the PBC OFF mode or KARAOKE
mode.
Operation
1. Play the disc you want to see a digest of.
2. Press the VIDEO INTRO button on the Player or the remote
control just after starting disc play. Then the Player starts to
display in sequence the first five (5) seconds and track numbers of all tracks on the disc.
VIDEO
INTRO
VIDEO
INTRO
or
(Remote control)
3. To select a track during digest display, press the number key
corresponding to the item number on the television screen.
VIDEO INTRO
123
456
789
(Television screen)
Programming during VIDEO INTRO
Operation
1. Stop play.
2. Press the PROGRAM button so that PROGRAM is lit in the
display.
3. Press the disc button you want to play, and enter 1 on the
keypad.
4. Press the
press the VIDEO INTRO button.
5. The Player starts to display in sequence the first five (5)
seconds and track numbers of all tracks on the disc. Select the
number you want to program. You can program nine (9) tracks.
6. Press the
33
3 button and then, after the disc has started to play,
33
33
3 button to play.
33
Viewing the highlights of a video CD
This function is used for a movie video CD.
Preparations
• When you play a video CD with the Playback Control function, the
mode switch is recommended to be in the PBC OFF mode or
KARAOKE mode.
• This function is controlled by the remote control unit.
Operation
1. Start playing the track you want to see the highlights of.
2. After the track begins to play, press the HIGHLIGHT button on
the remote control.
(Remote control)
(Television screen)
3. To select one of the nine (9) segments, press the number key
(1 to 9) of the segment which you want to play.
Notes
• When you choose a highlight it will start from five (5) seconds before
the shown time below each segment.
• The highlights show the proceeding five (5) seconds up to the
displayed time on each highlight.
• The segments are each of nine (9) equal-time period divisions of the
track.
• Nine (9) different highlights are displayed for one (1) minute.
• If no highlight is choosen in the one (1) minute period in normal
mode or PBC OFF mode the next nine (9) segment highlights will
begin, in KARAOKE mode highlights will stop.
• While in VIDEO INTRO or HIGHLIGHT, sometimes image is
garbled partially. This symptom is caused by noise in the disc itself
or incorrect manufacturing, it is not caused by a malfunction of the
Player.
Page 11
VARIOUS UNIQUE FUNCTIONS
Playback with the
Bookmark function
Selecting the surround mode
You can change the sound ambiance using the Surround function.
Operation
1. Choose from among the following three surround modes to
change the disc mood.
CLUB: A more intimate sound with greater resonance and
bass.
HALL: Enhances the mid-frequency range (which the human
voice occupies), imitating the effect achieved in a
concert hall.
STADIUM: Adds presence and spreads the sound, like in a sta-
dium.
2. To select the surround mode, push the SURROUND button
until the name of the desired sound mode appears on the
television screen and in the display window.
SURROUND
Each time you press the button, you toggle the mode as
follows:
CLUB HALL STADIUM OFF
Marking a segment for later viewing with
the Bookmark function
The Bookmark function lets you mark a segment of a Video CD, so that
you can have almost instant playback of a desired scene later.
Even if you take the disc out of the player, its bookmark will stay
recorded for later use, until you erase them, or disconnect the power
cord.
Operation
While playing the disc, press the BOOKMARK button at the
segment you want to mark for later playing.
BOOKMARK
Notes
• The Bookmark function works only with Video CDs.
• You can register one bookmark in a single disc and registration for
up to ten discs is possible.
• The Bookmark function is most easily used when the Player is in
PBC OFF mode.
• If you mark a segment when the Player is set for the Playback
Control (PBC) function, the mark is placed at the beginning of the
scene.
• The Bookmark function does not work in Random and Program
modes.
• When you disconnect the power cord, Bookmark registration is
erased.
(Television screen)
3. To cancel the effect, press the SURROUND button until the
word “OFF” appears on the television screen.
Note
• When the Player is in one of the three Surround modes, you cannot
use the key control, digital echo, vocal replace and MPX functions.
Page 12
Playing the segment you marked
Press the BOOKMARK button when playback is stopped.
Canceling the bookmark
After pressing the BOOKMARK button to start playing the segment you marked, press CANCEL button.
CANCEL
(Remote control)
Using a microphone
MIN MAX
DIGITAL ECHO
VARIOUS UNIQUE FUNCTIONS
English
Using a wired microphone
Operation
1. Insert the connector cable to the end of the microphone.
2. Up to three (3) microphones can be connected to the MIC jacks
on the front panel.
MIC 1
MIN MAX
3. Switch the microphone’s power on.
4. Turn the MIC 1 through MIC 3 knobs clockwise (level up) or
counterclockwise (level down) as desired.
MIC 1
MIC 2
MIN MAX
MIC 2
MIC 3
MIN MAX
MIC 3
Adjusting echo effect
Turn the DIGITAL ECHO knob clockwise (level up) or counterclockwise (level down) to adjust the echo effect as desired.
Vocal replace
Preparation
This function is used for multiplex sound discs.
Operation
1. Press the VOCAL REPLACE button during play or stop. REPLACE will appear on the display window and VO.REPLACE
will appear on the television screen. When you start singing,
the vocal of the disc is removed and your voice is inserted into
the music.
VOCAL
REPLACE
MIN MAX
MIN MAX
MIN MAX
ATTENTION
When you are not using the microphone, it is recommended to set
the MIC switch to OFF; otherwise the batteries will discharge even
when not in use.
Adjusting music key
Press the KEY CONTROL buttons ( or #) to change the key in
which the music plays. To return the music to its original key,
press the NORMAL button.
You can adjust the music on the remote control unit also.
DOWN
Notes
• The degree the key has been sharpened or flattened is displayed
on the television screen.
• When the song ends the key control will return to NORMAL mode
automatically.
KEY CONTROL
NORMAL UP
2. To cancel voice replacement, press the VOCAL REPLACE
button again.
Note
• You cannot use the Vocal Replace function with a disc that has
vocals recorded on the left channel.
ATTENTION
Be sure to remove the microphone
Note when connecting the sound output to the input of a TV or VCR:
If an excessively strong signal is given to a unit through a microphone, for example when using Karaoke, it may cause an adverse
effect such as distorted sound. Lower the sound volume using the
microphone control.
Karaoke etiquette
Be aware of your neighbors when enjoying karaoke music. Particularly late at night, the sound you enjoy may reach your neighbors
more than you expect. Common sense and courtesy are always
appreciated.
Page 13
OPERATION OF PLAYBACK CONTROL FUNCTION
Playing Video CDs with
Playback Control function
This Player provides a Playback Control function which utilizes a
procedure (menu selection) programmed in a video CD. The playback
operation procedure may differ depending on the disc you use.
The Playback Control function is described below and in the figure.
• High-resolution still image display - Super-fine reproduction of still
images with more than 4 times the resolution of video tape.
• Menu-driven playback - interactive menus for easy selection of
tracks
Preparations
• A video CD with the Playback Control function is required for this
operation.
• Only the NORMAL mode can be used.
• The buttons available for use are the number keys, the 4/¢
PREV/NEXT buttons, 3 SELECT button, DISC (1 through 3)
buttons, and
Button functions
Number keys............................ Select a specific menu item from the
(Including +20 button and television screen or monitor.
+10 button)
4/¢ PREV/NEXT buttons ..Move through menu.
3 SELECT button .................... Starts up a video CD with the PBC
DISC (1 through 3) buttons ....... Start up a video CD with the PBC
RETURN button................ Returns to the menu.
RETURN button.
function in DISC tray 1 to 3.
function in the specified DISC tray.
Operation
1. Verify that the Player is in NORMAL mode.
2. Press the DISC (1 through 3) or
Player starts up the PBC function. “Pb” is shown in the Display
window. The main menu, “PBC”, and disc/track number are
displayed on the television screen.
3. To move through the menus, press the
buttons.
33
3 SELECT button, and then the
33
SELECT
or
2-PBC PBC
1
2
3
4
(Television screen)
44
¢¢
4/
¢ PREV/NEXT
44
¢¢
NEXTPREV
Page 14
4. When the menu you want appears, select an item in the menu
by using the number keys. The numbers on the number keys
correspond to the menu item numbers.
5. To return to a menu and stop the track being played, press the
RETURN button.
RETURN
Notes
• Page numbers in the menu show that preceding pages exist. To
move from the current menu, press the 4/¢ PREV/NEXT
buttons.
• If you have no desire to use the PBC function when playing a disc
with the PBC function, switch the MODE switch to “PBC OFF”
before playing.
• When you change the mode switch except NORMAL mode during
play Playback Control disc, the play stops, so reset again from the
beginning.
• If you press number keys directly to select the track, you can’t enter
the Player into PBC mode.
OPERATION OF PLAYBACK CONTROL FUNCTION
English
Video CD with Playback Control function
What is Playback Control function?
The Playback Control function, ushering a new video CD age, allows
you to enjoy menu-driven operation and high-resolution still images
having a resolution four times greater than moving pictures.
Example of playback by the Playback Control function
1
2
3
12
1
2
3
1
Moving
Moving
213
Moving
Moving
A selection menu is displayed when you start playing a video CD disc
with the Playback Control feature. The selection menu shows a list
of numbers for selection. Some discs may show moving pictures or
a divided screen.
1. When a list of numbers is displayed, selecting a number shows its
contents.
1
2
2
• Menu-driven playback
You can interact with the screen using a menu display to select and
play an entry.
• High-resolution still image display
You can display high-quality images four times clearer than moving
pictures.
Menu screen
3
Moving
To next screen
Still
To previous screen
Still
Moving
Moving
3. When the selection menu is redisplayed after you have played
your selection, selecting a number again can replay its contents.
(Some discs may show the menu screen several times.)
When “Next” and “Prev” are shown, pressing “NEXT” or “PREV”
can change the selection menu.
4. After playback, press RETURN to go back to the previous screen.
Press
RETURN.
Press
RETURN.
Press
RETURN.
2. When a moving picture is displayed, pressing SELECT at the time
when a part of the movie you desire is shown plays the movie.
Note
When a menu is displayed for a long time, about 10 minutes, the
screen background automatically fades out to prevent screen burnin while the setting is suspended.
Page 15
GRAPHIC/DIGITAL AUDIO CDs
Playing CD Graphics/
digital audio CDs
Playing CD Graphics
Basic video CD-playing procedures apply although the pictures are
still. A CD Graphics is identified by “CD-G” shown on the display.
Notes
• The following operations may distort the image on the screen.
Searching for starting point of music
Fast forwarding/reversing
Stop/pause
• If paused, the screen changes to blue in a few minutes. This is to
prevent burn-in of the TV screen.
Playing digital audio CDs
Basic video CD-playing procedures apply to the reproduction of sound.
Note
No indicator will turn on to show the type of the disc on the display.
Page 16
SPECIFICATIONS
Main specifications
English
XL-MV338BK
Model Video CD player
Playback disc Video CD (with/without Playback Control function)
Total harmonic 0.01% (1kHz)
distortion
S/N ratio 93 dB
Frequency 20Hz – 20kHz
response
Input terminal Microphone 2 mV (9.1 k )
Output Line output 2.0 Vrms (full scale)
terminal
Echoing Digital echoing
Power AC 115-127/220-240V
requirements adjustable with the voltage selector
Power 22 watts
consumption 5 watts (in standby mode)
Mass 5.3 Kg (11.7 lbs)
Dimensions 447x 127 x 340.3 mm
CD Graphics
Digital Audio CD
Image output 1.0 Vp-p (75 )
Video (composite)
, 50/60Hz
17-11/16 x 5 x13-7/16 inches
Accessories
AC power cord............................................................................1
Audio Video cord ........................................................................ 1
Remote control unit (RM-SXMV5U) ........................................... 1
Batteries (R03(UM-4)/AAA(24F)) .......................................... 2
Page 17
TROUBLESHOOTING
Troubleshooting
What appears to be a malfunction may not always be serious. Please go through the following list before requesting service.
Symptom
Power does not come on.
Remote control does not work.
No image is displayed on the
monitor.
Playback does not start.
Speaker does not produce
sound.
Sound is distorted or noise is
generated.
Image is garbled.
Sound is intermittent.
Image is garbled.
Possible cause
Power plug is disconnected from AC outlet.
Battery is exhausted.
The tip of the remote controller is not pointed at the right
receiving part of the player.
The video cable is not connected.
The TV is not set in video mode.
An incompatible disc is loaded.
No disc is loaded.
Disc is loaded upside down.
Audio cable is not connected.
Operation of the external amplifier is wrong.
Disc is dirty.
Connection is wrong.
Disc is dirty.
Remedy
Firmly connect the plug to AC outlet.
Replace the battery with a new one.
Use the remote control correctly.
Firmly connect the cable.
Set the TV in video mode.
Load a disc compatible with the player.
Load a disc.
Reload the disc with the label up.
Firmly connect the cable.
Operate the amplifier correctly.
Wipe off the disc surface with a soft cloth.
Correctly connect cables. (See page 2.)
Wipe the disc surface with a soft cloth.
(See page 1)
Disc is scratched.
Disc is warped.
Disc tray does not come out when
OPEN/CLOSE button is pressed.
Operation is not possible.
The malfunction may be caused by a device other than the player. Check other devices connected to the player.
Power plug is disconnected from the power outlet.
Microcomputer malfunctions due to lightning or static
electricity.
Replace the disc with a new one.
Firmly insert the plug into the outlet.
Turn off the power, then on again.
Page 18
English
We would like to thank you for purchasing one of our JVC products.
Before connecting this unit to the wall outlet, please read the instructions carefully to ensure that you obtain the best possible performance.
If you have any questions, please consult your JVC dealer.
Table of contents
GENERAL INFORMATION............................................................. 1
Care and handling of compact discs ............................................... 1
BEFORE USING FOR THE FIRST TIME ....................................... 2
Basic Connections ...........................................................................2
Connecting player to a TV or amplifier
using the Audio Video cord ........................................................ 2
Video out select ..........................................................................2
Connecting the power cord ........................................................ 2
Installing batteries............................................................................ 3
Putting batteries in the remote control ....................................... 3
OVERVIEW OF CONTROLS .......................................................... 4
Left front panel of the Player ...................................................... 4
Center front panel of the Player ................................................. 4
Right front panel of the Player.................................................... 4
On the remote control unit..........................................................5
BASIC OPERATIONS..................................................................... 6
Now you can play a variety of video CDs!!...................................... 6
Overview of the three modes ..................................................... 6
Triple disc tray usage ................................................................. 6
Description of the display window .............................................. 6
Preparation for playing ...............................................................7
Inserting/removing the disc(s) .................................................... 7
Starting to play disc(s) ................................................................7
Using number keys.....................................................................7
Stopping play ..............................................................................8
Pausing play ...............................................................................8
Auto search/Manual search........................................................ 8
Using stereo headphone ............................................................ 8
VARIOUS UNIQUE FUNCTIONS ................................................... 9
Various functions can enhance your enjoyment ............................. 9
Display of operations status ....................................................... 9
Programming the track sequence you want............................... 9
Canceling a programmed track .................................................. 9
Clearing a program...................................................................10
Repeating tracks....................................................................... 10
Randomly playing tracks .......................................................... 10
Playing a multiplex sound CD .................................................. 10
Viewing the VIDEO INTRO of a video CD ............................... 11
Programming during VIDEO INTRO ........................................ 11
Viewing the highlights of a video CD........................................ 11
Selecting the surround mode ................................................... 12
Playback with the Bookmark function............................................ 12
Marking a segment for later viewing with the Bookmark function.... 12
Playing the segment you marked ............................................. 12
Canceling the bookmark........................................................... 12
Using a microphone....................................................................... 13
Using a wired microphone........................................................13
Adjusting music key.................................................................. 13
Adjusting echo effect ................................................................ 13
Vocal replace ............................................................................13
OPERATION OF PLAYBACK CONTROL FUNCTION ............... 14
Playing Video CDs with Playback Control function ....................... 14
Video CD with Playback Control function................................. 15
GRAPHIC/DIGITAL AUDIO CDs.................................................. 16
Playing CD Graphics/digital audio CDs......................................... 16
Playing CD Graphics ................................................................ 16
Playing digital audio CDs ......................................................... 16
SPECIFICATIONS......................................................................... 17
Main specifications ........................................................................17
TROUBLESHOOTING .................................................................. 18
Troubleshooting .............................................................................18
Page 19
Main (AC) Line Instruction (not applicable for Europe, U.S.A., Canada,
Australia and U.K.)
LINE VOLTS
220V-240V
115V-127V
AC POWER CORD
IMPORTANT for main (AC) line
BEFORE PLUGGING IN, do check that your main (AC)
line voltage corresponds with the position of the voltage
selector switch provided on the outside of this equipment
and, if different, reset voltage selector switch, to prevent
damage or risk of fire/electric shock.
EN, CH 0797TTYUVNJSC
VICTOR COMPANY OF JAPAN, LIMITED
JVC
Loading...
