JVC LCT2385-001B-A User Manual

LCD Television Users Guide

LT-32P679

32" class (31.5" Diagonal)

SLEEP

TV STB VCR DVD AUDIO

MODE

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

TUNE

– CH + – VOL +

iPod MUTING

U

N

E

M

F

A

V

O

R

I

T

E

DVR

STATUS

SOUND

SUB CH ML/MTS DISPLAY

TV/VCR

iTV

iPod is a trademark of Apple Inc., registered in the
U.S. and other countries.

POWER

INPUT

+

RETURN

TV

0

B

A

C

OK

K

T

C

E

P

S

A

PCON

VIDEO

GUIDE

SUB T.

RM-C1480

TV

Important Note:

In the spaces below, enter the model and serial number of your television (located at the
rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this
guide. Keep this user’s guide in a convenient place for future reference. Keep the carton
and original packaging for future use.

Serial Number:

Model Number:

LCT2385-001B-A

0608TSH-II-IM

Table of Contents

Warnings . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . 6

Remote Control . . . . . . . . . . . . . 10

TV Basic Controls . . . . . . . . . . . 12

Setup . . . . . . . . . . . . . . . . . . . 16

Initial Setup . . . . . . . . . . . . . . . . . . . 16

Key Features . . . . . . . . . . . . . . . 18

Remote Control Functions . . . . . 19

Sleep . . . . . . . . . . . . . . . . . . . . . 19

Return+ TV . . . . . . . . . . . . . . . . 19

Favorite . . . . . . . . . . . . . . . . . . . 19

Aspect . . . . . . . . . . . . . . . . 20

Sound . . . . . . . . . . . . . . . . 20

Video . . . . . . . . . . . . . . . . 20

Guide . . . . . . . . . . . . . . . . 21

SUB CH . . . . . . . . . . . . . . . . 21

ML/MTS . . . . . . . . . . . . . . . . 21

Customizing your TV . . . . . . . 22

Picture . . . . . . . . . . . . . . . . . 23

Video Status . . . . . . . . . . . . . . . . 23

Color Temp . . . . . . . . . . . . . . . . 24

Color Management . . . . . . . . . . . . . 24

Dynamic Gamma . . . . . . . . . . . . . . 24

Smart Picture . . . . . . . . . . . . . . . . 25

Digital VNR . . . . . . . . . . . . . . . . . 25

MPEG NR . . . . . . . . . . . . . . . . . 25

Natural Cinema . . . . . . . . . . . . . . . . . 25

Video Reset . . . . . . . . . . . . . . . . . 25

Display . . . . . . . . . . . . . . . . 26

Video Input Label . . . . . . . . . . . . . . 26

Photo Viewer . . . . . . . . . . . . . . . . 26

Aspect . . . . . . . . . . . . . . . . . . . 28

TV . . . . . . . . . . . . . . . . . 29

Closed Caption . . . . . . . . . . . . . . . . 29

C.C. Setting . . . . . . . . . . . . . . . . . . . 29

Tuner Mode . . . . . . . . . . . . . . . . 30

Auto Scan . . . . . . . . . . . . . . . . 30

Add Channel . . . . . . . . . . . . . . . . 31

Edit Channel . . . . . . . . . . . . . . . . 31

V-Chip . . . . . . . . . . . . . . . . 31

Guide . . . . . . . . . . . . . . . . 31

TV (V-Chip) . . . . . . . . . . . . . . . . 32

Password . . . . . . . . . . . . . . . . 33

MPAA . . . . . . . . . . . . . . . . 33

Can. Eng. . . . . . . . . . . . . . . . . 34

Can. Fre. . . . . . . . . . . . . . . . . 35

TVPG . . . . . . . . . . . . . . . . . 36

Sound . . . . . . . . . . . . . . . . . 37

MTS . . . . . . . . . . . . . . . . 37

Digital Audio (ML) . . . . . . . . . . . . 37

Surround . . . . . . . . . . . . . . . . 37

Sound Status . . . . . . . . . . . . . . . . 38

Audio Reset . . . . . . . . . . . . . . . . 38

Power . . . . . . . . . . . . . . . . . 39

Sleep Timer . . . . . . . . . . . . . . . . 39

Power Indicator . . . . . . . . . . . . 39

Illumination . . . . . . . . . . . . . . . . 39

Setting . . . . . . . . . . . . . . . . . 40

Plug-In Menu . . . . . . . . . . . . . . . . 40

Time Zone . . . . . . . . . . . . 40

D.S.T. . . . . . . . . . . . . . . . . 40

Language . . . . . . . . . . . . . . . . 40

Noise Mute . . . . . . . . . . . . 40

Front Panel Lock . . . . . . . . . . . . 41

Transparency . . . . . . . . . . . . 41

Auto Shut Off . . . . . . . . . . . . . . . . 41

System Info . . . . . . . . . . . . . . . . 41

Auto Demo . . . . . . . . . . . . 41

Optical Out . . . . . . . . . . . . 41

Enjoy Movies/Music from your

iPod . . . . . . . . . . . . . . . . . . 42

Connecting Your Devices . . . . . 47

Programming Your Remote . . . . 52

Troubleshooting . . . . . . . . . . . . 59

Specifi cations . . . . . . . . . . . . 61

Warranty . . . . . . . . . . . . 62

2

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Warnings

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service
personnel.

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid improper installation and never position the unit where good ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do not attempt to repair
it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to disconnect both the

power plug from the AC outlet and antenna for your safety.

* To prevent electric shock do not use this polarized plug with an extension cord, receptacle or

other outlet unless the blades can be fully inserted to prevent blade exposure.

• As an “ENERGY STAR®” partner,
JVC has determined that this
product or product model meets the
“ENERGY STAR
efficiency.

®

” guidelines for energy

3

Warnings

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal

of these materials may be regulated in your community due to

environmental considerations. For disposal or recycling information,

please contact your local authorities or for USA, the Electronic Industries

Alliance: http://www.eiae.org

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use
caution when moving the cart/apparatus combination to avoid injury
from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,

such as vases, shall be placed on the apparatus.

16) Place the television on a stable, flat surface. Failure to do so can result in the television

falling, causing injury.

17) DO NOT allow young children to play around or on the television. Do not hang from the

TV. Failure to do so can result in the television falling, causing injury.

4

Warnings

18) DO NOT allow young children to play with the plastic bag that came with the television
when you unpacked it. Failure to do so can result in suffocation, causing injury.

19) Avoid improper installation and never position the unit where good ventilation is impossible.
When installing this TV, distance recommendations must be maintained between the set
and the wall, as well as inside a tightly enclosed area or piece of furniture. Keep to the
minimum distance guidelines shown for safe operation.

150 mm

5 7/8 in

200 mm

7 7/8 in

150 mm

5 7/8 in

200 mm

7 7/8 in

50 mm

2 in

20) Cautions for installation

— Do not tilt the TV towards the left or right, or towards the back.

— Install the TV in a corner on the floor so as to keep cords out of the way.
— The TV will generate a slight amount of heat during operation. Ensure that

sufficient space is available around the TV to allow satisfactory cooling.

— Have two people remove the TV from the box with the screen facing away

from you. It's possible your clothing, (such as a belt buckle or button) may
scratch the front of the TV. Do the same when moving the TV to another
location.

21) When attaching to a wall, use the optional JVC wall mounting unit.

For LT-32P679: JVC-XUF-2637 LCD FLAT WALL MOUNT
Caution
— Consult qualified installers.
— See the included manual on mounting procedures.
— JVC is not responsible for damages or injuries due to improper mounting.
— Use with other wall mounting unit is capable of resulting in instability or causing possible

injury.

22) Make enough room for inserting and removing the power plug. Place the TV as close
to the outlet as possible. The main power supply for this TV is controlled by inserting or
removing the power plug.

23) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

24) When this TV is connected to the wall outlet, it is always on standby even when all the LED

lamps are not lit. To shut down the TV, unplug the TV from the wall outlet.

Connect the stand

The TV stand is not attached to the TV when you purchased it. Please follow the steps below on

how to connect the stand to the TV.

1) Insert the TV stand onto the TV.

2) Tighten the 5 screws to the back of the

TV.

5

Warnings

FCC Notice:

Caution: Changes or modifi cations not expressly approved by party responsible for

compliance could void the user's authority to operate the equipment.

We have an important note for customers who subscribe to basic cable services (do not have
a separate cable box) and plan to use their JVC TV remote control to select channels.

Once you run the Auto Tuner Setup (which detects and programs all the channels your TV is
receiving through the RF input), every channel number available from your cable company
will appear in your television’s Channel Summary and they will all be marked as available for
scanning. Even though every channel is detected and appears as available, you will only be
able to view those that you specifi cally subscribe to from your cable company. This will likely
mean there are blank channels between those channels you wish to scan or “surf”.

We apologize for any inconvenience this may cause but it is important to note that this is
not a malfunction of your television. If you want to sequentially scan those channels you
subscribe to without blank ones in between, you can contact your cable company for their
cable box and remote, or manually deselect them using the edit / skip feature on page 30.

Precautions

Avoiding Temporary Burn-in

Displaying fi xed images for extended periods of time can leave a subtle but temporary burn-in
image on your screen. To avoid this, mix your viewing pattern.

Examples include, but are not limited to the following:

• Stock-market report bars

• Shopping channel logos and pricing

displays

• Video game patterns or scoreboards

• Bright station logos

• Internet web sites or other computer-style

images

• DVD discs, video tapes, laser discs

• Broadcast, cable, satellite channels or

digital television tuners/converters

TV on

For example...

TV off

XYZ XYZ

6

Precautions

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth, slightly
moistened with water. You can add a few drops of mild liquid detergent to the water to help
remove spots of oily dirt.

• DO NOT allow liquid to enter the TV through the ventilation slots.

• DO NOT use strong or abrasive cleaners on the TV.

• DO NOT spray liquids or cleaners directly on the TV’s surface.

• DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with a
soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen cleaner
and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the screen.
These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image
distortions.

Tidying the cables

A cable holder which keeps your connection cables tidy is attached to the back of the stand.

7

Precautions

Disconnecting the stand

If you disconnect the stand, attach the bottom cover and the screw (supplied) into the hole.

1) Place the TV face down on a soft cloth on a table.

2) Remove the five screws from the back of the TV.

3) Pull out the stand from the TV.

4) Cover the hole with the supplied bottom cover and tighten the screw.

Notes:

• To re-install the stand, reverse the procedure from 4) to 1).

• If you fi nd it diffi cult to remove the screws from inset screw wells, use a magnetized
screwdriver.

8

Package Contents

Make sure you have the following.

Precautions

Television x 1

Remote Control x 1

SLEEP

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

RETURN

TUNE

0

– CH + – VOL +

iPod MUTING

U

N

OK

E

M

F

A

V

O

E

R

P

I

T

S

E

A

DVR

PCON

STATUS

VIDEO

GUIDE

SOUND

SUB CH ML/MTS DISPLAY

SUB T.

TV/VCR

iTV

RM-C1480

TV

Dock Adapter x 5

ABC

DE

Insert the batteries

Use two “AA” batteries (included).

Place the "–" end in the unit first, making sure the "+" and
"–" markings are correct. Place the "–" end in the unit
first.

AA Batteries x 2

+

POWER

+

TV

B

A

C

K

T

C

+

AA Alkaline

AA Alkaline

–

–

Screw x 1

Bottom Cover x 1

TV Stand

Philips type screws x 5

If this symbol is shown, it is only valid
in the European Union

9

TV DVD/DVR DBB TUNER USB

Remote Control

80

R

S

US

V

O

GUIDE

S

SUB C

S

DIS

SOUND

M

F

A

V

O

R

I

T

E

B

A

C

K

PCO

The following pages gives you a brief description of each button’s function. For more detailed
information on the remote control buttons, see pages 19 - 21. This remote can also control up
to four other devices. See page 52 - 58.

SLEEP

POWER

Choose how long the TV will stay on before

turning off. See page 19.

Turns the TV on or off.

TV STB VCR DVD AUDIO

MODE

Switch between “TV / STB /

VCR / DVD / AUDIO devices.

See page 52.

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

Switch between devices

connected to Video-1, 2, 3,

4 and 5.

For V4 (Video-4) and V5 (Video-5) you must select the signal
input type fi rst (ie. composite, S-Video, or component). To do
so, you need to press the V4 or V5 button until the correct
type is highlighted. Select “Composite 1” for composite video
signal input, “S-Video” for S-video signal input, or “Component
1” for component video signal input. Select “Composite 2” for
composite video signal input or “Component 2” for component
video signal input.

123

456

789

TUNE

0

RETURN

TV

+

Change channels. Input

remote codes. See page 52.

POWER

SLEEP

TV STB VCR DVD AUDIO

MODE

INPUT

V1 V2 V3 V4 V5

TV DVD/DVR DBB TUNER USB

123

456

789

TUNE

RETURN

TV

0

– CH + – VOL +

iPod MUTING

U

N

OK

OK

E

M

F

A

V

O

R

I

T

E

DVR

DV

STATUS

TAT

VIDEO

SOUND

SUB CH ML/MTS DISPLAY

H ML/MT

SUB T.

TV/VCR

TV/VCR

iTV

IDE

UB T.

T

C

E

P

S

A

PCON

GUIDE

PLAY

+

B

A

C

K

N

TUNE

+

RETURN

TV

– CH +

– VOL +

iPod

MUTING

10

Lets you decide the input channel and select

it. After pressing the remote 0 - 9 buttons,

press TUNE.

Lets you go back to the previously selected

channel. See page 19.

Move sequentially through the channels.

Raise or lower the volume.

Control your iPod connected to the TV.

See page 42.

Turns the TV volume to 0. Press again to

restore the volume.

RM-C1480

RM-C14

TV

STAT

Remote Control

R

A

T

4

TU

T

od

–

V3

V5

R

TUNER

80

U

N

E

M

B

A

C

K

F

A

V

S

A

SOUND

VIDEO

GUIDE

SUB CH

TV/VCR

ML/MTS

SUB T.

DISPLAY

Used to access the TV’s onscreen menus.

See page 22.

POWER

TBVC

POWER

UDIO

OK

Used to navigate through the TV’s

onscreen menus.

SLEEP

LEEP

TV STB VCR DVD AUDIO

DE

MODE

INPUT

INPU

V1 V2 V3 V4 V5

Go back to a previous onscreen menu or to

correct a mistake.

VD/DV

123

B

TV DVD/DVR DBB TUNER USB

456

O

R

I

T

E

T

C

E

P

Save your favorite channels. See page 19.

Change the aspect ratio of the image on your

TV screen. See page 20.

789

TUNE

NE

– CH + – VOL +

CH + – VOL +

iPod MUTING

P

RETURN

RETURN

TV

V

0

0

UTING

+

Choose several types of sound frequencies.

See page 20.

Choose different display settings according to

personal preferences. See page 20.

Programming information. (Digital channels

only). See page 21.

Used to select sub channels.

U

N

OK

E

M

F

A

V

O

R

I

T

E

DVR

STATUS

VIDEO

SOUND

SUB CH ML/MTS DISPLAY

SUB T.

TV/VCR

B

A

C

K

T

C

E

P

S

A

PCON

GUIDE

(Digital channels only). See page 21.

Listen to a program in stereo, mono or

iTV

another language (SAP). (Depending on

availability in the program). See page 21.

RM-C1480

View current channel information.

RM-C14

TV

* See page 52 for buttons that control your external devices.

11

TV Basic Controls

Before you connect your television to another device, please refer to the proper diagrams for
your specific TV and remote. These will help assist you in understanding how to connect your
television to another device, as well as use the remote to set up your television. Some of the
connection terminals are color coded for easy connection with the proper cables.

Front Panel

Illumination for iPod

TeleDock

Power Lamp
Remote Control Sensor

Notes:

• Do not use unreasonable force to the TeleDock.

• When not using the TeleDock, close the cover.

• Do not touch the connector pins of the TeleDock or the iPod terminal pins.

• Do not put different devices on the TeleDock. It may cause a connection failure.

Side Panel

12

INPUT

MENU

CHANNEL

VOLUME

BACK

POWER

PHOTO VIEWER

Input

Change the input

MENU

Used to access the TV’s onscreen menus.

+CH–

Move sequentially through the channels.

+VOL–

OK

Raises or lowers the volume.

POWER

Turn the TV on or off.

Photo Viewer Connector

• Do not use Photo Viewer connector to
connect the iPod

AUDIO OUT

L

L

L

P

B

L

PB

R

R

R

P

R

R

PR

VIDEO

Y

VIDEO

Y

AUDIO

COMPONENT

AUDIO

COMPONENT

AUDIO OUT

INPUT 1

HDMI ANALOG

AUDIO

INPUT 5

INPUT 4

S-VIDEO

DIGITAL AUDIO OPTICAL OUT

LC34324-001A

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

L

R

INPUT 1
HDMI ANALOG
AUDIO

L

R

AUDIO

VIDEO

L

R

INPUT 5

COMPONENT

Y

B

R

P

P

AUDIO

VIDEO

L

R

S-VIDEO

INPUT 4

COMPONENT

DIGITAL AUDIO OPTICAL OUT

Y

PB

PR

LC34324-001A

INPUT 1 INPUT 2 INPUT 3

75 Ω

(VHF/UHF)

* For more detailed information, see

pages 47 - 51.

TV Basic Controls

F

Antenna / Cable

A / B A

DVD Player

A

G

H

Audio System

* This is used

when you are
using HDMI
analog audio

C / E

C / E

D

STB (Digital Cable,
satellite) Tuner Box

Video Camera

Game Console

13

TV Basic Controls

Device Side With Cables TV Side

A

HDMI HDMI Cable INPUT 1, 2 or 3

B

Good Best

C

VIDEO and AUDIO

D

E

F

DVI + Audio

Component

Video + Audio

S-Video + Audio

Composite

Video + Audio

Antenna / Cable

(VHF / UHF) RF Cable

DVI – HDMI Cable,

Audio Cable

Component

Video + Audio INPUT 4 or 5

S-Video Cable,

Audio Cable

Composite

Video + Audio INPUT 4 or 5

Input 1 +

HDMI ANALOG AUDIO

INPUT 4 +

AUDIO Input

75Ω

(VHF / UHF)

G

AUDIO

H

Good Best

14

OPTICAL INPUT

OPTICAL AUDIO

AUDIO INPUT

(L / R) Audio Cable

Cable

DIGITAL AUDIO

OPTICAL OUT

AUDIO OUT

(L / R)

Compatible Signal Notes

Input

• HDMI (Digital)
SD: 480i, 480p
HD: 1080i, 1080p/60Hz, 720p
Audio L/R

Input

• DVI (Digital)
SD: 480i, 480p
HD: 1080i, 1080p/60Hz, 720p

• Audio L/R (Analog)

Input

• Component (Analog)
SD: 480i, 480p
HD: 1080i, 720p

• Audio L/R (Analog)

Input

• S-Video (Analog)

• Audio L/R (Analog)

TV Basic Controls

See page 51.

See page 50.

See page 48.

Input

• Composite (Analog)

• Audio L/R (Analog)

ATSC (Digital)
NTSC (Analog)
Clear QAM (Digital)

Output

• Audio L/R (Digital)
(PCM or Dolby Digital)

Output

• Audio L/R (Analog)
(Fixed)

See page 48.

See page 47.

See page 49.

See page 49.

15

Setup

TV

CR

A

O

UT

4

TUNE

T

d

G

–

80

US

V

CR

M

A

V

O

T

A

B

A

C

K

1

V2

3V4V5

V

Initial setup

When you turn on your TV for the first time, the Initial Setup menu appears automatically.
These menus will help you setup your TV with basic information for Language, Time and

Tuner Setup. You can also set this setting in the “Plug in Menu”.

POWER

SLEEP

LEEP

TV STB VCR DVD AUDIO

TB V

DE

MODE

INPUT

INP

V1 V2 V3 V4 V5

V

TV DVD/DVR DBB TUNER USB

TV DVD/DVRBB TUNERB

V

123

456

789

7

TUNE

– CH + – VOL +

CH + – VOL +

iPod MUTING

o

U

N

E

M

F

A

V

O

R

I

T

DVR

STATUS

TAT

SOUND

OUND

SUB CH ML/MTS DISPLAY

UB CH ML/MTS DISPLAY

TV/VCR

TV/V

iTV

iT

0

OK

E

VIDEO

IDEO

SUB T.

RM-C1480

RM-C14

TV

RETURN

TV

TIN

T

C

E

P

S

A

PCON

CON

GUIDE

UIDE

B T.

V

1) Turn on the TV

POWER

UDI

2) Set the language

Set Language/Langue/Idioma

English

+

V

B

A

C

K

Next

1 Select a language

OK

2 Select “Next”

OK

3 Move to next menu

3) Set time attribute

Set Time Attribute

Time Zone

D.S.T.

Atlantic

ON

Next

1 Change settings

OK

2 Select an item
3 Select “Next”

OK

4 Move to next menu

Time Zone Choose the time zone you live in.

D.S.T. Changes the clock automatically for daylight

saving time. On / Off

16

Initial setup (Continued)

od

G

– VO

80

R

US

O

E

R

.

D

M

A

V

O

T

B

A

C

K

Setup

– CH + – VOL +

– CH +

iPod MUTING

P

U

N

E

M

F

A

V

O

R

I

T

E

DVR

V

STATUS

TAT

VIDEO

VIDE

SOUND

N

SUB CH ML/MTS DISPLAY

B CHL/MTSISPLAY

SUB T.

TV/VCR

TV/VC

iTV

RM-C1480

OK

UB T

M-C14

L +

UTIN

T

C

E

P

S

A

PCON

GUIDE

ID

TV

4) Set TV attribute

Set TV Attribute

B

A

C

K

Tuner Mode Air

Start Scan Exit

Tuner Mode Choose Air (antenna) or Cable

* If you use a set top box (satellite or cable box), press “Exit” to

skip this step.

Cable Users: After your auto tuner setup is complete, you may,
(depending on the type of hookup), have only 1 channel, usually
2, 3 or 4 in the auto tuner memory. This is normal.

1 Change settings

OK

2 Select an item

3 Select “Start Scan”

OK

4 Start scanning

channels

“Thank you! Setup is now complete”

Note:

• If you want to turn off the Auto Demo, press the MENU button.

17

Key Features

Your JVC TV is equipped with many features. Here are some key features
highlighted in detail.

1 Simple playback of video and music on

TV. You can charge your iPod. You
can watch a program while listening
to the iPod (source of program must
be from TV’s Internal Tuner). You
can view photos from the iPod while
listening to the iPod.

2 Dynamic Gamma and Color Management give further

fi ne tuned picture reproduction. Smart Picture adjusts the
best possible picture quality automatically scene by scene
based on the incoming signal from any source!

3 JVC exclusive oblique cone speakers provide excellent

TV sound quality. OmniSurround sound provides you 4
different settings based on the program you are watching.
The equalizer will fi ne tune your listening preferences.

Dock adapter (supplied)

TeleDock

4 Full connectivity with 3 HDMI, 2 Component, 1 S-video and others. The variety of

connections are explained on pages 47 to 51.

x 3 x 2

5 Aspect mode will show every pixel you are getting in High Defi nition. Full – with slight

overscan. Panarama and Cinema will fi ll the screen with various aspect settings. Mini Mode
will show a better picture with a smaller screen for low resolution content from your iPod.

Or...

Full or Widescreen Mode – For high
quality iPod sources.

18

Mini Mode – For low quality iPod

sources.

x 1

Remote Control Functions

SLEEP

Sleep

Allows you to choose how long the TV will stay on before turning off.

Notes:

• When you press the SLEEP button several times, you can set the interval at Off, 15, 30, 45,
60, 90, 120, 150 and 180 minutes.

• 60 seconds before the TV turns off, a message will appear and it will count the remaining
time. If you want to extend the time, press the SLEEP button and you can change the
interval. If you don’t press the SLEEP button, within 60 seconds the TV will turn off.

+

RETURN

TV

Return+ TV

Has three functions.

Return – Returns to the channel viewed just before the channel currently onscreen.

Return+ – Lets you program a specific channel to return to while scanning through the

channels using the – CH + button as you memorize the channel.

TV – Returns to the TV mode as you are watching a video, DVD, etc.

Note:

• Press TUNE and RETURN+ TV buttons. This will memorize the current channel to return
to while you scan through the other channels. To cancel, press TUNE and RETURN+ TV
buttons again.

F

A

V

O

R

I

T

E

Favorite

Allows you to save channels you like so you can view them easily. First you must register the
channels you like.

Notes:

• Go to the channel you want to register and press the FAVORITE. A list will appear. Press
the FAVORITE button again to register your channel.

• To view your favorite channels, press FAVORITE. Move to select your channel and

press OK.

• To erase your favorite channels, press FAVORITE. Move to select your channel and

press .

• Both analog and digital channels can be registered.

• The channels you registered will appear in numerical order at the top of the list.

19

Remote Control Functions

STAT

T

C

Aspect

E

P

S

A

Allows you to adjust the way the image appears on your TV based on the format that is being
received.

Panorama / Cinema / Full / Panorama Zoom / Cinema Zoom / Regular / Slim

See page 28.

Notes:

• You can select the aspect mode by pressing the ASPECT button.

• You can also access the aspect modes using the buttons on the side of the TV, by using the

MENU button, then the – CH + button.

SOUND

Sound

You can choose several types of sound modes. Speech / Jazz / Classic / Rock / User

Notes:

• You can choose the different sound modes by pressing the SOUND button.

• If you select User, you can customize the various sound frequencies.

VIDEO

Video

Allows you to choose different picture settings according to personal preferences. You can
access this feature for each input (TV, V1, V2, V3, V4, V5).

Standard / Dynamic / Theater / Game

See page 23.

20
