PARTS LIST
[ KV-MH6500 ]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
E ----------- Continental Europe
J -------------- Northern America
49795
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~02)
Packing materials and accessories parts list (Block No.M3)
3- 2
3- 3
3- 8
3-1
Exploded view of general assmbly and parts list
1
2
3
Block No.
M
M
1
M
6
General assembly
Symbol No.
Part No. Part Name Description Local
4
5
Block No. [M][1][M][M]
1 MH6500-REAR MOUNTING SLEEVE
2 CB-MH6500JE P.C.B.ASSY
3 PUOT01007610 INSULATOR SHEET
4 MH6500-LCD L.C.D.ASSY
5 CB-MH6500JE-SW SW.P.C.B.ASSY
6 MH6500-FPA FRONT PANEL ASS
3-2
Electrical parts list
key board
Symbol No.
D1 PU61CL196YGCDT LED SMD
D2 PU61CL196YGCDT LED SMD
D3 PU61CL196YGCDT LED SMD
D4 PU61CL196YGCDT LED SMD
D5 PU6114Z6V8S Z DIODE
C52 PU171.6KZ106Z CHIP CAP
R1 PU16110TW331J CHIP RESISTOR
R2 PU16110TW331J CHIP RESISTOR
R3 PU16110TW221J CHIP RESISTOR
R13 PU16110TW470J CHIP RESISTOR
R14 PU16110TW471J CHIP RESISTOR
R16 PU16110TW102J CHIP RESISTOR
DOWN PU311047 TACT SWITCH
M1 PU611005 SENSOR SMD
MENU PU311047 TACT SWITCH
MODE PU311047 TACT SWITCH
UP PU311047 TACT SWITCH
XXXXX PU192502V03 PCB
Monitor board
Symbol No.
Q1 PU622SC2712GR TRANSISTOR
Q2 PU622SA1797 TRANSISTOR
Q3 PU62KN3906S TRANSISTOR
Q4 PU62KN3904S TRANSISTOR
Q5 PU622SC2712GR TRANSISTOR
Q6 PU622SC2712GR TRANSISTOR
Q7 PU62KN3906S TRANSISTOR
Q11 PU62KN3906S TRANSISTOR
Q16 PU62KN3906S TRANSISTOR
Q106 PU62KN3904S TRANSISTOR
Q211 PJ78L05A IC
Q301 PU62KTC2022 TRANSISTOR
Q409 PU622SC2712GR TRANSISTOR
Q414 PU62KN3906S TRANSISTOR
Q501 PU62DTC124EKA TRANSISTOR
Q502 PU62DTC124EKA TRANSISTOR
Q503 PU62DTC124EKA TRANSISTOR
Q510 PU622SA1797 TRANSISTOR
Q511 PU622SC2712GR TRANSISTOR
Q604 PU622SC2712GR TRANSISTOR
Q610 AIC1732-33CX IC
Q660 PU622SA1037AKR TRANSISTOR
Q701 PU622SC2712GR TRANSISTOR
Q702 PU622SA1037AKR TRANSISTOR
Q703 PU62IMZ1A TRANSISTOR
Q770 PU622SA1037AKR TRANSISTOR
D1 PU6114Z12V0S ZENER DIODE SMD
D2 PU61DA204UT1064 DIODE SMD/ROHM
D3 PU61DA204UT1064 DIODE SMD/ROHM
D4 PU61DA204UT1064 DIODE SMD/ROHM
D5 PU61BAS16 FR DIODE
D6 PU6114Z7V5S ZENER DIODE SMD
D7 PU6114Z7V5S ZENER DIODE SMD
D8 PU6114Z7V5S ZENER DIODE SMD
D9 PU611SS356 DIODE SMD/ROHM
D301 PU61BAS16 FR DIODE
D302 PU61BAS16 FR DIODE
D303 PU61BAS16 FR DIODE
D304 PU61RB160L40 DIODE SMD/ROHM
D406 PU61DA204UT1064 DIODE SMD/ROHM
Part No. Part Name Description Local
Part No. Part Name Description Local
Block No. [0][1][0][0]
Block No. [0][2][0][0]
Symbol No.
D408 PU61DA204UT1064 DIODE SMD/ROHM
D409 PU61DA204UT1064 DIODE SMD/ROHM
D410 PU61BAS16 FR DIODE
D412 PU61BAS16 FR DIODE
D413 PU61BAS16 FR DIODE
D701 PU611SS356 DIODE SMD/ROHM
D702 PU61MA338 FR DIODE
D703 PU61RB500V40 DIODE SMD
D704 PU61RB500V40 DIODE SMD
C1 PU171.6KW104K CHIP CAP
C2 PU171.6KW104K CHIP CAP
C3 PU175KW560J CHIP CAP
C4 PU175KW330J CHIP CAP
C5 PU171.6KW104K CHIP CAP
C6 PU175KW560J CHIP CAP
C7 PU175KW180J CHIP CAP
C8 PU175KW180J CHIP CAP
C9 PU171.6KW104K CHIP CAP
C10 PU171.6KW104K CHIP CAP
C11 PU171.6KW104K CHIP CAP
C12 PU171010 CHIP TRIMMER
C13 PU175KW102J CHIP CAP
C14 PU171.6KZ106Z CHIP CAP
C15 PU175KW221J CHIP CAP
C16 PU175KW103K CHIP CAP
C17 PU171.6KW104K CHIP CAP
C18 PU171.6KZ106Z CHIP CAP
C19 PU171.6KY225Z CHIP CAP
C20 PU171.6BC227M E/C SMD
C21 PU171.6KW104K CHIP CAP
C22 PU171.6KW104K CHIP CAP
C23 PU171.6KW474Z CHIP CAP
C24 PU171.6KW104K CHIP CAP
C25 PU175KW103K CHIP CAP
C26 PU171.6KW104K CHIP CAP
C27 PU171.6KY225Z CHIP CAP
C28 PU171LL228MH E/C DIP
C29 PU171.6KW104K CHIP CAP
C30 PU175KW103K CHIP CAP
C31 PU175KW103K CHIP CAP
C32 PU171.6KY475Z CHIP CAP
C33 PU171.6KW104K CHIP CAP
C34 PU171008 HIGH CAP
C35 PU171.6KY225Z CHIP CAP
C36 PU175KW121J CHIP CAP
C37 PU175KW820J CHIP CAP
C38 PU171.6KW104K CHIP CAP
C154 PU172.5BC476M E/C SMD
C200 PU172.5BC476M E/C SMD
C201 PU171.6KW474Z CHIP CAP
C202 PU171.6KW474Z CHIP CAP
C205 PU175KW471J CHIP CAP
C301 PU175KW471J CHIP CAP
C302 PU175KW471J CHIP CAP
C304 PU175KW471J CHIP CAP
C305 PU175KW471J CHIP CAP
C306 PU171.6KW104K CHIP CAP
C307 PU172.5BC476M E/C SMD
C309 PU172.5BC476M E/C SMD
C310 PU171.6KW104K CHIP CAP
C311 PU172.5BC476M E/C SMD
C312 PU173.5BC226M E/C SMD
C313 PU171.6KW104K CHIP CAP
C315 PU172.5BC476M E/C SMD
C316 PU171.6KW104K CHIP CAP
C317 PU172.5BC476M E/C SMD
C318 PU172.5BC476M E/C SMD
C319 PU171.6KW104K CHIP CAP
C320 PU172.5BC476M E/C SMD
C321 PU175KW102J CHIP CAP
C418 PU175KW102J CHIP CAP
C419 PU171.6KZ106Z CHIP CAP
C422 PU175KW102J CHIP CAP
C423 PU171.6KZ106Z CHIP CAP
C424 PU175KW102J CHIP CAP
Part No. Part Name Description Local
3-3
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
C425 PU171.6KZ106Z CHIP CAP
C501 PU171.6KY475Z CHIP CAP
C502 PU175KW270J CHIP CAP
C503 PU175KW270J CHIP CAP
C504 PU171KW105Z CHIP CAP
C505 PU171.6KW104K CHIP CAP
C506 PU171.6KZ106Z CHIP CAP
C508 PU175KW330J CHIP CAP
C509 PU175KW330J CHIP CAP
C510 PU175KW270J CHIP CAP
C511 PU175KW270J CHIP CAP
C513 PU171.6BC107M E/C SMD
C516 PU171.6KW104K CHIP CAP
C517 PU171.6KW104K CHIP CAP
C521 PU175KW103K CHIP CAP
C522 PU171.6KW104K CHIP CAP
C523 PU171.6KW104K CHIP CAP
C602 PU171.6KZ106Z CHIP CAP
C604 PU171.6KW104K CHIP CAP
C605 PU171.6BC107M E/C SMD
C606 PU171.6KW104K CHIP CAP
C607 PU171.6KW104K CHIP CAP
C608 PU171.6KW104K CHIP CAP
C609 PU171.6KW104K CHIP CAP
C610 PU171.6KW104K CHIP CAP
C611 PU175KW682K CHIP CAP
C612 PU171.6KY335Z CHIP CAP
C613 PU175KW103K CHIP CAP
C614 PU175KW122K CHIP CAP
C615 PU175KW103K CHIP CAP
C616 PU175KW103K CHIP CAP
C617 PU175KW103K CHIP CAP
C618 PU175KW103K CHIP CAP
C619 PU175KW103K CHIP CAP
C620 PU171.6KW473K CHIP CAP
C621 PU171.6KW104K CHIP CAP
C622 PU175KW103K CHIP CAP
C623 PU175KW103K CHIP CAP
C624 PU171KW105Z CHIP CAP
C625 PU171KW105Z CHIP CAP
C626 PU171KW105Z CHIP CAP
C627 PU171.6KW474Z CHIP CAP
C628 PU175KW103K CHIP CAP
C630 PU175KW103K CHIP CAP
C631 PU171.6KW104K CHIP CAP
C632 PU175KW103K CHIP CAP
C633 PU171.6KZ106Z CHIP CAP
C634 PU175KW103K CHIP CAP
C637 PU171.6KW104K CHIP CAP
C638 PU171.6KW104K CHIP CAP
C639 PU175KW121J CHIP CAP
C640 PU171.6BC107M E/C SMD
C641 PU171.6BC107M E/C SMD
C643 PU171.6KZ106Z CHIP CAP
C663 PU175KW122K CHIP CAP
C664 PU175KW681J CHIP CAP
C665 PU175KW103K CHIP CAP
C666 PU175KW560J CHIP CAP
C667 PU175KW103K CHIP CAP
C668 PU175KW562K CHIP CAP
C669 PU175KW103K CHIP CAP
C701 PU171.6KZ106Z CHIP CAP
C702 PU171.6KZ106Z CHIP CAP
C703 PU171.6KW104K CHIP CAP
C704 PU172.5BC476M E/C SMD
C705 PU171.6KW104K CHIP CAP
C706 PU171.6KW104K CHIP CAP
C707 PU171.6KZ106Z CHIP CAP
C709 PU171.6KY225Z CHIP CAP
C710 PU171.6KW104K CHIP CAP
C711 PU171.6KZ106Z CHIP CAP
C712 PU171.6KW104K CHIP CAP
C718 PU171.6KW104K CHIP CAP
C719 PU171KW105Z CHIP CAP
C720 PU171.6KZ106Z CHIP CAP
C721 PU175KW102J CHIP CAP
C722 PU171.6KW104K CHIP CAP
C723 PU175KW561J CHIP CAP
C725 PU175KW152K CHIP CAP
C726 PU171.6KW104K CHIP CAP
C727 PU175KW680J CHIP CAP
C728 PU171.6KW104K CHIP CAP
C729 PU171.6KW104K CHIP CAP
C742 PU171.6KZ106Z CHIP CAP
C743 PU171.6KW104K CHIP CAP
C744 PU171.6KW104K CHIP CAP
C745 PU171.6KZ106Z CHIP CAP
C746 PU171.6KZ106Z CHIP CAP
C747 PU171.6KZ106Z CHIP CAP
C748 PU171.6KZ106Z CHIP CAP
C749 PU171.6KW104K CHIP CAP
C750 PU171.6KW104K CHIP CAP
C751 PU171.6KW104K CHIP CAP
C752 PU171.6KW104K CHIP CAP
C760 PU171.6KZ106Z CHIP CAP
C761 PU175KW122K CHIP CAP
C770 PU175KW122K CHIP CAP
R1 PU16110TW0R0J CHIP RESISTOR
R1 PU16110TW101J CHIP RESISTOR
R2 PU16110TW332J CHIP RESISTOR
R3 PU16110TW473J CHIP RESISTOR
R4 PU16110TW103J CHIP RESISTOR
R5 PU16110TW302J CHIP RESISTOR
R6 PU16110TW152J CHIP RESISTOR
R7 PU16110TW0R0J CHIP RESISTOR
R8 PU16110TW101J CHIP RESISTOR
R9 PU16110TW103J CHIP RESISTOR
R10 PU16110TW303J CHIP RESISTOR
R11 PU16110TW103J CHIP RESISTOR
R13 PU16110TW122J CHIP RESISTOR
R14 PU16110TW183J CHIP RESISTOR
R15 PU16110TW820J CHIP RESISTOR
R16 PU16110TW103J CHIP RESISTOR
R17 PU16110TW223J CHIP RESISTOR
R18 PU16110TW473J CHIP RESISTOR
R19 PU16110TW101J CHIP RESISTOR
R20 PU16110TW0R0J CHIP RESISTOR
R21 PU16110TW0R0J CHIP RESISTOR
R22 PU16110TW332J CHIP RESISTOR
R23 PU16110TW332J CHIP RESISTOR
R24 PU16110TW103J CHIP RESISTOR
R25 PU16110TW101J CHIP RESISTOR
R26 PU16110TW104J CHIP RESISTOR
R27 PU16110TW153J CHIP RESISTOR
R28 PU16110TW331J CHIP RESISTOR
R29 PU16110TW243J CHIP RESISTOR
R30 PU16110TW103J CHIP RESISTOR
R32 PU16110TW683J CHIP RESISTOR
R33 PU16110TW223J CHIP RESISTOR
R34 PU16110TW474J CHIP RESISTOR
R35 PU16110TW103J CHIP RESISTOR
R36 PU16110TW473J CHIP RESISTOR
R37 PU16110TW332J CHIP RESISTOR
R38 PU16110TW3R3J CHIP RESISTOR
R39 PU16110TW223J CHIP RESISTOR
R40 PU16110TW332J CHIP RESISTOR
R42 PU16110TW222J CHIP RESISTOR
R43 PU16110TW102J CHIP RESISTOR
R44 PU16110TW101J CHIP RESISTOR
R45 PU16110TW101J CHIP RESISTOR
R46 PU16110TW0R0J CHIP RESISTOR
R47 PU16110TW124J CHIP RESISTOR
R48 PU16110TW513J CHIP RESISTOR
R49 PU16110TW104J CHIP RESISTOR
R50 PU16110TW824J CHIP RESISTOR
R51 PU16110TW103J CHIP RESISTOR
R52 PU16110TW104J CHIP RESISTOR
R53 PU16110TW104J CHIP RESISTOR
R54 PU16110TW394J CHIP RESISTOR
R55 PU16110TW244J CHIP RESISTOR
R56 PU16110TW0R0J CHIP RESISTOR
R57 PU16110TW681J CHIP RESISTOR
R58 PU16110TW223J CHIP RESISTOR
R59 PU16110TW223J CHIP RESISTOR
R60 PU16110TW824J CHIP RESISTOR
3-4
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R61 PU16110TW821J CHIP RESISTOR
R62 PU16110TW243J CHIP RESISTOR
R63 PU16110TW153J CHIP RESISTOR
R64 PU16110TW153J CHIP RESISTOR
R65 PU16110TW102J CHIP RESISTOR
R66 PU16110TW333J CHIP RESISTOR
R68 PU16110TW010J CHIP RESISTOR
R69 PU16110TW3R3J CHIP RESISTOR
R70 PU16110TW3R3J CHIP RESISTOR
R72 PU16110TW3R3J CHIP RESISTOR
R124 PU16110TW101J CHIP RESISTOR
R130 PU16110TW562J CHIP RESISTOR
R131 PU16110TW104J CHIP RESISTOR
R135 PU16110TW393J CHIP RESISTOR
R201 PU16110TW393J CHIP RESISTOR
R202 PU16110TW393J CHIP RESISTOR
R203 PU16110TW224J CHIP RESISTOR
R214 PU16110TW183J CHIP RESISTOR
R215 PU16110TW333J CHIP RESISTOR
R216 PU16110TW102J CHIP RESISTOR
R301 PU16110TW393J CHIP RESISTOR
R302 PU16110TW393J CHIP RESISTOR
R303 PU16110TW332J CHIP RESISTOR
R305 PU16110TW333J CHIP RESISTOR
R306 PU16110TW333J CHIP RESISTOR
R307 PU16110TW242J CHIP RESISTOR
R308 PU16110TW122J CHIP RESISTOR
R309 PU16110TW513J CHIP RESISTOR
R310 PU16110TW153J CHIP RESISTOR
R313 PU16110TW183J CHIP RESISTOR
R314 PU16110TW333J CHIP RESISTOR
R441 PU16110TW101J CHIP RESISTOR
R442 PU16110TW101J CHIP RESISTOR
R445 PU16110TW101J CHIP RESISTOR
R446 PU16110TW473J CHIP RESISTOR
R447 PU16110TW103J CHIP RESISTOR
R448 PU16110TW223J CHIP RESISTOR
R453 PU16110TW243J CHIP RESISTOR
R454 PU16110TW683J CHIP RESISTOR
R455 PU16110TW153J CHIP RESISTOR
R456 PU16110TW101J CHIP RESISTOR
R457 PU16110TW473J CHIP RESISTOR
R458 PU16110TW223J CHIP RESISTOR
R459 PU16110TW433J CHIP RESISTOR
R460 PU16110TW101J CHIP RESISTOR
R470 PU16110TW223J CHIP RESISTOR
R500 PU16110TW103J CHIP RESISTOR
R501 PU16110TW103J CHIP RESISTOR
R502 PU16110TW102J CHIP RESISTOR
R503 PU16110TW103J CHIP RESISTOR
R504 PU16110TW102J CHIP RESISTOR
R505 PU16110TW102J CHIP RESISTOR
R506 PU16110TW102J CHIP RESISTOR
R507 PU16110TW105J CHIP RESISTOR
R508 PU16110TW104J CHIP RESISTOR
R509 PU16110TW223J CHIP RESISTOR
R510 PU16110TW103J CHIP RESISTOR
R511 PU16110TW103J CHIP RESISTOR
R513 PU16110TW104J CHIP RESISTOR
R517 PU16110TW102J CHIP RESISTOR
R519 PU16110TW101J CHIP RESISTOR
R520 PU16110TW101J CHIP RESISTOR
R521 PU16110TW101J CHIP RESISTOR
R535 PU16110TW103J CHIP RESISTOR
R536 PU16110TW103J CHIP RESISTOR
R539 PU16110TW103J CHIP RESISTOR
R543 PU16110TW101J CHIP RESISTOR
R550 PU16110TW473J CHIP RESISTOR
R552 PU16110TW473J CHIP RESISTOR
R553 PU16110TW103J CHIP RESISTOR
R608 PU16110TW750J CHIP RESISTOR
R609 PU16110TW750J CHIP RESISTOR
R610 PU16110TW750J CHIP RESISTOR
R612 PU16110TW121J CHIP RESISTOR
R613 PU16110TW153J CHIP RESISTOR
R614 PU16110TW153J CHIP RESISTOR
R615 PU16110TW183J CHIP RESISTOR
R616 PU16110TW105J CHIP RESISTOR
R617 PU16110TW474J CHIP RESISTOR
R618 PU16110TW153J CHIP RESISTOR
R619 PU16110TW153J CHIP RESISTOR
R620 PU16110TW102J CHIP RESISTOR
R621 PU16110TW102J CHIP RESISTOR
R622 PU16110TW334J CHIP RESISTOR
R623 PU16110TW101J CHIP RESISTOR
R624 PU16110TW102J CHIP RESISTOR
R625 PU16110TW684J CHIP RESISTOR
R626 PU16110TW101J CHIP RESISTOR
R627 PU16110TW102J CHIP RESISTOR
R628 PU16110TW563J CHIP RESISTOR
R629 PU16110TW393J CHIP RESISTOR
R630 PU16110TW563J CHIP RESISTOR
R631 PU16110TW393J CHIP RESISTOR
R632 PU16110TW565J CHIP RESISTOR
R633 PU16110TW103J CHIP RESISTOR
R634 PU16110TW103J CHIP RESISTOR
R635 PU16110TW562J CHIP RESISTOR
R636 PU16110TW101J CHIP RESISTOR
R637 PU16110TW101J CHIP RESISTOR
R638 PU16110TW101J CHIP RESISTOR
R640 PU16110TW103J CHIP RESISTOR
R641 PU16110TW102J CHIP RESISTOR
R642 PU16110TW562J CHIP RESISTOR
R643 PU16110TW183J CHIP RESISTOR
R644 PU16110TW153J CHIP RESISTOR
R645 PU16110TW393J CHIP RESISTOR
R646 PU16110TW183J CHIP RESISTOR
R651 PU16110TW392J CHIP RESISTOR
R653 PU16110TW103J CHIP RESISTOR
R654 PU16110TW103J CHIP RESISTOR
R655 PU16110TW123J CHIP RESISTOR
R656 PU16110TW123J CHIP RESISTOR
R660 PU16110TW102J CHIP RESISTOR
R661 PU16110TW910J CHIP RESISTOR
R662 PU16110TW471J CHIP RESISTOR
R663 PU16110TW331J CHIP RESISTOR
R665 PU16110TW106J CHIP RESISTOR
R666 PU16110TW562J CHIP RESISTOR
R667 PU16110TW152J CHIP RESISTOR
R668 PU16110TW331J CHIP RESISTOR
R669 PU16110TW562J CHIP RESISTOR
R701 PU16110TW101J CHIP RESISTOR
R702 PU16110TW101J CHIP RESISTOR
R703 PU16110TW563J CHIP RESISTOR
R704 PU16110TW563J CHIP RESISTOR
R705 PU16110TW223J CHIP RESISTOR
R706 PU16110TW223J CHIP RESISTOR
R707 PU16110TW393J CHIP RESISTOR
R708 PU16110TW822J CHIP RESISTOR
R709 PU16110TW273J CHIP RESISTOR
R710 PU16110TW683J CHIP RESISTOR
R711 PU16110T W153J CHIP RESISTOR
R712 PU16110TW393J CHIP RESISTOR
R713 PU16110TW302J CHIP RESISTOR
R714 PU16110TW153J CHIP RESISTOR
R715 PU16110TW224J CHIP RESISTOR
R716 PU16110TW752J CHIP RESISTOR
R717 PU16110TW153J CHIP RESISTOR
R719 PU16110TW273J CHIP RESISTOR
R720 PU16110TW103J CHIP RESISTOR
R721 PU16110T W0R0J CHIP RESISTOR
R722 PU16110TW105J CHIP RESISTOR
R723 PU16110TW683J CHIP RESISTOR
R725 PU16110TW333J CHIP RESISTOR
R726 PU16110TW223J CHIP RESISTOR
R727 PU16110TW102J CHIP RESISTOR
R728 PU16110TW473J CHIP RESISTOR
R729 PU16110TW683J CHIP RESISTOR
R730 PU16110TW474J CHIP RESISTOR
R731 PU16110TW472J CHIP RESISTOR
R732 PU16110TW222J CHIP RESISTOR
R736 PU16110TW202J CHIP RESISTOR
R737 PU16110TW102J CHIP RESISTOR
R738 PU16110TW102J CHIP RESISTOR
R739 PU16110TW102J CHIP RESISTOR
R740 PU16110TW472J CHIP RESISTOR
3-5
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
R741 PU16110TW472J CHIP RESISTOR
R742 PU16110TW472J CHIP RESISTOR
R745 PU16110TW101J CHIP RESISTOR
R746 PU16110TW101J CHIP RESISTOR
R751 PU16110TW104J CHIP RESISTOR
R752 PU16110TW0R0J CHIP RESISTOR
R754 PU16110TW153J CHIP RESISTOR
R760 PU16110TW332J CHIP RESISTOR
R761 PU16110TW101J CHIP RESISTOR
R763 PU16110TW103J CHIP RESISTOR
R765 PU16110TW103J CHIP RESISTOR
R770 PU16110TW101J CHIP RESISTOR
R771 PU16110TW103J CHIP RESISTOR
R772 PU16110TW333J CHIP RESISTOR
R773 PU16110TW103J CHIP RESISTOR
R776 PU16110TW0R0J CHIP RESISTOR
R556A PU16110TW332J CHIP RESISTOR
R556B PU16110TW332J CHIP RESISTOR
VR+5 PU29R3S472 MVR32
L1 PU291007220 INDUCTOR SMD
L2 PU291007220 INDUCTOR SMD
L3 PU291012 INDUCTOR PW SMD
L13 PU181016 FERRITE BEAD
L200 PU291012 INDUCTO R PW SMD
L301 PU291011 INDUCTOR SMD
L302 PU291007330 INDUCTOR SMD
L303 PU292002 TRANSFORMER
L304 PU291007330 INDUCTOR SMD
L305 PU291011 INDUCTOR SMD
L501 PU291007150 INDUCTOR SMD
L600 PU291007100 INDUCTOR SMD
L602 PU291007100 INDUCTOR SMD
L661 PU291002 COIL SMD
L701 PU291007100 INDUCTOR SMD
L702 PU291007100 INDUCTOR SMD
L703 PU291007100 INDUCTOR SMD
L704 PU291007100 INDUCTOR SMD
L706 PU291007100 INDUCTOR SMD
L707 PU291007022 INDUCTOR SMD
L712 PU291007100 INDUCTOR SMD
T1 PU292021
TRANSFORMER
SMD
U702 MN13821G IC
U704 LMC7101BIM5 IC
VBRI PU29R3S473 MVR32
VCDC PU29R3S104 MVR32
VCNT PU29R3S473 MVR32
VCOL PU29R3S473 MVR32
VCOM PU29R3S473 MVR32
VFREQ PU29R3S103 MVR32
VFRQ PU29R3S103 MVR32
VGA1 PU29R3S473 MVR32
VGA2 PU29R3S473 MVR32
VINV PU29R3S201 MVR32
VPIC PU29R3S473 MVR32
VRGB PU29R3S473 MVR32
VSUB PU29R3S473 MVR32
VSUR PU29R3S473 MVR32
VTIN PU29R3S473 MVR32
W702 PU16110TW0R0J CHIP RESISTOR
W704 PU16110TW0R0J CHIP RESISTOR
W705 PU16110TW0R0J CHIP RESISTOR
W707 PU16110TW0R0J CHIP RESISTOR
W708 PU16110TW0R0J CHIP RESISTOR
W709 PU16110TW0R0J CHIP RESISTOR
W710 PU16110TW0R0J CHIP RESISTOR
W712 PU16110TW0R0J CHIP RESISTOR
W714 PU16110TW102J CHIP RESISTOR
W719 PU16110TW0R0J CHIP RESISTOR
XXXXX PU192500V03 PCB
XXXXX PUPL06007510 SPACER
XXXXX PUS1T03I10SZ SCREW
XXXXX PUN03B06I2.0SZ NUT
Y1 PU64200716 CRYSTAL
Y2 PU64200616 CRYSTAL
Y3 PU64200220 CRYSTAL
Y4 PU64200220 CRYSTAL
FB602 PU181009 FERRITE BEAD
FB606 PU181009 FERRITE BEAD
GASC PU16110TW0R0J CHIP RESISTOR
GDC1 PU16110TW0R0J CHIP RESISTOR
GDC2 PU16110TW0R0J CHIP RESISTOR
GDC3 PU16110TW0R0J CHIP RESISTOR
GAGV PU16110TW0R0J CHIP RESISTOR
GAGV1 PU16110TW0R0J CHIP RESISTOR
GINV1 PU16110TW0R0J CHIP RESISTOR
GINV2 PU16110TW0R0J CHIP RESISTOR
GINV3 PU16110TW0R0J CHIP RESISTOR
GMCU1 PU16110TW0R0J CHIP RESISTOR
GMCU2 PU16110TW0R0J CHIP RESISTOR
J1 PU12100911 PIN HEADER
J2 PU12100330 CONNECTOR
J3 PU12103105 CONNECTOR
M1 PU121013 WAFER
QM301 PU62IMZ1A TRANSISTOR
QM701 PU62IMX1 TRANSISTOR
U1 74HC4053D IC
U2 TC203G04AF IC
U3 TC4W53F IC
U5 AP4532M IC
U7 AP4532M IC
U8 BIT3105 IC
U201 TL1451ACPWLE IC
U501 PIC16C505 IC
U503 MB90097-PFV IC
U504 24LC02B IC
U506 M66242FP IC
U600 IR3Y29BM IC
U601 74HC4053D IC
U602 DG419DY IC
U701 LF353MX IC
3-6
<MEMO>
3-7
Packing materials and accessories parts list
Block No.
M
3
M
M
J Version
A12
A10
A13
A14
E Version
A8
A7
A6
A5
A4
A3
A1
A2
A11
A9
3-8
Packing and accessories
Block No. [M][3][M][M]
Symbol No.
A 1 PUPL05001614 MOUNTING SLEEVE
A 2 PUPL08002213 TRIMRING
A 3 LVT0990-001A INST BOOK EN GE FR NL
A 4 LVT0990-002A INST BOOK SP IT PO RU
A 5 LVT0990-003A INST BOOK SW DA FI GR
A 6 LVT0990-004A INST.SHEET
A 7 LVT0990-005A INST.SHEET
A 8 LVT0990-006A INST.SHEET
A 9 PUKV90BOX KV-90BOX
A 10 PURC9000 REMCON
A 11 PU141820 DIN CORD
A 12 PU141942 POWER CORD
A 13 LVT0989-001A INST BOOK EN SP FR
A 14 LVT0989-002A INST.SHEET
Part No. Part Name Description Local
MH65
00E
MH65
00E
MH65
00E
MH65
00E
MH65
00E
MH65
00E
MH65
00J
MH65
00J
3-9
Loading...
