JVC KS-F550R, KS-FX650R User Manual

ENGLISH

CASSETTE RECEIVER

CASSETTEN-RECEIVER RADIOCASSETTE RADIO/CASSETTESPELER

KS-FX650R/KS-F550R

KS-FX650R

Detachable

M ulti M usic Scan

SCM

KS-F550R

SCM

40Wx4

PTY

40Wx4

PTY

CD CHANGER CONTROL

RDS

DETACHABLE CONTROL PANEL

RDS

KS-FX650R

FM/AM

KS-F550R

DEUTSCH

FRANÇAIS

RND

SSM

RPT

DAB

TAPE

SSM

RPT

TAPE

NEDERLANDS

For installation and connections, refer to the separate manual. Für den Einbau und die Anschlüsse siehe das eigenständige Handbuch. Pour l’installation et les raccordements, se référer au manuel séparé. Bijzonderheden over de installatie en aansluiting van het apparaat vindt u in de desbetreffende handleiding.

INSTRUCTIONS

BEDIENUNGSANLEITUNG MANUEL D'INSTRUCTIONS GEBRUIKSAANWIJZING

FSUN3109-311

[E]

Thank you for purchasing a JVC product. Please read all instructions carefully before operation, to ensure your complete understanding and to obtain the best possible performance from the unit.

CONTENTS

BASIC OPERATIONS.................................................... 4

RADIO BASIC OPERATIONS......................................... 5

ENGLISH

Listening to the radio .....................................................................5

Storing stations in memory............................................................6

FM station automatic preset: SSM .............................................. 6

Manual preset .............................................................................. 7

Tuning into a preset station ...........................................................8

RDS OPERATIONS ....................................................... 9

What you can do with RDS EON ..................................................9

Tracing the same programme automatically

(Network-Tracking Reception) ..................................................... 9

Using Standby Reception .......................................................... 11

Selecting Your Favorite Programme for PTY

Standby Reception ..................................................................... 12

Searching Your Favorite Programme ........................................ 12

Other convenient RDS functions and adjustments....................15

Automatic selection of the station when

using the number buttons .......................................................... 15

Changing the display mode while listening to an FM station ..... 16

Setting the TA volume level ....................................................... 16

Automatic clock adjustment ....................................................... 16

TAPE OPERATIONS .................................................... 17

Listening to a tape ........................................................................17

Finding the beginning of a tune................................................... 19

Other convenient tape functions..................................................20

Prohibiting cassette ejection ...................................................... 20

Skipping the blank portions on the tape .................................... 20

Playing the current tune repeatedly ...........................................20

SOUND ADJUSTMENTS .............................................. 21

Adjusting the sound...................................................................... 21

Using the Sound Control Memory ..............................................22

Selecting and storing the sound modes .................................... 22

Recalling the sound modes ....................................................... 23

Storing your own sound adjustments .........................................24

OTHER MAIN FUNCTIONS .......................................... 25

Setting the clock ............................................................................25

Changing the general settings...................................................... 26

Basic Procedure ........................................................................ 26

Canceling Advanced SCM......................................................... 27

Selecting 24-hour or 12-hour clock............................................ 28

Selecting the level display ......................................................... 28

Selecting the display mode while using the CD changer

(ONLY FOR KS-FX650R) .......................................................... 28

Selecting the telephone muting ................................................. 29

Selecting the external component to use

(ONLY FOR KS-FX650R) .......................................................... 29

Detaching the control panel .........................................................30

CD CHANGER OPERATIONS........................................ 31

(ONL Y FOR KS-FX650R)

Playing CDs ................................................................................... 31

Selecting CD playback modes......................................................33

EXTERNAL COMPONENT OPERATIONS ........................ 34

(ONL Y FOR KS-FX650R)

DAB TUNER OPERATIONS ......................................... 35

Tuning into an ensemble and one of the services .......................35

Storing DAB services in memory ................................................37

T uning into a preset DAB service ................................................39

MAINTENANCE ......................................................... 40

To extend the lifetime of the unit.................................................40

How to reset your unit ..................................................................40

ENGLISH

TROUBLESHOOTING .................................................. 41

SPECIFICATIONS ....................................................... 42

Note:

For security reasons, a numbered ID card is provided with this unit, and the same ID number is imprinted on the unit’s chassis. Keep the card in a safe place, as it will help the authorities to identify your unit if stolen.

BEFORE USE

★

For saf ety ....

• Do not raise the volume level too much, as this will block outside sounds, making driving dangerous.

• Stop the car before performing any

★

Temperature inside the car....

If you have parked the car for a long time in hot or cold weather, wait until the temperature in the car becomes normal before operating the unit.

complicated operations.

BASIC OPERATIONS

ENGLISH

KS-FX650R

KS-F550R

Note:

When you use this unit for the first time, set the built-in cloc k (see page 25).

Turn on the power.

Note on One-Touch Operation:

When you select a source in step 2 below , the power automatically turns on. You do not have to press this button to turn on the power.

DAB

Select the source.

FM/AM

TAPE

To operate the tuner, see pages 5 – 16. To operate the tape deck, see pages 17 – 20.

For KS-FX650R To operate the CD changer, see pages 31 – 33. To operate the external component, see pages 34 To operate the DAB tuner, see pages 35

– 39

Adjust the volume.

Volume level appears

Volume level indicator

Adjust the sound as you want (see pages 21 – 24).

To drop the volume in a moment

Press briefly while listening to any source. “ATT” starts flashing on the display, and the volume level will drop soon. To resume the previous volume level, press the same button briefly again.

To turn off the power

Press for more than 1 second.

RADIO BASIC OPERATIONS

Listening to the radio

KS-FX650R

FM/AM

KS-F550R

SSM

FM1 FM2

To search stations of higher frequencies.

To search stations of lower frequencies.

FM3 AM

FM3

Audio (see page 28) or volume level indicator

KS-FX650R

KS-F550R

Select the band (FM1,FM2, FM3 or AM) you want.

Y ou can select an y one of FM1, FM2, and FM3 to listen to an FM station.

Selected band appears

Start searching a station.

When a station is received, searching stops.

ENGLISH

To stop searching before a station is received, press the same button you have pressed

for searching.

To tune in a particular frequency without searching

1 Select the band (FM or AM).

For KS-FX650R: Press FM/AM repeatedly. For KS-F550R: Press FM or AM.

2 Press and hold

Now you can manually change the frequency while “M” is flashing.

3 Press ¢ or 4 repeatedly until the frequency you want is reached.

• If you hold down the button, the frequency keeps changing (in 50 kHz intervals for FM and

9kHz intervals for AM–MW/LW) until you release the button.

¢ or 4 until “M” (for Manual) starts flashing on the display.

Storing stations in memory

FM1 FM2

FM3

You can use one of the following two methods to store broadcasting stations in memory.

• Automatic preset of FM stations: SSM (Strong-station Sequential Memory)

ENGLISH

• Manual preset of both FM and AM stations

FM station automatic preset: SSM

You can preset up to 6 local FM stations in each FM band (FM1, FM2, and FM3).

KS-FX650R

FM/AM

FM1 FM2

FM3 AM

KS-F550R

Select the FM band number (FM1, FM2 or FM3) you want to store FM stations into.

Press and hold both buttons for more than

SSM

Local FM stations with the strongest signals are searched and stored automatically in the band number you have selected (FM1, FM2 or FM3). These stations are preset in the number buttons — No. 1 (lowest frequency) to No. 6 (highest frequency). When automatic preset is over, the station stored in number button 1 will be automatically tuned in.

2 seconds.

“SSM” appears, then disappears when automatic preset is over.

Manual preset

You can preset up to 6 stations in each band (FM1, FM2, FM3 and AM) manually. EXAMPLE: Storing an FM station of 88.3 MHz into preset number 1 of the FM1 band

FM/AM

KS-F550RKS-FX650R

Select the FM1 band.

Tune into a station of 88.3 MHz.

SSM

See page 5 to tune into a station.

ENGLISH

Press and hold the button for more than 2 seconds.

“P1” flashes for a few seconds.

Repeat the above procedure to store other stations into other preset numbers.

Notes:

• A previously preset station is erased when a new station is stored in the same preset number.

• Preset stations are erased when the po wer supply to the memory circuit is interrupted (for example, during battery replacement). If this occurs, preset the stations again.

Tuning into a preset station

You can easily tune into a preset station. To do this, you must store stations first. If you have not stored them yet, see pages 6 and 7.

ENGLISH

KS-FX650R MO

RND

KS-F550R

KS-FX650R

FM/AM

KS-F550R

2 1

FM1 FM2

FM3 AM

FM3

Select the band (FM1, FM2, FM3 or AM) you want.

Select the number (1 – 6) for the preset station you want.

When an FM stereo broadcast is hard to receive:

Press MO RND (mono/random: for KS-FX650R) or MO (mono: for KS-F550R) while listening to an FM stereo broadcast. The MONO (mono) indicator lights up on the display. The sound you hear becomes monaural but reception will be improved. To restore the stereo effect, press the same button again.

Lights up when receiving an FM broadcast in stereo.

RDS OPERATIONS

What you can do with RDS EON

RDS (Radio Data System) allows FM stations to send an additional signal along with their regular programme signals. For example, the stations send their station names, as well as information about what type of programme they broadcast, such as sports or music, etc. Another advantage of RDS function is called “EON (Enhanced Other Networks).” The EON indicator lights up while receiving an FM station with the EON data. By using the EON data sent from a station, you can tune into a different station of a different network broadcasting your favorite programme or traffic announcement while listening to another programme or to another source such as Tape.

By receiving the RDS signals, this unit can do the following:

• Tracing the same programme automatically (Network-Tracking Reception)

• Standby Reception of TA (Traffic Announcement) or your favorite programme

• PTY (Programme Type) search

• TP (Traffic Programme) search

• And some other functions

Tracing the same programme automatically (NetworkTracking Reception)

When driving in an area where FM reception is not good, the tuner built in this unit automatically tunes in another RDS station, broadcasting the same programme with stronger signals. So, you can continue to listen to the same programme in its finest reception, no matter where you drive. (See the illustration on the next page.) Two types of the RDS data are used to make Network-Tracking Reception work correctly — PI (Programme Identification) and AF (Alternative Frequency). Without receiving these data correctly from the RDS station you are listening to, NetworkTracking Reception will not operate.

ENGLISH

To use Network-Tracking Reception, press and hold TP/RDS (Traffic

RDS

Programme/Radio Data System) for more than 1 second. Each time you press and hold the button, Network-Tracking Reception modes change as follows:

Mode 1 Mode 2 Mode 3

AF indicator REG indicatior

Mode 1

The AF indicator lights up but the REG indicator does not. Network-Tracking is activated with Regionalization set to “off.” Switches to another station within the same network when the receiving

ENGLISH

signals from the current station become weak.

Note:

In this mode, the programme may differ from the one currently received.

Mode 2

Both the AF indicator and the REG indicator light up. Network-Tracking is activated with Regionalization set to “on.” Switches to another station, within the same network, broadcasting the same programme when the receiving signals from the current station become weak.

Mode 3

Neither the AF indicator nor the REG indicator lights up. Network-Tracking is deactivated.

The same programme can be received on different frequencies.

Programme 1 broadcasting on frequency A

Programme 1 broadcasting on frequency B

Programme 1 broadcasting on frequency E

Programme 1 broadcasting on frequency C

Programme 1 broadcasting on frequency D

Using Standby Reception

Standby Reception allows the unit to switch temporarily to your favorite programme (PTY: Programme Type) and Traffic Announcement (T A) from the current source (another FM station and TAPE (or CD Changer and other connected components for KS-FX650R)).

Note:

Standby Reception will not work if you are listening to an AM station.

TA Standby Reception

ENGLISH

• When you press TP/RDS while listening to an FM station, the TP indicator

RDS

is lit during reception of a TP (T r affic Programme) station and the T A standb y mode is engaged.

Note:

When the station being received is not a TP station, the TP indicator flashes. Press

¢ or 4 to engage the TA standby mode. “SEARCH” appears on the display, and TP station sear ch starts. When a TP station is tuned in, the TP indicator is lit.

• If you are listening to TAPE (or CD Changer for KS-FX650R), and wish to

listen to a TP station, press TP/RDS to enter the TA standby mode. (The TP indicator lights up.)

If a traffic programme starts broadcasting while the TA standby mode is active, “TRAFFIC” appears and the playback source changes to the FM band. The volume increases to the preset TA volume level and the traffic programme can be heard (see page 16).

To deactivate the TA standby mode, press TP/RDS again.

PTY Standby Reception

PTY

• When you press PTY while listening to an FM station, the PTY indicator is

lit during reception of a PTY station and the PTY standby mode is engaged. The selected PTY name stored on page 12 flashes for 5 seconds.

Note:

When the station being received is not a PTY station, the PTY indicator flashes. Press

the display, and PTY station search starts. When a PTY station is tuned in, the PTY indicator is lit.

¢ or 4 to engage the PTY standby mode. “SEARCH” appears on

• If you are listening to TAPE (or CD Changer for KS-FX650R), and wish to

listen to a selected PTY broadcast, press PTY to enter the PTY standby mode. (The PTY indicator lights up.)

If the selected PTY programme starts broadcasting while the PTY standby mode is active, the selected PTY name appears and the playback source changes to the FM band. The selected PTY programme can then be heard.

To deactivate the PTY standby mode, press PTY again.

Selecting Your Favorite Programme for PTY Standby Reception

You can select your favorite programme for PTY Standby Reception to store in memory. When shipped from the factory, “NEWS” is stored as the programme type for PTY Standby Reception.

ENGLISH

SSM

Press and hold SEL (Select) for more than 2 seconds to enter the general settings mode (see page 26).

Select “PTY STBY (Standby)” if not shown on the display.

Select one of twenty-nine PTY codes. (See the table on page 15.)

Selected code name appears on the display and is stored into memory.

Finish the setting.

Searching Your Favorite Programme

You can search one of your 6 favorite programme types stored in memory. When shipped from the factory, the following 6 programme types have been stored in the number buttons (1 to 6).

To change the factory preset settings, see page 13. To search your favorite programme, see page 14.

AFFAIRS

VARIED

POP M

ROCK M

EASY M

CLASSICS

To store your favorite programme types

SSM

54 2

Press and hold SEL (Select) for more than 2 seconds to enter the general settings mode (see page 26).

Select “PTY SRCH (Search)” if not sho wn on the display.

Select one of twenty-nine PTY codes. (See the table on page 15.)

Selected code name appears on the display.

• If the code already stored in memory is selected, it will flash on the display.

ENGLISH

Press and hold the number button for more than 2 seconds to store the PTY code selected into the preset number you want.

The selected code name will flash on the display.

Finish the setting.

To search your favorite programme type

ENGLISH

PTY

Press and hold PTY (Programme Type) for more than 1 second while listening to an FM station.

The last selected PTY code appears.

Select one of the PTY codes stored in the preset number buttons (1 – 6).

Ex. When “ROCK M” is stored in the preset number button 2

PTY search for your favorite programme starts after 5 seconds.

• If there is a station broadcasting a programme of the same PTY code you selected, that station is tuned in.

• If there is no station broadcasting a programme of the same PTY code you selected, the station will not change.

Note:

In some areas, the PTY search will not work correctly.

Other convenient RDS functions and adjustments

Automatic selection of the station when using the number buttons

Usually when you press the number button, the preset station is tuned in. However, when the preset station is an RDS station, something different will happen. If the signals from that preset station are not sufficient for good reception, this unit, using the AF data, tunes in another frequency broadcasting the same programme as the original preset station is broadcasting. In case no other station is tuned in, y ou can also search all receivable frequencies for the same programme. (Programme search) To activate programme search, follow the procedure below.

• Programme search takes a while.

• See also “Changing the general settings” on page 26.

1.Press and hold SEL (select) for more than 2 seconds to call up the general setting mode.

2.Press

3.Select “ON” by turning the control dial clockwise. Now programme search is activated.

To cancel programme search, repeat the same procedure and select “OFF” in step 3 by turning the control dial counterclockwise.

PTY codes

NEWS: News AFFAIRS: Topical programmes

INFO: Programmes which impart

SPORT: Sport events EDUCATE: Educational programmes DRAMA: Radio plays CULTURE: Programmes on national or

SCIENCE: Programmes on natural V ARIED: Other programmes like POP M: Pop music

ROCK M: Rock music EASY M: Easy-listening music LIGHT M: Light music CLASSICS: Classical music OTHER M: Other music WEATHER: Weather information FINANCE: Reports on commerce,

CHILDREN: Entertainment programmes for

¢ or 4 to select “P(programme)-SEARCH.”

expanding on current news or affairs

advice on a wide variety of topics

regional culture science and technology comedies or ceremonies

trading, the Stock Market, etc. children

SOCIAL: Programmes on social

activities

RELIGION: Programmes dealing with any

aspect of belief or faith, or the nature of existence or ethics

PHONE IN: Programmes where people

can express their views either by phone or in a public forum

TRA VEL: Programmes about travel

destinations, package tours, and travel ideas and opportunities

LEISURE: Programmes concerned with

recreational activities such as gardening, cooking, fishing,

etc. JAZZ: Jazz music COUNTRY: Country music NATION M: Current popular music from

another nation or region, in

that country’s language OLDIES: Classic pop music FOLK M: Folk music DOCUMENT: Programmes dealing with

factual matters, presented in

an investigative style

ENGLISH

Changing the display mode while listening to an FM station

You can change the initial indication on the display to station frequency, station name (PS NAME), station frequency (FREQ) or clock time while listening to an FM RDS station.

ENGLISH

• See also “Changing the general settings” on page 26.

1. Press and hold SEL (select) for more than 2 seconds to call up the general settings mode.

2. Select “DISPMODE” with

3. Use the control dial to select the desired indication from the following: PS NAME (station name), FREQ (station frequency), and CLOCK (clock time).

Note:

By pressing DISP, you can also change the display while listening to an FM RDS station. Each time you press the button, the following information appears on the display:

PS NAME (Station name)

CLOCK (Clock time)

★

The display returns to the initially preset mode after a short while.

¢ or 4.

FREQ (Station frequency)

PTY (Programme type)

Setting the TA volume level

You can preset the volume level for TA Standby Reception. When a traffic programme is received, the volume level automatically changes to the preset level.

• See also “Changing the general settings” on page 26.

1. Press and hold SEL (select) for more than 2 seconds to call up the general setting mode.

2. Press

3. Set to the desired volume level with the control dial.

¢ or 4 to select “TA VOL (volume).”

Automatic clock adjustment

When shipped from the factory , the cloc k built in this unit is set to be readjusted automatically using the CT (Clock Time) data in the RDS signal. If you do not want to use automatic clock adjustment, follow the procedure below.

• See also “Changing the general settings” on page 26.

1. Press and hold SEL (select) for more than 2 seconds to call up the general setting mode.

2. Press ¢ or 4 to select “AUTO ADJ (adjust).”

3. Select “ADJ OFF” by turning the control dial counterclockwise. Now automatic clock adjustment is canceled.

T o reactivate clock adjustment, repeat the same procedure and select “ADJ ON” in step 3 by turning the control dial clockwise.

Note:

It takes about 2 minutes to adjust the time using the CT data. So, you must tune to the station for more than 2 minutes continuously; otherwise, the clock time will not be adjusted.

TAPE OPERATIONS

Listening to a tape

Multi Music Scan

Note on One-Touch Operation:

When a cassette is already in the cassette compartment, pressing TAPE 2 3 turns on the unit and starts tape play automatically.

TAPE

Insert a cassette.

The unit turns on and tape play starts automatically. When one side of the tape reaches its end during play, the other side of the tape automatically starts playing. (Auto Reverse)

Select the tape direction.

Each time you press the button, the tape direction changes alternately – forward (

) and reverse ( ).

ENGLISH

To stop play and eject the cassette

Press 0. Tape play stops and the cassette automatically ejects from the cassette compartment. If you change the source to FM/AM (or CD Changer for KS-FX650R), the tape play also stops (without ejecting the cassette this time).

• You can also eject the tape with the unit turned off.

To fast-forward and rewind a tape

• Press ¢ for more than 1 second to fast-forward the tape. When the tape reaches its end, the tape is reversed and pla yback starts from the beginning of the other side.

ENGLISH

• Press When the tape reaches its end, playback of the same side starts.

To stop fast-forward and rewind at any position on the tape, press TAPE 2 3 . Tape play starts from that position on the tape.

4 for more than 1 second to rewind the tape.

Tape direction

Finding the beginning of a tune

Multi Music Scan allows you to automatically start playback from the beginning of a specified tune. You can specify up to 9 tunes ahead of or before the current tune.

¢ 4

During playback

ENGLISH

To locate a tune ahead of the current

SSM

When the beginning of the specified tune is located, playback starts automatically.

Notes:

• While locating a specified tune: – If the tape is rewound to its beginning, playback starts from the beginning of that side. – If the tape is fast forwarded to the end, it is reversed and played from the beginning of the other

side.

• In the following cases, the Multi Music Scan function may not operate correctly: – Tapes with tunes having long pianissimo passages (very quiet parts) or non-recorded portions

between tunes. – Tapes with short non-recorded sections. – Tapes with high level of noise or humming between tunes.

tune on the tape. To locate a tune

before the current tune on the tape.

Specify how many tunes ahead of or before the current tune the tune you want is located.

Each time you set the tune, the number changes up to ±9.

Other convenient tape functions

ENGLISH

RPT

TAPE

Prohibiting cassette ejection

You can prohibit the cassette ejection and can “lock” a cassette in the cassette compartment. Press and hold TAPE 23 and 0 for more than 2 seconds. “NO EJECT” flashes on the display for about 5 seconds, and the cassette is “locked”. T o cancel the prohibition and “unlock” the cassette, press and hold TAPE more than 2 seconds again. “EJECT OK” flashes again for about 5 seconds, and this time the cassette is “unlock”.

Skipping the blank portions on the tape

You can skip blank portions between the tunes. (Blank Skip) When this function is on, the unit skips blank portions of 15 seconds or more, fast-forwards to the next tune, then starts playing it.

• See also “Changing the general settings” on page 26.

1. Press and hold SEL (select) for more than 2 seconds to call up the general settings mode.

2. Select “B.SKIP (blank skip)” with

3. Select the desired mode with the control dial. The Blank Skip mode alternates between on and off.

¢ or 4.

2 3

23 and 0 for

Note:

When the tape reaches its end while fast-forwar ding, the tape dir ection will be c hanged automatically .

Playing the current tune repeatedly

You can play the current tune repeatedly. (Repeat Play)

RPT

Press the RPT button while a tune you would like to hear over again is being played back. When the tape reaches the end of the tune, the tape is automatically rewound to the beginning of that tune and playback resumes from there. This operation will be repeated till the RPT button is pressed again.

Notes:

• In the following cases, Blank Skip and Repeat Play may not operate correctly:

– Tapes with tunes having long pianissimo passages (very quiet parts) or non-recorded portions

during tunes. – Tapes with short non-recorded sections. – Tapes with high level noise or humming between tunes.

– Tapes with tunes recorded at low recording levels.

Each time you briefly press RPT while playing a tape, Repeat Play turns on and off alternately.

Lights up when Repeat Play is turned on

SOUND ADJUSTMENTS

Adjusting the sound

You can adjust the sound characteristics to your preference.

ENGLISH

Select the item you want to adjust.

Indication To do: Range

BAS Adjust the bass –06 (min.) — +06 (max.) (Bass)

TRE Adjust the treble –06 (min.) — +06 (max.) (Treble)

FAD Adjust the front and rear speaker R06 (rear only) — F06 (front only) (Fader)* balance

BAL Adjust the left and right speaker L06 (left only) — R06 (right only) (Balance) balance

LOUD Boost low and high frequencies to

(Loudness)

VOL Adjust the volume 00 (min.) — 50 (max.) (Volume)

Note:

* If you are using a two-speaker system, set the fader level to “00”.

produce a well-balanced sound at low ON — OFF volume level.

Adjust the level.

Note:

Normally the control dial works as the volume control. So you do not have to select “VOL” to adjust the volume level.

Using the Sound Control Memory

You can select and store a preset sound adjustment suitable to each playback source.

(Advanced SCM)

ENGLISH

Selecting and storing the sound modes

Once you select a sound mode, it is stored in memory, and will be recalled every time you select the same source. A sound mode can be stored for each of the following sources — FM1, FM2, FM3, AM, TAPE and CD Changer (and external components: ONLY FOR KSFX650R).

• If you do not want to store the sound mode separately for each playback source, but want to use the same sound mode for all the sources, see “Canceling Advanced SCM” on page 27.

“Link” indicator

SCM

Indication For: Range

SCM OFF (Flat sound) 00 00 On BEAT Rock or disco music +02 00 On POP Light music +04 +01 Off SOFT Quiet background music +01 –03 Off

Select the sound mode you want.

Each time you press the button, the sound mode changes as follows:

SCM OFF BEAT

• If the “Link” indicator is lit on the display (with “SCM LINK” set to “LINK ON”—see page 27), the selected sound mode can be stored in memory for the current source, and the effect applies to the current source.

• If the “Link” indicator is NOT lit on the display (with “SCM LINK” set to “LINK OFF”, the selected sound mode effect applies to any source.

POP

Bass Treble Loudness

SOFT

Recalling the sound modes

ENGLISH

Source buttons

KS - FX650R

FM/AM

TAPE

Select the source while the “Link” indicator is lit on the display.

The “Link” indicator starts flashing, and the sound mode stored in memory for the selected source is recalled.

Equalization pattern of the selected sound mode appears.

Loud (loudness) indicator

Notes:

KS - F550R

TAPE

Sound mode indicator

• You can adjust each sound mode to your preference, and store it in memory. If you want to adjust and store your original sound mode, see “Storing your own sound adjustments” on page 24.

• To adjust the bass and tr eble reinfor cement levels or to turn on/off the loudness function temporar ily, see page 21. (Your adjustments will be canceled if another source is selected.)

Storing your own sound adjustments

You can adjust the sound modes (BEAT, POP, SOFT,: see page 22) to your preference and store your own adjustments in memory.

ENGLISH

SCM

Call up the sound mode you want to adjust.

See page 22 for details.

Within

5 seconds

Select “BAS (Bass), ” “TRE (Treble)” or “LOUD (Loudness). ”

Within

5 seconds

Adjust the bass or treble level or turn the loudness function ON/OFF.

See page 21 for details.

Within

5 seconds

Press and hold SCM (Sound Control Memory) until the sound mode you have selected flashes on the display.

Your setting is stored in memory.

Repeat the same procedure to store other settings.

To reset to the factory settings

Repeat the same procedure and reassign the preset values listed in the table on page 22.

OTHER MAIN FUNCTIONS

Setting the clock

SSM

2,3

1,4

ENGLISH

2,3

Press and hold SEL for more than 2 seconds to call up the general settings mode.

Set the hour. 1 Select “CLOCK H” if not shown on

the display.

2 Adjust the hour.

Set the minute.

1 Select “CLOCK M”. 2 Adjust the minute.

Finish the setting.

To check the current clock time (changing the display mode)

Press DISP repeatedly . Each time you press the button, the displa y mode changes as follo ws:

During tuner operation:

Clock

Note:

For the indication change during RDS operation, see page 16.

During CD changer operation (ONL Y FOR KS-FX650R):

Note:

For the indication change during DAB operation, see page 36.

• If the unit is not in use when you press DISP, the power turns on, the clock time is shown for

5 seconds, then the power turns off.

Frequency

Clock

During tape operation:

Play mode

Clock

During external component operation (ONLY FOR KS-FX650R):

LINE IN

Disc numberElapsed playing time

Clock

Changing the general settings

You can change the settings of the items listed on the next page.

ENGLISH

Basic Procedure

SSM

1,4

Press and hold SEL for more than 2 seconds to call up the general settings mode.

Select the item you want to adjust (see page 27.)

Select or adjust the item selected above.

Finish the setting.

1 2

Select.

CLOCK H Hour adjustment Back Advance CLOCK M Minute adjustment Back Advance SCM LINK Sound control memory linkage LINK OFF LINK ON LINK ON below 24H/12H 24/12-hour time display 12H 24H 24H 28 AUTO ADJ Automatic setting of the clock OFF ON ON 16 DISPMODE Display mode

CH DISP Changer display

PTY STBY PTY standby 29 programmes types NEWS 12 PTY SRCH PTY search (See page 15.) (See pg 12.) 12-14 TA VOL Traffic announcement volume VOL (00 – 50) VOL 20 11,16 P-SEARCH Programme search OFF ON OFF 15 LEVEL Level display

TEL Audio mute for cellular

B.SKIP Blank skip OFF ON OFF 20

★

LINE IN

★

Displayed only when one of the following sources is selected — FM, AM and TAPE.

(ONLY FOR KS-FX650R)

phone system

External component (ONLY FOR KS-FX650R)

SSM

Set.

PS NAME

TIME DISC DISC 28

AUDIO 1

OFF

CHANGER LINE IN CHANGER 29

FREQ

CLOCK

AUDIO 2

OFF

MUTING 1

MUTING 2

Factorypreset settings

0:00 25

PS NAME 16

AUDIO 2 28

OFF 29

See page

• Press SEL (select) when the setting is complete.

Canceling Advanced SCM

You can cancel the Advanced SCM (Sound Control Memory), and unlink the sound modes and the playback sources. When shipped from the factory, a different sound mode can be stored in memory for each source so that you can change the sound modes simply by changing the sources.

• LINK ON: Advanced SCM (different sound modes for different sources)

• LINK OFF: Conventional SCM (one sound mode for all sources)

ENGLISH

1.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

2.Select “SCM LINK” with

¢ or 4.

3.Select the desired mode with the control dial. The SCM LINK mode changes as follows:

LINK OFFLINK ON

Selecting 24-hour or 12-hour clock

You can change the clock built in this unit either to 24-hour system or 12-hour system.

1.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

2.Select “24H/12H” with ¢ or 4.

ENGLISH

3.Select “24H” or “12H” with the control dial. The clock alternates between 24-hour system and 12-hour system.

12H24H

Selecting the level display

You can select the level display according to your preference. When shipped from the factory, “AUDIO 2” is selected.

• AUDIO 1: Shows the audio level indicator and the equalization pattern indicator.

• AUDIO 2: Alternates “AUDIO 1” setting and illumination display.

• OFF: Erases the audio level indicator and the equalization pattern indicator.

1.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

2.Select “LEVEL” with ¢ or 4.

3.Select the desired mode with the control dial. The level display setting changes as follows:

AUDIO 1 AUDIO 2 OFF

Selecting the display mode while using the CD changer (ONLY FOR KS-FX650R)

You can change the initial indication on the display either to disc number or to elapsed playing time, while using the CD changer.

1.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

2.Select “CH DISP” with

3.Select “DISC” or “TIME” with the control dial.

¢ or 4.

TIMEDISC

Selecting the telephone muting

This mode is used when a cellular phone system is connected. Depending on the phone system used, select either “MUTING 1” or “MUTING 2”, whiche ver mutes the sounds from this unit. When shipped from the factory, this mode is deactivated.

• MUTING 1: Select this if this setting can mute the sounds.

• MUTING 2: Select this if this setting can mute the sounds.

• OFF: Cancels the telephone muting.

1.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

2.Select “TEL” with

3.Select “MUTING 1”, “MUTING 2” or “OFF” with the control dial. The telephone muting mode changes as follows:

¢ or 4.

MUTING 1 MUTING 2 OFF

Selecting the external component to use (ONLY FOR KS-FX650R)

You can connect the external component to the CD changer jack on the rear using the Line Input Adaptor KS-U57 (not supplied). To use the external component as the playback source through this unit, you need to select which component — CD changer or external component — to use. When shipped from the factory, CD changer is selected as the external component.

• LINE IN: To use the extenal component other than CD changer

• CHANGER: To use the CD changer

ENGLISH

1.To change the source to FM, AM or TAPE, press FM/AM or

2.Press and hold SEL (Select) for more than 2 seconds to call up the general settings mode.

3.Select “LINE IN” with ¢ or 4.

4.Select the desired mode with the control dial. The external component selecting mode changes as follows:

TAPE 2 3 .

CHANGERLINE IN

Note:

For connecting the Line Input Adaptor KS-U57 and the external component, refer to the Installation/ Connection Manual (separate volume).

Detaching the control panel

You can detach the control panel when leaving the car. When detaching or attaching the control panel, be careful not to damage the connectors on

ENGLISH

the back of the control panel and on the panel holder.

How to detach the control panel

Before detaching the control panel, be sure to turn off the power.

Unlock the control panel.

M u lti

u s ic S c a n

Lift and pull the control panel

out of the unit.

Multi Music Scan

How to attach the control panel

Insert the left side of the control panel into the groove on the panel holder.

Multi Music Scan

lti M u

ic S c

Press the right side of the

control panel to fix it to the panel holder .

Multi

Music

Scan

Put the detached control panel into the provided case.

Note on cleaning the connectors:

If you frequently detach the contr ol panel, the connectors will deteriorate. T o minimize this possibility , periodically wipe the connectors with a cotton swab or cloth moistened with alcohol, being careful not to damage the connectors.

Connectors

+ 136 hidden pages
