WMA (Windows Media Audio) Decoding FormatMax. Bit Rate : 192 kbps
GENERAL
Power RequirementOperating VoltageDC 14.4 V (11 V to 16 V allowance)
Grounding SystemNegative ground
Allowable Operating Temperature0°C to +40°C
Dimensions (W × H × D)Installation Size (approx.)182 mm × 52 mm × 150 mm
Panel Size (approx.)188 mm × 58 mm × 11 mm
Mass (approx.)1.5 kg (excluding accessories)
Design and specifications are subject to change without notice.
1-2 (No.MA147)
Page 3
1.1Safety Precautions
SECTION 1
PRECAUTIONS
!
!
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.
(No.MA147)1-3
Page 4
1.2Preventing static electricity
Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser
diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs.
1.2.1 Grounding to prevent damage by static electricity
Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as CD players.
Be careful to use proper grounding in the area where repairs are being performed.
(1) Ground the workbench
Ground the workbench by laying conductive material (such as a conductive sheet) or an iron plate over it before placing the
traverse unit (optical pickup) on it.
(2) Ground yourself
Use an anti-static wrist strap to release any static electricity built up in your body.
(caption)
Anti-static wrist strap
1M
Conductive material
(conductive sheet) or iron plate
(3) Handling the optical pickup
• In order to maintain quality during transport and before installation, both sides of the laser diode on the replacement optical
pickup are shorted. After replacement, return the shorted parts to their original condition.
(Refer to the text.)
• Do not use a tester to check the condition of the laser diode in the optical pickup. The tester's internal power source can easily
destroy the laser diode.
1.3Handling the traverse unit (optical pickup)
(1) Do not subject the traverse unit (optical pickup) to strong shocks, as it is a sensitive, complex unit.
(2) Cut off the shorted part of the flexible cable using nippers, etc. after replacing the optical pickup. For specific details, refer to the
replacement procedure in the text. Remove the anti-static pin when replacing the traverse unit. Be careful not to take too long a
time when attaching it to the connector.
(3) Handle the flexible cable carefully as it may break when subjected to strong force.
(4) It is not possible to adjust the semi-fixed resistor that adjusts the laser power. Do not turn it.
1.4Attention when traverse unit is decomposed
*Please refer to "Disassembly method" in the text for the CD pickup unit.
• Apply solder to the short land before the flexible wire is disconnected from the connector on the CD pickup unit.
(If the flexible wire is disconnected without applying solder, the CD pickup may be destroyed by static electricity.)
• In the assembly, be sure to remove solder from the short land after connecting the flexible wire.
Short-circuit point
(Soldering)
Flexible wire
1-4 (No.MA147)
Pickup
Page 5
1.5Important for laser products
!
1.CLASS 1 LASER PRODUCT
2.DANGER : Invisible laser radiation when open and inter
lock failed or defeated. Avoid direct exposure to beam.
3.CAUTION : There are no serviceable parts inside the
Laser Unit. Do not disassemble the Laser Unit. Replace
the complete Laser Unit if it malfunctions.
4.CAUTION : The CD,MD and DVD player uses invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
REPRODUCTION AND POSITION OF LABELS
WARNING LABEL
CAUTION : Visible and Invisible
CLASS 1
LASER PRODUCT
laser radiation when open and
interlock failed or defeated.
AVOID DIRECT EXPOSURE TO
BEAM. (e)
ADVARSEL : Synlig og usynlig
laserstråling når maskinen er
åben eller interlocken fejeler.
Undgå direkte eksponering til
stråling. (d)
VARNING : Synlig och
osynling laserstrålning när
den öppnas och spärren är
urkopplad. Betrakta ej
strålen. (s)
VARO : Avattaessa ja suojalukitus
ohitettuna tai viallisena olet alttiina
näkyvälle ja näkymättömälle
lasersäteilylle. Vältä säteen
kohdistumista suoraan itseesi. (f)
(No.MA147)1-5
Page 6
2.1HOW TO IDENTIFY MODELS
2.1.1 NAME PLATE
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
Discernment sign
1-6 (No.MA147)
Page 7
SECTION 3
DISASSEMBLY
3.1Main body
3.1.1 Removing the front panel assembly
(See Fig.1)
(1) Push the detach button in the lower right part of the front
panel assembly and remove the front panel assembly.
(2) Take out the front panel assembly.
3.1.2 Removing the bottom cover
(See Fig.2)
(1) Turn the main body up side down.
(2) Insert a screwdriver under the joints to release the two
joints a on the left side, two joints b on the right side and
joint c on the back side of the main body, then remove the
bottom cover from the main body.
CAUTION:
When releasing the joints using a screwdriver, do not damage
the main board.
Front panel assembly
Detach button
Fig.1
Bottom cover
Joint b
Joint a
Joint a
Joint b
Joint c
Fig.2
(No.MA147)1-7
Page 8
3.1.3 Removing the front chassis assembly
(See Figs.3 and 4)
• Prior to performing the following procedures, remove the front
panel assembly and bottom cover.
(1) Remove the two screws A on the both sides of the main
body. (See Fig.3)
(2) Remove the two screws B on the front side of the main
body. (See Fig.4)
(3) Release the two joints d and two joints e on the both sides
of the main body, then remove the front chassis assembly
forward. (See Fig.3)
Joint d
A
Joint e
A
3.1.4 Removing the side panel
(See Fig.5)
Reference:
Remove the front panel assembly as required. (Refer to "3.1.1
Removing front panel assembly")
(1) Remove the two screws C and screw D attaching the side
panel on the left side of the main body.
(2) Take out the side panel from the main body.
Joint d
B
CCD
Joint e
Front chassis assembly
Fig.3
Front chassis assembly
Fig.4
1-8 (No.MA147)
Side panel
Fig.5
Page 9
3.1.5 Removing the rear bracket
(See Fig.6)
• Prior to performing the following procedure, remove the bottom
cover.
(1) Remove the three screws E, three screws F and three
screws G attaching the rear bracket on the back side of the
main body.
(2) Take out the rear bracket.
Reference:
When attaching the rear bracket to the main body, insert the
subwoofer output into the slot of the rear bracket.
3.1.6 Removing the main board
(See Fig.7)
• Prior to performing the following procedure, remove the front
panel assembly, front chassis assembly, side panel, bottom
cover and rear bracket.
(1) Remove the two screws H attaching the main board.
(2) Disconnect the connector CN501
board.
and take out the main
Rear bracket
F
EE
Insert the steering
remote into the slot.
Fig.6
CN501
Main board
H
GFG
H
3.1.7 Removing the CD mecha control board
(See Fig.8)
• Prior to performing the following procedure, remove the front
panel assembly, front chassis assembly, side panel, bottom
cover, rear bracket and main board.
(1) Disconnect the card wire from the connector CN601
CD mecha control board.
(2) Remove the five screws J attaching the CD mecha control
board.
(3) Release the claw f, and take out the CD mecha control
board.
Reference:
When attaching the CD mecha control board, attach it to the
claw f and pass the slot g of it into the boss of the CD mechanism assembly.
on the
Claw f
CN601
Fig.7
J
Slot g
J
J
CD mecha control board
Fig.8
(No.MA147)1-9
Page 10
3.1.8 Removing the CD mechanism assembly
(See Fig.9)
• Prior to performing the following procedure, remove the front
panel assembly, front chassis assembly, side panel, bottom
cover, rear bracket, main board and CD mecha control board.
(1) Remove the three screws K attaching the top chassis.
(2) Take out the CD mechanism assembly.
K
3.1.9 Removing the switch board
(See Figs.10 to 12)
• Prior to performing the following procedure, remove the front
panel assembly.
(1) Remove the five screws L attaching the front panel assem-
bly. (See Fig.10)
(2) Release the nine joints h, and take out the rear cover. (See
Fig.11)
(3) Release the joint i, and take out the switch board. (See
Fig.12)
Note:
When removing the rear cover assembly and switch board, be
careful not to lose the compression spring and comp. spring.
(See Fig.12)
CD mechanism assembly
Rear cover
Joint h
Top chassis
K
Fig.9
L
Fig.10
Joint h
1-10 (No.MA147)
Joint h
Compression spring
Front panel assembly
Rear cover
Fig.11
Fig.12
Joint h
Switch board
Comp. spring
Page 11
3.2CD Mechanism section
A
3.2.1 Removing the top cover
(See Figs.1 and 2)
(1) Remove the four screws A on the both side of the body.
(2) Lift the front side of the top cover and move the top cover
backward to release the two joints a.
Top cover
Joints a
A
Joints a
A
Fig.1
Fig.2
Top cover
(No.MA147)1-11
Page 12
3.2.2 Removing the connector board
(See Figs.3 to 5)
CAUTION:
Before disconnecting the flexible wire from the pickup, solder
the short-circuit point on the pickup. No observance of this instruction may cause damage of the pickup.
(1) Remove the screw B fixing the connector board.
(2) Solder the short-circuit point on the pickup.
(3) Disconnect the flexible wire from the pickup.
(4) Move the connector board in the direction of the arrow to
release the two joints b.
(5) Unsolder the wires on the connector board if necessary.
CAUTION:
Unsolder the short-circuit point after reassembling.
B
Connector board
Flexible wire
Wires
Joints b
Short-circuit point
Fig.3
Short-circuit point
(Soldering)
Pickup
Flexible wire
Frame
Pickup
Fig.4
B
Connector board
Fig.5
1-12 (No.MA147)
Page 13
3.2.3 Removing the DET switch
(See Figs.6 and 7)
(1) Extend the two tabs c of the feed sw. holder and pull out
the switch.
(2) Unsolder the DET switch wire if necessary.
DET
switch
Connector
board
Pickup
Fig.6
DET switch
Tab c
Tab c
DET switch wire
Feed sw. holder
Fig.7
(No.MA147)1-13
Page 14
3.2.4 Removing the chassis unit
r
(See Figs.8 and 9)
• Prior to performing the following procedure, remove the top
cover and connector board.
(1) Remove the two suspension springs (L) and (R) attaching
the chassis unit to the frame.
CAUTION:
• The shape of the suspension spring (L) and (R) are different. Handle them with care.
• When reassembling, make sure that the three shafts
on the underside of the chassis unit are inserted to the
dampers certainly.
Suspension spring (R)
Chassis unit
Suspension spring (L)
Frame
Suspension spring (R)
Chassis unit
Shafts
Damper
Damper
Suspension spring (L)
Fig.8
Shaft
Dampe
Frame
Fig.9
1-14 (No.MA147)
Page 15
3.2.5 Removing the clamper assembly
(See Figs.10 and 11)
• Prior to performing the following procedure, remove the top
cover.
(1) Remove the clamper arm spring.
(2) Move the clamper assembly in the direction of the arrow to
release the two joints d.
Clamper arm
spring
Joint d
Joint d
Clamper assembly
Fig.10
Clamper arm spring
Chassis rivet
assembly
Joint d
Clamper assembly
Chassis rivet assembly
Joint d
Fig.11
(No.MA147)1-15
Page 16
3.2.6 Removing the loading / feed motor assembly
(See Figs.12 and 13)
• Prior to performing the following procedure, remove the top
cover, connector board and chassis unit.
(1) Remove the screw C and move the loading / feed motor as-
sembly in the direction of the arrow to remove it from the
chassis rivet assembly.
(2) Disconnect the wire from the loading / feed motor assembly
if necessary.
CAUTION:
When reassembling, connect the wire from the loading /
feed motor assembly to the flame as shown in Fig.12.
Loading / feed motor assembly
Fig.12
Loading / feed motor assembly
C
Fig.13
1-16 (No.MA147)
Page 17
3.2.7 Removing the pickup unit
r
(See Figs.14 to 18)
• Prior to performing the following procedure, remove the top
cover, connector board and chassis unit.
(1) Remove the screw D and pull out the pu. shaft holder from
the pu. shaft.
(2) Remove the screw E attaching the feed sw. holder.
(3) Move the part e of the pickup unit upward with the pu. shaft
and the feed sw. holder, then release the joint f of the feed
sw. holder in the direction of the arrow. The joint g of the
pickup unit and the feed rack is released, and the feed sw.
holder comes off.
(4) Remove the pu. shaft from the pickup unit.
(5) Remove the screw F attaching the feed rack to the pickup
unit.
3.2.8 Reattaching the pickup unit
(See Figs.14 to 17)
(1) Reattach the feed rack to the pickup unit using the screw F.
(2) Reattach the feed sw. holder to the feed rack while setting
the joint g to the slot of the feed rack and setting the joint f
of the feed rack to the switch of the feed sw. holder correctly.
(3) As the feed sw. holder is temporarily attached to the pickup
unit, set to the gear of the joint g and to the bending part of
the chassis (joint h) at a time.
CAUTION:
Make sure that the part i on the underside of the feed
rack is certainly inserted to the slot j of the change lock
lever.
(4) Reattach the feed sw. holder using the screw E.
(5) Reattach the pu. shaft to the pickup unit. Reattach the pu.
shaft holder to the pu. shaft using the screw D.
Part e
Joint g
Feed sw. holder
Feed rack
Part i
E
Slot j
F
Fig.15
Pu. shaft
Pickup unit
Joint f
Joint h
Fig.16
Feed rack
Pickup unit
Feed sw. holder
D
Pu. shaft holde
Joint f
Pu. shaft
D
Pu. shaft holder
Feed sw. holder
Pickup unit
Fig.14
Part e
E
Joint g
Pickup unit
Feed rack
Fig.17
Pickup unit
Joint g
Joint f
Feed sw. holder
Fig.18
(No.MA147)1-17
Page 18
3.2.9 Removing the trigger arm
r
(See Figs.19 and 20)
• Prior to performing the following procedure, remove the top
cover, connector board and clamper unit.
(1) Turn the trigger arm in the direction of the arrow to release
the joint k and pull out upward.
CAUTION:
When reassembling, insert the part m and n of the trigger
arm into the part p and q at the slot of the chassis rivet
assembly respectively and join the joint k at a time.
Chassis rivet assembly
Trigger arm
Chassis
rivet
assembly
Joint k
Trigger arm
Fig.19
Part p
Part q
Part m
Part n
3.2.10 Removing the top plate assembly
(See Fig.21)
• Prior to performing the following procedure, remove the top
cover, connector board, chassis unit, and clamper assembly.
(1) Remove the screw H.
(2) Move the top plate assembly in the direction of the arrow to
release the two joints r.
(3) Unsolder the wire marked s if necessary.
H
Fig.20
Top plate assembly
Joints
s
Fig.21
1-18 (No.MA147)
Page 19
3.2.11 Removing the mode sw. / select lock arm
(See Figs.22 and 23)
• Prior to performing the following procedure, remove the top
plate assembly.
(1) Bring up the mode sw. to release from the link plate (joint t)
and turn in the direction of the arrow to release the joint u.
(2) Unsolder the wire of the mode sw. marked s if necessary.
(3) Turn the select lock arm in the direction of the arrow to re-
lease the two joints v.
(4) The select lock arm spring comes off the select lock arm at
the same time.
Link plate
Joint u
Fig.22
Joint t
Mode sw.
Select lock arm
s
Top plate
Select lock arm
Link plate
Select lock arm
Fig.23
Top plate
Hook w
Select lock
arm spring
Joints v
(No.MA147)1-19
Page 20
3.2.12 Reassembling the mode sw. / select lock arm
(See Figs.24 to 26)
REFERENCE:
Reverse the above removing procedure.
(1) Reattach the select lock arm spring to the top plate and set
the shorter end of the select lock arm spring to the hook w
on the top plate.
(2) Set the other longer end of the select lock arm spring to the
boss x on the underside of the select lock arm, and join the
select lock arm to the slots (joint v). Turn the select lock
arm as shown in the figure.
(3) Reattach the mode sw. while setting the part t to the first
peak of the link plate gear, and join the joint u.
CAUTION:
When reattaching the mode sw., check if the points y and
z are correctly fitted and if each part operates properly.
Select lock arm spring
Hook w
Joint v
Joint v
Select lock arm
Boss x
Fig.24
Joint t
Point y
Link plate
Point z
Link plate
Fig.25
Mode sw.
Select
lock arm
Joint t
Joint u
Fig.26
1-20 (No.MA147)
Page 21
3.2.13 Removing the select arm R / link plate
(See Figs.27 and 28)
• Prior to performing the following procedure, remove the top
plate assembly.
(1) Bring up the select arm R to release from the link plate
(joint a') and turn as shown in the figure to release the two
joints b' and joint c'.
(2) Move the link plate in the direction of the arrow to release
the joint d'. Remove the link plate spring at the same time.
REFERENCE:
Before removing the link plate, remove the mode sw..
Select arm R
Joint b'
Link plate spring
Joint c'
Joint a'
Link plate
Joint b'
Fig.27
Joint r
3.2.14 Reattaching the Select arm R / link plate
(See Figs.29 and 30)
REFERENCE:
Reverse the above removing procedure.
(1) Reattach the link plate spring.
(2) Reattach the link plate to the link plate spring while joining
them at joint d'.
(3) Reattach the joint a' of the select arm R to the first peak of
the link plate while joining the two joints b' with the slots.
Then turn the select arm R as shown in the figure. The top
plate is joined to the joint c'.
CAUTION:
When reattaching the select arm R, check if the points e'
and f' are correctly fitted and if each part operates properly.
Top plate
Select arm R
Joint b'
Joint d'
Link plate
Fig.28
Link plate spring
Joint c'
Joint d'
Joint b'
Joint a'
Fig.29
Joint a'
Point e'
Link plate
Point f'
Fig.30
(No.MA147)1-21
Page 22
3.2.15 Removing the loading roller assembly
(See Figs.31 to 33)
• Prior to performing the following procedure, remove the
clamper assembly and top plate assembly.
(1) Push inward the loading roller assembly on the gear side
and detach it upward from the slot of the joint g' of the lock
arm rivet assembly.
(2) Detach the loading roller assembly from the slot of the joint
h' of the lock arm rivet assembly.
The roller guide comes off the gear section of the loading
roller assembly.
Remove the roller guide and the HL washer from the shaft
of the loading roller assembly.
(3) Remove the screw J attaching the lock arm rivet assembly.
(4) Push the shaft at the joint i' of the lock arm rivet assembly
inward to release the lock arm rivet assembly from the slot
of the L side plate.
(5) Extend the lock arm rivet assembly outward and release
the joint j' from the boss of the chassis rivet assembly. The
roller guide springs on both sides come off at the same
time.
CAUTION:
When reassembling, reattach the left and right roller
guide springs to the lock arm rivet assembly before reattaching the lock arm rivet assembly to the chassis rivet
assembly. Make sure to fit the part k' of the roller guide
spring inside of the roller guide. (Refer to Fig.34.)
Roller guide
spring
Part k'
Chassis rivet assembly
Loading roller assembly
Loading roller assembly
Roller guide
spring
Fig.32
Boss
Roller guide
Joint h'
Roller guide spring
Loading roller assembly
HL washer
Loading roller assembly
Joint g'
Lock arm rivet assembly
Fig.31
Roller guide
Roller guide spring
Roller guide spring
J
Lock arm rivet assembly
Lock arm rivet assembly
L side plate
Roller guide spring
Joint i'
Joint j'
Fig.33
Roller guide
HL washer
Roller shaft assembly
Loading roller
Roller guide spring
Fig.34
1-22 (No.MA147)
Page 23
3.2.16 Removing the loading gear 5, 6 and 7
(See Figs.35 and 36)
• Prior to performing the following procedure, remove the top
cover, chassis unit, pickup unit and top plate assembly.
(1) Remove the screw K attaching the loading gear bracket.
The loading gear 6 and 7 come off the loading gear bracket.
(2) Pull out the loading gear 5.
K
Loading gear 5
Loading gear bracket
K
Loading gear 6
Loading gear 5
Loading gear 3
Fig.35
Loading gear bracket
Loading gear 6
Loading gear 7
Fig.36
(No.MA147)1-23
Page 24
3.2.17 Removing the gears
(See Figs.37 to 40)
• Prior to performing the following procedure, remove the top
cover, chassis unit, top plate assembly and pickup unit.
• Pull out the loading gear 3. (See Fig.35.)
(1) Pull out the feed gear.
(2) Move the loading plate assembly in the direction of the ar-
row to release the L side plate from the two slots m' of the
chassis rivet assembly. (See Fig.37.)
(3) Detach the loading plate assembly upward from the chas-
sis rivet assembly while releasing the joint n'. Remove the
slide hook and loading plate spring from the loading plate
assembly.
(4) Pull out the loading gear 2 and remove the change lock le-
ver.
(5) Remove the E ring and washer attaching the change gear
2.
(6) The change gear 2, change gear spring and adjusting
washer come off.
(7) Remove the loading gear 1.
(8) Move the change plate rivet assembly in the direction of the
arrow to release from the three shafts of the chassis rivet
assembly upward. (See Fig.38.)
(9) Detach the loading gear plate rivet assembly from the shaft
of the chassis rivet assembly upward while releasing the
joint p'. (See Figs.38 and 40.)
(10) Pull out the loading gear 4.
Change plate
rivet assembly
Shafts
E ring
Loading plate assembly
Loading plate spring
Joint p'
Loading gear 4
Loading gear plate
rivet assembly
Shaft
Loading gear 2
Loading gear 1
Chassis rivet assembly
Change gear 2
Fig.38
Joint n'
Slide hook
Feed gear
Fig.37
Slot m'
L side plate
Loading plate assembly
Joint n'
Slot m'
Chassis rivet assembly
Chassis rivet assembly
E ring
Washer
Change gear 2
Change gear
spring
Adjusting
washer
Change plate
rivet assembly
L side plate
Slot m'
Slot m'
Fig.39
Loading gear 1
Loading gear 2
Change lock lever
Loading gear 4
1-24 (No.MA147)
Chassis rivet assembly
Loading gear plate rivet
assembly
Fig.40
Page 25
3.2.18 Removing the turn table / spindle motor
(See Figs.41 and 42)
• Prior to performing the following procedure, remove the top
cover, connector board, chassis unit and clamper assembly.
(1) Remove the two screws L attaching the spindle motor as-
sembly through the slot of the turn table on top of the body.
(2) Unsolder the wire on the connector board if necessary.
Turn table
L
Fig.41
L
Turn table
Spindle motor
Fig.42
(No.MA147)1-25
Page 26
SECTION 4
ADJUSTMENT
4.1Adjustment method
Test instruments required for adjustment
(1) Digital oscilloscope (100MHz)
(2) Electric voltmeter
(3) Digital tester
(4) Tracking offset meter
(5) Test Disc JVC :CTS-1000
(6) Extension cable for check
EXTSH002-22P × 1
Standard volume position
Balance and Bass &Treble volume : lndication"0"
Loudness : OFF
How to connect the extension cable for adjusting
Caution:
Be sure to attach the heat sink and rear bracket onto the power amplifier IC and regulator IC respectively, before supply the power.
If voltage is applied without attaching these parts, the power amplifier IC and regulator IC will be destroyed by heat.
Standard measuring conditions
Power supply voltageDC14.4V(11 to 16V)
Load impedance20KΩ(2 Speakers connection)
Output LevelLine out 2.5V (Vol. MAX)
Dummy load
Exclusive dummy load should be used for AM,and FM. For FM
dummy load,there is a loss of 6dB between SSG output and
antenna input.The loss of 6dB need not be considered since
direct reading of figures are applied in this working standard.
Extension cable: EXTSH002-22P
Heat sink
Rear bracket
1-26 (No.MA147)
Page 27
5.1Feed section
SECTION 5
TROUBLESHOOTING
Is the voltage output at
IC621 pin 40?
YES
Is 4V present at both
sides of the feed motor?
YES
Check the feed motor.
5.2Focus section
5.3Spindle section
NO
Is the wiring for IC621
pin 40 correct?
NO
Is 6V or 2V present at
IC681 pins 17 and 18?
Check IC681.
When the lens is
moving:
Does the S-search
waveform appear at
IC681 pins 13 and 14?
NO
NO
YES
4V
YES
Is 5V present at IC681
pin 6?
Check the vicinity of
IC621.
YES
Check the feed motor
connection wiring.
Check the circuits in
NO
the vicinity of IC681
pins 1 and 2.
Check the pickup and
its connections.
NO
Check CD 8V.
YES
YES
Is the disk rotated?
YES
Does the RF signal
appear at IC601 pin 19?
YES
Is the RF waveform
at IC601 pin 19 distorted?
YES
Proceed to the Tracking
section
5.4Tracking section
When the disc is rotated
at first:
NO
Is 4V present between
IC681 pins 15 and 16?
Check the spindle motor
and its wiring.
NO
Check the circuits in
the vicinity of IC601
or the pickup.
NO
Approx. 1.2V
Is the tracking error
signal output at IC601
pins 10 and 11?
NO
NO
YES
Check the circuits in
the vicinity of IC601
pins 2 to 12.
Is 4V present at IC621
pin 41?
YES
Check the vicinity of
IC681
NO
Check the pickup and
its connections.
NO
Check IC621.
YES
Check IC621.
(No.MA147)1-27
Page 28
5.5Signal processing section
Is the sound output from
both channels (L, R)?
YES
Normal
NO
No sound from either
channel.
Is 9V present at IC161
pin 26?
Is the audio signal
(including sampling
output components)
output to IC572 pins 1
and 7 during playback?
Is the audio signal
output at IC161 pins 1
to 2 during playback?
YES
YES
YES
Compare the L-ch and
NO
R-ch to locate the
defective point.
NO
Is 9V present at IC901
pin 10?
Check the connection
between IC901 pin10
and IC161 pin 26.
NO
Check IC572 and its
peripheral circuits.
NO
Check IC161 and its
peripheral circuits.
YES
NO
Check IC901 and its
peripheral circuits.
YES
Check the power amp.
IC301.
1-28 (No.MA147)
Page 29
5.6Maintenance of laser pickup
(1) Cleaning the pick up lens
Before you replace the pick up, please try to clean the lens
with a alcohol soaked cotton swab.
(2) Life of the laser diode
When the life of the laser diode has expired, the following
symptoms will appear.
• The level of RF output (EFM output: amplitude of eye
pattern) will be low.
5.7Replacement of laser pickup
Turn of the power switch and, disconnect the
power cord.
Replace the pickup with a normal one. (Refer
to "Removing the pickup unit" on the previous page.)
Is RF output
1.3 0.4Vp-p?
NO
Replace it.
YES
OK
(3) Semi-fixed resistor on the APC PC board
The semi-fixed resistor on the APC printed circuit board
which is attached to the pickup is used to adjust the laser
power.Since this adjustment should be performed to match
the characteristics of the whole optical block, do not touch
the semi-fixed resistor.
If the laser power is lower than the specified value, the laser diode is almost worn out, and the laser pickup should
be replaced. If the semi-fixed resistor is adjusted while the
pickup is functioning normally, the laser pickup may be
damaged due to excessive current.
Plug the power cord in, and turn the power on.
At this time, check that the laser emits for about
seconds and the objective lens moves up and down.
Note: Do not observe the laser beam directly.
Play a disc.
Check the eye-pattern at
IC601 pin 19.
Finish.
(No.MA147)1-29
Page 30
5.816 PIN CORD DIAGRAM
8
6
5
4
3
2
1
7
BK
RD
BL
BL/WH
WH
GN
VI
GY
YL
OR/WH
NC
BR
WH/BK
GN/BK
VI/BK
GY/BK
16 YL
8 BK
7 RD
15 OR/WH
13 BR
3 GN
11 GN/BK
10
16
15
14
13
12
11
BK
RD
BL
Black
Red
Blue
WH White
BR
9
MEMORY
GND
ACC
ILL
TEL
RL+
RL-
Brown
GN
Green
VIViolet
GY
YL
Gray
Yellow
OROrange
GND
RR
FR
FL
2 VI
10 VI/BK
4 WH
12 WH/BK
1 GY
9 GY/BK
5 BL/WH
6 BL
Rear Right
Front Right
Front Left
RR+
RR-
FL+
FL-
FR+
FR-
REMOTE
ANT
REMOTE
CAUTION!
POWER
ANT
ACC
ILL
OUTPUT ONLY
ANTENNA
Auto Antenna
ACC Line
Illuminations Control
RL
REMOTE
TEL
1-30 (No.MA147)
Rear Left
Remote out
Telephone muting
GND
MEMORY
Ground
Memory Backup Battery+
Page 31
(No.MA147)1-31
Page 32
Victor Company of Japan, Limited
AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(No.MA147)
Printed in Japan
VPT
Page 33
SCHEMATIC DIAGRAMS
CD RECEIVER
KD-G615
CD-ROM No.SML200502
Area suffix
UT ------------------------ Taiwan
UH --------------------- Thailand
UN ------------------------ Asean
U ------------------- Other Areas
Contents
Block diagram
Standard schematic diagrams (For UT,UH,UN,U version)
Standard schematic diagrams (For UT2,UH2,UN2,U2 version)
Printed circuit boards
COPYRIGHT 2005 Victor Company of Japan, Limited.
2-1
2-2
2-5
2-8 to 10
No.MA147SCH
2005/2
Page 34
Safety precaution
!
!
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.
Please use enough caution not to see the beam directly or touch it in case of an
adjustment or operation check.
AV & MULTIMEDIA COMPANY CAR ELECTRONICS CATEGORY 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan
(No.MA147SCH)
Printed in Japan
VPT
Page 47
PARTS LIST
[ KD-G615 ]
* All printed circuit boards and its assemblies are not available as service parts.
Area suffix
UT
UH
UN
U
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
CD mechanism assembly and parts list (Block No.MB)
Electrical parts list (Block No.01~03) (KD-G615_UT,UH,UN,U)
Electrical parts list (Block No.04~06) (KD-G615_UH2,UN2,U2)
Packing materials and accessories parts list (Block No.M3)
Taiwan
Thailand
Asean
Other Areas
3-2
3-5
3-7
3-12
3-19
MA147
3-1
Page 48
Exploded view of general assembly and parts list
3
3
Block No.
B
2
M
1
M
1
M
A
8
11
69
only UT version
55
Mechanism
control board
C
54
11
5
24
18
15
29
2
12
4
16
10
4
9
Switch
board
36
34
4
37
41
65
26
38
13
44
3-2
32
40
31
30
33
35
43
53
42
39
45
48
70
52
Page 49
o.
M
M
1
M
1
5
7
61
10
A
8
57
58
7
60
62
63
56
59
5
24
4
26
29
3
C
B
Main board
64
7
A
68
16
6
15
18
23
9
38
22
25
17
14
28
20
21
27
6
19
68
67
50
13
10
44
12
Switch
board
5
39
42
70
43
52
48
53
46
47
49
51
66
3-3
Page 50
General Assembly
Block No. [M][1][M][M]
Symbol No.Part No.Part NameDescriptionLocal
1GE10043-210ATOP CHASSIS
2GE40135-001AEARTH PLATE
3GE30938-003ASIDE PANEL
4QYSDST2604ZATA P SC R EWM2.6 x 4mm(x3)
5GE40235-001ASCREW(x2)
6GE40235-004ASCREW(x2)
7QYSDST2604ZATA P SC R EWM2.6 x 4mm(x3)
8QYSDST2610ZATA P SC R EWM2.6 x 10mm
9QYSDSF2006ZATAP SC R EWM2 x 6mm(x2)
10QYSDST2004ZATAP SCREWM2 x 4mm(x2)
11QYSDST2004ZATAP SCREWM2 x 4mm(x5)
12GE30823-005AF . CHASSIS ASSY
13FSYH4036-098SHEET
14GE30827-002AOPEN LEVER
15GE30824-002ALOCK LEVER(O.L)
16GE31245-002ARELEASE LEVER
17GE30829-001ALOCK LEVER(T OP)
18GE31607-001ALOCK LEVER(L)
19GE31608-001ALOCK LEVER(R)
20GE40154-001AGEAR
21QZW0108-002OIL DAMPER
22GE40153-001AT . S PRING
23GE40157-001AT . S PRING
24VKW5264-005T.SPRING
25FSKW4012-002T.SPRING
26VKW5263-002T.SPRING
27GE40155-001AT . S PRING
28QYSDSF2006ZATAP SCREWM2 x 6mm
29GE40156-001ABLIND
30GE31590-015AFRONT PANEL ASSY
31GE31591-002AFINDER ASSY
32GE40254-004AVOLUME KNOB ASS
33GE31599-001ARIM LENS
34GE31593-003AD.FUNC BTN
35GE20175-008APRESET BUTTON
36GE31594-001AUP/DOWN BTN
37GE31595-001ASEARCH BTN
38VKZ4777-010MINI SCREW
39GE31601-004AEJECT BUTTON
40GE31598-001ARIM COVER
41FSKW3002-012COMP.SPRING
42GE40202-012ACOMPRESSION SPRING
43GE10107-002AREAR COVER
44VKZ4777-010MINI SCREW(x4)
45GE31603-001ALCD CASE
46GE31604-001ALCD LENS
47GE31605-001ALENS CASE
48GE40251-002ALIGHTING SHEET
49GE30393-002ABOTTOM COVER
50FSMA3005-001INSULATOR
51GE31467-002ANAME PLA T EG615U2,G615UH2,G615U N 2
51GE31467-001ANAME PLA T EG615U,G615U H,G615UN,G 615UT
52QLD0354-001LCD MODULE
53QNZ0772-001RUB BER CONN
54QUQ105-2207AEFFC WIRE22pin 7cm
55VYSH101-009SPACER
56QMFZ047-150-TFUSE15A
57GE30912-015AREAR BRACKET
58QYSDST2606Z ATA P SCREWM2.6 x 6mm
59QYSDST2606Z ATA P SCREWM2.6 x 6mm
60QYSDST2606Z ATA P SCREWM2.6 x 6mm
61QYSDSF2606ZATA P SCREWM2.6 x 6mm(x2)
62QYSDSF2606Z ATA P SCREWM2.6 x 6mm
63GE40172-004AIC BRACKET
64GE40124-002AREG BRACKET
65GE30854-001ALED HOLDER
66LV41843-002ALASER CAUTION
67QAM0684-001SUBWOOFER CABLE
68VYTA500-001PIN CAP(x2)
69GE31574-007AUT LABELG615UT
70GE40218-032ASHEET
3-4
Page 51
CD mechanism assembly and parts list
Grease
TNG-87
GP-501MK
CFD-005Z
GP-305T
26
74
72
35
TN-2001-1013
34
33
111
Block No.
M
2
M
B
M
C
101
93
112
24
76
94
31
22
122
61
36
29
100
116
111
25
73
85
15
111
37
A
19
B
21
62
D
75
38
95
14
100
112
96
97
123
11
32
a
114
D
90
89
113
38
30
A
C
B
92
18
82
115
87
88
20
13
23
125
32
99
12
121
16
17
124
86
27
28
83
98
83
4
84
73
74
94
81
75
77
a
111
91
111
93
71
3
3
1
111
The parts without symbol number are not service.
3-5
Page 52
CD mechanism
Symbol No.Part No.Part NameDescriptionLocal
130320101TFRAME
230320102TTOP COVER
330320115TDANPER F(x2)
430320116TDANPER R
11303205505TCHASSIS RIVET
12303205503TCHANGE P. RVT A
13303205301TCLAMPER ASSY
14303205302TSPINDLE M O TOR A
1530320502TCLAMPER ARM
1630320503TCHANGE G EAR SPG
1730320505TCHANG E G EAR 2
1830320506TFEED GEAR
1930320507TFEED RACK
2030320509TCHAN G E LOCK RAR
2130320510TFEED SW H OLDER
2230320511TPU SHAFT HOLDER
2330320513TCLAMPER SUB SPG
2430320514TFD SUB HOLDER
2530320518TTOP PLATE
2630320519TSELECT LOCK ARM
2730320520TTRIGGER ARM
2830320521TSLIDE HOOK
2930320522TPU SHAFT
3030320525TCLAMPER ARM SPG
3130320526TSELECT L ARM SP
3230320538TSUSPENSION SP R(x2)
3330320529TSELECT ARM R
3430320530TLINK PLATE
3530320531TLINK PLATE SPG
3630320523TCUSHION F
3730320524TCUSHION R(x2)
3830320539TSUSPENSION SP L(x2)
6169011614TPICKUP OPT-725
6264180406TDET SW ESE22
71303210302TCONN BOAR D ASSY
7230321002TMODE SW
7330321003TLOAD MOTOR WIRE
7430321005TMODE SW WIRE
7530321009TSL WIRE
7630321011TWIRE HOLDER
7719501403TWIRE CLUMPER
8130321 1301TROLLER SHAFT AS
82303211501TL GEAR PLATE RV
83303211302TLOADING PL ATE A
8430321 1502TLOCK ARM RV ASS
85303211303TL/F MOTOR ASSY
863032 1101TLOADING G EAR 1
873032 1102TLOADING G EAR 2
883032 1103TLOADING G EAR 3
893032 1104TLOADING G EAR 4
903032 1105TLOADING G EAR 5
913032 1106TLOADING G EAR 6
923032 1107TLOADING G EAR 7
9330321149TROLLER GUIDE(x2)
9430321 114TROLLER GUIDE SP(x2)
9530321116TDISC STOPPER AR
9630321 117TDISC ST ARM SPG
9730321118TLD GEAR BRACKET
9830321125TL SIDE PLATE
9930321131TLOAD PLATE SPG
10030321133TLDG ROLLER(x2)
10118211223TCOLLAR SCREW
1119P0420031TSCREW(x6)
1129P0420041TTAP.SCREW(x2)
1139B0320041TSCREW
1149C0117183TSCREW(x2)
1159C0120203TSCREW
1169C0317503TSCREW
1219W0130170 TP W 3.5X8X0.3
1229W0513060THL WASHER
1239W0710070TL WASHER
1249E0100152TE RING
1259W0113020TPW 2.1X4X0.13
D1MA111-XSI DIODE
D2MA111-XSI DIODE
D4MA111-XSI DIODE
D5MA111-XSI DIODE
D6MA111-XSI DIODE
D242MA111-XSI DI O D E
D243RB160M-30-XSB DIODE
D244UDZS5.1B-XZ DIODE
D251UDZS4.7B-XZ DIODE
D271MA111-XSI DI O D E
D273MA111-XSI DI O D E
D321MA111-XSI DI O D E
D325UDZS11B-XZ D I OD E
D331MA111-XSI DI O D E
D341MA111-XSI DI O D E
D351MA111-XSI DI O D E
D701MA8062/M/-XZ DIODE
D702MA8062/M/-XZ DIODE
D703MA8062/M/-XZ DIODE
D704MA8062/M/-XZ DIODE
D705MA8062/M/-XZ DIODE
D706MA8062/M/-XZ DIODE
D707MA8062/M/-XZ DIODE
D708MA8062/M/-XZ DIODE
D709MA8062/M/-XZ DIODE
D710MA111-XSI DI O D E
D711MA8062/M/-XZ DIODE
D713UDZS5.6B-XZ DIODE1.5k
D714SML-310VT/JK/-XLED
D715SML-310VT/JK/-XLED
D716SML-310VT/JK/-XLED
D717MA8062/M/-XZ DIODE
Part No.Part NameDescriptionLocal
Ω
1/10W J
Symbol No.
D718MA8062/M/-XZ DIODE
D719MA8062/M/-XZ DIODE
D720MA8062/M/-XZ DIODE
D781MA111-XSI DIODE
D782MA111-XSI DIODE
D783MA111-XSI DIODE
D784UDZS11B-XZ DIODE
D851RB160M-30-XS B DIOD E
D852RB160M-30-XS B DIOD E
D891MA111-XSI DIODE
D892MA111-XSI DIODE
D9011N5401-F64DIODE
D902MA111-XSI DIODE
D971RB160M-30-XS B DIOD E
D972RB160M-30-XS B DIOD E
D996RB160M-30-XS B DIOD E
D997RB160M-30-XS B DIOD E
C1QEKJ1CM-226ZE CAPACITOR22uF 16V M
C2NCB3 1E K-104XC CAPACITOR0.1 uF 25V K
C3NCB3 1E K-104XC CAPACITOR0.1 uF 25V K
C4QERF 1A M- 227ZE CAPACITOR220uF 10V M
C5QEK J1HM- 104ZE CAPACITOR0.1uF 50V M
C6NCB3 1E K-104XC CAPACITOR0.1 uF 25V K
C9QEKJ1CM-226ZE CAPACITOR22uF 16V M
C10NCB31E K-10 4XC CAPACITOR0.1uF 25V K
C11NCB31E K-10 4XC CAPACITOR0.1uF 25V K
C12QERF 1A M- 227ZE CAPACITOR220uF 10V M
C30NCB31H K- 103XC CAPACITOR0.01uF 50V K
C31QERF 1A M- 107ZE CAPACITOR100uF 10V M
C32NDC31HJ-470XC CAPACITOR47pF 50V J
C33QEK J0JM-47 6ZE CAPACITOR47uF 6.3V M
C34NCB31E K- 47 3XC CAPACITOR0.047uF 25V K
C35NDC31HJ-100XC CAPACITOR10pF 50V J
C36NDC31HJ-7R0XC CAPACITOR7pF 50V J
C37NDC31HJ-100XC CAPACITOR10pF 50V J
C38NCB31HK-102XC CAP ACITOR1000pF 50V K
C39NCB31HK-102XC CAP ACITOR1000pF 50V K
C40QERF1CM-106ZE CAPACITOR10uF 16V M
C41NCB31E K- 47 3XC CAPACITOR0.047uF 25V K
C42NCB31H K- 103XC CAPACITOR0.01uF 50V K
C43QFV61HJ-473ZMF CAPACITOR0.047uF 50V J
C44NCB31H K- 103XC CAPACITOR0.01uF 50V K
C45NCB31HK-272XC CAP ACITOR2700pF 50V K
C46NCB31H K- 103XC CAPACITOR0.01uF 50V K
C47NCB31H K- 103XC CAPACITOR0.01uF 50V K
C48NCB31E K- 47 3XC CAPACITOR0.047uF 25V K
C49NCB31HK-102XC CAP ACITOR1000pF 50V K
C50NDC31HJ-101XC CAPACITOR100pF 50V J
C51NCB31HK-331XC CAPACITOR330pF 50V K
C81QERF 1H M-105 ZE CAPACITOR1uF 50V M
C82NCB31HK-182XC CAP ACITOR1800pF 50V K
C85NCB31HK-123XC CAPACITOR0.012uF 50V K
C91QERF 1H M-105 ZE CAPACITOR1uF 50V M
C92NCB31HK-182XC CAP ACITOR1800pF 50V K
C95NCB31HK-123XC CAPACITOR0.012uF 50V K
C161QEK J1 H M - 10 5ZE CAPACITOR1uF 50V M
C162QERF1HM-105ZE CAPACITOR1uF 50V M
C163QTE 1H55-225ZE CAPACITOR2.2uF 50V
C165QERF1HM-105ZE CAPACITOR1uF 50V M
C171QEK J1 H M - 10 5ZE CAPACITOR1uF 50V M
C172QERF1HM-105ZE CAPACITOR1uF 50V M
C173QTE 1H55-225ZE CAPACITOR2.2uF 50V
C174QERF1HM-105ZE CAPACITOR1uF 50V M
C175QERF1HM-105ZE CAPACITOR1uF 50V M
C176NCB31HK-473XC CAPACITOR0.047uF 50V K
C177NCB31HK-473XC CAPACITOR0.047uF 50V K
C179QERF1CM-476ZE CAPACITOR47uF 16V M
C181QERF1CM-107ZE CAPACITOR100u F 16V M
C182NCB31EK-104XC CAPACITOR0.1uF 25V K
C184NCB31CK-224XC CAPACITOR0.22uF 16V K
C241QERF1HM-105ZE CAPACITOR1uF 50V M
C242QERF1CM-226ZE CAPACITOR22uF 16V M
C243NCB31EK-473XC CAPACITOR0.047uF 25V K
C245QERF 1HM-224ZE CAPACITOR0.22uF 50V M
C251NCB31HK - 822XC CAPACITOR8200pF 50V K
Part No.Part N am eDescriptionLocal
3-7
Page 54
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C252QE RF0JM-476ZE CAPACITOR47uF 6.3V M
C253QERF1CM-106ZE CAPACITOR10uF 16V M
C254NCB31EK-823XC CAPACITOR0.082uF 25V K
C255QERF1CM-476ZE CAPACITOR47uF 16V M
C256NCB31EK-104XC CAPACITOR0.1uF 25V K
C261QERF1HM-225ZE CAPACITOR2.2uF 50V M
C262QERF1HM-225ZE CAPACITOR2.2uF 50V M
C272ND C31HJ-101XC CAPACITOR100pF 50 V J
C273ND C31HJ-101XC CAPACITOR100pF 50 V J
C274NCB31EK-223XC CAPACITOR0.022uF 25V K
C275NCB31EK-223XC CAPACITOR0.022uF 25V K
C276NCB31EK-223XC CAPACITOR0.022uF 25V K
C277NCB31EK-562XC CAPACITOR5600pF 25V K
C278NCB31EK-123XC CAPACITOR0.012uF 25V K
C279QE RF0JM-476ZE CAPACITOR47uF 6.3V M
C281NCB31EK-823XC CAPACITOR0.082uF 25V K
C298NCB31EK-104XC CAPACITOR0.1uF 25V K
C301QFV91HJ-474ZMF CAPACITOR0.47uF 50V J
C302QFV91HJ-474ZMF CAPACITOR0.47uF 50V J
C303ND C31HJ-101XC CAPACITOR100pF 50 V J
C304ND C31HJ-101XC CAPACITOR100pF 50 V J
C311QFV91HJ-474ZMF CAPACITOR0.47uF 50V J
C312QFV91HJ-474ZMF CAPACITOR0.47uF 50V J
C313ND C31HJ-101XC CAPACITOR100pF 50 V J
C314ND C31HJ-101XC CAPACITOR100pF 50 V J
C315QERF1HM-225ZE CAPACITOR2.2uF 50V M
C316QERF1EM-475ZE CAPACITOR4.7uF 25V M
C317QERF1CM-226ZE CAPACITOR22uF 16V M
C318QEKJ 1HM-225ZE CAPACITOR2.2uF 50V M
C319NCB31EK-104XC CAPACITOR0.1uF 25V K
C320NCB31EK-104XC CAPACITOR0.1uF 25V K
C322NCB21HK-472XC CAPACITOR4700pF 50V K
C323NCB21HK-472XC CAPACITOR4700pF 50V K
C324NCB21HK-472XC CAPACITOR4700pF 50V K
C325NCB21HK-472XC CAPACITOR4700pF 50V K
C341NCB31EK-104XC CAPACITOR0.1uF 25V K
C367QERF1EM-475ZE CAPACITOR4.7uF 25V M
C368QERF1EM-475ZE CAPACITOR4.7uF 25V M
C387QERF1EM-475ZE CAPACITOR4.7uF 25V M
C388QERF1EM-475ZE CAPACITOR4.7uF 25V M
C701NDC31HJ-220XC CAPACITOR22pF 50V J
C702NDC31HJ-270XC CAPACITOR27pF 50V J
C703NDC31HJ-270XC CAPACITOR27pF 50V J
C704ND C31HJ-8R0XC C APACITOR8pF 50V J
C705NCB31EK-104XC CAPACITOR0.1uF 25V K
C706NCB31EK-104XC CAPACITOR0.1uF 25V K
C707NCB31EK-104XC CAPACITOR0.1uF 25V K
C708NCB31EK-104XC CAPACITOR0.1uF 25V K
C709NCB31HK-103XC CAPACITOR0.01uF 50V K
C710QEKJ0JM-476ZE CAPACITOR47uF 6.3V M
C711QERF1AM-227ZE CAPACITOR220uF 10V M
C713NCB31CK-224XC CAPACITOR0.22uF 16V K
C716NCB31EK-104XC CAPACITOR0.1uF 25V K
C717NCB31EK-104XC CAPACITOR0.1uF 25V K
C720NCB31HK-103XC CAPACITOR0.01uF 50V K
C721NCB31HK-103XC CAPACITOR0.01uF 50V K
C722NCB31HK-103XC CAPACITOR0.01uF 50V K
C723NCB31EK-104XC CAPACITOR0.1uF 25V K
C724NCB31EK-104XC CAPACITOR0.1uF 25V K
C725NCB31EK-104XC CAPACITOR0.1uF 25V K
C726NCB31EK-104XC CAPACITOR0.1uF 25V K
C727NCB31EK-104XC CAPACITOR0.1uF 25V K
C728ND C31HJ-101XC CAPACITOR100pF 50 V J
C729ND C31HJ-101XC CAPACITOR100pF 50 V J
C730ND C31HJ-101XC CAPACITOR100pF 50 V J
C740NCB31EK-104XC CAPACITOR0.1uF 25V K
C743NCB31AK-334XC CAPACITOR0. 33 uF 10V K
C744NCB31EK-104XC CAPACITOR0.1uF 25V K
C745NCB31AK-334XC CAPACITOR0. 33 uF 10V K
C746NCB31EK-104XC CAPACITOR0.1uF 25V K
C747NCB31EK-473XC CAPACITOR0.047uF 25V K
C771NCB31EK-473XC CAPACITOR0.047uF 25V K
C781QE RF0JM-476ZE CAPACITOR47uF 6.3V M
C782NCB31AK-474XC CAPACITOR0. 47 uF 10V K
C784QERF1CM-107ZE CAPACITOR100uF 16V M
C801NCB31EK-473XC CAPACITOR0.047uF 25V K
C802NCB31HK-472XC CAPACITOR4700pF 50V K
C803NDC31HJ-220XC CAPACITOR22pF 50V J
C804NDC3 1HJ-220XC CAPACITOR22pF 50V J
C851QERF1CM-106ZE CAPACITOR10uF 16V M
C852NCB31EK-103XC CAPACITOR0.01uF 25V K
C881QERF1CM-226ZE CAPACITOR22uF 16V M
C891NCB31EK-104XC CAPACITOR0.1uF 25V K
C901QEZ0723-338E CAPACITOR3300uF
C902QERF1HM-225ZE CAPACITOR2.2uF 50V M
C903QERF1CM-476ZE CAPACITOR47uF 16V M
C904QERF1CM-106ZE CAPACITOR10uF 16V M
C905QERF1CM-476ZE CAPACITOR47uF 16V M
C906NCB31EK-104XC CAPACITOR0.1uF 25V K
C907QERF1AM-227ZE CAPA CITOR220uF 10V M
C908QERF1AM-227ZE CAPA CITOR220uF 10V M
C909QERF1AM-227ZE CAPA CITOR220uF 10V M
C910QERF1CM-476ZE CAPACITOR47uF 16V M
C911QERF1CM-106ZE CAPACITOR10uF 16V M
C912NCB31EK-104XC CAPACITOR0.1uF 25V K
C914QERF1CM-107ZE CAPACITOR100uF 16V M
C915NCB31CK-104XC CAPACITOR0.1uF 16V K
C916QERF1CM-476ZE CAPACITOR47uF 16V M
C961NDC3 1H J - 471XC C APACITOR470pF 50V J
C962NDC3 1H J - 471XC C APACITOR470pF 50V J
C963NDC3 1H J - 471XC C APACITOR470pF 50V J
C964NDC3 1H J - 471XC C APACITOR470pF 50V J
C965NDC3 1H J - 471XC C APACITOR470pF 50V J
C966NDC3 1H J - 471XC C APACITOR470pF 50V J
C967NDC3 1H J - 471XC C APACITOR470pF 50V J
C968NDC3 1H J - 471XC C APACITOR470pF 50V J
C971NCB31EK-104XC CAPACITOR0.1uF 25V K
R260NRS A63J-473XM G R ESISTOR47kΩ 1/16W J
R261NRS A63J-821XM G R ESISTOR820
R271NRS A63J-222XM G R ESISTOR2.2k
R274NRS A63J-473XM G R ESISTOR47k
R275NRS A63J-105XM G R ESISTOR1M
R276NRS A63J-105XM G R ESISTOR1M
R277NRS A63J-105XM G R ESISTOR1M
R278NRS A63J-105XM G R ESISTOR1M
R279NRS A63J-473XM G R ESISTOR47k
R291NRSA63J-0R0XMG RESISTOR0
R292NRSA63J-0R0XMG RESISTOR0
R293NRS A63J-101XM G R ESISTOR100
R294NRS A63J-101XM G R ESISTOR100
R301NRS A63J-473XM G R ESISTOR47k
R302NRS A63J-473XM G R ESISTOR47k
R307NRS A63J-122XM G R ESISTOR1.2k
R308NRS A63J-122XM G R ESISTOR1.2k
R311NRSA63J-473XM G R ESISTOR47k
R312NRS A63J-473XM G R ESISTOR47k
R317NRS A63J-122XM G R ESISTOR1.2k
R318NRS A63J-122XM G R ESISTOR1.2k
R321NRS A63J-222XM G R ESISTOR2.2k
R322NRS A63J-821XM G R ESISTOR820
R323NRS A63J-101XM G R ESISTOR100
R331NRS A63J-222XM G R ESISTOR2.2k
R332NRS A63J-821XM G R ESISTOR820
R333NRS A63J-101XM G R ESISTOR100
R341NRS A63J-222XM G R ESISTOR2.2k
R342NRS A63J-821XM G R ESISTOR820
R343NRS A63J-101XM G R ESISTOR100
R351NRS A63J-222XM G R ESISTOR2.2k
R352NRS A63J-821XM G R ESISTOR820
R353NRS A63J-101XM G R ESISTOR100
R368NRS A63J-473XM G R ESISTOR47k
R369NRS A63J-473XM G R ESISTOR47k
R388NRS A63J-473XM G R ESISTOR47k
R389NRS A63J-473XM G R ESISTOR47k
R395NRSA63J-0R0XMG RESISTOR0
R396NRSA63J-0R0XMG RESISTOR0
R397NRSA63J-0R0XMG RESISTOR0
R398NRSA63J-0R0XMG RESISTOR0
R701NRS A63J-473XM G R ESISTOR47k
R709NRS A63J-103XM G R ESISTOR10k
R714NRS A63J-103XM G R ESISTOR10k
R719NRSA63J-0R0XMG RESISTOR0
R720NRS A63J-122XM G R ESISTOR1.2k
R721NRS A63J-102XM G R ESISTOR1k
R722NRS A63J-103XM G R ESISTOR10k
R723NRS A63J-103XM G R ESISTOR10k
R725NRS A63J-103XM G R ESISTOR10k
R726NRS A63J-103XM G R ESISTOR10k
R728NRS A63J-103XM G R ESISTOR10k
R729NRS A63J-473XM G R ESISTOR47k
R730NRS A63J-103XM G R ESISTOR10k
R731NRS A63J-473XM G R ESISTOR47k
R732NRS A63J-103XM G R ESISTOR10k
R734NRS A63J-222XM G R ESISTOR2.2k
R735NRS A63J-222XM G R ESISTOR2.2k
R736NRS A63J-222XM G R ESISTOR2.2k
R737NRSA63J-0R0XMG RESISTOR0
R738NRS A63J-472XM G R ESISTOR4.7k
R739NRS A63J-472XM G R ESISTOR4.7k
R740NRS A63J-472XM G R ESISTOR4.7k
R741NRS A63J-103XM G R ESISTOR10k
R743NRS A63J-103XM G R ESISTOR10k
R744NRS A63J-103XM G R ESISTOR10k
R745NRS A63J-103XM G R ESISTOR10k
R746NRS A63J-103XM G R ESISTOR10k
R747NRS A63J-472XM G R ESISTOR4.7k
R748NRS A63J-472XM G R ESISTOR4.7k
R749NRS A63J-472XM G R ESISTOR4.7k
R750NRS A63J-103XM G R ESISTOR10k
R751NRS A63J-103XM G R ESISTOR10k
R753NRS A63J-473XM G R ESISTOR47k
R754NRS A63J-821XM G R ESISTOR820
R755NRS A63J-106XM G R ESISTOR10M
R756NRS A63J-473XM G R ESISTOR47k
R757NRS A63J-222XM G R ESISTOR2.2k
C601NCB31HK-223XC CAPACITOR0.022uF 50V K
C602NC S3 1HJ-681XC CAPACITOR68 0p F 50V J
C603NBE20JM-106XTA E CAPACITOR10 uF 6.3V M
C611NCB31HK-123XC CAPACITOR0.012uF 50V K
C612NBE20JM-475XTA E CAPACITOR4.7uF 6.3V M
IC501TMP91CW12AF5VD9 IC
IC502BR24L01AFV-W-XIC
IC503SN74AHCT126PW-X IC(DIGITAL)
IC504NJU7241F33-XIC
IC571PCM1753-XIC
IC572NJM4580V-XIC
IC573SN74AHCU04PW-XIC
IC601TA2157FN-XRF AMP IC
IC621TC94A14FAC D LSI IC
IC651NJU7772F15-XIC
IC652TC94A34FG-002IC
IC681BA5830FP-XIC
Q501UN2111- XTRANSISTOR
Q502UN2211-XT R ANSISTOR
Q571UN2111- XTRANSISTOR
Q572UN2211-XT R ANSISTOR
Q5732SB624/4/-XTRANSISTOR
Q574UN2211-XT R ANSISTOR
Q6012SB1132/QR/-WT RANSISTOR
Q6512SB624/4/-XTRANSISTOR
Q652UN2211-XT R ANSISTOR
Q6812SB1184/QR/-XTRANSISTOR
D506MA111-XSI DIODE
D6821SR154-400-XDIODE
Part No.Part NameDescriptionLocal
3-10
Page 57
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part N am eDescriptionLocal
C501NCB31HK-103XC CAPACITOR0.01uF 50V K
C502NCB31HK-103XC CAPACITOR0.01uF 50V K
C503NEA G0JM-107XE CAPACITOR100uF 6.3V M
C504NDC31HJ-220XC CAPACITOR22pF 50V J
C505NDC31HJ-220XC CAPACITOR22pF 50V J
C506NCB31HK-103XC CAPACITOR0.01uF 50V K
C507NCB31HK-103XC CAPACITOR0.01uF 50V K
C508NCB31HK-103XC CAPACITOR0.01uF 50V K
C509NCB31HK-103XC CAPACITOR0.01uF 50V K
C510NCB31HK-103XC CAPACITOR0.01uF 50V K
C511NCB31CK-104XC CAPACITOR0.1uF 16V K
C512NEA G0JM-107XE CAPACITOR100uF 6.3V M
C513NCB31HK-103XC CAPACITOR0.01uF 50V K
C514NCS31HJ-102XC CAPACITOR1000pF 50 V J
C551NCB31HK-103XC CAPACITOR0.01uF 50V K
C561NCB31EK-123XC CAPACITOR0.012uF 25V K
C571NDC31HJ-270XC CAPACITOR27pF 50V J
C572NDC31HJ-270XC CAPACITOR27pF 50V J
C573NCB31CK-104XC CAPACITOR0.1uF 16V K
C574NEA G0JM-107XE CAPACITOR100uF 6.3V M
C575NEA G0JM-107XE CAPACITOR100uF 6.3V M
C577NCB31CK-104XC CAPACITOR0.1uF 16V K
C578NEA G0JM-107XE CAPACITOR100uF 6.3V M
C580NCB31EK-123XC CAPACITOR0.012uF 25V K
C581NDC31HJ-101XC CAPACITOR100pF 50V J
C582NDC31HJ-101XC CAPACITOR100pF 50V J
C583NCS31HJ-821XC CAPACITOR820pF 50V J
C584NCS31HJ-821XC CAPACITOR820pF 50V J
C585NEAG1VM-475XE CAPACITOR4.7uF 35V M
C586NEAG1VM-475XE CAPACITOR4.7uF 35V M
C587NDC31HJ-151XC CAPACITOR150pF 50V J
C588NDC31HJ-151XC CAPACITOR150pF 50V J
C589NEAG1VM-475XE CAPACITOR4.7uF 35V M
C590NEAG1VM-475XE CAPACITOR4.7uF 35V M
C591NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C592NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C593NEAG 1CM-476XE CAPACITOR47 uF 16V M
C594NCS31HJ-102XC CAPACITOR1000pF 50 V J
C595NCB31CK-473XC CAPACITOR0.047uF 16V K
C596NDC31HJ-101XC CAPACITOR100pF 50V J
C597NCS31HJ-102XC CAPACITOR1000pF 50 V J
C598NCS31HJ-102XC CAPACITOR1000pF 50 V J
C601NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C602NCB31HK-103XC CAPACITOR0.01uF 50V K
C603NEA G0JM-107XE CAPACITOR100uF 6.3V M
C604NCB31HK-103XC CAPACITOR0.01uF 50V K
C605NCB31HK-682XC CAPACITOR6800pF 50V K
C606NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C607NCB31HK-103XC CAPACITOR0.01uF 50V K
C608NCB31CK-104XC CAPACITOR0.1uF 16V K
C609NCB31CK-104XC CAPACITOR0.1uF 16V K
C610NDC31HJ-5R0XC CAPACITOR5pF 5 0V J
C611NDC31HJ-680XC CAPACITOR68pF 50V J
C612NCB31HK-103XC CAPACITOR0.01uF 50V K
C613NCB31HK-103XC CAPACITOR0.01uF 50V K
C614NCB31HK-103XC CAPACITOR0.01uF 50V K
C616NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C621NCB31HK-103XC CAPACITOR0.01uF 50V K
C622NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C623NDC31HJ-470XC CAPACITOR47pF 50V J
C624NCB31HK-153XC CAPACITOR0.015uF 50V K
C625NCB31HK-103XC CAPACITOR0.01uF 50V K
C626NCB31HK-272XC CAPACITOR2700pF 50V K
C627NCB31HK-103XC CAPACITOR0.01uF 50V K
C628NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C629NCB31EK-333XC CAPACITOR0.033uF 25V K
C630NCB31EK-333XC CAPACITOR0.033uF 25V K
C631NDC31HJ-471XC CAPACITOR470pF 50V J
C632NDC31HJ-471XC CAPACITOR470pF 50V J
C633NCB31CK-473XC CAPACITOR0.047uF 16V K
C634NCB31CK-473XC CAPACITOR0.047uF 16V K
C635NCB31CK-473XC CAPACITOR0.047uF 16V K
C636NCB31CK-473XC CAPACITOR0.047uF 16V K
C637NCB31CK-473XC CAPACITOR0.047uF 16V K
C638NCB31HK-103XC CAPACITOR0.01uF 50V K
C639NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C640NCB31HK-103XC CAPACITOR0.01uF 50V K
C641NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C642NDC31HJ-101XC CAPACITOR100pF 50V J
C643NCB31HK-103XC CAPACITOR0.01uF 50V K
C644NCB31AK-334XC CAPACITOR0.33uF 10V K
C645NEA G 0J M - 476XE CAPACITOR47uF 6. 3V M
C646NCB31HK-103XC CAPACITOR0.01uF 50V K
C651NEA G 0J M - 476XE CAPACITOR47uF 6. 3V M
C652NCB31HK-103XC CAPACITOR0.01uF 50V K
C653NEA G 0J M - 476XE CAPACITOR47uF 6. 3V M
C654NCB31CK-104XC CAPACITOR0.1uF 16V K
C655NCB31HK-103XC CAPACITOR0.01uF 50V K
C656NCB31CK-104XC CAPACITOR0.1uF 16V K
C659NCB31CK-104XC CAPACITOR0.1uF 16V K
C660NDC31HJ-101XC CAPACITOR100pF 50V J
C661NCB31HK-103XC CAPACITOR0.01uF 50V K
C662NDC31HJ-101XC CAPACITOR100pF 50V J
C663NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C664NCB31HK - 222XC CAPACITOR2200pF 50V K
C665NCB31EK-104XC CAPACITOR0.1uF 25V K
C666NDC31HJ-101XC CAPACITOR100pF 50V J
C667NCB31HK-103XC CAPACITOR0.01uF 50V K
C668NEA G 0J M - 476XE CAPACITOR47uF 6. 3V M
C669NCB31HK-103XC CAPACITOR0.01uF 50V K
C682NEAG1VM-475XE CAPACITOR4.7uF 35V M
C683NCB31CK-104XC CAPACITOR0.1uF 16V K
C684NEAG1CM-476XE CAPACITOR47uF 16V M
C689NEAG1CM-476XE CAPACITOR47uF 16V M
C690NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C693NEAG1CM-476XE CAPACITOR47uF 16V M
L501NQL114K-470XINDUCITOR47uH K
L502NQL114K-470XINDUCITOR47uH K
L572NQL114K-470XINDUCITOR47uH K
L621NQL114K-470XINDUCITOR47uH K
L622NQL114K-470XINDUCITOR47uH K
L623NQL114K-470XINDUCITOR47uH K
L651NQL114K-470XINDUCITOR47uH K
L652NQL114K-470XINDUCITOR47uH K
L653NQL114K-470XINDUCITOR47uH K
IC31TB2118 F - XPLL IC
IC161TDA7404D-E-XIC
IC251NJM4565M-WEIC
IC271CD4066BPW-XIC
IC301TB2906HQIC
IC701UPD784217AGC322IC
IC702IC-PST3433U-XIC
IC771BR24L16F-W-XIC
IC801HD74HC126FP-XIC
IC901HA13164AIC
Q1KTD1304-XTRANSISTOR
Q52SB709A/R/-XTRANSISTOR
Q62SB624/4/-XT RAN SISTOR
Q7UN2211-XTRANSISTOR
Q8UN2211-XTRANSISTOR
Q31UN2211-XTRANSISTOR
Q2412SD601A/R/-XTRANSISTOR
Q271KTD1304-XTRANSISTOR
Q272UN2111- XTRANSISTOR
Q273UN2211-XT R ANSISTOR
Q274UN2211-XT R ANSISTOR
Q321KTD1304-XTRANSISTOR
Q331KTD1304-XTRANSISTOR
Q341KTD1304-XTRANSISTOR
Q351KTD1304-XTRANSISTOR
Q701UN2211-XT R ANSISTOR
Q702UN2211-XT R ANSISTOR
Q703UN2211-XT R ANSISTOR
Q704UN2211-XT R ANSISTOR
Q705UN2211-XT R ANSISTOR
Q781UN2111- XTRANSISTOR
Q782KTD1304-XTRANSISTOR
Q784UN2111- XTRANSISTOR
Q881UN2211-XT R ANSISTOR
Q891UN2211-XT R ANSISTOR
Q9012SB1132/QR/-WT RANSISTOR
Q976UN2211-XT R ANSISTOR
Part No.Part NameDescriptionLocal
3-12
Page 59
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part N am eDescriptionLocal
Q9772SB709A/QR/ -XTRANSISTOR
D1MA111-XSI DIODE
D2MA111-XSI DIODE
D4MA111-XSI DIODE
D5MA111-XSI DIODE
D6MA111-XSI DIODE
D242MA111-XSI DI O D E
D243RB160M-30-XSB DIODE
D244UDZS5.1B-XZ DIODE
D251UDZS4.7B-XZ DIODE
D271MA111-XSI DI O D E
D273MA111-XSI DI O D E
D321MA111-XSI DI O D E
D325UDZS11B-XZ D I OD E
D331MA111-XSI DI O D E
D341MA111-XSI DI O D E
D351MA111-XSI DI O D E
D701MA8062/M/-XZ DIODE
D702MA8062/M/-XZ DIODE
D703MA8062/M/-XZ DIODE
D704MA8062/M/-XZ DIODE
D705MA8062/M/-XZ DIODE
D706MA8062/M/-XZ DIODE
D707MA8062/M/-XZ DIODE
D708MA8062/M/-XZ DIODE
D709MA8062/M/-XZ DIODE
D710MA111-XSI DI O D E
D711MA8062/M/-XZ DIODE
D713UDZS5.6B-XZ DIODE1.5k
D714SML-310VT/JK/-XLED
D715SML-310VT/JK/-XLED
D716SML-310VT/JK/-XLED
D717MA8062/M/-XZ DIODE
D718MA8062/M/-XZ DIODE
D719MA8062/M/-XZ DIODE
D720MA8062/M/-XZ DIODE
D781MA111-XSI DI O D E
D782MA111-XSI DI O D E
D783MA111-XSI DI O D E
D784UDZS11B-XZ D I OD E
D851RB160M-30-XSB DIODE
D852RB160M-30-XSB DIODE
D891MA111-XSI DI O D E
D892MA111-XSI DI O D E
D9011N5401-F64DIODE
D902MA111-XSI DI O D E
D971RB160M-30-XSB DIODE
D972RB160M-30-XSB DIODE
D996RB160M-30-XSB DIODE
D997RB160M-30-XSB DIODE
C1QEKJ1CM-226ZE CAPACITOR22uF 16 V M
C2NCB31EK-104XC CAPACITOR0.1uF 25V K
C3NCB31EK-104XC CAPACITOR0.1uF 25V K
C4QERF1AM-227ZE CAPACITOR220uF 10V M
C5QEKJ1HM-104ZE CAPACITOR0.1uF 50V M
C6NCB31EK-104XC CAPACITOR0.1uF 25V K
C9QEKJ1CM-226ZE CAPACITOR22uF 16 V M
C10NCB31EK-104XC CAPACITOR0.1uF 25V K
C11NCB31EK-104XC CAPACITOR0.1uF 25V K
C12QERF1AM-227ZE CAPACITOR220uF 10V M
C28NCB 31 HK-10 3XC CAPACITOR0.01uF 50V K
C30NCB31EK-473XC CAPACITOR0.047uF 25V K
C31QERF1AM-107ZE CAPACITOR100uF 10V M
C32NDC 31HJ-47 0XC CAPACITOR47pF 50V J
C33QEKJ0JM-476ZE CAPACITOR47uF 6. 3V M
C34NCB31EK-473XC CAPACITOR0.047uF 25V K
C35NDC 31HJ-10 0XC CAPACITOR10pF 50V J
C36NDC 31HJ-7R 0XC CAPACITOR7pF 50V J
C37NDC 31HJ-10 0XC CAPACITOR10pF 50V J
C38NCB 31 HK-10 2XC CAPACITOR1000pF 50V K
C39NCB 31 HK-10 2XC CAPACITOR1000pF 50V K
C40QERF1CM-106ZE CAPACITOR10uF 16V M
C41NCB31EK-473XC CAPACITOR0.047uF 25V K
C42NCB 31 HK-10 3XC CAPACITOR0.01uF 50V K
C43QFV61HJ-473ZMF CAPACITOR0.047uF 50V J
C44NCB 31 HK-10 3XC CAPACITOR0.01uF 50V K
Ω
1/10W J
C45NCB31HK-272XC CAP ACITOR2700pF 50V K
C46NCB31H K- 103XC CAPACITOR0.01uF 50V K
C47NCB31H K- 103XC CAPACITOR0.01uF 50V K
C48NCB31E K- 47 3XC CAPACITOR0.047uF 25V K
C49NCB31HK-102XC CAP ACITOR1000pF 50V K
C50NDC31HJ-101XC CAPACITOR100pF 50V J
C51NCB31H K- 103XC CAPACITOR0.01uF 50V K
C81QERF 1H M-105 ZE CAPACITOR1uF 50V M
C82NCB31HK-152XC CAP ACITOR1500pF 50V K
C85NCB31HK-123XC CAPACITOR0.012uF 50V K
C91QERF 1H M-105 ZE CAPACITOR1uF 50V M
C92NCB31HK-152XC CAP ACITOR1500pF 50V K
C95NCB31HK-123XC CAPACITOR0.012uF 50V K
C161QEK J1 H M - 10 5ZE CAPACITOR1uF 50V M
C162QERF1HM-105ZE CAPACITOR1uF 50V M
C163QTE 1H55-225ZE CAPACITOR2.2uF 50V
C165QERF1HM-105ZE CAPACITOR1uF 50V M
C171QEK J1 H M - 10 5ZE CAPACITOR1uF 50V M
C172QERF1HM-105ZE CAPACITOR1uF 50V M
C173QTE 1H55-225ZE CAPACITOR2.2uF 50V
C174QERF1HM-105ZE CAPACITOR1uF 50V M
C175QERF1HM-105ZE CAPACITOR1uF 50V M
C176NCB31HK-473XC CAPACITOR0.047uF 50V K
C177NCB31HK-473XC CAPACITOR0.047uF 50V K
C179QERF1CM-476ZE CAPACITOR47uF 16V M
C181QERF1CM-107ZE CAPACITOR100u F 16V M
C182NCB31EK-104XC CAPACITOR0.1uF 25V K
C184NCB31CK-224XC CAPACITOR0.22uF 16V K
C241QERF1HM-105ZE CAPACITOR1uF 50V M
C242QERF1CM-226ZE CAPACITOR22uF 16V M
C243NCB31EK-473XC CAPACITOR0.047uF 25V K
C245QERF 1HM-224ZE CAPACITOR0.22uF 50V M
C251NCB31HK - 822XC CAPACITOR8200pF 50V K
C252QERF 0JM-476ZE CAPACITOR47uF 6.3V M
C253QERF1CM-106ZE CAPACITOR10uF 16V M
C254NCB31EK-823XC CAPACITOR0.082uF 25V K
C255QERF1CM-476ZE CAPACITOR47uF 16V M
C256NCB31EK-104XC CAPACITOR0.1uF 25V K
C261QERF1HM-225ZE CAPACITOR2.2uF 50V M
C262QERF1HM-225ZE CAPACITOR2.2uF 50V M
C272NDC31HJ-101XC CAPACITOR100pF 50V J
C273NDC31HJ-101XC CAPACITOR100pF 50V J
C274NCB31EK-223XC CAPACITOR0.022uF 25V K
C275NCB31EK-223XC CAPACITOR0.022uF 25V K
C276NCB31EK-223XC CAPACITOR0.022uF 25V K
C277NCB31EK-562XC CAPACITOR5600pF 25V K
C278NCB31EK-123XC CAPACITOR0.012uF 25V K
C279QERF 0JM-476ZE CAPACITOR47uF 6.3V M
C281NCB31EK-823XC CAPACITOR0.082uF 25V K
C298NCB31EK-104XC CAPACITOR0.1uF 25V K
C301QFV 91HJ-474ZMF CAPACITOR0.47uF 50V J
C302QFV 91HJ-474ZMF CAPACITOR0.47uF 50V J
C303NDC31HJ-101XC CAPACITOR100pF 50V J
C304NDC31HJ-101XC CAPACITOR100pF 50V J
C311QFV 91 H J- 474ZMF CAPACITOR0.47uF 50V J
C312QFV 91HJ-474ZMF CAPACITOR0.47uF 50V J
C313NDC31HJ-101XC CAPACITOR100pF 50V J
C314NDC31HJ-101XC CAPACITOR100pF 50V J
C315QERF1HM-225ZE CAPACITOR2.2uF 50V M
C316QERF 1EM-475ZE C APACITOR4.7uF 25V M
C317QERF1CM-226ZE CAPACITOR22uF 16V M
C318QEK J1 H M - 22 5ZE CAPACITOR2.2uF 50V M
C319NCB31EK-104XC CAPACITOR0.1uF 25V K
C320NCB31EK-104XC CAPACITOR0.1uF 25V K
C322NCB21HK - 472XC CAPACITOR4700pF 50V K
C323NCB21HK - 472XC CAPACITOR4700pF 50V K
C324NCB21HK - 472XC CAPACITOR4700pF 50V K
C325NCB21HK - 472XC CAPACITOR4700pF 50V K
C341NCB31EK-104XC CAPACITOR0.1uF 25V K
C367QERF 1EM-475ZE C APACITOR4.7uF 25V M
C368QERF 1EM-475ZE C APACITOR4.7uF 25V M
C387QERF 1EM-475ZE C APACITOR4.7uF 25V M
C388QERF 1EM-475ZE C APACITOR4.7uF 25V M
C701NDC31HJ-220XC CAPACITOR22pF 50V J
C702NDC31HJ-270XC CAPACITOR27pF 50V J
C703NDC31HJ-270XC CAPACITOR27pF 50V J
C704NDC31HJ-8R0XC CAPACITOR8pF 50V J
C705NCB31EK-104XC CAPACITOR0.1uF 25V K
3-13
Page 60
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part NameDescriptionLocal
C706NCB31EK-104XC CAPACITOR0.1uF 25V K
C707NCB31EK-104XC CAPACITOR0.1uF 25V K
C708NCB31EK-104XC CAPACITOR0.1uF 25V K
C709NCB31HK-103XC CAPACITOR0.01uF 50V K
C710QEKJ0JM-476ZE CAPACITOR47uF 6.3V M
C711QERF1AM-227ZE CAPACITOR220uF 10V M
C713NCB31CK-224XC CAPACITOR0.22uF 16V K
C716NCB31EK-104XC CAPACITOR0.1uF 25V K
C717NCB31EK-104XC CAPACITOR0.1uF 25V K
C720NCB31HK-103XC CAPACITOR0.01uF 50V K
C721NCB31HK-103XC CAPACITOR0.01uF 50V K
C722NCB31HK-103XC CAPACITOR0.01uF 50V K
C723NCB31EK-104XC CAPACITOR0.1uF 25V K
C724NCB31EK-104XC CAPACITOR0.1uF 25V K
C725NCB31AK-224XC CAPACITOR0. 22 uF 10V K
C726NCB31EK-104XC CAPACITOR0.1uF 25V K
C727NCB31EK-104XC CAPACITOR0.1uF 25V K
C728ND C31HJ-101XC CAPACITOR100pF 50 V J
C729ND C31HJ-101XC CAPACITOR100pF 50 V J
C730ND C31HJ-101XC CAPACITOR100pF 50 V J
C733NCB31HK-103XC CAPACITOR0.01uF 50V K
C740NCB31EK-104XC CAPACITOR0.1uF 25V K
C741NCB31AK-224XC CAPACITOR0. 22 uF 10V K
C743NCB31AK-334XC CAPACITOR0. 33 uF 10V K
C744NCB31EK-104XC CAPACITOR0.1uF 25V K
C745NCB31AK-334XC CAPACITOR0. 33 uF 10V K
C746NCB31EK-104XC CAPACITOR0.1uF 25V K
C747NCB31EK-473XC CAPACITOR0.047uF 25V K
C771NCB31EK-473XC CAPACITOR0.047uF 25V K
C781QE RF0JM-476ZE CAPACITOR47uF 6.3V M
C782NCB31AK-474XC CAPACITOR0. 47 uF 10V K
C784QERF1CM-107ZE CAPACITOR100uF 16V M
C801NCB31EK-473XC CAPACITOR0.047uF 25V K
C802NCB31HK-472XC CAPACITOR4700pF 50V K
C803NDC31HJ-220XC CAPACITOR22pF 50V J
C804NDC31HJ-220XC CAPACITOR22pF 50V J
C851QERF1CM-106ZE CAPACITOR10uF 16V M
C852NCB31EK-103XC CAPACITOR0. 01 uF 25V K
C881QERF1CM-226ZE CAPACITOR22uF 16V M
C891NCB31EK-104XC CAPACITOR0.1uF 25V K
C901Q EZ0723-338E CAPACITOR3300uF
C902QERF1HM-225ZE CAPACITOR2.2uF 50V M
C903QERF1CM-476ZE CAPACITOR47uF 16V M
C904QERF1CM-106ZE CAPACITOR10uF 16V M
C905QERF1CM-476ZE CAPACITOR47uF 16V M
C906NCB31EK-104XC CAPACITOR0.1uF 25V K
C907QERF1AM-227ZE CAPACITOR220uF 10V M
C908QERF1AM-227ZE CAPACITOR220uF 10V M
C909QERF1AM-227ZE CAPACITOR220uF 10V M
C910QERF1CM-476ZE CAPACITOR47uF 16V M
C911QERF1CM-106ZE CAPACITOR10uF 16V M
C912NCB31EK-104XC CAPACITOR0.1uF 25V K
C914QERF1CM-107ZE CAPACITOR100uF 16V M
C915NCB31CK-104XC CAPACITOR0.1uF 16V K
C916QERF1CM-476ZE CAPACITOR47uF 16V M
C961ND C31HJ-471XC CAPACITOR470pF 50 V J
C962ND C31HJ-471XC CAPACITOR470pF 50 V J
C963ND C31HJ-471XC CAPACITOR470pF 50 V J
C964ND C31HJ-471XC CAPACITOR470pF 50 V J
C965ND C31HJ-471XC CAPACITOR470pF 50 V J
C966ND C31HJ-471XC CAPACITOR470pF 50 V J
C967ND C31HJ-471XC CAPACITOR470pF 50 V J
C968ND C31HJ-471XC CAPACITOR470pF 50 V J
C971NCB31EK-104XC CAPACITOR0.1uF 25V K
R1NRS181J-120XM G R ESISTOR12
R2NRSA63J-473XMG RESISTOR47 k
R4NRSA63J-332XMG RESISTOR3.3k
R5NRSA63J-473XMG RESISTOR47 k
R6NRSA63J-472XMG RESISTOR4.7k
R7NRSA63J-473XMG RESISTOR47 k
R8NRSA63J-103XMG RESISTOR10 k
R9NRSA63J-101XMG RESISTOR10 0
R11N RSA 63 J-103XMG RESISTOR10k
R31N RS1 81 J-100XM G RES ISTOR10
R32N RSA 63 J-622XMG RESISTOR6.2k
R33N RSA 63 J-103XMG RESISTOR10k
R38N RSA 63 J-101XMG RESISTOR100
R714NRS A63J-103XM G R ESISTOR10kΩ 1/16W J
R719NRSA63J-0R0XMG RESISTOR0
R720NRS A63J-122XM G R ESISTOR1.2k
R721NRS A63J-102XM G R ESISTOR1k
R722NRS A63J-103XM G R ESISTOR10k
R723NRS A63J-103XM G R ESISTOR10k
R725NRS A63J-103XM G R ESISTOR10k
R726NRS A63J-103XM G R ESISTOR10k
R728NRS A63J-103XM G R ESISTOR10k
R729NRS A63J-473XM G R ESISTOR47k
R730NRS A63J-103XM G R ESISTOR10k
R731NRS A63J-473XM G R ESISTOR47k
R732NRS A63J-103XM G R ESISTOR10k
R734NRS A63J-222XM G R ESISTOR2.2k
R735NRS A63J-222XM G R ESISTOR2.2k
R736NRS A63J-222XM G R ESISTOR2.2k
R737NRSA63J-0R0XMG RESISTOR0
R738NRS A63J-472XM G R ESISTOR4.7k
R739NRS A63J-472XM G R ESISTOR4.7k
R740NRS A63J-472XM G R ESISTOR4.7k
R741NRS A63J-103XM G R ESISTOR10k
R743NRS A63J-103XM G R ESISTOR10k
R744NRS A63J-103XM G R ESISTOR10k
R745NRS A63J-103XM G R ESISTOR10k
R746NRS A63J-103XM G R ESISTOR10k
R747NRS A63J-472XM G R ESISTOR4.7k
R748NRS A63J-472XM G R ESISTOR4.7k
R749NRS A63J-472XM G R ESISTOR4.7k
R750NRS A63J-103XM G R ESISTOR10k
R751NRS A63J-103XM G R ESISTOR10k
R753NRS A63J-473XM G R ESISTOR47k
R754NRS A63J-821XM G R ESISTOR820
R755NRS A63J-106XM G R ESISTOR10M
R756NRS A63J-473XM G R ESISTOR47k
R757NRS A63J-222XM G R ESISTOR2.2k
R758NRS A63J-473XM G R ESISTOR47k
R759NRS A63J-473XM G R ESISTOR47k
R763NRS A63J-102XM G R ESISTOR1k
R764NRS A63J-101XM G R ESISTOR100
R765NRS 181J-271XMG RESI STO R270
R766NRS A63J-473XM G R ESISTOR47k
R767NRS A63J-473XM G R ESISTOR47k
R770NRS A63J-473XM G R ESISTOR47k
R771NRS A63J-271XM G R ESISTOR270
R772NRS A63J-271XM G R ESISTOR270
R775NRS A63J-473XM G R ESISTOR47k
R776NRS A63J-473XM G R ESISTOR47k
R780NRS A63J-473XM G R ESISTOR47k
R781NRS A63J-473XM G R ESISTOR47k
R783NRS A63J-103XM G R ESISTOR10k
R784NRS A63J-473XM G R ESISTOR47k
R785NRS A63J-222XM G R ESISTOR2.2k
R787NRS A63J-103XM G R ESISTOR10k
R791NRSA63J-0R0XMG RESISTOR0
R792NRSA63J-0R0XMG RESISTOR0
R793NRSA63J-0R0XMG RESISTOR0
R801NRS A63J-473XM G R ESISTOR47k
R802NRS A63J-473XM G R ESISTOR47k
R803NRS A63J-101XM G R ESISTOR100
R804NRS A63J-223XM G R ESISTOR22k
R805NRS A63J-104XMG RESISTOR100k
R806NRS A63J-103XM G R ESISTOR10k
R807NRS A63J-104XMG RESISTOR100k
R808NRS A63J-331XM G R ESISTOR330
R809NRS A63J-223XM G R ESISTOR22k
R810NRS A63J-101XM G R ESISTOR100
R851NRS A63J-103XM G R ESISTOR10k
R881NRS A63J-473XM G R ESISTOR47k
R882NRS A63J-472XM G R ESISTOR4.7k
R891NRS A63J-102XM G R ESISTOR1k
R892NRS A63J-473XM G R ESISTOR47k
R893NRSA63J-0R0XMG RESISTOR0
R901QRE142J-102XC RESISTOR1k
R902NRS A02J-912XM G R ESISTOR9.1k
R903NRS A02J-472XM G R ESISTOR4.7k
R904NRS A02J-221XM G R ESISTOR220
R971NRS 181J-222XMG RESI STO R2.2k
R972NRS 181J-222XMG RESI STO R2.2k
C601NCB31HK-223XC CAPACITOR0.022uF 50V K
C602NCS31HJ-681XC CAPACITOR680pF 50V J
C603NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C611NCB31HK-123XC CAPACITOR0.012uF 50V K
C612NBE20JM-475XTA E CAPACITOR4.7uF 6.3V M
IC501TMP91CW12AF5VD9 IC
IC502BR24L01AFV-W-XIC
IC503SN74AHCT126PW-X IC(DIGITAL)
IC504NJU7241F33-XIC
IC571PCM1753-XIC
IC572NJM4580V-XIC
IC573SN74AHCU04PW-XIC
IC601TA2157FN-XRF AMP IC
IC621TC94A14FAC D LSI IC
IC651NJU7772F15-XIC
IC652TC94A34FG-002IC
IC681BA5830FP-XIC
Q501UN2111- XTRANSISTOR
Q502UN2211-XT R ANSISTOR
Q571UN2111- XTRANSISTOR
Q572UN2211-XT R ANSISTOR
Q5732SB624/4/-XTRANSISTOR
Q574UN2211-XT R ANSISTOR
Q6012SB1132/QR/-WT RANSISTOR
Q6512SB624/4/-XTRANSISTOR
Q652UN2211-XT R ANSISTOR
Q6812SB1184/QR/-XTRANSISTOR
D506MA111-XSI DIODE
D6821SR154-400-XDIODE
C501NCB31HK-103XC CAPACITOR0.01uF 50V K
C502NCB31HK-103XC CAPACITOR0.01uF 50V K
C503NEAG0JM-107XE CAPACITOR100uF 6.3V M
C504NDC3 1HJ-220XC CAPACITOR22pF 50V J
C505NDC3 1HJ-220XC CAPACITOR22pF 50V J
C506NCB31HK-103XC CAPACITOR0.01uF 50V K
C507NCB31HK-103XC CAPACITOR0.01uF 50V K
C508NCB31HK-103XC CAPACITOR0.01uF 50V K
C509NCB31HK-103XC CAPACITOR0.01uF 50V K
C510NCB31HK-103XC CAPACITOR0.01uF 50V K
C511NCB31CK-104XC CAPACITOR0.1uF 16V K
C512NEAG0JM-107XE CAPACITOR100uF 6.3V M
C513NCB31HK-103XC CAPACITOR0.01uF 50V K
C514NCS31HJ-102XC CAPACITOR1000pF 50V J
C551NCB31HK-103XC CAPACITOR0.01uF 50V K
C561NCB31EK-123XC CAPACITOR0. 01 2uF 25V K
C571NDC3 1HJ-270XC CAPACITOR27pF 50V J
C572NDC3 1HJ-270XC CAPACITOR27pF 50V J
C573NCB31CK-104XC CAPACITOR0.1uF 16V K
C574NEAG0JM-107XE CAPACITOR100uF 6.3V M
C575NEAG0JM-107XE CAPACITOR100uF 6.3V M
C577NCB31CK-104XC CAPACITOR0.1uF 16V K
C578NEAG0JM-107XE CAPACITOR100uF 6.3V M
C580NCB31EK-123XC CAPACITOR0. 01 2uF 25V K
C581NDC3 1H J - 101XC C APACITOR100pF 50V J
C582NDC3 1H J - 101XC C APACITOR100pF 50V J
C583NCS31H J -821XC CAPACITOR820p F 50V J
C584NCS31H J -821XC CAPACITOR820p F 50V J
C585NEAG1VM-475XE CAPACIT OR4.7uF 35V M
C586NEAG1VM-475XE CAPACIT OR4.7uF 35V M
C587NDC3 1H J - 151XC C APACITOR150pF 50V J
C588NDC3 1H J - 151XC C APACITOR150pF 50V J
C589NEAG1VM-475XE CAPACIT OR4.7uF 35V M
C590NEAG1VM-475XE CAPACIT OR4.7uF 35V M
C591NEAG0JM-476XE CAPACITOR47uF 6.3V M
C592NEAG0JM-476XE CAPACITOR47uF 6.3V M
C593NEAG1CM-476XE CAPACITOR47uF 16V M
C594NCS31HJ-102XC CAPACITOR1000pF 50V J
C595NCB31C K-473XC CAPACITOR0.047uF 16V K
C596NDC3 1H J - 101XC C APACITOR100pF 50V J
C597NCS31HJ-102XC CAPACITOR1000pF 50V J
C598NCS31HJ-102XC CAPACITOR1000pF 50V J
C601NEAG0JM-476XE CAPACITOR47uF 6.3V M
C602NCB31HK-103XC CAPACITOR0.01uF 50V K
C603NEAG0JM-107XE CAPACITOR100uF 6.3V M
Part No.Part NameDescriptionLocal
3-16
Page 63
Symbol No.
Part No.Part NameDescriptionLocal
Symbol No.
Part No.Part N am eDescriptionLocal
C604NCB31HK-103XC CAPACITOR0.01uF 50V K
C605NCB31HK-682XC CAPACITOR6800pF 50V K
C606NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C607NCB31HK-103XC CAPACITOR0.01uF 50V K
C608NCB31CK-104XC CAPACITOR0.1uF 16V K
C609NCB31CK-104XC CAPACITOR0.1uF 16V K
C610NDC31HJ-5R0XC CAPACITOR5pF 5 0V J
C611NDC31HJ-680XC CAPACITOR68pF 50V J
C612NCB31HK-103XC CAPACITOR0.01uF 50V K
C613NCB31HK-103XC CAPACITOR0.01uF 50V K
C614NCB31HK-103XC CAPACITOR0.01uF 50V K
C616NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C621NCB31HK-103XC CAPACITOR0.01uF 50V K
C622NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C623NDC31HJ-470XC CAPACITOR47pF 50V J
C624NCB31HK-153XC CAPACITOR0.015uF 50V K
C625NCB31HK-103XC CAPACITOR0.01uF 50V K
C626NCB31HK-272XC CAPACITOR2700pF 50V K
C627NCB31HK-103XC CAPACITOR0.01uF 50V K
C628NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C629NCB31EK-333XC CAPACITOR0.033uF 25V K
C630NCB31EK-333XC CAPACITOR0.033uF 25V K
C631NDC31HJ-471XC CAPACITOR470pF 50V J
C632NDC31HJ-471XC CAPACITOR470pF 50V J
C633NCB31CK-473XC CAPACITOR0.047uF 16V K
C634NCB31CK-473XC CAPACITOR0.047uF 16V K
C635NCB31CK-473XC CAPACITOR0.047uF 16V K
C636NCB31CK-473XC CAPACITOR0.047uF 16V K
C637NCB31CK-473XC CAPACITOR0.047uF 16V K
C638NCB31HK-103XC CAPACITOR0.01uF 50V K
C639NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C640NCB31HK-103XC CAPACITOR0.01uF 50V K
C641NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C642NDC31HJ-101XC CAPACITOR100pF 50V J
C643NCB31HK-103XC CAPACITOR0.01uF 50V K
C644NCB 31 AK- 334XC CAPACITOR0.33u F 10V K
C645NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C646NCB31HK-103XC CAPACITOR0.01uF 50V K
C651NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C652NCB31HK-103XC CAPACITOR0.01uF 50V K
C653NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C654NCB31CK-104XC CAPACITOR0.1uF 16V K
C655NCB31HK-103XC CAPACITOR0.01uF 50V K
C656NCB31CK-104XC CAPACITOR0.1uF 16V K
C659NCB31CK-104XC CAPACITOR0.1uF 16V K
C660NDC31HJ-101XC CAPACITOR100pF 50V J
C661NCB31HK-103XC CAPACITOR0.01uF 50V K
C662NDC31HJ-101XC CAPACITOR100pF 50V J
C663NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C664NCB31HK-222XC CAPACITOR2200pF 50V K
C665NCB31EK-104XC CAPACITOR0.1uF 25V K
C666NDC31HJ-101XC CAPACITOR100pF 50V J
C667NCB31HK-103XC CAPACITOR0.01uF 50V K
C668NEA G 0J M - 476XE C APACITOR47uF 6. 3V M
C669NCB31HK-103XC CAPACITOR0.01uF 50V K
C682NEAG1VM-475XE CAPACITOR4.7uF 35V M
C683NCB31CK-104XC CAPACITOR0.1uF 16V K
C684NEAG 1CM-476XE CAPACITOR47 uF 16V M
C689NEAG 1CM-476XE CAPACITOR47 uF 16V M
C690NBE20JM-106XTA E CAPACITOR10uF 6.3V M
C693NEAG 1CM-476XE CAPACITOR47 uF 16V M
R501NRS A63J-102XM G R ESISTOR1k
R502NRS A63J-102XM G R ESISTOR1k
R503NRS A63J-102XM G R ESISTOR1k
R504NRS A63J-101XM G R ESISTOR100
R505NRS A63J-101XM G R ESISTOR100
R506NRS A63J-473XM G R ESISTOR47k
R507NRS A63J-473XM G R ESISTOR47k
R508NRS A63J-473XM G R ESISTOR47k
R509NRS A63J-473XM G R ESISTOR47k
R510NRS A63J-101XM G R ESISTOR100
R511NRSA63J-102XM G R ESISTOR1k
R512NRS A63J-473XM G R ESISTOR47k
R513NRS A63J-102XM G R ESISTOR1k
R514NRS A63J-473XM G R ESISTOR47k
R515NRS A63J-473XM G R ESISTOR47k
R516NRS A63J-102XM G R ESISTOR1k
L501NQL114K-47 0XINDUCITOR47uH K
L502NQL114K-47 0XINDUCITOR47uH K
L572NQL114K-47 0XINDUCITOR47uH K
L621NQL114K-47 0XINDUCITOR47uH K
L622NQL114K-47 0XINDUCITOR47uH K
L623NQL114K-47 0XINDUCITOR47uH K
L651NQL114K-47 0XINDUCITOR47uH K
L652NQL114K-47 0XINDUCITOR47uH K
L653NQL114K-47 0XINDUCITOR47uH K
A 1GET0265-001AINST BOOKENG THAG615U,G615U 2 ,G615UH,G615UH 2
A 1GET0265-003AINST BOOKENG INAG615UN,G61 5UN2
A 1GET0265-007 AINST BOOKENG CHI(TAIWAN)G615UT
A 2GET0265-004AINSTALL MANUALG615U,G615U2,G615UH,G615UH 2
A 2GET0265-006AINSTALL MANUALG615UN,G615UN 2
A 2GET0265-008AINSTALL MANUALG615UT
A 3RM-RK50REMOCON UNIT
A 4------------BATTERY
A 5VKZ4027-202PLUG NUT
A 6VKH4871-003MOUNT BOLT
A 7VKZ4328-00 3LOCK NUT
A 8QYWWS53A0 08ZAWASHER0m m/ 5. 3 m m x
A 9GE40130-00 2AHO O K(x2)
A 10GE20137-003AMOUNTI NG SL EEVE
A 11GE20149-014ATRI M PL ATE
A 12FSJB3002-3 0CHARD CASE
A 13QAM0308-00416P CORD ASSY
A 14GET0265-002AINST BOOKKOR CHI(TAIWAN) ARA PERG615U, G615U2
A 15GET0265-009 AINST BOOKRUSG615U,G615 U 2
A 16GET0265-005 AINSTALL MANUALG615U,G615U2
A 17GET0265-010 AINSTALL MANUALG615U,G615U2
KITSRW-385USCREW PARTS KITA5 A6 A7 A8 A9
P 1GE31468-00 2ACARTON
P 2FSPG4002-001POLY BAG(x2)G615U,G615 U 2
P 2FSPG4002-001POLY BAGG615UH,G615UH2
P 2FSPG4002-001POLY BAGG615UN,G615UN 2, G615UT
P 3QPC030043 15PPOLY BAG3 0cm x 43cm
P 4QPA00801205POLY BAG8cm x 12cm
P 5GE10108-002APAPER CUSHION(x2)
P 6FSYH4036-06 8SHEET
P 7QPA01003003POLY BAG10cm x 30cm
3-21
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
