PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list
CD mechanism assembly and parts list
CD changer mechanism assembly and parts list
Cassette mechanism assembly and parts list
Electrical parts list
Packing materials and accessories parts list
[ MX-J300 ]
3-2
3-5
3-6
3-8
3-9
3-20
Area suffix
J ----------------------------- U.S.A.
C -------------------------- Canada
MX-J300
3-1
MX-J300
Exploded view of general assembly and parts list
Parts list (General assembly)
Item Parts number Parts name Area
A
1 GJ460400090101 KNOB VOLUME 1
2 GJ460400070101 KNOB POWER 1
3 GJ460400100101 KNOB OPEN/CLOS 1
4 GJ460400110101 KNOB MODE 1(CD)
5 GJ460400110101 KNOB MODE 1(AUX)
6 GJ460400120101 KNOB MODE 1(TAPE)
7 GJ460400120101 KNOB MODE 1(AM/FM)
8 GJ460400060101 KNOB CD EJECT 1
9 GJ460400010101 CD TRAY COVER 1(A)
10 GJ460400020101 CD TRAY COVER 1(B)
11 GJ460400030101 CD TRAY COVER 1(C)
12 GJ460400160101 CABINET FRONT 1
13 GJ460400420101 HEAT SINK COVER 1
14 GJ751000030101 DAMPER GEAR 2
15 GJ460170340101 DISC STOP BKT 1
16 GJ460400040104 INDICATOR MODE 1(CD)
17 GJ460400040103 INDICATOR MODE 1(AUX)
18 GJ460400040102 INDICATOR MODE 1(TAPE)
19 GJ460400040101 INDICATOR MODE 1(AM/FM)
20 GJ460400050101 INDICATOR POWER 1
21 GJ460400210101 DOOR CASS L 1
22 GJ460400220101 DOOR CASS R 1
23 GJ460400230101 LENS CASS R 1
24 GJ460400240101 LENS CASS L 1
25 GJ460400080101 LENS DISPLAY 1
26 GJ460170330101 LOGO JVC 1
27 GJ460170350101 HOLDER LED 4
28 GJ460400400101 HOUSING LED 2
29 GJ460400130101 KNOB CONTROL 1
30 GJ460400140101 PANEL ROLLING 1
31 GJ460400150101 COVER ROLLING 1
32 GJ712000250100 SHAFT 1
33 GJ560400010101 BRACKET ROLLING 1
34 GJ560400100101 SHIELD CORE 1
35 GJ460400260101 GEAR HOLDER (L) 1
36 GJ460400270101 GEAR HOLDER (R) 1
37 GJ460400320101 PULLEY 1
38 GJ460400330101 HOLDER A 1
39 GJ460400340101 HOLDER B 1
40 GJ460400280101 ARM 2
41 GJ460400290101 GEAR A 2
42 GJ460400300101 GEAR B 1
43 GJ460400310101 GEAR C 1
44 GJ460400350101 CIRCLE RACK (L) 1
45 GJ460400360101 CIRCLE RACK (R) 1
46 GJ460400410101 CASE 1
47 GJ460400370101 WORM + PULLEY 1
48 GJ460400380101 PANEL HOLDER L 1
Q'ty Description
LED12,LED13,LED14,LED15
Block No. M1MM
3-2
MX-J300
VR EVEKD
NUT M9
WASHER
Parts list
Item Parts number Parts name Area
A
49 GJ460400390101 PANEL HOLDER R 1
50 GJ771000110100 BELT 1
51 560400030101/S/ CASE TOP 1
52 GJ560170090201 CASE BOTTOM 1
53 GJ560400050203 CASE REAR 1
54 GJ780000210100 HEAT SINK 1
55 GJ780000220100 HEAT SINK 1
56 GJ780000180100 HEAT SINK 1
57 GJ560400070101 SHIELD 1
58 GJ560400020101 B. CHANGER 1
59 GJ560400060201 BRACKET IC 1
60 GJ560170110101 BRACKET B 1
61 GJ560400040101 BRACKET DISPLAY 1
62 GJ560170040101 BRACKET PCB 1
63 GJ560170200101 B. CHEAT SINK 1
64 GJ711001600300 S. CASS DOOR L 1
65 GJ711001610200 S. CASS DOOR R 1
66 GJ422253701 SPRING(LOCK) 2
67 GJ460400250101 H. DOOR LOCKER 2
68 GJ422250501 HOLDER LOCK 2
69 GJ796000030000 CORD BUSHING 1
A
70 GJ763000320106 FELT SHEET 4
71 GJ732000010101 CABLE TIE 1
72 G560350030101 HIMELON 2
73 GJ421038001 RIVET/SNAP 1
74 GJ793000060001 SPONGY 2
75 -------------- CD CHANGER 1
76 GJ342020150913 JACK SPK 4PINS 1 J303
77 GJ342030140109 JACK RCA 4PINS 1 J301
78 GJ342040140109 JACK SPK 4PINS 1 J302
79 --------------- MAIN BOARD 1
80 BJ753GN FL DISPLAY 1 FL701
81 MXN-13FB12F MOTOR 1 MO701
82 --------------- DISPLAY BOARD 1
83 --------------- POWER SW. BOARD 1
84 --------------- FUNCTION BOARD (1) 1
85 --------------- FUNCTION BOARD (2) 1
86 --------------- EJRCT SW. BOARD 1
87 --------------- VOLUME BOARD 1
88 GJ299000570003
89 --------------90 --------------91 --------------- MULTICONTROL BOARD 1
92 -------------- H.PHONE JACK BOARD 1
93 GJ34201016011 PHONE JACK 1 J1053
94 --------------- CASSETTE BOARD 1
95 CASSETTE MECHA 1
96 GJ336760060013 1 T951
A
(General assembly)
---------------
Block No. M1MM
Q'ty Description
1 S1001
1
1
POWER TRANS.
Parts list
Item Parts number Parts name Area
A
97 --------------- POWER TRANS. BOARD 1
98 QMPD200-200-JD AC-POWER CORD 1
A
99 GJ560170290101 B. OPENING 1
100 GJ782010070100 RUBBER SHEET 2
101 GJ711001790100 EJECT SPRING L 1
102 GJ711001800100 EJECT SPRING R 1
103 GJ560400240101 SHEILDING PLATE 1
104 GJ370339701 CLAMP 1
105 GJ703200600100 SPECIAL SCREW 2M2X6
106 GJ703200800100 SPECIAL SCREW 22.6PTX8
107 GJ702244260812 SCREW TT2.6X8 2 D. PCB/CASE
108 GJ702244260812 SCREW TT2.6X8 4 ROLLING PANEL
109 GJ702244260812 SCREW TT2.6X8 2 BKT/R. PANEL
110 GJ702244260812 SCREW TT2.6X8 4 CONTROL PCB
111 GJ702244260812 SCREW TT2.6X8 4 G. HOLDER/CASE
112 GJ702244260812 SCREW TT2.6X8 2 HOLDER A
113 GJ702244260812 SCREW TT2.6X8 2 HOLDER B
114 GJ702244260812 SCREW TT2.6X8 3 POWER PCB
115 GJ702244260812 SCREW TT2.6X8 5 MODE PCB
116 GJ702244260812 SCREW TT2.6X8 4 CD EJECT PCB
117 GJ702244300612 SCREW TT3X6 1 B.PCB/CHANGER
118 GJ702244300612 SCREW TT3X6 4 CASS PCB/DECK
119 GJ702244300612 SCREW TT3X6 1 DISC STOP
120 GJ702244300612 SCREW TT3X6 2 H.SINK B./BOTTOM
121 GJ702244300612 SCREW TT3X6 3 HEAT SINK/REAR
122 GJ702244300612 SCREW TT3X6 2 TOP/REAR/BOTTOM
123 GJ702244300612 SCREW TT3X6 1 REAR/BOTTOM
124 GJ702244300612 SCREW TT3X6 4 TOP/REAR CASE
125 GJ702244300612 SCREW TT3X6 1 PCB BKT/REAR
126 GJ702244300612 SCREW TT3X6 1 BOTTOM CASE/PCB
127 GJ702244300612 SCREW TT3X6 1 CLAMP
128 GJ702244300612 SCREW TT3X6 2 EJECT SPRING
129 GJ702244300612 SCREW TT3X6 2 F.CABI/BOTTOM
130 GJ702244300812 SCREW TT3X8 2 TR./HEAT SINK
131 GJ702244300812 SCREW TT3X8 6 DECK/PANEL
132 GJ702244300812 SCREW TT3X8 2 CHANGER/REAR
133 GJ702244300812 SCREW TT3X8 2 HEAT SINK COVER
134 GJ702244300812 SCREW TT3X8 2 STAY B./CHANGER
135 GJ702244300812 SCREW TT3X8 1 H.SINK BKT/REAR
136 GJ702244301012 SCREW TT3X10 5 JACK
137 GJ702244301012 SCREW TT3X10 4 CASE/ROLLING
138 GJ702244301012 SCREW TT3X10 4 STAY BRACKET
139 GJ702244301412 SCREW TT3X14 1 TRANSISTOR/H.SINK
140 GJ702244301812 SCREW TT3X18 2 POWER IC/H.SINK
141 GJ702244300652 SCREW TT3X6 2 TOP/BOTTOM CASE
142 GJ702264400612 SCREW TT4X6 6 X'FORMER
143 GJ703300800202 SCREW SPTT 3X8 1 JACK/PANEL
144 GJ703300802002 SCREW SPTT3X8 2 DECK
(General assembly)
Block No. M1MM
Q'ty Description
ARM/ROLLING PANEL
ARM/CIRCLE RACK
3-3
MX-J300
Exploded view of general assembly and parts list
Block No.
For spring protect
M
5
4
M
1
M
A
A
A
3
2
Accessories
1
3-4
HABC DEFG
CD mechanism assembly and parts list
Grease Point
FG-87HS
(Grease to apply have to be a little for the exchange.)
3
FG-87HS
2
FG-87HS
FG-87HS
Block No.
M
2
MX-J300
M
M
12
1
EXL-M7TMB
EXL-M7MB
ABCD
Parts list ( CD mechanism )
A
Item
1 E102731-221SM MECHA BASE 1
2 OPTIMA-7B OPTICAL PICK UP 1
3 E406777-002SM CD SHAFT 1
4 LV31002-001A CD RACK 1
5 E307745-441SM MECHA GEAR 1
6 QYSDSP2003N SCREW 4
7 E406750-442SM PINION GEAR 1
8 EPB-001PK TURN TABLE 1 SINGLE CD
9 E406784-001 FEED MOTOR 1
10 QAR0130-001 SPPINDLE MOTOR 1
11 EMW10190-441 P.C.BOARD 1
12 QGA2001F1-06 6P PLUG ASSY 1
13 QSW0506-001 LEAF SWITCH 1
14 E75832-221SS SPECIAL SCREW 1
Parts number Parts name
EPB309173PKA TURN TABLE 1 CHANGER CD
Q'ty
Block No. M2MM
Description
Area
3-5
MX-J300
CD changer mechanism assembly and parts list
VC3-21M
Block No.
M
3
M
M
5
F
75
51
21
76
65
G
72
27
27
27
4
34
69
25
3
FIG A
27
FIG A
F
G
27
H
17
2
27
27
Grease = EM-30L
= EBS0006-009B
1
= FL-7750
H
11.6 0.2mm
27
FIG C
FIG B
the same.
3-6
FIG C
Opposite side
FIG B
ABCD
MX-J300
Parts list (CD changer mechanism)
Item Parts number Parts name Area
A
1 VKS1144-003 CHASSIS 1
2 VKS3698-003 TRAY GUIDE 2
3 VKS5532-003 PULLEY GEAR 2
4 VKB3000-164 BELT 2
5 VKS5505-003 GEAR B 2
6 VKS5506-002 GEAR C 3
7 VKS5507-002 CROSS GEAR U 1
8 VKS5508-002 CROSS GEAR L 1
9 VKS5510-003 SELECT LEVER 1
10 VKH5769-001 S.G.SHAFT 1
11 VKS5511-002 SELECT GEAR 1
12 VKW5155-003 COMP.SPRING 1 FOR SELECT GEAR
13 VKM3846-002 GEAR BRACKET 1
14 VKS5509-002MM CYLINDER GEAR 1
15 MSN5D257A-SA2 D.C.MOTOR ASS'Y 2
16 QYSPSPD2616Z SCREW 2 FOR MOTOR
17 LV40612-001A COMP.SPRING 1
18 VKM3825-00AMM C.G.BASE ASS'Y 1
19 VKZ3172-00ASS CAM SW. R ASS'Y 1
20 VKZ3173-00ASS CAM SW. L ASS'Y 1
21 QYSPST2606Z SCREW 4
22 VKS2263-002MM CAM R1 1
23 VKS2264-002MM CAM R2 1
24 VKS2265-002MM CAM GEAR L 1
25 WDL316050MM SLIT WASHER 2
27 QYSBSF2608Z T.SCREW 16
28 VKS3702-00FMM DRIVE UNIT 1
29 VKS2247-004 MECHA HOLDER A 1
30 VKL7767-00B BRACKET ASS'Y 1
31 QYSBSF2606Z SCREW 2 FOR BRACKET
32 VKM3860-00A M.HOLDER B AS'Y 1
33 VKL7802-00C M.HOLDER C AS'Y 1
34 QYSDST2604Z SCREW 3
35 VKL7810-00A LIFTER ASS'Y R 1
36 VKL7811-00A LIFTER ASS'Y L 1
37 VKL7812-00A LIFTER ASS'Y H 1
38 VKL2732-002 LIFTER BASE 1
39 VKM3857-001 LIFTER BRACKET 1
41 WDL266035-2 SLIT WASHER 1
43 VKS5514-002MM LOCK LEVER 3
44 VKY3133-002MM RETURN SPRING 1
46 VKY3134-003MM CLICK SPRING 1
47 VKS2252-00E TRAY ASS'Y 3
48 VKS2250-003 TOP BRACKET 1
49 VKS5515-002 S.TRAY STOPPER 1
50 VKW5156-004 TORSION SPRING 1
51 VKS3703-00G CLAMPER ASS'Y 1
62 LV40761-003A INSULATOR 4
65 --------------- CD MECHA 1
69 QGB2012J1-10 CONNECTOR 1
71 VKW5187-001 ROD 1
72 VYSA1R2-033 SPACER 1 FOR EWS176-008
73 LE30611-001A C.B HOLDER 1 FOR CD CB
74 QYSBSF3008Z SCREW 2 FOR HOLDER
75 QUQ610-1509AJ CARD WIRE 1 TRAVERSE 15
76 EWS176-008 FLAT WIRE 1 TRAVERSE 6
Q'ty Description
Block No. M3MM
3-7
MX-J300
Cassette mechanism assembly and parts list
Unit number : CMAT5Z212A
3
2
Block No.
M
M
3
M
1
ABCD
Parts list ( Cassette mechanism )
A
Item
03-1
03-2
04
06
25
29-1
29-2
30
31-1
31-2
32
42
43
Parts number
F513-852
F513-855
F525-336
F522-060
FF19N-21
FR24Y-11
FR25B-11
FR25A-21
F514-133
F514-135
F514-134
FF19S-31
UE20P-12
PLATE HD BLK
PLATE HD BLK
MTR MAIN BLK
CLUTCH ASSY BLK
MAIN BELT
ASSY F/W
ASSY F/W
ASSY F/W 1
ROLLER PINCH BLK R
ROLLER PINCH BLK R
ROLLER PINCH BLK L
F/R BELT MO
SPLFE L
Parts name
Q'ty
1
1
1
2
2
1
1
1
1
1
2
4
Block No. M3MM
Description
Area
3-8
Electrical parts list
Electrical parts list (Main board)
Item
A
C 1 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 2 GJ116222821 A.CAPACITOR 50V CH J 4.7PF
C 3 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 4 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 5 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 11 GJ116223621 A.CAPACITOR 50V CH J 15PF
C 12 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 13 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 14 GJ111067121 C.CAPACITOR 47000PF F Z 50V
C 15 GJ116222921 A CAPACITOR 50V HC J 5.6PF
C 16 GJ111067121 C.CAPACITOR 47000PF F Z 50V
C 17 GJ116223421 A.CAPACITOR 50V CH J 12PF
C 18 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 19 GJ270111070310 E.CAPACITOR 10V M 100UF
C 20 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 21 GJ116223421 A.CAPACITOR 50V CH J 12PF
C 22 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 25 GJ116228821 A.CAPACITOR 50V B K 330PF
C 26 GJ116229021 A.CAPACITOR 50V B K 470PF
C 27 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 29 GJ264266822101 A.CAPACITOR 16V X M 0.0068UF
C 30 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 31 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 32 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 33 GJ116229521 C.CAPACITOR 1500PF 30% 16V
C 34 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 35 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 36 GJ270111070310 E.CAPACITOR 10V M 100UF
C 37 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 38 GJ283111532432 POL,F.CAPACITOR 100V K 0.015UF
C 39 GJ283111532432 POL,F.CAPACITOR 100V K 0.015UF
C 40 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF
C 41 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF
C 42 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 43 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 44 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 49 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 51 GJ116223421 A.CAPACITOR 50V CH J 12PF
C 52 GJ116223421 A.CAPACITOR 50V CH J 12PF
C 53 GJ270124760310 E.CAPACITOR 16V M 47UF
C 54 GJ282031052415 M.CAPACITOR 50V J 1UF
C 55 GJ283113922432 POL,F.CAPACITOR 100V K 0.0039UF
C 56 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 57 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 58 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 59 GJ270111070310 E.CAPACITOR 10V M 100UF
C 60 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 62 GJ116228221 A.CAPACITOR 50V B K 100PF
C 63 GJ116228221 A.CAPACITOR 50V B K 100PF
C 64 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 65 GJ116219921 A.CAPACITOR 50V SL J 10PF
C 66 GJ116228221 A.CAPACITOR 50V B K 100PF
C 101 GJ116228221 A.CAPACITOR 50V B K 100PF
C 102 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 103 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 104 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 105 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 106 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 107 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 108 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 109 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 110 GJ283118232432 POL,F.CAPACITOR 100V K 0.082UF
C 111 GJ283118232432 POL,F.CAPACITOR 100V K 0.082UF
Parts number Parts name Area
Block No. 01
Remarks
Item
A
C 112 GJ283115622432 POL,F.CAPACITOR 100V K 0.0056UF
C 113 GJ283111242432 POL,F.CAPACITOR 100V K 0.12UF
C 114 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 115 GJ270111070310 E.CAPACITOR 10V M 100UF
C 117 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 118 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 119 GJ116229021 A.CAPACITOR 50V B K 470PF
C 120 GJ116228621 A.CAPACITOR 50V B K 220PF
C 121 GJ270194760310 E.CAPACITOR 50V VX M 47UF
C 122 GJ283111832432 POL,F.CAPACITOR 100V K 0.0018UF
C 123 GJ116219921 A.CAPACITOR 50V SL J 10PF
C 124 GJ270191070310 E.CAPACITOR 50V M 100UF
C 125 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 126 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 128 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 130 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 201 GJ116228221 A.CAPACITOR 50V B K 100PF
C 202 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 203 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 204 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 205 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 206 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 207 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 208 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 209 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 210 GJ283118232432 POL,F.CAPACITOR 100V K 0.082UF
C 211 GJ283118232432 POL,F.CAPACITOR 100V K 0.082UF
C 212 GJ283115622432 POL,F.CAPACITOR 100V K 0.0056UF
C 213 GJ283111242432 POL,F.CAPACITOR 100V K 0.12UF
C 214 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 215 GJ270111070310 E.CAPACITOR 10V M 100UF
C 217 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 218 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 219 GJ116229021 A.CAPACITOR 50V B K 470PF
C 220 GJ116228621 A.CAPACITOR 50V B K 220PF
C 221 GJ270194760310 E.CAPACITOR 50V VX M 47UF
C 222 GJ283111832432 POL,F.CAPACITOR 100V K 0.0018UF
C 223 GJ116219921 A.CAPACITOR 50V SL J 10PF
C 224 GJ270191070310 E.CAPACITOR 50V M 100UF
C 225 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 226 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 228 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 230 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 301 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 302 GJ270111070310 E.CAPACITOR 10V M 100UF
C 303 GJ270124760310 E.CAPACITOR 16V M 47UF
C 304 GJ283111222432 POL,F.CAPACITOR 100V K 0.0012UF
C 305 GJ283111042432 POL,F.CAPACITOR 100V K 0.1UF
C 306 GJ270121060310 E.CAPACITOR 16V VX M 10UF
C 307 GJ116228221 A.CAPACITOR 50V B K 100PF
C 308 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 309 GJ270124760310 E.CAPACITOR 16V M 47UF
C 310 GJ270111070310 E.CAPACITOR 10V M 100UF
C 311 GJ270124760310 E.CAPACITOR 16V M 47UF
C 312 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 313 GJ270124760310 E.CAPACITOR 16V M 47UF
C 314 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 315 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 316 GJ270124760310 E.CAPACITOR 16V M 47UF
C 318 GJ270122260310 E.CAPACITOR 16V M 22UF
C 319 GJ270121080110 E.CAPACITOR 16V M 1000UF
C 320 GJ270111070310 E.CAPACITOR 10V M 100UF
C 321 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
Parts number Parts name Area
MX-J300
Remarks
3-9
MX-J300
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list (Main board)
Item
A
C 322 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 323 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 324 GJ270112270310 E.CAPACITOR 10V M 220UF
C 325 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 326 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 327 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 328 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 329 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 330 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 331 GJ270191050310 E.CAPACITOR 50V VX M 1UF
C 364 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 381 GJ116259621 A.CAPACITOR 25V F Z 0.022UF
C 901 GJ283116832432 POL,F.CAPACITOR 100V K 0.0068UF
C 902 GJ283116832432 POL,F.CAPACITOR 100V K 0.0068UF
C 903 GJ283116832432 POL,F.CAPACITORA100V K 0.0068UF
C 904 GJ283116832432 POL,F.CAPACITORA100V K 0.0068UF
C 905 GJ270193380610 E.CAPACITOR 50V SM M 3300UF
C 906 GJ270193380610 E.CAPACITOR 50V SM M 3300UF
C 907 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 908 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 909 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 910 GJ116415921 C.CAPACITOR 0.1MF F Z 50V
C 911 GJ270144780110 E.CAPACITOR 25V M 4700UF
C 912 GJ270304760314 E.CAPACITOR 63V VX M 47UF
C 913 GJ270192260310 E.CAPACITOR 50V VX M 22UF
C 914 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 915 GJ270192260310 E.CAPACITOR
C 916 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 917 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF
A
C 918 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 919 GJ270111070310 E.CAPACITOR 10V M 100UF
C 920 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 921 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 922 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 923 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 924 GJ270124760310 E.CAPACITOR 16V M 47UF
C 925 GJ270112260310 E.CAPACITOR 10V M 22UF
CF 1 GJ178140611 CERAMIC FILTER SFE10.7MS3GA
CF 2 GJ178140611 CERAMIC FILTER SFE10.7MS3GA
CF 3 CDA10.7MG80A DESCRIMINATOR GJ178117111
CN301 GJ340022090108 CONNECTOR 9PIN
CN302 GJ340072040102 CONNECTOR 4PINS
CN303 GJ340022190108 CONNECTOR 19PIN
CN304 GJ340022150108 CONNECTOR 15PIN
CN305 GJ340022130108 CONNECTOR 13PIN
CN91A GJ340072040102 CONNECTOR 4PINS
CN91B GJ340072050102 CONNECTOR 5PINS
D 1 1SS133T-77 DIODE GJ871999133
D 2 1SS133T-77 DIODE GJ871999133
D 3 1SS133T-77 DIODE GJ871999133
D 4 1SS133T-77 DIODE GJ871999133
D 5 SVC203SPA-JV-T DIODE GJ310050080104
D 6 SVC203SPA-JV-T DIODE GJ310050080104
D 7 1SS133T-77 DIODE GJ871999133
D 8 1SS133T-77 DIODE GJ871999133
D 9 1SS133T-77 DIODE GJ871999133
D 10 1SS133T-77 DIODE GJ871999133
D 11 1SS133T-77 DIODE GJ871999133
D 12 1SS133T-77 DIODE GJ871999133
D 301 MTZJ5.1A ZENER DIODE GJ871992333
D 302 1SS133T-77 DIODE GJ871999133
D 303 1SS133T-77 DIODE GJ871999133
D 304 1SS133T-77 DIODE GJ871999133
Parts number Parts name Area
Block No. 01
Remarks
50V VX M 22UF
Item
A
D 305 1SS133T-77 DIODE GJ871999133
D 307 1SS133T-77 DIODE GJ871999133
D 308 1SS133T-77 DIODE GJ871999133
D 309 1SS133T-77 DIODE GJ871999133
D 311 1SS133T-77 DIODE GJ871999133
D 312 1N4003S-P DIODE GJ310020300203
D 314 1SS133T-77 DIODE GJ871999133
D 315 1SS133T-77 DIODE GJ871999133
D 316 1SS133T-77 DIODE GJ871999133
D 317 1SS133T-77 DIODE GJ871999133
D 318 1SS133T-77 DIODE GJ871999133
D 901 TS6B02G DIODE
A
D 902 1N4003S-P DIODE
A
D 903 1N4003S-P DIODE
A
D 904 1N4003S-P DIODE
A
D 905 1N4003S-P DIODE
A
D 906 1N4003S-P DIODE GJ310020300203
D 907 MTZJ33C-T77 ZENER DIODE GJ871998334
D 908 MTZJ6.2A-T77 ZENER DIODE GJ871992341
D 909 1SS133T-77 DIODE GJ871999133
D 910 MTZJ6.2A-T77 ZENER DIODE GJ871992341
D 911 MTZJ5.6C ZENER DIODE GJ871992339
D 912 MTZJ13C ZENER DIODE GJ871992385
D 913 MTZJ12C ZENER DIODE GJ871992381
D 914 1SS133T-77 DIODE GJ871999133
D 915 MTZJ6.8B ZENER DIODE GJ871992346
D 916 MTZJ10A ZENER DIODE GJ871992370
FW303 GJ353190150110 CABLE 19PIN
IC 1 TA2104BN IC GJ313020351101
IC 2 LC72136N IC GJ313070221000
IC301 TDA7442D IC GJ313070511342
IC302 BA15218DIP IC GJ313010023103
IC303 BA15218DIP IC GJ313010023103
IC304 STK402-120 IC GJ313040561406
J 301 GJ342030140109 JA CK RCA 4PINS
J 302 GJ342040140109 JA CK SPK 4 PIN
J 303 GJ342020150913 JA CK SPK 4PINS
L 1 VQC1505-002S COIL GJ320020260109
L 2 GJ320050190103 C O I L
L 6 GJ320020270109 C O I L
L 8 GJ141052131 MICRO INDUCTOR 100UH 5%
L 9 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 10 GJ141414631 INDUCTOR 2.2UH 5%
L 51 GJ141033631 INDUCTOR 220UH 10%
L 101 GJ320080170105 COIL SPRING
L 201 GJ320080170105 COIL SPRING
L 301 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 302 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 303 GJ241131001301 F.BEAD INDUCTOR 10UH
L 304 GJ141039721 F.BEAD INDUCTOR 1.1UH
LC 1 GJ123671122 FILTER
Parts number Parts name Area
GJ310020320223
GJ310020300203
GJ310020300203
GJ310020300203
GJ310020300203
1 2SC1923(O) TRANSISTOR GJ312010162201
5 DTC114YSTP TRANSISTOR GJ872990437
6 DTC114YSTP TRANSISTOR GJ872990437
7 DTA114YSTP TRANSISTOR GJ872990281
8 DTC114YSTP TRANSISTOR GJ872990437
102 KTC3199TPGR TRANSISTOR GJ312030111210
103 2SD2144S/VW/-T TRANSISTOR GJ872992241
104 2SA1175TP-F TRANSISTOT GJ872910154
105 2SD2144S/VW/-T TRANSISTOR GJ872992241
202 KTC3199TPGR TRANSISTOR GJ312030111210
203 2SD2144S/VW/-T TRANSISTOR GJ872992241
204 2SA1175TP-F TRANSISTOT GJ872910154
Remarks
3-10
MX-J300
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list (Main board)
Item
A
R 1 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 2 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 11 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 12 GJ250084742103 CARBON RESISTOR 1/6W J 470K
R 13 GJ250085602103 CARBON RESISTOR 1/6W J 56
R 14 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 15 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 16 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 17 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 18 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 19 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 21 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 22 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 23 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 24 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 25 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 26 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 27 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 51 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 52 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 53 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 54 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 55 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 56 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 57 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 58 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 59 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 60 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 61 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 62 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 63 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 64 GJ250084732103 CARBON RESISTOR 1/6W J 47K
Parts number Parts name Area
205 2SD2144S/VW/-T TRANSISTOR GJ872992241
301 KTC3199TPGR TRANSISTOR GJ312030111210
302 KTC3199TPGR TRANSISTOR GJ312030111210
303 2SA1175TP-F TRANSISTOT GJ872910154
304 DTC114ESTP TRANSISTOR GJ872902967
305 DTA114ES TRANSISTOR GJ872902921
306 DTA114ES TRANSISTOR GJ872902921
307 KTC3199TPGR TRANSISTOR GJ312030111210
308 KTC3199TPGR TRANSISTOR GJ312030111210
309 KTC3199TPGR TRANSISTOR GJ312030111210
310 2SC945/QP/-T TRANSISTOR GJ872914245
311 DTC114ESTP TRANSISTOR GJ872902967
312 KTC3199TPGR TRANSISTOR GJ312030111210
313 KTC3199TPGR TRANSISTOR GJ312030111210
314 KTC3199TPGR TRANSISTOR GJ312030111210
901 2SA943/R/ TRANSISTOR GJ872999343
902 DTC114YSTP TRANSISTOR GJ872990437
903 DTC114YSTP TRANSISTOR GJ872990437
904 2SB1375 TRANSISTOR GJ872920960
905 KTC3199TPGR TRANSISTOR GJ312030111210
906 KTC3199TPGR TRANSISTOR GJ312030111210
907 2SB1375 TRANSISTOR GJ872920960
908 2SA1175TP-F TRANSISTOT GJ872910154
909 DTA114TS TRANSISTOR GJ872990435
910 DTC114TSTP TRANSISTOR GJ872990440
911 KTC3199TPGR TRANSISTOR GJ312030111210
912 DTC114YSTP TRANSISTOR GJ872990437
913 2SA1175TP-F TRANSISTOT GJ872910154
914 KTC3199TPGR TRANSISTOR GJ312030111210
915 2SB1375 TRANSISTOR GJ872920960
916 KTC3199TPGR TRANSISTOR GJ312030111210
Block No. 01
Remarks
Item
A
R 65 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 67 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 68 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 69 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 70 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 71 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 72 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 101 GJ250083932103 CARBON RESISTOR 1/6W J 39K
R 102 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 106 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 107 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 108 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 109 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 110 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 111 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 112 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 113 GJ250081242103 CARBON RESISTOR 1/6W J 120K
R 114 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 115 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 116 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 117 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 118 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 119 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 120 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 121 GJ250086812103 CARBON RESISTOR 1/6W J 680
R 122 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 123 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 124 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 125 GJ252561081708 RESISTOR
A
R 126 GJ252561081708 RESISTOR
A
R 127 GJ255051512601 FUSE RESISTOR
A
R 128 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 129 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 130 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 131 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 132 GJ255053912601 RESISTOR 390 OHM 1/4W 5%
R 133 GJ255053912601 RESISTOR 390 OHM 1/4W 5%
R 134 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 136 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 137 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 138 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 139 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 140 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 141 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 142 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 150 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 151 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 181 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 201 GJ250083932103 CARBON RESISTOR 1/6W J 39K
R 202 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 206 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 207 GJ250082732103 CARBON RESISTOR 1/6W J 27K
R 208 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 209 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R 210 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R 211 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 212 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 213 GJ250081242103 CARBON RESISTOR 1/6W J 120K
R 214 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 215 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 216 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 217 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 218 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
Parts number Parts name Area
Remarks
2W K 0.1
2W K 0.1
150 OHM 1/4W 5%
3-11
MX-J300
Electrical parts list (Main board)
Item
A
R 219 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 220 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 221 GJ250086812103 CARBON RESISTOR 1/6W J 680
R 222 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 223 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 224 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R 225 GJ252561081708 RESISTOR 2W K 0.1
R 226 GJ252561081708 RESISTOR 2W K 0.1
R 227 GJ255051512601 FUSE RESISTOR
A
R 228 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 229 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 230 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 231 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 232 GJ255053912601 RESISTOR 390 OHM 1/4W 5%
R 233 GJ255053912601 RESISTOR 390 OHM 1/4W 5%
R 234 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 236 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 237 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 238 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 239 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 240 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 241 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 242 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 250 GJ250082202103 CARBON RESISTOR 1/6W J 22
R 251 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 281 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 301 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 302 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 303 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 304 GJ250084702103 CARBON RESISTOR 1/6W J 47
R 305 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 306 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 307 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 308 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 309 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 310 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 311 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 312 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 313 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 314 GJ250084742103 CARBON RESISTOR 1/6W J 470K
R 315 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 316 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 321 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 322 GJ250081502103 CARBON RESISTOR 1/6W J 15
R 323 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 324 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 325 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 326 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 327 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 328 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 329 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 330 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 331 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 332 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 333 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 334 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 335 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 336 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 337 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 338 GJ250081812103 CARBON RESISTOR 1/6W J 180
R 339 GJ250081532103 CARBON RESISTOR 1/6W J 15K
R 340 GJ250083302103 CARBON RESISTOR 1/6W J 33
R 341 GJ250082212103 CARBON RESISTOR 1/6W J 220
Parts number Parts name Area
Block No. 01
Remarks
150 OHM 1/4W 5%
Item
A
R 342 GJ250088212103 CARBON RESISTOR 1/6W J 820
R 343 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 344 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 901 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 902 GJ255051012601 FUSE RESISTOR
A
R 903 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 904 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 905 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 906 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 907 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 908 GJ255052292601 FUSE RESISTOR
A
R 909 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 910 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 911 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 912 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 913 GJ250084712103 CARBON RESISTOR 1/6W J 470
R 914 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 915 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 916 GJ250081092103 CARBON RESISTOR 1/6W J 1
R 917 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 918 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 928 GJ250083302103 CARBON RESISTOR 1/6W J 33
R 929 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 930 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 931 GJ250081022103 CARBON RESISTOR 1/6W J 1K
RY301 GJ151592111 RELAY 12V
T 2 GJ123388511 IFT
X 1 VCX5044-001 X'TAL GJ361000130003
Parts number Parts name Area
100 OHM 1/4W 5%
2.2 OHM 1/4W 5%
Remarks
3-12
MX-J300
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list (Dispiay board)
Item
A
C 701 GJ116415921 C.CAPACITOR 0.1MF F Z % 50V
C 702 GJ112689891 E.CAPACITOR 220MF 20% 10V
C 703 GJ112691651 E.CAPACITOR 1000MF 20% 6.3V
C 705 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 706 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 707 GJ116221321 A.CAPACITOR 50V SL J 39PF
C 708 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 709 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 710 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 711 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 712 GJ116220721 A.CAPACITOR 50V SL J 22PF
C 713 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 714 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 715 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 716 GJ270114760310 E.CAPACITOR 10V M 47UF
C 717 GJ116415921 C.CAPACITOR 0.1MF F Z % 50V
C 718 GJ270192260310 E.CAPACITOR 50V M 22UF
C 719 GJ270192260310 E.CAPACITOR 50V M 22UF
C 720 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 721 GJ270111070310 E.CAPACITOR 10V M 100UF
C 722 GJ270112270310 E.CAPACITOR 10V VX M 220UF
C 723 GJ270191050310 E.CAPACITOR 50V M 1UF
CN701 GJ340021130108 CONNECTOR 13PIN
CN702 GJ340021150308 CONNECTOR 15PIN
CN703 GJ345252020109 W A F E R 2PINS
CN704 GJ340021160108 CONNECTOR 16PIN
CN705 GJ340121050108 CONNECTOR 5PIN
CN706 GJ340072030102 CONNECTOR 3PINS
CN707 GJ340072040102 CONNECTOR 4PINS
CN708 GJ340072050102 CONNECTOR 5PINS
D 701 1SS133T-77 DIODE GJ871999133
D 702 1SS133T-77 DIODE GJ871999133
D 703 1SS133T-77 DIODE GJ871999133
D 704 1SS133T-77 DIODE GJ871999133
FL701 BJ753GN DISPLAY GJ373020031110
FW701 GJ353130280110 CABLE FFC/FPC 13PINS
FW702 GJ353150230110 CABLE FFC/FPC 15PINS
FW703 GJ353050150207 CABLE FFC/FPC 5PIN
IC701 MN101C35DYA IC GJ313010661223
IC702 GP1U291Q IC GJ313010661005
IC703 TA8409S IC GJ313080291401
L 701 GJ141033031 INDUCTOR 22UH 10%
L 702 GJ141050931 INDUCTOR 10UH 5%
L 703 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 704 GJ141039721 F.BEAD INDUCTOR 1.1UH
L 707 GJ141050931 INDUCTOR 10UH 5%
L 708 GJ141050931 INDUCTOR 10UH 5%
MO701 MXN-13FB12F MOTOR GJ38102029003
NC703 GJ354005120100 WIRE KIT 2PINS
Parts number Parts name Area
701 KTC3199/GL/-T TRANSISTOR GJ312030111210
702 KTC3199/GL/-T TRANSISTOR GJ312030111210
703 KTC3199/GL/-T TRANSISTOR GJ312030111210
704 2SC2668(O) TRANSISTOR GJ312020351201
705 2SC2668(O) TRANSISTOR GJ312020351201
706 2SA1175/F/ TRANSISTOR GJ872910154
707 DTA114ES TRANSISTOR GJ872902921
708 DTA114ES TRANSISTOR GJ872902921
709 DTA114ES TRANSISTOR GJ872902921
710 DTA114ES TRANSISTOR GJ872902921
711 DTA114ES TRANSISTOR GJ872902921
712 KTC3199/GL/-T TRANSISTOR GJ312030111210
713 DTC114YSTP TRANSISTOR GJ872990437
714 DTC114YSTP TRANSISTOR GJ872990437
Block No. 02
Remarks
Item
A
R 701 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 702 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 703 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 704 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 705 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 706 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 707 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 708 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 709 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 710 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 711 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 712 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 713 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 714 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 715 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 716 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 717 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 718 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 719 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 720 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 721 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 722 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 723 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 724 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 725 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 726 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 727 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 728 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 729 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 730 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 731 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 732 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 733 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 734 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 735 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 736 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 737 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 738 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 739 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 740 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 741 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 742 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 743 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 744 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R 745 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 746 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 747 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 748 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 749 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 750 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 751 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 752 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 753 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 754 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 755 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 756 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 757 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 758 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 759 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 760 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 761 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 762 GJ250081032103 CARBON RESISTOR 1/6W J 10K
Parts number Parts name Area
715 DTC114YSTP TRANSISTOR GJ872990437
Remarks
3-13
MX-J300
Electrical parts list
Item
A
R 763 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 764 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 765 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 766 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 767 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 768 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 769 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 770 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 771 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 772 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 773 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 774 GJ250081822103 CARBON RESISTOR 1/6W J 1.8K
R 775 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 776 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 778 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 779 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 780 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 781 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 782 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 783 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 784 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 785 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 786 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 787 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 788 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 789 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 790 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 791 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 792 GJ250083312103 CARBON RESISTOR 1/6W J 330
R 793 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 794 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 795 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 796 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 797 GJ250083392103 CARBON RESISTOR 1/6W J 3.3
R 798 GJ250083912103 CARBON RESISTOR 1/6W J 390
R 799 GJ250081512103 CARBON RESISTOR 1/6W J 150
RA701 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA702 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA703 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA704 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA705 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA706 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA707 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA708 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA709 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA710 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA711 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA712 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA713 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA714 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA715 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA716 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA717 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA718 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA719 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA720 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA721 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA722 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA723 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA724 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA725 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA726 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA727 GJ250082242103 CARBON RESISTOR 1/6W J 220K
Parts number Parts name Area
(Display board)
Block No. 02
Remarks
Item
A
RA728 GJ250082242103 CARBON RESISTOR 1/6W J 220K
RA729 GJ250082242103 CARBON RESISTOR 1/6W J 220K
R1037 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R1038 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R1039 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R1040 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R1041 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R1042 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R1043 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R1044 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1045 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1046 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1047 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R1048 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R1049 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1050 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R1051 GJ250084732103 CARBON RESISTOR 1/6W J 47K
X 701 CSA8.00MTZ 200 RESONATOR GJ178159811
X 702 GJ361000230009 CRYSTAL 32.768KHZ
Electrical parts list
A
Electrical parts list
A
Electrical parts list
A
Parts number Parts name Area
(Power switch board)
Item
Parts number Parts name Area
LED11 GJ374301012101 LED
R1006 GJ250086812103 CARBON RESISTOR 1/6W J 680
S1001 SOA-123HS TACT SWITCH GJ390110181120
W1002 GJ353030140107 CABLE FLAT 3PINS
(Function board 1)
Item
Parts number Parts name Area
LED12 SLR-342MCT32 LED GJ374301022103
LED13 SLR-342MCT32 LED GJ374301022103
R1001 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1002 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1003 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1007 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1008 GJ250083312103 CARBON RESISTOR 1/6W J 330
S1002 SOA-123HS TACT SWITCH GJ390110181120
S1003 SOA-123HS TACT SWITCH GJ390110181120
S1004 SOA-123HS TACT SWITCH GJ390110181120
W1001 GJ353050150107 FLAT CABLE 5PINS
(Function board 2)
Item
Parts number Parts name Area
LED14 SLR-342MCT32 LED GJ374301022103
LED15 SLR-342MCT32 LED GJ374301022103
R1009 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1017 GJ250083312103 CARBON RESISTOR 1/6W J 330
R1018 GJ250083312103 CARBON RESISTOR 1/6W J 330
S1005 SOA-123HS TACT SWITCH GJ390110181120
S1006 SOA-123HS TACT SWITCH GJ390110181120
W1003 GJ353040150107 FLAT CABLE 4PINS
Remarks
Block No. 03
Remarks
Block No. 04
Remarks
Block No. 05
Remarks
3-14
MX-J300
Electrical parts list
Item
A
R1010 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1011 GJ250086812103 CARBON RESISTOR
R1012 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1013 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1014 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1015 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
S1007 SOA-123HS TACT SWITCH GJ390110181120
S1008 SOA-123HS TACT SWITCH GJ390110181120
S1009 SOA-123HS TACT SWITCH GJ390110181120
S1010 SOA-123HS TACT SWITCH GJ390110181120
S1011 SOA-123HS TACT SWITCH GJ390110181120
S1012 SOA-123HS TACT SWITCH GJ390110181120
W1004 GJ353020120107 CABLE FLAT 2PINS
Parts number Parts name Area
Electrical parts list
Item
A
C1001 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C1002 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
S1001 GJ299000570003 VR EVEKD
W1005 GJ353030080107 FLAT CABLE 3PINS
Parts number Parts name Area
Electrical parts list
Item
A
CN709 GJ340121050108 CONNECTOR 5PIN
R1019 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1020 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1021 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1022 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1023 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1024 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1025 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R1026 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R1027 GJ250081232103 CARBON RESISTOR 1/6W J 12K
R1028 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1029 GJ250086812103 CARBON RESISTOR 1/6W J 680
R1030 GJ250088212103 CARBON RESISTOR 1/6W J 820
R1031 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R1032 GJ250081522103 CARBON RESISTOR 1/6W J 1.5K
R1033 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R1034 GJ250082722103 CARBON RESISTOR 1/6W J 2.7K
R1035 GJ250085622103 CARBON RESISTOR 1/6W J 5.6K
R1036 GJ250081232103 CARBON RESISTOR 1/6W J 12K
S1002 GJ390030211108 PUSH SWITCH CLOSE
S1003 GJ390030191108 PUSH SWITCH OPEN
S1013 SOA-123HS TACT SWITCH GJ390110181120
S1014 SOA-123HS TACT SWITCH GJ390110181120
S1015 SOA-123HS TACT SWITCH GJ390110181120
S1016 SOA-123HS TACT SWITCH GJ390110181120
S1017 SOA-123HS TACT SWITCH GJ390110181120
S1018 SOA-123HS TACT SWITCH GJ390110181120
S1019 SOA-123HS TACT SWITCH GJ390110181120
S1020 SOA-123HS TACT SWITCH GJ390110181120
S1021 SOA-123HS TACT SWITCH GJ390110181120
S1022 SOA-123HS TACT SWITCH GJ390110181120
S1023 SOA-123HS TACT SWITCH GJ390110181120
S1024 SOA-123HS TACT SWITCH GJ390110181120
S1025 SOA-123HS TACT SWITCH GJ390110181120
S1026 SOA-123HS TACT SWITCH GJ390110181120
S1027 SOA-123HS TACT SWITCH GJ390110181120
S1028 SOA-123HS TACT SWITCH GJ390110181120
S1029 SOA-123HS TACT SWITCH GJ390110181120
S1030 SOA-123HS TACT SWITCH GJ390110181120
S1031 SOA-123HS TACT SWITCH GJ390110181120
Parts number Parts name Area
(Eject switch board)
(Volume board)
(Multicontrol board)
1/6W J 680
Block No. 08
Block No. 06
Remarks
Block No. 07
Remarks
Remarks
Electrical parts list
Item
A
C1051 GJ116229421 A.CAPACITOR 50V B K 1000PF
C1052 GJ116229421 A.CAPACITOR 50V B K 1000PF
J1053 GJ342010160111 PHONE JACK
L1051 GJ141033231 INDUCTOR 47UH 10%
L1052 GJ141033231 INDUCTOR 47UH 10%
L1053 GJ141039721 F.BEAD INDUCTOR 1.1UH
W1051 GJ353040350107 FLAT CABLE 4PINS
Parts number Parts name Area
(H.phone jack board)
Block No. 09
Remarks
3-15
MX-J300
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Q
Electrical parts list
Item
A
C 351 GJ270192250310 E.CAPACITOR 50V VX M 2.2UF
C 352 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 353 GJ270114760310 E.CAPACITOR 10V M 47UF
C 354 GJ270124760310 E.CAPACITOR 16V M 47UF
C 355 GJ116229321 A.CAPACITOR 50V B K 820PF
C 357 GJ283111532432 CAPACITOR 100V K 0.015UF
C 359 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 360 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 361 GJ283116822432 CAPASITER 100V K 0.0068UF
C 362 GJ283115622432 CAPACITOR 100V K 0.0056UF
C 363 GJ283115622432 CAPACITOR 100V K 0.0056UF
C 364 GJ111067121 C.CAPACITOR 47000PF F Z 50V
C 365 GJ270111070310 E.CAPACITOR 10V M 100UF
C 369 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 370 GJ270121070310 E.CAPACITOR 16V VX M 100UF
C 371 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 372 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 373 GJ116230621 A.CAPACITOR 16V Y M 0.01UF
C 401 GJ116229121 A.CAPACITOR 50V B K 560PF
C 402 GJ116229121 A.CAPACITOR 50V B K 560PF
C 403 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 404 GJ283111832432 CAPACITOR 100V K 0.018UF
C 405 GJ270111070310 E.CAPACITOR 10V M 100UF
C 406 GJ116228621 A.CAPACITOR 50V B K 220PF
C 407 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 408 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 409 GJ264261822101 A.CAPACITOR 16V X M 0018UF
C 410 GJ264263322101 A.CAPACITOR 16V X M 0.0033U
C 411 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 412 GJ283115632432 CAPACITOR 100V K 0.056UF
C 414 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 415 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 416 GJ270192240310 E.CAPACITOR 50V VX M 0.22UF
C 417 GJ116229021 A.CAPACITOR 50V B K 470PF
C 418 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 419 GJ116221521 A.CAPACITOR 50V SL J 47PF
C 501 GJ116229121 A.CAPACITOR 50V B K 560PF
C 502 GJ116229121 A.CAPACITOR 50V B K 560PF
C 503 GJ116221121 A.CAPACITOR 50V SL J 33PF
C 504 GJ283111832432 CAPACITOR 100V K 0.018UF
C 505 GJ270111070310 E.CAPACITOR 10V M 100UF
C 506 GJ116228621 A.CAPACITOR 50V B K 220PF
C 507 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 508 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 509 GJ264261822101 A.CAPACITOR 16V X M 0018UF
C 510 GJ264263322101 A.CAPACITOR 16V X M 0.0033U
C 511 GJ270141060310 E.CAPACITOR 25V VX M 10UF
C 512 GJ283115632432 CAPACITOR 100V K 0.056UF
C 514 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 515 GJ270144750310 E.CAPACITOR 25V VX M 4.7UF
C 516 GJ270192240310 E.CAPACITOR 50V VX M 0.22UF
C 517 GJ116229021 A.CAPACITOR 50V B K 470PF
C 518 GJ116229421 A.CAPACITOR 50V B K 1000PF
C 519 GJ116221521 A.CAPACITOR 50V SL J 47PF
CN351 GJ340022090108 CONNECTOR 9PIN
CN352 GJ340022160108 CONNECTOR 16PIN
CN353 GJ340022130108 CONNECTOR 13 PIN
CN354 GJ158015511 HEADER 3PINS
C9101 GJ116228621 A.CAPACITOR 50V B K 220PF
C9102 GJ116230621 A CAPACITOR 16V Y M 0.01UF
D 353 1SS133T-77 DIODE GJ871999133
D 354 1SS133T-77 DIODE GJ871999133
FW351 GJ353090220110 CABLE FFC/FPC 9PINS
Parts number Parts name Area
(Casstte amplifier board)
Block No. 10
Remarks
Item
A
FW352 GJ353160230110 CABLE FFC/FPC 16PINS
FW353 GJ353130240110 CABLE FFC/FPC 13PINS
IC401 BA3126N IC GJ313030301403
IC402 TA8189N IC GJ875924258
L 351 GJ320060040105 COIL
R 351 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 352 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 353 GJ250081052103 CARBON RESISTOR 1/6W J 1M
R 354 GJ250082212103 CARBON RESISTOR 1/6W J 220
R 355 GJ250081032103 CARBON RESISTOR 1/6W J 10K
F
F
R 357 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 358 GJ250081832103 CARBON RESISTOR 1/6W J 18K
R 359 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 360 GJ250081002103 CARBON RESISTOR 1/6W J 10
R 361 GJ250084792103 CARBON RESISTOR 1/6W J 4.7
R 362 GJ250085602103 CARBON RESISTOR 1/6W J 56
R 368 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 370 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 371 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 372 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 373 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 374 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 375 GJ250084732103 CARBON RESISTOR 1/6W J 47K
R 376 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 378 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 379 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 380 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 381 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 382 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 383 GJ250085632103 CARBON RESISTOR 1/6W J 56K
R 386 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 387 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 388 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 389 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 390 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 391 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 392 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 393 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 394 GJ250081512103 CARBON RESISTOR 1/6W J 150
R 399 GJ250081022103 CARBON RESISTOR 1/6W J 1K
R 401 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 402 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 404 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 405 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 406 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 407 GJ250088232103 CARBON RESISTOR 1/6W J 82K
Parts number Parts name Area
352 KTC3200GR TRANSISTOR GJ312030131210
354 DTA114YSTP TRANSISTOR GJ872990281
356 2SC2001/LK/-T TRANSISTOR GJ312020012202
357 2SC2001/LK/-T TRANSISTOR GJ312020012202
358 2SA1175TPF TRANSISTOR GJ872910154
360 DTC144ESATP TRANSISTOR GJ872903003
365 DTC144ESATP TRANSISTOR GJ872903003
366 DTC114YSTP TRANSISTOR GJ872990437
367 2SA934/QR/-T TRANSISTOR GJ872999343
368 2SA934/QR/-T TRANSISTOR GJ872999343
369 KTC3199/GL/T TRANSISTOR GJ312030111210
370 2SA934/QR/-T TRANSISTOR GJ872999343
371 KTC3199/GL/T TRANSISTOR GJ312030111210
402 2SD2144S/VW/-T TRANSISTOR GJ872992241
403 2SD2144S/VW/-T TRANSISTOR GJ872992241
502 2SD2144S/VW/-T TRANSISTOR GJ872992241
503 2SD2144S/VW/-T TRANSISTOR GJ872992241
Remarks
3-16
MX-J300
Electrical parts list
Item
A
R 408 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 409 GJ250081842103 CARBON RESISTOR 1/6W J 180K
R 410 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 411 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 412 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 413 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 414 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 415 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 416 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 417 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 418 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 501 GJ250081042103 CARBON RESISTOR 1/6W J 100K
R 502 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 504 GJ250081012103 CARBON RESISTOR 1/6W J 100
R 505 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 506 GJ250088222103 CARBON RESISTOR 1/6W J 8.2K
R 507 GJ250088232103 CARBON RESISTOR 1/6W J 82K
R 508 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 509 GJ250081842103 CARBON RESISTOR 1/6W J 180K
R 510 GJ250081222103 CARBON RESISTOR 1/6W J 1.2K
R 511 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
R 512 GJ250083322103 CARBON RESISTOR 1/6W J 3.3K
R 513 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 514 GJ250084722103 CARBON RESISTOR 1/6W J 4.7K
R 515 GJ250081032103 CARBON RESISTOR 1/6W J 10K
R 516 GJ250086822103 CARBON RESISTOR 1/6W J 6.8K
R 517 GJ250082232103 CARBON RESISTOR 1/6W J 22K
R 518 GJ250082222103 CARBON RESISTOR 1/6W J 2.2K
Parts number Parts name Area
(Casstte amplifier board)
Block No. 10
Remarks
Electrical parts list
Item
A
F 951 GJ369000110008 FUSE
A
F 952 GJ369000480008 FUSE
A
FT951 QNG0003-001Z FUSE CLIP FOR TWE USE
FT952 QNG0003-001Z FUSE CLIP FOR TWE USE
FW951 GJ353090190107 CABLE FLAT 9PINS
R 951 GJ251273352201 RESISTOR 1/2W 3.3M 5%
A
T 951 GJ336760060013 POWER TRANS.
A
TB901 GJ727000010000 SOLDERING
TB902 GJ727000010000 SOLDERING
Parts number Parts name Area
(Power transformer board)
3.15A 250V
1.6A 250V
120V 60HZ
Block No. 11
Remarks
3-17
MX-J300
Q
Q
Q
Electrical parts list
Item
A
C 251 NCS21HJ-100X C CAPACITOR
C 252 NCS21HJ-100X C CAPACITOR
C 253 NCB21EK-104X C CAPACITOR
C 254 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 255 NCB21EK-104X C CAPACITOR
C 281 NCB21HK-223X C CAPACITOR
C 291 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 601 NCB21HK-102X C CAPACITOR
C 602 NCB21HK-102X C CAPACITOR
C 603 NCB21HK-223X C CAPACITOR
C 604 NCB21HK-223X C CAPACITOR
C 605 NCS21HJ-271X C CAPACITOR
C 606 NCS21HJ-181X C CAPACITOR
C 607 NCB21HK-222X C CAPACITOR
C 608 NCB21HK-223X C CAPACITOR
C 610 NCB21EK-104X C CAPACITOR
C 611 NCB21EK-104X C CAPACITOR
C 612 QER41HM-105 E CAPACITOR 1.0MF 20% 50V
C 613 NCS21HJ-101X C CAPACITOR
C 614 NCB21HK-273X C CAPACITOR
C 615 NCB21HK-472X C CAPACITOR
C 616 NCB21HK-103X C CAPACITOR
C 617 NCS21HJ-331X C CAPACITOR
C 621 NCB21EK-104X C CAPACITOR
C 623 NCF21CZ-105X C CAPACITOR
C 624 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 631 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 632 NCF21CZ-105X C CAPACITOR
C 633 NCB21HK-223X C CAPACITOR
C 651 NCS21HJ-120X C CAPACITOR
C 652 NCS21HJ-150X C CAPACITOR
C 653 NCB21EK-104X C CAPACITOR
C 654 NCB21HK-223X C CAPACITOR
C 655 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 656 NCB21EK-104X C CAPACITOR
C 657 NCB21HK-222X C CAPACITOR
C 658 NCB21HK-222X C CAPACITOR
C 661 NCB21EK-104X C CAPACITOR
C 662 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 663 NCB21EK-104X C CAPACITOR
C 664 NCB21HK-223X C CAPACITOR
C 665 NCB21HK-223X C CAPACITOR
C 666 NCS21HJ-471X C CAPACITOR
C 667 NCF21CZ-105X C CAPACITOR
C 668 NCB21HK-473X C CAPACITOR
C 671 NCB21EK-104X C CAPACITOR
C 672 QER41AM-107 E CAPACITOR 100MF 20% 10V
C 801 NCB21HK-822X C CAPACITOR
C 802 NCB21HK-152X C CAPACITOR
C 811 NCS21HJ-221X C CAPACITOR
C 812 NCS21HJ-221X C CAPACITOR
C 813 NCS21HJ-221X C CAPACITOR
C 814 NCS21HJ-221X C CAPACITOR
C 821 NCF21CZ-105X C CAPACITOR
C 822 QER41AM-227 E CAPACITOR 220MF 20% 10V
C 851 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 852 QER41CM-106 E CAPACITOR 10MF 20% 16V
C 855 NCB21EK-104X C CAPACITOR
C 859 NCF21CZ-105X C CAPACITOR
C 860 NCF21CZ-105X C CAPACITOR
CN151 QGF1016F1-15 15FFC CONNECTOR VIDEO CD
CN152 QGA2001F1-12 12P CN RIG VIDEO CD
CN601 QGF1016F1-15 15FFC CONNECTOR TRAVERSE
Parts number Parts name Area
(CD servo board)
Block No. 12
Remarks
Item
A
CN651 QGF1016F1-19 CONNECTOR MAIN
CN652 QGF1016F1-05 CONNECTOR OSD
CN653 QGF1016F1-13 CONNECTOR CD TEXT
CN801 QGA2001C1-06 6P PLUG ASSY TRAVERSE
CN851 QGD2503F1-03 SOCKET DISC DETECTION
CN854 QGB2016K1-07 CONNECTOR TRAY SWITCH
CN855 QGB2012K2-10 CONNECTOR CAM SWITCH
IC251 UPD78055GCA37 IC MICOM
IC601 AN8806SB-W IC RF AMP
IC651 MN35510 IC DSP & DAC
IC801 BA6897FP-W IC PU DRIVE
IC851 TA8409S IC L MOTOR DRIVE
IC852 TA8409S IC R MOTOR DRIVE
L 851 QQL01BK-100Z INDUCTOR VS DE-COUPLE
L 853 QQL01BK-100Z INDUCTOR L MOTOR
L 854 QQL01BK-100Z INDUCTOR R MOTOR
R 251 NRSA02J-102X MG RESISTOR
R 252 NRSA02J-102X MG RESISTOR
R 253 NRSA02J-102X MG RESISTOR
R 254 NRSA02J-102X MG RESISTOR
R 255 NRSA02J-102X MG RESISTOR
R 256 NRSA02J-102X MG RESISTOR
R 257 NRSA02J-102X MG RESISTOR
R 258 NRSA02J-102X MG RESISTOR
R 259 NRSA02J-101X MG RESISTOR
R 260 NRSA02J-102X MG RESISTOR
R 261 NRSA02J-102X MG RESISTOR
R 262 NRSA02J-102X MG RESISTOR
R 263 NRSA02J-102X MG RESISTOR
R 264 NRSA02J-102X MG RESISTOR
R 265 NRSA02J-223X MG RESISTOR
R 266 NRSA02J-102X MG RESISTOR
R 267 NRSA02J-102X MG RESISTOR
R 268 NRSA02J-102X MG RESISTOR
R 269 NRSA02J-102X MG RESISTOR
R 274 NRSA02J-102X MG RESISTOR
R 275 NRSA02J-102X MG RESISTOR
R 276 NRSA02J-102X MG RESISTOR
R 277 NRSA02J-102X MG RESISTOR
R 278 NRSA02J-102X MG RESISTOR
R 279 NRSA02J-102X MG RESISTOR
R 281 NRSA02J-102X MG RESISTOR
R 282 NRSA02J-102X MG RESISTOR
R 283 NRSA02J-102X MG RESISTOR
R 284 NRSA02J-102X MG RESISTOR
R 285 NRSA02J-102X MG RESISTOR
R 286 NRSA02J-102X MG RESISTOR
R 287 NRSA02J-102X MG RESISTOR
R 288 NRSA02J-102X MG RESISTOR
R 291 NRSA02J-122X MG RESISTOR
R 292 NRSA02J-103X MG RESISTOR
R 293 NRSA02J-102X MG RESISTOR
R 601 NRSA02J-274X MG RESISTOR
R 602 NRSA02J-154X MG RESISTOR
R 603 NRSA02J-273X MG RESISTOR
R 604 NRSA02J-104X MG RESISTOR
R 605 NRSA02J-154X MG RESISTOR
R 606 NRSA02J-474X MG RESISTOR
R 607 NRSA02J-102X MG RESISTOR
R 611 NRSA02J-113X MG RESISTOR
Parts number Parts name Area
291 2SB1357/EF/-T TRANSISTOR
631 2SA1037AK/RS/-X TRANSISTOR
842 DTA144ES-T TRANSISTOR
Remarks
3-18
MX-J300
Electrical parts list
Item
A
R 612 NRSA02J-125X MG RESISTOR
R 631 NRSA02J-2R2X MG RESISTOR
R 632 NRSA02J-100X MG RESISTOR
R 634 NRSA02J-120X MG RESISTOR
R 635 NRSA02J-121X MG RESISTOR
R 636 NRSA02J-910X MG RESISTOR
R 651 NRSA02J-271X MG RESISTOR
R 652 NRSA02J-220X MG RESISTOR
R 657 NRSA02J-102X MG RESISTOR
R 658 NRSA02J-102X MG RESISTOR
R 661 NRSA02J-220X MG RESISTOR
R 662 NRSA02J-471X MG RESISTOR
R 663 NRSA02J-124X MG RESISTOR
R 665 NRSA02J-683X MG RESISTOR
R 666 NRSA02J-155X MG RESISTOR
R 667 NRSA02J-562X MG RESISTOR
R 671 NRSA02J-102X MG RESISTOR
R 672 NRSA02J-102X MG RESISTOR
R 673 NRSA02J-102X MG RESISTOR
R 674 NRSA02J-101X MG RESISTOR
R 675 NRSA02J-102X MG RESISTOR
R 676 NRSA02J-102X MG RESISTOR
R 677 NRSA02J-102X MG RESISTOR
R 678 NRSA02J-102X MG RESISTOR
R 679 NRSA02J-102X MG RESISTOR
R 680 NRSA02J-102X MG RESISTOR
R 681 NRSA02J-102X MG RESISTOR
R 682 NRSA02J-102X MG RESISTOR
R 683 NRSA02J-102X MG RESISTOR
R 684 NRSA02J-271X MG RESISTOR
R 685 NRSA02J-102X MG RESISTOR
R 686 NRSA02J-101X MG RESISTOR
R 687 NRSA02J-102X MG RESISTOR
R 688 NRSA02J-101X MG RESISTOR
R 689 NRSA02J-102X MG RESISTOR
R 690 NRSA02J-101X MG RESISTOR
R 691 NRSA02J-101X MG RESISTOR
R 692 NRSA02J-101X MG RESISTOR
R 693 NRSA02J-471X MG RESISTOR
R 694 NRSA02J-102X MG RESISTOR
R 801 NRSA02J-222X MG RESISTOR
R 802 NRSA02J-472X MG RESISTOR
R 803 NRSA02J-123X MG RESISTOR
R 804 NRSA02J-154X MG RESISTOR
R 805 NRSA02J-123X MG RESISTOR
R 806 NRSA02J-223X MG RESISTOR
R 807 NRSA02J-222X MG RESISTOR
R 808 NRSA02J-223X MG RESISTOR
R 811 NRSA02J-473X MG RESISTOR
R 812 NRSA02J-223X MG RESISTOR
R 831 NRSA02J-151X MG RESISTOR
R 832 NRSA02J-103X MG RESISTOR
R 842 NRSA02J-472X MG RESISTOR
R 851 NRSA02J-102X MG RESISTOR
R 852 NRSA02J-102X MG RESISTOR
R 853 NRSA02J-102X MG RESISTOR
R 854 NRSA02J-102X MG RESISTOR
R 855 NRSA02J-102X MG RESISTOR
R 856 NRSA02J-102X MG RESISTOR
R 857 NRSA02J-272X MG RESISTOR
R 859 NRSA02J-181X MG RESISTOR
R 861 NRSA02J-102X MG RESISTOR
R 862 NRSA02J-102X MG RESISTOR
Parts number Parts name Area
(CD servo board)
Block No. 12
Remarks
Item
A
R 863 NRSA02J-102X MG RESISTOR
R 864 NRSA02J-102X MG RESISTOR
R 865 NRSA02J-102X MG RESISTOR
R 866 NRSA02J-102X MG RESISTOR
R 880 NRSA02J-102X MG RESISTOR
R 881 NRSA02J-102X MG RESISTOR
R 882 NRSA02J-102X MG RESISTOR
R 883 NRSA02J-102X MG RESISTOR
R 884 NRSA02J-102X MG RESISTOR
R 885 NRSA02J-102X MG RESISTOR
R 886 NRSA02J-102X MG RESISTOR
R 887 NRSA02J-102X MG RESISTOR
W 601 QUB220-07HPDT SIN TWIST WIRE D.GND
X 251 QAX0360-001Z CRYSTAL FOR IC251
X 651 QAX0413-001Z CRYSTAL FOR IC651
Electrical parts list
A
CN804 QGB2016J1-07 CONNECTOR
SW 1 QSW0859-001 DETECT SWITCH
SW 2 QSW0859-001 DETECT SWITCH
SW 3 QSW0859-001 DETECT SWITCH
SW 4 QSW0859-001 DETECT SWITCH
SW 5 QSW0859-001 DETECT SWITCH
SW 6 QSW0859-001 DETECT SWITCH
Parts number Parts name Area
(CD select switch board)
Item
Parts number Parts name Area
Remarks
Block No. 13
Remarks
3-19
MX-J300
Packing materials and accessories parts list
Block No.
Block No.
M
M
4
M
M
5
M
M
A12
3-20
MX-J300
Parts list (Packing)
Item Parts number Parts name Area
A
P 1 GJ560400190101 CARTON 1
P 2 GJ560400120101 POLYFOAM, RIGHT 1
P 3 GJ560400110101 POLYFOAM, LEFT 1
P 4 GJ560400160101 POLYFOAM,BOTTOM 1
P 5 GJ560400150101 POLYFOAM,TOP 1
P 6 GJ740082550400 POLYBAG 1
P 7 GJ740666420300 POLYBAG 1
P 8 GJ740362550000 POLYBAG 1
P 9 GJ740486230300 POLYBAG 2
P 10 GJ740122550000 POLYBAG 1
Q'ty Description
Parts list (Accessoris)
Item Parts number Parts name Area
A
A 1 RM-SMXJ10/J/ ASS'Y REMOTE 1
A 2 GJ460220010201 ANTENNA LOOP 1
A 3 -------------- BATTERY 2
A 4 LVT0484-004C INSTRUCTIONS C1 ENG,FRE
LVT0484-001C INSTRUCTIONS J1 ENG
A 5 GJ351001402431 ANTENNA WIRE 1
A 6 BT-20044G SAFETY GUIDE J1
A 7 BT-51020-2 ACC R. CARD J1
A 8 BT-52002-1 ACCY,W.CARD C1
A 9 BT-20071B SVC.LIST C1
A 12 MXJ300K-SPBOX SPEAKER BOX (PAIR)L&R
Q'ty Description
2
Block No. M4MM
Block No. M5MM
3-21
Loading...
