JVC I'Art Pro AV-48WP74, I'Art Pro AV-56WP74, I'Art Pro AV-65WP74 User Manual

Important Note:

In the spaces below, enter the model and serial number of your television
(located at the rear of the television cabinet). Staple your sales receipt or invoice
to the inside cover of this guide. Keep this user’s guide in a convenient place for
future reference. Keep the carton and original packaging for future use.

LCT1282-001A-A

0103-TN-II-IM

Model Number:

Serial Number:

Illustration of AV-65WP74 and RM-C1200G

For Models:

AV-65WP74
AV-56WP74
AV-48WP74

Projection Television Users Guide

Important Safety Precautions

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV SET

TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good
ventilation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do
not attempt to repair it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to

disconnect both the power plug from the AC outlet and antenna for your
safety.

* To prevent electric shock do not use this polarized plug with an

extension cord, receptacle or other outlet unless the blades can be fully
inserted to prevent blade exposure.

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service
personnel.

The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

IMPORTANT RECYCLING INFORMATION

This product utilizes both a Cathode Ray Tube (CRT) and other components that
contain lead. Disposal of these materials may be regulated in your community due to
environmental considerations. For disposal or recycling information, please contact
your local authorities, or the Electronic Industries Alliance: http://www.eiae.org

CAUTION:

Please read and retain for your safety.

Electrical energy can perform many useful functions. This TV set has been engineered and
manufactured to assure your personal safety. But improper use can result in potential
electrical shock or fire hazards. In order not to defeat the safeguards incorporated in this
TV set, observe the following basic rules for its installation, use and servicing. Also follow all

warnings and instructions marked on your TV set.

INSTALLATION

1 Your TV set is equipped with a polarized AC line plug (one

blade of the plug is wider than the other). This safety feature
allows the plug to fit into the power outlet only one way.
Should you be unable to insert the plug fully into the outlet,
try reversing the plug. Should it still fail to fit, contact your
electrician.

2 Operate the TV set only from a power source as indicated on the TV set or refer to the

operating instructions for this information. If you are not sure of the type of power supply to
your home, consult your TV set dealer or local power company. For battery operation, refer
to the operating instructions.

3 Overloaded AC outlets and extension cords are dangerous, and so are frayed power cords

and broken plugs. They may result in a shock or fire hazard. Call your service technician for
replacement.

4 Do not allow anything to rest on or roll over the power cord, and do not place the TV set

where power cord is subject to traffic or abuse. This may result in a shock or fire hazard.

5 Do not use this TV set near water — for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near swimming pool, etc.

6 If an outside antenna is connected to the TV set, be sure the antenna system is grounded

so as to provide some protection against voltage surges and built-up static charges.
Section 810 of the National Electrical Code provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna discharge unit,
connection requirements for the grounding electrode.

(POLARIZED-TYPE)

Important Safeguards

• As an “ENERGY STAR®” partner,
JVC has determined that this
product or product model meets the
“ENERGY STAR®” guidelines for energy
efficiency.

7 An outside antenna system should not be located in the vicinity of overhead power lines or

other electric light or power circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.

8 TV sets are provided with ventilation openings in the cabinet to allow heat generated during

operation to be released.

Therefore:

— Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa,

rug, etc.

— Never place a TV set in a “built-in” enclosure unless proper ventilation is provided.
— Never cover the openings with a cloth or other material.
— Never place the TV set near or over a radiator or heat register.

9 To avoid personal injury:

— Do not place a TV set on a sloping shelf unless properly secured.

— Use only a cart or stand recommended by the TV set manufacturer.
— Do not try to roll a cart with small casters across thresholds or deep pile carpets.
— Wall or shelf mounting should follow the manufacturer’s instructions, and should use a

mounting kit approved by the manufacturer.

10 Caution children about dropping or pushing objects into the TV set through cabinet

openings. Some internal parts carry hazardous voltages and contact can result in a fire or
electrical shock.

11 Unplug the TV set from the wall outlet before cleaning. Do not use liquid or an aerosol

cleaner.

12 Never add accessories to a TV set that has not been designed for this purpose. Such

additions may result in a hazard.

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

Use

13 For added protection of the TV set during a lightning storm or when the TV set is to be left

unattended for an extended period of time, unplug it from the wall outlet and disconnect
the antenna. This will prevent damage to product due to lightning storms or power line
surges.

14 A TV set and cart combination should be moved with care. Quick stops, excessive force,

and uneven surfaces may cause the TV set and cart combination to overturn.

15 Unplug this TV set from the wall outlet and refer servicing to qualified service personnel

under the following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the TV set.
C. If the TV set has been exposed to rain or water.
D. If the TV set does not operate normally by following the operating instructions.

Adjust only those controls that are covered in the operating instructions as improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the TV set to normal operation.

E. If the TV set has been dropped or damaged in any way.
F. When the TV set exhibits a distinct change in performance — this indicates a need for

service.

16 Do not attempt to service this TV set yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service
personnel.

17 When replacement parts are required, have the service technician verify in writing that the

replacement parts he uses have the same safety characteristics as the original parts. Use
of manufacturer’s specified replacement parts can prevent fire, shock, or other hazards.

18 Upon completion of any service or repairs to this TV set, please ask the service technician

to perform the safety check described in the manufacturer’s service literature.

19 When a TV set reaches the end of its useful life, improper disposal could result in a picture

tube implosion. Ask a qualified service technician to dispose of the TV set.

20 Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to the
point of cable entry as practical.

PORTABLE CART WARNING

(Symbol provided by RETAC)

Service

Table of Contents

Unpacking your TV . . . . . . . . . . . . 7

TV Models . . . . . . . . . . . . . . . . 8

TV Remote Controls . . . . . . . . . . . 9

Getting Started . . . . . . . . . . . . . 10

The Remote Control . . . . . . . . . . 10

Connecting Your Devices . . . . . . . 11

Interactive Plug In Menu . . . . . . . . 18

Setting CATV, VCR and DVD Codes . . . 21

CATV or Satellite Codes . . . . . . . . 21

VCR Codes . . . . . . . . . . . . . . 22

DVD Codes . . . . . . . . . . . . . . 23

Search Codes . . . . . . . . . . . . . 24

Using the Guide . . . . . . . . . . . . . 25

Onscreen Menu System . . . . . . . . . 26

Auto Tuner Setup . . . . . . . . . . . . 28

Channel Summary . . . . . . . . . . . . 28

V-Chip . . . . . . . . . . . . . . . . . . 29

Set Lock Code . . . . . . . . . . . . . 35

Adjusting CRT Color Conversion . . . . . 36

Auto Demo . . . . . . . . . . . . . . . 38

Power Indicator . . . . . . . . . . . . . 38

Position Adjustment . . . . . . . . . . . 38

Digital-In . . . . . . . . . . . . . . . . . 39

TV Speaker . . . . . . . . . . . . . . . 39

Audio Out . . . . . . . . . . . . . . . . 40

Center CH Input . . . . . . . . . . . . . 40

Language . . . . . . . . . . . . . . . . 40

Closed Caption . . . . . . . . . . . . . 41

Noise Muting . . . . . . . . . . . . . . 41

Front Panel Lock . . . . . . . . . . . . 42

Auto Shut Off . . . . . . . . . . . . . . 42

XDS ID . . . . . . . . . . . . . . . . . 42

Picture Settings . . . . . . . . . . . . . 43

Adjust Picture Settings . . . . . . . . . 43

Color Temperature . . . . . . . . . . . . 43

Digital Noise Clear . . . . . . . . . . . . 44

VSM . . . . . . . . . . . . . . . . . . . 44

Reset . . . . . . . . . . . . . . . . . . 44

Sound Settings . . . . . . . . . . . . . 45

Adjust Sound Settings . . . . . . . . . 45

MTS (Multi-channel Sound) . . . . . . . 45

Set Clock . . . . . . . . . . . . . . . . 46

On/Off Timer . . . . . . . . . . . . . . . 47

Multi Screen Function . . . . . . . . . . 48

Split . . . . . . . . . . . . . . . . . . . 48

POP . . . . . . . . . . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . 49

EZ-Surf . . . . . . . . . . . . . . . . . 50

Freeze . . . . . . . . . . . . . . . . . . 50

Swap . . . . . . . . . . . . . . . . . 50

Select . . . . . . . . . . . . . . . . . . 50

Power . . . . . . . . . . . . . . . . . . 51

Number Buttons . . . . . . . . . . . . . 51

100+ Button . . . . . . . . . . . . . . . 51

Input . . . . . . . . . . . . . . . . . . . 51

Digital-In . . . . . . . . . . . . . . . . . 51

Return +/TV . . . . . . . . . . . . . . . 52

Sound . . . . . . . . . . . . . . . . . . 52

Muting . . . . . . . . . . . . . . . . . . 52

Video Status . . . . . . . . . . . . . . . 53

Natural Cinema . . . . . . . . . . . . . 53

TheaterPro D6500K . . . . . . . . . . . 53

Sleep Timer . . . . . . . . . . . . . . . 54

Display . . . . . . . . . . . . . . . . . 54

Aspect . . . . . . . . . . . . . . . . . 55

Aspect Ratios . . . . . . . . . . . . . 55

C.C. . . . . . . . . . . . . . . . . . . . 56

Menu . . . . . . . . . . . . . . . . . . 56

OK . . . . . . . . . . . . . . . . . . . 56

Back . . . . . . . . . . . . . . . . . . . 56

TV/CATV Slide Switch . . . . . . . . . . 57

VCR/DVD Slide Switch . . . . . . . . . 57

VCR Buttons . . . . . . . . . . . . . . . 57

DVD Buttons . . . . . . . . . . . . . . . 57

Light . . . . . . . . . . . . . . . . . . . 57

Troubleshooting . . . . . . . . . . . . . 58

Warnings . . . . . . . . . . . . . . . . 60

Warranty . . . . . . . . . . . . . . . . . 61

Authorized Service Centers . . . . . . . 63

Specifications . . . . . . . . . . Back Cover

Quick Setup . . . . . . . . . . . 7

Remote Programming . . . . . 21

Onscreen Menus . . . . . . . . 25

Button Functions . . . . . . . 48

Appendices . . . . . . . . . . 58

Initial Setup . . . . . . . . . . 28

Clock Timers . . . . . . . . . . 46

Picture Adjust . . . . . . . . . 43

Sound Adjust . . . . . . . . . 45

Two AA

Batteries

1 Television

1 Remote Control

Used to connect an
external antenna or
cable TV system to
your TV.

Used to make video
connections with S-Video
VCRs, Camcorders and
DVD players.

We recommend that before you start using your new television, you read your entire User’s
Guide so you can learn about your new television’s many great features. If you’re anxious to
start using your television right away, a quick setup guide follows on the next few pages.

Note: Your television
and/or remote
control may differ
from the examples
illustrated here.

Quick Setup Unpacking your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new
television, please check to make sure you have all of the following items. In addition to this
guide, your television box should include:

Once you have unpacked your television, the next step is to connect it to your antenna/
cable or satellite system and to connect the audio/video devices you want to use with your
television. To make these connections you will use plugs like the ones illustrated below.

Coaxial Cables

7

S-Video Cable

Used to connect
audio/video devices
like VCRs, DVD players,
stereo amplifiers, game
consoles, etc.

Component Cables

Composite Cables

Audio Cables

MODELS:
AV-65WP74
AV-56WP74
AV-48WP74

MODELS: AV-65WP74, AV-56WP74, AV-48WP74

Quick Setup TV Models

NOTE: Before you connect your television to another device, please refer to the proper

diagrams for your specific TV and remote. These will help assist you in understanding
how to connect your television to another device, as well as use the remote to set up
your television.

Rear Panel Diagram

Front Panel Diagram

8

MODELS:
AV-65WP74
AV-56WP74
AV-48WP74

Quick Setup TV Remote Controls

RM-C1200G

9

• For information on remote control buttons, see pages 48 - 57.

These quick setup pages will provide you, in three easy steps, with the basic information you
need to begin using your new television right away.

If you have questions, or for more detailed information on any of these steps, please consult
other sections of this manual.

Before you can operate your remote
control, you first need to install the
batteries (included).

Slide the cover on the back of the
remote down towards the bottom of
the remote control. Insert two batteries
(included) carefully noting the “+” and
“–” markings, placing the “–” end in
the unit first. Slide the cover back into
place.

When you change the batteries, try to complete the task within three minutes. If you
take longer than three minutes, the remote control codes for your VCR, DVD, and/or
cable box/satellite receiver may have to be reset. See pages 21 - 24.

Quick Setup Getting Started

Getting Started

Step 1 – The Remote Control

10

Key Feature Buttons

The four key feature buttons at the center of the remote
can be used for basic operation of the television. The top
and bottom buttons will scan forward and back through
the available channels. To move rapidly through the
channels using JVC’s Hyperscan feature, press and hold
CH+ or CH–. The channels will zip by at a rate of five
channels per second. The right and left buttons will turn
the volume up or down. These buttons are also marked
with four arrows and are used with JVC’s onscreen menu
system. To use the onscreen menus, press the MENU
button.

Quick Setup Connections

Please follow the flow chart below to determine which connection setup is right for you. Then,
refer to the appropriate diagrams to connect your television to other devices that you may
have. After you are finished connecting your devices, plug the power cord into the nearest
power outlet and turn on the TV.

Step 2 – Connecting Your Devices

11

A VCR is not necessary for operation of the television. If you follow these diagrams and the
television does not work properly, contact your local cable operator.

• To connect a DVD player, see Diagram #3. A DVD player is optional.

• If you have a satellite television system, please refer to the satellite TV manual.





 

  













Basic Operation

Turn the television on and off by pressing the POWER button at the top right
corner of the remote. If this is the first time you are turning on the TV, the
interactive plug-in menu appears.

• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if
you need to operate a cable box.

• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to
DVD to control a DVD player. Please see pages 21 to 24 for instructions on
programming your remote control to operate a cable box, VCR or DVD player.

Quick Setup Connections

12

Notes:

• If your VCR is a mono sound unit, it will have only one audio out jack. Connect it to the
LEFT AUDIO INPUT on the front of the TV.

• Use the S-Video connection if possible for superior picture quality.

• Your VCR must be turned on to view premium cable channels.

Diagram #2

Note:

• If you do not have a cable box, connect the cable wire from the wall outlet into the back of
the TV.

Diagram #1

Quick Setup Connections

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary
colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete
one set of connections (DVD or audio output) before starting the other to avoid accidentally
switching the cables.

• You may also connect the DVD player to Input 1.

Diagram #3

13

JVC’s AV compu link feature makes playing video tapes or DVDs totally automatic. Simply
insert a pre-recorded tape into your JVC brand VCR or DVD into your JVC DVD player
and the device will automatically turn on and begin playback. At the same time, using the
AV compu link, the VCR or DVD player sends a signal to the television telling it to turn on
and switch to the proper video input.

• The AV compu link cable may be included with the JVC AV compu link unit you
wish to connect. If it is not, contact JVC Parts Department at (800)-882-2345, or
www.jvcservice.com for part # EWP 805-012.

• AV Compu Link can only be used with JVC brand products.

Notes:

• In order for the VCR playback to begin automatically, the recording tabs must be removed
from the VHS tape. If the tab is in place, automatic switching will occur when you push the
VCR’s PLAY button.

• If your JVC brand VCR has “A code/B code remote control switching” (see your VCR’s
instruction book), using VCR A code will switch the TV to input 1.

• Refer to your DVD instruction book for detailed connection information.

• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see
the receiver connection instructions for detailed connection information.

• AV compu link is compatible with select AV compu link receivers.

Connecting to JVC AV Compu Link

Quick Setup Connections

14

AV Compu Link Cable

To Connect: Plug one end of the AV compu link cable

into the AV COMPU LINK INPUT on your VCR, DVD, or
other compu link device. Plug the other end of the AV
compu link cable into the AV COMPU LINK at the rear
of the television.

Note:

• The AV compu link cable has a male 3.5 mm (mono)
plug on each end.

Quick Setup Connections

1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on
the front of the TV, OR connect an S-Video cable from the front of the TV to the camcorder.

2) Connect a white composite cable from the camcorder LEFT AUDIO OUT, into the
LEFT AUDIO IN on the front of the TV.

3) Connect a red composite cable from the camcorder RIGHT AUDIO OUT, into the
RIGHT AUDIO IN on the front of the TV.

Note:

• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to

the LEFT AUDIO IN on the front of the TV.

You may connect a camcorder, game console or other equipment to your television by using
the front input jacks (Input 4) located under the front panel door. To access, pull on the door
to open it. You can also connect these using the television’s rear input jacks, using the same
instructions.

15

Connecting to a Camcorder

16

Quick Setup Connections

Connecting to the Surround Amplifier

1) Connect the black speaker cable from the TV’s SPEAKER INPUT terminal to the
surround amplifier’s CENTER SPEAKER OUTPUT terminal.

2) Connect the red speaker cable from the TV’s SPEAKER INPUT terminal to the
surround amplifier’s CENTER SPEAKER OUTPUT terminal.

1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to
the LEFT AUDIO INPUT on the amplifier.

2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to
the RIGHT AUDIO INPUT on the amplifier.

3) Connect a black composite cable from the SUBWOOFER OUT on the back of the TV to
the LINE INPUT of the subwoofer.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

Connecting to an External Amplifier

Note: Please read the benefit of this feature on page 40.

Subwoofer Out - Use a powered subwoofer with the surround feature to simulate a home

theater system. Simply connect the subwoofer to the back of the TV.

By inputting a high bandwidth digital content protection high definition picture source to the
digital-in terminal of this television, high-definition pictures can be displayed on the screen in
their digital form. (This terminal is for use in the future when high bandwidth digital content
protection DTV decoders and DVD players and D-VHS are put on the market.)

1) Connect the DTV DIGITAL RGB OUTPUT TERMINAL to the DIGITAL INPUT TERMINAL of
the television, and then tighten the 2 screws.

2) Connect the DTV decoder LEFT AUDIO OUTPUT to the DIGITAL-IN LEFT AUDIO INPUT.

3) Connect the DTV decoder RIGHT AUDIO OUTPUT to the DIGITAL-IN RIGHT AUDIO
INPUT.

• The Digital-In terminal can only be used with 1080i, 720p and 480p picture signals. Set

the DTV decode digital-out terminal output setting to 1080i, 720p or 480p. For detailed
information, refer to the DTV decoder instruction manual. If you can not display the picture
because your DTV decoder does not have a digital-out terminal output setting, use the
component video input (or the S-Video input or video input). Refer to page 13. In this case
the picture will be displayed as an analog signal.

• The digital-in terminal is not compatible with the picture signal of a personal computer.

• Use a DVI-D single link 19-pin cable (commercially available) in order to digitally connect

the television with a DTV decoder.

If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance may
be slightly shifted. In cases such as this, the horizontal balance can be adjusted by accessing
“DIGITAL-IN” in the INITIAL SETUP menu. (Refer to page 39.)

After the connections
have been made,
tighten the screw to
secure the cables.

DTV decoder

Quick Setup Connections

Connecting to a Digital TV Receiver w/HDCP

17

When you turn your television on for the first time the interactive plug-in menu will appear.
The plug-in menu helps you to get your TV ready to use by letting you set your preferences
for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You

can choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug-in items before you start using your
television.

Step 3 – The Interactive Plug In Menu

Quick Setup Plug-In Menu

18

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically
switches to the LANGUAGE settings. You can choose to view your onscreen menus in three
languages: English, French (Français) or Spanish (Español).

è

To choose a language:

(English, Français or Español)

†

To NEXT (To set clock)

Language

(To be continued...)

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose
AUTO, see auto clock set above.

è

To choose MANUAL

†

To TIME

è

To set the hour

†

To minute

è

To set the minute

†

To Start Clock

Manual Clock Set

Note:

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

Quick Setup Plug-In Menu

19

Before you use any of your TV’s timer functions, you must first set the clock. You
may precisely set your clock using the XDS time signal broadcast by most public
broadcasting stations. If you do not have this in your area, you will have to set the clock
manually. See manual clock set below. To set the clock using the XDS signal:

è

To choose AUTO

†

To TIME ZONE

è

To select your time zone: (Atlantic, Eastern,
Central, Mountain, Pacific, Alaska or
Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

è

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

Notes:

• The Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight
Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The
clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before
operating any timer functions.

Auto Clock Set

(To be continued...)

Quick Setup Plug-In Menu

20

In auto tuner setup, the TV automatically scans through all available channels, memorizing the
active ones and skipping over blank ones or channels with weak signals. This means when
you scan (using the CHANNEL +/– buttons) you will receive only clear, active channels.

è

To choose CABLE or AIR (or SKIP when you

skip Auto Tuner Setup)

†

To START

NOW

PROGRAMMING !

48

Programming will take approximately 1 to 2

minutes.

Auto Tuner Setup

The Quick Setup is complete

When the setup is finished, THANK YOU!! SETUP IS NOW COMPLETE is displayed. Your
quick setup is now complete. You can now begin watching your television, or you can
continue on in this guide for more information on programming your remote control, or using
the JVC onscreen menu system to customize your television viewing experience.

Notes:

• Noise muting will not work during Auto Tuner Setup.

• Skip appears only for interactive plug-in menu.

• The interactive plug-in menu setting does not appear if your TV has been turned on before.
In this case, use the menu to perform these settings. See pages 40, 46 and 28.

Cable Box and Satellite Users: After your auto tuner setup is complete, you may,
(depending on the type of hookup), have only 1 channel, usually 3 or 4 in the auto tuner
memory. This is normal.

You can program your remote to operate your cable box, satellite receiver, VCR or DVD
player by using the instructions and codes listed below. If the equipment does not respond
to any of the codes listed below or to the code search function, use the remote control
supplied by the manufacturer.

The remote control is programmed with cable box and satellite codes for power on/off,
channel up/down, and 10 key operation.

1) Find the cable box or satellite brand from the list of codes shown below.

2) Slide the 2-way selector switch to “CATV”.

3) Press and hold down the DISPLAY button, then enter the first code number listed with the
10 key pad.

4) Release the DISPLAY button, and confirm the operation of the cable box/satellite receiver.

• If your cable or satellite box does not respond to the first code, try the others listed. If it

does not respond to any code, try the search codes function, on page 24.

Remote Programming

21

Setting the CATV, VCR and DVD Codes

Cable Box or Satellite Codes

The remote control is programmed with VCR codes for power on/off, play, stop, fast-forward,
rewind, pause, record, channel up/down operation.

1) Find the VCR brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”.

3) Press and hold down the DISPLAY button, then enter the first code number listed with the
10 key pad.

4) Release the DISPLAY button, and confirm the operation of the VCR.

• If your VCR does not respond to the first code, try the others listed. If it does not respond

to any of the codes, try the search codes function on page 24.

• After you program your remote, some VCR buttons may not work properly. If so, use the

VCR’s remote.

• To record, hold down the R

EC button on the remote and press PLAY.

Remote Programming

VCR Codes

22

The remote control is programmed with DVD codes for power on/off, play, stop, fast-forward,
rewind, previous/next chapter, tray open/close, and still/pause operation.

1) Find the DVD player brand from the list of codes shown below.

2) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “DVD”.

3) Press and hold down the DISPLAY button, then enter the first code number listed with the
10 key pad.

4) Release the DISPLAY button, and confirm the operation of the DVD player.

• If your DVD player does not respond to the first code, try the others listed. If it does not

respond to any of the codes, try the search codes function on page 24.

• After you program your remote, some DVD buttons may not work properly. If so, use the

DVD player’s remote.

Remote Programming

DVD Codes

23

Remote Programming

24

Cable/Satellite Search Codes Function

1) Slide the first 2-Way Mode Selector switch to CATV.

2) Press the POWER and RETURN+/TV buttons. Hold for at least three seconds and release.

3) Press the POWER button on the remote, and see if the cable or satellite box responds.

4) If there was a response, press RETURN+/TV. The codes are now set. If there was no
response, repeat Step 3. If you repeat Step 3 a total of 80 times without a response, use
the remote control that came with your equipment.

5) Press RETURN+/TV to exit.

VCR/DVD Search Codes Function

1) Slide the first 2-way selector switch to “TV” and the other 2-way selector switch to “VCR”
or “DVD”.

2) Press the VCR or DVD POWER and RETURN+/TV buttons. Hold for at least three seconds
and release.

3) Press the VCR or DVD POWER button, and see if the VCR or DVD responds.

4) If there was a response, press RETURN+/TV. The codes are now set. If there was no
response, repeat Step 3. If you repeat Step 3 a total of 80 times for the VCR (40 times for
the DVD player), and there is no response, use the remote control that came with your
equipment.

5) Press RETURN+/TV to exit.

Search Codes

To bring up the onscreen menu, press the MENU button on the remote control. The item that
appears in green is the one currently selected. If you use the Menu button on the TV’s front
panel instead of the remote, an additional menu screen showing INPUT and ASPECT will
appear between INITIAL SETUP and PICTURE ADJUST. The “interactive plug-in menu” will
appear the first time the TV is plugged in.

Note:

• Menus shown in this book are illustrations, not exact replications of the television’s

onscreen displays.

Certain symbols are used throughout this guide to help you learn about the features of your
new television. The ones you will see most frequently are:

π†

Up and Down arrows mean press the CH+ or CH– buttons. Pressing the CH+ or CH–

buttons let you:

• Move vertically in a main menu screen

• Move through a submenu screen

• Move to the next letter, number, or other choice in a submenu

• Back up to correct an error

• Scan through TV channels (when not in a menu screen)

è

Left and right arrows mean press the VOLUME+ or VOLUME– buttons to move left or right

to:

• Select a highlighted menu item

• Select an item in a submenu

• Select numbers in certain menu options

• Turn the volume up or down (when not in a menu screen)

The “press button” icon means you should press the button named on your remote

control. (Button names appear in S

MALL CAPITAL LETTERS.)

The “helping arrow” icon points to the highlighted or selected item in a menu.

Onscreen Menus

25

Using the Guide

Your television comes with JVC’s onscreen menu system. The onscreen menus let you make
adjustments to your television’s operation simply and quickly. Examples of the onscreen
menus are shown on the next page. Detailed explanations on using each menu follow later in
this guide. For information about the interactive plug-in Menu, see pages 18 - 20.

Onscreen Menus

26

The Onscreen Menu System

To open the onscreen menu system, press the MENU button on the remote control. You
navigate within the onscreen menus by using the four directional arrow buttons on the
remote control. (These buttons are also the CH +/– and VOL +/– buttons. Channel and volume
functions will not operate when the onscreen menu is active).

The selected feature and option on a menu screen are highlighted in a different color.

To move to a different feature use the π† arrows to move up or down the list. When you
press the up arrow at the top of the list or the down arrow at the bottom, the next menu
screen will appear. Use the arrows √ ® to select an option from the highlighted feature.
Pressing MENU on the remote control will close the onscreen menu system and return you to
normal television viewing.

Each menu and its features will be discussed in the following pages of this guide.

Notes:

• If you do not press any buttons for a few seconds, the onscreen menu will automatically
shut off.

• Button names in this guide are shown in SMALL CAPITAL LETTERS.

• Menus may appear in different sizes onscreen depending on the aspect ratio selected.

• Some menu items may not appear in menu screens when certain aspect ratios or inputs
are selected.

Selected Option
(Green)

Selected Option
(Blue)

The Onscreen Menu System

INITIAL SETUP 03

PICTURE ADJUST 01

PICTURE ADJUST 02

SOUND ADJUST

CLOCK/TIMERS

INITIAL SETUP 02

Press the MENU button

Onscreen Menus

INITIAL SETUP 01

Notes:

• The DIGITAL-IN menu can only be displayed
when a 480p picture signal is input to the
digital-in terminal and the picture is being
displayed on the screen.

• When the Menu button on the TV front panel
is pressed, the FRONT PANEL CONTROL
menu between INITIAL SETUP 03 and
PICTURE ADJUST 01 will appear.

27

Initial Setup

28

Auto Tuner Setup

The auto tuner setup function is described on page 20 as the interactive plug-in menu. If you
need to run the auto tuner setup again, follow the steps below.

Press the MENU button

π†

To AUTO TUNER SETUP

è

To operate

è

To choose CABLE or AIR

Press the OK button to start

Programming will take approximately 1 to 2 minutes. The auto tuner is finished when the
message PROGRAMMING OVER! appears onscreen.

Channel Summary

Channel summary allows you to customize the line-up of channels received by your TV.
You can add or delete channels from the line-up or prevent any unauthorized viewers from
watching any or all 181 channels.

Press the MENU button

π†

To CHANNEL SUMMARY

è

To operate

The Channel summary screen will now be displayed with
the channels set to scan marked with an “”. You can
delete channels from the scan by removing the “”. If any
channels were missed during auto tuner setup and you wish
to add them, you may by placing an “” next to the channel
number.

π†

è

To the SCAN column

Press the OK button to include or delete from scan

Press the MENU button when finished

You can block access to a channel by activating the channel lock.

Press the MENU button

π†

To CHANNEL SUMMARY

è

To operate

π†

è

To the Lock Column ( )

Press the ZERO button to lock or unlock that channel

Press the MENU button when finished

Press the Menu button when finished

When a viewer attempts to watch a guarded channel, the following message appears:

To watch a channel that you have locked, enter the Lock Code using the 10 key pad.
If the wrong code is entered, the message “INVALID LOCK CODE!” will flash on the screen.

The channel cannot be accessed until the correct
code is entered.

Notes:

• Once a channel has been unlocked, it will
remain unlocked until the television is turned
off.

• See also “Set Lock Code”, page 35.

THIS CHANNEL IS LOCKED BY
CHANNEL GUARD.
PLEASE ENTER LOCK CODE BY
10 KEY PAD TO UNLOCK IT.

NO. - - - -

Initial Setup

29

Channel Guard Message

You can customize the V-Chip settings of your television to match your personal tastes. The
V-Chip menu below is the starting point for your V-Chip settings

You can use US V-Chip settings (for programming broadcast from the United States),
Canadian V-Chip settings (for programming broadcast from Canada), and movie ratings. You
may use any or all of the settings (US V-Chip, Canada V-Chip, Movie ratings). Descriptions for
setting each of the three V-Chip formats appear in the next six pages along with descriptions
of the rating categories.

To access the rating categories:

Press the MENU button

π†

To V-CHIP

è

To operate (Lock icon will appear)

Press ZERO to access the V-Chip menu

è

To turn V-Chip ON or OFF (V-Chip must be turned
ON for rating settings to operate)

π†

To move to SET US TV RATINGS,
SET MOVIE RATINGS, or SET CANADIAN RATINGS
(see following pages for descriptions of each item)

V-Chip

Your TV is equipped with V-Chip technology which enables you to block channels or content
that you feel to be inappropriate for children, based on US and Canada rating guidelines.
V-Chip has no effect on video signals from a DVD discs, VCR tapes or Camcorder connection.

Note: Some programs, and movies are broadcast without a ratings signal. Even if you set
up V-CHIP ratings limits, these programs will not be blocked. See page 30 for information on
how to block unrated programs.

Note (for Canadian viewers): The V-Chip function is based on specifications designed for
the United States and therefore may not work properly in Canada.

You can block programs that are not rated.

Press the MENU button

π†

To V-CHIP

è

To operate (The lock icon appears)

Press ZERO to access V-Chip setup options

π†

To UNRATED

è

To VIEW or BLOCK

Press MENU when done

Directions to Block Unrated Programs

Initial Setup

Unrated Programs

Unrated programming refers to any programming which does not contain a rating signal.
Programming on television stations which do not broadcast rating signals will be placed in the
“Unrated Programming” category.

Examples of Unrated programs:

• Emergency Bulletins • Locally Originated Programming

• News • Political Programs

• Public Service Announcements • Religious Programs

• Sports • Weather

• Some Commercials

Note:

• TV programs or movies that do not have rating signals will be blocked if the unrated
category is set to BLOCK.

30

U.S. PARENTAL RATING SYSTEMS
Programs with the following ratings are appropriate for children.

 TV Y is Appropriate for All Children

Programs are created for very young viewers and should be suitable for all ages, including
children ages 2 - 6.

 TV Y7 is for Older Children

Most parents would find such programs suitable for children 7 and above. These programs
may contain some mild fantasy violence or comedic violence, which children should be
able to discern from reality.

Programs with the following ratings are designed for the entire audience.
 TV G stands for General Audience

Most parents would find these programs suitable for all age groups. They contain little or
no violence, no strong language, and little or no sexual dialog or situations.

 TV PG Parental Guidance Suggested

May contain some, but not much, strong language, limited violence, and some suggestive
sexual dialog or situations. It is recommended that parents watch these programs first, or
with their children.

 TV 14 Parents Strongly Cautioned

Programs contain some material that may be unsuitable for children under the age of 14
including possible intense violence, sexual situations, strong coarse language, or intensely
suggestive dialog. Parents are cautioned against unattended viewing by children under 14.

 TV MA Mature Audiences Only

These programs are specifically for adults and may be unsuitable for anyone under 17
years of age. TV MA programs may have extensive V, S, L, or D.

US V-Chip Ratings

Initial Setup

31

Viewing Guidelines

In addition to the ratings categories explained above, information on specific kinds of
content are also supplied with the V-Chip rating. These types of content may also be
blocked. The content types are:

• V/FV is for VIOLENCE/FANTASY VIOLENCE

• S stands for SEXUAL CONTENT

• L stands for strong LANGUAGE

• D stands for suggestive DIALOG

Initial Setup

32

Line up the cursor in the column (TV PG, TV G, etc.) with the content row (V/FV, S, etc.) and
press the

π† or

è

to move the cursor to the correct location. Press OK to turn the locking

feature on or off. An item is locked if the icon appears instead of a “—”.

For example. To block viewing of all TV 14 shows, move the cursor to the top row of that
column and add a lock icon. Once you’ve put a lock on the top row, everything in that column
is automatically locked.

π†

è

To the TV 14 Column

Press the OK button to lock

Press the MENU button when finished

Note:

• If you want to change the setup, move the cursor to the top
column and change the lock icon to “—” by pressing OK
again. You may then select individual categories to block.

Directions to set US V-Chip Ratings

Press the MENU button

π†

To V-CHIP

è

To operate (lock icon appears)

Press ZERO to access the V-Chip menu

è

To turn V-Chip ON or OFF

π†

To move to SET US TV RATINGS

è

To operate

Setting US V-Chip Ratings

Initial Setup

 NR – Not Rated

This is a film which has no rating. In many cases these films were imported from countries
which do not use the MPAA ratings system. Other NR films may be from amateur producers
who didn’t intend to have their film widely released.

NR (Not Rated) Programming may contain all types of programming including

children’s programming, foreign programs, or adult material.

 G – General Audience

In the opinion of the review board, these films contain nothing in the way of sexual content,
violence, or language that would be unsuitable for audiences of any age.

 PG – Parental Guidance

Parental Guidance means the movie may contain some contents such as mild violence,
some brief nudity, and strong language. The contents are not deemed intense.

 PG-13 – Parents Strongly Cautioned

Parents with children under 13 are cautioned that the content of movies with this rating
may include more explicit sexual, language, and violence content than movies rated PG.

 R – Restricted

These films contain material that is explicit in nature and is not recommended for
unsupervised children under the age of 17.

 NC-17 – No One Under 17

These movies contain content which most parents would feel is too adult for their children
to view. Content can consist of strong language, nudity, violence, and suggestive or explicit
subject matter.

 X – No One under 18

Inappropriate material for anyone under 18.

Movies Ratings

Press the MENU button

π†

To V-CHIP

è

To operate (Lock icon appears)

Press ZERO to access V-Chip setup options

π†

To SET MOVIE RATINGS

è

To enter movies menu

For example:

To block viewing of X and NC-17 rated from shows:

π†

è

To the X Column

Press the OK button to lock

π†

è

To the NC-17 Column

Press the OK button to lock

Press the MENU button to finish

Directions to set Movie (MPAA) Ratings

33

Press the MENU button

π†

To V-CHIP

è

To operate (lock icon appears)

Press ZERO to access V-Chip setup options

π†

To SET CANADIAN RATINGS ENG (for English)

è

To enter ratings menu

For example:

To block viewing of programming rated 14+ and 18+:

è

To the 18+ Column
Press the OK button to lock

è

To the 14+ Column

Press the OK button to lock

Press the MENU button to finish

Note:

• For instructions on “SET CANADIAN RATINGS FRE (in French)”, please see page 34 in the

French side of this user’s guide.

Directions to set Canadian V-Chip Ratings

 E – Exempt

Exempt programming includes: news, sports, documentaries and other information
programming, talk shows, music videos, and variety programming.

 C – Programming Intended for Children

Violence Guidelines: There will be no realistic scenes of violence. Depictions of aggressive
behavior will be infrequent and limited to portrayals that are clearly imaginary, comedic or
unrealistic in nature.

 C8+ – Programming Intended for Children 8 and Over

Violence Guidelines: Any realistic depictions of violence will be infrequent, discreet, of low
intensity and will show the consequences of the acts. There will be no offensive language,
nudity or sexual content.

 G – General Audience

Programming will contain little violence and will be sensitive to themes which could affect
younger children.

 PG – Parental Guidance

Programming intended for a general audience, but which may not be suitable for younger
children. Parents may consider some content not appropriate for children aged 8-13.

 14+ – 14 Years and Older

Parents are strongly cautioned to exercise discretion in permitting viewing by pre-teens
and early teens. Programming may contain mature themes and scenes of intense violence.

 18+ – Adult

Material intended for mature audiences only.

Canadian V-Chip Ratings

Initial Setup

34

Channel guard and V-Chip settings are protected by a four-digit lock code. Your TV comes
pre-set with a lock code of “0000”. You may change the code to any four-digit number you
wish. To change the lock code, follow the steps below.

Press the MENU button

π†

To SET LOCK CODE

è

To operate (lock icon appears)

Press ZERO to access the lock code

The first digit will be highlighted

è

To select the number

π†

To move to the next digit

Continue to follow these directions for all four numbers

Press the OK button to finish (your lock code is now set)

Press the Menu button when finished

• After a power interruption you must reset the lock code.

• Write your lock code number down and keep it hidden from potential viewers.

• If you forget the lock code, a new code may be set using the steps listed above.

Notes:

When a viewer attempts to watch a blocked channel, this message appears:

The channel will remain blocked until the correct lock code is entered (see above for
information on setting your lock code).

THIS PROGRAMMING EXCEEDS
YOUR RATING LIMITS.
PLEASE ENTER LOCK CODE BY
10 KEY PAD TO UNLOCK IT.
NO. - - - -

Initial Setup

35

Set Lock Code

Initial Setup

This TV has three color projection tubes: one for red, green, and blue. When mixed together in
the proper portions, the output of these three color tubes can produce any color. To produce
these colors, however, the beams must be precisely aligned over each other so that the colors
can be mixed. The produce of aligning these picture beams is called “convergence”.

Attention:

• Please have your TV on for at least 20 minutes before using this feature.

• This adjustment will be needed only when the colors of the characters/lines are separated
and lack in distinction. If not, please don’t perform the adjustment.

Colors may become separated after the TV has been moved, or
over a long period of time if regularly subjected to low levels of
vibrations. If the colors become separated, please perform the
adjustments below again. In the beginning, please be sure to

perform AUTO convergence adjustment.

Press the MENU button

π†

To CONVERGENCE

è

To Enter

π†

To select “AUTO” (The convergence adjustment will

start. It will take about 50 seconds).

When the adjustment is finished, it will return to what you

were watching.

Note:

• You can reset the adjustment if you do not like the results. See the next page.

• If you want to adjust it more, you can perform the manual color convergence adjustment.
See the next page.

• You can also access this feature by pressing the channel up and channel down buttons
simultaniously on the front panel of your TV.

36

Adjusting CRT Color Convergence

Auto

Press the MENU button

π†

To CONVERGENCE

è

To Enter

π†

To choose MANUAL

è

To Enter

If all the lines are white, no convergence adjustment is
necessary. If not, you need to perform the manual color

convergence below.

Select the location you want to adjust by using the

number buttons on the remote control.

You can select any of the 81 points.

Press the SELECT button to change the color of the

box to the color of the cross you wish to adjust

(red or blue).

π†

è

Adjust the position of the cross.

Adjust the three color crosses until they overlap and appear as a single white

cross.

Press the OK button

Notes:

• When you adjust the convergence, make sure you start with the center position (position 5),
and work your way around radially for best results.

• When you make the adjustment in the center (position 5), you are making the adjustment
for the whole screen. In other positions, you are making the adjustment only in that area.

• You can reset the adjustment if you do not like the results. See below.

• If you perform AUTO CONVERGENCE after performing MANUAL CONVERGENCE, your
manual convergence you performed will be cancelled.

Initial Setup

37

Adjusting CRT Color Convergence (continued...)

Manual

Reset

RESET resets all convergence adjustments to the factory default settings.

Press the MENU button

π†

To CONVERGENCE

è

To Enter

π†

To RESET

è

To enter

When the adjustment is reset, it will return to what you were watching.

This function lets you preview the many different viewing modes of your TV. It will cycle
through “index”, “pop”, “split demo”, “freeze”, all of the different “aspect” ratios and all of the
different “video status” modes.

Press the MENU button

π†

To AUTO DEMO

è

To turn AUTO DEMO ON or OFF

Note: To stop auto demo, press the MENU button, and

select auto demo by pressing the

π†

buttons, and

turn it off by pressing the

è

buttons. Press the

MENU button to finish.

Auto Demo

Initial Setup

38

Power indicator allows you to adjust the brightness of
the power indicator

Press the MENU button

π†

To POWER INDICATOR

è

To adjust POWER INDICATOR LOW or HIGH

Position adjustment allows you to adjust the position of the picture on the screen vertically
when the aspect is set to panorama, cinema, or full.

Press the MENU button

π†

To POSITION ADJUSTMENT

è

To enter

π†

è

To adjust the position

Press the MENU button to finish

Notes:

• To reset the adjustment to the center, press the OK button.

• When the arrow disappears, while you are adjusting the position, the position is at it’s
maximum limit.

• If you select regular size with aspect or Multi Screen, position adjustment option is not
seen.

• When you change the screen size, perform the position adjustment again.

• position adjustment allows you to adjust the screen position vertically and horizontally when
the aspect is set HD panorama or cinema zoom for 1080i signal.

Power Indicator

Position Adjustment

The DIGITAL-IN option can only be displayed in the INITIAL SETUP menu when a 480p picture
signal is being input to the DIGITAL-IN terminal.

This option adjusts the position when a 480p picture signal is being displayed on the screen.

There are two types of 480p picture signals: 640x480 and 720x480. If the displayed picture is
slightly shifted, the position can be adjusted by selecting either SIZE1 or SIZE2.

Press the MENU button

π†

To DIGITAL-IN

è To enter

è To select SIZE1 or SIZE2

Press the MENU button to finish

Note:

The DIGITAL-IN menu can only be displayed when a 480p picture signal is input to the
Digital-In terminal and the picture is being displayed on the screen.

Digital-In

Initial Setup

39

If your TV is connected to a stereo system, you can turn off the TV speakers and listen to the
audio through your stereo.

Press the MENU button

π†

To TV SPEAKER

è

To turn the TV’s speakers ON or OFF

Press the MENU button when finished

Notes:

• Before you turn the TV speaker setting from OFF to
ON, make sure that the TV volume level is low! If
the TV volume is set too high, the sound level will be extremely loud.

• After a power interruption, the TV speaker settings will return to “ON”.

TV Speaker

When you are using a surround system, you can substitute the speaker of this television for
the center speaker of you surround system. Set CENTER CH INPUT to on when you use the
speaker as the center speaker of your surround system.

Press the MENU button

π†

To CENTER CH INPUT

è

To adjust CENTER CH INPUT to “ON” or “OFF”

Press the MENU button when finished

The language function is described on page 18 as the interactive plug-in menu. If you need to
choose the language again, follow the steps below.

Press the Menu button

π†

To LANGUAGE

è

To choose a language: ENG. (English), FRAN.

(French) or ESP. (Spanish)

Press the MENU button when finished

Language

If your television is connected to an external speaker source, audio out gives you the option of
controlling the volume level with your TV’s remote control.

Press the MENU button

π†

To AUDIO OUT

è

To VARI or FIX

Press the MENU button when finished

VARI: Lets you adjust the volume of the external speakers
using the VOLUME +/– buttons on your TV’s remote control.

FIX: The volume of the external speakers is adjusted using
the audio device’s remote control.

Initial Setup

40

Audio Out

Center CH Input

Many broadcasts now include an onscreen display of dialog called closed captions. Some
broadcasts may also include displays of additional information in text form. Your television
can access and display this information using the closed caption feature. To activate the
closed caption feature, follow the steps below.

Press the MENU button

π†

To CLOSED CAPTION

è

To operate

π†

To select CAPTION or TEXT

è

To select a caption (CC1 to CC4) or text channel

(T1 to T4)

Press the OK button to save

Press the MENU button when finished

• Closed caption subtitles are usually found on closed caption channel CC1. Some programs
may include additional text information which is usually found on text channel T1. The other
channels are available for future use.

• Closed captioning may not work correctly if the signal being received is weak or if you are
playing a video tape.

• Most broadcasts containing closed captioning will display a notice at the start of the
program.

• To select the mode, press the C.C. button. See page 56.

Notes:

Closed Caption

This feature inserts a blank gray screen over channels which are not broadcasting or are too
weak to be received clearly.

Press the MENU button

π†

To NOISE MUTING

è

To turn noise muting ON or OFF

Press the MENU button when finished

Note:

• Noise muting will not work during auto tuner setup or when
you operate channel summary.

Noise Muting

Initial Setup

41

This allows you to lock the keys on the front of the TV, so that a child may not accidentally
change your viewing preferences.

Press the MENU button

π†

To FRONT PANEL LOCK

è

To turn ON or OFF

Press the MENU button when finished

Initial Setup

42

Front Panel Lock

You can turn off this feature in the following ways:

• Unplug the power cord, and plug it back in. Do this if
your batteries die, or you lose your remote control.

• Use the remote control.

• Press the MENU button on the front of the TV for more than 3 seconds. In this case, the
OSD for FRONT PANEL LOCK will appear.

Note:

• To turn ON/OFF the TV, press the power button for more than 3 seconds. This feature will
remain ON.

This function automatically shuts off your TV when there is no signal from the channel the
TV is on.

Press the MENU button

π†

To AUTO SHUT OFF

è

To turn ON or OFF

Press the MENU button when finished

• If the channel that you have on does not receive a
signal for more than one minute, the blinking text
“NOT RECEIVING A SIGNAL” appears on the screen, and
starts the countdown. If no signal is being received within
10 minutes, the TV shuts itself off.

XDS ID Display provides a channel’s call letters, the network’s name, and even a program
name. The XDS ID information is provided by the broadcaster.

Press the MENU button

π†

To XDS ID

è

To turn ON or OFF

Press the MENU button when finished

Auto Shut Off

XDS ID

Press the MENU button

π† To TINT, COLOR, PICTURE, BRIGHT or

DETAIL

√ ®

To enter

√ ®

To adjust the setting

π†

To move to the next setting

Press the MENU button when finished

These settings allow you to change and adjust the way the picture appears on your television.

TINT

Tint allows you to adjust the levels of red and green in your TV picture.

COLOR

The color function lets you make all the colors in the TV picture appear either more vivid or
subtle.


Picture allows you to adjust the levels of black and white on the TV screen, giving you a
darker or brighter picture overall.

BRIGHT

You can adjust the overall brightness of the TV picture with the Bright control.

DETAIL

The Detail feature adjusts the level of fine detail displayed in the picture.

Picture Adjust

43

Picture Settings

Adjust the Picture Settings

Color Temperature

You can decide how strong or dull the colors appear on the TV screen.

Press the MENU button

π†

To COLOR TEMPERATURE

è

To enter

è

To set LOW or HIGH

Press the MENU button when finished

Velocity scan modulation circuitry varies the electron beam’s horizontal scanning speed to
help accentuate the differences in picture brightness to sharpen the edges of images.

Press the MENU button

π†

To VSM

è

To enter

è

To turn VSM ON or OFF

Picture Adjust

44

(VSM) Velocity Scan Modulation

With digital noise clear, this helps take our static or noise from a channel that may not be
coming in clearly.

Press the MENU button

π†

To DIG. NOISE CLEAR

è

To enter

π†

To select the mode “LOW”, “HIGH” or “OFF”

Press the MENU button when finished

Digital Noise Clear

Reset

Reset resets all picture adjustments (tint, color, picture, bright, detail, color temperature, dig.
noise clear and VSM) at once to the default settings.

Press the MENU button

π†

To RESET

è

To enter

The onscreen menu disappears for a moment, and

then the settings are reset to the default setting for
all the picture adjustments.

Press the MENU button when finished

MTS technology allows several audio signals to be broadcast at once, giving you a choice
in what you wish to hear with a TV program. In addition to mono or stereo sound, an
MTS broadcast may also include a second audio program (SAP).

Press the MENU button

π†

To MTS

è

Select the mode

(The ON AIR arrow tells you if a broadcast is in stereo and/or
contains an SAP).

Press the MENU button when finished

Notes:

• Keep the TV in stereo mode to get the best sound quality. The sound will work in stereo
mode even if a certain broadcast is in mono sound only.

• Choose the mono setting to reduce excessive noise on a certain channel or broadcast.

• Selecting SAP will allow you to hear an alternative soundtrack, if one is available.

• MTS unavailable if your television’s input source is in input 1, 2, 3 or 4 mode, as described
on page 51.

These settings allow you to change and adjust the way the picture appears on your television.

BASS – You can increase or decrease the level of low-frequency sound in the TV’s audio with

the bass adjustment.

TREBLE – Use treble to adjust the level of high-frequency sound in your TV’s audio.

BALANCE – Adjust the level of sound between the TV’s left and right speakers with the

balance setting.

Press the MENU button

π† To BASS, TREBLE or BALANCE

√ ®

To adjust the setting

π†

To move to the next setting

Press the MENU button when finished

Note:

• You can reset the sound adjustments (BASS, TREBLE and BALANCE) you set at once as
the default setting when you select reset. See page 44.

• You can adjust BALANCE only when A.H.S. is off. See page 52.

Sound Adjust

45

Sound Settings

MTS (Multi-Channel Television Sound)

Adjust the Sound Settings

Clock/Timers

46

Set Clock

The set clock function is described on page 19 as the interactive plug-in menu. You can
choose to set the clock automatically, or manually. If you need to set the clock again, follow
the steps below.

Press the MENU button

π†

To SET CLOCK

è

To operate

When you set the clock automatically, choose AUTO by pressing the √ or ® arrows.

π†

To TIME ZONE

è

To select your time zone

π†

To D.S.T. (daylight savings time)

è

To turn D.S.T. ON or OFF

Press OK to finish

Press the MENU button when finished

When you set the clock manually, choose MANUAL by pressing the √ or ® arrows.

π†

To move to the hour

è

To set the hour

π†

To move to minutes

è

To set the minutes

Press OK to start clock

Press the MENU button when finished

The on/off timer lets you program your television to turn itself on or off. You can use it as an
alarm to wake up, to help you remember important programs, or as a decoy when you’re not
home.

Press the MENU button

π†

To ON/OFF TIMER

è

To operate (begins with ON TIME)

è

To set the hour (AM/PM) you want the TV to turn on

†

To move to minutes

è

To set the minutes

†

To accept ON TIME and move to OFF TIME (the time

the TV will turn off). Set the OFF TIME the same way as ON TIME

†

To accept OFF TIME and move to CHANNEL

è

To select channel

†

To ON VOLUME

è

To set the volume level

†

To move to MODE

è

Choose ONCE or EVERYDAY

†

To ON/OFF TIMER

è

Choose YES to accept the timer setting, choose NO if you don’t wish to accept

Press the OK button to finish

Press the MENU button to exit the menu

• The on/off time cannot be set to locked or guarded channels.

• In order for the on/off timer to work, the clock must be set.

• After a power interruption, the timer settings must be reset.

Notes:

Clock/Timers

47

On/Off Timer

Your television has three kinds of screen: SPLIT (2 channels), POP (4 channels), and INDEX
(12 channels).

Two channels (or input) will now appear onscreen.
The channel (or input) you were watching before
pressing SPLIT will appear on the left, the new
channel will appear on the right. The sound will
continue to come from the main screen channel (or
input). To turn split-screen off and return to normal
television viewing, press SPLIT again or press the
BACK button.

Activate the split-screen option by pressing SPLIT on the remote control.

Note:

• You can enter the SPLIT mode when the screen is in NORMAL, POP or INDEX mode.

• Split-screen functions will not work with locked channels or channels blocked by V-Chip
ratings limits. A grey screen will display instead.

• With split screen, the picture from the component terminal and HDCP terminal will not be
displayed.

• The aspect of MAIN CHANNEL PICTURE becomes 16:9 when you input the picture of
480p, 720p and 1080i from the component terminal and HDCP terminal.

• After you press the SELECT button, and select SPLIT SCREEN when you press the
OK button, select normal screen. If you don’t operate, the MAIN CHANNEL SCREEN will
be automatically selected about 8 seconds later.

• Main channel picture and split-screen will not display the same RF channel.

Button Functions

48

Multi Screen Function

Split

Note: After you press any multiscreen button, if you press the menu button, only the picture

adjust screen will appear.

You can view three separate pictures (still images) on screen on the right side of the TV’s main
picture. The picture of the still image will be renewed in order (from top to bottom).

To change the channel of separate pictures:

• Press the SELECT button and select the separate picture which you want to change. Press
the NUMBER buttons and select the channel.

To display the channel of the separate picture on the full screen:

• Press the SELECT button and select the separate picture which you want to display on the
full screen. Press the OK button.

Notes:

• This function will not work when the picture from all external input is displayed.

• SWAP function will not work.

Cable Box Note:

The 2–Tuner Multi Screen function may not operate when used with certain cable boxes. This
is because while some models of cable boxes may receive up to 181 channels, and may
only send the signal from one channel to your television. (Please refer to diagram on page

12). For the 2–Tuner Multi screen function to operate correctly, it must have access to all

available channels. Since the television is receiving the signal from only one channel from the
cable box, it is impossible for the 2–Tuner Multi screen function to display a second, different
channel. Because there are many different models of cable boxes in use today, if you are
having problems operating your 2–Tuner Multi screen function feature with your cable box, we
recommend you contact your local cable company for connection advice.

MAIN PICTURE

SEPARATE PICTURES

Button Functions

49

This allows you to quickly look at up to 12 channels at a time so that you can decide which
one to watch.

Notes:

• Only RF input signal will be displayed.

• You can watch the channel added in channel summary. See page 28.

Index

POP

You can exchange the channel (or input) displayed in the split screen window for the main
screen image by pressing the SWAP button.

Note: This function will not work with POP screen. It will only work in SPLIT mode.

Freeze

Swap

With SELECT, you can select the picture (channel) while viewing POP or SPLIT screen. When
you press SELECT button, the channel number on the top will be highlighted. Each press of
SELECT will shift the channel.

Button Functions

50

Select

EZ-Surf allows you to surf all the available channels so that you don’t have to change your
current program to see what else is on TV.

Press the EZ SURF button.

• When you press the EZ SURF button, it will scan
through all the channels you can recieve, and display
the channel information on the lower of the TV screen.

• If you are using the POP/INDEX feature, it will be
cancelled when you press the EZ SURF button.

• When you are in SPLIT MODE and you press the
EZ SURF button, your TV screen will look like this. The
left side is the current program, and the right side will
scan through all of the available channels you can
recieve.

EZ-Surf

Note: When the screen is in freeze mode, if you do not operate it within 15 minutes, this

function will cancel out.

Pressing the FREEZE button causes the screen to change to the split-screen display with the
still picture displayed on the right. In order to return to the normal display, press the FREEZE
button once again.

Button Functions

51

Turns the TV on or off.

Press the POWER button

Use the number buttons on the remote control to move directly to a specific channel. For
example, to move to channel 7:

0 (Zero)

7 (Seven)

Power

Number Buttons - 10Key Pad

Use the 100+ button to directly access channels above channel 99. For example, to move to
channel 124, press 100+, 2 (Two), 4 (Four).

100+ Button

Selects the signal input source for the television: Input-1, 2, 3 or 4 for video devices like
VCR’s DVD players, or camcorders.

INPUT 1, 2, 3, 4

Note:

• When you return to TV mode, press the RETURN +/TV button or direct 10 key pad.

Input

Digital-In

Use this button to directly select the digital-in input.

Press the DIGITAL-IN button

• Digital-In will display only when the 480p picture signal in Digital-In is displayed.

The return+/TV button has three functions:

Return - Returns to the channel viewed just before the channel currently onscreen.

Return+ - Lets you program a specific channel to return to while scanning through the

channels using the CH+ and CH– buttons.

TV - Returns to the TV mode.

RETURN+/TV and hold for three seconds

The channel currently active has been programmed as your return+ channel. Now scan

through the channels using the CHANNEL+/– buttons.

RETURN+/TV

You will return to your programmed channel.

• To cancel your return+ channel, press and hold the RETURN+ button for three seconds. The
message “RETURN CHANNEL CANCELLED!” will appear.

• Return+ works only with the Channel+/– buttons. Pressing any number key will cancel
return+.

RETURN CHANNEL

PROGRAMMED !

Button Functions

52

Return +/TV

By pressing the sound button, you can change the A.H.S. (Advanced Hyper Surround) mode
and BBE on or off.

A.H.S. - Adds a more spacious surround sound. Music gives basic effect and movie for more
effect.

BBE - BBE high definition audio adds natural, clear and extraordinary sound quality to any
program.

Press the SOUND button

π†

To select A.H.S. or BBE

è

To choose the setting

Press the MENU when finished

Note: BBE is a registered trademark of BBE Sound, Inc. For U.S., licensed from
BBE Sound, Inc. under USP 4638258, 4482866 and 5510572. For Canada, licensed from
BBE Sound, Inc. BBE is a registered trademark of BBE Sound, Inc.

Sound

The MUTING button instantly turns the volume down completely when you press it. Press
MUTING and the volume level will instantly go to zero. To restore the volume to its previous
level, press MUTING again.

Muting

The Video status button gives you a choice of four TV picture display settings, including a
display of your own preferences.

Standard - Resets the picture display to the factory settings.

Dynamic - Gives a vivid picture with better contrast when viewing

in a brightly lit room.

Theater - Gives a rich, film-like look to video when viewing in a

dimly lit room.

Game - Used for when you are playing video games connected to

your TV.

Press the VIDEO STATUS button
By every press of the VIDEO STATUS button, you change the mode.

Note: You can also change the mode by pressing the π† buttons.

Video Status

Button Functions

53

Natural cinema corrects the problem of blurred edges which may occur when viewing a program
originally shot on film (such as motion pictures) or animation. If you notice blurring at the edges
of these programs, press NATURAL CINEMA and set it to AUTO. Natural Cinema helps correct
conversion errors that occur when film, which is shot at 24 frames-per-second, is broadcast at
the television rate of 30 frames-per-second.

Press the NATURAL CINEMA button

Notes: The natural cinema mode is automatically set to “AUTO” in

the following cases:

• Turning on or off

• Changing the channel or input mode

• Using multi-screen functions

Natural Cinema

The TheaterPro D6500K color temperature technology function makes sure that the video you
watch is set to the standard color temperature, so that what you see is as true to what the
film to video editors intended it to be.

Press the THEATERPRO button

TheaterPro D6500K

Button Functions

54

The Sleep Timer can turn the TV off for you after you fall asleep. Program it to work in
intervals of 15 minutes, for a total time of up to 180 minutes.

Press the SLEEP TIMER button

Sleep Timer Message

20 seconds before the automatic shutoff, this message will appear:

You then have 20 seconds to press the SLEEP TIMER button to

delay the shut off for another 15 minutes.

GOOD NIGHT!!

PUSH SLEEP TIMER BUTTON

TO EXTEND.

Sleep Timer

The display screen shows the current status of timers, inputs, and XDS ID.

Press the DISPLAY button

The screen to the right shows the following information:

•

The current channel or AV input (Channel 05)

• The current time (12:20 pm)

• Sleep timer status/minutes remaining (The Sleep Timer
is off)

• On/off timer status (Set to turn on everyday at 7:00 PM,
off at 10:00 PM)

• Each Press of the DISPLAY button changes the display
mode:

Display - Full screen shown above

Time - Shows the current time only

Channel - Shows the current channel

Off - Turns display off

Notes:

• You may also turn off the display at any step by pressing MENU.

• If the clock, sleep timer or on/off timer are not set, the display screen will show:
“CLOCK NOT SET”, “SLEEP TIMER OFF”, and “ON/OFF TIMER OFF” respectively.

Display

This feature will help you adjust the picture you are watching to give you the best possible
picture quality.

REGULAR - The regular ratio is used
when you want to watch a 4:3 broadcast
or recorded program without modifying
the original picture to fit the dimensions
of your 16:9 screen. The 4:3 picture
will fil lthe screen from top to bottom,
while black bars will appear to fill up the
remaining space along the picture’s sides.
The 4:3 picture will be centered within the
boundaries of the 16:9 screen.

Button Functions

55

Aspect

Aspect Ratios

PANORAMA - With this ratio a normal

4:3 aspect picture is stretched to fit the
dimensions of the 16:9 aspect screen.

CINEMA - This ratio “zooms in” on
the center part of a 4:3 aspect picture,
blowing it up to fill the 16:9 screen.

FULL - This is the ratio to use when
watching 16:9 High-Definition broadcasts.

HD PANORAMA - This ratio streches
the High-Definition 16:9 aspect image to
eliminate the black side bars.

CINEMA ZOOM - This ratio streches
the High-Definition 16:9 aspect image to
eliminate the black surrounding bars.

The MENU button allows you to access JVC’s onscreen menu system. Press MENU to activate
the onscreen menu system.

• See individual topics like “Sound Adjust” for specific information on using menus.

Menu

C.C. (Closed Caption)

Button Functions

56

Back

OK

Use the C.C. (Closed Caption) button to select the mode of closed
caption.

Press the C.C. button

• See page 41 when you set the caption/text mode.

This button allows you to go back in the menu to change a selection or correct a mistake.

This button confirms your selection when you are in one of the onscreen menus.

When you change the aspect ratios, it is different from their broadcast or recorded program.

Aspect Ratios (Continued)

Press the ASPECT button

• By pressing the ASPECT button, you can change the size.

NTSC, 480i, 480p,

HDCP 480p

HD, HDCP 1080i

720P, HDCP 720p

Notes:

• You can also choose the size by pressing the

π† buttons.

• When you change the aspect ratio or signal, reset the picture position to center.

Use either the television’s own tuner or a cable box to select channels. Set this switch to TV
to operate the television’s built-in tuner. Move the switch to CATV to operate a cable box.

Note:

• See page 21 for information on programming your remote for cable box operation.

You can control a VCR or DVD player with the buttons on the lower part of the remote control.
Move the slide switch to VCR or DVD to operate.

Notes:

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other
manufacturer’s brand VCR, please see the code chart and instructions on page 22.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other
manufacturer’s brand DVD player, please see the code chart and instructions on page 23.

TV/CATV Slide Switch

VCR/DVD Slide Switch

You can also use this remote control to operate the basic functions of your DVD player. These
functions include: play, rewind, fast-forward, stop, still/pause, previous/next, tray open/close,
power on, and power off.

Move the selector switch to DVD to operate.

• The remote is preset with the code 000 to control JVC-brand DVD players. For any other
manufacturer’s brand DVD player, please see the code chart and instructions on page 23.

You can use this remote control to operate the basic functions of your VCR. These functions
include: play, record, rewind, fast-forward, stop, pause, channel scan, TV/VCR, power on, and
power off.

Move the selector switch to VCR to operate.

• The remote is preset with the code 000 to control JVC-brand VCR’s. For any other
manufacturer’s brand VCR, please see the code chart and instructions on page 22.

Button Functions

VCR Buttons

DVD Buttons

57

Your remote control includes illuminated buttons for key features like Channel +/– and
Volume +/–. Press the light button to turn the illumination on for 4 seconds.

Light

Troubleshooting

58

Troubleshooting

59

The following are not malfunctions.

• The television may make a creaking sound if the temperature of the room or the temperature
of the inside of the television changes. If there is no problem with the screen or sound, then
there is no need to worry.

• The operation of this television is not guaranteed below 0°C. If the power is turned on when
the temperature is below 0°C, the picture may be disturbed. Use the television when the
temperature is 0°C or higher.

• Although the picture may be temporarily disturbed and noise may be seen on the screen if
the power is turned on immediately after it has been turned off, this is not a malfunction.

Refer to the table below to check the condition. If you think that there is a problem, contact
the JVC Service Center where you purchased the television.

Caring for the Cabinet

Normally, light dusting with a soft, non-scratching duster will keep your TV clean.

If you wish to wipe down the television, first unplug it. Then wipe gently with a soft cloth,
slightly moistened with water. You can add a few drops of mild liquid detergent to the water to
help remove spots of oily dirt.

DO NOT allow liquid to enter the TV through the ventilation slots.

DO NOT use strong or abrasive cleaners on the TV.

DO NOT spray liquids or cleaners directly on the TV’s surface.

DO NOT rub or scrub the TV harshly. Wipe the set gently with a soft cloth.

Caring for the Screen

The screen is treated with an electrostatic-proof coating. When it gets dirty, wipe it gently with
a soft cloth. If the screen is very dirty, wipe it down with a cloth dipped in a diluted kitchen
cleaner and thoroughly wrung-out. Then wipe immediately after with a clean, dry cloth.

Do not apply alcohol, organic solvents (like acetone), acidic or alkaline cleansers to the
screen. These will remove the coating layer and cause discolorations.

Do not push or hit the screen. This could cause scratches on the screen surface and image
distortions.

Warnings

60

61

JVC COMPANY OF AMERICA warrants this product and all parts thereof, except as set forth
below ONLY TO THE ORIGINAL PURCHASER AT RETAIL to be FREE FROM DEFECTIVE
MATERIALS AND WORKMANSHIP from the date of original retail purchase for the period shown
below. (“The Warranty Period”)

This limited warranty is valid only in the fifty (50) United States, The District of Columbia
and Commonwealth of Puerto Rico.

WHAT WE WILL DO:

If this product is found to be defective within the warranty period, JVC will repair or replace
defective parts at no charge to the original owner.
Such repair and replacement services shall be rendered during regular business hours by JVC
authorized service centers. Parts used for replacement are warranted only for the remainder of
this Warranty Period. Televisions with a screen size of 25 inches and larger are covered on
an in-home basis.

WHAT YOU MUST DO FOR WARRANTY SERVICE:

Either contact the selling dealer (retailer) or call 1-800-252-5722 to arrange In-home
service. In-home service will require clear access to the Television by the service
technician.

WHAT IS NOT COVERED:

This limited warranty provided by JVC does not cover:

1. Products which have been subject to abuse, accident, alteration, modification, tampering,
negligence, misuse, faulty installation, lack of reasonable care, or if repaired or serviced by
anyone other than a service facility authorized by JVC to render such service, or if affixed
to any attachment not provided with the products, or if the model or serial number has
been altered, tampered with, defaced or removed. AV-65WP74 ONLY: If the upper unit is
removed from the lower unit by anyone other than a dealer or service facility authorized by
JVC.

2. Initial installation, installation and removal from “built-in” entertainment centers and other
mounting systems.

3. Operational adjustments covered in the Owner’s Manual, normal maintenance, including
head cleaning.

4. Damage that occurs in shipment, due to an act of God, and cosmetic damage.

5. Signal reception problems and failures due to line power surge.

6. Products used for commercial purposes (including but not limited to rental).

7. Accessories.

8. Batteries (except that Rechargeable Batteries are covered for 90 days from date of
purchase).

There are no express warranties except as listed above.

PARTS 1 YEAR

LABOR 1 YEAR

Warranty

62

Warranty

THE DURATION OF ANY IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILTY, IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY HEREIN.

JVC SHALL NOT BE LIABLE FOR THE LOSS OF USE OF THE PRODUCT, INCONVENIENCE,
OR ANY OTHER DAMAGES, WHETHER DIRECT, INCIDENTAL OR CONSEQUENTIAL
(INCLUDING, WITHOUT LIMITATION, DAMAGE TO TAPES, RECORDS OR DISCS)
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH
OF THIS WARRANTY, ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, ARE
LIMITED TO THE WARRANTY PERIOD SET FORTH ABOVE.

Some states do not allow the exclusion of incidental or consequential damages or limitations
on how long the warranty lasts, so these exclusions or limitations may not apply to you. This
warranty gives you specific legal rights and you may also have other rights which vary state
to state.

JVC COMPANY OF AMERICA 1700 Valley Road
DIVISION OF JVC AMERICAS CORP. Wayne, New Jersey 07470

http://www.jvc.com

REFURBISHED PRODUCTS CARRY A SEPARATE WARRANTY. THIS WARRANTY DOES
NOT APPLY. FOR DETAILS OF REFURBISHED PRODUCT WARRANTY, PLEASE REFER
TO THE REFURBISHED PRODUCT WARRANTY INFORMATION PACKAGED WITH EACH
REFURBISHED PRODUCT.

For customer use:

Enter below the Model No. and Serial No. which is located either on the rear, bottom or
side of the cabinet.

Retain this information for future reference.

Model No.: Serial No.:
Purchase Date: Name Of Dealer:

Authorized Service Centers

63

QUALITY SERVICE

HOW TO LOCATE YOUR JVC SERVICE CENTER

TOLL FREE: 1 [phone]

http://www.jvc.com

Dear Customer,

In order to receive the most satisfaction from your purchase, please read the instruction
booklet before operating the unit. In the event that repairs are necessary, call our Customer
Relations Department at 1-800-537-5722 or visit our website at www.JVC.com

Remember to retain your Bill of Sale for Warranty Service.

Don’t service the television yourself

Caution

To prevent electrical shock, do not open the cabinet. There are no user serviceable parts
inside. Please refer to qualified service personnel for repairs.

Accessories

To purchase accessories for your JVC product, please call toll free:1 [phone] or on the
web at www.JVC.com

Specifications subject to change without notice.

Specifications

JVC COMPANY OF AMERICA

Division of JVC Americas Corp.

1700 Valley Road

Wayne, New Jersey, 07470

JVC CANADA, INC.

21 Finchdene Square

Scarborough, Ontario

Canada, M1X 1A7
