JVC GZ-R495 User Manual

Basic User Guide

CAMCORDER

GZ-R495AE
GZ-R495BE
GZ-R495DE
GZ-R495WE

B5A-2472-01

EN

Detailed User Guide

.

For more details on operating this
product, please refer to the “Detailed
User Guide” at the following website.

http://manual3.jvckenwood.com/index.html/

o

Dear Customers

Thank you for purchasing this JVC product.
Before use, please read the Safety Precautions and Cautions on
ensure safe use of this product.

Mobile User Guide

.

When you are outside, refer to
the “Mobile User Guide”.
Mobile User Guide can be
viewed with standard browser
for Android tablet and iPhone.

http://manual3.jvckenwood.com/mobile/eu/

o

p. 2 and p. 15 to

Safety Precautions

Blue to N
(Neutral) or Blac

k
Brown to L (Live)
or Red

IMPORTANT (for owners in the U.K.)
Connection to the mains supply in the
United Kingdom.

DO NOT cut off the mains plug from
this equipment.

If the plug fitted is not suitable for the
power points in your home or the cable is
too short to reach a power point, then
obtain an appropriate safety approved
extension lead or consult your dealer.

BE SURE to replace the fuse only with an
identical approved type, as originally
fitted, and to replace the fuse cover.
If nonetheless the mains plug is cut off be
sure to remove the fuse and dispose of the
plug immediately, to avoid possible shock
hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a
mains plug then follow the instructions
given below:

DO NOT make any connection to the
Larger Terminal coded E or Green.
The wires in the mains lead are coloured
in accordance with the following code:

.

If these colours do not correspond with the
terminal identifications of your plug,
connect as follows:
Blue wire to terminal coded N (Neutral) or
coloured black.
Brown wire to terminal coded L (Live) or
coloured Red.
If in doubt — consult a competent
electrician.

CAUTIONS:

0

To prevent shock, do not open the
cabinet. No user serviceable parts
inside. Refer servicing to qualified
personnel.

0

When you are not using the AC adapter
for a long period of time, it is
recommended that you disconnect the
power cord from AC outlet.

CAUTION:

A built-in lithium-ion battery is inside the
unit. When discarding the unit,
environmental problems must be
considered and the local rules or laws
governing the disposal of these batteries
must be followed strictly.

NOTES:

0

The rating plate and safety caution are on
the bottom and/or the back of the main unit.

0

The serial number plate is on the bottom
and/or the back of the main unit.

0

The rating information and safety caution
of the AC adapter are on its upper and/
or lower sides.

WARNING:

The camcorder with battery installed
should not be exposed to excessive heat
such as direct sunlight, fire or the Iike.

CAUTION:

The mains plug shall remain readily
operable.

0

Remove the mains plug immediately if
the camcorder functions abnormally.

CAUTIONS:

0

Be sure to use the supplied AC adapter.

0

Do not use the supplied AC adapter with
other devices.

CAUTION:

To avoid electric shock or damage to the
unit, first firmly insert the small end of the
power cord into the AC Adapter until it is
no longer wobbly, and then plug the larger
end of the power cord into an AC outlet.

.

2 EN

Do not point the lens directly into the sun.
This can cause eye injuries, as well as
lead to the malfunctioning of internal
circuitry. There is also a risk of fire or
electric shock.

CAUTION!

The following notes concern possible
physical damage to this unit and to the
user.

Carrying or holding this unit by the LCD
monitor can result in dropping the unit, or
in a malfunction.

Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious
damage to the unit.

CAUTION!

Connecting cables (Audio/Video, etc.) to
this unit and leaving it on top of the TV is
not recommended, as tripping on the
cables will cause this unit to fall, resulting
in damage.

.

Information on Disposal of Old
Electrical and Electronic Equipment
and Batteries (applicable for
countries that have adopted separate
waste collection systems)

Products and batteries with the symbol
(crossed-out wheeled bin) cannot be
disposed as household waste.

Old electrical and electronic equipment
and batteries should be recycled at a
facility capable of handling these items
and their waste byproducts.

Contact your local authority for details in
locating a recycle facility nearest to you.
Proper recycling and waste disposal will
help conserve resources whilst
preventing detrimental effects on our
health and the environment.

Notice: The sign “Pb” below the symbol
for batteries indicates that this battery
contains lead.

SOME DO’S AND DON’TS ON THE SAFE
USE OF EQUIPMENT

This equipment has been designed and
manufactured to meet international safety
standards but, like any electrical equipment,
care must be taken if you are to obtain the
best results and safety is to be assured.

DO read the operating instructions before
you attempt to use the equipment.

DO ensure that all electrical connections
(including the mains plug, extension leads and
interconnections between pieces of
equipment) are properly made and in
accordance with the manufacturer’s
instructions. Switch off and withdraw the mains
plug when making or changing connections.

DO consult your dealer if you are ever in
doubt about the installation, operation or
safety of your equipment.

DO be careful with glass panels or doors on
equipment.

DON’T continue to operate the equipment if
you are in any doubt about it working
normally, or if it is damaged in any way —
switch off, withdraw the mains plug and
consult your dealer.

DON’T remove any fixed cover as this may
expose dangerous voltages.

DON’T leave equipment switched on when
it is unattended unless it is specifically stated
that it is designed for unattended operation
or has a standby mode. Switch off using the
switch on the equipment and make sure that
your family knows how to do this.
Special arrangements may need to be made
for infirm or handicapped people.

DON’T use equipment such as personal
stereos or radios so that you are distracted
from the requirements of road safety. It is
illegal to watch television whilst driving.

DON’T listen to headphones at high volume,
as such use can permanently damage your
hearing.

DON’T obstruct the ventilation of the
equipment, for example with curtains or soft
furnishings. Overheating will cause damage
and shorten the life of the equipment.

EN 3

DON’T use makeshift stands and NEVER fix
legs with wood screws — to ensure complete
safety always fit the manufacturer’s
approved stand or legs with the fixings
provided according to the instructions.

ABOVE ALL

0

NEVER let anyone especially children
push anything into holes, slots or any other
opening in the case — this could result in
a fatal electrical shock;

0

NEVER guess or take chances with
electrical equipment of any kind — it is
better to be safe than sorry!

This product is licensed under the AVC
Patent Portfolio License for the personal
use of a consumer or other uses in which
it does not receive remuneration to (i)
encode video in compliance with the AVC
standard (“AVC Video”) and/or (ii) decode
AVC Video that was encoded by a
consumer engaged in a personal activity
and/or was obtained from a video provider
licensed to provide AVC Video. No
license is granted or shall be implied for
any other use.

Additional information may be obtained
from MPEG LA, LLC.
See http://www.mpegla.com

Make a backup of important recorded
data

JVC will not be responsible for any lost
data. It is recommended to copy your
important recorded data to a disc or other
recording media for storage once every 3
months.

M/D on the unit denotes the month and
year of production.

.

This unit is equipped with Water
proof, Dust proof, Drop proof and
Freeze proof.

Water proof: Equivalent to IEC

Standard publication 529 IPX8
and IPX6 (1 hour at depths up to
5 m (16.4 ft))

Dust proof: Equivalent to IEC
Standard publication 529 IP5X

Drop proof: This camera clears
company testing compliant with
"MIL-STD-810F Method; 516.5
Shock: dropping onto plywood 3
cm thick from a height of 1.5 m"

Freeze proof: Allowable
operating temperatures: −10 °C
to +40 °C
Note: Temperatures between

−10 °C and 0 °C temporarily
lower battery performance,
reducing the time available for
recording.

Precautions for waterproof function

0

Malfunction due to misuse by the
customer is not covered by warranty.

0

Before use in water, be sure to read and
understand the “Detailed User Guide”.

0

Close the terminal cover firmly until it
clicks and confirm that the red sign
completely goes off.

0

Make sure that there is no damage to and
no foreign material adhered to the
packing inside the cover.

0

Use the camcorder in marine water and
fresh water not deeper than 5 m or for not
more than 1 hour.

0

The waterproof cannot be guaranteed if
the camcorder is subject to impact such
as dropping.

0

Do not jump or dive into water holding the
camcorder.

0

Do not use the camcorder in strong water
flows such as in rapids or under
waterfalls. The strong water pressure
may impair the waterproof performance.

0

Do not soak the camcorder in hot springs
or water of 40 °C or higher.

4 EN

Fogging inside the Lens

Open the terminal cover.

Lens protective glass

Models with waterproof function are airtight.
When the temperature rises during
recording, condensation can occur inside
the lens due to the internal humidity.

During recording

To prevent the temperature of this unit from
rising, we recommend that you use the unit
in the following ways.

Avoid frequent exposure to direct

A

sunlight.

Record under the shade or use an
umbrella. Best if you could keep a wet
towel cover the unit.

The use of a tripod is recommended.

B

Long hours of recording while holding the
unit in your hands will cause the
temperature of the unit to rise.

It is better to leave the terminal cover open

C

while recording.

However, the waterproof, dust-proof and
shockproof features do not function in this
condition. Do take note of the environment
when using the camera. (Do not use a wet
towel.)

Make sure to turn off the power when you

D

are not recording.

The power turns off when the LCD monitor
is closed.

During charging

It is recommended to charge the unit in a low
humidity environment.

The moist air inside the unit can cause
condensation.

We recommend that you charge the unit in a
room where humidifier is not in use, and in
an air-conditioned room during summer.

When fogging occurs inside the lens

Open the terminal cover to reduce the
temperature, close the LCD monitor and
leave the camera as it is for a while.

.

Protecting the Lens

There is a protective glass in front of the lens
to protect the lens.

0

If the protective glass is dirty, wipe clean
using a commercially available cleaning
cloth.

.

EN 5

Contents

Safety Precautions ................................. 2

Verifying the Accessories ...................... 6

Names of Parts and Functions ............... 7

Date and Time Setting
Open the terminal cover (SD card cover)

........................... 8

Getting Started

Charging the Battery ............................ 10

Inserting an SD Card ........................... 11

Recording

Video Recording .................................. 12

Video Quality ....................................... 13

...... 9

Playback

Playing Back/Deleting Files on this Unit

Further Information

Troubleshooting/Cautions ....................

Recordable Time/Specifications .......... 18

..... 14

Verifying the Accessories

AC Adapter

UIA312-0520

.

AV Cable

E3A-0085-00

.

0

Please

consult your JVC dealer or the nearest JVC service center when purchasing

a new AV cable.

0

Attach the lens cap when carrying the camera around and when the camera is not
in use.

Power Cord

.

Lens Cap

.

Adapter Cable

QAM1580-001

.

Core Filter

(for AV Cable)

.

USB Cable

(Type A - Micro Type B)

.

Basic User Guide

(this manual)

.

15

6 EN

Names of Parts and Functions

8

b

a

0

c

d

9

4

56

7

2

1

3

3 cm

To be connected to this unit

Release the
stopper.

Wind once

.

Lens Protective Glass

A

If the protective glass is dirty, wipe
using

a commercially available cloth.

Stereo Microphone

B

LCD Monitor

C

CHARGE (Charging) Lamp (p. 10)

D

POWER/ACCESS (Power/Access)

E

Lamp
Zoom/Volume Lever (p. 12, 14)

F

Strap Mount

G

Attaching the Core Filter

o

Attach the core filter to the AV Cable as shown in the illustration. The core filter
reduces interference when this unit is connected to other devices.

.

START/STOP (Video Recording)

H

Button (p. 12)
Terminal Cover (SD Card Cover)

I

SD Card Slot (p. 11

J

Reset Button

K

HDMI Mini Connector

L

AV Connector

M

USB Connector

N

)

EN 7

Date and Time Setting

SET DATE/TIME!

OK

201812 10 00

24

TIME

DATE

SAVE

DATE & TIME

GMT

SAVE

DATE & TIME/AREA

Open the LCD monitor.

1

.

0

The unit turns on. When the LCD
monitor is closed, the unit turns off.

Tap [OK] when [SET DATE/

2

TIME!] is displayed.

.

Set the date and time.

3

.

0

the day, month, year, hour, or

When
minute item is tapped, 3 and 2 will
be displayed.
Tap 3 or 2 to adjust the value.

0

Repeat this step to input the day,
month, year, hour, and minute.

After setting the date and

4

time, tap [SAVE].

Select the region where you

5

live and tap [SAVE].

0

Time difference between the
selected city and the GMT
(Greenwich Mean Time) is
displayed.

0

Tap 0 or 1 to select the city name.

.

8 EN

Open the terminal cover (SD card cover)

Not properly closed if the red mark is visible!

(Rear)

Open the LCD monitor.

A

Slide down the terminal cover

B

lock and slide the cover aside
Lift the cover slowly.

C

To close

o

Leave the LCD monitor open first.

A

B

C

(The cover is not properly closed if the red mark at the terminal cover lock is
visible.)

.

down the cover slowly while making sure the gray waterproof seal fits into

Flip
the opening at the terminals.

Press the entire cover against the camcorder with equal force and firmly attach
the cover completely.

Slide the cover until it clicks into place.

CAUTION

0

Do not apply excessive force when opening or closing the terminal cover.

0

Do not open or close the terminal cover with wet or dirt/sand-covered hands.

0

Do not allow any dirt, lint, hair, sand, and other foreign substances to
accumulate between the waterproof seal and the case.

0

Never damage or scratch the waterproof seal and terminal cover. Doing so
can result in leaks. If the seal is damaged, contact your nearest JVC Service
Center for a replacement. (Charges apply.)

0

Read the “Detailed User Guide” carefully before using the camcorder under
water or in places exposed to water droplet.

EN 9

Charging the Battery

AC Adapter
(Provided)

Adapter Cable
(Provided)

Charging Lamp

To AC Outlet
(100 V to 240 V)

A

B

C

D

A battery is built into the camcorder.

.

Open the terminal cover (p. 9)

1

Connect adapter cable to AC adapter.

2

Plug in the AC adapter to AC outlet (100 V to 240 V).

3

Connect the other side to USB socket on the unit.

4

CAUTION

0

At the time of purchase or in case of the battery is not used for a long period

time, the charging time will be longer than usual. The camera does not turn

of
on if the remaining battery power is low. In this case, charge the battery for
more than 40 minutes before turning on the power.

0

Charging time: Approx. 6 h 10 m (when charging at 25°C)

0

The battery cannot be charged outside the room temperature range of 10°C
to 35°C. The CHARGE lamp does not light up when the battery is not being
charged. If the temperature increases or decreases during charging, the
CHARGE lamp will blink slowly and charging will stop. In this case, remove
the AC adapter, press the Reset button and wait until the room temperature
is within the above stated range before charging again.

0

You can record or play back videos during charging. (However, the charging
time will be longer than usual. In addition, the remaining battery power may
decrease according to conditions.) If the internal temperature rises when
using the unit, stop the charging temporarily. (The CHARGE lamp goes off.)

0

If malfunctions (such as overvoltage) occur, charging will stop. In this case,
the CHARGE lamp blinks quickly as a notification.

0

When the recording time becomes extremely short even when the battery is
fully charged, the battery needs to be replaced. For details on replacing the
built-in battery (subject to a fee), consult the nearest JVC service center.

0

For details on other charging methods, please refer to the “Detailed User Guide”.

10 EN

Inserting an SD Card

*

Insert an SD card.

Before inserting the SD card,
close the LCD monitor to turn off
this unit.

(Rear)

Label

Open the terminal cover.

The videos and the still images are recorded to the built-in memory at the initial
settings.

Insert a commercially available SD card if you want to record to the SD card.
For details on switching the media, please refer to the “Detailed User Guide”.

.

To remove the SD card

o

Push the SD card inward once, then pull it out straight.

NOTE

Operations are confirmed on the following SD cards.

Manufacturer Panasonic, TOSHIBA, SanDisk

Class 4 (

K

Video

A

Still Image

0

Using SD cards (including SDHC/SDXC cards) other than those specified
above may result in recording failure or data loss.

0

This

unit is not guaranteed to operate with all SD cards, even when using the

ones specified above. Some SD cards may not work due to specification
changes, etc.

0

To protect the data, do not touch the terminals of the SD card.

0

When using an SDXC card, check its compatibility with the OS of your
computer by referring to the Detailed User Guide.

0

Do not use a miniSD card or microSD card (even if the card is inserted in an
adapter). It may cause malfunction to the camcorder.

Class 4 (
Class 4 (

0

When recording with video quality [UXP], Class 6 (
or higher is recommended.

SD card (256 MB to 2 GB) / SDHC card (4 GB to 32 GB) / SDXC

B

card (64 GB to 128 GB)

) or higher compatible SD card (2 GB)/

K

) or higher compatible SDHC card (4 GB to 32 GB)/

K

) or higher compatible SDXC card (64 GB to 128 GB)

L

)

EN 11

Video Recording

H

P

A

C

A

T

W

Check if the recording
mode is A video.

If the mode is B still image,
tap B on the touch screen,
then tap A to switch.

Start recording.

Press again to stop.

Zooming

(Wide angle)

(Telephoto)

Zoom Lever

If the mode is H Manual, tap H on
the touch screen, then tap P to
switch.

Check if the recording mode
is P.

MENU

≪PLAY

0:00:00 [0:54]

REC

Recording in Progress
Recording-Standby

Battery Indicator

Recording Media

Image Stabilizer

Video Quality

Remaining Recording
Time

Scene Counter

Still Image

Recording Button

You can record without worrying about the setting details by using the P
Auto) mode. Settings such as exposure and focus will be adjusted automatically to
suit the shooting conditions.

(Intelligent

Before recording an important scene, it is recommended to conduct a trial recording.

.

0

You can also tap 6 on the touch screen to record. To stop recording, tap

7

. In addition, you can also tap D to zoom.

Indications during video recording

o

.

12 EN

NOTE

0

estimated recording time of the supplied battery is approximately 2 hour

The
50 minutes of actual recording and up to 5 hours 10 minutes of continuous
recording.

0

Do not remove SD card when the POWER/ACCESS lamp is lighted. The
recorded data may become unreadable.

0

With [AUTO POWER OFF] operation, the camera automatically turns off if no
operation is performed for 5 minutes, in order to conserve power. (The unit
enters into standby mode when the AC adapter is used.)

0

The angle of view may change when the image stabilizer is turned on or off.

0

When recording underwater, the internal mechanical noise (such as zooming
sound) may be easily picked up and recorded. This is not a malfunction.

Video Quality

This unit can perform recording in high definition (1920x1080).
Default setting of [VIDEO QUALITY] is XP.

To change the setting

o

Tap [MENU].

A

Tap [RECORD SETTING].

B

Tap [VIDEO QUALITY].

C

Tap the desired video quality.

D

AVCHD
(1920x1080)

* For the approximate video recording time, refer to p. 18.

UXP Higher video quality

XP

(Default)

EP

.

More recording time

EN 13

Playing Back/Deleting Files on this Unit

T

W

VOL.

＋

Tap on the files to delete.

Ta p R.

To delete unwanted files

Turn up the
volume

Turn down

the volume

Volume adjustment
during playback

Ta p u to return to the video
index screen.

Tap on the file to play back.

Tap "SET".

Ta p E to return to the
recording mode.

Ta p F on the touch screen
to select the playback mode.

Ta p e to pause playback.

Tap "OK".

Tap "EXECUTE" when the
confirmation message appears.

Ta p A or B to select the video
or still image mode.

A I mark appears on the selected file.
To remove the I mark, tap again.

DELETE

SEL ALL REL ALL SET

QUIT

Ta p I/J to select the media for
playback.

Select and play back the recorded videos or still images from an index screen
(thumbnail display).

.

To capture a still image during playback

o

A

Pause the playback with e.

B

Press the START/STOP button or tap the A on the LCD.

NOTE

0

While this unit may be used with the LCD monitor reversed and closed, the
temperature rises more easily. Leave the LCD monitor open when using this
unit.

0

The power may turn off to protect the circuit if the temperature of this unit rises
too much.

14 EN

Troubleshooting/Cautions

0

Troubleshooting

If you encounter problems with this unit,
check the following before requesting
service.

1.

Refer to the “Troubleshooting”
section in the “Detailed User Guide”.

If you have difficulties operating the
unit, refer to the detailed
descriptions in the “Detailed User
Guide”.

http://manual3.jvckenwood.com/
index.html/

2.

This unit is a microcomputer­controlled device. Electrostatic
discharge, external noise and
interference (from a TV, a radio, etc.)
might prevent it from functioning
properly.

In such a case, reset the unit.

Remove all the cables from this

A

unit.
Press the "Reset button" located

B

inside of the terminal cover.
(Before pressing the reset button,
close the LCD monitor to turn off
this unit.)

Reattach the AC adapter, open

C

the LCD monitor and this unit
powers on automatically.

3.

If the above do not solve the problem,
consult your nearest JVC dealer or
JVC service center.

Built-in Battery

This unit is equipped with a built-in lithium­ion battery. Before using this Unit, be sure
to read the following cautions:

0

To avoid hazards

…

do not burn.

…

do not modify or disassemble.

…

do not expose this Unit to temperatures
exceeding 60 °C, as this may cause the
built-in battery to overheat, explode or
catch fire.

To prevent damage and prolong
service life

…

do not subject to unnecessary shock.

…

charge within the temperature range of
10°C to 35°C. Cooler temperatures
require longer charging time, or in some
cases stop charging at all.

Warmer temperatures prevent complete
charging, or in some cases stop
charging at all.

…

store in a cool, dry place. Extended
exposure to high temperatures will
increase natural discharge and shorten
service life.

…

keep a 30% battery level (i) if the
battery is not to be used for a long period
of time.
In addition, fully charge and then fully
discharge the battery every 6 months,
then continue to store it at a 30% battery

i

level (

…

remove the AC adapter from the unit
when not in use, as some machines use
current even when switched off.

…

do not drop intentionally or subject to
strong impact.

).

Recording Medium

0

Be sure to follow the guidelines
below to prevent corruption or
damage to your recorded data.

0

Do not bend or drop the recording
medium, or subject it to strong
pressure, jolts or vibrations.

0

Do not splash the recording medium
with water.

0

Do not use, replace, or store the
recording medium in locations that are
exposed to strong static electricity or
electrical noise.

0

Do not turn off the camcorder power
during shooting, playback, or when
otherwise accessing the recording
medium.

EN 15

0

Do not bring the recording medium
near objects that have a strong
magnetic field or that emit strong
electromagnetic waves.

0

Do not store the recording medium in
locations with high temperature or
high humidity.

0

Do not touch the metal parts.

0

When erasing data using the
camcorder, the data won’t be erased
completely. When handing over your
camcorder and/or SD card, you are
recommended to erase all of the data by
either performing “FORMAT” or
“FACTORY PRESET” operation on this
unit, using commercially available
software, or by physically destroying the
camcorder.

LCD Monitor

0

To prevent damage to the LCD
monitor, DO NOT

…

push it strongly or apply any shocks.

…

place the camcorder with LCD monitor
on the bottom.

0

To prolong service life

…

avoid rubbing it with coarse cloth.

While the LCD monitor screen has more
than 99.99% effective pixels, 0.01% of
the pixels may be bright spots (red,
blue, green) or dark spots. This is not a
malfunction. The spots will not be
recorded.

Main Unit

0

For safety, DO NOT

…

open the camcorder’s chassis.

…

disassemble or modify the unit.

…

allow inflammables, water or metallic
objects to enter the unit.

…

disconnect the power supply while the
power is on.

…

place naked flame sources, such as
lighted candles, on the apparatus.

…

leave dust or metal objects adhered to
the power plug or an AC wall outlet.

…

insert any objects in the camcorder.

0

Avoid using the unit

…

in places subject to soot or steam such
as near a cooking stove.

…

in places subject to excessive shock or
vibration.

…

near a television set.

…

near appliances generating strong
magnetic or electric fields (speakers,
broadcasting antennas, etc.).

…

in places subject to extremely high (over
40 °C) or extremely low (under -10 °C)
temperatures.

0

DO NOT leave the unit

…

in places of over 50°C

…

in places where humidity is extremely
low (below 35 %) or extremely high
(above 80 %) with the terminal cover
open.

…

in direct sunlight.

…

in a closed car in summer.

…

near a heater.

…

in high places such as on a TV. Leaving
the unit in high places while a cable is
connected may result in a malfunction if
the cable is caught and the unit falls onto
the floor.

16 EN

0

To protect the unit, DO NOT

…

drop the unit or strike it against hard
objects.

…

subject it to shock or excessive vibration
during transportation.

…

keep the lens directed at extremely
bright objects for long periods.

…

expose the lens to direct sunlight.

…

swing it excessively when using the
hand strap.

…

swing the soft camcorder case
excessively when the camcorder is
inside it.

…

cover camcorder with a towel, cloth and
so on.

0

To prevent the unit from dropping

0

Fasten the grip belt securely.

0

When using the camcorder with a
tripod, attach the camcorder to the
tripod securely.

If the camcorder drops, you may be injured
and the camcorder may be damaged.

When a child uses the unit, there must be
parental guidance.

Dear Customer, [European Union]
This apparatus is in conformance with

the valid European directives and
standards regarding electromagnetic
compatibility and electrical safety.

European representative of
JVC KENWOOD Corporation is:
JVCKENWOOD Deutschland GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
GERMANY

Remember that this unit is intended
for private consumer use only.

Any commercial use without proper
permission is prohibited. (Even if you
record an event such as a show,
performance or exhibition for personal
enjoyment, it is strongly recommended
that you obtain permission beforehand.)

Trademarks

0

AVCHD and AVCHD logo are
trademarks of Panasonic Corporation
and Sony Corporation.

0

The terms HDMI and HDMI High­Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered
trademarks of HDMI Licensing
Administrator, Inc. in the United States
and other countries.

0

0

0

0

0

0

0

0

0

.

Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio and
the double-D symbol are trademarks of
Dolby Laboratories.
SDXC logo is a trademark of SD-3C LLC.
Windows® is either registered
trademark or trademark of Microsoft
Corporation in the United States and/or
other countries.
Apple, Mac, Mac OS, OS X, iMovie,
iPhoto, iPhone and Safari are
trademarks of Apple Inc., registered in
the U.S. and other countries.
Intel and Intel Core are trademarks or
registered trademarks of Intel
Corporation or its subsidiaries in the
United States and other countries.
Google™, Android™, YouTube™,
YouTube logo and Chrome™ are
trademarks and/or registered
trademarks of Google Inc.
QR Code is a registered trademark of
Denso Wave Incorporated.
Other product and company names
included in this instruction manual are
trademarks and/or registered
trademarks of their respective holders.
Marks such as ™ and ® have been
omitted in this manual.

EN 17

Recordable Time/Specifications

3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, JAPAN

Approximate Video Recording Time

Built-in

Quality

UXP 15 m 20 m 40 m 1 h 20 m 2 h 40 m 5 h 40 m 11 h 30 m

0

The recordable time is only a guide. The actual recording time may be longer or
shorter than the time indicated above.

memory

4 GB 4 GB 8 GB 16 GB 32 GB 64 GB 128 GB

XP 20 m 30 m 1 h 1 h 50 m 3 h 50 m 8 h 10 m 16 h 20 m
EP 1 h 20 m 1 h 40 m 3 h 30 m 7 h 14 h 28 h 50 m 57 h 50 m

Camera

Power supply Using AC adapter: DC 5 V
Power

consumption
Dimensions 60 mm x 59.5 mm x 128 mm

Weight Approx. 301 g

The specifications and appearance of this product are subject to changes for
further improvement without prior notice.

For more information, please refer to the Detailed User Guide.

http://manual3.jvckenwood.com/index.html/

2.2 W (when [MONITOR BRIGHTNESS] is set to [3] (standard))
Rated Current Consumption: 2A

(W x H x D: excluding grip belt)

SDHC/SDXC Card

©2018 JVC KENWOOD Corporation

18 EN

EU

0118TOH-SW-MT

B5A-2472-01

Grundlæggende brugervejledning

VIDEOKAMERA

GZ-R495AE
GZ-R495BE
GZ-R495DE
GZ-R495WE

DA

Detaljeret
brugervejledning

.

For yderligere oplysninger om
betjening af dette produkt, bedes du
henvise til „Detaljeret
brugervejledning“ på den følgende
website.

http://manual3.jvckenwood.com/index.html/

o

Kære kunder

Vi takker dig for at købe dette JVC produkt.
Inden du tager produktet i brug, bedes du læse Sikkerhedsforskrifterne og
Forholdsreglerne på side. 2 og side. 15
produktet.

for at sørge for sikker anvendelse af

Mobile Brugervejledning

.

Når du er udenfor, se „Mobile
Brugervejledning“. Mobile
Brugervejledning kan ses med en
standardbrowser for Android tablet
og iPhone.

http://manual3.jvckenwood.com/mobile/eu/

o

Sikkerhedsforskrifter

BEMÆRKNINGER:

0

Typebetegnelse og forsigtighedsregler
er anbragt på undersiden og/eller
bagsiden af hovedenheden.

0

Serienummerpladen er placeret på
batteripakningens monteringsdel.

0

Information om mærkekapacitet og
sikkerhedsforskrifter for
lysnetadapteren sidder på over- og/eller
undersiden.

FORSIGTIGHEDSREGLER:

0

Forsøg aldrig at lukke kabinettet op. Der
er risiko for at få elektrisk stød. Der findes
ingen dele i kameraet, som brugeren
selv kan reparere. Reparationer og
service skal udføres af fagfolk.

0

Hvis De ikke anvender lysnetadapter i
længere tid, anbefales det, at De tager
netledningen ud af stikkontakten i
væggen.

FORSIGTIG:

For at undgå
elektrisk stød eller
beskadigelse af
apparatet, skal
den lille ende af
netledningen
trykkes godt ind i lysnetadapteren, indtil
den ikke kan rokkes, hvorefter den store
ende af netledningen sættes i et
vekselstrømsudtag.

FORSIGTIG:

Der er et indbygget litium-ion-batteri inde
i enheden. Når du kasserer enheden, bør
du tage miljøproblemer i betragtning og
overholde de lokale regler og love, der
vedrører afhændelsen af disse batterier,
til punkt og prikke.

ADVARSEL:

Videokameraet med installeret batteri må
ikke udsættes for stærk varme som f.eks.
direkte sollys, ild eller lignende.

FORSIGTIG:

Netstikket skal være umiddelbart
tilgængeligt.

0

Fjern netstikket omgående, hvis denne
enhed fungerer unormalt.

FORSIGTIGHEDSREGLER:

0

Sørg for at bruge den medfølgende
lysnetadapter.

0

Den medfølgende lysnetadapter må ikke
bruges med andre anordninger.

2 DA

Ret ikke objektivet direkte mod solen.
Dette kan føre til øjenskader og bevirke,
at det interne kredsløb ikke fungerer, som
det skal. Desuden vil der være fare for
brand og/eller elektrisk stød.

FORSIGTIG!

De følgende bemærkninger vedrører
eventuel fysisk beskadigelse af kameraet
og personskade.

Hvis De bærer eller holder kameraet i
LCD-monitoren, risikerer De at tabe eller
beskadige den.

Brug ikke et trebenet stativ, hvis
underlaget er ustabilt eller ujævnt.
Stativet kan vælte, hvorved kameraet kan
lide skade.

FORSIGTIG!

Tilslutning af kabler (lyd/video, osv.) til
kameraet og anbringelse af det ovenpå et
fjernsyn frarådes, da der i så fald vil være
fare for at snuble over kablerne med
nedfald af kameraet og materiel skade og
personskade til følge.

Dette produkt er godkendt ifølge AVC
Patent Portfolio License for personlig brug
af en forbruger eller andre brugere, som
ikke modtager betaling for at (i) kode en
video i overenstemmelse med AVC­standarden („AVC Video“) og/eller (ii)
kode AVC video der er blevet kodet af en
forbruger, som er engageret i en personlig
aktivitet, og/eller er blevet indhentet fra en
videoleverandør der har licens til at levere
en AVC Video. Der er ikke bevilliget noget
licens, eller det skal antyde nogen anden
anvendelse.

Yderligere oplysninger kan fås fra MPEG
LA, L.L.C.
Se http://www.mpegla.com

.

Oplysninger om bortskafning af
gammelt elektrisk udstyr og batterier
(gælder for lande som har indført
separate systemer for indhentning af
affald)

Produkter og batterier med symbolet
(vogn med kryds) må ikke kasseres som
husholdningsaffald.

Gammelt elektrisk og elektronisk udstyr
og batterier skal recirkuleres på et anlæg,
der er i stand til at håndtere disse
elementer og deres affaldsprodukter.

Kontakt de lokale myndigheder for
oplysninger om et genbrugssted i
nærheden af dig. Korrekt recirkulering og
bortskaffelse af affald hjælper til med at
bevare ressourcer mens det forebygger
skadelige virkning af vores helbred og
miljøet.

Bemærk: Tegnet „Pb“ under symbolet for
batterier giver udtryk for at dette batteri
indeholder bly.

Lav en sikkerhedskopi af vigtige
optagede data

JVC er ikke ansvarlig for tab af data. Det
anbefales, at du kopierer vigtige,
optagede data til en disk eller et andet
optagemedie til lagring en gang hver
tredje måned.

M/D på enheden angiver måned og
produktionsår.

DA 3

Husk på, at dette kamera udelukkende er
beregnet til private indspilninger.

Enhver kommerciel anvendelse uden
forudgående tilladelse er forbudt. (Selv i
tilfælde hvor du indspiller en begivenhed
såsom et show, en forestilling eller en udstilling
til personlig brug, anbefales det stærkt, at du
på forhånd indhenter tilladelse.)

Varemærker

AVCHD og AVCHD-logoet er varemærker,

0

der tilhører Panasonic Corporation og Sony
Corporation.
Vilkårene HDMI og

0

HDMI High Definition
Multimedia Interface
og HDMI Logo er varemærker eller
registrerede varemærker tilhørende HDMI
Licensing Administrator, Inc. i USA og andre
lande.
Fremstillet under licens fra Dolby

0

Laboratories. Dolby og dobbelt-D symbolet
er varemærker, tilhørende Dolby, Dolby
Audio Laboratories.
SDXC-logoet er et varemærke der tilhører

0

SD-3C LLC.
Windows® er enten et registreret varemærke

0

eller et varemærke tilhørende Microsoft
Corporation i USA og/eller andre lande.
Apple, Mac, Mac OS, OS X, iMovie, iPhoto,

0

iPhone og Safari er varemærker, der tilhører
Apple Inc., registreret i USA og andre lande.
Intel og Intel Core er varemærker eller

0

registrerede varemærker, der tilhører Intel
Corporation eller deres datterselskaber i USA
og andre lande.
Google™, Android™, YouTube™, YouTube-

0

logoet og Chrome™ er varemærker og/eller
registrerede varemærker, der tilhører Google
Inc.
QR Code er et registreret varemærke

0

tilhørende Denso Wave Incorporated.
Andre produkt- og firmanavne, der er

0

omfattet i denne brugervejledning er
varemærker og/eller registrerede
varemærker der tilhører deres respektive
ejere.
Mæker som for eksempel ™ og ® er blevet

0

udeladt i denne manual.

.

Denne enhed er udstyret med
Vandtæt, Støvtæt, Faldsikkert og
Frostsikkert.

Vandtæt: Svarende til IEC

Standardpublikation 529 IPX8 og
IPX6 (1 time ved dybder på op til
5 m)

Støvtæt: Svarende til IEC
Standardpublikation 529 IP5X

Faldsikkert: Dette kamera
overholder selskabets testning i
overensstemmelse med „MIL­STD-810F Method; 516.5
Shock: Falde ned på 3 cm tyk
krydsfinér fra en højde på 1,5 m“

Frostsikker: Tilladt
driftstemperatur: -10 °C til +40 °C
Bemærk: Temperaturer mellem

-10 °C og 0 °C sænker midlertidig
batteriets ydeevne og reducerer
tiden tilgængelig til optagelse.

Forholdsregler for vandtæt funktion

0

Funktionsfejl på grund af forkert brug af
kunden dækkes ikke af garantien.

0

Før anvendelse i vand skal du læse og
forstå „Detaljeret brugervejledning“.

0

Luk terminaldækslet godt, indtil det
klikker, og bekræft at det røde lys slukkes
helt.

0

Sørg for, at der ingen skade er, og at
ingen fremmedlegemer sidder fast på
pakningen inden i dækslet.

0

Brug videokameraet i havvand og
ferskvand, der ikke er dybere end 5 m,
og ikke i mere end 1 time.

0

Vandtætheden kan ikke garanteres, hvis
videokameraet udsættes for stød, som
f.eks. ved tab.

0

Hop ikke i og dyk ikke ned i vand, mens
du holder videokameraet.

0

Anvend ikke videokameraet i stærke
vandstrømme ved eksempelvis rafting
eller under vandfald. Det stærke
vandtryk kan forringe vandtætheden.

0

Gennemvæd ikke videokameraet i
varme kilder eller vand over 40 °C.

4 DA

Tildugning indvendigt i objektivet

Åbn terminaldækslet.

Objektivets beskyttelsesglas

Modeller med vandtæt funktion er lufttætte.
Når temperaturen stiger under optagelse,
kan der opstå kondensering i objektivet som
følge af fugtighed indvendigt.

Under optagelse

For at undgå temperaturstigning i denne
enhed anbefaler vi dig, at du anvender
enheden på følgende måder.

Undgå hyppig udsættelse for direkte

A

sollys.

Optag i skygge, eller benyt en paraply.
Mest optimalt vil det være at lade et vådt
håndklæde dække enheden.

Det anbefales at anvende stativ.

B

Længere tids optagelse, mens du holder
enheden i hænderne, medfører
temperaturstigning i enheden.

Det er bedre at lade terminaldækslet stå

C

åbent under optagelse.

Funktionerne for vandtæt, støvtæt og
stødsikker virker dog ikke i denne tilstand.
Vær opmærksom på omgivelserne ved
anvendelse af kameraet. (Anvend ikke et
vådt håndklæde).

Sørg for, at der er slukket for strømmen,

D

når du ikke optager.

Strømmen slukker, når LCD-skærmen
lukkes.

Under opladning

Det anbefales at oplade enheden i et område
med lav luftfugtighed.

Fugtig luft inde i enheden kan medføre
kondensering.

Vi anbefaler, at du oplader enheden i et rum,
hvor der ikke benyttes luftfugter, og om
sommeren i et rum med aircondition.

Når der opstår tildugning indvendigt i
objektivet

Åbn terminaldækslet for at sænke
temperaturen, luk LCD-skærmen, og lad
kameraet være i et stykke tid.

.

Beskyttelse af objektivet

Der er beskyttelsesglas foran på objektivet
for at beskytte det.

0

Hvis beskyttelsesglasset er snavset, skal
du tørre det af med en renseklud, der fås i
handelen.

.

DA 5

Indhold

Sikkerhedsforskrifter .............................. 2

Kontrol af medfølgende tilbehør ............. 6

Delenes navne og deres funktioner ....... 7

Indstilling af dato og tid .......................... 8

Åbn terminaldækslet (SD-kortets låg)

.......... 9

Kom godt i gang

Opladning af batteriet .......................... 10

Indsættelse af SD-kort ......................... 11

Optagelse

Videooptagelse .................................... 12

Videokvalitet ........................................ 13

Afspilning

Afspilning/sletning af filer på denne enhed

........ 14

Yderligere oplysninger

Fejlfinding/Forholdsregler .................... 15

Optagelsestid/specifikationer .............. 18

Kontrol af medfølgende tilbehør

Lysnetadapter

UIA312-0520

.

AV-kabel

E3A-0085-00

.

0

Når du køber et nyt AV.-kabel bedes du kontakte din JVC-forhandler eller det
nærmeste JVC servicecenter for yderligere oplysninger.

0

Montér linselåget, når du bærer kameraet rundt, og når kameraet ikke er i brug.

Strømledning

.

Linselåg

.

Adapterkabel

QAM1580-001

.

Kernefilter

(for AV-kabel)

.

USB-kabel

(type A - Mikro type B)

.

Grundlæggende

brugervejledning

(denne håndbog)

.

6 DA

Delenes navne og deres funktioner

8

b

a

0

c

d

9

4

56

7

2

1

3

3 cm

Den skal kobles til apparatet

Udløs stopperen.

Sno en gang

.

Objektivets beskyttelsesglas

A

Hvis

beskyttelsesglasset er snavset,
skal du tørre det af med en klud, der
fås i handelen.

Stereomikrofon

B

LCD-skærm

C

CHARGE Lampen (opladning) (side. 10)

D

POWER/ACCESS Lampen (Strøm/

E

adgang)
Zoom/lydstyrke-reguleringsarm

F

(side. 12, 14)
Opstilling med stroppe

G

Fastgøring af kernefiltret

o

Fastgør

et kernefilter til AV-kablet, som vist på illustrationen. Kernefiltret reducerer

interferensen, når dette apparat er koblet til andre enheder.

.

START/STOP (Video-optagelse)-knap

H

(side. 12)
Terminaldæksel (SD-kortdæksel)

I

Port til SD-kort (side. 11)

J

Nulstillingsknap

K

HDMI mini-stikket

L

AV-stik

M

USB-stik

N

DA 7

Indstilling af dato og tid

SET DATE/TIME!

OK

201812 10 00

24

TIME

DATE

SAVE

DATE & TIME

GMT

SAVE

DATE & TIME/AREA

Åbn LCD-skærmen.

1

.

0

2

tænder. Enheden slukker,

Enheden
når LCD-skærmen er lukket.

Tryk [OK] når [SET DATE/
TIME!] bliver vist.

.

Angiv dato og klokkeslæt.

3

.

0

Når der trykkes på dag, måned, år,
time eller minut, bliver 3 og 2 vist.
Tryk på 3 eller 2 for at justere
værdien.

0

Gentag dette trin til at indstille dag,
måned, år, time og minut.

Efter indstilling af dato og

4

tid, tryk [SAVE].

Vælg din region og tryk på

5

[SAVE].

0

Tidsforskellen
og GMT (Greenwich Mean Time)
bliver vist.

0

Tryk på 0 eller 1 for at vælge byens
navn.

.

mellem den valgte by

8 DA

Åbn terminaldækslet (SD-kortets låg)

Ikke lukket ordentligt, hvis det røde mærke er synligt!

(Bagside)

Åbn LCD-skærmen.

A

Skub terminaldækslets lås ned,

B

og skub dækslet til side
Løft dækslet langsomt.

C

For at lukke

o

Lad først LCD-skærmen være åben.

A

B

C

(Dækslet
er synligt).

.

Klap dækslet langsomt ned, mens du sørger for, at den grå, vandtætte
forsegling passer ind i åbningen ved terminalerne.

Tryk hele dækslet ned mod videokameraet med jævn kraft, og montér
omhyggeligt dækslet helt.

Skub dækslet godt på plads, indtil den giver et klik.

er ikke lukket ordentligt, hvis det røde mærke på terminaldækslets lås

FORSIGTIG

0

Du må ikke være for voldsom, når du åbner eller lukker terminaldækslet.

0

Åbn eller luk ikke terminaldækslet, hvis dine hænder er våde eller fyldt snavs/
sand.

0

Sørg for, at der ikke samler sig snavs, støv, hår, sand og andre
fremmedlegemer mellem den vandtætte forsegling og kamerahuset.

0

Du må aldrig beskadige eller ridse den vandtætte forsegling og
terminaldækslet. Gør du det, kan det medføre lækager. Hvis forseglingen er
beskadiget, bedes du kontakte dit nærmeste JVC-servicecenter for
udskiftning. (Udskiftningen er ikke gratis).

0

Læs „Detaljeret brugervejledning“ omhyggeligt, før du anvender
videokameraet under vand eller på steder, der udsættes for vanddråber.

DA 9

Opladning af batteriet

Lysnetadapter
(medfølger)

Adapterkabel
(medfølger)

Ladelampe

Til stikkontakten
(100 V til 240 V)

A

B

C

D

Et batteri er bygget ind i videokameraet.

.

Åbn terminaldækslet (side. 9)

1

Tilslut Adapterkablet til AC-adapteren.

2

Tilslut AC-adapteren til stikkontakten (100 V til 240 V).

3

Forbind den anden side til USB-stikket på Enheden.

4

FORSIGTIG

0

På købstidspunktet, eller hvis batteriet ikke anvendes i længere tid, er opladningstiden
længere end normalt. Kameraet tændes ikke, hvis den resterende batterikapacitet er
lav. Hvis dette er tilfældet, skal du oplade batteriet i mere end 40 minutter, før du tænder
for strømmen.

0

Opladningstid: Ca. 6 t og 10 min (når der oplades ved 25°C)

0

Batteriet kan ikke oplades uden for en stuetemperatur på mellem 10 °C og 35 °C.
Lampen CHARGE begynder ikke at lyse, når batteriet ikke lades op. Hvis temperaturen
stiger eller falder under opladning, blinker lampen CHARGE langsomt, og opladningen
stopper. I så fald skal du fjerne lysnetadapteren, trykke på knappen Nulstil og vente,
til stuetemperaturen ligger inden for det ovennævnte interval, før du oplader igen.

0

Du kan optage eller afspille videoer under opladning. (Opladningstiden er dog længer
end normalt. Derudover reduceres den tilbageværende batterikapacitet muligvis i
henhold til forholdene). Hvis den indvendige temperatur stiger ved anvendelse af
enheden, skal du midlertidigt indstille opladningen. (Lampen CHARGE slukker).

0

Hvis der opstår funktionsfejl (såsom overspænding), stopper opladningen. I så fald
blinker lampen CHARGE hurtigt som underrettelse.

0

Når optagetiden bliver meget kort, selvom batteriet er fuldt opladet, skal du skifte
batteriet ud. For detaljer om udskiftning af det indbyggede batteri (mod betaling),
kontakt det nærmeste JVC-servicecenter.

0

For detaljer om andre opladningsmetoder, se „Detaljeret brugervejledning“.

10 DA
