GR-SX867U

JVC GR-SX867U Service Manual

Download
COMPACT VHS CAMCORDER
GR-SX867UM
SPECIFICATIONS
Camcorder
General
Format : VHS NTSC standard Power source : DC 6.0 V Power consumption : 3.6 W Video light : 3.0 W Signal system : NTSC-type Video recording system
Luminance : FM recording Color : Converted sub-carrier
Cassette : Tape speed
SP : 33.35 mm/sec. (1-5/16 ips) EP : 11.12 mm/sec. (7/16 ips)
Recording time (max.)
SP : 40 minutes EP : 120 minutes (with TC-40)
Operating
temperature :0°C to 40°C (32°F to 104°F) Operating humidity : 35% to 80% Storage temperature : Weight : Approx. 730 g (1.6 lbs) Dimensions : 198 mm x 119 mm x 91 mm
(W x H x D) (7-13/16" x 4-11/16" x 3-5/8")
Pickup : 1/4" format CCD Lens : F1.6, f = 3.9 to 62.4 mm,
direct recording Conforms to VHS standard
/ cassette
–20°C to 50°C (–4°F to 122°F)
(with the viewfinder fully tilted downward)
16:1 power zoom lens with auto iris and macro control, filter diameter 40.5 mm
Viewfinder : Electronic viewfinder with
White balance
adjustment : Auto/Manual adjustment
Connectors
JLIP : ø3.5 mm, 4-pole, mini-head
Video : 1 V (p-p), 75 Ω unbalanced,
Audio : 300 mV (rms), 1 kΩ analog
S-Video : Y : 1 V (p-p), 75 Ω, analog
0.55" color LCD
jack (compatible with RC-5325 plug)
analog output (via Video output connector)
output (via Audio output connector)
output
C : 0.29 V (p-p), 75 Ω, analog
output
AC Power Adapter/Charger AA-V16U
Power requirement : AC 110 V to 240 V`,
Power consumption : 23 W Output
Charge : DC 8.5 V VTR : DC 6.3 V
Charging system : Constant current, peak
Dimensions : 125 mm x 42 mm x 68 mm
(W x H x D) (4-15/16" x 1-11/16" x
Weight : Approx. 270 g (0.6 lbs)
50 Hz/60 Hz
, 1.3 A , 1.8 A
detection, timer controlled
2-11/16")
This service manual is made from all recycled paper.
COPYRIGHT
© 2000 VICTOR COMPANY OF JAPAN, LTD.
Cassette Adapter C-P7U
Dimensions : 188 mm x 25 mm x 104 mm
(W x H x D) (7-7/16" x 1" x 4-1/8") Weight : Approx. 240 g (0.53 lbs) Accessory : “AA (R6)”-size battery x 1
Optional Accessories
•Battery Packs BN-V12U, BN-V20U, BN-V856U
•Car Battery Charger BH-V3U
•Battery Charger BH-VC10U
•Audio/Video Cable
•S-Video Cable QAM0004-004
•Car Battery Cord AP-V7U
•Compact S-VHS (
20
•Compact VHS (
•Remote Control Unit RM-V700U
•Active Carrying Bag CB-V7U
Some accessories are not available in some areas.
Please consult your nearest JVC dealer for details
on accessories and their availability.
Specifications shown are for SP mode unless otherwise indicated. E & O.E. Design and specifications subject to change without notice.
) Cassettes ST-C-40/30/
) Cassettes TC-40/30/20
No. 86537
January 2000
TABLE OF CONTENTS
DIFFERENT TABLE ....................................................................................................................................................................... 1
4. CHARTS AND DIAGRAMS
4.1 MAIN CIRCUIT BOARD ............................................................................................................................................. 4-1
5. PARTS LIST
5.1 PACKING ASSEMBLY <M1> ..................................................................................................................................... 5-1
The following table indicate main different points between models GR-SX851U and GR-SX867UM.
ITEM
BODY COLOR Pearl gray Metallic gray
REMOTE CONTROLLER Optional Provided
ZOOM 300X 450X
The following table indicate different parts number between models GR-SX851U and GR-SX867UM.
PACKING ASSEMBLY<M1>
REF NO.
2 PACKING CASE LY31561-013A LY31561-026A
! 5 IB (EN) LYT0465-001A LYT0502-001A ! IB (SP) – LYT0502-002A ! IB (PT) – LYT0502-003A
7 REGIST. CARD BT-51020-2 –
17 BATTERY, RCU, R03 (AAA) X2 Not used Used
18 REMOTE CONTROLLER – LY42129-001A
FINAL ASSEMBLY <M2>
REF NO.
ITEM
ITEM
MODEL
MODEL
MODEL
GR-SX851U GR-SX867UM
GR-SX851U GR-SX867UM
GR-SX851U GR-SX867UM
! 106 FRONT COVER ASSY LY10124-038A LY10124-046A
! 107 CASS. COVER ASSY LY10189-001A LY10189-008A
110 TOP COVER LY10129-080A LY10129-091A
113 OPERATION UNIT LY10120-031A LY10120-047B
MAIN BOARD ASSEMBLY <01>
REF NO.
PW MAIN BOARD ASSY ✽ YB10271UA-04
D3002 DIODE ✽ DAN222
R3033 MG RESISTOR ✽ NRSA63J-103X
R3035 MG RESISTOR ✽ NRSA63J-103X
C4004 T CAPACITOR ✽ NBE20GM-336X
Note: Mark – is not used. Mark
Mark ✽ GR-SX851U was also changed.
ITEM
MODEL
is same as left.
GR-SX851U GR-SX867UM
1
4.1 MAIN CIRCUIT BOARD
SECTION 4
CHARTS AND DIAGRAMS
FOIL SIDE (B)
4-1
4-2
COMPONENT PARTS LOCATION GUIDE (MAIN)
REF.No. LOCATION
CAPACITOR
C101 A C 1A C102 B C 2A C103 B C 2A C104 B C 1A C105 B C 1A C106 B C 2A C107 B C 2B C108 A C 1C C109 A C 3D C110 A C 3D C111 B C 2A C112 B C 2A C113 A C 2A C114 A C 2A C115 B C 1A C116 A C 8C C118 A C 2A C119 A C 3A C120 A C 3A C121 B C 2A C122 B C 2A C123 B C 2A C124 B C 2A C125 A C 1A C126 A C 1A C127 A C 3A C128 A C 2A C129 A C 3A C130 B C 1A C131 A C 3A C132 A C 3B C133 A C 2C C134 A C 2C C135 A C 2B C136 A C 2B C137 A C 4B C138 A C 1B C140 A C 2B C143 A C 2B C144 A C 7B C146 A C 4E C147 A C 4E C1201 A C 4D C1202 A C 4D C1203 A C 4D C1204 B C 4C C1205 A C 4D C1206 A C 4D C1207 A C 4D C1601 B C 8C C1602 A C 7D C1603 B C 7C C1604 B C 7C C1605 B C 7C C1606 B C 8C C1607 B C 8C C1608 B C 8C C1609 B C 8C C1610 B C 8B C1611 A C 7C C1612 A C 8C C1613 A C 7C C1614 A C 8C C1615 A C 7C C1616 B C 8C C1617 A C 7C C1618 B C 8D C1619 B C 8D C1620 B C 8D C1621 A C 8C C1622 A C 8C C1623 A C 7C C1624 B C 7C C1625 B C 7C C1626 B C 7C C1627 B C 8C C1628 B C 8C C1629 B C 8C C1630 B C 8C C1631 B C 7C C1801 B C 2D C2001 B C 4D C2002 A C 4D C2003 B C 4D
REF.No. LOCATION REF.No. LOCATION
C2004 A C 4D C2005 B C 3D C2009 A C 4A C2010 A C 4A C2021 B C 4A C2022 B C 4A C2023 B C 3A C2024 B C 4A C2025 B C 4A C2026 B C 4A C2027 B C 3A C2028 B C 4A C2029 B C 3A C2030 B C 3A C2031 B C 3A C2051 B C 1C C2052 B C 1C C2061 B C 3A C2062 B C 3A C2071 B C 4A C2072 B C 4A C2073 A C 4A C2074 B C 4A C2076 B C 4A C2401 A C 6D C2402 A C 6E C2403 A C 7E C2404 A C 7E C2405 A C 7D C3002 B C 5C C3003 B C 4C C3004 B C 4B C3005 B C 4B C3006 B C 4B C3007 B C 4B C3008 A C 3C C3009 A C 4D C3010 A C 4C C3011 A C 4C C3012 A C 5C C3013 A C 4C C3014 A C 4C C3015 A C 5C C3016 A C 4C C3017 A C 4C C3018 A C 5C C3019 B C 4C C3020 A C 4C C3021 A C 5C C3022 A C 5C C3023 A C 4C C3024 A C 4C C3027 B C 4C C3028 B C 4C C3031 A C 4D C3032 B C 4B C3033 B C 4B C3035 B C 4B C3037 B C 3C C3038 B C 4C C3101 B C 1C C3103 B C 4B C3104 B C 4A C3105 A C 4A C3106 A C 4A C3107 B C 4A C3108 B C 4B C3109 B C 4B C3112 B C 4B C3113 B C 3B C3114 B C 3B C3115 B C 3A C3117 B C 3A C3118 B C 3A C3119 B C 1B C3120 B C 2C C3121 B C 2B C3132 B C 4A C3134 B C 4A C3135 B C 3E C3136 B C 4A C3501 A C 5A C3502 A C 5A C3503 B C 5A C3504 A C 5A
C3505 A C 5A C3506 B C 5A C3507 B C 5A C3508 A C 5A C3509 A C 5A C3510 B C 5A C3511 B C 5A C3512 B C 5A C3513 B C 5A C3514 A C 5A C3515 B C 5A C3516 B C 5A C3517 A C 5A C3518 B C 5A C3519 B C 5A C3520 B C 5A C3521 B C 5A C3522 A C 5A C3523 B C 5A C3524 B C 5A C3525 B C 5A C3526 A C 5A C3527 B C 5A C3901 A C 6A C4001 B C 2C C4002 B C 2C C4003 B C 2C C4004 A C 3C C4005 A C 3C C4006 B C 2B C4007 B C 1B C4008 B C 1C C4009 B C 2C C4010 B C 2D C4011 B C 2D C4012 B C 2D C4013 B C 2D C4014 B C 3D C4015 B C 3D C4016 B C 3D C4017 B C 3D C4018 B C 4C C4019 B C 4C C4020 B C 4C C4021 B C 3C C4022 B C 3B C4023 B C 3B C4024 B C 3B C4025 B C 2B C4026 B C 2B C4028 B C 2D C4029 B C 1D C4030 B C 2C C4034 A C 2C C4035 B C 2B C4036 B C 1B C4037 B C 2C C4038 B C 2D C4039 B C 2C C4040 A C 2C C4041 A C 2C C4042 A C 2D C4043 A C 2D C4044 A C 1C C4045 A C 2C C4046 A C 1C C4047 A C 2C C4048 A C 2C C4049 B C 3D C4050 B C 3C C4051 A C 2C C4055 B C 2D C4101 B C 3A C4102 B C 2A C4201 A C 5D C4202 A C 5D C4203 B C 5D C4204 B C 6D C4205 B C 5D C4206 B C 5D C4207 B C 5D C4208 B C 4E C4209 B C 5E C4210 B C 4E C4211 B C 4E
REF.No. LOCATION
C4212 B C 4E C4213 B C 5E C4214 B C 5D C4251 A C 6D C4252 B C 6E C4253 B C 5E C4254 B C 5E C4255 A C 5E C4256 A C 5D C4257 B C 6E C4501 A C 6D C4502 A C 5D C4503 A C 5D C4504 A C 5E C4505 B C 5D C4506 B C 5D C4507 B C 5D C4508 B C 5D C4509 B C 5D C4510 B C 5D C4511 B C 5D C4512 B C 4D C5203 B C 2E C5204 B C 2D C5205 B C 2D C5206 B C 2D C5207 B C 2D C5208 B C 2E C5209 B C 2E C5210 B C 2E C5211 B C 3D C5212 B C 2E C5213 B C 2E C5214 B C 3E C5215 B C 3D C5216 B C 3D C5218 B C 2E C5219 B C 2E C5220 A C 3E C5221 A C 3E C5222 A C 2D C5223 A C 2D C5224 A C 2D C5225 A C 2D C5226 A C 2E C5227 A C 2E C5228 A C 2E C5229 B C 3D C5230 B C 3D C5231 B C 3D C5232 A C 2E C5233 A C 2E C5234 A C 2E C5235 A C 2E C5236 A C 2E C5237 A C 2E C6001 B C 6E C6002 B C 6E C6003 A C 6D C6004 B C 7C C6005 B C 7C C6006 B C 7C C6007 B C 7C C6008 B C 7C C6009 B C 7C C6010 B C 7C C6011 B C 7C C6012 B C 7C C6013 B C 6C C6014 B C 7C C6015 B C 7C C6016 B C 7C C6017 B C 7C C6018 B C 7B C6019 B C 7B C6022 B C 7C C6111 B C 6C C6113 B C 6C C6114 B C 7C C6121 B C 6C C6123 B C 6C C6124 B C 7C C6125 A C 5D C6131 B C 6C C6132 B C 6C
REF.No. LOCATION
C6133 A C 7D C6134 A C 6D C6135 A C 7C C6141 B C 6B C6142 B C 5B C6143 B C 8B C6151 B C 6C C6153 B C 6C C6154 B C 6C C6155 B C 6E C6156 A C 6D C6157 B C 6C C6161 B C 6B C6162 B C 6B C6163 B C 7B C6164 A C 6C C6165 A C 7C C6167 B C 6C C6168 B C 6D C6169 B C 6D C6170 A C 6D C6171 B C 6D C6173 B C 6C C6174 A C 7C C6175 B C 6D C6201 A C 6D C7801 A C 7D C7802 A C 7D C7803 A C 7E C7804 A C 7E C7805 B C 7D C7806 B C 7D C7807 B C 7D C7809 A C 7E C7810 B C 7D C7811 B C 7D C7812 B C 7D C8001 A C 6A C8002 B C 6A C8003 B C 7A C8004 B C 7A C8005 B C 7A C8006 B C 7A C8007 B C 6A C8008 B C 6A C8009 B C 6B C8010 B C 6B C8011 B C 7B C8012 B C 7A C8013 A C 6A C8014 A C 6B C8015 A C 7B C8016 A C 7B C8017 A C 7B C8018 A C 7A C8019 A C 7A C8020 A C 8A C8021 A C 8B C8022 A C 8B C8023 A C 7B C8024 A C 6A C8025 A C 6A C8026 A C 6A C8027 B C 6A C8028 B C 6A C8029 B C 6A C8030 B C 6A C8031 B C 7A C8032 B C 8B C8033 B C 8B C8034 B C 8B C8035 B C 8B C8036 B C 7B C8037 B C 7B C8038 B C 8B C8039 A C 7B C8040 B C 6A C8041 A C 7B C8042 A C 7A C8043 A C 8A C8044 A C 8B
CONNECTOR
CN1 A C 4A CN2 A C 8A
REF.No. LOCATION
CN3 A C 4D CN4 A C 2A CN5 A C 5A CN7 A C 3D CN8 A C 4A CN11 A C 7D CN12 B C 7D CN13 A C 8C CN14 A C 2A CN15 A C 4D CN16 A C 7E CN18 A C 4E CN22 A C 3D CN25 A C 3C CN26 A C 3C CN27 B C 7E
DIODE
D101 A C 1A D102 A C 1B D103 A C 1B D105 A C 7A D106 A C 7A D107 A C 3C D501 A C 8B D502 A C 8B D503 A C 8B D504 A C 8B D505 A C 8B D506 A C 8B D1601 B C 8D D3001 B C 4B D3002 B C 5C D3101 B C 1B D3102 B C 1C D3103 B C 1B D4001 A C 2C D4002 A C 2C D5201 B C 3D D5202 B C 3D D6111 B C 5C D6121 B C 5C D6131 B C 6C D6141 B C 5C D6151 B C 6C D6152 B C 6D D6161 B C 7B D6162 B C 6B D6163 B C 6B D6164 B C 6D D6165 A C 7C
IC
IC101 A C 2B IC102 A C 2A IC103 B C 1A IC104 B C 2B IC105 B C 3B IC106 B C 1A IC107 A C 1A IC1201 B C 4D IC1601 B C 8C IC1801 A D 2D IC2001 B C 4D IC2401 A C 6E IC3001 A C 4C IC3002 A C 4B IC3003 B C 4C IC3004 B C 4C IC3101 B C 4A IC3501 B C 5A IC3901 A C 5A IC4001 B C 3C IC4002 A C 2C IC4003 A C 2C IC4004 A C 2C IC4005 A C 2C IC4201 B C 5E IC4202 B C 5D IC4251 B C 5E IC4501 B C 4D IC5201 B C 2D IC5202 A C 2D IC6001 B C 7C IC7801 A C 7D
REF.No. LOCATION
IC7802 A C 7D IC7803 B C 7D IC8001 B C 7A IC8002 A C 7B IC8003 A C 6A IC8004 A C 7B IC8005 B C 6A IC8006 B C 8B IC8007 B C 7A
COIL
L101 A C 2A L102 A C 3D L103 A C 3D L501 B C 8B L502 A C 8B L2001 B C 4E L2002 A C 4A L2003 A C 4D L2051 B C 1C L2052 B C 1C L2401 A C 6E L3002 B C 5C L3003 B C 5C L3101 B C 1C L3104 B C 3A L3106 B C 4A L3107 B C 4A L3501 A C 5A L3502 A C 5A L3901 A C 6A L4001 A C 2C L4002 A C 2C L4003 A C 1C L4004 A C 2D L4005 A C 1C L4201 A C 5E L4501 A C 6E L4502 A C 5E L4503 A C 5E L5201 B C 3E L5202 B C 2E L5203 A C 3E L5204 A C 2D L6001 B C 6D L6002 B C 6D L6004 B C 6D L6111 A C 6C L6121 A C 6C L6131 A C 6C L6141 A C 6B L6151 A C 6C L6161 A C 6B L6202 B C 6D L7801 A C 7D L7803 B C 7D L8001 B C 6A L8002 A C 6A L8003 A C 6A L8004 B C 8B
TRANSISTOR
Q101 A C 1B Q102 A C 1B Q103 A C 3D Q104 A C 8A Q105 A C 8A Q106 A C 8A Q107 A C 8A Q108 B C 1A Q109 B C 1A Q110 B C 1A Q111 A C 3B Q2001 A C 4D Q2006 B C 4A Q2007 B C 4D Q2008 B C 4D Q2061 B C 3A Q2071 B C 4A Q2072 B C 4A Q2401 B C 6E Q3002 B C 4C Q3003 B C 5C Q3004 B C 5C Q3005 B C 4C
4-3
REF.No. LOCATION
Q3101 B C 1B Q3102 B C 1B Q3103 B C 1C Q3104 B C 1C Q3105 B C 1B Q3106 B C 1B Q3113 B C 4A Q3114 B C 4A Q3501 A C 5A Q3502 A C 5A Q3506 A C 5A Q3509 B C 5A Q3901 A C 6A Q3902 A C 6A Q3903 A C 6A Q3904 A C 5A Q4001 A C 2D Q4002 A C 2D Q4004 A C 1C Q4101 B C 3A Q4102 B C 3A Q4103 B C 3A Q4201 B C 5D Q4251 A D 2D Q4501 B C 4D Q4502 A C 5E Q4503 A C 5E Q6111 B C 6C Q6112 B C 6C Q6121 B C 6C Q6122 B C 6C Q6123 B C 6D Q6124 B C 5D Q6131 B C 6C Q6141 B C 6C Q6151 B C 6C Q6161 B C 6C Q6162 A C 6C Q6163 A C 7C Q6164 A C 7C Q6165 B C 6D Q6166 B C 6D Q6167 B C 6D Q6168 A C 7D Q6201 B C 6E Q6202 B C 6E Q6203 B C 6E
RESISTOR
R101 B C 1A R102 B C 1A R103 A C 1A R104 A C 1A R105 A C 1B R106 A C 1B R107 A C 1B R108 A C 1B R109 A C 1B R110 A C 3D R111 A C 3D R112 A C 3D R113 A C 8A R114 A C 8A R115 A C 8A R116 A C 8A R117 B C 1A R118 A C 7A R119 A C 7A R120 A C 7A R121 A C 7A R122 A C 2A R123 B C 2A R124 B C 2B R125 A C 1B R126 A C 1B R127 A C 2B R128 B C 2B R129 B C 2B R130 A C 6B R131 A C 6B R132 B C 2B R133 B C 2B R134 A C 4E R135 B C 2B R136 A C 4E R137 A C 2B
REF.No. LOCATION REF.No. LOCATION
R138 A C 1B R139 B C 4C R140 A C 1B R141 A C 2B R142 A C 2A R143 B C 2A R144 B C 2A R145 A C 3C R146 A C 1A R147 A C 3A R148 A C 2C R150 A C 4E R152 A C 2A R153 A C 2A R154 A C 3A R155 A C 3A R156 A C 3A R157 A C 3A R158 A C 3A R159 A C 3A R160 A C 3A R161 A C 3A R162 B C 2A R163 A C 3B R164 A C 7E R165 B C 4C R166 B C 6D R167 A C 1B R168 A C 1B R169 A C 1B R170 A C 1B R171 A C 1B R501 A C 8C R502 A C 8C R504 A C 8B R505 A C 8B R1201 B C 4C R1202 B C 4D R1203 B C 4D R1204 B C 4D R1601 A C 8C R1602 A C 8C R1603 B C 7C R1604 B C 7C R1605 B C 7C R1606 B C 7C R1607 B C 7C R1608 B C 7C R1609 B C 7C R1610 B C 8B R1611 B C 7C R1612 B C 8C R1613 B C 8B R1614 B C 8C R1615 B C 8C R1616 B C 8C R1617 B C 8C R1618 A C 8C R1619 A C 8C R1620 A C 8C R1621 A C 8C R1622 A C 8C R1623 B C 8C R1624 B C 7B R1625 B C 8C R1626 A C 7C R1627 A C 8C R1628 B C 8D R1629 B C 8D R1630 B C 8D R1631 B C 8B R1632 B C 8C R1633 B C 8C R2001 B C 3D R2002 B C 4D R2003 B C 3D R2004 B C 4D R2005 A C 4D R2006 A C 4D R2011 B C 4D R2012 B C 4D R2016 B C 4A R2021 B C 4A R2022 B C 4A R2023 B C 4A R2024 B C 4A
R2025 B C 4A R2026 B C 1C R2027 B C 1C R2029 B C 3B R2061 B C 3A R2062 B C 4A R2063 B C 4A R2071 B C 4A R2072 B C 4A R2073 B C 4A R2074 B C 4A R2075 B C 4A R2076 B C 4A R2401 A C 7E R2402 A C 7E R2403 A C 7E R2404 A C 7E R3001 B C 4B R3002 A C 4C R3004 A C 5C R3006 A C 4C R3007 A C 4C R3008 A C 5C R3009 A C 3B R3010 A C 3B R3014 B C 4C R3015 B C 4C R3016 B C 4C R3017 B C 4C R3018 A C 4C R3021 B C 4C R3022 B C 5C R3023 B C 5C R3024 B C 5C R3025 B C 4B R3026 B C 4B R3027 B C 4B R3028 A C 4B R3029 B C 4C R3030 B C 3C R3031 B C 4C R3032 B C 5C R3033 B C 5C R3034 A C 3C R3035 B C 4C R3036 B C 4C R3101 B C 3A R3102 B C 3A R3103 B C 3A R3108 B C 3A R3109 B C 1B R3110 B C 1B R3111 B C 1B R3112 B C 1C R3113 B C 1C R3114 B C 1C R3115 B C 1B R3116 B C 1B R3117 B C 1B R3131 B C 4A R3132 B C 4A R3134 B C 3E R3135 B C 4A R3136 B C 4A R3137 B C 4A R3138 B C 4A R3501 A C 5A R3503 B C 5A R3504 A C 5A R3506 A C 5A R3508 B C 5A R3509 A C 5A R3515 A C 5A R3519 B C 5A R3520 B C 5A R3536 A C 5A R3537 A C 5A R3538 A C 5A R3539 A C 5A R3540 B C 5A R3901 A C 5A R3902 A C 6A R4001 B C 2C R4002 B C 1C R4003 B C 2C
REF.No. LOCATION
R4004 B C 2C R4006 B C 2C R4007 B C 2C R4008 B C 1D R4009 B C 2D R4010 B C 2C R4011 B C 1D R4012 B C 1D R4013 B C 2D R4014 B C 2D R4015 A C 2D R4016 A C 2D R4017 A C 2D R4018 A C 2D R4019 A C 2D R4020 A C 2D R4021 A C 2D R4022 A C 2D R4023 A C 2D R4024 A C 2D R4025 A C 2C R4026 A C 2C R4027 A C 1C R4029 A C 1C R4035 B C 2B R4036 B C 2B R4037 B C 2B R4038 B C 3B R4101 B C 3A R4102 B C 3A R4103 B C 3A R4104 B C 3A R4105 B C 3A R4106 B C 2A R4107 B C 2A R4108 B C 2A R4109 B C 3A R4110 B C 3A R4111 B C 3A R4201 B C 5D R4202 B C 5D R4203 B C 6D R4204 B C 5D R4205 B C 5D R4206 B C 5D R4207 B C 5D R4208 B C 5D R4209 B C 5D R4210 B C 5D R4211 B C 5D R4212 B C 5D R4213 B C 5D R4214 B C 6D R4215 B C 5D R4216 B C 5D R4217 B C 5D R4218 B C 4E R4219 B C 4E R4220 B C 4E R4221 B C 4E R4222 B C 4E R4223 B C 4E R4224 B C 4E R4251 B C 6E R4252 B C 6E R4253 B C 5E R4254 B C 6E R4255 B C 5E R4256 B C 5E R4257 B C 5E R4258 B C 6E R4259 B C 6E R4262 A C 5E R4501 B C 5D R4502 B C 5D R4503 B C 4D R4504 B C 4D R4505 B C 5D R4506 B C 4D R4507 B C 4D R4513 B C 4D R4514 B C 5D R4515 B C 5D R4516 A C 5E R4518 A C 5E
REF.No. LOCATION
R4519 A C 5E R4520 A C 5E R5201 B C 2E R5202 B C 2E R5211 B C 3D R5212 A C 2D R5213 A C 2D R5214 A C 2D R5215 A C 2D R5216 A C 2D R5217 B C 3D R5218 A C 2D R5220 A C 2D R6001 B C 7C R6002 B C 7C R6009 B C 7C R6010 B C 7C R6011 B C 7C R6012 B C 7C R6111 B C 6C R6112 B C 6C R6113 B C 6C R6114 B C 6C R6115 B C 6C R6121 B C 6C R6122 B C 6C R6123 B C 6C R6124 B C 6C R6125 B C 5D R6126 B C 5D R6127 B C 5D R6128 B C 5D R6129 B C 6C R6131 A C 6C R6132 A C 6C R6133 B C 7C R6134 B C 7C R6135 A C 7C R6136 A C 7D R6137 B C 6C R6138 B C 6C R6141 B C 6B R6142 B C 7C R6143 B C 6C R6144 B C 6B R6145 B C 7B R6146 B C 7B R6151 B C 7C R6152 B C 6C R6153 B C 6C R6154 B C 7C R6161 B C 6B R6162 B C 7B R6163 B C 7C R6164 B C 7B R6165 A C 6C R6166 A C 6C R6167 A C 6C R6168 A C 6C R6169 A C 6C R6170 A C 7C R6171 A C 7C R6172 B C 6D R6173 B C 6D R6174 B C 6D R6175 B C 6D R6176 B C 6D R6177 B C 6D R6178 B C 6D R6179 B C 7C R6180 A C 7D R6181 A C 7D R6182 A C 7C R6183 A C 7D R6201 B C 6E R6202 B C 6E R6203 B C 6E R6204 B C 6E R6205 B C 6E R6206 B C 6E R6902 B C 6D R6903 B C 7B R6907 B C 7C R6914 B C 7B R6931 B C 6C R6932 B C 6C
REF.No. LOCATION
R7801 A C 7D R7802 A C 7D R7803 A C 7D R7804 A C 7D R7808 B C 7D R7809 A C 7E R7810 A C 7D R8001 A C 7B R8002 B C 7A R8003 B C 7A R8004 B C 7B R8005 B C 7B R8006 A C 7B R8007 A C 7B R8008 B C 6A R8009 B C 6A R8010 B C 6A R8011 B C 6A R8012 B C 6B R8013 B C 6A R8014 B C 6A R8015 B C 6B R8016 B C 6B R8017 B C 6B R8018 B C 6B R8019 B C 6B R8020 B C 6B R8021 B C 6B R8022 B C 6A R8023 B C 6A R8024 B C 6A R8025 B C 6A R8026 B C 6A R8027 B C 8A R8028 B C 6A RA101 A C 2A RA102 A C 2B RA103 B C 2B RA104 B C 2B RA105 B C 2B RA106 A C 3B RA107 A C 3A RA108 A C 3A RA109 A C 3A
TEST POINT
TP101 A C 2C TP102 B C 2B TP103 A C 2A
OTHER
F6001 B C 5D F6003 B C 6D F6004 B C 6D F7801 A C 7D FL4101 B C 3A FL4102 B C 3A J501 B D 8B J502 A D 5C J503 B D 8A J504 A D 1C J505 A D 1B SW503 A C 8D X101 B C 2A X102 A C 1A X3001 A D 4B X8001 B C 8A
4-4
COMPONENT SIDE (A)
4-5
4-6
SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
5.1 PACKING ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
4
6
FINAL ASSY
18
17
BATTERY PACK (BN-V11U)
<M2>
8
10
1
5
AC POWER ADAPTER
AA-V16U
16
Refer to MANUAL No. 86526 sec.6
11
3
2
LABEL (SERIAL)
GR-AX850U/UC
Packing
5-1
# REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- -----------------------------------------------------
✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽✽
PACKING ASSEMBLY <M1>
1 LY30023-002A POLY BAG 2 LY31561-026A PACKING CASE 3 LY31562-001A CUSHION 4 QPA02003006 POLY BAG
!
5 LYT0502-001A IB(EN)
! ! !
6 PECA0903 LI BATTERY 8 QAM0170-001 DC CABLE 10 LY20186-001A SHOULDER STRAP 11 – BATTERY,CASS.ADAPTER,R6(AA) 16 YQ31963A-3 CASS.ADAPTER ASSY
17 – BATTERY,RCU,R03(AAA)X2 18 LY42129-001A REMOTE CONTROLLER
LYT0502-002A IB(SP) LYT0502-003A IB(PT)
or YQ31963B-3 CASS.ADAPTER ASSY
• INSTRUCTIONS
EN........... ENGLISH
SP ........... SPANISH
PT ........... PORTUGUESE
5-2
Ozaki-M13C6C
VICTOR COMPANY OF JAPAN, LIMITED VIDEO DIVISION
S40894
Printed in Japan
