SECTION 5
PARTS LIST
SAFETY PRECAUTION
Parts identified by the symbol are critical for safety. Replace only with specified part numbers.
5.1 PACKING AND ACCESSORY ASSEMBLY <M1>
The instruction manual to be provided with this product will differ according to the destination.
4
FINAL ASSY
<M2>
14
13
11
16
15
3
7
8
26
5
23
21
22
10
12
5-1
6
2
1
LABEL
(SERIAL)
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
******************************
PACKING AND ACCESSORY ASSEMBLY <M1>
1 LY32179-003A PACKING CASE
2 LY32553-001A CUSHION
3 LY30023-002A POLY BAG
4 QPA02003506 POLY BAG,A,B,C
YQM30061-3 POLY BAG,D
!
5 LTY0860-002B INST.BOOK(GE),B
!
!
!
!
!
!
!
!
!
!
6 PEMC1174
7 BT-54008-2 GUARANTY CARD,D
8 BT-54013-2 WARRANTY CARD,A,B,C
10 PEAC0362-150 CABLE ASSY,AUDIO/VIDEO CABLE
!
11 LY20847-001B AC ADAPTER,AP-V12EG,A,B,C
!
!
12 QMPL120-190-JR POWER CORD,A,B,C
!
!
13 YQ10629E BATTERY PACK,BN-V11U-E
14 LY20186-001A SHOULDER STRAP
15 LY43388-001A LENS CAP
16 – BATTERY,AA(R6),A
21 YQ31963B-3 CASSETTE ADAPTER,A
22 YQ43446 POLY BAG,A
23 QAM0004-003 S CABLE,B,C,D
26 LYT0194-001B Q.CARD(JUK),D
LYT0860-003B INST.BOOK(FR),B
LYT0860-004B INST.BOOK(DU),B
LYT0860-005B INST.BOOK(SP),B
LYT0860-006B INST.BOOK(IT),B
LYT0860-011A INST.BOOK(RU),C
LYT0860-012A INST.BOOK(CZ),C
LYT0860-013A INST.BOOK(PO),C
LYT0860-014A INST.BOOK(HU),C
LYT0861-001B INST.BOOK(EN),D
LYT0933-001A INST.BOOK(RU),A
CONNECTOR,CABLE ADAPTER,VC-V3595E,B,C,D
LY20847-001C AC ADAPTER,AP-V12EG,D
QMPP110-190-JR POWER CORD,D
MODEL MARK
GR-SX23EG-R A
GR-SX24EG-X B
GR-SX24EG-Z C
GR-SX24EK D
• INSTRUCTIONS
GE ...... GERMANY
FR ....... FRENCH
DU ...... DUTCH
SP ....... SPANISH
IT ........ ITALIAN
RU....... RUSSIAN
CZ ....... CZECH
PO ...... POLISH
HU ...... HUNGARIAN
EN ....... ENGLISH
5-2
5.2 FINAL ASSEMBLY <M2>
4
h
J
5
3
110
110B
116
117
111
117
118
114
j
h
116
116
112
110A
ELECTRONIC
VIEWFINDER
115
u
g
116
<M4>
110C
y
CCD
<02>
113
u
v
nn
113
145
ss
113
257
148
147
s
ff
144
p
148
n
cc
s
n
136
MAIN
<01>
nn
139
aa
1
w
148
148
146
y
ff
z
bb
gg
w
jj
dd
ee
x
143
5-3
251C
ss
251C
251C
251C
251C
251B
OPTICAL BLOCK
SECTION
251C
251C
251A
251C
251D
252
253
e
251C
251
254
135A
256
255
256
135B
135C
135F
135K
135D
135
135H
135E
135E
135G
13
135
1
k
b
m
jj
136
141
142
gg
125
131
131
f
126
140A
w
135E
5E
35J
135E
149
v
130
126
p
k
c
149
f
aa
g
e
140C
d
j
a
b
140
162
161
MECHANISM
<M3>
c
131
162
h
140E
140F
136
140E
mm
140B
a
rr
140B
107
m
151
mm
105
rr
140D
pp
105
101E
101E
140D
150
RATING
LABEL
101
150
dd
ee
x
bb
101F
z
155
d
cc
156
156
159
156
165
101C
106A
164
163
102
106
pp
101B
kk
159A
158
157
kk
156
160
160
103
104
104
101D
101A
5-4
# REF No. PART No. PART NAME, DESCRIPTION # REF No. PART No. PART NAME, DESCRIPTION
---------------- ----------------------- ----------------------------------------------------- ----------------- ----------------------- -----------------------------------------------------
141 LY32327-001A SHIELD CASE(MAIN)
******************************
FINAL ASSEMBLY <M2>
101 LY20680-017A CASSETTE COVER(S)ASSY,B,D
LY20680-021A CASSETTE COVER(S)ASSY,A,C
101A LY32405-002A PLATE(WINDOW S)
101B LY42883-001A MARK
101C LY32562-002A STICKER(B)
101D LY32024-001B HINGE(CASSETTE COVER)
101E QYSLSF2060D SCREW,X2
101F LY43537-001A STICKER(E),A,C
102 QYSLSP2030D SCREW
103 LY10272-018A UPPER CASE(S),B,C,D
LY10272-023A UPPER CASE(S),A
104 QYSLSF2060D SCREW,X2
105 QYSLSF2060D SCREW,X2
106 LY32041-001E BUTTON(PUSH)ASSY
106A LY30002-049B COMPRESSION SPRING
107 LY32038-001A UPPER COVER(S)ASSY
110 LY20684-020A LOWER CASE ASSY,A
LY20684-021A LOWER CASE ASSY,B,C,D
110A LY40081-001A CAP
110B LY20682-001A GRIP BELT
110C LY30018-003A SPECIAL SCREW
111 LY31945-003A COVER(JACK)
112 LY31946-001A COVER(JIG)
113 QYSLSF2050Z SCREW,X3
114 QYSLSF2060D SCREW
115 QYSLSF2060D SCREW
116 QYSLSF2060D SCREW,X4
117 QYSLSF2060D SCREW,X2
118 QYSLSF2060D SCREW
125 LY20614-002C TOP OPERATION UNIT,B,C,D
LY20614-014C TOP OPERATION UNIT,A
126 QYSLSF2060D SCREW,X2
130 LY20615-006E REAR UNIT
131 QYSLSF2060D SCREW,X3
135 LY20683-030A FRONT COVER ASSY,A
LY20683-033A FRONT COVER ASSY,B,C,D
135A LY31937-001A HOOD
135B LY31938-001A COVER(HOOD)
135C LY31936-001A RING
135D LY32482-001A MICROPHONE
135E QYSLSF2060D SCREW,X4
135F LY30934-022A COVER(LIGHT),A
LY32040-001A DC LIGHT,B,C,D
135G LY32058-001A STICKER(A),A
LY32058-002A STICKER(A),B,C,D
135H LY32060-005A STICKER(C),A
LY32060-004A STICKER(C),B,C,D
135J LY30029-0B4A SPACER(A),B,C,D
135K YQ44341-6 CAUTION LABEL,B,C,D
136 QYSLSF2060D SCREW,X3
139 QYSPSTU1725M SCREW
140 LY20832-002B FRAME ASSY,A
LY20832-001B FRAME ASSY,B,C,D
140A YQ31843 BASE
140B QYSLSF2060D SCREW,X2
140C LY30029-0A4A SPACER(A)
140D LY41082-001A CUSHION(OP),X2
140E YQ43810-1-1 CONTACT(LIGHT),X2,B,C,D
140F WJM0259-001A E-SI C WIRE C-F,B,C,D
142 QYSPSPU1720Z SCREW
143 QYSLSF2060D SCREW
144 QYSLSF2060D SCREW
145 WJT0072-001A E-CARD WIRE,OP-MAIN CN15
146 QAL0389-001 FPC,MAIN CN22-CCD CN5301
147 LY20613-001B ZOOM UNIT
148 QYSLSF2060D SCREW,X4
149 LY41173-001A SPECIAL SCREW,X2
150 LY30018-050A SPECIAL SCREW,X2
151 QYSLSP2030D SCREW
155 LY31808-001C CASSETTE HOUSING FINAL ASSY
156 LY42722-003A SCREW,X4
157 LY31294-001B CASSETTE COVER INSIDE
158 LY32026-001B BRACKET(C.C/S)
159 LY31790-001A FRONT FRAME ASSY
159A YQ44144-1-1 TAPE GUIDE
160 SPSH1725M SCREW,X2
161 LY32326-001A BRACKET(MECHA)
162 LY42722-003A SCREW,X2
163 QYSLSF1750D SCREW
164 LY31807-001A SIDE BRACKET L
165 LY42722-003A SCREW
– OPTICAL BLOCK SECTION –
251 LY30948-003A OP BLOCK ASSY
251A PTY30948-002 FOCUS MOTOR
251B PTY30948-301 ZOOM MOTOR
251C PTY30151-016 TAPPING SCREW,X9
251D PTY30948-006 IRIS MOTOR UNIT
252 LY43383-001A OPTICAL LPF
253 LY31370-001A SPACER RUBBER
254 LY20497-001A CCD SPACER
255 LYH30374-001A CCD BASE ASSY
256 QYSPSGU2080Z SCREW,X2
257 LY30018-072A SPECIAL SCREW
5-5
(Sanwa)-M2C6B2/7B3
GR-SX23EG,SX24EG/EK
E. & O. E. No. 86661
