JVC GR-DX67EK, GR-DX77EK, GR-DX77ER, GR-DX77EX, GR-DX77EY User Manual
...
DIGITAL VIDEO CAMERA
Dear Customer,
Thank you for purchasing this digital
video camera. Before use, please read
the safety information and precautions
contained in the pages 3 – 4 to ensure
safe use of this product.
ENGLISH
GETTING STARTED
6
GR-DX97
GR-DX77
GR-DX67
GR-DX57
Please visit our Homepage on the World Wide Web for
Digital Video Camera:
http://www.jvc.co.jp/english/cyber/
For Accessories:
http://www.jvc.co.jp/english/accessory/
GR-DX48
GR-DX37
GR-DX28
GR-DX27
VIDEO RECORDING &
PLAYBACK
DIGITAL STILL CAMERA
(D.S.C.) RECORDING &
PLAYBACK (GR-DX97/77/67
only)
ADVANCED FEATURES
REFERENCES
TERMS Back cover
15
21
27
45
The camcorder illustrations appearing in this instruction
manual are of the GR-DX97.
The D.S.C. (Digital Still Camera) features are available
on GR-DX97, GR-DX77 and GR-DX67.
INSTRUCTIONS
To deactivate the demonstration, set
“DEMO MODE” to “OFF”.
(墌 pg. 27, 29)
LYT1246-001A
EN
2 EN
Major Features of this Camcorder
Wipe/Fader Effects
You can use the Wipe/Fader Effects to make prostyle scene transitions. (墌 pg. 34)
Fade in
Fade out
Program AE with Special Effects
For example, “SPORTS” mode allows fast-moving
images to be captured one frame at a time, for vivid,
stable slow-motion. (墌 pg. 35)
LED Light
You can brighten the subject in the dark place with
the LED Light. (墌 pg. 31)
Backlight Compensation
Simply pressing the BACK LIGHT button brightens
the image darkened by backlight. (墌 pg. 33)
● You can also select a spot metering area so that
more precise exposure compensation is available.
(墌 pg. 33, Spot Exposure Control)
Navigation Function (GR-DX97/77/67 only)
The Navigation Function helps you check tape
contents by making thumbnail images on a memory
card. (墌 pg. 35)
ONITNAV I GA
TC : 13 : 23 : 15
1 2 3
4 5 00 6
3. 2 54DAT E : 2 :’ 0 43:29
E-Mail Clip Recording (GR-DX97/77/67 only)
You can record video clips on the memory card as
files which can be sent via e-mail. (墌 pg. 24)
SAFETY PRECAUTIONS
IMPORTANT (for owners in the U.K.)
Connection to the mains supply in the United
Kingdom.
DO NOT cut off the mains plug from this equipment.
If the plug fitted is not suitable for the power points in your
home or the cable is too short to reach a power point, then
obtain an appropriate safety approved extension lead or
consult your dealer.
BE SURE to replace the fuse only with an identical
approved type, as originally fitted, and to replace the
fuse cover.
If nonetheless the mains plug is cut off be sure to remove
the fuse and dispose of the plug immediately, to avoid
possible shock hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a mains plug then
follow the instructions given below:
DO NOT make any connection to the Larger Terminal
coded E or Green.
The wires in the mains lead are coloured in accordance
with the following code:
Blue to N (Neutral) or
Black
Brown to L (Live) or
Red
If these colours do not correspond with the terminal
identifications of your plug, connect as follows:
Blue wire to terminal coded N (Neutral) or coloured black.
Brown wire to terminal coded L (Live) or coloured Red.
If in doubt — consult a competent electrician.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD,
DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.
CAUTIONS:
● To prevent shock, do not open the cabinet. No user
serviceable parts inside. Refer servicing to qualified
personnel.
● When you are not using the AC Adapter for a long period
of time, it is recommended that you disconnect the
power cord from AC outlet.
CAUTION:
To avoid electric shock or
damage to the unit, first
firmly insert the small end
of the power cord into the
AC Adapter until it is no
longer wobbly, and then
plug the larger end of the
power cord into an AC
outlet.
CAUTIONS:
● This camcorder is designed to be used with PAL-type
colour television signals. It cannot be used for playback
with a television of a different standard. However, live
recording and LCD monitor/viewfinder playback are
possible anywhere.
● Use the JVC BN-V107U/V114U battery packs and, to
recharge them or to supply power to the camcorder from
an AC outlet, use the provided multi-voltage AC Adapter.
(An appropriate conversion adapter may be necessary
to accommodate different designs of AC outlets in
different countries.)
EN 3
Caution on Replaceable lithium battery
The battery used in this device may present a fire or
chemical burn hazard if mistreated.
Do not recharge, disassemble, heat above 100°C or
incinerate.
Replace battery with Panasonic (Matsushita Electric),
Sanyo, Sony or Maxell CR2025.
Danger of explosion or Risk of fire if the battery is
incorrectly replaced.
● Dispose of used battery promptly.
● Keep away from children.
● Do not disassemble and do not dispose of in fire.
NOTES:
● The rating plate (serial number plate) and safety caution
are on the bottom and/or the back of the main unit.
● The rating information and safety caution of the AC
Adapter are on its upper and lower sides.
When the equipment is installed in a cabinet or on a shelf,
make sure that it has sufficient space on all sides to allow
for ventilation (10 cm or more on both sides, on top and at
the rear).
Do not block the ventilation holes.
(If the ventilation holes are blocked by a newspaper, or
cloth etc. the heat may not be able to get out.)
No naked flame sources, such as lighted candles, should
be placed on the apparatus.
When discarding batteries, environmental problems must
be considered and the local rules or laws governing the
disposal of these batteries must be followed strictly.
The apparatus shall not be exposed to dripping or
splashing.
Do not use this equipment in a bathroom or places with
water.
Also do not place any containers filled with water or liquids
(such as cosmetics or medicines, flower vases, potted
plants, cups etc.) on top of this unit.
(If water or liquid is allowed to enter this equipment, fire or
electric shock may be caused.)
Do not point the lens or the viewfinder directly into the sun.
This can cause eye injuries, as well as lead to the
malfunctioning of internal circuitry. There is also a risk of
fire or electric shock.
CAUTION!
The following notes concern possible physical damage to
the camcorder and to the user.
Carrying or holding the camcorder by the viewfinder and/or
the LCD monitor can result in dropping the unit, or in a
malfunction.
Take care not to get your finger caught in the cassette
holder cover. Do not let children operate the camcorder, as
they are particularly susceptible to this type of injury.
Do not use a tripod on unsteady or unlevel surfaces. It
could tip over, causing serious damage to the camcorder.
CAUTION!
Connecting cables (Audio/Video, S-Video, etc.) to the
camcorder and leaving it on top of the TV is not
recommended, as tripping on the cables will cause the
camcorder to fall, resulting in damage.
4 EN
SOME DO’S AND DON’TS ON THE SAFE USE OF EQUIPMENT
This equipment has been designed and
manufactured to meet international safety standards
but, like any electrical equipment, care must be taken
if you are to obtain the best results and safety is to
be assured.
DO read the operating instructions before you attempt to use
the equipment.
DO ensure that all electrical connections (including the mains
plug, extension leads and interconnections between pieces
of equipment) are properly made and in accordance with the
manufacturer’s instructions. Switch off and withdraw the
mains plug when making or changing connections.
DO consult your dealer if you are ever in doubt about the
installation, operation or safety of your equipment.
DO be careful with glass panels or doors on equipment.
DON’T continue to operate the equipment if you are in any
doubt about it working normally, or if it is damaged in any way
— switch off, withdraw the mains plug and consult your
dealer.
DON’T remove any fixed cover as this may expose
dangerous voltages.
DON’T leave equipment switched on when it is unattended
unless it is specifically stated that it is designed for
unattended operation or has a standby mode. Switch off
using the switch on the equipment and make sure that your
family knows how to do this. Special arrangements may need
to be made for infirm or handicapped people.
DON’T use equipment such as personal stereos or radios so
that you are distracted from the requirements of road safety. It
is illegal to watch television whilst driving.
DON’T listen to headphones at high volume, as such use can
permanently damage your hearing.
DON’T obstruct the ventilation of the equipment, for example
with curtains or soft furnishings. Overheating will cause
damage and shorten the life of the equipment.
DON’T use makeshift stands and NEVER fix legs with wood
screws — to ensure complete safety always fit the
manufacturer’s approved stand or legs with the fixings
provided according to the instructions.
DON’T allow electrical equipment to be exposed to rain or
moisture.
ABOVE ALL
● NEVER let anyone especially children push anything into
holes, slots or any other opening in the case — this could
result in a fatal electrical shock;
● NEVER guess or take chances with electrical equipment of
any kind — it is better to be safe than sorry!
This camcorder is designed exclusively for the digital video
cassette, SD Memory Card and MultiMediaCard. Only
cassettes marked “” and memory cards* marked
“” or “” can be used with this unit.
Before recording an important scene…
…make sure you only use cassettes with the Mini DV mark
.
…make sure you only use memory cards* with the mark
or .
…remember that this camcorder is not compatible with other
digital video formats.
…remember that this camcorder is intended for private
consumer use only. Any commercial use without proper
permission is prohibited. (Even if you record an event such as
a show, performance or exhibition for personal enjoyment, it
is strongly recommended that you obtain permission
beforehand.)
* Memory cards can be used with GR-DX97, GR-DX77 and
GR-DX67 only.
®
● Microsoft
or trademarks of Microsoft Corporation in the United States
and/or other countries.
● Macintosh is a registered trademark of Apple Computer,
Inc.
● QuickTime is a registered trademark of Apple Computer,
Inc.
and Windows® are either registered trademarks
GETTING STARTED 6
Index ..............................................................................6
Provided Accessories ....................................................9
Power ...........................................................................11
Operation Mode ...........................................................12
Date/Time Settings ......................................................12
Grip Adjustment ...........................................................13
Viewfinder Adjustment .................................................13
Brightness Adjustment Of The Display ........................13
Tripod Mounting ...........................................................13
Loading/Unloading A Cassette .................................... 14
Loading/Unloading A Memory Card (GR-DX97/77/67
only) .........................................................................14
VIDEO RECORDING & PLAYBACK 15
VIDEO RECORDING ........................................................15
Basic Recording ...........................................................15
Tape Remaining Time .............................................15
LCD Monitor And Viewfinder ...................................15
Zooming ...................................................................16
Journalistic Shooting ...............................................16
Interface Shooting ...................................................16
Time Code ...............................................................17
Recording From The Middle Of A Tape ...................17
VIDEO PLAYBACK ..........................................................17
Normal Playback ..........................................................17
Still Playback ...........................................................17
Shuttle Search .........................................................18
Blank Search ...........................................................18
Connections To A TV Or VCR .....................................18
Playback Using The Remote Control ...........................19
DIGITAL STILL CAMERA (D.S.C.) RECORDING &
PLAYBACK (GR-DX97/77/67 only) 21
D.S.C. RECORDING (GR-DX97/77/67 only) ....................21
Basic Shooting (D.S.C. Snapshot) ...............................21
Interval Shooting ......................................................21
D.S.C. PLAYBACK (GR-DX97/77/67 only) ......................22
Normal Playback Of Images ........................................22
Auto Playback Of Images ............................................ 22
Playback Of Video Clips .............................................. 22
Index Playback Of Files ...............................................23
Viewing File Information ..............................................23
Removing On-Screen Display .....................................23
ADDITIONAL FEATURES FOR D.S.C. (GR-DX97/77/67 only) ......24
E-Mail Clip Recording ..................................................24
Dubbing Still Images Recorded On A Tape To A Memory
Card .........................................................................24
Resetting The File Name .............................................24
Protecting Files ............................................................25
Deleting Files ...............................................................25
Setting Print Information (DPOF Setting) .....................26
Initialising A Memory Card ........................................... 26
CONTENTS
EN 5
ADVANCED FEATURES 27
MENUS FOR DETAILED ADJUSTMENT .............................. 27
Changing The Menu Settings ...................................... 27
Recording Menus ........................................................ 28
Playback Menus .......................................................... 30
FEATURES FOR RECORDING ........................................... 31
LED Light .................................................................... 31
Night Scope ................................................................. 32
Snapshot (For Video Recording) ................................. 32
Manual Focus .............................................................. 32
Exposure Control ........................................................ 33
Iris Lock ....................................................................... 33
Backlight Compensation ............................................. 33
Spot Exposure Control ................................................ 33
White Balance Adjustment .......................................... 34
Manual White Balance Adjustment ............................. 34
Wipe Or Fader Effects ................................................. 34
Program AE With Special Effects ................................ 35
Navigation Function (GR-DX97/77/67 only) ................ 35
EDITING ........................................................................ 37
Dubbing To Or From A VCR ....................................... 37
Dubbing To Or From A Video Unit Equipped With A DV
Connector (Digital Dubbing) .................................... 38
Connection To A Personal Computer ......................... 39
Audio Dubbing ............................................................. 40
Insert Editing ............................................................... 40
Random Assemble Editing [R.A.Edit] .......................... 41
REFERENCES 45
TROUBLESHOOTING ...................................................... 45
USER MAINTENANCE ..................................................... 48
CAUTIONS ..................................................................... 49
SPECIFICATIONS ............................................................ 51
TERMS Back cover
GETTING STARTED
A
6 EN
Index
U
C
S
O
F
L
I
T
H
G
I
N
B
G
H
SET
T
T
A
H
C
G
K
I
L
To open the connector cover, pull the bottom
end of the cover, then open it.
Bottom end
When Using the LCD Monitor
Correct direction for
opening
Correct direction for
closing
The LCD monitor cannot be rotated downward
( direction) from the position illustrated above.
Rotating to the wrong direction may cause a malfunction.
Make sure to rotate to the correct direction.
TTENTION:
● Be careful not to cover h, k and p during shooting.
● Be careful not to cover
g during playback.
Controls
a Menu Button [MENU] (墌 pg. 27)
b Sub Zoom Buttons [T/W] (墌 pg. 16)
Speaker Volume Control [VOL. +, –] (墌 pg. 17)
c Snapshot Button [SNAPSHOT] (墌 pg. 21, 32)
d Recording Start/Stop Button (墌 pg. 15)
e VIDEO/MEMORY Switch (GR-DX97/77/67 only)
(墌 pg. 12)
f Power Zoom Lever [T/W] (墌 pg. 16)
g Dioptre Adjustment Control (墌 pg. 13)
h Power Switch [A, M, PLAY, OFF] (墌 pg. 12)
i Lock Button (墌 pg. 12)
j Set Button [SET] (墌 pg. 27)
k Stop Button [8] (墌 pg. 17)
Backlight Compensation Button [BACK LIGHT]
(墌 pg. 33)
Down Button [ ] (墌 pg. 27)
l Rewind Button [
Night Button [NIGHT] (墌 pg. 32)
Left Button [ ] (墌 pg. 27)
3
] (墌 pg. 17)
m Play/Pause Button [4/9] (墌 pg. 17)
Manual Focus Button [FOCUS] (墌 pg. 32)
Up Button [ ] (墌 pg. 27)
n Fast-Forward Button [
LED Light Button [LIGHT] (墌 pg. 31)
Right Button [ ] (墌 pg. 27)
5
] (墌 pg. 17)
o Information Button [INFO] (GR-DX97/77/67 only)
(墌 pg. 23)
E-Mail Clip Recording Button [E-MAIL] (GR-DX97/77/
67 only) (墌 pg. 24)
p Index Button [INDEX] (GR-DX97/77/67 only)
(墌 pg. 23)
Navigation Button [NAVI] (GR-DX97/77/67 only)
(墌 pg. 36)
q Thumbnail Storing Button (GR-DX97/77/67 only)
[NAVI STORE] (墌 pg. 36)
r D.S.C. Playback Select Button [SELECT] (GR-DX97/
77/67 only) (墌 pg. 22, 23)
s Battery Release Switch [BATT.RELEASE] (墌 pg. 11)
t Cassette Open/Eject Switch [OPEN/EJECT]
(墌 pg. 14)
Connectors
The connectors are located beneath the covers.
U Microphone connector [MIC] (墌 pg. 30, 40)
(An optional microphone can be used during video
recording and audio dubbing. To stabilise the
microphone, use of an optional shoe adapter is
recommended.)
V USB (Universal Serial Bus) Connector (except
GR-DX27) (墌 pg. 39)
W S-Video/Audio/Video Input*/Output Connector [AV]
(墌 pg. 18, 37, 42)
* GR-DX97/77/57/37 only
X DC Input Connector [DC] (墌 pg. 11)
Y Digital Video Connector [DV IN*/OUT] (i.Link**)
(墌 pg. 38, 39)
* GR-DX97/77/57/37 only
**i.Link refers to the IEEE1394-1995 industry specification
and extensions thereof. The logo is used for products
compliant with the i.Link standard.
GETTING STARTED
EN 7
Indicators
D POWER/CHARGE Lamp (墌 pg. 11, 15)
E Tally Lamp (墌 pg. 15, 29)
Other Parts
c Viewfinder (墌 pg. 13)
d LCD Monitor (墌 pg. 15, 16)
e Battery Pack Mount (墌 pg. 11)
f Grip Strap (墌 pg. 13)
g Speaker (墌 pg. 17)
h Stereo Microphone (墌 pg. 40)
(When using an optional conversion lens, it may cover
this area. In this case, use of an optional microphone
is recommended.)
i LED Light (墌 pg. 31)
j Remote Sensor (墌 pg. 19)
k Camera Sensor
l Tripod Mounting Socket (墌 pg. 13)
m Monitor Latch
n Card Cover [MEMORY CARD] (GR-DX97/77/67 only)
(墌 pg. 14)
o Cassette Holder Cover (墌 pg. 14)
p Lens
LCD Monitor/Viewfinder Indications
During Video Recording Only
1h40m
REC
r
e
SOUND12BIT
15:55
a Navigation Indicator (GR-DX97/77/67 only) (墌 pg. 35)
b Selected Wipe/Fader Effect Indicator (墌 pg. 34)
c Tape Running Indicator (墌 pg. 15)
(Rotates while tape is running.)
d Selected Wide Mode Indicator (墌 pg. 29)
e Thumbnail Storing Indicator (墌 pg. 35)
f Recording Speed Mode (SP/LP) (墌 pg. 28)
g Tape Remaining Time (墌 pg. 15)
h REC: (Appears during recording.) (墌 pg. 15)
PAUSE: (Appears during Record-Standby mode.)
(墌 pg. 15)
i Insert Editing/Insert Editing Pause Mode (墌 pg. 40)
j Wind Cut Indicator (墌 pg. 29)
k Auxiliary Microphone Level Indicator
(Appears when an optional microphone is connected.
墌 pg. 30, “AUX MI C” )
l Time Code (墌 pg. 30, 31)
m Digital Image Stabiliser (“DIS”) (墌 pg. 28)
n Sound Mode Indicator (墌 pg. 28)
(Appears for approx. 5 seconds after turning on the
camcorder.)
GETTING STARTED
GETTING STARTED
8 EN
During D.S.C. Recording Only (GR-DX97/77/67 only)
6345
1024
51
7
a Image Size: 1024 (1024 x 768) or 640 (640 x 480)
(墌 pg. 30)
b : Focus Icon (墌 pg. 21)
c Shooting Icon (墌 pg. 21)
d Card Icon (墌 pg. 21)
e Picture Quality: (FINE) and (STANDARD) (in
f Remaining Number Of Shot (墌 pg. 21)
g Clock Icon (墌 pg. 21)
: Interval Shooting Icon (墌 pg. 21)
(Appears and blinks during shooting.)
: Appears during shooting.
: Blinks in white when a memory card is not loaded.
: Blinks in yellow while the camcorder is reading
the data in the memory card such as Navigation
thumbnail images, video clips, still images, etc.
order of quality) (墌 pg. 30)
(Displays the approximate remaining number of shots
that can be stored during D.S.C. recording, or the
remaining number of storable thumbnail images when
it reaches 10 or less during video recording.)
During E-Mail Clip Recording (GR-DX97/77/67 only)
During Both Video And D.S.C. Recording
8
9
1
40
2
3
4
3
5
6
7
a Operation Mode (墌 pg. 12)
b : Night-Scope Indicator (墌 pg. 32)
: Gain Up Mode (墌 pg. 28)
c LED Light Indicator (墌 pg. 31)
d White Balance Indicator (墌 pg. 34)
e : Spot Exposure Control Indicator (墌 pg. 33)
: Backlight Compensation Indicator (墌 pg. 33)
±: Exposure Adjustment Indicator (墌 pg. 33)
f Selected Program AE With Special Effects Indicator
(墌 pg. 35)
g Iris Lock Indicator (墌 pg. 33)
h Approximate Zoom Ratio (墌 pg. 16)
i Zoom Indicator (墌 pg. 16)
j O: (Appears when taking Snapshot.) (墌 pg. 32)
k BRIGHT: Brightness Control Indicator (LCD monitor/
Viewfinder) (墌 pg. 13)
l Battery Indicator (墌 pg. 47)
m Date/Time (墌 pg. 12)
n Manual Focus Adjustment Indicator (墌 pg. 32)
x
BRIGHT
W
T
1 0 1110.:0
O
0
q
w
4
.
0
0
er
160
a Image Size: 160 (160 x 120)
b Shooting Icon (墌 pg. 21, 24)
c E-Mail Clip Recording Indicator (墌 pg. 24)
d Memory Card Remaining Time For E-Mail Clip
Recording (墌 pg. 24)
e E-Mail Clip Recording Time (墌 pg. 24)
f Auxiliary Microphone Level Indicator
(Appears when an optional microphone is connected.
墌 pg. 30, “AUX MI C” )
0
hm
PILC-E
:10
00 : 15
During Video Playback
1
BIT
1L2
2 0 :/2M
I
X
GETTING STARTED
EN 9
Provided Accessories
4
3
2
5
6
BLANK SEARCH
PUSH "STOP" BUTTON
MIC
TO CANCEL
V
O
LUME
1
:
25
0
1 0 1110.:0
.
9
7
4
0
0
8
a Sound Mode Indicator (墌 pg. 30)
b Blank Search Indicator (墌 pg. 18)
c Thumbnail Storing Indicator (墌 pg. 36)
d Tape Speed (墌 pg. 28)
e U : Playback
5
: Fast-Forward/Shuttle Search
3
: Rewind/Shuttle Search
9 : Pause
9 U : Forward Frame-By-Frame Playback/Slow-
Motion
Y 9 : Reverse Frame-By-Frame Playback/SlowMotion
D : Audio Dubbing
9D : Audio Dubbing Pause
(Appear while a tape is running.)
f Sound Input For Audio Dubbing (墌 pg. 40)
g Battery Indicator (墌 pg. 47)
h Date/Time (墌 pg. 29, 31)
i VOLUME : Volume Level Indicator ( 墌 pg. 17)
BRIGHT : Brightness Control Indicator (LCD monitor/
Viewfinder) (墌 pg. 13)
: Auxiliary Microphone Level Indicator
(Appeares when an optional microphone is connected
during Audio Dubbing. 墌 pg. 40)
j Time Code (墌 pg. 30, 31)
During D.S.C. Playback (GR-DX97/77/67 only)
1
BR I GHT
4
a Operation Mode Indicator (墌 pg. 23)
b Folder/File Number (墌 pg. 23)
c Battery Indicator (墌 pg. 47)
d Brightness Control Indicator (LCD monitor/Viewfinder)
(墌 pg. 13)
2
100-0013
3
OR
a AC Adapter AP-V14E (LY21104-012A) or AP-V15E
(LY21153-003A)
b Power Cord
c Battery Pack BN-V107U-S
d S/AV/Editing Cable
e Audio Extension Cable (for optional microphone,
墌 pg. 10 for connection)
f USB Cable (except GR-DX27)
g Core Filter [large] (except GR-DX27) (for USB Cable
墌 pg. 10 for attachment)
h Core Filter [small] (for Audio Extension Cable
墌 pg. 10 for attachment)
i CD-ROM (except GR-DX27)
j Cable Adapter
k Remote Control Unit RM-V720U
l Lithium Battery CR2025* (for remote control unit)
m Memory Card 8 MB (GR-DX97/77/67 only) (Already
inserted in the camcorder)
n Lens Cap (墌 pg. 10 for attachment)
* A lithium battery is pre-installed in the Remote Control Unit
at time of shipment (with insulation sheet). To use the
Remote Control Unit, remove the insulation sheet.
NOTES:
● In order to maintain optimum performance of the
camcorder, provided cables may be equipped with one or
more core filter. If a cable has only one core filter, the end
that is closest to the filter should be connected to the
camcorder.
● Make sure to use the provided cables for connections. Do
not use any other cables.
GETTING STARTED
GETTING STARTED
10 EN
How To Attach The Lens Cap
To protect the lens, attach the
provided lens cap to the
camcorder as shown in the
illustration.
NOTE:
To confirm the lens cap is on
correctly make sure the cap is flush
to the camcorder.
Place here during shooting.
How To Use The Audio Extension Cable
When using an optional
external microphone,
connect to the provided
Audio extension cable
(with a core filter
attached), then connect
the Audio extension
cable to the camcorder.
The core filter reduces
interference. (See the
right column.)
Open the cover.
Audio extension cable
To M IC
(provided)
Core filter
How To Attach The Core Filter (for USB Cable (except GR-DX27) and Audio Extension Cable)
Attach the core filters to the cables. The core filter
reduces interference.
1 Release the stoppers on both ends of the core filter.
Stopper
2 Run the cable through the core filter, leaving approx.
3 cm of cable between the cable plug and the core filter.
USB cable
Wind the cable once around the outside of the core filter
as shown in the illustration.
3 cm
Audio Extension cable
Wind the cable twice around the outside of the core filter
as shown in the illustration.
3 cm
● Wind the cable so that it is not slack.
Core filter (large)
Wind once.
Core filter (small)
Wind twice.
3 Close the core filter until it clicks shut.
USB cable
Audio Extension cable
Stereo microphone
NOTES:
● Take care not to damage the cable.
● When connecting a cable, attach the end with the core filter
to the camcorder.
A
Power
This camcorder’s 2-way power supply system lets you
choose the most appropriate source of power. Do not use
provided power supply units with other equipment.
Charging The Battery Pack
POWER/CHARGE lamp
Power switch
Open the cover.
To DC connector
AC Adapter
Power cord
To AC outlet
Battery pack
1 Set the Power Switch to “OFF”.
2 Inser t the terminal end a of the battery pack into the
battery pack mount.
3 Firmly push the end b of the battery pack until it locks
into place.
4 Connect the AC Adapter to the camcorder, then
connect the Power Cord to the AC Adapter.
5 Plug the Power Cord into an AC outlet. The POWER/
CHARGE lamp on the camcorder blinks to indicate
charging has started.
6 When the POWER/CHARGE lamp goes out, charging
is finished. Unplug the Power Cord from the AC outlet.
Disconnect the AC Adapter from the camcorder.
To detach the battery pack
While sliding BATT. RELEASE, remove the battery pack.
Battery pack Charging time
BN-V107U* Approx. 1 hr. 30 min.
BN-V114U Approx. 3 hr.
* Provided
NOTES:
● If the protective cap is attached to the battery pack, remove
it first.
● During charging, the camcorder cannot be operated.
● Charging is not possible if the wrong type of battery is used.
● When charging the battery pack for the first time or after a
long storage period, the POWER/CHARGE lamp may not
light. In this case, remove the battery pack from the
camcorder, then try charging again.
● If the battery operation time remains extremely short even
after having been fully charged, the battery is worn out and
needs to be replaced. Please purchase a new one.
BATT. RELEASE
GETTING STARTED
● Since the AC Adapter processes electricity internally, it
becomes warm during use. Be sure to use it only in wellventilated areas.
● Using the optional AA-V100 AC Power Adapter/Charger,
you can charge the BN-V107U/V114U battery pack without
the camcorder. However, it cannot be used as an AC
Adapter.
EN 11
Using The Battery Pack
Perform steps 2 – 3 in “Charging The Battery Pack”.
Maximum continuous recording time
Battery pack LCD monitor on Viewfinder on
BN-V107U* 1 hr. 15 min. 1 hr. 35 min.
BN-V114U 2 hr. 30 min. 3 hr. 10 min.
* Provided
NOTES:
● Recording time is reduced significantly under the following
conditions:
• Zoom or Record-Standby mode is engaged repeatedly.
• The LCD monitor is used repeatedly.
• The playback mode is engaged repeatedly.
• The LED Light is used.
● Before extended use, it is recommended that you prepare
enough battery packs to cover 3 times the planned
shooting time.
TTENTION:
Before detaching the power source, make sure that the
camcorder’s power is turned off. Failure to do so can result in
a camcorder malfunction.
Using AC Power
Connect the AC Adapter to the camcorder, then connect
the Power Cord to the AC Adapter as shown in the
illustration.
NOTE:
The provided AC Adapter features automatic voltage
selection in the AC range from 110 V to 240 V.
About Batteries
DANGER! Do not attempt to take the batteries apart, or
expose them to flame or excessive heat, as it may cause
a fire or explosion.
WARNING! Do not allow the battery or its terminals to
come in contact with metals, as this can result in a short
circuit and possibly start a fire.
The Benefits Of Lithium-Ion Batteries
Lithium-ion battery packs are small but have a large
power capacity. However, when one is exposed to cold
temperatures (below 10°C), its usage time becomes
shorter and it may cease to function. If this happens,
place the battery pack in your pocket or other warm,
protected place for a short time, then re-attach it to the
camcorder.
GETTING STARTED
GETTING STARTED
12 EN
Operation Mode
To turn on the camcorder, set the Power Switch to any
operation mode except “OFF” while pressing down the
Lock Button located on the switch.
POWER/CHARGE lamp
Lock Button
MENU
PLAY
OFF
A
Power Switch
VIDEO/MEMORY (GR-DX97/77/67 only)
Choose the appropriate operation mode according to
your preference using the Power Switch and VIDEO/
MEMORY Switch. (GR-DX97/77/67 only)
Power Switch Position
A (Full Auto Recording):
Allows you to record using NO special effects or
manual adjustments. Suitable for standard recording.
The “A” indicator appears on the display.
M (Manual Recording):
Allows you to set various recording functions using the
Menus. (墌 pg. 27)
If you want more creative capabilities than Full Auto
Recording, try this mode.
OFF:
Allows you to switch off the camcorder.
PLAY:
● Allows you to play back a recording on the tape.
● Allows you to play back a video clip on the memory
card. (GR-DX97/77/67 only)
● Allows you to display a still image stored in the
memory card or to transfer a still image stored in the
memory card to a PC. (GR-DX97/77/67 only)
● Allows you to set various playback functions using
the Menus. (墌 pg. 27)
SET
(Up)
SET
(Down)
Power-Linked Operation
When the Power Switch is set to “A” or “M”, you can also
turn on/off the camcorder by opening/closing the LCD
monitor or pulling out/pushing in the viewfinder.
INFORMATION:
The following explanations in this manual supposes the
use of LCD monitor in your operation. If you want to use
the viewfinder, close the LCD monitor and pull out the
viewfinder fully.
Date/Time Settings
The date/time is recorded onto the tape at all times, but
its display can be turned on or off during playback.
(墌 pg. 27, 31)
1 Set the Power Switch to “M” while pressing down the
Lock Button located on the switch.
2 Open the LCD monitor fully. (墌 pg. 15)
3 Press MENU. The Menu Screen appears.
ASERA CM I
LA
YP
4 Press or to select “n”,
and press SET. The CAMERA
DISPLAY Menu appears.
5 Press or to select
“CLOCK ADJ.”, and press SET.
The parameter for “Day” is
highlighted.
6 Press or to input the day,
and press SET. Repeat to input the
month, year, hour and minute.
7 Press or to select
“BRETURN”, and press SET twice.
The Menu Screen closes.
Built-in Clock’s Rechargeable Lithium Battery
If the camcorder is not used for approx. 3 months, the
clock’s lithium battery will become discharged and the
date/time stored in memory will be lost. When this
occurs, first connect the camcorder to an AC outlet using
the AC Adapter for over 24 hours to charge the clock’s
rechargeable lithium battery. Then perform the date/time
setting before using the camcorder.
Note that the camcorder can be used without setting the
date/time.
D
I
HTBR G
E
NCREON S
T/D
1
J AD .
NRE TUR
I Y
D
P
ASERA CM
LA
OK
CL C 21
J
AD . 71
NRE TUR
V
LC –
AUMET–/TI DA E OT
OFDEM– CO TI E
F
ON X–MIC AU
20 OK CL C 21.
. 04
7
: 3 0
. 04
20.
: 3 0
VIDEO/MEMORY Switch Position
(GR-DX97/77/67 only)
VIDEO:
Allows you to record on a tape or play back a tape. If
“REC SELECT” is set to “ / ” (墌 pg. 30), still
images are recorded both on the tape and the memory
card.
MEMORY:
● Allows you to record in a memory card or access
data stored in a memory card.
● When the Power Switch is set to “A” or “M”, the
currently selected image size appears.
GETTING STARTED
PAUSE
EN 13
Grip Adjustment
1 Adjust the velcro strip.
2 Pass your right hand through the loop and grasp the
grip.
3 Adjust your thumb and fingers through the grip to
easily operate the Recording Star t/Stop Button and
Power Zoom Lever. Be sure to fasten the velcro strip to
your preference.
Viewfinder Adjustment
1 Set the Power Switch to “A” or “M” while pressing
down the Lock Button located on the switch.
2 Make sure the LCD monitor is closed and locked. Pull
out the viewfinder fully and adjust it manually for best
viewability.
3 Turn the Dioptre Adjustment Control until the
indications in the viewfinder are clearly focused.
Brightness Adjustment Of The Display
1 Set the Power Switch to “M”
or “PLAY” while pressing down
the Lock Button located on the
switch.
2 Open the LCD monitor fully.
(墌 pg. 15)
● To adjust the brightness of the
viewfinder, pull out the
viewfinder fully and set
“PRIORITY” to “FINDER”
(墌 pg. 27, 29).
3 Press MENU. The Menu
Screen appears.
4 Press or to select
“n”, and press SET. The
CAMERA DISPLAY Menu
appears.
MENU
(Left)
(Down)
BRIGHT
(Up)
SET
SET
(Right)
5 Press or to select “BRIGHT”, and press SET.
The Menu Screen closes and the brightness control
indicator appears.
6 Press or until the appropriate brightness is
reached.
7 Press SET.
Tripod Mounting
To attach the camcorder to a
tripod, align screw to the
mounting socket on the
camcorder. Then tighten the
screw clockwise.
GETTING STARTED
Dioptre Adjustment Control
CAUTION:
When retracting the viewfinder, take care not to pinch your
fingers.
GETTING STARTED
A
14 EN
Loading/Unloading A Cassette
The camcorder needs to be powered up to load or eject a
cassette.
PUSH HERE
OPEN/EJECT
Cassette holder
1 Slide and hold OPEN/EJECT in the direction of the
arrow, then pull the cassette holder cover open until it
locks. The cassette holder opens automatically.
● Do not touch internal components.
2 Insert or remove a tape and press “PUSH HERE” to
close the cassette holder.
● Be sure to press only the section labelled “PUSH HERE” to
close the cassette holder; touching other parts may cause
your finger to get caught in the cassette holder, resulting in
injury or product damage.
● Once the cassette holder is closed, it recedes
automatically. Wait until it recedes completely before
closing the cassette holder cover.
● When the battery pack’s charge is low, you may not be able
to close the cassette holder cover. Do not apply force.
Replace the battery pack with a fully charged one or use
AC power before continuing.
3 Close the cassette holder cover firmly until it locks into
place.
To protect valuable recordings
Slide the erase protection tab on the back of the tape in
the direction of “SAVE”. This prevents the tape from
being recorded over. To record on this tape, slide the tab
back to “REC” before loading it.
NOTES:
● If you wait a few seconds and the cassette holder does not
open, close the cassette holder cover and try again. If the
cassette holder still does not open, turn the camcorder off
then on again.
● If the tape does not load properly, open the cassette holder
cover fully and remove the cassette. A few minutes later,
insert it again.
● When the camcorder is suddenly moved from a cold place
to a warm environment, wait a short time before opening
the cassette holder cover.
Cassette holder
cover
Erase protection tab
Make sure the window side
is facing out.
Loading/Unloading A Memory Card (GR-DX97/77/67 only)
The provided memory card is already inserted in the
camcorder at the time of purchase.
Card Cover (MEMORY CARD)
Clipped edge
Write/erase protection tab
1 Make sure the camcorder’s power is off.
2 Open the card cover (MEMORY CARD).
3 To load a memory card, firmly insert it with its
clipped edge first.
To unload a memory card, push it once. After the
memory card comes out of the camcorder, pull it out.
● Do not touch the terminal on the reverse side of the label.
4 Close the card cover.
To protect valuable files (available only for SD
Memory Card)
Slide the write/erase protection tab on the side of the
memory card in the direction of “LOCK”. This prevents
the memory card from being recorded over. To record on
this memory card, slide the tab back to the position
opposite to “LOCK” before loading it.
NOTES:
● Some brands of memory cards are not compatible with this
camcorder. Before purchasing a memory card, consult its
manufacturer or dealer.
● Before using a new memory card, it is necessary to format
the card. (墌 pg. 26)
TTENTION:
Do not insert or remove the memory card while the
camcorder is turned on, as this may cause the memory card
to be corrupted or cause the camcorder to become unable to
recognise whether or not the card is installed.
Memory card
Label
Basic Recording
NOTE:
Before continuing, perform the procedures listed below:
● Power (墌 pg. 11)
● Loading A Cassette (墌 pg. 14)
Power Switch
Lock Button
POWER/CHARGE Lamp
Tal ly Lam p
(Lights while recording is in progress.)
Power Zoom Lever
Recording Start/Stop Button
VIDEO/MEMORY (GR-DX97/77/67 only)
VIDEO RECORDING
EN 15
Tape Remaining Time
Approximate tape remaining time
appears on the display. “– h ––m”
means the camcorder is calculating
the remaining time. When the
remaining time reaches 2 minutes,
the indication starts blinking.
● The time required to calculate and display the remaining
tape length, and the accuracy of the calculation, may vary
according to the type of tape used.
LCD Monitor And Viewfinder
While using the LCD monitor:
Make sure the viewfinder is pushed back in. Pull on the
bottom end of the LCD monitor to open it. It can rotate
270° (90° downward, 180° upward).
While using the viewfinder:
Make sure the LCD monitor is closed and locked. Pull out
the viewfinder fully.
180˚
1 Remove the lens cap. (墌 pg. 10)
2 Open the LCD monitor fully.
3 Set the VIDEO/MEMORY Switch to “VIDEO”.
(GR-DX97/77/67 only)
4 Set the Power Switch to “A” or “M” while pressing
down the Lock Button located on the switch.
● The POWER/CHARGE lamp lights and the camcorder
enters the Record-Standby mode. “PAU SE ” is displayed.
● To record in LP (Long Play) mode, 墌 pg. 27, 28.
5 To start recording, press the Recording Start/Stop
Button. The tally lamp lights and “T REC” appears on
the display while recording is in progress.
6 To stop recording, press the Recording Start/Stop
Button again. The camcorder re-enters the RecordStandby mode.
Approximate recording time
Ta pe
30 min. 30 min. 45 min.
60 min. 60 min. 90 min.
80 min. 80 min. 120 min.
NOTES:
● If the Record-Standby mode continues for 5 minutes, the
camcorder’s power shuts off automatically. To turn the
camcorder on again, push back and pull out the viewfinder
again or close and re-open the LCD monitor.
● When a blank portion is left between recorded scenes on
the tape, the time code is interrupted and errors may occur
when editing the tape. To avoid this, refer to “Recording
From The Middle Of A Tape” (墌 pg. 17).
● To turn the tally lamp or beep sounds off, 墌 pg. 27, 29.
Recording mode
SP LP
NOTES:
● The image will not appear simultaneously on the LCD
monitor and the viewfinder except during Interface
Shooting. (墌 pg. 16) When the viewfinder is pulled out
while the LCD monitor is opened, you can select which one
to use. Set “PRIORITY” to the desired mode in SYSTEM
Menu. (墌 pg. 27, 29)
● Coloured bright spots may appear all over the LCD monitor
or the viewfinder. However, this is not a malfunction.
(墌 pg. 46)
VIDEO RECORDING & PLAYBACK
VIDEO RECORDING
T
W
T
W
16 EN
Zooming
Produces the zoom in/out effect, or an instantaneous
change in image magnification.
Zoom In
Slide the Power Zoom Lever towards “T” (or press Sub
Zoom Button T).
Zoom Out
Slide the Power Zoom Lever towards “W” (or press Sub
Zoom Button W).
The further you slide the Power Zoom Lever, the quicker the
zoom action.
Zoom in (T: Telephoto)
1xW
T
12xW
T
20xW
T
12xW
or
T
Zoom out (W: Wide angle)
Digital zoom zone
12X (optical) zoom zone
Approximate zoom ratio
Sub Zooming buttons
When you hold the
camcorder as
illustrated, pressing
the Sub Zoom
Buttons (instead of
sliding the Power
Zoom Lever) is more
easy to operate
Zooming function.
NOTES:
● Focusing may become unstable during Zooming. In this
case, set the zoom while in Record-Standby, lock the focus
by using the manual focus (墌 pg. 32), then zoom in or out
in Record mode.
● Zooming is possible to a maximum of 700X, or it can be
switched to 12X magnification using the optical zoom.
(墌 pg. 28)
● Zoom magnification of over 12X is done through Digital
image processing, and is therefore called Digital Zoom.
● During Digital zoom, the quality of image may suffer.
● Zooming is possible to a maximum of 10X regardless of the
“ZOOM” setting (墌 pg. 28) when the VIDEO/MEMORY
Switch is set to “MEMORY”. (GR-DX97/77/67 only)
Macro shooting (as close as approx. 5 cm to the subject) is
●
possible when the Power Zoom Lever is set all the way to
“W”. Also see “TELE MACRO” in MANUAL Menu on page 28.
● When shooting a subject close to the lens, zoom out first. If
zoomed-in in the auto focus mode, the camcorder may
automatically zoom out depending on the distance between
the camcorder and the subject. This will not occur when
“TELE MACRO” is set to “ON”. (墌 pg. 28)
or
40xW
T
Journalistic Shooting
In some situations, different
shooting angles may provide
more dramatic results. Hold the
camcorder in the desired position
and tilt the LCD monitor in the
most convenient direction. It can
rotate 270° (90° downward, 180°
upward).
Interface Shooting
The person you shoot can
view himself/herself in the
LCD monitor, and you can
even shoot yourself while
viewing your own image in the
LCD monitor.
1) Open the LCD monitor and
tilt it upward to 180° so that it
faces forward.
2) Point the lens toward the
subject (yourself when selfrecording) and start recording.
● During Interface Shooting, the
monitor image appears
inverted as it would when
viewing a mirror. However, the
actual recorded image does
not appear inverted.
● During Interface Shooting, the “Tape Running” indicator
and warning indications (墌 pg. 47, 48) are the only ones
that are shown; they appear reversed in the display as they
would when viewing a mirror, but are not reversed in the
recording.
● The tape remaining indicator does not appear during
interface shooting. However, when the remaining time
reaches 2 minutes, the indicator appears showing the
remaining time: (blinking) (blinking)
(blinking)
Self
Recording
