HD MEMORY CAMERA

LYT2339-003A

Detailed User Guide

GZ-HM960/GZ-HM860

Table of Contents

Beginner's Guide ............................................................ 5

Charging .................................................................................. 5

Recording ................................................................................ 5

Playback .................................................................................. 5

Shooting Tips ........................................................................... 5

Holiday Season/Christmas ...................................................... 6

Wedding .................................................................................. 7

Travel ....................................................................................... 8

Amusement Park ................................................................... 10

Getting Started

Precautions on Playing Back 3D Images (for GZ-HM960)

............................................................................................ 12

Verifying the Accessories ...................................................... 13

Attaching the Core Filter ..................................................... 14

Charging the Battery Pack ..................................................... 15

Grip Adjustment ..................................................................... 16

Inserting an SD Card ............................................................. 16

Types of Usable SD Card ................................................... 17

Using an Eye-Fi Card ......................................................... 18

Using the Touch Screen ........................................................ 18

Names of Buttons and Functions on the LCD Monitor ....... 19

Clock Setting ......................................................................... 20

Resetting the Clock ............................................................ 21

Changing the Display Language ............................................ 22

Holding this Unit .................................................................... 22

Tripod Mounting .................................................................... 22

Using the Remote Control ...................................................... 23

Using Bluetooth-compliant Devices ....................................... 24

Registering a Bluetooth-compliant Device ......................... 25

Connecting to a Registered Bluetooth-compliant Device

........................................................................................ 27

Changing the Settings of a Registered Bluetooth-compliant

Device ............................................................................ 28

Transferring Still Images to a Bluetooth-compliant Device

........................................................................................ 29

Operation Using a Smartphone .......................................... 30

Bluetooth Application for Smartphones .............................. 31

Radio Waves Used by this Product .................................... 38

Using this Unit Overseas ....................................................... 39

Charging the Battery Pack Overseas ................................. 39

Setting the Clock to Local Time when Traveling ................. 39

Setting Daylight Saving Time ............................................. 40

Optional Accessories ............................................................. 40

Recording

Taking Videos in Intelligent Auto Mode .................................. 42

Zooming ............................................................................. 44

Capturing Still Images During Video Recording ................. 44

Taking Still Images in Intelligent Auto Mode .......................... 45

Zooming ............................................................................. 47

Manual Recording ................................................................. 47

Scene Selection ................................................................. 48

Adjusting Focus Manually .................................................. 49

Using Focus Assist ............................................................. 50

Adjusting Brightness .......................................................... 50

Setting Shutter Speed ........................................................ 51

Setting Aperture ................................................................. 51

Setting White Balance ........................................................ 52

Setting Backlight Compensation ........................................ 53

Taking Close-up Shots ....................................................... 54

Creating Animation Effects (ANIMATION EFFECT) .............. 54

Registering Human Face Personal Authentication Information

............................................................................................ 56

Setting SMILE%/NAME DISPLAY ...................................... 58

Editing the Registered Face Information ............................ 59

Capturing Subjects Clearly (TOUCH PRIORITY AE/AF) ....... 61

Capturing Smiles Automatically (SMILE SHOT) .................... 62

Recording while Displaying a Magnified View of a Selected Face

(FACE SUB-WINDOW) ...................................................... 63

Reducing Camera Shake ....................................................... 64

Taking Videos in iTunes Format ............................................ 65

Slow-motion (High-speed) Recording .................................... 66

Recording at Intervals (TIME-LAPSE RECORDING) ............. 67

Recording Automatically by Sensing Movements (AUTO REC)

............................................................................................ 69

Taking Group Shots (Self-timer) ............................................ 70

Setting the USER Button ....................................................... 71

Remaining Recording Time/Battery Power ............................ 72

Playback

Playing Back Videos .............................................................. 74

Playing Back 3D Images (for GZ-HM960) .......................... 76

Playing a Video with Defective Management Information

........................................................................................ 76

Playing Back Still Images ....................................................... 77

Playing Back 3D Images (for GZ-HM960) .......................... 78

Slideshow Playback ........................................................... 78

Searching for a Specific Video/Still Image ............................. 79

Date Search ....................................................................... 79

Connecting to and Viewing on TV .......................................... 79

Playing Back 3D Images (for GZ-HM960) .......................... 80

Playing Back 2D Images (for GZ-HM960/GZ-HM860)

........................................................................................ 82

Playing Back a DVD or Blu-ray Disc Created on this Unit

............................................................................................ 84

Editing

Deleting Unwanted Files ........................................................ 85

Deleting the Currently Displayed File ................................. 85

Deleting Selected Files ...................................................... 85

Protecting Files ...................................................................... 86

Protecting/Releasing Protection of the Currently Displayed File

........................................................................................ 86

Protecting/Releasing Protection of Selected Files .............. 86

Capturing a Still Image in the Video during Playback ............. 88

Combining Videos Recorded by Seamless Recording .......... 88

Capturing a Required Part in the Video (TRIMMING) ............ 89

Capturing Videos for Uploading to YouTube .......................... 90

Preparing Videos to Transfer to iTunes .................................. 91

Copying

Creating Discs with a DVD Writer .......................................... 92

Preparing a DVD Writer (CU-VD3U) .................................. 93

Preparing a DVD Writer (CU-VD50U) ................................ 94

Creating a Disc ................................................................... 94

Playing Back with a DVD Writer ......................................... 99

Finalizing Discs After Copying ............................................ 99

Creating Discs with an External Blu-ray Drive ...................... 100

Preparing an External Blu-ray Drive ................................. 100

Creating a Disc ................................................................. 101

Playing Back with an External Blu-ray Drive ..................... 104

Creating a Disc Using a Connected Blu-ray Recorder ......... 105

Dubbing Files to a Disc by Connecting to a DVD Recorder

.......................................................................................... 105

Dubbing Files to a VHS Tape by Connecting to a VCR ........ 106

Using a USB External Hard Disk Drive ................................ 106

Preparing a USB External Hard Disk Drive ....................... 107

Copying All Files .............................................................. 107

Playing Back Files in the USB External Hard Disk Drive

...................................................................................... 108

Deleting Folders in the USB External Hard Disk Drive ..... 109

Formatting the USB External Hard Disk Drive .................. 109

Importing Files from the USB External Hard Disk Drive

...................................................................................... 110

Copying Files to an SD Card ................................................ 111

Moving Files to an SD Card ................................................. 112

Copying to Windows PC ...................................................... 113

Verifying System Requirements (Guideline) ..................... 113

Installing the Provided Software (Built-in) ......................... 114

Backing Up All Files ......................................................... 115

Organizing Files ............................................................... 116

Recording Videos to Discs ............................................... 117

Backing Up Files Without Using Provided Software ......... 118

List of Files and Folders ................................................... 119

Copying to Mac Computer ................................................... 120

Menu Settings

Operating the Menu ............................................................. 121

Operating the Main Menu ................................................. 121

Operating the Common Menu .......................................... 121

Operating the Face Short Cut Menu ................................. 122

Main Menu for Video Recording .......................................... 123

SCENE SELECT .............................................................. 125

FOCUS ............................................................................ 125

FOCUS ASSIST ............................................................... 125

FOCUS ASSIST COLOR ................................................. 125

BRIGHTNESS ADJUST ................................................... 125

SHUTTER SPEED ........................................................... 125

APERTURE PRIORITY .................................................... 125

WHITE BALANCE ............................................................ 125

BACKLIGHT COMP. ........................................................ 125

TELE MACRO .................................................................. 125

TOUCH PRIORITY AE/AF ............................................... 125

LIGHT .............................................................................. 126

DIS ................................................................................... 126

GAIN UP .......................................................................... 126

WIND CUT ....................................................................... 127

EXPORT SHOOTING ...................................................... 127

ANIMATION EFFECT ...................................................... 127

HIGH SPEED RECORDING ............................................ 127

TIME-LAPSE RECORDING ............................................. 127

AUTO REC ...................................................................... 127

FACE SUB-WINDOW ...................................................... 127

SHUTTER MODE ............................................................ 128

CONT. SHOOTING SPEED ............................................. 128

SMILE SHOT ................................................................... 129

SMILE%/NAME DISPLAY ................................................ 129

FACE REGISTRATION .................................................... 129

VIDEO QUALITY .............................................................. 129

ZOOM .............................................................................. 130

SEAMLESS RECORDING ............................................... 130

x.v.Color ........................................................................... 131

ZOOM MIC ...................................................................... 131

USER BUTTON SETTING ............................................... 131

Main Menu for Still Image Recording ................................... 132

SCENE SELECT .............................................................. 134

FOCUS ............................................................................ 134

FOCUS ASSIST ............................................................... 134

FOCUS ASSIST COLOR ................................................. 134

BRIGHTNESS ADJUST ................................................... 134

SHUTTER SPEED ........................................................... 134

APERTURE PRIORITY .................................................... 134

WHITE BALANCE ............................................................ 134

BACKLIGHT COMP. ........................................................ 134

TELE MACRO .................................................................. 134

TOUCH PRIORITY AE/AF ............................................... 134

FLASH ............................................................................. 135

SELF-TIMER .................................................................... 135

GAIN ................................................................................ 135

AUTO REC ...................................................................... 136

SHUTTER MODE ............................................................ 136

CONT. SHOOTING SPEED ............................................. 136

SMILE SHOT ................................................................... 137

SMILE%/NAME DISPLAY ................................................ 137

FACE REGISTRATION .................................................... 137

IMAGE SIZE ..................................................................... 137

USER BUTTON SETTING ............................................... 137

Main Menu for Video Playback ............................................ 138

SEARCH DATE ................................................................ 139

PROTECT/CANCEL

........................................................ 139

COPY ............................................................................... 139

MOVE .............................................................................. 139

TRIMMING ....................................................................... 139

UPLOAD SETTINGS ....................................................... 139

EXPORT SETTINGS ........................................................ 139

PLAYBACK OTHER FILE ................................................ 139

SEAMLESS REC CTRL ................................................... 139

K2 TECHNOLOGY .......................................................... 139

Main Menu for Still Image Playback ..................................... 140

SEARCH DATE ................................................................ 141

SLIDE SHOW EFFECTS (for GZ-HM860) ....................... 141

PROTECT/CANCEL ........................................................ 141

COPY ............................................................................... 141

MOVE .............................................................................. 141

STILL IMAGE TRANSFER ............................................... 141

Common Menu .................................................................... 142

CLOCK ADJUST .............................................................. 144

DATE DISPLAY STYLE ................................................... 144

LANGUAGE ..................................................................... 144

MONITOR BRIGHTNESS ................................................ 144

REC MEDIA FOR VIDEO ................................................. 145

REC MEDIA FOR IMAGE ................................................ 145

OPERATION SOUND ...................................................... 146

AUTO POWER OFF ......................................................... 146

QUICK RESTART ............................................................ 147

REMOTE .......................................................................... 147

DEMO MODE .................................................................. 148

3D LEVEL ADJUST (for GZ-HM960) ............................... 148

TOUCH SCREEN ADJUST ............................................. 149

3D DISPLAY WARNING (for GZ-HM960) ........................ 150

DISPLAY ON TV .............................................................. 150

VIDEO OUTPUT .............................................................. 151

COMPONENT OUTPUT .................................................. 151

HDMI OUTPUT ................................................................ 152

HDMI CONTROL ............................................................. 153

Bluetooth .......................................................................... 153

AUTO FINALIZE .............................................................. 153

FACTORY PRESET ......................................................... 154

UPDATE .......................................................................... 154

PC SOFTWARE UPDATE ............................................... 154

FORMAT BUILT-IN MEM. ................................................ 154

FORMAT SD CARD ......................................................... 155

ERASE ALL DATA ........................................................... 155

Names of Parts

Front .................................................................................... 156

Rear ..................................................................................... 156

Bottom ................................................................................. 157

Interior ................................................................................. 157

LCD Monitor ........................................................................ 158

Indications on the LCD monitor

Common Recording Indications .......................................... 159

Video Recording .................................................................. 159

Still Image Recording ........................................................... 160

Video Playback .................................................................... 160

Still Image Playback ............................................................ 161

Troubleshooting

Battery Pack ........................................................................ 162

Recording ............................................................................ 162

Card ..................................................................................... 163

Playback .............................................................................. 163

Editing/Copying ................................................................... 164

Computer ............................................................................. 164

Screen/Image ...................................................................... 165

Other Problems ................................................................... 165

Error Message? ................................................................... 166

Maintenance

Specifications

Charging

Refer to the operating instructions found in the animation on the Detailed User Guide.

Recording

Refer to the operating instructions found in the animation on the Detailed User Guide.

Playback

Refer to the operating instructions found in the animation on the Detailed User Guide.

Shooting Tips

Basic Way to Hold a Camcorder ~ Recording Stable Images ~

This is the standard way of shooting while standing up. Be sure to master this basic technique in order to achieve stable images.

[Getting Ready]

A Open your feet to the width of your shoulders. B Keep the elbow of your right arm, which is holding the camcorder, close

to your side.

C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

Extending Your Hands to Shoot ~ High-Angle Shooting ~

Extend your hand when your subject is being hidden behind a crowd of people.

[Getting Ready]

A Open your feet to the width of your shoulders. B Extend your right hand and hold the camcorder over your head. C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

Caution :

Use this way of shooting only as a last resort as it is difficult to achieve stable images.

Set to the wide angle as much as possible as the image will be prone to camera shake.

Be considerate. Do not inconvenience the people around you.

Squatting and Shooting at Eye Level

Staying low is a common position to take when shooting small children. By recording from the eye level of the child, you can capture all his cute expressions clearly.

[Getting Ready]

A Kneel down with your left knee while keeping your right foot on the

ground.

B Place the elbow of your right arm, which is holding the camcorder, on

your right knee.

C Hold the LCD monitor with your left hand and adjust the angle

accordingly.

Panning

Refer to the operating instructions found in the animation on the Detailed User Guide.

Use this method to shoot a wide angle of view.

[Getting Ready]

A Shoot by rotating your body instead of moving your arms while keeping

the basic way of holding a camcorder as stated above.

B Stand facing the direction where the rotation will stop. C Twist your upper body to the direction where recording will start. D Press the start button and record for 2 seconds, then slowly twist back

your body to face the front. Record for another 2 seconds while facing the front, then press the stop button. (The 90 degrees rotation should take about 5 seconds, giving the feeling of a slow motion.)

Beginner's Guide

Holiday Season/Christmas

Record the happy Christmas celebration with your family!

Photo by 101st CAB, Wings of Destiny

Creative Commons Attribution-No Derivative Works 3.0

Decorating the Tree and Preparing the Dinner

The decoration of tree and preparation of dinner are part of the joy of Christmas. Be sure to record these happy family times!

Decorating the tree

A tree is the most important thing to bring out the mood of Christmas. Simply the scene of all family members engaging in the decorating of a fir tree with various colorful ornaments is full of the feeling of happiness.

Preparing the Dinner

Photo by Manicosity

Creative Commons Attribution-No Derivative Works 3.0

Record the scenes as everyone helps to prepare the feast of the night. You can film the mother who is cooking, the children who are helping, and of course, the process of making a cake!

Recording the Christmas Party

Photo by InnerSpirit

Creative Commons Attribution-No Derivative Works 3.0

After all preparations, it is finally the Christmas party itself. Not only should you record the candle-blowing scene, but also the smiles of the family while being surrounded by good food, or even the father who is slightly drunk from champagne!

Finding the Presents

For children, the greatest joy of Christmas is receiving presents the next morning. Their expression of delight when finding a present next to their pillow is a recording opportunity not to be missed. Get ready to shoot before the children wake up!

Useful Shooting Techniques

Wedding

Create an awesome wedding video for the bride and groom!

Discussing and Planning Before the Event

Before the day of the wedding reception, it is important to discuss with the bride and groom about various details such as the order of the ceremony and whether there are any entertainment programs or change of clothes. By understanding the preferences of the bride and groom, you will be able to shoot more appropriately.

Finding out the route of entrance

The highlight of a wedding reception is the entrance of the bride and groom. Find out which door they will enter from and the route they will take from the person-in-charge of the wedding hall in advance. Set up the tripod at a place where you can follow the couple using zoom without having to move around.

Number of times and timing of clothes-changing

Find out the timing of any changing of clothes so as to capture the scene well when the bride and groom enter again. You can also make use the time while the bride and groom are changing to record comments of well wishes from the guests.

Finding the Right Angle to Capture Both Bride and Groom

Composing the picture with the groom in front and the guests at the back

The main characters of a wedding are of course the bride and groom. Record their expressions clearly during the toast, speech, entertainment programs, and other scenes. Another recommendation is to capture the face shots of the guests, then pan towards the groom. Picture composition containing the crowd of guests only lacks fun, so be sure to pay attention to the shooting angle and size.

Recording the Expressions and Comments of Guests

Setting the shot from eye level to chest level

You can record comments from the guest by going around asking, "Please say a few words for the bride and groom". This can be done at the guests' waiting room, when the bride and groom are changing, or during the entertainment programs.

Closing Up on the Bride's Face During the Thank You Speech

Touching highlight scene

The climax of the event finally comes during the bride and groom's thank you speech and presentation of flowers. The touching words of appreciation from the bride and tears of joy from the parents are scenes that must not be missed. Start by closing up on the bride's face using zoom. As the tears start to form in the bride's eyes, continue shooting for a little longer. Then, slowly zoom out to the wide angle to show the parents who are moved by the speech.

Useful Shooting Techniques

Advanced Operation with Two Camcorders

If video-editing is to be done, record using two camcorders so that a video with varying scenes can be created. You can try asking a close friend who has a camcorder at home. Set the borrowed camcorder on a tripod to focus on taking close-up shots of the bride and groom. In this way, the other camcorder can be moved around to record other scenes, enabling an interesting video with changing scenes to be created through editing and compilation. As most people own at least a digital camera nowadays, even if you are really unable to find an extra camcorder, inserting still pictures to the video at various points is also a good way to add variety. Do give it a try!

<Camcorder 1> Closing up on the bride and groom all the time

<Camcorder 2> Recording the congratulatory messages from friends at the same time

Travel

Capture all the good times of your domestic or overseas trips!

Bringing the Necessary Equipment

The necessary things to bring on a trip depends on your traveling purpose and the destination. For overseas trips in particular, you have to think about what to bring in accordance to the local conditions. Here are some suggestions for your consideration.

Camcorder

Think about how many hours of shooting you will usually perform in a day. Be sure to prepare enough recording medium especially for long overseas trips. If you are recording in SD cards, get ready the sufficient number of cards, including some for backup.

Battery Pack

Prepare a battery pack that is ready for double the expected recording time in a day. For example, if you plan to record for 2 hours a day, prepare a battery pack that is ready for 4 hours (actual recording time). For a day trip, you can prepare a battery with low capacity but for a long trip, do prepare a few batteries with high capacities.

AC Adapter

The JVC AC adapter supports voltages from 100 V to 240 V, and hence can be used anywhere in the world. Bring along the adapter if you are traveling for a long time. Charge the battery pack while sleeping so that you can record with full battery power the next day.

Power Plug Adapter

The shape of the power plug varies according to countries. Be sure to check the shape of the power plug beforehand, and bring the appropriate power plug adapter. “Charging the Battery Pack Overseas” (A p. 39)

Useful Shooting Techniques

Battery Charger

Recording cannot be performed when an AC adapter is connected to the camcorder for battery charging. You can bring an additional battery charger to charge battery packs if you plan to use the camcorder for recording at night. You can also charge multiple battery packs by using both the battery charger and this camcorder at the same time.

Tripod

A tripod is an essential item to take stable images. Select an appropriate tripod in accordance to your purpose and style of traveling, such as a compact one to be used on a table or one that is at least 1 m tall.

Recording the Excitement Before Departure

It may be a little abrupt to start your travel video at the destination suddenly. Record also the preparations prior to departure if it is a family trip, or the time when everyone is gathered at the meeting place if you are traveling with your friends. For overseas trips, taking a shot of the signs and displays at the airport of the flight you are taking may be useful for future reference.

Using Pan at the Places of Interest

Tourists spots with beautiful scenery or historical sites are places that you would certainly want to record. To capture the magnificence of a scene which cannot be fitted into a single frame, try the panning technique. Refer to the "Shooting Tips" found in this website on how to use panning effectively. In addition, you may also like to take a shot of the signs or monuments that can often be found at the tourist spots.

Showing Everyone Having a Good Time

When taking a video, it is rather dull to shoot only the scenery or historical sites. Talk about your feelings while recording the breath-taking scenery of an attraction so that it will be an interesting scene to view later.

Useful Shooting Techniques

Amusement Park

Take more shots of the smiling faces of everyone in the family!

Taking Videos or Still Images According to the Attraction

You may choose to take videos all the time. However, you may want to take some still images too. The following section explains the scenarios suitable for taking videos or still images.

Scenarios suitable for taking videos

Scenarios with changes in body movement are suitable for taking videos. This includes situations where there are rapid changes in facial expressions or voices of surprise and delight. *Some amusement parks do not allow passengers to perform any recording. Be sure to check beforehand. [Examples]

Merry-go-round, go kart, coffee cup, etc.

Scenarios suitable for taking still images (photos)

Scenarios with little movement of the subject are suitable for taking still images. Try to take the still images from an angle such that the surroundings can be seen clearly. [Examples]

Carousal, ferris wheel, fun bicycle rides, etc.

Inducing Responses by Calling Out

Videos with no waving of hands nor laughter are not only dull when you view them later, but also put the capability of the audio-recording function of the camcorder to a waste. When recording, induce more reactions by enthusiastically waving your hands or shouting out "Is it fun?" and the like.

Capturing the Best Moment in a Video as a Still Image

Shots with the eyes closed are often taken by accident. To reduce such mistakes, make use of the function to capture still images from videos. As videos are actually continuous recording of 60 still images within 1 minute, using this function allows you to select the best moment and save it as a still image. “Capturing a Still Image in the Video during Playback” (A p. 88)

Photo by just that good guy jim

Creative Commons Attribution-No Derivative Works 3.0

Video Playback in Progress

Photo by talk rhubarb

Creative Commons Attribution-No Derivative Works 3.0

Capturing a Still Image

Photo by just that good guy jim

Creative Commons Attribution-No Derivative Works 3.0

Video Playback in Progress

Useful Shooting Techniques

Advanced Operation with Backlight Compensation

When the subject’s face is in backlight or when the expression cannot be seen clearly, the Intelligent Auto function of this unit automatically increases its brightness for recording. If Intelligent Auto fails to function as expected or if the brightness correction is insufficient, you can increase the brighness by using backlight compensation in the Manual mode. “Setting Details” (A p. 53)

Useful Shooting Techniques

Precautions on Playing Back 3D Images (for GZ-HM960)

Images recorded in 2D mode can be converted to 3D and played back on this unit. You can enjoy realistic and powerful 3D images by playing back on a 3D compatible TV. Before use, please read the following precautions to ensure safe and comfortable viewing of the 3D images.

Playing Back 3D Images

This unit makes use of the misalignment between the images that enter the left and right eyes to create the 3D effect during 3D playback. As the images that enter the left and right eyes are different, fatigue may be experienced. In addition, depending on the content of the video, an illusion of movement may be experienced and result in motion sickness.

3D Display on the LCD Monitor

3D images are supported by the LCD monitor. Press the “3D” button to change the display on the LCD monitor between 3D and 2D.

3D effect appears stronger when viewed at appromimately 30 cm from the front.

3D effect may be weak if viewed from an angle other than the front.

The LCD monitor appears darker when 3D images are displayed. Change the display to 2D when it is difficult to see, such as when using this unit outdoors.

Caution :

Viewing of 3D images is not recommended for people with medical history of photosensitivity, with heart diseases, feel unwell, suffer from lack of sleep, suffer from fatigue, or are drunk.

Medical conditions may worsen.

If you have vision problems such as short-sightedness, long-sightedness, varying vision in the left and right eyes, or astigmatism, it is recommended to correct your vision by wearing glasses, etc. Stop viewing of 3D images if you see double images.

3D images may appear differently for different people. Correct your vision appropriately before viewing the 3D images.

Stop viewing of 3D images if you experience fatigue or discomfort.

Continual viewing of the 3D images may result in health problems. Take an adequate rest. Viewing of 3D images in an environment where shaking of the monitor is expected, such as while riding in a vehicle or during walking, may result in fatigue or discomfort.

If you experience fatigue or discomfort while viewing 3D images on the LCD monitor, set the display to 2D.

Continual viewing of the 3D images may result in health problems.

Rest well after viewing 3D images.

After viewing 3D images, check that you do not experience fatigue or discomfort before driving, etc.

Take a break every 30 to 60 minutes when viewing 3D images.

Long periods of viewing may cause visual fatigue.

Keep a distance of at least 3 times the effective height of the screen when viewing of the 3D images on a 3D compatible TV.

Viewing of the 3D images from a distance shorter than the recommended distance may cause visual fatigue.

TV Size Recommended Distance

54” Approx. 2.0 m (6’6-3/4”)

50” Approx. 1.9 m (6’2-3/4”)

46” Approx. 1.7 m (5’6-7/8”)

42” Approx. 1.6 m (5’3”)

Viewing of 3D images is only recommended for ages 5 to 6 and above.

Guardians should pay close attention to children as health problems may result if fatigue and discomfort are not noticed immediately.

3D Effect Mechanism

3D images on the LCD monitor of this unit are displayed using the parallax barrier system. Placed in front of an image source, a parallax barrier consists of a series of slits arranged alternately for the left and right eyes, allowing each eye to see a different image when viewing from a distance, thus creating the 3D effect. As such, 3D effect may appear weak depending on the angle of viewing.

Getting Started

Verifying the Accessories

If any of the items are missing or defective, consult your JVC dealer or the nearest JVC service center.

Illustration Description

AC Adapter AC-V11U (for GZ-HM860)

Connects to this unit to charge the battery pack. It can also be used when recording or playing back videos indoors.

AC Adapter AP-V30U (for GZ-HM960)

Connects to this unit to charge the battery pack. It can also be used when recording or playing back videos indoors.

Battery Pack BN-VG114U

Attaches to this unit to supply power.

Remote Control RM-V760U

Operates certain functions from a distance.

HDMI Mini Cable

Connects this unit to a TV to play back recorded images on the TV in a better quality.

AV Cable

Connects this unit to a TV to play back recorded images on the TV.

USB Cable (Type A - Mini Type B)

Connects this unit to a computer.

Core Filter (Large)×2 (for AV Cable and optional Component Cable) Core Filter (Small) (for AC Adapter)

The core filter reduces interference when this unit is connected to other devices.

Getting Started

Basic User Guide

Read well and keep in a safe place where it can be accessed easily when necessary.

Memo :

SD cards are sold separately.

“Types of Usable SD Card” (A p. 17) “Using an Eye-Fi Card” (A p. 18)

When using the AC adapter overseas, please prepare a commercially available converter plug for the country or region of visit.

“Charging the Battery Pack Overseas” (A p. 39)

Attaching the Core Filter

Attach the core filter to the power cord of the AC adapter, AV Cable and optional Component Cable as shown in the illustration. The core filter reduces interference when this unit is connected to other devices.

Getting Started

Charging the Battery Pack

Charge the battery pack immediately after purchase and when the remaining battery power is low. The battery pack is not charged at the time of purchase.

Attach the battery pack.

Align the top of the battery with the mark on this unit, and slide in until the battery clicks into place.

Connect the AC adapter to the DC connector.

* The AC adapter shown in the illustration is AC-V11U.

Plug in the power.

The charging lamp blinks when charging is in progress. It goes out when charging is finished.

Caution :

Be sure to use JVC battery packs.

If you use any other battery packs besides JVC battery packs, safety and performance cannot be guaranteed.

Charging time: Approx. 2 h 30 m (using supplied battery pack) The charging time is when the unit is used at 25°C. If the battery pack is charged outside the room temperature range of 10°C to 35°C, charging may take a longer time or it may not start. The recordable and playable time may also be shortened under some usage conditions such as at low temperature.

Be sure to use the supplied JVC AC adapter.

If you use any other AC adapters besides the supplied JVC AC adapter, malfunctions may occur.

Rechargeable Batteries：

When using the battery in a low temperature environment (10°C or below), the operating time may be shortened, or it may not function properly. When using this unit outdoors in the winter weather, warm the battery, such as by placing it in the pocket, before attaching it. (Keep away from direct contact with a warm pack.)

Do not expose the battery to excessive heat, such as direct sunlight or fire.

After removing the battery, store it in a dry place between 15°C to 25°C.

Keep a 30 % battery level (X) if the battery pack is not to be used for a long period of time. In addition, fully charge and then fully discharge the battery pack every 6 months, then continue to store it at a 30 % battery

level (X).

Memo :

You can connect this unit to the AC adapter to record for long hours indoors. (Battery charging begins when the LCD monitor is closed.)

Detaching the Battery Pack

Slide the battery release lever to detach the battery from this unit.

Approximate Battery Charging Time (Using AC Adapter)

Battery Pack Charging Time

BN-VG114U (Supplied)

2 h 30 m

BN-VG121U 3 h 30 m

BN-VG138U 6 h 10 m

When the battery life is reached, the recording time becomes shorter even if the battery pack is fully charged. (Replace the battery pack with a new one.)

* The charging time is when the unit is used at 25°C. If the battery pack is charged outside the room temperature range of 10°C to 35°C, charging may take a longer time or it may not start. The recordable and playable time may also be shortened under some usage conditions such as at low temperature. “Approximate Recording Time (Using Battery)” (A p. 73)

Getting Started

Grip Adjustment

A Pull back the pad B Adjust the length of the belt C Attach the pad

Caution :

Be sure to fasten the grip belt properly. If the belt is loose, this unit may drop and result in injuries or damages.

Inserting an SD Card

When a commercially available SD card is inserted, recordings can still be made to the card without stopping when the remaining recording time on the built-in memory runs out. “Types of Usable SD Card” (A p. 17) “Using an Eye-Fi Card” (A p. 18) “Approximate Video Recording Time” (A p. 73)

Close the LCD monitor.

Open the cover.

Insert an SD card.

Insert with the terminal side facing outward.

Warning

Make sure not to insert the card in the wrong direction. It may cause damage to the unit and card.

Turn off the power of this unit before inserting or removing a card.

Do not touch the metal contact area when inserting the card.

Memo :

When “SEAMLESS RECORDING” is set to “ON”, recordings can still be made to the SD card without stopping when the remaining recording time on the built-in memory runs out.

Both videos and still images can be recorded on one SD card. It is recommended to confirm the video operation of the SD card before usage.

“SEAMLESS RECORDING” (A p. 130)

To record to the card, it is necessary to perform media settings. When no card is available, set media settings to “BUILT-IN MEMORY” for recording.

“REC MEDIA FOR VIDEO” (A p. 145) “REC MEDIA FOR IMAGE” (A p. 145)

To use cards that have been used on other devices, it is necessary to format (initialize) the card using “FORMAT SD CARD” from media settings.

“FORMAT SD CARD” (A p. 155)

Getting Started

Removing the Card

Push the SD card inward once, then pull it out straight.

Types of Usable SD Card

The following SD cards can be used on this unit. Operations are confirmed on the SD cards from the following manufacturers.

Panasonic

TOSHIBA

SanDisk

Eye-Fi

SD Card

This unit supports 256 MB to 2 GB SD cards.

Use a Class 4 or higher compatible SD card (2 GB) for video recording.

SDHC Card

Use a Class 4 or higher compatible SDHC card (4 GB to 32 GB) for video recording.

SDXC Card

Use a Class 4 or higher compatible SDXC card (Max. 64 GB).

Memo :

Using SD cards (including SDHC/SDXC cards) other than those specified above may result in recording failure or data loss.

To record videos with “VIDEO QUALITY” set to “UXP”, use of a Class 6 compliant SDHC/SDXC card is recommended.

Class 4 and Class 6 are guaranteed to have a minimum transfer rate of 4 MB/s and 6 MB/s respectively during reading or writing of data.

You can also use a Class 10 compliant SDHC/SDXC card.

Both videos and still images can be recorded on one SD card. It is recommended to confirm the video operation of the SD card before usage.

To protect the data, do not touch the terminals of the SD card.

When your computer cannot recognize the SDXC card

Confirm and update the OS of your computer.

Windows XP / Windows XP SP1

Necessary to update to SP2 or higher.

Windows XP SP2 / Windows XP SP3

Necessary to download the update software. (KB955704)

http://www.microsoft.com/downloads/details.aspx? FamilyID=1cbe3906-ddd1-4ca2-b727c2dff5e30f61&displaylang=en

Windows Vista Necessary to update to SP1 or higher.

Windows Vista SP1 / Windows Vista SP2

Necessary to download the update software. (KB975823)

32 bit version

http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=2d1abe01-0942-4f8aabb2-2ad529de00a1

64 bit version

http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=7d54c53f-017c-4ea5ae08-34c3452ba315

Windows 7 Necessary to download the update software.

(KB976422)

32 bit version

http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=3ee91fc2-a9bc-4ee1aca3-2a9aff5915ea

64 bit version

http://www.microsoft.com/downloads/en/ details.aspx?FamilyID=73f766dd-7127-4445b860-47084587155f

Mac OS X 10.4 Tiger / Mac OS X

10.5 Leopard

Not compatible.

Mac OS X 10.6 Snow Leopard

Necessary to update to 10.6.5 or later.

Getting Started

Using an Eye-Fi Card

Eye-Fi is an SD memory card with wireless LAN function. Using an Eye-Fi card, you can transfer videos and still images to a computer or the web. (A broadband wireless LAN environment is required.) Use of Eye-Fi card may be illegal and prohibited in countries and regions where it has not been approved by competent authorities. Please contact Eye-Fi support for the details of approved countries and regions.

Types of Cards

The following Eye-Fi cards can be used on this unit. Eye-Fi X2 Series

Eye-Fi Connect X2

Eye-Fi Explore X2

Eye-Fi Pro X2

Using the Eye-Fi Card

Make settings on the Eye-Fi card with Eye-Fi Center. For how to install and operate the Eye-Fi Center, refer to its instruction manual.

Recorded videos and still images are automatically transferred. (The files already transferred earlier are not transferred again.)

Memo :

You cannot transfer files during the recording mode, editing and formatting of the card.

You cannot transfer video files larger than 2 GB. (as of December, 2010)

Transfer may take long or be interrupted depending on the connection conditions.

Icon Description

Identifying the Eye-Fi card

Ready for transfer from the Eye-Fi card

Transferring from the Eye-Fi card (animated)

We recommend using the AC adapter when transferring files of large size.

If it doesn’t operate properly, first make use of Eye-Fi Helper to confirm that the settings of the Eye-Fi card are correct. In addition, try the data transfer by inserting the Eye-Fi card into other equipment such as a computer.

Do not use the camcorder in places where wireless use is prohibited such as on a plane.

Before deleting a file, check that you have transferred it to a computer or uploaded it to a video sharing website.

For the latest information on the Eye-Fi card, refer to the website of EyeFi, Inc.

http://www.eye.fi/

Using the Touch Screen

Icon operation buttons, thumbnails, and menu items are displayed on the touch screen according to the mode in use.

There are two ways to operate the touch screen, namely “tap” and “drag”. The following are some examples.

A Tap the displayed button (icon) or thumbnail (file) on the touch screen to make selection. B Drag the thumbnails on the touch screen to search for the desired file.

Memo :

The touch screen of this unit is pressure-sensitive. When the touch screen does not respond smoothly, apply slightly more force to your fingertip.

Tap the buttons (icons) on the touch screen accurately. The buttons may not respond if they are not tapped on the right area.

Do not press or rub with excessive force.

If you apply a protect sheet or a sticker, the touch screen may not respond smoothly.

Do not operate the touch screen using an object with a sharp or hard tip.

Pressing two or more places at a time may cause a malfunction.

Perform “TOUCH SCREEN ADJUST” if the reactive area of the screen is misaligned with the touched area. (Adjust by lightly tapping with a corner of an SD card, etc. Do not press with an object with a sharp tip or do not press hard.)

“TOUCH SCREEN ADJUST” (A p. 149)

Getting Started

Names of Buttons and Functions on the LCD Monitor

The following screens are displayed during the video and still image modes, and operate as the touch screens.

Recording Screen (Video/Still Image)

Face Short Cut Menu Button

Displays a short cut screen of face recognition functions.

“Operating the Face Short Cut Menu” (A p. 122)

Zoom Button

“Zooming” (A p. 44)

Recording/Playback Mode Button

Switches between recording and playback modes.

Recording Start/Stop Button

g: Video Recording Start Button

a: Video Recording Stop Button

Q: Still Image Recording Button

Menu Button

“Operating the Menu” (A p. 121)

Display Button

Some displays disappear after approximately 3 seconds. Use the n button to change the displays as shown below.

Tap n button Displays appear for approximately 3 seconds with every tap.

Tap and hold n button Displays are fixed such that they do not disappear. After setting, the

display button changes from n to m. Tap m to release the displays.

Playback Screen (Video)

Recording/Playback Mode Button

Switches between recording and playback modes.

Index Screen Button

“Operation Buttons for Video Playback” (A p. 74)

Delete Button

“Deleting the Currently Displayed File” (A p. 85)

Volume Adjustment Button

“Adjusting the Volume of Videos” (A p. 75)

Menu Button

“Operating the Menu” (A p. 121)

Operation Buttons

“Operation Buttons for Video Playback” (A p. 74)

Playback Screen (Still Image)

Recording/Playback Mode Button

Switches between recording and playback modes.

Index Screen Button

“Operation Buttons for Still Image Playback” (A p. 77)

Delete Button

“Deleting the Currently Displayed File” (A p. 85)

Menu Button

“Operating the Menu” (A p. 121)

Operation Buttons

“Operation Buttons for Still Image Playback” (A p. 77)

Index Screen

Date Button

“Operation Buttons for Video Playback” (A p. 74) “Operation Buttons for Still Image Playback” (A p. 77)

Recording/Playback Mode Button

Switches between recording and playback modes.

Index Screen Switching Button (Still image only)

“Operation Buttons for Still Image Playback” (A p. 77)

Delete Button

“Deleting Selected Files” (A p. 85)

Playback Media Button

Switches between SD card and built-in memory.

Menu Button

“Operating the Menu” (A p. 121)

Page Forward/Back Button

“Operation Buttons for Video Playback” (A p. 74) “Operation Buttons for Still Image Playback” (A p. 77)

Getting Started

Menu Screen

Help Button

Menu Items

Return Button

Common Menu Button

Close Button

“Operating the Menu” (A p. 121)

Clock Setting

The “SET DATE/TIME!” screen appears when you turn on this unit for the first time after purchase, when it has not been used for a long time, or when the clock is not set yet. Set the clock before recording.

Open the LCD monitor.

The unit turns on.

When the LCD monitor is closed, the unit turns off.

Tap “YES” when “SET DATE/TIME!” is displayed.

Set the date and time.

When the year, month, day, hour, or minute item is tapped, “∧” and “∨” will be displayed.

Tap ∧ or ∨ to adjust the year, month, day, hour, and minute.

After setting the date and time, tap “SET”.

Select the region where you live and tap “SAVE”.

The city name and time difference are displayed.

Tap < or > to select the city name.

Memo :

The clock can be reset again later.

“Resetting the Clock” (A p. 21)

When using this unit overseas, you can set it to the local time for recording.

“Setting the Clock to Local Time when Traveling” (A p. 39)

“SET DATE/TIME!” is displayed when you turn on this unit after it has not been used for a prolonged period. Connect the AC adapter for more than 24 hours to charge the internal clock battery of this unit before setting the clock.

Getting Started

Resetting the Clock

Set the clock with “CLOCK ADJUST” from the menu.

Tap “MENU”.

Tap “Q”.

Tap “CLOCK ADJUST”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap “CLOCK SETTING”.

Set the date and time.

When the year, month, day, hour, or minute item is tapped, “∧” and “∨” will be displayed.

Tap ∧ or ∨ to adjust the year, month, day, hour, and minute.

After setting the date and time, tap “SET”.

Select the region where you live and tap “SAVE”.

The city name and time difference are displayed.

Tap < or > to select the city name.

Getting Started

Changing the Display Language

The language on the display can be changed.

Tap “MENU”.

Tap “Q”.

Tap “LANGUAGE”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap to the desired language.

Tap ∧ or ∨ to move upward or downward for more selection.

Holding this Unit

When holding this unit, keep your elbows close to your sides to prevent camera shake.

Caution :

Be careful not to drop this unit during transportation.

Guardians should pay close attention when this unit is being used by children.

Memo :

If camera shake is excessive, use the digital image stabilizer.

“Reducing Camera Shake” (A p. 64)

Tripod Mounting

This unit can be mounted on a tripod (or monopod). This is useful for preventing camera shake and recording from the same position.

To prevent this unit from falling off, check the tripod mounting screw holes and positioning holes on the unit carefully before mounting, and turn the screws until they are fastened firmly.

Caution :

To prevent injuries or damages which may result if this unit falls off, read the instruction manual of the tripod (or monopod) to be used and make sure that it is securely attached.

Memo :

It is recommended to use a tripod or monopod when recording in conditions prone to camera shake (such as in dark places or when zoomed to the telephoto end).

Set the digital image stabilizer to b (OFF) when using a tripod for recording.

“Reducing Camera Shake” (A p. 64)

Getting Started

Using the Remote Control

You can operate this unit from a distance away using the supplied remote control.

Memo :

Point the remote control toward the sensor directly and use it within 5 m from this unit.

The transmitted beam may not be effective or may cause incorrect operation when the sensor is directly exposed to sunlight or powerful lighting.

Preparing the Remote Control

Using the Remote Control for the First Time

A button battery (CR2025) is included inside the remote control at the time of purchase. Remove the insulation sheet before use.

Reinserting the Battery

Pull out the battery holder by pressing the lock tab.

Insert the button battery with the + side facing upward.

Operation Buttons on Remote Control Unit

Recording Start/Stop Button

Starts/stops video recording.

Still Image Button

Takes a still image.

Zoom Button

T: Zooms in

W: Zooms out

Basic Playback Operations

Operation Button Description

Playback/Pause Button

d / e

Starts/pauses playback of videos or slideshows.

Left Button j

Moves the cursor to the left.

Performs reverse search during playback.

Right Button i

Moves the cursor to the right.

Performs forward search during playback.

T Button N

Turns up (+) the volume during video playback.

W Button O

Turns down (-) the volume during video playback.

Index Button

Stops playback and returns to index screen.

Info Button

Recording: Displays the remaining time (for video only) and battery power.

Playback: Displays file information such as recording date.

Getting Started

Using Bluetooth-compliant Devices

This unit is equipped with Bluetooth function. You can do the following using a Bluetooth-compliant device via wireless connection.

Capabilities of Bluetooth-compliant Devices

Capability Bluetooth-compliant Device

Control the camcorder

Smartphone

Monitor the image during recording

Smartphone

Import recorded still images

Smartphone

BIP/OPP-compliant device (such as some mobile phones)

Record the location information *1

Smartphone

GPS Receiver

Transfer recorded videos

Smartphone (Android 2.1 or higher compatible devices only)

Listen to audio sound/Record audio sound

Headset

*1 The recorded location information can be used on the software provided with this unit. For more information, refer to “MediaBrowser Help”.

Using a Bluetooth-compliant Device

For smartphones, install its exclusive application.

“Registering a Bluetooth-compliant Device” (A p. 25)

Connect the Bluetooth-compliant device to the camcorder.

“Connecting to a Registered Bluetooth-compliant Device” (A p. 27)

Perform some rehearsals (test recordings) before the actual shooting.

Perform the actual shooting (operations).

Improving the Communication

A Some connected devices may not be able to support the capabilities

of this unit.

Verify the compatibility before using. B Make sure that there are no obstacles between the Bluetooth-

compliant device and the camcorder.

Position the Bluetooth-compliant device such that it can be seen by the camcorder.

Any obstacles or human subjects between the Bluetooth-compliant device and the camcorder will interrupt the communication.

When using a headset, use it while facing this unit directly.

C Make use of the Bluetooth-compliant device as near to the camcorder

as possible.

Although connections within a range of 10 m may be supported by this unit, the nearer the device, the better the communication.

*If the communication is weak, data transfer may take a longer time or there may be noise in the audio sound.

Getting Started

Compliant Bluetooth Devices

This unit can be connected to the following Bluetooth-compliant devices for use. Refer to the instruction manual of the device, except smartphones, to check its Bluetooth profile.

Device Selection

(Bluetooth setting

on this unit)

Target Device/Compliant Profile

Smartphone

Android Smartphone (Android 2.1 or higher, with Bluetooth SPP profile)

BlackBerry Bold

Touch Diamond

Touch Pro

BIP/OPP BIP (Basic Imaging Profile, Imaging Responsor)

OPP (Object Push Profile, Push Server)

GPS Receiver SPP (Serial Port Profile, Device B)

Headset 1 HSP (Headset Profile, HS)

For details, refer to the following homepage.

http://www.jvc-victor.co.jp/english/download/bluetooth/index.html

Caution :

Operation is not guaranteed on all devices.

Communication may not be carried out properly near radio equipment or broadcasting stations. In this case, change the location accordingly.

Radio wave interference by wireless LAN equipment Wireless LAN equipment makes use of the same frequency bandwidth (2.4 GHz) as that of the Bluetooth devices. Using this product near such equipment may cause radio wave interference, and result in a drop in communication speed or connection failure. In this case, turn off the power of devices that are not in use.

Registering a Bluetooth-compliant Device

In order to use a Bluetooth-compliant device with this unit, it is necessary to perform registration (pairing) on this unit.

Searching for Bluetooth-compliant Devices to Register

Tap “MENU”.

Tap “Q”.

Tap “Bluetooth”.

Tap “REGISTER DEVICE”.

Tap “SEARCH FOR DEVICE”.

Select to enable search for the device to register and tap “OK”.

Getting Started

The system starts to search for Bluetooth-compliant devices in the area that can be registered.

The method of setting varies with the device. Refer also to the instruction manual of the device.

Tap the device to register.

If the device to register cannot be found, check the device settings again and restart search.

If the device name cannot be acquired, the Bluetooth device address (BD address) will appear instead.

Characters in the device name that cannot be displayed are shown as □.

Tap “YES”.

If authentication of the device is necessary, the passkey entry screen will appear.

If authentication of the device is not necessary, the passkey entry screen will not appear.

Enter the passkey for the device to register.

Tap on a numeric character to enter it.

Tap “DELETE” to clear the last numeric character.

After input of the numeric characters is complete, tap “SET”.

The number of digits in a passkey varies with the device to register.

A passkey is also known as a "PIN code".

For details on the passkey, refer to the instruction manual of the device to register.

After registration of the device is complete, tap “OK”.

Responding to Registration Requests from Bluetoothcompliant Devices

Tap “MENU”.

Tap “Q”.

Tap “Bluetooth”.

Tap “REGISTER DEVICE”.

Tap “WAIT FOR DEVICE”.

Tap “OK” when “WAIT FOR REQUEST FROM Bluetooth DEVICEALL CURRENT CONNECTIONS WILL BE DISCONNECTED” is displayed.

This unit goes into a standby mode to wait for registration requests from Bluetooth-compliant devices. Perform the registration settings on the device to register.

Getting Started

The method of setting varies with the device. Refer also to the instruction manual of the device.

Tap “YES”.

If authentication of the device is necessary, the passkey entry screen will appear.

If authentication of the device is not necessary, the passkey entry screen will not appear.

Enter the passkey for the device to register.

Tap on a numeric character to enter it.

Tap “DELETE” to clear the last numeric character.

After input of the numeric characters is complete, tap “SET”.

The number of digits in a passkey varies with the device to register.

A passkey is also known as a "PIN code".

For details on the passkey, refer to the instruction manual of the device to register.

After registration of the device is complete, tap “OK”.

Memo :

Registration may fail depending on the device you are using. In addition, connection may fail to establish even if the device is registered.

Results of device search vary according to the selected device, condition of signals, and position of the device.

The auto power off, power-saving, and demo modes are not available during registration of a Bluetooth device.

Deleting Registered Devices

You can delete a registered device by selecting “DELETE DEVICE” in step

Connecting to a Registered Bluetooth-compliant Device

To use a Bluetooth-compliant device on this unit, it is necessary to establish connection with the device after registering it. To establish connection with a Bluetooth-compliant device, make use of the menu to set the connection with the device to ON.

Tap “MENU”.

Tap “Q”.

Tap “Bluetooth”.

Tap “CONNECT”.

Tap the device to connect.

When a device with the “OFF” icon is tapped, the icon changes to “ON”, and an icon indicating the radio reception status is displayed.

When a device with the “ON” icon is tapped, it gets disconnected and the icon changes to “OFF”.

When an unregistered item is selected, a screen to select device will appear.

Getting Started

Caution :

If connection cannot be established with a device, check the registered devices and register again.

Up to two Bluetooth devices can be connected to this unit.

Sending or receiving of audio data using the headset is not possible in the still image recording mode.

When “FACTORY PRESET” in the COMMON (basic settings) menu is executed, all information of the registered Bluetooth-compliant devices will be erased.

The auto power off, power-saving and demo modes are not available when a Bluetooth device is connected.

About Disconnections：

Connection of this unit with the Bluetooth-compliant device will be cut off automatically in the following cases.

When the power of this unit is turned off

When this unit is connected to a DVD writer or PC with a USB cable

When time-lapse shooting is performed

When “FACTORY PRESET” in the COMMON (basic settings) menu is executed

Memo :

When communication with the connected device fails, this unit will disconnect the device after about 10 seconds.

Indications when a Bluetooth-compliant Device is Connected

You can check the Bluetooth connection status on the recording screen.

Display Icon

Description

GPS Communication Status

Displays the communication status with the GPS. The icon will appear blinking if location information cannot be acquired from the GPS.

Radio Reception Status

Displays the radio reception status of the Bluetooth connection.

Bluetooth Microphone Volume

Displays the microphone's volume level when the Bluetooth microphone is enabled.

Memo :

The radio reception status is only a guide. It is not displayed in real-time.

Indications may not be updated according to the condition of signals. The response is especially slow when the radio reception status changes from weak to strong.

The radio reception status is not displayed during BIP/OPP connection.

As communication with the connected device is necessary to retrieve radio reception status, the status may not be updated if communication is interrupted suddenly such as by turning off the power.

Table of Compatible Connections

Connection Case Case 1 Case 2 Case 3 Case 4 Case 5

Headset 1

P P

Headset 2

GPS Receiver -

P P

- -

BIP/OPP - - - - -

Smartphone - - -

P P

Changing the Settings of a Registered Bluetooth-compliant Device

You can change the settings of a registered Bluetooth-compliant device. The audio settings of the headsets may also be changed.

Tap “MENU”.

Tap “Q”.

Tap “Bluetooth”.

Tap “CHANGE SETTINGS”.

Tap the desired device.

Getting Started

Smartphone Changes the mobile phone to be used as smartphone.

GPS Receiver Changes the device to be used as GPS receiver.

Headset 1/ Headset 2

Changes the device to be used as headset 1 or headset

2. Audio settings (“EARPHONES AUDIO”, “MIC AUDIO”) may also be turned ON/OFF. EARPHONES AUDIO 1/2: Selects whether to output the headset microphone input from the headset earphones.

Microphone audio of the camera will be output from the earphones even when this is set to “OFF”.

“EARPHONES AUDIO 1/2” is common for headset 1 and headset 2. ON/OFF cannot be set separately.

MIC AUDIO: Selects ON/OFF for the headset microphone input.

Memo :

The connection setting becomes “OFF” after the device is changed. Change the setting to “ON” from the menu.

“Connecting to a Registered Bluetooth-compliant Device” (A p. 27)

Transferring Still Images to a Bluetooth-compliant Device

When Bluetooth connection is established with a BIP/OPP-compliant device, you can transfer recorded still image data to this device.

Select still image mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “STILL IMAGE TRANSFER”.

Set the connected device to the data reception mode.

For detailed operating instructions, refer to the instruction manual of the connected device.

Check to ensure that the image to be transferred is correct and tap “YES” .

The image to be transferred appears on this screen.

Tap h / g to select the previous or next file.

Confirm the destination to transfer to and tap “TRANSFER”.

Getting Started

To reduce the image for transferring, tap “SHRINK AND TRANSFER” .

To change the destination to transfer to, tap “CHANGE DESTINATION”.

After image transfer is complete, tap “EXIT”.

To continue to transfer more images, tap “SEND OTHER IMAGES”.

“DEVICE IS NOT SET” appears when the destination to transfer to is not set. Tap “SET” and select the device to transfer to.

Memo :

If the connected device is compliant with both BIP and OPP, BIP connection takes priority. Selection of connection is not possible. OPP connection will only take place if BIP connection fails.

Before starting image transfer, be sure to turn on the Bluetooth connectivity of the connected device and set it to the data reception mode. Transmission will fail if the Bluetooth connectivity is set after image transfer starts.

To transfer still images to a smartphone, make use of an application software for smartphones. (When a registered smartphone is selected as the destination to transfer to, the smartphone setting is canceled and it is necessary to make the setting once more.)

“Operation Using a Smartphone” (A p. 30)

Only one still image can be transferred at a time. To transfer more still images, tap “SEND OTHER IMAGES” and select another image.

Still images cannot be transferred from the connected device to the camcorder.

Depending on the specifications of the connected device, you may not be able to see or edit the file even if it is transferred successfully. To see or edit the file on the connected device, refer to the instruction manual of the connected device for the compatible image size and transfer using “SHRINK AND TRANSFER”.

About BIP Connection：

The conditions (image size, data size) for still image transfer are obtained from the connected device. Still images are then transferred as follows according to the obtained conditions. (1) If the image size meets the conditions, the image will be transferred without any changes. (2) If the image size is too big, the image will be reduced to VGA (640×480) or FWVGA (854×480). (3) If the data size is too big, the image will also be reduced to VGA (640×480) or FWVGA (854×480).

About OPP Connection：

Still image transfer may fail even if the connected device is compliant with OPP connection. It depends on the file format that can be received by the device.

When “SHRINK AND TRANSFER” is selected, the still image to transfer will be reduced to the following sizes.

- For still images with 4:3 aspect ratio: VGA (640×480)

- For still images with 16:9 aspect ratio: FWVGA (854×480)

Operation Using a Smartphone

You can use a smartphone as a remote control for this unit using the preinstalled application on the phone. This unit supports the following smartphones.

Android Smartphone (Android 2.1 or higher, with Bluetooth SPP profile)

BlackBerry Bold

Touch Diamond

Touch Pro

Memo :

Operation is not guaranteed on all devices.

For details, refer to the following homepage.

http://www.jvc-victor.co.jp/english/download/bluetooth/index.html

Application Software for Android Smartphone

- For downloads, refer to the following.

http://www.jvc-victor.co.jp/english/download/bluetooth/index.html

Application Software for Android Smartphone

- For operating instructions, refer to the following.

“Bluetooth Application for Smartphones” (A p. 31)

Application Software for BlackBerry Bold / Touch Diamond / Touch Pro

- For downloads and operating instructions, refer to the following.

http://www.jvc-victor.co.jp/english/download/bluetooth/index.html

Caution :

When a smartphone is used as a remote control, the simultaneous still image recording function on this unit will be disabled.

Bluetooth capabilities are limited during HDMI connection in the 3D mode. Set this unit to the 2D mode in this case. (for GZ-HM960)

Memo :

Data packet charges may be incurred when using GPS.

When the smartphone is connected to other Bluetooth-compliant devices, connection of the phone with this unit may fail.

When the smartphone is connected to this unit, connection of the phone with other Bluetooth-compliant devices may fail.

Disconnection may occur due to requests from the smartphone. Restart the application on the phone if it is disconnected.

Getting Started

Bluetooth Application for Smartphones

Capabilities of this Application

By installing this application on a smartphone, you can connect the smartphone to this camera via Bluetooth connection and make use of the following functions.

Operate with a smartphone - Remote control function

You can use a smartphone as a remote control for this unit.

Record and display location information - GPS function

You can obtain the GPS location information with a smartphone, and add this information to the image data recorded by this camera.

The location information is sent only in the video/still image recording mode.

By recording videos/still images with location information, you can display the information during playback.

Caution :

Packet communication fees may be incurred when the GPS function is used.

Display the camera’s screen on a smartphone - MONITOR function

Images on the camera during the video recording mode can be displayed on a smartphone as a series of continuous still images.

Import recorded images to a smartphone - CAPTURE function

Images recorded on the camera can be resized and imported to a smartphone as still images.

This function is available in the video/still image playback mode.

Import recorded videos to a smartphone - Video transfer function

Videos recorded on the camera can be resized and imported to the smartphone.

This function is available in the video playback mode.

Operating Conditions

To use this application, your smartphone has to meet the following requirements.

A OS: Android 2.1 or higher B Supports Bluetooth function and the Serial Port Profile (SPP) C Supports GPS function D Able to connect to the internet or “Android Market™” (required for

software installation)

Terms Used in this Guide

：

In this guide, operations on the touch panel are described as “tap”.

While the names of the buttons on a smartphone are written as “MENU” or “RETURN”, they may vary according to the smartphone in use.

Refer also to the instruction manual of your smartphone.

Installing the Application from Android Market

Tap [Market] on the home screen.

Search for the “Everio Controller” application.

Tap on the “Everio Controller” application.

The detailed information of the application is displayed.

Tap [FREE]F[OK].

For applications that access data or functions of this unit, a screen that shows the data or functions that will be used is displayed. After checking, tap [OK].

Downloading starts.

After downloading is complete, Install_End appears on the status bar at the top of the screen. The installed application will be added to the application list automatically.

Deleting Applications

A Tap [Market] on the home screen. B Press the menu button and tap [My apps].

A list of previously downloaded applications is displayed.

C Tap on the “Everio Controller” application. D Tap [Uninstall], then tap [OK].

Memo :

The specifications of Android Market™ are subject to changes without prior notice. For operating details, refer to the help file of Android Market™.

Preparing for Bluetooth Connection

Tap “MENU”. (Operation on this camera)

Tap “Q”. (Operation on this camera)

Tap “Bluetooth”. (Operation on this camera)

Tap “REGISTER DEVICE”. (Operation on this camera)

Tap “WAIT FOR DEVICE”. (Operation on this camera)

Tap “OK” when “WAIT FOR REQUEST FROM Bluetooth DEVICEALL CURRENT CONNECTIONS WILL BE DISCONNECTED” is displayed. (Operation on this camera)

Getting Started

When “WAITING FOR REQUEST FROM THE DEVICE” appears, perform the following operations on the smartphone.

Press the “MENU” button on the home screen, then tap [Settings]>[Wireless & networks]>[Bluetooth settings]. (Operation on the smartphone)

Tap [Bluetooth] to add a check mark. (Operation on the smartphone)

The Bluetooth function turns on.

A search for Bluetooth devices starts, and the detected Everio model name appears in the list.

If the device does not appear in the list, tap [Scan for devices] and search again.

Tap the Everio model name. (Operation on the smartphone)

Pairing starts.

Tap “YES”. (Operation on this camera)

Starting/Exiting the Application

Starting the Application

Tap “MENU”. (Operation on this camera)

Tap “Q”. (Operation on this camera)

Tap “Bluetooth”. (Operation on this camera)

Tap “CONNECT”. (Operation on this camera)

Tap “SMARTPHONE”. (Operation on this camera)

Select and tap on the smartphone to connect to from the list. (Operation on this camera)

Check that the icon changes to “ON”. (The icon changes between “ON” and “OFF” with every tap.)

To select again, select from “CHANGE SETTINGS”.

“Changing the Settings of a Registered Bluetooth-compliant Device” (A p. 28)

Tap “L” to exit the menu. (Operation on this camera)

Tap “Everio Controller” on the application list. (Operation on the smartphone)

Tap the model name of the camera in use. (Operation on the smartphone)

Exiting the Application

Press the “RETURN” button. (Operation on the smartphone)

Tap “OK”. (Operation on the smartphone)

Caution :

Be sure to exit the application using the above procedure.

Getting Started

Displays on the Screen

Video Recording Mode

Video Playback Mode

Still Image Recording Mode

Still Image Playback Mode

Getting Started

Names of Buttons and Functions

Name of Button Function Mode

Video Still Image

Recording Playback Recording Playback

Video/Still Image Mode *1

Switches between video and still image modes.

P P P P

Recording/Playback Mode *1

Switches between recording and playback modes.

P P P P

Zoom (T) Zooms to the T (telephoto) end.

Zoom (W) Zooms to the W (wide angle) end.

Record Starts video recording.

- - -

Stop Stops video recording.

- - -

Shutter Takes a still image. - -

d (Play) *2

Starts playback of the selected video or still image. During video/still image playback: Starts/pauses playback.

j (Rewind)

During index screen display: Moves the cursor to the left.

During video playback: Performs reverse search. During still image playback: Returns to the previous image.

i (Fast Forward)

During index screen display: Moves the cursor to the right.

During video playback: Performs forward search. During still image playback: Advances to the next image.

h (Reverse Skip)

During video playback: Returns to the beginning of the scene.

- -

g (Forward Skip)

During video playback: Advances to the next video. -

- -

Index During playback: Returns to the index screen. -

SNAP SHOT *3

During video playback: Captures a still image from the video when this is tapped while playback is paused.

- -

*1 Switching of modes cannot be performed during video recording. *2 If location information is recorded in the video or still image, the location will be displayed on the map. *3 Captured still images are stored in the same media as the original image.

Getting Started

Operating Details

Displaying Camera’s Screen on Smartphone

- MONITOR Function

Switch to the video recording mode.

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [MONITORING] to display a check mark in the checkbox.

Press the “RETURN” button to exit the settings menu.

The camera’s screen appears on the smartphone.

Canceling the Monitor Display

：

Remove the check mark from the checkbox in step 4.

Memo :

Images are displayed as a series of continuous still images.

Displaying the Map During Video or Still Image Playback

Switch to the video playback mode.

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [SHOW MAP] to display a check mark in the checkbox.

Press the “RETURN” button to exit the settings menu.

When a video or still image is played back, a map will be displayed based on the recorded location information.

Canceling the Map Display

：

Remove the check mark from the checkbox in step 4.

Memo :

This function is also available in the still image playback mode.

To display the map, it is necessary to activate location information transmission during video or still image recording.

During video playback, the map changes (moves) together with the changes in location information.

To display the map, internet connection is required. (Packet communication fees may be incurred.)

Recording Location Information

Switch to the video recording mode.

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [SEND LOCATION INFO] to display a check mark in the checkbox.

Press the “RETURN” button to exit the settings menu.

Canceling Location Information Transmission

：

Remove the check mark from the checkbox in step 4.

Memo :

This function is not available if there is no GPS function in the smartphone.

By default, the location information will be transmitted every 1 second. You can change the transmission interval from the settings menu.

Changing the Transmission Interval

Switch to the video recording mode.

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [CHANGE INTERVAL] to display the setting window.

Getting Started

Move the slide bar in the setting window to the right and left to change the interval.

Tap [OK] to complete the setting.

Press the “RETURN” button to exit the settings menu.

Canceling the Setting：

Press the “RETURN” button in step 6

Memo :

This function is not available if there is no GPS function in the smartphone.

Displaying Google Map™：

When “Map” is tapped, a map will be displayed on the full screen.

For operating instructions of the map, refer to the instruction manual of the smartphone.

To cancel the magnified display of the map, press the “RETURN” button.

Transferring Videos to a Smartphone

Switch to the video playback mode.

Tap j/i to select the video to transfer.

Tap d to start playback.

Tap d at the scene to start transferring to pause playback.

Press the “MENU” button to display the transfer (VIDEO TRANSFER) button, then tap on it.

Move the slide bar in the setting window to the right and left to select the length of the video.

Memo :

The length of video that can be transferred is limited. By default, it is set to 10 seconds. You can set the time between 10 seconds to 180 seconds.

Tap [START].

Preparation for the transfer starts on the camera, and the transferring starts when preparation is done.

A progress status is displayed when transferring starts on the smartphone.

After transferring is complete, a window to select the data processing method appears.

Tap [OK] to complete the transfer.

Checking the Transferred Video：

Tap [PLAY] in step 8 to play back the transferred video.

Uploading the Transferred Video to Youtube, etc.：

Tap [SHARE] in step 8 to display the list of destinations (services) to upload to. Tap the desired service to start the uploading process.

To make use of a service, it is necessary to perform registration beforehand.

Canceling the Transfer：

Tap [CANCEL] in step 7 during transferring.

Transferring Still Images to a Smartphone

Switch to the video or still image playback mode.

Tap j/i to select the still image to transfer.

Tap d to start playback.

* For still image playback, proceed to step 5.

For video playback, tap d at the scene to transfer to pause playback.

Press the “MENU” button to display the transfer (CAPTURE) button.

Tap the transfer (CAPTURE) button to display the settings menu.

Preparation for the transfer starts on the camera, and the transferring starts when preparation is done.

A progress status is displayed when transferring starts on the smartphone.

After transferring is complete, a window to select the data processing method appears.

Getting Started

Tap [OK] to complete the transfer.

Checking the Transferred Still Image：

Tap [PLAY] in step 7 to play back the transferred still image.

Uploading the Transferred Still Image：

Tap [SHARE] in step 7 to display the list of destinations (services) to upload to. Tap the desired service to start the uploading process.

To make use of a service, it is necessary to perform registration beforehand.

Canceling the Transfer：

Tap [CANCEL] in step 6 during transferring.

Changing the Connected Camera

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [CHANGE CONNECTING DEVICE] to display the setting window.

Tap [OK] in the setting window.

The connection gets disconnected, and a device selection window appears.

Tap on the device to connect to from the list displayed in the device selection window.

The selected device gets connected.

* It is necessary to perform pairing beforehand for the camera to change to.

Canceling the Setting

：

Tap [CANCEL] in step 4.

Changing the Software’s Background Color

Press the “MENU” button to display the settings (SETTINGS) button.

Tap the settings (SETTINGS) button to display the settings menu.

Tap [BACKGROUND COLOR] to display the setting window.

Tap the desired color in the background color setting window.

Press the “RETURN” button once.

The background changes to the selected color.

Canceling the Setting

：

Tap [CANCEL] in step 4.

Settings Menu

You can display the settings menu by pressing the “MENU” button.

Getting Started

Troubleshooting

Trouble Reason and Action

Unable to connect to camera.

Check that there are no obstacles between the device and the camera.

Perform registration (pairing) of the Bluetooth device again.

Delete the registered camera in the smartphone, then execute pairing again.

Turn off the Bluetooth setting of the smartphone, then turn it on again.

Reset the software in the smartphone.

Operations do not work.

Check that there are no obstacles between the device and the camera.

Operations may not work depending on the mode or when the menu is displayed on the camera.

Check the status and mode of the camera.

Operations do not work when the camera is in the quick restart standby mode.

The image from the camera does not appear.

The image appears only during the video recording mode.

The image will not appear if the MONITOR function is not turned on.

Restart the application if the Bluetooth connection gets disconnected.

Monitor image does not get updated when the MONITOR function is being used.

Restart the MONITOR application and connect to Bluetooth again.

Depending on the state of the camera, the updating speed of the MONITOR image may drop such that the changes cannot be seen.

When connected to another Bluetooth device other than the smartphone, disconnect the device.

The progress bar does not show any progression during CAPTURE or video transfer.

When connected to another Bluetooth device other than the smartphone, disconnect the device.

The message “THE DESTINATION TO SAVE THE DATA IS RUNNING OUT OF MEMORY” appears.

This message appears when data cannot be written to the built-in memory of the smartphone. Check whether the SD card has been inserted into the smartphone correctly and that there is enough space left in the card.

* For details on the smartphone’s memory and SD card, refer to the instruction manual of the smartphone.

Unable to transfer still image/video to the smartphone.

Files cannot be transferred when the HDMI cable is connected. Disconnect the HDMI cable before transferring.

Radio Waves Used by this Product

This product makes use of radio waves in the ISM band (2.4 GHz). Although a radio station license is not required for using this product, please take note of the following.

Do not use this product near the following places.

Industrial, scientific, or medical equipment, such as microwave ovens and pacemakers

In-plant radio stations for detecting moving objects, such as those employed in the manufacturing lines of plants (radio station license required)

Specified low-power radio stations (radio station license not required)

Wireless LAN equipment

Equipment such as the above mentioned devices makes use of the same frequency bandwidth as that of Bluetooth. Using this product near the above equipment may cause radio wave interference, and result in communication failure or a drop in communication speed.

Avoid using this product near a TV or radio set.

TV or radio sets make use of a radio wave frequency bandwidth that is different from that of Bluetooth, and therefore has no effect on communication by this product or the TV/radio set. However, when a TV/radio set is placed close to a Bluetooth product, electromagnetic waves emitted by the Bluetooth product may cause noise to occur in the sound or images of the TV/radio.

Radio signals are unable to penetrate through reinforced steel, metal, or concrete.

The radio waves used by this product are unable to penetrate through reinforced steel, metal, or concrete materials. Communication cannot be established if two rooms or floors are separated by these materials. *Communication also gets weaker when there are human subjects or parts of the body in between the Bluetooth devices. Make sure that there are no obstructions in between the devices when in use.

Getting Started

Using this Unit Overseas

The shape of the power outlet varies according to countries and regions. To charge the battery pack, you need a converter plug that matches the shape of the outlet. “Charging the Battery Pack Overseas” (A p. 39) Change the date and time display to the local time by selecting your travel destination in “AREA SETTING” of “CLOCK ADJUST”. “Setting the Clock to Local Time when Traveling” (A p. 39) When “ON” is selected in “DST SETTING” of “CLOCK ADJUST”, the time is set 1 hour ahead. “Setting Daylight Saving Time” (A p. 40)

Charging the Battery Pack Overseas

The shape of the power outlet varies according to countries and regions. To charge the battery pack, you need a converter plug that matches the shape of the outlet.

Setting the Clock to Local Time when Traveling

Change the date and time display to the local time by selecting your travel destination in “AREA SETTING” of “CLOCK ADJUST”. Restore the region settings after you returned from the trip.

Tap “MENU”.

Tap “Q”.

Tap “CLOCK ADJUST”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap “AREA SETTING”.

Select the area you are traveling to and tap “SAVE”.

The city name and time difference are displayed.

Tap < or > to select the city name.

Memo :

Setting “AREA SETTING” changes the clock time such that time difference is accounted for. After returning to your country, re-select the region that was set initially to restore the original clock settings.

Getting Started

Setting Daylight Saving Time

When “ON” is selected in “DST SETTING” of “CLOCK ADJUST”, the time is set 1 hour ahead.

Tap “MENU”.

Tap “Q”.

Tap “CLOCK ADJUST”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap “DST SETTING”.

Tap “ON”.

Memo :

What is daylight saving time? Daylight saving time is the system of setting the clock 1 hour ahead for a fixed period in summer. It is used mainly in the Western countries.

Restore the daylight saving time settings after you returned from the trip.

Optional Accessories

You can record for a longer time by using the optional battery pack.

Product Name Description

Battery Pack

BN-VG114U

BN-VG121U

BN-VG138U

Provides a longer recording time. It can also be used as a spare battery pack.

Battery Charger

AA-VG1

Enables the battery pack to be charged without using this unit.

Component Cable

QAM1266-001

For viewing in high picture quality.

Consult your nearest JVC service center.

HDMI Cable

VX-HD310

VX-HD315

VX-HD320

VX-HD330

For viewing in high picture quality.

Transmits video, audio, and control signals between devices.

Memo :

The above optional accessories may not be supported in some regions.

For more information, refer to the catalog.

BN-VG114U is the same battery pack that comes with this unit.

Getting Started

Approximate Recording Time (Using Battery)

3D Display on LCD Monitor (for GZ-HM960)

Battery

Pack

Actual Recording Time Continuous Recording

Time

BNVG114U (Supplied)

35 m 1 h

BNVG121U

50 m 1 h 30 m

BNVG138U

1 h 30 m 2 h 45 m

2D Display on LCD Monitor (for GZ-HM960)

Battery

Pack

Actual Recording Time Continuous Recording

Time

BNVG114U (Supplied)

40 m 1 h 10 m

BNVG121U

1 h 1 h 45 m

BNVG138U

1 h 40 m 3 h 5 m

2D Display on LCD Monitor (for GZ-HM860)

Battery

Pack

Actual Recording Time Continuous Recording

Time

BNVG114U (Supplied)

40 m 1 h 15 m

BNVG121U

1 h 5 m 1 h 55 m

BNVG138U

1 h 55 m 3 h 25 m

The above are values when “LIGHT” is set to “OFF” and “MONITOR BRIGHTNESS” is set to “3” (standard).

The actual recording time may be shorter if zooming is used or if recording is stopped repeatedly. (It is recommended to prepare battery packs ready for three times the expected recording time.)

When the battery life is reached, the recording time becomes shorter even if the battery pack is fully charged. (Replace the battery pack with a new one.)

Getting Started

Taking Videos in Intelligent Auto Mode

You can record without worrying about the setting details by using the Intelligent Auto mode. Settings such as exposure and focus will be adjusted automatically to suit the shooting conditions.

In case of specific shooting scenes such as person etc., its icon is displayed on the screen.

Before recording an important scene, it is recommended to conduct a trial recording.

Open the LCD monitor and select the video mode.

The video mode icon appears.

Check if the recording mode is Intelligent Auto.

If the mode is H Manual, press the i.AUTO button to switch. The mode changes between Intelligent Auto and Manual with every press.

Start recording.

Press again to stop.

Some displays disappear after approximately 3 seconds. Use the n button to change the displays.

“Operation Buttons for Video Recording” (A p. 43)

Memo :

3D images are supported by the LCD monitor of this unit. This allows you to check the 3D effect while recording. To switch to 3D mode, refer to “Playing Back 3D Images”. (for GZ-HM960)

“Playing Back 3D Images (for GZ-HM960)” (A p. 76)

When recording in 3D mode, the image is recorded in 2D even though the display on the LCD monitor is 3D. (for GZ-HM960)

Indications During Video Recording

Display Icon Description

Video Quality Displays the icon of the “VIDEO QUALITY”

setting selected in the recording menu. “VIDEO QUALITY” (A p. 129)

TOUCH PRIORITY AE/AF

Displays the setting of “TOUCH PRIORITY AE/ AF”. By default, it is set to “FACE TRACKING” . “Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 61)

Time Displays the current time.

“Clock Setting” (A p. 20)

Image Stabilizer Sets whether to reduce camera shake.

“Reducing Camera Shake” (A p. 64)

Recording Media Displays the icon of the media where videos

are recorded to. The recording media can be changed. “REC MEDIA FOR VIDEO” (A p. 145)

Battery Indicator Displays the approximate remaining battery

power. Details of the battery power can be displayed by pressing the INFO button. “Remaining Recording Time/Battery Power” (A p. 72)

Recording Mode Press the i.AUTO button to switch the

recording mode between P (Intelligent Auto) and H (Manual).

Remaining Recording Time

Displays the remaining time for video recording.

Scene Counter (Recorded Time)

Displays the elapsed time of the video that is currently being recorded.

Recording

Scenes of Intelligent Auto

Display Icon Description

Captures one’s skin beautifully.

Allows people to be captured naturally.

Focuses at a far distance and captures a sharp image with vivid colors.

Records with minimal noise in the overall image.

Allows night scenes to be captured accurately with minimal noise in the overall image.

Prevents colors from fading even when recording in a bright environment.

Records while focusing on a near object.

Reproduces the green color of trees vividly.

Reproduces the colors of sunset naturally.

Adjusts settings so that the subject does not appear too dark due to backlight.

Allows people to be captured naturally with minimal noise in the overall image.

Records while focusing on a near object even in a dark environment.

Memo :

Scenes can be detected according to the shooting conditions and automatically adjusted in Intelligent Auto mode.

Some functions may not work properly depending on the shooting conditions.

Operation Buttons for Video Recording

Operation

Button

Description

Face Short Cut Menu Button

Displays a short cut screen of face recognition functions. “Operating the Face Short Cut Menu” (A p. 122)

B / C

T/W Zoom Allows the same functions as the zoom

lever to be performed. Camera shake that often occurs when using the zoom lever can be minimized. “Zooming” (A p. 44)

Recording/ Playback Mode

Switches between recording and playback modes.

E / F

Recording Start

Record-Standby

Functions as the START/STOP button.

MENU Displays the various menus of video

recording. “Operating the Menu” (A p. 121)

Display Button n

Some displays disappear after approximately 3 seconds.

Use the n button to change the displays as shown below.

Tap n button Displays appear for approximately 3 seconds with every tap.

Tap and hold n button Displays are fixed such that they do not disappear. After setting, the display

button changes from n to m. Tap m to release the displays.

Recording

Useful Settings for Recording

When “QUICK RESTART” is set to “ON”, this unit turns on immediately if you open the LCD monitor within 5 minutes after the power is turned off by closing the monitor.

“QUICK RESTART” (A p. 147)

When “AUTO POWER OFF” is set to “ON”, this unit turns itself off automatically to conserve power when it is not operated for 5 minutes. (only when using the battery pack)

“AUTO POWER OFF” (A p. 146)

When “TOUCH PRIORITY AE/AF” is set to “FACE TRACKING”, this unit detects faces and automatically adjusts its brightness and focus to record the faces more clearly.

“Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 61)

If the remaining space on the built-in memory runs out while “SEAMLESS RECORDING” is set to “ON”, recording continues after switching to the SD card.

“SEAMLESS RECORDING” (A p. 130)

Caution :

Do not expose the lens to direct sunlight.

Do not use this unit in the rain, snow, or places with high humidity like the bathroom.

Do not use this unit in places subject to excessive humidity or dust, as well as places exposed to steam or smoke directly.

Do not remove the battery pack, AC adapter, or SD card when the access lamp is lighted. The recorded data may become unreadable.

“ACCESS (Access) Lamp” (A p. 156)

This unit is a microcomputer-controlled device. Electrostatic discharge, external noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such a case, turn off the power, then remove the AC adapter and battery pack. This unit will be reset.

Make a backup of important recorded data. It is recommended to copy your important recorded data to a DVD or other recording media for storage. JVC will not be responsible for any lost data.

Memo :

Check the remaining recording time in the media before you start shooting. If there is not enough space, move (copy) the data to a computer or disc.

When there are many files in the media, it may take time for them to be displayed on the playback screen. Wait for a while as the access lamp appears blinking, which indicates normal operation.

Do not forget to make copies after recording!

Recording stops automatically as it cannot be performed for 12 or more consecutive hours according to specifications. (It may take some time to resume recording.)

For long recordings, the file is split into two or more files if the size exceeds 4 GB.

You can connect this unit to the AC adapter to record for long hours indoors.

Depending on the shooting conditions, the four corners of the screen may appear dark, but this is not a malfunction. In this case, change the shooting conditions by moving the zoom lever, etc.

Zooming

The angle of view can be adjusted using zoom.

Use the W end (wide angle end) to shoot a wider field of view.

Use the T end (telephoto end) to magnify the subject for shooting.

Memo :

When digital zoom is used, the image becomes grainy as it is digitally enlarged.

The zoom ratio range can be changed.

“ZOOM” (A p. 130)

Capturing Still Images During Video Recording

Still images can be captured by pressing the SNAPSHOT button while in the video mode (standby or recording).

“PHOTO” lights up on the screen when a still image is being captured.

The still images captured during video recording are saved to the destination set in “REC MEDIA FOR IMAGE”.

Memo :

The size of the still image that is captured in the video mode is 1920 x

1080.

Operation is invalid under the following conditions:

- when menu is being displayed

- when remaining recording time or battery power is being displayed

- when TIME-LAPSE RECORDING is in use

- when “FACE SUB-WINDOW” is set

- when “ANIMATION EFFECT” is set

- when “HIGH SPEED RECORDING” is set

Recording

Taking Still Images in Intelligent Auto Mode

You can record without worrying about the setting details by using the Intelligent Auto mode.

Open the LCD monitor and select the still image mode.

The still image mode icon appears.

Check if the recording mode is Intelligent Auto.

If the mode is H Manual, press the i.AUTO button to switch. The mode changes between Intelligent Auto and Manual with every press.

Set the focus on the subject.

When focused, the focus icon lights up in green.

Take a still image.

PHOTO lights up when a still image is being captured.

Some displays disappear after approximately 3 seconds. Use the n button to change the displays.

“Operation Buttons for Still Image Recording” (A p. 46)

Memo :

3D images are supported by the LCD monitor of this unit. This allows you to check the 3D effect while recording. To switch to 3D mode, refer to “Playing Back 3D Images”. (for GZ-HM960)

“Playing Back 3D Images (for GZ-HM960)” (A p. 78)

When recording in 3D mode, the image is recorded in 2D even though the display on the LCD monitor is 3D. (for GZ-HM960)

Continuous recording of still images (continuous shooting) can be performed on this unit.

“CONT. SHOOTING SPEED” (A p. 136)

Indications During Still Image Recording

Display Icon Description

Image Size Displays the icon of the image size.

The size of still images can be changed.

“IMAGE SIZE” (A p. 137)

TOUCH PRIORITY AE/AF

Displays the setting of “TOUCH PRIORITY AE/ AF”. By default, it is set to “FACE TRACKING” . “Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 61)

Time Displays the current time.

“Clock Setting” (A p. 20)

Recording Media Displays the icon of the media where still

images are recorded to. The recording media can be changed. “REC MEDIA FOR IMAGE” (A p. 145)

Battery Indicator Displays the approximate remaining battery

power. Details of the battery power can be displayed by pressing the INFO button. “Remaining Recording Time/Battery Power” (A p. 72)

Recording Mode Press the i.AUTO button to switch the

recording mode between P (Intelligent Auto) and H (Manual). “Scenes of Intelligent Auto” (A p. 43)

Remaining Number of Shots

Displays the remaining number of shots for still image recording.

Recording in Progress

“PHOTO” appears when a still image is being captured.

Focus Lights up in green when focused.

Shutter Speed Displays the shutter speed.

Recording

Operation Buttons for Still Image Recording

Operation

Button

Description

Face Short Cut Menu Button

Displays a short cut screen of face recognition functions. “Operating the Face Short Cut Menu” (A p. 122)

B / C

T/W Zoom Allows the same functions as the zoom

lever to be performed. Camera shake that often occurs when using the zoom lever can be minimized. “Zooming” (A p. 47)

Recording/ Playback Mode

Switches between recording and playback modes.

Snapshot

Functions as the SNAPSHOT button. However, focus cannot be set by pressing halfway.

MENU Displays the various menus of still image

recording. “Operating the Menu” (A p. 121)

Display Button n

Some displays disappear after approximately 3 seconds.

Use the n button to change the displays as shown below.

Tap n button Displays appear for approximately 3 seconds with every tap.

Tap and hold n button Displays are fixed such that they do not disappear. After setting, the display

button changes from n to m. Tap m to release the displays.

Useful Settings for Recording

When “AUTO POWER OFF” is set to “ON”, this unit turns itself off automatically to conserve power when it is not operated for 5 minutes. (only when using the battery pack)

“AUTO POWER OFF” (A p. 146)

When “TOUCH PRIORITY AE/AF” is set to “FACE TRACKING”, this unit detects faces and automatically adjusts its brightness and focus to record the faces more clearly.

“Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 61)

Caution :

Do not expose the lens to direct sunlight.

Do not use this unit in the rain, snow, or places with high humidity like the bathroom.

Do not use this unit in places subject to excessive humidity or dust, as well as places exposed to steam or smoke directly.

Do not remove the battery pack, AC adapter, or SD card when the access lamp is lighted. The recorded data may become unreadable.

“ACCESS (Access) Lamp” (A p. 156)

Memo :

Before recording an important scene, it is recommended to conduct a trial recording.

The digital image stabilizer does not work when recording still images.

Depending on the shooting conditions, the four corners of the screen may appear dark, but this is not a malfunction. In this case, change the shooting conditions by moving the zoom lever, etc.

Recording

Zooming

The angle of view can be adjusted using zoom.

Use the W end (wide angle end) to shoot a wider field of view.

Use the T end (telephoto end) to magnify the subject for shooting.

The following zoom options are available:

- Optical Zoom (1 - 10x)

Memo :

Only optical zoom is available in the still image recording mode.

Manual Recording

You can adjust settings, such as brightness and shutter speed, by using the manual mode. Manual recording can be set for both video and still image modes.

Open the LCD monitor and select the video or still image mode.

The video A or still image B icon appears.

Select the Manual recording mode.

If the mode is P Intelligent Auto, press the i.AUTO button to switch to H Manual.

The mode changes between Intelligent Auto and Manual with every press.

Tap “MENU”.

Tap the item to set manually.

For details on the various manual settings, refer to “Manual Recording Menu”.

Memo :

The manual settings are displayed only in the manual mode.

Recording

Manual Recording Menu

The following items can be set.

Name Description

SCENE SELECT

Recordings that suit the shooting conditions can be performed easily.

“Scene Selection” (A p. 48)

FOCUS

Use manual focus if the subject is not focused automatically.

“Adjusting Focus Manually” (A p. 49)

FOCUS ASSIST

Focused subject is outlined in color for more precise focus.

“Using Focus Assist” (A p. 50)

FOCUS ASSIST COLOR

Sets the color of the outline of a focused object when Focus Assist is used.

“FOCUS ASSIST COLOR” (A p. 125)

BRIGHTNESS ADJUST

Overall brightness on the screen can be adjusted.

Use this when recording in a dark or bright location.

“Adjusting Brightness” (A p. 50)

SHUTTER SPEED

Shutter speed can be adjusted.

Use this when shooting a fast-moving subject or to emphasize the subject's movement.

“Setting Shutter Speed” (A p. 51)

APERTURE PRIORITY

You can adjust the aperture to capture an image with only the subject in focus while blurring the surroundings.

“Setting Aperture” (A p. 51)

WHITE BALANCE

Overall color on the screen can be adjusted.

Use this when the color on the screen appears differently from the actual color.

“Setting White Balance” (A p. 52)

BACKLIGHT COMP.

Corrects the image when the subject appears dark due to backlight.

Use this when shooting against the light.

“Setting Backlight Compensation” (A p. 53)

TELE MACRO

Use this to take close-up (macro) shots of the subject.

“Taking Close-up Shots” (A p. 54)

Scene Selection

Common scenes that are often encountered can be recorded with the most suitable settings.

Tap “MENU”.

Tap “SCENE SELECT”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap the appropriate scene.

Tap “OFF” to cancel the selection.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Recording

*The image is only an impression.

Setting Effect

b NIGHTALIVE

Increases gain and brightens the scene automatically using a slow shutter when the surrounding is dark. To prevent camera shake, use a tripod.

t NIGHT

Captures night scenes naturally.

w PORTRAIT

Blurs the background to bring out the people in the picture.

u SPORTS

Captures fast-moving subjects clearly in every single frame.

v SNOW

Prevents the subject from appearing too dark when recording snow scenes on a sunny day.

g SPOTLIGHT

Prevents the human subject from appearing too bright under light.

Memo :

All scenes of “SCENE SELECT” cannot be set during “TIME-LAPSE RECORDING”.

Adjusting Focus Manually

Set this when the focus is not clear in Intelligent Auto or when manual focusing is desired.

Tap “MENU”.

Tap “FOCUS”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “MANUAL”.

Adjust the focus.

Tap E to focus on a distant subject.

Tap p to focus on a near subject.

Tap “SET” to confirm.

When focus is confirmed, the focusing frame disappears and E and p are displayed. (The icons may appear blinking.)

Memo :

A subject that is focused at the telephoto (T) end remains in focus when it is zoomed out to the wide angle (W) end.

Recording

Using Focus Assist

Focused subject is outlined in color for more precise focus.

Tap “MENU”.

Tap “FOCUS ASSIST”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Adjust the focus.

Tap E to focus on a distant subject.

Tap p to focus on a near subject.

Tap “SET” to confirm.

Memo :

The image becomes black and white while the outline of the focused object is displayed in the selected color. Change outline color if it becomes difficult to see.

“FOCUS ASSIST COLOR” (A p. 125)

Adjusting Brightness

You can adjust the brightness to your preferred level.

Tap “MENU”.

Tap “BRIGHTNESS ADJUST”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “MANUAL”.

Adjust the brightness value.

Compensation range during video recording: -6 to +6

Compensation range during still image recording: -2.0 to +2.0

Tap ∧ to increase the brightness.

Tap ∨ to decrease the brightness.

Tap “SET” to confirm.

Memo :

Settings can be adjusted separately for videos and still images.

Recording

Setting Shutter Speed

You can set the shutter speed to suit the type of subject.

Tap “MENU”.

Tap “SHUTTER SPEED”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “MANUAL”.

Adjust the shutter speed.

Shutter speed can be set from 1/2 to 1/4000. (Up to 1/500 for still image.)

Tap ∧ to increase the shutter speed.

Tap ∨ to decrease the shutter speed.

Tap “SET” to confirm.

Memo :

Settings can be adjusted separately for videos and still images.

While fast-moving subjects can be captured clearly by increasing “SHUTTER SPEED”, the screen appears darker. When recording in dark places such as indoors, check the brightness of the LCD monitor and set “SHUTTER SPEED” accordingly.

Setting Aperture

You can adjust the aperture to capture an image with only the subject in focus.

Tap “MENU”.

Tap “APERTURE PRIORITY”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “MANUAL”.

Adjust the aperture.

Aperture can be set from F1.2 to F5.6.

If you want the background to be in focus as well (larger aperture value), tap ∧.

If you want the background to appear blurry (smaller aperture value), tap ∨.

Tap “SET” to confirm.

Memo :

Settings can be adjusted separately for videos and still images.

When zoomed to the telephoto end, setting the aperture to the minimum value (F1.2) does not stop it down all the way. In this case, the aperture value is set according to the zoom and indicated in yellow. Set the zoom to the wide angle end to enable the aperture to be stopped down all the way.

Recording

The larger the aperture value, the darker the subject appears.

Setting White Balance

You can set the color tone to suit the light source.

Tap “MENU”.

Tap “WHITE BALANCE”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap the appropriate shooting environment.

Tap ∧ or ∨ to move the cursor.

Setting

Details

AUTO Adjusts automatically to the natural colors.

MWB Use this when the problem of unnatural colors is

not resolved.

FINE Set this when shooting outdoors on a sunny day.

CLOUD Set this when shooting on a cloudy day or inside a

shade.

HALOGEN Set this when shooting under illumination such as

a video light.

MARINE:BLUE Set this when shooting the sea at deep water area

(water appears blue) using an optional marine case.

MARINE:GREEN Set this when shooting the sea at shallow water

area (water appears green) using an optional marine case.

Using MWB

Hold a sheet of plain white paper in front of the lens so that the white paper fills the screen.

Tap “MWB” and keep touching while the icon appears and blinks.

Release your touch after the menu disappears and o lights up.

Memo :

Recording

The setting will not change if “MWB” is being tapped too fast (less than 1 second).

Setting Backlight Compensation

You can correct the image when the subject appears too dark due to backlight.

Tap “MENU”.

Tap “BACKLIGHT COMP.”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “ON”.

After setting, the backlight icon l appears.

Recording

Taking Close-up Shots

You can take close-up shots of an object using the tele macro function.

*The image is only an impression.

Tap “MENU”.

Tap “TELE MACRO”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “ON”.

After setting, the tele macro icon o appears.

Setting

Details

OFF Enables close-up shots up to 1 m at the telephoto (T) end.

Enables close-up shots up to 5 cm at the wide angle (W) end.

ON Enables close-up shots up to 60 cm at the telephoto (T) end.

Enables close-up shots up to 5 cm at the wide angle (W) end.

Caution :

When you are not taking close-up shots, set “TELE MACRO” to “OFF”. Otherwise, the image may be blur.

Creating Animation Effects (ANIMATION EFFECT)

You can add various effects to videos to create a different atmosphere from the usual recording.

Open the LCD monitor and select the video mode.

The video mode icon appears.

Tap “MENU”.

Tap “ANIMATION EFFECT”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Select a desired effect and tap “SET”.

Tap < or > to select an item.

To select another effect, tap J. To cancel the effect, tap L.

Memo :

After setting the animation effect, press the START/STOP button on this unit to start recording.

Recording

During Setting After Setting Note

. .

Animation (effect) appears when smiles are detected.

. .

Animation (effect) appears when smiles are detected.

. .

Animation (effect) appears when smiles are detected.

. .

Animation (effect) appears when smiles are detected.

. .

Animation (effect) appears when the screen is touched.

Recording

Registering Human Face Personal Authentication Information

By registering the face of a person beforehand, focus and brightness can be adjusted automatically by the face tracking function. Up to 6 faces, together with names and priority levels, can be registered. It is recommended to register the faces that are often being recorded by this camera beforehand.

Select video or still image mode.

The video or still image mode icon appears.

Tap “MENU”.

Tap “FACE REGISTRATION”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “REGISTER NEW FACE”.

Point the camera toward the human subject.

Information is collected before face registration recording. The frame appears blinking while information is being collected.

Adjust to fit the face within the frame while it is blinking. The frame stops blinking and lights up after information collection is complete.

To cancel the registration, tap “STOP”. When “CANCEL FACE RECOGNITION?” appears, tap “YES” to return to the normal recording mode.

Tap “RECORD” and record the face from the front.

A face is captured to be used on the face registration index screen.

Other than tapping “RECORD”, you can also record by pressing the SNAPSHOT button fully.

A sound can be heard when recording is complete.

To cancel the registration, tap “STOP”. When “CANCEL FACE RECOGNITION?” appears, tap “YES” to return to the normal recording mode.

Tap “YES” to continue recording.

To proceed to collect face information in the four directions of up, down, left, and right, tap “YES”. It is recommended to continue recording to increase the accuracy of face recognition.

To end face registration recording, tap “NO”. Go to step 10.

Rotate the face slowly in four directions to register the face information.

Rotate the face slowly while looking at the camera. A sound can be heard when recording is complete for each direction. (4 times in total) Repeat the step until recording (registration) is complete for all directions.

Registration of the four directions may fail depending on the shooting environment. In this case, tap “STOP” to cancel recording, then tap “NO” and go to step 10.

If the face cannot be properly recognized during recording, register the face again.

Face the camera with a smiling face.

Recording starts automatically. Using the smile % display as a reference, smile such that the value is as high as possible.

A sound can be heard when recording is complete.

To cancel recording of smiling face and proceed to enter a name, tap “STOP”, then tap “NO” and go to step 10.

Recording

Tap “OK”.

Tapping “OK” registers the recorded face and the screen for entering a name appears.

To cancel the registration, tap “STOP”. When “CANCEL FACE RECOGNITION?” appears, tap “YES” to return to the normal recording mode.

Tap on the on-screen keyboard to enter a name, then tap “REG.”.

Tap “DELETE” to delete a character.

Tap “CANCEL” to exit.

Tap “A/a/1” to select character input type from upper case letter, lower case letter, and number.

Tap E or F to move one space to the left or right.

Up to 8 characters can be entered.

How to input characters Example: To enter “KEN”

Tap “JKL” 2 times F Tap “DEF” 2 times F Tap “MNO” 2 times

Tap the desired priority level, then tap “REG.”.

Upon registration, the last number is assigned as the priority level. During face detection, the subject with the highest priority (lowest number) will be detected.

You can change the priority level of a subject by tapping on the number. Example: To change the priority level of number 3 to number 1, tap number 1. The priority level of the registered subject becomes number 1, while the priority levels of the original number 1 and the ones below drop by one place. (In this example, the original number 1 becomes number 2, and the orignal number 2 becomes number 3.)

When “REG.” is tapped, the registration complete screen appears.

Tap “OK” to complete the registration.

You can edit registered face information in “EDIT”.

“Editing the Registered Face Information” (A p. 59)

Memo :

Faces may not be registered correctly in the following cases:

- when the face appears either too small or too large compared to the frame

- when it is too dark or too bright

- when the face appears horizontal or slanted

- when a part of the face is hidden

- when there are multiple faces within the frame

To increase the accuracy of face recognition, fit only one face within the frame and register in a bright environment.

Faces may not be recognized correctly depending on the shooting conditions and environment. In this case, register the face again.

Faces may not be recognized correctly during recording if the face recognition level is low. In this case, register the face again.

Face tracking, face sub-window, and name display may not work properly depending on the registered faces, shooting conditions (distance, angle, brightness, etc.), and expressions.

Face tracking, face sub-window, and name display may not work properly for people with similar facial features, such as siblings, parents, children, etc.

Recording

Setting SMILE%/NAME DISPLAY

“SMILE%/NAME DISPLAY” allows you to set the items to display when faces are detected. This item is only displayed when “TOUCH PRIORITY AE/AF” is set to “FACE TRACKING”. “Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)” (A p. 61)

Open the LCD monitor and select the video or still image mode.

The video or still image mode icon appears.

Tap “MENU”.

Tap “SMILE%/NAME DISPLAY”.

Tap the desired setting.

Setting

Details

OFF Displays only the frames when faces are detected.

ON Displays the frames, names, and smile levels (%) when faces

are detected.

Frame: Appears around detected faces. Name: Appears for faces that are registered. Smile level: Appears in value (0 % - 100 %) for detected smiles.

Memo :

The camera is able to detect up to 16 faces. Smile levels will be displayed for up to 3 of the largest faces displayed on the screen.

Some faces may not be detected depending on the shooting environment.

You can register personal authentication information like face, name, and priority level of person before recording.

Up to 3 registered names will be displayed according to the priority level.

“Registering Human Face Personal Authentication Information” (A p. 56)

“SMILE%/NAME DISPLAY” is set to “ON” when the demo mode is activated.

“DEMO MODE” (A p. 148)

Recording

Editing the Registered Face Information

Editing Registered Face Information

You can change the name, priority level, and face information that are registered.

Tap “MENU”.

Tap “FACE REGISTRATION”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “EDIT”.

Tap the person to edit.

Tap the item to edit.

If you select “RECORD AGAIN”, proceed to step 5 in ““Registering Human Face Personal Authentication Information” (A p. 56) ”.

If you select “CHANGE NAME”, proceed to step 11 in ““Registering Human Face Personal Authentication Information” (A p. 57) ”.

If you select “CHANGE ORDER OF PRIORITY”, proceed to step 12 in ““Registering Human Face Personal Authentication Information” (A p. 57) ”.

“Registering Human Face Personal Authentication Information” (A p. 56)

Recording

Canceling (Deleting) Registered Face Information

You can cancel (delete) the face information that is registered.

Tap “MENU”.

Tap “FACE REGISTRATION”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “CANCEL”.

Tap the person to cancel registration of.

A appears on the selected person.

To remove A from a person, tap on the person again.

Tap “SET”.

Tap “YES”.

Tap “YES” to delete the face information of the selected person.

Tap “NO” to return to the previous screen.

Tap “OK” when the deletion complete screen appears.

Recording

Capturing Subjects Clearly (TOUCH PRIORITY AE/AF)

“TOUCH PRIORITY AE/AF” is a function that adjusts focus and brightness based on a tapped position. By registering the face of a person beforehand, you can enable tracking of the person even without specific selection during recording. This function is available for both videos and still images.

You can set this function by pressing the AF button too. (for GZ-HM860)

“AF Button (for GZ-HM860)” (A p. 156)

Select video or still image mode.

The video or still image mode icon appears.

Tap “MENU”.

Tap “TOUCH PRIORITY AE/AF”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap the desired setting.

Focus and brightness will be adjusted automatically based on the tapped position (face/color/area). A blue frame appears around the selected subject (face/color), while a white frame appears around the selected area.

To reset, tap the desired position (face/color/area) again.

To cancel “FACE TRACKING”, tap the blue frame.

To cancel “COLOR TRACKING”, tap the blue frame.

To cancel “AREA SELECT”, tap the white frame.

Setting

Details

OFF Deactivates the function.

FACE TRACKING

e appears on the screen. Recording is performed while tracking and automatically adjusting the tapped face (subject) with appropriate focus and brightness. In addition, a blue frame appears around the tapped face (subject). (When the face of a person is registered, it becomes the main subject and the blue frame appears even without specific selection.)

COLOR TRACKING

f appears on the screen. Recording is performed while tracking and automatically adjusting the tapped color (subject) with appropriate focus and brightness. In addition, a blue frame appears around the tapped color (subject).

AREA SELECT

g appears on the screen. Recording is performed while automatically adjusting the tapped area (fixed position) with appropriate focus and brightness. In addition, a white frame appears around the tapped area.

Memo :

When “TOUCH PRIORITY AE/AF” is set, “FOCUS” will be set to “AUTO” automatically.

If the camera loses track of a subject, tap the subject again.

Settings are canceled when zoom operation is performed. (“AREA SELECT” only)

When “FACE TRACKING” is set after face registration, the blue frame appears around the face with the highest priority registered.

When recording registered faces using “FACE TRACKING”, focus and brightness will be adjusted automatically even without specific selection. In addition, registered faces may be tracked back again even if they are lost. Therefore, it is recommended to register the faces that are often being recorded by this camera beforehand.

“Registering Human Face Personal Authentication Information” (A p. 56)

When “COLOR TRACKING” is set, the targeted subject (color) may change if similar colors are detected. In this case, tap the subject again. The targeted subject (color) may also be tracked back again if it appears in the center of the screen within a specific time.

Caution :

Subjects near the sides of the LCD monitor may not respond or be recognized when tapped. In this case, move the subject to the center and tap again.

“COLOR TRACKING” may not function properly in the following cases:

- when recording subjects with no contrast

- when recording subjects that are moving at high speed

- when recording in a dark place

- when the surrounding brightness changes

When “FACE TRACKING” is set, the subject may be lost if the camera is moved vertically or horizontally very fast. For unregistered faces, they cannot be tracked back again. To track back the subject, tap on it again. For registered faces, focus and brightness will be adjusted automatically even without specific selection. In addition, registered faces may be tracked back again even if they are lost. Therefore, it is recommended to register the faces that are often being recorded by this camera beforehand.

“Registering Human Face Personal Authentication Information” (A p. 56)

Recording

Capturing Smiles Automatically (SMILE SHOT)

“SMILE SHOT” automatically captures a still image upon detection of a smile. This function is available for both videos and still images.

Select video or still image mode.

The video or still image mode icon appears.

Tap “MENU”.

Tap “SMILE SHOT”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “ON”.

Point the camera toward the human subject.

A still image is automatically captured when smiles are detected.

PHOTO lights up when a still image is being captured.

You can display the name and smile level (%) together with the frame by setting “SMILE%/NAME DISPLAY” in the menu to “ON” before recording.

“Setting SMILE%/NAME DISPLAY” (A p. 58)

Memo :

This function may not work properly depending on the shooting conditions (distance, angle, brightness, etc.) and the subject (direction of face, smile level, etc.). It is also difficult to detect a smile in backlight.

After a smile is detected and captured, it takes time before the next recording may be performed.

“SMILE SHOT” does not work in the following cases:

- when menu is being displayed

- when remaining recording time or battery power is being displayed

- when “FACE SUB-WINDOW” is set

- when “ANIMATION EFFECT” is set

“Recording while Displaying a Magnified View of a Selected Face (FACE SUB-WINDOW)” (A p. 63) “Creating Animation Effects (ANIMATION EFFECT)” (A p. 54)

Caution :

When “TOUCH PRIORITY AE/AF” is set to “AREA SELECT” or “COLOR TRACKING”, “SMILE SHOT” does not work.

If appropriate results cannot be obtained, record with “SMILE SHOT” set to “OFF”.

Recording

Recording while Displaying a Magnified View of a Selected Face (FACE SUB-WINDOW)

You can record while viewing both the overall image of the scene and magnified image of a subject’s expression. Frames appear around the faces that can be magnified. Tap a frame to track and magnify the face in a subwindow.

Open the LCD monitor and select the video mode.

The video mode icon appears.

Tap “MENU”.

Tap “FACE SUB-WINDOW”.

Tap on the frame of the face to magnify.

When the face within a frame is tapped, it is displayed in a subwindow. The display position of the sub-window is set automatically according to the position of the tapped face.

The frame of the tapped face changes to blue.

When the tapped face disappears from the screen, the sub-window disappears too. When the face reappears on the screen., the subwindow is displayed again automatically.

To exit “FACE SUB-WINDOW”, tap “L”.

Caution :

Take note of the following when “FACE SUB-WINDOW” is set.

- Functions such as digital zoom, zoom operation on the touch screen, simultaneous still image recording, “TIME-LAPSE RECORDING”, “HIGH SPEED RECORDING”, and “AUTO REC” are not available.

- Settings such as “FOCUS” and “BRIGHTNESS ADJUST” are set to “AUTO” automatically.

- If “TOUCH PRIORITY AE/AF” is set to FACE TRACKING, appropriate focus and brightness will be adjusted for the person displayed in the subwindow.

- “ANIMATION EFFECT” is not available.

The sub-window display will also be recorded.

Memo :

When a face is magnified and displayed in the sub-window, only the name of the person will be displayed.

The face sub-window mode is canceled when the power is turned off.

Frames do not appear around the faces in the face sub-window mode as easily as in the other modes. They appear around the faces that can be magnified only. The frames do not appear in the following cases:

- when the face of the subject is extremely small

- when the surrounding is too dark or too bright

- when the face appears horizontal or slanted

- when the face appears bigger than the sub-window (such as when it is zoomed in)

- when a part of the face is hidden

“Registering Human Face Personal Authentication Information” (A p. 56)

Recording

Reducing Camera Shake

When the image stabilizer is set, camera shake during recording can be effectively reduced.

Open the LCD monitor and select the video mode.

Tap “MENU”.

Tap “DIS” (image stabilizer).

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap the desired setting.

Setting

Details

b OFF

Deactivates image stabilizer.

a ON

Reduces camera shake under normal shooting conditions.

c ON (AIS)

Reduces camera shake more effectively when shooting bright scenes on the wide angle end. Only on the wide angle end (approx. 5x).

Setting the Enhanced AIS Mode

The area of correction in the enhanced AIS mode is greater than that in the AIS mode. Camera shake can be reduced more effectively even when recording is performed by zooming from wide angle to telephoto, or moving together with the subject. Set the enhanced AIS mode as follows.

A Assign “DIS” to the USER button. “Setting the USER Button” (A p. 71)

B Press and hold the USER button.

The Enhanced AIS mode is set and s is displayed. The mode is canceled when the button is released. To perform recording in the Enhanced AIS mode, press the record button while holding the USER button. The mode is canceled when recording is stopped.

Memo :

It is recommended to set the image stabilizer to “OFF” when shooting a subject of little movement with the unit on a tripod.

Complete stabilization may not be possible if camera shake is excessive.

This setting is effective for video recording only.

Recording

Taking Videos in iTunes Format

By recording with the EXPORT setting turned on, you can transfer the videos to Apple's software iTunes when this unit is connected to a PC. “LIB.” is displayed when recording videos in iTunes format. Use the provided software to transfer the videos. “Installing the Provided Software (Built-in)” (A p. 114)

Memo :

For more information on iTunes and iPod, please visit the following website.

http://www.apple.com/itunes/

Select video mode.

The video mode icon appears.

Tap “MENU”.

Tap “EXPORT SHOOTING”.

Tap “ON”.

When set to “ON”, a “LIB.” mark appears on the screen.

To cancel this setting, set to “OFF”.

Start recording.

Press again to stop.

Memo :

“EXPORT SHOOTING” is not available when “TIME-LAPSE RECORDING” is set.

Transferring Recorded Videos to iPod

You can export videos to iTunes using the provided software Everio MediaBrowser 3 BE. Install the software on your PC and connect this unit to the PC.

For details on how to use the software, refer to the help file.

For details on transferring files to iPod, refer to the help file of iTunes.

“Installing the Provided Software (Built-in)” (A p. 114) “Backing Up All Files” (A p. 115)

Trouble with Exporting Files to iTunes

Refer to “Q&A”, “Latest Information”, “Download Information”, etc. in “Click for Latest Product Info” in the help file of the provided software Everio MediaBrowser 3 BE.

Recording

Slow-motion (High-speed) Recording

You can record videos in slow-motion by increasing the recording speed to emphasize the movements, and play back the slow-motion video smoothly. This is a handy function for checking movements, such as golf swings.

Recording Speed 300 fps

Image Size 720×480

Maximum Recording Time 144 m

Maximum Playback Time 12 h

Image Size when Connected to Monitor

1,920×1,080

Open the LCD monitor and select the video mode.

The video mode icon appears.

Tap “MENU”.

Tap “HIGH SPEED RECORDING”.

Tap “ON”.

When “ON” is tapped, 300 frames can be recorded in 1 second.

To cancel high-speed recording, tap “OFF”.

Start recording.

Press the START/STOP button again to stop recording.

Settings of high-speed recording are not saved when the power is turned off.

Memo :

Images may appear grainier than other videos. The image displayed on the LCD monitor during recording also may also appear grainier.

Audio sound is not recorded together with the video.

When high-speed recording is enabled, only the optical zoom can be used. However, zooming cannot be performed after recording starts.

The playback time will be 5 times of the actual recorded time. (Example: If the recorded time is 1 minute, the playback time will be 5 minutes.)

During high-speed recording, “TOUCH PRIORITY AE/AF” is set to “OFF” . In addition, as “DIS” is set to “OFF”, it is recommended that a tripod be used, and recording be performed in a bright location with the subject magnified as much as possible.

“Tripod Mounting” (A p. 22)

Recording

Recording at Intervals (TIME-LAPSE RECORDING)

Enables the changes of a scene that occur slowly over a long period to be shown within a short time by taking frames of it at a certain interval. This is useful for making observations such as the opening of a flower bud.

Open the LCD monitor and select the video mode.

The video mode icon appears.

Tap “MENU”.

Tap “TIME-LAPSE RECORDING”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap to select a recording interval (1 to 80 seconds).

The greater the number of seconds, the longer the recording interval.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Start recording.

A frame is taken at intervals of the selected period.

When the recording interval is set to “20SEC INTERVAL” or higher, this unit switches to the power-saving mode between recordings. At the next point to record, the power-saving mode will be turned off and recording will start automatically.

Press the START/STOP button again to stop recording.

Recording

Indications During Time-Lapse Recording

Display Description

Video Quality Displays the icon of the video quality that is set.

Speed Indicator Displays the recording interval that is set.

Recorded Time Displays the actual recorded time of the video.

Recorded time increases in units of frames.

Actual Elapsed Time

Displays the actual elapsed time after recording starts.

Remaining Recording Time

Remaining time left to record with the currently selected video quality.

Time-Lapse Setting

The greater the number of seconds, the longer the recording interval.

Setting Details

OFF Deactivates the function.

1SEC INTERVAL Takes a frame at 1-second intervals.

Recorded videos will be played back at 30 times speed.

2SEC INTERVAL Takes a frame at 2-second intervals.

Recorded videos will be played back at 60 times speed.

5SEC INTERVAL Takes a frame at 5-second intervals.

Recorded videos will be played back at 150 times speed.

10SEC INTERVAL Takes a frame at 10-second intervals.

Recorded videos will be played back at 300 times speed.

20SEC INTERVAL Takes a frame at 20-second intervals.

Recorded videos will be played back at 600 times speed.

40SEC INTERVAL Takes a frame at 40-second intervals.

Recorded videos will be played back at 1 200 times speed.

80SEC INTERVAL Takes a frame at 80-second intervals.

Recorded videos will be played back at 2 400 times speed.

Caution :

Audio cannot be recorded during time-lapse recording.

Zooming, simultaneous still image recording, and image stabilizer are not available in time-lapse recording.

When recording is stopped with the recorded time less than “0:00:00:17” , the video will not be saved.

Seamless recording is disabled in time-lapse recording.

Memo :

Settings of time-lapse recording are not saved when the power is turned off.

Recording stops automatically 99 hours after it is started.

Make use of a tripod and AC adapter for time-lapse recordings with long intervals. It is also recommended to fix the focus and white balance manually.

“Tripod Mounting” (A p. 22) “Adjusting Focus Manually” (A p. 49) “Setting White Balance” (A p. 52)

Recording

Recording Automatically by Sensing Movements (AUTO REC)

This function enables the unit to record automatically by sensing the changes in subject’s movement (brightness) within the red frame displayed on the LCD monitor. (AUTO REC) It can be set for both video and still image modes.

Select video or still image mode.

The video or still image mode icon appears.

Compose the picture according to the subject.

Adjust the angle of view with the zoom, etc.

Tap “MENU”.

Tap “AUTO REC”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “ON”.

Recording starts automatically when the subject within the red frame moves.

A red frame appears 2 seconds after the menu display disappears.

For video recording, recording continues while there are still movements of the subject (changes in brightness) within the red frame. When there are no more movements of the subject (changes in brightness) within the red frame, recording will stop in 5 seconds.

To stop video recording manually, press the START/STOP button. However, as the “AUTO REC” setting remains at “ON” even after the video recording is stopped, recording starts again when movements of the subject (changes in brightness) are detected within the red frame. To cancel “AUTO REC”, set it to “OFF”.

Caution :

The only manual recording setting available is “TELE MACRO”. The rest are all set to “AUTO”.

Digital zoom, image stabilizer, self-timer, and continuous shooting are not available after “AUTO REC” is set.

“AUTO REC” cannot be used together with “TIME-LAPSE RECORDING” . When both are set, priority is given to “TIME-LAPSE RECORDING”.

“IMAGE SIZE” cannot be changed after “AUTO REC” is selected. Set it before selecting “AUTO REC”.

The auto power off and power-saving modes are not available after “AUTO REC” is set.

Memo :

Recording stops when there are no changes for 5 seconds during video recording.

Settings of “AUTO REC” are not saved when the power is turned off.

Recording may not start when the movements of the subject within the red frame are too fast or the changes in brightness are too small.

Recording may start due to changes in brightness even if there is no movement within the red frame.

While zooming, recording cannot be started.

Recording

Taking Group Shots (Self-timer)

The 10-second self-timer and Face Detection self-timer are convenient functions for taking group photos. The 2-second self-timer is useful for preventing camera shake caused by pressing the shutter button.

Memo :

When shooting a photo using the self-timer function, use of a tripod is recommended. “Tripod Mounting” (A p. 22)

Using the 2-/10-second Self-timer

Select still image mode.

The still image mode icon appears.

Tap “MENU”.

Tap “SELF-TIMER”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “2SEC” or “10SEC”.

Set the focus on the subject.

When focused, the focus icon lights up in green.

Take a still image.

A timer appears and countdown to shooting starts.

To stop the self-timer, press the SNAPSHOT button again.

Using the Face Detection Self-timer

Pressing the SNAPSHOT button starts face detection, and shooting is performed three seconds after another person enters the frame. This function is useful when you want to include the photographer in the group photo.

Select still image mode.

The still image mode icon appears.

Tap “MENU”.

Tap “SELF-TIMER”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Tap “FACE DETECTION”.

Recording

After making sure that everyone is facing the camera, press the SNAPSHOT button.

Frames appear around the faces of the subjects.

Pressing the SNAPSHOT button again starts the 10-second selftimer.

The photographer enters the frame.

The shutter is released three seconds after the photographer enters the frame.

To stop the self-timer, press the SNAPSHOT button again.

Memo :

The “FACE DETECTION” function may fail to detect faces depending on the shooting environment.

Setting the USER Button

By assigning one of manual adjustment functions that you frequently use to the USER button, you can access the function quickly.

Assigning a Function to the USER Button

Select video or still image mode.

The video or still image mode icon appears.

Tap “MENU”.

Tap “USER BUTTON SETTING”.

Tap ∧ or ∨ to move upward or downward for more selection.

Tap L to exit the menu.

Tap J to return to the previous screen.

Select the desired function.

You can select one of the following functions.

- NIGHTALIVE

- TOUCH PRIORITY AE/AF (for GZ-HM960)

- FOCUS

- BRIGHTNESS ADJUST

- SHUTTER SPEED

- APERTURE PRIORITY

- BACKLIGHT COMP.

- WHITE BALANCE

- FOCUS ASSIST

- FLASH (still image mode)

- SHUTTER MODE

- CONT. SHOOTING SPEED

- DIS (video mode)

- SELF-TIMER (still image mode)

Recording

Making Adjustments with the USER Button

Operate as follows.

Functions with settings that change (or turn ON/OFF) with every press (NIGHTALIVE, BACKLIGHT COMP., DIS, SELF-TIMER, SHUTTER MODE, CONT. SHOOTING SPEED, FOCUS ASSIST, FLASH)

Press the USER button to change the setting.

Functions with manual adjustments (FOCUS, BRIGHTNESS ADJUST, SHUTTER SPEED, APERTURE PRIORITY)

Press the USER button to switch between automatic and manual. For details on manual adjustments, refer to “Manual Recording” (A p. 47) . “Manual Recording” (A p. 47)

Functions with a selection menu (TOUCH PRIORITY AE/AF, WHITE BALANCE)

1) Press the USER button.

2) Tap the desired function to set.

Memo :

The USER button is invalid when the menu is displayed.

Remaining Recording Time/Battery Power

You can check the remaining video recording time on the built-in memory and SD card as well as the remaining battery power.

Open the LCD monitor and select the video or still image mode.

The video or still image mode icon appears.

Press the INFO button.

If in the still image mode, go directly to step 4.

Display the remaining recording time.

The remaining recording time is displayed only in the video recording mode.

Press the INFO button to check the remaining recording time of each recording media.

To display the remaining battery power, tap l.

Tap J to return to the recording mode.

To exit the display, tap L.

Display the remaining battery power.

For video recording, tap J to return to the remaining recording time display. For still image recording, tap to return to the recording mode.

To exit the display, press the INFO button or tap L.

Remaining battery power will not be displayed when the AC adapter is connected.

Memo :

You can change to the desired video quality by tapping on it from the remaining recording time display.

Recording

Approximate Video Recording Time

Quality Built-in Memory SDHC/SDXC Card

16 GB 4 GB 8 GB 16 GB 32 GB 48 GB 64 GB

UXP 1 h 20 m 20 m 40 m 1 h 20 m 2 h 50 m 4 h 20 m 5 h 50 m

XP 2 h 30 m 1 h 2 h 4 h 10 m 6 h 10 m 8 h 20 m

SP 2 h 50 m 40 m 1 h 20 m 2 h 50 m 5 h 50 m 8 h 40 m 11 h 50 m

EP 7 h 1 h 40 m 3 h 40 m 7 h 10 m 14 h 50 m 21 h 50 m 29 h 50 m

The actual recording time may shorten depending on the shooting environment.

Approximate Number of Still Images (Unit: Number of Shots)

Image Size Built-in Memory SDHC Card

16 GB 4 GB 8 GB 16 GB 32 GB

3,968×2,976 (4:3)

2,200 500 1,100 2,300 4,700

2,656×1,992 (4:3)

4,900 1,200 2,600 5,200 9,999

2,304×1,728 (4:3)

6,500 1,700 3,400 6,900 9,999

1,600×1,200 (4:3)

9,999 3,500 7,100 9,999 9,999

640×480 (4:3)

9,999 9,999 9,999 9,999 9,999

1,920×1,080 (16:9)

9,999 3,200 6,700 9,999 9,999

Approximate Recording Time (Using Battery)

3D Display on LCD Monitor (for GZ-HM960)

Battery Pack Actual Recording Time Continuous Recording Time

BN-VG114U (Supplied)

35 m 1 h

BN-VG121U 50 m 1 h 30 m

BN-VG138U 1 h 30 m 2 h 45 m

2D Display on LCD Monitor (for GZ-HM960)

Battery Pack Actual Recording Time Continuous Recording Time

BN-VG114U (Supplied)

40 m 1 h 10 m

BN-VG121U 1 h 1 h 45 m

BN-VG138U 1 h 40 m 3 h 5 m

2D Display on LCD Monitor (for GZ-HM860)

Battery Pack Actual Recording Time Continuous Recording Time

BN-VG114U (Supplied)

40 m 1 h 15 m

BN-VG121U 1 h 5 m 1 h 55 m

BN-VG138U 1 h 55 m 3 h 25 m

The above are values when “LIGHT” is set to “OFF” and “MONITOR BRIGHTNESS” is set to “3” (standard).

The actual recording time may be shorter if zooming is used or if recording is stopped repeatedly. (It is recommended to prepare battery packs ready for three times the expected recording time.)

Recording

Playing Back Videos

You can select and play back the recorded videos from an index screen (thumbnail display).

Select video mode.

Tap q to select the playback mode.

Tap on the file to start playback.

Tap I/J to select the media for playback.

Tap e to pause.

Tap u to return to the index screen.

Operation Buttons for Video Playback

During Index Screen Display

Display Description

Date Moves to the previous/next date

< Displays the previous index screen (thumbnail

display)

You can perform the same operation with the zoom lever.

> Displays the next index screen (thumbnail

display)

You can perform the same operation with the zoom lever.

Thumbnail (File) Tap on thumbnail - Starts playback

Drag to right - Scrolls to the right to show the previous index screen (thumbnail display) Drag to left - Scrolls to the left to show the next index screen (thumbnail display)

Recording/ Playback Mode

Switches between recording and playback modes.

Displays the index screen (thumbnail display) to perform deletion

I/J

Switches between the index screen of the builtin memory and SD card

MENU Displays the menu screen

Playback

During Video Playback

Display Description

Timeline Bar Tap on a random position - Moves to the

tapped position Drag playback point to the left or right - Starts playback from the new position

Pointer Displays the current estimated playback

position within the scene

Returns to the beginning of the scene

Reverse search

Reverse slow-motion / Press and hold to start reverse slow playback

d / e

Playback/pause

Forward search

Forward slow-motion / Press and hold to start slow playback

Advances to the next video

Recording/ Playback Mode

Switches between recording and playback modes.

Stop (returns to index screen)

Displays the index screen (thumbnail display) to perform deletion

Volume adjustment

MENU Displays the menu screen

Memo :

Tap or drag on the operation area of the touch screen.

Operations buttons on the touch screen disappear if the unit is not operated for about 5 seconds. Tap on the screen to display the operation buttons again.

You can search for a specific file by the recording date.

“Date Search” (A p. 79)

Caution :

Make a backup of important recorded data. It is recommended to copy your important recorded data to a DVD or other recording media for storage.

Adjusting the Volume of Videos

You can tap on the volume adjustment button to control the volume.

Tap U.

Tap “+” or “-”.

Volume can also be adjusted using the zoom lever during playback.

Tap L to exit volume adjustment.

Volume adjustment is disabled when an AV cable (audio/video) or HDMI cable is connected.

Checking the Recording Date and Other Information

Pause the playback and press the INFO button.

You can display the recording date and duration of the selected file.

Playback

Playing Back 3D Images (for GZ-HM960)

Switch to the 3D mode by pressing the 3D button such that the button lights up.

The mode changes between 3D and 2D with every press of the 3D button. When the 3D mode is activated, the button lights up.

Caution :

To play back 3D images, refer also to “Precautions on Playing Back 3D Images”.

“Precautions on Playing Back 3D Images (for GZ-HM960)” (A p. 12)

Some subjects may appear unnatural when played back in 3D mode. Sometimes, the 3D effect may not even be seen. In this case, it is recommended to play back the video in 2D mode.

Memo :

3D images are supported by the LCD monitor of this unit. You can play back 3D images on the LCD monitor. If you are using a 3D compatible TV, you can also play back 3D images by connecting with an HDMI cable.

“Playing Back 3D Images (for GZ-HM960)” (A p. 80)

When recording in 3D mode, the image is recorded in 2D even though the display on the LCD monitor is 3D.

When 3D images are played back on a 3D compatible TV, the display on the LCD monitor is in 2D.

When this unit is connected to a 3D compatible TV via an HDMI cable and set to the recording mode while in 3D mode, 3D images will appear on the TV.

The 3D effect of 3D images may appear either too strong or too weak. In these cases, you can correct the 3D effect by adjusting the parallax (3D LEVEL ADJUST).

“3D LEVEL ADJUST (for GZ-HM960)” (A p. 148)

Fatigue or discomfort may be experienced if you view 3D images for a long period of time. When viewing 3D images on this unit, a message will be displayed every 30 minutes. To turn off the message display, set “3D DISPLAY WARNING” to “OFF”.

“3D DISPLAY WARNING (for GZ-HM960)” (A p. 150)

Playing a Video with Defective Management Information

The management information of a video may be damaged if recording is not performed correctly, such as turning off the power in the middle of recording. You can perform the following operations to play back the videos with defective management information.

Select video mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “PLAYBACK OTHER FILE”.

Tap on the file to start playback.

“Playing Back Videos” (A p. 74)

Memo :

An MTS file is created in the EXTMOV folder when management information is corrupted.

Depending on the condition of the damaged file, playback might fail or may not run smoothly.

Playback

Playing Back Still Images

You can select and play back the recorded still images from an index screen (thumbnail display).

Select still image mode.

Tap q to select the playback mode.

Tap on the file to start playback.

Tap I/J to select the media for playback.

Tap u to return to the index screen.

The W button on the index screen is only displayed during still image playback. Still images that are recorded continuously within 2 seconds or with the continuous shooting mode will be grouped together and displayed with a green frame on a separate index screen. The index screen changes between the normal index screen and

group index screen with every tap of the W button.

Operation Buttons for Still Image Playback

During Index Screen Display

Still images that are recorded continuously within 2 seconds or with the continuous shooting mode will be grouped together. Only the first recorded file is shown and the group is displayed with a green frame.

Display Description

Date Moves to the previous/next date

< Displays the previous index screen (thumbnail

display)

You can perform the same operation with the zoom lever.

> Displays the next index screen (thumbnail

display)

You can perform the same operation with the zoom lever.

Thumbnail (File) Tap on thumbnail - Starts playback

Drag to right - Scrolls to the right to show the previous index screen (thumbnail display) Drag to left - Scrolls to the left to show the next index screen (thumbnail display)

Recording/ Playback Mode

Switches between recording and playback modes.

Still images that are recorded continuously within 2 seconds or with the continuous shooting mode will be grouped together and displayed with a green frame on a separate index screen. The index screen changes between the normal index screen and group index screen with every tap of the button.

Displays the index screen (thumbnail display) to perform deletion

I/J

Switches between the index screen of the builtin memory and SD card

MENU Displays the menu screen

Recording Date Recording date (only displayed on the first file

of each date)

Playback

During Still Image Playback

Display Description

Continuous playback of grouped files (such as still images captured by continuous shooting).

Rotates to the left (rotates by -90° with each tap)

Rotates to the right (rotates by 90° with each tap)

Returns to the previous still image

Reverse playback during slideshow

d / e

Starts/pauses slideshow “Slideshow Playback” (A p. 78)

Normal playback during slideshow

Advances to the next still image

Recording/ Playback Mode

Switches between recording and playback modes.

Returns to index screen

Displays the index screen (thumbnail display) to perform deletion

MENU Displays the menu screen

Memo :

Tap or drag on the operation area of the touch screen.

Operations buttons on the touch screen disappear if the unit is not operated for about 5 seconds. Tap on the screen to display the operation buttons again.

You can rotate a still image 90° to the right or left during playback. Rotation applies to the on-screen display only.

You can search for a specific file by the recording date. This is useful when searching from a large number of files.

“Date Search” (A p. 79)

Caution :

Playing Back 3D Images (for GZ-HM960)

Switch to the 3D mode by pressing the 3D button such that the button lights up.

The mode changes between 3D and 2D with every press of the 3D button. When the 3D mode is activated, the button lights up.

Caution :

To play back 3D images, refer also to “Precautions on Playing Back 3D Images”.

“Precautions on Playing Back 3D Images (for GZ-HM960)” (A p. 12)

Some subjects may appear unnatural when played back in 3D mode. Sometimes, the 3D effect may not even be seen. In this case, it is recommended to play back the video in 2D mode.

Memo :

“Playing Back 3D Images (for GZ-HM960)” (A p. 80)

When recording in 3D mode, the image is recorded in 2D even though the display on the LCD monitor is 3D.

When 3D images are played back on a 3D compatible TV, the display on the LCD monitor is in 2D.

When this unit is connected to a 3D compatible TV via an HDMI cable and set to the recording mode while in 3D mode, 3D images will appear on the TV.

The 3D effect of 3D images may appear either too strong or too weak. In these cases, you can correct the 3D effect by adjusting the parallax (3D LEVEL ADJUST).

“3D LEVEL ADJUST (for GZ-HM960)” (A p. 148)

“3D DISPLAY WARNING (for GZ-HM960)” (A p. 150)

Slideshow Playback

Still images can be played back in a slideshow. Tap I during still image playback to start the slideshow.

“Operation Buttons for Still Image Playback” (A p. 77)

Memo :

Effects can be added to the transitions in slideshow playback. (for GZHM860)

“SLIDE SHOW EFFECTS (for GZ-HM860)” (A p. 141)

Playback

Searching for a Specific Video/Still Image

When there is a large number of recorded videos and still images, it is difficult to look for the desired file from the index screen. Use the search function to find the file you want. “To search by recording dates” (A p. 79)

Date Search

You can search and play videos or still images according to recording dates.

Tap “MENU”.

Tap I/J to select the media for playback.

Searching can be performed in both the video and still image modes. *The image shows the video mode.

Tap “SEARCH DATE”.

Tap a recording date, then tap “NEXT”.

Tap again to cancel the selected date.

Tap on the file to start playback.

You can select videos in the video mode and still images in the still image mode.

Only the files recorded on the selected date are displayed.

Tap L to stop searching and return to the index screen (thumbnail display).

Deleting Files of a Selected Date

：

Tap A on the index screen (thumbnail display) to delete unwanted files. “Deleting Unwanted Files” (A p. 85)

Connecting to and Viewing on TV

You can connect this unit to a TV for playback. Select the most suitable way of connecting to the TV based on the image to view (3D/2D image).

Refer also to the instruction manual of the TV in use.

“Playing Back 3D Images (for GZ-HM960)” (A p. 80) “Playing Back 2D Images (for GZ-HM960/GZ-HM860)” (A p. 82)

Unnatural Displays on TV

Trouble Action

Images do not appear on the TV properly.

Disconnect the cable and connect again.

Turn off and on this unit again.

Images may not appear properly when the remaining battery power is low. Use an AC adapter.

When connected via the component connector, check if the setting of “COMPONENT OUTPUT” in the connection settings menu suits the connected TV. (Set to “1080i” by default)

“COMPONENT OUTPUT” (A p. 151)

Images are projected vertically on the TV.

Set “VIDEO OUTPUT” in the “COMMON” menu to “4:3”.

“VIDEO OUTPUT” (A p. 151)

Images are projected horizontally on the TV.

Adjust the TV's screen accordingly.

The color of images looks strange.

If the video was recorded with “x.v.Color” set to “ON”, set the x.v.Color setting of the TV to on.

“x.v.Color” (A p. 131)

Adjust the TV's screen accordingly.

3D images are not displayed in 3D. (for GZ-HM960)

Set “HDMI OUTPUT” in the “COMMON” menu to “CERTAIN TV TYPES”.

“HDMI OUTPUT” (A p. 152)

Double images are seen. (for GZ-HM960)

Double images of the subject may be seen depending on the scene. It may also become difficult to see the images after adjusting the parallax manually or changing the video quality on TV. In this case, it is recommended to play back the video in 2D mode. (For details, refer to the instruction manual of the TV.)

HDMI-CEC functions do not work properly, and the TV does not work in conjunction with this unit.

TVs may operate differently depending on the specifications, even if they are HDMI-CEC compliant. Therefore, the HDMI-CEC functions of this unit cannot be guaranteed to operate in combination with all the TVs. In such cases, set “HDMI CONTROL” to “OFF”.

“HDMI CONTROL” (A p. 153)

The language on the display changed.

It may occur when you connect this unit to a TV with different language setting using an HDMI mini cable.

Caution :

Do not remove the recording medium or perform any other operation (such as turning off the power) while accessing files. Also, be sure to use the provided AC adapter, as the data on the recording medium may be corrupted if the battery becomes exhausted during operation. If the data on the recording medium becomes corrupted, format the recording medium to use the medium again.

Memo :

Fatigue or discomfort may be experienced if you view 3D images for a long period of time. When viewing 3D images on this unit, a message will be

Playback

displayed every 30 minutes. To turn off the message display, set “3D DISPLAY WARNING” to “OFF”. (for GZ-HM960)

“3D DISPLAY WARNING (for GZ-HM960)” (A p. 150)

If the left and right images of an object close to the camera do not appear to be in alignment, or the 3D effect of a distant object is weak, you can change the way they appear to the eye by adjusting the parallax. (for GZHM960)

“3D LEVEL ADJUST (for GZ-HM960)” (A p. 148)

Playing Back 3D Images (for GZ-HM960)

If you are using a 3D compatible TV, you can play back 3D images by connecting to the HDMI connector.

Use a High Speed HDMI mini cable as the HDMI mini cable when not using the provided one.

Refer also to the instruction manual of the TV in use.

Connect to a TV.

Turn off the camcorder by pressing the M button for about 2 seconds.

Connect the AC adapter to this unit.

Press the external input button on the TV to switch to the input from this unit via the connected connector.

Play back a file.

“Playing Back Videos” (A p. 74) “Playing Back Still Images” (A p. 77)

Playback

Caution :

To play back 3D images, refer also to “Precautions on Playing Back 3D Images”.

“Precautions on Playing Back 3D Images (for GZ-HM960)” (A p. 12)

If you experience fatigue or discomfort while viewing 3D images, it is recommended to play back in 2D mode.

“HDMI OUTPUT” (A p. 152)

Memo :

When connected to the TV via the provided HDMI mini cable, images and sounds may not be output properly depending on the TV connected. In such cases, perform the following operations.

1) Disconnect the HDMI mini cable and connect it again.

2) Turn off and on this unit again.

Do not disconnect the HDMI cable when “SEAMLESS REC CTRL”, “COPY”, “MOVE”, or “UPLOAD SETTINGS” are in use. The process may be aborted.

If 3D images cannot be seen properly, change the setting in “HDMI OUTPUT”. Refer also to the instruction manual of the TV in use.

“HDMI OUTPUT” (A p. 152)

When connected to a 3D compatible TV in the recording mode, images are output in “SIDE-BY-SIDE OUTPUT” regardless of the “HDMI OUTPUT” setting.

The displayed 3D images may vary depending on the size of the TV connected.

For questions about the TV or method of connection, contact your TV's manufacturer.

Operating in Conjunction with TV via HDMI

Connecting this unit to an HDMI-CEC-enabled TV using the HDMI cable allows linked operations with the TV to be performed.

HDMI-CEC (Consumer Electronics Control) is an industry standard that enables interoperability between HDMI-CEC compliant devices that are connected via HDMI cables.

Memo :

Not all HDMI-control devices comply with the HDMI-CEC standard. The HDMI control function of this unit will not work when connected to these devices.

This unit is not guaranteed to operate with all HDMI-CEC-enabled devices.

Depending on the specifications of each HDMI-CEC-enabled device, some functions may not work with this unit. (For details, refer to the instruction manual of your TV.)

Unintended operations may occur with some connected devices. In these cases, set “HDMI CONTROL” to “OFF”.

“HDMI CONTROL” (A p. 153)

Preparations

Connect an HDMI cable between this unit and the TV.

“Playing Back 3D Images (for GZ-HM960)” (A p. 80) “Connecting via the HDMI Mini Connector” (A p. 82)

Turn on the TV and set the HDMI-CEC related setting to “ON”. (For details, refer to the instruction manual of the TV.)

Turn on this unit and set “HDMI CONTROL” in the “COMMON” menu to “ON”.

“HDMI CONTROL” (A p. 153)

Operation Method 1

Turn on this unit.

Select the playback mode.

Connect the HDMI cable.

TV turns on automatically and switches to HDMI input mode when this unit is turned on.

Operation Method 2

Turn off the TV.

This unit turns off automatically.

Memo :

Depending on the TV connected, the display language of this unit will automatically switch to the language that is selected for the TV when this unit is turned on. (This is applicable only if this unit supports the language selected for the TV.) To use this unit with a language that differs from the display language of the TV, set “HDMI CONTROL” to “OFF”.

The display language of the TV will not switch automatically, even if the display language of this unit is changed.

These functions may not work correctly when devices such as amplifier and selector are connected. Set “HDMI CONTROL” to “OFF”.

If HDMI-CEC does not work properly, turn off and on this unit again.

Playback

Playing Back 2D Images (for GZ-HM960/GZ-HM860)

The image quality on TV varies with the type of TV and the connecting cable. Select the connector that best suits your TV.

Refer also to the instruction manual of the TV in use.

“Connecting via the HDMI Mini Connector” (A p. 82) “Connecting via the Component Connector” (A p. 83) “Connecting via the AV Connector” (A p. 84)

Connecting via the HDMI Mini Connector

If you are using an HDTV, you can play back in HD quality by connecting to the HDMI connector.

Use a High Speed HDMI mini cable as the HDMI mini cable when not using the provided one.

Refer also to the instruction manual of the TV in use.

Connect to a TV.

Turn off the camcorder by pressing the M button for about 2 seconds.

Connect the AC adapter to this unit.

* The AC adapter shown in the illustration is AC-V11U.

Press the external input button on the TV to switch to the input from this unit via the connected connector.

Play back a file.

“Playing Back Videos” (A p. 74) “Playing Back Still Images” (A p. 77)

Memo :

Change the settings in “HDMI OUTPUT” according to the connection.

“HDMI OUTPUT” (A p. 152)

When connected to the TV via the HDMI mini cable, images and sounds may not be output properly depending on the TV connected. In such cases, perform the following operations.

1) Disconnect the HDMI mini cable and connect it again.

2) Turn off and on this unit again.

For questions about the TV or method of connection, contact your TV's manufacturer.

Playback

Operating in Conjunction with TV via HDMI

Connecting this unit to an HDMI-CEC-enabled TV using the HDMI cable allows linked operations with the TV to be performed.

HDMI-CEC (Consumer Electronics Control) is an industry standard that enables interoperability between HDMI-CEC compliant devices that are connected via HDMI cables.

Memo :

Not all HDMI-control devices comply with the HDMI-CEC standard. The HDMI control function of this unit will not work when connected to these devices.

This unit is not guaranteed to operate with all HDMI-CEC-enabled devices.

Depending on the specifications of each HDMI-CEC-enabled device, some functions may not work with this unit. (For details, refer to the instruction manual of your TV.)

Unintended operations may occur with some connected devices. In these cases, set “HDMI CONTROL” to “OFF”.

“HDMI CONTROL” (A p. 153)

Preparations

Connect an HDMI cable between this unit and the TV.

“Playing Back 3D Images (for GZ-HM960)” (A p. 80) “Connecting via the HDMI Mini Connector” (A p. 82)

Turn on the TV and set the HDMI-CEC related setting to “ON”. (For details, refer to the instruction manual of the TV.)

Turn on this unit and set “HDMI CONTROL” in the “COMMON” menu to “ON”.

“HDMI CONTROL” (A p. 153)

Operation Method 1

Turn on this unit.

Select the playback mode.

Connect the HDMI cable.

TV turns on automatically and switches to HDMI input mode when this unit is turned on.

Operation Method 2

Turn off the TV.

This unit turns off automatically.

Memo :

The display language of the TV will not switch automatically, even if the display language of this unit is changed.

These functions may not work correctly when devices such as amplifier and selector are connected. Set “HDMI CONTROL” to “OFF”.

If HDMI-CEC does not work properly, turn off and on this unit again.

Connecting via the Component Connector

You can connect this unit to the component connector of a TV to play back videos in analog high-definition quality.

Refer also to the instruction manual of the TV in use.

Connect to a TV.

Turn off the camcorder by pressing the M button for about 2 seconds.

Connect the AC adapter to this unit.

* The AC adapter shown in the illustration is AC-V11U.

Press the external input button on the TV to switch to the input from this unit via the connected connector.

Play back a file.

“Playing Back Videos” (A p. 74) “Playing Back Still Images” (A p. 77)

Memo :

When playing back in HD quality, set “COMPONENT OUTPUT” in the common menu to “1080i”.

The video is output in standard quality if the setting remains at “480i”.

“COMPONENT OUTPUT” (A p. 151)

For questions about the TV or method of connection, contact your TV's manufacturer.

Playback

Connecting via the AV Connector

By connecting the supplied AV cable to the AV connector, videos can be played back on a TV.

Refer also to the instruction manual of the TV in use.

Connect to a TV.

Turn off the camcorder by pressing the M button for about 2 seconds.

Connect the AC adapter to this unit.

* The AC adapter shown in the illustration is AC-V11U.

Press the external input button on the TV to switch to the input from this unit via the connected connector.

Play back a file.

“Playing Back Videos” (A p. 74) “Playing Back Still Images” (A p. 77)

Memo :

For questions about the TV or method of connection, contact your TV's manufacturer.

Playing Back a DVD or Blu-ray Disc Created on this Unit

BD/DVDs created using the backup function on this unit can be played back on TV using an optional DVD writer (DVDs only) with playback function (CUVD50U) or a normal BD/DVD player. DVDs can also be played back on this unit by connecting the optional DVD writer with playback function.

Playback Device DVD

(DVDVideo

format)

DVD

(AVCHD

format)

Blu-ray

Disc

DVD writer connected to this unit

P P

External Blu-ray drive connected to this unit

P P P

DVD player/ DVD recorder

P P*

Blu-ray player/ Blu-ray recorder

P P* P*

DVD writer with playback function (CU-VD50U)

P P

*Only for AVCHD compatible devices

Caution :

DVDs that are created in AVCHD format cannot be played back on DVD players with standard quality. You may not be able to remove the disc from the player.

Playback

Deleting Unwanted Files

Delete unwanted videos and still images when the space in the recording media is running out. The capacity of the recording media can be restored after deleting the files. “Deleting the Currently Displayed File” (A p. 85) “Deleting Selected Files” (A p. 85)

Memo :

Deleted files cannot be restored.

Files that are protected cannot be deleted. Release protection before deleting the file.

“Protecting Files” (A p. 86)

Be sure to back up important files on a computer.

“Backing Up All Files” (A p. 115)

Deleting the Currently Displayed File

Deletes the currently displayed file.

Caution :

Deleted files cannot be restored.

Tap A.

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap “YES”.

Tap h / g to select the previous or next file.

When no file remains, the screen returns to the index screen.

Deleting Selected Files

Deletes the selected files.

Caution :

Deleted files cannot be restored.

Select video or still image mode.

Tap q to select the playback mode.

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap A.

Tap on the files to delete.

P appears on the selected files. To remove P from a file, tap on the file again.

Tap “SEL ALL” to select all files.

Tap “REL ALL” to release all selections.

Tap on the files to delete, then tap “J”.

Tap “SET”.

Tap “EXECUTE” to confirm the deletion.

Editing

After deleting is complete, tap “OK”.

To cancel the deletion, tap “QUIT”.

Protecting Files

Prevent important videos/still images from being deleted accidently by protecting them. “Protecting/Releasing Protection of the Currently Displayed File” (A p. 86) “Protecting/Releasing Protection of Selected Files” (A p. 86)

Caution :

When the recording media is formatted, even the protected files will be deleted.

Protecting/Releasing Protection of the Currently Displayed File

Protects or releases protection of the currently displayed file.

Tap “MENU”.

Tap “PROTECT/CANCEL”.

Tap “YES”.

Tap h / g to select the previous or next file.

After setting, tap “OK”.

Protecting/Releasing Protection of Selected Files

Protects or releases protection of the selected files.

Select video or still image mode.

Tap q to select the playback mode.

Editing

Tap “MENU”.

Tap “PROTECT/CANCEL”.

Tap on the files to protect or release protection of.

P appears on the selected files. To remove P from a file, tap on the file again.

I and P are displayed on the files that are already protected. To release protection of a file, tap on the file such that P is removed.

Tap “SEL ALL” to select all files.

Tap “REL ALL” to release all selections.

Tap on the files to protect or release protection of, then tap “J”.

When using an Eye-Fi card, if the transfer mode of Eye-Fi Helper is set to “Selective Share” or “Selective Transfer”, M will be displayed.

Tap “SET” to complete the setting.

Protect marks I appear on the selected files. Protect marks I disappear from the deselected files.

Editing

Capturing a Still Image in the Video during Playback

You can capture still images of the scenes you like in the recorded videos.

Select video mode.

Tap q to select the playback mode.

Tap on the desired video.

Tap pause e at the desired scene during playback.

After pausing the video, you can fine-tune the point to capture by tapping forward slow-motion k and reverse slow-motion l.

Capture a still image.

Memo :

Still images are captured with a size of 1920×1080.

Captured still images are stored in the media where the video is being played back from.

Combining Videos Recorded by Seamless Recording

Videos that are recorded on two separate media and with “SEAMLESS RECORDING” in the video recording menu enabled can be combined into a single video. “SEAMLESS RECORDING” (A p. 130)

Select video mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “SEAMLESS REC CTRL”.

Tap “COMBINE SCENES”.

This unit starts a search to detect seamless videos. Combining cannot be performed if no seamless videos are found.

Tap “YES”.

Editing

Tap the media to store to.

Tap “YES”.

Combining of the videos starts.

After videos are combined, tap “OK”.

Memo :

Seamless videos cannot be combined if there is not enough free space in the built-in memory or SD card. Check the amount of remaining free space before combining.

How to Enable Seamless Video Recording Again

To start seamless recording again after the previous session is complete, it is necessary to combine seamless videos, or delete the combination information of the seamless videos. To delete the combination information of seamless videos, select “DEL COMBINED SCENES” in step 5.

Capturing a Required Part in the Video (TRIMMING)

Select the required part of a video and save it as a new video file.

The original video remains in its existing location.

Select video mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “TRIMMING”.

Tap the video to edit.

Tap e to pause playback at the desired start point, then tap “A”.

When “A” is tapped, the start point is set.

After setting the start point, tap d to continue playback.

Editing

Tap e to pause playback at the desired end point, then tap “B”.

When “B” is tapped, the end point is set.

To reset the start or end point, tap “A” or “B” at the desired scene (position).

Tap “SET”.

When “SET” is tapped, the trimming area is confirmed.

Tap “YES”.

After copying, tap “OK”.

When copying finishes, the copied file is added to the index screen.

Memo :

The division point may deviate slightly from the selected scene.

Capturing Videos for Uploading to YouTube

Capture and copy a part of a recorded video (maximum 15 minutes) for uploading to YouTube, and save it as a YouTube video. When capturing videos for YouTube, the duration cannot be longer than 15 minutes.

Select video mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “UPLOAD SETTINGS”.

Tap the video to edit.

Tap “TRIM”.

When trimming is not necessary, tap “DO NOT TRIM”.

If the selected video is more than 15 minutes, trimming is necessary.

Editing

Tap e to pause playback at the desired start point, then tap “A”.

Tap e to pause playback at the desired end point, then tap “B”.

To reset the start or end point, tap “A” or “B” at the desired scene (position).

When capturing videos for YouTube, the duration cannot be longer than 15 minutes.

Tap “SET”.

Tap “YES”.

After copying, tap “OK”.

When copying finishes, the copied file is added to the index screen.

To exit upload settings, tap “STOP” on the upload settings screen.

Memo :

The division point may deviate slightly from the selected scene.

Uploading Videos to YouTube

You can upload your videos to YouTube using the provided software Everio MediaBrowser 3 (3 BE). Install the software on your PC and connect this unit to the PC.

For details on how to use the software, refer to the help file.

“Installing the Provided Software (Built-in)” (A p. 114) “Connecting this Unit to PC” (A p. 115)

Trouble with Uploading Videos

：

Check if you have created an account with YouTube. (You need a YouTube account to upload files to YouTube.)

Refer to “Q&A”, “Latest Information”, “Download Information”, etc. in “Click for Latest Product Info” in the help file of the provided software Everio MediaBrowser 3 (3 BE).

Preparing Videos to Transfer to iTunes

Set EXPORT attributes to the recorded videos by adding a “LIB.” mark. When EXPORT attributes are set, the videos can be registered to iTunes easily using the supplied software on a PC.

Select video mode.

Tap q to select the playback mode.

Tap “MENU”.

Tap “EXPORT SETTINGS”.

Editing

Tap the video to edit.

“LIB.” appears on the selected files. To remove “LIB.” from a file, tap on the file again.

To exit “EXPORT SETTINGS”, tap “DONE”.

Tap “CHECK” to check the selected video. Tap the video to check on the screen that appears after tapping “CHECK”. The beginning of the video (still image) is displayed. After setting the video, tap “LIB.”.

Tap “J” to return to the “EXPORT SETTINGS” index screen.

After selecting all the files, tap “YES”.

Memo :

You can take videos in iTunes format by setting “EXPORT SHOOTING” before recording.

“Taking Videos in iTunes Format” (A p. 65)

The format of recorded videos changes when they are transferred to a PC using the supplied software. Files that are stored on this unit will not be affected.

The “LIB.” mark does not appear on other index screens.

Transferring Converted Videos to iPod

You can export videos to iTunes using the provided software Everio MediaBrowser 3 BE. Install the software on your PC and connect this unit to the PC.

For details on how to use the software, refer to the help file.

For details on transferring files to iPod, refer to the help file of iTunes.

“Installing the Provided Software (Built-in)” (A p. 114) “Backing Up All Files” (A p. 115)

Trouble with Exporting Files to iTunes

：

Refer to “Q&A”, “Latest Information”, “Download Information”, etc. in “Click for Latest Product Info” in the help file of the provided software Everio MediaBrowser 3 BE.

Creating Discs with a DVD Writer

You can copy the recorded files to discs or play back the created discs using an optional DVD writer.

Compatible DVD Writers

Product Name Description

DVD Writer

CU-VD3U

Enables the images recorded on this unit to be copied to a DVD without using a PC.

DVD Writer

CU-VD50U

Creates DVDs and functions as an external DVD drive when connected to a PC. In addition, created DVDs can be played back by connecting the CU-VD50U to a TV.

Creating Discs with a DVD Writer

Preparing a DVD Writer

“Preparing a DVD Writer (CU-VD3U)” (A p. 93) “Preparing a DVD Writer (CU-VD50U)” (A p. 94)

Copying to Discs

“Copying All Files” (A p. 95) “Copying Files by Date” (A p. 96) “Copying Selected Files” (A p. 97)

Other Operations

“Playing Back with a DVD Writer” (A p. 99) “Finalizing Discs After Copying” (A p. 99)

Memo :

When there are many files to back up, it may take time for the backup to be completed. Wait for a while as the access lamp appears blinking, which indicates normal operation.

Date and time information as saved as subtitles in the created discs.

Copying

Changing the Media of the DVD Writer

Set the type of media according to the loaded DVD.

Prepare a DVD writer.

“Preparing a DVD Writer (CU-VD3U)” (A p. 93) “Preparing a DVD Writer (CU-VD50U)” (A p. 94)

Tap “CHANGE REC. MEDIA” in the “BACK-UP” menu.

Tap “DVD(AVCHD)” or “DVD-Video”.

The media changes to the tapped item. Select the appropriate setting according to the disc.

Selecting “DVD(AVCHD)” enables you to save videos in a DVD in the high definition quality.

Selecting “DVD-Video” enables you to save videos in a DVD after converting to the standard image quality.

Preparing a DVD Writer (CU-VD3U)

Connect the USB cable and the AC adapter.

Turn off the camcorder by pressing the M button for about 2 seconds.

* The AC adapter shown in the illustration is AC-V11U.

A Connect the USB cable of the DVD writer to this unit. B Connect the AC adapter of the DVD writer. C Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

This unit turns on and the “BACK-UP” menu appears.

While the USB cable is connected, the “BACK-UP” menu is displayed.

Refer also to the instruction manual of the DVD writer.

Insert a new disc.

A Press the eject button to open the disc tray. B Pull out the tray completely and load a new disc properly. C Push the disc tray in until it clicks into place.

Caution :

Be sure to turn off the power when connecting the devices. Otherwise, electric shocks or malfunctions may occur.

Copying

Preparing a DVD Writer (CU-VD50U)

Connect the USB cable and the AC adapter.

Turn off the camcorder by pressing the M button for about 2 seconds.

* The AC adapter shown in the illustration is AC-V11U.

A Connect the USB cable provided with the DVD writer. B Connect the AC adapter of the DVD writer. C Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

This unit turns on and the “BACK-UP” menu appears.

While the USB cable is connected, the “BACK-UP” menu is displayed.

Refer also to the instruction manual of the DVD writer.

Turn on the DVD writer and insert a new disc.

A Press the power button to turn on the power. B Press the eject button to open the disc tray. C Pull out the tray completely and load a new disc properly. D Push the disc tray in until it clicks into place.

Caution :

Be sure to turn off the power when connecting the devices. Otherwise, electric shocks or malfunctions may occur.

Memo :

All buttons on the DVD writer CU-VD50U, other than the power and eject buttons, will not work when connected to this unit.

Creating a Disc

Prepare a DVD writer.

Insert a new disc into the DVD writer.

“Preparing a DVD Writer (CU-VD3U)” (A p. 93) “Preparing a DVD Writer (CU-VD50U)” (A p. 94)

Copy files to the disc with the following methods.

“Copying All Files” (A p. 95) “Copying Files by Date” (A p. 96) “Copying Selected Files” (A p. 97)

Copying

Copying All Files

All videos or still images recorded on this unit will be copied. You can also select and copy only the videos or still images that have never been copied.

Select video or still image mode.

Tap “CREATE FROM ALL” (video) or “SAVE ALL” (still image).

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap on the media to copy.

Tap the desired method.

While the video mode is shown in the image, the same operations apply for the still image mode.

“ALL SCENES” (video)/“ALL IMAGES” (still image):

All videos or still images in this unit are copied.

“UNSAVED SCENES” (video)/“UNSAVED IMAGES” (still image):

Videos or still images that have never been copied are automatically selected and copied.

Tap “EXECUTE”.

The number of discs required to copy the files is displayed. Prepare the discs accordingly.

Tap “YES” or “NO”. (A mode only)

When “YES” is selected, videos with similar recording dates are displayed in groups.

When “NO” is selected, videos are displayed according to recording dates.

Tap “EXECUTE”.

When “INSERT NEXT DISC” appears, change the disc.

After copying, tap “OK”.

Press and hold the M button for 2 seconds or more to turn off this unit and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is complete.

Files that are not on the index screen during playback cannot be copied.

Memo :

To check the created disc, refer to ““Playing Back with a DVD Writer” (A p. 99) ”.

“Playing Back with a DVD Writer” (A p. 99)

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the “COMMON” menu is set to “OFF”. “AUTO FINALIZE” (A p. 153)

To play back on other devices, tap “YES”.

To add more files to the DVD later, tap “NO”.

Memo :

When two or more DVDs are created simultaneously, all the discs other than the last one will be finalized automatically even when “AUTO FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACKUP” menu.

“Finalizing Discs After Copying” (A p. 99)

DVD-Video discs will be finalized automatically regardless of the “AUTO FINALIZE” setting.

To play back a BD-R disc on other devices, select “FINALIZE” after creating the disc. (The “AUTO FINALIZE” function in the “COMMON” menu can only be used for creating DVDs.)

Copying

Copying Files by Date

Videos or still images are sorted and copied according to the date on which they were recorded.

Select video or still image mode.

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still image).

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap on the media to copy.

Tap “CREATE BY DATE” (video) or “SAVE BY DATE” (still image).

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap to select a recording date.

Tap “EXECUTE”.

The number of discs required to copy the files is displayed.

Prepare the discs accordingly.

Copying

Tap “YES” or “NO”. (A mode only)

When “YES” is selected, videos with similar recording dates are displayed in groups.

When “NO” is selected, videos are displayed according to recording dates.

Tap “EXECUTE”.

When “INSERT NEXT DISC” appears, change the disc.

After copying, tap “OK”.

Press and hold the M button for 2 seconds or more to turn off this unit and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is complete.

Files that are not on the index screen during playback cannot be copied.

Memo :

To check the created disc, refer to ““Playing Back with a DVD Writer” (A p. 99) ”.

“Playing Back with a DVD Writer” (A p. 99)

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the “COMMON” menu is set to “OFF”. “AUTO FINALIZE” (A p. 153)

To play back on other devices, tap “YES”.

To add more files to the DVD later, tap “NO”.

Memo :

When two or more DVDs are created simultaneously, all the discs other than the last one will be finalized automatically even when “AUTO FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACKUP” menu.

“Finalizing Discs After Copying” (A p. 99)

DVD-Video discs will be finalized automatically regardless of the “AUTO FINALIZE” setting.

To play back a BD-R disc on other devices, select “FINALIZE” after creating the disc. (The “AUTO FINALIZE” function in the “COMMON” menu can only be used for creating DVDs.)

Copying Selected Files

Select and copy the desired videos or still images individually.

Select video or still image mode.

Tap “SELECT AND CREATE” (video) or “SELECT AND SAVE” (still image).

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap on the media to copy.

Tap “SELECT FROM SCENES” (video) or “SELECT FROM IMAGES” (still image).

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap on the videos or still images to copy.

A check mark appears on the selected file. To remove the check mark, tap on the file again.

Tap “CHECK” to check the file.

While the video mode is shown in the image, the same operations apply for the still image mode.

After selecting all the files, tap “SAVE”.

Copying

While the video mode is shown in the image, the same operations apply for the still image mode.

Tap “EXECUTE”.

The number of discs required to copy the files is displayed. Prepare the discs accordingly.

Tap “YES” or “NO”. (A mode only)

When “YES” is selected, videos with similar recording dates are displayed in groups.

When “NO” is selected, videos are displayed according to recording dates.

Tap “EXECUTE”.

When “INSERT NEXT DISC” appears, change the disc.

After copying, tap “OK”.

Press and hold the M button for 2 seconds or more to turn off this unit and disconnect the USB cable.

Caution :

Do not turn off the power or remove the USB cable until copying is complete.

Files that are not on the index screen during playback cannot be copied.

Memo :

To check the created disc, refer to ““Playing Back with a DVD Writer” (A p. 99) ”.

“Playing Back with a DVD Writer” (A p. 99)

Copying

When “DO YOU WANT TO FINALIZE?” appears

This appears when “AUTO FINALIZE” in the “COMMON” menu is set to “OFF”. “AUTO FINALIZE” (A p. 153)

To play back on other devices, tap “YES”.

To add more files to the DVD later, tap “NO”.

Memo :

When two or more DVDs are created simultaneously, all the discs other than the last one will be finalized automatically even when “AUTO FINALIZE” is set to “OFF”.

You can finalize a DVD even when “FINALIZE” is selected in the “BACKUP” menu.

“Finalizing Discs After Copying” (A p. 99)

DVD-Video discs will be finalized automatically regardless of the “AUTO FINALIZE” setting.

To play back a BD-R disc on other devices, select “FINALIZE” after creating the disc. (The “AUTO FINALIZE” function in the “COMMON” menu can only be used for creating DVDs.)

Playing Back with a DVD Writer

You can play back the DVDs created on this unit.

Prepare a DVD writer.

Insert the DVD to play back into the DVD writer.

“Preparing a DVD Writer (CU-VD3U)” (A p. 93) “Preparing a DVD Writer (CU-VD50U)” (A p. 94)

Tap “PLAYBACK” in the BACK-UP menu.

An index screen (thumbnail display) of the videos in the disc appears.

Tap on the file to start playback.

Tap “J” to return to the “BACK-UP” menu.

For details on video playback, refer to ““Operation Buttons for Video Playback” (A p. 74) ”.

“Operation Buttons for Video Playback” (A p. 74)

To exit, stop playback and turn off the camcorder by pressing the M button for about 2 seconds. Then, disconnect the USB cable.

Memo :

When playing back a disc created in DVD-Video format, no information such as date and time will be displayed.

Discs created with a DVD writer or external Blu-ray drive as well as files copied to an external hard disk drive can be converted to 3D for playback. (for GZ-HM960)

Finalizing Discs After Copying

Finalize the disc after copying is finished. This enables the disc to be played back using this unit, PC, DVD writer, DVD player, or external Blu-ray drive that supports the BD-MV and AVCHD formats.

Select video or still image mode.

Tap “FINALIZE”.

Tap “YES”.

After finalizing, tap “OK”.

Copying

Creating Discs with an External Blu-ray Drive

You can copy the recorded files to discs or play back the created discs using an optional external Blu-ray drive.

Compatible External Blu-ray Drives

You can use BE08LU20 from LG. (as of December, 2010)

Creating Discs with an External Blu-ray Drive

Preparing an External Blu-ray Drive

“Preparing an External Blu-ray Drive” (A p. 100)

Copying to Discs

“Copying All Files” (A p. 101) “Copying Files by Date” (A p. 102) “Copying Selected Files” (A p. 103) Select and copy the desired videos or still images individually.

Other Operations

“Playing Back with an External Blu-ray Drive” (A p. 104)

Memo :

The recordable time on the disc varies according to the way of recording.

When there are many files to back up, it may take time for the backup to be completed. Wait for a while as the access lamp appears blinking, which indicates normal operation.

Date and time information as saved as subtitles in the created discs.

Changing the Media of the External Blu-ray Drive

Set the type of media according to the loaded Blu-ray disc or DVD.

Prepare an external Blu-ray drive.

Insert a disc into the external Blu-ray drive.

“Preparing an External Blu-ray Drive” (A p. 100)

Tap “CHANGE REC. MEDIA” in the “BACK-UP” menu.

Tap “Blu-ray DISC”, “DVD(AVCHD)”, or “DVD-Video”.

The media changes to the tapped item. Select the appropriate setting according to the disc.

Selecting “Blu-ray DISC” enables you to save videos in a Blu-ray disc in the high definition quality.

Selecting “DVD(AVCHD)” enables you to save videos in a DVD in the high definition quality.

Selecting “DVD-Video” enables you to save videos in a DVD after converting to the standard image quality.

Preparing an External Blu-ray Drive

Memo :

When connecting to the external Blu-ray drive, use a USB cable with MiniA (Male) – B (Male) connectors. The USB cable provided with this unit cannot be used.

To use the USB cable provided with the external Blu-ray drive, purchase the USB extension cable.

Mini-A (Male) – A (Female) (Part number: QAM0852-001)

Connect the USB cable and the AC adapter.

Turn off the camcorder by pressing the M button for about 2 seconds.

* The AC adapter shown in the illustration is AC-V11U.

A Connect the USB cable of the external Blu-ray drive to this unit. B Connect the AC adapter of the external Blu-ray drive. C Turn on the external Blu-ray drive. D Connect the AC adapter to this unit.

This unit powers on automatically when the AC adapter is connected.

This unit turns on and the “BACK-UP” menu appears.

While the USB cable is connected, the “BACK-UP” menu is displayed.

Refer also to the instruction manual of the external Blu-ray drive.

Copying

100

JVC Everio GZ-HM860, Everio GZ-HM960, GZ-HM970, GZ-HM870, GZ-HM855 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
