Emerald FTR Series LED HDTV
User Manual
EM42FTR
EM48FTR
EM55FTR
EM65FTR
42” Class
48” Class
55” Class
65” Class
Before operating your LED TV, please read this manual thoroughly.
(*Images shown in this user manual are for illustration purpose only.)
Rev. 12/13
®
Contents
Congratulations on purchasing your new JVC TV. To get the most out of your JVC LED TV, read these
instructions before making any adjustments, and retain them for future reference.
For assistance, call the JVC Customer Support and Service Center 1-855-868-1928 or visit our website
http://jvc-tv.com/support
We recommend that you register your JVC LED TV either at our website http://jvc-tv.com/support or ll
out and mail the Product Registration Card on the back of the manual.
Retain your purchase receipt and write down the model and serial number located at the back of your
LED TV for easy reference when obtaining service support.
Serial Number:
Model Number:
This product qualies for ENERGY STAR in the
“factory default” setting and this is the setting in which
power savings will be achieved. Changing the factory
default picture setting or enabling other features will
increase power consumption that could exceed the
limits necessary to qualify for Energy Star rating.
HIGH-DEFINITION MULTIMEDIA INTERFACE
The terms HDMI and HDMI High-Denition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS;
IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. JVC, THE JVC LOGO, AND OTHER
JVC TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF JVC KENWOOD Corporation.
PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
Copyrights © 2014 AmTRAN Video Corporation. ALL RIGHTS RESERVED.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To Reduce The Risk Of Electric Shock, Do Not Remove Cover (Or Back). No User-Serviceable Parts
Inside. Refer Servicing To Qualied Service Personnel.
The lightning ash with arrowhead symbol, within
an equilateral triangle is intended to alert the user
to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES
AWAY FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
WARNING : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient
or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect
the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult
the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance,
(example – use only shielded interface cables when connecting to computer or peripheral devices). Any
changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Responsible Party: AmTRAN Video Corporation
Address: 9 Goddard, Irvine, CA 92618 USA
Telephone No: 1-855-868-1926
CAUTION: Changes or modications not expressly approved by the party responsible for compliance with the FCC Rules
could void the user’s authority to operate this equipment.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
2
Important Safety Instructions
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding-type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not t into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
ENGLISH
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects lled with liquids, such
as vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching
such power lines or circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of re or electric
shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage
points or short out parts that could result in re or electric shock. Never spill or spray any type
of liquid into the unit.
19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable
system is grounded to provide some protection against voltage surges and built-up static
charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information
with respect to proper grounding of the mast and supporting structure, grounding of the
lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna
discharge unit, connection to grounding electrodes, and requirements for the grounding
electrode.
20) When replacement parts are required, be sure the service technician uses replacement parts
specied by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform
safety checks to determine that the unit is in proper operating condition.
3
Important Safety Instructions
22) When you connect the product to other equipment, turn o the power and unplug all of the
equipment from the wall outlet. Failure to do so may cause an electric shock and serious
personal injury. Read the owner’s manual of the other equipment carefully and follow the
instructions when making any connections.
23) Sudden high volume sound may cause hearing or speaker damage. When you use
headphones, (if the unit is equipped with a headphone jack) keep the volume at a moderate
level. If you use headphones continuously with high volume sound, it may cause hearing
damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may
cause speaker overheating and re.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, species that the
cable ground shall be connected to the grounding system of the building, as close to the point
of cable entry as practical.
26) The socket-outlet must be installed near the unit and easily accessible.
CHILD SAFETY:
It Makes A Difference How and Where You Use TV
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger TVs are popular purchases. However, TVs are not
always supported on the proper stands or installed according to the manufacturer’s recommendations.
TVs that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACTURER CARES !
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT t all. Follow the manufacturer’s recommendations for the safe installation and use of your TV.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place TVs on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” TV. Care should be
taken to place or install the display where it cannot be pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected to the TV so that they cannot be pulled or grabbed by curious
children.
4
Important Safety Instructions
CONDENSATION
Moisture will form in the operating section of the unit if the unit is brought from cool surroundings
into a warm room or if the temperature of the room rises suddenly. When this happens, unit’s
performance will be impaired. To prevent this, let the unit stand in its new surroundings for
about an hour before switching it on, or make sure that the room temperature rises gradually.
Condensation may also form during the summer if the unit is exposed to the breeze from an air
conditioner. In such cases, change the location of the unit.
HOW TO HANDLE THE LED PANEL
• Do not press hard or jolt the LED panel. It may cause the LED panel glass to break and injury may
occur.
• If the LED panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may
cause skin inammation.
• If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the
liquid gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15
minutes or longer in clean water.
Possible Adverse Effects on LED Panel:
If a xed (non-moving) pattern remains on the LED Panel for long periods of time, the image can become
permanently engrained in the LED Panel and cause subtle but permanent ghost images. This type of
damage is NOT COVERED BY YOUR WARRANTY. Never leave your TV on for long periods of time while it is
displaying the following formats or images:
• Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
ENGLISH
• Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9)
media on a normal (4:3) display (black bars at top and bottom of screen); or viewing normal
style (4:3) media on a widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation.
• LED Panels are manufactured using an extremely high level of precision technology, however
sometimes parts of the screen may be missing picture elements or have luminous spots. This is not a
sign of a malfunction.
• Do not install the TV near electronic equipment that produces electromagnetic waves. Some
equipment placed too near this unit may cause interference.
• Eect on infrared devices – There may be interference while using infrared devices such as
infrared cordless headphones.
5
Important Safety Instructions
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that
the antenna or cable system is electrically grounded to provide some protection against voltage
surges and static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to
proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of the grounding conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements of the grounding electrode.
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
(NEC SECTION 810-21)
Lightning Protection
For added protection of the TV during a lightning storm or when it is left unattended or unused
for long periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable
system.
Power Lines
Do not locate the antenna near overhead light or power circuits, or where it could fall into such
power lines or circuits.
6
DTV Transition Advisory
Important Safety Instructions
As of June 12, 2009, all U.S. television stations have switched to digital broadcasting. As a result,
owners of analog television sets must connect a digital-to-analog converter box to the television
set or subscribe to cable or satellite TV to receive over-the-air TV. Analog-only TVs continue to
work as before to receive low power, Class A or translator television stations and with cable and
satellite TV services, gaming consoles, VCRs, DVD players, and similar products.
For more information about the DTV transition, visit www.dtv.gov.
FCC’s Consumer Center
Email: dtvinfo@fcc.gov
Phone: 1-888-CALL-FCC (1-888-225-5322)
Fax: 1-866-418-0232; or writing to:
Mail: Federal Communications Commission
Consumer and Governmental Aairs Bureau
Consumer Inquiries and Complaints Division
445 12th Street, SW
Washington, DC 20554
ENGLISH
7
Contents
Contents
Contents ...........................................................................1
Important Safety Instructions ................................... 3
Television Antenna Connection Protection ... 6
External Television Antenna Grounding .... 6
DTV Transition Advisory ........................................ 7
Contents ...........................................................................8
Attaching the Stand ...................................................10
Unpacking the TV ..................................................10
EM42FTR ..............................................................10
EM48FTR ..............................................................10
EM55FTR ..............................................................10
EM65FTR ..............................................................10
Removing the Stand .............................................10
Package Contents ........................................................11
Remote Control Batteries .........................................11
Parts and Functions ....................................................12
Front View .................................................................12
Rear View ..................................................................12
EM42FTR ..............................................................12
EM48FTR ..............................................................12
EM55FTR ..............................................................12
EM65FTR ..............................................................12
Remote Control ......................................................13
Making Connections ..................................................14
Connecting Antenna / Cable .............................14
Connecting HD Devices ......................................14
Connecting External Speakers / Soundbar / AV
Receivers ...................................................................15
Digital Connection ..........................................15
Basic Operations ..........................................................16
Setup Wizard ...........................................................16
Exit Store Demo ................................................17
Basic TV Operation ................................................17
One button operation ...................................17
Changing Channel ...........................................18
Mute Volume .....................................................19
Set Sleep Timer .................................................19
Display Info.........................................................19
Set Aspect Ratio ...............................................19
Selecting Input Source ........................................20
Multimedia Mode ..................................................20
Playing Multimedia Files ...............................20
Multimedia: Photo ...........................................21
Audio Only Mode ...................................................21
Wall Mount ...............................................................22
Installing Wall Mount ...........................................22
Adjusting the Menu Settings ..................................23
Menu Operation .....................................................23
Input Menu ..............................................................24
Picture Menu ...........................................................24
Picture Mode .....................................................24
Backlight .............................................................24
Contrast ...............................................................24
Brightness ...........................................................24
Color .....................................................................24
Tint ........................................................................24
Sharpness ...........................................................25
Size & Position ...................................................25
Color Temperature ...........................................25
Advanced Picture(*May be unavailable on
certain models.) ................................................25
Reset Picture Mode .........................................25
Audio Menu .............................................................25
Bass .......................................................................25
Treble ....................................................................25
Balance ................................................................25
Lip Sync ...............................................................26
TV Speakers ........................................................26
Audio Only ..........................................................26
Digital Audio Out .............................................26
Equalizer Settings ............................................26
Reset Audio Mode ...........................................26
Setup Menu .............................................................26
Name Input ........................................................26
CEC Settings .......................................................27
Menu Language ...............................................27
Time & Local Settings .....................................27
Parental Control ................................................27
Setup Wizard ......................................................28
System Information .........................................28
Reset All Settings .............................................28
Closed Caption .......................................................29
Wide ............................................................................29
Channel Menu ........................................................30
Select Antenna / Cable ..................................30
8
Scan Channels ...................................................30
Add Channel ......................................................31
Delete Channel .................................................31
Sleep Timer ..............................................................31
Appendix ........................................................................32
Supported Resolution ..........................................32
Troubleshooting ..........................................................33
Specications ................................................................34
Roku QSG and troubleshooting .............................36
Limited Warranty .........................................................38
ON PARTS AND LABOR ...................................38
Parts and Labor .................................................38
Type of Service ..................................................38
Limitations and Exclusions ...........................38
Contents
ENGLISH
9
Attaching the Stand
The stand installation varies depending on
model. Perform the installation according to the
instructions of your TV model.
Unpacking the TV
1 Remove TV accessories and protective foam.
2 Remove TV from the box and place it on a at
and clean surface with TV screen facing down.
3 Attach the stand to TV using the provided
screw.
EM42FTR
EM48FTR
Removing the Stand
When the TV needs to be transported, remove
the stand and pack the TV back in the carton.
To remove the stand, perform the assemble
steps in reverse order according to your TV
model.
EM55FTR
EM65FTR
10
Package Contents
Check if the following items are included in your package.
LED TV
Remote Control
SLEEP
MEDIA
N
E
U
M
I
N
T
F
U
O
P
N
I
OK
N
W
R
I
U
D
T
E
E
R
A
U
O
I
D
VOL CH
MUTE
1 2 3
4 5 6
7 8 9
_
ENT
0
HDMI PC TV
VIDEO COMP MUSIC
Quick Start Guide
Power Cord
Quick Start
Guide
DOWNLOAD FULL VERSION USER MANUAL
http://jvc-tv.com/support
Batteries
ENGLISH
Roku Streaming Stick
Remote Control Batteries
1 Push the tab, then lift to open the cover.
2 Insert the batteries, making sure the [+] and
[-] polarities are correct.
3 Close the battery cover.
Battery Precautions:
Be sure to follow the correct polarity. Incorrect installation
may cause battery leakage or damage the remote control.
Always replace batteries in pair. Do not combine a used
battery with a new one.
Do not use dierent battery types together
(e.g. “Alkaline” and “Carbon-zinc”).
If the remote control is not to be used for a long period of
time, remove the batteries to prevent battery leakage.
11
Front View
Parts and Functions
Power indicator
Remote control IR receiver
Rear View
EM42FTR
EM48FTR
EM55FTR
EM65FTR
(*MHL port does not charge
when TV is OFF.)
12
Parts and Functions
Remote Control
1 IR Transmitter: Sends remote control signal to
the TV.
2 SLEEP button: Select a sleep mode timer (O,
30 minutes, 60 minutes, 90 minutes, 120 minutes,
180 minutes).
3 Playback controls: The buttons are
used for Photo, Music, Video, HDMI CEC enabled
devices and HDMI MHL enabled devices.
4 INPUT button: Change the input source.
5 WIDE button: Change the display mode
(Normal, Wide, Zoom Panoramic).
6 MUTE button: Turn the TV audio o or on.
7 VOL (Volume) buttons: Press VOL
increase volume or VOL
to decrease volume.
8 Number pad (0~9, –): Use the number keys to
directly change channel.
9 HDMI button: Press to directly set HDMI as the
input source signal.
10 VIDEO button: Press to directly set Composite
VIDEO as the input source signal.
11 COMP button: Press to directly set Component
as the input source signal.
12 Remote Control LED: Lights red when a
button is pressed.
13 POWER button: Turn the TV on or o.
14 HOME button: Press to display ROKU
home screen while ROKU streaming stick is in
use.
15 MENU button: Display the MENU screen.
16 *INFO button: Press to obtain more
information or access special options on Roku.
17 Direction buttons
/ / / :
Navigate the menu, select options, or adjust
settings value.
18 OK button: Enter a menu or conrm an option.
19 ←RETURN button: Return to a previous
menu or screen.
20 AUDIO button: Enter Audio Only mode and
turn the screen o. See page 24.
21 CH (Channel) buttons: Use CH
increase the channel number or CH to
decrease the channel number.
22 ENT (Enter) button: Access the entered
channel number or display the Channel list screen.
23 TV button: Directly set TV as the input source
signal.
to
to
24 PC button: Directly set PC as the input source
signal (This function is only available to models
with VGA input)
25 MUSIC button: Directly set Music as the input
source signal.
1
2
3
4
5
6
7
8
9
10
11
Notes:
To obtain best results, use the remote control with a proper
distance from the TV and ensure that there are no obstacles
between them.
Aim the remote control transmitter to the remote control
sensor on the TV.
Do not expose the remote control to direct sunlight. This
may aect the performance of the remote control.
12
13
14
15
16
17
18
19
20
21
22
23
24
25
ENGLISH
13
Making Connections
Connecting Antenna / Cable
Connect the 75 ohm coaxial cable directly to the DTV/TV Cable/Antenna jack of the TV.
DTV / TV
CABLE / ANTENNA
75 ohm coaxial cable
Connecting HD Devices
You can connect dierent devices to the TV using HDMI, Composite, or Component connections.
Check the type of connection available on your device.
14
Making Connections
Connecting External Speakers / Soundbar / AV Receivers
Digital Connection
Connect the SPDIF/Optical audio cable to the Audio OUT optical port of the TV and the optical
port of the soundbar, AV receiver, or audio system.
Digital Audio System
TV
AUDIO OUT
OPTICAL
Note:
• The optical audio cable is not included with the TV.
Audio OUT
Optical audio cable
Audio IN
OPTICAL
Connecting Music Port
ENGLISH
The TV supports music playback from portable music players, such as an MP3 player or iPodTM.
15
Basic Operations
Setup Wizard
The Setup Wizard will assist you with setting up
your TV for the rst time. Please follow the
instruction carefully.
Note: If you would like to setup over-the-air or cable
programming, make sure the antenna or cable TV system is
connected. See page 14 for setup.
1 When you turn on the TV for the rst time, the
Setup Wizard screen will appear.
2 Press or to select the menu language, then
press OK.
Menu Language
Language Selection
Language:
English
4 Press or to select the Time Zone, then press
OK.
Time Zone
Select the Time Zone
Time Zone:
Change Select
OK
Alaska
RETURN
Previous Setup
INFO
Exit
5 Press or to set Daylight Saving Time “ON” or
“OFF”, then press OK.
Daylight Saving
Daylight Saving Selection.
Change Select
OK
INFO
Exit
3 Press or to select the TV Mode, then press
OK.
TV Mode options :
• Home Use: Select this mode for in home
use.
• Store Demo: Select this mode for in
store demo.
Note:
• Store Demo is for retailers only.
• To exit Store Demo, see page 18.
Daylight Saving:
Change Select
OK
Off
RETURN
Previous Setup
INFO
Exit
6 Press or to select the TV service, then press
OK.
Auto Scan
Select the Signal Type of your TV input
and start auto scan.
Start Scan
Cable
RETURN
Previous Setup
INFO
Exit
Signal Type:
ChangeMove Select
OK
16
Basic Operations
7 Press OK to start channel scan.
Scanning
Channel scan in process, if you want to stop
scanning, please press "Stop Scan".
Scan Status:
Analog Channel:
Digital Channel:
OK
0%
Stop Scan
Select
0
0
Note:
• Scanning may take some time to complete.
• Select Stop Scan to cancel the auto scan at anytime.
8 When auto scan is complete, press OK to
continue.
Exit Store Demo
1 Press RETURN.
2 Press or to select “OK”, then press OK to
conrm.
Do you wish to exit Retail Mode?
CancelOK
ENGLISH
Scan Finish
Channel scan completed.
Analog Channels:
Digital Channels:
OK
Select
OK
12
26
RETURN
9 Press OK to complete setup.
Finish
Initial Setup has finished, please press "OK" to
exit Setup Wizard.
OK
Previous Setup
INFO
Exit
OK
Select
RETURN
Previous Setup
INFO
Exit
17
Basic Operations
Changing Channel
Press the number buttons to directly select
channels.
Note: After pressing the number buttons, there will be
a few seconds delay before the TV changes channel. To
change to the channel right away, press ENT after pressing
the number buttons.
To Browse Channel
Press the Channel up/down buttons on the remote
control.
CH
Press to scroll through the
channels manually.
To Select Analog Channels
1~9 Press 1~9 as needed. Example,
to select channel 2, press 2, then
press ENT.
10~99 Press the 2 digits in order.
Example, to select channel 15,
press 1, 5, then ENT.
100~135: Press the 3 digits in order,
Example, to select channel 130,
press 1, 3, 0, then press ENT.
18
_
_
Basic Operations
To Select Digital Channels
Press the rst 3 digits, then press
the remaining number. Example, to select channel
15-1, press 1, 5,
To Select by Channel List
All channels found from channel scan are listed on
the Channel List screen. You can select channels
from this screen.
, 1, then press ENT.
, followed by
1 Press ENT to display the Channel List screen.
2 Press or to select a channel number,
then press ENT.
3 Press RETURN to close the Channel List
screen.
Mute Volume
Press MUTE to turn the sound o. To turn the
sound back on, press MUTE again or any of the
VOL buttons.
Set Aspect Ratio
1 Press WIDE to display the Wide menu.
2 Press WIDE repeatedly or press or to
scroll through the options, then press OK.
Normal
When watching a 4:3 content,
the TV displays a standard
picture with black side bars.
When viewing a 16:9 content,
it displays a full picture.
Wide
When displaying a 4:3
content, the picture is
stretched horizontally to ll
the width of the screen. When
watching a 16:9 content, the
image is slightly overscan.
ENGLISH
Set Sleep Timer
Sleep timer sets the TV to automatically turn o
after a preset amount of time. After setting a preset
amount of time, the TV will automatically turn o
after the timer has expired.
1 Press SLEEP to display the Sleep screen.
2 Press SLEEP repeatedly or press or to
scroll through the options, then press OK.
To cancel sleep, set the timer to O.
Display Info
Press INFO to display the channel or input
information on the screen.
Press INFO again to hide the Info screen.
Zoom
The entire picture is uniformly
enlarged to retain its original
proportion. However, some
parts of the picture may be
hidden.
Panoramic
The picture is stretched
horizontally on the left and
right sides to ll the width of
the screen. The center of the
picture is not stretched.
Stretch
The picture is stretched
horizontally on the left and
right sides.
Note:
• Panoramic mode is only available on 4:3 contents.
• Stretch is only available on 16:9 contents.
19
Basic Operations
I
N
P
U
T
I
N
F
O
M
E
N
U
VOL CH
MUTE
SLEEP
OK
W
I
D
E
A
U
D
I
O
R
E
T
U
R
N
MEDIA
1 2 3
4 5 6
7 8 9
_
0
ENT
HDMI PC TV
VIDEO COMP MUSIC
Aspect Ratio options in PC mode.
Normal
When watching a 4:3 content, the TV displays
a standard picture with black side bars. When
viewing a 16:9 content, it displays the full
picture, pixel to pixel.
Multimedia Mode
The TV Allows you to play image slide shows from a
USB memory stick.
Note:
• Only supported multimedia les can be played back.
Stretch
When watching a 4:3 content, the picture is
stretched hozontally to ll the width of the
screen. When watching a 16:9 content, the
picture is stretched Horizontally on the left
and right sides.
Selecting Input Source
The TV provides various ways to select the
input source:
On the Remote Control
• Press INPUT repeatedly to scroll through
the input source options, then press OK
to select the input.
• To directly select an input source, press
the direct input button located at the
bottom of the remote control.
Playing Multimedia Files
1 Insert the USB memory stick into the USB slot
of the TV.
TV
(side panel)
USB
Take note of the correct direction.
Do not force the device into the slot.
2 A message box will appear on the screen.
Press
or to select OK.
USB media detected. Enter multimedia
menu?
CancelOK
3 Press OK to select your option.
4 Press or to select the USB source, then
press OK.
20
5 If prompted, press or to select Photo
player, then press OK.
6 The displayed screen varies depending on the media type you selected.
Basic Operations
Press
, , or to select a le or function, then press OK.
Multimedia: Photo
1
2
3
4
1 Start Slideshow button: Play slide show.
2 Sort button: Change sorting order. The label on this button varies depending on the
current sorting order. (Name A-Z, Name Z-A, Newest First, Oldest First)
3 View button: Change view mode. The button label varies depending on the current view.
(Folders, Thumbnails)
4 Setting button: Change slide show settings.
File Name:P1130130
Resolution:
768x1024
Size:
113KB
Start Slideshow
Sort:
Newest First
View:
Thumbnails
Setting
ENGLISH
PATH:/MMP/Photo/
.. P1130130 P1130131
P1130132 P1130133 P1130134
P1130135 P1130136 P1130137
Page 1 of 7
Audio Only Mode
While watching TV or playing music, you can set the TV to Audio Only mode to turn o the TV display and
save power.
1 Press AUDIO to activate Audio Only mode. A message appears on the screen, then after a few
seconds, the TV display turns o.
2 Press any button to turn on the display again and exit Audio Only mode.
21
Basic Operations
Wall Mount
Installing Wall Mount
The wall mount kit allows you to mount the TV on the wall. For detailed information on installing the wall
mount, see the instructions provided with the wall mount kit.
Note: The wall mount kit is not included with the product.
For product protection and safety reasons, JVC strongly recommends contacting a technician or professional for assistance installing the wall mount and setting up the TV. If you
decide to install the wall mount and TV without the assistance of a technician or professional, JVC will not be responsible for any damage to the product or injury to yourself or
others.
Do not install your wall mount while your TV is turned on. It can result in personal injury
due to electric shock
1 Disconnect all cables connected to the TV.
2 CarefullyplacetheTVonaatandcleansurfacewithscreenfacingdown.Itis
recommendedtoplacetheTVcoverorprotectionsheetbetweentheTVandat
surface.
3 Remove the screw attaching the stand and TV.
4 Remove and store the stand for future use.
Wall Mount Specications (VESA)
Product Model # VESA hole pattern (mm) Standard Screw
EM42FTR (42”)
EM48FTR (48”)
EM55FTR(55”)
EM65FTR (65”)
200 x 200
200 x 200
400 x 400
400 x 400
M4
M4
M8
M8
22
Adjusting the Menu Settings
Menu Operation
Main Menu
ENGLISH
Options or submenu
*Input sources menu varies depending on model.
1 Display the menu.
2 Select a menu option.
3 Adjust or select the
setting.
Remote Control
Press MENU.
1. Press
2. Press OK or
an option.
1. Press
press or to adjust a setting, such as
Brightness.
2. Press OK to apply the settings.
or to select a menu or option.
to enter a menu or conrm
or to select an option. Or,
4 Exit the menu.
To exit the menu, press RETURN. Or, to
return to a previous screen one at a time,
press MENU or
.
23
Adjusting the Menu Settings
Input Menu
Select the input source signal.
• TV: To watch analog or digital TV channels.
• Video: To use VCRs, camcorders, or game consoles connected via
composite connection.
• Component: To use VCRs, camcorders, or game consoles connected via
component connection.
• HDMI-1 : To connect HD devices via HDMI Connection.
• HDMI/MHL: To connect MHL devices via HDMI/MHL Connection.
• Music: To play music from a music player connected via music port.
Picture Menu
Adjust picture options such as Brightness, contrast, and advanced picture settings.
Picture Mode
Select the picture mode.
Custom For custom picture settings.
Standard For standard picture settings.
Movie For moving pictures such as movies.
Game
Vivid For bright and vivid picture settings.
Sport Suggested settings for sporting events.
For fast and dynamic pictures suitable with playing
games.
Backlight
Adjust the backlight that aects the overall brilliance of the picture. (0 ~100)
Contrast
Adjust the white level in the picture. Low contrast makes pictures look dark, high contrast makes
pictures washed out. (0 ~100)
Brightness
Adjust the brightness setting. (0 ~100)
Color
Adjust the amount of color level in the picture. (0 ~100)
Tint
Adjust the picture hue. (-50 ~ 50)
24
Adjusting the Menu Settings
Sharpness
Adjust the sharpness of the edges of elements in the picture.
Size & Position
Horiz. Position / Vertical Position Adjust the horizontal / vertical position of the picture.
Horizontal Size / Vertical Size Adjust the horizontal / vertical size of the picture.
Color Temperature
Color Temperature
Red / Green / Blue Gain
Red / Green / Blue Oset
Reset Color Temperature Reset the color temperature to default settings.
Apply a preset color temperature setting.
(Custom / Cool / Natural / Warm)
Adjust the red / green / blue gain settings according to your
preference.
Adjust the red / green / blue oset settings according to your
preference.
Advanced Picture(*May be unavailable on certain models.)
CrystalColor
Dynamic Contrast
Adaptive Backlight Enable or disable adaptive backlight. (O / On)
Noise Reduction
Digital NR
CrystalColor produces more vivid and crisp color
pictures. (Off / Normal / Rich)
Dynamic contrast automatically enhances the
image for greater picture details.
Reduce the noise level.
(O / Low / Medium / High)
Reduce noise level of digital signals.
(O / Low / Medium / High)
ENGLISH
Film Mode
Produce smoother motion picture when viewing
movies .
Reset Picture Mode
Reset the picture mode settings to default.
Audio Menu
Bass
Adjust the bass level to your preference. (-12 ~ 12)
Treble
Adjust the treble level to your preference. (-12 ~ 12)
Balance
Adjust the audio level of the L/R channels of the speakers to your preference. (-10 ~ 10)
25
Adjusting the Menu Settings
Lip Sync
Adjust to match the movements and the lips of the person talking on the
screen. (0 ~ 5)
TV Speakers
Turn the internal speakers on or o.
Audio Only
Output audio from the TV speakers but turn o the TV display. See page
24.
Digital Audio Out
Select the type of digital audio output. (O / Dolby Digital / PCM)
Equalizer Settings
Adjust the equalizer settings. (120Hz / 500Hz / 1.5KHz / 5KHz / 10KHz)
Reset Audio Mode
Reset the audio mode settings to default settings.
Setup Menu
Name Input
The Name Input feature of the TV allows you to add a label name on an input source.
To label an input source , perform the following steps:
1 Press MENU.
2 Press or to select “Setup”, then press or OK.
3 Press or to select “Name Input”, then press or OK.
4 Press or to select “Input Source”, then press or OK.
5 Press or to select the input source that you want to add
a label name to, then press OK.
6 To select a custom label:
1. Press
then press
or to select “Input Labels”,
or OK.
2. Press
To enter desired label:
1. Press
2. Press
3. Press
or to select “Custom” and press OK.
or to select the text box, then press OK.
, , or to select a character, then press OK.
, , or to select “OK”, then press OK.
Press RETURN to close the menu screen.
26
Input Source
Input Labels
Component
Custom
My Input
Adjusting the Menu Settings
CEC Settings
CEC allows you to control devices using your TV remote control when the CEC devices are
connected via HDMI.
CEC Function
Device Search If CEC Function is enabled, select to search for CEC devices.
System Audio Control Connect to your device though Audio Return Channel-enabled HDMI Port
Enable or disable CEC function.
(HDMI 1)
Menu Language
Select the on-screen menu language.
Time & Local Settings
Time Zone Select a location to apply the time zone.
Daylight Saving Enable or disable daylight saving time.
Parental Control
The Parental Control feature allows you to control and restrict TV programs by Channel Lock , TV
Rating, or Movie Rating.
Access Parental Control Menu
The Parental Control menu requires you to enter the password to access its submenu.
ENGLISH
1 Press MENU.
2 Press or to select “Setup”, then press or OK.
3 Press or to select “Parental Control”, then press or OK.
4 Enter the 4-digit password. Press , or to select “OK”, then press OK to access the submenu
options.
Please enter password.
CancelOK
Note: The default password is “0000”.
5 Press or to select the submenu options, then press or OK to enter the submenu.
Restrict By Channel
Use the Channel Lock feature to restrict viewing a specied channel. Once locked channel is selected, the
TV displays a blank screen.
1 In the “Parental Control” menu, press or to select “Channel Lock”, then press or OK.
2 Press or to highlight a channel that you want to lock.
27
Press OK to mark and lock the channel.
3
Adjusting the Menu Settings
Enable Rating
Off
4 Press to return to the previous screen or press RETURN to close the
menu screen.
Restrict By TV/Movie Rating
You can select which TV/Movie rating to lock for viewing.
1 In the “Parental Control” menu, press or to select a rating
submenu, then press or OK.
• “Enable Rating”: Select “On” to enable rating.
• “USA-TV”: Set the rating by age level and genre.
• “USA-Movie”: Set by USA movie rating standards.
• “CAN-English”: Set by Canadian English movie rating standards.
• “CAN-French”: Set by Canadian French movie rating standards.
• “Block Unrated Shows”: Select “On” to block unrated shows.
Channel Lock
USA-TV
USA-Movie
CAN-English
CAN-French
Alt. Region Rating
Block Unrated Shows
New Password
Reset Parental Settings
2 Press or , then press OK to select the rating.
3 Press to return to the previous screen or press RETURN to close the menu screen.
Change Password
Off
1 In the “Parental Control” menu, press or to select “Change Password”, then press or OK.
2 Enter a new password, then press OK.
3 Re-enter the new password, then press OK to complete.
Power Indicator
To turn on/o the LED power indicator while TV is on.
Setup Wizard
Run the guided setup.
System Information
Display the system information of the TV.
Reset All Settings
Reset all TV settings to default settings.
28
Adjusting the Menu Settings
Note: Either “Analog Closed Caption” or “Digital Closed Caption” is available depending on your TV service.
Note: refer to Basic Operation section for details.
Closed Caption
Closed Caption decodes and displays closed caption data of television programs
as subtitle. This feature displays text on the screen or it translates and displays text
in another language.
ENGLISH
1 Press MENU.
2 Press or to select “Closed Caption”, then press or OK.
3 Press or to select “Analog Closed Caption” or
“Digital Closed Caption, then press
or OK.
4 Press or to select a closed caption type or select “O” to disable this
feature, then press OK.
For digital closed caption, you can select closed caption options, such as text
size and text color. Press
OK. Select desired options.
or to select “Digital CC Options”, then press
5 Press RETURN to close the menu screen.
Wide
Select WIDE to change TV viewing aspect ratio.
Analog Closed Caption
Digital Closed Caption
Digital CC Options
Off
Off
1 Press MENU.
2 Press or to select “Wide”, then press or OK.
3 Press or to select “Normal” or “Wide”,
“Zoom”, “ Panoramic“
29
Channel Menu
Select Antenna / Cable
Select Antenna or Cable for the service connected to your TV.
1 Press MENU.
2 Press or to select “Channel”, then press or OK.
Adjusting the Menu Settings
TV Mode
Auto Channel Scan
Partial Channel Scan
Cable
3 Press or to select “TV Mode”, then press or OK.
4 Press or to select “Antenna” or “Cable”, then press OK.
Find Channel
Channel Management
Digital MTS
English
Scan Channels
Auto Scan Channels
When you run auto scan, the TV scans for all available channels. Make sure the antenna/cable is
connected properly. See page 14.
1 Press MENU.
2 Press or to select “Auto Channel Scan”, then press or OK.
3 Press or to select “Start Scan”, then press OK.
Scanning progress is displayed on the menu screen. To stop scanning, select “Stop Scan” and press
OK.
Note: Auto scan may take 15 to 30 minutes to nd available channels.
30
Partial Scan Channels
You can partially scan for network signal within a specied range of channels.
1 Press MENU.
2 Press or to select “Partial Channel Scan”, then press or OK.
3 Press or to select “Scan Mode”, then press or OK.
4 Press or to select an option, then press OK.
• “Analog/Digital”: scan for both analog and digital channels
• “Analog”: scan for analog channels
• “Digital”: scan for digital channels
5 Press or to select “From Channel”, then enter a starting channel range.
6 Press or to select “To Channel”, then enter an ending channel range.
7 Press or to select “Start Scan”, then press OK.
Scanning progress is displayed on the menu screen. To stop scan, select “Stop Scan” and press OK.
Add Channel
ENGLISH
New channels may be added to your area periodically. Use the Add Channel function to add new
channels.
1 Press MENU.
2 Press or to select “Channel”, then press or OK.
3 Press or to select “Find Channel”, then press or OK.
4 Press or to select “Enter Channel”, then enter a channel.
5 Press to select “Add Channel”, then press OK.
Added channels are listed on the Channel List screen.
Delete Channel
To remove a channel from the Channel List screen.
1 Press MENU.
2 Press or to select “Channel”, then press or OK.
3 Press or to select “Channel Management”, then press or OK.
4 Press or , then press OK to mark the channels that you want to remove from the
Channel List.
5 Press RETURN to close the menu screen.
Sleep Timer
Sleep timer sets the TV to automatically turn o after a preset amount of time.
31
Appendix
Supported Resolution
Model Name EM42FTR / EM48FTR / EM55FTR / EM65FTR
720 x 400 @ 70Hz
Supported PC Timing
(HDMI)
Supported Video Timing (NTSC, Composite) 480i
Supported Video Timing
(ATSC, Composite, HDMI)
640 x 480 @ 60, 75Hz
800 x 600 @ 60, 75Hz
1024 x 768 @ 60, 75Hz
1920 x 1080 @ 60Hz
480i, 480p, 720p, 1080i, 1080p
32
Troubleshooting
If your TV fails to work properly, check the following guidelines for possible causes and solutions.
Consult your local dealer or service outlet if problems persist.
Problem Solution
No power. • Make sure the power cord is plugged in.
• The power is o, press the Power button to turn on the TV.
• Try another outlet.
• Unplug the unit for an hour, then plug it back in.
Poor sound or no sound.
Poor picture or no picture. • The channel or cable TV is experiencing problems, tune to
• Press the VOL
Function button on the TV to adjust volume .
• Press MUTE on the remote control to ensure that mute is not on.
• The channel or cable TV is experiencing problems, tune to
another channel.
• Check the TV audio settings.
• Check for possible sources of interference.
another channel.
button on the remote control or the Power/Multi
ENGLISH
• Make sure that channels are set into memory.
• Check the antenna or cable TV connections.
• Check for possible sources of interference.
Poor reception on some
channels.
The remote control does
not work.
TV shuts o. • Sleep timer is set.
No CATV reception. • Check all cable TV connections.
• The channel or cable TV is experiencing problems, tune to
another channel.
• Make sure that channels are set into memory.
• The network signal is weak, adjust the antenna to receive better
reception.
• Check for possible sources of interference.
• Batteries may be weak, dead, or inserted incorrectly.
• Point the remote control directly at the remote sensor on the TV
with an angle of 35º.
• Remove any obstacles between the remote control and the TV.
• Remote control is out of range, move closer to the TV.
• Power is interrupted.
Closed caption is not
activated.
• Set the TV Mode in Channel menu.
• The program tuned is not closed captioned. Try another channel.
• Enable Closed Caption in the menu.
33
Specications
Speaker Output Power:
USB Multimedia:
Audio Only Mode:
Input Port Naming:
Remote:
USB:
Music Port:
Mechanical
Stereo Audio Out:
Input / Output
Built-in NTSC / ATSC / Clear QAM Tuner:
Color Enhancement:
(Approx.):
(Approx.):
Backlit:
Refresh Rate / Frame Rate:
Specications are subject to change without prior notice.
EM42FTR EM48FTR
Display Specification:
Size Class (Diagonal):
42” (actual viewable size: 42”) 48” (actual viewable size: 47.6”)
Resolution / Aspect:
Contrast Ration:
TV Features
PIP / POP:
Close Caption:
Parental Control:
Electronic Programming Guide (EPG): No No
Picture Modes:
Audio
Audio Technology:
Graphic Equalizer:
Convenience Features
Ambient Sensor:
Interactive Setup Guide:
HDMI-ARC:
HDMI-CEC:
Energy Saving Features
Auto Power OFF (DPMS):
Energy Star:
1920 x 1080 / 16:9 1920 x 1080 / 16:9
DLED DLED
CM120Hz CM120Hz
1200:1 1200:1
Yes Yes
Yes Yes
No No
Yes Yes
Yes Yes
Yes Yes
MTS Stereo Decoder, MTS Stereo Decoder,
Dolby Digital Decoder Dolby Digital Decoder
(5.1 Ch Pass Through) (5.1 Ch Pass Through)
Yes Yes
10 Watts x 2 10 Watts x 2
No No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes, Energy Star 6.0 Yes, Energy Star 6.0
Input:
Antenna In:
HDMI:
Component:
Composite (RCA):
VGA / RGB:
Output:
Optical Digital Audio Out:
Wall Mount Pattern:
Without Stand (WxHxD) and Weight
With Stand (WxHxE) and Weight
34
1 1
3 (one port for MHL) 3 (one port for MHL)
1 1
1 (shared with component) 1 (shared with component)
0 0
1 1
1 1
1 1
1 1
200mm x 200mm 200mm x 200mm
37.7" x 22.1" x 2.5" / 15.9 lbs 43.2"x 27.0" x 2.0" / 36.5 lbs
37.7" x 24.2" x 7.7" / 17.6 lbs 43.2" x 29.1" x 9.5" / 38.1 lbs
Color Enhancement:
(Approx.):
Optical Digital Audio Out:
Wall Mount Pattern:
Stereo Audio Out:
Refresh Rate / Frame Rate:
Display Specification:
PIP / POP:
Close Caption:
Electronic Programming Guide (EPG):
Graphic Equalizer:
Input Port Naming:
Remote:
Antenna In:
Energy Saving Features
Input / Output
Composite (RCA):
Music Port:
USB:
Size Class (Diagonal):
EM55FTR EM65FTR
55” (actual viewable size: 54.6”) 65” (actual viewable size: 65”)
ENGLISH
Resolution / Aspect:
Backlit:
Contrast Ration:
TV Features
Built-in NTSC / ATSC / Clear QAM Tuner:
Parental Control:
Picture Modes:
Audio
Audio Technology:
Speaker Output Power:
Convenience Features
Ambient Sensor:
Interactive Setup Guide:
Audio Only Mode:
HDMI-ARC:
HDMI-CEC:
USB Multimedia:
1920 x 1080 / 16:9 1920 x 1080 / 16:9
DLED DLED
CM120Hz CM120Hz
1200:1 4000:1
Yes Yes
Yes Yes
No No
Yes Yes
Yes Yes
No No
Yes Yes
MTS Stereo Decoder, MTS Stereo Decoder,
Dolby Digital Decoder Dolby Digital Decoder
(5.1 Ch Pass Through) (5.1 Ch Pass Through)
Yes Yes
15 Watts x 2 15 Watts x 2
No No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Auto Power OFF (DPMS):
Energy Star:
Input:
HDMI:
Component:
VGA / RGB:
Output:
Mechanical
Without Stand (WxHxD) and Weight
(Approx.):
With Stand (WxHxE) and Weight
Yes Yes
Yes, Energy Star 6.0 Yes, Energy Star 6.0
1 1
3 (one port for MHL) 3 (one port for MHL)
1 1
1 (shared with component) 1 (shared with component)
0 0
1 1
1 1
1 1
1 1
400mm x 400mm 400mm x 400mm
48.6"x 28.5" x 2.8" / 38.6 lbs 60" x 38.5" x 2.25" / 91.6 lbs
48.6" x 30.2" x 11" / 43.9 lbs 60" x 41" x 15.4" / 103.5 lbs
35
36
ENGLISH
37
38
Limited Warranty
ON PARTS AND LABOR
This Limited Warranty covers units that are purchased as new and in the United States Only. This Product
is manufactured, distributed, and warranted by AmTRAN Video Corporation (hereinafter known as
“Warrantor”) under brand license by JVC KENWOOD Corporation. The Warrantor provides a warranty to
the original purchaser of a new Product against defects in materials and workmanship for a period of
one (1) year of non-commercial usage and ninety (90) days of commercial use. If a Product covered by
this warranty is determined to be defective within the warranty period, the Warrantor will either repair or
replace the Product at its sole option and discretion.
To obtain warranty service, contact our Technical Support:
Visit the Web Site: http://jvc-tv.com/support
Or call our Customer Support and Service Center
1-855-868-1928
PRE-AUTHORIZATION MUST BE OBTAINED BEFORE SENDING ANY PRODUCT TO A DESIGNATED SERVICE
CENTER.
Proof of purchase in the form of a purchase receipt or copy thereof is required to show that a
Product is within the warranty period.
ENGLISH
Parts and Labor
There will be no charge for parts or labor during the warranty period. Replacement parts and
Products may be new or recertied at the Warrantor’s option and sole discretion. Replacement parts and
Products are warranted for the remaining portion of the original warranty or for ninety (90) days
from warranty service or replacement, whichever is longer.
Type of Service
Defective Products must be sent to the designated service center to obtain warranty service. The Warrantor
is not responsible for the transportation costs to the service center, but will cover the costs for return
shipping to the customer. PRE-AUTHORIZATION IS REQUIRED BEFORE SENDING ANY
PRODUCT TO A DESIGNATED SERVICE CENTER FOR WARRANTY SERVICE.
Product returned to designated service centers must utilize either the original carton box and shipping
material or packaging that aords an equal degree of protection. Technical Support will
provide instructions for packing and shipping the covered Product to the designated service center.
Limitations and Exclusions
The Warrantor’s one-year limited warranty only covers defects in materials and workmanship. This warranty
does not cover product issues caused by any other reason, including but not limited to cosmetic damage,
normal wear and tear, improper operation, improper voltage supply or power surges, signal issues,
damages from shipping, acts of God, any type of customer misuse, modications or adjustments, as well
as installation and set-up issues or any repairs attempted by anyone other than by an authorized service
center. Products with unreadable or removed serial numbers, or requiring routine maintenance are not
covered. This one year limited warranty does not cover Products that are sold “AS IS”, “Open Box”, “FACTORY
RECERTIFIED”, or by a non-authorized reseller.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED OR DESCRIBED
ABOVE. ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY
39
AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED IN DURATION TO THE PERIOD OF TIME
SET FORTH ABOVE. THE WARRANTOR’S TOTAL LIABILITY FOR ANY AND ALL LOSSES AND DAMAGES
RESULTING FROM ANY CAUSE WHATSOEVER INCLUDING WARRANTOR’S NEGLIGENCE, ALLEGED
DAMAGE, OR DEFECTIVE GOODS, WHETHER SUCH DEFECTS ARE DISCOVERABLE OR LATENT, SHALL
IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCT. THE WARRANTOR SHALL NOT BE
RESPONSIBLE FOR LOSS OF USE, LOSS OF INFORMATION OR DATA, COMMERCIAL LOSS, LOST REVENUE
OR LOST PROFITS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS
WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE. THIS WARRANTY IS SUBJECT TO CHANGE WITHOUT NOTICE.
CHECK TV.JVC.COM FOR THE MOST CURRENT VERSION.
Personal Data
If your Product is capable of storing personal data and other information, all contents and information
will be deleted in the course of some in-home and all ship-in warranty service. If this occurs, your
product will be restored to you congured as originally purchased. You will be responsible for restoring
all applicable data and passwords. Recovery and reinstallation of user data is not covered under this
Limited Warranty. In order to protect your personal information, we recommends that you always clear
all personal information from the unit before it is serviced, regardless of the servicer.
Important Open Source Software Notice
Some JVC device may contain free software which is based on the license granted under the GNU
General Public License and Lesser General Public License (hereinafter “GPL/LPGL”) that are subject to the
GPL2.0/LGPL2.1 You may use, modify, or distribute only if you agree to all of the terms and conditions of
the GPL/LGPL. For more details on the list of JVC devices with open source software, please visit
http://jvc-tv.com/support
Please note that any software component developed or created independently by AmTRAN Video
Corporation shall not be subject to “GPL/LGPL” requirement for provision of the source code. Users are
urged to read the details for the relevant license carefully before using the software component covered
by “GPL/LGPL.”
You can obtain a copy of the GPL/LGPL license from http://www.gnu.org/licenses/gpl and http://www.
gnu.org/licenses/lgpl.
For details of any open source software on your JVC device, please visit the following web site:
http://jvc-tv.com/support
Please note that we are unable to answer any inquiry relating to the contents, etc of the source code.
Permission is hereby granted, free of charge, to any person obtaining a copy of any such software and
associated documentation les (the “Open Source Software”), to deal in the Open Source Software
without restriction including without limitation the rights to use, copy, modify, merge, publish,
distribute, sublicense, and/or sell copies of the Open Source Software, and to permit persons to whom
the Open Source Software is furnished to do so, subject to the following conditions:
THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTIBILITY, FITNESS FOR A PARTICULAR
PURPOSE AND NON-INFRINGEMENT, IN NO EVENT SHALL THE AUTHORS OR COPYRIGHT HOLDERS BE
LIABLE FOR ANY CLAIM, DAMAGES OR OTHER LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT
OR OTHERWISE, ARISING FROM, OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR
OTHER DEALINGS IN THE SOFTWARE.
40
Roku Streaming Stick™
Important Product Information
The License Agreement
The Roku and third-party software license terms can be found at: www.roku.com/license. Use of the
Roku Streaming Stick (“Streaming Stick”) constitutes acceptance of as well as agreement to those license
terms.
One (1) Year Limited Hardware Warranty
Subject to the additional terms and conditions set forth below, Roku provides this Limited Warranty:
•OnlytothepersonorentitythatoriginallypurchasedtheStreamingStickfromRokuorfromoneofits
authorized re-sellers or distributors; and
•OnlyforStreamingStickspurchasedanddeliveredtotheenduserwithintheUnitedStatesand
Canada.
Limited Warranty
Roku warrants the Streaming Stick hardware against defects in materials and workmanship under normal
use for a period of one (1) year from the date of purchase (“Warranty Period”). If Roku determines that the
Streaming Stick’s hardware is defective, Roku will either repair the unit or replace
the unit with either a new or rebuilt Streaming Stick, at its option. If the Warranty Period has expired or
is otherwise not applicable (see Scope and Limitation on Warranty below), we will return the Streaming
Stick to you. More information about this warranty can be found at www.roku.com/support. THE
FOREGOING SETS FORTH ROKU’S SOLE OBLIGATION AND YOUR EXCLUSIVE REMEDY IN THE EVENT OF
ANY BREACH OF THIS LIMITED WARRANTY. Return and Warranty Service Process Please access and review
the online help resources at www.roku.com/ support before seeking warranty service. To return or obtain
warranty service for a Streaming Stick, you must rst obtain a Return Merchandise Authorization (RMA)
number from a Customer Support Representative (CSR) at Roku. Customer Support
ENGLISH
contact information can be found by visiting www.roku.com/support. RMA numbers expire thirty days
from issuance. Roku may attempt to troubleshoot a warranty-related problem prior to issuing a RMA
number. Please be prepared to provide additional information upon request. Once a RMA number is
obtained, you must ship your Streaming Stick, freight prepaid, together with proof of purchase and all
accessories, in either the original packaging or packaging aording an equal degree of protection, to the
Roku authorized distribution facility identied by the CSR. Failure to return any of the accessories could
result in a delay and/or result in an invoice to you or credit to Roku for the missing accessories. Important:
When emailing for a RMA number, please provide the following information with your request: (a)
model number, (b) serial number, (c)problem description, (d) software version (located in the System
Conguration menu), (e) date of purchase, (f) place of purchase (reseller or online place of purchase),
and (g) return shipping address (P.O. boxes are not accepted). Scope of and Limitation on Warranty The
warranty on the Streaming Stick is limited to the repair or replacement of defective units as described
in the Limited Warranty section above. This warranty does not cover customer training or education,
installation, set up adjustments, or signal reception problems. This warranty also does
not cover any issue related to the service provided by your Service Provider, including but not limited to
service disruption, changes in service terms, changes in oerings, changes in format, or technical
problems. This warranty does not cover damage due to acts of God, accident, misuse, abuse, negligence,
commercial use or modication of, or to any part of, your Streaming Stick.
41
This warranty does not cover damage due to improper operation or maintenance, connection to
improper voltage supply or attempted repair by anyone other than a facility authorized by Roku to
service your Streaming Stick. This warranty does not cover consumables (such as fuses and batteries).
Legal Notices
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one of the following measures:
•Reorientorrelocatethereceivingantenna.
•Increasetheseparationbetweentheequipmentandreceiver.
•Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthereceiveris
connected.
•Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Caution: Any changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment. IEEE 802.11b or 802.11g operation
of this product in the U.S.A. is rmwarelimited to channels 1 through 11. Wireless Radio Use:
This device is restricted to indoor use when operating in the 5.15 to 5.25 GHz frequency band.
IMPORTANT NOTE:
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be installed and operated with minimum
distance 20cm between the radiator and your body. This transmitter must not be collocated or operating
in conjunction with any other antenna or transmitter.
Note to US model owner:
To comply with US FCC regulation, the country selection function has been completely removed
from all US models. The availability of some specic channels and/or operational frequency bands are
country dependent and are rmware programmed at the factory to match the intended destination. The
rmware setting is not accessible by the end user.
Industry Canada statement
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interferencereceived, including interference that may cause undesired operation.
42
French translation:
Ce dispositif est conforme à la norme CNR-210 d’Industrie Canada applicable aux appareils radio
exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif
ne doit pas produire de brouillage préjudiciable, et (2) ce dispositive doit accepter tout brouillage reçu,
y compris un brouillage susceptible de provoquer un fonctionnement indésirable.
Safety Precautions
The Streaming Stick has been designed with the highest concern for safety. However, any electrical
device, if used improperly, has the potential for causing re, electrical shock or personal injury. To help
ensure accident-free operation, follow these guidelines:
•Observeallwarnings,precautionsandinstructions.
•Stopuse,unplugthedevicethattheStreamingStickisinsertedintofromtheelectricaloutletand
disconnect any other cables immediately if the Streaming Stick or the device functions in an abnormal
manner, produces unusual sounds or smells or becomes too hot to touch.
•Formoreinformationonproductsafetyandtroubleshooting,pleasegotowww.roku.com/support.
Use and Handling
•Whenplayingvideogames,useinawell-litareaandstandorsitasfarawayfromthescreenaspossible.
ENGLISH
•Takea10-15minutebreakeveryhourifplayingvideogamesandavoidprolongeduseoftheremote.
•Stopplayingvideogamesifyoubegintofeeltiredorifyouexperiencediscomfortorpaininyour
hands or arms while operating the remote if the condition persists, consult a doctor.
•Ifyouexperienceanyofthefollowinghealthproblems,discontinueuseoftheStreamingStick
immediately:
— Dizziness, nausea, fatigue or symptoms similar to motion sickness.
— Discomfort or pain in a part of the body, such as eyes, ears, hands, or arms. If symptoms persist,
consult your physician.
•KeeptheStreamingStickandanyaccessories,includingtheremote,outofthereachofsmallchildren.
•DonottouchtheStreamingStickduringanelectricalstorm.
•Donotallowliquid,smallparticlesorotherforeignobjectstogetintotheStreamingStickor
accessories.
•DonotexposetheStreamingSticktosmokeorsteam.
•DonotexposetheStreamingStickoraccessoriestohigh,temperatures,highhumidityordirect
sunlight.
www.roku.com
Copyright © 2013 Roku, Inc. All rights reserved. Roku and
the Roku logo are trademarks or registered trademarks of Roku, Inc.
43
Do not send product or other
correspondence to this address
Attn: Product Registration
P.O. BOX 50427
IRVINE, CA 92619
Place
Stamp
Here
Register Online: http://jvc-tv.com/support
First Name
Last Name
Address
Apt. #
City
State
Zip Code
Phone Number
E-mail Address
Model Number
Serial Number
Dealer Name
Purchase Price
Date of Purchase
Comments
I would like to receive the JVC Community e-mail newsletter
Loading...
