JVC EM55RF5, EM50RF5, EM43RF5, EM40RF5 Quick Start Guide

Emerald Series

(EMxxNF5/EMxxRF5)

QUICK START GUIDE

*All Images shown in QSG are for illustration purpose only.

Rev. 1/15 Emerald Series QUICK START GUIDE

IMPORTANT SAFETY INFORMATION

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated dangerous voltage with the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.

• Read and follow all these instructions.

• Heed all warnings.

• Do not use this device near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with manufacturer’s

instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or

other heat-generation devices.

• Do not defeat the safety purpose of the polarized or grounding-type plug. A

polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched, particularly at plugs,

convenience receptacles, and the point where they exit from the device.

• Only use attachments/accessories specified by the manufacturer.

• Use only with the cart, stand, tripod, bracket, or table specified by

the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.

• Unplug this apparatus during lightning storms or when unused for long periods of

time.

• Refer all servicing to qualified service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.

• Apparatus should not be exposed to dripping or splashing, and objects filled with

liquids, such as vases, should not be placed on the apparatus.

• An outside antenna system should not be located in the vicinity of overhead

power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits, as contact
with them might be fatal.

• Do not overload wall outlets and extension cords, as this can result in a risk or fire

or electric shock.

• Do not push objects through any openings in this unit as they may touch

dangerous voltage points or short out parts that could result in fire or electric
shock. Never spill or spray any type of liquid into the unit.

• If an outside antenna or cable system is connected to the unit, be sure the

antenna or cable system is grounded to provide some protection against voltage
surges and built-up static charges, Section 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with respect to proper grounding practices.

• When replacement parts are required, be sure the service technician uses

replacement parts specified by the manufacturer or those that have the same
characteristics as the original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.

• Upon completion of any service or repairs to this unit, ask the service technician

to perform safety checks to determine that the unit is in proper operating
condition.

• When you connect the product to other equipment, turn off the power and

unplug all of the equipment from the wall outlet.

• Sudden high volume sound may cause hearing or speaker damage. When you

use headphones (if the unit is equipped with a headphone jack), keep the volume
at a moderate level.

Rev. 1/15 Emerald Series QUICK START GUIDE

CHECK MATERIALS IN PACKAGE

Roku® Streaming Stick™

(Roku Ready® Version)

(Included only in EMxxRF5 models)

DOWNLOAD FULL VERSION USER MANUAL

http://jvc-tv.com

Rev. 1/15 Emerald Series QUICK START GUIDE

REMOTE CONTROL (EMxxNF5 Models)

LED indicator

Playback Controls

Control USB multimedia and HDMI-CEC/MHL devices

INPUT button

Select Input source

MENU button

AUDIO button

Enter Audio Only Mode

IR Transmitter
TV POWER button
BACK button

Go back to previous selection

MEDIA button

Access USB Multimedia

INFO button

Directional buttons

OK button

VOLUME Controls

MUTE button

Number Pad

To directly key in channels.

Use “-” for sub-channel.

Example: 2-1 or 18-7

CHANNEL Controls

Last button

Return to previous channel

Rev. 1/15 Emerald Series QUICK START GUIDE

REMOTE CONTROL (EMxxRF5 Models)

LED indicator

**Playback Controls

Control USB multimedia and HDMI-CEC/MHL devices

INPUT button

Select Input source

MENU button

AUDIO button

Enter Audio Only Mode

IR Transmitter
TV POWER button

 button**

Go back to previous selection

ROKU Home button**

Enter ROKU Home Page

INFO* button**

Enter ROKU Special Options

Directional buttons

OK button

VOLUME Controls

MUTE button

Number Pad

To directly key in channels.

Use “-” for sub-channel.

Example: 2-1 or 18-7

CHANNEL Controls

Last button**

Return to previous channel

**Compatible with ROKU® Streaming Stick™

Rev. 1/15 Emerald Series QUICK START GUIDE

FRONT VIEW

Power Indicator & Remote Sensor

Rev. 1/15 Emerald Series QUICK START GUIDE

REAR VIEW

EM40NF5
EM40RF5

USB

HDMI / MHL

Digital Optical Out

Audio Out

Power / Multi-Function Button

AC Power

Power / Multi-Function Button Operation:

•Press the button to show Quick Control Menu and switch between options

•Press and hold the button to select highlighted option

•To power off TV, press and hold the button while Quick Control Menu is not on screen

HDMI-1/

ARC

Component /

Video Input

Audio Input/

Music Port

Antenna

Input
