JVC EM50RF5, EM55RF5, EM43RF5 User Manual
Emerald Series LED HDTV
USER MANUAL
EM40NF5 40” Class
EM43NF5 43” Class
EM50NF5 50” Class
EM55NF5 55” Class
EM40RF5 40” Class
EM43RF5 43” Class
EM50RF5 50” Class
EM55RF5 55” Class
Before operating your LED TV, please read this manual thoroughly.
(*Images shown in this user manual are for illustration purpose only.)
1
Rev. 1/15
2
Contents
Congratulations on purchasing your new JVC TV. To get the most out of your JVC LED TV, read these
instructions before making any adjustments, and retain them for future reference.
For assistance, call the JVC Customer Support and Service Center 1-855-868-1928 or visit our website:
http://jvc-tv.com/support
We recommend that you register your JVC LED TV either at our website: http://jvc-tv.com/support or ll
out and mail the Product Registration Card on the back of the manual.
Retain your purchase receipt and write down the model and serial number located at the back of your
LED TV for easy reference when obtaining service support.
Serial Number:
Model Number:
MHL, Mobile High-Denition Link and the MHL Logo are
trademarks or registered trademarks of the MHL, LLC.
The terms HDMI and HDMI High-Denition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other countries.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS;
IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. JVC, THE JVC LOGO, AND OTHER
JVC TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF JVC KENWOOD Corporation.
PRODUCT SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.
This product qualies for ENERGY STAR in the “factory default” setting
and this is the setting in which power savings will be achieved.
Changing the factory default picture setting or enabling other
features will increase power consumption that could exceed the
limits necessary to qualify for Energy Star rating.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
Copyrights © 2015 AmTRAN Video Corporation. ALL RIGHTS RESERVED.
3
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To Reduce The Risk Of Electric Shock, Do Not Remove Cover (Or Back). No User-Serviceable Parts
Inside. Refer Servicing To Qualied Service Personnel.
The lightning ash with arrowhead symbol, within
an equilateral triangle is intended to alert the user
to the presence of uninsulated dangerous voltage
within the product’s enclosure that may be of
sucient magnitude to constitute a risk of electric
shock.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE. TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
WARNING: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the following measures: - Reorient
or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect
the equipment into an outlet on a circuit dierent from that to which the receiver is connected. - Consult
the dealer or an experienced radio/TV technician for help. FCC Caution: To assure continued compliance,
(example – use only shielded interface cables when connecting to computer or peripheral devices). Any
changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
Responsible Party: AmTRAN Video Corporation
Address: 9 Goddard, Irvine, CA 92618 USA
Telephone No: 1-855-868-1926
CAUTION: Changes or modications not expressly approved by the party responsible for compliance with the FCC Rules
could void the user’s authority to operate this equipment.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
4
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding-type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your safety. If the provided plug does not
t into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched, particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specied by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15) Apparatus should not be exposed to dripping or splashing, and objects lled with liquids, such as
vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing
an outside antenna system, extreme care should be taken to keep from touching such power lines
or circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of re or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points
or short out parts that could result in re or electric shock. Never spill or spray any type of liquid into
the unit.
19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system
is grounded to provide some protection against voltage surges and built-up static charges, Section
810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
20) When replacement parts are required, be sure the service technician uses replacement parts
specied by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in re, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety
checks to determine that the unit is in proper operating condition.
5
Important Safety Instructions
22) When you connect the product to other equipment, turn o the power and unplug all of the
equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal
injury. Read the owner’s manual of the other equipment carefully and follow the instructions when
making any connections.
23) Sudden high volume sound may cause hearing or speaker damage. When you use headphones,
(if the unit is equipped with a headphone jack) keep the volume at a moderate level. If you use
headphones continuously with high volume sound, it may cause hearing damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause
speaker overheating and re.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, species that the cable ground
shall be connected to the grounding system of the building, as close to the point of cable entry as
practical.
26) The socket-outlet must be installed near the unit and easily accessible.
CHILD SAFETY:
It Makes A Difference How and Where You Use TV
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger TVs are popular purchases. However, TVs are not
always supported on the proper stands or installed according to the manufacturer’s recommendations.
TVs that are inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and
cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT t all. Follow the manufacturer’s recommendations for the safe installation and use of your TV.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place TVs on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” TV. Care should be
taken to place or install the display where it cannot be pushed, pulled over, or knocked down.
Care should be taken to route all cords and cables connected to the TV so that they cannot be pulled or grabbed by curious
children.
6
Important Safety Instructions
CONDENSATION
Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into
a warm room or if the temperature of the room rises suddenly. When this happens, unit’s performance
will be impaired. To prevent this, let the unit stand in its new surroundings for about an hour before
switching it on, or make sure that the room temperature rises gradually. Condensation may also form
during the summer if the unit is exposed to the breeze from an air conditioner. In such cases, change the
location of the unit.
HOW TO HANDLE THE LED PANEL
• Do not press hard or jolt the LED panel. It may cause the LED panel glass to break and injury may
occur.
• If the LED panel is broken, make absolutely sure that you do not touch the liquid in the panel. This
may cause skin inammation.
• If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also if the liquid
gets in your eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or
longer in clean water.
Possible Adverse Effects on LED Panel:
If a xed (non-moving) pattern remains on the LED Panel for long periods of time, the image can become
permanently ingrained in the LED Panel and cause subtle but permanent ghost images. This type of
damage is NOT COVERED BY YOUR WARRANTY. Never leave your TV on for long periods of time while it is
displaying the following formats or images:
• Fixed Images, such as stock tickers, video game patterns, TV station logos, and website.
• Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on
a widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation.
• LED Panels are manufactured using an extremely high level of precision technology, however
sometimes parts of the screen may be missing picture elements or have luminous spots. This is not a
sign of a malfunction.
• Do not install the TV near electronic equipment that produces electromagnetic waves. Some
equipment placed too near this unit may cause interference.
• Eect on infrared devices – There may be interference while using infrared devices such as infrared
cordless headphones.
7
Important Safety Instructions
Television Antenna Connection Protection
External Television Antenna Grounding
If an outside antenna/satellite dish or cable system is to be connected to the TV, make sure that the
antenna or cable system is electrically grounded to provide some protection against voltage surges and
static charges.
Article 810 of the National Electrical Code, ANSI/NFPSA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of the grounding conductors, location of antenna discharge unit, connection to grounding
electrodes, and requirements of the grounding electrode.
ANTENNA LEAD IN WIRE
GROUND CLAMP
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
(NEC SECTION 810-21)
Lightning Protection
For added protection of the TV during a lightning storm or when it is left unattended or unused for long
periods of time, unplug the TV from the wall outlet and disconnect the antenna or cable system.
Power Lines
Do not mount the antenna near overhead light or power circuits, or where it could fall into such power
lines or circuits.
8
Important Safety Instructions
DTV Transition Advisory
As of June 12, 2009, all U.S. television stations have switched to digital broadcasting. As a result, owners
of analog television sets must connect a digital-to-analog converter box to the television set or subscribe
to cable or satellite TV to receive over-the-air TV. Analog-only TVs continue to work as before to receive
low power, Class A or translator television stations and with cable and satellite TV services, gaming
consoles, VCRs, DVD players, and similar products.
For more information about the DTV transition, visit www.dtv.gov.
FCC’s Consumer Center
Email: dtvinfo@fcc.gov
Phone: 1-888-CALL-FCC (1-888-225-5322)
Fax: 1-866-418-0232; or writing to:
Mail: Federal Communications Commission
Consumer and Governmental Aairs Bureau
Consumer Inquiries and Complaints Division
445 12th Street, SW
Washington, DC 20554
9
Attaching the Stand
The stand installation varies depending on
model. Perform the installation according to the
instructions of your TV model.
Unpacking the TV
1 Remove TV accessories and protective foam.
2 Remove TV from the box and place it on a at
and clean surface with TV screen facing down.
3 Attach the stand to TV using the provided screw.
EM40NF5
EM40RF5
EM43NF5
EM43RF5
EM50NF5
EM50RF5
EM55NF5
EM55RF5
Removing the Stand
When the TV needs to be transported, remove the
stand and pack the TV back in the carton.
To remove the stand, perform the assemble steps
in reverse order according to your TV model.
10
Package Contents
Check if the following items are included in your package.
LED TV
Remote Control
Quick Start Guide
Quick Start
Guide
DOWNLOAD FULL VERSION USER MANUAL
http://jvc-tv.com/support
Batteries
Power Cord
Remote Control Batteries
1 Push the tab, then lift to open the cover.
2 Insert the batteries, making sure the [+] and [-]
polarities are correct.
3 Close the battery cover.
Battery Precautions:
Be sure to follow the correct polarity. Incorrect installation
may cause battery leakage or damage the remote control.
Always replace batteries in pair. Do not combine a used
battery with a new one.
Do not use dierent battery types together
(e.g. “Alkaline” and “Carbon-zinc”).
If the remote control is not to be used for a long period of
time, remove the batteries to prevent battery leakage.
11
Parts and Functions
EM40NF5
EM40RF5
Front View
Power indicator
Remote control IR receiver
EM40NF5
EM40RF5
Rear View
USB
HDMI/MHL
Digital Optical
Output
Audio Out
Power Button
12
AC Power
HDMI-1/
ARC
Component/
Video Input
Audio Input/
Music Port
Antenna
Input
Parts and Functions
EM43NF5
EM43RF5
Front View
Power indicator
Remote control IR receiver
Power and
Function Buttons
EM43NF5
EM43RF5
Rear View
USB
HDMI/MHL
Digital Optical
Output
Audio Out
13
AC Power
HDMI-1/
ARC
HDMI-2
Component/
Video Input
Audio Input/
Music Port
Antenna
Input
Parts and Functions
EM50NF5
EM50RF5
Front View
Power indicator
Remote control IR receiver
Power and
Function Buttons
EM50NF5
EM50RF5
Rear View
USB
HDMI/MHL
Digital Optical
Output
Audio Out
14
AC Power
HDMI-1/
ARC
HDMI-1
HDMI-2
Component/
Video Input
Audio Input/
Music Port
Antenna
Input
Loading...
