JVC DT-V17L3D User Manual

DT-V17L3D

CAUTION:

To reduce the risk of electric shock. Do
not remove cover (or back). No user
serviceable parts inside. Refer servicing
to qualified service personnel.

RISK OF ELECTRICAL SHOCK

DO NOT OPEN

The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated “dangerous voltage”
within the product’s enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.

The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.

CAUTION

INSTRUCTIONS

MULTI FORMAT LCD MONITOR

Table of Contents

Safety Precautions .............................................. 2

IMPORTANT SAFEGUARDS ........................... 2

Installation ............................................................ 4

Daily Operations / Connections ......................... 6

Front panel ....................................................... 6

Rear panel ........................................................ 8

Available signals ............................................... 9

Menu Configuration—MAIN MENU .................. 10

Menu Configuration—SET-UP MENU ............... 14

External Control ................................................. 16

About the external control .............................. 16

Using the MAKE/TRIGGER system ............... 17

Using the serial communication ..................... 18

Troubleshooting ................................................. 19

Self-check program ........................................ 20

Maintenance ....................................................... 20

Specifications .................................................... 21

General ........................................................... 21

Input/output terminals ..................................... 21

Dimensions ..................................................... 22

LCT2457-001A

Safety Precautions

2

WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO

RAIN OR MOISTURE. NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE
PLACED ON THE APPARATUS.

IMPORTANT SAFEGUARDS

Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure
your personal safety. But IMPROPER USE CAN RESULT IN POTENTIAL ELECTRIC SHOCK OR FIRE. In order
not to defeat the safeguards incorporated into this product, observe the following basic rules for its installation,
use, and service. Please read these “IMPORTANT SAFEGUARDS” carefully before use.

• All the safety and operating instructions should be read before the product is operated.

• The safety and operating instructions should be retained for future reference.

• All warnings on the product and in the operating instructions should be adhered to.

• All operating instructions should be followed.

POWER CONNECTION

The power supply voltage rating of this product is AC 120 V (For U.S.A. and Canada) and AC 220 – 240 V (For
European countries, Asian countries, and United Kingdom).
The power cord attached conforms to the following power supply voltage and countries. Use only the power
cord designated to ensure safety and EMC regulations of each country.

• Not all types of power cords are supplied to this product.

For U.S.A. and Canada:
AC 120 V

This plug will fit only into a grounded power outlet. If you are unable to insert the plug into the outlet, contact
your electrician to install the proper outlet. Do not defeat the safety purpose of the grounded plug.

• This product should be operated only with the type of power source indicated on the label. If you are not
sure of the type of power supply of your home, consult your product dealer or local electric power company.

Warning:

• Do not use the same power cord for AC 120 V as for AC 220 – 240 V. Doing so may cause malfunction,
electric shock or fire.

Note for United Kingdom power cord only

The plug of United Kingdom power cord has a built-in fuse. When replacing the fuse, be sure to use only a
correctly rated approved type, re-fit the fuse cover. (Consult your dealer or qualified personnel.)

How to replace the fuse

Open the fuse compartment with the blade screwdriver, and replace the fuse.

Warning: This is a class A product. In a domestic environment this product may cause radio interference in

which case the user may be required to take adequate measures.

• Before connecting other products such as VCR’s and personal computers, you should turn off the power of
this product for protection against electric shock.

• Do not use attachments not recommended by the manufacturer as they may be hazardous.

• When replacement parts are required, be sure the service technician has used replacement parts
specified by the manufacturer or equivalents. Unauthorized substitutions may result in fire, electric shock, or
other hazards.

• Upon completion of any service or repairs to this product, ask the service technician to perform safety
checks to determine that the product is in proper operating condition.

For European and
Asian countries:
AC 220 – 240 V

For United Kingdom:
AC 220 – 240 V

Fuse

Under the following conditions,

1. Turn off the power.

2. Unplug this product from the wall outlet.

3. Refer service to qualified service personnel.

a) When the product emits smoke or unusual

smell.

b) When the product exhibits a distinct change in

performance —for example, no picture or no
sound.

c) If liquid has been spilled, or objects have fallen

on the product.
d) If the product has been exposed to rain or water.
e) If the product has been dropped or damaged in

any way.
f) When the power supply cord or plug is

damaged.

• Do not install this product in the following places:
– in a damp or dusty room
– where the product is exposed to soot or

steam, such as near the cooking counter or a

humidifier
– near heat sources
– where condensation easily occurs, such as

near the window

• Do not place this product on an unstable cart,
stand, or table. The product may fall, causing
serious injury to a child or adult, and serious
damage to the product.

The product should be mounted according to the

manufacturer’s instructions, and should use a
mount recommended by the manufacturer.

• Do not use this product near water.

• Be sure to install the product in the place where
proper temperature and humidity are kept (☞
“Operating conditions” on page 21).

This product becomes hot during its use. Take

enough care when handling the product.

Do not attempt to service this product yourself, as
opening or removing covers may expose you to
dangerous voltages and other hazards. Refer all
service to qualified service personnel.

Do not use the product for a long time if the sound
is distorted.

Use only the power source specified on the unit.

• AC power: 120 V/220 – 240 V, 50 Hz/60 Hz

• DC power: 12 – 17 V

• The AC power supply is controlled by turning on/
off the POWER switch on the rear panel. If the
product is installed in a place where you cannot
easily turn on/off the POWER switch, control the
AC power supply by plugging/unplugging the
power cord into/from the AC outlet. In this case,
install the product as close to the AC outlet as
possible, and leave enough space for plugging/
unplugging the power cord. If the product is
installed in a place where you cannot easily
plug/unplug the power cord, equip an easily
accessible device to the wiring of the building for
turning on/off the power.

• When the product is left unattended and unused
for a long period of time, unplug it from the wall
outlet and disconnect the cable system.

• Do not overload wall outlets, extension cords, or
convenience receptacles on other equipment as
this can result in a risk of fire or electric shock.

• Use only the accessory cord designed for this
product to prevent shock.

• Slots and openings in the cabinet are provided
for ventilation. These ensure reliable operation
of the product and protect it from overheating.
These openings must not be blocked or covered.

• Never push objects of any kind into this product
through openings as they may touch dangerous
voltage points or short-circuit the parts, which
could result in a fire or electric shock.

• Never spill liquid of any kind on the product.

• Never place anything on the product. (Placing
liquids, naked flames, cloths, paper, etc. on the
product may cause a fire.)

• Do not apply any strong shock to the LCD panel.
(Do not hit any object against it or push it with a
sharp-pointed tool.)

• Do not put heavy objects on the product.

• Do not step on or hang on the product.

Caution for use of the product in the high
temperature

Do not use the product in places of high
temperature; otherwise, parts of this product or
the LCD panel may be damaged. This product
is equipped with a temperature sensor to give
warning if the temperature becomes too high. If
the temperature exceeds the range of normal use,
“TEMP. OVER” is displayed, and the power is turned
off automatically if the temperature becomes any
higher. In this case, move the product to a place of
low temperature to let it cool down.

U.S.A. only

FCC NOTICE
CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the

equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the interference at
his own expense.

IMPORTANT RECYCLING INFORMATION

This product has a fluorescent lamp that contains mercury. Disposal of these materials
may be regulated in your community due to environmental considerations. For disposal
or recycling information, please contact your local authorities or for USA, the Electronic
Industries Alliance: http://www.eiae.org

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS

APPARATUS TO RAIN OR MOISTURE.

WARNING: THIS APPARATUS MUST BE CONNECTED TO A MAINS SOCKET OUTLET

WITH A PROTECTIVE EARTHING CONNECTION.

CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.

REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE.

IMPORTANT SAFETY INSTRUCTIONS

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11) Only use attachments/accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.

15) Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases, shall be
placed on the apparatus.

16) Batteries shall not be exposed to excessive heat such as sunshine, fire or the like.

17) When discarding batteries, environmental problems must be considered and the local rules or laws governing the
disposal of these batteries must be followed strictly.

European Union only

Dear Customer,

This apparatus is in conformance with the valid
European directives and standards regarding
electromagnetic compatibility and electrical safety.

European representative of Victor Company of Japan,
Limited is:
JVC Technical Services Europe GmbH
Postfach 10 05 04
61145 Friedberg
Germany

Information for Users on Disposal of Old
Equipment

[European Union]

This symbol indicates that the
electrical and electronic equipment
should not be disposed as general
household waste at its end-of­life. Instead, the product should
be handed over to the applicable
collection point for the recycling of
electrical and electronic equipment
for proper treatment, recovery and
recycling in accordance with your

Attention:

This symbol is
only valid in the
European Union.

be caused by inappropriate waste handling of this
product. For more information about collection point
and recycling of this product, please contact your
local municipal office, your household waste disposal
service or the shop where you purchased the product.

Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.

(Business users)

If you wish to dispose of this product, please visit our
web page www.jvc-europe.com to obtain information
about the take-back of the product.

[Other Countries outside the European Union]

If you wish to dispose of this product, please do so in
accordance with applicable national legislation or other
rules in your country for the treatment of old electrical
and electronic equipment.

national legislation.

By disposing of this product
correctly, you will help to conserve
natural resources and will help
prevent potential negative effects
on the environment and human
health which could otherwise

EMC Supplement

This equipment is in conformity with the provisions
and protection requirements of the corresponding
European Directives. This equipment is designed for
professional video appliances and can be used in the
following environments:

• Controlled EMC environment (for example purpose
built broadcasting or recording studio), and rural
outdoors environment (far away from railways,
transmitters, overhead power lines, etc.)

In order to keep the best performance and ensure
electromagnetic compatibility, we recommend to use
cables not exceeding the following length:

Cable Length

Power cord 2.0 m
(attached cable (H05VV-F 3 x 0.75 mm

Video signal cable (coaxial cable) 2.0 m

Audio signal cable (shielded cable) 1.5 m

DVI cable (shielded cable) 2.0 m

RS-232C cable (shielded cable) 2.0 m
(A straight cable with a D-sub 9-pin connector)

RS-485 cable (twist pair cable) 2.0 m
(A straight LAN cable)

REMOTE cable (twist pair cable) 2.0 m
(A straight LAN cable)

The inrush current of this apparatus is 8.947 ampere.

CAUTION

In case where the strong electromagnetic waves or
magnetism are near the audio cable or the signal
cable, the sound or the picture will contain noise. In
such cases, please keep the cable away from the
sources of the disturbance.

2

))

3

Installation

4

CAUTION

• Do not rest your arm on the monitor or lean against the monitor.

• Do not touch the LCD panel when installing the monitor.

• Be sure to install the monitor securely to prevent the monitor from falling over, which may cause damage to the monitor
or injury.

You can place the monitor in the following two ways when using it on the supplied stand.

You can tilt the monitor as follows.

Monitor

About 12°

0°

About 8°

• When the monitor is not tilted (0°), the
guidelines align as illustrated below.

• You can select the stand height—higher position
or lower position (☞ “To adjust the stand height” on
page 5).

Stand

Guidelines

When the stand plate is attached to the higher
position of the stand body (☞ “To adjust the stand
height” on page 5), you can place the monitor as
illustrated below.

1 Remove the screws on the right side of the stand

(see the illustration below), then lift the stand up
by about 144°.

About
144°

Screw
(silver)

2 Attach the removed screws and place the monitor

as illustrated below.

To detach the stand

CAUTION

Lay the monitor on a cloth with the LCD panel facing down to prevent the LCD panel from being damaged.

Attachment screws

Screw holes for stand attachment

Stand body

Monitor

To install the stand

When attaching the stand to the monitor, insert the guides of the stand into the guide holes on the monitor to
place the stand in the correct position. Then fix the stand firmly with the attachment screws.

Guide holes

CAUTION

• Be careful not to pinch your fingers in the gap between
the monitor and the stand.

• When the stand plate is attached to the lower
position of the stand body, you cannot tilt the monitor
downward.

• To place the monitor as illustrated on the left again,
remove the screws on the right side of the stand,
return the monitor angle to 0°, then reattach the
removed screws.

CAUTION

• When lifting up the stand...
– lay the monitor on a cloth with the LCD panel

facing down to prevent the LCD panel from being
damaged.

– be careful not to pinch your fingers in the moving

parts.

• Make sure of lifting the stand up until it stops (about
144°); otherwise the monitor may fall over.

• Place the monitor on a mat to avoid scratching the
table surface.

• Do not lift up the stand when the stand plate is
attached to the lower position of the stand body.

• When the battery is attached, the stand may not be
lifted up depending on the type of the battery.

Guides

Stand body

Screw holes
for stand
attachment

Stand plate

Monitor

To adjust the stand height

To change the stand height, detach the stand from the monitor (☞ “To detach the stand” on page 4). Then,
change the position of the stand plate according to the stand height you want by choosing the screw holes to use.

<Higher position> <Lower position>

Stand plate

Screw holes for higher position

Stand plate

Screw holes for lower position

To prevent an accidental fall

Fix the monitor to a wall by using strings.

Fixing the monitor

Attach the hook (not provided) to the VESA mounting holes on the rear panel (use the two holes on the upper
side) using M4 x 10 mm screws (not provided). Bind the hooks on the rear panel of the monitor to a wall or a pillar
using durable string.

VESA mounting holes

Stand body

Stand body

Hook and screw (M4 x 10 mm)

(not provided)

Hook (not provided)

5

Daily Operations / Connections

6

7 Front panel

Tally lamp

This lamp is controlled by the tally function of the
MAKE/TRIGGER terminal.

• You can select the color of the tally lamp from

GREEN” or “RED”.

“
☞ “ TALLY SELECT” in “FUNCTION SETTING” on
page 14 and “External Control” on page 16

1 Speakers (stereo)

The speakers emit the same audio signal emitted
from the AUDIO (MONITOR OUT) terminals.
(☞ “ 5 AUDIO (MONITOR OUT) terminals” on
page 8)

2 VOLUME adjustment knob

Adjusts the volume.

3 Picture adjustment knob

PHASE: Adjusts the picture hue.
CHROMA: Adjusts the picture color density.
BRIGHT: Adjusts the picture brightness.
CONTRAST: Adjusts the picture contrast.

4 MUTING button

Tu r ns off the sound when no menu screen is
displayed.

• To cancel the function, press the button again or
turn the VOLUME adjustment knob.

• Muting function is also canceled when
“BALANCE” of “AUDIO SETTING” in the MAIN
MENU is changed (☞ page 12).

• “NO EFFECT” is displayed when you press a button which is not available for the current input or signal format (the lamp lights even when the function does not
actually work).

• The items controlled by the MAKE system cannot be controlled by the buttons on the front panel (“REMOTE ON” is displayed and the lamps do not light).

5 / / / buttons

When a menu screen is displayed

Selects or adjusts menu items. (☞
Operations” on page 7)

When no menu screen is displayed

Selects the audio channels of EMBEDDED AUDIO
signals. (☞ “Audio Channel Selection” on page 7)

•

Pressing button while holding button displays the
SET-UP MENU. (☞

6 MENU button

Activates/deactivates the display of the MAIN MENU.
(☞ “Menu Operations” on page 7)

7 COLOR OFF button/lamp

Displays only the luminance signal.

• This function does not work for RGB input signals.

8 1:1 button/lamp

Displays the picture in the original resolution of the
input signal.

• The aspect ratio of the picture may change
depending on the input signal.

9 AREA MARKER button/lamp

Displays/hides the area marker.

• Select the style of the area marker in “MARKER”
of the MAIN MENU (☞ page 11).

• This function works only when displaying the
picture in 16:9 aspect ratio.

• This function does not work when “AREA
MARKER” or “R-AREA MARKER” is set to “OFF”
in “MARKER.”

p SAFETY MARKER button/lamp

Displays/hides the safety marker.

• Adjust the area of the safety marker in “MARKER”
of the MAIN MENU (☞ page 11).

• This function does not work when displaying the
picture in the 1:1 mode.

• This function does not work when “SAFETY
MARKER” or “R-SAFETY MARKER” is set to
“OFF” in “MARKER.”

“Menu Operations” on page 7)

“Menu

q SCREENS CHECK button/lamp

Displays only the selected element (R, G, or B) of
the video signal.

• Each time you press this button, the screen
changes in the following order.

RGB (Normal screen) Red screen

Green screenBlue screen

w ASPECT button/lamp

Changes the aspect ratio of the picture from 4:3
to 16:9 when the picture of 16:9 aspect ratio is
squeezed into 4:3 format signal.

• To return to 4:3, press the button again.

• This function does not work when displaying the
picture in the 1:1 mode.

e WAVE FORM button/lamp

Displays/hides the indication of the wave form
monitor.

• Adjust the settings of the wave form monitor in
“WAVE FORM SETTING” of the MAIN MENU
(☞ page 13).

r T.C. (time code) button/lamp

Activates/deactivates the display of the time data
(time code) contained in the SDI signal.
(☞

“On the

Information Display

t INPUT SELECT buttons/lamps

Selects an input.

SDI 1: E. AUDIO HD/SD SDI (IN 1) terminal
SDI 2: E. AUDIO HD/SD SDI (IN 2) terminal
DVI: DVI-D (HDCP) terminal
COMPO.: COMPO. terminal
VIDEO: VIDEO terminal

• The lamp for the selected input lights.

” on page 7)

y Power lamp

Unlit: The monitor is completely off (both the

POWER switch and DC switch on the rear panel
are turned off).

Lights in Green: The monitor is on.
Lights in orange: The monitor is off (on standby).
Flashes in orange: The monitor is in the P. SAVE

(power save) mode (☞ “NO SYNC ACTION” in
“SYNC FUNCTION” on page 13).

u button

Tu r ns on and off (on standby) the monitor.

• The power switches (the POWER switch and DC
switch) are equipped on the rear panel of the
monitor (☞ p, w on page 8).

• To turn off the monitor completely, turn off the
POWER switch and DC switch.

i DC lamp

When the DC 12 V power voltage is being lowered
due to the battery consumption, the lamp changes
to orange from green. When the voltage becomes
lower than a certain level, the monitor automatically
turns off and the lamp turns to red.

• Make sure to turn off the POWER switch and
DC switch on the rear panel before replacing the
battery.

• The length of time that the lamp lights in orange
differs depending on the type of battery or the
battery condition. It is recommended to replace
the battery when the lamp turns to orange.

Menu Operations

On the Information Display

On the Status DisplayAudio Channel Selection

1 Display the menu.

To display the MAIN MENU

\

Press MENU button.

To display the SET-UP MENU

\

Press button while holding button.

MAIN MENU

Selected item

Operation guide

SET-UP MENU

Selected item

Operation guide

2 Press buttons to select an item,

then press button.

• For some items, adjustments will be made by
pressing .

Ex.: When “MARKER” in the MAIN
MENU is selected

3 Press buttons to select an item,

then press buttons to make
adjustments.

4 Press MENU button to finish the

menu operation.

• Pressing MENU button repeatedly
deactivates the display of the menu.

Select audio channels emitted from the speakers
(L/R) and the AUDIO (MONITOR OUT) (OUT1(L)/
OUT2(R)) terminals, when EMBEDDED AUDIO
signals come in to the E. AUDIO HD/SD SDI
terminal (IN1 or IN2) and SDI input (1 or 2) is
selected.

• You have to choose a group of selectable audio
channels before the channel selection (☞
“E.AUDIO GROUP” in “AUDIO SETTING” on
page 12).

• The setting is memorized for each input (SDI 1
and SDI 2).

1 Press or button when a menu

is not displayed.

The screen for audio channel selection is
displayed.

• The screen for audio channel selection
automatically disappears in about 30
seconds after the previous operation.

Audio channel selection screen

Selected item

2 Press buttons to select the left

(L ch) or right (R ch).

3 Press buttons to select an

audio channel.

• Each time you press the button, the audio
channel changes according to the settings of
“E.AUDIO GROUP” (☞ “NOTE” on page 12).

4 Press MENU button.

The screen for audio channel selection
disappears.

Using the audio level meter

You can check the conditions of the current
EMBEDDED AUDIO signals in the audio level meter.
(☞

“On the Information Display” on the right,“LEVEL

METER SETTING” in “AUDIO SETTING” on page 12)

The monitor displays the information below.

•

Make the setting to display/hide each information

using the MENU with the exception of
controlled with T.C. button (☞ r on page 6).

• Select the position of the information display
(☞ “POSITION” in “INFORMATION” on page

15).

1 Audio level meter

Not displayed when “LEVEL METER ch” is set

•
to “OFF.”

2 Signal format

• Displayed when “STATUS DISPLAY” is set to

• For the contents displayed, see “On the

3

Source name assigned in “CHARACTER SET.”

• Displayed when “SOURCE ID” is set to “ON.”

• Displayed in large letters when “STATUS

☞ “INFORMATION” on page 15

4 CRC error indication

• Displayed when “

• A red square is displayed when an error

5 Time code

• When the input signal includes no time code,

☞ “ r T.C. (time code) button/lamp” on page 6

• When any information of 1, 2, 3, or 4

above is displayed while signals come in from
equipment other than a computer, the picture is
displayed without overlapping the information
display area.

However, the information display will overlap

with the picture when...
– displaying the picture with higher resolution

than the resolution of the panel in 1:1 mode.

.

– “SD4:3 LARGE” setting is “ON.”

(☞ “FUNCTION SETTING” on page 14).

(☞ “AUDIO SETTING” on page 12)

“ON.” (☞ “INFORMATION” on page 15)

signal format” below and “Available signals”
on page 9.

DISPLAY” is set to “OFF” or “AUTO.”

CRC ERROR

(☞ “INFORMATION” on page 15)

occurs.

“TC – –:– –:– –:– –” is displayed.

5,

” is set to “ON.”

If you press the INPUT SELECT button (☞ t on
page 6) currently lit, the status of the input signal
and setting of muting are displayed for about 3
seconds.

• Make the setting to display/hide the status in
“STATUS DISPLAY” of the “INFORMATION” (☞
page 15).

• When “STATUS DISPLAY” is set to “AUTO” or
“ON,” the status below is also displayed in the
following cases:
– When you change the input
– When the signal condition of the current input

changes

– When you turn on the monitor

• When “STATUS DISPLAY” is set to “ON,” the
signal format will remain displayed 3 seconds
after the status is displayed.

1 Signal format

• For the contents displayed, see “On the
signal format” below and “Available signals”
on page 9.

2 Signal format of DVI input

☞ “DVI INPUT SEL.” on page 10

3 Setting of “MUTING”

• Displayed only when muting is activated.

☞ “ 4 MUTING button” on page 6

On the signal format

The following messages appear depending on the
type of input signals and their conditions.

When a DVI-D signal protected with HDCP is input

\

“*” (at the end of the indication)

When no video signal comes in

\

“NO SYNC”

When a noncompliant video signal comes in

\

“Out of range”

When “COLOR SYSTEM” (☞ “FUNCTION
SETTING” on page 14) is set to “AUTO” and the
noncompliant composite video signals come in

\

“OTHERS”

7

Daily Operations / Connections (cont.)

8

8

7 Rear panel

Carry handle

Use this handle when carrying the monitor.

e

r

CAUTION

Do not connect the
power cord until all
other connections are
completed.

1 REMOTE terminal

Te r minal for controlling the monitor by an external
control. (☞ “External Control” on page 16)

2 VIDEO terminals (BNC)

Input (IN) and output (OUT) terminals for the
composite video signals.

3 COMPO. (Y, PB/B-Y, PR/R-Y) terminals (BNC)

Input (IN) and output (OUT) terminals for the analog
component video (color difference) signals.

4 AUDIO (IN) terminals (pin jack)

Input terminals for the analog audio signals.

• Use this terminal for the analog audio connection
of the SDI.

5 AUDIO (MONITOR OUT) terminals (pin jack)

Output terminals for the analog audio signal.

• The terminals emit the audio signals through
the AUDIO (IN) terminal or EMBEDDED AUDIO
signals through the E. AUDIO HD/SD SDI (IN 1 or
IN 2) input terminal.

• The signal is output from this terminal only
when the monitor is on or in “P.SAVE” (power
save) mode. (☞ “NO SYNC ACTION” in “SYNC
FUNCTION” on page 13)

• The EMBEDDED AUDIO signal...

– is decoded into an analog signal, then emitted.
– is emitted only when “SDI 1” or “SDI 2” is

selected, and when EMBEDDED AUDIO
signals come in to the E. AUDIO HD/SD SDI
(IN 1 or IN 2) terminal.

6 E. AUDIO HD/SD SDI (IN 1, IN 2) terminals (BNC)

Input terminals for the HD/SD SDI signals.

• The terminals accept also EMBEDDED AUDIO
signals including up to 12 audio channels with a
sampling frequency of 48 kHz.

7 E. AUDIO HD/SD SDI (SWITCHED OUT) terminal

(BNC)

Output terminal for the HD/SD SDI signals.

• The SDI signals of the current input (SDI 1 or SDI

2) are re-clocked, then emitted.

• When an input other than SDI 1 and SDI 2 is
selected, the SDI signal of the input selected last
time is emitted from this terminal.

• The signals are emitted from this terminal only
when the monitor is on or in “P.SAVE” (power
save) mode.

8 DVI-D (HDCP) terminal

Input terminal for the DVI-D signal compatible with
HDCP.

• When the picture is not displayed correctly,
change the setting of “DVI INPUT SEL.”

(☞ page 10).

9 DC IN 12V terminal

DC 12 V (maximum
DC 17 V) power input
connector.

When using DC 12 V power (maximum DC 17 V),
check the DC IN 12V terminal pin signal, and use
the correct polarity. If the polarity is reversed, this
could cause a fire or personal injury.

• While using both the AC and DC 12 V power
supply, AC power supply is preferentially used. If
the AC power supply is cut off (for example, when
turning off the POWER switch), the power supply
automatically switches to the DC 12 V power
supply.

p DC switch

Tu r ns the DC 12 V power on or off.

• You need to press

6) on the front panel to turn on the monitor after
turning on the DC switch.

• The monitor consumes the battery even while the
monitor is on standby. To save battery life, turn off
the DC switch.

q AC IN terminal

AC power input connector.
Connect the provided AC power cord to an AC
outlet.

• Attach the provided power cord holder to prevent
accidental disconnection of the AC power cord (☞
“Attaching the power cord holder” on page 9).

button (☞ u on page

w POWER switch

Tu r ns AC power on or off.

• You need to press button (☞ u on page 6)

to use the monitor after turning on the POWER
switch.

e Screw holes for external battery attachment

Attach external battery for DC 12 V power supply
by using 2 screw holes. Choose the appropriate
screw holes from 1, 2, 3 or 4, according to the type
of external battery.

• Use the Anton Bauer Dionic 90 (mount: QR DXC­M3A) external battery.

CAUTION

• Do not use the external battery for DC 24 V
power supply.

• Use only the battery specified above. If a heavy
battery is used, it may fall off depending on the
way the monitor is used.

• When an external battery is attached, attach the
ferrite core (provided) to the power cord from the
mount as illustrated below.

Ex.: When the Anton Bauer mount (QR DXC-M3A) is used

Ferrite core

r Security slot

Attach a security wire to this slot.

Note for connections

• Before making any connections, turn off all the
equipment.

• Use a cord whose plugs correctly match the
terminals on this monitor and the equipment.

• Plugs should be firmly inserted; poor connections
could cause noise.

• When unplugging a cord, be sure to grasp its plug
and pull it out.

• DO NOT connect the power cord until all connections
are complete.

• Refer also to the user manual of each piece of
equipment.

7 Available signals

The following signals are available for this monitor.

Video signals

Signal format

No. Signal name

1 NTSC NTSC
2PAL PA L
3 B/W50 B/W50
4 B/W60 B/W60
5 480/60i 480/60i —
6 576/50i 576/50i —
7 480/60p 480/60p —
8 576/50p 576/50p —
9 640*480/60p 640*480/60p — — —

10 720/60p 720/60p —
11 720/50p 720/50p —
12 720/30p 720/30p —
13 720/25p 720/25p —
14 720/24p 720/24p —
15 1080/60i 1080/60i —
16 1035/60i 1035/60i — √*
17 1080/50i 1080/50i —
18 1080/60p 1080/60p — — —
19 1080/50p 1080/50p — — —
20 1080/30p 1080/30p —
21 1080/25p 1080/25p —
22 1080/24p 1080/24p —
23 1080/30psF 1080/60i — √*
24 1080/24psF 1080/24psf —

1

*

Analog component signals are compatible with Y on sync signals.
*2 Compatible with EMBEDDED AUDIO signals
*3 The signal is recognized as 1080/60i.

shown in the

status display

(☞ page 7)

VIDEO

√
√
√
√

COMPO.

(Analog

component)*

Input terminal

E. AUDIO HD/

1

(IN 1, IN 2)*
—— —
—— —
—— —
—— —

√√ √
√√ √
√
√

√√ √
√√ √
√√
√√
√√
√√ √

3

√√ √

√√ √
√√ √
√√ √

3

√√

SD SDI

—
—

√

3

√*

√: Acceptable

—: Not acceptable

DVI-D (HDCP)

(Digital component/

2

digital RGB)

√*

Computer signals (preset)

DVI-D (HDCP) terminals

No. Signal name

1VGA60 640 480 31.5 59.9 Non-interlace
2WVGA60 852 480 31.5 59.9 Non-interlace
3SVGA60 800 600 37.9 60.3 Non-interlace
4XGA60 1024 768 48.4 60.0 Non-interlace
5WXGA (1280) 1280 768 47.8 60.0 Non-interlace
6WXGA+60
7SXGA60*
8WSXGA+60*
9UXGA60*

10 WUXGA60*

√
√
√

—
—
—

3

√
√

—
—

11 720/60p 1280 720 45.0 60.0 Non-interlace
12 1080/60p*
13 720/50p 1280 720 37.5 50.0 Non-interlace
14 1080/50p*

4

When No. 7–10, 12 and 14 signals come in, thin lines will become obscured because their signal resolution is higher

*

than the screen resolution.

• Non-preset signals may not be displayed normally even if their frequency is within the acceptable range (☞
“Horizontal/vertical frequency (computer signal)” on page 21).

• When a preset signal comes in, the signal format is shown on the status display. For other signals, the
resolution is shown.

Specification of the DVI-D (HDCP) terminal

Connect it to the DVI-D output terminal on a personal computer.

4

4

4

4

4

Pin No. Input signal Pin No. Input signal Pin No. Input signal

1
2
3
4
5
6
7
8

Horizontal Vertical Horizontal (kHz) Vertical (Hz)

4

T.M.D.S Data 2–
T.M.D.S Data 2+
T.M.D.S Data 2 shield
NC
NC
DDC Clock
DDC Data
NC

Resolution Frequency

1440 900 55.9
1280 1024 64.0 60.0 Non-interlace
1680 1050 65.2 60.0 Non-interlace
1600 1200 75.0 60.0 Non-interlace
1920 1200 74.0 60.0 Non-interlace

1920 1080 67.5 60.0 Non-interlace

1920 1080 56.25 50.0 Non-interlace

9

T. M.D.S Data 1–

10

T.M.D.S Data 1+

11

T.M.D.S Data 1 shield

12

NC

13

NC

14

+5 V Power

15

GND

16

Hot Plug Detect

60.0 Non-interlace

17
18
19
20
21
22
23
24

Scan system

T.M.D.S Data 0–
T.M.D.S Data 0+
T.M.D.S Data 0 shield
NC
NC
T.M.D.S Clock shield
T.M.D.S Clock+
T.M.D.S Clock–

Attaching the power cord holder

The provided power cord holder prevents accidental
disconnection of the AC power cord from the AC IN terminal.

• The power cord holder consists of two parts, a case and a
cover.

1

Case

AC IN
terminal

23

Cover

CAUTION

• Use only the provided screws.

• Make sure the plug will not be pulled out
after the cover is attached to the case.

To detach the cover

9

Menu Configuration—MAIN MENU

10

For the operation procedure, see page 7.

Operation guide

Shows the buttons for each operation.

• The menu automatically disappears in about 30 seconds after the previous operation.

• Some items may not appear on the menu depending on the input or the input signal.

• The items controlled by the MAKE system do not appear on the menu.

PICTURE FUNCTION

Setting for the picture quality

Item To do Setting value

APERTURE

1

FREQ.*
APERTURE

1

LEVEL*
CTI
LTI
I/P MODE

sub menu

reset

1

Memorized for each input.

*

BACK LIGHT

Adjusts the brightness of the display.

DVI INPUT SEL.

When “AUTO” is selected, the format of signals come in to the DVI-D (HDCP) terminal is automatically
recognized. (Normally, select “AUTO.”)

• Select “MODE1”, “MODE2” or “MODE3” when the picture is not displayed correctly with “AUTO.”

• DVI-D input of the monitor is compatible with HDCP.

Select the frequency of the luminance signal compensated in
“APERTURE LEVEL.”

Compensate the frequency response of the luminance signal of the
video signal.

Adjust the clearness of the outlines of the chrominance signal. OFF, NORMAL, HARD
Adjust the clearness of the outlines of the luminance signal. OFF, NORMAL, HARD
Selects a proper mode corresponding to the input picture. NORMAL, CINEMA,

Display the sub menu which enables you to adjust the items of “PICTURE FUNCTION” while
viewing the actual picture.

Restore the default settings for all the items in “PICTURE FUNCTION.”

Setting value: –20 – +20

Setting value: AUTO, MODE1, MODE2, MODE3

OFF, LOW, HIGH

01 – 10

FIELD

Operation guide

Shows the buttons for each operation.

• The menu automatically disappears in about 30 seconds after the previous operation.

• Some items may not appear on the menu depending on the input or the input signal.

• The items controlled by the MAKE system do not appear on the menu.

MARKER*1*

2

Settings for marker functions

1/2

Item To do Setting value

AREA MARKER*

MARKER ASPECT*

SAFETY MARKER

SAFETY AREA
FRAME

CENTER MARKER

LINE BRIGHTNESS

3

3

Activate/deactivate the area marker and select the
style of it.

Select the aspect ratio of the area marker. 4:3, 14:9, 13:9, 2.35:1, 1.85:1,

Activate/deactivate the safety marker and select the
style of it.

Adjust the area of the safety marker. 80% – 100%
Displays/hides the frame indicating the area of

specified aspect ratio.
Displays/hides the marker indicating the center

position of the picture.
Adjust the brightness of the marker. HIGH, LOW

the

☞ “NOTE”

1.66:1
☞ “NOTE”

OFF, ON

OFF, ON

2/2

Item To do Setting value

R-AREA MARKER*

R-MARKER ASPECT*

R-SAFETY MARKER

R-SAFETY AREA

3

Activate/deactivate the area marker and select the
style of it.

3

Select the aspect ratio of the area marker. 4:3, 14:9, 13:9, 2.35:1, 1.85:1,

Activate/deactivate the safety marker and select the
style of it.

Adjust the area of the safety marker. 80% – 100%

☞ “NOTE”

1.66:1
☞ “NOTE”

• The area marker or the safety marker is displayed by using AREA MARKER or SAFETY MARKER button, or
external control.

• Select either non-“R-” items or “R-” items to activate by using external control (☞

“External Control”

on page 16).

• When a picture is displayed in 4:3 aspect ratio, the safety marker for the 4:3 area is displayed.

• To display the safety marker for the area of a picture displayed in 16:9 aspect ratio, hide the area marker.

(☞ “NOTE”)

NOTE

Setting of “AREA MARKER”, “SAFETY MARKER”, “R-AREA MARKER”,
“R-SAFETY MARKER”

The setting values and features are as follows.

OFF: Deactivate the marker.
LINE: Displays the area with an outline.
HALF: The area outside the specified aspect ratio of the screen is displayed at 50% transparency.
HALF+L: The area of the specified aspect ratio of the screen is indicated by an outline, and the area

outside of that is displayed at 50% transparency.

BLK.: The area outside the specified aspect ratio of the screen is black. Only the portion of the picture

within the designated area is displayed.

BLK. +L: The area of the specified aspect ratio of the screen is indicated by an outline, and the area

outside of that becomes black so that only the area inside the line is displayed.

*1 Memorized for each input.
*2 Not displayed when picture is displayed in the 1:1 mode.
*3 Displayed only when picture is displayed in 16:9 aspect ratio.

11

Menu Configuration—MAIN MENU

Adjustment bar

Operation guide

Shows the buttons for each
operation.

• The menu automatically disappears in about 30 seconds after the previous operation.

• Some items may not appear on the menu depending on the input or the input signal.

• The items controlled by the MAKE system do not appear on the menu.

NOTE

Displayed when selecting
“BALANCE.”

(cont.)

AUDIO SETTING

Settings for the audio output balance, EMBEDDED AUDIO signals and level meter

Item To do Setting value

BALANCE

E.AUDIO GROUP*

LEVEL METER
SETTING*

LEVEL METER ch

BAR TYPE

REFERENCE
LEVEL

OVER LEVEL

BAR BRIGHTNESS

1

*

Memorized for each input.

1

Adjust the balance between the right and left
speakers.

1

Select the audio channel group of the
EMBEDDED AUDIO signals.

Adjust the level meter display for the
EMBEDDED AUDIO signals.

Select how the audio channels are displayed on
the level meter.

Select the color of the level meter display. 3COLORS (3 colors to indicate variations in

Select the standard input level indicated on the
level meter.

Select the input level’s lower limit indicated in
red for the “3COLORS” display.

Select the brightness of the level meter. LOW, HIGH

L5 – L1, 0, R1 – R5

☞ “NOTE”

☞ “NOTE”

OFF, LINE (Displays the channels 1 – 6
at the left of the screen and 7 – 12 at the
right.), DIVIDE (Displays the odd channels at
the left of the screen and the even channels
at the right.)

input levels), W.100 (white)
–20dB, –18dB

–10dB, –8dB, –6dB, –4dB, –2dB

12

Settings of “E.AUDIO GROUP”

The setting values and selectable audio channels of EMBEDDED AUDIO signals are as follows.

1G: channel(s) 1/2/3/4/1+2/3+4/1 – 4 (1G)
2G: channel(s) 5/6/7/8/5+6/7+8/5 – 8 (2G)
1-2G: channel(s) 1/2/3/4/5/6/7/8/1+2/3+4/5+6/7+8/1 – 4 (1G)/5 – 8 (2G)/1 – 8 (1G+2G)
3G: channel(s) 9/10/11/12/9+10/11+12/9 – 12 (3G)
1-3G: channel(s) 1/2/3/4/5/6/7/8/9/10/11/12/1+2/3+4/5+6/7+8/9+10/11+12/1 – 4 (1G)/5 – 8 (2G)/

9 – 12 (3G)/1 – 8 (1G+2G)/1 – 12 (1-3G)

Example of the level meter display —Level meter position and audio channels

Ex.: When “LEVEL METER ch” is set to “LINE” and “BAR TYPE” is set to “3COLORS”

OVER LEVEL REFERENCE LEVEL

Red

Yellow

Green

• When “BAR TYPE” is set to “W.100,” the standard input level set in “REFERENCE LEVEL” is displayed with
the line indication. The input level set in “OVER LEVEL” is not displayed.

• The level meter with no audio signal input is displayed in white for “3COLORS,” and in gray for “W.100.”

• You can select the position of the level meter display—top or bottom of the screen (☞ “POSITION” in
“INFORMATION” on page 15).

Operation guide

Shows the buttons for each
operation.

NOTE

Example of the wave form monitor

Ex.: When “MARKING” is set to “ON” and “LEVEL” is set to “080”

Red

White

• The wave which goes over the value set on “LEVEL”
is indicated in Red.

WAVE FORM SETTING*

1

Settings for the wave form monitor

Item To do Setting value

POSITION

FILTER

GAIN

OVER LEVEL

MARKING

LEVEL

AUTO OFF

1

*

This function does not work for the signals as follows:

RGB input signals (digital), DVI signals (digital/inputted from personal computer), 1080/60p (analog/digital), 1080/50p

(analog/digital), 640 *480/60p (analog/digital).

Select the position of the wave form monitor. 1 (lower right), 2 (lower left), 3 (upper left),

Activates/deactivates the low-pass filter for the
incoming wave form data.

Adjust the gain level for the incoming wave form
data.

Select the over level for the incoming luminance
signals.

Activates/deactivates the function to change the
color of a wave form when the signal exceeds the
limit specified on “LEVEL” (☞ below).

Adjust the lower limit for the luminance signal 070 –109
Activates/deactivates the function to make the

wave form monitor indication go off automatically
15 minutes after displaying it.

4 (upper right)
FLAT (no filter), LOWPASS

–10 – +10

☞ “NOTE”

OFF, ON

ON, OFF

SYNC FUNCTION

Settings for the synchronization with signals

Item To do Setting value

NO SYNC ACTION

DELAY TIME

LOW LATENCY

• When setting “NO SYNC ACTION” to “GRAY B.,” the screen color changes to gray and the power consumption
of the back light is saved by half.

Selecting “P.SAVE” (power save mode) saves more power consumption by turning off the back light.

Select the screen status when no signal is
coming in.

Select the period until the screen status
changes as selected in “NO SYNC ACTION”
after signals stop coming in.

Activates/deactivates the function to shorten
the time taken to display the picture (low latency
function).

• If the picture is not displayed steadily while
“ON” is selected, select “OFF.”

• While “ON” is selected, the displayed picture
may become unstable when an operation
using buttons on the front panel or the menu
is performed, or when the signal format
changes.

OFF,
P. SAVE (power save mode),
GRAY B. (gray screen)

30sec., 5min., 15min.

ON, OFF

Video signal

Start End

13

Menu Configuration—SET-UP MENU

For the operation procedure, see page 7.

Operation guide

Shows the buttons for each
operation.

• The menu automatically
disappears in about 30
seconds after the previous
operation.

• Some items may not appear
on the menu depending on
the input or the input signal.

• The items controlled by
the MAKE system do not
appear on the menu.

NOTE

Settings of “sub menu POSI.”

The setting values and features are as follows.
LOWER1: Displays the current setting and adjustment bar at the

lower part of the screen.

UPPER1: Displays the current setting and adjustment bar at the

upper part of the screen.

LOWER2: Displays the current setting at the lower part of the

screen.

UPPER2: Displays the current setting at the upper part of the

screen.

• The adjustment bar is not displayed for some items.

Settings of “SD4:3 LARGE”

The setting values and features are as follows.
OFF: Fit the vertical picture size into the pixel numbers of

the monitor display.

ON: Fit the vertical picture size into that of the monitor

display.

FUNCTION SETTING

Setting for the sub menu display, color system, color of the tally lamp and the picture size.

Item To do Setting value

sub menu POSI.
COLOR

SYSTEM
TALLY SELECT
SD4:3 LARGE

Select the contents and displaying position of “sub menu.”
Select the color system.

• If the picture is unstable with “AUTO,” select “PAL” or “NTSC.”
Select the color of the tally lamp. GREEN, RED
Change the picture size of 4:3

format signal.

☞ “NOTE”
AUTO, NTSC, PAL

☞ “NOTE”

PICTURE SUB ADJ.

Adjusts the standard level for the picture adjustment and selects the set-up level for the input video signal.

Item To do Setting value

CONTRAST*

BRIGHT*

CHROMA*

PHASE*

NTSC SETUP

COMPO.
LEVEL

sub menu

reset

1

*

Memorized for each input.

1

Adjust the standard level for the contrast adjusted
with CONTRAST knob on the front panel.

1

Adjust the standard level for the brightness
adjusted with BRIGHT knob on the front panel.

1

Adjust the standard level for the chroma adjusted
with CHROMA knob on the front panel.

1

Adjust the standard level for the phase adjusted
with PHASE knob on the front panel.

Select the set-up level of the input NTSC signal. 00 (compliant with 0% set-up signal), 7.5 (compliant

Select the level of the analog component signal
(480i and 576i only).

Display the sub menu which enables you to adjust the items in “PICTURE SUB ADJ.” while viewing the
actual picture.

Restore the default settings for all the items in “PICTURE SUB ADJ.”

–20 – +20

–20 – +20

–20 – +20

–20 – +20

with 7.5% set-up signal)
B75 (compliant with BetacamVTR 7.5% set-up

signal), B00 (compliant with BetacamVTR 0% set­up signal), SMPTE (compliant with M2VTR signals)

SIZE/POSI. ADJ.

Adjusts the size and position of the picture.

Item To do Setting value

2

H SIZE*
H POSITION*

2

V SIZE*
V POSITION*
sub menu

reset

2

*

Memorized for each signal format.

Adjust the horizontal picture size.

2

Adjust the horizontal picture position.
Adjust the vertical picture size.

2

Adjust the vertical picture position.
Display the sub menu which enables you to adjust the items of “SIZE/POSI. ADJ.” while viewing the

actual picture.
Restore the default settings for all the items in “SIZE/POSI. ADJ.”

Setting value varies depending on
the signals.

WHITE BALANCE SET.

Selects the color temperature and adjusts the drive level and cutoff point of each color (R/G/B).

Item To do Setting value

COLOR TEMP.
R DRIVE, G DRIVE,

B DRIVE*
R CUT OFF, G CUT

OFF, B CUT OFF*
sub menu

reset

3

*

3

Memorized for each color temperature.

Select the color temperature. 9300K, 6500K, USER
Adjust the drive level of each color (red, green, and blue). MIN – 000 – MAX (in 256 grades)

Adjust the cutoff point of each color (red, green, and blue). MIN – 000 – MAX (in 256 grades)

3

Display the sub menu which enables you to adjust the items in “WHITE BALANCE SET.” while
viewing the actual picture.

Restore the default settings for the drive levels and cutoff points of the selected color
temperature.

14

Operation guide

Shows the buttons for each
operation.

• The menu automatically disappears in about 30 seconds after the previous operation.

• Some items may not appear on the menu depending on the input or the input signal.

• The items controlled by the MAKE system do not appear on the menu.

NOTE

Setting of “CHARACTER SET.”

Assign a name for each video source.

1 Change the input to one that you want to assign a video source name for.
2 Select “CHARACTER SET.”
3 Press buttons to select the first character.

• Each time you press button, the character changes as follows. Press button to reverse the order.

Space

REMOTE SETTING

Settings for the external control

Item To do Setting value

SERIAL TYPE

PA RALLEL TYPE

PIN1, PIN2, PIN3,
PIN4, PIN5

(☞ “External Control” on pages 16 to 18)

Select the input terminal used for external control by
serial communication.

Select the external control method for the MAKE/
TRIGGER terminal.

Assign the control functions to the pins of the MAKE/
TRIGGER terminal.

• Assign a function to each pin terminal by selecting
“SET” in “PARALLEL TYPE” mentioned above. (The
functions are assigned for “PIN6” – “PIN8” and you
cannot change the assignment of these functions.)

RS232C, RS485

MAKE, TRIGGER, SET

☞ “Functions controlled by the MAKE/
TRIGGER system” on page 17

INFORMATION

Settings for the information display of the monitor

Item To do Setting value

POSITION

SOURCE ID

CHARACTER SET.*

STATUS DISPLAY

CRC ERROR

SUB HOUR METER
MODEL
VERSION
HOUR METER

1

Memorized for each input.

*

CONTROL LOCK

Tu r ns on (or off) the control lock function to disable the buttons on the front panel.

• The following operations are available even when this function is activated.
– Turning on/off (on standby) the monitor
– Displaying the SET-UP MENU (by pressing button while holding button) and turning “CONTROL LOCK”

to “OFF”

– Operating the monitor by an external control

If you try other operations, “ Control lock on!” appears on the screen.

Select the position to show the information display (☞ “On the
Information Display” on page 7).

Select if the name assigned in “CHARACTER SET.” is displayed on
the screen (☞ “On the Information Display” on page 7).

1

Assign a name to each video source as you like (10 characters at
maximum). You can also enter a name using the RS-232C system.

Select if the status of the current input and the setting of muting are
displayed on the screen (☞ “On the Status Display” on page 7).

Select if the CRC error indication for the input HD SDI signal is displayed
on the screen

Display the hours of use (unit: hour). You can reset this item.
Display the model name of the monitor.
Display the version of the monitor.
Display the total hours of use (unit: hour). This item is used for maintenance of the monitor. You

cannot reset this item.

Setting value: OFF, ON

(☞ “On the Information Display” on page 7).

UPPER, LOWER

OFF, ON

☞ “NOTE”

AUTO, OFF, ON

ON, OFF

all reset

Restores all the settings and adjustments of the monitor to the default.

• “HOUR METER” and the settings done by using the adjustment knobs on the front panel will not be reset.

• When you operate the monitor with the AC power supply, the monitor is turned off (on standby) then turned
on automatically. When you operate the monitor with the DC 12 V power supply, the monitor is turned off (on
standby).

4 Press button to move the arrow to the next space.

• The characters entered before moving the arrow are memorized.

5 Repeat steps 3 and 4 (10 characters at maximum).
6 Press MENU button to store the name.

15

External Control

16

7 About the external control

This monitor has three external control terminals.

• MAKE/TRIGGER terminal (RJ-45): The following external control systems are available.
(1) MAKE (make contact) system: Controls the monitor by short-circuiting the corresponding pin terminal to

the GND pin terminal, or disconnecting (opening) it.

(2) TRIGGER (trigger) system: Controls the monitor by sending the pulse signal instantaneously to the

corresponding pin terminal.

☞ “Using the MAKE/TRIGGER system” on page 17

• RS-485 terminals (RJ-45): Controls the monitor with the RS-485 system. (☞ “Using the serial communication”
on page 18)

• RS-232C terminal (D-sub 9-pin): Controls the monitor with the RS-232C system. (☞ “Using the serial
communication” on page 18)

Set the following items of “REMOTE SETTING” in SET-UP MENU according to the external control terminal and
control system (☞ “SERIAL TYPE”, “PARALLEL TYPE” on page 15).

Control terminal Control system

MAKE/TRIGGER
terminal

RS-485 terminal Serial
RS-232C terminal RS-232C

1

*

For a monitor connected to a personal computer etc, select the terminal the equipment is actually connected to. For

other monitors, select “RS485.”

MAKE

TRIGGER

RS-485

communication

“SERIAL TYPE” setting “PARALLEL TYPE” setting

The settings of this unit

—MAKE

— TRIGGER

1

RS485*

RS232C*

1

—
—

Control priority is as follows.

MAKE > TRIGGER = serial communication = buttons and menu on the monitor

• You can use the external control even when “CONTROL LOCK” is set to “ON” (☞ page 15).

• When the monitor is off (on standby), external control is not available. But certain external controls (
terminating communication, turning on the monitor

<MAKE/TRIGGER system>

You can control the monitor by a personal computer or dedicated controller*

• For the details, see page 17.

*2 The controller is not commercially available. Consult your dealer if you need it.

<Serial communication>

PC, etc.

RS-485 IN

or

RS-232C

• For the details, see page 18.

RS-485

RS-485

OUT

) are available through the serial communication (☞ page 18).

2

.

IN

RS-485

OUT

RS-485

IN

RS-485

OUT

starting/

7 Using the MAKE/TRIGGER system

The MAKE/TRIGGER terminal is configured as follows. You can assign a function to each pin terminal in
“REMOTE SETTING” (☞ “PIN1, PIN2, PIN3, PIN4, PIN5” in “PARALLEL TYPE” on page 15).

• You cannot change the functions assigned to the pin terminals from 6th to 8th.

Pin No.

1

2

3

This is a female terminal.

*1 The 6th pin terminal controls turning on or off the tally lamp (available to control even when the 7th pin terminal is

invalid).

*2 The 7th pin terminal makes the external control valid/invalid. Make sure to control the terminal by the MAKE system.

4

5

6

7

8

To assign the functions to the pin terminals

For the operation procedure, see page 7.

1 Select “REMOTE SETTING” on the SET-UP MENU.
2 Set “PARALLEL TYPE” to “SET.”
3 Select a pin name (“PIN1” – “PIN5”) for which you want to assign a function, then select the function you want

to assign.

• For selectable functions, see the tables on the right.

Operation of the external control

1 Set “PARALLEL TYPE” of “REMOTE SETTING” to “MAKE” or “TRIGGER” in the SET-UP MENU.
2 Short-circuit the 7th pin terminal (ENABLE) to the 8th pin terminal (GND) so that the monitor can be controlled

by the external control.

3 When the “MAKE” system is selected: Operate each function by short-circuiting the corresponding pin terminal

to the 8th pin terminal (GND) or opening it.
When the “TRIGGER” system is selected: Operate each function by pulse control, that is short-circuiting the
corresponding pin terminal to the 8th pin terminal (GND) for about 1 second and opening it.

• When changing the input with MAKE system, only one pin terminal must be short-circuited. (Other pin terminals
must be opened.)

• When selecting the “TRIGGER” system, you can operate only one function at a time. Operate the functions one
by one.

Pin name

PIN1

PIN2

PIN3

PIN4

PIN5

PIN6 (TALLY)*

PIN7 (ENABLE)*

PIN8 (GND)

1

2

<Functions controlled by the MAKE/TRIGGER system>

Display Functions to be controlled Opening Short-circuiting

TA LLY SEL Selects the color of the tally lamp. Green Red
SDI 1 Changes the input to “SDI 1.” Invalid Valid
SDI 2 Changes the input to “SDI 2.” Invalid Valid
DVI Changes the input to “DVI.” Invalid Valid
COMPONENT Changes the input to “COMPO.” Invalid Valid
VIDEO Changes the input to “VIDEO.” Invalid Valid
A.MARKER The area marker indication Off On
S.MARKER The safety marker indication Off On
FRAME Indication of the area of
C.MARKER The center marker indication Off On
MARK.SEL Selects the items of “MARKER”*
ASPECT Changes the aspect ratio. 4:3 16:9
1:1 Displays in 1:1 mode. Off On
STATUS Status display*
L.METER Audio level meter display *
TIME CODE Time code display Off On
SOURCE ID
WAVE FORM Wave form monitor display *
COLOR OFF Color off Color Monochrome
SCR CHECK Screens check *
I/P MODE Change a mode according to a input picture. *
MUTING Muting on/off Off On
– – – No function — —

3

Selects which functions in “MARKER” are activated, non-“R-” items or “R-” items (☞ “MARKER” on page 11).

*
*4 Displays the information shown when INPUT SELECT button of the current input is pressed (☞ “On the Status Display”

on page 7). While controlling with the MAKE system, the information is displayed only at the moment of short-circuiting.

*5 While controlling with the MAKE system, the level meter is switched between displayed (short-circuiting) and hidden

(opening). When “LEVEL METER ch” is set to “OFF,” the level meter is not displayed (“NO EFFECT” appears). While
controlling with the TRIGGER system, the pattern of the audio channel display is switched.

*6 Must be controlled with the TRIGGER system. Controls whether displaying/hiding the wave form monitor (This function

cannot be controlled with the MAKE system.).

*7 While controlling with the MAKE system, the screen is switched between normal screen (opening) and blue screen

(short-circuiting). While controlling with the TRIGGER system, the screen changes as same as when pressing
SCREENS CHECK button (☞

8

Must be controlled with the TRIGGER system. The mode changes in the order of “NORMAL” \ “CINEMA” \ “FIELD”.

*

(This function cannot be controlled with the MAKE system.)

☞ “SOURCE ID” in “INFORMATION” on page 15

4

q on page 6).

the specified aspect ratio

3

Off On

Non-“R-” items “R-” items

☞ “On the Status Display” on page 7

5

Off On

6

7

8

• You cannot assign the same function to different pin terminals.

• The TRIGGER system switches each function by short-circuiting the pin terminal for about 1 second and
opening it.

17

External Control (cont.)

18

7 Using the serial communication

You can control the monitor from a personal computer etc. via the RS-485 or RS-232C terminal.

• Consult your dealer for the details of the external control specification.

<Communication specifications>

Input terminal Cable

RS-485 A straight LAN cable

RS-232C A straight cable with a D-sub 9-pin

connector (male for the monitor,
female for the personal computer
etc.)

Terminal

specification

☞ See below

<Specifications of the RS-485 terminal> <Specifications of the RS-232C terminal>

This is a female terminal. This is a female terminal.

Pin No. IN terminal signal OUT terminal signal Pin No. Signal

1

TXD + TXD +

2

TXD – TXD –

3

RXD + RXD +

4

NC NC

5

NC NC

6

RXD – RXD –

7

NC NC

8

GND GND

1

2

3

4

5

6

7

8

9

• The 7th terminal and the 8th terminal are connected.

<Command outline>

All commands consist of the following segments.

Header Monitor ID Command ID Function Data Cr (0DH)

On Header

“!”: Operation commands from the personal computer, etc. For details, see <Basic command list> on the right.
“?”: Reference commands from the personal computer, etc.
“@”: Status returns from the monitor

• To start communication, send the connection command from the personal computer etc.

• To terminate the communication, send the termination command from the personal computer etc.

Communication specifications

Baud Rate: 4800 bps
Data Bits: 8 bits
Parity: No parity
Stop Bits: 1 bit
Flow Control: No control
Communication Code: ASCII Code

NC

RXD

TXD

NC

GND

NC

RTS

CTS

NC

Example of communication procedures

1 Starting the communication:

PC, etc.

connection command (!00BCN1Cr)

2 Monitor’s status (@00BOKCr)

3 Selecting “SDI 1” input (!00BINACr)

4 Monitor’s status (@00BOKCr)

5 Te rminating the communication: termination command

(!00BCN0Cr)

6 Monitor’s status (@00BOKCr)

Monitor

<Basic command list>

No. Commands Functions Data

1!***1BCN1Cr Starts communication (connection) No data

2!***

3!***
4!***

5!***

6!***

7!***

8!***

9!***
10 !
11 !
12 !
13 !
14 !
15 !
16 !
17 !
18 !
19 !
20 !
21 !
22 !

*

*

*

*

*

*

*

*

*

*

*

*

*

1

BCN0Cr

1

BIDSETxx*2Cr Assigns the control ID 01 – 99

1

BIDRETCr Initializes the control ID No data

1

BIDDSPxx*2Cr Displays/hides the ID

1

BIDCHKxx*2Cr

1

BMENUCr

1

BUPCr

1

BDOWNCr

1

**

BADJRCr Makes setting/adjustment ( ) No data

1

BADJLCrMakes setting/adjustment ( ) No data

**
**1BSETUPCr Displays the SET-UP MENU No data

1

BPW1Cr Turns on the monitor No data

**
**1BPW0Cr Turns off the monitor (on standby) No data

1

BINACr Selects “SDI 1” input No data

**
**1BINBCr Selects “SDI 2” input No data

1

BINCCr Selects “DVI” input No data

**
**1BINDCr Selects “COMPO.” input No data

1

BINECr Selects “VIDEO” input No data

**

1

BD ISPCr Displays the status*

**
**1BAMUTE xx*2Cr Turns muting on/off 00: Off, 01: On

1

BASPxx*2Cr Changes the aspect ratio 00: 4:3, 01: 16:9

**

Te rminates communication
(termination)

Flashes/hides the selected ID No. of
the monitor

Displays the MAIN MENU/Quits the
menu operation

Moves the cursor upward ( )

Moves the cursor downward ( )

3

No data

00: Hide
01: Display

00: Hide
01: Display

No data

No data

No data

No data

• “Cr” is 0Dh.

• The commands for starting communication (connection) (No. 1), terminating communication (termination)
(No. 2), and turning on the monitor (No. 13) can be used while the monitor is off (on standby).

*1 Enter the monitor’s ID for “ **.” The initial setting of the monitor’s ID is “00.” When connecting several monitors, “00” is a

command for controlling all monitors at once.

*2 Enter the appropriate data to “xx.”
*3 Displays the information shown when the INPUT SELECT button currently lit is pressed (☞ “On the Status Display” on

page 7).

Troubleshooting

Solutions to common problems related to the monitor are described here. If none of the solutions presented here
solve the problem, unplug the monitor and consult an authorized dealer or service center.

Symptom Probable cause and corrective action Page

button.

No power supply

No picture with the
power on

No sound

“OTHERS” or “Out of
range” appears.

“NO SYNC” appears.

Wrong color, no color

• Press the

• Turn on the POWER switch or DC switch on the rear panel.

• Firmly insert the AC power plug or DC 12 V power plug.

• When using a DC 12 V power supply, charge the battery or replace it
with a charged one.

• Select the correct input using the INPUT SELECT buttons.

• Connect the signal cable firmly.

• Turn on the power of the connected component and set the output
correctly.

• Check whether the input signal format is acceptable on the monitor.

• Adjust the volume level.

• Deactivate the muting function.

• Connect the signal cable firmly.

• Turn on the power of the connected component and set the output
correctly.

• Check whether the input signal format is acceptable on the monitor. 7, 9

• Select the correct input using the INPUT SELECT buttons.

• Connect the signal cable firmly.

• Turn on the power of the connected component and output video
signals. Or, check whether the video output of the component (video
output setting of the VCR or graphic board of the computer) is set
correctly.

• Adjust each picture adjustment knob on the front panel or adjust the
items of “PICTURE SUB ADJ.” in the SET-UP MENU. Or, perform
“reset” in “PICTURE SUB ADJ.”

• Check whether the setting of COLOR OFF or SCREENS CHECK
buttons are appropriate.

• Select the proper color system (“COLOR SYSTEM”) in “FUNCTION
SETTING” of the SET-UP MENU.

• Adjust the items of “WHITE BALANCE SET.” in the SET-UP MENU.
Or, perform “reset” in “WHITE BALANCE SET.”

6
8
8
8

6
8

—

9

6
6
8

—

6
8

—

6, 14

6

14

14

Symptom Probable cause and corrective action Page

The picture becomes
blurred.

Wrong picture position,
wrong picture size.

Some items do not
appear on the menu.

Buttons on the monitor
do not work.

The following are not malfunctions.

• When a still image is displayed for a long time, it may remain indistinctly on the screen after the picture has
changed. Though the remaining picture will disappear after a while, there may be a case that it remains
for a long period depending on the length of time the still image was displayed for. This is due to the
characteristics of the LCD display and is not a malfunction.

• Red spots, blue spots and green spots on the panel surface are a normal characteristic of LCD displays,
and not a problem. The LCD display is built with very high precision technology; however, be aware that a
few pixels may be missing or constantly lit.

• The following symptoms are problems only when pictures or sounds are not played back normally.
– A slight electric shock occurs when you touch the monitor.
– The top and/or rear panel of the monitor becomes hot.
– The monitor emits a cracking noise.
– The monitor emits a mechanical noise.

• Adjust the picture contrast or brightness by using the adjustment
knobs on the front panel. Or, adjust “CONTRAST” or “BRIGHT” of
“PICTURE SUB ADJ.” in the SET-UP MENU.

• Check whether the setting of 1:1 or ASPECT buttons is appropriate.

• Check whether the input signal format is acceptable on the monitor.

• Adjust the picture size (H SIZE/V SIZE) or position (H POSITION/V
POSITION) of “SIZE/POSI. ADJ.” in the SET-UP MENU.

• For some signals, the picture cannot be displayed fully in the effective
screen area. There is no sure method to solve this problem.

• The items which are not available for the current input or the current
input signal are not displayed on the menu. Change the input or the
input signal.

• The items controlled by the MAKE system do not appear on the
menu.

• Set “CONTROL LOCK” in the SET-UP MENU to “OFF.”

• You cannot use the buttons for the items controlled by the MAKE
system. Disable the external control.

6, 14

6
9

14

—

—

17

15

16,17

19

Troubleshooting (cont.)

Maintenance

20

7 Self-check program

This monitor has a self-check function, which allows it to detect malfunctions and alert you. This makes
troubleshooting easier. Whenever a problem occurs, one or some of the INPUT SELECT lamps will flash. If this
happens, follow the steps below and contact your dealer to resolve the problem.

When the screen goes blank, and one or some of the INPUT SELECT lamps (DVI, COMPO., VIDEO) on the

front control panel start flashing...

1 Check which lamps are flashing.

Unplug this product from the wall outlet before cleaning.

Screen

To avoid irreparable change in appearance of the screen such as uneven color, discoloration, scratches, be
careful about the following:

• Do not paste or stick anything using any glues or adhesive tapes.

• Do not write anything on the screen.

• Do not strike the screen with a hard object.

• Avoid condensation on the screen.

• Do not wipe the screen with solvent such as alcohol, thinner, or benzine.

• Do not wipe the screen forcefully.

Wipe stains off the screen with a soft cloth. If the screen gets heavily stained, wipe it with a soft cloth soaked in
water-diluted neutral detergent and wrung well, then wipe with a soft dry cloth.

Cabinet

To avoid the deterioration or damages of the cabinet such as its paint’s peeling away, be careful about the
following:

• Do not wipe the cabinet using solvent such as alcohol, thinner, or benzine.

• Do not expose the cabinet to any volatile substance such as insecticides.

• Do not allow any rubber or plastic in contact for a long time.

• Do not wipe the cabinet forcefully.

Wipe stains off the cabinet with a soft cloth. If the cabinet gets heavily stained, wipe it with a soft cloth soaked in
water-diluted neutral detergent and wrung well, then wipe with a soft dry cloth.

Ventilation openings

Use a vacuum cleaner to get rid of the dust around the intakes (all the openings). If a vacuum cleaner is not
available, use a cloth and wipe it off. Leaving the dust around the intakes may prevent proper temperature control
and cause damage to the product.

2 Press button to turn off (on standby) the monitor.
3 Turn off the POWER switch and DC switch on the rear panel.
4

When the AC power supply is used: Disconnect the AC power cord from the AC outlet.

When a DC 12 V power supply is used: Detach the battery or disconnect the plug

from the DC IN 12V terminal.

5 Contact your dealer with the information about which lamps were flashing.

• If you turn on the monitor soon after turning it off (or after a short-term power failure), the INPUT SELECT
lamps may flash and no image may be displayed.

When this happens, turn off power and wait at least 10 seconds before turning on the monitor again.
If the INPUT SELECT lamps do not flash, you can use the monitor as normal.

Specifications

7 General

Model name DT-V17L3D

Type Multi format LCD monitor

Screen size Type 17 wide format

Aspect ratio 16:10

LCD panel 17˝ wide, active matrix TFT

Effective screen size Width: 367.2 mm (14 7/16˝)

Number of pixels displayed 1 440 x 900

Number of colors displayed 16.77 million

Viewing angle (TYP.) 160° (Horizontally), 140° (Vertically)

Panel brightness (TYP.) 400 cd/m

Contrast ratio (TYP.) 600:1

Horizontal/vertical frequency
(computer signal)

Compliant video signal format

Format HD SDI: BTA S-004B, SMPTE292M

Audio output Internal speaker: 1.0 W + 1.0 W

Operating conditions Operating temperature: 5°C – 35°C (41°F – 95°F)

Power requirements AC 120 V/AC 220 – 240 V, 50 Hz/60 Hz

Rated current 0.56 A (AC 120 V)/0.36 A (AC 220 – 240 V)

External dimensions
(excluding protruding parts)

Weight 7 kg (15.5 lbs) (with the stand)

Accessories AC power cord, Power cord holder x 1, Screw x 2 (for power cord holder),

Height: 229.5 mm (9˝)

2

H: 31.469 kHz – 75.000 kHz
V: 48 Hz – 65 Hz

* Some signals within this frequency range may not be displayed (“Out of

range” is displayed).

☞ “Available signals” on page 9

SD SDI: ITU-R BT.656: 525/625
SMPTE259M: 525
EMBEDDED AUDIO: SMPTE299M, SMPTE272M

Operating humidity: 20% – 80% (non-condensing)
(Slightly variable depending on ambient conditions for installation.)

DC 12 – 17 V

3.0 A (DC 12 – 17 V)

Width: 395 mm (15 5/8˝) (with the stand), 395 mm (15 5/8˝) (without the stand)
Height: 344.8 mm (13 5/8˝) (with the stand), 304 mm (12˝) (without the stand)
Depth: 199 mm (7 7/8˝) (with the stand), 86 mm (3 1/2˝) (without the stand)

5.3 kg (11.7 lbs) (without the stand)

Ferrite core x 1 (for external battery)

7 Input/output terminals

VIDEO Input/output of composite signal:

DVI-D (HDCP) DVI-D signal input (compatible with HDCP):

COMPO. (Y, P

Video

E. AUDIO HD/SD SDI (IN 1)

E. AUDIO HD/SD SDI (IN 2)

E. AUDIO HD/SD SDI
(SWITCHED OUT)

AUDIO (IN) Analog audio signal input: 1 line, RCA connector x 2,

AUDIO (MONITOR OUT) Analog audio signal output: 1 line, RCA connector x 2,

Audio

REMOTE (MAKE/TRIGGER)

REMOTE (RS-485)

control

External

REMOTE (RS-232C)

B/B-Y, PR/R-Y) Input/output of analog component signal:

1 line, BNC connector x 2, 1 V(p-p), 75 Ω

* The input (IN) and output (OUT) terminals are bridge-connected (auto

termination).

DVI-D connector x 1 (compatible with DDC2B)

1 line, BNC connector x 6
Y: 1 V(p-p), 75 Ω
PB/B-Y, PR/R-Y: 0.7 V(p-p), 75 Ω
* The input (IN) and output (OUT) terminals are bridge-connected (auto

termination).

Digital signal input (compatible with EMBEDDED AUDIO signals):

auto detection, 1 line, BNC connector x 1

Digital signal output (compatible with EMBEDDED AUDIO signals):

1 line switched out, BNC connector x 1

500 mV (rms), high impedance

500 mV (rms)

☞ “Using the MAKE/TRIGGER system” on page 17

☞ “Using the serial communication” on page 18

Use the Anton Bauer Dionic 90 (mount: QR DXC-M3A) external battery.

CAUTION

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

Notice on transportation

This monitor is precision equipment and needs dedicated packing material for transportation.
Never use any packing material supplied from sources other than JVC or JVC-authorized dealers.

• For easy understanding, pictures and illustrations are shown by being emphasized, omitted or composed,
and may be slightly different from actual products.

• Design and specifications are subject to change without notice.

• All company names and product names mentioned herein are used for identification purposes only, and
may be the trademarks or registered trademarks of their respective companies.

21

Specifications (cont.)

22

7 Dimensions

<Front view> <Side view> <Rear view>

304 (12)

344.8 (13 5/8)*/309.5 (12 1/4)**

* at the higher position
** at the lower position

Unit: mm (inch)

395 (15 5/8)

240 (9 1/2)

86 (3 1/2 )

40 (1 5/8)

1.5 (1/16)

34 (1 3/8)

199 (7 7/8)

VESA mounting holes
(Size: 4-M4, depth: 10 mm)

100

100115

DT-V17L3D MULTI FORMAT LCD MONITOR

© 2008 Victor Company of Japan, Limited 0708STH-MW-VP
