Page 1

SERVICE MANUAL

REAR PROJECTION TELEVISION

YA09720045

AV-48WP55/H, AV-56WP55 AV-65WP55

/H,

BASIC CHASSIS

1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8

3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13

4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-26

5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-66

[AV-65WP55]

TABLE OF CONTENTS

No.YA097

2004/5

Page 2

SPECIFICATION

Items Contents

AV-48WP55 AV-56WP55 AV-65WP55

Dimensions (W × H × D) 120cm × 124cm × 60.8cm

(47-1/4" × 49" × 24")

Mass 82 kg ( 181 lbs ) 93.2 kg ( 205.7 lbs ) 108.7 kg ( 239.7 lbs ) TV RF System CCIR (M) Color System NTSC Sound System BTSC system (Multi Channel Sound) Teletext System Closed caption (T1-T4 / CC1-CC4) Receiving Channels

and Frequency

CATV Receiving Channels and Frequency

TV / CATV Total Channel 180 Channels Intermediate

Frequency Color Sub Carrier 3.58MHz Power Input AC 120V, 60Hz Power Consumption 248W (Max) Screen Transparent screen (unitized fresnel lens / double lenticular lens) Screen Size 48" (122cm)

Projection Tube 17cm (6.7") tube × 3 ( R/G/B )

High Voltage 31kV+1.0kV/-1.3kV (at zero beam current)

Speaker 13cm round type × 2

Audio Power Output 10W+10W

Antenna Terminal 75Ω unbalanced, F-type connector × 1

External Input (1/2/3/4)

Digital Input

[AV-65WP55]

Audio Output (FIX) 500mV(rms) (-4dBs), low impedance (1kHz when modulated 100%)

AV Compulink lll 3.5mm mini jack × 1 Remote Control Unit RM-C1257G (AA/R6/UM-3 battery × 2)

Design & specifications are subject to change without notice.

Component Video

VHF Low

VHF High

UHF

CATV 54MHz~804MHz

Video IF

Sound IF

[INPUT-1/2] 720p/1080i

480i/480p

S-Video

[INPUT-1/3/4]

Video Audio

Video

Audio

02ch~06ch : 54MHz~88MHz 07ch~13ch : 174MHz~216MHz 14ch~69ch : 470MHz~806MHz

Low Band : 02~06 High Band : 07~13 Mid Band : A~I by 14~22 Super Band : J~W by 23~36 Hyper Band : W+1~W+28 by 37~64 Ultra Band : W+29~W+58, W+59~W+84 by 65~94, 100~125 Sub Mid Band : A-8, A-4~A-1 by 01, 96~99

45.75MHz

41.25MHz (4.5MHz)

Measured diagonally 16:9 ratio (W:106.3 cm, H:59.8 cm)

RCA pin jack × 6 Y : 1V (p-p) (Sync signal: ±0.35V, 3-value sync.), 75Ω

Pb/Pr : ±0.35V, 75Ω Y : 1V (p-p) Positive (Negative sync provided), 75Ω Pb/Pr : 0.7V, 75Ω Mini-DIN 4pin × 3 Y: 1V (p-p) positive (negative sync provided), 75Ω

C: 0.286V(p-p) (burst signal)

1V (p-p) positive (negative sync provided), 75Ω (RCA pin jack × 4) 500mV(rms) (-4dBs), high impedance (RCA pin jack × 9)

HDMI connector (Digital-input terminal is not compatible with computer signal) Digital : HDMI connector

Analog : 500mV(rms) (-4dBs), high impedance (RCA pin jack × 2)

(RCA pin jack × 2)

136.8cm × 138.6cm × 66.7cm (53-7/8" × 54-5/8" × 26-3/8")

56" (142cm) Measured diagonally 16:9 ratio (W:124 cm, H:69.8 cm)

156.6cm × 149.5cm × 72.8cm (61-3/4" × 58-7/8" × 28-3/4")

65" (165cm) Measured diagonally 16:9 ratio (W:143.9 cm, H:81.0 cm)

1-2 (No.YA097)

Page 3

SECTION 1

PRECAUTION

1.1 SAFETY PRECAUTIONS

(1) The design of this product contains special hardware, many

circuits and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Service should be performed by qualified personnel only.

(2) Alterations of the design or circuitry of the products should not be

made. Any design alterations or additions will void the manufacturer's warranty and will further relieve the manufacturer of responsibility for personal injury or property damage resulting therefrom.

(3) Many electrical and mechanical parts in the products have special

safety-related characteristics. These characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety characteristics are identified in the parts list of Service manual. Electrical components having such features are

identified by shading on the schematics and by ( ) on the parts list in Service manual. The use of a substitute replacement

which does not have the same safety characteristics as the recommended replacement part shown in the parts list of Service manual may cause shock, fire, or other hazards.

(4) Use isolation transformer when hot chassis.

The chassis and any sub-chassis contained in some products are connected to one side of the AC power line. An isolation transformer of adequate capacity should be inserted between the product and the AC power supply point while performing any service on some products when the HOT chassis is exposed.

(5) Don't short between the LIVE side ground and ISOLATED (NEU-

TRAL) side ground or EARTH side ground when repairing. Some model's power circuit is partly different in the GND. The difference of the GND is shown by the LIVE : ( ) side GND, the ISOLATED (NEUTRAL) : ( ) side GND and EARTH : ( ) side GND. Don't short between the LIVE side GND and ISOLATED (NEUTRAL) side GND or EARTH side GND and never measure the LIVE side GND and ISOLATED (NEUTRAL) side GND or EARTH side GND at the same time with a measuring apparatus (oscilloscope etc.). If above note will not be kept, a fuse or any parts will be broken.

(6) If any repair has been made to the chassis, it is recommended that

the B1 setting should be checked or adjusted (See B1 POWER SUPPLY check).

(7) The high voltage applied to the picture tube must conform with that

specified in Service manual. Excessive high voltage can cause an increase in X-Ray emission, arcing and possible component damage, therefore operation under excessive high voltage conditions should be kept to a minimum, or should be prevented. If severe arcing occurs, remove the AC power immediately and determine the cause by visual inspection (incorrect installation, cracked or melted high voltage harness, poor soldering, etc.). To maintain the proper minimum level of soft X-Ray emission, components in the high voltage circuitry including the picture tube must be the exact replacements or alternatives approved by the manufacturer of the complete product.

(8) Do not check high voltage by drawing an arc. Use a high voltage

meter or a high voltage probe with a VTVM. Discharge the picture tube before attempting meter connection, by connecting a clip lead to the ground frame and connecting the other end of the lead through a 10k

(9) When service is required, observe the original lead dress. Extra

precaution should be given to assure correct lead dress in the high voltage circuit area. Where a short circuit has occurred, those components that indicate evidence of overheating should be replaced. Always use the manufacturer's replacement components.

Ω 2W resistor to the anode button.

(10) Isolation Check (Safety for Electrical Shock Hazard)

After re-assembling the product, always perform an isolation check on the exposed metal parts of the cabinet (antenna terminals, video/audio input and output terminals, Control knobs, metal cabinet, screw heads, earphone jack, control shafts, etc.) to be sure the product is safe to operate without danger of electrical shock.

a) Dielectric Strength Test

The isolation between the AC primary circuit and all metal parts exposed to the user, particularly any exposed metal part having a return path to the chassis should withstand a voltage of 1100V AC (r.m.s.) for a period of one second.

(. . . . Withstand a voltage of 1100V AC (r.m.s.) to an appliance rat-

ed up to 120V, and 3000V AC (r.m.s.) to an appliance rated 200V or more, for a period of one second.) This method of test requires a test equipment not generally found in the service trade.

b) Leakage Current Check

Plug the AC line cord directly into the AC outlet (do not use a line isolation transformer during this check.). Using a "Leakage Current Tester", measure the leakage current from each exposed metal part of the cabinet, particularly any exposed metal part having a return path to the chassis, to a known good earth ground (water pipe, etc.). Any leakage current must not exceed 0.5mA AC (r.m.s.). However, in tropical area, this must not exceed 0.2mA AC (r.m.s.).

Alternate Check Method

Plug the AC line cord directly into the AC outlet (do not use a line isolation transformer during this check.). Use an AC voltmeter having 1000 following manner. Connect a 1500 a 0.15

µF AC-type capacitor between an exposed metal part

Ω per volt or more sensitivity in the

Ω 10W resistor paralleled by

and a known good earth ground (water pipe, etc.). Measure the AC voltage across the resistor with the AC voltmeter. Move the resistor connection to each exposed metal part, particularly any exposed metal part having a return path to the chassis, and measure the AC voltage across the resistor. Now, reverse the plug in the AC outlet and repeat each measurement. Any voltage measured must not exceed 0.75V AC (r.m.s.). This corresponds to 0.5mA AC (r.m.s.). However, in tropical area, this must not exceed 0.3V AC (r.m.s.). This corresponds to 0.2mA AC (r.m.s.).

AC VOLTMETER (HAVING 1000 /V, OR MORE SENSITIVITY)

0.15 F AC-TYPE

PLACE THIS PROBE

1500 10W

(11) High voltage hold down circuit check.

GOOD EARTH GROUND

ON EACH EXPOSED ME TAL PAR T

After repair of the high voltage hold down circuit, this circuit shall be checked to operate correctly.See item "How to check the high voltage hold down circuit".

This mark shows a fast operating fuse, the letters indicated below show the rating.

A V

POWER CORD REPLACEMENT WARNING.

Connecting the white line side of power cord to "WHT" character side.

PWB

White line side

WHT

(No.YA097)1-3

Page 4

1.2 INSTALLATION [ AV-65WP55 ]

1.2.1 REMOVING THE UPPER UNIT FROM THE LOWER UNIT

1.2.1.1 TYPES AND PLACES OF SCREWS

• Be careful not to confuse the following four types of screws.

Type

Ref. Place for attaching screws Quantity Color Shape A A A B C D

Front panel bracket Rear cover bracket Rear cover (for attaching the body) Inside the Front door (in the jack part) Rear cover (for attaching the body bracket) Rear cover (for attaching the speaker panel)

4 2 2 2 2 4

FRONT SIDE

Black

Gold

Black

diameter of 4mm-length of 18mm, acute tip

diameter of 3mm-length of 12mm, flat tip diameter of 4mm-length of 12mm, flat tip diameter of 4mm-length of 20mm, flat tip

A : diameter of 4mm - length

of 18mm, black, acute tip

REAR SIDE

D : diameter of 4mm - length

of 20mm, black, flat tip

B : diameter of 3mm - length of 12mm, black, flat tip

A : diameter of 4mm - length

of 18mm, black, acute tip

C : diameter of 4mm - length

of 12mm, gold, flat tip

A : diameter of 4mm - length

of 18mm, black, acute tip

1-4 (No.YA097)

A : diameter of 4mm - length of 18mm, black, acute tip

D : diameter of 4mm - length

of 20mm, black, flat tip

Page 5

1.2.1.2 DISASSEMBLY PROCEDURE

• Make sure that the power cord is pulled out from the AC wall socket. (1) Remove the 2 screws [ A ] on the left rear side of the set,

and then remove the rear cover bracket. [Fig.1]

(2) Remove the 2 screws [ B ] inside of the front door. [Fig.2]

* The screws attach the speaker grill.

(3) Remove the 2 screws [ D ] on the left edge of the rear

cover, and remove the 2 screws [ D ] on the right edge of the rear cover. [Fig.2] * The screws attach the speaker grill.

(4) Pull the speaker grill in front direction, and remove the

speaker grill. [Fig.2]

(5) Remove the 2 screws [ A ] on the left front panel bracket,

and remove the 2 screws [ A ] on the right front panel bracket. [Fig.2]

(6) Remove 1 screw [ C ] on the left edge of the rear cover, and

1 screw [ C ] on the right edge of the rear cover. [Fig.3]

(7) Remove 1 screw [ A ] on the left side of the rear cover, and

remove 1 screw [ A ] on the right side of the rear cover. [Fig.3]

(8) Move the rear cover approx. 3cm in rear direction. Then,

remove the upper unit from the lower unit by lifting the upper unit slowly. [Fig.3]

•VOID seal [ a ] attached to the left front panel bracket in order to confirm that a person except JVC installation workers has disassembled the set. This seal is removed when the upper unit is removed, and the letters of "VOID" appears in the place where the seal. [Fig.2]

• Two or more people are required to move the upper unit.

• Reflecting mirror is attached to the upper unit. So, handle it carefully so as to protect it from shocks.

• In placing the upper unit on the ground, be careful not to insert the connector for the auto-convergence on the right side of the upper unit between the upper unit and the ground.

• In placing the upper unit on the ground, be careful not to insert dust inside the upper unit.

• Be careful not to hurt yourself because metal brackets for attaching the front panel are on the ceiling part of the lower unit.

(9) Cover the lower unit with the Top Sheet in order not to

insert dust in the lower unit. Top Sheet is the one used for package. [Fig.4]

Fig.2

SPEAKER GRILL

UPPER

UNIT

LOWER

UNIT

Fig.3

TOP SHEET

Fig.1

REAR COVER

BRACKET

Fig.4

(No.YA097)1-5

Page 6

1.2.1.3 REASSEMBLY PROCEDURE

• Make sure that power cord is pulled out from the AC wall socket.

• Remove the Top Sheet which covers the lower unit. (1) Lift the upper unit slowly, and then place the upper unit on

the lower unit.

• In placing the upper unit on the lower unit, be careful not to insert the connector for the auto-convergence on the left side of the upper unit between the upper unit and the lower unit.

(2) Adjust the front side of the upper unit to the brackets on the

lower unit for attaching the upper unit.

(3) Attach 2 screws [ A ] to the both side of the rear cover.

[Fig.2]

(4) Attach 2 screws [ A ] to the both edge of the rear cover.

[Fig.2] (5) Attach the 4 screws [ A ] to the front panel bracket. [Fig.2] (6) Attach the VOID seal [ b ] on the front right side of the set

to the right front panel bracket. [Fig.5] (7) Attach the 2 screws [ B ] to the front door. [Fig.2] (8) Attach the speaker grill to the front side. (9) Attach 4 screws [ D ] to the both edge of the rear cover.

[Fig.2]

(10) Attach the 2 screws [ B ] to the front door.[Fig.2]

• Make sure that all the screws are attached certainly in order to fix the upper unit.

• After assembly procedure is completed, make sure that there is no dust in the inner side of the screen.

Fig.5

1-6 (No.YA097)

Page 7

1.2.2 INSTALLATION SITE

(1) The rear of this set is provided with ventilation openings.

Install the set more than 5 cm from a wall and in a location with good ventilation.

(2) Avoid the following types of locations.

a) Unstable locations (location must be able to

withstand heavy weight). b) Locations subjected to direct sunlight. c) Near stoves or other heating devices. d) Locations subjected to humidity or oily smoke. e) Dusty locations.

f) Locations with strong vibration.

1.2.3 INSTALLATION ADJUSTMENT

When installing, moving or changing the orientation of the set, perform static convergence adjustment according to the following procedure. Adjusting CRT color convergence have MANUAL and RESET. It adjust on the MENU screen.

NOTE :

Please have you TV on for at least 20 minutes before sing this feature. This adjustment will be needed only when the colors of the characters/lines are separated and lack in distinction. If not, please don't perform the adjustment.

MANUAL

(1) Press the [MENU] key, and select the

"CONVERGENCE" in the INITIAL SETUP menu with [function up/down] key.

(2) Press the [function left/right] key, the CONVERGENCE

menu appears.

(3) Press the [function up/down] key, and select the

"MANUAL".

(4) Press the [function left/right] key, then CONVERGENCE

adjustment screen appear. [Fig.1]

• If all the crosses are white, no convergence adjustment is needed.

(5) Select the location you want to adjust by using the

[number (2/4/5/6/8)] keys on the remote control unit. [Fig.2]

(6) Press the [SELECT] key to change the color of the box

to the color of the cross you want to adjust (red or blue).

• You cannot adjust the green cross.

(7) Use the [function up/down] key and the [function left/

right] keys to adjust the position of the cross.

(8) Adjust the three colors crosses until they overlap and

appear as a single white cross.

(9) Press the [OK] key.

NOTE :

• When you adjust the convergence, make sure you start with the center position (position 5), and work your way around radial for best results.

• When you make the adjustment in the center (positions 5), you are making the adjustment for the whale screen. In other positions, you are making the adjustment only in that area.

• You can reset the adjustment if you do not like the results, See below.

(10) Press the [menu] key to end the convergence

adjustment procedure.

(more than 5cm)

Wall

VENTILATION OPENING

RESET

RESET in the CONVERGENCE menu resets all convergence adjustments to the factory default setting.

Fig.1

Fig.2

(No.YA097)1-7

Page 8

SECTION 2

S-VIDEO

VIDEO

OPERATE

/ MONO

SPECIFIC SERVICE INSTRUCTIONS

2.1 FEATURES

• Rear Projection HDTV.

• 3-2 PULL DOWN : You can enjoy DVD movies at the highest picture quality.

• MOTION COMPENSATION : With this function, the seamless reproduction of dynamic motion on the screen has been realized.

• Bullet-in DSD (Digital Super Detail) circuit and 3 dimension Y/C separate circuit.

• Receive DTV broadcast (1080i / 720p / 480p / 480i)

• Built-in Component (Y / Pb / Pr) input.

• Built-in A.H.S. circuit.

2.2 DIFFERENCE LIST

Item AV-48WP55 AV-56WP55 AV-65WP55

DIGITAL INPUT TERMINAL --- --- available

2.3 FUNCTIONS

FRONT CONTROL KEY & TERMINAL

MENU button ( OPERATE ٕ )

OPERATE

CHANNERL -/+ button ( OPERATE / )

VOLUME -/+ button

MAIN POWER button

POWER LED (Blue)

INPUT4 terminal ( S-VIDEO / VIDEO / AUDIO )

REAR TERMINAL

UNPLUG THE POWER CORD FROM AC OUTLET BEFORE REMOVING THE REAR COVER

When the rear cover is removed, follow "CAUTION AT DISASSEMBLY" procedure in the service manual before plugging the TV's power cord into an AC outlet. Failure to follow the procedure will result in PERMANENT damage to some of the television features. DÉBRANCHEZ LE CORDON DE LA PRISE DE COURANT

C.A. AVANT DE RETIRER LE COUVERCLE ARRIÈRE. Une fois le couvercle arrière déposé suivez l procédure « ATTENTION LORS DU DÉMONTAGE » décrite dans une prise c.a. L'omission de suivre la procédure causera des dommages PERMANENTS à certaines fonctions du téléviseur.

Licensed from BBE Sound, Inc. under USP4638258, 4482866 and 5510752. BBE is a registered trademark of BBE Sound, Inc. Sous licence de BBE Sound, Inc. BBE est une marque de fabrique déposée de BBE Sound, Inc. Autorizado con licencia de BBE Sound, Inc. BBE es une marca comercial registrada de BBE Sound, Inc.

75 (VHF/UHF)

AV COMPULINK

S-VIDEO

CENTER CHANNEL INPUT

AUDIO OUT

AUDIO VIDEO

VIDEO

INPUT4

1 2

INPUT-3

INPUT-2

INPUT-1

L / MONO

[AV-65WP55]

DIGITAL IN

OVER

S-VIDEO

AUDIO (ANALOG)

VIDEO (DIGITAL)

AUDIO (DIGITAL)

COMPONENT VIDEO

DIGITAL IN terminal [AV-65WP55] ( HDMI connector : VIDEO / AUDIO )

AUDIO INPUT (For DIGITAL IN) terminal [AV-65WP55]

INPUT-1 terminal ( S-VIDEO / VIDEO / AUDIO )

INPUT-2 terminal ( VIDEO / AUDIO )

INPUT-1INPUT-2

INPUT-3 terminal ( S-VIDEO / VIDEO / AUDIO )

INPUT-1 COMPONENT VIDEO terminal ( Y / Pb / Pr )

INPUT-2 COMPONENT VIDEO terminal ( Y / Pb / Pr )

CENTER CHANNEL INPUT terminal

AUDIO OUT terminal

673 491011 5

AV COMPULINK

Antenna terminal ( VHF / UHF )

1-8 (No.YA097)

Page 9

REMOTE CONTROL UNIT [RM-C1257G]

MULTI SCREEN

FREEZE

SWAP

SELECT

C.C.INDEXTWIN

INPUT

POWER key

VCR / DVD switch

TV / CATV switch

MULTI SCREEN operation keys

DISPLAY key

SLEEP TIMER key

SOUND

TUNE

ASPECT

LIGHT

BACK

SOUND key

VIDEO STATUS key

THEATER PRO key

ASPECT key

MUTING key (memory key)

VOL+/- (/) keys

MENU key

C.C.(Closed Caption) key

RM-C1257G

INPUT key

Number (1~0) keys

RETURN+ key

TUNE key

LIGHT key

OK key

CH+/- (/) keys

BACK key

VCR / DVD operation keys

(No.YA097)1-9

Page 10

2.4 TECHNICAL INFORMATION

2.4.1 MAIN MICRO COMPUTER (CPU) FUNCTION (MN102H75K)

Pin No. Pin name I/O Function

1 NC O --------

2 /MICON_V I V.sync for OSD

3 LB_PRO I

Low B protection detection [Protection:H]

4 NC - --------

5 /RST I Main CPU reset [Reset:L]

6 NC O --------

7/TEST I+3.3V

8 OSD_YS O OSD Ys (blanking)

9SDA4 I/OI

C bus (data) for JCC5055

10 NC O --------

11 A_MU O Audio muting [Muting:H]

12 /MICON_H I H sync for OSD

13 NC O --------

14 P46,OSDXI I Oscillation for OSD

15 P45,OSDXO O Oscillation for OSD

16 SDA2 I/O I

C bus (data) for MTS

17 AC-IN I AC for timer count

18 SCL2 O I

C bus (clock) for MTS

19 NC O --------

20 VCOI I LPF

21 PDO O LPF

22 /IP_RESET O Reset for DIST [Reset:L]

23 OSD_YM O OSD Ym (transparence)

24 OSD_B O OSD blue

25 POWER_LED O

Lighting for POWER LED [HIGH / ON:H]

26 OSD_G O OSD green

27 OSD_R O OSD red

28 VREF I Reference voltage for OSD

29 IP_ERR I DIST program load detect.

30 IREF I Reference current for OSD

31 COMP I Phase adjust for OSD

32 AVDD I +3.3V

33 CLL I Clamp low level

34 VREFLS I Reference voltage for SUB CCD

35 SUB_CCD I

Video for sub closed caption decoder

36 NC - --------

37 VSS I GND

38 MAIN_CCD I

Video for main closed caption decorder

39 VREFHS I Reference voltage for MAIN CCD

40 CLH I Clamp high level

41 VDD/VPP I +3.3V

42 SCL4 O I

C bus (data) for JCC5055

Pin No. Pin name I/O Function

43 NC O --------

44 ON_TIM O

Lighting for on timer operating [LOW / ON:H]

45 SBO 0 O Convergence control [RXD]

46 SBD 0 I Convergence control [TXD]

47 SBT1 I --------

48 AP_DATA - --------

49 BS_RST - --------

50 SQR - --------

51 BS1.5CTL - --------

52 NC O --------

53 NC O --------

54 DC_COTL O Black level DC reproduce control

55 NC O --------

56 NC O --------

57 NC O --------

58 /LOB_POW O LowB power control [Power on:L]

59 COMPULINK I AV COMPULINK III control

60 /POWERGOOD I Power condition check

61 /MECA_ON I Machine SW interrupt [Pushing:L]

62 /MAIN_POW O Main power control [Power on :L]

63 NC - --------

64 /B1 POW O B1 power control [Power on:L]

65 AFC I AFT voltage

66 X_RAY I

X-ray protection detection

[Protection : 2.0V]

67 SPRIT O NC

68 KEY2 I Front key scan 2 (CH+, VOL-/+)

69 KEY1 I Front key scan 1 (MENU, CH-)

70 SCL1 O I

71 SDA1 I/O I

C bus (clock) for EEP-ROM

C bus (data) for EEP-ROM

72 REMO I Remote control

73 NC O --------

74 VSS I GND

75 OSC2 O 4MHz oscillation for system clock

76 OSC1 I 4MHz oscillation for system clock

77 VDD I +3.3V

78 SCL0 O I

C bus (clock) for general

79 AP_CLK O --------

80 SDA0 I/O I

C bus (data) for general

81 NC O --------

82 NC O --------

83 NC - --------

84 P_MU O Picture muting [Muting:H]

1-10 (No.YA097)

Page 11

2.5 MAIN PARTS LOCATION

2.5.1 PWB ASS'Y ARRANGEMENT

The PWB ASS'Y is indicated below.

PWB ASS'Y name AV-48WP55H AV-56WP55H AV-65WP55H

MAIN PWB ASS'Y SRP-1012A-M2 SRP-1013A-M2 SRP-1002A-M2

MI-COM & DIST MODULE PWB ASS'Y SRP0D001A-M2 ←← POWER PWB ASS'Y SRP-9001A-M2 ←← DEF / CONVERGENCE OUT PWB ASS'Y SRP-2012A-M2 ← SRP-2013A-M2

DIGITAL CONVERGENCE MODULE PWB ASS'Y SRP0K012A-M2 SRP0K013A-M2 SRP0K014A-M2

DIGITAL INPUT MODULE PWB ASS'Y --- --- SRP-7812A-M2

FRONT CONTROL PWB ASS'Y SRP0L012A-M2 ←← REMOCON SENSOR PWB ASS'Y SRP-8001A-M2 ←← VM PWB ASS'Y SRP-7201A-M2 ←← R CRT SOCKET PWB ASS'Y SRP-3101A-M2 ←← G CRT SOCKET PWB ASS'Y SRP-3201A-M2 ←← B CRT SOCKET PWB ASS'Y SRP-3301A-M2 ←←

PROJECTION UNIT

FRONT CONTROL ASS'Y

B CRT SOCKET PWB

G CRT SOCKET PWB

MI-COM & DIST MODULE PWB

MAIN PWB

FRONT CONTROL PWB

DIGITAL INPUT MODULE PWB [AV-65WP55]

R CRT SOCKET PWB

REMOCON SENSOR PWB

VM PWB

DIGITAL CONVERGENCE MODULE PWB

DEF / CONVERGENCE OUT PWB

POWER PWB

AV TERMINAL BOARD

(This figure is only MAIN UNIT)

(No.YA097)1-11

Page 12

2.6 SCREEN HANDLING CAUTIONS

2.6.1 SCREEN STORAGE Store the SCREEN ASS'Y in a standing position in order to avoid deformation. If the screen is stored horizontally, there is risk of

deforming the screen face. When necessary to place the SCREEN ASS'Y horizontally, position the screen side upwards and sure to place spacers between the screen and resting site (floor or stand etc.) to prevent the screen from sagging.

2.6.2 SCREEN SURFACE

Since the screen surface is easily scratched or soiled, use ample care when handling.

DISASSEMBLY PROCEDURE

If the screen or screen panel need to be replaced, remove the 14 (48 inch) / 20 (56 inch, 65 inch) screws A.

FRONT PANEL

SCREEN BRACKET

(TOP)

SCREEN

BRACKET

(LEFT)

(x 14) [48 inch] (x 20) [56 inch, 65 inch]

Leave the screen with protector, fresnel lens and double lenticular lens attached. If cannot be disassembled further.

SCREEN

SCREEN BRACKET

(RIGHT)

56 inch 65 inch only

SCREEN BRACKET

(BOTTOM)

2.7 PROJECTION UNIT REPLACEMENT

2.7.1 ADJUSTMENT DURING REPLACEMENT

When replacing the three R, G and B projection units, first replace the R and B units and perform focus / screen / raster centering adjustments with reference to the G unit. Then replace the G unit and perform G focus / screen / convergence adjustment. Finally perform R & B . Convergence adjustments. Use care to simultaneously removes all three-projection units.

2.7.2 DISASSEMBLY CAUTION

The projection units include locations that are not to be disassembled during service. When replacing projection unit parts, disassemble to the state indicated in the figure below. The figure indicates screws and wires that are not to be removed. Use care not to remove these.

Deflection yoke wires : to connector on DEF / CONVERGENCE OUT PWB ASS'Y. [R="RHV", G="GHV", B="BHV"] Convergence yoke wires : to connector on DEF / CONVERGENCE OUT PWB ASS'Y. [R="R", G="G", B="B"]

Check that tape is applied to the CRT neck. If absent, the deflection yoke can dislodge.

Do not remove screws

LENS ASS'Y

LENS ASS'Y SCREW ( x 4)

1-12 (No.YA097)

R CRT SOCKET PWB ASS'Y G CRT SOCKET PWB ASS'Y B CRT SOCKET PWB ASS'Y

2/4 POLE MAGNET

TAPE

VM PWB (G only)

ANODE wires : to DIVIDER

DEF. / CONVER. YOKE

CRT ASS'Y (COUPLER ASS'Y)

Do not disassembly

Page 13

SECTION 3

DISASSEMBLY

3.1 DISASSEMBLY PROCEDURE [AV-65WP55]

• Make sure that the power cord is pulled out from the AC wall socket.

3.1.1 SPEAKER GRILLE

(1) Remove 2 screws [ A ] from rear side. (2) Open the door of the FRONT CONTROL BOX and remove

2 screws [ B ] from front side.

(3) Take out the SPEAKER GRILLE.

3.1.2 SPEAKER

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ C ]. (2) Take out the SPEAKER. (3) Disconnect the speaker wire from speaker terminal.

*Remove the both side SPEAKER same manner.

3.1.3 FRONT BOARD

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ D ]. (2) Take out the FRONT BOARD.

3.1.4 FRONT CONTROL BOX

• Take out the SPEAKER GRILLE. (1) Remove 2 screws [ E ]. (2) Remove 2 screws [ F ]. (3) Disconnect the connector [BH], [R], [BG] on the FRONT

CONTROL PWB.

(4) Take out the FRONT CONTROL BOX.

3.1.5 FRONT CONTROL PWB

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove 2 screws [ G ]. (2) Remove 3 screws [ H ] from rear side of FRONT CONTROL

BOX.

(3) Take out the FRONT CONTROL PWB.

SPEAKER

WIRE

SPEAKER

SPEAKER GRILL

FRONT

CONTROL PWB

FRONT

CONTROL BOX

FRONT BOARD

Fig.1

FRONT

CONTROL BOX

DIGITAL INPUT MODULE [AV-65WP55]

AV TERMINAL BOARD

POWER CORD

CAUTION AT DISASSEMBLY

Prior to disassembly, unplug the power code from the AC outlet without fail. (Turn the power "off".) Short the SB connector [1] pin and [2] pin of the DIGITAL INPUT MODULE. (At the time of assembling) Before the rear panel is inserted into the cabinet, release the short-circuit between the SB connector [1] pin and [2] pin of the DIGITAL INPUT MODULE.

1 3

SB connector

2 4

After releasing the short-circuit between the SB connectors, do not turn the power on until the rear panel is inserted into the cabinet. Negligence in carrying out the above steps may cause the inactivation of the TV.

Fig.2

(No.YA097)1-13

Page 14

3.1.6 SCREEN ASS'Y

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove 4 screws [ I ] attaching the FRONT BRACKET. (2) Remove 10 screws [ J ] from rear side. (3) Take out the SCREEN ASS'Y.

NOTE :

• Please place the SCREEN ASS'Y on a flat table without fail.

• Because of the large size, at least two parsons are

recommended for removal and reassemble.

• Use care not to scratch the screen during work.

• During assembly, be sure to engage the left and right tabs

with the cabinet mounting positions.

• When than sporting the SCREEN ASS'Y, avoid grasping the

top of the screen panel, instead grasp the left and right areas.

3.1.7 MIRROR

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 10 screws [ K ] attaching the mirror brackets of the

upper, left and right side.

(2) Raise slightly to disengage of the mirror from the bottom

bracket. (If necessary, loosen the screws attaching the bottom bracket)

(3) Take out the MIRROR.

NOTE :

• The MIRROR is frontcoated. Do not touch the front of the MIRROR.

• At least 2 persons are recommended for removable and reassemble.

SCREEN ASS'Y

Fig.3

MIRROR

BRACKET

MIRROR BRACKET

1-14 (No.YA097)

Fig.4

Page 15

3.1.8 REAR PANEL

(1) Remove 3 screws [ L ]. (2) Remove 4 screws [ M ]. (3) Take out the REAR PANEL.

NOTE :

• Before the rear panel is inserted into the cabinet, release the short-circuit between the [SB] connector (1) pin and (2) pin of the DIGITAL INPUT UNIT. (Refer to "CAUTION AT DISASSEMBLY" on Page 13).

• After releasing the short-circuit between the [SB] connectors, do not turn the power on until the rear panel is inserted into the cabinet.

• Prior to starting the work, be sure to read the following written instructions on the CAUTION LABEL attached to the REAR PANEL.

Prior to starting the work, be sure to read the following

written instructions on the CAUTION LABEL attached to the REAR PANEL.

UNPLUG THE POWER CORD FROM AC OUTLET BEFORE OPEN THE REAR COVER (PANEL). When the rear cover (panel) is removed, follow "CAUTION AT DISASSEMBLY" procedure in the service manual before plugging the TV's power cord into an AC outlet. Failure to follow the procedure will result in PERMANENT damage to some of the television features.

PARTITION

REAR PANEL

REAR COVER

BRACKET

Fig.5

3.1.9 PARTITION

• Take out the REAR PANEL. (1) Pull out the PARTITION backward.

3.1.10 REAR COVER

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 2 screws [ N ]. (2) Take out the REAR COVER BRACKET. (3) Remove 2 screws [ O ]. (4) Remove 2 screws [ P ] from front side. (5) Slightly pull for backside to disengage of the REAR COVER

from hooks.

(6) Take out the REAR COVER.

NOTE :

• Because of the large size, at least two persons are

recommended for removal and reassemble.

REAR COVER

BRACKET

HOOK

Fig.6

(No.YA097)1-15

Page 16

3.1.11 MAIN UNIT

• Take out the SPEAKER GRILLE.

• Take out the FRONT PANEL.

• Take out the REAR PANEL. (1) Remove 4 screws [ Q ] from front side. (2) Take out the connector [BH], [R], [BG] on the FRONT

CONTROL PWB.

(3) Remove 2 screws [ R ] attaching the MAIN CHASSIS and

BODY.

(4) Pull out the MAIN UNIT rear side.

NOTE :

• Except for confirmation of projection of images on the screen and audio output through the speakers, the removed MAIN UNIT is still workable in the same state as if it is still built in the TV set. Therefore, the MAIN UNIT can be removed, if necessary, for board diagnosis, electric testing, etc. apart from confirmation of screen images and audio output.

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

• Because of the large size, at least two persons are recommended for removal and reassemble.

• When carrying the MAIN UNIT, use care not to drop, shock or shake it.

• Do not stain or damage the lens of the PROJECTION UNIT.

• Do not look the projection side of a PROJECTION UNIT when the image is projected.

BODY

FOCUS PACK

SPEAKER

WIRE

MAIN UNIT

SPEAKER

WIRE

SPEAKER CONNECTOR

Fig.7

3.1.11.1 CHECKING THE P.W. BOARD

When checking the MAIN PWB, POWER PWB, DEF & CONVERGENCE OUT PWB, etc., raise the MAIN UNIT with the front side down for the make of convenience.

3.1.12 FOCUS PACK

• Take out the MAIN UNIT. (1) Remove 1 screw [ S ]. (2) Take out the FOCUS PACK. (3) Take out 9 wires connecting the FOCUS PACK.

3.1.13 AV TERMINAL BOARD

• Take out the REAR PANEL. (1) Remove 4 screws [ T ]. (2) Pull out the POWER CORD CLAMP from AV TERMINAL

BOARD right side.

(3) Disconnect the connector [AU], [DC], [Q] and [SR] on the

DIGITAL INPUT MODULE PWB.

(4) Take out the AV TERMINAL BOARD.

3.1.14 DIGITAL INPUT MODULE

• Take out the AV TERMINAL BOARD. (1) Remove 1 screw [ U ]. (2) Remove 2 screws [ V ] from rear side of the AV TERMINAL

BOARD.

(3) Take out the DIGITAL INPUT MODULE.

NOTE:

• When removing the DIGITAL INPUT MODULE, refer to the "CAUTION AT DISASSEMBLY" section on page 13.

MAIN

CHASSIS

AV TERMINAL

BOARD

DIGITAL INPUT

MODULE

POWER CORD

1-16 (No.YA097)

Fig.8

Page 17

3.1.15 MAIN CHASSIS

• Take out the REAR PANEL. (1) Remove 2 screws [ W ]. (2) Remove 2 screws [ R ]. (3) Pull out the MAIN CHASSIS for backside.

NOTE:

• If necessary, remove the anode wires, connectors, respectively.

3.1.16 MI-COM & DIST MODULE PWB

• Take out the REAR PANEL.

• Take out the MAIN CHASSIS. (1) Disconnect the connector [ CN000E ], [ CN000Y ] on the

MI-COM & DIST MODULE PWB. (2) Remove 2 screws [ X ]. (3) Take out the MI-COM & DIST MODULE PWB.

MI-COM & DIST

MODULE PWB

3.1.17 DIGITAL CONVERGENCE MODULE PWB

• Take out the REAR PANEL.

• Take out the MAIN CHASSIS. (1) Remove 2 screws [ Y ]. (2) Take out the DIGITAL CONVERGENCE MODULE PWB.

3.1.18 PROJECTION UNIT

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the REAR PANEL.

• Take out the MAIN UNIT. (1) Take out the CRT SOCKET PWB. (2) Remove 4 screws [ Z ]. (3) Pull out the PROJECTION UNIT upward.

NOTE :

• Refer to "PROJECTION UNIT REPLACEMENT" on page 1-12 when taking out and replacing the PROJECTION UNIT.

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

3.1.19 HV DIVIDER

• Take out the REAR PANEL. (1) Remove 1 screw [ a ]. (2) Take out the HV DIVIDER.

*Wires of the transformer (FBT) and CRT of each PROJECTION UNIT can be removed by turning the connector portions.

NOTE :

• If necessary, remove the anode wires, and replacing the HV DIVIDER, take care to correctly engage the connector.

MAIN

CHASSIS

Turn

CONNECTOR

Pull

DIGITAL CONVERGENCE

MODULE PWB

Fig.9

PROJECTION UNIT

REMOCON

SENSOR PWB

HV DIVIDER

Fig.10

3.1.20 REMOCON SENSOR PWB

• Take out the REAR PANEL. (1) Disconnect the connector [ R ]. (2) Remove 1 screw [ b ]. (3) Take out the REMOCON SENSOR PWB.

(No.YA097)1-17

Page 18

3.2 DISASSEMBLY PROCEDURE [AV-48WP55, AV-56WP55]

• Make sure that the power cord is pulled out from the AC wall socket.

3.2.1 SPEAKER GRILLE

(1) Remove 4 screws [ A ] from rear side. (2) Open the door of the FRONT CONTROL BOX and remove

2 screws [ B ] from front side.

(3) Take out the SPEAKER GRILLE.

3.2.2 SPEAKER

• Take out the SPEAKER GRILLE (1) Remove 4 screws [ C ]. (2) Take out the SPEAKER. (3) Disconnect the speaker wire from speaker terminal.

*Remove the both side SPEAKER same manner.

3.2.3 FRONT BOARD

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ D ]. (2) Take out the FRONT BOARD.

3.2.4 FRONT CONTROL BOX

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ E ]. (2) Disconnect the connector [BH], [R], [BG] on the FRONT

CONTROL PWB.

(3) Take out the FRONT CONTROL BOX.

3.2.5 FRONT CONTROL PWB

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove 2 screws [ F ]. (2) Remove 3 screws [ G ] from rear side of FRONT

CONTROL BOX.

(3) Take out the FRONT CONTROL PWB.

SPEAKER

SPEAKER GRILL

CONTROL PWB

WIRE

FRONT

CONTROL BOX

FRONT BOARD

Fig.1

3.2.6 SCREEN ASS'Y

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove 2 screws [ H ] attaching the FRONT BRACKET. (2) Remove 10 screws [ I ] from rear side. (3) Take out the SCREEN ASS'Y.

NOTE :

• Please place the SCREEN ASS'Y on a flat table without fail.

• Because of the large size, at least two parsons are recommended for removal and reassemble.

• Use care not to scratch the screen during work.

• During assembly, be sure to engage the left and right tabs with the cabinet mounting positions.

• When than sporting the SCREEN ASS'Y, avoid grasping the top of the screen panel, instead grasp the left and right areas.

FRONT

CONTROL BOX

Fig.2

SCREEN ASS'Y

Fig.3

1-18 (No.YA097)

Page 19

3.2.7 MIRROR

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 9 screws [ J ] attaching the mirror brackets of the

upper, left and right side.

(2) Raise slightly to disengage of the mirror from the bottom

bracket. (If necessary, loosen the screws attaching the bottom bracket)

(3) Take out the MIRROR.

NOTE :

• The MIRROR is frontcoated. Do not touch the front of the MIRROR.

• At least 2 persons are recommended for removable and reassemble.

3.2.8 REAR PANEL

(1) Remove 6 screws [ K ]. (2) Remove 4 screws [ L ]. (3) Take out the REAR PANEL.

3.2.9 PARTITION

• Take out the REAR PANEL. (1) Pull out the PARTITION backward.

MIRROR

BRACKET

MIRROR BRACKET

Fig.4

PARTITION

3.2.10 REAR COVER

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 2 screws [ M ]. (2) Remove 2 screws [ N ] from front side. (3) Slightly pull for backside to disengage of the REAR COVER

from hooks.

(4) Take out the REAR COVER.

NOTE :

• Because of the large size, at least two persons are

recommended for removal and reassemble.

REAR PANEL

Fig.5

REAR COVER

HOOK

BRACKET

Fig.6

(No.YA097)1-19

Page 20

3.2.11 MAIN UNIT

• Take out the SPEAKER GRILLE.

• Take out the FRONT PANEL.

• Take out the REAR PANEL. (1) Remove 4 screws [ O ] from front side. (2) Take out the connector [BH], [R], [BG] on the FRONT

CONTROL PWB.

(3) Remove 2 screws [ P ] attaching the MAIN CHASSIS and

BODY.

(4) Pull out the MAIN UNIT rear side.

NOTE :

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

• Because of the large size, at least two persons are recommended for removal and reassemble.

• When carrying the MAIN UNIT, use care not to drop, shock or shake it.

• Do not stain or damage the lens of the PROJECTION UNIT.

• Do not look the projection side of a PROJECTION UNIT when the image is projected.

BODY

FOCUS PACK

SPEAKER

WIRE

MAIN UNIT

SPEAKER

WIRE

SPEAKER CONNECTOR

Fig.7

3.2.11.1 CHECKING THE P.W. BOARD

When checking the MAIN PWB, POWER PWB, DEF & CONVERGENCE OUT PWB, etc., raise the MAIN UNIT with the front side down for the make of convenience.

3.2.12 FOCUS PACK

• Take out the MAIN UNIT. (1) Remove 1 screw [ Q ]. (2) Take out the FOCUS PACK. (3) Take out 9 wires connecting the FOCUS PACK.

3.2.13 AV TERMINAL BOARD

• Take out the REAR PANEL. (1) Remove 4 screws [ R ]. (2) Pull out the POWER CORD CLAMP from AV TERMINAL

BOARD right side.

(3) Disconnect the connector [AU], [DC], [Q] and [SR] on the

DIGITAL INPUT MODULE PWB.

(4) Take out the AV TERMINAL BOARD.

MAIN

CHASSIS

AV TERMINAL

BOARD

1-20 (No.YA097)

POWER CORD

Fig.8

Page 21

3.2.14 MAIN CHASSIS

• Take out the REAR PANEL. (1) Remove 2 screws [ S ]. (2) Remove 2 screws [ P ]. (3) Pull out the MAIN CHASSIS for backside.

NOTE:

If necessary, remove the anode wires, connectors, respectively.

3.2.15 MI-COM & DIST MODULE PWB

• Take out the REAR PANEL.

• Take out the MAIN CHASSIS. (1) Disconnect the connector [ CN000E ], [ CN000Y ] on the

MI-COM & DIST MODULE PWB. (2) Remove 2 screws [ T ]. (3) Take out the MI-COM & DIST MODULE PWB.

MI-COM & DIST

MODULE PWB

3.2.16 DIGITAL CONVERGENCE MODULE PWB

• Take out the REAR PANEL.

• Take out the MAIN CHASSIS. (1) Remove 2 screws [ U ]. (2) Take out the DIGITAL CONVERGENCE MODULE PWB.

3.2.17 PROJECTION UNIT

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the REAR PANEL.

• Take out the MAIN UNIT. (1) Take out the CRT SOCKET PWB. (2) Remove 4 screws [ V ]. (3) Pull out the PROJECTION UNIT upward.

NOTE :

• Refer to "PROJECTION UNIT REPLACEMENT" on page 1-12 when taking out and replacing the PROJECTION UNIT.

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

3.2.18 HV DIVIDER

• Take out the REAR PANEL. (1) Remove 1 screw [ W ]. (2) Take out the HV DIVIDER.

*Wires of the transformer (FBT) and CRT of each PROJECTION UNIT can be removed by turning the connector portions.

NOTE :

• If necessary, remove the anode wires, and replacing the HV DIVIDER, take care to correctly engage the connector.

MAIN

CHASSIS

Turn

CONNECTOR

Pull

DIGITAL CONVERGENCE

MODULE PWB

Fig.9

PROJECTION UNIT

REMOCON

SENSOR PWB

HV DIVIDER

Fig.10

3.2.19 REMOCON SENSOR PWB

• Take out the REAR PANEL. (1) Disconnect the connector [ R ]. (2) Remove 1 screw [ X ]. (3) Take out the REMOCON SENSOR PWB.

(No.YA097)1-21

Page 22

3.3 MEMORY IC REPLACEMENT

3.3.1 MEMORY IC

This memory IC stores data for proper operation of the video and deflection circuits. When replacing, be sure to use an IC containing this (initial value) data.

3.3.2 MEMORY IC REPLACEMENT PROCEDURE

(1) Power off

Switch off the power and disconnect the power cord from the wall outlet.

(2) Replace the memory IC

Initial value must be entered into the new IC.

(3) Power on

Connect the power cord to the wall outlet and switch on the power.

(4) SERVICE MENU setting

Before entering the SERVICE MENU, confirm that the setting of TV/CATV SW of the REMOTE CONTROL UNIT is at the "TV" side and the setting of VCR/DVD SW of the REMOTE CONTROL UNIT is at the "VCR" side. If the switches have not been properly set, you cannot enter the SERVICE MENU.

a) Press [SLEEP TIMER] key and, while the indication

of SLEEP TIMER 0 MIN is being displayed, press [DISPLAY] key and [VIDEO STATUS] key (Fig.2)

simultaneously. b) The SERVICE MENU screen of Fig.1 is displayed. c) Verify what to set in the SERVICE MENU, and set

whatever is necessary (Fig.1).

Refer to the SERVICE ADJUSTMENT for setting. d) Press the [BACK] key twice to return normal screen.

(5) Receive channel setting

Refer to the OPERATING INSTRUCTIONS (USER'S GUIDE) and set the receive channels (Channels Preset) as described.

(6) User settings

Check the user setting items according to after page. Where these do not agree, refer to the OPERATING INSTRUCTIONS (USER'S GUIDE) and set the items as described.

SERVICE MENU SELECT KEY

VCR/DVD switch

TV/CATV switch

DISPLAY SLEEP

TIMER VIDEO

STATUS MEMORY

(MUTING

FUNCTION (LEFT)

SERVICE MENU

1.PICTURE/SOUND

2.YC SEP

3.WHITE BALANCE

4.MEMORY SETUP

5.RF AFC

6.CONVER A

Fig.1

MULTI SCREEN

SWAP

FREEZE

SELECT

SOUND

TUNE

ASPECT

RM-C1257G

Fig.2

7.CONVER B

8.IP

9.DSD

0.HDMI

C.C.INDEXTWIN

INPUT

LIGHT

BACK

POWER

NUMBER

FUNCTION (UP)

FUNCTION (RIGHT)

BACK

FUNCTION (DOWN)

3.3.3 SERVICE ADJUSTMENT ITEM

Setting item Item No. Remark Setting item Item No. Remark

1.PICTURE/SOUND 6.CONVER A AUDIO A01~A27 Convergence adjustment CPA01~CPA11 VIDEO S01~S99 CCA01~CCA12 DEFLECTION D01~D32 CDA01~CDA07 FACTORY setting F01~F70 CBA01~CBA94

2.YC SEP 7.CONVER B YC separation setting YCM001~YCM185

YCS001~YCS114 Do not adjust

Convergence adjustment ------

8.IP DIST process setting IPA001~IPA042 Do not adjust

3.WHITE BALANCE 9.DSD LOW LIGHT/HIGH LIGHT adjustment

BR, DRV R, DRV B, CUT R, CUT G, CUT B

DSD process setting DSA001~DSA053

DSB001~DSB053

4.MEMORY SETUP ------ Do not adjust DSC001~DSC044

5.RF AFC DSD001~DSD017 TUNER RF AFT setting TUNER, AFC,FINE

Do not adjust

0.HDMI Digital input setting HDM001~HDM080

RHD001~RHD170

1-22 (No.YA097)

Do not adjust

Page 23

3.3.4 FACTORY SHIPPING SETTING

USER SETTING

Setting item Setting value Setting item Setting value

POWER CHANNEL VOLUME INPUT

DISPLAY ASPECT VIDEO STATUS

Off CABLE-02 10 TV

OFF REGULAR DYNAMIC

SOUND

A.H.S OFF

SPLIT SOURCE LEFT SIDE : CA 02

RIGHT SIDE : INPUT1

POSITION ADJUSTMENT XDS ID CONVERGENCE POWER INDICATOR

Center ON AUTO HIGH

TINT / COLOR / PICTURE/ BRIGHT / DETAIL

COLOR TEMPERATURE DIG. NOISE CLEAR VSM (Velocity Scan Modulation)

NATURAL CINEMA BASS / TREBLE / BALANCE MTS ON / OFF TIMER LANGUAGE NOISE MUTING FRONT PANEL LOCK CLOSED CAPTION FRONT PANEL LOCK V1 SMART INPUT VIDEO INPUT LABEL

AUTO SHUT OFF DIGITAL-IN DIGITAL AUDIO CHANNEL SUMMARY

V-CHIP AUTO DEMO

Refer to setting of Video status memory at shipping factory setting

LOW OFF ON

AUTO Center STEREO OFF ENG ON OFF OFF ( CC1 / T1 ) OFF OFF BLANK

OFF SIZE 1

DIGITAL Refer to Last memory (CH. summary) OFF OFF

VIDEO STATUS MEMORY (NTSC / 480i / 480p)

Item

TINT COLOR PICTURE BRIGHT DETAIL

Setting value

STANDARD 0 0 0 0 0 THEATER 0 0 0 0 0 DYNAMIC 0 0 +10 0 +5 GAME 0 0 -10 0 0

(720p / 1080i)

Item

TINT COLOR PICTURE BRIGHT DETAIL

Setting value

STANDARD 0 0 0 0 0 THEATER 0 0 0 0 0 DYNAMIC 0 0 +5 0 +10 GAME 0 0 -10 0 0

(No.YA097)1-23

Page 24

CHANNEL SETTING (CHANNEL SUMMARY)

Band CH display Setting Band CH display Setting

VHF LOW 2 USED SUPER N 27 NOT USED

3 NOT USED O 28 USED 4 USED P 29 NOT USED 5 USED Q 30 NOT USED 6 USED R 31 USED

VHF HIGH 7 USED S 32 USED

8 NOT USED T 33 NOT USED

9 USED U 34 NOT USED 10 NOT USED V 35 NOT USED 11 USED W 36 USED 12 NOT USED SUBMID A-7 93 NOT USED 13 USED A-6 94 NOT USED

UHF 14 USED A-5 95 NOT USED

36 USED A-4 96 USED 41 NOT USED A-3 97 USED 46 NOT USED A-2 98 USED 63 USED A-1 99 NOT USED 69 USED A-8 01 NOT USED

MID A 14 USED HYPER W+11 47 USED

B 15 USED W+12 48 USED C 16 USED W+17 53 USED D 17 USED W+23 59 USED E 18 USED ULTRA W+29 65 NOT USED F 19 NOT USED W+51 NOT USED G 20 NOT USED W+78 NOT USED H 21 USED W+84 NOT USED

I 22 NOT USED

SUPER J 23 NOT USED

K 24 USED L 25 NOT USED

M 26 NOT USED

1-24 (No.YA097)

Page 25

3.4 REPLACEMENT OF CHIP COMPONENT

3.4.1 CAUTIONS

(1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it.

3.4.2 SOLDERING IRON

(1) Use a high insulation soldering iron with a thin pointed end of it. (2) A 30w soldering iron is recommended for easily removing parts.

3.4.3 REPLACEMENT STEPS

1. How to remove Chip parts

2. How to install Chip parts

[Resistors, capacitors, etc.]

(1) As shown in the figure, push the part with tweezers and

alternately melt the solder at each end.

(2) Shift with the tweezers and remove the chip part.

[Transistors, diodes, variable resistors, etc.]

(1) Apply extra solder to each lead.

SOLDER

[Resistors, capacitors, etc.]

(1) Apply solder to the pattern as indicated in the figure.

(2) Grasp the chip part with tweezers and place it on the

solder. Then heat and melt the solder at both ends of the chip part.

[Transistors, diodes, variable resistors, etc.]

(1) Apply solder to the pattern as indicated in the figure. (2) Grasp the chip part with tweezers and place it on the

solder.

(3) First solder lead A as indicated in the figure.

(2) As shown in the figure, push the part with tweezers and

alternately melt the solder at each lead. Shift and remove the chip part.

NOTE :

After removing the part, remove remaining solder from the pattern.

(4) Then solder leads B and C.

(No.YA097)1-25

Page 26

SECTION 4

ADJUSTMENT

4.1 ADJUSTMENT PREPARATION

(1) You can make the necessary adjustments for this unit with

either the Remote Control Unit or with the adjustment tools and parts as given below.

(2) Adjustment with the Remote Control Unit is made on the

basis of the initial setting values, however, the new setting values which set the screen to its optimum condition may

differ from the initial settings. (3) Make sure that AC power is turned on correctly. (4) Turn on the power for set and test equipment before use,

and start the adjustment procedures after waiting at least

30 minutes. (5) Unless otherwise specified, prepare the most suitable

reception or input signal for adjustment. (6) Never touch any adjustment setting value which are not

specified in the list for this adjustment. (7) Presetting before adjustment

Unless otherwise specified in the adjustment instructions,

preset the following functions with the remote control unit.

4.2 MEASURING INSTRUMENT AND FIXTURES

(1) DC voltmeter (or digital voltmeter) (2) Oscilloscope (3) Signal generator (Pattern generator)

[NTSC / 480i / 480p / 720p / 1080i / HDMI] (4) TV audio multiplex signal generator (5) Remote control unit

SETTING POSITION

Setting item Setting position

VIDEO STATUS STANDARD

TINT / COLOR / PICTURE / BRIGHT / DETAIL

COLOR TEMPERATURE LOW

DIG. NOISE CLEAR OFF

NATURAL CINEMA AUTO

VSM OFF

BASS / TREBLE / BALANCE Center

A.H.S OFF

ASPECT FULL

VERTICAL POSITION Center

ON/OFF TIMER OFF

AUTO SHUTOFF OFF

4.3 ADJUSTMENT FLOWCHART

WHEN REPLACING SCREEN AND PROJECTION UNIT

• Contains only the main adjustments. Also confirm other adjustments as required.

1 Projection unit

Install projection tube

LENS FOCUS

BEAM SPOT

CRT FOCUS

SCREEN & LOW LIGHT

DEFLECTION

CONVERGENCE

(match to unreplaced tube)

HIGH LIGHT

END

3 Projection unit

Install projection tube

LENS FOCUS

BEAM SPOT

CRT FOCUS

SCREEN & LOW LIGHT

DEFLECTION

G CONVERGENCE

R CONVERGENCE

B CONVERGENCE

HIGH LIGHT

END

SCREEN

LENS FOCUS

G convergence

disturbed

G CONVERGENCE

R CONVERGENCE

B CONVERGENCE

END

1-26 (No.YA097)

Page 27

4.4 ADJUSTMENT LOCATION

REMOCON SENSOR PWB

TOP

FRONT CONTROL PWB

LED

POWER SW

DIGITAL INPUT MODULE PWB [AV-65WP55]

FRONT

R SPEAKER L SPEAKER

FRONT FRONT

MENU CH - CH + VOL - VOL +

BG BHR

S-VIDEO VIDEO

MAIN PWB

CN1001

INPUT-4

CN001

TU1101

CN1002

CN1004

CN002

MI-COM & DIST MODULE PWB

DEF & CONVERGENCE OUT PWB CN00Y

CN000Y

G CRT SOCKET PWB E

CN000E

CN1003

CN003

FUSE

F801 (125V 7A)

POWER PWB

(No.YA097)1-27

Page 28

TOP

RGB

RG B

FOCUS PACK

SCREEN

FOCUS

FBT

VM PWB

B VM COIL G VM COIL

R VM COIL

RGB

MI-COM&DIST MODULE PWB CN000E

GBN

TP-EB

BSC

B CRT SOCKET PWB

GBK

MI-COM&DIST MODULE PWB CN000Y

CN007

TP-B

CN007

CN00Y

CN00N

GBN A

TP-EG

GSC

GBK

CN0B1

RGN

TP-G

G CRT

TP-ER

SOCKET PWB

RGK

DIGITAL CONVERGENCE

MODLUE PWB

CN0G1

CN0R1

RSC

RGN

RGK

CN011

CN012

TP-R

R CRT SOCKET PWB

FRONTFRONT

CN008

POWER PWB

DEF & CONVERGENCE OUT PWB

1-28 (No.YA097)

CN008

5Pin : 4Pin : 3Pin : 2Pin : 1Pin :

DAF

TP-91(B1) NC X-ray1 X-ray2 TP-E( )

CNRHV

CNGHV

CNBHV

R CONVER. YORK

G CONVER. YORK

B CONVER. YORK

R DEF YORK

G DEF YORK

B DEF YORK

B CRT

FOCUS PACK

CN0AA

CN00A

FBT

G CRT

R CRT

R G B

HV DIVIDER

Page 29

4.5 BASIC OPERATION OF SERVICE MENU

CPA01 FINE OFF 0

SERVICE MENU

A01~A27

S01~S99

D01~D32

F01~F70

1.PICTURE/SOUND

2.YC SEP

3.WHITE BALANCE

4.MEMORY SETUP

5.RF AFC

6.CONVER A

7.CONVER B

8.IP

9.DSD

0.HDMI

1.PICTURE/SOUND 5.RF AFC

NTSC FULL ST L FL MUTE

TOO HIGH

TUNER AFC

A01 IN LEVEL 008

FINE

6.CONVER A

A01 IN LEVEL 008

S01 COLOR 099

CPA01 FINE OFF 0

D01 V.SIZE 049

F01 001

7.CONVER B

GOOD TOO LOW

MAIN

+28

DO NOT ADJUST

CPA01~CPA11 CCA01~CCA12 CDA01~CDA07

CBA01~CBA94

DO NOT ADJUST

YCM001~YCM185

YCS001~YCS114

2.YC SEP

NTSC FULL ST L FL MUTE

YCM001 000 002

3.WHITE BALANCE

BR 118 DRV R 089 B 108 CUT R 247 G 244 B 226

4.MEMORY SETUP

ADDR 0000

01234567

AA 55 00 00 FF 00 00 00

89ABCDEF

00 00 00 00 00 00 00 00

8.IP

NTSC FULL ST L FL MUTE

IPA001 0C7

9.DSD

NTSC FULL ST L FL MUTE

DSA001 0CF 002

0.HDMI

NTSC FULL ST L FL MUTE

HDM001 000

DO NOT ADJUST

IPA001~IPA042

DO NOT ADJUST

DSA001~DSA053 DSB001~DSB053 DSC001~DSC044 DSD001~DSD017

DO NOT ADJUSTDO NOT ADJUST

HDM001~HDM080

RHD001~RHD170

(No.YA097)1-29

Page 30

4.5.1 TOOL OF SERVICE MENU OPERATION

Operate the SERVICE MENU with the REMOTE CONTROL UNIT.

4.5.2 SERVICE MENU ITEMS

In general, basic setting (adjustments) items or verifications are performed in the SERVICE MENU.

1.PICTURE / SOUND This sets the setting values of the VIDEO, AUDIO and DEFLECTION circuits.

2.YC SEP This is used when the YC SEPARATION circuit is adjusted. [Do not adjust]

3.WHITE BALANCE This sets the setting values of the WHITE BALANCE.

4.MEMORY SETUP This sets the setting values of the MEMORY ADDRESS. [Do not adjust]

5.RF AFC This is used when the IF VCO is adjusted. [Do not adjust]

6.CONVER A This is used when the CONVERGENCE is adjusted.

7.CONVER B This is used when the CONVERGENCE is adjusted.

8.IP This sets the setting value of the DIST circuit. [Do not adjust]

9.DSD This sets the setting value of the DSD circuit. [Do not adjust]

0.HDMI This sets the setting value of the DIGITAL INPUT circuit. [Do not adjust].

4.5.3 BASIC OPERATIONS OF THE SERVICE MENU

(1) How to enter the SERVICE MENU

Press [SLEEP TIMER] key and, while the indication of "SLEEP TIMER 0 MIN." is being displayed, press [DISPLAY] key and [VIDEO STATUS] key simultaneously to enter the SERVICE MENU screen.

(2) Releasing SERVICE MENU

After returning to the SERVICE MENU upon completion of the setting work, press the [BACK] key again.

4.5.4 DESCRIPTION OF STATUS DISPLAY

The status display on the upper part of the SERVICE MENU screen is common.

(1) SIGNAL SYSTEM

NTSC : Composite, S-video (Y / C), No signal. DVD : 480i (component) ED : 480p HD : 1080i 720 : 720p HED1 : HDMI 480p SIZE1 HED2 : HDMI 480p SIZE2 HHD : HDMI 1080i H750 : HDMI 720p

(2) ASPECT / MULTI

1) ONE SCREEN

FULL : FULL PANO : PANORAMA

SIGNAL SYSTEM

ASPECT/ MULTI

VIDEO STATUS

NTSC FULL ST L FL MUTE

A01 IN LEVEL 008

[1.PICTURE/SOUND]

(4) WHITE BALANCE

H: HIGH L: LOW

(5) IP CONVERTING MODE

FL : FRAME LI : LINE 23 : COMPULSORY NATURAL CINEMA IN

STATUS DISPLAY

MEMORY MODE

IP CHANGING MODE

WHITE BALANCE

CINE : CINEMA REGU : REGULAR

2) MULTI SCREEN

(6) MEMORY MODE

MUTE : Press [MUTING] key DIR : Change data then memory at the same time.

M1 : One screen (for adjustment) M2-1 : TWIN (4 : 3) M2-2 : TWIN (16 : 9) M12 : INDEX

(3) VIDEO STATUS

ST : STANDARD DA : DYNAMIC TH : THEATER GA : GAME

1-30 (No.YA097)

Page 31

4.5.5 SERVICE MENU SETTING

1. PICTURE/SOUND

AUDIO / VIDEO / DEFLECTION circuit adjustment.

1. SETTING ITEM No.

A : AUDIO S : SIGNAL D : DEFLECTION F : FACTORY SETTING

• Press [CH+] / [CH-] key

F01D01S01A01

Item No. is up/down

• Press [SLEEP TIMER] key

Skip change

2. SETTING ITEM NAME Describe setting item name

3. SETTING VALUE

• Press [VOL+] / [VOL-] key Set the setting value.

• Press [MUTING] key Memorize the data.

1.PICTURE/SOUND

NTSC FULL ST L FL MUTE

3. WHITE BALANCE

Adjustment of LOW LIGHT / HIGH LIGHT.

1. SELECT ITEM

• Press [CH+] / [CH-] key

2. SETTING VALUE BRIGHT

• Press [VOL+] / [VOL-] key DRIVE [2] key : DRIVE R is up [5] key : DRIVE R is down [3] key : DRIVE B is up [6] key : DRIVE B is down CUTOFF [7] key : CUTOFF G is up [TUNE] key : CUTOFF G is down [8] key : CUTOFF R is up

F01D01S01A01

[0] key : CUTOFF R is down [9] key : CUTOFF B is up [RETURN+] key : CUTOFF B is down

3. WHITE BALANCE

BRIGHT VALUE

R.DRIVE VALUE

B.DRIVE VALUE

BR 118 DRV R 089 B 108 CUT R 247 G 244 B 226

B.CUT OFF VALUE

G.CUT OFF VALUE R.CUT OFF VALUE

A01 IN LEVEL 008

SETTING ITEM No.

A01~A27 / S01~S99 D01~D32 / F01~F70

2. YC SEP

YC separation circuit setting.

[Do not adjust]

2.YC SEP

NTSC FULL ST L FL MUTE

YCM001 000 002

SETTING ITEM No.

YCM001~YCM185

YCS001~YCS114

SETTING VALUE

SETTING ITEM NAME

SETTING VALUE

4. MEMORY SETUP

Main memory data edition.

[Do not adjust]

4.MEMORY SETUP

ADDR 0000

01234567

AA 55 00 00 FF 00 00 00

89ABCDEF

00 00 00 00 00 00 00 00

5. RF AFC

Setting the RF VCO adjustment.

[Do not adjust]

5.RF AFC

TOO HIGH

GOOD TOO LOW

TUNER

MAIN AFC FINE

+28

(NOTE) AFC Select ON / OFF FINE FineTuning(-77~+77) AFC ON:Auto Setting

(No.YA097)1-31

Page 32

6. CONVER A

CPA01 FINE OFF 0

Setting the CONVERGENCE PHASE adjustment.

• Setting for 6.CONVER A is described in the CONVERGENCE adjustment.

6.CONVER A

CPA01 FINE OFF 0

SETTING ITEM No.

CPA01~CPA11 CCA01~CCA12 CDA01~CDA07 CBA01~CBA94

SETTING ITEM NAME SETTING VALUE

8. IP

DIST circuit data setting.

[Do not adjust]

NTSC FULL ST L FL MUTE

IPA001 0C7

8.IP

SETTING ITEM No.

IPA001~IPA042

SETTING VALUE

• Press [INPUT] key

CBA01CDA01CCA01CPA01

Skip change

7. CONVER B

Setting the CONVERGENCE POINT (fine).

• Setting for 7.CONVER B is described in the CONVERGENCE adjustment.

7.CONVER B

9. DSD

DSD circuit data setting.

[Do not adjust]

9.DSD

NTSC FULL ST L FL MUTE

DSA001 0CF 002

• Press [SLEEP TIMER] key

Skip change

0. HDMI

DIGITAL INPUT circuit data setting.

[Do not adjust]

0.HDMI

NTSC FULL ST L FL MUTE

HDM001 000

SETTING ITEM No.

DSA001~DSA053

DSB001~DSB053 DSC001~DSC044 DSD001~DSD017

SETTING VALUE

DSD001DSC001DSB001DSA001

SETTING ITEM No.

HDM001~HDM080

RHD001~RHD170

SETTING VALUE

4.5.6 DESCRIPTION OF TEST MODE

(1) Press [SLEEP TIMER] key and set 30 minutes. (2) While the indication "SLEEP TIMER 30 MIN." is being

displayed, press [DISPLAY] key and [VIDEO STATUS] key simultaneously to enter the TEST MODE MENU screen as shown

in the Fig.1. (3) Press [ 5 ] key to enter the 5.CONVER OFF. (4) Press [INPUT] key to select the crosshatch pattern.

TEST MODE

1. I2C STOP

2. STATUS DISP.

4. SELF-CHK

5. CONVER OFF

ROM CORRECTION : ACT ROM VERSION :

*******

Fig. 1

1-32 (No.YA097)

Fig. 2

Fig. 3

Page 33

4.6 INITIAL SETTING VALUE OF SERVICE MENU

(1) Adjustment of the SERVICE MENU is made on the basis of the initial setting values; however, the new setting values which set

the screen in its optimum condition may differ from the initial setting. (2) Do not change the initial setting values of the setting items NOT LISTED IN ADJUSTMENT. (3) "---" is not adjusted. Setting value is not displayed.

CAUTION:

Never change the initial setting value any adjustments except for those that are designated in the adjustment procedures.

In case where you have made undesignated adjustments by mistake, never press the [MUTING] key on the remote control unit. Whenever you had not pressed the [MUTING] key, you would be able to recover the initial value by switching the [POWER] key.

4.6.1 [1. PICTURE / SOUND]

AUDIO SYSTEM

Item

No.

Item name Variable range

AV-48WP55 AV-56WP55 AV-65WP55

Initial setting value

A01 IN LEVEL 000~015 008 008 008

A02 LOW SEP 000~063 035 035 035

A03 HI SEP 000~063 020 020 020

A04 BBE BASS -128~+127 +010 +010 +010

A05 BBE TRE -128~+127 000 000 000

A06 SURROUND 000 / 001 000 000 000

A07 BASS OFS -128~+127 -017 -017 -017

A08 TRE OFS -128~+127 -009 -009 -009

A09 AHS MVE -128~+127 000 000 000

A10 AHS MSC -128~+127 000 000 000

A11 (Not display) 000 / 001 000 000 000

A12 (Not display) 000 / 001 000 000 000

A13 (Not display) 000 / 001 000 000 000

A14 (Not display) 000 / 001 000 000 000

A15 (Not display) 000 / 001 000 000 000

A16 (Not display) 000 / 001 000 000 000

A17 (Not display) 000 / 001 000 000 000

A18 (Not display) 000 / 001 000 000 000

A19 (Not display) 000 / 001 000 000 000

A20 (Not display) 000 / 001 000 000 000

A21 (Not display) 000 / 001 000 000 000

A22 (Not display) 000 / 001 000 000 000

A23 (Not display) 000 / 001 000 000 000

A24 (Not display) 000 / 001 000 000 000

A25 (Not display) 000 / 001 000 000 000

A26 (Not display) 000 / 001 000 000 000

A27 (Not display) 000 / 001 000 000 000

(No.YA097)1-33

Page 34

DEFLECTION SYSTEM

Item

No.

Item name Variable range

SINGLE PICTURE

(FULL)

TWIN / INDEX

D01 V. SIZE 000~127 059 059

D02 EW 000~063 033 033

D03 H. SIZE 000~063 033 033

D04 V. SCORE 000~063 040 040

D05 V. LINE 000~063 042 042

D06 V. CENT 000~063 025 025

D07 EW.TRAP 000~063 031 031

D08 BOT.CORN 000~015 008 008

D09 TOP.CORN 000~015 008 008

D10 V. EHT 000~007 005 005

D11 H. EHT 000~007 005 005

D12 (Not display) 000~007 006 006

D13 (Not display) 000~015 000 000

D14 H. CENTER 000~255 117 117

D15 H. FREQ 000~255 190 190

D16 (Not display) 000~127 100 100

D17 (Not display) 000~003 000 000

D18 (Not display) 000 / 001 000 000

D19 (Not display) 000 / 001 000 000

D20 (Not display) 000 / 001 000 000

D21 (Not display) 000 / 001 000 000

D22 (Not display) 000 / 001 000 000

D23 (Not display) 000 / 001 000 000

D24 (Not display) 000 / 001 000 000

D25 (Not display) 000 / 001 000 000

D26 (Not display) 000 / 001 000 000

D27 (Not display) 000 / 001 000 000

D28 (Not display) 000 / 001 000 000

D29 (Not display) 000 / 001 000 000

D30 (Not display) 000 / 001 000 000

D31 (Not display) 000 / 001 000 000

D32 (Not display) 000 / 001 000 000

1-34 (No.YA097)

Page 35

VIDEO SYSTEM

( NTSC / 480i )

NTSC 480i

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

48" 56" 65" 48" 56" 65" 48" 56" 65" 48" 56" 65"

S01 COLOR 000~255 098 099 099 088 085 085 081 081 081 069 073 073

S02 TINT 000~255 060 059 059 052 055 055 062 064 061 060 061 061

( 480p / 720p / 1080i )

480p 720p / 1080i

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

48" 56" 65" 48" 56" 65" 48" 56" 65" 48" 56" 65"

S01 COLOR 000~255 075 081 081 066 073 073 067 070 070 063 070 070

S02 TINT 000~255 059 058 058 059 058 058 063 063 063 057 059 059

( NTSC / 480i / 480p )

NTSC 480i / 480p

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

48" 56" 65" 48" 56" 65" 48" 56" 65" 48" 56" 65"

S03 BRIGHT 000~255 125 128 128 122 120 120 124 127 127 120 123 123

S04 CONTRAST 000~127 049 051 051 040 044 044 060 064 061 046 047 047

( 720p / 1080i )

720p / 1080i

Item

No.

Item name Variable range

STANDARD THEATER

48" 56" 65" 48" 56" 65"

S03 BRIGHT 000~255 127 130 130 123 125 125

S04 CONTRAST 000~127 056 066 066 044 046 046

( NTSC / 480i )

NTSC 480i

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

48" 56" 65" 48" 56" 65" 48" 56" 65" 48" 56" 65"

S05 0 MTX SW 000~003 000 000 000 000 000 000 000 000 000 000 000 000

S06 INPUT SW 000~003 001 001 001 001 001 001 001 001 001 001 001 001

S07 B-Y 000~063 010 010 010 020 024 024 015 011 011 026 020 020

S08 R-Y 000~015 007 007 007 000 000 000 007 007 007 000 000 000

S09 G-YMATRI 000~003 001 001 001 003 003 003 001 001 001 003 003 003

( 480p / 720p / 1080i )

480p 720p / 1080i

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

48" 56" 65" 48" 56" 65" 48" 56" 65" 48" 56" 65"

S05 0 MTX SW 000~003 000 000 000 000 000 000 000 000 000 000 000 000

S06 INPUT SW 000~003 001 001 001 001 001 001 000 000 000 000 000 000

S07 B-Y 000~063 015 017 017 025 021 021 023 021 021 025 021 020

S08 R-Y 000~015 008 008 007 002 002 002 004 004 004 003 003 003

S09 G-YMATRI 000~003 001 001 001 003 003 003 002 002 002 002 002 002

(No.YA097)1-35

Page 36

( NTSC / 480i )

NTSC 480i

Item

No.

Item name Variable range

HIGH

STANDARD THEATER STANDARD THEATER

LOW

48" 56" 65" 48" 56" 65"

HIGH LOW HIGH

LOW

HIGH LOW

S10 DRIVE R 000~255 --- 085 078 078 --- --- --- 086 072 072 --- ---

S11 (Not display) -128 ~ +127 +004 --- --- --- +006 +014 +005 --- --- --- +006 +014

S12 DRIVE B 000~255 --- 080 084 089 --- --- --- 078 079 079 --- ---

S13 (Not display) -128 ~ +127 +004 --- --- --- -007 -022 +005 --- --- --- -007 -022

( 480p / 720p / 1080i )

480p 720p / 1080i

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER

HIGH LOW HIGH LOW HIGH

48" 56" 65"

LOW

HIGH LOW

S10 DRIVE R 000~255 --- --- --- --- --- 084 074 074 --- ---

S11 (Not display) -128 ~ +127 +003 000 000 +001 +005 --- --- --- +005 +008

S12 DRIVE B 000~255 --- --- --- --- --- 078 083 083 --- ---

S13 (Not display) -128 ~ +127 +007 000 -005 -021 +005 --- --- --- +001 -009

( NTSC / 480i / 480p / 720p / 1080i )

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER STANDARD THEATER

NTSC 480i / 480p 720p / 1080i

S14 CUTOF R 000~255 185 --- 185 --- 185 ---

S15 (Not display) -128 ~ +127 --- -004 --- 000 --- -008

S16 CUTOF G 000~255 185 --- 185 --- 185 ---

S17 (Not display) -128 ~ +127 --- 000 --- 000 --- 000

S18 CUTOF B 000~255 185 --- 185 --- 185 ---

S19 (Not display) -128 ~ +127 --- -004 --- 000 --- -008

S20 CUTOF SW R 000~003 001 --- 001 --- 001 ---

S21 CUTOF SW G 000~003 001 --- 001 --- 001 ---

S22 CUTOF SW B 000~003 001 --- 001 --- 001 ---

1-36 (No.YA097)

Page 37

( NTSC / 480i / OTHERS SIGNAL )

Item

No.

Item name Variable range

STANDARD THEATER STANDARD THEATER STANDARD THEATER

NTSC 480i OTHERS SIGNAL

S23 DC CTL 000~255 255 255 255 255 255 255

Item

No.

Item name Variable range Initial setting value

S24 RGBLIMT 000~015 000

( NTSC / 480i / OTHERS SIGNAL )

Item

No.

Item name Variable range NTSC 480i OTHERS SIGNAL

S25 BL STRT 000~015 015 015 015

S26 BL GAIN 000~015 008 008 008

S27 YGM LVL 000~015 000 000 000

S28 YGM GAIN 000~015 015 015 015

S29 YWD STRT 000~015 002 000 000

S30 YWD GAIN 000~015 005 002 003

Item

No.

Item name Variable range STANDARD THEATER

S31 COL OFST -128~+127 --- ---

S32 TNT OFST -128~+127 --- ---

( TWIN / FREEZE )

Item

No.

Item name Variable range

TWIN / FREEZE

STANDARD THEATER

S33 BRT OFST -128~+127 -002 000

S34 CNT OFST -128~+127 -011 000

Item

No.

Item name Variable range STANDARD THEATER

S35 DCTRN SW 000 / 001 000 000

S36 BL OFF 000 / 001 000 001

S37 YGM OFF 000 / 001 000 001

S38 ABL OFF 000 / 001 000 000

S39 ACL OFF 000 / 001 000 000

Item

No.

Item name Variable range Initial setting value

S40 BLCNT LK 000 / 001 000

S41 YGCNT LK 000 / 001 000

S42 DCTRN PL 000 / 001 000

S43 ABL GAIN 000~015 015

S44 ABL STRT 000~015 015

S45 ACL GAIN 000~015 015

S46 ACL STRT 000~015 000

(No.YA097)1-37

Page 38

( TWIN / REGULER / THEATER / OTHERS )

Item

No.

Item name Variable range

MULTI SCREEN ASPECT VIDEO STATUS

TWIN REGULAR THEATER

OTHERS

S47 ACL EERG 000~255 255 255 255 255

Item

No.

Item name Variable range Initial setting value

S48 CHRM GM 000~255 255

Item

No.

Item name Variable range Initial setting value

S49 OSDR DC 000~127 064

S50 OSDB DC 000~127 064

S51 BLK OFF 000 / 001 000

Item

No.

Item name Variable range STANDARD THEATER

S52 CNT UNDR -128~+127 -030 -021

S53 CNT UPPR -128~+127 +013 +020

S54 BRT UNDR -128~+127 -020 -020

Item

No.

Item name Variable range Initial setting value

S55 EETH BRT -128~+127 000

S56 EETH CNT -128~+127 000

S57 BREE CNT 000~031 000

S58 DKEE CNT 000~031 000

S59 DREE BRT 000~127 000

S60 BREE ACL 000~255 000

S61 DKEE ACL 000~255 000

S62 VMOFF DE -128~+127 +002

S63 VM LOW -128~+127 -025

S64 VM MID -128~+127 -015

S65 VM HIGH -128~+127 +010

S66 VM L- -128~+127 -004

S67 VM LH -128~+127 -002

S68 VM MH -128~+127 000

S69 VM M+ -128~+127 +001

S70 BLK R 000 / 001 000

S71 BLK G 000 / 001 000

S72 BLK B 000 / 001 000

S73 (Not display) 000 / 001 000

Item

No.

S81 (Not display) 000 / 001 000

S82 (Not display) 000 / 001 000

S83 (Not display) 000 / 001 000

S84 (Not display) 000 / 001 000

S85 (Not display) 000 / 001 000

S86 (Not display) 000 / 001 000

S87 (Not display) 000 / 001 000

S88 (Not display) 000 / 001 000

S89 (Not display) 000 / 001 000

S90 (Not display) 000 / 001 000

S91 (Not display) 000 / 001 000

S92 (Not display) 000 / 001 000

S93 (Not display) 000 / 001 000

S94 (Not display) 000 / 001 000

S95 (Not display) 000 / 001 000

S96 (Not display) 000 / 001 000

S97 (Not display) 000 / 001 000

S98 (Not display) 000 / 001 000

S99 (Not display) 000 / 001 000

S74 (Not display) 000 / 001 000

S75 (Not display) 000 / 001 000

S76 (Not display) 000 / 001 000

S77 (Not display) 000 / 001 000

S78 (Not display) 000 / 001 000

S79 (Not display) 000 / 001 000

S80 (Not display) 000 / 001 000

Item name Variable range Initial setting value

1-38 (No.YA097)

Page 39

OTHERS

Item

No.

Item name Variable range

Initial setting value

48" 56" 65"

F01 E 1 000~255 003 004 004

F02 E 2 000~255 002 002 002

F03 (Not display) 000~255 127 127 127

F04 CATVMAX 000~255 001 001 001

F05 (Not display) 000 / 001 050 050 114

F06 (Not display) 000~255 000 000 000

F07 (Not display) 000~255 007 007 015

F08 (Not display) 000~255 000 000 000

Item

No.

Item name Variable range

ASPECT

CINEMA OTHERS

F09 AUTOSCR1 000~015 000 000

F10 AUTOSCR2 000~015 000 000

F11 AUTOSCR3 000~015 000 000

F12 AUTOSCR4 000~015 000 000

F13 AUTOSCR5 000~015 000 000

F14 AUTOSCR6 000~015 000 000

F15 AUTOSCR7 000~015 000 000

Item

No.

Item name Variable range Initial setting value

F16 (Not display) 000~127 070

F17 (Not display) 000 / 001 000

F18 FIX DATA 000 / 001 000

F19 (Not display) 000 / 001 000

F20 (Not display) 000~255 005

F21 (Not display) 000~255 002

F22 (Not display) 000 / 001 000

F23 (Not display) 000~255 000

F24 (Not display) 000~255 141

F25 (Not display) 000~255 006

F26 (Not display) 000~255 040

F27 (Not display) 000~255 040

Item

No.

Item name Variable range Initial setting value

F29 (Not display) 000 / 001 000

F30 (Not display) 000 / 001 000

F31 (Not display) 000 / 001 000

F32 ATT V 000 / 001 000

F33 ATT U 000 / 001 000

F34 ATT C 000 / 001 000

F35 (Not display) 000 / 001 000

F36 (Not display) 000 / 001 000

F37 (Not display) 000 / 001 000

F38 DC1 000 / 001 000

F39 DC4 000 / 001 000

F40 DC5 000 / 001 000

F28 (Not display) 000 /001 000

Item

No.

Item name Variable range NTSC 480i 480p 720p 1080i

F41 SS LV 000~003 000 002 002 002 002

F42 SS CP 000 / 001 000 000 000 000 000

F43 SS HDP 000~063 039 039 037 025 024

Item

No.

Item name Variable range Initial setting value

F44 (Not display) 000 / 001 000

F45 (Not display) 000 / 001 000

F46 OUT LV. 000 / 001 000

F47 LMT BTM 000 / 001 000

F48 LMT TOP 000 / 001 000

F49 (Not display) 000 / 001 001

F50 (Not display) 000 / 001 001

F51 (Not display) 000~015 011

F52 (Not display) 000~063 055

F53 (Not display) -128~+127 000

F54 (Not display) 000~255 015

F55 (Not display) 000 / 001 000

F56 (Not display) 000~255 188

F57 (Not display) 000~255 105

Item

No.

Item name Variable range Initial setting value

F58 (Not display) 000~255 077

F59 (Not display) 000 / 001 001

F60 (Not display) 000 / 001 000

F61 (Not display) 000 / 001 001

F62 (Not display) 000 / 001 000

F63 (Not display) -128~+127 000

F64 (Not display) -128~+127 +010

F65 (Not display) -128~+127 000

F66 (Not display) 000~007 006

F67 (Not display) 000~003 000

F68 (Not display) 000~255 126

F69 (Not display) 000 / 001 001

F70 (Not display) 000 / 001 000

(No.YA097)1-39

Page 40

4.6.2 [2.YC SEP] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

Variable

range

Initial setting

value

YCM001 (Not display) 000 / 001 000

YCM002 (Not display) 000 / 001 000

YCM003 (Not display) 000 / 001 000

YCM004 (Not display) 000~003 001

YCM005 (Not display) 000~255 239

YCM006 (Not display) 000~003 001

YCM007 (Not display) 000~255 239

YCM008 (Not display) 000 / 001 000

YCM009 (Not display) 000~003 000

YCM010 (Not display) 000 / 001 000

YCM011 (Not display) 000 / 001 000

YCM012 (Not display) 000 / 001 000

YCM013 (Not display) 000 / 001 000

YCM014 (Not display) 000~003 000

YCM015 (Not display) 000 / 001 000

YCM016 (Not display) 000~003 001

YCM017 (Not display) 000 / 001 001

YCM018 (Not display) 000~003 000

YCM019 (Not display) 000 / 001 000

YCM020 (Not display) 000 / 001 000

YCM021 (Not display) 000~003 002

YCM022 (Not display) 000~007 004

YCM023 (Not display) 000 / 001 001

YCM024 (Not display) 000 / 001 000

YCM025 (Not display) 000~007 005

YCM026 (Not display) 000~015 003

YCM027 (Not display) 000~003 000

YCM028 (Not display) 000~007 003

YCM029 (Not display) 000~007 002

YCM030 (Not display) 000~003 003

YCM031 (Not display) 000 / 001 000

YCM032 (Not display) 000~003 003

YCM033 (Not display) 000 / 001 001

YCM034 (Not display) 000 / 001 000

YCM035 (Not display) 000~255 096

YCM036 (Not display) 000 / 001 001

YCM037 (Not display) 000~003 001

YCM038 (Not display) 000~127 062

YCM039 (Not display) 000~127 073

Item No. Item name

Variable

range

Initial setting

value

YCM040 (Not display) 000~003 002

YCM041 (Not display) 000~063 016

YCM042 (Not display) 000 / 001 000

YCM043 (Not display) 000 / 001 000

YCM044 (Not display) 000~255 241

YCM045 (Not display) 000 / 001 000

YCM046 (Not display) 000~255 165

YCM047 (Not display) 000 / 001 001

YCM048 (Not display) 000 / 001 001

YCM049 (Not display) 000 / 001 001

YCM050 (Not display) 000 / 001 001

YCM051 (Not display) 000 / 001 001

YCM052 (Not display) 000 / 001 000

YCM053 (Not display) 000 / 001 001

YCM054 (Not display) 000~003 003

YCM055 (Not display) 000~003 003

YCM056 (Not display) 000~003 000

YCM057 (Not display) 000 / 001 000

YCM058 (Not display) 000 / 001 001

YCM059 (Not display) 000 / 001 001

YCM060 (Not display) 000 / 001 000

YCM061 (Not display) 000 / 001 001

YCM062 (Not display) 000~015 001

YCM063 (Not display) 000~015 004

YCM064 (Not display) 000 / 001 000

YCM065 (Not display) 000~063 060

YCM066 (Not display) 000~063 040

YCM067 (Not display) 000~063 025

YCM068 (Not display) 000~063 012

YCM069 (Not display) 000~063 036

YCM070 (Not display) 000~063 031

YCM071 (Not display) 000~255 031

YCM072 (Not display) 000 / 001 001

YCM073 (Not display) 000 / 001 001

YCM074 (Not display) 000~063 024

YCM075 (Not display) 000 / 001 000

YCM076 (Not display) 000 / 001 001

YCM077 (Not display) 000~063 010

YCM078 (Not display) 000~063 001

YCM079 (Not display) 000~255 000

YCM080 (Not display) 000~255 000

YCM081 (Not display) 000~255 000

YCM082 (Not display) 000~255 000

YCM083 (Not display) 000 / 001 001

YCM084 (Not display) 000~063 012

1-40 (No.YA097)

Page 41

Item No. Item name

Variable

range

Initial setting

value

YCM085 (Not display) 000 / 001 000

YCM086 (Not display) 000 / 001 000

YCM087 (Not display) 000~063 028

YCM088 (Not display) 000 / 001 001

YCM089 (Not display) 000~031 000

YCM090 (Not display) 000~003 000

YCM091 (Not display) 000~015 000

YCM092 (Not display) 000~015 000

YCM093 (Not display) 000~015 002

YCM094 (Not display) 000~063 000

YCM095 (Not display) 000~255 040

YCM096 (Not display) 000 / 001 001

YCM097 (Not display) 000~063 063

YCM098 (Not display) 000~015 008

YCM099 (Not display) 000~015 005

YCM100 (Not display) 000~015 008

YCM101 (Not display) 000~015 005

YCM102 (Not display) 000~015 000

YCM103 (Not display) 000~015 002

YCM104 (Not display) 000~015 008

YCM105 (Not display) 000~015 006

YCM106 (Not display) 000~255 010

YCM107 (Not display) 000~255 032

YCM108 (Not display) 000~255 031

YCM109 (Not display) 000~255 064

YCM110 (Not display) 000 / 001 000

YCM111 (Not display) 000 / 001 001

YCM112 (Not display) 000 / 001 001

YCM113 (Not display) 000 / 001 001

YCM114 (Not display) 000 / 001 000

YCM115 (Not display) 000 / 001 001

YCM116 (Not display) 000 / 001 000

YCM117 (Not display) 000 / 001 000

YCM118 (Not display) 000 / 001 001

YCM119 (Not display) 000 / 001 000

YCM120 (Not display) 000 / 001 000

YCM121 (Not display) 000~003 003

YCM122 (Not display) 000 / 001 000

YCM123 (Not display) 000~255 026

YCM124 (Not display) 000 / 001 000

YCM125 (Not display) 000~255 025

YCM126 (Not display) 000 / 001 000

YCM127 (Not display) 000 / 001 001

YCM128 (Not display) 000 / 001 001

YCM129 (Not display) 000 / 001 001

Item No. Item name

Variable

range

Initial setting

value

YCM130 (Not display) 000~003 001

YCM131 (Not display) 000~255 050

YCM132 (Not display) 000~255 154

YCM133 (Not display) 000~255 055

YCM134 (Not display) 000~007 001

YCM135 (Not display) 000~255 136

YCM136 (Not display) 000 / 001 000

YCM137 (Not display) 000 / 001 001

YCM138 (Not display) 000~007 003

YCM139 (Not display) 000~255 089

YCM140 (Not display) 000~007 000

YCM141 (Not display) 000~255 252

YCM142 (Not display) 000 / 001 001

YCM143 (Not display) 000~007 005

YCM144 (Not display) 000~255 128

YCM145 (Not display) 000 / 001 000

YCM146 (Not display) 000 / 001 001

YCM147 (Not display) 000 / 001 001

YCM148 (Not display) 000 / 001 001

YCM149 (Not display) 000 / 001 000

YCM150 (Not display) 000 / 001 000

YCM151 (Not display) 000~255 136

YCM152 (Not display) 000 / 001 001

YCM153 (Not display) 000 / 001 001

YCM154 (Not display) 000 / 001 001

YCM155 (Not display) 000~003 000

YCM156 (Not display) 000~015 015

YCM157 (Not display) 000~015 004

YCM158 (Not display) 000 / 001 001

YCM159 (Not display) 000~127 004

YCM160 (Not display) 000 / 001 000

YCM161 (Not display) 000~031 000

YCM162 (Not display) 000 / 001 000

YCM163 (Not display) 000~015 003

YCM164 (Not display) 000~007 002

YCM165 (Not display) 000~031 016

YCM166 (Not display) 000~255 235

YCM167 (Not display) 000~003 000

YCM168 (Not display) 000~063 000

YCM169 (Not display) 000~015 003

YCM170 (Not display) 000~015 003

YCM171 (Not display) 000~007 000

YCM172 (Not display) 000~255 096

YCM173 (Not display) 000~007 003

YCM174 (Not display) 000~255 056

(No.YA097)1-41

Page 42

Item No. Item name

Variable

range

Initial setting

value

YCM175 (Not display) 000 / 001 000

YCM176 (Not display) 000 / 001 000

YCM177 (Not display) 000~255 022

YCM178 (Not display) 000 / 001 001

YCM179 (Not display) 000 / 001 000

YCM180 (Not display) 000~007 004

YCM181 (Not display) 000~003 001

YCM182 (Not display) 000~003 001

YCM183 (Not display) 000~003 001

YCM184 (Not display) 000~003 001

YCM185 (Not display) 000~255 000

Item No. Item name

Variable

range

Initial setting

value

YCS001 (Not display) 000 / 001 000

YCS002 (Not display) 000 / 001 000

YCS003 (Not display) 000 / 001 000

YCS004 (Not display) 000~003 001

YCS005 (Not display) 000~255 239

YCS006 (Not display) 000~003 001

YCS007 (Not display) 000~255 239

YCS008 (Not display) 000 / 001 000

YCS009 (Not display) 000~003 000

YCS010 (Not display) 000 / 001 000

YCS011 (Not display) 000 / 001 000

YCS012 (Not display) 000 / 001 000

YCS013 (Not display) 000 / 001 000

YCS014 (Not display) 000~003 000

YCS015 (Not display) 000 / 001 000

YCS016 (Not display) 000~003 001

YCS017 (Not display) 000 / 001 001

YCS018 (Not display) 000~003 000

YCS019 (Not display) 000~001 000

YCS020 (Not display) 000~001 000

YCS021 (Not display) 000~003 002

YCS022 (Not display) 000~007 004

YCS023 (Not display) 000 / 001 001

YCS024 (Not display) 000 / 001 000

YCS025 (Not display) 000~015 005

YCS026 (Not display) 000~015 003

YCS027 (Not display) 000~003 000

YCS028 (Not display) 000~007 004

YCS029 (Not display) 000~007 006

YCS030 (Not display) 000~003 001

YCS031 (Not display) 000 / 001 000

YCS032 (Not display) 000~003 003

Item No. Item name

Variable

range

Initial setting

value

YCS033 (Not display) 000 / 001 001

YCS034 (Not display) 000 / 001 000

YCS035 (Not display) 000~255 096

YCS036 (Not display) 000 / 001 001

YCS037 (Not display) 000~003 001

YCS038 (Not display) 000~127 062

YCS039 (Not display) 000~127 073

YCS040 (Not display) 000~003 002

YCS041 (Not display) 000~063 016

YCS042 (Not display) 000 / 001 000

YCS043 (Not display) 000 / 001 000

YCS044 (Not display) 000~255 164

YCS045 (Not display) 000 / 001 000

YCS046 (Not display) 000~255 110

YCS047 (Not display) 000 / 001 001

YCS048 (Not display) 000~031 000

YCS049 (Not display) 000~003 000

YCS050 (Not display) 000~015 000

YCS051 (Not display) 000~015 008

YCS052 (Not display) 000~015 001

YCS053 (Not display) 000~063 030

YCS054 (Not display) 000~255 030

YCS055 (Not display) 000 / 001 000

YCS056 (Not display) 000~063 016

YCS057 (Not display) 000~015 008

YCS058 (Not display) 000~015 005

YCS059 (Not display) 000~015 008

YCS060 (Not display) 000~015 005

YCS061 (Not display) 000~015 000

YCS062 (Not display) 000~015 002

YCS063 (Not display) 000~015 008

YCS064 (Not display) 000~015 006

YCS065 (Not display) 000~255 010

YCS066 (Not display) 000~255 032

YCS067 (Not display) 000~255 031

YCS068 (Not display) 000~255 064

YCS069 (Not display) 000 / 001 000

YCS070 (Not display) 000 / 001 001

YCS071 (Not display) 000 / 001 001

YCS072 (Not display) 000 / 001 001

YCS073 (Not display) 000 / 001 000

YCS074 (Not display) 000 / 001 001

YCS075 (Not display) 000 / 001 000

YCS076 (Not display) 000 / 001 000

YCS077 (Not display) 000 / 001 001

1-42 (No.YA097)

Page 43

Item No. Item name

Variable

range

Initial setting

value

YCS078 (Not display) 000 / 001 000

YCS079 (Not display) 000 / 001 000

YCS080 (Not display) 000~003 003

YCS081 (Not display) 000 / 001 000

YCS082 (Not display) 000~255 000

YCS083 (Not display) 000~255 000

YCS084 (Not display) 000~007 000

YCS085 (Not display) 000~255 014

YCS086 (Not display) 000 / 001 000

YCS087 (Not display) 000 / 001 001

YCS088 (Not display) 000 / 001 000

YCS089 (Not display) 000 / 001 000

YCS090 (Not display) 000~255 136

YCS091 (Not display) 000 / 001 001

YCS092 (Not display) 000 / 001 001

YCS093 (Not display) 000 / 001 001

YCS094 (Not display) 000~003 000

YCS095 (Not display) 000~015 015

YCS096 (Not display) 000~015 004

YCS097 (Not display) 000 / 001 001

YCS098 (Not display) 000~127 007

YCS099 (Not display) 000~031 000

YCS100 (Not display) 000 / 001 000

YCS101 (Not display) 000~015 003

YCS102 (Not display) 000~007 002

YCS103 (Not display) 000~031 016

YCS104 (Not display) 000~255 235

YCS105 (Not display) 000~003 000

YCS106 (Not display) 000~063 000

YCS107 (Not display) 000~015 003

YCS108 (Not display) 000~015 003

YCS109 (Not display) 000 / 001 000

YCS110 (Not display) 000~003 001

YCS111 (Not display) 000~003 001

YCS112 (Not display) 000~003 001

YCS113 (Not display) 000~003 001

YCS114 (Not display) 000~255 000

4.6.3 [3.WHITE BALANCE]

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

Variable

range

Initial setting

value

BR (Not display) 000~255 118

DRV R (Not display) 000~255 089

DRV B (Not display) 000~255 108

CUT R (Not display) 000~255 247

CUT G (Not display) 000~255 244

CUT B (Not display) 000~255 226

4.6.4 [6.CONVER A]

Item No. Item name

Variable

range

Initial setting

value

CPA01 FINE OFF 0 / 1 0

CPA02 TPOH 0~4095 114

CPA03 TPOV LINE 0~255 017

CPA04 TPOV OFST 0~7 0

CPA05 FINEP 0~4095 1245

CPA06 STARTLIN A 0~127 56

CPA07 STARTLIN B -7~7 -1

CPA08 CAU H2 0~15 0

CPA09 COARS OFST -511~511 -50

CPA10 V1OFSTA -511~511 7

CPA11 V1OFSTB -31~31 0

Item No. Item name

Variable

range

Initial setting value

GREEN RED BLUE

CCA01 C H CENT -512~511 0 -240 395

CCA02 C H SIZE -512~511 -27 -54 16

CCA03 C H LIN -512~511 -96 240 -348

CCA04 C H SKEW -512~511 0 0 -10

CCA05 C EW PIN -512~511 -91 -26 -17

CCA06 C H BOW -512~511 0 -30 21

CCA07 C V CENT -512~511 -19 8 12

CCA08 C V SKEW -512~511 0 0 4

CCA09 C V SIZE -512~511 -108 -77 -105

CCA10 C V LIN -512~511 15 12 8

CCA11 C V KEY -512~511 0 114 -77

CCA12 C TB PIN -512~511 230 153 230

(No.YA097)1-43

Page 44

Item No. Item name

Variable

range

Initial setting

value

CDA01 DF DC -512~511 0

CDA02 DF H1 -512~511 0

CDA03 DF H2 -512~511 0

CDA04 DF V1 -512~511 0

CDA05 DF V2 -512~511 0

CDA06 DF V1H1 -512~511 0

CDA07 DF V2H2 -512~511 0

Item No. Item name

Variable

range

Initial setting

value

CBA01 ADD RATIO 0~3 0

CBA02 INTERLACE 0 / 1 0

CBA03 CKOUT FRE 0~3 0

CBA04 DF MUTE 0 / 1 0

CBA05 ODD LEVEL 0 / 1 1

CBA06 HRET SAMPL 0~3 2

CBA07 HRETS 0 / 1 0

CBA08 HRET TIME -512~511 0

CBA09 H1 CENT RE 0 / 1 1

CBA10 DF CENT RE 0 / 1 0

CBA11 VIPOL 0~127 68

CBA12 V1CENTUP 0~4095 466

CBA13 RVCLMP STR 0~15 0

CBA14 RVCLMPTER 0~15 0

CBA15 RVCLMP CEN 0 / 1 0

CBA16 GVCLMP STR 0~15 0

CBA17 GVCLMPTER 0~15 0

CBA18 GVCLMP CEN 0 / 1 0

CBA19 BVCLMP STR 0~15 0

CBA20 BVCLMPTER 0~15 0

CBA21 BVCLMP CEN 0 / 1 0

CBA22 RHCLMP STR 0~15 0

CBA23 RHCLMPTER 0~15 0

CBA24 RHCLMP CEN 0 / 1 0

CBA25 GHCLMP STR 0~15 0

CBA26 GHCLMPTER 0~15 0

CBA27 GHCLMP CEN 0 / 1 0

CBA28 BHCLMP STR 0~15 0

CBA29 BHCLMPTER 0~15 0

CBA30 BHCLMP CEN 0 / 1 0

CBA31 PATTERN H 0~3 1

CBA32 PATTERN W 0~3 1

CBA33 HATCH PAT 0~15 1

CBA34 CURS SPACE 0~7 1

CBA35 HATCH COL 0~7 2

CBA36 BORDER COL 0~7 0

Item No. Item name

Variable

range

Initial setting

value

CBA37 CURSOL COL 0~7 0

CBA38 CROSS COL 0~7 0

CBA39 SQUARE COL 0~7 0

CBA40 XCPOS VPOS 0~31 16

CBA41 XCPOS HPOS 0~31 16

CBA42 CURSOL PAT 0~3 0

CBA43 MTPH1 -32768~32767 0

CBA44 MTPH2 -32768~32767 0

CBA45 MTPV1 -32768~32767 0

CBA46 MTPV2 -32768~32767 0

CBA47 YSP -7~7 0

CBA48 BL1POSV 0~2047 0

CBA49 BL1POSH 0~4095 0

CBA50 BL2POSV 0~2047 0

CBA51 BL2POSH 0~4095 0

CBA52 XPOSV 0~2047 580

CBA53 XPOSH 0~4095 1012

CBA54 XLLENV 0~2047 276

CBA55 XLLENH 0~4095 450

CBA56 SQ1POSV 0~2047 30

CBA57 SQ1POSH 0~4095 1024

CBA58 SQ1VSIZE 0~255 128

CBA59 SQ1HSIZE 0~255 100

CBA60 SQ2POSV 0~2047 594

CBA61 SQ2POSH 0~4095 282

CBA62 SQ2VSIZE 0~255 100

CBA63 SQ2HSIZE 0~255 110

CBA64 SQ3POSV 0~2047 1008

CBA65 SQ3POSH 0~4095 1024

CBA66 SQ3VSIZE 0~255 160

CBA67 SQ3HSIZE 0~255 100

CBA68 SQ4POSV 0~2047 594

CBA69 SQ4POSH 0~4095 1612

CBA70 SQ4VSIZE 0~255 100

CBA71 SQ4HSIZE 0~255 116

CBA72 SQ5POSV 0~2047 547

CBA73 SQ5POSH 0~4095 1013

CBA74 SQ5VSIZE 0~255 70

CBA75 SQ5HSIZE 0~255 4

CBA76 SQ6POSV 0~2047 580

CBA77 SQ6POSH 0~4095 984

CBA78 SQ6VSIZE 0~255 4

CBA79 SQ6HSIZE 0~255 64

CBA80 SQ7POSV 0~2047 456

CBA81 SQ7POSH 0~4095 888

1-44 (No.YA097)

Page 45

Item No. Item name

Variable

range

Initial setting

value

CBA82 SQ7VSIZE 0~255 255

CBA83 SQ7HSIZE 0~255 255

CBA84 SQ8POSV 0~2047 0

CBA85 SQ8POSH 0~4095 0

CBA86 SQ8VSIZE 0~255 0

CBA87 SQ8HSIZE 0~255 0

CBA88 ODEVP 0~3072 1584

CBA89 DFP 0~4095 0

CBA90 PWMH1P 0~4095 0

CBA91 PWMH1W 0~4095 0

CBA92 PWMV1P 0~1023 0

CBA93 PWMV1W 0~1023 1

CBA94 PWMH2W 0~4095 0

4.6.5 [8.IP] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

Variable

range

Initial setting

value

IPA001 (Not display) 000~0FF 0C7

IPA002 (Not display) 000~0FF 000

IPA003 (Not display) 000~0FF 000

IPA004 (Not display) 000~0FF 08A

IPA005 (Not display) 000~01F 001

IPA006 (Not display) 000~0FF 037

IPA007 (Not display) 000~00F 000

IPA008 (Not display) 000~0FF 000

IPA009 (Not display) 000~00F 000

IPA010 (Not display) 000~0FF 080

IPA011 (Not display) 000~00F 002

IPA012 (Not display) 000~0FF 02B

IPA013 (Not display) 000~00F 002

IPA014 (Not display) 000~0FF 000

IPA015 (Not display) 000~00F 002

IPA016 (Not display) 000~0FF 080

IPA017 (Not display) 000~00F 001

IPA018 (Not display) 000~0FF 000

IPA019 (Not display) 000~00F 001

IPA020 (Not display) 000~0FF 080

IPA021 (Not display) 000~00F 016

IPA022 (Not display) 000~0FF 023

IPA023 (Not display) 000~00F 000

Item No. Item name

Variable

range

Initial setting

value

IPA024 (Not display) 000 / 001 001

IPA025 (Not display) 000 / 001 001

IPA026 (Not display) 000~03F 01F

IPA027 (Not display) 000~003 000

IPA028 (Not display) 000~03F 008

IPA029 (Not display) 000~03F 02B

IPA030 (Not display) 000~00F 005

IPA031 (Not display) 000~007 001

IPA032 (Not display) 000~03F 010

IPA033 (Not display) 000 / 001 001

IPA034 (Not display) 000~03F 039

IPA035 (Not display) 000 / 001 001

IPA036 (Not display) 000~03F 00E

IPA037 (Not display) 000~03F 02E

IPA038 (Not display) 000~03F 01E

IPA039 (Not display) 000~003 002

IPA040 (Not display) 000~003 003

IPA041 (Not display) 000~00F 008

IPA042 (Not display) 000~03F 020

4.6.6 [9.DSD] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

Variable

range

Initial setting

value

DSA001 (Not display) 000~03F 01F

DSA002 (Not display) 000~03F 012

DSA003 (Not display) 000~03F 02E

DSA004 (Not display) 000~003 000

DSA005 (Not display) 000 / 001 000

DSA006 (Not display) 000~003 001

DSA007 (Not display) 000~03F 010

DSA008 (Not display) 000 / 001 001

DSA009 (Not display) 000~03F 010

DSA010 (Not display) 000 / 001 001

DSA011 (Not display) 000 / 001 001

DSA012 (Not display) 000~03F 006

DSA013 (Not display) 000~03F 010

DSA014 (Not display) 000~03F 020

DSA015 (Not display) 000~003 001

DSA016 (Not display) 000 / 001 001

DSA017 (Not display) 000~003 000

(No.YA097)1-45

Page 46

Item No. Item name

Variable

range

Initial setting

value

DSA018 (Not display) 000~03F 000

DSA019 (Not display) 000 / 001 001

DSA020 (Not display) 000~03F 01D

DSA021 (Not display) 000 / 001 001

DSA022 (Not display) 000~03F 00C

DSA023 (Not display) 000 / 001 001

DSA024 (Not display) 000~03F 006

DSA025 (Not display) 000/001 001

DSA026 (Not display) 000~03F 02F

DSA027 (Not display) 000 / 001 001

DSA028 (Not display) 000~03F 007

DSA029 (Not display) 000 / 001 001

DSA030 (Not display) 000 / 001 001

DSA031 (Not display) 000~03F 023

DSA032 (Not display) 000 / 001 000

DSA033 (Not display) 000~003 000

DSA034 (Not display) 000~03F 008

DSA035 (Not display) 000 / 001 001

DSA036 (Not display) 000 / 001 001

DSA037 (Not display) 000~03F 023

DSA038 (Not display) 000 / 001 000

DSA039 (Not display) 000~003 000

DSA040 (Not display) 000~03F 008

DSA041 (Not display) 000 / 001 001

DSA042 (Not display) 000 / 001 001

DSA043 (Not display) 000 / 001 001

DSA044 (Not display) 000~03F 011

DSA045 (Not display) 000 / 001 000

DSA046 (Not display) 000~003 002

DSA047 (Not display) 000~03F 005

DSA048 (Not display) 000 / 001 001

DSA049 (Not display) 000~03F 000

DSA050 (Not display) 000 / 001 001

DSA051 (Not display) 000~03F 00B

DSA052 (Not display) 000 / 001 001

DSA053 (Not display) 000 / 001 001

Item No. Item name

Variable

range

Initial setting

value

DSB001 (Not display) (Not display) 01F

DSB002 (Not display) (Not display) 012

DSB003 (Not display) (Not display) 02E

DSB004 (Not display) (Not display) 000

DSB005 (Not display) (Not display) 000

DSB006 (Not display) (Not display) 001

DSB007 (Not display) (Not display) 011

DSB008 (Not display) (Not display) 001

DSB009 (Not display) (Not display) 010

DSB010 (Not display) (Not display) 001

DSB011 (Not display) (Not display) 001

DSB012 (Not display) (Not display) 008

DSB013 (Not display) (Not display) 012

DSB014 (Not display) (Not display) 025

DSB015 (Not display) (Not display) 001

DSB016 (Not display) (Not display) 001

DSB017 (Not display) (Not display) 001

DSB018 (Not display) (Not display) 000

DSB019 (Not display) (Not display) 001

DSB020 (Not display) (Not display) 010

DSB021 (Not display) (Not display) 001

DSB022 (Not display) (Not display) 00C

DSB023 (Not display) (Not display) 001

DSB024 (Not display) (Not display) 005

DSB025 (Not display) (Not display) 001

DSB026 (Not display) (Not display) 02F

DSB027 (Not display) (Not display) 001

DSB028 (Not display) (Not display) 007

DSB029 (Not display) (Not display) 001

DSB030 (Not display) (Not display) 001

DSB031 (Not display) (Not display) 023

DSB032 (Not display) (Not display) 000

DSB033 (Not display) (Not display) 000

DSB034 (Not display) (Not display) 008

DSB035 (Not display) (Not display) 001

DSB036 (Not display) (Not display) 001

DSB037 (Not display) (Not display) 023

DSB038 (Not display) (Not display) 000

DSB039 (Not display) (Not display) 000

DSB040 (Not display) (Not display) 008

DSB041 (Not display) (Not display) 001

DSB042 (Not display) (Not display) 001

DSB043 (Not display) (Not display) 001

DSB044 (Not display) (Not display) 00E

DSB045 (Not display) (Not display) 000

1-46 (No.YA097)

Page 47

Item No. Item name

Variable

range

Initial setting

value

DSB046 (Not display) (Not display) 002

DSB047 (Not display) (Not display) 005

DSB048 (Not display) (Not display) 001

DSB049 (Not display) (Not display) 000

DSB050 (Not display) (Not display) 001

DSB051 (Not display) (Not display) 010

DSB052 (Not display) (Not display) 001

DSB053 (Not display) (Not display) 001

Item No. Item name

Variable

range

Initial setting

value

DSC001 (Not display) 000~00F 008

DSC002 (Not display) 000~0FF 098

DSC003 (Not display) 000~03F 01F

DSC004 (Not display) 000~003 000

DSC005 (Not display) 000~0FF 000

DSC006 (Not display) 000 / 001 000

DSC007 (Not display) 000 / 001 000

DSC008 (Not display) 000 / 001 000

DSC009 (Not display) 000~00F 000

DSC010 (Not display) 000~0FF 000

DSC011 (Not display) 000~00F 00F

DSC012 (Not display) 000~0FF 0FF

DSC013 (Not display) 000~00F 001

DSC014 (Not display) 000~0FF 0E8

DSC015 (Not display) 000~00F 005

DSC016 (Not display) 000~0FF 018

DSC017 (Not display) 000~00F 000

DSC018 (Not display) 000~0FF 000

DSC019 (Not display) 000~00F 000

DSC020 (Not display) 000~0FF 000

DSC021 (Not display) 000~00F 000

DSC022 (Not display) 000~0FF 000

DSC023 (Not display) 000~00F 000

DSC024 (Not display) 000~0FF 000

DSC025 (Not display) 000~00F 000

DSC026 (Not display) 000~0FF 080

DSC027 (Not display) 000~00F 000

DSC028 (Not display) 000~0FF 040

DSC029 (Not display) 000~00F 005

DSC030 (Not display) 000~0FF 040

DSC031 (Not display) 000~00F 000

DSC032 (Not display) 000~0FF 0C0

DSC033 (Not display) 000~00F 000

DSC034 (Not display) 000~0FF 080

DSC035 (Not display) 000~00F 000

Item No. Item name

Variable

range

Initial setting

value

DSC036 (Not display) 000~0FF 040

DSC037 (Not display) 000~00F 005

DSC038 (Not display) 000~0FF 040

DSC039 (Not display) 000~00F 000

DSC040 (Not display) 000~0FF 0C0

DSC041 (Not display) 000~00F 004

DSC042 (Not display) 000~0FF 075

DSC043 (Not display) 000 / 001 000

DSC044 (Not display) 000 / 001 000

Item No. Item name

Variable

range

Initial setting

value

DSD001 (Not display) 000~255 001

DSD002 (Not display) 000~255 002

DSD003 (Not display) 000~255 001

DSD004 (Not display) 000~255 002

DSD005 (Not display) 000~255 001

DSD006 (Not display) 000~255 002

DSD007 (Not display) 000~255 001

DSD008 (Not display) 000~255 002

DSD009 (Not display) -128~127 +001

DSD010 (Not display) -128~127 +001

DSD011 (Not display) -128~127 +002

DSD012 (Not display) -128~127 +002

DSD013 (Not display) -128~127 -001

DSD014 (Not display) -128~127 +001

DSD015 (Not display) 000~0FF 001

DSD016 (Not display) 000~0FF 001

DSD017 (Not display) 000~0FF 001

4.6.7 [0.HDMI] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

Variable

range

Initial setting

value

HDM001 (Not display) 000 / 001 000

HDM002 (Not display) 000 / 001 000

HDM003 (Not display) 000 / 001 000

HDM004 (Not display) 000 / 001 000

HDM005 (Not display) 000 / 001 001

HDM006 (Not display) 000~003 000

HDM007 (Not display) 000 / 001 000

HDM008 (Not display) 000 / 001 000

(No.YA097)1-47

Page 48

Item No. Item name

Variable

range

Initial setting

value

HDM009 (Not display) 000 / 001 000

HDM010 (Not display) 000 / 001 000

HDM011 (Not display) 000 / 001 000

HDM012 (Not display) 000 / 001 000

HDM013 (Not display) 000 / 001 001

HDM014 (Not display) 000 / 001 000

HDM015 (Not display) 000 / 001 000

HDM016 (Not display) 000~255 000

HDM017 (Not display) 000~255 000

HDM018 (Not display) 000~255 000

HDM019 (Not display) 000 / 001 001

HDM020 (Not display) 000~255 000

HDM021 (Not display) 000~007 002

HDM022 (Not display) 000~063 006

HDM023 (Not display) 000~063 006

HDM024 (Not display) 000~063 006

HDM025 (Not display) 000 / 001 000

HDM026 (Not display) 000~003 000

HDM027 (Not display) 000~255 212

HDM028 (Not display) 000~003 000

HDM029 (Not display) 000~255 192

HDM030 (Not display) 000~003 000

HDM031 (Not display) 000~255 212

HDM032 (Not display) 000~003 000

HDM033 (Not display) 000~255 191

HDM034 (Not display) 000~003 001

HDM035 (Not display) 000~255 012

HDM036 (Not display) 000~255 026

HDM037 (Not display) 000~255 001

HDM038 (Not display) 000~255 012

HDM039 (Not display) 000 / 001 001

HDM040 (Not display) 000 / 001 001

HDM041 (Not display) 000 / 001 000

HDM042 (Not display) 000~255 001

HDM043 (Not display) 000~007 003

HDM044 (Not display) 000~003 000

HDM045 (Not display) 000~003 000

HDM046 (Not display) 000 / 001 001

HDM047 (Not display) 000~015 007

HDM048 (Not display) 000~255 000

HDM049 (Not display) 000~255 000

HDM050 (Not display) 000~015 000

HDM051 (Not display) 000 / 001 000

HDM052 (Not display) 000 / 001 000

HDM053 (Not display) 000 / 001 000

Item No. Item name

Variable

range

Initial setting

value

HDM054 (Not display) 000 / 001 000

HDM055 (Not display) 000 / 001 000

HDM056 (Not display) 000 / 001 000

HDM057 (Not display) 000 / 001 001

HDM058 (Not display) 000 / 001 000

HDM059 (Not display) 000 / 001 001

HDM060 (Not display) 000 / 001 000

HDM061 (Not display) 000 / 001 001

HDM062 (Not display) 000 / 001 001

HDM063 (Not display) 000 / 001 000

HDM064 (Not display) 000 / 001 000

HDM065 (Not display) 000 / 001 001

HDM066 (Not display) 000 / 001 000

HDM067 (Not display) 000 / 001 001

HDM068 (Not display) 000~031 004

HDM069 (Not display) 000 / 001 000

HDM070 (Not display) 000 / 001 001

HDM071 (Not display) 000 / 001 000

HDM072 (Not display) 000 / 001 000

HDM073 (Not display) 000 / 001 000

HDM074 (Not display) 000~031 008

HDM075 (Not display) 000 / 001 001

HDM076 (Not display) 000 / 001 001

HDM077 (Not display) 000 / 001 001

HDM078 (Not display) 000 / 001 001

HDM079 (Not display) 000 / 001 001

HDM080 (Not display) 000 / 001 001

Item No. Item name

Variable

range

Initial setting

value

RHD001 (Not display) (Not display) 001

RHD002 (Not display) (Not display) 000

RHD003 (Not display) (Not display) 042

RHD004 (Not display) (Not display) 099

RHD005 (Not display) (Not display) 000

RHD006 (Not display) (Not display) 000

RHD007 (Not display) (Not display) 0B7

RHD008 (Not display) (Not display) 0FF

RHD009 (Not display) (Not display) 0FF

RHD010 (Not display) (Not display) 0FE

RHD011 (Not display) (Not display) 0FF

RHD012 (Not display) (Not display) 000

RHD013 (Not display) (Not display) 0FB

RHD014 (Not display) (Not display) 0FF

RHD015 (Not display) (Not display) 0E3

RHD016 (Not display) (Not display) 0FF

1-48 (No.YA097)

Page 49

Item No. Item name

Variable

range

Initial setting

value

RHD017 (Not display) (Not display) 0FF

RHD018 (Not display) (Not display) 0DE

RHD019 (Not display) (Not display) 0FF

RHD020 (Not display) (Not display) 0FB

RHD021 (Not display) (Not display) 0FE

RHD022 (Not display) (Not display) 0DF

RHD023 (Not display) (Not display) 0FF

RHD024 (Not display) (Not display) 0F7

RHD025 (Not display) (Not display) 0B3

RHD026 (Not display) (Not display) 0E7

RHD027 (Not display) (Not display) 000

RHD028 (Not display) (Not display) 000

RHD029 (Not display) (Not display) 000

RHD030 (Not display) (Not display) 000

RHD031 (Not display) (Not display) 000

RHD032 (Not display) (Not display) 000

RHD033 (Not display) (Not display) 0E0

RHD034 (Not display) (Not display) 001

RHD035 (Not display) (Not display) 023

RHD036 (Not display) (Not display) 00A

RHD037 (Not display) (Not display) 000

RHD038 (Not display) (Not display) 000

RHD039 (Not display) (Not display) 000

RHD040 (Not display) (Not display) 000

RHD041 (Not display) (Not display) 000

RHD042 (Not display) (Not display) 020

RHD043 (Not display) (Not display) 000

RHD044 (Not display) (Not display) 000

RHD045 (Not display) (Not display) 000

RHD046 (Not display) (Not display) 000

RHD047 (Not display) (Not display) 00C

RHD048 (Not display) (Not display) 000

RHD049 (Not display) (Not display) 068

RHD050 (Not display) (Not display) 03C

RHD051 (Not display) (Not display) 001

RHD052 (Not display) (Not display) 008

RHD053 (Not display) (Not display) 004

RHD054 (Not display) (Not display) 000

RHD055 (Not display) (Not display) 000

RHD056 (Not display) (Not display) 000

RHD057 (Not display) (Not display) 000

RHD058 (Not display) (Not display) 000

RHD059 (Not display) (Not display) 00B

RHD060 (Not display) (Not display) 002

RHD061 (Not display) (Not display) 000

Item No. Item name

Variable

range

Initial setting

value

RHD062 (Not display) (Not display) 000

RHD063 (Not display) (Not display) 000

RHD064 (Not display) (Not display) 000

RHD065 (Not display) (Not display) 000

RHD066 (Not display) (Not display) 000

RHD067 (Not display) (Not display) 000

RHD068 (Not display) (Not display) 000

RHD069 (Not display) (Not display) 000

RHD070 (Not display) (Not display) 000

RHD071 (Not display) (Not display) 000

RHD072 (Not display) (Not display) 000

RHD073 (Not display) (Not display) 000

RHD074 (Not display) (Not display) 000

RHD075 (Not display) (Not display) 000

RHD076 (Not display) (Not display) 000

RHD077 (Not display) (Not display) 000

RHD078 (Not display) (Not display) 000

RHD079 (Not display) (Not display) 000

RHD080 (Not display) (Not display) 000

RHD081 (Not display) (Not display) 000

RHD082 (Not display) (Not display) 000

RHD083 (Not display) (Not display) 000

RHD084 (Not display) (Not display) 000

RHD085 (Not display) (Not display) 000

RHD086 (Not display) (Not display) 000

RHD087 (Not display) (Not display) 000

RHD088 (Not display) (Not display) 000

RHD089 (Not display) (Not display) 000

RHD090 (Not display) (Not display) 000

RHD091 (Not display) (Not display) 000

RHD092 (Not display) (Not display) 000

RHD093 (Not display) (Not display) 000

RHD094 (Not display) (Not display) 000

RHD095 (Not display) (Not display) 000

RHD096 (Not display) (Not display) 000

RHD097 (Not display) (Not display) 000

RHD098 (Not display) (Not display) 000

RHD099 (Not display) (Not display) 000

RHD100 (Not display) (Not display) 000

RHD101 (Not display) (Not display) 000

RHD102 (Not display) (Not display) 000

RHD103 (Not display) (Not display) 000

RHD104 (Not display) (Not display) 000

RHD105 (Not display) (Not display) 000

RHD106 (Not display) (Not display) 000

(No.YA097)1-49

Page 50

Item No. Item name

Variable

range

Initial setting

value

RHD107 (Not display) (Not display) 000

RHD108 (Not display) (Not display) 000

RHD109 (Not display) (Not display) 000

RHD110 (Not display) (Not display) 000

RHD111 (Not display) (Not display) 000

RHD112 (Not display) (Not display) 000

RHD113 (Not display) (Not display) 000

RHD114 (Not display) (Not display) 000

RHD115 (Not display) (Not display) 000

RHD116 (Not display) (Not display) 000

RHD117 (Not display) (Not display) 000

RHD118 (Not display) (Not display) 000

RHD119 (Not display) (Not display) 000

RHD120 (Not display) (Not display) 000

RHD121 (Not display) (Not display) 000

RHD122 (Not display) (Not display) 000

RHD123 (Not display) (Not display) 000

RHD124 (Not display) (Not display) 000

RHD125 (Not display) (Not display) 000

RHD126 (Not display) (Not display) 000

RHD127 (Not display) (Not display) 000

RHD128 (Not display) (Not display) 000

RHD129 (Not display) (Not display) 000

RHD130 (Not display) (Not display) 000

RHD131 (Not display) (Not display) 000

RHD132 (Not display) (Not display) 000

RHD133 (Not display) (Not display) 000

RHD134 (Not display) (Not display) 000

RHD135 (Not display) (Not display) 000

RHD136 (Not display) (Not display) 000

RHD137 (Not display) (Not display) 000

RHD138 (Not display) (Not display) 000

RHD139 (Not display) (Not display) 000

RHD140 (Not display) (Not display) 000

RHD141 (Not display) (Not display) 000

RHD142 (Not display) (Not display) 000

RHD143 (Not display) (Not display) 000

RHD144 (Not display) (Not display) 000

RHD145 (Not display) (Not display) 000

RHD146 (Not display) (Not display) 000

RHD147 (Not display) (Not display) 000

RHD148 (Not display) (Not display) 000

RHD149 (Not display) (Not display) 000

RHD150 (Not display) (Not display) 000

RHD151 (Not display) (Not display) 000

Item No. Item name

Variable

range

Initial setting

value

RHD152 (Not display) (Not display) 000

RHD153 (Not display) (Not display) 000

RHD154 (Not display) (Not display) 000

RHD155 (Not display) (Not display) 000

RHD156 (Not display) (Not display) 000

RHD157 (Not display) (Not display) 000

RHD158 (Not display) (Not display) 000

RHD159 (Not display) (Not display) 000

RHD160 (Not display) (Not display) 000

RHD161 (Not display) (Not display) 000

RHD162 (Not display) (Not display) 000

RHD163 (Not display) (Not display) 000

RHD164 (Not display) (Not display) 000

RHD165 (Not display) (Not display) 000

RHD166 (Not display) (Not display) 000

RHD167 (Not display) (Not display) 000

RHD168 (Not display) (Not display) 000

RHD169 (Not display) (Not display) 000

RHD170 (Not display) (Not display) 000

1-50 (No.YA097)

Page 51

4.7 ADJUSTMENT PROCEDURE

4.7.1 CHECK ITEMS

Item

X-RAY PROTECTOR check

Measuring

instrument

Resistor

[6.8kΩ 1/4W ±34Ω]

S1 connector 2 pin : X-Ray2 3 pin : X-Ray1 [DEF/ CONVEGENCE OUT PWB]

CONNECTOR

12345

Test point Adjustment part Description

(1) Receive NTSC whole black signal.

(2) Connect resistor 6.8kΩ (1/4W, ±34Ω) between 2 pin

& 3 pin of the S1 connector.

(3) Confirm that the X-RAY protector functions operated.

RESISTOR

6.8K 34 1/4W

X-RAY2

TP-E

( )

HIGH VOLTAGE check

X-RAY1NCTP-91B

139.5V

Signal generator

CN008

X-RAY

R565

CRT Anode (1) Receive NTSC whole black signal.

HV voltmeter

4.7.2 HORIZONTAL FREQUENCY ADJUSTMENT

Item

H. FREQUENCY adjustment

Measuring

instrument

Signal generator

Test point Adjustment part Description

[1.PICTURE/SOUND] D15 : H. FREQ.

D18 : DEF. RST Remote control unit

Unoptimum synchronization

(Horizontal frequency difference)

Optimum synchronization

(Horizontal frequency

optimal condition)

TP-91

D561D562

TP-E

R562

T502

FBT

R563

R561

54321

SERVICE CONNECTOR

FR311 D311

C311

(2) Connect the HV voltmeter between CRT anode and

GND.

(3) Check the high voltage DC 31.0kV (+1.0kV / -1.3kv).

(1) Receive NTSC crosshatch signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select < D18 > (DEF. RST) and change the data 0

to 1 (free run).

(5) While observing the screen, adjust the < D15 >

(H. FREQ) so that an optimum horizontal

synchronization is obtained. (see figure) (6) Press [MUTING] key to memorize the set value. (7) After adjustment, select < D18 > and change the

data 1 to 0. (8) Press [MUTING] key to memorize the set value.

(No.YA097)1-51

Page 52

4.7.3 FOCUS & BEAM SPOT ADJUSTMENT

Item

FOCUS & BEAM SPOT

Measuring

instrument

Signal generator

Test point Adjustment part Description

adjustment

Similar adhesive (Securing adhesive)

LENS FOCUS

SCREW

PROJECTION UNIT & LENS ASS'Y

(CRT adjustment location)

BEAM SPOT adjustment point

< Beam shape : circle >< Beam shape : distortion >

round as circle

4 pole magnet adjustment

DEFLECTION

YOKE

4 POLE MAGNET

red

green

CENTERING

2 POLE MAGNET

< Defocus > < Optimum Focus >

optimum center and defocus center should be same point

2 pole magnet adjustment

blueblue

TEST MODE [5.CONVER OFF]

R Def. yoke (DY) G Def. yoke (DY) B Def. yoke (DY) [PROJECTION UNIT]

R LENS FOCUS screw G LENS FOCUS screw B LENS FOCUS screw [PROJECTION UNIT (LENS ASS'Y)]

4 pole magnet 2 pole magnet [PROJECTION UNIT

(R / G / B CRT neck)]

R FOCUS VR G FOCUS VR B FOCUS VR [FOCUS PACK]

MAGNET

(1) Receive NTSC crosshatch signal. (2) Select FULL mode with [ASPECT] key. (3) Select DYNAMIC mode with [VIDEO STATUS] key. (4) Select 5.CONVER OFF from TEST MODE menu,

then dot pattern is appear. (5) Press [INPUT] key to appear crosshatch pattern. (6) Adjust the R, G and B DY position to mark straight

horizontal line.

LENS FOCUS

(1) Makes a red single color.

NOTE:

When making a single color, while adjusting focus of one CRT, put the cap on other lens.

(2) By turning the LENS FOCUS screw (in LENS

ASS'Y), for optimum focus at the screen center.

Check for absence of difference in the peripheral

focus. If the peripheral focus is poor, slightly shift the

center focus to obtain overall balanced focus.

(3) In the same manner, produce green and blue single

color and adjust their respective focus.

(4) After adjustment, fixes a screw.

NOTE:

There is not a difference in the focus in the top and the bottom, on either side, in the diagonal. When the difference of the focus is big, it removes a main lens, and it puts a washer between the main lens and the coupler and adjusts it.

BEAM SPOT

(5) Change dot pattern with [INPUT] key. (6) Makes a red single color. (7) Turn the R FOCUS VR clockwise from just focus

point, to set the dot diameter approx. to Ø30mm.

(8) Turn the 4 pole magnet of the projection unit CRT

neck and make beam shape round as circle on the

position between center and both ends of the

screen.

(9) Adjust the R FOCUS VR for optimum focus at the

position indicated in the figure.

(10) Turn the 2 pole magnet of the CRT neck as optimum

focus and defocus center should become the same

point.

(11) In the same manner, adjust for the green and blue

single color focus.

(12) Secure the 4 and 2 pole magnets with similar adhe-

sive.

CRT FOCUS

(13) Receive NTSC crosshatch signal. (14) Select DYNAMIC mode with [VIDEO STATUS] key. (15) Makes a red single color. (16) Adjust the R FOCUS VR for optimum focus at the

position indicated in the figure.

(17) In the same manner, adjust for the green and blue

single color focus.

CRT FOCUS adjustment point

1-52 (No.YA097)

Page 53

4.7.4 DEFLECTION & CONVERGENCE ADJUSTMENT

• The adjustment using the remote control unit is made on the basis of the initial setting values.

• The setting values which adjust the screen to the optimum condition can be different from the initial setting values.

• At first the adjustment in FULL mode should be done, then the data for the other ASPECT mode is corrected in the respective value at the same time.

4.7.4.1 FLOWCHART OF ADJUSTMENT

CAUTION:

All adjustments of the DEFLECTION circuit for this model should be carried out under the status without convergence operation. To enter the mode without convergence operation, select 1.PICTURE/SOUND and change the data in the setting item F62 from 0 to 1. (For details, please refer to the adjustment of DEFLECTION.) As a result, you can get the screen as shown in bellow figure. Adjust the DEFLECTION circuit in order of the steps indicated by the downward arrows.

NOTE:

When every adjustment of the DEFLECTION circuit has completed, start the adjustment of convergence.

Adjustment

location

sequence

Overall position & size

Center

Center perimeter

(If center deviated, readjust)

PREPARATION

Without convergence operation

SCREEN TILT

H.POSITION /SIZE (coarse)

RASTER CENTERING

H.SIZE

SIDE PIN

TRAPEZIUM

CONVERGENCE

CONVERGENCE PHASE

Perimeter

(If center deviated, readjust)

Corner (Final adjust)

R and B only

Crosshatch Completed

(From a collection of squares)

DEFLECTION

V.POSITION / SIZE / LINEARITY

H.POSITION

OVERALL CONVERGENCE

( LINE / POINT )

(No.YA097)1-53

Page 54

4.7.4.2 PREPARATION

Item

SCREEN TILT adjustment

Measuring

instrument

Signal generator

Remote control unit

H. POSITION / SIZE (coarse)

Signal generator

adjustment

Remote control unit

RASTER CENTERING

Signal generator

adjustment

Remote control unit

R G B

Test point Adjustment part Description

TEST MODE [5.CONVER OFF]

• Confirm correct FOCUS adjustment. (1) Receive NTSC crosshatch signal. (2) Enter TEST MODE [5.CONVER OFF].

G DEF. YOKE R DEF. YOKE B DEF. YOKE [PROJECTION UNIT]

(3) Select crosshatch pattern with [INPUT] key. (4) Makes a green single color.

NOTE :

When making a single color, while adjusting of one CRT, put the cap on other lens.

(5) Temporarily secure the G deflection yoke to the top

of the neck and adjust the tilt of the deflection yoke so that the horizontal line at the center becomes flat. After adjustment, fasten the temporal screw.

(6) Adjust the tilt of the R and B deflection yokes in the

same manner as for green.

NOTE :

Make sure that the adjustment of CRT FOCUS is optimized at the center and at the fringe of the center in turn. If the proper adjustment has not been done, adjust FOCUS VR again.

[1.PICTURE/SOUND] D03 : H. SIZE D14 : H. CENTER F62 : Without convergence operation

(1) Receive NTSC circle (or crosshatch) signal. (2) Select 1. PICTURE/SOUND from SERVICE MENU. (3) Select < F62 > (Without convergence operation) with

[CH +] / [CH -] keys.

(4) Change the data 0 to 1, then it makes picture without

convergence operation.

(5) Makes a green single color.

NOTE :

When making a single color, while adjusting of one CRT, put the cap on other lens.

(6) Select < D03 > (H. SIZE) and shorten the level until

and perpendicular amplitude of vibration with until the blanking in Left and Right and on either side can be seen.

(7) Select < D14 > (H. CENTER) and adjust horizontal

position to make the screen center and signal center.

(8) Select < D03 > and adjust horizontal size to make

screen picture approx. 92% of H-SIZE.

(9) Press [MUTING] key to memorize the set value.

(10) After adjustment, select < F62 > and change the

data 1 to 0.

(11) Press [MUTING] key to memorize the set value.

TEST MODE [5. CONVER OFF]

NOTE :

Carry out after finishing adjustment of H. POSITION and H. SIZE.

G CENTERING magnet R CENTERING magnet B CENTERING magnet [DEF. YOKE]

(1) Receive NTSC crosshatch signal. (2) Enter TEST MODE [5.CONVER OFF] and select

crosshatch pattern with [INPUT] key.. (3) Select crosshatch pattern with [INPUT] key. (4) Adjust G CENTERING magnet to make horizontal

and vertical line center as mechanical center of

screen. (5) Red and blue color too, are reflected by it. (6) Using R CENTERING magnet and B CENTERING

magnet, adjusts for the line of the red(L1) and the

blue(L2) to become the position of the left figure.

NOTE :

mechanical center

R G B

Vertical center position of the red and blue are the same as green.

L1 = 40mm L2 = 45mm

1-54 (No.YA097)

Page 55

4.7.4.3 DEFLECTION ADJUSTMENT

Item

V. POSITION / SIZE /

Measuring

instrument

Signal generator

Test point Adjustment part Description

LINEARITY adjustment

Remote control unit

no-signal area

AV-48WP55 AV-56WP55 AV-65WP55

C 35mm 50mm 80mm

H. POSITION adjustment

Signal generator

Remote control unit

[1.PICTURE/SOUND] D01 : V. SIZE D05 : V. LINE D06 : V. CENT F62 : Without convergence operation

[1.PICTURE/SOUND] D14 : H. CENTER F62 : Without convergence operation

• To memorize every time after finish adjustment on each mode.

(1) Receive NTSC circle pattern signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select < F62 > (Without convergence operation). (5) Change the data 0 to 1, then it makes picture without

convergence operation.

(6) Select < D01 > (V. SIZE), < D05 > (V. LINE) and

< D06 > (V. CENT).

(7) Adjust < D01 >, < D05 > and < D06 > to make A = B

(precision ±2mm), and adjust to make C same value

as table. (8) Press [MUTING] key to memorize the set value. (9) After adjustment, select < F62 > and change the

data 1 to 0.

(10) Press [MUTING] key to memorize the set value.

NOTE :

Do not adjust < D04 > (V. SCORE), if it is different vertical position after adjust vertical linearity, to adjust vertical position.

convergence operation. (6) Select < D14 > (H. CENTER). (7) Adjust < D14 > to make D = E as shown figure. (8) Press [MUTING] key to memorize the set value. (9) After adjustment, select < F62 > and change the

data 1 to 0.

(10) Press [MUTING] key to memorize the set value.

H. SIZE adjustment

Signal generator

[1.PICTURE/SOUND] D03 : H. SIZE F62 : Without

Remote

convergence operation

control unit

Screen size

(92%)

Picture size

100%

(1) Receive NTSC crosshatch signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select < F62 > (Without convergence operation). (5) Change the data 0 to 1, then it makes picture without

convergence operation. (6) Select < D03 > (H. SIZE). (7) Adjust < D03 > to make sure that the vertical screen

size of the picture size is 92%. (8) Press [MUTING] key to memorize the set value. (9) After adjustment, select < F62 > and change the

data 1 to 0.

(10) Press [MUTING] key to memorize the set value.

(No.YA097)1-55

Page 56

Item

SIDE PIN adjustment

TRAPEZIUM adjustment

Measuring

instrument

Signal generator

Remote control unit

Signal generator

Remote control unit

Test point Adjustment part Description

[1.PICTURE/SOUND] D02 : EW D08 : BOT.CORN D09 : TOP.CORN F62 : Without convergence operation

convergence operation.

(6) Select < D02 > (EW), < D08 > (BOT.CORN) and

< D09 > (TOP.CORN).

Straight

(7) Adjust < D02 >, < D08 >, < D09 > to make the vertical

lines at the left and right edges of the screen straight. (8) Press [MUTING] key to memorize the set value. (9) After adjustment, select < F62 > and change the

data 1 to 0.

(10) Press [MUTING] key to memorize the set value.

NOTE :

After making adjustments, confirm that the horizontal position is properly adjusted. If the horizontal is out of alignment, readjust it. Adjust H. SIZE & SIDE PIN reparably.

[1.PICTURE/SOUND] D07 : EW.TRAP F62 : Without convergence operation

convergence operation. (6) Select < D07 > (EW.TRAP).

Parallel

(7) Adjust < D07 > to bring the vertical lines at the right

and left edges of the screen parallel. (8) Press [MUTING] key to memorize the set value. (9) After adjustment, select < F62 > and change the

data 1 to 0.

(10) Press [MUTING] key to memorize the set value.

NOTE :

After making adjustments, confirm that the horizontal position is properly adjusted. If the horizontal is out of alignment, readjust it. Adjust H. SIZE & SIDE PIN reparably.

1-56 (No.YA097)

Page 57

4.7.4.4 CONVERGENCE ADJUSTMENT

Item

CONVERGENCE PHASE

Measuring

instrument

Signal generator

Test point Adjustment part Description

[check]

Remote control unit

Item nameItem No.

CPA04 TPOV OFST 0

CPA05 FINEP 1245 CPA06 STARTLIN A 56

CPA07 STARTLIN B -1

CPA08 CAU H2 0

CPA09 COARS OFST -50

CPA10 V1OFSTA 7

CPA11 V1OFSTB 0

Table-1

[6.CONVER A] CPA04 : TPOV OFST CPA05 : FINEP CPA06 : STARTLIN A CPA07 : STARTLIN B CPA08 : CAU H2 CPA09 : COARS OFST CPA10 : V1OFSTA CPA11 : V1OFSTB

Initial setting

value

NOTE:

Be sure to make it the value of Table-1. Supposing data differs, correct to the value of Table-1. When data is corrected (when the [MUTING] key is pushed), it is necessary to perform an AUTO CONVERGENCE PRESET, after a convergence adjusts exactly. (1) Receive NTSC crosshatch signal. (2) Select 6.CONVER A from SERVICE MENU. (3) Select < CPA > item with [INPUT] key. (4) Check and set data that < CPA04 > ~ < CPA11> are

same value as table1.

(5) Press [MUTING] key to memorize the set values.

REMOTE CONTROL KEY POSITION

INPUT key

CPA

CCA**

CBA

CDA

SELECT key

For adjusting color change

MUTING key

For storing adjustment data in memory

CH+ / CH- keys

Item No. change [CH+] : up [CH- ] : down

VOL+ / VOL- keys

Setting value change [VOL+] : up [VOL- ] : down

OK key

For display color change Two colors : adjusting color + green Three colors : RGB

MULTI SCREEN

FREEZE

SOUND

SWAP

TUNE

ASPECT

RM-C1257G

SELECT

C.C.INDEXTWIN

INPUT

LIGHT

BACK

(No.YA097)1-57

Page 58

Item

OVERALL CONVERGENCE (LINE) [check]

CCA01 CCA02 CCA03 CCA04 CCA05 CCA06 CCA07 CCA08 CCA09 CCA10 CCA11 CCA12

Measuring

instrument

Signal generator

Remote control unit

Item nameItem No.

H CENT

H SIZE

H LIN

H SKEW

EW PIN

H BOW

V CENT

V SKEW

V SIZE

V. LIN V. KEY TB PIN

Test point Adjustment part Description

[ 6.CONVER A ] CPA01 : FINE OFF CCA01 : H CENT CCA02 : H SIZE CCA03 : H LIN CCA04 : H SKEW CCA05 : EW PIN CCA06 : H BOW CCA07 : V CENT CCA08 : V SKEW CCA09 : V SIZE CCA10 : V LIN CCA11 : V KEY CCA12 :TB PIN

NOTE:

Be sure to make it the value of Table-2. Supposing data differs, correct to the value of Table-2. When data is corrected (when the [MUTING] key is pushed), it is necessary to perform an AUTO CONVERGENCE PRESET, after a convergence adjusts exactly. (1) Receive NTSC crosshatch signal. (2) Select 6.CONVER A from SERVICE MENU. (3) Select < CPA01 > (FINE OFF). (4) Change the data 0 to1. (Clear the fine adjustment

data)

(5) Select < CCA > item with [INPUT] key. Then a green

crosshatch pattern for adjustment will be displayed on the screen.

Initial setting value

GREEN

-27

-96 0

-91 0

-19 0

-108 15

280

RED

-246

-54

240

-26

-30 8 0

-77

12 114 153

BLUE

395

-348

-10

-17 21 12

-105 8

-77

230

(6) Check and set data < CCA01 > ~ < CCA11 > are

same value as table2.

(7) Press [SELECT] key to change the adjusting color to

red and blue.

NOTE:

Press [OK] key to change the display colors. Whenever [OK] key is pressed, the menu will sequence in this order: "Two colors (adjusting

color+green)" → "Three colors (RGB)"

(8) Press [MUTING] key to memorize the set value.

(9) Select < CPA01 >. (10) Change the < CPA01 > 1 to 0. (11) Press [MUTING] key to memorize the set values.

Table-2

1-58 (No.YA097)

Page 59

Item

H#4 : 0 V#4 : 0

OVERALL CONVERGENCE (POINT) adjustment

V#0 V#1

V#2

V#3

V#4

V#5

V#6

V#7 V#8

rea C

AV-48WP55 174 AV-56WP55 204 407 509 611 96 192 287 335 AV-65WP55 237

Measuring

instrument

Test point Adjustment part Description

Signal generator

Remote control unit

Cursor

Point of adjustment

Fig.1

H#1 H#5 H#6 H#8H#7

Area D

H#4H#3H#2H#0

H#4 : 0 V#4 : 0

Area A

Fig.2

348

435

522

473

592

710

111

SPAN TABLE (mm)

REMOTE CONTROL KEY POSITION

[ 7.CONVER B ] NOTE:

Perform this adjustment after performing OVERALL CONVERGENCE (LINE) check. It adjusts displaying and checking adjustment data by the [DISPLAY] key. Adjust in order of Area A, Area B, Area C and Area D. (1) Receive NTSC crosshatch signal. (2) Select 7.CONVER B from SERVICE MENU. Then

(3) Press [DISPLAY] key for displaying and checking

(4) Press [ 2 ] / [ 4 ] / [ 5 ] / [ 6 ] / [ 8 ] keys respectively,

(5) Press [CH+] / [CH-] / [VOL+] / [VOL-] keys, adjust the

(6) Adjust Area A. (7) Adjust Area B. (8) Adjust Area C. (9) Adjust Area D. It adjusts toward an outside from the

(10) Press [SELECT] key to select the red and blue

Area B

164

222

246

333

287

388

(11) Press [OK] key to change the display colors to three

(12) Press [MUTING] key to memorize the set values.

H#0H#1

appear green crosshatch pattern for adjustment. (See Fig.1)

adjustment data.

move the cursor to the adjusting point.

position of the adjusting point so that it is located at the place as shown in Fig.2.

inner side of a screen. (e.g. H#3 > H#2 > ---) H#0 is fixed data with the value inputted by adjustment of Area C. When the point of H#0 needs to be adjusted, adjusts the data of H#1 and H#2. If the data of H#1 adjusts H#0, H#2 will move, the data of H#2 adjusts H#1 and H#2. It repeats if needed. (See Fig.3)

crosshatch patterns, respectively, and make convergence adjustments so that they align with the adjusting points of the green crosshatch pattern (reference color).

colors from two colors (adjusting color + green) and make sure that the convergence has been aligned with each other.

ADJUSTMENT PROCEDURE OF LINE H#1

H#2 H#0 H#1 H#2 H#0H#1 H#2

DISPLAY key

Displaying adjustment data

Number keys

For cursor shifting

[2] : up [4] : left [5] : center [6] : right [8] : down

MULTI SCREEN

FREEZE

SWAP

SOUND

TUNE

ASPECT

MUTING key

For storing adjustmentdata in memory

RM-C1257G

SELECT

INPUT

C.C.INDEXTWIN

LIGHT

BACK

SELECT key

For adjusting color change

INPUT key

For adjustment pattern change

Crosshatch / Adjust point crosshatch

OK key

Display colors change for adjusting

VOL+ / VOL- / CH+ / CH- keys

For convergence adjustments

[CH+] : up [CH- ] : down [VOL+] : left [VOL -] : right

NOTE: Adjust in consideration of a surrounding line moving.

Fig.3

(No.YA097)1-59

Page 60

4.7.5 VIDEO ADJUSTMENT

Item

RGB CUTOFF adjustment

Measuring

instrument

Signal generator

Oscilloscope

Remote control unit

Item No. Item name Initial setting value

BRIGHT

S03

CUTOF R

S14

CUTOF G

S16

CUTOF B

S18

CUTOFSWR

S20

CUTOFSWG

S21

CUTOFSWB

S22

Test point Adjustment part Description

TP-R [R CRT SOCKET PWB] TP-G [G CRT SOCKET PWB] TP-B [B CRT SOCKET PWB]

[1.PICTURE/SOUND] S14: CUTOF R S16: CUTOF G S18: CUTOF B

R SCREEN VR G SCREEN VR B SCREEN VR [FOCUS PACK]

(1) Receive NTSC signal (include 0% or -3% black). (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Select FULL mode with [ASPECT] key. (4) Set the COLOR TEMP is LOW mode. (5) Connect the oscilloscope to TP-G. (6) Select 1.PICTURE/SOUND from SERVICE MENU. (7) Select < S03 > (BRIGHT). (8) Set < S03 > to 127. (9) Select < S16 > (CUTOF G).

(10) Adjust < S16 > so that the 0% or -3% signal portion

127

185

001

and the 100% signal portion of both sides may

become the 180V.

(11) Press [MUTING] key to memorize the set value. (12) Receive 480i component signal (include 0% or -3%

black).

(13) Select < S03 >. (14) Set < S03 > to 127. (15) Select < S16 >. (16) Set < S16 > same as memorized NTSC value. (17) Select STANDARD mode with [VIDEO STATUS] key. (18) Select FULL mode with [ASPECT] key. (19) The COLOR TEMP set at the LOW mode. (20) Set 1080i component signal (include 0% or -3%

black).

(21) Select < S03 >. (22) Set < S03 > to 127. (23) Select < S16 >. (24) Set < S16 > same as memorized NTSC value. (25) Connect the oscilloscope to TP-R and < S14 >

(CUTOF R) adjust same manner as for 6. ~ 13.

above.

(26) Connect the oscilloscope to TP-B and < S18 >

(CUTOF B) adjust same manner as for 6. ~ 13.

above.

(27) Adjust SCREEN VR for RGB respectively, so that

the black (3%) becomes faintly whitish.

NOTE :

If it is difficult to adjust the SCREEN precisely, adjust the SCREEN VR for one of three colors while masking other two colors.

1-60 (No.YA097)

Page 61

Item

WHITE BALANCE (LOW LIGHT) adjustment

BRIGHT LEVEL DRIVE CUTOFF

Item No. Item name

S03 S10 S12 S14 S16 S18

WHITE BALANCE (HIGH LIGHT) adjustment

Item

S10 089 052 057

S12 108 107 109

Measuring

instrument

Signal generator

Test point Adjustment part Description

[3.WHITE BALANCE] BR CUT R

Remote

CUT B

control unit

3. WHITE BALANCE

BR DRV

GBCUT

Setting value

REMOTE CONTROL UNIT

TUNE

1.PICTURE/SOUND 3.WHITE BALANCE Initial setting

value BRIGHT DRIVE R DRIVE B CUTOF R CUTOF G CUTOF B

127 085 085 185 185 185

Signal generator

RETURN+

Item name

BR DRV R DRV B CUT R CUT G CUT B

Initial setting

[1.PICTURE/SOUND] S10: DRIVE R

S12: DRIVE B Remote control unit

[3.WHITE BALANCE]

DRV R

DRV B

Signal

NTSC 480i 1080i

REMOTE CONTROL UNIT

Initial setting value

DRIVE B

value

127 085 085 215 215 215

NOTE :

Before starting the adjustment, warm up the unit for more than 30 minutes. (1) Receive NTSC gray scale signal (include 0% black). (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Set the COLOR TEMP is LOW mode. (4) Select 3.WHITE BALANCE from SERVICE MENU. (5) Select , < DRV R >, < DRV B >, < CUT R >,

< CUT G > and < CUT B >. (6) Set the initial setting value. (7) Adjust so that the LOW-LIGHT should be

visible. (8) Adjust using [ 8 ] / [ 0 ] keys and [ 9 ] / [ RETURN + ]

keys so that a black portion may become black. (9) Press [MUTING] key to memorize the set values.

(10) Input 480i component signal (include 0% black) from

COMPONENT VIDEO terminal.

(11) Repeat steps 5 ~ 9 above. (12) Input 1080i component signal (include 0% black)

from COMPONENT VIDEO terminal.

(13) Repeat steps 5 ~ 9 above.

NOTE:

• 3. WHITE BALANCE , < DRV R >, < DRV B >,

< CUT R >, < CUT G > and < CUT B > are equal to 1. PICTURE/SOUND < S03 >, < S10 >, < S12 >, < S14 >, < S16 > and < S18 >.

• 3. WHITE BALANCE , < DRV R > and < DRV

B > are same value as 1. PICTURE/SOUND < S03 >, < S10 > and < S12 >.

• 3. WHITE BALANCE < CUT R >, < CUT G > and < CUT

B > are same value as 1. PICTURE/SOUND < S14 >, < S16 > and < S18 > plus 30.

• For example, 3.WHITE BALANCE value was

changed from 127 to 120, 1.PICTURE/SOUND < S03 > value was changed from 127 to 120 automatically.

3. WHITE BALANCE < CUT R > value was changed from 215 to 210, 1.PICTURE/SOUND < S03 > value was changed from 185 to 180 automatically.

(1) Receive NTSC grayscale signal (include 75%

white). (2) Select STANDARD mode with [VIDEO STATUS] key. (3) Set the COLOR TEMP is LOW mode. (4) Select 1.PICTER/SOUND from SERVICE MENU. (5) Select < S10 > (DRIVE R) and < S12 > (DRIVE B). (6) Set the initial setting value. (7) Select 3.WHITE BALANCE from SERVICE MENU. (8) Adjust using [ 2 ] / [ 5 ]] keys and [ 3 ] / [ 6 ] keys so

that the natural white should be visible on 75% white. (9) Press [MUTING] key to memorize the set value.

(10) Input 480i component grayscale signal (include 75%

white) from COMPONENT VIDEO terminal.

(11) Repeat steps 4 ~ 9 above. (12) Input 1080i component grayscale signal (include

75% white) from COMPONENT VIDEO terminal.

(13) Repeat steps 4 ~ 9 above.

DRIVE R

(No.YA097)1-61

Page 62

Item

SUB BRIGHT adjustment

Measuring

instrument

Signal generator

Test point Adjustment part Description

Remote control unit

Setting value

STANDARD THEATER

Item

S03

Signal

NTSC 480i 1080i

STANDARD THEATER

118 118

Table-1

SUB CONTRAST

Signal generator

adjustment (1)

Remote control unit

Setting value

STANDARD THEATER

Item

S04

Signal

NTSC 480i 1080i

STANDARD THEATER

054 054

Table-2

SUB CONTRAST adjustment (2)

Signal generator

TP-G [G CRT SOCKET PWB]

Oscilloscope

Remote control unit

SETTING VOLTAGE [V

Signal

Video Status

STANDARD 68 80 80

THEATER 60 65 60

NTSC 480i 1080i

Table-3

[1.PICTURE/SOUND] S03: BRIGHT

STANDARD THEATER

118

[1.PICTURE/SOUND] S04: CONTRAST

STANDARD THEATER

054

[1.PICTURE/SOUND] S04: CONTRAST

(p-p)]

(1) Receive NTSC signal (include 0% or -2% black). (2) Select STANDARD mode with [VIDEO STATUS] key. (3) Set the COLOR TEMP is LOW mode. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select < S03 > (BRIGHT). (6) Set the initial setting value. (See Table-1) (7) If the brightness is not the best with the initial setting

value, make fine adjustment until you get the best brightness.

(8) Press [MUTING] key to memorize the set values.

118118

(9) Select THEATER mode with [VIDEO STATUS] key. (10) Repeat steps 4 ~ 8 above. (11) Input 480i component signal (include 0% or -2%

black) from COMPONENT VIDEO terminal. (12) Repeat steps 2 ~ 10 above. (13) Input 1080i component signal (include 0% or -2%

black) from COMPONENT VIDEO terminal. (14) Repeat steps 2 ~ 10 above.

[ Method of adjustment without measuring instrument ]

(1) Receive NTSC glay scale signal. (2) Select STANDARD mode with [VIDEO STATUS]

key.

(3) Set the COLOR TEMP is LOW mode. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select < S04 > (CONTRAST). (6) Set the initial setting value. (See Table-2) (7) If the contrast is not the best with the initial setting

value, make fine adjustment of the < S04 > until you

054054

get the optimum contrast.

(8) Press [MUTING] key to memorize the set values.

(9) Select THEATER mode with [VIDEO STATUS] key. (10) Repeat steps 4 ~ 8 above. (11) Input 480i component black & white signal from

COMPONENT VIDEO terminal. (12) Repeat steps 2 ~ 10 above. (13) Receive 1080i component black & white signal from

COMPONENT VIDEO terminal. (14) Repeat steps 2 ~ 10 above.

[ Method of adjustment with measuring instrument ]

(1) Receive NTSC gray scale signal (include -3%). (2) Select STANDARD mode with [VIDEO STATUS] key. (3) Select FULL mode with [ASPECT] key. (4) Set the COLOR TEMP is LOW mode. (5) Connect the oscilloscope to TP-G. (6) Select 1.PICTURE/SOUND from SERVICE MENU. (7) Select < S04 > (CONTRAST). (8) Adjust < S04 > so that the -3% signal portion and the

100% signal portion of both sides may become the

follow table voltage.

(9) Press [MUTING] key to memorize the set value. (10) Select THEATER mode with [VIDEO STATUS] key. (11) Repeat steps 8 ~ 9 above. (12) Receive 480i component gray scale signal (include

-3%). (13) Repeat steps 2 ~ 11 above. (14) Set 1080i component gray scale signal (include -3%). (15) Repeat steps 2 ~ 11 above.

1-62 (No.YA097)

Page 63

Item

SUB COLOR / SUB TINT / B-Y GAIN adjustment (1)

Measuring

instrument

Signal generator

Remote control unit

Test point Adjustment part Description

TP-R [R CRT SOCKET PWB] TP-B

[1.PICTURE/SOUND] S01 : COLOR S02 : TINT

S07 : B-Y [B CRT SOCKET PWB] TP-E (GND)

Signal

Item

S01

S02 060 050 068 066062 059 065065

S07 017 027 024 018012 013 020019

NTSC 480i 480p

STANDARD THEATER

096 083

Initial setting value

STANDARD THEATER

075

STANDARD THEATER

076085 079

720p / 1080i

STANDARD THEATER

071074

[ Method of adjustment without measuring instrument ]

(1) Receive NTSC color bar signal (include 75% white). (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Select 1.PICTURE/SOUND from SERVICE MENU. (4) Select < S01 > (COLOR) and < S02 > (TINT). (5) Set the initial setting value. (6) If the color or tint is not the best with the initial setting

values, make fine adjustment until you get the best

color or the best tint. (7) Select < S07 > (B-Y). (8) Set the initial setting value. (9) If the color bar is not clearly with the initial setting

value, make fine adjustment until you get the clearly

color bar.

(10) Press [MUTING] key to memorize the set value. (11) Select THEATER mode with [VIDEO STATUS] key. (12) Repeat steps 3 ~ 10 above. (13) Input 480i component color bar signal from

COMPONENT VIDEO terminal.

(14) Repeat steps 2 ~ 12 above. (15) Input 480p component color bar signal from

COMPONENT VIDEO terminal.

(16) Repeat steps 2 ~ 12 above. (17) Input 1080i component color bar signal from

COMPONENT VIDEO terminal.

(18) Repeat steps 2 ~ 12 above.

(No.YA097)1-63

Page 64

Item

SUB COLOR / SUB TINT / B-Y GAIN adjustment (2)

Setting item

Measuring

instrument

Signal generator

Oscilloscope

Remote control unit

Test point Adjustment part Description

TP-R [R CRT SOCKET PWB] TP-B [B CRT SOCKET PWB] TP-E (GND)

[1.PICTURE/SOUND] S01 : COLOR S02 : TINT S07 : B-Y

[ Method of adjustment with measuring instrument ]

(1) Receive NTSC color bar signal (include 75% white). (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Connect the oscilloscope to TP-R. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select < S01 > (COLOR) and < S02 > (TINT). (6) Adjust < S01 > and < S02 > to be following setting

value A[V]. (Refer to the bellow table) (7) Press [MUTING] key to memorize the set values. (8) Select THEATER mode with [VIDEO STATUS] key. (9) Adjust < S01 > and < S02 > to be following setting

value B[V] same as above. (Refer to the table)

(10) Press [MUTING] key to memorize the set values.

(-)

(+)

YR(W-Y) (W-R)

Fig.1

(11) Select STANDARD mode with [VIDEO STATUS]

key.

(12) Connect the oscilloscope to TP-B. (13) Adjust < S07 > (B-Y) to be setting value C[V]. (Refer

to the table)

(14) Press [MUTING] key to memorize the set values. (15) Select THEATER mode with [VIDEO STATUS] key. (16) Adjust < S07 > to be setting value D[V]. (Refer to the

table)

(17) Press [MUTING] key to memorize the set values. (18) Confirm that LOW-LIGHT is not different after

(-)

(+)

(W-B)

adjusting. If it is green or magenta, to adjust LOW-

LIGHT again. If adjust again, to set offset value

again.

(19) Input 480i component color bar from COMPONENT

VIDEO terminal.

(20) Repeat steps 2 ~ 18 above. (21) Input 480p component color bar from COMPONENT

VIDEO terminal.

Fig.2

(22) Repeat steps 2 ~ 18 above. (23) Input 1080i component color bar from

Setting value [V]

COMPONENT VIDEO terminal.

(24) Repeat steps 2 ~ 18 above.

STANDARD THEATER STANDARD THEATER

Signal

NTSC +41

480i +22

480p +33

1080i +27

S01

(W-R)

S02

(W-Y)

+15

+18

+12

S01

(W-R)

+26

+12

+16

+12

S02

(W-Y)

Table

1-64 (No.YA097)

S07

(W-B)

+20

S07

(W-B)

+15

-7

-4

Page 65

4.7.6 AUDIO (MTS) ADJUSTMENT

Item

MTS INPUT LEVEL

Measuring

instrument

Remote control unit

check

MTS SEPARATION adjustment

TV audio multiplex signal

AUDIO OUT L output R output

generator

Oscilloscope

Remote control unit

L-Channel signal waveform

1 cycle

Test point Adjustment part Description

[1.PICTURE/SOUND] A01 : IN LEVEL

(1) Select 1.PICTURE / SOUND from SERVICE MENU. (2) Select < A01 > (IN LEVEL). (3) Verify that < A01 > is set at its initial setting value.

[1.PICTURE/SOUND] A02: LOW SEP. A03 : HI SEP.

(1) Input stereo L signal (300Hz) from the TV audio

multiplex signal generator to the antenna terminal.

(2) Connect an oscilloscope to L OUTPUT pin of the

AUDIO OUT, and display one cycle portion of the 300Hz signal.

(3) Change the connection of the oscilloscope to R

OUTPUT pin of the AUDIO OUT, and enlarge the

voltage axis. (4) Select < A02 > (LOW SEP.). (5) Set the initial setting value of < A02 >. (6) Adjust < A02 > so that the stroke element of the

R-Channel crosstalk portion

Minimum

300Hz signal will become minimum. (7) Change the signal to 3kHz, and similarly adjust

< A03 > (HI SEP.). (8) Press [MUTING] key to memorize the set values.

(No.YA097)1-65

Page 66

SECTION 5

TROUBLESHOOTING

5.1 SELF-DIAGNOSIS FUNCTIONS

• This model has self-check functions that inform of the failure of the TV by detecting abnormality.

• Operational state is always monitored and the identified is memorized on the record. Therefore, diagnosis may be prevented against expectations if "NG" are indicated in many items. When recurrence of symptoms can be predicted, erase (reset) the history of failure and allow the unit to again record the results of diagnosis.

5.1.1 HOW TO ENTER THE SELF-DIAGNOSIS MODE

(1) Set the < SLEEP TIMER 30 MIN. > with [SLEEP TIMER]

key. (Fig.1)

(2) During the < SLEEP TIMER 30 MIN. > display, press

[DISPLAY] key and [VIDEO STATUS] key at the same time. (3) Then < TEST MODE > screen is displayed. (Fig.2) (4) Press [ 4 ] key then < SELF-CHECK > screen is appear.

(Fig.3)

SLEEP TIMER 30 MIN.

5.1.2 HOW TO EXIT FROM THE SELF-DIAGNOSIS MODE

With initialization

By using the remote control unit, turn the power off. At this time, the failure record is cleared.

With not initialization

(1) Take off the AC plug from the wall outlet. At this time, the

failure record is not cleared.

(2) Press the [BACK] key the SELF-CHECK screen return to

TEST MODE screen.

5.1.3 EXPLANATION FOR ACTIVATION OF SELF-DIAGNOSIS FUNCTIONS

• The latest failure is stored on the record at the end.

The failure record for each check item is counted to the number of 9 at the maximum, When more than 9 failures are stored on the record, the counter remains stopped at 9.

• SYNC is neither counted nor stored in memory.

• Because of the timing of Vcc start-up and shut-down of the IC

connecting to the I

C bus during which the power is turned on and off, the operation may be interpreted as an error. In order to avoid the misinterpretation, the self-check functions should be started at about 3 seconds after the power is turned on.

Fig.1

TEST MODE

1. I2C STOP

2. STATUS DISP

4. SELF-CHK

5. CONVER OFF

ROM CORRECTION : ACT ROM VER. : MN102H75

Fig.2

ITEM COUNTRESULT

XRAY

OCP LOB SYNC MEM VCD AIO TUN DET HDMI

OK M:OK OK OK OK OK OK OK

TIM

S:OK

AVS W

SPRT

NG2 OK HD:OK OK

Fig.3

SELF-CHECK SCREEN

Indication Check item Details of detection Method of detection

XRAY X-ray radiation protection ------ ------

OCP B1 over-current protection B1 over-current is detected.

Q971 : DEF & CONVERGENCE OUT PWB

At about 3 seconds after the power is turned on, the self-check function starts. If NG is detected for 200ms, the power is turned off automatically.

LOB Low B short protection Operation of low B short protection

circuit. Q1961(5V), Q1962(9V) : MAIN PWB

At about 3 seconds after the power is turned on, the self-check function starts. If NG is detected for 200ms, the power is turned off automatically.

TIM Timer The AC power frequency is changed as

follows :

50Hz → 60Hz 60Hz → 50Hz

Periodically check the power frequency by counting the AC pulse and monitor whether or not the frequency is changed except for the time immediately after resetting.

IC1701(MICOM) : 17pin

1-66 (No.YA097)

Page 67

Indication Check item Details of detection Method of detection

SYNC Presence or absence of

synchronized signal

Presence of synchronized signal. HD : Component signal M : NTSC main signal S : NTSC sub signal IC1301(AN15394A) : MI-COM & DIST

When entering the self-check mode, "OK" is shown. While running the mode with picture signal, if the synchronized signal is disappeared, "NG" is shown.

MODULE PWB

MEM Memory (EEP-ROM) ACK is returned when I

carried out. IC1703(MEMORY) : MI-COM & DIST

C traffic is

The state is monitored every time when I2C traffic is carried out. Then the state is counted as a failure if ACK is not returned.

MODULE PWB

AVSW AV switch Ditto

Ditto IC1301(AN15852A) and IC1501(CXA2069Q) : MAIN PWB

VCD Video process

(RGB process)

Ditto IC1301(AN15394A) : MI-COM & DIST

Ditto

MODULE PWB

AIO Audio process

(MTS decode / audio control)

YC 3D YC separation Ditto

Ditto IC1502(M62320) : MAIN PWB

Ditto

Ditto IC3001(MN82832) : MI-COM & DIST MODULE PWB

TUN RF tuner Ditto

Ditto RF tuner

DET DIST process Ditto

Ditto IC201(JCC5055) : MI-COM & DIST MODULE PWB

HDMI Digital input process

[AV-65WP55]

Ditto IC001(SiI9993) : DIGITAL INPUT

Ditto

MODULE PWB

SPRT ---- ---- ----

5.1.4 SELF-CHECK DISPLAY LED

The self-check results are shown on the following LED display. Method of indication when the raster is not displayed.

Each failure is shown by turning POWER LED on and off at specified intervals.

• For X-ray radiation protection, B1 over-current protection, low B short protection and CRT neck broken protection, the power of the TV is turned off if NG is detected. Immediately after the power is turned off, POWER LED will be turning on and off. When the power is turned off, you cannot turn the power on again until the AC plug is taken out and put in again.

Item POWER LED ON / OFF intervals

X-ray radiation

Turning on and off 0.1-second intervals

protection

B1 over-current

Turning on and off 1-second intervals

protection

Low B short protection Turning on and off 2-second intervals

CRT neck broken

Turning on and off 3-second intervals

protection

(No.YA097)1-67

Page 68

1-68 (No.YA097)

Page 69

JVC SERVICE & ENGINEERING COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

www.jvcservice.com(US Only)

JVC CANADA INC.

Head office : 21 Finchdene Square Scarborough, Ontario M1X 1A7 (416)293-1311

(No.YA097)

Printed in Japan

WPC

JVC AV-48WP55/H, AV-56WP55/H, AV-65WP55/H, AV-N48P55/H, AV-N56P55/H Service Manual And Parts List

Specifications and Main Features

Frequently Asked Questions

User Manual
