JVC AV 65WP74, AV 48WP74, AV 56WP74 User Manual

Projection Television Users Guide

For Models:

AV-65WP74 AV-56WP74 AV-48WP74

Illustration of AV-65WP74 and RM-C1200G

Important Note:

In the spaces below, enter the model and serial number of your television (located at the rear of the television cabinet). Staple your sales receipt or invoice to the inside cover of this guide. Keep this user’s guide in a convenient place for future reference. Keep the carton and original packaging for future use.

Model Number:

Serial Number:

LCT1282-001A-A

0103-TN-II-IM

Important Safety Precautions

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: To reduce the risk of electric shock. Do not

remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS TV SET

TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE FOLLOWING RULES

REGARDING THE USE OF THIS UNIT.

1. Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good

4. Do not allow objects or liquid into the cabinet openings.

5. In the event of trouble, unplug the unit and call a service technician. Do

Changes or modifications not approved by JVC could void the warranty.

* When you don’t use this TV set for a long period of time, be sure to

* To prevent electric shock do not use this polarized plug with an

ventilation is unattainable.

not attempt to repair it yourself or remove the rear cover.

disconnect both the power plug from the AC outlet and antenna for your safety.

extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure.

IMPORTANT RECYCLING INFORMATION

This product utilizes both a Cathode Ray Tube (CRT) and other components that contain lead. Disposal of these materials may be regulated in your community due to environmental considerations. For disposal or recycling information, please contact your local authorities, or the Electronic Industries Alliance: http://www.eiae.org

• As an “ENERGY STAR®” partner, JVC has determined that this product or product model meets the “ENERGY STAR®” guidelines for energy efficiency.

Important Safeguards

CAUTION:

Please read and retain for your safety.

Electrical energy can perform many useful functions. This TV set has been engineered and manufactured to assure your personal safety. But improper use can result in potential electrical shock or fire hazards. In order not to defeat the safeguards incorporated in this TV set, observe the following basic rules for its installation, use and servicing. Also follow all

warnings and instructions marked on your TV set.

INSTALLATION

1 Your TV set is equipped with a polarized AC line plug (one

blade of the plug is wider than the other). This safety feature allows the plug to fit into the power outlet only one way. Should you be unable to insert the plug fully into the outlet, try reversing the plug. Should it still fail to fit, contact your electrician.

2 Operate the TV set only from a power source as indicated on the TV set or refer to the

operating instructions for this information. If you are not sure of the type of power supply to your home, consult your TV set dealer or local power company. For battery operation, refer to the operating instructions.

3 Overloaded AC outlets and extension cords are dangerous, and so are frayed power cords

and broken plugs. They may result in a shock or fire hazard. Call your service technician for replacement.

4 Do not allow anything to rest on or roll over the power cord, and do not place the TV set

where power cord is subject to traffic or abuse. This may result in a shock or fire hazard.

5 Do not use this TV set near water — for example, near a bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement, or near swimming pool, etc.

6 If an outside antenna is connected to the TV set, be sure the antenna system is grounded

so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National Electrical Code provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection requirements for the grounding electrode.

(POLARIZED-TYPE)

7 An outside antenna system should not be located in the vicinity of overhead power lines or

other electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with them might be fatal.

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

8 TV sets are provided with ventilation openings in the cabinet to allow heat generated during

operation to be released.

Therefore:

— Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa,

rug, etc.

— Never place a TV set in a “built-in” enclosure unless proper ventilation is provided. — Never cover the openings with a cloth or other material. — Never place the TV set near or over a radiator or heat register.

9 To avoid personal injury:

— Do not place a TV set on a sloping shelf unless properly secured.

— Use only a cart or stand recommended by the TV set manufacturer. — Do not try to roll a cart with small casters across thresholds or deep pile carpets. — Wall or shelf mounting should follow the manufacturer’s instructions, and should use a

mounting kit approved by the manufacturer.

Use

10 Caution children about dropping or pushing objects into the TV set through cabinet

openings. Some internal parts carry hazardous voltages and contact can result in a fire or electrical shock.

11 Unplug the TV set from the wall outlet before cleaning. Do not use liquid or an aerosol

cleaner.

12 Never add accessories to a TV set that has not been designed for this purpose. Such

additions may result in a hazard.

PORTABLE CART WARNING

(Symbol provided by RETAC)

13 For added protection of the TV set during a lightning storm or when the TV set is to be left

unattended for an extended period of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to product due to lightning storms or power line surges.

14 A TV set and cart combination should be moved with care. Quick stops, excessive force,

and uneven surfaces may cause the TV set and cart combination to overturn.

Service

15 Unplug this TV set from the wall outlet and refer servicing to qualified service personnel

under the following conditions: A. When the power cord or plug is damaged or frayed. B. If liquid has been spilled into the TV set. C. If the TV set has been exposed to rain or water. D. If the TV set does not operate normally by following the operating instructions.

Adjust only those controls that are covered in the operating instructions as improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the TV set to normal operation.

E. If the TV set has been dropped or damaged in any way. F. When the TV set exhibits a distinct change in performance — this indicates a need for

service.

16 Do not attempt to service this TV set yourself as opening or removing covers may

expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

17 When replacement parts are required, have the service technician verify in writing that the

replacement parts he uses have the same safety characteristics as the original parts. Use of manufacturer’s specified replacement parts can prevent fire, shock, or other hazards.

18 Upon completion of any service or repairs to this TV set, please ask the service technician

to perform the safety check described in the manufacturer’s service literature.

19 When a TV set reaches the end of its useful life, improper disposal could result in a picture

tube implosion. Ask a qualified service technician to dispose of the TV set.

20 Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Table of Contents

Quick Setup . . . . . . . . . . . 7

Unpacking your TV . . . . . . . . . . . . 7

TV Models . . . . . . . . . . . . . . . . 8

TV Remote Controls . . . . . . . . . . . 9

Getting Started . . . . . . . . . . . . . 10

The Remote Control . . . . . . . . . . 10

Connecting Your Devices . . . . . . . 11

Interactive Plug In Menu . . . . . . . . 18

Remote Programming . . . . . 21

Setting CATV, VCR and DVD Codes . . . 21

CATV or Satellite Codes . . . . . . . . 21

VCR Codes . . . . . . . . . . . . . . 22

DVD Codes . . . . . . . . . . . . . . 23

Search Codes . . . . . . . . . . . . . 24

Onscreen Menus . . . . . . . . 25

Using the Guide . . . . . . . . . . . . . 25

Onscreen Menu System . . . . . . . . . 26

Initial Setup . . . . . . . . . . 28

Auto Tuner Setup . . . . . . . . . . . . 28

Channel Summary . . . . . . . . . . . . 28

V-Chip . . . . . . . . . . . . . . . . . . 29

Set Lock Code . . . . . . . . . . . . . 35

Adjusting CRT Color Conversion . . . . . 36

Auto Demo . . . . . . . . . . . . . . . 38

Power Indicator . . . . . . . . . . . . . 38

Position Adjustment . . . . . . . . . . . 38

Digital-In . . . . . . . . . . . . . . . . . 39

TV Speaker . . . . . . . . . . . . . . . 39

Audio Out . . . . . . . . . . . . . . . . 40

Center CH Input . . . . . . . . . . . . . 40

Language . . . . . . . . . . . . . . . . 40

Closed Caption . . . . . . . . . . . . . 41

Noise Muting . . . . . . . . . . . . . . 41

Front Panel Lock . . . . . . . . . . . . 42

Auto Shut Off . . . . . . . . . . . . . . 42

XDS ID . . . . . . . . . . . . . . . . . 42

Picture Adjust . . . . . . . . . 43

Picture Settings . . . . . . . . . . . . . 43

Adjust Picture Settings . . . . . . . . . 43

Color Temperature . . . . . . . . . . . . 43

Digital Noise Clear . . . . . . . . . . . . 44

VSM . . . . . . . . . . . . . . . . . . . 44

Reset . . . . . . . . . . . . . . . . . . 44

Sound Adjust . . . . . . . . . 45

Sound Settings . . . . . . . . . . . . . 45

Adjust Sound Settings . . . . . . . . . 45

MTS (Multi-channel Sound) . . . . . . . 45

Clock Timers . . . . . . . . . . 46

Set Clock . . . . . . . . . . . . . . . . 46

On/Off Timer . . . . . . . . . . . . . . . 47

Button Functions . . . . . . . 48

Multi Screen Function . . . . . . . . . . 48

Split . . . . . . . . . . . . . . . . . . . 48

POP . . . . . . . . . . . . . . . . . . . 49

Index . . . . . . . . . . . . . . . . . . 49

EZ-Surf . . . . . . . . . . . . . . . . . 50

Freeze . . . . . . . . . . . . . . . . . . 50

Swap . . . . . . . . . . . . . . . . . 50

Select . . . . . . . . . . . . . . . . . . 50

Power . . . . . . . . . . . . . . . . . . 51

Number Buttons . . . . . . . . . . . . . 51

100+ Button . . . . . . . . . . . . . . . 51

Input . . . . . . . . . . . . . . . . . . . 51

Digital-In . . . . . . . . . . . . . . . . . 51

Return +/TV . . . . . . . . . . . . . . . 52

Sound . . . . . . . . . . . . . . . . . . 52

Muting . . . . . . . . . . . . . . . . . . 52

Video Status . . . . . . . . . . . . . . . 53

Natural Cinema . . . . . . . . . . . . . 53

TheaterPro D6500K . . . . . . . . . . . 53

Sleep Timer . . . . . . . . . . . . . . . 54

Display . . . . . . . . . . . . . . . . . 54

Aspect . . . . . . . . . . . . . . . . . 55

Aspect Ratios . . . . . . . . . . . . . 55

C.C. . . . . . . . . . . . . . . . . . . . 56

Menu . . . . . . . . . . . . . . . . . . 56

OK . . . . . . . . . . . . . . . . . . . 56

Back . . . . . . . . . . . . . . . . . . . 56

TV/CATV Slide Switch . . . . . . . . . . 57

VCR/DVD Slide Switch . . . . . . . . . 57

VCR Buttons . . . . . . . . . . . . . . . 57

DVD Buttons . . . . . . . . . . . . . . . 57

Light . . . . . . . . . . . . . . . . . . . 57

Appendices . . . . . . . . . . 58

Troubleshooting . . . . . . . . . . . . . 58

Warnings . . . . . . . . . . . . . . . . 60

Warranty . . . . . . . . . . . . . . . . . 61

Authorized Service Centers . . . . . . . 63

Specifications . . . . . . . . . . Back Cover

Quick Setup Unpacking your TV

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new television, please check to make sure you have all of the following items. In addition to this guide, your television box should include:

Two AA

1 Television

Once you have unpacked your television, the next step is to connect it to your antenna/ cable or satellite system and to connect the audio/video devices you want to use with your television. To make these connections you will use plugs like the ones illustrated below.

1 Remote Control

Batteries

Note: Your television and/or remote control may differ from the examples illustrated here.

Coaxial Cables

Component Cables

Composite Cables

Audio Cables

Used to connect an external antenna or cable TV system to your TV.

S-Video Cable

Used to make video connections with S-Video VCRs, Camcorders and DVD players.

We recommend that before you start using your new television, you read your entire User’s Guide so you can learn about your new television’s many great features. If you’re anxious to start using your television right away, a quick setup guide follows on the next few pages.

Used to connect audio/video devices like VCRs, DVD players, stereo amplifiers, game consoles, etc.

Quick Setup TV Models

NOTE: Before you connect your television to another device, please refer to the proper

diagrams for your specific TV and remote. These will help assist you in understanding how to connect your television to another device, as well as use the remote to set up your television.

Rear Panel Diagram

MODELS: AV-65WP74 AV-56WP74 AV-48WP74

Front Panel Diagram

MODELS: AV-65WP74, AV-56WP74, AV-48WP74

Quick Setup TV Remote Controls

RM-C1200G

MODELS: AV-65WP74 AV-56WP74 AV-48WP74

• For information on remote control buttons, see pages 48 - 57.

Quick Setup Getting Started

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you need to begin using your new television right away.

If you have questions, or for more detailed information on any of these steps, please consult other sections of this manual.

Step 1 – The Remote Control

Before you can operate your remote control, you first need to install the batteries (included).

Slide the cover on the back of the remote down towards the bottom of the remote control. Insert two batteries (included) carefully noting the “+” and “–” markings, placing the “–” end in the unit first. Slide the cover back into place.

When you change the batteries, try to complete the task within three minutes. If you take longer than three minutes, the remote control codes for your VCR, DVD, and/or cable box/satellite receiver may have to be reset. See pages 21 - 24.

Key Feature Buttons

The four key feature buttons at the center of the remote can be used for basic operation of the television. The top and bottom buttons will scan forward and back through the available channels. To move rapidly through the channels using JVC’s Hyperscan feature, press and hold CH+ or CH–. The channels will zip by at a rate of five channels per second. The right and left buttons will turn the volume up or down. These buttons are also marked with four arrows and are used with JVC’s onscreen menu system. To use the onscreen menus, press the MENU button.

Quick Setup Connections





 

  













Basic Operation

Turn the television on and off by pressing the POWER button at the top right corner of the remote. If this is the first time you are turning on the TV, the interactive plug-in menu appears.

• Make sure the TV/CATV switch is set to TV. Move the switch to CATV only if you need to operate a cable box.

• Slide the VCR/DVD selector switch to VCR to control a VCR. Slide to DVD to control a DVD player. Please see pages 21 to 24 for instructions on programming your remote control to operate a cable box, VCR or DVD player.

Step 2 – Connecting Your Devices

Please follow the flow chart below to determine which connection setup is right for you. Then, refer to the appropriate diagrams to connect your television to other devices that you may have. After you are finished connecting your devices, plug the power cord into the nearest power outlet and turn on the TV.

A VCR is not necessary for operation of the television. If you follow these diagrams and the television does not work properly, contact your local cable operator.

• To connect a DVD player, see Diagram #3. A DVD player is optional.

• If you have a satellite television system, please refer to the satellite TV manual.

Quick Setup Connections

Diagram #1

Note:

• If you do not have a cable box, connect the cable wire from the wall outlet into the back of the TV.

Diagram #2

Notes:

• If your VCR is a mono sound unit, it will have only one audio out jack. Connect it to the LEFT AUDIO INPUT on the front of the TV.

• Use the S-Video connection if possible for superior picture quality.

• Your VCR must be turned on to view premium cable channels.

Quick Setup Connections

Notes:

• Green, blue and red are the most common colors for DVD cables. Some models may vary colors. Please consult the user’s manual for your DVD player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete one set of connections (DVD or audio output) before starting the other to avoid accidentally switching the cables.

• You may also connect the DVD player to Input 1.

Diagram #3

Quick Setup Connections

Connecting to JVC AV Compu Link

JVC’s AV compu link feature makes playing video tapes or DVDs totally automatic. Simply insert a pre-recorded tape into your JVC brand VCR or DVD into your JVC DVD player and the device will automatically turn on and begin playback. At the same time, using the AV compu link, the VCR or DVD player sends a signal to the television telling it to turn on and switch to the proper video input.

• The AV compu link cable may be included with the JVC AV compu link unit you wish to connect. If it is not, contact JVC Parts Department at (800)-882-2345, or www.jvcservice.com for part # EWP 805-012.

• AV Compu Link can only be used with JVC brand products.

AV Compu Link Cable

Notes:

• In order for the VCR playback to begin automatically, the recording tabs must be removed from the VHS tape. If the tab is in place, automatic switching will occur when you push the VCR’s PLAY button.

• If your JVC brand VCR has “A code/B code remote control switching” (see your VCR’s instruction book), using VCR A code will switch the TV to input 1.

• Refer to your DVD instruction book for detailed connection information.

• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see the receiver connection instructions for detailed connection information.

• AV compu link is compatible with select AV compu link receivers.

To Connect: Plug one end of the AV compu link cable into the AV COMPU LINK INPUT on your VCR, DVD, or other compu link device. Plug the other end of the AV compu link cable into the AV COMPU LINK at the rear of the television.

Note:

• The AV compu link cable has a male 3.5 mm (mono) plug on each end.

Quick Setup Connections

Connecting to a Camcorder

You may connect a camcorder, game console or other equipment to your television by using the front input jacks (Input 4) located under the front panel door. To access, pull on the door to open it. You can also connect these using the television’s rear input jacks, using the same instructions.

1) Connect a yellow composite cable from the camcorder VIDEO OUT, into the VIDEO IN on the front of the TV, OR connect an S-Video cable from the front of the TV to the camcorder.

2) Connect a white composite cable from the camcorder LEFT AUDIO OUT, into the LEFT AUDIO IN on the front of the TV.

3) Connect a red composite cable from the camcorder RIGHT AUDIO OUT, into the RIGHT AUDIO IN on the front of the TV.

Note:

• If your camcorder is a mono sound model it will have only one AUDIO OUT. Connect it to

the LEFT AUDIO IN on the front of the TV.

Quick Setup Connections

Connecting to an External Amplifier

Subwoofer Out - Use a powered subwoofer with the surround feature to simulate a home theater system. Simply connect the subwoofer to the back of the TV.

1) Connect a white composite cable from the LEFT AUDIO OUTPUT on the back of the TV to the LEFT AUDIO INPUT on the amplifier.

2) Connect a red composite cable from the RIGHT AUDIO OUTPUT on the back of the TV to the RIGHT AUDIO INPUT on the amplifier.

3) Connect a black composite cable from the SUBWOOFER OUT on the back of the TV to the LINE INPUT of the subwoofer.

Notes:

• Refer to your amplifier’s manual for more information.

• You can use AUDIO OUTPUT for your home theater system.

Connecting to the Surround Amplifier

Note: Please read the benefit of this feature on page 40.

1) Connect the black speaker cable from the TV’s SPEAKER INPUT terminal to the surround amplifier’s CENTER SPEAKER OUTPUT terminal.

2) Connect the red speaker cable from the TV’s SPEAKER INPUT terminal to the surround amplifier’s CENTER SPEAKER OUTPUT terminal.

Quick Setup Connections

Connecting to a Digital TV Receiver w/HDCP

By inputting a high bandwidth digital content protection high definition picture source to the digital-in terminal of this television, high-definition pictures can be displayed on the screen in their digital form. (This terminal is for use in the future when high bandwidth digital content protection DTV decoders and DVD players and D-VHS are put on the market.)

After the connections have been made, tighten the screw to secure the cables.

DTV decoder

1) Connect the DTV DIGITAL RGB OUTPUT TERMINAL to the DIGITAL INPUT TERMINAL of the television, and then tighten the 2 screws.

2) Connect the DTV decoder LEFT AUDIO OUTPUT to the DIGITAL-IN LEFT AUDIO INPUT.

3) Connect the DTV decoder RIGHT AUDIO OUTPUT to the DIGITAL-IN RIGHT AUDIO INPUT.

• The Digital-In terminal can only be used with 1080i, 720p and 480p picture signals. Set

the DTV decode digital-out terminal output setting to 1080i, 720p or 480p. For detailed information, refer to the DTV decoder instruction manual. If you can not display the picture because your DTV decoder does not have a digital-out terminal output setting, use the component video input (or the S-Video input or video input). Refer to page 13. In this case the picture will be displayed as an analog signal.

• The digital-in terminal is not compatible with the picture signal of a personal computer.

• Use a DVI-D single link 19-pin cable (commercially available) in order to digitally connect

the television with a DTV decoder.

If 480p signals (640x480 or 720x480) are displayed on the screen, the horizontal balance may be slightly shifted. In cases such as this, the horizontal balance can be adjusted by accessing “DIGITAL-IN” in the INITIAL SETUP menu. (Refer to page 39.)

Quick Setup Plug-In Menu

Step 3 – The Interactive Plug In Menu

When you turn your television on for the first time the interactive plug-in menu will appear. The plug-in menu helps you to get your TV ready to use by letting you set your preferences for:

• The language in which you want the onscreen menus to appear.

• Setting the TV’s clock to the correct time so your timer functions will work properly. You

can choose “AUTO” or “MANUAL” for setting the clock.

• The auto tuner setup of which channels you wish to receive.

We recommend you complete the interactive plug-in items before you start using your television.

Language

After the “JVC INTERACTIVE PLUG IN MENU” has been displayed, the TV automatically switches to the LANGUAGE settings. You can choose to view your onscreen menus in three languages: English, French (Français) or Spanish (Español).

√®

To choose a language:

(English, Français or Español)

†

To NEXT (To set clock)

(To be continued...)

Quick Setup Plug-In Menu

Auto Clock Set

Before you use any of your TV’s timer functions, you must first set the clock. You may precisely set your clock using the XDS time signal broadcast by most public broadcasting stations. If you do not have this in your area, you will have to set the clock manually. See manual clock set below. To set the clock using the XDS signal:

√®

To choose AUTO

†

To TIME ZONE

√®

To select your time zone: (Atlantic, Eastern, Central, Mountain, Pacific, Alaska or Hawaii)

†

To move to D.S.T. (Daylight Savings Time)

√®

To turn D.S.T. ON or OFF

†

To NEXT (To Auto Tuner Setup)

Notes:

• The Daylight Savings Time feature automatically adjusts your TV’s clock for Daylight Savings. The clock will move forward one hour at 2:00 am on the first Sunday in April. The clock will move back one hour at 2:00 am on the last Sunday in October.

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

Manual Clock Set

To set your clock manually (without using the XDS signal), choose MANUAL. If you choose AUTO, see auto clock set above.

√®

To choose MANUAL

†

√®

†

√®

†

Note:

• You will have to reset the clock after a power interruption. You must set the clock before operating any timer functions.

To TIME

To set the hour

To minute

To set the minute

To Start Clock

(To be continued...)

Quick Setup Plug-In Menu

Auto Tuner Setup

In auto tuner setup, the TV automatically scans through all available channels, memorizing the active ones and skipping over blank ones or channels with weak signals. This means when you scan (using the CHANNEL +/– buttons) you will receive only clear, active channels.

√®

skip Auto Tuner Setup)

†

To choose CABLE or AIR (or SKIP when you

To START

NOW

PROGRAMMING !

Programming will take approximately 1 to 2

When the setup is finished, THANK YOU!! SETUP IS NOW COMPLETE is displayed. Your quick setup is now complete. You can now begin watching your television, or you can continue on in this guide for more information on programming your remote control, or using the JVC onscreen menu system to customize your television viewing experience.

Notes:

• Noise muting will not work during Auto Tuner Setup.

• Skip appears only for interactive plug-in menu.

• The interactive plug-in menu setting does not appear if your TV has been turned on before. In this case, use the menu to perform these settings. See pages 40, 46 and 28.

Cable Box and Satellite Users: After your auto tuner setup is complete, you may, (depending on the type of hookup), have only 1 channel, usually 3 or 4 in the auto tuner memory. This is normal.

minutes.

The Quick Setup is complete

+ 44 hidden pages
