AV-48WP74 AV-56WP74

SERVICE MANUAL

REAR PROJECTION TELEVISION

5210520034

BASIC CHASSIS

AV-48WP74/HA,

SB3

AV-56WP74

/HA

TABLE OF CONTENTS

1 PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5

3 ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21

4 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-64

No.52105

2003/4

AV-48WP74 AV-56WP74

SPECIFICATION

Items

Dimensions (W x H x D) 120.0cm x 124.4cm x 60.9cm

( 47 1/4" x 49" x 24" ) Mass 81kg (179 Ibs) 95kg (209 Ibs) TV RF System

Color System Sound System

TV Receiving Channels and Frequency

VL Band

VH Band

UHF Band

CATV Receiving Channels and Frequency

Low Band

High Band

Mid Band Super Band Hyper Band

Ultra Band

Sub Mid Band TV/CATV Total Channel 180 Channels Antenna Terminal (VHF/UHF) 75ohm unbalanced F-type connector Intermediate Frequency

Video IF Carrier

Sound IF Carrier Color Sub Carrier 3.58MHz Power Input

Power Consumption Screen Transparent screen (unitized fresnel lens/double lenticular lens) Screen Size 48" (122cm) Measured diagonally, 16:9 ratio

Projection Tube High Voltage

Speaker Audio Power Output

External Input

Video Input Audio Input

S-Video

Component Input

Digital Input

Audio Input Subwoofer Output More than 0 to 1000mV (rms) (+2.2dBs) (RCA pin jack x1) Audio Output (VARI/FIX) VARI : More than 0 to 1000mV (rms) (+2.2dBs)

Speaker Input 45W 16ohm (maximum input)

AV Compulink lll Ø3.5mm mini jack Remote Control Unit RM-C1200G (AA/R6/UM-3 battery x 2)

Design & specifications are subject to change without notice.

CCIR (M) NTSC BTSC System (Multi Channel Sound)

(02~06) 54MHz~88MHz (07~13) 174MHz~216MHz (14~69) 470MHz~806MHz

54MHz~804MHz

(02~06, A-8) by (02~06 & 01) (07~13) by (07~13) (A~1) by (14~22) (J~W) by (23~36) (W+1~W+28) by (37~64) (W+29~W+84) by (65~125) (A8, A4~A1) by (01, 96~99)

45.75MHz

41.25MHz (4.5MHz)

120V AC, 60Hz 248W (Max)

(W:106.3 cm x H:59.8 cm) 17cm (6.7") tube x 3 ( R/G/B )

31kV±1.0kV (at zero beam current) 16cm round x 2 (Woofer), 5.5cm round x 2 (Tweeter)

10W+10W

1V (p-p), 75ohm (RCA pin jack x 4) 500mV(rms) ( -4dBs), high impedance (RCA pin jack x 8) Y: 1V (p-p) positive, 75ohm negative sync provided C: 0.286V(p-p) (burst signal) Mini-DIN 4pin connector x 2 Y: 1V (p-p), 75ohm (RCA pin jack x 2) Pb: ±0.35V(p-p), 75ohm (RCA pin jack x 2) Pr: ±0.35V(p-p), 75ohm (RCA pin jack x 2) 1080i DTV (digital broadcast) ready

DVI-D signal link 19pin connector (Digital-input terminal is not compatible with computer signal) 500mV(rms) ( -4dBs), high impedance (RCA pin jack x 2)

FIX : 500mV(rms) (-4dBs), low impedance (1kHz when modulated 100%) (RCA pin jack x 2)

AV-48WP74 AV-56WP74

Contents

136.8cm x 138.6cm x 66.7cm ( 53 7/8" x 54 5/8" x 26 3/8" )

56" (142cm) Measured diagonally, 16:9 ratio (W:124 cm x H:69.8 cm)

1-2 (No.52105)

SECTION 1

PRECAUTIONS

AV-48WP74 AV-56WP74

1.1 SAFETY PRECAUTIONS

(1) The design of this product contains special hardware, many circuits

and components specially for safety purposes. For continued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Service should be performed by qualified personnel only.

(2) Alterations of the design or circuitry of the products should not be

made. Any design alterations or additions will void the manufacturer's warranty and will further relieve the manufacturer of responsibility for personal injury or property damage resulting therefrom.

(3) Many electrical and mechanical parts in the products have special

safety-related characteristics. These characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by using replacement components rated for higher voltage, wattage, etc. Replacement parts that have these special safety characteristics are identified in the parts list of Service manual. Electrical components having such features are

identified by shading on the schematics and by ( ) on the parts list in Service manual. The use of a substitute replacement which

does not have the same safety characteristics as the recommended replacement part shown in the parts list of Service manual may cause shock, fire, or other hazards.

(4) Use isolation transformer when hot chassis.

The chassis and any sub-chassis contained in some products are connected to one side of the AC power line. An isolation transformer of adequate capacity should be inserted between the product and the AC power supply point while performing any service on some products when the HOT chassis is exposed.

(5) Don't short between the LIVE side ground and ISOLATED

(NEUTRAL) side ground or EARTH side ground when repairing.

Some model's power circuit is partly different in the GND. The difference of the GND is shown by the LIVE : ( ) side GND, the ISOLATED(NEUTRAL) : ( ) side GND and EARTH : ( ) side GND. Don't short between the LIVE side GND and ISOLATED(NEUTRAL) side GND or EARTH side GND and never measure with a measuring apparatus (oscilloscope etc.) the LIVE side GND and ISOLATED(NEUTRAL) side GND or EARTH side GND at the same time. If above note will not be kept, a fuse or any parts will be broken.

(6) The high voltage applied to the picture tube must conform with that

specified in Service manual. Excessive high voltage can cause an increase in X-Ray emission, arcing and possible component damage, therefore operation under excessive high voltage conditions should be kept to a minimum, or should be prevented. If severe arcing occurs, remove the AC power immediately and determine the cause by visual inspection (incorrect installation, cracked or melted high voltage harness, poor soldering, etc.). To maintain the proper minimum level of soft X-Ray emission, components in the high voltage circuitry including the picture tube must be the exact replacements or alternatives approved by the manufacturer of the complete product.

(7) If any repair has been made to the chassis, it is recommended that

the B1 setting should be checked or adjusted (See ADJUSTMENT OF B1 POWER SUPPLY).

(8) Do not check high voltage by drawing an arc. Use a high voltage

meter or a high voltage probe with a VTVM. Discharge the picture tube before attempting meter connection, by connecting a clip lead to the ground frame and connecting the other end of the lead through a 10kΩ 2W resistor to the anode button.

(9) When service is required, observe the original lead dress. Extra

precaution should be given to assure correct lead dress in the high voltage circuit area. Where a short circuit has occurred, those components that indicate evidence of overheating should be replaced. Always use the manufacturer's replacement components.

(10) Isolation Check

(Safety for Electrical Shock Hazard)After re-assembling the product, always perform an isolation check on the exposed metal parts of the cabinet (antenna terminals, video/audio input and output terminals, Control knobs, metal cabinet, screwheads, earphone jack, control shafts, etc.) to be sure the product is safe to operate without danger of electrical shock.

a) Dielectric Strength Test

The isolation between the AC primary circuit and all metal parts exposed to the user, particularly any exposed metal part having a return path to the chassis should withstand a voltage of 1100V AC (r.m.s.) for a period of one second.

(. . . . Withstand a voltage of 1100V AC (r.m.s.) to an appliance

rated up to 120V, and 3000V AC (r.m.s.) to an appliance rated 200V or more, for a period of one second.) This method of test requires test equipment not generally found in the service trade.

b) Leakage Current Check

Plug the AC line cord directly into the AC outlet (do not use a line isolation transformer during this check.). Using a "Leakage Current Tester", measure the leakage current from each exposed metal part of the cabinet, particularly any exposed metal part having a return path to the chassis, to a known good earth ground (water pipe, etc.). Any leakage current must not exceed 0.5mA AC (r.m.s.). However, in tropical area, this must not exceed 0.2mA AC (r.m.s).

• Alternate Check Method Plug the AC line cord directly into the AC outlet (do not use a line isolation transformer during this check.). Use an AC voltmeter having 1000 ohms per volt or more sensitivity in the following manner. Connect a 1500ohm 10W resistor paralleled by a 0.15µF AC-type capacitor between an exposed metal part and a known good earth ground (water pipe, etc.). Measure the AC voltage across the resistor with the AC voltmeter. Move the resistor connection to each exposed metal part, particularly any exposed metal part having a return path to the chassis, and measure the AC voltage across the resistor. Now, reverse the plug in the AC outlet and repeat each measurement. Any voltage measured must not exceed 0.75V AC (r.m.s.). This corresponds to 0.5mA AC (r.m.s.). However, in tropical area, this must not exceed 0.3V AC (r.m.s.). This corresponds to 0.2mA AC (r.m.s.).

AC VOLTMETER (HAVING 1000 /V, OR MORE SENSITIVITY)

0.15 F AC-TYPE

PLACE THIS PROBE

GOOD EARTH GROUND

1500 10W

ON EACH EXPOSED ME TAL PART

(11) High voltage hold down circuit check.

After repair of the high voltage hold down circuit, this circuit shall be checked to operate correctly. See item "How to check the high voltage hold down circuit".

This mark shows a fast operating fuse, the letters indicated below show the rating.

A V

POWER CORD REPLACEMENT WARNING.

Connecting the white line side of power cord to "WHT" character side.

PWB

White line side

WHT

(No.52105)1-3

AV-48WP74 AV-56WP74

1.2 INSTALLATION

1.2.1 INSTALLATION SITE

(1) The rear of this set is provided with ventilation openings.

Install the set more than 5 cm from a wall and in a location with good ventilation.

(2) Avoid the following types of locations.

a) Unstable locations (location must be able to

withstand heavy weight). b) Locations subjected to direct sunlight. c) Near stoves or other heating devices. d) Locations subjected to humidity or oily smoke. e) Dusty locations.

f) Locations with strong vibration.

1.2.2 INSTALLATION ADJUSTMENT

When installing, moving or changing the orientation of the set, perform static convergence adjustment according to the following procedure. Adjusting CRT color convergence have two method, AUTO, MANUAL and RESET. It adjust on the MENU screen.

NOTE :

Please have you TV on for at least 20 minutes before sing this feature. This adjustment will be needed only when the colors of the characters/lines are separated and lack in distinction. If not, please don

AUTO

(1) Press the [MENU] key, and select the

(2) Press the [function left/right] key, then CONVERGENCE

(3) Press the [function up/down] key, and select the

(4) Press the [function left/right] key. (5) he convergence adjustment will start. It will take about 50

MANUAL

(1) Press the [MENU] key, and select the

(2) Press the [function left/right] key, the CONVERGENCE

(3) Press the [function up/down] key, and select the

(4) Press the [function left/right] key, then CONVERGENCE

(5) Select the location you want to adjust by using the

(6) Press the [SELECT] key to change the color of the box

(7) Use the [function up/down] key and the [function left/

(8) Adjust the three colors crosses until they overlap and

(9) Press the [OK] key.

't perform the adjustment.

"CONVERGENCE" in the INITIAL SETUP menu with the [function up/down] key.

menu appear.

"AUTO".

seconds.

"CONVERGENCE" in the INITIAL SETUP menu with [function up/down] key.

menu appears.

"MANUAL".

adjustment screen appear. [Fig.1]

• If all the crosses are white, no convergence adjustment is needed.

[number (2/4/5/6/8)] keys on the remote control unit. [Fig.2]

to the color of the cross you want to adjust (red or blue).

• You cannot adjust the green cross.

right] keys to adjust the position of the cross.

appear as a single white cross.

(more than 5cm)

Wall

VENTILATION OPENING

NOTE :

• When you adjust the convergence, make sure you start with the center position (position 5), and work your way around radial for best results

• When you make the adjustment in the center (positions 5), you are making the adjustment for the whale screen. In other positions, you are making the adjustment only in that area.

• You can reset the adjustment if you do not like the results, See below.

• If you perform AUTO CONVERGENCE after performing MANUAL CONVERGENCE, your manual convergence you performed will be cancelled.

(10) Press the [MENU] key to end the convergence

adjustment procedure.

RESET

RESET in the CONVERGENCE menu resets all convergence adjustments to the factory default setting.

Fig.1

Fig.2

1-4 (No.52105)

AV-48WP74

S-VIDEO

VIDEO

OPERATE

/ MONO

SUPER FOCUS

AV-56WP74

SECTION 2

SPECIFIC SERVICE INSTRUCTIONS

2.1 FEATURES

• New chassis design enable use of an interactive on screen control.

• 2-3 PULL DOWN : You can enjoy DVD movies at the highest picture quality.

• MOTION COMPENSATION : With this function, the seamless reproduction of dynamic motion on the screen has been realized.

• Bullet-in DSD (Digital Supper Detail) circuit and 3 dimension Y/C separate circuit.

• Receive DTV broadcast (1080i / 720p / 480p / 480i)

• Built-in HDCP / Component (Y / Pb / Pr) input.

• Built-in Hyper Sound, BBE circuit.

2.2 FUNCTIONS

FRONT CONTROL KEY & TERMINAL

MENU Button ( OPERATE )

SUPER

FOCUS

OPERATE

CHANNERL -/+ Button ( OPERATE / )

VOLUME -/+ Button

MAIN POWER Button

POWER LED (Blue)

INPUT4 ( AUDIO / VIDEO / S-VIDEO )

REAR TERMINAL

SPEAKER INPUT 16 45W MAX

OUT

S-VIDEO

AUDIO OUTSUBWOOFER

INPUT-3

INPUT-2

INPUT-1

AV COMPULINK

AUDIO

VIDEO

VIDEO S-VIDEO

OVER

INPUT4

L / MONO

COMPONENT VIDEO

INPUT-2

INPUT-1

DIGITAL IN

DIGITAL IN ( DVI-D Signal Link 19pin )

INPUT 1 ( AUDIO / VIDEO / S-VIDEO )

INPUT 2 ( AUDIO / VIDEO / S-VIDEO )

INPUT 3 ( AUDIO / VIDEO )

COMPONENT VIDEO INPUT 1 ( Y / Pb / Pr )

COMPONENT VIDEO INPUT 2 ( Y / Pb / Pr )

SPEAKER INPUT

SUBWOOFER / AUDIO OUT

AV COMPULINK

AUDIO INPUT (For DIGITAL IN)

AUDIO

(No.52105)1-5

AV-48WP74 AV-56WP74

REMOTE CONTROL UNIT [RM-C1200G]

VCR

CATV

SPLIT

FREEZE

DVD

ASPECT

MULTI SCREEN

POP

INDEX

SWAP

SELECT

POWER Key

ASPECT Key

POWER

EZ SURF

VCR / DVD Switch

TV / CATV Switch

Input select Keys

INPUT1

INPUT2

INPUT3

INPUT4

DIGITAL-IN

SLEEP TIMER

100+

THEATER

PRO

DISPLAY

NATURAL

CINEMA

SOUND

MUTING

VOL

VCR CHANNEL

PREV NEXT

PLAY FFREW

VCR/DVD

POWER

VOL

RETURN+ /TV

VIDEO

STATUS

LIGHT

C.C.

BACK

TV/VCR

STOP

PAUSE

STILL/PAUSE

REC

OPEN/CLOSE

THEATER PRO Key

SLEEP TIMER Key

DISPLAY Key

MUTING Key (memory Key)

Function up / down / right / left Keys (CH + / CH - / VOL + / VOL - Keys)

MENU Key

MULTI SCREEN operation Keys

Number (1~0)Keys

100+ Key

RETURN+ / TV Key

VIDEO STATUS Key

NATURAL CINEMA Key

LIGHT Key

SOUND Key

C.C.(Closed Caption) Key

1-6 (No.52105)

RM-C1200G

OK Key

BACK Key

VCR / DVD operation Keys

DIGITAL-IN TERMINAL FUNCTIONS

AV-48WP74 AV-56WP74

Pin name

No.

1 RX2-

2 RX2+

3 GND2/ 4

4 RX4-

5 RX4+

6 SCL

7 SDA

8NC

9 RX1-

10 RX1+

11 GND1/3

12 RX3-

Pin name

No.

13 RX3+

14 5V

15 GND

16 HTPLG

17 RX0-

18 RX0+

19 GND0/5

20 RX5-

21 RX5+

22 GNDC

23 TXC+

24 TXC-

PIN ASSIGNMENT

(No.52105)1-7

AV-48WP74 AV-56WP74

2.3 TECHNICAL INFORMATION

2.3.1 MAIN MICRO COMPUTER (CPU) FUNCTION (MN102H75K)

Pin No. Pin name I/O Function

1 NC - --------

2 /MICON_V I V.sync for OSD

3 LB_PRO I Low B protection detection

4 NC - --------

5 /RST I Main cpu reset input

6 NC - --------

7 /TEST I +3.3V

8 OSD_YS O OSD Ys output

9 NC - --------

10 NC - --------

11 A_MU O Audio muting

12 /MICON_H I H sync input

13 M_MU O Monitor sound out muting

14 P46,OSDXI - Keep for OSD

15 P45,OSDXO - Keep for OSD

16 SDA2 I/O I

C bus (CLK) for MTS

17 AC_IN I AC (60Hz) input

18 SCL2 O I

C bus (DATA) for MTS

19 TU_POW O Tuner power control

20 VCOI I LPF input

21 PDO O LPF output

22 /IP_RESET O Reset

23 OSD_YM O OSD YM output

24 OSD_B O OSD blue output

25 POWER_LED O Lighting for POWER LED

26 OSD_G O OSD green output

27 OSD_R O OSD red output

28 VREF I --------

29 IP_ERR I AMDP program load detect.

30 IREF I --------

31 COMP I --------

32 AVDD I +3.3V

33 CLL I For sub CCD

34 VREFLS I STD VOL for sub CCD

35 SUB_CCD I For sub CCD

36 NC - --------

37 VSS I GND

38 MAIN_CCD I For main CCD

39 VREFHS I STD VOL for main CCD

40 CLH I For main CCD

41 VDD/VPP O +3.3V

42 CLK SW1 O IP clock switch

Pin No. Pin name I/O Function

43 CLK SW2 O IP clock switch

44 ON_TIM O Lighting for ON TIMER

45 CONVER_RXD O Convergence control

46 CONVER TXD I Convergence control

47 SBT1 I --------

48 NC - --------

49 NC - --------

50 NC - --------

51 NC - --------

52 EE_ABL O ACL control

53 CHROMA O Chroma / gamma control

54 DC_COTL O DC, control

55 NC - --------

56 NC - --------

57 TU2_AID I Main AFC input

58 /LOB_POW O Low B power control

59 COMPULINK I AV COMPULINK lll input

60 /POWERGOOD I Power condition check

61 MECA_ON I Machine SW interrupt

62 /MAIN_POW O Main power control

63 NC - --------

64 /B1 POW O B1 power control

65 C/N I AFC voltage input

66 X_RAY I X-ray protection detection

67 NC - --------

68 KEY2 I Front key input 2

69 KEY1 I Front key input 1

70 SCL1 O I

71 SDA1 I/O I

C bus (CLK) for EEP-ROM

C bus (SDA) for EEP-ROM

72 REMO I Remote control input

73 NC - --------

74 VSS I GND

75 OSC2 O 4MHz clock oscillation

76 OSC1 I 4MHz clock oscillation

77 VDD I +3.3V

78 SCL0 O I

C bus (CLK) for general

79 AP_CLK - --------

80 SDA0 I/O I

C bus (SDA) for general

81 NC - --------

82 NC - --------

83 NC - --------

84 P_MU O Picture muting

1-8 (No.52105)

2.4 MAIN PARTS LOCATION

2.4.1 PWB ASS'Y ARRANGEMENT

The PWB ASS'Y is indicated below.

PWB ASS’Y NAME AV-48WP74 AV-56WP74

MAIN PWB ASS'Y SSB-1070A-M2 SSB-1069A-M2

RECEIVER PWB ASS'Y SSB0R368A-M2 SSB0R368A-M2

MI-COM & DIST MODULE PWB ASS'Y SSB0D070A-M2 SSB0D069A-M2

POWER & DEF PWB ASS'Y SSB-2070A-M2 SSB-2069A-M2

DEF OSC PWB ASS'Y SSB0H068A-M2 SSB0H068A-M2

LINE FILTER PWB ASS'Y SSB-9068A-M2 SSB-9068A-M2

FRONT RELAY PWB ASS'Y SSB0L268A-M2 SSB0L268A-M2

CONVERGENCE OUT PWB ASS'Y SSB-5068A-M2 SSB-5068A-M2

DIGITAL CONVERGENCE MODULE PWB ASS'Y SSB0K070A-M2 SSB0K069A-M2

DIGITAL INPUT MODULE PWB ASS'Y -------- --------

REMOCON SENSOR PWB ASS'Y SSB-8068A-M2 SSB-8068A-M2

R CRT SOCKET PWB ASS'Y SSB-3168A-M2 SSB-3168A-M2

G CRT SOCKET PWB ASS'Y SSB-3268A-M2 SSB-3268A-M2

B CRT SOCKET PWB ASS'Y SSB-3368A-M2 SSB-3368A-M2

G VM PWB ASS'Y SSB-7268A-M2 SSB-7268A-M2

FRONT CONTROL PWB ASS'Y SSB0L068A-M2 SSB0L068A-M2

AV-48WP74 AV-56WP74

FRONT CONTROL ASS'Y PROJECTION UNIT

FRONT CONTROL PWB

DIGITAL CONVERGENCE MODULE PWB

CRT SOCKET PWB (R/G/B)VMPWB (G only)

REMOCON SENSOR PWB

DEF OSC PWB

DIGITAL INPUT MODULE PWB

CONVERGENCE OUT PWB

FRONT RELAY PWB

MI-COM & DIST MODULE PWB

LINE FILTER PWB

MAIN PWB

RECEIVER PWB

POWER & DEF PWB

AV TERMANEL BOARD

(This figure is only MAIN UNIT)

(No.52105)1-9

AV-48WP74 AV-56WP74

2.5 SCREEN HANDLING CAUTIONS

2.5.1 SCREEN STORAGE Store the SCREEN ASS'Y in a standing position in order to avoid deformation. If the screen is stored horizontally, there is risk of

deforming the screen face. When necessary to place the SCREEN ASS'Y horizontally, position the screen side upwards and sure to place spacers between the screen and resting site (floor or stand etc.) to prevent the screen from sagging.

2.5.2 SCREEN SURFACE

Since the screen surface is easily scratched or soiled, use ample care when handling.

DISASSEMBLY PROCEDURE

If the screen or screen panel need to

FRONT CABINET

be replaced, remove the 24 screws A.

SCREEN BRACKET

(TOP)

SCREEN BRACKET

(RIGHT)

SENSOR

A( x 7)

Leave the screen with protector fresnel lens and double lenticular lens attached. If cannot be disassembled further.

SCREEN

SENSOR

SCREEN BRACKET

(LEFT)

A( x 5)

A( x 7)

A( x 5)

SENSOR

SCREEN BRACKET

(BOTTOM)

2.6 PROJECTION UNIT REPLACEMENT

2.6.1 ADJUSTMENT DURING REPLACEMENT

When replacing the three R, G and B projection units, first replace the R and B units and perform focus / screen / raster centering adjustments with reference to the G unit. Then replace the G unit and perform G focus / screen / convergence adjustment. Finally perform R & B convergence adjustments. Use care to simultaneously removes all three-projection units.

2.6.2 DISASSEMBLY CAUTION

The projection units include locations that are not to be disassembled during service. When replacing projection unit parts, disassemble to the state indicated in the figure below. The figure indicates screws and wires that are not to be removed. Use care not to remove these.

Deflection yoke wires : to connector on POWER & DEF. PWB ASS'Y. [R="RHV", G="GHV", B="BHV"] Convergence yoke wires : to connector on CONVERGENCE PWB ASS'Y. [R="R", G="G", B="B"]

LENS ASS'Y SCREW ( x 4)

1-10 (No.52105)

Check that tape is applied to the CRT neck. If absent, the deflection yoke can dislodge.

Do not remove screws

LENS ASS'Y

R CRT SOCKET PWB ASS'Y G CRT SOCKET PWB ASS'Y B CRT SOCKET PWB ASS'Y

PC MAGNET

PC MAGNET TAPE

VM PWB (G only)

ANODE wires : to DIVIDER

DEF. / CONVER. YOKE

CRT ASS'Y (COUPLER ASS'Y)

Do not disassembly

2.7 DISASSEMBLY PROCEDURE

• Make sure that the power cord is pulled out from the AC outlet.

2.7.1 SPEAKER GRILLE

(1) Remove 4 screws [ A ] from rear side. (2) Open the door of the FRONT CONTROL BOX and remove

2 screws [ B ] from front side.

(3) Take out the SPEAKER GRILLE.

2.7.2 SPEAKER (WOOFER)

• Take out the SPEAKER GRILLE (1) Remove 4 screws [ C ]. (2) Take out the WOOFER. (3) Disconnect the speaker wire from speaker terminal.

*Remove the both side speaker same manner.

2.7.3 SPEAKER (TWEETER)

• Take out the SPEAKER GRILLE (1) Remove 2 screws [ D ]. (2) Take out the TWEETER. (3) Disconnect the speaker wire from speaker terminal.

*Remove the both side speaker same manner.

2.7.4 FRONT BOARD

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ E ]. (2) Take out the FRONT BOARD.

2.7.5 FRONT CONTROL BOX

• Take out the SPEAKER GRILLE. (1) Remove 4 screws [ F ] attaching the FRONT CONTROL

BOX.

(2) Disconnect the connector [BH], [R], [BG] on the FRONT

CONTROL PWB.

(3) Take out the FRONT CONTROL BOX.

2.7.6 FRONT CONTROL PWB

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove 3 screws [ G ] from rear side of FRONT

CONTROL BOX.

(2) Take out the FRONT CONTROL PWB.

SPEAKER WIRE

SPEAKER

(WOOFER)

SPEAKER

(TWEETER)

BH BGR

FRONT CONTROL BOX

REAR SIDE

AV-48WP74 AV-56WP74

FRONT CONTROL

BOX

FRONT BOARD

SPEAKER GRILL

Fig.1

FRONT CONTROL PWB

Fig.2

CAUTION AT DISASSEMBLY

48WP74CP-S : DIGITAL INPUT MODULE [AV-48WP74] 56WP74CP-S : DIGITAL INPUT MODULE [AV-56WP74]

AV JACK BOARD

POWER CORD

SB connector

Prior to disassembly, unplug the power code from the AC outlet

without fail. (Turn the power "off".)

Short the SB connector [1] pin and [2] pin of the DIGITAL INPUT

MODULE. (At the time of assembling)

Before the rear panel is inserted into the cabinet, release the

short-circuit between the SB connector [1] pin and [2] pin of the

DIGITAL INPUT MODULE.

After releasing the short-circuit between the SB connectors, do

not turn the power on until the rear panel is inserted into the

cabinet.

Negligence in carrying out the above steps may cause the

inactivation of the TV.

(No.52105)1-11

AV-48WP74 AV-56WP74

2.7.7 SCREEN ASS'Y

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX. (1) Remove the 2 screws [ H ] under the SCREEN ASS'Y from

front side. (2) Remove 10 screws [ I ] from rear side. (3) Take out the connector [ CN00Z ]. (4) Take out the SCREEN ASS'Y.

NOTE :

• Please place the SCREEN ASS'Y on a flat table without fail.

• Because of the large size, at least two parsons are recommended for removal and reassemble.

• Use core not to scratch the screen during work.

• During assembly, be sure to engage the left and right tabs with the cabinet mounting positions.

• When supporting the SCREEN ASS'Y, grasp the both sides of the screen panel instead of the upper side of the screen panel.

2.7.8 MIRROR

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 2 screws [ J ] attaching the mirror stopper. (2) Raise slightly to disengage of the mirror from the hooks. (3) Take out the MIRROR.

NOTE :

• The MIRROR is front-coated. Do not touch the front of the MIRROR.

• At least 2 persons are recommended for removable and reassemble.

SCREEN ASS'Y

CN00Z

Fig.3

MIRROR

MIRROR STOPPER

Fig.4

1-12 (No.52105)

2.7.9 REAR PANEL

(1) Loosen 7 screws [ K ]. (2) Remove 4 screws [ L ]. (3) Raise slightly REAR PANEL upward. (4) Take out the REAR PANEL.

NOTE :

• Before the rear panel is inserted into the cabinet, release the short-circuit between the [SB] connector (1) pin and (2) pin of the DIGITAL INPUT UNIT. (Refer to "CAUTION AT DISASSEMBLY" on Page 11).

• After releasing the short-circuit between the [SB] connectors, do not turn the power on until the rear panel is inserted into the cabinet.

Prior to starting the work, be sure to read the following written instructions on the CAUTION LABEL attached to the REAR PANEL.

UNPLUG THE POWER CORD FROM AC OUTLET BEFORE OPEN THE REAR COVER (PANEL). When the rear cover (panel) is removed, follow "CAUTION AT DISASSEMBLY" procedure in the service manual before plugging the TV's power cord into an AC outlet. Failure to follow the procedure will result in PERMANENT damage to some of the television features.

PARTITION

AV-48WP74 AV-56WP74

REAR PANEL

Fig.5

2.7.10 PARTITION

• Take out the REAR PANEL. (1) Pull out the PARTITION back ward.

2.7.11 REAR COVER

• Take out the SPEAKER GRILLE.

• Take out the FRONT CONTROL BOX.

• Take out the SCREEN ASS'Y. (1) Remove 2 screws [ M ]. (Fig.5) (2) Remove 2 screws [ N ] from front side. (3) Slightly pull for backside to disengage of the REAR

COVER from hooks.

(4) Take out the REAR COVER.

• Because of the large size, at least two persons are recommended for removal and reassemble.

REAR COVER

BRACKET

Fig.6

(No.52105)1-13

AV-48WP74 AV-56WP74

2.7.12 MAIN UNIT

• Take out the SPEAKER GRILLE.

• Take out the connector [BH], [R], [BG] on the FRONT CONTROL PWB.

• Take out the REAR PANEL. (1) Remove 4 screws [ O ] from front side. (2) Remove 1 screw [ P ] and 3 screws [ Q ] attaching the

MAIN CHASSIS and BODY.

(3) Pull out the MAIN UNIT rear side.

NOTE :

• Except for confirmation of projection of images on the screen and audio output through the speakers, the removed MAIN UNIT is still workable in the same state as if it is still built in the TV set. Therefore, the MAIN UNIT can be removed, if necessary, for board diagnosis, electric testing, etc. apart from confirmation of screen images and audio output.

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

• Because of the large size, at least two persons are recommended for removal and reassemble.

• When carrying the MAIN UNIT, use care not to drop, shock or shake it.

• Do not stain or damage the lens of the PROJECTION UNIT.

• Do not look through the PROJECTION UNIT.

2.7.12.1 CHECKING THE P.W. BOARD

When checking the MAIN PWB, POWER & DEF PWB, etc., raise the MAIN UNIT with the HV DIVIDER side down for the sake of convenience. You can checking the POWER & DEF PWB and CONVERGENCE OUT PWB.

REAR SIDE

MAIN UNIT

BODY

Fig.7

2.7.13 LINE FILTER PWB

• Take out the REAR PANEL.

• Take out the AV TERMINAL BOARD. (Refer to next page) (1) Disconnect the connector [B], [F] on the LINE FILTER

PWB.

(2) Remove 3 screws [ R ] attaching the LINE FILTER

BRACKET and earth wire. (3) Remove 3 screws [ S ] attaching LINE FILTER PWB. (4) Take out the LINE FILTER PWB.

LINE FILTER BRACKET

LINE FILTER PWB

LINE FILTER BRACKET

Fig.8

1-14 (No.52105)

2.7.14 AV TERMINAL BOARD

• Take out the REAR PANEL (1) Remove 9 screws [ T ]. (2) Remove 1 screws [ U ]. (3) Pull out the POWER CORD CLAMP from AV TERMINAL

BOARD left side. (4) Remove the nut [ V ] attaching the ANTENNA TERMINAL. (5) Take out the AV TERMINAL BOARD.

2.7.15 DIGITAL INPUT MODULE

• Take out the REAR PANEL (1) Remove 2 screws [ W ] from rear side of the AV TERMINAL

BOARD.

(2) Take out the DIGITAL INPUT MODULE.

NOTE :

• When removing the DIGITAL INPUT MODULE, refer to the "CAUTION AT DISASSEMBLY" section on page 11.

DIGITAL INPUT

MODULE

ANTENNA TERMINAL

POWER CORD

CLAMP

AV-48WP74 AV-56WP74

AV TERMINAL

BOARD

POWER CORD

Fig.9

2.7.16 MAIN CHASSIS

• Take out the REAR PANEL.

• Take out the AV TERMINAL BOARD.

• Take out the LINE FILTER BRACKET. (1) Remove 2 screws [ X ] both side of the MAIN CHASSIS. (2) Remove 1 screws [ Y ] attaching the earth wire. (3) Remove 1 screw [ P ] attaching the MAIN CHASSIS and

BODY.(Fig.7)

(4) Pull out the MAIN CHASSIS for back side.

NOTE :

• If necessary, remove the anode wires, connectors, respectively.

EARTH WIRE

MAIN CHASSIS

X Y

Fig.10

(No.52105)1-15

AV-48WP74 AV-56WP74

2.7.17 PROJECTION UNIT

• Take out the SPEAKER GRILLE

• Take out the FRONT CONTROL BOX

• Take out the REAR PANEL

• Take out the MAIN UNIT. (1) Take out the CRT SOCKET PWB. (2) Remove 4 screws [ Z ] attaching the PROJECTION UNIT. (3) Pull out the PROJECTION UNIT, upward.

NOTE :

• Refer to "PROJECTION UNIT REPLACEMENT" on page 10 when taking out and replacing the PROJECTION UNIT.

• When wire clamps are removed during work, use care to restore them precisely to their original positions. Performance can be affected if these are not returned to the original positions.

2.7.18 HV DIVIDER

• Take out the REAR PANEL (1) Remove 1 screws [ a ] attaching the HV DIVIDER. (2) Take out the HV DIVIDER.

Wires of the transformer (FBT) and CRT of each PROJECTION UNIT can be removed by turning the connector portions.

NOTE :

• If necessary, remove the anode wires, and replacing the HV DIVIDER, take care to correctly engage the [ b ] connector.

2.7.19 REMOCON SENSOR PWB

• Take out the REAR PANEL (1) Remove 1 screws [ c ] attaching the REMOCON SENSOR

PWB.

(2) Take out the REMOCON SENSOR PWB.

PROJECTION UNIT

REMOCON

SENSOR PWB

HV DIVIDER

Turn

Pull

Fig.11

1-16 (No.52105)

2.8 REPLACEMENT OF CHIP COMPONENT

2.8.1 CAUTIONS

(1) Avoid heating for more than 3 seconds. (2) Do not rub the electrodes and the resist parts of the pattern. (3) When removing a chip part, melt the solder adequately. (4) Do not reuse a chip part after removing it.

2.8.2 SOLDERING IRON

(1) Use a high insulation soldering iron with a thin pointed end of it. (2) A 30w soldering iron is recommended for easily removing parts.

2.8.3 REPLACEMENT STEPS

1. How to remove Chip parts [Resistors, capacitors, etc.]

(1) As shown in the figure, push the part with tweezers and

alternately melt the solder at each end.

AV-48WP74 AV-56WP74

2. How to install Chip parts [Resistors, capacitors, etc.]

(1) Apply solder to the pattern as indicated in the figure.

(2) Shift with the tweezers and remove the chip part.

[Transistors, diodes, variable resistors, etc.]

(1) Apply extra solder to each lead.

SOLDER

(2) As shown in the figure, push the part with tweezers and

alternately melt the solder at each lead. Shift and remove the chip part.

(2) Grasp the chip part with tweezers and place it on the

solder. Then heat and melt the solder at both ends of the chip part.

[Transistors, diodes, variable resistors, etc.]

(1) Apply solder to the pattern as indicated in the figure. (2) Grasp the chip part with tweezers and place it on the

solder.

(3) First solder lead A as indicated in the figure.

(4) Then solder leads B and C.

Note :

After removing the part, remove remaining solder from the pattern.

(No.52105)1-17

AV-48WP74 AV-56WP74

2.9 MEMORY IC REPLACEMENT

2.9.1 MEMORY IC

This memory IC stores data for proper operation of the video and deflection circuits. When replacing, be sure to use an IC containing this (initial value) data.

2.9.2 MEMORY IC REPLACEMENT PROCEDURE

(1) Power off

Switch off the power and disconnect the power cord from the wall outlet.

(2) Replace the memory IC

Initial value must be entered into the new IC.

(3) Power on

Connect the power cord to the wall outlet and switch on the power.

(4) SERVICE MENU setting

a) Press [SLEEP TIMER] key and, while the indication of

SLEEP TIMER 0 MIN is being displayed, press [DISPLAY] key and [VIDEO STATUS] key on the

remote control unit (Fig.2) simultaneously. b) The SERVICE MENU screen of Fig.1 is displayed. c) Verify what to set in the SERVICE MENU, and set

whatever is necessary (Fig.1).

Refer to the SERVICE ADJUSTMENT for setting.

d) Press the [BACK] key twice to return normal screen.

(5) Receive channel setting

Refer to the OPERATING INSTRUCTIONS (USER'S GUIDE) and set the receive channels (Channels Preset) as described.

(6) User settings

Check the user setting items according to after page. Where these do not agree, refer to the OPERATING INSTRUCTIONS (USER'S GUIDE) and set the items as described.

DISPLAY

SLEEP TIMER

MEMORY (MUTING)

FUNCTION (LEFT)

SERVICE MENU

1.PICTURE/SOUND

2.YC SEP

3.WHITE BALANCE

4.MEMORY SETUP

5.RF AFC

6.CONVER A

7.CONVER BD

8.PP

9.IP

0.GCR

Fig.1

SERVICE MENU SELECT KEY

VCR

DVD

CATV

SPLIT

FREEZE

INPUT1

INPUT2

INPUT3

INPUT4

DIGITAL-IN

SLEEP TIMER

MUTING

VCR CHANNEL

PREV NEXT

REC

OPEN/CLOSE

MULTI SCREEN

POP

SWAP

100+

THEATER

PRO

DISPLAY

VOL

RM-C1200G

PLAY FFREW

STOP

ASPECT

INDEX

SELECT

NATURAL

CINEMA

SOUND

VCR/DVD

POWER

EZ SURF

RETURN+ /TV

VIDEO

STATUS

LIGHT

C.C.

VOL

BACK

TV/VCR

PAUSE

STILL/PAUSE

POWER

NUMBER

VIDEO STATUS

FUNCTION (UP)

FUNCTION (RIGHT)

BACK

FUNCTION (DOWN)

Fig.2

2.9.3 SERVICE ADJUSTMENT ITEM

Setting item Item No. Remark Setting item Item No. Remark

1.PICTURE / SOUND 7.CONVER B AUDIO A01~A27 Convergence adjustment -----VIDEO S01~S99 8.PP DEFLECTION D01~D32 Multi-picture adjustment and FACTORY setting F01~F70 PPA001~PPA008 Do not adjust

setting

ADM001~ADM034 Do not adjust

2.YC SEP PPB001~PPB036 Do not adjust YC separation setting YCM001~YCM185 Do not adjust PPC001~PPC008 Do not adjust

YCS001~YCS114 Do not adjust PPD001~PPD025 Do not adjust

3.WHITE BALANCE 9.IP LOW LIGHT / HIGH LIGHT adjustment

BR, DRV R, DRV B,

CWT R, CWT G,

DIST process setting IPA001~IPA120 Do not adjust

CWT B

4.MEMORY SETUP ------ Do not adjust IPB001~IPB079 Do not adjust

5.RF AFC IPC001~IPC044 Do not adjust Tuner AFC setting TUNER, AFC,FINE Do not adjust IPD001~IPD026 Do not adjust

6.CONER A IPE001~IPE015 Do not adjust Convergence adjustment CPA01~CPA08 0.GCR

CCA01~CCA09 Ghost reduction setting Not use CBA01~CBA80 Do not adjust

1-18 (No.52105)

AV-48WP74 AV-56WP74

2.9.4 SHIPPING FACTORY SETTING

VIDEO STATUS MEMORY (NTSC / 480p)

Setting value

Item

STANDARD 00000LOW

THEATER 0 0 0 0 0 HIGH

DYNAMIC 0 0 10 0 5 HIGH

GAME 0 0 -10 0 0 HIGH

(HD)

Item

STANDARD 00000LOW

THEATER 0 0 0 0 0 HIGH

DYNAMIC 00500LOW

GAME 0 0 -10 0 0 HIGH

CHANNEL SETTING (CHANNEL SUMMARY)

Band CH display Band CH display

VHF LOW 2 SUPER K 24

VHF HIGH 7 W 36

UHF 14 HYPER W+11 47

MID A 14

B15

C16

D17

E18

H21

TINT COLOR PICTURE BRIGHT DETAIL

Setting value

TINT COLOR PICTURE BRIGHT DETAIL

4O28

5R31

6S32

9SUBMIDA-496

11 A-3 97

13 A-2 98

36 W+12 48

63 W+17 53

69 W+23 59

COLOR

TEMPERATURE

COLOR

TEMPERATURE

(No.52105)1-19

AV-48WP74 AV-56WP74

SHIPPING FACTORY SETTING (USER SETTING)

Setting item Setting value Setting item Setting value

POWER CHANNEL VOLUME INPUT

DISPLAY NATURAL CINEMA SLEEP TIMER ASPECT VIDEO STATUS

SOUND A.H.S BBE

HYPER SURROUND OFF

SPLIT SOURCE

POP SOURCE

VERTICAL POSITION CENTER CH INPUT XDS ID CONVERGENCE POWER INDICATOR

OFF CABLE-02 10 TV

OFF AUTO 0 REGULAR DYNAMIC

OFF ON

left side : CA 02 right side : CA 04

left side : CA 02 right upper : CA 04 right center : CA 05 right bottom : CA 07

Center OFF ON Optimum condition HIGH

TINT / COLOR / PICTURE/ BRIGHT / DETAIL

COLOR TEMPERATURE DIG. NOISE CLEAR

BASS / TREBLE / BALANCE MTS

SET CLOCK ON / OFF TIMER LANGUAGE NOISE MUTING CLOSED CAPTION FRONT PANEL LOCK

AUTO SHUT OFF AUTO TUNER SET UP DIGITAL-IN ( at 480p signal input ) CHANNEL SUMMARY

V-CHIP SET LOCK CODE AUTO DEMO

Refer to setting of Video status memory at shipping factory setting

HIGH OFF

Center STEREO

Unnecessary to set NO ENG ON OFF ( CC1 / T1 ) OFF

OFF Unnecessary to set SIZE 1

Refer to Last memory (CH. summary) OFF Unnecessary to set OFF

1-20 (No.52105)

SECTION 3

ADJUSTMENTS

AV-48WP74 AV-56WP74

3.1 ADJUSTMENT PREPARATION

(1) You can make the necessary adjustments for this unit with

either the Remote Control Unit or with the adjustment tools and parts as given below.

(2) Adjustment with the Remote Control Unit is made on the

basis of the initial setting values, however, the new setting values which set the screen to its optimum condition may

3.2 ADJUSTMENT EQUIPMENT

(1) DC voltmeter (or digital voltmeter) (2) Oscilloscope (3) Signal generator (Pattern generator)

[NTSC / 480i / 480p / 720p / 1080i / HDCP] (4) TV audio multiplex signal generator (5) Remote control unit

differ from the initial settings. (3) Make sure that AC power is turned on correctly. (4) Turn on the power for set and test equipment before use,

and start the adjustment procedures after waiting at least

30 minutes. (5) Unless otherwise specified, prepare the most suitable

reception or input signal for adjustment. (6) Never touch any adjustment setting value which are not

specified in the list for this adjustment. (7) Presetting before adjustment

Unless otherwise specified in the adjustment instructions,

preset the following functions with the remote control unit:

• SETTING POSITION

Setting item Setting position Setting item Setting position

VIDEO STATUS STANDARD ASPECT FULL

BASS / TREBLE / BALANCE Center VERTICAL POSITION Center

HYPER SURROUND OFF BBE ON

TINT / COLOR / PICTURE /

Center ON/OFF TIMER NO

BRIGHT / DETAIL

COLOR TEMPERATURE HIGH AUTO SHUTOFF OFF

DIGITAL NOISE CLEAR OFF

3.3 ADJUSTMENT FLOWCHART

WHEN REPLACING SCREEN AND PROJECTION UNIT

• Contains only the main adjustments. Also confirm other adjustments as required.

1 Projection unit

Install projection tube

LENS FOCUS

BEAM SPOT

CRT FOCUS

SCREEN & LOW LIGHT

CONVERGENCE

(match to unreplaced tube)

HIGH LIGHT

END

3 Projection unit

Install projection tube

LENS FOCUS

BEAM SPOT

CRT FOCUS

SCREEN & LOW LIGHT

G CONVERGENCE

R CONVERGENCE

B CONVERGENCE

HIGH LIGHT

SCREEN

LENS FOCUS

G convergence

disturbed

G CONVERGENCE

R CONVERGENCE

B CONVERGENCE

END

(No.52105)1-21

AV-48WP74 AV-56WP74

3.4 ADJUSTMENT LOCATION (1/2)

CONVERGENCE OUT PWB

IC805

B G R

IC804

R/G/B CRT SOCKET PWB

MAIN PWB

FRONT

DIGITAL CONVERGENCE MODULE PWB

MI-COM & DIST PWB

P BG

FRONT RELAY PWB

FRONT

RECEIVER PWB

CONVERGENCE

OUT PWB

FRONT

MI-COM&DIST MODULE PWB

FRONT CONTROL PWB

TOP

POWER SW

MENU CH - CH +

CN001

CN002

LED

INPUT 3

REMOCON SENSOR PWB

POWER SW

VOL - VOL +

BHR

POWER&DEF PWB

G VM PWB

LINE FILTER PWB

POWER CORD

SPEAKER

1-22 (No.52105)

SUB TUNER

(TU101)

MAIN TUNER

DIGITAL INPUT MODULE PWB

G CRT

SOCKET

PWB

AUDIO / VIDEO

S-VIDEO

CN00Y

CN00E

COMPONENT

VIDEO-V

CN003

DIGITAL INPUT MODULE PWB

AUDIO

CN010

DEF OSC PWB

3.5 ADJUSTMENT LOCATION (2/2)

AV-48WP74 AV-56WP74

DIGITAL INPUT MODULE PWB

TOP

REAR

FOCUS PACK

RRGGB

TOP

SCREEN

FOCUS

MAIN PWB

CONNECTOR

MAIN PWB

LINE FILTER PWB

CRT SOCKET PWB

RGK

TP-E

RBN RGNRBN RGN

R CRT SOCKET

PWB

TP-R TP-B

G VM PWB

M-I COM & DISC MODULE PWB

RGK

GBK GBK

TP-E

TP-G

G CRT SOCKET

PWB

POWER & DEF PWB

TP-E

B CRT SOCKET

PWB

TOP

FRONT

5Pin : TP-91(B1)

4Pin : NC

3Pin : X-ray1

2Pin : X-ray2

1Pin : TP-E ( )

CN001

CN002

CN003

DEF OSC PWB

CN010

FOCUS PACK

RHV

GHV

HV DIVIDER

BHV

AAS1

FBT

(No.52105)1-23

AV-48WP74 AV-56WP74

3.6 BASIC OPERATION OF SERVICE MENU

Function

(Right / Left) key

Function

(Up / Down) key

SERVICE MENU

1.PICTURE/SOUND

2.YC SEP

3.WHITE BALANCE

4.MEMORY SETUP

5.RF AFC

6.CONVER A

1.PICTURE/SOUND

NTSC CINE ST L FL MUTE

A01 001

A01~A27

A01

S01~S99

S01

7.CONVER B

8.PP

9.IP

0.GCR

4.MEMORY SETUP

ADDRESS(H) 0000

5.RF AFC

TUNER

AFC

FINE

6.CONVER A

CPA01 OSDH

DO NOT ADJUST

CPA01~08 CCA01~09 CBA01~80

DO NOT ADJUST

YCM001~185

YCS001~114

D01~D32

D01

F01~F70

F01

2.YC SEP 8.PP

NTSC CINE ST L FL MUTE

YC01

3. WHITE BALANCE

DRV R069 B054 CUT R078 G079 B079

7.CONVER B

PPA001

9.IP

NTSC CINE ST L FL MUTE

IPA001

ADM001~034 PPA001~008 PPB001~036 PPC001~008 PPD001~025

DO NOT ADJUST

IPA001~120 IPB001~079 IPC001~044 IPD001~026 IPE001~015

1-24 (No.52105)

3.6.1 TOOL OF SERVICE MENU OPERATION

Operate the SERVICE MENU with the REMOTE CONTROL UNIT.

3.6.2 SERVICE MENU ITEMS

In general, basic setting (adjustments) items or verifications are performed in the SERVICE MENU.

1.PICTURE / SOUND ....This sets the setting values of the VIDEO,AUDIO and DEFLECTION circuits.

2.YC SEP.......................This is used when the YC separation circuit is adjusted. [Do not adjust]

3.WHITE BALANCE ......This sets the setting values of the WHITE BALANCE.

4.MEMORY SETUP....... This sets the setting values of the MEMORY ADDRESS. [Do not adjust]

5.RF AFC.......................This is used when the IF VCO is adjusted. [Do not adjust]

6.CONVER A ................. This is used when the CONVERGENCE is adjusted.

7.CONVER B ................. This is used when the CONVERGENCE is adjusted.

8.PP ...............................This sets the setting value of the output of MULTI-PICTURE circuit.

9.IP ................................This sets the setting value of the DIST circuit. [Do not adjust]

0.GCR............................This model do not built-in.

3.6.3 BASIC OPERATIONS OF THE SERVICE MENU (1) How to enter the SERVICE MENU.

Press [SLEEP TIMER] key and, while the indication of "SLEEP TIMER 0 MIN." is being displayed, press [DISPLAY] key and [VIDEO STATUS] key on the remote control unit simultaneously to enter the SERVICE MENU screen as shown in the fig.1.

(2) Releasing SERVICE MENU

After returning to the SERVICE MENU upon completion of the setting work, press the BACK key again.

AV-48WP74 AV-56WP74

3.6.4 DESCRIPTION OF STATUS DISPLAY

The status display on the upper part of the SERVICE MENU screen is common (to all models).

(1) COLOR SYSTEM

NTSC : 480i (COMPOSITE/S input) DVD : 480i (COMPONENT) ED : 480p HD : 1080i 720 : 720p HED1 : HDCP 480p SIZE1 HED2 : HDCP 480p SIZE2 HHD : HDCP 1080i H750 : HDCP 720p

(2) ASPECT / MULTI

ONE SCREEN FULL : FULL PANO : PANORAMA CINE : CINEMA REGU : REGULAR

MULTI SCREEN M1 : One screen (for adjustment) M2-1 : SPLIT (4 : 3) M2-2 : SPLIT (16 : 9) M4 : POP M12 : INDEX

STATUS DISPLAY

NTSC CINE ST L FL MUTE

COLOR SYSTEM

ASPECT/ MULTI

VIDEO STATUS

A01 IN LEVEL 001

[SERVICE SCREEN]

MEMORY MODE

IP CHANGIN MODE

WHITE BALANCE

(4) WHITE BALANCE

H: HIGH L: LOW

(5) IP CHANGING MODE

FL : FRAME L1 : LINE 23 : COMPULSORY NATURAL CINEMA IN

(6) MEMORY MODE

MUTE : Press [MUTING] key DIR : Change data then memory at the same time.

(3) VIDEO STATUS

ST : STANDARD DA : DYNAMIC TH : THEATER GA : GAME

(No.52105)1-25

AV-48WP74 AV-56WP74

3.6.5 SERVICE MENU SETTING

1. PICTURE/SOUND

AUDIO, VIDEO, DEFLECTION data adjustment.

1.SETTING ITEM No. A : AUDIO S : SIGNAL D : DEFLECTION F : FACTORY SETTING

• Press [CH+] / [CH-] key

Item No. is up/down

• Press [SLEEP TIMER] key

Skip change

2.SETTING ITEM NAME

Describe setting item name

3. WHITE BALANCE

Adjustment of LOW LIGHT / HIGH LIGHT

1.SELECT ITEM

• Press [CH+] / [CH-] key

2.SETTING VALUE BRIGHT

• Press [VOL+] / [VOL-] key DRIVE [4] key : DRIVE R is up [7] key : DRIVE R is down

F01D01S01A01

[6] key : DRIVE B is up [9] key : DRIVE B is down CUTOFF [4] key : CUTOFF R is up [7] key : CUTOFF R is down

F01D01S01A01

[5] key : CUTOFF G is up [8] key : CUTOFF G is down [6] key : CUTOFF B is up [9] key : CUTOFF B is down

3. WHITE BALANCE

3.SETTING VALUE

Set the setting value.

• Press [VOL+] / [VOL-] key

Set the setting value.

• Press [MUTING] key

Memorize the data.

1.PICTURE/SOUND

NTSC CINE ST L FL MUTE

A01 IN LEVEL 001

SETTING ITEM No.

A01~A27 / S01~S99 D01~D32 / F01~F70

2. YC SEP

YC separation circuit setting

[Do not adjust]

2.YC SEP

NTSC CINE ST L FL MUTE

SETTING VALUE

SETTING ITEM NAME

DRV R069 B054 CUT R078 G079 B079

4. MEMORY SETUP [Do not adjust]

4.MEMORY SETUP

ADDRESS(H) 0000

R.DRIVE VALUE B.DRIVE VALUE

B.CUT OFF VALUE G.CUT OFF VALUE R.CUT OFF VALUE

1-26 (No.52105)

SETTING ITEM No.

SETTING VALUE

YC001

AV-48WP74 AV-56WP74

5. RF AFC [Do not adjust]

5.RF AFC

TUNER

AFC

FINE

(NOTE) TUNER 1(MAIN) / 2(SUB) AFC Select ON / OFF FINE FineTuning(-77~+77) AFC ON:Auto Setting

6. CONVER A

Setting the CONVERGENCE PHASE adjustment

• Setting for 6.CONVER A is described in the CONVER-

GENCE adjustment page.

6.CONVER A

CPA01

OSDH

SETTING ITEM No.

CPA01~08 CCA01~09 CBA01~80

SETTING ITEM NAME

SETTING VALUE

8. PP

MULTI-PICTURE circuit data setting

• Do not adjust (except ADM012~ADM014 : Refer to VIDEO ADJUSTMENT page)

8.PP

PPA001

SETTING ITEM No.

PPA001~PPA008 PPB001~PPB036 PPC001~PPC008 PPD001~PPD025

ADM001~ADM034

SETTING VALUE

9. IP

DIST circuit data setting

[Do not adjust]

NTSC PIP

IPA001

9.IP

OFF FRAM

SETTING ITEM No.

IPA001~IPA120

IPB001~IPB079 IPC001~IPC044 IPD001~IPD026 IPE001~IPE015

SETTING VALUE

7. CONVER B

Setting the CONVERGENCE POINT (fine)

• Setting for 7.CONVER B is described in the CONVERGENCE adjustment page.

7.CONVER B

(No.52105)1-27

AV-48WP74 AV-56WP74

3.7 INITIAL SETTING VALUE OF SERVICE MENU

(1) Adjustment of the SERVICE MENU is made on the basis of the initial setting values; however, the new setting values which set

the screen in its optimum condition may differ from the initial setting. (2) Do not change the initial setting values of the setting items NOT LISTED IN ADJUSTMENT. (3) The (*1 or *2) marked items in following table, it is NO REQUIREMENT for adjustment. If values had change by the missing, set

the initial values in the following table. (4) "---" is not adjusted. Setting value is not displayed

CAUTION:

Never change the initial setting value any adjustments except for those that are designated in the adjustment procedures.

In case where you have made undesignated adjustments by mistake, never press the [MUTING] key on the remote control unit. Whenever you had not pressed the [MUTING] key, you would be able to recover the initial value by switching the [POWER] key.

3.7.1 [1. PICTURE / SOUND]

AUDIO SYSTEM

Item

No.

A01 IN LEVEL 000~015 009 009

A02 LOW SEP 000~063 035 035

A03 HI SEP 000~063 020 020

A04 BBE BASS -128~+127 +010 +004

A05 BBE TRE -128~+127 000 +004

A06 SURROUND 000~015 000 000

A07 BASS OFS -128~+127 -017 -007

A08 TRE OFS -128~+127 -011 -005

A09 AHS MVE -128~+127 000 000

A10 AHS MSC -128~+127 000 000

A11 (Not display) 000 / 001 000 000

A12 (Not display) 000 / 001 000 000

A13 (Not display) 000 / 001 000 000

A14 (Not display) 000 / 001 000 000

A15 (Not display) 000 / 001 000 000

A16 (Not display) 000 / 001 000 000

A17 (Not display) 000 / 001 000 000

A18 (Not display) 000 / 001 000 000

A19 (Not display) 000 / 001 000 000

A20 (Not display) 000 / 001 000 000

A21 (Not display) 000 / 001 000 000

A22 (Not display) 000 / 001 000 000

A23 (Not display) 000 / 001 000 000

A24 (Not display) 000 / 001 000 000

A25 (Not display) 000 / 001 000 000

A26 (Not display) 000 / 001 000 000

A27 (Not display) 000 / 001 000 000

Item name Variable range

AV-48WP74 AV-56WP74

Initial setting value

1-28 (No.52105)

DEFLECTION SYSTEM

AV-48WP74 AV-56WP74

Item

No.

D01 V. SIZE 000~127 053 053

D02 EW 000~063 013 013

D03 H. SIZE 000~127 045 045

D04 V. SCORE 000~063 040 040

D05 V. LINE 000~031 040 040

D06 V. CENT 000~127 024 024

D07 EW.TRAP 000~127 028 028

D08 BOT.CORN 000~031 008 008

D09 TOP.CORN 000~031 008 008

D10 V. EHT 000~007 005 005

D11 H. EHT 000~007 003 003

D12 (Not display) 000~031 006 006

D13 (Not display) 000~031 000 000

D14 H. CENTER 000~255 091 091

D15 H. FREQ 000~255 182 182

D16 (Not display) 000 / 001 000 000

D17 (Not display) 000~015 000 000

D18 (Not display) 000~015 000 000

D19 (Not display) 000~015 000 000

D20 (Not display) 000~015 000 000

D21 (Not display) 000~015 000 000

D22 (Not display) 000 / 001 000 000

D23 (Not display) 000~031 000 000

D24 (Not display) 000~031 000 000

D25 (Not display) 000~015 000 000

D26 (Not display) 000~015 000 000

D27 (Not display) 000~127 000 000

D28 (Not display) 000~003 000 000

D29 (Not display) 000 / 001 000 000

D30 (Not display) 000 / 001 000 000

D31 (Not display) 000 / 001 000 000

D32 (Not display) 000 / 001 000 000

Item name Variable range

SINGLE PICTURE

Initial setting value

(FULL)

SPRIT / POP / MULTI

(No.52105)1-29

AV-48WP74 AV-56WP74

VIDEO SYSTEM ( NTSC / 480i / 480p )

Item

No.

S01 COLOR 000~255 095 087 081 072 074 068

S02 TINT 000~255 062 050 066 062 063 063

( 720p / 1080i / HDCP )

Item

No.

S01 COLOR 000~255 066 064 --- --- --- ---

S02 TINT 000~255 064 058 --- --- --- ---

( NTSC / 480i )

Item

No.

S03 BRIGHT 000~255 133 121 130 129

S04 CONTRAST 000~127 052 045 065 046

( 480p / 720p / 1080i / HDCP)

Item

No.

S03 BRIGHT 000~255 130 130 --- ---

S04 CONTRAST 000~127 065 044 --- ---

Item name Variable range

STANDARD THEATER STANDARD THEATER STANDARD THEATER

STANDARD THEATER

NTSC 480i 480p

720p / 1080i HDCP

480p 1080i / 720p

STANDARD THEATER STANDARD THEATER

NTSC 480i

STANDARD THEATER STANDARD THEATER

480p / 720p / 1080i HDCP

STANDARD THEATER STANDARD THEATER

( NTSC / 480i )

Item

No.

S05 0 MTX SW 000~003 000 000 000 000

S06 INPUT SW 000~003 001 001 001 001

S07 B-Y 000~063 013 024 013 024

S08 R-Y 000~015 007 000 007 000

S09 G-Y MATRI 000~003 001 003 001 003

( 480p / 720p / 1080i / HDCP )

Item

No.

S05 0 MTX SW 000~003 000 000 000 000

S06 INPUT SW 000~003 001 001 000 000

S07 B-Y 000~063 016 016 022 027

S08 R-Y 000~015 007 002 004 003

S09 G-Y MATRI 000~003 001 003 002 002

Item name Variable range

STANDARD THEATER STANDARD THEATER

NTSC 480i

480p / HDCP480p 1080i / 720p / HDCP1080i / HDCP720p

1-30 (No.52105)

( NTSC / 480i )

AV-48WP74 AV-56WP74

Item

No.

S10 DRIVE R 000~255 073 --- --- --- --- 074 --- ---

S11 (Not display) -128~+127 --- 004 010 006 005 --- 002 005

S12 DRIVE B 000~255 060 --- --- --- --- 058 --- ---

S13 (Not display) -128~+127 --- 004 -018 -007 005 --- -010 -018

( 480p / 720p / 1080i )

Item

No.

S10 DRIVE R 000~255 --- --- --- --- --- 074 --- ---

S11 (Not display) -128~+127 003 004 003 001 005 --- 005 008

S12 DRIVE B 000~255 --- --- --- --- --- 058 --- ---

S13 (Not display) -128~+127 007 004 000 -010 005 --- 001 -009

( HDCP )

Item

No.

S10 DRIVE R 000~255 --- --- --- ---

S11 (Not display) -128~+127 005 0 005 008

S12 DRIVE B 000~255 --- --- --- ---

S13 (Not display) -128~+127 005 0 001 -009

Item name Variable range

STANDARD THEATER STANDARD THEATER

HIGH LOW HIGH LOW HIGH LOW HIGH LOW

STANDARD THEATER STANDARD THEATER

HIGH LOW HIGH LOW HIGH LOW HIGH LOW

STANDARD THEATER

HIGH LOW HIGH LOW

NTSC 480i

480p 720p / 1080i

HDCP

( NTSC / 480i )

Item

No.

S14 CUTOF R 000~255 158 --- 164 ---

S15 (Not display) -128~+127 --- -004 --- 001

S16 CUTOF G 000~255 119 --- 119 ---

S17 (Not display) -128~+127 --- 0 --- 000

S18 CUTOF B 000~255 185 --- 190 ---

S19 (Not display) -128~+127 --- -004 --- 000

S20 CUTOF SW R 000~003 001 --- 001 ---

S21 CUTOF SW G 000~003 001 --- 001 ---

S22 CUTOF SW B 000~003 001 --- 001 ---

Item name Variable range

STANDARD THEATER STANDARD THEATER

NTSC 480i

(No.52105)1-31

AV-48WP74 AV-56WP74

( 480p / 720p / 1080i )

Item

No.

S14 CUTOF R 000~255 165 --- --- ---

S15 (Not display) -128~+127 --- -008 000 -006

S16 CUTOF G 000~255 119 --- --- ---

S17 (Not display) -128~+127 --- 000 000 000

S18 CUTOF B 000~255 190 --- --- ---

S19 (Not display) -128~+127 --- -008 000 -011

S20 CUTOF SW R 000~003 001 --- --- ---

S21 CUTOF SW G 000~003 001 --- --- ---

S22 CUTOF SW B 000~003 001 --- --- ---

( NTSC / 480i / OTHERS )

Item

No.

S23 DC CTL 000~255 000 255 000 255 000 255

( NTSC / 480i / OTHERS SIGNAL)

Item

No.

S24 RGBLIMT 000~015 000 000 000

S25 BL STRT 000~015 015 015 015

S26 BL GAIN 000~015 008 008 008

S27 YGM LVL 000~015 000 000 000

S28 YGM GAIN 000~015 015 015 015

S29 YWD START 000~015 002 000 000

S30 YWD GAIN 000~015 005 002 003

Item name Variable range

Item name Variable range NTSC 480i OTHERS SIGNAL

STANDARD THEATER STANDARD THEATER

STANDARD THEATER STANDARD THEATER STANDARD THEATER

480p / 720p / 1080i HDCP

NTSC 480i OTHERS SIGNAL

( NTSC / 480i / 480p )

Item

No.

S31 COL OFST 000~255 --- --- --- --- --- ---

S32 TNT OFST 000~255 --- --- --- --- --- ---

(720p / 1080i / HDCP)

Item

No.

S31 COL OFST 000~255 --- --- 010 007 007 000

S32 TNT OFST 000~255 --- --- 003 006 004 000

( NTSC / 480i / 480p / 720p / 1080i )

Item

No.

S33 BRT OFST -128~+127 --- --- --- --- --- ---

S34 CNT OFST -128~+127 --- --- --- --- --- ---

1-32 (No.52105)

Item name Variable range

STANDARD THEATER STANDARD THEATER STANDARD THEATER

NTSC 480i 480p

720p / 1080i

NTSC 480i / 480p 720p / 1080i

480p 1080i / 720p

HDCP

(HDCP / POP / MULTI )

AV-48WP74 AV-56WP74

Item

No.

S33 BRT OFST -128~+127 000 -004 -003 000

S34 CNT OFST -128~+127 000 000 -003 -005

(SPRIT)

Item

No.

S33 BRT OFST -128~+127 000 -004 --- ---

S34 CNT OFST -128~+127 000 000 --- ---

Item

No.

S35 DCTRN SW 000 / 001 000 000

S36 BL OFF 000 / 001 000 000

S37 YGM OFF 000 / 001 000 000

S38 ABL OFF 000 / 001 000 000

S39 ACL OFF 000 / 001 000 000

Item name Variable range

STANDARD THEATER STANDARD THEATER

Item name Variable range

Item name Variable range STANDARD THEATER

STANDARD THEATER STANDARD THEATER

480p 1080i / 720p

SPRIT POP / MULTI

HDCP

Item

No.

S40 BLCNT LK 000 / 001 000

S41 YGCNT LK 000 / 001 000

S42 DCTRN PL 000 / 001 000

S43 ABL GAIN 000~015 015

S44 ABL STRT 000~015 015

S45 ACL GAIN 000~015 015

S46 ACL STRT 000~015 000

Item

No.

S47 ACL EERG 000~255 255 255 255 255 255 255

( NTSC / 480i / OTHERS )

Item

No.

S48 CHRM GM 000~255 128 128 128 128 128 128

Item name Variable range Initial setting value

Item name Variable range

MULTI SCREEN ASPECT VIDEO STATUS

SPLIT OTHERS REGULAR OTHERS THEATER OTHERS

NTSC 480i OTHERS SIGNAL

STANDARD THEATER STANDARD THEATER STANDARD THEATER

(No.52105)1-33

AV-48WP74 AV-56WP74

(ALL SIGNAL )

Item

No.

S49 OSDR DC 000~127 064

S50 OSDB DC 000~127 064

S51 BLK OFF 000 / 001 000

S52 CNT UNDR -128~+127 -030

S53 CNT UPPR -128~+127 +013

S54 BRT UNDR -128~+127 -020

S55 EETH BRT -128~+127 000

S56 EETH CNT -128~+127 000

S57 BREE CNT 000~031 000

S58 DKEE CNT 000~031 000

S59 DREE BRT 000~127 000

S60 BREE ACL 000~255 000

S61 DKEE ACL 000~255 000

S62 VMOFF DE -128~+127 +005

S63 VM LOW -128~+127 -020

S64 VM MID -128~+127 -010

S65 VM HIGH -128~+127 +010

S66 VM L- -128~+127 -002

S67 VM LH -128~+127 -001

S68 VM MH -128~+127 000

S69 VM M+ -128~+127 +001

S70 (Not display) 000 / 001 000

S71 (Not display) 000 / 001 000

S72 (Not display) 000 / 001 000

S73 (Not display) 000 / 001 000

S74 (Not display) 000 / 001 000

Item name Variable range Initial setting value

Item

No.

S75 (Not display) 000 / 001 000

S76 (Not display) 000 / 001 000

S77 (Not display) 000 / 001 000

S78 (Not display) 000 / 001 000

S79 (Not display) 000 / 001 000

S80 (Not display) 000 / 001 000

S81 (Not display) 000 / 001 000

S82 (Not display) 000 / 001 000

S83 (Not display) 000 / 001 000

S84 (Not display) 000 / 001 000

S85 (Not display) 000 / 001 000

S86 (Not display) 000 / 001 000

S87 (Not display) 000 / 001 000

S88 (Not display) 000 / 001 000

S89 (Not display) 000 / 001 000

S90 (Not display) 000 / 001 000

S91 (Not display) 000 / 001 000

S92 (Not display) 000 / 001 000

S93 (Not display) 000 / 001 000

S94 (Not display) 000 / 001 000

S95 (Not display) 000 / 001 000

S96 (Not display) 000 / 001 000

S97 (Not display) 000 / 001 000

S98 (Not display) 000 / 001 000

S99 (Not display) 000 / 001 000

Item name Variable range Initial setting value

OTHERS

Item

No.

F01 (Not display) 000~255 069

F02 (Not display) 000~255 000

F03 (Not display) 000~255 000

F04 (Not display) 000~255 150

F05 CATVMAX 000 / 001 001

F06 (Not display) 000 / 001 000

F07 (Not display) 000~255 000

F08 (Not display) 000~255 008

1-34 (No.52105)

Item name Variable range Initial setting value

AV-48WP74 AV-56WP74

Item

No.

F09 AUTO SCR 1 000~015 001 002

F10 AUTO SCR 2 000~015 002 004

F11 AUTO SCR 3 000~015 003 004

F12 AUTO SCR 4 000~015 004 005

F13 AUTO SCR 5 000~015 005 006

F14 AUTO SCR 6 000~015 006 007

F15 AUTO SCR 7 000~015 007 007

Item

No.

F16 Not use 000~127 070

F17 Not use 000 / 001 000

F18 FIX DATA 000 / 001 000

F19 (Not display) 000 / 001 000

F20 (Not display) 000~255 005

F21 (Not display) 000~255 002

F22 (Not display) 000 / 001 000

F23 (Not display) 000~255 000

F24 (Not display) 000~255 141

F25 (Not display) 000~255 006

F26 (Not display) 000~255 040

F27 (Not display) 000~255 040

F28 (Not display) 000 / 001 000

Item name Variable range CINEMA Except CINEMA

Item name Variable range Initial setting value

Item

No.

F29 (Not display) 000 / 001 000

F30 (Not display) 000 / 001 000

F31 (Not display) 000 / 001 000

F32 (Not display) 000 / 001 000

F33 (Not display) 000 / 001 000

F34 (Not display) 000 / 001 000

F35 (Not display) 000 / 001 000

F36 (Not display) 000 / 001 000

F37 (Not display) 000 / 001 000

F38 (Not display) 000 / 001 000

F39 (Not display) 000 / 001 000

F40 (Not display) 000 / 001 000

Item name Variable range Initial setting value

( NTSC / 480i / 480p / 1080i / 720p)

Item

No.

F41 (Not display) 000~003 000 000 000 000 000

F42 (Not display) 000 / 001 000 000 000 000 000

F43 (Not display) 000~063 039 015 025 025 025

Item

No.

F44 (Not display) 000 / 001 000

F45 (Not display) 000~007 ---

F46 OUT LX 000~255 ---

F47 LMT BTM 000~255 ---

F48 LMT TOP 000~255 ---

F49 (Not display) 000 / 001 ---

F50 (Not display) 000 / 001 001

F51 (Not display) 000~007 003

F52 (Not display) 000~063 053

F53 (Not display) -128~+127 000

F54 (Not display) 000~255 015

F55 (Not display) 000~255 040

F56 (Not display) 000~255 207

F57 (Not display) 000~255 128

Item name Variable range NTSC 480i 480p 1080i 720p

Item name Variable range Initial setting value

Item

No.

F58 (Not display) 000~255 047

F59 (Not display) 000 / 001 001

F60 ATT GAIN 000 / 001 000

F61 (Not display) 000 / 001 001

F62 (Not display) 000 / 001 000

F63 (Not display) -128~+127 +020

F64 (Not display) -128~+127 000

F65 (Not display) -128~+127 -010

F66 (Not display) 000~007 004

F67 (Not display) 000~003 003

F68 (Not display) 000~255 126

F69 (Not display) 000 / 001 000

F70 (Not display) 000 / 001 000

Item name Variable range Initial setting value

(No.52105)1-35

AV-48WP74 AV-56WP74

3.7.2 [2.YC SEP] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

YCM001 (Not display) 000 / 001 000

YCM002 (Not display) 000 / 001 000

YCM003 (Not display) 000 / 001 000

YCM004 (Not display) 000~003 001

YCM005 (Not display) 000~255 239

YCM006 (Not display) 000~003 001

YCM007 (Not display) 000~255 239

YCM008 (Not display) 000 / 001 000

YCM009 (Not display) 000~003 000

YCM010 (Not display) 000 / 001 000

YCM011 (Not display) 000 / 001 000

YCM012 (Not display) 000 / 001 000

YCM013 (Not display) 000 / 001 000

YCM014 (Not display) 000~003 000

YCM015 (Not display) 000 / 001 000

YCM016 (Not display) 000~003 001

YCM017 (Not display) 000 / 001 001

YCM018 (Not display) 000~003 000

YCM019 (Not display) 000 / 001 000

YCM020 (Not display) 000 / 001 000

YCM021 (Not display) 000~003 002

YCM022 (Not display) 000~007 004

YCM023 (Not display) 000 / 001 001

YCM024 (Not display) 000 / 001 000

YCM025 (Not display) 000~015 005

YCM026 (Not display) 000~015 003

YCM027 (Not display) 000~003 000

YCM028 (Not display) 000~007 003

YCM029 (Not display) 000~007 002

YCM030 (Not display) 000~003 003

YCM031 (Not display) 000 / 001 000

YCM032 (Not display) 000~003 003

YCM033 (Not display) 000 / 001 001

YCM034 (Not display) 000 / 001 000

YCM035 (Not display) 000~255 096

YCM036 (Not display) 000 / 001 001

YCM037 (Not display) 000~003 001

YCM038 (Not display) 000~127 062

Variable

range

Initial setting

value

Item No. Item name

YCM039 (Not display) 000~127 068

YCM040 (Not display) 000~003 002

YCM041 (Not display) 000~063 016

YCM042 (Not display) 000 / 001 000

YCM043 (Not display) 000 / 001 000

YCM044 (Not display) 000~255 182

YCM045 (Not display) 000 / 001 000

YCM046 (Not display) 000~255 127

YCM047 (Not display) 000 / 001 001

YCM048 (Not display) 000 / 001 001

YCM049 (Not display) 000 / 001 001

YCM050 (Not display) 000 / 001 001

YCM051 (Not display) 000 / 001 001

YCM052 (Not display) 000 / 001 000

YCM053 (Not display) 000 / 001 001

YCM054 (Not display) 000~003 003

YCM055 (Not display) 000~003 003

YCM056 (Not display) 000~003 000

YCM057 (Not display) 000 / 001 000

YCM058 (Not display) 000 / 001 001

YCM059 (Not display) 000 / 001 001

YCM060 (Not display) 000 / 001 000

YCM061 (Not display) 000 / 001 001

YCM062 (Not display) 000~015 001

YCM063 (Not display) 000~015 004

YCM064 (Not display) 000~003 000

YCM065 (Not display) 000~063 060

YCM066 (Not display) 000~063 040

YCM067 (Not display) 000~063 025

YCM068 (Not display) 000~063 012

YCM069 (Not display) 000~063 036

YCM070 (Not display) 000~063 031

YCM071 (Not display) 000~127 031

YCM072 (Not display) 000 / 001 001

YCM073 (Not display) 000 / 001 001

YCM074 (Not display) 000~063 024

YCM075 (Not display) 000 / 001 000

YCM076 (Not display) 000 / 001 001

YCM077 (Not display) 000~063 010

YCM078 (Not display) 000~063 001

YCM079 (Not display) 000~255 000

YCM080 (Not display) 000~255 000

YCM081 (Not display) 000~255 000

YCM082 (Not display) 000~255 000

YCM083 (Not display) 000 / 001 001

Variable

range

Initial setting

value

1-36 (No.52105)

AV-48WP74 AV-56WP74

Item No. Item name

YCM084 (Not display) 000~063 012

YCM085 (Not display) 000 / 001 000

YCM086 (Not display) 000 / 001 000

YCM087 (Not display) 000~063 028

YCM088 (Not display) 000 / 001 001

YCM089 (Not display) 000~031 000

YCM090 (Not display) 000~003 000

YCM091 (Not display) 000~015 000

YCM092 (Not display) 000~015 000

YCM093 (Not display) 000~015 002

YCM094 (Not display) 000~063 000

YCM095 (Not display) 000~255 025

YCM096 (Not display) 000 / 001 001

YCM097 (Not display) 000~063 063

YCM098 (Not display) 000~015 008

YCM099 (Not display) 000~015 005

YCM100 (Not display) 000~015 008

YCM101 (Not display) 000~015 005

YCM102 (Not display) 000~015 000

YCM103 (Not display) 000~015 002

YCM104 (Not display) 000~015 008

YCM105 (Not display) 000~015 006

YCM106 (Not display) 000~255 010

YCM107 (Not display) 000~255 032

YCM108 (Not display) 000~255 031

YCM109 (Not display) 000~255 064

YCM110 (Not display) 000 / 001 000

YCM111 (Not display) 000 / 001 001

YCM112 (Not display) 000 / 001 001

YCM113 (Not display) 000 / 001 001

YCM114 (Not display) 000 / 001 000

YCM115 (Not display) 000 / 001 001

YCM116 (Not display) 000 / 001 000

YCM117 (Not display) 000 / 001 000

YCM118 (Not display) 000 / 001 001

YCM119 (Not display) 000 / 001 000

YCM120 (Not display) 000 / 001 000

YCM121 (Not display) 000~003 003

YCM122 (Not display) 000 / 001 000

YCM123 (Not display) 000~255 000

YCM124 (Not display) 000 / 001 000

YCM125 (Not display) 000~255 002

YCM126 (Not display) 000 / 001 000

YCM127 (Not display) 000 / 001 001

YCM128 (Not display) 000 / 001 001

Variable

range

Initial setting

value

Item No. Item name

YCM129 (Not display) 000 / 001 001

YCM130 (Not display) 000~003 001

YCM131 (Not display) 000~255 050

YCM132 (Not display) 000~255 131

YCM133 (Not display) 000~255 055

YCM134 (Not display) 000~007 001

YCM135 (Not display) 000~255 136

YCM136 (Not display) 000 / 001 000

YCM137 (Not display) 000 / 001 001

YCM138 (Not display) 000~007 003

YCM139 (Not display) 000~255 141

YCM140 (Not display) 000~007 000

YCM141 (Not display) 000~255 014

YCM142 (Not display) 000 / 001 000

YCM143 (Not display) 000~007 005

YCM144 (Not display) 000~255 128

YCM145 (Not display) 000 / 001 000

YCM146 (Not display) 000 / 001 001

YCM147 (Not display) 000 / 001 000

YCM148 (Not display) 000 / 001 001

YCM149 (Not display) 000 / 001 000

YCM150 (Not display) 000 / 001 000

YCM151 (Not display) 000~255 136

YCM152 (Not display) 000 / 001 001

YCM153 (Not display) 000 / 001 001

YCM154 (Not display) 000 / 001 001

YCM155 (Not display) 000~003 000

YCM156 (Not display) 000~015 015

YCM157 (Not display) 000~015 004

YCM158 (Not display) 000 / 001 001

YCM159 (Not display) 000~127 004

YCM160 (Not display) 000 / 001 001

YCM161 (Not display) 000~031 000

YCM162 (Not display) 000 / 001 000

YCM163 (Not display) 000~015 003

YCM164 (Not display) 000~007 002

YCM165 (Not display) 000~031 016

YCM166 (Not display) 000~255 235

YCM167 (Not display) 000~003 000

YCM168 (Not display) 000~063 000

YCM169 (Not display) 000~015 003

YCM170 (Not display) 000~015 003

YCM171 (Not display) 000~007 000

YCM172 (Not display) 000~255 096

YCM173 (Not display) 000~007 003

Variable

range

Initial setting

value

(No.52105)1-37

AV-48WP74 AV-56WP74

Item No. Item name

YCM174 (Not display) 000~255 056

YCM175 (Not display) 000 / 001 000

YCM176 (Not display) 000 / 001 000

YCM177 (Not display) 000~255 022

YCM178 (Not display) 000 / 001 001

YCM179 (Not display) 000 / 001 000

YCM180 (Not display) 000~007 004

YCM181 (Not display) 000~003 001

YCM182 (Not display) 000~003 001

YCM183 (Not display) 000~003 001

YCM184 (Not display) 000~003 001

YCM185 (Not display) 000~255 000

YCS001 (Not display) 000 / 001 000

YCS002 (Not display) 000 / 001 000

YCS003 (Not display) 000 / 001 000

YCS004 (Not display) 000~003 001

YCS005 (Not display) 000~255 239

YCS006 (Not display) 000~003 001

YCS007 (Not display) 000~255 239

YCS008 (Not display) 000 / 001 000

YCS009 (Not display) 000~003 000

YCS010 (Not display) 000 / 001 000

YCS011 (Not display) 000 / 001 000

YCS012 (Not display) 000 / 001 000

YCS013 (Not display) 000 / 001 000

YCS014 (Not display) 000~003 000

YCS015 (Not display) 000 / 001 000

YCS016 (Not display) 000~003 001

YCS017 (Not display) 000 / 001 001

YCS018 (Not display) 000~003 000

YCS019 (Not display) 000~001 000

YCS020 (Not display) 000~001 000

YCS021 (Not display) 000~003 002

YCS022 (Not display) 000~007 004

YCS023 (Not display) 000 / 001 001

YCS024 (Not display) 000 / 001 000

YCS025 (Not display) 000~015 005

YCS026 (Not display) 000~015 003

YCS027 (Not display) 000~003 000

YCS028 (Not display) 000~007 003

YCS029 (Not display) 000~007 006

YCS030 (Not display) 000~003 003

YCS031 (Not display) 000 / 001 000

YCS032 (Not display) 000~003 003

YCS033 (Not display) 000 / 001 001

Variable

range

Initial setting

value

Item No. Item name

YCS034 (Not display) 000 / 001 000

YCS035 (Not display) 000~255 096

YCS036 (Not display) 000 / 001 001

YCS037 (Not display) 000~003 001

YCS038 (Not display) 000~127 062

YCS039 (Not display) 000~127 068

YCS040 (Not display) 000~003 001

YCS041 (Not display) 000~063 016

YCS042 (Not display) 000 / 001 000

YCS043 (Not display) 000 / 001 000

YCS044 (Not display) 000~255 144

YCS045 (Not display) 000 / 001 000

YCS046 (Not display) 000~255 100

YCS047 (Not display) 000 / 001 001

YCS048 (Not display) 000~031 000

YCS049 (Not display) 000~003 000

YCS050 (Not display) 000~015 000

YCS051 (Not display) 000~015 008

YCS052 (Not display) 000~015 001

YCS053 (Not display) 000~063 030

YCS054 (Not display) 000~255 030

YCS055 (Not display) 000 / 001 001

YCS056 (Not display) 000~063 016

YCS057 (Not display) 000~015 008

YCS058 (Not display) 000~015 005

YCS059 (Not display) 000~015 008

YCS060 (Not display) 000~015 005

YCS061 (Not display) 000~015 000

YCS062 (Not display) 000~015 002

YCS063 (Not display) 000~015 008

YCS064 (Not display) 000~015 006

YCS065 (Not display) 000~255 010

YCS066 (Not display) 000~255 032

YCS067 (Not display) 000~255 031

YCS068 (Not display) 000~255 064

YCS069 (Not display) 000 / 001 000

YCS070 (Not display) 000 / 001 001

YCS071 (Not display) 000 / 001 001

YCS072 (Not display) 000 / 001 001

YCS073 (Not display) 000 / 001 000

YCS074 (Not display) 000 / 001 001

YCS075 (Not display) 000 / 001 000

YCS076 (Not display) 000 / 001 000

YCS077 (Not display) 000 / 001 001

YCS078 (Not display) 000 / 001 000

Variable

range

Initial setting

value

1-38 (No.52105)

AV-48WP74 AV-56WP74

Item No. Item name

YCS079 (Not display) 000 / 001 000

YCS080 (Not display) 000~003 003

YCS081 (Not display) 000 / 001 000

YCS082 (Not display) 000~255 000

YCS083 (Not display) 000~255 000

YCS084 (Not display) 000~007 000

YCS085 (Not display) 000~255 014

YCS086 (Not display) 000 / 001 000

YCS087 (Not display) 000 / 001 001

YCS088 (Not display) 000 / 001 000

YCS089 (Not display) 000 / 001 000

YCS090 (Not display) 000~255 136

YCS091 (Not display) 000 / 001 001

YCS092 (Not display) 000 / 001 001

YCS093 (Not display) 000 / 001 001

YCS094 (Not display) 000~003 000

YCS095 (Not display) 000~015 015

YCS096 (Not display) 000~015 004

YCS097 (Not display) 000 / 001 001

YCS098 (Not display) 000~127 007

YCS099 (Not display) 000~031 000

YCS100 (Not display) 000 / 001 000

YCS101 (Not display) 000~015 003

YCS102 (Not display) 000~007 002

YCS103 (Not display) 000~031 016

YCS104 (Not display) 000~255 235

YCS105 (Not display) 000~003 000

YCS106 (Not display) 000~063 000

YCS107 (Not display) 000~015 003

YCS108 (Not display) 000~015 003

YCS109 (Not display) 000 / 001 000

YCS110 (Not display) 000~003 001

YCS111 (Not display) 000~003 001

YCS112 (Not display) 000~003 001

YCS113 (Not display) 000~003 001

YCS114 (Not display) 000~255 000

Variable

range

Initial setting

value

3.7.3 [3.WHITE BALANCE]

NOTE :

Initial setting value is reference value at following condition. INPUT SYGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPRETURE : LOW

Item No. Item name

BR (Not display) 000~238 133

DRV R (Not display) 000~255 072

DRV B (Not display) 000~255 060

DRV R (Not display) 000~255 188

DRV G (Not display) 000~255 149

DRV B (Not display) 000~255 215

3.7.4 [6.CONVER A]

Item No. Item name

CPA01 OSD H 0~4095 147

CPA02 OSD V 0~1023 18

CPA03 FINE H 0~4095 1660

CPA04 FINE V 0~4095 50

CPA05 CAU V 0~4095 3920

CPA06 CAU H1 0~65535 0

CPA07 CAU H2 0~255 11

CPA08 FINE OFF 0 / 1 0

CCA01 C H CENT -512~+511 0

CCA02 C H SIZE -512~+511 -12

CCA03 C H LINE -512~+511 -29

CCA04 C H SKEW -512~+511 0

CCA05 C EW PIN -512~+511 17

CCA06 C H BOW -512~+511 0

CCA07 C V CENT -512~+511 0

CCA08 C V SKEW -512~+511 0

CCA09 C V SIZE -512~+511 -95

Item No. Item name

CBA01 LINE COMP 0~3 2

CBA02 INTER NUM 0~15 9

CBA03 INTERLACE 0 / 1 0

CBA04 ADD RATIO 0~3 0

CBA05 DAC NUM 0 / 1 1

CBA06 CKOUT FRF 0~7 0

CBA07 ODD LAVEL 0 / 1 1

CBA08 V1CNTUP 0~4095 310

CBA09 RETRACE 0 / 1 1

CBA10 RV CLAMP 0 / 1 1

Variable

range

Variable

range

Variable

range

Initial setting

value

Initial setting

value

Initial setting

value

(No.52105)1-39

AV-48WP74 AV-56WP74

Item No. Item name

CBA11 GV CLAMP 0 / 1 1

CBA12 BV CLAMP 0 / 1 1

CBA13 RH CLAMP 0 / 1 0

CBA14 GH CLAMP 0 / 1 0

CBA15 BH CLAMP 0 / 1 0

CBA16 PATTERN H 1 0~3 1

CBA17 PATTERN W 1 0~3 1

CBA18 CURSPACE 0~3 0

CBA19 ODEV POSI 0~4095 1

CBA20 HBLKOUT 0 / 1 1

CBA21 HBLKOP 0~4095 2091

CBA22 HBLKOW 0~4095 373

CBA23 PWM1P 0~4095 0

CBA24 PWM1W 0~4095 256

CBA25 PWM2P 0~4095 0

CBA26 PWM2W 0~4095 0

CBA27 VBLK01P 0~1023 0

CBA28 VBLK01W 0~1023 1

CBA29 VBLK02P 0~1023 0

CBA30 VBLK02W 0~1023 0

CBA31 VBLK03P 0~1023 0

CBA32 VBLK03W 0~1023 0

CBA33 VBLK04P 0~1023 0

CBA34 VBLK04W 0~1023 0

CBA35 HATCH COL 0~7 2

CBA36 BORDE COL 0~7 0

CBA37 CROSS COL 0~7 0

CBA38 BLOCK COL 0~7 0

CBA39 AF1 POSV 0~2490 0

CBA40 AF1POSH 0~4095 62

CBA41 AF1VSIZE 0~255 200

CBA42 AF1HSIZE 0~511 100

CBA43 AF2POSV 0~2490 548

CBA44 AF2POSH 0~4095 200

CBA45 AF2VSIZE 0~255 100

CBA46 AF2HSIZE 0~511 200

CBA47 AF3POSV 0~2490 946

CBA48 AF3POSH 0~4095 1061

CBA49 AF3VSIZE 0~255 200

CBA50 AF3HSIZE 0~511 100

CBA51 AF4POSV 0~2490 546

CBA52 AF4POSH 0~4095 1730

CBA53 AF4VSIZE 0~255 100

CBA54 AF4HSIZE 0~511 200

CBA55 AF5POSH 0~2490 548

Variable

range

Initial setting

value

Item No. Item name

CBA56 AF5POSV 0~4095 1016

CBA57 AF5HSIZE 0~255 4

CBA58 AF5VSIZE 0~511 80

CBA59 AF6POSH 0~2490 505

CBA60 AF6POSV 0~4095 1056

CBA61 AF6VSIZE 0~255 80

CBA62 AF6HSIZE 0~511 4

CBA63 AF7POSV 0~2490 0

CBA64 AF7POSH 0~4095 0

CBA65 AF7VSIZE 0~255 0

CBA66 AF7HSIZE 0~511 0

CBA67 AF8POSV 0~2490 0

CBA68 AF8POSH 0~4095 0

CBA69 AF8VSIZE 0~255 0

CBA70 AF8HSIZE 0~511 0

CBA71 BL1POSV 0~2490 0

CBA72 BL1POSH 0~4095 0

CBA73 BL2POSV 0~255 0

CBA74 BL2POSH 0~511 0

CBA75 XLPOSV 0~2490 545

CBA76 XLPOSH 0~4095 1056

CBA77 XLLENV 0~255 185

CBA78 XLLENH 0~511 421

CBA79 FINE LIMT 0~2490 80

CBA80 DC LIMT 0~4095 50

3.7.5 [8.PP]

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC

ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

ADM001 (Not display) 000~0FF 0D6

ADM002 (Not display) 000~00F 007

ADM003 (Not display) 000~003 001

ADM004 (Not display) 000~007 005

ADM005 (Not display) 000~01F 016

ADM006 (Not display) 000~0FF 036

ADM007 (Not display) 000~0FF 08A

ADM008 (Not display) 000~0FF 020

Variable

range

Variable

range

Initial setting

value

Initial setting

value

1-40 (No.52105)

AV-48WP74 AV-56WP74

Item No. Item name

ADM009 (Not display) 000~0FF 0FF

ADM010 (Not display) 000~0FF 0FF

ADM011 (Not display) 000~0FF 0FF

ADM012 (Not display) 000~07F 03A

ADM013 (Not display) 000~07F 02C

ADM014 (Not display) 000~07F 03C

ADM015 (Not display) 000 / 001 001

ADM016 (Not display) 000 / 001 001

ADM017 (Not display) 000 / 001 000

ADM018 (Not display) 000 / 001 001

ADM019 (Not display) 000 / 001 000

ADM020 (Not display) 000 / 001 000

ADM021 (Not display) 000 / 001 001

ADM022 (Not display) 000 / 001 000

ADM023 (Not display) 000 / 001 000

ADM024 (Not display) 000 / 001 001

ADM025 (Not display) 000 / 001 000

ADM026 (Not display) 000 / 001 001

ADM027 (Not display) 000 / 001 001

ADM028 (Not display) 000 / 001 001

ADM029 (Not display) 000 / 001 001

ADM030 (Not display) 000~01F 003

ADM031 (Not display) 000 / 001 001

ADM032 (Not display) 000 / 001 000

ADM033 (Not display) 000 / 001 001

ADM034 (Not display) 000~0FF 032

Item No. Item name

PPA001 (Not display) 000~255 000

PPA002 (Not display) 000~255 000

PPA003 (Not display) 000~255 047

PPA004 (Not display) 000~255 000

PPA005 (Not display) 000~255 000

PPA006 (Not display) 000~255 001

PPA007 (Not display) 000~255 047

PPA008 (Not display) 000~255 023

Item No. Item name

PPB001 (Not display) 000~031 000

PPB002 (Not display) 000~255 000

PPB003 (Not display) 000~255 000

PPB004 (Not display) 000~031 000

PPB005 (Not display) 000~255 00D

PPB006 (Not display) 000~255 0F8

PPB007 (Not display) 000~031 000

Variable

range

Variable

range

Variable

range

Initial setting

value

Initial setting

value

Initial setting

value

Item No. Item name

PPB008 (Not display) 000~255 01B

PPB009 (Not display) 000~255 0D0

PPB010 (Not display) 000~031 000

PPB011 (Not display) 000~255 000

Item No. Item name

PPB012 (Not display) 000~255 000

PPB013 (Not display) 000~031 000

PPB014 (Not display) 000~255 000

PPB015 (Not display) 000~255 000

PPB016 (Not display) 000~031 000

PPB017 (Not display) 000~255 000

PPB018 (Not display) 000~255 000

PPB019 (Not display) 000~031 000

PPB020 (Not display) 000~255 000

PPB021 (Not display) 000~255 000

PPB022 (Not display) 000~031 000

PPB023 (Not display) 000~255 000

PPB024 (Not display) 000~255 000

PPB025 (Not display) 000~031 000

PPB026 (Not display) 000~255 000

PPB027 (Not display) 000~255 000

PPB028 (Not display) 000~031 000

PPB029 (Not display) 000~255 000

PPB030 (Not display) 000~255 000

PPB031 (Not display) 000~031 000

PPB032 (Not display) 000~255 000

PPB033 (Not display) 000~255 000

PPB034 (Not display) 000~031 000

PPB035 (Not display) 000~255 000

PPB036 (Not display) 000~255 000

Item No. Item name

PPC001 (Not display) 000~00F 000

PPC002 (Not display) 000~0FF 00C

PPC003 (Not display) 000~0FF 002

PPC004 (Not display) 000~00F 000

PPC005 (Not display) 000~0FF 000

PPC006 (Not display) 000~00F 000

PPC007 (Not display) 000~0FF 000

PPC008 (Not display) 000~03F 000

Variable

range

Variable

range

Variable

range

Initial setting

value

Initial setting

value

Initial setting

value

(No.52105)1-41

AV-48WP74 AV-56WP74

Item No. Item name

PPD001 (Not display) 000~0FF 008

PPD002 (Not display) 000~00F 063

PPD003 (Not display) 000~0FF 063

PPD004 (Not display) 000~00F 0CB

PPD005 (Not display) 000~0FF 0C0

PPD006 (Not display) 000~00F 045

PPD007 (Not display) 000~0FF 041

PPD008 (Not display) 000~00F 035

PPD009 (Not display) 000~0FF 030

PPD010 (Not display) 000~00F 000

PPD011 (Not display) 000~0FF 024

PPD012 (Not display) 000~00F 001

PPD013 (Not display) 000~0FF 039

PPD014 (Not display) 000~00F 000

PPD015 (Not display) 000~0FF 096

PPD016 (Not display) 000~00F 001

PPD017 (Not display) 000~0FF 086

PPD018 (Not display) 000~00F 000

PPD019 (Not display) 000~0FF 024

PPD020 (Not display) 000~00F 001

PPD021 (Not display) 000~0FF 050

PPD022 (Not display) 000~00F 000

PPD023 (Not display) 000~0FF 0AA

PPD024 (Not display) 000~00F 001

PPD025 (Not display) 000~0FF 072

3.7.6 [9.IP] (All fixed)

NOTE :

Initial setting value is reference value at following condition. INPUT SIGNAL : NTSC ASPECT : FULL MULTI : SINGLE VIDEO STATUS : STANDARD COLOR TEMPERATURE : LOW

Item No. Item name

IPA001 (Not display) 000 / 001 001

IPA002 (Not display) 000~03F 030

IPA003 (Not display) 000~03F 02E

IPA004 (Not display) 000~03F 030

IPA005 (Not display) 000~003 000

IPA006 (Not display) 000~003 000

IPA007 (Not display) 000~00F 008

IPA008 (Not display) 000~03F 000

IPA009 (Not display) 000~03F 01D

IPA010 (Not display) 000~03F 010

IPA011 (Not display) 000~03F 018

Variable

range

Variable

range

Initial setting

value

Initial setting

value

Item No. Item name

IPA012 (Not display) 000~03F 028

IPA013 (Not display) 000~003 002

IPA014 (Not display) 000~003 002

IPA015 (Not display) 000~00F 00F

IPA016 (Not display) 000~03F D1B

IPA017 (Not display) 000 / 001 001

IPA018 (Not display) 000~03F 0FF

IPA019 (Not display) 000 / 001 001

IPA020 (Not display) 000 / 001 001

IPA021 (Not display) 000~03F 01F

IPA022 (Not display) 000~003 000

IPA023 (Not display) 000~03F 008

IPA024 (Not display) 000 / 001 001

IPA025 (Not display) 000 / 001 001

IPA026 (Not display) 000~03F 01F

IPA027 (Not display) 000~003 000

IPA028 (Not display) 000~03F 008

IPA029 (Not display) 000~03F 01C

IPA030 (Not display) 000~00F 000

IPA031 (Not display) 000~007 001

IPA032 (Not display) 000~03F 010

IPA033 (Not display) 000 / 001 001

IPA034 (Not display) 000~03F 034

IPA035 (Not display) 000 / 001 001

IPA036 (Not display) 000~03F 00E

IPA037 (Not display) 000~03F 02E

IPA038 (Not display) 000~03F 01E

IPA039 (Not display) 000~003 002

IPA040 (Not display) 000~003 003

IPA041 (Not display) 000~00F 008

IPA042 (Not display) 000~03F 020

IPA043 (Not display) 000~03F 020

IPA044 (Not display) 000~03F 006

IPA045 (Not display) 000~03F 00E

IPA046 (Not display) 000~03F 01E

IPA047 (Not display) 000~003 002

IPA048 (Not display) 000~003 003

IPA049 (Not display) 000~00F 008

IPA050 (Not display) 000~03F 020

IPA051 (Not display) 000 / 001 001

IPA052 (Not display) 000~03F 020

IPA053 (Not display) 000 / 001 001

IPA054 (Not display) 000 / 001 001

IPA055 (Not display) 000~03F 020

IPA056 (Not display) 000~003 002

Variable

range

Initial setting

value

1-42 (No.52105)

AV-48WP74 AV-56WP74

Item No. Item name

IPA057 (Not display) 000~03F 020

IPA058 (Not display) 000 / 001 001

IPA059 (Not display) 000 / 001 001

IPA060 (Not display) 000~03F 020

IPA061 (Not display) 000~003 002

IPA062 (Not display) 000~03F 020

IPA063 (Not display) 000~03F 020

IPA064 (Not display) 000~00F 008

IPA065 (Not display) 000~007 002

IPA066 (Not display) 000~03F 020

IPA067 (Not display) 000 / 001 001

IPA068 (Not display) 000~03F 020

IPA069 (Not display) 000~003 000

IPA070 (Not display) 000~0FF 000

IPA071 (Not display) 000~00F 008

IPA072 (Not display) 000~0FF 098

IPA073 (Not display) 000 / 001 000

IPA074 (Not display) 000 / 001 000

IPA075 (Not display) 000~0FF 013

IPA076 (Not display) 000 / 001 000

IPA077 (Not display) 000 / 001 000

IPA078 (Not display) 000 / 001 000

IPA079 (Not display) 000 / 001 000

IPA080 (Not display) 000 / 001 000

IPA081 (Not display) 000 / 001 000

IPA082 (Not display) 000 / 001 000

IPA083 (Not display) 000 / 001 000

IPA084 (Not display) 000 / 001 000

IPA085 (Not display) 000 / 001 000

IPA086 (Not display) 000 / 001 000

IPA087 (Not display) 000 / 001 000

IPA088 (Not display) 000 / 001 000

IPA089 (Not display) 000 / 001 000

IPA090 (Not display) 000 / 001 000

IPA091 (Not display) 000~00F 000

IPA092 (Not display) 000~0FF 000

IPA093 (Not display) 000~00F 00F

IPA094 (Not display) 000~0FF 0FF

IPA095 (Not display) 000~00F 000

IPA096 (Not display) 000~0FF 000

IPA097 (Not display) 000~00F 00F

IPA098 (Not display) 000~0FF 0FF

IPA099 (Not display) 000~00F 000

IPA100 (Not display) 000~0FF 000

IPA101 (Not display) 000~00F 000

Variable

range

Initial setting

value

Item No. Item name

IPA102 (Not display) 000~0FF 000

IPA103 (Not display) 000~00F 000

IPA104 (Not display) 000~0FF 000

IPA105 (Not display) 000~00F 000

IPA106 (Not display) 000~0FF 000

IPA107 (Not display) 000~00F 000

IPA108 (Not display) 000~0FF 080

IPA109 (Not display) 000~00F 000

IPA110 (Not display) 000~0FF 040

IPA111 (Not display) 000~00F 005

IPA112 (Not display) 000~0FF 040

IPA113 (Not display) 000~00F 000

IPA114 (Not display) 000~0FF 0C0

IPA115 (Not display) 000~00F 002

IPA116 (Not display) 000~0FF 0ET

IPA117 (Not display) 000 / 001 000

IPA118 (Not display) 000 / 001 000

IPA119 (Not display) 000 / 001 000

IPA120 (Not display) 000 / 001 000

Item No. Item name

IPB001 (Not display) 000~0FF 000

IPB002 (Not display) 000~0FF 0D4

IPB003 (Not display) 000~00F 000

IPB004 (Not display) 000~0FF 0FC

IPB005 (Not display) 000~00F 003

IPB006 (Not display) 000~0FF 089

IPB007 (Not display) 000~00F 003

IPB008 (Not display) 000~0FF 089

IPB009 (Not display) 000~00F 002

IPB010 (Not display) 000~0FF 02D

IPB011 (Not display) 000~00F 001

IPB012 (Not display) 000~0FF 073

IPB013 (Not display) 000~00F 000

IPB014 (Not display) 000~0FF 069

IPB015 (Not display) 000~00F 000

IPB016 (Not display) 000~0FF 00E

IPB017 (Not display) 000~00F 000

IPB018 (Not display) 000~0FF 016

IPB019 (Not display) 000~00F 000

IPB020 (Not display) 000~0FF 010

IPB021 (Not display) 000~00F 000

IPB022 (Not display) 000~0FF 02D

IPB023 (Not display) 000~00F 000

IPB024 (Not display) 000~0FF 000

Variable

range

Variable

range

Initial setting

value

Initial setting

value

(No.52105)1-43

AV-48WP74 AV-56WP74

Item No. Item name

IPB025 (Not display) 000~00F 00F

IPB026 (Not display) 000~0FF 000

IPB027 (Not display) 000~00F 005

IPB028 (Not display) 000~0FF 033

IPB029 (Not display) 000~00F 000

IPB030 (Not display) 000~0FF 04A

IPB031 (Not display) 000~00F 00F

IPB032 (Not display) 000~0FF 000

IPB033 (Not display) 000~00F 00F

IPB034 (Not display) 000~0FF 000

IPB035 (Not display) 000~00F 001

IPB036 (Not display) 000~0FF 000

IPB037 (Not display) 000 / 001 000

IPB038 (Not display) 000~007 000

IPB039 (Not display) 000~00F 000

IPB040 (Not display) 000~00F 003

IPB041 (Not display) 000~00F 000

IPB042 (Not display) 000~0FF 000

IPB043 (Not display) 000~00F 002

IPB044 (Not display) 000~0FF 0DB

IPB045 (Not display) 000~00F 000

IPB046 (Not display) 000~0FF 000

IPB047 (Not display) 000~00F 00F

IPB048 (Not display) 000~0FF 0FF

IPB049 (Not display) 000~00F 00F

IPB050 (Not display) 000~0FF 0FF

IPB051 (Not display) 000~00F 00F

IPB052 (Not display) 000~0FF 0FF

IPB053 (Not display) 000~00F 00F

IPB054 (Not display) 000~0FF 0FF

IPB055 (Not display) 000~00F 000

IPB056 (Not display) 000~0FF 0CE

IPB057 (Not display) 000~00F 00F

IPB058 (Not display) 000~0FF 000

IPB059 (Not display) 000~007 004

IPB060 (Not display) 000~003 000

IPB061 (Not display) 000~003 002

IPB062 (Not display) 000 / 001 000

IPB063 (Not display) 000~0FF 040

IPB064 (Not display) 000~0FF 080

IPB065 (Not display) 000~0FF 080

IPB066 (Not display) 000 / 001 000

IPB067 (Not display) 000~00F 000

IPB068 (Not display) 000~00F 000

IPB069 (Not display) 000~00F 000

Variable

range

Initial setting

value

Item No. Item name

IPB070 (Not display) 000~00F 00F

IPB071 (Not display) 000~0FF 000

IPB072 (Not display) 000~00F 000

IPB073 (Not display) 000~0FF 000

IPB074 (Not display) 000 / 001 000

IPB075 (Not display) 000 / 001 000

IPB076 (Not display) 000 / 001 000

IPB077 (Not display) 000~00F 001

IPB078 (Not display) 000 / 001 001

IPB079 (Not display) 000~0FF 089

Item No. Item name

IPC001 (Not display) 000~003 002

IPC002 (Not display) 000~0FF 018

IPC003 (Not display) 000 / 001 000

IPC004 (Not display) 000 / 001 000

IPC005 (Not display) 000~00F 000

IPC006 (Not display) 000~0FF 000

IPC007 (Not display) 000~00F 008

IPC008 (Not display) 000~0FF 097

IPC009 (Not display) 000~00F 004

IPC010 (Not display) 000~0FF 064

IPC011 (Not display) 000~00F 000

IPC012 (Not display) 000~0FF 000

IPC013 (Not display) 000~003 000

IPC014 (Not display) 000 / 001 000

IPC015 (Not display) 000 / 001 001

IPC016 (Not display) 000~0FF 000

IPC017 (Not display) 000 / 001 000

IPC018 (Not display) 000~07F 000

IPC019 (Not display) 000 / 001 000

IPC020 (Not display) 000~07F 001

IPC021 (Not display) 000~00F 000

IPC022 (Not display) 000~0FF 068

IPC023 (Not display) 000~003 000

IPC024 (Not display) 000~0FF 00F

IPC025 (Not display) 000 / 001 000

IPC026 (Not display) 000~07F 020

IPC027 (Not display) 000~001 000

IPC028 (Not display) 000~07F 01B

IPC029 (Not display) 000 / 001 001

IPC030 (Not display) 000 / 001 000

IPC031 (Not display) 000 / 001 000

IPC032 (Not display) 000 / 001 001

IPC033 (Not display) 000 / 001 000

Variable

range

Variable

range

Initial setting

value

Initial setting

value

1-44 (No.52105)

AV-48WP74 AV-56WP74

Item No. Item name

IPC034 (Not display) 000 / 001 000

IPC035 (Not display) 000 / 001 000

IPC036 (Not display) 000 / 001 000

IPC037 (Not display) 000 / 001 000

IPC038 (Not display) 000 / 001 000

IPC039 (Not display) 000 / 001 001

IPC040 (Not display) 000 / 001 000

IPC041 (Not display) 000 / 001 000

IPC042 (Not display) 000 / 001 000

IPC043 (Not display) 000 / 001 000

IPC044 (Not display) 000 / 001 000

Item No. Item name

IPD001 (Not display) 000~0FF 040

IPD002 (Not display) 000~0FF 000

IPD003 (Not display) 000~0FF 000

IPD004 (Not display) 000~007 000

IPD005 (Not display) 000~0FF 014

IPD006 (Not display) 000~007 002

IPD007 (Not display) 000~0FF 034

IPD008 (Not display) 000 / 001 001

IPD009 (Not display) 000~00F 001

IPD010 (Not display) 000~0FF 03C

IPD011 (Not display) 000~00F 008

IPD012 (Not display) 000~0FF 086

IPD013 (Not display) 000~007 001

IPD014 (Not display) 000~007 000

IPD015 (Not display) 000 / 001 000

IPD016 (Not display) 000 / 001 000

IPD017 (Not display) 000~0FF 000

IPD018 (Not display) 000~007 000

IPD019 (Not display) 000~0FF 018

IPD020 (Not display) 000~007 002

IPD021 (Not display) 000~0FF 02F

IPD022 (Not display) 000 / 001 001

IPD023 (Not display) 000~00F 001

IPD024 (Not display) 000~0FF 03D

IPD025 (Not display) 000~00F 008

IPD026 (Not display) 000~0FF 042

Variable

range

Variable

range

Initial setting

value

Initial setting

value

Item No. Item name

IPE001 (Not display) 000~255 001

IPE002 (Not display) 000~255 002

IPE003 (Not display) 000~255 001

IPE004 (Not display) 000~255 002

IPE005 (Not display) 000~255 001

IPE006 (Not display) 000~255 002

IPE007 (Not display) 000~255 001

IPE008 (Not display) 000~255 001

IPE009 (Not display) -128~+127 +015

IPE010 (Not display) -128~+127 +015

IPE011 (Not display) -128~+127 +015

IPE012 (Not display) -128~+127 +015

IPE013 (Not display) -128~+127 -004

IPE014 (Not display) -128~+127 +008

IPE015 (Not display) 000~015 068

Variable

range

Initial setting

value

(No.52105)1-45

AV-48WP74 AV-56WP74

3.8 ADJUSTMENT PROCEDURE

3.8.1 CHECK ITEMS

Item

HIGH VOLTAGE check

Measuring instrument

Signal generator

High voltage meter

Test point Adjustment part Description

CRT Anode (1) Receive NTSC whole black signal.

(2) Connect the high voltage meter between CRT anode

and GND.

(3) Check that the high voltage range DC 31.0kV±1.0kV.

X-RAY PROTECTOR check

3.8.2 HORIZONTAL FREQUENCY ADJUSTMENT

Item

H. FREQUENCY adjustment

Resistor [6.8k ohm 1/4W ±5%]

Measuring instrument

Signal generator

Remote control unit

S1 connector 2 pin : X-Ray2 3 pin : X-Ray1

Test point Adjustment part Description

[1.PICTURE/SOUND] D15 : H. FREQ. D19 : DEF. RST

(1) Receive any broadcast. (2) Connect resistor 6.8k ohm(1/4W, ±5%) between 2 pin

& 3 pin of the connector S1.

(3) Confirm that the X-RAY protector functions operated.

(1) Receive any broadcast. (2) Press [ASPECT] key and select FULL mode. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select <D19> (DEF. RST) and change the data 0 to 1. (5) While observing the screen, adjust the <D15> (H.

FREQ) so that an optimum horizontal synchronization is obtained.

(6) After adjustment, select <D19> and change the data

1 to 0.

(7) Press [MUTING] key to memorize the set value.

1-46 (No.52105)

3.8.3 FOCUS & BEAM SPOT ADJUSTMENT

Item

FOCUS & BEAM SPOT

Measuring

instrument

Signal generator

Test point Adjustment part Description

adjustment

Similar adhesive (Securing adhesive)

DEFLECTION

YOKE

LENS FOCUS

SCREW

PROJECTION UNIT & LENS ASS'Y

(CRT adjustment location)

CRT FOCUS adjustment point

CENTERING

MAGNET

4 POLE MAGNET

R Def. Yoke (DY) G Def. Yoke (DY) B Def. Yoke (DY) [PROJECTION UNIT]

R LENS FOCUS screw G LENS FOCUS screw B LENS FOCUS screw [PROJECTION UNIT (LENS ASS'Y)]

R SCREEN VR G SCREEN VR B SCREEN VR [FOCUS PACK]

4 pole magnet 2 pole magnet [PROJECTION UNIT (R / G / B CRT neck)]

R FOCUS VR G FOCUS VR B FOCUS VR [FOCUS PACK]

2 POLE MAGNET

AV-48WP74 AV-56WP74

(1) Receive NTSC cross-hatch signal. (2) Press [ASPECT] key and select FULL mode. (3) If the picture tilted, adjust the R, G and B DY position

to mark straight horizontal line.

LENS FOCUS

(1) Makes a red single color.

NOTE :

When making a single color, It squeezes SCREEN VR in each one, or it does a lid to the lens in of the adjustment color and it makes it single color.

(2) By turning the LENS FOCUS screw (in LENS

ASS'Y), for optimum focus at the screen center. Check for absence of difference in the peripheral focus. If the peripheral focus is poor, slightly shift the center focus to obtain overall balanced focus.

(3) In the same manner, produce green and blue single

color and adjust their respective focus.

(4) After adjustment, it fixes a screw.

NOTE :

There is not a difference in the focus in the top and the bottom, on either side, in the diagonal. When the difference of the focus is big, it removes a main lens, and it puts a washer between the main lens and the coupler and it adjusts it.

BEAM SPOT

(5) Receive NTSC dot pattern signal. (6) Makes a red single color.

NOTE :

When making a single color, It squeezes SCREEN VR in each one, or it does a lid to the lens in of the adjustment color and it makes it single color.

(7) Turn the R FOCUS VR to set the dot diameter to

about Ø30mm.

(8) Turn the 4 pole magnet of the projection unit CRT

neck and to where the dots at the screen center are nearly circular.

(9) Return the R FOCUS VR to its original position (just

focus).

(10) Turn the 2 pole magnet of the CRT neck to minimize

expansion of the dots.

(11) In the same manner, adjust for the green and blue

single color focus.

(12) Secure the 4 and 2 pole magnets with similar

adhesive.

CRT FOCUS

(13) Receive NTSC crosshatch signal. (14) Makes a red single color.

NOTE :

When making a single color, It squeezes SCREEN VR in each one, or it does a lid to the lens in of the adjustment color and it makes it single color.

(15) Adjust the R FOCUS VR for optimum focus at the

position indicated in the figure.

(16) In the same manner, adjust for the green and blue

single color focus.

(17) After adjustment, return the SCREEN VRs to their

original positions.

NOTE :

When moving screen VR, always return to original.

(No.52105)1-47

AV-48WP74 AV-56WP74

3.8.4 DEFLECTION & CONVERGENCE ADJUSTMENT

• The adjustment using the remote control unit is made on the basis of the initial setting values.

• The setting values which adjust the screen to the optimum condition can be different from the initial setting values.

• At first the adjustment in FULL mode should be done, then the data for the other ASPECT mode is corrected in the respective value at the same time.

3.8.4.1 FLOWCHART OF ADJUSTMENT

CAUTION:

All adjustments of the DEFLECTION circuit for this model should be carried out under the status without convergence operation. To enter the mode without convergence operation, select 1.PICTURE/SOUND and change the data in the setting item F62 from 0 to 1. (For details, please refer to the adjustment of DEFLECTION.) As a result, you can get the screen as shown in bellow figure. Adjust the DEFLECTION circuit in order of the steps indicated by the downward arrows. NOTE: When every adjustment of the DEFLECTION circuit has completed, start the adjustment of convergence.

Adjustment

location

sequence

PREPARATION

Without

Overall position & size

convergence operation

H.SIZE

Center

Center perimeter

(If center deviated, readjust)

Perimeter

(If center deviated, readjust)

Center (Final adjust)

R and B only

SCREEN TILT

PASTER CENTERING & H.POSITION /SIZE

(coarse)

DEFLECTION

V.POSITION / SIZE / LINEARITY

H.POSITION

SIDE PIN

TRAPEZIU

CONVERGENCE

CONVERGENCE PHASE

OVERALL CONVERGENCE

Crosshatch Completed

(From a collection of squares)

1-48 (No.52105)

3.8.4.2 PREPARATION

Item

SCREEN TILT adjustment

Measuring

instrument

Signal generator

Remote control unit

RASTER CENTERING &

Signal generator

H. POSITION / SIZE (coarse) adjustment

Remote control unit

L1=30mm L2=45mm

Test point Adjustment part Description

1. PICTER/SOUND menu

0F62

Select item Change value

0 1

R G B

[1.PICTURE/SOUND] F62 : Without convergence operation

G DEF. YOKE R DEF. YOKE B DEF. YOKE [PROJECTION UNIT]

[1.PICTURE/SOUND] D03 : H. SIZE D14 : H. CENTER F62 : Without convergence operation

G CENTERING magnet R CENTERING magnet B CENTERING magnet [DEF. YOKE]

AV-48WP74 AV-56WP74

• Confirm correct FOCUS adjustment. (1) Receive NTSC cross-hatch signal. (2) Select 1. PICTURE/SOUND from SERVICE MENU. (3) Select <F62> (Without convergence operation) with

[CH +] / [CH -] keys.

(4) Change the data 0 to 1, then it makes picture without

convergence operation.

(5) Makes a green single color.

NOTE :

When making a single color, It squeezes SCREEN VR in each one, or it does a lid to the lens in the adjustment color and it makes it single color.

(6) Temporarily secure the G deflection yoke to the top

of the neck and adjust the tilt of the deflection yoke so that the horizontal line at the center becomes flat. After adjustment, fasten the temporal screw.

(7) Adjust the tilt of the R and B deflection yokes in the

same manner as for green.

NOTE :

Make sure that the adjustment of CRT FOCUS is optimized at the center and at the fringe of the center in turn. If the proper adjustment has not been done, adjust FOCUS VR again.

(1) Receive NTSC circle (or cross-hatch) signal. (2) Select 1. PICTURE/SOUND from SERVICE MENU. (3) Select <F62> (Without convergence operation) with

[CH +] / [CH -] keys.

(4) Change the data 0 to 1, then it makes picture without

convergence operation.

(5) Makes a green single color.

NOTE :

When making a single color, it squeezes SCREEN VR in each one, or it does a lid to the lens in the adjustment color and it makes it single color.

(6) Select <D03> (H. SIZE) and shorten the level until

and perpendicular amplitude of vibration with until the blanking in Left and Right and on either side can be seen.

(7) Select <D14> (H. CENTER) and adjust horizontal

position to make the screen center and signal center.

(8) Select <D03> and adjust horizontal size to make

screen picture approx. 92% of H-SIZE.

(9) After adjustment, select <F62> and change the data

1 to 0. (10) Press [MUTING] key and memorize the set value. (11) Adjust G CENTERING magnet to make horizontal

and vertical line center as mechanical center of

screen. (12) Red and blue color too, are reflected by it. (13) Using R CENTERING magnet and B CENTERING

magnet, adjusts for the line of the red(L1) and the

blue(L2) to become the position of the left figure.

NOTE :

Vertical center position of the red and blue are the same as green.

(No.52105)1-49

AV-48WP74 AV-56WP74

3.8.4.3 DEFLECTION ADJUSTMENT

Item

V. POSITION / SIZE /

Measuring instrument

Signal generator

LINEARITY adjustment

Remote control unit

Test point Adjustment part Description

[1.PICTURE/SOUND] D01 : V. SIZE D05 : V. LINE D06 : V. CENT F62 : Without convergence operation

• To memorize every time after finish adjustment on each mode. (1) Receive NTSC circle pattern signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select <F62> (Without convergence operation). (5) Change the data 0 to 1, then it makes picture without

convergence operation.

(6) Select <D01> (V. SIZE), <D05> (V. LINE), <D06>

(V. CENT).

(7) Adjust <D01>, <D05> and <D06> to make A = B

(precision ±2mm), and adjust to make C = 55mm (AV-48WP74) / 75mm (AV-56WP74)

(8) Press [MUTING] key and memorize the set value.

NOTE :

Do not adjust <D04> (V. S-CORRECTION), if it is different vertical position after adjust vertical linearity, to adjust vertical position.

H. POSITION adjustment

H. SIZE adjustment

Signal generator

Remote control unit

Signal generator

Remote control unit

Screen size

(92%)

[1.PICTURE/SOUND] D14 : H. CENTER F62 : Without convergence operation

[1.PICTURE/SOUND] D03 : H. SIZE F62 : Without convergence operation

(1) Receive NTSC circle pattern signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select <F62> (Without convergence operation). (5) Change the data 0 to 1, then it makes picture without

convergence operation. (6) Select <D14> (H. CENTER). (7) Adjust <D14> to make D = E as shown figure. (8) Press [MUTING] key and memorize the set value.

(1) Receive NTSC cross-hatch signal. (2) Select FULL mode with [ASPECT] key. (3) Select 1. PICTURE/SOUND from SERVICE MENU. (4) Select <F62> (Without convergence operation). (5) Change the data 0 to 1, then it makes picture without

convergence operation. (6) Select <D03> (H. SIZE). (7) Adjust <D03> to make sure that the vertical screen

size of the picture size is 92%. (8) Press [MUTING] key and memorize the set value.

1-50 (No.52105)

Picture size

100%

AV-48WP74 AV-56WP74

Item

SIDE PIN adjustment

Measuring

instrument

Signal generator

Remote control unit

Test point Adjustment part Description

[1.PICTURE/SOUND] D02 : EW D08 : BOT.CORN D09 : TOP.CORN F62 : Without convergence operation

convergence operation.

(6) Select <D02> (EW), <D08> (BOT.CORN), <D09>

(TOP.CORN).

(7) Adjust <D02>, <D08>, <D09> to make the vertical

lines at the left and right edges of the screen straight.

(8) Press [MUTING] key and memorize the set value.

Straight

NOTE :

After making adjustments, confirm that the horizontal position is properly adjusted. If the horizontal is out of alignment, readjust it. Adjust H SIZE & SIDE PIN reparably.

TRAPEZIUM adjustment

Signal generator

Remote control unit

Parallel

[1.PICTURE/SOUND] D07 : EW.TRAP F62 : Without convergence operation

convergence operation. (6) Select <D07> (EW.TRAP). (7) Adjust <D07> to bring the vertical lines at the right

and left edges of the screen parallel. (8) Press [MUTING] key and memorize the set value.

NOTE :

After making adjustments, confirm that the horizontal position is properly adjusted. If the horizontal is out of alignment, readjust it. Adjust H SIZE & SIDE PIN reparably.

(No.52105)1-51

AV-48WP74 AV-56WP74

3.8.4.4 CONVERGENCE ADJUSTMENT(1) ••••••• RGB together

Item

CONVERGENCE PHASE adjustment

Screen center

Fig. 2:CPA03<FINE H> adj.

Measuring instrument

Signal generator

Remote control unit

Horizontal center line

Fig. 1:Screen center

Test point Adjustment part Description

[6.CONVER A] CPA03 : FINE H CPA04 : FINE V CPA05 : CAU V CPA07 : CAU H2

Vertical center line

Fig. 3:CPA04<FINE V> adj.

NOTE:

Retain the default value of this adjustment. It is not necessary to carry out the adjustment unless the image on the screen is significantly deformative. If you performed this adjustment, open the user MENU "INITIAL SETUP" and execute AUTO of CONVERGENCE after the adjustment. (1) Receive NTSC cross-hatch signal. (2) Select 6.CONVER A from SERVICE MENU. (3) Select <CPA03> (FINE H). (4) Adjust the peak A as shown in Fig. 2 agrees with the

horizontal center line by using [ 2 ] & [ 8 ] keys. (5) Select <CPA04> (FINE V). (6) Adjust the peak B as shown in Fig. 3 agrees with the

vertical center line by using [ 4 ] & [ 6 ] keys. (7) Select <CPA05> (CAU V). (8) Adjust the intersection point of the horizontal center

line and the vertical center line agrees with the

screen center by using [ 2 ] & [ 8 ]. (Fig.4) (9) Select < CPA07>(CAU H2).

(10) Adjust the intersection point of the horizontal center

line and the vertical center line agrees with the

screen center by using [ 4 ] & [ 6 ]. (Fig.5)

(11) Press [MUTING] key and memorize the set values.

Fig. 4:CPA05<CAU V> adj.

REMOTE CONTROL KEY POSITION

VCR

CATV

MULTI SCREEN

SPLIT

POP

FREEZE

SWAP

INPUT1

INPUT2

INPUT3

INPUT4

THEATER

DIGITAL-IN

PRO

SLEEP TIMER

DISPLAY

MUTING

VOL

VCR CHANNEL

PREV NEXT

REC

OPEN/CLOSE

DVD

100+

NATURAL

PLAY FFREW

STOP

RM-C1200G

Fig. 5:CPA07<CAU H> adj.

POWER

ASPECT

INDEX

EZ SURF

SELECT

CINEMA

SOUND

VCR/DVD

POWER

STILL/PAUSE

VOL

PAUSE

RETURN+ /TV

VIDEO

STATUS

LIGHT

TV/VCR

C.C.

BACK

Number key

Screen center adjustment

[2] : Up [4] : Left [6] : Right [8] : Down

CH+ / CH- keys

Adjustment item select [CH +] : Up [CH - ] : Down

1-52 (No.52105)

3.8.4.5 DEFLECTION ADJUSTMENT(2) ••••••• RGB respectively

Item

OVERALL CONVERGENCE adjustment (1) [LINE]

Measuring

instrument

Signal generator

Remote control unit

Test point Adjustment part Description

[ 6.CONVER A ] CPA08 : FINE OFF CCA01 : C H CENT CCA02 : C H SIZE CCA03 : C H LIN CCA05 : C EW PIN CCA09 : V SIZE CCA10 : V KEY CCA11 : TB PIN

For this adjustment, it is necessary to use a remote control unit (e.g. RMC322G) with INPUT key. In order to change the adjusting items, use INPUT key. When you press INPUT key, the adjusting items will change in the order of CPA CCA CBA key.

Fourth lines from the horizontal center line right

A3A2

Cursor

AV-48WP74 1060

AV-56WP74 1240

Fourth lines from the vertical center line upward and downward.

182

348

600

164

213

407

102

700

192

136

159

SPAN TABLE (mm)

REMOTE CONTROL KEY POSITION

[RM-C322G]

VCR

CATV

DVD

POWER

ASPECT

MULTI SCREEN

SPLIT

POP

INDEX

EZ SURF

FREEZE

SWAP

INPUT key

CPA CCA CBA

MUTING key

For storing data in memory

adjustment

OK key

For display colors change for adjusting

INPUT1

INPUT2

INPUT3

INPUT4

DIGITAL-IN

SLEEP TIMER

MUTING

VCR CHANNEL

PREV NEXT

REC

OPEN/CLOSE

VOL

THEATER

PRO

DISPLAY

RM-C1200G

SELECT

100+

NATURAL

CINEMA

SOUND

VCR/DVD POWER

PLAY FFREW

STOP

RETURN+ /TV

VIDEO

STATUS

LIGHT

C.C.

VOL

BACK

TV/VCR

PAUSE

STILL/PAUSE

SELECT key

For adjusting

color change

CH+ / CH- key

Item No.change

[CH+] : up

[CH- ] : down

VOL+ / VOLkey

Setting value change

[VOL+] : up

[VOL -] : down

AV-48WP74 AV-56WP74

NOTE:

Retain the default value of this adjustment. It is not necessary to carry out the adjustment unless the image on the screen is significantly deformative. If you performed this adjustment, open the user MENU "INITIAL SETUP" and execute AUTO of CONVERGENCE after the adjustment. (1) Receive NTSC cross-hatch signal. (2) Select 6.CONVER A from SERVICE MENU. (3) Select <CPA08> (FINE OFF). (4) Change the data 0 to1. (Clear the fine adjustment data) (5) Press [INPUT] key to select <CCA01> (C H CENT).

Then a green cross-hatch pattern for adjustment will be displayed on the screen.

(6) Make sure that the heavy lines as shown in figure are

almost in alignment with the lines of the green crosshatch pattern (reference color). If the lines are out of alignment significantly, adjust <CCA02> (C H SIZE), <CCA03> (C H LIN), <CCA05> (C EW PIN), <CCA09> (V SIZE) and <CCA11> (TB PIN), respectively. (Refer to under figure)

(7) Press [SELECT] key to change the adjusting color to

red and blue, in turn, and make the adjustments in the same manner as for 6. above.

*In adjustments for red and blue, the adjustment of

<CCA10> (V KEY) is also available.

NOTE:

Press [OK] key to change the display colors. Whenever [OK] key is pressed, the menu will sequence in this order: "Two colors (adjusting color+green)"--->"Three colors (RGB)"

(8) When the adjustments have been completed, press

[MUTING] key and memorize the set values.

(9) Select <CPA08>. (10) Change the <CPA08> 1 to 0. (11) Press [MUTING] key and memorize the set values.

<CCA02> H. SIZE

A=B

<CCA03> C H LIN <CCA10> V KEY

STRAIGHT

<CCA05> EW PIN

<CCA09> V. SIZE

PARALLEL

STRAIGHT

<CCA11> TB PIN

(No.52105)1-53

AV-48WP74 AV-56WP74

Item

OVERALL CONVERGENCE adjustment (2) [POINT]

Measuring instrument

Test point Adjustment part Description

Signal generator

Remote control unit

Cursor

<CROSS-HATCH (H13 x V15 points) >

Fig.1

[ 7.CONVER B ] NOTE:

Perform this adjustment after performing OVERALL CONVERGENCE adjustment (1).

(1) Select 7.CONVER B from SERVICE MENU. Then

(2) Press [ 2 ] / [ 4 ] / [ 6 ] / [ 8 ] key respectively, move

(3) Press [CH+] / [CH-] / [VOL+] / [VOL-] key, adjust the

(4) Press [SELECT] key to select the red and blue

(5) Press [OK] key to change the display colors to three

Point of adjustment

(6) Press [INPUT 2] or [INPUT4] key. After changing the

(7) Press [MUTING] key and memorize the set values.

appear green cross-hatch pattern for adjustment. (See Fig.1)

the cursor to the adjusting point.

position of the adjusting point so that it is located at the place as shown in Fig1.

cross-hatch patterns, respectively, and make convergence adjustments so that they align with the adjusting points of the green cross-hatch pattern (reference color).

colors from two colors (adjusting color + green) and make sure that the convergence has been aligned with each other.

pattern to the fine grid cross-hatch pattern, make sure that the convergence has been adjusted properly.

AV-48WP74 174

AV-56WP74 204

Fig.2

348

435

522

407

509

611

SPAN TABLE (mm)

164

192

246

287

335

REMOTE CONTROL KEY POSITION

INPUT key

For adjustment change

INPUT 1/3 = Cross-hatch INPUT 2/4 = Fine grid cross-hatch

MUTING key

For storing adjustment data in memory

OK key

For display colors change for adjusting

pattern

CATV

SPLIT

FREEZE

INPUT1

INPUT2

INPUT3

INPUT4

DIGITAL-IN

SLEEP TIMER

MUTING

VOL

VCR CHANNEL

PREV NEXT

REC

OPEN/CLOSE

VCR

DVD

MULTI SCREEN

POP

SWAP

100+

THEATER

NATURAL

PRO

DISPLAY

PLAY FFREW

STOP

RM-C1200G

ASPECT

INDEX

SELECT

CINEMA

SOUND

VOL

VCR/DVD

POWER

STILL/PAUSE

EZ SURF

PAUSE

POWER

RETURN+ /TV

VIDEO

STATUS

LIGHT

C.C.

BACK

TV/VCR

SELECT key

For adjusting color change

Number key

For cursor shifting

[2] : up [4] : left [6] : right [8] : down

VOL+ / VOLCH+ / CH- keys

For convergence adjustments

[CH+] : up [CH- ] : down [VOL+] : left [VOL -] : right

1-54 (No.52105)

3.8.5 VIDEO ADJUSTMENT

Item

A-D CONVERTER

Measuring

instrument

Signal generator

OFFSET adjustment (1)

Remote control unit

Upper side of screen whole black

Fig. 1 <FULL screen>

Fig. 2 <SPLIT screen>

Test point Adjustment part Description

[1.PICTURE/SOUND] F44 : Image adjustment F45 : Image adjustment of mode change F47 : Minimum value B at the time of detection F48 : Maximum value A at the time of detection

[WHITE BALANCE LOW LIGHT ADJUSTMENT for SINGLE SCREEN]

(1) Input the 480i (DVD) whole black signal from the

COMPONENT VIDEO terminal.

(2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Select FULL mode with [ASPECT] key. (4) Select 1.PICTURE / SOUND from SERVICE MENU. (5) It goes into the zero mode screen of difference

adjustment of color, using <F44>(Image adjustment)

as 0 to 1, and using <F45>(Image adjustment mode

change) as 0 to 3.

[8.PP] ADM012 : R offset AMD013 : G offset AMD014 : B offset

(6) Set <F47> (minimum value B at the time of

detection) to 0 and <F48> (maximum value A at the

time of detection) to 0. (7) Press [MUTING] key and memorize the set value. (8) Press [BACK] key and display SERVICE MENU

screen again. (9) Select 8. PP from SERVICE MENU.

(10) Adjust <ADM012> (R offset setup) and <ADM014>

(B offset setup) so that the adjustment result out put

screen in the upper half of a screen becomes black

color.(Fig.1)

(11) If the screen is reddish, adjust <ADM012>(R offset

setup) so that the redness is reduced to the

minimum.

(12) If the screen is bluish, adjust <ADM014>(B offset

setup) so that the blue is reduced to the minimum.

(13) Press [MUTING] key and memorize the set value.

To be slightly whitish rather than whole black

[BRIGHTNESS ADJUSTMENT for SPLIT RIGHT SCREEN]

(1) Select STANDARD mode with [VIDEO STATUS]

key. (2) Select FULL mode with [ASPECT] key. (3) Press [SPLIT] key to enter the SPLIT screen mode,

then input gray scale signal on both left and right

channels. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) It goes into the Y adjustment MAX mode, using

<F45> as 0 and using <F44> as 0 to 1. (6) Set <F47> to 16 and <F48> to 16. (7) Press [MUTING] key and memorize the set value. (8) Press [BACK] key and display the SERVICE MENU. (9) Select 8. PP from SERVICE MENU.

(10) Adjust <ADM013> (G offset setup) so that the

screen on the right upper side becomes slightly

whitish rather (6% black) than whole black.(Fig.2)

(11) Press [MUTING] key and memorize the set value.

AV-48WP74 AV-56WP74

(No.52105)1-55

AV-48WP74 AV-56WP74

Item

A-D CONVERTER OFFSET adjustment (2)

Measuring

instrument

Signal generator

Remote control unit

Test point Adjustment part Description

[1.PICTURE/SOUND] F44 : Image adjustment F45 : Image adjustment of mode change F47 : Minimum value B at the time of detection F48 : Maximum value A at the time of detection

[WHITE BALANCE LOW LIGHT ADJUSTMENT for SPLIT RIGHT SCREEN]

(1) Press [SPLIT] key to enter the SPLIT screen mode. (2) Select STANDARD with [VIDEO STATUS] key. (3) Select FULL mode with [ASPECT] key. (4) Select 1 PICTURE SOUND from SERVICE MENU. (5) It goes into the zero mode screen of difference

adjustment of color, using <F45>(Image adjustment mode change) as 0 to 3 and <F44>(Image adjustment) as 0 to 1.

(6) Set <F47> (minimum value B at the time of

detection) to 0 and <F48> (minimum value A at the [8.PP] ADM012 : R offset

AMD013 : G offset AMD014 : B offset

time of detection) to 0.

(7) Press [MUTING] key and memorize the set value. (8) Press [BACK] key and back to SERVICE MENU. (9) Select 8.PP from SERVICE MENU.

(10) Adjust <ADM012> (R offset setup) and <ADM014>

Whole black

(G offset setup) so that right upside screen becomes

whole black.

(11) Press [MUTING] key and memorize the set value. (12) Select 1.PICTURE/SOUND from SERVICE MENU. (13) Change the data of <F44> 1 to 0 and <F45> 3 to 0. (14) Press [MUTING] key and memorize the set value.

Fig. 3 <SPLIT screen>

1-56 (No.52105)

AV-48WP74 AV-56WP74

Item

RGB CUTOFF adjustment

Regular mode screen

Measuring

instrument

Signal generator

Oscilloscope

Remote control unit

Test point Adjustment part Description

TP-R [R CRT SOCKET PWB] TP-G [G CRT SOCKET PWB] TP-B [B CRT

[1.PICTURE/SOUND] S14: CUTOF R S16: CUTOF G S18: CUTOF B

R SCREEN VR G SCREEN VR B SCREEN VR [FOCUS PACK]

SOCKET PWB]

TP-E

TP-G

CRT SOCKET PWB

Whole black signal (0%)

No signal No signal

(1) Receive NTSC whole black (0%) signal. (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Select REGULAR mode with [ASPECT] key. (4) The COLOR TEMP set at the LOW mode. (5) Connect the oscilloscope to TP-G on the G CRT

SOCKET PWB. (6) Select 1.PICTURE/SOUND from SERVICE MENU. (7) Select <S16> (CUTOF G). (8) Adjust <S16> so that the central 0% signal portion

and the non-signal portion of both sides may

become the same voltage. (9) Press [MUTING] key and memorize the set value.

(10) Receive 480i component whole black (0%) signal. (11) Set <S16> data same as memorized NTSC <S16>

data.

(12) Set 1080i component whole black (0%) signal. (13) Set <S16> data same as memorized NTSC <S16>

data.

(14) Connect the oscilloscope to TP-R <S14> (CUTOF

R) and adjust same manner as for 6. ~ 13. above.

(15) Connect the oscilloscope to TR-B <S18> (CUTOF

B).and adjust same manner as for 6. ~ 13. above.

(16) Adjust SCREEN VR for RGB respectively, so that

the black (3%) becomes faintly whitish.

NOTE :

If it is difficult to adjust the SCREEN precisely, adjust the SCREEN VR for one of three colors while masking other two colors.

Oscilloscope waveform

0 %

(No.52105)1-57

AV-48WP74 AV-56WP74

Item

WHITE BALANCE (LOW LIGHT) adjustment

BRIGHT LEVEL DRIVE CUTOFF

Measuring

instrument

Signal generator

Remote control unit

3. WHITE BALANCE

BR DRV

SETTING VALUE

NTSC

BR 133

DRV R 073

CUT R 188

Test point Adjustment part Description

[1.PICTURE/SOUND] S14: CUTOF R S16: CUTOF G S18: CUTOF B S20: CUTOF SW R S21: CUTOF SW G S22: CUTOF SW B

(1) Receive NTSC black & white pattern signal (color

off).

(2) Select STANDARD mode with [VIDEO STATUS]

key. (3) The COLOR TEMP is set at the LOW mode. (4) Select 3.WHITE BALANCE from SERVICE MENU. (5) Increase bright level to confirm LOW-LIGHT with

[VOL +] key. (6) Adjust using [ 4 ] / [ 7 ] (R CUTOFF), [ 6 ] / [ 9 ] (B

CUTOFF) key so that a black portion may become

black. (7) Press [MUTING] key and memorize the set values. (8) Input 480i component black & white pattern signal

from COMPONENT VIDEO terminal. (9) Repeat steps 5 ~ 7 above.

(10) Input 1080i component black & white signal from

GBCUT

COMPONENT VIDEO terminal.

(11) Repeat steps 5 ~ 7 above.

NOTE :

Setting value

Before starting the adjustment, warm up the unit for more than 30 minutes.

B 060

G 149 B 215

480i

DRV R 074

CUT R 194

1080i

DRV R 074

CUT R 195

REMOTE CONTROL UNIT

123

R CUTOFF

456

R CUTOFF B CUTOFFG CUTOFF

789

B 058

G 149 B 210

B 058

G 149 B 210

EXIT

B CUTOFFG CUTOFF

OSD ON/OFF

1-58 (No.52105)

AV-48WP74 AV-56WP74

Item

WHITE BALANCE (HIGH LIGHT) adjustment

Setting Item Setting value

Item

S10 073 074 074

S12 060 058 058

Signal

Measuring

instrument

Test point Adjustment part Description

Signal generator

Remote control unit

1. PICTUER/SOUND

NTSC FULL DA H FL MUTE

DRIVE RS10

INITIAL SETTING VALUE

Setting value

NTSC 480i 1080i

[1.PICTURE/SOUND] S10: DRIVE R S12: DRIVE B

(1) Receive NTSC black & white signal (color off). (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) The COLOR TEMP is set at LOW mode. (4) Select 1.PICTER/SOUND from SERVICE MENU. (5) Select <S10> (DRIVE R) or <S12> (DRIVE B). (6) Adjust <S10> or <S12> so that the natural white

should be visible. (7) Press [MUTING] key and memorize the set values. (8) Input 480i component black & white signal from

COMPONENT VIDEO terminal. (9) Repeat steps 5 ~ 7 above.

(10) Input 1080i component black & white signal from

COMPONENT VIDEO terminal.

(11) Repeat steps 5 ~ 7 above.

SUB BRIGHT adjustment

Item

S03

Signal

Signal generator

Remote control unit

Setting value

NTSC 480i 1080i

STANDARD THEATER

131 121

STANDARD THEATER

[1.PICTURE/SOUND] S03: BRIGHT

STANDARD THEATER

129

130

130130

(1) Receive NTSC black & white signal. (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) The COLOR TEMP is set at the LOW mode. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select <S03> (BRIGHT). (6) Set initial setting value. (See Table) (7) If the brightness is not the best with the initial setting

value, make fine adjustment until you get the best

brightness. (8) Press [MUTING] key and memorize the set values. (9) Select THEATER mode with [VIDEO STATUS] key.

(10) Select 1.PICTURE/SOUND from SERVICE MENU. (11) Select <S03>. (12) Set initial setting value. (See Table) (13) If the brightness is not the best with the initial setting

value, make fine adjustment until you get the best

brightness.

(14) Press [MUTING] key and memorize the set values. (15) Input 480i component black & white signal from

COMPONENT VIDEO terminal.

(16) Repeat steps 2 ~ 14 above. (17) Input 1080i component black & white signal from

COMPONENT VIDEO terminal.

(18) Repeat steps 2 ~ 14 above.

(No.52105)1-59

AV-48WP74 AV-56WP74

Item

SUB CONTRAST adjustment

Item

S04

SUB COLOR / SUB TINT / B-Y GAIN adjustment (1)

Signal generator

Remote control unit

Signal

Signal generator

Remote control unit

Measuring

instrument

NTSC 480i 1080i

STANDARD THEATER

052 045

Test point Adjustment part Description

Setting value

STANDARD THEATER

046

TP-R TP-B TP-E (GND)

[1.PICTURE/SOUND] S04: CONTRAST

STANDARD THEATER

065

044065

[1.PICTURE/SOUND] S01 : COLOR S02 : TINT S07 : B-Y

(1) Receive NTSC black & white signal. (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) The COLOR TEMP is set at the LOW mode. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select <S04> (CONTRAST). (6) Set Initial setting value. (See Table) (7) If the contrast is not the best with the initial setting

value, make fine adjustment of the <S04> until you

get the optimum contrast. (8) Press [MUTING] key and memorize the set values. (9) Select THEATER mode with [VIDEO STATUS] key.

(10) Select 1.PICTURE/SOUND from SERVICE MENU. (11) Select <S04>. (12) Set Initial setting value. (See Table) (13) If the contrast is not the best with the initial setting

value, make fine adjustment of the <S04> until you

get the optimum contrast.

(14) Input 480i component black & white signal from

COMPONENT VIDEO terminal.

(15) Repeat steps 2 ~ 13 above. (16) Receive 1080i component black & white signal from

COMPONENT VIDEO terminal.

(17) Repeat steps 2 ~ 13 above.

[ Method of adjustment without measuring instrument ]

(1) Receive NTSC color bar signal. (2) Select STANDARD mode with [VIDEO STATUS]

key. (3) Select 1.PICTURE/SOUND from SERVICE MENU. (4) Select <S01> (COLOR) or <S02> (TINT). (5) Set the initial setting values. (6) If the color or tint is not the best with the initial setting

values, make fine adjustment until you get the best

color or the best tint. (7) Select <S07> (B-Y). (8) Set the initial setting values. (9) If the color bar is not clearly with the initial setting

value, make fine adjustment until you get the clearly

color bar.

(10) Press [MUTING] key and memorize the set values. (11) Select THEATER mode with [VIDEO STATUS] key. (12) Select <S01> or <S02> . (13) Set the initial setting values. (14) If the color or tint is not the best with the initial setting

values, make fine adjustment until you get the best

color or the best tint.

(15) Select <S07>. (16) Set the initial setting values. (17) If the color bar is not clearly with the initial setting

value, make fine adjustment until you get the clearly

color bar.

(18) Press [MUTING] key and memorize the set values. (19) Input 480i component color bar signal from

COMPONENT VIDEO terminal.

(20) Repeat steps 2 ~ 18 above. (21) Input 480p component color bar signal from

COMPONENT VIDEO terminal.

(22) Repeat steps 2 ~ 18 above. (23) Input 1080i component color bar signal from

COMPONENT VIDEO terminal.

(24) Repeat steps 2 ~ 18 above.

1-60 (No.52105)

AV-48WP74 AV-56WP74

Item

SUB COLOR / SUB TINT / B-Y GAIN Adjustment (2)

Setting item

Measuring

instrument

Signal generator

Oscilloscope

Test point Adjustment part Description

TP-R TP-B TP-E (GND)

[1.PICTURE/SOUND] S01 : COLOR S02 : TINT S07 : B-Y

Remote control unit

(-)

YR(W-Y) (W-R)

(+)

Fig.1

(-)

(W-B)

(+)

Fig.2

Setting value

A [V]

STANDARD THEATER STANDARD THEATER

Setting value

B [V]

Setting

value C [V]

Setting

value

D [V]

[ Method of adjustment with measuring instrument ]

(1) Receive NTSC color bar signal. (2) Select STANDARD mode with [VIDEO STATUS]

key.

(3) Connect the oscilloscope to TP-R on the R CRT

SOCKET PWB. (4) Select 1.PICTURE/SOUND from SERVICE MENU. (5) Select <S01> (COLOR) or <S02> (TINT). (6) Adjust <S01> and <S02> to be following setting

value A[V]. (Refer to the bellow table) (7) Press [MUTING] key and memorize the set values. (8) Select THEATER mode with [VIDEO STATUS] key. (9) Adjust <S01> and <S02> to be following setting

value B[V] same as above. (Refer to the bellow

table)

(10) Press [MUTING] key and memorize the set values. (11) Select STANDARD mode with [VIDEO STATUS]

key.

(12) Connect the oscilloscope to TP-B on the B CRT

SOCKET PWB.

(13) Adjust <S07> (B-Y) to be setting value C[V]. (Refer

to the bellow table)

(14) Press [MUTING] key and memorize the set values. (15) Select THEATER mode with [VIDEO STATUS] key. (16) Adjust <S07> to be setting value D[V]. (Refer to the

bellow table)

(17) Press [MUTING] key and memorize the set values. (18) Confirm that LOW-LIGHT is not different after

adjusting COLOR, TINT and B-Y GAIN. If it is green

or magenta, to adjust LOW-LIGHT again. If adjust

again, to set offset value again.

(19) Press [MUTING] key and memorize the set values. (20) Input 480i component color bar from COMPONENT

VIDEO terminal.

(21) Repeat steps 2 ~ 19 above. (22) Input 480p component color bar from COMPONENT

VIDEO terminal.

(23) Repeat steps 2 ~ 19 above. (24) Input 1080i component color bar from

COMPONENT VIDEO terminal.

(25) Repeat steps 2 ~ 19 above.

Signal

NTSC +28

480i +19

480p +19

1080i +7

S01

(W-R)

S02

(W-Y)

+14

+11

+14

S01

(W-R)

+19

+11

S02

(W-Y)

S07

(W-B)

+10

-17

-25

-24

S07

(W-B)

+18

+12

-9

(No.52105)1-61

AV-48WP74 AV-56WP74

Item

MTS INPUT LEVEL check

MTS SEPARATION adjustment

Measuring

instrument

Remote control unit

TV audio multiplex signal generator

Oscilloscope

Remote control unit

L-Channel signal waveform

Test point Adjustment part Description

[1.PICTURE/SOUND] A01 : IN LEVEL

(1) Select 1.PICTURE / SOUND from SERVICE MENU. (2) Select <A01> (IN LEVEL). (3) Verify that<A01> is set at its initial setting value.

AUDIO OUT L output R output

[1.PICTURE/SOUND] A02: LOW SEP. A03 : HI SEP.

(1) Input stereo L signal (300Hz) from the TV audio

multiplex signal generator to the antenna terminal.

(2) Connect an oscilloscope to L OUTPUT pin of the

AUDIO OUT, and display one cycle portion of the 300Hz signal.

(3) Change the connection of the oscilloscope to R

OUTPUT pin of the AUDIO OUT, and enlarge the

voltage axis. (4) Select <A02> (LOW SEP.). (5) Set the initial setting value of <A02>. (6) Adjust <A02> so that the stroke element of the

R-Channel crosstalk portion

300Hz signal will become minimum. (7) Change the signal to 3kHz, and similarly adjust

<A03> (HI SEP.).

Minimum

1 cycle

1-62 (No.52105)

3.9 HOW TO CHECK THE HIGH VOLTAGE HOLD DOWN CIRCUIT

3.9.1 HIGH VOLTAGE HOLD DOWN CIRCUIT

After repairing the high voltage hold down circuit. This circuit shall be checked to operate correctly.

3.9.2 CHECKING OF THE HIGH VOLTAGE HOLD DOWN CIRCUIT

(1) Turn the power switch ON. (2) As shown in figure bellow, set the resistor (between S1 connector 2 & 3). (3) Make sure that the screen picture disappears (no raster). (4) Temporarily unplug the power cord. (5) Remove the resistor (between S1 connector 2 & 3). (6) Again plug the power cord, make sure that normal pictures is displayed on the screen.

RESISTOR

6.8K 0.5% 1/4W

SERVICE CONNENTOR

TP-91

FR811 D812

CN003

X-RAY

12345

TP-E

C562R565

D561 D562

R561

AV-48WP74 AV-56WP74

124

T502

FBT

R562

C811

CONNENTORS1

12345

X-RAY2

TP-E

( )

X-RAY1NCTP-91

140V

(No.52105)1-63

AV-48WP74 AV-56WP74

SECTION 4

TROUBLESHOOTING

4.1 SELF CHECK FUNCTIONS

• This model has self-check functions that inform of the failure of the TV by detecting abnormality.

• Operational state is always monitored and the identified is memorized on the record.

4.1.1 HOW TO ENTER THE SELF-CHECK MODE

(1) Set the <SLEEP TIMER 30MIN> with [SLEEP TIMER] key.

(Fig.1)

(2) During the <SLEEP TIMER 30MIN> display, press [DIS-

PLAY] key and [VIDEO STATUS] key at the same time. (3) Then <TEST MODE> screen is displayed. (Fig.2) (4) Press [ 4 ] key then <SELF-CHECK> screen is appear.

(Fig.3)

4.1.2 HOW TO EXIT FROM THE SELF-CHECK MODE

(1) By using the remote control unit, turn the power off. At this

time, the failure record is cleared. (2) Take off the AC plug from the wall outlet. At this time, the

failure record is not cleared.

SLEEP TIMER 30MIN

Fig.1

4.1.3 SELF-CHECK DISPLAY

The self-check results are shown on the following display. Method of indication when the raster is not displayed (Fig.3).

Each failure is shown by turning POWER LED on and off at specified intervals.

Item POWER LED ON / OFF intervals

X-ray protection Turning on and off 0.1-second intervals

B1 over-current protection

Low B short protection Turning on and off 2-second intervals

4.1.4 EXPLANATION FOR ACTIVATION OF SELF-CHECK FUNCTIONS

• For X-ray protection, B1 over-current protection and low B

short protection, the power of the TV is turned off if NG is detected. Immediately after the power is turned off, POWER LED will be turning on and off. When the power is turned off, you cannot turn the power on again until the AC plug is taken out and put in again.

• The latest failure is stored on the record at the end.

The failure record for each check item is counted to the number of 9 at the maximum, When more than 9 failures are stored on the record, the counter remains stopped at 9.

• SYNC is neither counted nor stored in memory.

• Because of the timing of Vcc start-up and shut-down of the IC

connecting to the I2C bus during which the power is turned on and off, the operation may be interpreted as an error. In order to avoid the misinterpretation, the self-check functions should be started at about 3 seconds after the power is turned on.

Turning on and off 1-second intervals

TEST MODE

1. I2C STOP

2. STATUS DISP.

4. SELF-CHK

5. CONVER OFF

ROM CORRECTION : ACT ROM VERSION :

Fig.2

ITEM COUNTRESULT

XRAY LOB SYNC MEM VCD AIO TUN PP

NG2 OK M:OK OK NG2 OK OK NG4

Fig.3 SELF-CHECK SCREEN

OCP TIM S:OK AVSW BS YC GCR IP

NG2 OK HD:NG OK OK OK OK OK

1-64 (No.52105)

Indication Check item Details of detection Method of detection

XRAY X-ray radiation protection Operation of X-ray protection circuit.

D561, D562 : POWER & DEF PWB

At about 3 seconds after the power is turned on, the self-check function starts. If NG is detected for 200ms, the power is turned off automatically.

OCP B1 over-current protection An B1 over-current is detected.

Q971 : POWER & DEF PWB

At about 3 seconds after the power is turned on, the self-check function starts. If NG is detected for 200ms, the power is turned off automatically.

LOB Low B short protection Operation of low B short protection

circuit. Q1961(5V), Q1962(9V) : MAIN PWB

At about 3 seconds after the power is turned on, the self-check function starts. If NG is detected for 200ms, the power is turned off automatically.

TIM Timer The AC power frequency is changed

as follows : 50Hz ---> 60Hz 60Hz ---> 50Hz

SYNC Presence or absence of

synchronized signal

Presence of synchronized signal. HD : HD signal M : NTSC main signal S : NTSC sub signal IC1301(AN5392) : MI-COM & DIST

Periodically check the power frequency by counting the AC pulse and monitor whether or not the frequency is changed except for the time immediately after resetting.

When entering the self-check mode, "OK" is shown. While running the mode with picture signal, if the synchronized signal is disappeared, "NG" is shown.

MODULE PWB

MEM Memory (EEP-ROM) ACK is returned when I

carried out. IC1703(MEMORY) : MI-COM & DIST

C traffic is

The state is monitored every time when I2C traffic is carried out. Then the state is counted as a failure if ACK is not returned.

MODULE PWB

AVSW AV switch Ditto

Ditto IC1301(AN15852A) and IC1501(CXA2069Q) : MAIN PWB

VCD Video / chroma process

(RGB process)

Ditto IC1301(AN5392) : MI-COM & DIST

Ditto

MODULE PWB

BS Broadcast satellite tuner Not used Not used

AIO Audio process

(MTS decode / audio control)

Ditto UPC1851BCU

Ditto

IC0201(CXA2134Q-X) : RECEIVER PWB

YC 3D YC separation Ditto

Ditto IC3001(MN82832) : MI-COM & DIST MODULE PWB

TUN RF tuner Ditto

Ditto Main & sub RF tuner

GCR Ghost reduction Not used Not used

PP Picture & Picture

(Multi-picture)

Ditto IC101(TMS57128GJG) : MI-COM &

Ditto

DIST MODULE PWB

IP DIST process Ditto

Ditto IC201(JCC5054) : MI-COM & DIST MODULE PWB

AV-48WP74 AV-56WP74

(No.52105)1-65

AV-48WP74 AV-56WP74

JVC SERVICE & ENGINEERING COMPANY OF AMERICA

DIVISION OF JVC AMERICAS CORP.

www.jvcservice.com(US Only)

JVC CANADA INC.

Head office : 21 Finchdene Square Scarborough, Ontario M1X 1A7 (416)293-1311

(No.52105)

Printed in Japan

20034WPC

Jvc AV-56WP74, AV-48WP74 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

SECTION 1

1.1 SAFETY PRECAUTIONS

1.2 INSTALLATION

SECTION 2

2.1 FEATURES

2.2 FUNCTIONS

2.3 TECHNICAL INFORMATION

2.4 MAIN PARTS LOCATION

2.5 SCREEN HANDLING CAUTIONS

2.6 PROJECTION UNIT REPLACEMENT

2.7 DISASSEMBLY PROCEDURE

2.8 REPLACEMENT OF CHIP COMPONENT

2.9 MEMORY IC REPLACEMENT

SECTION 3

3.1 ADJUSTMENT PREPARATION

3.2 ADJUSTMENT EQUIPMENT

3.3 ADJUSTMENT FLOWCHART

3.4 ADJUSTMENT LOCATION (1/2)

3.5 ADJUSTMENT LOCATION (2/2)

3.6 BASIC OPERATION OF SERVICE MENU

3.7 INITIAL SETTING VALUE OF SERVICE MENU

3.8 ADJUSTMENT PROCEDURE

3.9 HOW TO CHECK THE HIGH VOLTAGE HOLD DOWN CIRCUIT

SECTION 4

4.1 SELF CHECK FUNCTIONS
