SERVICE MANUAL
V-48WP30
REAR PROJECTION TELEVISION
AV-48WP30/B-ME
The following item for the AV-48WP30/B-ME model was changed partly from AV-48WP30/A-ME model.
Therefore, this service manual describes only the items which differ from those of the
AV-48W P30
For details other than those described in this manual, please refer to the AV-48WP30
service manual (No.51989, Apr. 2002) and AV-48WP30
/A-ME service manual.
Supplementary
/A-ME (No.51989B/C, Jul. 2002).
BASIC CHASSIS
SB2
/ME model
■ OUTLINE
Since the R/G/B CRT ASS’Ys were changed, we have issued the SERVICE MANUAL fo
AV-48W P30/B-ME.
■ HOW TO IDENTIFY MODELS
A suffix “B” is added to the serial No. after at the rating label.
1
COPYRIGHT © 2002 VICTOR COMPANY OF JAPAN, LTD.
AV-48WP3 0
Indicated B
No.51989D
Dec. 2002
AV-48WP30
■ DIFFERENCE LIST
EXPLODED VIEW PARTS LIST (Page 58)
Ref. No.
AV-48WP3 0
[ AV-48WP30/ME ]
[ AV-48WP30/A-ME ]
26 R CRT SA-M2 R CRT KIT SA-M2
27 G CRT SA-M2 G CRT KIT SA-M2
28 B CRT SA-M2 B CRT KIT SA-M2
CRT ASS’Y (COUPLER ASS’Y)
Part No.
/ME AV-48 WP3 0/A-ME AV-48WP3 0/B-ME
R CRT /B SA-M2
G CRT /B SA-M2
B CRT /B SA-M2
[ AV-48WP30/B-ME ]
CRT ASS’Y (COUPLER ASS’Y)
Part Name
R CRT ASS’Y
G CRT ASS’Y
B CRT ASS’Y
[Note]
When you replace the CRT ASS’Y for the AV-48WP30/ME and AV-48WP30/A-ME models with those for the
AV-48WP3 0/B-ME model, please change the three CRT ASS’Y for R/G/B all together.
They are not compatible with each other.
VICTOR COMPANY OF JAPAN, LIMITED
HOME AV NETWORK BUSINESS UNIT 12, 3-chome, Moriya-cho, Kanagawa-ku, Yokohama, Kanagawa-prefecture, 221-8528, Japan
2
Printed in Japan
