PARTS LIST
CAUTION
J The parts identified by the symbol are important for the safety . Whenever replacing these parts, be sure to use specified ones to secure the
safety.
J The parts not indicated in this Parts List and those which are filled with lines --- in the Parts No. columns will not be supplied.
J P.W. BOARD Ass'y will not be supplied, but those which are filled with the Parts No. in the Parts No. columns will be supplied.
ABBREVIATIONS OF RESISTORS, CAPACITORS AND TOLERANCES
RESISTORS CAPACITORS
CR Carbon Resistor C CAP. Ceramic Capacitor
FR Fusible Resistor E CAP. Electrolytic Capacitor
PR Plate Resistor M CAP. Mylar Capacitor
VR Variable Resistor CH CAP. Chip Capacitor
HV R High Voltage Resistor HV CAP. High Voltage Capacitor
MF R Metal Film Resistor MF CAP. Metalized Film Capacitor
MG R Metal Glazed Resistor MM CAP. Metalized Mylar Capacitor
MP R Metal Plate Resistor MP CAP. Metalized Polystyrol Capacitor
OM R Metal Oxide Film Resistor PP CAP. Polypropylene Capacitor
CMF R Coating Metal Film Resistor PS CAP. Polystyrol Capacitor
UNF R Non-Flammable Resistor TF CAP. Thin Film Capacitor
CH V R Chip Variable Resistor MPP CAP. Metalized Polypropylene Capacitor
CH MG R Chip Metal Glazed Resistor TAN. CAP. Tantalum Capacitor
COMP. R Composition Resistor CH C CAP. Chip Ceramic Capacitor
LPTC R Linear Positive Temperature Coefficient Resistor BP E CAP. Bi-Polar Electrolytic Capacitor
CH AL E CAP. Chip Aluminum Electrolytic Capacitor
CH AL BP CAP. Chip Aluminum Bi-Polar Capacitor
CH TAN. E CAP. Chip Tantalum Electrolytic Capacitor
CH AL BP E CAP. Chip Tantalum Bi-Polar Electrolytic Capacitor
RESISTORS
FGJKMNRHZP
±1% ±2% ±5% ±10% ±20% ±30%
+30%
-10%
+50%
-10%
+80%
-20%
+100%
-0%
(No.YA260)3-1
CONTENTS
USING P.W. BOARD & REMOTE CONTROL UNIT ................................................................................................... 3-2
EXPLODED VIEW PARTS LIST ................................................................................................................................. 3-3
EXPLODED VIEW ....................................................................................................................................................... 3-4
PRINTED WIRING BOARD PARTS LIST [AV-32T5SP, AV-32T5SR, AV-32T5BR] ................................................. 3-5
MAIN P.W. BOARD ASS'Y (SJW-1011A-U2) .................................................................................................... 3-5
POWER & DEF P.W. BOARD ASS'Y (SJW-2011A-U2) ....................................................................................3-8
CRT SOCKET P.W. BOARD ASS'Y (SJW-3011A-U2) ...................................................................................... 3-9
FRONT CONTROL P.W. BOARD ASS'Y (SJW-8011A-U2) ............................................................................ 3-10
SIDE CONTROL P.W. BOARD ASS'Y (SJW-8111A-U2) ................................................................................ 3-10
AV JACK P.W. BOARD ASS'Y (SJW0J011A-U2) ........................................................................................... 3-10
PRINTED WIRING BOARD PARTS LIST [AV-32T5SK, AV-32T5BK] ..................................................................... 3-11
MAIN P.W. BOARD ASS'Y (SJW-1911A-U2) .................................................................................................. 3-11
POWER & DEF P.W. BOARD ASS'Y (SJW-2011A-U2) .................................................................................. 3-14
CRT SOCKET P.W. BOARD ASS'Y (SJW-3011A-U2) .................................................................................... 3-14
FRONT CONTROL P.W. BOARD ASS'Y (SJW-8011A-U2) ............................................................................ 3-14
SIDE CONTROL P.W. BOARD ASS'Y (SJW-8111A-U2) ................................................................................ 3-14
AV JACK P.W. BOARD ASS'Y (SJW0J011A-U2) ........................................................................................... 3-14
REMOTE CONTROL UNIT PARTS LIST (RM-C1502) ............................................................................................. 3-14
REMOTE CONTROL UNIT PARTS LIST (RM-C1502B) .......................................................................................... 3-14
PACKING ................................................................................................................................................................... 3-15
PACKING PARTS LIST ............................................................................................................................................. 3-15
USING P.W. BOARD & REMOTE CONTROL UNIT
P.W.B ASS'Y AV-32T5SP AV-32T5SK AV-32T5SR AV-32T5BR AV-32T5BK
MAIN P.W.B SJW-1011A-U2 SJW-1911A-U2 SJW-1011A-U2 SJW-1011A-U2 SJW-1911A-U2
POWER & DEF P.W.B SJW-2011A-U2 ←←SJW-2011A-U2 ←
CRT SOCKET P.W.B SJW-3011A-U2 ←←SJW-3011A-U2 ←
FRONT CONTROL P.W.B SJW-8011A-U2 ←←SJW-8011A-U2 ←
SIDE CONTROL P.W.B SJW-8111A-U2 ←←SJW-8111A-U2 ←
AV JACK P.W.B SJW0J011A-U2 ←←SJW0J011A-U2 ←
REMOTE CONTROL UNIT RM-C1502 ←←RM-C1502B ←
3-2(No.YA260)
EXPLODED VIEW PARTS LIST
Ref.No. Part No. Part Name Description Local
V01 W76QEN693X001 ITC
L01 QQW0169-001 DEG COIL
T551 QQH0183-001 FB TRANSF
1 LC30628-002A DEG CLAMP (x4)
2 LC32668-001A SPRING
3 WJY0021-002B-E BRAIDED ASSY AV-32T5BK,AV-32T5BR,AV-32T5SP
3 WJY0021-002B BRAIDED ASSY AV-32T5SK,AV-32T5SR
4 WJY0013-002A-E BRAIDED ASSY AV-32T5BK,AV-32T5BR,AV-32T5SP
4 WJY0013-002A BRAIDED ASSY AV-32T5SK,AV-32T5SR
5 QAS0326-001 SPEAKER SP01/SP02(x2)
6 QYSBSAG4016NA TAP SCREW M4 x 16mm(x8)
7 LC11795-002C-U CONTROL BASE
8 LC11643-001A-U CHASSIS BASE
9 LC11782-003A-U AV TERMINAL BOARD AV-32T5BK,AV-32T5BR
9 LC11782-001B-U AV TERMINAL BOARD AV-32T5SK,AV-32T5SP,AV-32T5SR
10 QYSBSF3012MA TAP SCREW M3 x 12mm(x2)
11 QQR0491-001 FERRITE CORE
12 LC21383-001C-U POWER CORD CLAMP
13 QMPK160-185-JC POWER CORD(EU) 1.85m BLACK AV-32T5SP
13 QMPN130-185-JC POWER CORD(EK) 1.85m BLACK AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
14 QQR0491-001 FERRITE CORE (x2) AV-32T5BR,AV-32T5SP,AV-32T5SR
15 QQR0491-001 FERRITE CORE
16 QQR0491-001 FERRITE CORE
17 QYSBSAG4016NA TAP SCREW M4 x 16mm
18 QYSBSFG3010ZA TAP SCREW M3 x 10mm(x2)
19 LC11825-002B-U SIDE CONTROL BASE
20 LC32584-002A-C CONTROL SHEET
21 LC11770-003B-U REAR COVER AV-32T5BK,AV-32T5BR
21 LC11770-001B-U REAR COVER AV-32T5SK,AV-32T5SP,AV-32T5SR
22 QYSBSAG4016NA TAP SCREW M4 x 16mm(x13)
23 LC33060-001C-C WINDOW
24 LC41852-001A JVC MARK
25 LC30789-002B-U WARNING LABEL AV-32T5SP
26 LC11364-0A1A-U RATING LABEL AV-32T5BK
26 LC11364-091A-U RATING LABEL AV-32T5BR
26 LC11364-073A-U RATING LABEL AV-32T5SK
26 LC12098-002A-U RATING LABEL AV-32T5SP
26 LC11364-074A-U RATING LABEL AV-32T5SR
30 LC12184-002A-U FRONT CABINET ASSY AV-32T5BK,AV-32T5BR
30 LC12184-001A-U FRONT CABINET ASSY AV-32T5SK,AV-32T5SR
40 SJW-3011A-U2 CRT SOCKET PWB
41 SJW-8011A-U2 FRONT CONTROL PWB
42 SJW-2011A-U2 POWER & DEF PWB AV-32T5BK
42 SJW-2011A-S2 POWER & DEF PWB AV-32T5BR,AV-32T5SK,AV-32T5SP,AV-32T5SR
43 SJW0J011A-U2 AV JACK PWB
44 SJW-1911A-U2 MAIN PWB AV-32T5BK,AV-32T5SK
44 SJW-1011A-U2 MAIN PWB AV-32T5BR,AV-32T5SP,AV-32T5SR
45 SJW-8111A-U2 SIDE CONTROL PWB
(No.YA260)3-3
EXPLODED VIEW
1
L01
2
1
V01
3
4
40
6
5
23
6
5
24
41
7
15
<FRONT SIDE VIEW>
30
42
8
T551
21
20
17
19
45
18
16
14
44
14
12
11
9
43
10
13
25
3-4(No.YA260)
22
26
PRINTED WIRING BOARD PARTS LIST [AV-32T5SP, AV-32T5SR, AV-32T5BR]
MAIN P.W. BOARD ASS'Y (SJW-1011A-U2)
Ref No. Part No. Part Name Description Local
IC201 CXA2089Q-X IC
IC551 LA6515 IC
IC602 AN5277 IC
IC603 BD3869AF-X IC
IC701 TDA12020-32T5SP IC(MCU) (SERVICE)
IC702 ATF16-32T5SK IC (SERVICE)
IC902 AN78L09-T IC
Q101 2SC5397/CD/-T TRANSISTOR
Q102 UN2212-X DIGI TRANSISTOR
Q201 2SC3928A/QR/-X TRANSISTOR
Q202 2SC3928A/QR/-X TRANSISTOR
Q207 UN2226-X DIGI TRANSISTOR
Q210 2SA1530A/QR/-X TRANSISTOR
Q211 UN2226-X DIGI TRANSISTOR
Q212 2SA1530A/QR/-X TRANSISTOR
Q213 UN2226-X DIGI TRANSISTOR
Q214 UN2226-X DIGI TRANSISTOR
Q215 KTA1267/YG/-T TRANSISTOR
Q217 KTC3199/YG/-T TRANSISTOR
Q218 2SC3928A/QR/-X TRANSISTOR
Q219 2SC3928A/QR/-X TRANSISTOR
Q220 2SC3928A/QR/-X TRANSISTOR
Q221 2SC3928A/QR/-X TRANSISTOR
Q301 2SA1530A/QR/-X TRANSISTOR
Q302 2SC3928A/QR/-X TRANSISTOR
Q551 2SC3928A/QR/-X TRANSISTOR
Q552 2SA1530A/QR/-X TRANSISTOR
Q617 2SC3928A/QR/-X TRANSISTOR
Q618 2SC3928A/QR/-X TRANSISTOR
Q620 UN2213-X DIGI TRANSISTOR
Q621 2SA1530A/QR/-X TRANSISTOR
Q622 2SC3928A/QR/-X TRANSISTOR
Q703 2SC3928A/QR/-X TRANSISTOR
Q704 2SC3928A/QR/-X TRANSISTOR
Q707 2SC3928A/QR/-X TRANSISTOR
Q708 2SC3928A/QR/-X TRANSISTOR
Q709 2SA562TM/Y/-T TRANSISTOR
Q710 2SA562TM/Y/-T TRANSISTOR
Q711 2SC3928A/QR/-X TRANSISTOR
Q712 2SA1530A/QR/-X TRANSISTOR
D101 1SS356-X SI DIODE
D201 UDZS12B-X Z DIODE
D203 NCB21EK-104X C CAPACITOR 0.1uF 25V K
D204 UDZS12B-X Z DIODE
D205 UDZS12B-X Z DIODE
D206 UDZS12B-X Z DIODE
D207 UDZS12B-X Z DIODE
D208 UDZS12B-X Z DIODE
D209 UDZS12B-X Z DIODE
D211 UDZS12B-X Z DIODE
D212 UDZS12B-X Z DIODE
D213 UDZS12B-X Z DIODE
D214 UDZS12B-X Z DIODE
D215 UDZS12B-X Z DIODE
D301 1SS355-X SI DIODE
D302 1SS355-X SI DIODE
D303 1SS355-X SI DIODE
D304 NRSA02J-222X MG RESISTOR 2.2kΩ 1/10W J
D607 1SS355-X SI DIODE
D608 1SS355-X SI DIODE
D609 1SS355-X SI DIODE
D611 UDZS33B-X Z DIODE
D613 UDZS33B-X Z DIODE
D616 1SS355-X SI DIODE
D621 UDZS5.6B-X Z DIODE 1.5k
D701 1SS355-X SI DIODE
D702 1SS357-X SB DIODE
D704 UDZS6.8B-X Z DIODE
D705 1SS355-X SI DIODE
D706 1SS355-X SI DIODE
D707 1SS355-X SI DIODE
D708 1SS355-X SI DIODE
D711 RB161L-40-X SB DIODE
D712 1N4003SG-T2 SI DIODE
D713 UDZS2.0B-X Z DIODE
D714 UDZS2.0B-X Z DIODE
D981 1SS355-X SI DIODE
D982 1SS355-X SI DIODE
D983 1N4003SG-T2 SI DIODE
Ω
1/10W J
Ref No. Part No. Part Name Description Local
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 QETN1HM-106Z E CAPACITOR 10uF 50V M
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 QETN1AM-108Z E CAPACITOR 1000uF 10V M
C107 NCB31HK-222X C CAPACITOR 2200pF 50V K
C108 QETN1HM-226Z E CAPACITOR 22uF 50V M
C110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C114 NCB31HK-472X C CAPACITOR 4700pF 50V K
C115 NCB31HK-472X C CAPACITOR 4700pF 50V K
C116 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C117 NCB31HK-102X C CAPACITOR 1000pF 50V K
C118 NCB31HK-472X C CAPACITOR 4700pF 50V K
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C205 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C207 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C208 NDC31HJ-390X C CAPACITOR 39pF 50V J
C209 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C210 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C213 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C214 NDC31HJ-390X C CAPACITOR 39pF 50V J
C216 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C217 NDC31HJ-390X C CAPACITOR 39pF 50V J
C218 NDC31HJ-390X C CAPACITOR 39pF 50V J
C220 QETN1HM-106Z E CAPACITOR 10uF 50V M
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QETN1HM-106Z E CAPACITOR 10uF 50V M
C223 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C224 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C226 QETN1HM-106Z E CAPACITOR 10uF 50V M
C227 QETN1HM-106Z E CAPACITOR 10uF 50V M
C228 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C229 QETN1HM-106Z E CAPACITOR 10uF 50V M
C230 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C231 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C232 QETN1CM-107Z E CAPACITOR 100uF 16V M
C233 QETN1CM-107Z E CAPACITOR 100uF 16V M
C234 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C235 QETN1CM-107Z E CAPACITOR 100uF 16V M
C236 QETN1CM-477Z E CAPACITOR 470uF 16V M
C237 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C238 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C239 QETN1CM-477Z E CAPACITOR 470uF 16V M
C240 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C241 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NDC31HJ-100X C CAPACITOR 10pF 50V J
C302 NDC31HJ-100X C CAPACITOR 10pF 50V J
C303 QETN1CM-227Z E CAPACITOR 220uF 16V M
C304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C305 NDC31HJ-100X C CAPACITOR 10pF 50V J
C306 QETN1AM-227Z E CAPACITOR 220uF 10V M
C551 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C552 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C553 QETN1EM-476Z E CAPACITOR 47uF 25V M
C554 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C555 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C561 NDC31HJ-561X C CAPACITOR 560pF 50V J
C562 NCB11EK-105X C CAPACITOR 1uF 25V K
C617 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C619 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C620 QETN1HM-107Z E CAPACITOR 100uF 50V M
C621 QETM1VM-228 E CAPACITOR 2200uF 35V M
C622 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C623 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C626 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C627 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C628 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C630 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C632 QETN1HM-106Z E CAPACITOR 10uF 50V M
C633 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C634 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C643 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C644 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C645 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C662 NDC31HJ-391X C CAPACITOR 390pF 50V J
C663 NDC31HJ-391X C CAPACITOR 390pF 50V J
C666 NCB31HK-222X C CAPACITOR 2200pF 50V K
C667 NCB31HK-222X C CAPACITOR 2200pF 50V K
C668 NCB31AK-105X C CAPACITOR 1uF 10V K
C669 NCB31AK-105X C CAPACITOR 1uF 10V K
C670 QETN1EM-226Z E CAPACITOR 22uF 25V M
C671 NCB31CK-104X C CAPACITOR 0.1uF 16V K
(No.YA260)3-5
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
C672 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C673 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 QETN1EM-476Z E CAPACITOR 47uF 25V M
C703 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C704 QETN1HM-106Z E CAPACITOR 10uF 50V M
C705 NCB31HK-332X C CAPACITOR 3300pF 50V K
C706 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C707 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C708 QETN1HM-106Z E CAPACITOR 10uF 50V M
C709 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C710 QETN1HM-106Z E CAPACITOR 10uF 50V M
C711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C712 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C713 NDC31HJ-470X C CAPACITOR 47pF 50V J
C714 NDC31HJ-470X C CAPACITOR 47pF 50V J
C715 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C716 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C717 NDC31HJ-470X C CAPACITOR 47pF 50V J
C718 NDC31HJ-470X C CAPACITOR 47pF 50V J
C719 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C720 NDC31HJ-470X C CAPACITOR 47pF 50V J
C721 NDC31HJ-470X C CAPACITOR 47pF 50V J
C722 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C723 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C724 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C725 QETN1HM-106Z E CAPACITOR 10uF 50V M
C726 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C727 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C728 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C729 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C730 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C731 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C732 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C733 QETN1HM-106Z E CAPACITOR 10uF 50V M
C734 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C735 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C736 NDC31HJ-561X C CAPACITOR 560pF 50V J
C737 QETN1CM-107Z E CAPACITOR 100uF 16V M
C738 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C739 QETN1CM-107Z E CAPACITOR 100uF 16V M
C740 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C741 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C742 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C743 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C744 QETN1CM-107Z E CAPACITOR 100uF 16V M
C745 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C746 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C747 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C748 QETN1HM-226Z E CAPACITOR 22uF 50V M
C749 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C750 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C751 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C752 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C753 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C754 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C755 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C756 QETN1CM-107Z E CAPACITOR 100uF 16V M
C757 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C758 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C759 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C760 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C761 NCB31HK-682X C CAPACITOR 6800pF 50V K
C762 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C763 QETN1CM-107Z E CAPACITOR 100uF 16V M
C764 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C765 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C766 QETN1HM-106Z E CAPACITOR 10uF 50V M
C767 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C768 NCB31HK-102X C CAPACITOR 1000pF 50V K
C769 NCB31HK-102X C CAPACITOR 1000pF 50V K
C770 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C771 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C772 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C775 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C776 NCB31HK-102X C CAPACITOR 1000pF 50V K
C777 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C779 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C780 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C781 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C782 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C783 NRSA63J-0R0X MG RESISTOR 0
C784 QETN1HM-106Z E CAPACITOR 10uF 50V M
C788 NRSA63J-0R0X MG RESISTOR 0
C790 NDC31HJ-2R0X C CAPACITOR 2pF 50V J
C791 NCB31HK-102X C CAPACITOR 1000pF 50V K
C792 NCB31HK-102X C CAPACITOR 1000pF 50V K
Ω
1/16W J
Ω
1/16W J
C793 NCB31HK-102X C CAPACITOR 1000pF 50V K
C904 QETN1CM-107Z E CAPACITOR 100uF 16V M
C905 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C906 QETN1CM-107Z E CAPACITOR 100uF 16V M
R101 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R102 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R103 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R104 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R105 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R106 NRSA63J-150X MG RESISTOR 15Ω 1/16W J
R107 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R108 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R110 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R111 NRSA63J-330X MG RESISTOR 33Ω 1/16W J
R112 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R113 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R114 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R115 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R116 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R119 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R201 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R202 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R208 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R209 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R210 NRSA63J-333X MG RESISTOR 33k
R211 NRSA63J-333X MG RESISTOR 33k
R212 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R213 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R214 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R215 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R216 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R217 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R218 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R220 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R221 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R222 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R226 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R227 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R229 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R232 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R233 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R234 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R235 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R236 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R237 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R238 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R239 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R240 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R241 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R242 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R243 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R244 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R245 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R246 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R247 NRSA63J-101X MG RESISTOR 100
R249 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R251 NRSA63J-822X MG RESISTOR 8.2k
R253 NRSA63J-153X MG RESISTOR 15k
R255 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R258 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R259 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R260 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R261 NRSA63J-391X MG RESISTOR 390
R262 NRSA63J-391X MG RESISTOR 390
R263 NRSA63J-104X MG RESISTOR 100k
R264 NRSA63J-101X MG RESISTOR 100
R265 NRSA63J-101X MG RESISTOR 100
R266 NRSA63J-101X MG RESISTOR 100
R267 NRSA63J-101X MG RESISTOR 100
R268 NRSA63J-101X MG RESISTOR 100
R269 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R270 NRSA63J-101X MG RESISTOR 100
R271 NRSA63J-333X MG RESISTOR 33k
R272 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R273 NRSA63J-222X MG RESISTOR 2.2k
R274 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R275 NRSA63J-391X MG RESISTOR 390
R276 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R277 NRSA63J-153X MG RESISTOR 15k
R279 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R280 NRSA63J-562X MG RESISTOR 5.6k
R281 NRSA63J-681X MG RESISTOR 680
R282 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R283 QRG01GJ-101 OMF RESISTOR 100Ω 1W J
R284 QRK126J-181X UNF C RESISTOR 180
R285 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/2W J
Ω
1/16W J
3-6(No.YA260)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R286 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R287 QRK126J-151X UNF C RESISTOR 150Ω 1/2W J
R288 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R289 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R290 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R291 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R292 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R293 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R295 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R296 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R297 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R298 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R299 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R300 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R301 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R302 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R304 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R305 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R306 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R307 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R308 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R313 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R314 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R316 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R317 NRSA63J-0R0X MG RESISTOR 0
R318 NRSA63J-0R0X MG RESISTOR 0
R319 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R551 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R552 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R553 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R554 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R555 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R556 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R557 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R558 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R559 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R560 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R561 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R562 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R563 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R564 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R629 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R633 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R634 QRK126J-2R2X UNF C RESISTOR 2.2Ω 1/2W J
R636 QRK126J-2R2X UNF C RESISTOR 2.2Ω 1/2W J
R641 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R642 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R646 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R647 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R648 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R649 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R650 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R653 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R663 NRSA63J-822X MG RESISTOR 8.2k
R664 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R669 NRSA63J-0R0X MG RESISTOR 0
R670 NRSA63J-0R0X MG RESISTOR 0
R671 QRE121J-562Y C RESISTOR 5.6kΩ 1/2W J
R672 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R673 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R674 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R675 NRSA63J-0R0X MG RESISTOR 0
R676 NRSA63J-0R0X MG RESISTOR 0
R685 NRSA63J-394X MG RESISTOR 390k
R686 NRSA63J-394X MG RESISTOR 390k
R687 NRSA63J-562X MG RESISTOR 5.6k
R688 NRSA63J-562X MG RESISTOR 5.6k
R689 NRSA63J-221X MG RESISTOR 220
R690 NRSA63J-221X MG RESISTOR 220
R701 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R709 NRSA63J-102X MG RESISTOR 1k
R710 NRSA63J-123X MG RESISTOR 12k
R711 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R712 NRSA63J-101X MG RESISTOR 100
R713 NRSA63J-272X MG RESISTOR 2.7kΩ 1/16W J
R714 NRSA63J-105X MG RESISTOR 1M
R715 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R717 NRSA63J-101X MG RESISTOR 100
R719 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R720 NRSA63J-104X MG RESISTOR 100k
R721 NRSA63J-101X MG RESISTOR 100
R724 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R725 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R726 NRSA63J-221X MG RESISTOR 220
R727 NRSA63J-332X MG RESISTOR 3.3k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R728 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R729 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R730 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R731 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R733 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R735 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R736 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R737 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R739 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R740 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R741 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R742 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R743 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R744 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R745 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R746 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R747 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R749 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R750 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R751 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R753 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R754 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R757 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R758 NRSA63J-103X MG RESISTOR 10k
R760 NRSA63J-102X MG RESISTOR 1k
R763 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R764 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R765 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R766 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R767 QRK126J-3R9X UNF C RESISTOR 3.9Ω 1/2W J
R768 QRK126J-3R9X UNF C RESISTOR 3.9Ω 1/2W J
R769 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R770 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R771 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R772 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R773 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R774 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R776 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R777 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R778 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R779 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R780 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R782 NDC31HJ-470X C CAPACITOR 47pF 50V J
R784 NDC31HJ-470X C CAPACITOR 47pF 50V J
R786 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R787 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R788 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
L101 QQL244K-100Z PEAKING COIL 10uH K
L102 QQL244K-270Z PEAKING COIL 27uH K
L103 QQL244K-4R7Z PEAKING COIL 4.7uH K
L104 QQL244K-1R5Z COIL 1.5uH K
L701 NQR0199-004X FERRITE BEADS
L702 NQR0199-001X FERRITE BEADS
L703 NQR0199-004X FERRITE BEADS
L704 NQR0199-004X FERRITE BEADS
L705 NQR0199-004X FERRITE BEADS
L706 NQR0199-004X FERRITE BEADS
L707 NQR0199-004X FERRITE BEADS
L708 NQR0199-004X FERRITE BEADS
L709 NQR0199-004X FERRITE BEADS
L710 NQR0199-004X FERRITE BEADS
L711 NQR0199-004X FERRITE BEADS
L712 NQR0199-004X FERRITE BEADS
L713 NQR0199-004X FERRITE BEADS
L714 NQR0199-004X FERRITE BEADS
L715 NQR0199-004X FERRITE BEADS
L716 NQR0199-004X FERRITE BEADS
L717 NQR0199-004X FERRITE BEADS
L718 NQR0199-004X FERRITE BEADS
CF101 QAX0619-001 C TRAP 40.40MHz
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN003 QGB1506L1-16 CONNECTOR B-B (1-16)
CN004 QGB1506L1-16 CONNECTOR B-B (1-16)
CN00B QJB003-042424-E SIN ID C-B WIRE
CN00K QJK002-034423-E SIN CR C-B WIRE
CN00S QJK002-053620-E SIN CR C-B WIRE
K551 QQR0621-002Z FERRITE BEADS
K552 QQR0621-002Z FERRITE BEADS
SF101 QAX0531-001 SAW FILTER
SF102 QAX0621-001 SAW FILTER
TU101 QAU0373-001 TUNER
X701 QAX0799-001Z CRYSTAL
Ω
1/16W J
Ω
1/16W J
(No.YA260)3-7
POWER & DEF P.W. BOARD ASS'Y (SJW-2011A-U2)
Ref No. Part No. Part Name Description Local
IC401 LA78041 IC
IC901 ICE1QS01 IC
IC951 SE140N IC
IC961 PQ120RDA1SZ IC
IC962 PQ050RDA1SZ IC
IC965 BA033T REGULATOR IC
Q402 KTC3199/YG/-T TRANSISTOR
Q461 RDN050N20 POWER MOS FET
Q501 BSN304-T MOS FET
Q521 2SC5902-RL POW TRANSISTOR H. OUT
Q541 KTC3199/YG/-T TRANSISTOR
Q571 DTC124ESA-T DIGI TRANSISTOR
Q572 KTC3199/YG/-T TRANSISTOR
Q573 RDN050N20 POWER MOS FET
Q574 RDN050N20 POWER MOS FET
Q591 2SA1208/ST/Z1-T TRANSISTOR
Q592 DTC124ESA-T DIGI TRANSISTOR
Q593 KTC3199/YG/-T TRANSISTOR
Q901 STP13NK60ZFP POWER MOS FET
Q902 KTA1267/YG/-T TRANSISTOR
Q931 KTC3199/YG/-T TRANSISTOR
Q932 DTC124ESA-T DIGI TRANSISTOR
Q934 KTC3199/YG/-T TRANSISTOR
D402 1SR35-400A-T2 SI DIODE
D491 1SS133-T2 SI DIODE
D493 1SS133-T2 SI DIODE
D521 RH3G-F1 SI DIODE
D522 RU4AM-LFT2 SI DIODE
D523 FR105GT-T3 SI DIODE
D525 MTZJ5.1B-T2 Z DIODE
D541 FR105GT-T3 SI DIODE
D551 FR105GT-T3 SI DIODE
D553 FR105GT-T3 SI DIODE
D554 FR105GT-T3 SI DIODE
D592 MTZJ7.5B-T2 Z DIODE
D593 FR105GT-T3 SI DIODE
D594 MTZJ7.5S-T2 Z DIODE
D901 D3SBA60 DIODE
D902 FR107GT-T3 SI DIODE
D904 1SR35-400A-T2 SI DIODE
D905 1SR35-400A-T2 SI DIODE
D906 1SR35-400A-T2 SI DIODE
D907 1SR35-400A-T2 SI DIODE
D911 MTZJ18C-T2 Z DIODE
D951 RU4AM-F1 SI DIODE
D953 FR105GT-T3 SI DIODE
D954 FR105GT-T3 SI DIODE
D955 FSF05A20 SI DIODE
D957 FR105GT-T3 SI DIODE
D958 1SR35-400A-T2 SI DIODE
D963 MTZJ3.9B-T2 Z DIODE
D964 MTZJ33B-T2 Z DIODE
D965 MTZJ4.7B-T2 Z DIODE
D967 MTZJ5.6B-T2 Z DIODE
D981 1SS133-T2 SI DIODE
D983 1SS133-T2 SI DIODE
C401 QEHR1VM-227Z E CAPACITOR 220uF 35V M
C402 QETM1VM-108 E CAPACITOR 1000uF 35V M
C405 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C406 QCZ0337-180Z C CAPACITOR 18pF 2kV J
C408 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C409 QDC31HJ-470Z C CAPACITOR 47pF 50V J
C410 QFVF1HJ-334Z MF CAPACITOR 0.33uF 50V J
C411 QFLC2AJ-104Z M CAPACITOR 0.1uF 100V J
C461 QEZ0195-475Z BP E CAPACITOR 4.7uF 50V M
C491 QETN1HM-106Z E CAPACITOR 10uF 50V M
C502 QCB32HK-681Z C CAPACITOR 680pF 500V K
C503 QEHR2CM-105Z E CAPACITOR 1uF 160V M
C521 QFZ0196-352 MPP CAPACITOR 3500pF 1.5kV H
C522 QFZ0196-103 MPP CAPACITOR 0.01uF 1.5kV H
C523 QFP32GJ-223 PP CAPACITOR 0.022uF 400V J
C524 QFM72DK-104 M CAPACITOR 0.1uF 200V K
C526 QFZ0197-254 MPP CAPACITOR 0.25uF 250V J
C527 QEHR2EM-475Z E CAPACITOR 4.7uF 250V M
C529 QFM72DK-393 M CAPACITOR 0.039uF 200V K
C530 QCB32HK-561Z C CAPACITOR 560pF 500V K
C531 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C533 QCS32HJ-560Z C CAPACITOR 56pF 500V J
C541 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C551 QETN2EM-106Z E CAPACITOR 10uF 250V M
C552 QCB32HK-152Z C CAPACITOR 1500pF 500V K
C553 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
Ref No. Part No. Part Name Description Local
C554 QCB32HK-152Z C CAPACITOR 1500pF 500V K
C555 QEHR1EM-108Z E CAPACITOR 1000uF 25V M
C560 QETM2CM-227 E CAPACITOR 220uF 160V M
C572 QFZ0197-154 MPP CAPACITOR 0.15uF 250V J
C591 QETN1AM-107Z E CAPACITOR 100uF 10V M
C592 QETN1EM-476Z E CAPACITOR 47uF 25V M
C593 QETN2AM-106Z E CAPACITOR 10uF 100V M
C594 QETN1AM-227Z E CAPACITOR 220uF 10V M
C901 QFZ9075-473 MPP CAPACITOR 0.047uF AC275V M
C903 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C904 QCZ9054-472 C CAPACITOR 4700pF AC250V Z
C905 QCZ9054-472 C CAPACITOR 4700pF AC250V Z
C906 QCZ9054-472 C CAPACITOR 4700pF AC250V Z
C907 QEZ0649-227 E CAPACITOR 220uF 400V M
C908 QCB32HK-103 C CAPACITOR 0.01uF 500V K
C909 QCZ0122-561 C CAPACITOR 560pF 2kV K
C910 QCZ0122-391 C CAPACITOR 390pF 2kV K
C911 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C912 QFLC1HJ-681Z M CAPACITOR 680pF 50V J
C913 QDC31HJ-820Z C CAPACITOR 82pF 50V J
C914 QFLC2AJ-683Z M CAPACITOR 0.068uF 100V J
C916 QETN1EM-107Z E CAPACITOR 100uF 25V M
C918 QFZ9072-104 MM CAPACITOR 0.1uF AC250V K
C919 QFLC1HJ-102Z M CAPACITOR 1000pF 50V J
C920 QDC31HJ-150Z C CAPACITOR 15pF 50V J
C933 QETM1VM-338 E CAPACITOR 3300uF 35V M
C951 QCZ0122-561 C CAPACITOR 560pF 2kV K
C952 QEZ0203-227 E CAPACITOR 220uF 160V M
C953 QCB32HK-391Z C CAPACITOR 390pF 500V K
C954 QTMM1EM-228 E CAPACITOR 2200uF 25V M
C955 QCB32HK-391Z C CAPACITOR 390pF 500V K
C956 QTMM1CM-228 E CAPACITOR 2200uF 16V M
C959 QETM1VM-338 E CAPACITOR 3300uF 35V M
C964 QFVF1HJ-684Z MF CAPACITOR 0.68uF 50V J
C965 QETN1VM-477Z E CAPACITOR 470uF 35V M
C966 QCB31HK-103Z C CAPACITOR 0.01uF 50V K
C967 QETN1AM-227Z E CAPACITOR 220uF 10V M
C968 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C969 QEHR1CM-477Z E CAPACITOR 470uF 16V M
C970 QEHR1CM-107Z E CAPACITOR 100uF 16V M
C974 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C975 QETN1AM-227Z E CAPACITOR 220uF 10V M
C976 QETN1EM-476Z E CAPACITOR 47uF 25V M
C991 QCZ9079-332 C CAPACITOR 3300pF AC250V M
R401 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R402 QRE141J-101Y C RESISTOR 100Ω 1/4W J
R403 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R404 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R414 QRE121J-5R6Y C RESISTOR 5.6Ω 1/2W J
R415 QRX01GJ-1R8 MF RESISTOR 1.8Ω 1W J
R416 QRG01GJ-820 OMF RESISTOR 82Ω 1W J
R417 QRE121J-100Y C RESISTOR 10Ω 1/2W J
R461 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R462 QRE141J-823Y C RESISTOR 82kΩ 1/4W J
R467 QRL039J-120 OMF RESISTOR 12
R492 QRE141J-683Y C RESISTOR 68kΩ 1/4W J
R493 QRE141J-224Y C RESISTOR 220k
R495 QRE141J-103Y C RESISTOR 10k
R496 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R497 QRE141J-153Y C RESISTOR 15kΩ 1/4W J
R501 QRE141J-561Y C RESISTOR 560Ω 1/4W J
R502 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R503 QRE121J-152Y C RESISTOR 1.5k
R504 QRL039J-332 OMF RESISTOR 3.3k
R505 QRL039J-332 OMF RESISTOR 3.3k
R506 QRE141J-222Y C RESISTOR 2.2k
R521 QRE121J-150Y C RESISTOR 15
R522 QRL039J-103 OMF RESISTOR 10k
R523 QRE121J-471Y C RESISTOR 470
R524 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J
R525 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R541 QRE141J-332Y C RESISTOR 3.3k
R542 QRE141J-333Y C RESISTOR 33k
R543 QRE121J-272Y C RESISTOR 2.7kΩ 1/2W J
R544 QRE141J-392Y C RESISTOR 3.9k
R545 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R546 QRE141J-223Y C RESISTOR 22k
R551 QRT039J-1R2 MF RESISTOR 1.2Ω 3W J
R552 QRT039J-1R2 MF RESISTOR 1.2
R553 QRF104K-5R6 UNF WW RESISTOR 5.6Ω 10W K
R554 QRZ9021-1R2 FUSI RESISTOR 1.2Ω 1W J
R555 QRZ9011-4R7 FUSI RESISTOR 4.7Ω 1/2W J
R571 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R572 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R573 QRE141J-183Y C RESISTOR 18k
R574 QRE121J-124Y C RESISTOR 120k
Ω
3W J
Ω
1/4W J
Ω
1/4W J
Ω
1/2W J
Ω
3W J
Ω
3W J
Ω
1/4W J
Ω
1/2W J
Ω
3W J
Ω
1/2W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
1/4W J
Ω
3W J
Ω
1/4W J
Ω
1/2W J
3-8(No.YA260)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R575 QRE141J-123Y C RESISTOR 12kΩ 1/4W J
R576 QRE121J-124Y C RESISTOR 120kΩ 1/2W J
R577 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R591 QRE121J-123Y C RESISTOR 12kΩ 1/2W J
R592 QRA14CF-1201Y CMF RESISTOR 1.2kΩ 1/4W F
R593 QRE141J-183Y C RESISTOR 18kΩ 1/4W J
R594 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R595 QRA14CF-1962Y CMF RESISTOR 19.6kΩ 1/4W F
R596 QRA14CF-2671Y CMF RESISTOR 2.67kΩ 1/4W F
R597 QRE141J-273Y C RESISTOR 27kΩ 1/4W J
R902 QRE121J-331Y C RESISTOR 330Ω 1/2W J
R903 QRF104K-3R9 UNF WW RESISTOR 3.9Ω 10W K
R904 QRE121J-474Y C RESISTOR 470kΩ 1/2W J
R905 QRE121J-474Y C RESISTOR 470kΩ 1/2W J
R907 QRL039J-823 OMF RESISTOR 82kΩ 3W J
R908 QRL039J-823 OMF RESISTOR 82kΩ 3W J
R909 QRE121J-185Y C RESISTOR 1.8MΩ 1/2W J
R910 QRE121J-334Y C RESISTOR 330kΩ 1/2W J
R911 QRE121J-394Y C RESISTOR 390kΩ 1/2W J
R912 QRE141J-470Y C RESISTOR 47Ω 1/4W J
R913 QRE121J-330Y C RESISTOR 33Ω 1/2W J
R914 QRE141J-474Y C RESISTOR 470kΩ 1/4W J
R915 QRE141J-104Y C RESISTOR 100kΩ 1/4W J
R916 QRE141J-823Y C RESISTOR 82kΩ 1/4W J
R917 QRE141J-223Y C RESISTOR 22kΩ 1/4W J
R918 QRE141J-120Y C RESISTOR 12
R931 QRE141J-472Y C RESISTOR 4.7k
R934 QRE141J-103Y C RESISTOR 10kΩ 1/4W J
R935 QRE141J-223Y C RESISTOR 22kΩ 1/4W J
R937 QRE141J-562Y C RESISTOR 5.6kΩ 1/4W J
R938 QRE141J-331Y C RESISTOR 330Ω 1/4W J
R939 QRZ9017-4R7 FUSI RESISTOR 4.7Ω 1/4W J
R941 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R942 QRL039J-102 OMF RESISTOR 1kΩ 3W J
R943 QRL039J-102 OMF RESISTOR 1kΩ 3W J
R944 QRE141J-102Y C RESISTOR 1kΩ 1/4W J
R952 QRE141J-222Y C RESISTOR 2.2kΩ 1/4W J
R964 QRE121J-222Y C RESISTOR 2.2kΩ 1/2W J
R967 QRL039J-223 OMF RESISTOR 22kΩ 3W J
R991 QRZ9046-825Z C RESISTOR 8.2MΩ 1/2W K
L461 QQLZ036-821 COIL 820uH K
L521 QQR1422-003 CHOKE COIL
L522 QQR1106-002 LINEARITY COIL
L901 QQL402K-100 CHOKE COIL 10uH K
L902 QQL402K-100 CHOKE COIL 10uH K
L903 QQR1200-001 CHOKE COIL
L951 QQLZ026-460 COIL 46uH Å}7%
L952 QQL26AK-820Z CHOKE COIL 82uH K
L954 QQL26AM-5R6Z CHOKE COIL 5.6uH M
L955 QQL26AK-220Z CHOKE COIL 22uH K
T501 QQR1414-001 DRIVE TRANSF
T901 QQS0262-001 SW TRANSF
CN003 QGB1506M1-16 CONNECTOR B-B (1-16)
CN004 QGB1506M1-16 CONNECTOR B-B (1-16)
CN0HV QGZ8005C3-05 CONNECTOR (1-5)
CP951 ICP-N50-T IC PROTECTOR 2.0A
CP952 ICP-N50-T IC PROTECTOR 2.0A
CP953 QMFZ049-4R0Z-E FUSE 4A 125V
CP955 ICP-N75-T IC PROTECTOR 2.7A
K401 QQR0621-002Z FERRITE BEADS
K503 QQR0582-001Z FERRITE BEADS
K504 QQR0582-001Z FERRITE BEADS
K901 QQR1113-001Z FERRITE BEADS
K902 QQR0621-002Z FERRITE BEADS
K951 QQR0872-001Y FERRITE BEADS
K952 QQR0621-002Z FERRITE BEADS
K953 QQR0621-002Z FERRITE BEADS
K954 QQR0621-002Z FERRITE BEADS
K956 QQR0621-002Z FERRITE BEADS
LF902 QQR1095-001 LINE FILTER
PC571 PC123Y22FZ PHOTO COUPLER
PC901 PC123Y22FZ PHOTO COUPLER
Ω
1/4W J
Ω
1/4W J
CRT SOCKET P.W. BOARD ASS'Y (SJW-3011A-U2)
Ref No. Part No. Part Name Description Local
IC3101 TDA6107AJF/N1 IC
Q3304 KTC3199/YG/-T TRANSISTOR
Q3305 KTC3199/YG/-T TRANSISTOR
Q3306 KTA1267/YG/-T TRANSISTOR
Q3309 2SA1837 POW TRANSISTOR
Q3310 2SC4793 POW TRANSISTOR
D3101 FR105GT-T3 SI DIODE
D3102 FR105GT-T3 SI DIODE
D3103 FR105GT-T3 SI DIODE
D3111 1SR35-400A-T2 SI DIODE
D3301 UDZS15B-X Z DIODE
D3302 FR105GT-T3 SI DIODE
D3303 FR105GT-T3 SI DIODE
C3101 QFK62EK-104Z MM CAPACITOR 0.1uF 250V K
C3102 NDC31HJ-101X C CAPACITOR 100pF 50V J
C3103 QETN2EM-475Z E CAPACITOR 4.7uF 250V M
C3111 QETM2EM-336 E CAPACITOR 33uF 250V M
C3112 QETM2EM-106 E CAPACITOR 10uF 250V M
C3113 QCZ0131-222 C CAPACITOR 2200pF 2kV K
C3301 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C3305 QETN1HM-335Z E CAPACITOR 3.3uF 50V M
C3306 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3307 NDC31HJ-150X C CAPACITOR 15pF 50V J
C3308 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3309 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3310 QETN2CM-106Z E CAPACITOR 10uF 160V M
C3312 QCB32HK-472Z C CAPACITOR 4700pF 500V K
C3314 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3315 QCS32HJ-680Z C CAPACITOR 68pF 500V J
C3316 QETN1CM-107Z E CAPACITOR 100uF 16V M
C3317 QETN1AM-337Z E CAPACITOR 330uF 10V M
R3101 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R3102 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R3103 NRSA63J-151X MG RESISTOR 150Ω 1/16W J
R3104 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K
R3105 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K
R3106 QRC121K-561Z COMP RESISTOR 560Ω 1/2W K
R3107 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R3108 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R3109 QRZ0107-152Z C RESISTOR 1.5kΩ 1/2W K
R3110 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R3121 QRE121J-474Y C RESISTOR 470kΩ 1/2W J
R3122 QRZ0107-102Z C RESISTOR 1kΩ 1/2W K
R3123 QRE121J-105Y C RESISTOR 1MΩ 1/2W J
R3124 QRZ0107-474Z C RESISTOR 470kΩ 1/2W K
R3301 QRZ9021-561 FUSI RESISTOR 560Ω 1W J
R3303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R3312 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R3313 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R3314 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R3315 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R3316 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R3317 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R3318 QRJ146J-100X UNF C RESISTOR 10Ω 1/4W J
R3319 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R3320 NRSA63J-122X MG RESISTOR 1.2k
R3321 NRSA63J-390X MG RESISTOR 39Ω 1/16W J
R3322 QRE121J-2R7Y C RESISTOR 2.7
R3323 QRE121J-563Y C RESISTOR 56k
R3324 QRE121J-563Y C RESISTOR 56kΩ 1/2W J
R3325 NRSA63J-122X MG RESISTOR 1.2kΩ 1/16W J
R3326 QRE121J-2R7Y C RESISTOR 2.7Ω 1/2W J
R3327 NRSA63J-390X MG RESISTOR 39Ω 1/16W J
R3328 NRSA63J-121X MG RESISTOR 120
R3329 QRL029J-391 OMF RESISTOR 390
L3101 QQL244J-5R6Z COIL 5.6uH J
L3301 QQL244J-391Z PEAKING COIL 390uH J
CN3008 QJK002-073622-E SIN CR C-B WIRE
CN3009 QJK002-063231-E SIN CR C-B WIRE
CN30E2 QGZ8005C3-01 CONNECTOR (1-1)
CN30SC QGZ0017C1-01Z CONNECTOR (1-1)
K3301 QQR1523-001Z CHOKE COIL
K3302 QQR1523-001Z CHOKE COIL
K3303 QQR1523-001Z CHOKE COIL
K3304 QQR1523-001Z CHOKE COIL
K3305 QQR0621-002Z FERRITE BEADS
SG3101 QAF0056-501Z SURGE ABSORBER 500V M
SG3102 QAF0056-501Z SURGE ABSORBER 500V M
SG3103 QAF0056-501Z SURGE ABSORBER 500V M
SK3001 QNZ0536-001 CRT SOCKET
Ω
1/16W J
Ω
1/2W J
Ω
1/2W J
Ω
1/16W J
Ω
2W J
(No.YA260)3-9
FRONT CONTROL P.W. BOARD ASS'Y (SJW-8011A-U2)
Ref No. Part No. Part Name Description Local
IC8851 RPM7238-H5 IR DETECT UNIT
Q8801 UN2212-X DIGI TRANSISTOR
Q8802 UN2212-X DIGI TRANSISTOR
D8801 LH22440-T16 LED POWER
C8851 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C8852 QETN1CM-107Z E CAPACITOR 100uF 16V M
C8901 QFZ9072-474 MM CAPACITOR 0.47uF AC250V K
R8801 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R8802 NRSA63J-561X MG RESISTOR 560Ω 1/16W J
R8803 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R8851 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R8852 QRE121J-470Y C RESISTOR 47Ω 1/2W J
CN800W WJK0200-008A-E E-SI C WIRE C-B
F8901 QMF5AD2-3R15-J1 FUSE 3.15A AC250V
LF8901 QQR1095-001 LINE FILTER
S8901 QSW0824-001 PUSH SWITCH POWER
SIDE CONTROL P.W. BOARD ASS'Y (SJW-8111A-U2)
Ref No. Part No. Part Name Description Local
C8101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8102 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C8103 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8104 NCB31HK-102X C CAPACITOR 1000pF 50V K
C8131 NCB31HK-472X C CAPACITOR 4700pF 50V K
C8132 NCB31HK-472X C CAPACITOR 4700pF 50V K
C8133 NCB31CK-104X C CAPACITOR 0.1uF 16V K
R8101 NRSA63J-821X MG RESISTOR 820Ω 1/16W J
R8102 NRSA63J-152X MG RESISTOR 1.5kΩ 1/16W J
R8111 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R8112 QRE121J-271Y C RESISTOR 270Ω 1/2W J
R8113 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R8114 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R8133 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
L8111 QQL244K-5R6Z PEAKING COIL 5.6uH K
L8112 QQL244K-5R6Z PEAKING COIL 5.6uH K
L8131 QQL244K-270Z PEAKING COIL 27uH K
L8132 QQL244K-270Z PEAKING COIL 27uH K
J8111 QMS3001-C01 3.5 JACK HEADPHONE
J8131 QNN0591-001 PIN JACK EXT-4
K8111 NQR0389-003X FERRITE BEADS
K8131 NQR0389-003X FERRITE BEADS
S8101 QSW0619-003Z TACT SWITCH VOL UP
S8102 QSW0619-003Z TACT SWITCH MENU
S8103 QSW0619-003Z TACT SWITCH VOL DOWN
Ref No. Part No. Part Name Description Local
C0110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0111 QETN1HM-106Z E CAPACITOR 10uF 50V M
C0112 QETN1HM-106Z E CAPACITOR 10uF 50V M
C0113 QETN1HM-106Z E CAPACITOR 10uF 50V M
R0101 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0102 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0103 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0104 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0105 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0106 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0107 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0108 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0109 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0110 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0111 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0112 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R0120 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R0121 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R0122 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R0123 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
CN0001 QGB1505K1-35 CONNECTOR B-B (1-35)
J0001 QNZ0465-001 21P CONNECTOR EXT-2/EXT-3
J0002 QNZ0463-001 21P CONNECTOR EXT-1
K0101 NQR0389-003X FERRITE BEADS
K0102 NQR0389-003X FERRITE BEADS
K0103 NQR0389-003X FERRITE BEADS
AV JACK P.W. BOARD ASS'Y (SJW0J011A-U2)
Ref No. Part No. Part Name Description Local
D0101 UDZS5.6B-X Z DIODE 1.5kΩ 1/10W J
D0102 UDZS5.6B-X Z DIODE 1.5k
D0103 UDZS5.6B-X Z DIODE 1.5k
D0104 UDZS5.6B-X Z DIODE 1.5k
D0115 UDZS5.6B-X Z DIODE 1.5k
D0116 UDZS5.6B-X Z DIODE 1.5k
D0117 UDZS5.6B-X Z DIODE 1.5k
D0118 UDZS5.6B-X Z DIODE 1.5kΩ 1/10W J
D0119 UDZS5.6B-X Z DIODE 1.5k
C0101 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0102 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0103 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0104 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0105 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0106 NDC31HJ-221X C CAPACITOR 220pF 50V J
C0107 NCB31HK-472X C CAPACITOR 4700pF 50V K
C0108 NDC31HJ-221X C CAPACITOR 220pF 50V J
C0109 NCB31HK-472X C CAPACITOR 4700pF 50V K
3-10(No.YA260)
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
Ω
1/10W J
PRINTED WIRING BOARD PARTS LIST [AV-32T5SK, AV-32T5BK]
MAIN P.W. BOARD ASS'Y (SJW-1911A-U2)
Ref No. Part No. Part Name Description Local
IC201 CXA2089Q-X IC
IC551 LA6515 IC
IC602 AN5277 IC
IC603 BD3869AF-X IC
IC701 TDA12020-32T5SP IC(MCU) (SERVICE)
IC702 ATF16-32T5SK IC (SERVICE)
IC902 AN78L09-T IC
Q101 2SC5397/CD/-T TRANSISTOR
Q201 2SC3928A/QR/-X TRANSISTOR
Q202 2SC3928A/QR/-X TRANSISTOR
Q207 UN2226-X DIGI TRANSISTOR
Q210 2SA1530A/QR/-X TRANSISTOR
Q211 UN2226-X DIGI TRANSISTOR
Q212 2SA1530A/QR/-X TRANSISTOR
Q213 UN2226-X DIGI TRANSISTOR
Q214 UN2226-X DIGI TRANSISTOR
Q215 KTA1267/YG/-T TRANSISTOR
Q217 KTC3199/YG/-T TRANSISTOR
Q218 2SC3928A/QR/-X TRANSISTOR
Q219 2SC3928A/QR/-X TRANSISTOR
Q220 2SC3928A/QR/-X TRANSISTOR
Q221 2SC3928A/QR/-X TRANSISTOR
Q301 2SA1530A/QR/-X TRANSISTOR
Q302 2SC3928A/QR/-X TRANSISTOR
Q551 2SC3928A/QR/-X TRANSISTOR
Q552 2SA1530A/QR/-X TRANSISTOR
Q617 2SC3928A/QR/-X TRANSISTOR
Q618 2SC3928A/QR/-X TRANSISTOR
Q620 UN2213-X DIGI TRANSISTOR
Q621 2SA1530A/QR/-X TRANSISTOR
Q622 2SC3928A/QR/-X TRANSISTOR
Q703 2SC3928A/QR/-X TRANSISTOR
Q704 2SC3928A/QR/-X TRANSISTOR
Q707 2SC3928A/QR/-X TRANSISTOR
Q708 2SC3928A/QR/-X TRANSISTOR
Q709 2SA562TM/Y/-T TRANSISTOR
Q710 2SA562TM/Y/-T TRANSISTOR
Q711 2SC3928A/QR/-X TRANSISTOR
Q712 2SA1530A/QR/-X TRANSISTOR
D201 MA8120/M/-X Z DIODE
D203 NCB21EK-104X C CAPACITOR 0.1uF 25V K
D204 MA8120/M/-X Z DIODE
D205 MA8120/M/-X Z DIODE
D206 MA8120/M/-X Z DIODE
D207 MA8120/M/-X Z DIODE
D208 MA8120/M/-X Z DIODE
D209 MA8120/M/-X Z DIODE
D211 MA8120/M/-X Z DIODE
D212 MA8120/M/-X Z DIODE
D213 MA8120/M/-X Z DIODE
D214 MA8120/M/-X Z DIODE
D215 MA8120/M/-X Z DIODE
D301 MA111-X SI DIODE
D302 MA111-X SI DIODE
D303 MA111-X SI DIODE
D304 NRSA02J-222X MG RESISTOR 2.2k
D607 MA111-X SI DIODE
D608 MA111-X SI DIODE
D609 MA111-X SI DIODE
D611 MA8330/L/-X Z DIODE
D613 MA8330/L/-X Z DIODE
D616 MA111-X SI DIODE
D621 MA8056/M/-X Z DIODE
D701 MA111-X SI DIODE
D702 1SS357-X SB DIODE
D704 MA8068/M/-X Z DIODE
D705 MA111-X SI DIODE
D706 MA111-X SI DIODE
D707 MA111-X SI DIODE
D708 MA111-X SI DIODE
D711 RB161L-40-X SB DIODE
D712 1N4003SG-T2 SI DIODE
D713 UDZS2.0B-X Z DIODE
D714 UDZS2.0B-X Z DIODE
D981 MA111-X SI DIODE
D982 MA111-X SI DIODE
D983 1N4003SG-T2 SI DIODE
C101 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C102 QETN1HM-106Z E CAPACITOR 10uF 50V M
Ω
1/10W J
Ref No. Part No. Part Name Description Local
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 QETN1AM-108Z E CAPACITOR 1000uF 10V M
C107 NCB31HK-222X C CAPACITOR 2200pF 50V K
C108 QETN1HM-226Z E CAPACITOR 22uF 50V M
C110 NCB31HK-472X C CAPACITOR 4700pF 50V K
C111 NCB31HK-472X C CAPACITOR 4700pF 50V K
C113 NCB31HK-472X C CAPACITOR 4700pF 50V K
C115 NCB31HK-472X C CAPACITOR 4700pF 50V K
C116 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C118 NCB31HK-472X C CAPACITOR 4700pF 50V K
C203 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C204 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C205 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C207 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C208 NDC31HJ-390X C CAPACITOR 39pF 50V J
C209 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C210 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C213 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C214 NDC31HJ-390X C CAPACITOR 39pF 50V J
C216 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C217 NDC31HJ-390X C CAPACITOR 39pF 50V J
C218 NDC31HJ-390X C CAPACITOR 39pF 50V J
C220 QETN1HM-106Z E CAPACITOR 10uF 50V M
C221 QETN1HM-106Z E CAPACITOR 10uF 50V M
C222 QETN1HM-106Z E CAPACITOR 10uF 50V M
C223 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C224 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C226 QETN1HM-106Z E CAPACITOR 10uF 50V M
C227 QETN1HM-106Z E CAPACITOR 10uF 50V M
C228 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C229 QETN1HM-106Z E CAPACITOR 10uF 50V M
C230 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C231 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C232 QETN1CM-107Z E CAPACITOR 100uF 16V M
C233 QETN1CM-107Z E CAPACITOR 100uF 16V M
C234 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C235 QETN1CM-107Z E CAPACITOR 100uF 16V M
C236 QETN1CM-477Z E CAPACITOR 470uF 16V M
C237 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C238 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C239 QETN1CM-477Z E CAPACITOR 470uF 16V M
C240 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C241 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NDC31HJ-100X C CAPACITOR 10pF 50V J
C302 NDC31HJ-100X C CAPACITOR 10pF 50V J
C303 QETN1CM-227Z E CAPACITOR 220uF 16V M
C304 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C305 NDC31HJ-100X C CAPACITOR 10pF 50V J
C306 QETN1AM-227Z E CAPACITOR 220uF 10V M
C551 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C552 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C553 QETN1EM-476Z E CAPACITOR 47uF 25V M
C554 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C555 NCF31CZ-224X C CAPACITOR 0.22uF 16V Z
C561 NDC31HJ-561X C CAPACITOR 560pF 50V J
C562 NCB11EK-105X C CAPACITOR 1uF 25V K
C617 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C619 QENC1HM-106Z BP E CAPACITOR 10uF 50V M
C620 QETN1HM-107Z E CAPACITOR 100uF 50V M
C621 QETM1VM-228 E CAPACITOR 2200uF 35V M
C622 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C623 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C626 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C627 QFVF1HJ-224Z MF CAPACITOR 0.22uF 50V J
C628 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C630 QETN1EM-108Z E CAPACITOR 1000uF 25V M
C632 QETN1HM-106Z E CAPACITOR 10uF 50V M
C633 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C634 QETN1CM-108Z E CAPACITOR 1000uF 16V M
C662 NDC31HJ-391X C CAPACITOR 390pF 50V J
C663 NDC31HJ-391X C CAPACITOR 390pF 50V J
C666 NCB31HK-222X C CAPACITOR 2200pF 50V K
C667 NCB31HK-222X C CAPACITOR 2200pF 50V K
C668 NCB31AK-105X C CAPACITOR 1uF 10V K
C669 NCB31AK-105X C CAPACITOR 1uF 10V K
C670 QETN1EM-226Z E CAPACITOR 22uF 25V M
C671 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C672 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C673 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 QETN1EM-476Z E CAPACITOR 47uF 25V M
C703 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C704 QETN1HM-106Z E CAPACITOR 10uF 50V M
C705 NCB31HK-332X C CAPACITOR 3300pF 50V K
(No.YA260)3-11
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
C706 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C707 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C708 QETN1HM-106Z E CAPACITOR 10uF 50V M
C709 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C710 QETN1HM-106Z E CAPACITOR 10uF 50V M
C711 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C712 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C713 NDC31HJ-470X C CAPACITOR 47pF 50V J
C714 NDC31HJ-470X C CAPACITOR 47pF 50V J
C715 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C716 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C717 NDC31HJ-470X C CAPACITOR 47pF 50V J
C718 NDC31HJ-470X C CAPACITOR 47pF 50V J
C719 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C720 NDC31HJ-470X C CAPACITOR 47pF 50V J
C721 NDC31HJ-470X C CAPACITOR 47pF 50V J
C722 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C723 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C724 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C725 QETN1HM-106Z E CAPACITOR 10uF 50V M
C726 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C727 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C728 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C729 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C730 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C731 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C732 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C733 QETN1HM-106Z E CAPACITOR 10uF 50V M
C734 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C735 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C736 NDC31HJ-561X C CAPACITOR 560pF 50V J
C737 QETN1CM-107Z E CAPACITOR 100uF 16V M
C738 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C739 QETN1CM-107Z E CAPACITOR 100uF 16V M
C740 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C741 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C742 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C743 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C744 QETN1CM-107Z E CAPACITOR 100uF 16V M
C745 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C746 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C747 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C748 QETN1HM-226Z E CAPACITOR 22uF 50V M
C749 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C750 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C751 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C752 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C753 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C754 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C755 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C756 QETN1CM-107Z E CAPACITOR 100uF 16V M
C757 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C758 NDC31HJ-7R0X C CAPACITOR 7pF 50V J
C759 NCB30JK-225X C CAPACITOR 2.2uF 6.3V K
C760 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C761 NCB31HK-682X C CAPACITOR 6800pF 50V K
C762 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C763 QETN1CM-107Z E CAPACITOR 100uF 16V M
C764 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C765 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C766 QETN1HM-106Z E CAPACITOR 10uF 50V M
C767 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C768 NCB31HK-102X C CAPACITOR 1000pF 50V K
C769 NCB31HK-102X C CAPACITOR 1000pF 50V K
C770 NCB31CK-473X C CAPACITOR 0.047uF 16V K
C771 QFVF1HJ-104Z MF CAPACITOR 0.1uF 50V J
C772 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C775 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C776 NCB31HK-102X C CAPACITOR 1000pF 50V K
C777 NCB31CK-224X C CAPACITOR 0.22uF 16V K
C779 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C780 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C781 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C782 NRSA63J-0R0X MG RESISTOR 0
C783 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
C784 QETN1HM-106Z E CAPACITOR 10uF 50V M
C788 NRSA63J-0R0X MG RESISTOR 0
C791 NCB31HK-102X C CAPACITOR 1000pF 50V K
C792 NCB31HK-102X C CAPACITOR 1000pF 50V K
C793 NCB31HK-102X C CAPACITOR 1000pF 50V K
C904 QETN1CM-107Z E CAPACITOR 100uF 16V M
C905 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C906 QETN1CM-107Z E CAPACITOR 100uF 16V M
R101 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R102 NRSA63J-101X MG RESISTOR 100
R103 NRSA63J-101X MG RESISTOR 100
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R104 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R105 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R106 NRSA63J-150X MG RESISTOR 15Ω 1/16W J
R107 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R108 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R110 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R111 NRSA63J-330X MG RESISTOR 33Ω 1/16W J
R112 NRSA63J-331X MG RESISTOR 330Ω 1/16W J
R114 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R115 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R116 NRSA63J-681X MG RESISTOR 680Ω 1/16W J
R119 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R201 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R202 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R208 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R209 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R210 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R211 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R212 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R213 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R214 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R215 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R216 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R217 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R218 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R220 NRSA63J-822X MG RESISTOR 8.2k
R221 NRSA63J-153X MG RESISTOR 15k
R222 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R226 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R227 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R229 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R232 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R233 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R234 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R235 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R236 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R237 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R238 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R239 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R240 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R241 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R242 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R243 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R244 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R245 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R246 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R247 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R249 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R251 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R253 NRSA63J-153X MG RESISTOR 15kΩ 1/16W J
R255 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R258 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R259 NRSA63J-823X MG RESISTOR 82kΩ 1/16W J
R260 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R261 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R262 NRSA63J-391X MG RESISTOR 390
R263 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R264 NRSA63J-101X MG RESISTOR 100
R265 NRSA63J-101X MG RESISTOR 100
R266 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R267 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R268 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R269 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R270 NRSA63J-101X MG RESISTOR 100
R271 NRSA63J-333X MG RESISTOR 33k
R272 NRSA63J-333X MG RESISTOR 33k
R273 NRSA63J-222X MG RESISTOR 2.2k
R274 NRSA63J-222X MG RESISTOR 2.2k
R275 NRSA63J-391X MG RESISTOR 390
R276 NRSA63J-391X MG RESISTOR 390
R277 NRSA63J-153X MG RESISTOR 15k
R279 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R280 NRSA63J-562X MG RESISTOR 5.6k
R281 NRSA63J-681X MG RESISTOR 680
R282 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R283 QRG01GJ-101 OMF RESISTOR 100
R284 QRK126J-181X UNF C RESISTOR 180Ω 1/2W J
R285 NRSA63J-101X MG RESISTOR 100
R286 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R287 QRK126J-151X UNF C RESISTOR 150
R288 NRSA63J-750X MG RESISTOR 75Ω 1/16W J
R289 NRSA63J-101X MG RESISTOR 100
R290 NRSA63J-101X MG RESISTOR 100
R291 NRSA63J-680X MG RESISTOR 68Ω 1/16W J
R292 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R293 NRSA63J-103X MG RESISTOR 10k
R295 NRSA63J-102X MG RESISTOR 1k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1W J
Ω
1/16W J
Ω
1/2W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
3-12(No.YA260)
Ref No. Part No. Part Name Description Local
Ref No. Part No. Part Name Description Local
R296 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R297 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R298 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R299 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R300 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R301 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R302 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R303 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R304 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R305 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R306 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R307 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R308 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R313 NRSA63J-470X MG RESISTOR 47Ω 1/16W J
R314 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R316 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R317 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R318 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R319 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R551 NRSA63J-124X MG RESISTOR 120kΩ 1/16W J
R552 NRSA63J-100X MG RESISTOR 10Ω 1/16W J
R553 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R554 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R555 NRSA63J-154X MG RESISTOR 150kΩ 1/16W J
R556 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R557 NRSA63J-100X MG RESISTOR 10
R558 NRSA63J-562X MG RESISTOR 5.6k
R559 NRSA63J-333X MG RESISTOR 33kΩ 1/16W J
R560 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R561 NRSA63J-683X MG RESISTOR 68kΩ 1/16W J
R562 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R563 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R564 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R629 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R631 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R633 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R634 QRK126J-2R2X UNF C RESISTOR 2.2Ω 1/2W J
R636 QRK126J-2R2X UNF C RESISTOR 2.2Ω 1/2W J
R641 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R642 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R646 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R647 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R648 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R649 NRSA63J-471X MG RESISTOR 470Ω 1/16W J
R650 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R653 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R663 NRSA63J-822X MG RESISTOR 8.2kΩ 1/16W J
R664 NRSA63J-183X MG RESISTOR 18kΩ 1/16W J
R669 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R670 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R671 QRE121J-562Y C RESISTOR 5.6kΩ 1/2W J
R672 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R673 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R674 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R675 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R676 NRSA63J-0R0X MG RESISTOR 0
R685 NRSA63J-394X MG RESISTOR 390kΩ 1/16W J
R686 NRSA63J-394X MG RESISTOR 390k
R687 NRSA63J-562X MG RESISTOR 5.6k
R688 NRSA63J-562X MG RESISTOR 5.6kΩ 1/16W J
R689 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R690 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R701 NRSA63J-391X MG RESISTOR 390Ω 1/16W J
R709 NRSA63J-102X MG RESISTOR 1k
R710 NRSA63J-123X MG RESISTOR 12k
R711 NRSA63J-103X MG RESISTOR 10k
R712 NRSA63J-101X MG RESISTOR 100
R713 NRSA63J-272X MG RESISTOR 2.7k
R714 NRSA63J-105X MG RESISTOR 1M
R715 NRSA63J-103X MG RESISTOR 10k
R717 NRSA63J-101X MG RESISTOR 100
R719 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R720 NRSA63J-104X MG RESISTOR 100k
R721 NRSA63J-101X MG RESISTOR 100
R724 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R725 NRSA63J-103X MG RESISTOR 10k
R726 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R727 NRSA63J-332X MG RESISTOR 3.3k
R728 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R729 NRSA63J-101X MG RESISTOR 100
R730 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R731 NRSA63J-222X MG RESISTOR 2.2k
R733 NRSA63J-101X MG RESISTOR 100
R734 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R735 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R736 NRSA63J-101X MG RESISTOR 100
R737 NRSA63J-122X MG RESISTOR 1.2k
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
Ω
1/16W J
R738 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R739 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R741 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R742 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
R743 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R744 NRSA63J-332X MG RESISTOR 3.3kΩ 1/16W J
R745 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R746 NRSA63J-123X MG RESISTOR 12kΩ 1/16W J
R747 NRSA63J-393X MG RESISTOR 39kΩ 1/16W J
R749 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R750 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R751 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R752 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R753 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R754 NRSA63J-273X MG RESISTOR 27kΩ 1/16W J
R757 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R758 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R760 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J
R763 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R764 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R765 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R766 NRSA63J-221X MG RESISTOR 220Ω 1/16W J
R767 QRK126J-3R9X UNF C RESISTOR 3.9Ω 1/2W J
R768 QRK126J-3R9X UNF C RESISTOR 3.9Ω 1/2W J
R769 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R770 NRSA63J-473X MG RESISTOR 47k
R771 NRSA63J-472X MG RESISTOR 4.7k
R772 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R773 NRSA63J-222X MG RESISTOR 2.2kΩ 1/16W J
R774 NRSA63J-104X MG RESISTOR 100kΩ 1/16W J
R776 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R777 NRSA63J-101X MG RESISTOR 100Ω 1/16W J
R778 NRSA63J-223X MG RESISTOR 22kΩ 1/16W J
R779 NRSA63J-103X MG RESISTOR 10kΩ 1/16W J
R780 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J
R782 NDC31HJ-470X C CAPACITOR 47pF 50V J
R784 NDC31HJ-470X C CAPACITOR 47pF 50V J
R786 NRSA63J-220X MG RESISTOR 22Ω 1/16W J
R787 NRSA63J-0R0X MG RESISTOR 0Ω 1/16W J
R788 NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J
L101 QQL244K-100Z PEAKING COIL 10uH K
L102 QQL244K-270Z PEAKING COIL 27uH K
L103 QQL244K-4R7Z PEAKING COIL 4.7uH K
L104 QQL244K-1R5Z COIL 1.5uH K
L701 NQR0199-004X FERRITE BEADS
L702 NQR0199-001X FERRITE BEADS
L703 NQR0199-004X FERRITE BEADS
L704 NQR0199-004X FERRITE BEADS
L705 NQR0199-004X FERRITE BEADS
L706 NQR0199-004X FERRITE BEADS
L707 NQR0199-004X FERRITE BEADS
L708 NQR0199-004X FERRITE BEADS
L709 NQR0199-004X FERRITE BEADS
L710 NQR0199-004X FERRITE BEADS
L711 NQR0199-004X FERRITE BEADS
L712 NQR0199-004X FERRITE BEADS
L713 NQR0199-004X FERRITE BEADS
L714 NQR0199-004X FERRITE BEADS
L715 NQR0199-004X FERRITE BEADS
L716 NQR0199-004X FERRITE BEADS
L717 NQR0199-004X FERRITE BEADS
L718 NQR0199-004X FERRITE BEADS
CN001 QGB1505J1-35 CONNECTOR B-B (1-35)
CN003 QGB1506L1-16 CONNECTOR B-B (1-16)
CN004 QGB1506L1-16 CONNECTOR B-B (1-16)
CN00B QJB003-042424 SIN ID C-B WIRE
CN00K QJK002-034423 SIN CR C-B WIRE
CN00S QJK002-053620 SIN CR C-B WIRE
K551 QQR0621-002Z FERRITE BEADS
K552 QQR0621-002Z FERRITE BEADS
SF101 QAX0531-001 SAW FILTER
SF102 QAX0795-001 SAW FILTER
TU101 QAU0344-002 TUNER
X701 QAX0799-001Z CRYSTAL
Ω
1/16W J
Ω
1/16W J
(No.YA260)3-13
POWER & DEF P.W. BOARD ASS'Y (SJW-2011A-U2)
REFER TO PARTS LIST IN PAGE 3-8 FOR THIS P.W. BOARD.
SIDE CONTROL P.W. BOARD ASS'Y (SJW-8111A-U2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
CRT SOCKET P.W. BOARD ASS'Y (SJW-3011A-U2)
REFER TO PARTS LIST IN PAGE 3-9 FOR THIS P.W. BOARD.
AV JACK P.W. BOARD ASS'Y (SJW0J011A-U2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
FRONT CONTROL P.W. BOARD ASS'Y (SJW-8011A-U2)
REFER TO PARTS LIST IN PAGE 3-10 FOR THIS P.W. BOARD.
REMOTE CONTROL UNIT PARTS LIST (RM-C1502)
Ref.No. Part No. Part Name Description Local
2AK061080 BATTERY COVER AV-32T5SK,AV-32T5SP,AV-32T5SR
REMOTE CONTROL UNIT PARTS LIST (RM-C1502B)
Ref.No. Part No. Part Name Description Local
2AK044990 BATTERY COVER AV-32 T5B K,AV-3 2T5 BR
3-14(No.YA260)
PACKING
9
5
10 11
3
13 14
12
8
15 16 17
4
7
7
6
1
3
2
PACKING PARTS LIST
Ref.No. Part No. Part Name Description Local
1 GA10002-004A-U PACKING CASE AV-32 T5S P
1 GA10002-002A-U PACKING CASE
2 GA10001-051A-U EURO LABEL AV-32 T5B K
2 GA10001-032A-U EURO LABEL AV-3 2T5 BR
2 GA10001-003A-U EURO LABEL AV-32 T5S K
2 GA10001-001A-U EURO LABEL AV-32 T5S P
2 GA10001-002A-U EURO LABEL AV-3 2T5 SR
3 LC11861-001C-U CUSHION ASSY 4pcs in 1set
3 LC11861-001B-U CUSHION ASSY 4pcs in 1set AV-32T5SR
4 RM-C1502B-1C REMOCON AV-32 T5B K,AV-3 2T5 BR
4 RM-C1502-1C REMOCON AV-32T5SK,AV-32T5SP,AV-32T5SR
5 ------------ BATTERY R6P/AA(x2)
6 AEM1078-001A-U POLY BAG
7 GA10007-001A-U CUSHION For STAND/2pcs in 1set
8 GA30017-001A-U PACKING CASE For STAND
9 AEM3021-003B-E DOCUMENT BAGS
10 LCT1795-001A-U INST BOOK
10 LCT1794-001A-U INST BOOK English
11 LCT1796-001A-U INST BOOK Finn/Norwegian/Swedish AV-32T5SP
12 ------------ WARRANTY CARD BT-54026-1E AV-32T5BK,AV-32T5BR
12 ------------ WARRANTY CARD BT-54023-1E AV-32T5SK,AV-32T5SR
13 GA30011-001A-U REGISTRATION CARD AV-32T5BK,AV-32T5BR
13 AEM3148-001B-U REGISTRATION CARD AV-32T5SK,AV-32T5SR
14 QQR0675-001 CORE FILTER AV-32T5BR,AV-32T5SP,AV-32T5SR
15 GA30014-001A-U FIXING KIT
16 GA40022-001A-U SHELF SUPPORT Silver/4pcs in 1set AV-32T5SK,AV-32T5SR
16 GA40022-002A-U SHELF SUPPORT Brack/4pcs in 1set AV-32T5BK,AV-32T5BR
17 GA30015-001A-U
ASSEMBLY INSTRUCTIONS
English/French/German/Italian/Dutch/Portuguese/Spanish
For STAND
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SP
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32T5BK,AV-32T5BR,AV-32T5SK,AV-32T5SR
AV-32 T5S P
(No.YA260)3-15
Loading...
