JVC AV 32F802, AV 27F702, AV 36F802, AV 32F702, AV 36F702 User Manual

COLOR TELEVISION
USER'S GUIDE

For models:

AV-36F802
AV-36F702
AV-32F802
AV-32F702
AV-27F802
AV-27F702

Illustration of AV-27F802 and RM-C301G

IMPORTANT NOTE TOTHE CUSTOMER

In the spaces below, enter the model and serial number of your television (locat-

ed at the rear of the television cabinet). Staple your sales receipt or invoice to

the inside cover of this guide. Keep this user's guide in a convenient place for

future reference. Keep the carton and original packaging for future use.

Serial Number

Model Number

LCT0821-001D-A

0901-TN-FAA-JIM

IMPORTANT SAFETY PRECAUTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION:To reduce the risk of electric shock.

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualified service personnel.

The lightning flash with arrowhead symbol, with­in an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous
voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.

The exclamation point within an equilateral trian­gle is intended to alert the user to the presence
of important operating and maintenance (servic­ing) instructions in the literature accompanying
the appliance.

WARNING: TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT

EXPOSE THIS TV SET TO RAIN OR MOISTURE.

CAUTION: TO INSURE PERSONAL SAFETY, OBSERVE THE

FOLLOWING RULES REGARDING THE USE OF
THIS UNIT.

1.Operate only from the power source specified on the unit.

2. Avoid damaging the AC plug and power cord.

3. Avoid Improper installation and never position the unit where good venti­lation is unattainable.

4. Do not allow objects or liquid into the cabinet openings.

5.In the event of trouble, unplug the unit and call a service technician.Do
not attempt to repair it yourself or remove the rear cover.

Changes or modifications not approved by JVC could void the warranty.
* When you don’t use this TV set for a long period of time, be sure to dis-

connect both the power plug from the AC outlet and antenna for your
safety.

* To prevent electric shock do not use this polarized plug with an extension
cord, receptacle or other outlet unless the blades can be fully inserted to
prevent blade exposure.

IMPORTANT SAFEGUARDS

CAUTION:

Please read and retain for your safety.

Electrical energy can perform many useful functions. This TV set has been engineered and
manufactured to assure your personal safety. But improper use can result in potential electrical
shock or fire hazards. In order not to defeat the safeguards incorporated in this TVset,
observe the following basic rules for its installation, use and servicing.
And also follow all warnings and instructions marked on your TV set.

INSTALLATION

1 Your TV set is equipped with a polarized AC line plug (one blade of the plug is wider than the

other).

(POLARIZED-TYPE)

This safety feature allows the plug to fit into the power outlet only one way. Should you be
unable to insert the plug fully into the outlet, try reversing the plug.
Should it still fail to fit, contact your electrician.

2 Operate the TVset only from a power source as indicated on the TV set or refer to the oper-

ating instructions for this information. If you are not sure of the type of power supply to your
home, consult your TV set dealer or local power company.For battery operation, refer to the
operating instructions.

3 Overloaded AC outlets and extension cords are dangerous, and so are frayed power cords

and broken plugs. They may result in a shock or fire hazard. Call your service technician for
replacement.

4 Do not allow anything to rest on or roll over the power cord, and do not place the TV set

where power cord is subject to traffic or abuse. This may result in a shock or fire hazard.

5 Do not use this TV set near water — for example, near a bathtub, washbowl, kitchen sink, or

laundry tub, in a wet basement, or near swimming pool, etc.

6 If an outside antenna is connected to the TV set, be sure the antenna system is grounded so

as to provide some protection against voltage surges and built-up static charges. Section
810 of the National Electrical Code provides information with respect to proper grounding of
the mast and supporting structure, grounding of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location of antenna discharge unit, connection require­ments for the grounding electrode.

7 An outside antenna system should not be located in the vicinity of overhead power lines or

other electric light or power circuits, or where it can fall into such power lines or circuits.
When installing an outside antenna system, extreme care should be taken to keep from
touching such power lines or circuits as contact with them might be fatal.

EXAMPLE OF ANTENNA GROUNDING

AS PER NATIONAL ELECTRICAL CODE

8 TV sets are provided with ventilation openings in the cabinet to allow heat generated during

operation to be released.
Therefore:
— Never block the bottom ventilation slots of a portable TV set by placing it on a bed, sofa,

rug, etc.
— Never place a TV set in a “built-in” enclosure unless proper ventilation is provided.
— Never cover the openings with a cloth or other material.
— Never place the TV set near or over a radiator or heat register.

9 To avoid personal injury:

— Do not place a TV set on a sloping shelf unless properly secured.
— Use only a cart or stand recommended by the TVset manufacturer.
— Do not try to roll a cart with small casters across thresholds or deep pile carpets.
—Wall or shelf mounting should follow the manufacturer’s instructions, and should use a

mounting kit approved by the manufacturer.

USE
10 Caution children about dropping or pushing objects into the TV set through cabinet open-

ings. Some internal parts carry hazardous voltages and contact can result in a fire or elec­trical shock.

11 Unplug the TV set from the wall outlet before cleaning. Do not use liquid or an aerosol

cleaner.

12 Never add accessories to a TV set that has not been designed for this purpose. Such addi-

tions may result in a hazard.

13 For added protection of the TV set during a lightning storm or when the TV set is to be left

unattended for an extended period of time, unplug it from the wall outlet and disconnect the
antenna.This will prevent damage to product due to lightning storms or power line surges.

14 A TVset and cart combination should be moved with

care. Quick stops, excessive force, and uneven sur­faces may cause the TV set and cart combination to
overturn.

SERVICE

15 Unplug this TV set from the wall outlet and refer servicing to qualified service personnel

under the following conditions:
A.When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the TV set.
C. If the TV set has been exposed to rain or water.
D.If the TV set does not operate normally by following the operating instructions.Adjust

only those controls that are covered in the operating instructions as improper adjustment
of other controls may result in damage and will often require extensive work by a quali-

fied technician to restore the TV set to normal operation.
E.If the TV set has been dropped or damaged in any way.
F. When the TV set exhibits a distinct change in performance — this indicates a need for

service.

16 Do not attempt to service this TV set yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all servicing to qualified service person­nel.

17 When replacement parts are required, have the service technician verify in writing that the

replacement parts he uses have the same safety characteristics as the original parts.Use
of manufacturer’s specified replacement parts can prevent fire, shock, or other hazards.

18 Upon completion of any service or repairs to this TV set, please ask the service technician

to perform the safety check described in the manufacturer’s service literature.

19 When a TV set reaches the end of its useful life, improper disposal could result in a picture

tube implosion.Ask a qualified service technician to dispose of the TV set.

20 Note to CATV system installer.

This reminder is provided to call the CATV system installer’s attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to the
point of cable entry as practical.

Table of Contents

UNPACKING YOUR TV . . . . . 7

QUICK SETUP. . . . . . . . . . . 8

Getting Started . . . . . . . . . 8

Remote Control . . . . . . . . . 8

Batteries . . . . . . . . . . . . . 8

Basic Operation . . . . . . . . . 8

Making Basic Connections . . . 9

Plug In Menu . . . . . . . . . . 10

CONNECTIONS . . . . . . . . . 11

Cable and VCR Connections . . . . . . . 11

Connecting to a DVDPlayer . . . . . . . . 14

Connecting to an External Amplifier . . . . 15

Connecting to a Camcorder . . . . . . . . 15

Connecting to JVC AV Compu Link . . . . 6

REMOTE CONTROL . . . . . . 17

Remote Control Basics . . . . . 17

Changing the Batteries . . . . . 17

REMOTE PROGRAMMING . . .18

CATV and Satellite Codes . . . 18

VCR Codes . . . . . . . . . . . 19

DVD Codes . . . . . . . . . . . 20

ONSCREEN MENUS . . . . . . 21

Using the Guide . . . . . . . . 21

The Onscreen Menus . . . . . . 21

PLUG IN MENU . . . . . . . . . 22

Introduction . . . . . . . . . . . 22

Language . . . . . . . . . . . . 22

Auto Tuner Setup . . . . . . . . 22

Auto Clock Set . . . . . . . . . 23

Manual Clock Set . . . . . . . . 24

Finish . . . . . . . . . . . . . . 24

CHANNEL SUMMARY . . . . . 25

Channel Summary . . . . . . . 25

V–CHIP . . . . . . . . . . . . . 26

US V–Chip Ratings . . . . . . . 27

Setting US V–Chip Ratings . . . 28

Directions . . . . . . . . . . . . 28

Set Ratings . . . . . . . . . . . 29

Movie Ratings . . . . . . . . . . 30

Directions for Movie Settings . 30
Canadian V–Chip Ratings . . . 31
Canadian V–Chip Directions . . 31

Unrated Programs . . . . . . . 32

Set Lock Code . . . . . . . . . 33

PICTURE SETTINGS . . . . . . . 34

Tint . . . . . . . . . . . . . . . . . 34

Color . . . . . . . . . . . . . . . 34

Picture . . . . . . . . . . . . . . . 34

Bright . . . . . . . . . . . . . . . 34

Detail . . . . . . . . . . . . . . . 34

Noise Muting . . . . . . . . . . . 35

Set Video Status . . . . . . . . . . 35

SOUND SETTINGS . . . . . . . 36

Bass . . . . . . . . . . . . . . . 3 6

Treble . . . . . . . . . . . . . . . 36

Balance . . . . . . . . . . . . . . 36

MTS (Multi-channel Sound) . . . . 36

GENERAL ITEMS . . . . . . . . 37

Purity . . . . . . . . . . . . . . . 37

On/Off Timer . . . . . . . . . . . . 37

TV Speaker . . . . . . . . . . . . 38

Audio Out . . . . . . . . . . . . . 38

V4 Component-In/

V2 Component-In . . . . . . . . . 39

Closed Caption . . . . . . . . . . 39

BUTTON FUNCTIONS . . . . . . 40

Menu . . . . . . . . . . . . . . 40

Exit and PIP Off . . . . . . . . . 40

Display . . . . . . . . . . . . . . 40

Video Status . . . . . . . . . . . . 41

Sleep Timer . . . . . . . . . . . 41

Hyper Surround . . . . . . . . . 41

Muting . . . . . . . . . . . . . . . 41

BBE . . . . . . . . . . . . . . . 42

100+ . . . . . . . . . . . . . . . . 42

Return+ . . . . . . . . . . . . . 42

Input . . . . . . . . . . . . . . 42

VCR Buttons . . . . . . . . . . . 43

DV D Buttons . . . . . . . . . . 4 3

TV/CATV Switch . . . . . . . . . . 43

VCR/DVD Switch . . . . . . . . . 43

Light . . . . . . ... . . . . . . 43

PIP (Picture-In-Picture) . . . . . 44

Introduction . . . . . . . . . . . . 44

On/Move . . . . . . . . . . . . . . 44

Freeze . . . . . . . . . . . . . . . 45

Swap . . . . . . . . . . . . . . . . 45

Channel +/– . . . . . . . . . . . . 45

Source . . . . . . . . . . . . . . . 45

APPENDICES . . . . . . . . . . .46

Troubleshooting . . . . . . . . . 46

Warranty . . . . . . . . . . . . 47

Authorized Service Centers . . 49

Search Codes . . . . . . . . . . 50

Specifications . . . . . . . . . . .51

Unpacking Your Television

Thank you for your purchase of a JVC Color Television. Before you begin setting up your new
television, please check to make sure you have all of the following items. In addition to this
guide, your television box should include:

1 Remote

1 Television

Once you have unpacked your television, the next step is to connect it to your antenna/cable
or satellite system and to connect the audio/video devices you want to use with your televi­sion. To make these connections you will use plugs like the ones illustrated below.

Control

Two AA

Batteries

A matching TV stand
is also available
(optional).

Note:Your remote
control may differ from
the example illustrated
here.

RF Connectors

Used to connect a
coaxial cable from an
external antenna or Cable
TV system.

A/V Input Plug

Used to connect
audio/video devices like
VCRs, DVD players, stereo
amplifiers, game consoles,
etc.

S-Video Plug

Used to make video con­nections with VCRs,
DVDs, Camcorders, etc
(optional).

We recommend that before you start using your new television, you read your entire User’s
Guide so you can learn about your new television’s many great features. But if you’re anxious
to start using your television right away, a quick setup guide follows on the next three pages.

AV Compu Link Cable

Used to connect JVC AV
Compu Link
capable components for
an automated home the­ater.

7

Quick Setup 1

Getting Started

These quick setup pages will provide you, in three easy steps, with the basic information you
need to begin using your new television right away. This information includes basic instructions
on operating your remote control, making a simple cable/antenna and optional VCR connection
and, finally, information on programming your television's Auto Tuner.

If you have questions, or for more detailed information on any of these steps, please consult
other sections of this manual.

Step One - The Remote Control

The remote control is the key to operating your television's many great features. Before you
can operate your remote control, you first need to install the batteries (included).

Slide the cover on the back of the remote down towards the bottom of the remote control.
Insert two batteries (included) carefully noting the “+”and “–” markings, placing the “–”end in
the unit first. Slide the cover back into place.

Basic Operation

Turn the television on and off by pressing the POWER button at the top right corner of the
remote.

Power Button

The four key feature buttons at the center of the remote can be used for basic operation of the
television.The top and bottom buttons will scan forward and back through the available chan­nels.The right and left buttons will turn the volume up or down.These buttons are also marked
with four arrows and are also used with JVC's onscreen menu system.You will need to use
these buttons later in the Quick Setup.

The next step is to connect your television to an antenna or cable.

Proceed to Step Two

Key Feature Buttons

+

8

Quick Setup 2

Step Two - Making Basic Connections

Next you will need to connect your television to an antenna or cable system. The most basic
antenna/cable connection is shown below. For more detailed connections, such as ones where
a cable box is required, see pages 11 to 13.

Cable/RF connector

Illustration of AV-27F802

1) Connect an RF cable out from the wall outlet in to the RF Input on the back of the TV.
You may also wish to connect a VCR at this point. A basic VCR connection is shown below.

For detailed instructions on connecting a other components or a home theater system, see
pages 14 to 16.

NOTE: A VCRis not required to operate your television.

AVCables/Plugs

Illustration of AV-27F802

1) Connect the yellow video cable out from the VCR’s Video Output, in to the TV’s Video
Input jack, OR connect an S-Video cable from the VCR’s S-Video output, to the TV’s
S-Video input.

2) Connect the white audio cable out from the VCR’s Left Audio Output, in to the TV’s Left
Audio Input Jack.

3) Connect the red audio cable out from the VCR’s Right Audio Output, in to the TV’s Right
Audio Input jack.

Finally, once you have finished your connections, plug the power cord into the nearest power
outlet and turn on the television.

Proceed to Step Three

+

9

Quick Setup 3

Step Three - The Plug In Menu

When you turn your television on for the first time the Plug In Menu will appear. This menu
sets some of the basic settings for your television. A complete description of the Plug In Menu
can be found starting on page 22. We recommend you complete the Plug In Menu items
before you start using your television. But to begin watching your television right away you only
need to run the Auto Tuner Setup. This lets your television learn the channels it is able to
receive. To run the Auto Tuner Setup follow the steps below.

PLUG IN MENU

LANGUAGE ENG FRE SPA
AUTO TUNER SETUP
SET CLOCK

FINISH

SELECT BY
OPERATE BY

Press the buttons to move to AUTO TUNER SETUP
Press the buttons to begin AUTO TUNER SETUP

EXIT BY

TUNER MODE : CABLE AIR

START

EX
IT

To choose CABLE (if you are connected to a cable system) or AIR (if you use
an antenna)

To move to START
To start Auto Tuner Setup

The Auto Tuner will now memorize all of the clear, active channels your television can
receive. This will take one or two minutes.

NOW

PROGRAMMING!

48

The Auto Tuner is finished when the message PROGRAMMING OVER! appears onscreen.
Your Quick Setup is now complete. You can now begin watching your television, or you can

continue on in this guide for more information on connecting audio/video devices, programming
your remote control, or using the JVC onscreen menu system to customize your television
viewing experience.

The Quick Setup
is complete

10

Connections

Cable and VCR Connections

There are three basic types of antenna or cable connections:

• If you have an antenna or have a cable system that does not require you use a cable box
to select channels, please refer to Diagram #1.

• If you have a cable system that requires the use of a cable box to access all the chan­nels, please refer to Diagram #2. If you cannot operate your Picture-In-Picture
function using Diagram #2, try the connection shown in Diagram #3. It is possible yo
cable box allows the signal of only one channel at a time to be sent to your television.

• If you have a cable system that requires the use of a cable box to access certain
premium channels, but not “basic”cable channels, please refer to Diagram #3.

• For your convenience, connection to a VCR is also shown in the following diagrams. A
VCR is not necessary for operation of the television or Picture-In-Picture (PIP) function.
You may omit the VCR from your connections if you wish.

• For instructions on connecting a VCR only, please see the Quick Setup on page 9.

• For information on using PIP, please see page 44.

• The PIP feature is available on models AV-36F802, AV-32F802 and AV-27F802 only.

Diagram #1

Illustration of AV-27F802

1) Connect the antenna or cable TV wire from the wall outlet, in to the RF Input of the two-way
splitter.

2) Connect an RFcable from the one of the RF Outputs on the splitter, in to the RF Input on
the back of the VCR.

3) Connect an RFcable from the other the RFOutput on the splitter, in to the RF Input on the
back of the TV.

4) Connect the yellow video cable out from the VCR’sVideo Output, in to the TV’s Video Input
jack, OR connect an S-Video cable from the VCR’s S-Video output, to the TV’s S-Video
input.

5) Connect the white audio cable out from the VCR’s Left Audio Output, in to the TV’s Left
Audio Input Jack.

6) Connect the red audio cable out from the VCR’s Right Audio Output, in to the TV’s Right
Audio Input jack.

• If your VCRis a mono sound unit, it will have only one Audio Out jack. Connect it to the

TV’s Left Audio Input.

• Please consult your VCR’s owner’s manual for more information on its operation.

11

Connections

Cable and VCR Connections - Continued

Diagram #2

Illustration of AV-27F802

1) Connect the antenna or cable TV wire from the wall outlet, in to the RFInput of the cable

box.

2) Connect an RF cable from the RFOutput of the cable box, in to the RFInput on the back of

the VCR.

3) Connect an RF cable from the RF Output of the VCR, in to the RF Input on the back of the

TV.

4) Connect the yellow video cable out from the VCR’sVideo Output, in to the TV’s Video Input

jack, OR connect an S-Video cable from the VCR’s S-Video output, to the TV’s S-Video
input.

5) Connect the white audio cable out from the VCR’s Left Audio Output, in to the TV’s Left

Audio Input Jack.

6) Connect the red audio cable out from the VCR’s Right Audio Output, in to the TV’s Right

Audio Input jack.

• Please see page 44 for information on using the PIP feature with a Cable Box.

• If your VCRis a mono sound unit, it will have only one Audio Out jack. Connect it to the TV’s

Left Audio Input.

• Please consult your VCR’s owner’s manual for more information on its operation.

12

Connections

Cable and VCR Connections - Continued

Diagram #3

Illustration of AV-27F802

1) Connect the antenna or cable TV wire from the wall outlet, in to the RF Input of the two-way
splitter.

2) Connect an RFcable from the one of the RFOutputs on the splitter, in to the cable box RF
Input.

3) Connect an RF cable from the Cable Box Output, in to the VCR RF Input.

4) Connect an RFcable from the other the RFOutput on the splitter, in to the RF Input on the
back of the TV.

5) Connect the yellow video cable out from the VCR’s Video Output, in to the TV’s Video Input
jack, OR connect an S-Video cable from the VCR’s S-Video output, to the TV’s S-Video
input.

6) Connect the white audio cable out from the VCR’s Left Audio Output, in to the TV’s Left
Audio Input jack.

7) Connect the red audio cable out from the VCR’s Right Audio Output, in to the TV’s Right
Audio Input jack.

• Please see page 44 for information on using the PIP feature with a Cable Box.

• If your VCRis a mono sound unit, it will have only one Audio Out jack. Connect it to the

TV’s Left Audio Input.

• Please consult your VCR’s owner’s manual for more information on its operation.

The connection diagrams are intended to show some basic general connections.
Some cable companies may require special connections to properly use your televi­sion or 2-tuner PIP function. If you follow these diagrams and either the television or
PIPdoes not work properly, contact your local cable operator for more connection
information. Please see page 44 for more information on the PIP feature.

13

Connections

Connecting to a DVD player

Illustration of AV-27F802

1) Connect Green cable out from DVD player “Y”Component Output, in to TV“Y” Component
Input.

2) Connect Blue cable out from DVDplayer “PB” Component Output, in to TV “PB” Component
Input.

3) Connect Red cable out from DVD Player “PR” Component Output, in to TV “PR” Component
Input.

4) Connect White Audio cable out from DVDLeft Audio Output, in to TV Left Audio Input 2.

5) Connect Red Audio cable out from DVDRight Audio Output, in to TVRight Audio Input 2.

• Green, blue and red are the most common colors for DVD cables. Some models may vary

colors. Please consult the user’s manual for your DVD Player for more information.

• Be careful not to confuse the red DVD cable with the red audio cable. It is best to complete

one set of connections (DVDor Audio Output) before starting the other to avoid accidentally
switching the cables.

• See page 20 for instructions on programming your remote control to operate the basic func­tions of your DVD player.

• AV-36F802, AV-32F802 & AV-27F802: You may also connect the DVD player to Input 4. If
you use Input 4 for the DVD connection, you must set the V4 COMPONENT-IN on the initial
Setup Menu to “YES” for proper display of the DVD signal.

• AV-36F702, AV-32F702 & AV-27F702: If you use Input 2 (Component-In) for the DVDcon-
nection, you must set the V2 COMPONENT-IN on the initial Setup Menu to “YES” for prop­er display of the DVD signal.

NOTE: Progressive DVDPlayers (players with an output scan of 31.5 KHz) will not work prop­erly with this television.

14

Connections

Connecting to an External Amplifier

Illustration of AV-27F802

1) Connect the white audio cable from the TV’s Left Audio Output jack to the Amplifier’s Left
Audio Input jack.

2) Connect the red audio cable from the TV’s Right Audio Output jack to the Amplifier’s Right
Audio Input jack.

• See also “TV Speaker” and “Audio Out”on page 38 for more information on using external

speakers.

Connecting to a Camcorder

You may connect a camcorder to your television by using the front Input Jacks (Input 3)
located under the front panel door. To access, press lightly on the door to open it. You may
also connect a game console or other equipment using these jacks. Camcorders may also
be connected to the television’s rear input jacks.

Illustration of AV-27F802

1) Connect the yellow video cable out from the Camcorder’sVideo Output, in to the TV’s Video
Input jack, OR connect an S-Video cable from the Camcorder’s S-Video output, to the TV’s
S-Video Input.

2) Connect the white audio cable out from the Camcorder’s Left Audio Output, in to the TV’s

Left Audio Input jack.

3) Connect the red audio cable out from the Camcorder’s Right Audio Output, in to the TV’s

Right Audio Input jack.

• If your Camcorder is a mono sound model it will have only one audio jack. Connect it to the

TV’s Left Audio jack.

15

Connections

Connecting to JVC AV Compu Link

JVC’s AV Compu Link feature makes playing video tapes or DVDs totally automatic. Simply
insert a pre-recorded tape into your JVC-brand VCR or DVD into your JVC DVD player and
the device will automatically turn on and begin playback. At the same time, using the AV
Compu Link, the VCR or DVD player sends a signal to the television telling it to turn on and
switch to the proper video input.

• The AV Compu Link cable may be included with the JVC AVCompu Link accessory you
wish to connect. If it is not, contact an authorized JVCService Center for
part # EWP 805-012.

• AV Compu Link can only be used with JVC-brand products.

Illustration of AV-27F802
To Connect: Plug one end of the AV Compu Link cable into the AV Compu Link input on your

VCR, DVD, or other Compu Link device. Plug the other end of the AV Compu Link cable into
the AV Compu Link input at the rear of the television.

NOTE:

• In order for the VCR playback to begin automatically, the recording tabs must be remove from
the VHS tape. If the tab is in place, automatic switching will occur when you push the VCR’s
PLAY button.

• The AV Compu Link cable has a male 3.5 mm (mono) plug on each end.

• If your JVC-brand VCR has “A Code/B Code Remote Control Switching”(see your VCR’s
instruction book), using VCR A Code will switch the TV to input 1.

• To connect a JVC HiFi receiver or amplifier for a completely automated home theater, see
the HiFi’s connection instructions for detailed connection information.

• AVCOMPU LINK EX is compatible with the following receivers:RX-664V, RX-665V,
RX-668VBK, RX-774V, RX-778VBK, RX-884V, RX-888VBK, RX-1024V, RX-1028VBK, and
later receiver models.

16

Remote Control

Remote Control Basics

• Before you can operate the remote control, you must first
install the batteries (included). See “Changing the
Batteries” at the bottom of this page for instructions. (For
an illustration, please see page 8.)

• Press the POWER button to turn the television on or off.

• Make sure the TV/CATV switch is set to TV. Move the
switch to CATV only if you need to operate a cable box.

• Slide the VCR/DVDselector switch to VCR to control a
VCR, slide to DVD to control a DVD player. Please see
pages 18 to 20 for instructions on programming your
remote control to operate a Cable box, VCR or DVD player.

• Press the CH+ and CH– buttons to scan through the chan­nels. Tap the CH+ or CH– button to move through the
channels one channel at a time.

• To move rapidly through the channels using JVC’s
Hyperscan feature, press and hold CH+ or CH–. The
channels will zip by at a rate of five channels per second.

• Press VOL+ or VOL– to raise or lower the volume. An indi­cator bar will appear onscreen to show you the television
volume level.

• The CH+/– and VOL+/– buttons are also used to navigate
JVC’s onscreen menu system.

• You can directly access specific channels using the 10-key
pad.

• For more information on remote control button features,
see pages 40 to 45. For information on using the
onscreen menus, see page 21.

NOTE: Remote control model RM-C301G is shown at the
left. A different model remote control may have come with
your television.

Changing the Batteries

Push down on the remote’s back cover and slide towards the bottom to remove it.
Insert two AA batteries (supplied), carefully noting the "+" and "–" markings on the batteries

and on the remote control. To avoid a potential short circuit, insert the "–" end first. Be sure to
use only size AA batteries.

When batteries are installed, slide the cover back into place (until it clicks into position).

• If the remote control acts erratically, replace the batteries. Typical battery life is six months to
one year. We recommend using alkaline batteries for longer battery life. When you change
the batteries, try to complete the task within three minutes. If you take longer than three min­utes, the remote control codes for your VCR, DVD, and/or Cable Box may have to be reset
(see pages 18-20).

17
